Micro Motion® Modbus Interface Tool
Slots and Slot Address Sequences
SA 1 Overview
Slots provide a way to read non-consecutive registers using one read command. When a slot address
sequence (a set of consecutive slots) has been configured, the transmitter automatically replicates
real-time data from non-consecutive addresses into the consecutive addresses of the slots. Without
slots, multiple read commands must be issued to read the non-consecutive addresses; with slots, only
one read command is required.
There are 64 slots: 32 slots used for sets of addresses (Slot Type 1) and 32 slots used for sets of
process variables (Slot Type 2). Each slot has a pre-assigned configuration register (integer) and a
corresponding value register pair. The configuration registers are read-write; the value register pairs
may be read-write or read-only.
For Slot Type 1:
• The configuration register stores a Modbus address. The address specifies the first register of
any two consecutive registers (Registers X and X+1) in the Modbus memory map. These
registers may contain boolean, integer, floating-point, ASCII, or binary data.
• The first register of the value register pair stores the real-time value of Register X, and the
second register stores the real-time value of Register X+1. Depending on the particular
registers specified, the second register may or may not contain useful data.
For Slot Type 2:
• The configuration register stores a process variable code.
• The value register pair stores the real-time value of the assigned process variable. Depending
on the data type of the process variable, the second register may or may not contain useful
data.
See Table SA-1 for a list of the 64 slots and their associated configuration registers and value register
pairs.
Section SA-2 provides instructions for configuring slot address sequences.
Section SA-3 provides instructions for reading slot address sequences.
Section SA-4 provides instructions for using long integers in slot address sequences.
Section SA-5 provides instructions for using binary (double-precision) values in slot address
sequences.
Section SA-6 provides detailed examples of slot address sequence setup and use.
Slots and Slot Address Sequences
Table SA-1 Slot address registers
Slot Type 1 Slot Type 2
Address of
Slot
0 655 687 688 751 783 784
1 656 689 690 752 785 786
2 657 691 692 753 787 788
3 658 693 694 754 789 790
4 659 695 696 755 791 792
5 660 697 698 756 793 794
6 661 699 700 757 795 796
7 662 701 702 758 797 798
8 663 703 704 759 799 800
9 664 705 706 760 801 802
10 665 707 708 761 803 804
11 666 709 710 762 805 806
12 667 711 712 763 807 808
13 668 713 714 764 809 810
14 669 715 716 765 811 812
15 670 717 718 766 813 814
16 671 719 720 767 815 816
17 672 721 722 768 817 818
18 673 723 724 769 819 820
19 674 725 726 770 821 822
20 675 727 728 771 823 824
21 676 729 730 772 825 826
22 677 731 732 773 827 828
23 678 733 734 774 829 830
24 679 735 736 775 831 832
25 680 737 738 776 833 834
26 681 739 740 777 835 836
27 682 741 742 778 837 838
28 683 743 744 779 839 840
29 684 745 746 780 841 842
30 685 747 748 781 843 844
31 686 749 750 782 845 846
configuration register
Address of value
1
register pair
Address of
configuration register
Address of value
2
register pair
(1) Contains a Modbus address.
(2) Contains a process variable code.
2 Micro Motion® Modbus Interface Tool
Slots and Slot Address Sequences
SA 2 Configuring slot address sequences
To configure a slot address sequence of Slot Type 1:
1. Determine the values that the read command will return, and the order in which they will be
returned.
For example, you might want to read volume flow rate and the volume flow unit.
2. Identify the addresses containing these values.
Volume flow rate is stored in register pair 253–254, and the volume flow unit is stored in
register 42.
3. Determine the slots to be used in the slot address sequence. Each value that the read command
will return requires a separate slot.
To read volume flow rate and the volume flow unit, you need two consecutive slots, e.g., Slot 0
and Slot 1.
4. Write the address of the first value, minus 1, to the configuration register of the first slot in the
sequence. See Table SA-1.
Write the value 252 to register 655. The contents of register 253 will be replicated in register
687, and the contents of register 254 will be replicated automatically in register 688.
5. Write the address of the second value, minus 1, to the configuration register of the second slot
in the sequence. See Table SA-1.
Write the value 41 to register 656. The contents of register 42 will be replicated in register 689.
Additionally, the contents of register 43 will be replicated automatically in register 690, and
register 690 will be read automatically. The host program must ignore the value from register
690.
6. Continue specifying register pairs in consecutive slots until all required values been
configured.
To configure a slot address sequence of Slot Type 2:
1. Determine the process variables that the read command will return, and the order in which
they will be returned. See the Integer Codes list in the Modbus Interface Tool for information
on process variables that can be assigned to slot addresses.
For example, you might want to read volume flow rate and volume total.
2. Identify the integer codes for the process variables.
The integer code for volume flow rate is 5; the integer code for volume total is 6.
3. Determine the slots to be used in the slot address sequence. Each value that the read command
will return requires a separate slot.
To read volume flow rate and volume total, you need two consecutive slots, e.g., Slot 2 and
Slot 3.
4. Write the integer code of the first process variable to the configuration register of the first slot
in the sequence. See Table SA-1.
Write the value 5 to register 753. A floating-point value representing volume flow rate will be
stored in registers 787–788.
Micro Motion® Modbus Interface Tool 3
Slots and Slot Address Sequences
5. Write the address of the second value to the configuration register of the second slot in the
sequence. See Table SA-1.
Write the value 6 to register 754. A floating-point value representing volume total will be
stored in registers 789–790.
6. Continue specifying integer codes in consecutive slots until all required values been
configured.
