M5Pi PCI/ISA
60/66MHz Pentium Processor
System Board Manual
Document Number: 06-00096-05, Rev. 1B
221 Warren Ave., Fremont, CA 94539-7085
October 1994
Copyright Notices
Micronics Computers, Inc.
The information contained in the M5Pi system board manual has been
carefully checked and is believed to be accurate. Micronics assumes no
responsibility for any inaccuracies that may be contained in this document.
Micronics makes no commitments to update or to keep the information in this
manual at a current level when changes are made to the product.
Micronics reserves the right to make improvements to this document and/or
product at any time and without notice.
All Rights Reserved. No part of this document may be photocopied, reproduced, translated, or reduced to any medium or machine form without prior,
written consent from Micronics.
COPYRIGHT (C) 1994, Micronics Computers, Inc.
Portions of the Manual
Portions of this manual were copied (with permission) from Phoenix Technologies, Ltd. and Micro Computer Systems, Inc. All rights reserved.
Trademarks
IBM is a registered trademark of International Business Machines. Microsoft,
Microsoft Word, Windows are registered trademarks of Microsoft Corporation. Intel and PCI are registered trademarks of Intel Corporation. UNIX is a
registered trademark of AT&T Corporation. Lotus 1-2-3 is a registered
trademark of Lotus Development Corp. MCS is a trademark of Micro
Computer Systems. All other product names mentioned herein are used for
identification purposes only and may be the trademarks of their respective
companies.
ii
Micronics Quick Installation
We know that many experienced people prefer to read as little of the documentation as possible. If this sounds like you, here’s the short form:
1. Ground yourself to prevent damaging static discharge, then remove
the M5Pi from its packaging.
2. Configure and verify the system board’s jumper settings. (See
Jumper Settings in Chapter 2)
3. Install the CPU and the system memory (Chapter 3).
4. Install the system board into the system case and make all necessary
case connections.
5. Install any ISA and PCI peripherals (Chapter 3).
6. Turn the computer on and press <Ctrl>, <Alt>, and <s>
simultaneously after you see the screen below.
8. Set the time and date. Adjust the BIOS settings to match your
configuration. If installing an IDE drive, select the IDE device you wish
iii
to configure. Press <Enter> with Auto selected and the BIOS will
automatically configure the drive for you. (See Chapter 4)
9. After you have configured the Main Setup menu, make any desired
setting configurations in the Advanced and Security menu. When
finished, go to the exit screen, select “Save Changes and Exit,” and you
are finished with the BIOS configuration (Chapter 4).
iv
Contents
Introduction ......................................................................1-1
Features ..................................................................................... 1-2
Software Compatibility ............................................................... 1-2
Configuring the M5Pi ....................................................... 2-1
Static Electricity .......................................................................... 2-1
Office Environment ..................................................................... 2-1
M5Pi Components ..................................................................... 2-2
Jumper Settings .......................................................................... 2-3
Installing the M5Pi, System Memor y, CPUs and
Peripherals ........................................................................3-1
Installation of the M5Pi ............................................................... 3-2
T ools Required......................................................................................... 3-2
Equipment Required................................................................................. 3-2
System Memory ......................................................................... 3-3
SIMMs Supported ................................................................................... 3-3
Upgrading Rules ...................................................................................... 3-3
Common Memory Configurations............................................................ 3-4
Installing the SIMMs............................................................................... 3-5
Removing SIMMs.................................................................................... 3-5
Installing a CPU.......................................................................... 3-6
Installing a PCI Peripheral Card .................................................. 3-7
Installing an ISA Peripheral Card ................................................ 3-8
The BIOS Setup Utility...................................................... 4-1
Configuration .............................................................................. 4-1
Initial Boot Up ............................................................................ 4-1
Setup ......................................................................................... 4-2
Running the Setup Procedure ...................................................... 4-3
Setting the CMOS Parameters .................................................... 4-4
Setting the CMOS Main Screen............................................................... 4-4
System Time and Date ............................................................................. 4-4
Diskette Drive A or B............................................................................... 4-4
v
Hard Disk 1-4 (IDE Drives Only) .............................................................. 4-4
Base Memory and Extended Memory......................................................4-4
Video Card................................................................................................ 4-5
Keyboard ................................................................................................. 4-5
Setting the CMOS Extended Screen ........................................... 4-5
Serial Port A ............................................................................................. 4-5
Serial Port B ............................................................................................. 4-6
Parallel Port .............................................................................................. 4-6
Secondary IDE ......................................................................................... 4-6
Onboard Floppy....................................................................................... 4-6
Swap Floppies.......................................................................................... 4-6
Boot Sequence......................................................................................... 4-6
Cache State .............................................................................................. 4-6
1st PCI Device.......................................................................................... 4-6
System BIOS ............................................................................................ 4-6
Video BIOS............................................................................................... 4-7
Option ROM ............................................................................................ 4-7
Re-Configuring Y our Computer................................................... 4-7
POST Messages .............................................................. A-1
Beep Codes ...................................................................... B-1
Hard Disk Drive Types..................................................... C-1
Specifications .................................................................. D-1
Environmental Specifications .......................................................D-2
T emperature Range ................................................................................. D-2
Relative Humidity ................................................................................... D-2
Battery Disposal .........................................................................D-3
FCC W arning Statement ............................................................. F-1
Glossary .....................................................................................G-1
Limited W arranty .......................................................................W-1
Non-W arranty Service...............................................................W-2
vi
List of Figures
Figure 2-1: M5Pi System Board ...................................................................... 2-2
Figure 3-1: Installing a 72-Pin SIMM.............................................................. 3-5
Figure 3-3: Installing a PCI Peripheral Card .................................................... 3-7
Figure 3-5: Installing an ISA Card .................................................................. 3-8
Figure 4-1: Power-Up Screen .......................................................................... 4-2
Figure 4-2: CMOS Main Screen...................................................................... 4-3
Figure 4-3: CMOS Extended Screen ............................................................... 4-5
Figure 4-4: Exit Pop-up Screen........................................................................ 4-8
List of Tables
T able 2-1: CPU Speed Selection ..................................................................... 2-3
T able 2-2: V ideo Selection .............................................................................. 2-3
T able 2-3: PCI IDE Selection........................................................................... 2-3
Table 2-4: PCI IDE IRQ14 Selection................................................................ 2-3
T able 2-5: Secondary IDE Controller IRQ Selection ....................................... 2-4
T able 2-6: IDE DMA Channel Selection ......................................................... 2-4
T able 2-7: Parallel Port IRQ Selection ............................................................. 2-4
T able 2-8: Parallel Port DMA Channel Selection ............................................ 2-5
T able 2-9: Flash ROM Selection ..................................................................... 2-5
T able 2-10: BIOS Reset ................................................................................... 2-5
T able 2-11: Reserved Jumper Settings............................................................ 2-6
T able 2-12: Case and Peripheral Connections ................................................ 2-7
T able 3-1: Common Memory Configurations.................................................. 3-4
vii
viii
Introduction
1
Congratulations for choosing the Micronics M5Pi! The M5Pi is a highperformance system board designed to be a foundation for serious
computer applications.
