Micronics Ultraflo 2000 Operating Manual

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

ULTRAFLO 2000 FLOW

& HEATMETER

Operating Manual

Micronics Limited, Unit B3 Knaves Beech Business Centre, Davies Way, High Wycombe, Bucks HP10 9QR UK.

Tel: [phone] Fax: [phone] e-mail [e-mail] www.micronicsltd.co.uk

1

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

CONTENTS

SYSTEM IDENTIFICATION

E1:High Flow 16

INTRODUCTION

E3:Hot Fault 16

HARDWARE

Electronics Housing 4
Transducers 4
Transducer Connections 4 W1:Check Data 16
Transducer Hardware 5 W2:Timing Poor 16
Transducer Mounting 5 W3:Signals Poor 16
Transducer Cables 6 W4:Ma (1) OVER 16
Keypad 6 W5:Ma (2) OVER 16
W6:Pulse At Max 17

MAIN MENU

Power up 7
Quick Start 8 Application Notes 17
View/Edit Site Data 10 Select a Metering Position 17
Set-up Sensors 11 Mounting The Transducers 18
Calibrate 4-20mA 12 Liquid Conditions 19
Read Flow 12 Propagation Velocity 19
Maximum Flow 19

FUNCTIONS

Display 13 Flow Range 19
Set-up 4-20mA 13
Pulses/Set Point 14
CutOff M/S 15
Set Zero Flow 15
Reset Total Flow 15
Reset Total Energy 15
Damping 15
Cal Factor 16
Diagnostics 16
Save And Exit 16

WARNING - users should ensure or note that:
a) The Ultraflo 2000 is not certified for use in hazardous areas.
b) The local site safety regulations are complied with.
c) Work is carried out in accordance with The Health & Safety at Work Act 1974.

3
4 E2:No Flow Sig 16

E4:Cold Fault 16

Application Temperature 19

ERROR MESSAGES

WARNING MESSAGES

APPLICATION INFORMATION

SPECIFICATION
HEATMETER INSTRUCTIONS
CE MARKING Guidance Notes
WARRANTY

20
21
22
22

2

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

F

F

FIGURE 1 - SYSTEM IDENTIFICATION

UP

4-20mA(1)

OUTPUT

4-20mA(2)

OUTPUT

PT100 TEMPERATURE
SENSORS
(if supplied)

The following information is requi red by Micronics when
placing an order.

EXAMPLE

POWER VOLTAGE................................ 24v DC

PIPE OD............................................... 60

PIPE MATERIAL ................................... STEEL

APPLICATION TEMP............................ 60°C

LIQUID ................................................ WATER

TRANSDUCER CABLE LENGTH......... 50 METRES

MAX FLOW IN UNITS........................... 150L/MIN

MAX ENERGY RATE

(HEATMETER ONLY) .......................1000KW

TEMPERATURE DIFFERENTIAL

(HEATMETER ONLY)........................... 25°C

TEMPERATURE PROBE CABLE

LENGTH (HEATMETER ONLY)............ 50 METRES

Example Order Code 24-60-S-60-W-50-150L/mi n

FLOW SENSORS ASSEMBLY

FLOW

RETURN

DOWN

ULTRAFLO

MICRONICS

u

24VDC

IN

u

2000

Figure 1

RELAY

OR

PULSE

OUTPUT

110/240V

SUPPLY

3

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

U

U
S

INTRODUCTION

The Ultraflo 2000 is a “Clamp-on” liquid flow meter
that uses the Transit Time method of
measurement to read flow. Using two PT100
temperature probes to measure temperature it
can also be used as a Heat/Energy meter.

The Ultraflo is able to m eas ure the flow of liquid in
any pipe from 13mm to 5000mm, providing the
pipe is flooded and the correct transducers are
used. Units are supplied according to application
data provided by the customer.

The instrument displays volumetric flow rate in

3

/hr, m3/min, m3/sec, g/min, USg/hr, l/m in, l/sec

m
and linear velocity in metres and feet per second.
The total volume of flow will be displayed, up to a
maximum 12-digit number. When supplied as a
Heatmeter, kW, kCal/hr, MJ/hr, MJ/min and
MJ/sec can be displayed, as well as the
temperature differential.

The flowmeter is supplied with electronics,
sensors and all mounting hardware. The
Heatmeter version will also be supplied with
PT100 temperature probes.

HARDWARE

Electronics Housing
An ABS housing with an opaque door contains the
master PCB. The housing is designed for wall
mounting using the brack ets provided (see Figure
2 for m ounting pattern) . Drilling f urther f ixing holes
in the Housing rem ove the IP67 protection rating
and CE approval.

Mounting the housing into position does not
require the rem oval of the electronics or the front
display panel.

Figure 2

DO NOT PROVIDE POWER to the instrument
until the service compartment cover has been
replaced.

The electronics are factory set for a particular
supply voltage. Should it be necessary to change
the settings for the power supply see page 7,
Power up.

Having completed the procedure f or mounting the
electronics, connecting all cables and checking

the power supply, the power can now be applied.
The Ultraflo 2000 is now ready for program ming.
A full programming procedure is described on
page 7.

Before programming the instrument, it is
necessary to attach the transducers to the pipe
wall such that they can be finally locked in the
correct position based on exact data pr ovided by
the instrument.

TRANSDUCERS

Each instrument uses two identical transducers,
which transmit and receive the ultrasonic waves.
They are clamped to the pipe surface using the
mounting hardware supplied, as described on
pages 5, 6.

The standard transducers are made from a Peek
material with an aluminium plate supporting the
stud, used to lock the sensor in position. A flying
armoured lead is attached between the sensor
block and the tuning circuit.

Figure 3

– 1MHz Sensors with TNC Coaxial

Connector

Transducers are supplied according to the pipe
size and flow velocity, and are available to meet
an operating temperature range from –20°C up to
+200°C.

Transducer Connections

Transducers are c onnected to the electronics from
the tuning circuit by TNC connectors. All other
output and input connections are made through
metal glands to the clearly marked terminals.

1 2 3 4 5 6 7 8 9 10 11 12 13
+ - + - + - + + - +

MA1 MA2 HOT COLD RELAY

Coax sensor connectors

Coax cable

NC COM NO

24V

+

F

220VAC

14 15 16 17 18

110VAC

F

24VDC

S

Only one current output can be used with the flow
meter, but both can be used when the Heatmeter
option is supplied. Connections 5-10 c an only be
used when the PT100 temperature probes are
supplied with the Heatmeter.

4

L N E

AC IN

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

Transducer Hardware

Transducer alignment guide rails, chains and
couplant are supplied with all units in order to
ensure that the transducers are accur ately aligned
with respect to the pipe axis.

