Technical Data Sheet
PS-001864, Rev E
Micro Motion® F-Series Coriolis Flow and
Density Meters
January 2019
F-Series Coriolis Flow and Density Meters January 2019
Detailed specifications
F-Series flow and density accuracy options
Liquid mass flow accuracy Gas mass
flow accuracy
0.20% 0.15% 0.10% 0.5% 0.002 0.001 0.0005
F025 • • • • • •
F050 • • • • • • •
F100 • • • • • • •
F200 • • • • • • •
F300 • • • • • • •
Note
High temperature and high pressure models (base model codes A, B, and P, for example, F050A) are not capable of enhanced
density accuracy of 0.0005 g/cm³ (0.5 kg/m³).
Density accuracy (g/cm3 )
Flow tube information
Model
F025 2 0.21 5.3 14.6 370
F050 2 0.35 8.8 18.8 478
Number of tubes Tube inside
diameter inches
Tube inside
diameter mm
Tube lengthinches Tube lengthmm
F100 2 0.65 16 25.1 637
F200 2 1.1 27 23.5 598
F300 2 1.6 40 34.4 874
ASME B16.5 specification flange compatibility
Model
F025 • • •
F050 • • •
F100 • • •
F200 • • •
F300 • •
1/2” 3/4” 1” 1-1/2” 2” 3” 4”
DIN specification flange compatibility
Model
F025 •
DN15 DN25 DN40 DN50 DN80 DN100
2 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Model DN15 DN25 DN40 DN50 DN80 DN100
F050 • •
F100 •
F200 • •
F300 • •
EN1092-1 specification flange compatibility
Model DN15 DN25 DN40 DN50 DN80 DN100
F025 • •
F050 • •
F100 •
F200 • •
F300 • •
JIS B 2220 specification flange compatibility
Note
Sensors with JIS process connections do not meet ASME B31.1 power piping code.
Model
F025 •
F050 •
F100 •
F200 • •
F300 • •
15mm 25mm 40mm 50mm 80mm 100mm
VCO/VCR specification flange compatibility and Tri-clamp compatible flanges
Model
F025 • • • •
F050 • • • •
F100 • •
VCO specification Tri-clamp compatible
#4 #8 #12 #16 1/2” 3/4” 1” 1-1/2” 2” 3”
F200 • •
F300 •
www.emerson.com 3
F-Series Coriolis Flow and Density Meters January 2019
Namur NE132 compliant flanges
Model DN15 DN25 DN50 DN80 DN100
F025 •
F050 • •
F100 •
F200 •
F300 • •
Transmitter compatibility
Sensor model Transmitter model or series
1500/2500 1700/2700 2200S 2400S 3000 series FMT 5700
All F-Series
models
• • • • • F025, F050,
F100
•
Process pressure ratings
Sensor maximum working pressure reflects the highest possible pressure rating for a given sensor. Process connection type and
environmental and process fluid temperatures may reduce the maximum rating. Refer to the Technical Data Sheet for common
sensor and fitting combinations.
All sensors comply with Council Directive 2014/68/EU on pressure equipment.
Note
F-Series sensors with JIS process connections do not comply with ASME B31.1 power piping code.
Sensor maximum working pressure for all models: 316L stainless steel (S/A), nickel alloy C22 (H/B), and high
pressure (P)
(1)
Model
F025S/A, F050S/A, F100S/A, F200S, F300S 1,450 psig (100 barg)
F025H/B, F050H/B, F100H/B, F200H, F300H 2,160 psig (149 barg)
F025P 2,320 psig (160 barg)
F050P 5,800 psig (400 barg)
Pressure
F100P 6,250 psig (431 barg)
Higher pressure ratings may be available. Contact factory for further information.
(1)
4 www.emerson.com
720 720
620
560
515
1440 1440
1240
1120
1025
1440
1363
600
800
1000
1200
1400
1600
Pressure (psi)
CL900
CL300
CL600
275
275
235
215
195
0
200
400
-200 -100 0 100 200 300 400
Temperature (°F)
CL150
1450 1450 1450
1500 1500 1500 1500
1450 1450 1450 1450
1600
1600
1504
1450
1500
1550
1600
1650
Pressure (psi)
F200S
F050S
F025& F100S
1363
1410
1363
1350
1400
-200 -100 0 100 200 300 400
Temperature (°F)
January 2019
F-Series Coriolis Flow and Density Meters
Temperature and pressure de-ratings
Note
■
The ratings in this section apply to the combined sensor and process connection to ensure that the meter does not exceed the
limits of either component.
■
The temperature and pressure de-ratings graphs do not represent all possible model and fitting combinations. For
combinations not listed here, contact a sales representative or the factory.