The M5Pi is a 60/66 MHz Pentium based board and is one of the most
powerful Intel-based products on the market.
The M5Pi comes with many built in features. These include support for
four IDE hard drives, support for two floppy drives, a bi-directional
parallel port, and two high speed serial ports.
Micronics builds all products to exacting standards, using the highest
quality components available. We are proud to provide this system
board and hope it brings you years of reliable service.
Micronics M5Pi System Board Manual
Features
The M5Pi includes the following features:
m Pentium processor support for 60MHz or 66MHz processors.
m Two 32-bit PCI slots, four ISA slots, and one shared (PCI or ISA) slot.
m 256K of L2 write-back cache.
m Supports up to 128MB of on-board system memory.
m Primary PCI Mode 3 IDE controller (supports two drives).
m Secondary ISA IDE controller (supports two drives).
m Floppy controller for two floppy drives (Supports 2.88MB, 1.44MB,
1.2MB, 720K, and 360K floppy drives).
m Two high speed NS16550 compatible serial ports.
m Bi-directional parallel port that is EPP and ECP compatible (see
Specifications).
m Upgradeable Flash Phoenix BIOS.
Software Compatibility
The M5Pi system board has been thoroughly tested for compatibility with a
variety of operating systems and environments, including:
m Windows, Windows for Workgroups, and Windows NT
m OS/2
m SCO UNIX and Open Desktop
m Novell Netware
m MS-DOS
m PC-DOS
m NeXTStep 3.2
1-2
Configuring the M5Pi
2
Although the M5Pi system board is packaged in protective materials, it
is important to use care while unpacking and setting up.
Static Electricity
The M5Pi is shipped from the factory in an antistatic bag. To reduce the
possibility of damage, it is important to neutralize any accumulated
static charges on your body before handling the board. The best way to
do this is to ground yourself using a special wrist or ankle strap. If you
do not have a strap, you should touch both of your hands to a safely
grounded object. After you have grounded yourself, ground the M5Pi
via the solder pads surrounding one of its mounting holes.
Once the M5Pi is removed from its packaging, place it on top of the
antistatic bag. Carefully inspect the board for damage which may have
occurred during shipment.
Office Environment
Make sure the finished computer system is in an area with good ventilation. The system should not be in direct sunlight, near heaters, or
exposed to moisture, dust, or dirt.
Micronics M5Pi System Board Manual
M5Pi Components
2-2
Figure 2-1 M5Pi System Board
Jumper Settings
Jumper Settings
Table 2-1 lists the jumper settings to select the speed of the CPU installed in
your system.
Speed
Jumper
60MHz
(default)
66MHz
W25 close open
W26 open close
W27 close open
Table 2-1 CPU Speed Selection
Table 2-2 lists the jumper settings to select the type of video installed.
Jumper Function Setting
W3 color (d e fault)
monochrome
Table 2-2 Video Selection
close
open
Table 2-3 lists the jumper settings to enable or disable the PCI IDE controller.
Jumper Function Setting
W20 PCI IDE enabled (default)
PCI IDE disabled
open
close
Table 2-3 PCI IDE Selection
Table 2-4 lists the jumper settings to set the PCI IDE hard disk controller’s
IRQ. Leave this set to IRQ14 unless you are using a SCSI controller and need
to free up an unnecessary IRQ, or if you want to use the ISA IDE controller as
the primary IDE controller.
Jumper Function Setting
W15 IRQ14 (default)
IRQ15
Table 2-4 PCI IDE IRQ14 Selection
1-2
2-3
2-3
Micronics M5Pi System Board Manual
Table 2-5 lists the jumper settings to set the secondary IDE controller’s IRQ.
If you set this for IRQ14, you must disable the PCI IDE controller (Table 2-4).
Jumper Function Setting
W14 IRQ15 (default)
IRQ14
Table 2-5 Secondary IDE Controller IRQ Selection
2-3
1-2
Table 2-6 lists the jumper settings to select the DMA channel for the IDE port.