A single guide rail assembly is supplied for
mounting the transduc ers in Reflex m ode and two
guide rails are provided for m ounting in Diagonal
mode.

Figure 4

– 1MHz Reflex Mounting Assembly

Figure 5

- Diagonal Beam Mounting Hardware

Transducer Mounting

The two different methods of mounting the
transducers are shown on pages 5 & 6. When
ordering the Ultraflo 2000 specific application
information should have been given. This
information determ ines the correct har dware to be
supplied with each instrument.

Reflex Mode

Reflex mode is a def ault setting on all applic ations
up to 215mm. Above this the instrument will
default to Diagonal mode. It is possible to change
these default settings if required (s ee page 11 Set
up sensors).

Before attempting to attach the transducers it is
imperative to ensure that the cor rect position has
been chosen to site the trans ducers and that the
pipe surface conditions are suitable. Go to page
17 and carefully follow all instructions for the

selecting and preparing the transducer mounting
site.

At this point program the instr ument to determine
the separation distance. When you have this
information from the instrument follow the set up
procedure below.

Procedure
a) Insert the transducers into the guide rail

so the tails come out of either end.

b) By turning the locking nut centre

clockwise, withdraw the transducers up
into the guide rail.

c) Apply a bead of coupling grease to each

transducer. See page 19, figure 15.

d) Attach both lengths of chain to the quick

links provided and offer the guide rail up
to the pipe wall at 45°.

e) Wrap the chain around the pipe and

connect to the ‘J’ bolt. Complete the same
for both ends of the guide rail then tighten
the locking nuts on the ‘J’ bolt. This will
secure the complete assembly to the pipe.

f) By turning the centre of the locking

assembly anti-clockwise lower one block
onto the pipe. Now adjust the second
block to required separ ation distance and
repeat the procedure. The separation
distance is measured f rom the front edge
of each block and not the centre of the
locking nut.

g) If the instrument now reads a negative

flow swapping the TNC connectors on the
instrument can change this.

h) Now lock the transducers in position by

tightening the nut on locking assembly.

“DO NOT USE EXCESS PRESSURE”.
Note: When m oving the transducers into position
ensure that they are withdrawn into the guide rail
as far as possible. T his ensures that the couplant
will not be removed from the transducer face
before it is screwed down into position.

Figure 6

ZERO

SEPARATION
DISTANCE

5

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

(D)

All transducers are m ounted in Reflex or Diagonal
mode as described on page 5 and 6. The guide
rail assemblies are held in position using chains.

Diagonal Beam Mode

Diagonal beam mounting means the two
transducer blocks ar e mounted on opposite sides
of the pipe as shown in f igure 7. This is the default
setting for all applications above 215mm.

If you encounter a difficult application or the
maximum flow velocity is outside of the default
operating range, when working in the Reflex
mode, it is poss ible to repr ogr am the instrument to
operate in Diagonal mode (see page 11, Set up
Sensors)

Diagonal Set up Procedure

a) Using whatever means available mark a

reference line around the circumference
of the pipe (reference line D). As shown
in figure 7.

b) Locate and mark two positions exactly

180° apart around this reference line.

c) On both of these positions draw a

reference line (E) perpendicular to line
(D), parallel to the pipe axis and
approximately 1 metre long. See figure 7.

d) Take each of the guide rails and load the

transducers as described previously on
page 5. Only one transducer goes in each
guide rail.

d) Attach the one guide rail to the pipe using

the chain provided, such that it is parallel
to the reference line (E) and position so
that the transducer face can be aligned
with reference line (D).

e) Program the flow meter and obtain the

separation distance.

f) From the intersection of the

circumference reference line (D) and the
second reference line (E) measure and
mark the separation distance XXX. Now
mount the second guide rail such that the
transducer face can be positioned on this
intersection ensuring that the guide rail is
parallel to the reference line (E). See
figure 7.

g) Screw down both of the transducers and

lock in position as previously described.

h) RG223 Coaxial Cable (50ohm), Different

lengths up to 200 metres available on
request.

Figure 7

SEPARATION

DISTANCE ‘xxx’ mm

Ref Line (E)

Chain

Ref Line (E)

Ref Line

HINT: DRAWING A TRUE CIRCUMFERENCE

AROUND A PIPE

An easy way to draw a perpendicular

circumference around a large pipe is to wrap a
length of mater ial such as chart paper around the
pipe, aligning the edges of the paper precisely at
the overlap. With the edge of the chart paper
being parallel, then either edge describes a
circumference around the pipe that is
perpendicular to the pipe axis.

BISECTING THE CIRCUMFERENCE
Mark the chart paper exactly where it overlaps.

Then after rem oving the paper from the pipe, fold
the measured length in half keeping the edges
parallel. The fold line now marks a distance
exactly half way around the pipe. Put the paper
back on the pipe and use the fold line to mark the
opposite side of the pipe.

Transducer Cables

The transducers are c onnected to the electronics

via 50ohm coaxial cables and TNC connectors.
The total length of the cable be up to a m axim um
of 200 mteres.

Keypad

All data is entered for set up and calibration via
the front panel keypad. Figure 9 shows the keypad
layout.

Keys

• To give a NO answer and scroll through listed

options, press SCROLL.

• To select options, store data and m ove on to

the next option, press ENTER.

6

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

• If data has been incorrectly entered, press Y
until the display is clear, then re-enter the data
correctly.

Restart Key

The RESTART k ey can be pressed at any point in
the program and will take the ins trument back to
the opening display. Press SCROLL to enter the
password 2000 and reprogram the instrument. If
the instrument has already been measuring flow
and the SCROLL key is not pressed, it
automatically returns to flow mode.

Scroll Key

When the SCROLL key is pressed in flow mode
the display will read the following.

Signal 80%

0.00 mA

This displays the signal level of the instrument and
the current output status of the 4- 20mA. Both will
be displayed if a Heatmeter is supplied.

Press ENTER again and the following will be
displayed.

ERRORS PENDING

No errors

This will display all Error and W arning messages

(see page 16). To program the Ultraflo 2000,
accurate application data must be k eyed in via the
keypad. Data and instructions are requested via
the display and all questions must be answered
before the program will step through to the point
of measuring flow.

Once the unit has been program med the data c an
be reviewed and changed if necessary.

The instrument displays information in the

following 3 ways.

Flow in selected units.
l/min 0.00

l 0.00

Energy in selected units.
kW 0.00

kWh 0.00

Temperature differential.
H 50°C C 10°C

Diff 40°C

PROGRAMMING/MAIN MENU

Power Up
DO NOT PROVIDE POWER TO THE
INSTRUMENT UNTIL THE SERVICE
COMPARTMENT COVER HAS BEEN
REPLACED.