F025S–F300S—ASME B16.5 F316/F316L
CL1500: F025S–F200S—ASME B16.5 F316/F316L
www.emerson.com 5
720 720
600
540
1440 1440
1200
1075
995
2160 2160
1800
1615
1490
1000
1500
2000
2500
Pressure (psi)
CL900
CL600
CL300
275
275
230
205
190
495
0
500
-200 -100 0 100 200 300 400
Temperature (°F)
CL150
3600
3600
3000
2690
2485
2850
2485
2600
2800
3000
3200
3400
3600
3800
Pressure (psi)
F200H
F025H
F050H
2683
2683
2683
2645
2400 2400 2400
2366
2283
2000
2200
2400
-200 -100 0 100 200 300 400
Temperature (°F)
F100H
F-Series Coriolis Flow and Density Meters January 2019
F025H–F300H—ASME B16.5 F304/F304L
CL900/1500: F025H–F200H—ASME B16.5 F304/F304L
6 www.emerson.com
720
620
560
515
480
450
439
1440
1240
1120
1025
955
900
881
1363
1285
1216
1185
600
800
1000
1200
1400
1600
Pressure (psi)
CL600
CL300
CL900/1500
275
235
215
195
170
140
121
0
200
400
-100 0 100 200 300 400 500 600 700
Temperature (°F)
CL150
720
600
540
495
465
440
428
1440
1200
1075
995
930
885
860
600
800
1000
1200
1400
1600
Pressure (psi)
CL600
CL300
275
230
205
190
170
140
121
0
200
400
-100 0 100 200 300 400 500 600 700
Temperature (°F)
CL150
January 2019 F-Series Coriolis Flow and Density Meters
F025A–F100A—ASME B16.5 F316/F316L
F025B–F100B—ASME B16.5 F304/F304L
www.emerson.com 7
3600
3000
2485
2330
2210
2148
2683
2645
2500
3000
3500
4000
Pressure (psi)
F025B
F050B
2400
2400
2366
2283
2224
2182
1500
2000
-100 0 100 200 300 400 500 600 700
Temperature (°F)
F100B
40
40 40
36
34
100
91
84
94
110
110
104
40
60
80
100
120
Pressure (Bar)
PN160: F200S
PN100/160: F025S-F100S
PN100: F300S
PN40: F025S-F300S
0
20
-150 -50 50 150 250
Temperature (°C)
F-Series Coriolis Flow and Density Meters January 2019
CL900/1500 F025B–F100B - ASME B16.5 F304/F304L
DIN 2635, 2637, 2638 F316/F316L
8 www.emerson.com
100
100 100
91
84
39 39
34
31
28
40
60
80
100
120
Pressure (Bar)
PN100
PN40
0
20
-150 -50 50 150 250
Temperature (°C)
40
40 40
36
34
32
30
29
100 100 100
91
84
80
74
71
40
60
80
100
120
Pressure (Bar)
PN100: F025A-F100A
PN40, F025A-F100A
39 39
34
31
28
26
24
23
0
20
-100 0 100 200 300 400
Temperature (°C)
PN40, F025B-F100B
January 2019 F-Series Coriolis Flow and Density Meters
EN 1092-1 F316/F316L and F304/304L
EN 1092-1 F316/F316L and F304/F304L
www.emerson.com 9
34 34 34
33
32
68
66
63
30
40
50
60
70
80
Pressur e (Bar)
40K
20K
141414
13
12
14
14
13
12
0
10
20
-150 -50 50 150 250
Temperature (°C)
10K
34 34 34
33
32
68 68 68
66
63
60
57
30
40
50
60
70
80
Pressur e (Bar)
40K: F025A-F100A
20K, F025A-F100A
14 14 14
13
12
11
10
30
29
0
10
20
-100 0 100 200 300 400
Temperature (°C)
10K, F025B-F100B
F-Series Coriolis Flow and Density Meters
JIS B 2220 F316/316L and F304/304L
January 2019
Note
Sensors with JIS process connections do not comply with ASME B31.1 power piping code.
JIS B 2220 F316/F316L and F304F/304L—High temperature
10 www.emerson.com
1450 1450 1450 1450
1363
1500 1500 1500
1479
1427
1100
1200
1300
1400
1500
1600
Pressur e (psi)
F025H-F100H
F025S-F100S
-
-
1000 1000 1000
986
951
800
900
1000
-200 -100 0 100 200 300 400
Temperature (°F)
F200S
F300S, F200H
F300H
1450 1450 1450 1450
1363
1500 1500 1500 1500
1410
900
1100
1300
1500
1700
Pressure (psi)
F050S
F025S,F100S
750 750 750 750
701
500
700
-200 -100 0 100 200 300 400
Temperature (°F)
3-INCH GROOVED COUPLING
January 2019 F-Series Coriolis Flow and Density Meters
Tri-Clamp compatible 316L and N06022
VCO/VCR 316/316L and 3-inch grooved coupling 316L
www.emerson.com 11
2320 2320
3700 3700
3571
4300
4300
4150
4600 4600
4439
2000
2500
3000
3500
4000
4500
5000
Pressure (psi)
VCO, F050P, #12
VCR, F050P #8
VCO/VCR, F025P
VCR, F050P #12
2181
500
1000
1500
-200 -100 0 100 200 300 400
Temperature (°F)
,
F-Series Coriolis Flow and Density Meters January 2019
VCO and VCR 316/316L—High pressure
12 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Hazardous area classifications
Detailed classifications
Note
All information and approvals may change depending on sensor/transmitter configurations and operating conditions. Please
reference appropriate certificates for exact approvals.
CSA and CSA C-US
Models F025, F050, F100, and F200 with junction box Ambient temperature: +140 °F max. (+60 °C max.)
Class I, Div. 1, Groups C and DClass I, Div. 2, Groups A, B, C, and
DClass II, Div. 1, Groups E, F, and G
All models with Model 2400S transmitter Ambient temperature: –40 to +140 °F (–40 to +60 °C)
Class I, Div. 2, Groups A, B, C, and DClass II, Div. 2, Groups F and
G
Models F025, F050, F100, and F200 with core processor, Model
2200S, or Model 1700/2700 transmitter
Models F300S and F300H with junction box Ambient temperature: +140 °F max. (+60 °C max.)
Models F300S and F300H with core processor, Model 2200S, or
Model 1700/2700 transmitter
All high-temperature models with junction box Ambient temperature: +140 °F max. (+60 °C max.)