Jumper Function Setting
W16 DMA Channel 6
DMA not used (default)
W17 DMA Channel 6
DMA not used (default)
Table 2-6 IDE DMA Channel Selection
close
open
close
open
Table 2-7 lists the jumper settings to set the parallel port’s IRQ.
2-4
Jumper Function Setting
W4 IRQ7 (default)
IRQ5
W19 IRQ7 (default)
IRQ5
Table 2-7 Parallel Port IRQ Settings
open
close
close
open
Jumper Settings
Table 2-8 lists the jumper settings to select a DMA channel for the parallel
port.
Jumper Function Setting
W6 DMA Channel 1
DMA Channel 3
DMA not used (default)
W7 DMA Channel 1
DMA Channel 3
DMA not used (default)
Table 2-8 Parallel Por t DMA Channel Selection
1-2
2-3
open
1-2
2-3
open
Table 2-9 lists the jumper settings for programming the Flash ROM.
Jumper Function Setting
W22 Flash ROM programming disabled (default)
Flash ROM programming enabled
Table 2-9 Flash ROM Selection
open
close
Table 2-10 lists the jumper settings to reset the CMOS to its default settings.
Resetting the CMOS will clear all settings.
Jumper Function Setting
W24 Clear CMOS
Normal (default)
Table 2-10 BIOS Reset
close
open
2-5
Micronics M5Pi System Board Manual
Table 2-11 lists reserved jumper settings. Do not reconfigure these jumpers.
Jumper Function Setting
W1 Normal (default)
For Micron DRAM only
open
close
W2 Reserved open
W8 Reserved 1-2
W9 Reserved 1-2
W12 PS/2 Mouse does not use IRQ12 (AT Version)
PS/2 Mouse uses IRQ12 (PS/2 Ve rsion)
open
close
W13 Reserved 1-2
W18 Reserved 1-2
W21 Reserved 2-3
J30 Reserved (60 MHz only) open
J31 Reserved- do not modify
Table 2-11 Reserved Jumper Settings
2-6
Jumper Settings
Table 2-12 lists the jumper settings for case and peripheral connections.
Jumper Function Notes
J19 PCI IDE Connector Primary
J20 ISA IDE Connector Secondary
J21 Floppy Connector
J18 Parallel Port Connector Can be disabled at the
CMOS configuration screen.
J12 Serial Port (Com1) Can be disabled at the
CMOS configuration screen.
J11 Serial Port (Com 2) Can be disabled at the
CMOS configuration screen.
J9 AT Keyboard AT Version only
J8 & J15 PS/2 Mouse and Keybd. PS/2 Version only
J10 Ext. Keyboard 1- Clock(Keybd), 2-Data,
3-N/C, 4-Ground, 5-VCC
J16 & J17 Power Supply Connector
J34 Hard Disk LED 1-+5V DC, 2-Ground
J35 Reset
J38 Turbo LED 1-+5V DC, 2-Ground
J37 Keylock/Power LED 1-Power; 2-N/C; 3-Ground;
4-Keyboard Lock; 5-Ground
J36 Speaker Connector 1-Speaker; 2-N/C;
3-Ground; 4-5V DC
J29 12V Fan Connector 1- +12V DC, 2-Ground
Table 2-12 Case and Peripheral Connections
2-7
Installing the M5Pi, System
3
Memory, CPUs and Peripherals
This section explains how to install the M5Pi system board, SIMMs,
CPUs, and peripherals.
Warning:
Before installing or removing any peripherals or components, make
sure you have a clear work space and that you adhere to all anti-static
precautions described on page 2-1. Micronics recommends only
trained technicians operate on the system board. Damage which
occurs to the board while adding or removing peripherals or components may void the warranty.
If problems arise while installing peripherals, contact the computer
outlet where you purchased the peripheral or Micronics’ Technical
Support Department.
Micronics M5Pi System Board Manual
Installation of the M5Pi
The installation of the M5Pi system board depends on the type of case you
use. The M5Pi is a Baby AT size system board and you should be able to
install it in most cases.
Prior to installing the M5Pi, make sure you have a clear work space available
and adhere to all anti-static precautions.
If you are unfamiliar with installing a system board, Micronics highly recommends you read the computer user’s manual or contact your dealer’s technical
support department.
Tools Required
Micronics recommends using the following tools to install the M5Pi:
m Small Phillips screwdriver.
m Tweezers or a pair of needle-nose pliers.
m Tray (to hold loose screws).
Equipment Required
Micronics recommends using the following equipment with the M5Pi for a
typical configuration:
m Chassis with standard hardware.
m A high quality power supply capable of providing continuous power
within a 5 volt range, plus or minus 5% (eg. 4.75 to 5.25). A power
filter may be used with a noisy AC power source..
m PS/2 compatible keyboard (PS/2 version).
m AT-compatible keyboard (AT version).
m Eight ohm speaker (included with most chassis).
m Standard ribbon cables for internal connections.
m Standard power cord (grounded).
m Heat sink with cooling fan (required).
3-2
Installing System Memory and Add-On Peripherals
System Memory
System memory devices, commonly known as SIMMs (Single Inline Memory
Modules), are necessary to operate the M5Pi system board. The M5Pi has
four SIMM sockets and can be upgraded to 128 Megabytes of RAM. This
section will explain the type of SIMMs supported, list the rules of adding
memory to the M5Pi, give some examples of common memory configurations,
and show how to physically install the new SIMMs.