The power supply is factory set. To change from
110/220VAC to 24VDC the left hand switch needs
to be in the down position. The right hand switch is
only used when changing from 110VAC to
220VAC.

When power is applied to the Ultraflo 2000 it will
react in 2 distinctly differ ent ways depending upon
whether any application data has been
programmed into the EEROM.

All new meters received f rom the fact ory will have
had the EEROM memory wiped clean.

Apply power. Initial display will show
Micronics Ltd

ULTRAFLO 2000

Within 5 seconds the display will change to

DIMENSION

Millimetres

Application data can now be keyed in.

If the instrument has been used then application data
will be stored in the EEROM and the following will be
displayed. If SCROLL is not pressed within 5 seconds
after the initial display, the instrument will go directly to
flow mode.

Apply power. Initial display will show

Micronics Ltd

ULTRAFLO 2000

PRESS SCROLL within 5 seconds of initial start up
Display will then show

ENTER PASSWORD

Key in password 2000 (only required if the unit has
been previously used)

The flow information can be factored to suit the
users requirements by selecting CAL FACTOR
from the FUNCTIONS m enu. The Totalised Flow
data can also be reset to zero.

7

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

ENTER PASSWORD

* * * *

Display will show:

MAIN MENU
Quick Start

MAIN MENU

To get into the
SCROLL, then enter the password 2000. The

MENU

scroll key.
Press ENTER to select.

MAIN MENU

has 5 options that are selectable by using the

press RESTART,

MAIN

MAIN MENU

Quick Start
View/Edit Site

Setup sensors
Calibrate 4-20mA
Read flow

MAIN MENU - Quick Start

Quick Start

The
read flow.

The display will show the following.

option enables the user to quickly

MAIN MENU

Quick Start

Press ENTER to select this option and enter
application data. The user now has the option of
selecting millimetres or inches.

Press SCROLL to display units and ENTER to select.

DIMENSION

Millimetres
Inches

LINING THICKNESS
mm/inches

If the pipe has a LINING enter the thickness now and
press ENTER. If there is no LINING press ENTER to
continue.

WALL

M/Steel

The display will show the following.
There are 11 wall material options that are selectable

by using the scroll key.
Select the material required and press ENTER when

displayed.

WALL
M/Steel

S/Steel 316
S/Steel 303
Plastic
Cast Iron
Ductile Iron
Copper
Brass
Concrete
Glass
Other m/s

Other m/s

If

speed of sound in metres per second of the particular
pipe material being used. Enter a figure and press
ENTER. Contact Micronics if the sound speed is not
known.

is selected the user needs to enter the

If a Lining material thickness has been selected
the following is displayed.

LINING
Steel

The display will show the following. Enter the outside

diameter and press ENTER.

PIPE OD
mm/inches

Enter the wall thickness in the selected units and press

ENTER.

There are 6 Lining material options that are

selectable by using the scroll k ey. These are only
displayed if a Lining was selected previously.

Select the material required then pr ess ENTER to
select.

LINING
Steel

WALL THICKNESS

mm/inches

The display will show the following.

Rubber
Glass
Epoxy
Concrete
Other m/s

If Other m/s is selected the user needs to k now
the speed of sound in metres per second of the
particular lining material being used. Enter a figure

8

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

and press ENTER. Contac t Micronics if the s ound
speed is not known.

The display will show the following.
FLUID

Water

Press Scroll. There are 6 fluid options that are
selectable by using the scroll key.

Select the fluid required then press enter to select.
FLUID

Water
Glycol 50%

Lub oil
Diesel oil
Freon
Other m/s

If Other m/s is selected the user needs to k now
the speed of sound in metres per second of the
particular fluid being measur ed. Enter a figure and
press ENTER. Contact Micronics if the sound
speed is not known.

The display will show the following.

FLUID TEMP

°C

To enter a minus temperature press Y on the
keypad. When the tem perature has been entered
press ENTER. The Ultraflo has a temperature
range between -20°C and +200°C.

If the temperature entered is out of range the

following will be displayed.

Temp out of rang
Press any key

When the correct temperature is entered the

following will be displayed.

Approx. max flow

* * * * l/m

NOTE: If you h ave purchased a Heatmeter the

following will be displayed unless water has
been selected.

RELATIVE SHC

XXX

Enter the specific heat capac ity of the liquid being
measured (Heatmeter only. See Heatmeter
Instructions on page 21) and press Enter.

If you have eneterd a SHC the following will now

be displayed.

RELATIVE DENSITY
XXX

Enter the relative density of the liquid being
measured (Heatmeter only. See the Heatmeter
instructions on page 21) and press Enter.

The following will now be displayed.

Approx. max flow

* * * * l/m

The data that is entered and the application
information that has been given to Mic ronics when
purchasing the equipment determine the
approximate maximum flow. The instrument will
always default to litres per minute.

The instrument now displays the maximum flow
rate that it is capable of with the sensors provided
and the application data that has been entered by
the user.

Pressing SCROLL at this point will allow the user
to change the units to be displayed in the flow
mode.

Press ENTER when the units have been selected.
The Heatmeter option will also display kW, Kcal/h,

MJ/h, MJ/m, kJ/m, kJ/s and Temp °C.

Approx max flow
* * * * l/s

* * * * l/m
* * * * Ml/d

* * * * g/m
* * * * kg/h
* * * * Usg/m
* * * * Uskg/h
* * * * m3/h
* * * * m3/m
* * * * m3/s
* * * * m/s
* * * * ft/s

The following will now be displayed.

Attach sensors

REFLEX Sep * * * mm/inches

Pressing ENTER at this point will take the
instrument into reading flow.

l/m 0.00
l 000.0

MAIN MENU - View/Edit Site

9

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

From the MAIN MENU select View/Edit site data
by pressing ENTER. This enables the user to view
and edit the application data that has been
entered into the unit previously.

The display will show the following. Press ENT ER
to select.

l/m 0.00
l 000.0

The display will show the following. Press ENT ER
to select.

MAIN MENU
View/Edit Site

The display will show the following.
VIEW/EDIT SITE

Dimension MM/INCHES

To change the dimensions press ENTER. Select
the units by pressing SCROLL. Press ENTER to
select. This will convert all previous data entered,
into the units selected.

The display will now show the following.

VIEW/EDIT SITE

Pipe OD 55.0

The display will now show the following.

VIEW/EDIT SITE

Lining -- --

It will only be possible to change the pipe lining
material if a lining thickness has been entered
previously. To change the lining material press
ENTER. Use the SCROLL key to select from the
options available and press ENTER.

