1.1 About this document
This document provides information about how to install, commission, and proof test a
4200 transmitter to comply with Safety Instrumented Systems (SIS) requirements.
Important
This manual assumes that:
• The transmitter has been installed correctly and completely according to the
instructions in the transmitter installation manual
• Users understand basic transmitter and sensor installation, configuration, and
maintenance concepts and procedures
1.2 Hazard messages
This document uses the following criteria for hazard messages based on ANSI standards
Z535.6-2011 (R2017).
DANGER
Serious injury or death will occur if a hazardous situation is not avoided.
WARNING
Serious injury or death could occur if a hazardous situation is not avoided.
CAUTION
Minor or moderate injury will or could occur if a hazardous situation is not avoided.
NOTICE
Data loss, property damage, hardware damage, or software damage can occur if a
situation is not avoided. There is no credible risk of physical injury.
Physical access
NOTICE
Unauthorized personnel can potentially cause significant damage and/or misconfiguration
of end users' equipment. Protect against all intentional or unintentional unauthorized use.
Physical security is an important part of any security program and fundamental to
protecting your system. Restrict physical access to protect users' assets. This is true for all
systems used within the facility.
Safety Manual for Safety Instrumented Systems (SIS) 5
Before you begin Safety Manual
August 2021 MMI- 20049802
1.3 Related documentation
See the approval documentation shipped with the transmitter, or download the
appropriate documentation from www.emerson.com:
• Micro Motion 4200 2-Wire Transmitter: Installation Manual
• Micro Motion 4200 2-Wire Transmitter: Configuration and Use Manual
• Micro Motion 4200 2-Wire Transmitter: Product Data Sheet
• Micro Motion ProLink III with ProcessViz Software User Manual
• Sensor installation manual, which is shipped with the sensor
• FMEDA report for Coriolis Flow Meter with 4200 Transmitter, prepared for Emerson by
exida.com LLC
6 Micro Motion 4200 2-Wire Transmitters
Safety Manual Installation and commissioning
MMI- 20049802 August 2021
2 Installation and commissioning
Use this section to install and commission a Coriolis flow meter with a 4200 transmitter
with SIS features.
IEC 61508 relevant requirements
The 4200 is certified per the relevant requirements of IEC 61508.
Systematic capability Safety Integrity Level (SIL) 3 capable
Random capability
Failure rates according to IEC 61508 in FIT
Device λ
4200 integral mount transmitter and 4200C 9-wire
remote mount transmitter
• Type B element
• SIL 2 capable @ HFT=0 (single meter)
• SIL 3 capable @ HFT=1 (multiple meters)
(1)
SD
0 152 2130 76
λ
SU
λ
DD
λ
DU
SIS-certified versions
Emerson maintains an SIS-compliant modification process. Changes made after initial
release do not affect overall SIS certification.
Version information is available from the display at About → Versions.
Table 2-1: SIS-certified versions for a 4200
Device Display tag Version
4200 firmware Core Processor 1.0 and later
4200 hardware Transmitter hardware 0 and later
On SIS applications for a 4200 with intrinsically safe outputs, the Channel A mA Output is
used for the safety critical variable (mass flow, volume flow, or density). The SIS features
are enabled through licensing. While other output channels can be licensed, they are
outside the scope of SIS usage.
Safety precautions
Prior to making any changes to the 4200, such as changing the configuration, upgrading
the firmware, replacing the transmitter hardware or sensor:
• Take appropriate action to avoid a false trip by electronically bypassing the safety
Programmable Logic Controller (PLC).
Important
Ensure alternate means are in place to maintain the process in a safe state.
9
(1) FIT = 1 failure / 10
Safety Manual for Safety Instrumented Systems (SIS) 7
hours
A
1
2
D
C
B
Installation and commissioning Safety Manual
August 2021 MMI- 20049802
• Prior to placing the meter online and removing the bypass from the safety PLC, verify
the transmitter configuration and all safety parameters.
2.1 Set up the 4200
Use this section to make sure the 4200 is installed and configured for SIS applications.
You can use ProLink III, the display, or a field communicator to verify, or if needed,
configure these settings. For more information, see the Micro Motion 4200 2-Wire
Transmitter: Configuration and Use Manual.
The sensor does not require special installation in addition to the standard installation
procedures in the sensor installation manual.
Procedure
1. Use the Micro Motion 4200 2-Wire Transmitter: Installation Manual to mount the
transmitter and install the sensor wiring.
2. Wire the Channel A passive (external) power to the appropriate output terminal and
pins.
Figure 2-1: Channel A mA/HART output wiring (externally powered)
A. mA HART output
B. Supply Voltage (see the following figure.)
C. Loop Resistance (see the following figure for maximum loop resistance.)
D. Input device
8 Micro Motion 4200 2-Wire Transmitters
Safety Manual Installation and commissioning
MMI- 20049802 August 2021
Figure 2-2: Channel A output supply voltage and loop resistance
A. Loop resistance (Ohms)
B. Supply voltage (Vs)
C. Maximum Loop Resistance (Ohms)
3. Verify that the following features are licensed: SIL and ChA.
Note
If SIL is not licensed, see Install the SIL license key.