SIMMs Supported
The M5Pi supports the following 72 pin, 60 or 70ns SIMMs:
4MB (1Mx36)
8MB (2Mx36)
16MB (4Mx36)
32MB (8Mx36)
Note:
For long term reliability, Micronics recommends using SIMMs with tin-plated
contacts. The use of gold-plated contacts may conflict with the tin alloy of the
SIMM socket.
Upgrading Rules
The following is a list of rules to follow when upgrading SIMMs. If you
follow these rules, your upgrade should be trouble-free:
m Use 70ns or faster SIMMs. Anything slower will not keep up with
the Pentium processor.
m Upgrade SIMMs two at a time. These SIMMs must be the same size
and preferably from the same manufacturer. To add 16MB of
memory to the system board, install two 8MB SIMMs into bank 0
and bank 1.
m When installing SIMMs, start with ‘bank 0’ and work your way up
(0,1,2,3).
3-3
Micronics M5Pi System Board Manual
Common Memory Configurations
The following table (Figure 3-1) lists the most common memory configurations. The M5Pi will accept any combination of SIMMs as long as the rules in
the previous section are followed.
Bank 0 Bank 1 Bank 2 Bank 3 Total
4MB 4MB 8MB
4MB 4MB 4MB 4MB 16MB
8MB 8MB 16MB
4MB 4MB 8MB 8MB 24MB
8MB 8MB 4MB 4MB 24MB
8MB 8MB 8MB 8MB 32MB
16MB 16MB 32MB
4MB 4MB 16MB 16MB 40MB
16MB 16MB 4MB 4MB 40MB
3-4
8MB 8MB 16MB 16MB 48MB
16MB 16MB 8MB 8MB 48MB
16MB 16MB 16MB 16MB 64MB
32MB 32MB 64MB
4MB 4MB 32MB 32MB 72MB
32MB 32MB 4MB 4MB 72MB
8MB 8MB 32MB 32MB 80MB
32MB 32MB 8MB 8MB 80MB
16MB 16MB 32MB 32MB 96MB
32MB 32MB 16MB 16MB 96MB
32MB 32MB 32MB 32MB 128MB
Table 3-1 Common Memor y Configurations
Installing System Memory and Add-On Peripherals
Installing the SIMMs
To install the SIMMs, locate the memory banks on the system board. Find the
lowest bank number available (0,1,2,3) and work your way up.
Perform the following steps to install the SIMMs:
1. Hold the SIMM so that the notched edge is aligned with the notch on
the SIMM socket (Figure 3-1).
2. Insert the SIMM at a 45 degree angle.
3. Gently push the SIMM into an upright position until it “locks” into
place (past the release tabs).
Figure 3-1 Installing a 72-Pin SIMM
Removing SIMMs
Perform the following steps to remove SIMMs, if necessary:
1. With both thumbs (or fingers), press the release tabs away from the
socket.
2. With the SIMM free from the release tabs, lift the module up and
place in an anti-static bag or package.
3-5
Micronics M5Pi System Board Manual
Installing a CPU
The M5Pi is designed to support 60 or 66MHz Pentium processors. Follow
the steps below to install a processor:
1. Turn off the computer and remove the computer cover.
2. Locate the ZIF socket illustrated in Figure 2-1.
3. Lift the lever of the socket.
4. Locate pin 1 on the processor and pin 1 on the socket (Figure 2-1).
Gently set the processor into the socket, making sure
pin 1 on the processor and pin 1 on the socket are aligned.
5. Push the lever down until it locks into place.
6. Make sure the CPU selection jumpers are set correctly (Chapter 2).
Warning:
Pentium processors require a heat-sink with a cooling fan. Failure to
provide adequate cooling of the processor may seriously affect system
performance or cause permanent damage to the processor.
3-6
Installing System Memory and Add-On Peripherals
Installing a PCI Peripheral Card
Micronics PCI slots accommodate all PCI peripherals which the PCI 2.0
specifications. Complete the following steps to install a PCI card:
1. Turn the computer system off and remove the computer cover.
2. Choose an unused PCI slot and remove the slot cover.
3. Insert the card with the bottom edge level to the slot. Never insert
the card at an angle!
4. Carefully push the card straight down, making sure the card is fully
inserted.
5. Replace the screw which holds the card into place.
6. Replace the computer cover.
7. Read the card’s manual for additional instructions concerning
installation and software drivers.
Figure 3-3 Installing a PCI Card
3-7
Micronics M5Pi System Board Manual
Installing an ISA Peripheral Card
Micronics ISA slots accommodate all standard ISA peripherals. Complete the
following steps to install an ISA card:
1. Turn the computer system off and remove the computer cover.
2. Choose an unused ISA slot and remove the slot cover.
3. Insert the card with the bottom edge level to the slot. Never insert
the card at an angle!
4. Carefully push the card straight down, making sure the card is fully
inserted.
5. Replace the screw which holds the card into place.
6. Replace the computer cover.
7. Read the card’s manual for additional instructions concerning
installation and software drivers.
3-8
Figure 3-5 Installing a ISA Card
4The BIOS Setup Utility
Configuration
After the M5Pi system board and all hardware is installed, the system is
ready for configuration. Before turning on the computer, make sure all
cables are correctly connected and all jumpers are correctly set.
It is recommended you keep the computer cover off the first time you
boot the system. If you have any difficulties, they will be easier to
correct.
Initial Boot Up
Power up the M5Pi. If the system doesn’t properly boot, check all your
cables and peripherals for bad connections. You may also get error
messages or beep codes. If this occurs, consult Appendices A and/or B
for a guide to possible solutions.
After the system properly boots, it is ready to be configured. The
following pages explain the proper procedures for BIOS configuration.