IECEx
Models F025, F050, F100, F200 with core processor or Model
1700/2700 transmitter
Models F025, F050, F100, F200 with Model 1700/2700
transmitter with THUM adapter
Models F025, F050, F100 and F200 with junction box Ex ib IIC T1–T6
Ambient temperature: –40 to +140 °F (–40 to +60 °C)
Class I, Div. 1, Groups C and DClass I, Div. 2, Groups A, B, C, and
DClass II, Div. 1, Groups E, F, and G
Class I, Div. 1, Groups C and DClass I, Div. 2, Groups A, B, C, and
DClass II, Div. 1, Groups E, F, and G
Ambient temperature: –40 to +140 °F (–40 to +60 °C)
Class I, Div. 1, Groups C and DClass I, Div. 2, Groups A, B, C, and
DClass II, Div. 1, Groups E, F, and G
Class I, Div. 1, Groups C and DClass I, Div. 2, Groups A, B, C, and
DClass II, Div. 1, Groups E, F, and G
Ex ib IIC T1–T5
Ex ib IIC T1–T4
Model F300S and F300H with core processor or Model
1700/2700 transmitter
Model F300S and F300H with Model 1700/2700 transmitter
with THUM adapter
Models F300S and F300H with junction box Ex ib IIB T1–T6
Models F025, F050, F100, F200 with Model 2200S transmitter Ex ib IIC T1–T4
Model F300S and F300H with Model 2200S transmitter Ex ib IIB T1–T4
Ex ib IIB T1–T5
Ex ib IIB T1–T4
www.emerson.com 13
F-Series Coriolis Flow and Density Meters January 2019
NEPSI
All models with Model 2400S transmitter Ex nA II T1–T5
Models F025, F050, F100, F200 with core processor or Model
Ex ib IIC T1–T5
1700/2700 transmitter
Models F025, F050, F100 and F200 with junction box Ex ib IIC T1–T6
Model F300S and F300H with core processor or Model
Ex ib IIB T1–T5
1700/2700 transmitter
Models F300S and F300H with junction box Ex ib IIB T1–T6
ATEX
All models with Model 2400S transmitter
II 3G Ex nA IIC T1–T5 Gc II 3D Ex tc IIIC T
Models F025, F050, F100, and F200 with integral core processor
Max. ambient for core processor is +60 °C
or Model 1700/2700 transmitter
Transmitter with THUM adapter and display
II 3G Ex nA IIC T1–T5 Gc
Transmitter with THUM adapter, without
display
II 2G Ex ib IIC T1–T4
Transmitter with display
(1)
°C Dc IP66
Core processor or transmitter without display
Models F025, F050, F100, and F200 with junction box when
connected to MVD transmitter
Models F025, F050, F100, and F200 with Model 2200S
transmitter
Model F300 with integral core processor or Model 1700/2700
transmitter (max. ambient for core processor is +60 °C)
(2)
(2)
Model F300 with junction box connected to MVD transmitter
Model F300 with Model 2200S transmitter
(2)
II 2G Ex ib IIB+H2 T1–T5 II 2D Ex tD A21 IP65 T
(1)
(1)
°C
°C
(1)
(1)
°C
(1)
(1)
II 2G Ex ib IIC T1–T5 II 2D Ex tD A21 IP65 T
I 2G Ex ib IIC T1–T6 II 2D Ex tD A21 IP65 T
II 2G Ex ib IIC T1–T4 II 2D Ex ibD 21 T
II 2G Ex ib IIB T1–T5 II 2D Ex tD A21 IP65 T
II 2G Ex ib IIB T1–T6 II 2D Ex tD A21 IP65 T
II 2G Ex ib IIB T1–T4 II 2D Ex ibD 21 T
°C
°C
°C
(1)
°C
14 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
For ambient and process temperature limits, refer to the appropriate approval certificate.
(1)
For transmitter with THUM adapter, the ATEX approval is 0575 II 2G Ex ib IIB T1–T4.
(2)
Process connections
Note
The tables in this section do not represent all possible model and flange combinations. For combinations not listed here, contact a
sales representative or the factory.
Dimensions with process connections
Dimension A is provided for each process fitting type, when available. It is the finished face-to-face dimension of the sensor with the
process connection ±0.125 in (±3.18 mm).
Weight with process connections
Product weights in this section include the weight of the sensor with the process connection and integral core processor, except
where noted. Values are rounded to ±1 lb (±0.5 kg). Contact the factory for product shipping weight.