SA 3 Reading slot address sequences
Refer to Table SA-1 and issue a read command that identifies the first value register in the sequence
and the number of registers to be read.
Note: When reading a slot address sequence, be sure to specify the value register pairs, not the
configuration registers, and be sure to process or ignore the value in the second register of the value
register pair, as appropriate.
SA 4 Long integers in slot address sequences
To include a long integer value in a slot address sequence, configure all registers that contain the long
integer value. Be sure to add them to the slot address sequence in the order you want to read them.
When reading the slot address sequence, the host program must be able to interpret and concatenate
the returned values as required.
SA 5 Binary (double-precision) values in slot address sequences
Several process variable codes are used in pairs to return double-precision values. These pairs include:
• 34 and 35
• 36 and 37
• 38 and 39
• 40 and 41
• 42 and 43
• 44 and 45
– used to return mass total
– used to return volume total
– used to return temperature-corrected volume total
– used to return standard volume total
– used to return net mass total
– used to return net volume total
To include a double-precision value in a slot address sequence, two slots are required. Configure the
first slot for the first process variable code, and configure the second slot for the second process
variable code. For example, to return mass total as a double-precision value, write 34 to the
configuration register of the first slot, and write 35 to the configuration register of the second slot.
When you read the first value register pair, the first register will contain Word 0 and the second
register will contain Word 1. When you read the second value register pair, the first register will
contain Word 2 and the second register will contain Word 3. The returned values are in a special,
non-standard, 8-byte floating point format.
Note: For MVD Direct Connect or Series 1000, Series 2000, or Series 3000 transmitters, byte order in
floating-point registers is configurable. Binary totals are not affected by byte order.
4 Micro Motion® Modbus Interface Tool
Slots and Slot Address Sequences
M Wor d 1 65536×()Word2+()65536×[]Word3+=
TotalFlow M 2
P47–()
×=
M 30140 65536×()53586+()65536×[]0+=
M 1.2945383
14
×10=
To t a l F low 1.294538314×10 2
27 47–()
×=
To t a l F low 1.2945383
14
×10 2
20–()
×=
To t a l F low 1.2945383
14
×10 9.53674327–×10×=
To t a l F low 123 456 789.125,,=
To convert the binary code to the total value, follow the steps below.
1. Calculate M:
2. Set P = Word 0.
3. Calculate as follows:
4. If you are reading mass total (codes 34 and 35), this value represents mass total in grams. If
you are reading volume total (codes 36 and 37), this value represents volume total in cubic
centimeters.
Note: Both M and P are twos complement notation. If you are working with negative values (i.e.,
reverse flow), adjust this method as required.
Example Reading binary totals
Reading the slot addresses returns the following values:
• Word 0 = 001B (decimal value: 27)
• Word 1 = 75BC (decimal value: 30140)
• Word 2 = D152 (decimal value: 53586)
• Word 3 = 0000 (decimal value: 0)
Calculate M:
P = 27.
Calculate total flow:
Micro Motion® Modbus Interface Tool 5
Slots and Slot Address Sequences
SA 6 Slot address examples
Example 1 Slot address sequence – Slot Type 1 (addresses)
Several times per day, the operator needs to read the following:
• Floating-point volume flow rate
• Volume flow unit
• Floating-point process density
•Density unit
The volume flow unit is gal/min (integer code 16). The density unit is
3
g/cm
(integer code 91).
Configure a slot address sequence so the operator can read the
required values by issuing a single read command. Slots 0 through 3
will be used.
1. Write the integer value 252 to register 655. The value represents
register pair 253–254, which stores the volume flow rate.
2. Write the integer value 41 to register 656. The value represents
register pair 42–43. Register 42 stores the volume flow unit. You
must ignore the value stored in register 43.
3. Write the integer value 248 to register 657. The value represents
register pair 249–250, which stores the process density.
4. Write the integer value 39 to register 658. The value represents
register pair 40–41. Register 40 stores the density unit. You must
ignore the value stored in register 41.
If the operator reads register pairs 687–688 through 693–694, the
transmitter returns a series of values similar to the following:
23.038 16 6 1.091 91 33
(Volume flow
rate)
(Volume flow unit plus
next register)
(Process
density)
(Density unit plus next
register)
6 Micro Motion® Modbus Interface Tool
Slots and Slot Address Sequences
Example 2 Slot address sequence – Slot Type 2 (process variables)
Several times per day, the operator needs to read the following:
• Temperature in degrees Fahrenheit
• Volume flow rate in gallons/minute
• Drive gain in milliamps
• Left pickoff voltage in millivolts
• Right pickoff voltage in millivolts
Configure a slot address sequence so the operator can read the
required values by issuing a single read command. Slots 4 through 8
will be used.
1. Write the integer value 1 to register 755. The value represents the
integer code for temperature.
2. Write the integer value 5 to register 756. The value represents the
integer code for volume flow.
3. Write the integer value 47 to register 757. The value represents the
integer code for drive gain.
4. Write the integer 49 to register 758. The value represents the
integer codes for left pickoff voltage.
5. Write the integer code 50 to register 759. The value represents the
integer code for the right pickoff voltage.
If the operator reads register pairs 791–792 to 799–800, the transmitter
returns a series of values similar to the following:
60.09 23.038 7.009 17087.05 17087.02
(Temperature) (Volume
flow rate)
(Drive gain) (Left pickoff) (Right pickoff)
Each of these values is returned using the unit that has been
configured for the process variable. This example assumes that the
required units (as listed above) have already been configured.
Micro Motion® Modbus Interface Tool 7
©2008, Micro Motion, Inc. All righ ts reserved. P/N MMI-20011357, Rev. A
*MMI-20011357*
Loading...