4-1
Micronics M5Pi System Board Manual
Setup
The Setup procedure is built into the system. Setup begins after the completed
system is powered up. Once the system is powered up and goes through a
memory test, the following screen appears on your monitor:
Figure 4-1 Power-Up Screen
If the systems detects a configuration error, it displays an error message. After
the error message, another message displays indicating the choice to “press
<F1> to continue (boot up), or <F2> to run the Setup procedure.” Normally,
you will press <Ctrl>, <Alt>, and <s> simultaneously to begin the Setup
procedure.
4-2
The BIOS Setup Utility
Running the Setup Procedure
If the system halts while booting, press <F2> and the CMOS Main Screen
(Figure 4-2) should appear with the prompt on the time line. If the system
does not halt and a DOS prompt does appears (i.e., A:\ or C:\), press the
<Ctrl>, <Alt>, and <s> keys simultaneously to begin the Setup procedure.
The M5Pi system board has two CMOS configuration screens: the Main
Screen (Figure 4-2) and the Extended Screen (Figure 4-3). To toggle between
the screens, press the PgUp/PgDn keys.
Figure 4-2 CMOS Main Screen
Now, configure the parameters to match your specific requirements. See the
following pages for procedures on how to set the computer’s parameters.
To return to the CMOS configuration screens at any time to change or view
any of these parameters, press <Ctrl>, <Alt>, and <s> simultaneously.
4-3
Micronics M5Pi System Board Manual
Setting the CMOS Parameters
Before running the computer, certain parameters on the CMOS configuration
screens must be set so the computer properly operates. First, set the
parameters on the CMOS Main Screen, then press the PgUp/PgDn key, and set
the parameters on the CMOS Extended Screen.
Note:
Some of the parameters are already set and should not be changed. Only
change the settings if necessary.
Setting the CMOS Main Screen
System Time and Date
To set the time, use the minus <-> key to decrease the number and the plus
<+> key to increase the number. To move the prompt forward, use the right
arrow <→> key; to move the prompt backward, use the left arrow <← > key.
Follow the same procedure for the date.
Diskette Drive A or B
This allows you to configure a diskette drive added or removed from your
computer. Use the <+/-> keys to toggle between the options.
Hard Disk 1-4 (IDE Drives Only)
This selection allows you to configure a hard disk installed in your system.
Use the <+/-> keys to toggle between the options. See Appendix C for a
complete listing of all possible hard drive types.
To install most SCSI hard drives, select NOT INSTALLED. To manually
configure the hard drive, select USER CONFIG. Press the down arrow <↓>
key and type in the appropriate parameters. To automatically configure an
IDE hard drive, select AUTO CONFIG. Drives that can be Auto-Configured
report parameters to the BIOS.
Base Memory and Extended Memory
Both of these memory settings are automatically configured. Press the down
arrow <↓> key to move to the next selection.
4-4
The BIOS Setup Utility
Video Card
This sets the type of monitor required for your computer. The display peripheral supports VGA/EGA, CGA80, CGA40, Monochrome (MONO), or no
monitor at all. Use the <+/-> keys to toggle between the options.
Keyboard
If the keyboard category is set to INSTALLED, the computer will test the
keyboard during boot. If set for NOT INSTALLED, the system will ignore
any keyboard errors and always attempt to boot. Set this for INSTALLED
unless using the system board in an application which does not require a
keyboard.
Setting the CMOS Extended Screen
You can toggle between the Main screen and the Extended screen (Figure 4-3)
using the PgUp and PgDn key.
Figure 4-3 CMOS Extended Screen
Serial Port A
Serial Port 1 may be set for COM1 (default), COM3, or may be disabled. Be
sure this setting does not conflict with any other peripherals.
4-5
Micronics M5Pi System Board Manual
Serial Port B
Serial Port 2 may be set for COM2 (default), COM4, or may be disabled. Be
sure this setting does not conflict with any other peripherals.
Parallel Port
The parallel port may be set for LPT1 (default), LPT2, or may be disabled. Be
sure this setting does not conflict with any other peripherals.
Secondary IDE
The ISA IDE controller can be set to ENABLED or DISABLED.
Onboard Floppy
The On Board Floppy controller can be set to ENABLED or DISABLED.
Swap Floppies
This category can be set to remap the floppy drives. It can be set for NORMAL (default) or SWAPPED. For normal operation, Drive A: and Drive B:
work normally. When “Swapped” is selected, Drive A: becomes Drive B:, and
Drive B: becomes Drive A:.
Boot Sequence
This category selects the order the system searches for a boot disk and can be
set for “A: First” or “C: First.”
Cache State
This category allows you to enable both the internal and the external cache,
enable the internal cache only, or disable both caches. For optimal performance, select BOTH.
Note:
External cache must be installed in order to select BOTH.
1st PCI Device
This selection allows you to set the IRQ of the 1st PCI device to IRQ9, IRQ11,
or IRQ15. The next IRQ will automatically be assigned to the next peripheral.
(eg. If slot 0 is empty, slot 1 has a SCSI controller, and slot 2 has a network
card, setting 1st PCI Device for IRQ9 will assign the SCSI controller to IRQ9
and the network card to IRQ11.)
Note:
Not all PCI peripherals require an IRQ and most video cards do not. Even if
slot 0 had a video card installed in the above example, the system would still
assign IRQ9 to the SCSI controller.
4-6
The BIOS Setup Utility
System BIOS
The System BIOS Option allows you to Shadow, Shadow & Cache, or Disable
the BIOS Shadow on the system board. Choosing SHADOWED copies the
system’s BIOS into RAM for faster execution. Choosing SHADOWED &
CACHED caches the shadowed system BIOS for even higher performance.
