RealSSD™ P400e Enterprise
Solid State Drives
Product Summary
Enabled by our advanced 25nm MLC NAND Flash, our RealSSD ™ P400e drive provides
reliable high performance for read-intensive applications such as boot drives, directattached storage, and blade servers. They can also serve as a primary drive in applications
that need more endurance and data reliability than a client drive can provide.
We specifically designed the P400e drive in response to customer requests for a drive
with a low total cost of ownership (TCO) and key features like high lifetime endurance,
enterprise-level data protection, and a wide selection of capacities. Its excellent dollarsper-IOP performance makes it a competitive replacement for enterprise HDD solutions.
In addition, as a NAND supplier, we’re able to leverage our renowned NAND design
expertise to build the best finished solution. When you buy a Micron SSD, you’re
buying from a NAND manufacturer who has direct control over the NAND design,
controller firmware, assembly, testing, and supply chain. This vertical integration delivers
quality control and design optimization that are unmatched by other SSD competitors—
you get the best that our product innovations, test and compatibility tools, and integrated
support structure have to offer.
P400e
1
Capacity
Interface
Sequential READ/WRITE up to 350/140 MB/s
Random READ/WRITE up to 50,000/7,000 IOPs
Active Average Power
Consumption
Idle Power Consumption 0.95W (Max)
Operating Shock 1500G/0.5ms
Operating Vibration 5–500Hz at 3.1G
MTBF 1.2 million device hours
Endurance
(Lifetime Data Written)
Operating Temp Commercial (0˚C to +70˚C)
Form Factor 2.5”
Weight <100g
1
Unformatted. 1GB = 1 billion bytes. Formatted capacity is less. 2Data taken at 25°C using a 6 Gb/s SATA interface.
2
50GB, 100GB, 200GB, 400GB
SATA 6 Gb/s;
backward-compatible to SATA 3 Gb/s
2.5W for 50GB, up to 5W for 400GB
up to 87.5TB for 50GB;
up to 175TB for 100GB, 200GB, and 400GB
P400e Advantages for Enterprise Applications
Performance
• Fast boot and application load times. Delivers superior performance over HDD and
other entry-level SSDs.
Durability and Endurance
• SSD durability and reliability with enterprise-focused endurance specifications for
long drive life.
Enterprise Data Path Protection
• Multiple error-correction checkpoints ensure that your data is protected throughout
the data path.
Compatibility
• Complies with SATA 6 Gb/s, making it an easy-to-adopt, drop-in HDD replacement,
which increases design flexibility and speeds time-to-market.
Low Power
• Consumes significantly less power than a typical enterprise HDD and requires almost
zero cooling.
NAND Expertise
• Leverages Micron’s proven quality and test capabilities to provide best-in-class
drive reliability.
Integrated Systems Testing
• Every RealSSD is tested extensively; test results are used to tailor and optimize
future designs.
Ideal for Use in Applications That Require:
•
High read workloads
•
Fast data recovery
•
Data integrity
•
Data reliability
•
Enterprise endurance
Typical Applications:
•
Application loading
•
Read caching
Part Density Size*
MTFDDAK050MAR-1J1AA
MTFDDAK100MAR-1J1AA
MTFDDAK200MAR-1K1AA
MTFDDAK400MAR-1K1AA 400GB
*Package height in millimeters.
100GB
200GB
50GB
•
OS loading for enterprise storage
•
Multi-threaded read workloads
Sequential
READ/WRITE
(MAX)
350/100MB/s
350/140MB/s
350/140MB/s
2.5“
(7mm)
2.5“
(7mm)
2.5“
(7mm)
2.5“
(7mm)
Voltage
5V
5V
5V
5V 350/140MB/s
Random
READ/WRITE
(MAX)
50,000/
7,000 IOPs
50,000/
7,000 IOPs
50,000/
7,000 IOPs
50,000/
7,000 IOPs
P400e Enterprise SSDs
Micron Start-to-Finish SSD
Manufacturing and Design
Integrated Systems Testing
• Every RealSSD is tested extensively;
test results are used to tailor and
optimize future designs.
Finished RealSSD Drives
• Unmatched performance
• Proven reliability
• Rigorous quality
Industry-Leading NAND Die
• Every NAND die is tested for performance
and quality.
Validated NAND Packages
• Rigorous quality and performance tests
ensure optimal reliability.
SSD P400e Part Numbering
MT FD D AK xxx M AR - 1 J 1 AA ES
Micron Technology
Flash Drive (SSD)
Drive Interface
D = SATA 6.0 Gb/s
Drive Form Factor
AK = 2.5-inch (7mm high)
Drive Density
050 = 50GB
100 = 100GB
200 = 200GB
400 = 400GB
NAND Type
M = MLC
AR = P400e
Production Status
Blank = Production
ES = Engineering sample
MS = Mechanical sample
Operating Temperature Range
Blank = Commercial (0˚C to +70˚C)
Hardware Feature Set
AA = Temperature-sensor-enabled
1 = 1st generation
BOM Revision
NAND Flash Component
J = 25nm 32Gb MLC
K = 25nm 64Gb MLC
Sector SizeProduct Family
1 = 512-byte
P400e Enterprise SSDs
Micron Delivers... You Benet By...
Worldwide leadership in
NAND Flash memory
Worldwide technical support
and factory engineering teams
A proven quality record
Controlled SSD BOM with
PCN notifications
Extensive testing
Utilizing steady product supply to meet
operational objectives and customer demand
Employing a network of experienced talent
dedicated to solving problems and delivering
customer solutions
Lowering product failure rates while increasing
marketability and brand reputation
Easy supply chain management and planning
Predictably reliable high-quality drives that
work with your platform
micron.com/ssd
8000 S. Federal Way • Boise, ID 83707 USA • (208) 368-3900
©2011 Micron Technology, Inc. All rights reserved. Micron, the Micron logo, and RealSSD are trademarks of Micron Technology,
Inc. All other trademarks are the property of their respective owners. Products are warranted only to meet Micron’s production
data sheet specifications. Products and specifications are subject to change without notice. Rev. 9/11 EN.L