The display will now show the following.
VIEW/EDIT SITE

Fluid WATER

To change the fluid type press ENTER. Use the
scroll key to select from the options available and
press ENTER.

The display will now show the following.
VIEW/EDIT SITE

Fluid °C 20.0

To change the fluid temperature press ENTER.
Press ENTER again when a new temper ature has
been entered.

The display will now show the following.

To change the outside diameter of the pipe press
ENTER. Enter the new outside diameter in the
units selected previously and press ENTER.

The display will now show the following.
VIEW/EDIT SITE

Wall thickness 3.0

To change the pipe wall thick ness press ENTER.
Enter the new wall thickness in the units selected
and press ENTER.

The display will now show the following.
VIEW/EDIT SITE

Lining thick 0.0

To change or enter a pipe lining thickness press
ENTER. Enter the new lining thickness in the units
selected previously and press ENTER.

The display will now show the following
VIEW/EDIT SITE

Wall M/Steel

To change the wall material of the pipe press
ENTER. Scrolls through the options, press
ENTER when a new material has been selected.

VIEW/EDIT SITE
Read flow

Pressing SCROLL at this point will ask the user if
they wish to exit the VIEW/EDIT SITE loop.
Pressing ENTER will tak e the instrument back to
the MAIN MENU option, Setup sensors.

Pressing ENTER will display the following.
Approx max flow

* * * * l/m

To change the f low units press SCROLL and use
the scroll k ey to select from the options available
and press ENTER.

Pressing ENTER will display the following.
Attach sensors

REFLEX Sep 10.2

Pressing ENTER at this point will take the
instrument into reading flow.

l/m 0.00

10

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

l 000.0

MAIN MENU - Setup sensors

Press ENTER to select this option.

MAIN MENU

Setup sensors

This gives the user the opportunity to change the
mode of operation from Reflex to Diagonal (see
figure 5, page 5).

When applic ation information is programmed into
the instrument it autom atically selects the mode of
operation from that data. It is poss ible however to
use the same sensors in different modes.

The Setup sensors option is available for two
main reasons. Firstly, if from the data that has
been entered the instruction comes back that the
sensors should be mounted in Diagonal mode, it
may be that this is not possible in the case of a
partially buried pipe. Under these circumstances,
provided that the velocity is low enough it may be
possible to use the transduc ers provided in Reflex
mode (see figure 4, page 5).

The second reason for this option is that in the

case of applications where the signal strength is
not strong enough to get through a cor roded pipe
in Reflex mode, the instrument may be used in
Diagonal mode. T his has the effect of increasing
the signal strength and maximum flow velocity.

The display will read the following.
SETUP SENSORS

Mode REFLEX

To change the m ode of operation press ENTER.
There are 4 options under the heading of SETUP
SENSORS and these are selectable by pressing
scroll.

The display will show the following.
SETUP SENSORS

Mode REFLEX
Sensor params

Read flow
Exit and default

Select mode of operation by pressing SCROLL

then press ENTER.

SETUP SENSORS
Mode REFLEX

The display will show the following.
MODE

Reflex

Pressing SCROLL will allow you to choose
between Reflex and Diagonal operation. Press
ENTER when new mode is selected.

The display will show the following.
SETUP SENSORS

Sensor params

The user cannot c hange this option. It is only used
by Micronics engineers to set sensor parameters
for a particular application and to make sure the
correct transducers are supplied with the
instrument. If this option is selected in error the
instrument will ask for a password that is only
known by Micronics engineers. Pressing SCROLL
will move the instrument onto the next option.

The display will show the following.
SETUP SENSORS

Read flow

If the sensor mode has been changed from the
default settings (i.e. Reflex to Diagonal or
Diagonal to Reflex) then this option will have to be
selected to make sure that the new mode of
operation is used to read flow. If this is not
selected the default settings will be used.

The display will show the following.
SETUP SENSORS

Exit and default

Press ENTER at this point to Exit and retur n to the
MAIN MENU. This will re-set all the default sensor
settings in the instrument that may have been
changed by the user.

Pressing ENTER to continue will display the
following.

11

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

Approx max flow

* * * * l/m

Pressing ENTER again displays the following.
Attach sensors

REFLEX Sep * * * mm/inches

The instrument now displays the mode of
operation and separation distance. Attach the
transducers as described on pages 5 and 6.

Pressing ENTER will take the instrument into
reading flow.

l/m 0.00
l 000.0

MAIN MENU - Calibrate 4-20mA

(Note: A meter is required to meas ure the output
current)

The display will read the following. Press ENT ER
to select.

MAIN MENU
Calibrate 4-20mA

The 4-20mA output is calibrated before it leaves
the factory and should not need adjusting,
although this option allows the user to adjust it if
necessary to match a specific requirement. The
DAC value is a number between 0 and 40,000,
which is a number internal to the Ultraflo.

The first stage is to adjust the output current to
4mA. Use the scr oll key, decimal point key or keys
5 and 6. The scroll and decimal point key move
the DAC value in large steps of 25. Keys 5 and 6
move the value one digit at a time.

The DAC value should be approximately 8000 for

4mA and 40,000 for 20mA. By watching the actual
current value displayed on the meter, it is possible
to set this exactly.

The display will show the following.
CAL 4mA

DAC value: 8000

Use the scroll and decimal point key to set and

keys 5 and 6 to trim. Press ENTER when
complete.

The display will then show the following.
CAL 20mA

DAC value: 40000

Use the scroll and decim al point key to set 20mA
and keys 5 and 6 to trim. Press ENTER when
complete.

The following will be displayed. Press SCROLL.
MAIN MENU

Calibrate 4-20mA

The following will be displayed.

MAIN MENU

Read flow

MAIN MENU - Read flow

Pressing SCROLL will take the instrum ent back to
MAIN MENU-Quick start.

Pressing ENTER displays the following.
Approx max flow

* * * * l/m

It is possible to change the flow units by pressing

SCROLL. When a new unit is selected press
ENTER.

Pressing ENTER displays the following. Press

ENTER to read flow.

Attach sensors
REFLEX Sep 10.2

This informs the user of the mode of operation

and the separation distance.

Pressing SCROLL takes the instrument into
SETUP SENSOR mode.

SETUP SENSORS
Mode REFLEX

Pressing ENTER will read flow.
l/m 0.00

l 0.00

When measuring flow there are only three keys
that are active. FUNCTION, RESTART and
SCROLL. (see also page 7)

The Function key when pressed in flow mode
displays a range of information that will improve
the performance of the instrument and will assist
with the setting up of the unit.