Standard fitting options
Model F025S
Code
113 1/2-
114 1/2-
115 1/2-
116 DN15 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 15.3
Description Dim A
inch
(mm)
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 16.0
inch
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 16.4
inch
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 16.9
inch
(406)
(416)
(428)
(387)
Weight
lb (kg)
14 (6.5)
15 (7)
16 (7)
15 (7)
www.emerson.com 15
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
120 DN15 PN100/
160
121 1/2-
inch
122 15mm 20K JIS B 2220 F316/316L Weld neck flange Raised face 15.4
150 ½-inch CL900/
1500
170 DN15 PN100/
160
172 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 15.3
176 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 15.2
178 DN15 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 15.4
183 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 13.9
DIN 2638 F316/F316L Weld neck flange Form E face 15.8
(401)
Tri-Clamp
compatible
ASME B16.5 F316/316L Weld neck flange Raised face 17.5
EN 1092-1 F316/F316L Weld neck flange Type B2 15.4
316L Hygienic fitting 14.0
(355)
(392)
(445)
(391)
(387)
(387)
(391)
(353)
Weight
lb (kg)
17 (8)
12 (5.5)
15 (7)
18 (8)
17 (8)
17 (8)
15 (7)
17 (7.5)
17 (8)
221 15mm 40K JIS B 2220 F316/316L Weld neck flange Raised face 16.5
(419)
222 DN15 DIN11851 316/316L Hygienic coupling 15.3
(387)
310 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 14.0
(355)
319 #8 VCO 316/316L Swagelok
compatible fitting
A94 1/2-
inch
A95 1/2-
inch
A96 1/2-
inch
A97 1/2-
inch
A99 3/4-
inch
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face
CL900/
1500
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 16.0
ASME B16.5 F316/F316L Weld neck flange Raised face
1/2-inch NPT
female adapter
63-125 RA face
finish
63-125 RA face
finish
63-125 RA face
finish
63-125 RA face
finish
15.8
(401)
16.0
(406)
16.4
(416)
16.9
(429)
17.5
(445)
(406)
(1)
19 (9)
12 (5.5)
15 (7)
12 (5.5)
14 (6)
16 (7)
14 (6)
21 (10)
14 (6)
16 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Code Description Dim A
inch
(mm)
B01 3/4-
inch
B02 3/4-
inch
B03 3/4-
inch
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 16.5
(419)
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 17.3
(438)
CL900/
1500
ASME B16.5 F316/F316L Weld neck flange Raised face 18.3
(464)
B04 1-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 16.3
(413)
B05 1-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 16.6
(422)
B06 1-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 17.1
(435)
B07 1-inch CL900/
1500
B09 1/2-
CL300 ASME B16.5 F316/F316L Weld neck flange RTJ face 16.8
inch
B10 1/2-
CL600 ASME B16.5 F316/F316L Weld neck flange RTJ face 16.8
inch
ASME B16.5 F316/F316L Weld neck flange Raised face 18.0
(457)
(427)
(427)
Weight
lb (kg)
18 (8)
18 (8)
23 (10)
16 (7)
19 (9)
20 (9)
28 (13)
16 (7)
16 (7)
B11 1/2-
inch
B77 #8 [blank] VCR F316/F316L Swagelok
B78 #12 [blank] VCR F316/F316L Swagelok
CL900/
1500
ASME B16.5 F316/F316L Weld neck flange RTJ face 17.5
(445)
compatible fitting
compatible fitting
Swagelok
compatible fitting
¾-inch 316 NPT
female adapter
17.2
(437)
15.4
(391)
C73 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type F 15.3
(387)
Dimension specified in table does NOT include fitting length. For installation, modify Dim. A value to include fitting.
(1)
Model F025A
Code
113 1/2-
114 1/2-
115 1/2-
Description Dim A
inch
(mm)
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 16.0
inch
(406)
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 16.4
inch
(416)
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 16.9
inch
(428)
21 (10)
13 (6)
14 (6)
15 (7)
Weight
lb
(1)
(kg)
12 (5.5)
13 (6)
13 (6)
www.emerson.com 17
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
122 15mm 20K JIS B 2220 F316/F316L Weld neck flange Raised face 15.4
(392)
150 1/2-
inch
170 DN15 PN100/
CL900/
1500
160
ASME B16.5 F316/F316L Weld neck flange Raised face 17.5
(444)
EN 1092-1 F316/F316L Weld neck flange Type B2 15.8
(401)
172 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 15.4
(391)
176 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 15.3
(387)
178 DN15 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 15.8
(401)
183 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 15.4
(391)
310 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Raised face 15.3
(387)
Weight shown includes the sensor, process fitting, and painted aluminum junction box, no electronics or transmitter.
(1)
Weight
lb
(1)
(kg)
13 (6)
15 (7)
15 (7)
15 (7)
13 (6)
15 (7)
15 (7)
13 (6)
Model F025P
Code
120 DN15 PN100/
150 1/2-
170 DN15 PN100/
178 DN15 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 15.8
180 DN25 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 16.8
319 #8 VCO 316/316L Swagelok
(1)
Description Dim A
DIN 2638 F316/F316L Weld neck flange Form E face 15.8
160
inch
CL900/
1500
ASME B16.5 F316/F316L Weld neck flange Raised face 17.5
EN 1092-1 F316/F316L Weld neck flange Type B2 15.8
160
1/2-inch NPT
compatible fitting
Dimension specified in table does NOT include fitting length. For installation, modify Dim. A value to include fitting.
female adapter
inch
(mm)
(401)
(444)
(401)
(401)
(427)24(10.5)
14.0
(355)
(1)
Weight
lb (kg)
17 (8)
17 (8)
17 (8)
17 (7.5)
12 (5.5)
18 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Model F025B
Code Description Dim A
inch
(mm)
517 1/2-
inch
520 1/2-
inch
521 1/2-
inch
522 15mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 15.5
524 DN15 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
Weight shown includes the sensor, process fitting, and painted aluminum junction box, no electronics or transmitter.