4. Verify all safety parameters:
a) Verify that all appropriate flow and density calibration parameters are set
(FCF, K1, K2, D1, D2, and DT).
b) Verify that the Lower Range Value (LRV) and the Upper Range Value (URV)
for Channel A mA Output 1 is configured.
c) Verify that the appropriate measurement units are configured (mass flow,
volume flow, density, and temperature).
d) Verify that the HART Primary Variable (PV) is assigned to Channel A mA
Output.
e) Verify that the appropriate low flow cutoff parameter is configured.
f) Verify that the appropriate damping values are configured - such as flow,
density, temperature, and added damping.
g) Verify that the mA Output Fault Action is set to Upscale or Downscale.
Safety Manual for Safety Instrumented Systems (SIS) 9
Installation and commissioning Safety Manual
August 2021 MMI- 20049802
2.2 Diagnostics for a 4200
The SIL license enables a mA Output to internal mA Readback comparison diagnostic.
If the difference between the programmed mA Output and the actual internal mA
Readback exceeds 0.2 mA, an Electronics Failed alert becomes active and all analog
outputs will be turned off (outputs all to 3.6 mA fault state) within 5 minutes. The alert
shows up as:
On the display as: Verification of mAO1 Failed
On ProLink III as: mAO Verification Failed
After 5 minutes, the outputs are turned back on, and the mA Output to internal mA
Readback comparison check is performed again. If the alert was due to a transient
condition, since cleared, the transmitter will resume normal operations. If the alert was
due to a component failure, the alert will remain active and the outputs will turn off again.
Note
The mA Output to mA Readback comparison diagnostic is disabled for the first 5 minutes
after the transmitter is powered up. This allows time to verify correct wiring and operation
of the ChA mA Output with internal mA Readback.
2.2.1
Enable or disable software write protection
When enabled, write protection prevents changes to the transmitter configuration. You
can perform all other functions, and you can view the transmitter configuration
parameters.
Write protection is enabled by toggling the physical write protect (dip) switch (identified
by a lock icon) located behind the display module.
Figure 2-3: Write protect (dip) switch behind the display module
10 Micro Motion 4200 2-Wire Transmitters
Safety Manual Installation and commissioning
MMI- 20049802 August 2021
Figure 2-4: Write protect on the display (upper right corner)
You cannot change write protection from any host configuration tool.
Note
Write protecting the transmitter primarily prevents accidental changes to configuration,
not intentional changes. Any user who can change the switch can disable write protection.
2.3 Update the firmware
If you need to update the firmware, contact customer service.
2.4 Replace equipment
If you need to replace hardware, purchase all spare parts from Emerson.
You cannot use user-supplied components on any Emerson printed circuit assemblies.
Procedure
1. Replace the hardware.
2. Verify the transmitter configuration and all safety parameters.
3. Enable write protection.
2.5 Install the SIL license key
Use this procedure if the license key was purchased after shipment.
Important
If you added a SIL license key to a meter that was originally installed for a different
function, note that the expected meter lifetime starts at the time of the original
installation and commissioning. Meter lifetime and all SIS calculations should include total
meter operational time.
Always perform Proof tests before placing the meter online.
Safety Manual for Safety Instrumented Systems (SIS) 11
Installation and commissioning Safety Manual
August 2021 MMI- 20049802
Prerequisites
Obtain the SIL license key from your local service office by requesting the model code:
LICKEY4200SI.
Note
After you obtain the license key, manually enter the license key using the display, ProLink
III, or a field communicator.
Procedure
1. To install a license using the display:
a) Choose Menu → Service Tools → License Manager.
Depending on the type of license key provided, choose either Enter
Permanent License or Enter Trial License
b) Use the arrow keys to enter the license key.
2. To install a license using ProLink III:
a) Open the license file.
b) Choose Device Tools → Configuration → Feature License.
c) Copy the license from the file to the appropriate License Key field.
d) Select Apply.
3. To install a license using a field communicator:
a) Choose Overview → Device Information → Licenses → Upload License.
b) Select the license feature to upload, Permanent Feature or Temporary
Feature.
c) Write the license key.
4. Use the following menu structures to verify that the license has been installed.
Display
ProLink III Device Tools → Configuration → Feature License
Field
communicator
Menu → Service Tools → License Manager
Overview → Device Information → Licenses
The features supported by the new license are displayed.
12 Micro Motion 4200 2-Wire Transmitters
Safety Manual Proof tests
MMI- 20049802 August 2021
3 Proof tests
Proof tests detect transmitter failures that are not detected by transmitter diagnostics —
mainly undetected failures that prevent the Safety Instrumented Function from
performing correctly.
The frequency of proof testing, or the proof test interval, is determined by reliability
calculations for your transmitter model's Safety Instrumented Functions.