This allows you to take advantage of the high-speed 32-bit bus and the 70
nanosecond RAM. Use the <+/-> key to toggle between the options.
Video BIOS
The Video BIOS Option allows you to Shadow, Shadow & Cache, or Disable
the BIOS Shadow on the system board. Choosing SHADOWED copies the
system’s video BIOS into RAM for faster execution. Choosing SHADOWED
& CACHED caches the shadowed video BIOS for even higher performance.
Use the <+/-> key to toggle between the options. The System BIOS Shadow
option must be set to SHADOW or SHADOW & CACHE before enabling the
Video BIOS Shadow options.
Option ROM
Some peripheral cards such as low-priced SCSI controllers and network
adapters which do not have their own BIOS require this feature. Check the
documentation of your peripheral cards to see if they need this feature.
4-7
Micronics M5Pi System Board Manual
Re-Configuring Your Computer
Press the <Esc> key to reach the Exit Pop-Up Screen. Now select <F4> to
save and initialize the new Setup.
4-8
Figure 4-4 Exit Pop-up Screen
A
POST Messages
The following table lists the Power On Self Test (POST) messages,
possible causes, and solutions.
Message Possible Cause Solution
NO DISKETTE
CONTROLLER
DISKETTE DRIVE
RESET FAILED
DISKETTE DRIVE A
FAILURE
DISKETTE DRIVE B
FAILURE
DISKETTE READ
FAILURE; STRIKE
F1 TO RETRY
BOOT
DISPLAY ADAPTER
FAILED USING
ALTERNATE
ERRORS FOUND;
DISK X FAILED
INITIALIZATION
ERRORS FOUND;
INCORRECT
CONFIGURATION
INFORMATION;
MEMORY SIZE
MISCOMPARE
Disk controller not
found.
Disk adapter has failed
or is improperly
configured.
Drive A failed or is
missing.
Drive B failed or is
missing.
Disk is not formatted or
is defective.
The color/monochrome
switch is not set
correctly, or the primary
video adapter failed.
Hard disk configuration
information is incorrect.
The size of the base or
the expansion memory,
does not agree with
configuration
information.
Change the
Configuration.
Check the disk adapter.
Check the A drive.
Check the B drive.
Replace the diskette with
a formatted diskette and
retry.
Change the switch to the
correct setting, or check
the primary video
adapter.
Rerun SETUP and enter
the correct hard disk
information.
Enter correct memory
size and rerun SETUP
procedure.
A-1
Micronics M5Pi System Board Manual
Message Possible Cause Solution
FIXED DISK
CONFIGURATION
FAILURE
The specified
configuration is not
supported.
Correct the hard disk
configuration.
FIXED DISK
CONTROLLER
FAILURE
FIXED DISK X
FAILURE (where X
=0 or 1)
HARD READ
FAILURE- STRIKE
F1 TO RETRY
BOOT
FDD CONTROLLER
FAILURE
FDD A IS NOT
INSTALLED
FDD B IS NOT
INSTALLED
KEYBOARD CLOCK
LINE FAILURE or
KEYBOARD DATA
LINE FAILURE
The controller card has
Replace controller card.
failed.
The hard disk crashed. Press F1 to reboot or
rerun SETUP. If this does
not work, replace hard
disk.
The hard disk failed. Press F1 to reboot or
rerun Setup. If this does
not work, replace hard
disk.
Diskette controller failed. Replace controller card.
Cannot find diskette
controller for drive A.
Cannot find diskette
controller for drive B.
Install or replace
controller card.
Install or replace
controller card.
Keyboard logic failed. Make sure the keyboard
cable is connected
correctly.
KEYBOARD STUCK
KEY FAILURE
REAL TIME CLOCK
FAILURE
TIME-OF-DAY NOT
SET- RUN SETUP
PROGRAM
BIOS XXXX ROM
BAD CHECKSUM
(where
XXXX=C8000 to
E0000)
A-2
A key is jammed or was
held down during boot.
The real-time clock logic
failed.
The real-time clock timeof-day is not running.
The optional ROM
checksum is bad.
Make sure the keys are
not jammed or dirty.
Check battery and
replace, if necessary
Run SETUP utility.
Replace add-on card.
Message Possible Cause Solution
DISKETTE READ
FAILURE, or NOT A
BOOT DISKETTE, or
Hard/floppy disk failed or
is not bootable.
Replace the diskette with
a bootable diskette and
retry.
NO BOOT DEVICE
AVAILABLE
POST Messages
DECREASING
AVAILABLE
MEMOR Y, o r
MEMORY FAILURE
AT AAAAAAAA
READ XXXX
EXPECTING YYYY
(where AAAAAAAA
= failing address,
XXXX=data read,
and YYYY=data
written)
The memory data
integrity failed.
Check contact points
between memory
modules and system
board. Replace memory
modules if necessary.
A-3
Beep Codes
B
Beep codes are a series of beeps sent through the speaker which indicate
a problem during POST. If text appears on the video screen, the M5Pi
has completed POST; any other tone from the speaker indicates something other than a POST error. These tones are not described in Table
B-1.
The beep error codes are a series of three sets of beeps. The duration of
the beep tones are constant, but the length of the pauses between the
beeps varies. For example, a 1-3-3 beep code will sound like one beep,
a pause, three beeps consecutively, another pause, and then three more
beeps.
One beep code is often misunderstood. With no video card installed, or
if the video card is failing, the system board will generate a long-shortlong-short beep code. This is often interpreted as a 1-2-1 beep code.