(1)
CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 16.4
(417)
CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 16.1
(408)
CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 16.4
(417)
(394)
15.3
stub
(388)
Models F025H
Code Description Dim A
inch
(mm)
517 1/2-
inch
CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 16.4
(417)
Weight
(1)
lb
(kg)
13 (6)
17 (8)
18 (8)
13 (6)
13 (6)
Weight
lb (kg)
15 (7)
520 1/2-
inch
521 1/2-
inch
522 15mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 15.5
524 DN15 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 16.1
(408)
CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 16.4
(417)
(394)
15.3
stub
(388)
Model F050S
Code
113 1/2-
114 1/2-
115 1/2-
116 DN15 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 17.4
Description Dim A
inch
(mm)
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 18.1
inch
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 18.5
inch
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 19.0
inch
(460)
(469)
(482)
(441)
19 (9)
20 (9)
15 (7)
15 (7)
Weight
lb (kg)
15 (7)
16 (7.5)
17 (7.5)
16 (7.5)
www.emerson.com 19
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
120 DN15 PN100/
160
122 15mm 20K JIS B 2220 F316/316L Weld neck flange Raised face 17.6
131 DN25 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 17.5
150 ½-inch CL900/1
500
170 DN15 PN100/
160
172 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 17.5
176 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 17.4
178 DN15 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 17.9
183 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 17.5
DIN 2638 F316/F316L Weld neck flange Form E face 17.9
(455)
(446)
(444)
ASME B16.5 F316/F316L Weld neck flange Type F 19.7
(498)
EN 1092-1 F316/F316L Weld neck flange Type B2 17.9
(455)
(445)
(441)
(455)
(445)
Weight
lb (kg)
18 (8.5)
18 (8)
18 (8.5)
18 (8.5)
18 (8.5)
18 (8.5)
16 (7.5)
18 (8)
18 (8.5)
221 15mm 40K JIS B 2220 F316/316L Weld neck flange Raised face 18.6
(473)
222 DN15 DIN11851 316/316L Hygienic coupling 16.0
(407)
239 #12 VCO 316/316L Swagelok
compatible fitting
310 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 17.4
322 3/4-
inch
A94 1/2-
inch
A95 1/2-
inch
A96 1/2-
inch
A97 1/2-
inch
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face
CL900/1
500
Tri-Clamp
compatible
ASME B16.5 F316/F316L Weld neck flange Raised face
316L Hygienic fitting 15.9
3/4-inch NPT
female adapter
63-125 RA face
finish
63-125 RA face
finish
63-125 RA face
finish
63-125 RA face
finish
16.4
(415)
(441)
(403)
18.1
(460)
18.5
(470)
19.0
(483)
19.6
(498)
19 (9)
13 (6)
14 (6)
16 (7.5)
13 (6)
16 (7)
17 (8)
17 (8)
22 (10)
20 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Code Description Dim A
inch
(mm)
A99 3/4-
inch
B01 3/4-
inch
B02 3/4-
inch
B03 3/4-
inch
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 18.3
(464)
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 18.6
(473)
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 19.4
(492)
CL900/1
500
ASME B16.5 F316/F316L Weld neck flange Raised face 20.4
(517)
B04 1-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 18.4
(467)
B05 1-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 18.8
(476)
B06 1-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 19.3
(489)
B07 1-inch CL900/1
500
B09 1/2-
CL300 ASME B16.5 F316/F316L Weld neck flange RTJ face 18.9
inch
ASME B16.5 F316/F316L Weld neck flange Raised face 20.1
(511)
(481)
Weight
lb (kg)
16 (7)
19 (9)
19 (9)
25 (11)
17 (8)
20 (9)
21 (10)
29 (13)
17(8)
B10 1/2-
inch
B11 1/2-
inch
B77 #8 [blank] VCR F316/F316L Swagelok
B78 #12 [blank] VCR F316/F316L Swagelok
CL600 ASME B16.5 F316/F316L Weld neck flange RTJ face 18.9
(481)
CL900/1
500
ASME B16.5 F316/F316L Weld neck flange RTJ face 19.6
(498)
compatible fitting
compatible fitting
¾ -inch 316
female adapter
¾ -inch 316
female adapter
19.3
(489)
17.5(445)15(7)
C73 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type F 17.4
(441)
F050A
Code
113 1/2-
114 1/2-
115 1/2-
Description Dim A
inch
(mm)
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 18.1
inch
(460)
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 18.5
inch
(469)
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 19.0
inch
(482)
17(8)
22(10)
14(6)
17(8)
Weight
(1)
lb
(kg)
13 (6)
14 (6.5)
15 (6.5)
www.emerson.com 21
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
122 15mm 20K JIS B 2220 F316/F316L Weld neck flange Raised face 17.6
(446)
150 1/2-
inch
170 DN15 PN100/
172 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 17.5
176 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 17.4
178 DN15 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 17.9
183 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 17.5
221 15mm 40K JIS B 2220 F316/316L Weld neck flange Raised face 18.6
310 DN15 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 17.4
CL900/
1500
160
ASME B16.5 F316/F316L Weld neck flange Raised face 19.6
(498)
EN 1092-1 F316/F316L Weld neck flange Type B2 17.9
(455)
(445)
(441)
(455)
(445)
(473)
(441)
Weight
(1)
lb
(kg)
14 (6.5)
16 (7.5)
16 (7.5)
16 (7.5)
14 (6.5)
16 (7)
16 (7.5)
22 (10)
14 (6.5)
Weight shown includes the sensor, process fitting, and painted aluminum junction box, no electronics or transmitter.