The proof tests must be performed at least as frequently as specified in the calculation to
maintain the required Safety Instrumented Function integrity.
3.1 Proof test options
The Coriolis flow meter with a 4200 transmitter has two proof tests you can use to detect
failures.
Proof tests can be performed using the display, ProLink III, or a field communicator.
Table 3-1: Proof test options
Proof test Description DU failure detection
1 • mA Output min-to-max test
• Checking for alarms
• Checking configuration
• Smart Meter Verification (SMV)
• Verification of onboard
temperature measurement
• Test for soft errors in RAM
1 and 2 • mA Output min-to-max test
• Checking for alarms
• Checking configuration
• SMV
• Verification of onboard
temperature measurement
• Test for soft errors in RAM
• Calibration against primary
standard
46%
99%
Safety Manual for Safety Instrumented Systems (SIS) 13
Proof tests Safety Manual
August 2021 MMI- 20049802
3.2 Proof test 1
Proof test 1 is recommended for a SIL-approved 4200 with either the integrated core
processor or the enhanced core processor.
Prerequisites
This procedure assumes that you are familiar with plant procedures.
Procedure
1. Take appropriate action to avoid a false trip by electronically bypassing the safety
Programmable Logic Controller (PLC).
Important
Ensure alternate means are in place to maintain the process in a safe state.
Example
Use Management of Change procedures to override the safety PLC function.
2. Disable write-protection.
3. Using an external device such as a fluke meter, test the mA Output by setting each
mA Output to the Fault Level specified for Upscale. Verify that the mA current
reaches that value, or use the default value (22mA).
This step tests for compliance voltage problems, such as low voltage on the loop
power supply, or increased wiring resistance.
4. Using an external device such as a fluke meter, test the mA Output by setting each
mA Output to the Fault Level specified for Downscale – 3.6 mA. Verify that the mA
current reaches that value, or use the default value: 4-20mA.
This step tests for possible failures related to quiescent current.
5. Read the sensor temperature value. Compare it to the process temperature, and
verify that this is a reasonable reading.
6. Power cycle the transmitter. Wait approximately 30 seconds for the flow meter to
return to normal operation.
7. Run an SMV test by using the Micro Motion 4200 2-Wire Transmitter: Configuration
and Use Manual.
8. Verify that the transmitter does not display alarms or warnings.
9. Verify all safety-critical configuration parameters.
10. Restore the loop to full operation.
11. Enable write-protection.
12. Remove the bypass from the safety PLC, or otherwise restore normal operation.
13. Document the results of this proof test as part of your plant safety management
procedures.
14 Micro Motion 4200 2-Wire Transmitters
Safety Manual Proof tests
MMI- 20049802 August 2021
3.3 Proof test 2
Proof test 2 is recommended for all SIL-approved 4200s.
Procedure
Perform a full calibration against a primary standard.
Note
The meter verification procedure and the onboard temperature verification tests are
incorporated into a full calibration.
Safety Manual for Safety Instrumented Systems (SIS) 15
Proof tests Safety Manual
August 2021 MMI- 20049802
16 Micro Motion 4200 2-Wire Transmitters
Safety Manual Operating constraints
MMI- 20049802 August 2021
4 Operating constraints
4.1 Reliability data
The 4200 transmitter:
• Has a specified safety deviation of 2%. Internal component failures are listed in the
device failure rate if they will cause an error of 2% or greater.
• Reports an internal failure within 5 minutes of fault occurrence – worst case scenario.
• Generates a valid signal within 30 seconds of a power-on startup.
FMEDA report
The Failure Mode, Effects, and Diagnostics Analysis (FMEDA) report is used to calculate the
failure rate. A FMEDA report for a 4200 transmitter contains:
• All failure rates and failure modes
• Common cause factors for applications with redundant devices that should be included
in reliability calculations
• The expected lifetime of your flow meter and transmitter, as the reliability calculations
are valid only for the lifetime of the equipment; useful flow meter lifetime is 50 years —
see the FMEDA report for details
Obtain a FMEDA report from www.emerson.com.
Environmental and application limits
See the sensor and 4200 product data sheets for environmental and application limits.
Using the 4200 transmitter outside environmental or application limits invalidates the
reliability data in the FMEDA report.
4.2 Report failures
Procedure
If you have detected any failures that compromise safety, contact the Emerson product
safety officer.
Contact the product safety officer through customer service. Customer service is available
24 hours a day, seven days a week. Contact information is located at the front of this
manual.
Safety Manual for Safety Instrumented Systems (SIS) 17
*MMI- 20049802 *
MMI- 20049802
Rev. AB
2021
For more information:
©
2021 Micro Motion, Inc. All rights reserved.
The Emerson logo is a trademark and service mark of Emerson
Electric Co. Micro Motion, ELITE, ProLink, MVD and MVD Direct
Connect marks are marks of one of the Emerson Automation
Solutions family of companies. All other marks are property of
their respective owners.
www.emerson.com
Loading...