But POST errors always vary in the length of the pause, and not the
duration of the beep tone.
Another way of identifying a POST error is to use a device called a
POST-card. This peripheral card is inserted into one of the ISA slots
and has an LED (or LCD) read out showing the contents of port 80h.
The following table provides a list of all beep codes and probable
causes.
B-1
Micronics M5Pi System Board Manual
Beep code Contents
Description
Port 80h
None 01h CPU register test in progress.
1-1-3 02h CMOS read/write failure.
1-1-4 03h ROM BIOS check failure.
1-2-1 04h Programmable interval timer failure.
1-2-2 05h DMA initialization failure.
1-2-3 06h DMA page register write/read failure.
1-3-1 08h RAM refresh verification failure.
None 09h First 64K RAM test in progress.
1-3-3 0Ah First 64K RAM chip or data line failure (multi-bit).
1-3-4 0Bh First 64K RAM odd/even logic failure.
1-4-1 0Ch Address line failure first 64K RAM.
1-4-2 0Dh Parity failure first 64K RAM.
2-1-1 10h Bit 0 first 64K RAM failure.
2-1-2 11h Bit 1 first 64K RAM failure.
2-1-3 12h Bit 2 first 64K RAM failure.
2-1-4 13h Bit 3 first 64K RAM failure.
2-2-1 14h Bit 4 first 64K RAM failure.
2-2-2 15h Bit 5 first 64K RAM failure.
2-2-3 16h Bit 6 first 64K RAM failure.
2-2-4 17h Bit 7 first 64K RAM failure.
2-3-1 18h Bit 8 first 64K RAM failure.
2-3-2 19h Bit 9 first 64K RAM failure.
2-3-3 1Ah Bit 10 first 64K RAM failure.
2-2-4 1Bh Bit 11 first 64K RAM failure.
2-3-1 1Ch Bit 12 first 64K RAM failure.
2-4-2 1Dh Bit 13 first 64K RAM failure.
B-2
Beep Codes
Beep code Contents
Description
Port 80h
2-4-3 1Eh Bit 14 first 64K RAM failure.
2-4-4 1Fh Bit 15 first 64K RAM failure.
3-1-1 20h Slave DMA register failure.
3-1-2 21h Master DMA register failure.
3-1-3 22h Master interrupt mask register failure.
3-1-4 23h Slave interrupt mask register failure.
None 25h Interrupt vector loading in progress.
3-2-4 27h Keyboard controller test failure.
None 28h CMOS power failure and checks calculation in
progress.
None 29h CMOS configuration validation in progress.
3-3-4 2Bh Screen initialization failure.
3-4-1 2Ch Screen retrace test failure.
3-4-2 2Dh Search for video ROM in progress.
None 2Eh Screen running with video ROM.
None 30h Screen operable.
None 30h Screen running with video ROM.
None 31h Monochrome monitor operable.
None 32h Color monitor (40 column) operable.
None 33h Color monitor (80 column) operable.
B-3
CHard Disk Drive Types
The following table lists the hard disk types supported by M5Pi.
Type Cyl Hd Pre LZ Sec Size (MB)
1 306 4 128 305 17 10
2 615 4 300 615 17 20
3 615 6 300 615 17 30
4 940 8 512 940 17 62
5 940 6 512 940 17 46
6 615 4 -1 615 17 20
7 462 8 256 511 17 30
8 733 5 -1 733 17 30
9 900 15 -1 901 17 112
10 820 3 -1 820 17 20
11 855 5 -1 855 17 35
12 855 7 -1 855 17 49
13 306 8 128 319 17 20
14 733 7 -1 733 17 42
15xxxxx x
16 820 6 -1 820 17 40
17 977 5 300 977 17 40
18 977 7 -1 977 17 56
19 1024 7 512 1023 17 59
20 733 5 300 932 17 30
21 733 7 300 932 17 42
22 733 5 300 933 17 30
23 1024 5 -1 1023 17 42
24 925 9 -1 925 17 69
25 699 7 256 700 17 40
26 1024 4 -1 1023 17 34
27 1024 5 -1 1023 17 42
28 1024 8 -1 1023 17 60
C-1
Micronics M5Pi System Board Manual
Type Cyl Hd Pre LZ Sec Size (MB)
29 512 8 256 512 17 34
30 615 2 615 615 17 10
31 989 5 0 909 17 41
32 1020 15 -1 1024 17 127
33 615 4 - 1 615 26 31
34 820 6 - 1 820 26 62
35 1024 9 1024 1024 17 76
36 1024 5 512 1024 17 42
37 1024 5 512 1024 26 65
38 823 10 256 824 17 60
39 615 4 128 664 17 20
40 615 8 128 664 17 40
41 917 15 -1 918 17 114
42 1023 15 -1 1024 17 127
43 823 10 512 823 17 60
User 1
User 2
User 3
User 4
Auto
Not Installed
C-2
Specifications
D
Processor 60MHz or 66MHz Pentium processor.
Chipset Intel 82430 PCI Set.
CPU Clock Select Frequency synthesizer chip.
Jumper selectable CPU selection.
Form Factor Baby AT size (8.5" x 13.75"). 4 layer PCB.
Expansion Four 16-bit ISA slots.
Two 32-bit PCI slots.
One shared ISA/PCI slot.
BIOS Phoenix BIOS on 1MB Flash EPROM.
Multiple sector transfer support.
IDE speed selection.
RAM Capacity 128MB
Keyboard PS/2 (PS/2 version).
AT-Compatible (AT version).
Mouse Built-in PS/2 support (PS/2 version only).
Internal Cache 16K.