(1)
Model F050P
Code
113 1/2-
114 1/2-
115 1/2-
116 DN15 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 17.4
120 DN15 PN100/
122 15mm 20K JIS B 2220 F316/F316L Weld neck flange Raised face 17.6
131 DN25 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 17.5
Description Dim A
inch
(mm)
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 18.1
inch
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 18.5
inch
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 19.0
inch
DIN 2638 F316/F316L Weld neck flange Form E face 17.9
160
(460)
(469)
(482)
(441)
(455)
(446)
(444)
Weight
lb (kg)
15 (7)
16 (7.5)
17 (7.5)
16 (7.5)
18 (8.5)
16 (7.5)
18 (8.5)
22 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Code Description Dim A
inch
(mm)
150 1/2-
inch
170 DN15 PN100/
CL900/
1500
160
ASME B16.5 F316/F316L Weld neck flange Raised face 19.6
(498)
EN 1092-1 F316/F316L Weld neck flange Type B2 17.9
(455)
178 DN15 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 17.9
(455)
180 DN25 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 18.9
(481)
222 DN15 DIN11851 316/316L Hygienic coupling 16.0
(407)
239 #12 VCO 316/316L Swagelok
compatible fitting
322 3/4-
inch
Dimension specified in table does NOT include fitting length. For installation, modify Dim. A value to include fitting.
(1)
Tri-Clamp
compatible
316L Hygienic fitting 15.9
3/4-inch NPT
female adapter
16.4
(415)
(403)
Model F050B
(1)
Weight
lb (kg)
18 (8.5)
18 (8.5)
18 (8)
25 (11)
13 (6)
14 (6)
13 (6)
Code
Description Dim A
inch
(mm)
517 1/2-
inch
520 1/2-
inch
521 1/2-
inch
CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 18.6
(471)
CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 18.2
(462)
CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 18.6
(471)
522 15mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 17.6
(447)
524 DN15 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
stub
Weight shown includes the sensor, process fitting, and painted aluminum junction box, no electronics or transmitter.
(1)
17.4
(442)
Model F050H
Code
517 1/2-
Description Dim A
inch
(mm)
CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 18.6
inch
(471)
Weight
(1)
lb
(kg)
14 (6.5)
18 (8.5)
19 (8.5)
14 (6.5)
14 (6.5)
Weight
lb (kg)
17 (7.5)
520 1/2-
inch
CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 18.2
(462)
20 (9.5)
www.emerson.com 23
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
521 1/2-
inch
522 15mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 17.6
524 DN15 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 18.6
(471)
(447)
17.4
stub
(442)
Model F100S
Code Description Dim A
inch
(mm)
128 1-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 22.7
(576)
129 1-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 23.2
(588)
130 1-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 23.7
(601)27(12.5)
Weight
lb (kg)
21 (9.5)
16 (7.5)
17 (7.5)
Weight
lb (kg)
24 (11)
27 (12)
131 DN25 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 21.4
(544)25(11.5)
137 DN25 PN100/160 DIN 2638 F316/F316L Weld neck flange Form E face 22.8
(580)
179 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 21.4
(544)25(11.5)
180 DN25 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 22.9
(580)
181 DN25 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 22.9
(580)
209 2-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 23.1
(585)32(14.5)
229 25mm 40K JIS B 2220 F316/316L Weld neck flange Raised face 22.9
(582)
230 DN25 DIN11851 316/316L Hygienic
coupling
311 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 21.4
928 1-inch CL900/1500 ASME B16.5 F316/F316L Weld neck flange Raised face 24.6
20.6
(522)
(544)25(11.5)
(624)
31 (14)
31 (14)
31 (14)
31 (14)
20 (9)
36 (16)
24 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Code Description Dim A
inch
(mm)
B14 1-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face
63-125 Ra face
finish
B15 1-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face
63-125 Ra face
finish
B16 1-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face
63-125 Ra face
finish
B17 1 1/2-
inch
B18 1 1/2-
inch
B19 1 1/2-
inch
B20 1 1/2-
inch
B21 1 1/2-
inch
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 22.9
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 23.4
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 24.3
CL900/1500 ASME B16.5 F316/F316L Weld neck flange Raised face 24.8
CL900/1500 ASME B16.5 F316/F316L Weld neck flange Raised face 23.6
22.7
(576)
23.2
(589)
23.7
(602)
(583)
(594)
(616)
(630)
(598)
Weight
lb (kg)
24 (11)
27 (12)
28 (13)
27 (12)
32 (15)
35 (16)
46 (21)
34 (15)
B22 1 1/2-
inch
B23 1 1/2-
inch
B24 1 -inch CL300 ASME B16.5 F316/F316L Weld neck flange RTJ face 23.7
B25 1 -inch CL600 ASME B16.5 F316/F316L Weld neck flange RTJ face 23.7
B26 1 1/2-
inch
B81 #16 [blank] VCO F316/F316L Swagelok
B82 #16 [blank] VCR F316/F316L Swagelok
C74 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type F 21.4
CL900/1500 ASME B16.5 F316/F316L Weld neck flange Raised face 24.3
(616)
CL900/1500 ASME B16.5 F316/F316L Weld neck flange Raised face 26.8
(679)
(602)
(602)
CL900/1500 ASME B16.5 F316/F316L Weld neck flange RTJ face 23.5
(641)
compatible
fitting
compatible
fitting
1-inch 316 NPT
female adapter
1-inch 316 NPT
female adapter
20.3
(514)
23.5
(641)
(545)
38 (17)
65 (29)
27 (12)
28 (13)
46 (21)
22 (10)
23 (10)
25 (11)
www.emerson.com 25
F-Series Coriolis Flow and Density Meters January 2019
Model F100A
Code Description Dim A
inch
(mm)
128 1-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 22.7
(576)
129 1-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 23.2
(588)32(14.5)
130 1-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 23.7
(601)25(11.5)
139 25mm 20K JIS B 2220 F316/F316L Weld neck flange Raised face 21.7
(550)23(10.5)
179 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 21.4
(544)23(10.5)
209 2-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 23.1
(585)30(13.5)
229 25mm 40K JIS B 2220 F316/316L Weld neck flange Raised face 22.9
(582)
311 DN25 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 21.4
(544)23(10.5)
928 1-inch CL900 ASME B16.5 F316/F316L Weld neck flange Raised face 24.6
(623)34(15.5)
Weight
(1)
lb
(kg)
22 (10)
31 (14)
Weight shown includes the sensor, process fitting, and painted aluminum junction box, no electronics or transmitter.