The Restart key will at any point in the program
display the start up message. This allows the us er
to restart the program from the beginning.

The Scroll key when pressed in flow mode will
display the signal level and the mA output.

12

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

Pressed for a second time it will display the
ERRORS PENDING (see page 16 - Error &
Warning Messages). When pressed for a third
time it will read flow.

FUNCTIONS

When the instrument is m easuring flow, there are
certain functions that the user can access. Thes e
functions are accessible by pressing the function
key on the keypad then entering the password

2000.

The display will read the following. Select one of
the options by using the scroll key and press
ENTER to select.

FUNCTIONS

Display L/M
Setup 4-20mA

Pulses/set point
Cutoff m/s 0.05
Set zero flow
Reset total flow
Damping 5
Cal factor 1.000
Diagnostics
Save and exit

FUNCTIONS – Display

The display will show the following. Press ENT ER

to select.

Functions
Display L/M

By pressing ENTER then SCROLL the user is
able to change the measuring units. When
selected press ENTER. The units displayed will
depend on whether a Flow meter or Heatmeter
has been purchased. Energy options appear the
list of flow units have been displayed. Press Enter
when you have selected what you would like
displayed. This is the same operation f or both the
Heatmeter and Flowmeter.

FUNCTIONS - Setup 4-20mA

If a Heatmeter is supplied there will be two 4­20mA outputs available for use. T hey can be set
up separately to whatever output is required.
When using the 4- 20mA to monitor temperature it
will only monitor the temperature difference and
not the individual temperatures of the flow and
return.

The display will show the following. Press ENT ER

to select.

mA out 0.00
Output OFF

Units L/M
Max. 1000

Min. 0.00
mA on error 22.0
Exit

The display will show the following. Press Enter to

select.

SETUP 4-20MA
Output OFF

This shows the user what the output is giving at

any particular time. Press SCROLL to continue.

The display shows the following. Select the output

required and press ENTER.

OUTPUT
OFF

4-20mA
0-20mA
0-16mA

It is possible to choose between switching the
output ON/OFF or selecting the output r equired by
pressing SCROLL and ENTER.

SETUP 4-20MA
Units L/M

It is possible to set the output different from that
on the display. For example the display may show
gallons/minute but the output needs to be set up in

3

/hour. When a Heatmeter is supplied the

m
options will include kW , kCal/hr, MJ/hr, min, sec
and temperature differential. Scroll through the
options and press ENTER to select.

Functions
Setup 4-20mA

The display will show the following. Scroll through

each item and press ENTER to select.

SETUP 4-20MA

13

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

The display will show the following.
SETUP 4-20MA

Max. 1000

This function allows the user to sc ale the 4-20mA.
Press ENTER to select and enter your required
maximum flow rate in the units selected. For
example when the flow rate reaches the maximum
set, the output will be 20mA. Press ENT ER when
complete.

The display will show the following.
SETUP 4-20MA

Min. 000

The user is now required to enter the minimum
flow rate required in the units selected. Press
ENTER when complete.

The display will show the following.

SETUP 4-20MA

mA on error 22

This gives an error output which would inform the
user of loss of s ignal. T his can be s et to any figure
between zero and 24mA, but defaults to 22mA.
Press ENTER to select, enter the f igure required
and press ENTER.

The display will show the following.
SETUP 4-20MA

Exit

Press SCROLL to stay in the SETUP 4-20mA
menu or ENTER to go back to the FUNCTIONS
menu.

FUNCTIONS - Pulses/set point

The following will be displayed. Press ENTER to

select.

FUNCTIONS
Pulses/set point

This gives the user a choice of using a pulse
output or the set point facility. Pulse output and set
point cannot be used at the same time.

Scroll through the following options. Press ENTER

to select.

PULSES/SET POINT
Units L/M

Output OFF
l/pulse
Set point
Exit

The display shows the following. Use the scroll

key to select units, press ENTER.

PULSES/SET POINT
Units L/M

At this point the user is able to select the units

required by pressing ENTER. Scroll through the
options required and press ENTER when
selected.

The display will show the following. Press ENT ER

to select.

PULSES/SET POINT
Output OFF/PULSES/SET POINT

Note: The display will show the previous selection.

OUTPUT

Off
Pulses

Set point

Press SCROLL to select and then ENTER.
This facility allows the user to set the Pulses/Set

point or switch it off altogether. Selec ting Off and
pressing ENTER will m ove the program to Cutoff
m/s. Press SCROLL to select Pulses or Set point
and press ENTER.

If Pulses were selected the dis play will show the

following.

PULSES

l/pulse 1000

This can be scaled to the users requirem ents up
to a maximum of one pulse per second.
Or

SET POINT

Set point 1000

The Set point can be set to the users
requirements to trigger an alarm or indicator,
when the flow has reached a minimum or
maximum level.

14

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

The instrument def aults to 1000. This will be in the
units selected previously. It can now be changed
to the required amount by pressing ENTER. Enter
the new amount then press ENTER.

The display now reads the following. Press
ENTER to return to Functions.

PULSES/SET POINT
Exit

FUNCTIONS - Cutoff m/s

The display will now show the following.
FUNCTIONS

Cutoff m/s

The instrument has a preset CUTOFF of

0.05m/sec, which has been progr ammed into the

instrument. Micronics cannot guarantee
measuring flows below this range because of
instabilities in the measuring process. It is possible
for the user to change or cancel this figure but
Micronics cannot guarantee the performance
below this. It is also possible to enter any figure up
to a velocity of 1m/sec.

FUNCTIONS - Set Zero Flow

Press ENTER to select.

Press ENTER

FUNCTIONS - Reset Total Flow

The display will now show the following.

FUNCTIONS

Reset total flow

This function resets the total Flow or Energy. If a
Heatmeter was supplied it is possible to re-set the
total Energy. Press ENTER.

The display will now ask the following.

RESET TOTAL FLOW

Are you sure?

Or

RESET TOTAL ENERGY

Are you sure?

Answer YES by pressing ENTER and NO by
pressing SCROLL.

If you have answered YES the following will be

displayed. Press SCROLL to continue.

FUNCTIONS
Cutoff m/s

On some applications the ins trum ent is capable of
picking up noise which may show a small offset
when in flow mode. This offset should be
cancelled out which will increase the accur acy of
the instrument.

Before this function is used you have to be sure
that the flow has stopped com pletely. To set zero
flow before the flow has stopped will result in an
error message. This will occur when the flow is still
above 0.25m/sec. This could mean that the flow
has not totally stopped. Press SCROLL to answer
NO and ENTER to answer YES.

The following is displayed.
FLOW > 0.25 m/s

Continue ?