External Cache 256K.
I/O Ports Built in support.
Two high speed serial ports (16550 compatible).
One bi-directional parallel port.
Enhanced Parallel Port (EPP) compatible.
Microsoft and Hewlett Packard Extended
Capabilities Port (ECP) compatible.
Floppy Port Supports two floppy drives (2.88, 1.44, 1.2, 720K,
360K).
PCI IDE Port Supports two IDE hard disks.
D-1
Micronics M5Pi System Board Manual
Mode 3 support.
Multiple sector transfer support.
LBA support.
Secondary IDE Support Supports two additional IDE hard disks.
LBA support.
Environmental Specifications
The environment in which the M5Pi is located is critical. Micronics recommends the following environmental specifications:
Temperature Rang e
Operating: 50 to 104 degrees Fahrenheit (10 to 50 degrees Celsius).
Non -Operating: 50 to 140 degrees Fahrenheit (10 to 60 degrees Celsius).
Shipping: -22 to 140 degrees Fahrenheit (-30 to 60 degrees Celsius).
Relative Humidity
Operating: 20% to 80%
Non-Operating: 5% to 90%
D-2
Battery Disposal
Warning:
DO NOT: open battery; dispose of in fire; recharge; put in backwards, mix
with used or other battery types.
May explode or leak and cause personal injury.
D-3
FCC Warning Statement
This equipment has been tested and found to comply within the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not used in accordance with the instructions, may
cause harmful interference to radio communications. Interference to radio or
television reception can be determined by turning the equipment off and on.
The user is encouraged to try to correct the interference by one or more of the
following measures:
M Reorient the receiving antenna.
M Increase the separation between the equipment and the receiver.
M Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
M Consult your dealer or an experienced radio/TV technician for help.
To meet FCC requirements, shielded cables and power cords are required.
Note:
Changes or modifications not expressly approved by Micronics could void the
user’s authority to operate the equipment.
F-1
Glossary
BIOS: Basic Input Output System. Maintains and controls the
entire functions of the computer.
Cache: Fast memory used to enhance the efficiency and speed of the
computer.
CPU: Central Processing Unit. Essentially, the “brains” of the
computer.
Disk Drive: Either a hard disk or a floppy diskette.
DRAM: Dynamic Random Access Memory.
EISA: Extended Industry Standard Architecture.
ISA: Industry Standard Architecture.
Jumpers: A device on the system board used to configure certain
information on the board.
POST: Power On Self Test. The computer’s self-diagnostic test,
which is executed whenever the system is booted.
Setup: Steps used to configure the system board.
SIMM: Single In-line Memory Module. SIMMs are banks of
memory used to increase the performance of the computer.
SRAM: Static Random Access Memory.
G-1
Limited Warranty
Except as described below, Micronics warrants the products to be free from
defects in material and workmanship in normal use for a period of one (1) year
from date of purchase. Should any product fail to perform according to this
warranty at any time during the warranty period, except as provided below,
Micronics or its authorized service centers will, at Micronics’ option, repair or
replace the product at no additional charge.
The warranty does not cover loss or damage which occurs in shipment or
which is due to: (1) improper installation or maintenance, misuse, neglect or
any cause other than ordinary commercial application, including without
limitation, accidents or acts of God; (2) adjustment, repair, or modification by
other than a Micronics authorized service center; (3) improper environment,
excessive or inadequate heating or air conditioning, or electrical power
failures, surges or other irregularities; (4) any statement about the product
other than those set forth in this warranty; or (5) nonconformity to models or
samples shown to the purchaser. Any models or samples were for the sole
purpose of suggesting the character of the product and are not intended to
form the basis of the bargain.
A receipt or copy of the invoice with the date of purchase from a Micronics
reseller is required before any warranty service can be rendered. Service can
be obtained by calling Micronics for a Return Merchandise Authorization
(RMA) Number.
The RMA Number should be prominently displayed on the outside of the
shipping carton of the returned product. Returned product should be shipped
prepaid or hand carried to Micronics. The purchaser assumes risk of loss or
damage in transit, and unless otherwise agreed to in writing by Micronics, will
pay inbound shipping charges.
The exclusive remedy of the purchaser under this warranty above will be
repair or replace at Micronics’ option, but if for any reason that remedy should
fail of its essential purpose, the exclusive remedy of the purchaser shall then
be actual damages up to amounts paid for the defective product by the
purchaser. This limited warranty shall be deemed to “fail of its essential
purpose” if, after repeated efforts, Micronics is unable to make the product
operate as warranted. Micronics’ liability for damages to the purchaser for
any cause whatsoever; regardless of the form of action and whether in contract
or in tort, shall be limited to the purchase price in effect when the cause of
action arose for the product that is the basis of the claim.
W-1
Micronics M5Pi System Board Manual
Micronics will not be liable for any lost profits or any indirect, special
incidental or consequential damages in connection with the product, even if
Micronics has been advised of the possibility of such damages.
Micronics makes no warranties or representations as to performance of
products or as to service to distributor or to any person, except as set forth in
Micronics; limited warranty accompanying delivery of product.
Micronics disclaims all other warranties whether oral, written, expressed, or
implied, including without limitation, the warranties of design, merchantability, or fitness for a particular purpose, if applicable, or arising from a course of
dealing, usage or trade practice.
Non-Warranty Service
After the one year warranty service is no longer in effect, repair service is still
available for Micronics products. For more information, contact Micronics’
RMA department at (510) 683-0428 or (510) 683-0389. The RMA department is open between 8:30 A.M. and 5 P.M. Pacific Standard Time.
W-2
Loading...