(1)
Model F100B
Code
530 1-inch CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 22.7
531 1-inch CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 23.2
532 25mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 21.8
534 DN25 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
535 1-inch CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 23.2
(1)
Description Dim A
stub
Weight shown includes the sensor, process fitting, and painted aluminum junction box, no electronics or transmitter.
inch
(mm)
(577)24(10.5)
(590)
(552)
21.5
(546)
(590)
Weight
(1)
lb
(kg)
26 (12)
25 (11)
25 (11)
26 (12)
26 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Model F100H
Code Description Dim A
inch
(mm)
530 1-inch CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 22.7
(577)26(11.5)
531 1-inch CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 23.2
(590)
532 25mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 21.8
(552)
534 DN25 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
stub
535 1-inch CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 23.2
21.5
(546)
(590)
Model F100P
Code Description Dim A
inch
(mm)
C55 1-inch CL2500 ASME B16.5 Nickel alloy C22 Weld neck flange RTJ 25.8
(655)
Weight
lb (kg)
28 (13)
27 (12)
27 (12)
28 (13)
Weight
lb (kg)
46 (21)
C56 1-1/2-
inch
C57 1-inch CL2500
C58 1-1/2-
inch
C64 1-inch CL2500 ASME B16.5 F316/F316L Weld neck flange RTJ 25.8
C65 1-1/2-
inch
CL2500 ASME B16.5 Nickel alloy C22 Weld neck flange RTJ 27.6
(701)76(34.5)
ASME B16.5 F316/F316L Weld neck flange RTJ 25.8
(360
bar)
CL2500(
360 bar)
CL2500 ASME B16.5 F316/F316L Weld neck flange RTJ 27.6
ASME B16.5 F316/F316L Weld neck flange RTJ 27.6
(655)
(701)
(655)
(701)
Model F200S
Code
312 DN40 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 23.4
316 DN50 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 23.7
Description Dim A
inch
(mm)
(595)48(21.5)
(601)
44 (20)
71 (32)
44 (20)
71 (32)
Weight
lb (kg)
51 (23)
341 1-1/2-
inch
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 24.8
(629)
46 (21)
www.emerson.com 27
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
342 1-1/2-
inch
343 1-1/2-
inch
351 1-1/2-
inch
352 2-inch Tri-Clamp
353 DN40 DIN11851 316/316L Hygienic coupling 23.2
363 DN40 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 24.8
365 DN50 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 25.3
366 DN40 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 24.8
367 DN50 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 25.3
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 25.3
(642)52(23.5)
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 25.8
(654)
Tri-Clamp
compatible
compatible
316L Hygienic fitting 23.3
(591)39(17.5)
316L Hygienic fitting 22.9
(581)
(589)
(629)56(25.5)
(641)
(629)56(25.5)
(641)
Weight
lb (kg)
55 (25)
39 (18)
46 (21)
64 (29)
64 (29)
368 DN40 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 23.4
(595)48(21.5)
369 DN50 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 23.7
(601)
378 DN50 PN100 DIN 2637 F316/F316L Weld neck flange Form E face 25.4
(646)
381 DN40 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 23.6
(599)48(21.5)
382 DN50 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 23.8
(605)
385 40mm 10K JIS B 2220 F316/F316L Weld neck flange Raised face 23.4
(595)
386 50mm 10K JIS B 2220 F316/316L Weld neck flange Raised face 23.7
(602)
387 40mm 20K JIS B 2220 F316/F316L Weld neck flange Raised face 23.4
(595)
388 50mm 20K JIS B 2220 F316/316L Weld neck flange Raised face 23.7
(602)
418 2-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 24.9
(632)50(22.5)
51 (23)
64 (29)
51 (23)
46 (21)
48 (22)
47 (21)
48 (22)
28 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Code Description Dim A
inch
(mm)
419 2-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 25.4
(645)54(24.5)
420 2-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 26.1
(664)
A31 1-1/2-
inch
A32 1-1/2-
inch
A33 1-1/2-
inch
A34 1-1/2-
inch
A35 2-inch CL900/1
A36 3-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 25.3
CL900/1
500
CL150 ASME B16.5 F316/F316L Weld neck flange Raised face
CL300 ASME B16.5 F316/F316L Weld neck flange Raised face
CL600 ASME B16.5 F316/F316L Weld neck flange Raised face
500
ASME B16.5 F316/F316L Weld neck flange Raised face 26.9
63-125 Ra face
finish
63-125 Ra face
finish
63-125 Ra face
finish
ASME B16.5 F316/F316L Weld neck flange Raised face 27.4
(683)
24.8
(629)
25.3
(641)
25.9
(657)
(695)
(641)
Weight
lb (kg)
58 (26)
65(29)
46(21)
52(24)
54(24)
83(38)
60(27)
A37 3-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 25.9
(657)
A38 3-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 26.6
(676)
A39 2-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face
63-125 Ra face