If the flow is below 0.25 m/sec then the following

will be displayed.

Stop the flow and
press ENTER

Follow the instructions on the display by pressing

ENTER.

Zero flow set

RESET TOTAL FLOW

Total reset

If you have answered NO the following will be

displayed. Press SCROLL to continue.

FUNCTIONS

Reset total flow

FUNCTIONS – Damping

The display will show the following.
FUNCTIONS

Damping 5

This option is used when flow readings are
unstable due to turbulence caused by internal
obstructions or bends etc. Damping or averaging
can be used to mak e the readings more stable. It
can be set to up-date the display between every 3
to 100 seconds. Press ENT ER to select. Enter the
time in seconds then press ENTER.

FUNCTIONS - Cal Factor

The display will show the following.
FUNCTIONS

15

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

Cal factor 1.000
This facility should never have to be used if the

correct application data has been entered into the
unit when being installed.

The calibration factor enables the instrument to be
calibrated to any existing meter or f low rate. The
transducers are always calibrated to work with the
electronics supplied. If for any reason the
transducers are dam aged the new ones supplied
will not have been calibrated with the electronics.
The calibration factor could then be used to give
the same reading as other transducers.

If the new reading is 4% higher than nor mal then
entering 0.96 will reduce the flow reading by 4%. If
the reading is 4% lower than normal, entering 1.04
would increase the reading by 4%. When the
instrument is s upplied it will always default to 1.00.
If it has to be changed the new cal number will
stay in the memory until changed again. Press
ENTER to select. Enter new data and press
ENTER.

FUNCTIONS - Diagnostics
The display will now read.

FUNCTIONS

Diagnostics

Diagnostics is not an option for the user. The
numbers displayed cannot be changed in any way
and are only of benefit to Micronics engineers
when testing the instrument or fault f inding. Press
SCROLL to continue.

FUNCTIONS - Save and Exit

The display now reads.

FUNCTIONS

Save and exit

Press SCROLL to start at the beginning of the
FUNCTIONS menu again or ENTER to save all
the changes made and read flow.

ERROR and WARNING MESSAGES
E1:High Flow?

When the instrument is programmed the user is
informed of the maximum flow rate that the
instrument can measure. If this is exceeded the
High flow message occurs.

It may be possible to get round these problems by
using another set of transducers in another mode.
This should not be necessary as the unit would
have been supplied for a particular application with
the correct transducers.

E2:No Flow Sig

This message appear s when the two transducers
cannot send or receive signals. T his c ould happen

for a variety of reasons. Firstly check that all
cables are connected, transducers are on the pipe
correctly and at the correct separation distance.
Check that there is couplant on the transducers.

This message may also appear when trying to
measure a partially full pipe, aerated liquid or
when the particulate content of that liquid is too
high. The condition of the pipe being measured
could also be a problem.

E3:HOT Fault

This message appears when the temperature
probe on the feed pipe is not connected. Check
the connections under the terminal lid.

E4:COLD Fault

Heatmeter)
This message appears when the temperature
probe on the return pipe is not connected. Check
the connections under the terminal lid.

WARNING MESSAGES
W1:Check Data

This message occurs when the application
information has been entered incorrectly or the
transducers have been attac hed to the wrong pipe
size. This will cause the timing to be in er ror. The
site data needs to be checked and the instrument
reprogrammed.

W2:Timing Poor

Unstable signal timing or diff ering up/down stream
times indicate that the liquid is aerated or pipe
surface is of poor quality.

W3:Signals Poor

This warning appears when there is a signal lower
than 25%. This could be due to the application or
a poor quality pipe etc.

W4:mA (1) Over

The mA (1) output is over range when the
Flow/Energy or Temperature diff erential is higher
than the maxim um m A range.. It is possible to re­scale the 4-20mA to be able to cope with the
higher range.

W5:mA (2) Over

Only one 4-20mA output is available with the
Flowmeter but both are available with the
Heatmeter. Both 4-20m A outputs are s et up in the
same way when supplied.

(only applicable for the Heatmeter)

(only applicable for the

16

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

W6:Pulse at Max

This message occurs when the pulses have
exceeded the maximum setting. It is possible to
re-scale the pulse output to cope with the higher
flow rate.

APPLICATION NOTES

The ULTRAFLO 2000 is a “Transit Time”
Ultrasonic flowmeter which has been designed to
work with “Clamp On” transducer s, thus enabling
liquid flowing within a closed pipe to be measured
accurately without the need for any mechanical
parts to be inserted either through the pipe wall or
protrude into the flow system.

The meter is controlled by a micro-processor
containing a wide range of data which enables the
instrument to measure flow in any pipe diameter
from 13mm bore up to 5000mm, made of any
material and over a wide range of operating
temperatures.

The system operates as follows:

When ultrasound is transmitted from transducer
“X” to transducer “Y” the speed at which the sound
travels through the liquid is accelerated slightly by
the velocity of the liquid. If sound is transm itted in
the opposite direction from “Y” to “X” it is
decelerated because it is travelling against the
flow of the liquid. The differ ence in time taken to
travel the same distance but in opposite directions
is directly proportional to the flow velocity of the
liquid.

Having measured the flow velocity and knowing
the pipe cross-sectional area, the volum etric flow
can be easily calculated. All of the calculations
required to first determine the c orrect siting of the
transducers and subsequently compute the actual
flow are carried out by the microprocessor.

To measure flow, it is first necessary to obtain
detailed information about eac h application, which
is then programmed into the processor via the
keypad. This information must be accurate
otherwise flow measurement errors will occur.

Further having calculated the precise position at
which the transducers m ust be clamped onto the
pipe wall, it is equally important to align and
separate the transducers accurately with respect
to one another, as failing to do so will again cause
errors in measurement.

“X”

FLOW

“Y”

Finally to ensure accurate flow measurem ent it is
imperative that the liquid is flowing uniformly within
the pipe and that the flow profile has not been
distorted by any upstream or downstream
obstructions.

To obtain the best r esults from the Ultraflo 2000 it
is absolutely necessary that the following rules for
positioning the transducers are adhered to and
that the condition of the liquid and the pipe wall
are suitable to allow transmission of the sound
along its predetermined path.

Selecting A Meter Position

As the transducers with the Ultraflo 2000 are
clamped to the outside surface of the pipe, the
meter has no way of determining exactly what is
happening to the liquid. The assum ption therefore
has to be m ade that the liquid is flowing uniform ly
along the pipe, either under fully turbulent
conditions or under laminar flow conditions.

It is further assumed that the flow velocity profile is
uniform f or 360° around the pipe ax is. T he Ultraf lo
2000 is normally supplied calibrated for use on
turbulent flows but by adjustment of the CAL
FACTOR the instrument can be used for lam inar
flow applications.

