Wiring Supplement

P/N MMI-20015706, Rev. AA
September 2009

Micro Motion® Model 775

Smart Wireless Integral-Mount THUM™ Adapter

Contents

THUM Adapter overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 3

Installation considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 4

Locating the THUM Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 4

THUM Adapter wiring requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 5

Wiring the integral-mount THUM Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 6

Post-installation and configuration of the THUM Adapter . . . . . . . . . . . . . . . . .page 7

About this supplement

The Micro Motion

®

Model 775: Smart Wireless Integral-Mount THUM™ Adapter Wiring Supplement provides

detailed information on wiring the integral-mount THUM Adapter wireless device to your Micro Motion
meter. This supplement is not a comprehensive guide for the Smart Wireless THUM Adapter device.

For additional information on installing and configuring the Smart Wireless THUM Adapter, refer to the

Smart Wireless THUM

™

Adapter Quick Installation Guide or Smart Wireless THUM™ Adapter Reference

Manual also available on the Micro Motion Product Documentation CD or at www.micromotion.com.

For more information on installing and configuring your Micro Motion meter, see the Micro Motion Product
Documentation CD for the appropriate product manual.

Safety and approval information

This Micro Motion product complies with all applicable European directives when properly installed in
accordance with the instructions in this manual. Refer to the EC declaration of conformity for directives that
apply to this product. The EC declaration of conformity, with all applicable European directives, and the
complete ATEX Installation Drawings and Instructions are available on the internet at
www.micromotion.com/atex or through your local Micro Motion support center.

For hazardous installations in Europe, refer to standard EN60079-14 if national standards do not apply.

Micro Motion customer service

For customer service, phone the support center nearest you:

• In the U.S.A., phone

800-522-MASS (800-522-6277) (toll-free)

• In Canada and Latin America, phone [phone]

•In Asia:

- In Japan, phone [phone]

- In other locations, phone [phone] (Singapore)

• In Europe:

- In the U.K., phone [phone] (toll-free)

- In other locations, phone [phone] (The Netherlands)

Customers outside the U.S.A. can also email Micro Motion customer service at [e-mail].

© 2009 Micro Motion, Inc. All rights reserved.

The Micro Motion and Emerson logos are trademarks and service marks of Emerson Electric Co. Micro Motion, ELITE, MVD,
ProLink, MVD Direct Connect, and PlantWeb are marks of one of the Emerson Process Management family of companies. All
other trademarks are property of their respective owners.

THUM Adapter overview

MICRO MOTION INC MIC

RO MOTI

ON INC

MODEL S/N MODEL S/

N

Smart Wireless THUM Adapter

Transmitter housing

Transmitter cover removed

Terminal block connectors

Smart Wireless
THUM Adapter

Transmitter housing

Transmitter cover removed

Terminal block
connectors

The Smart Wireless THUM™ Adapter acts as an extension of the HART function of the primary mA output
on your Micro Motion transmitter. It broadcasts HART data from the transmitter to the Wireless HART

™

network. The THUM Adapter can be used with any Micro Motion transmitter that supports HART over the
primary mA output. The Smart Wireless THUM Adapter is shipped integrally mounted to the Micro Motion
transmitter.

The THUM Adapter is installed using an approved thread sealant and secured to a torque value of 30–35
ft-lbs. Figure 1 shows an integrally mounted THUM adapter installed in a Model 2700 transmitter. Figure 2
shows an integrally mounted THUM adapter installed in a Model 2200S transmitter.

Figure 1 Integral-mount THUM Adapter components (Model 2700)

Figure 2 Integral-mount THUM Adapter components (Model 2200S)

Micro Motion Model 775 Wiring Supplement 3