Figure 11

Figure 11 shows a unifor m prof ile as com par ed to
a distorted profile.

The difference between (a) and (b) is that the
“Mean Velocity” of the flow across the pipe is
different and the Ultraflo 2000 expects a uniform
flow as in (a). The distorted flow in (b) will give
measurement er rors which cannot be predicted or
compensated for.

Flow profile distortions result from upstream
disturbances such as bends, tees , valves, pumps
and other similar obstructions. To ensure a
uniform prof ile the transducers must be mounted
far enough away from any cause of distortion such
that it no longer has an effect.

17

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

0

5

0

Figure 12

CORRECT

FLOW

INCORRECT

FLOW

< 20 D

10 2

2

The minimum length of upstream straight pipe is
20 diameters and 10 diameters downstream which
ensures that accurate results will be achieved.
Flow measurements can be made on shorter
lengths of straight pipe down to 10 diameters
upstream and 5 diameter s downstream, but when
the transducers are sited this close to any
obstruction errors can be considerable.

It is not possible to predict the amount of error as
this depends entirely upon the type of obstruction
and the configuration of the pipework. The
message therefore is clear. Do not expect to
obtain accurate results if the transducers are
positioned closer than allowed to any obstruction
that distorts the uniformity of the flow profile.

Examples of the effects of two different pipe
configurations are shown in Figure 13.

Figure

Mounting The Transducers

It will be impossible to achieve the accuracy of
measurement s pecified for the Ultraflo 2000 if the
transducers are not clam ped to the pipe correctly
and if the data - I.D., O.D., Temperature, Pipe
Material are not accurate.

The transducers are supplied with a guide rail, the
purpose of which is to ensure that the transducers
are aligned accurately with the pipe axis and that
the face of the sensor is tangential to the axis.

Apart from the correct positioning and alignment
of the transducers, of equal importance is the
condition of the pipe surface in the area under
each of the transducers.

An uneven surface that prevents the transducers
from sitting flat on the surface of the pipe can
cause Signal Level and Zero Offs et pr oblems. The
following procedure is offered as a guide to good
practice with respect to positioning and mounting
the transducers.

1. Select the site following the rules laid down on
page 17.

2. Inspect the surf ace of the pipe to ensure it is
free from rust and unevenness. Transducers
can be mounted directly on painted surfaces
as long as the surface is smooth and that the
underlying metal surface is free from rust
particles. On bitumen or rubber coated pipes
the coating must be removed in the area
under the transducers as it is pref erable that
the transducers are mounted directly on to
base metal.

3.

Transducers can be m ounted on both Vertical

Horizontal pipe runs.

or

Figure 14

- Horizontal pipes

‘A’

‘B’

TOP

CORRECT

INCORRECT

4. Apply interface couplant to the face of the
transducers.

The amount of couplant used is extremely
important particularly on pipes of less than 100mm
bore. Use the syringe supplied with the instrument
and apply couplant as shown.
On small pipes below 90mm the bead of grease
used must be approxim ately 20mm long and 2mm
maximum diam eter. Using m ore greas e will cause

18

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

(

wall signals to be generated which cause err ors in
measurement.

Figure 15

On Stainless Steel pipes the amount of couplant
applied should never exceed the amount indicated
in the examples above. For large plastic and steel
pipes the amount of couplant applied is less
critical however do not use more than is absolutely
necessary.

5. Attach the guide rail assembly to the pipe so
that it is perfectly parallel to the pipe axis.

6. When sc rewing the transducer s on to the pipe
surface use only enough force to ensure that
the transducer is flat against the pipe sur face
and then lock in position.

7. Clamping the transducers in exactly the
correct position is extremely important. The
Ultraflo 2000 calculates the separation
distance and the transducers must be
positioned and clamped exactly at the
distance specified.

8. Always use the couplant provided.

Liquid Conditions

Transit Time ultrasonic meters perform best on
liquids that are totally free from entr ained air and
solids. With sufficient air in the system the
Ultrasound beam can be attenuated totally and
therefore prevent the instrument from working.
Often it is possible to tell whether there is air in the
system or not.

If a flow signal cannot be obtained a simple test to
determine whether the flow is aerated involves
cutting off the flow for a per iod of 10 - 15 m inutes.
During this time the air bubbles will rise to the top
of the pipe and the flow signal should return.

When the flow signal has retur ned “Switch on” the
flow and if sufficient entrained air is locked in the
system it will very quickly disperse and kill the
signal.

Propagation Velocity

To make a flow measurement using the Ultraflo
2000 on any liquid other than water it is necessary
to know the propagation velocity in

metres/second, of the particular liquid. Micronics
can supply this information.

Maximum Flow

The Ultraflo 2000 is normally supplied with
hardware suitable for the specific application for
which the instrument has been purchased. It is
possible to use the instrument on a wide range of
applications as long as the transducers will cope
with the maximum velocity and temperature
required.

Application Temperature

On any application with an operating temperature
above or below ambient tem perature, ensure that
the transducers reach and are maintained at the
application temperature before undertaking
calibration.

When applying the transducers to low temperature
pipes, do not allow the pipe surface to ice up
between the transducer and the pipe wall.

Wherever possible insulate the transducers such
that variations in ambient air temperature do not
effect the relationship between the trans ducer and
the liquid temperature.

The instrument automatically compensates for
changes in application temperature over a range
of approximately +/- 20°C.

FLOW RANGE

Figure 16

I I I I I I I I I I I I

I I I I I I I I I I I I

I I I I I I I I I I I I

I I I I I I I I I I I I

I I I I I I I I I I I I

I I I I I I I I I I I I

I I I I I I I I I I I I

m/s 0.02 0.03 0.06 0.07 0.1 0.4 1.3 2 4 6 7 8

f/s 0.06 0.09 0.19 0.22 0.32 1.31 4.26 6.56 13.12 19.68 22.96 26.24

Transducer set "D" (5000mm)

Transducer set "C" (2000mm)

Transducer set "B" (1000mm)

Transducer set "C" (300mm)

Transducer set "B"

Transducer set "A" (89mm)

Transducer set "D" (1000mm)

90mm)

Transducer set "A"

19

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

SPECIFICATION

ELECTRONIC ENCLOSURE:
Protection Class IP67
Material ABS
Dimensions 264 x 230 x 101 mm
Display 2 x 16 Character Super Twist LCD backlit

All Other Connections IP65 Glands
Temperature Range 0°C to 50°C Operating

SUPPLY VOLTAGE:
Switchable 110–240 VAC ± 50/60 Hz Max. 5 watts
24 Volt DC

FLOW OUTPUTS:

Flow Display Volumetric Flow m3, litres, gallons (Imperial and US)
Flow Velocity metres/sec, feet/sec
Flow Rate 0.2…12 m/sec to 4 Significant Figures
Total Flow 12 Digits
Signal Level Indication
ERROR messages
Analogue
Resolution 0.1% of full scale
Set Point or Pulse Max. 1 pulse per second User definable scaling

HEATMETER OPTIONS:
Display Energy kW, kCal/hr, MJ/hr,min,sec, kJ/hr,min,sec
Analogue 2 off 4-20mA Opto isolated with user definable scaling
Pulse Output Max. 1 pulse per second User definable scaling
Temperature Sensors: PT100 -20°C to +220°C
Max. temp. differential 220°C

Pipe Sizes Flow Velocity Range

‘A’ 50 mm…89 mm 0.2 m/sec…4 m/sec (8 m/sec)
‘B’ 90 mm…1000 mm 0.2 m/sec…8 m/sec (12 m/sec)
‘C’ 300 mm…2000 mm 0.2 m/sec…4 m/sec (7 m/sec)
‘D’ 1000 mm…5000 mm 0.2 m/sec…4 m/sec (7.5 m/sec)

Frequency:
Flow Transducer Protection:
Flow Transducer Cables:
Flow Transducer Cable Length:
Flow Transducer Temp. Range:

ACCURACY:

± 1…2% of reading or ± 0.02 m/sec, whichever is the greater.
Specification assumes turbulent flow profile with Reynolds numbers above 4000.

REPEATABILITY:

± 0.5% with unchanged transducer position.

PIPE MATRIALS:

Any sonic conducting medium such as Carbon Steel, Stainless Steel, Copper, UPVC, PVDF, Concrete,
Galvanised Steel, Mild Steel, Glass, Brass. Includes lined pipes – Epoxy, Rubber Steel, Plastic.

Micronics reserve the right to alter any specification without notification.

Keypad IP67
Sensor Connections TNC Coax Connectors

-10°C to 60°C Storage

4 - 20mA into 750 Ω

1MHz, 2MHz, 0.5MHz
Standard: IP65
50 Ohm Coax Cable
3 metres Standard - Optional up to 200 metres

-20°C to +200°C (‘D’ only up +80°C)

Opto isolated with user definable scaling

20

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

1. Installation

Connect the flow transducers to the instrument as described in the HARDWARE section of this
manual. Note that the Ultraflo must read positive flow otherwise the energy displayed will read zero.

Attach the temperature probes to the outside of the flow and return pipes. Use the stainless steel
banding to attach the temperature probe. Heat sink compound should be applied between the probe
and pipe for better heat transfer. Lagging should then be wrapped over the temperature probe itself
to stabilise the temperature.

One temperature probe should be attached to the feed pipe as the HOT SENSOR and the other is
attached to the return pipe as the COLD SENSOR.

Figure 17

Remove the terminal lid and connect the temperature probes’ making sure the power is turned off.
Connect the HOT sensor to the terminal marked HOT (Pins 5,6,7) and the COLD sensor to the
terminal marked COLD (Pins 8,9,10). A reversed temperature connection will make the

measured energy zero.

MA1 MA2 HOT COLD RELAY 24VDC AC IN
IN

The WHITE core from each temperature probe must always be connected to the negative (Pins 6
and 9). The other two cores on each temperature probe connect to either of the positive terminals
(Pins 5, 7and Pins 8,10). Always remember to earth the PT100 probes using the screen core.

The PT100 are subject to interference from power sources such as, pumps and invertors and
any electrical equipment. The interference will cause an error in the measurement of
temperature.

2. Operation

Connect power to the instrument and wait for a few seconds.

1. Follow the Quick Start menu on page 8 to read flow. Note that if the fluid selected is not water,
the user will be prompted for the SHC (specific heat capacity) and the density relative to water
(specific gravity). For water @ 20°C the SHC is 4.2 kj/m
calculate the SHC figure to enter into the unit find the SHC of the liquid being measured in kJ/kg
K and divide by 4.2 kJ/kg K. Now enter this figure into the unit.

2. To calculate the relative density, find the density in kg/m
20°C (996 kg/m
available from your supplier.

3. Select the Energy units required when setting up the display or outputs from the FUNCTION
menu on page 13. Scroll through the options and press ENTER to select.

4. It is now possible to set either of the two 4-20mA outputs for Flow/Energy or Temperature
differential as described in FUNCTIONS on page 13.

HEATMETER INSTRUCTIONS

TEMPERATURE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ - + - + - + + - +

NC COM NO

PROBE

STAINLESS STEEL

BANDING

110/220VAC

24VDC 110VAC

F
U

+

S
E

L N E

220VAC

F
U
S
E

3

and the density is 996kg/m3. To

3

3

). Now enter this number into the unit. The SHC and Density figures are usually

and divide by the density of water @

HEAT SINK
COMPOUND

17 18

21

ULTRAFLO 2000 INSTALLATION & OPERATING INSTRUCTIONS

CE MARKING

The Ultraflo 2000 has been tested and found to conform to EN50081 - 1 Emission Standards and EN50082 -
1 Immunity Standards.

The tests were conducted by AQL - EMC Ltd, of 16 Cobham Road, Ferndown Industrial Estate, Wimborne,
UK BH21 7PG.

The unit was tested with all cables as supplied of a maximum length of 3m. While the operation of the unit
may not be affected by the use of longer cables, Micronics can make no statement about conformance to the
above standards when these cables are in use.

MANUFACTURERS WARRANTY

The Ultraflo 2000 Ultrasonic liquid flow meter is guaranteed by MICRONICS to be free from defects in
materials and workmanship for a period of one year from the date of shipment to the original customer,
provided that the equipment has been installed and used in the manner described in this User’s Manual.

Fuses and sensor cables are not included in this warranty.
Repair or replacement, at MICRONICS option, will be made without charge at its factory during the warranty

period.
If any problems develop, take the followings steps:

1) Notify MICRONICS or the Distributor from whom you purchased the meter giving full details of the
problem. Be sure to include the model and serial numbers of your flow meter. You will then receive
service data and/or shipping instructions, depending on your problem.

2) If you are instructed to send your meter back to the factory, please send it prepaid to the authorised
repair station, as indicated in the shipping instructions.

The warranty of the ULTRAFLO 2000 Ultrasonic Liquid Flow meter by MICRONICS is limited to those

stated above and MICRONICS will not be liable for anything beyond this.

Software Version: v1.12

Document Number 001 - 150

22