finish
A40 2-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face
63-125 Ra face
finish
A41 2-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face
63-125 Ra face
finish
A42 2-inch CL150 ASME B16.5 F316/F316L Weld neck flange RTJ face 25.3
A43 2-inch CL300 ASME B16.5 F316/F316L Weld neck flange RTJ face 26.0
A44 2-inch CL600 ASME B16.5 F316/F316L Weld neck flange RTJ face 26.3
A45 2-inch CL900/1
500
ASME B16.5 F316/F316L Weld neck flange RTJ face 27.5
24.8
(629)
25.3
(641)
26.18
(664)
(641)
(660)
(667)
(699)
68(61)
75(34)
50(23)
53(24)
57(26)
51(23)
55(25)
58(26)
84(38)
www.emerson.com 29
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
B55 2-inch CL600 ASME B16.5 A105 Carbon Steel Lap joint flange 316/316L stub 24.8
(629)
B85 50mm 10K JIS B 2220 A105 Carbon Steel Lap joint flange 316/316L stub 23.7
(602)
B86 50mm 20K JIS B 2220 A105 Carbon Steel Lap joint flange 316/316L stub 23.7
(602)
C75 DN40 PN40 EN 1092-1 F316/F316L Weld neck flange Type F 23.4
(595)
C76 DN50 PN40 EN 1092-1 F316/F316L Weld neck flange Type F 23.7
(629)
Model F200H
Code Description Dim A
inch
(mm)
537 1-1/2-
inch
CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 25.3
(641)
Weight
lb (kg)
57(26)
50 (23)
50 (23)
48 (22)
51 (23)
Weight
lb (kg)
64 (29)
540 1-1/2-
inch
541 1-1/2-
inch
542 40mm 10K JIS 2220 F304/F304L Lap joint flange N06022 stub 23.4
544 2-inch CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 24.8
545 2-inch CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 25.3
546 50mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 23.7
548 DN40 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
549 DN50 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 24.8
(628)
CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 25.3
(641)52(23.5)
(595)52(23.5)
(628)51(23.5)
(641)56(25.5)
(601)
23.6
stub
stub
(599)
23.8
(605)56(25.5)
46 (21)
55 (25)
50 (23)
30 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
F300S
Code Description Dim A
inch
(mm)
326 DN80 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 35.9
(912)
333 DN100 PN40 EN 1092-1 F316/F316L Weld neck flange Type D 36.5
(926)
355 3-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 36.9
(935)
356 3-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 37.6
(954)
357 3-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 38.4
(974)
358 3-inch CL900 ASME B16.5 F316/F316L Weld neck flange Raised face 37.7
(958)
359 DN100 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 38.4
(976)
361 3-inch Tri-Clamp
compatible
371 DN80 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 35.9
316L Hygienic fitting 35.1
(893)
(912)
Weight
lb (kg)
138
(63)
166
(75.5)
167
(76)
167
(76)
174
(79)
123
(56)
196
(89)
196
(89)
158
(72)
372 DN100 PN40 EN 1092-1 F316/F316L Weld neck flange Type B1 36.5
(926)
373 DN80 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 37.5
(952)
374 DN100 PN100 EN 1092-1 F316/F316L Weld neck flange Type B2 38.4
(976)
375 DN80 PN100 EN 1092-1 F316/F316L Weld neck flange Type D 37.5
(952)
391 DN80 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 36.0
(915)
392 DN100 PN40 DIN 2635 F316/F316L Weld neck flange Form C face 36.5
(926)
393 DN80 PN40 DIN 2635 F316/F316L Weld neck flange Form N grooved
face
394 DN100 PN40 DIN 2635 F316/F316L Weld neck flange Form N grooved
face
395 DN80 PN100 DIN 2637 F316/F316L Weld neck flange Form E face 37.8
396 DN100 PN100 DIN 2637 F316/F316L Weld neck flange Form E face 38.8
36.0
(915)
36.5
(926)
(958)
(983)
146
(66.5)
176
(80)
198
(90)
174
(79)
137
(62)
147
(66.5)
158
(71.5)
166
(75.5)
176
(80)
196
(89)
www.emerson.com 31
F-Series Coriolis Flow and Density Meters January 2019
Code Description Dim A
inch
(mm)
397 DN80 PN100 DIN 2637 F316/F316L Weld neck flange Form N grooved
face
398 DN100 PN100 DIN 2637 F316/F316L Weld neck flange Form N grooved
face
400 80mm 10K JIS B 2220 F316/F316L Weld neck flange Raised face 36.5
401 100mm10K JIS B 2220 F316/F316L Weld neck flange Raised face 36.7
402 80mm 20K JIS B 2220 F316/F316L Weld neck flange Raised face 36.5
410 3-inch Grooved coupling 316L Hygienic coupling 36.9
425 4-inch CL150 ASME B16.5 F316/F316L Weld neck flange Raised face 37.3
426 4-inch CL300 ASME B16.5 F316/F316L Weld neck flange Raised face 38.1
427 4-inch CL600 ASME B16.5 F316/F316L Weld neck flange Raised face 39.9
37.8
(958)
38.8
(983)
(927)
(932)
(927)
(935)
(945)
(969)
(1012)
Weight
lb (kg)
175
(79.5)
195
(89)
154
(70)
158
(72)
158
(71.5)
196
(89)
145
(66)
184
(83.5)
212
(96.5)
Model F300H
Code
539 3-inch CL600 ASME B16.5 F304/F304L Lap joint flange N06022 stub 36.0
550 3-inch CL150 ASME B16.5 F304/F304L Lap joint flange N06022 stub 37.5
551 3-inch CL300 ASME B16.5 F304/F304L Lap joint flange N06022 stub 36.8
552 80mm 10K JIS B 2220 F304/F304L Lap joint flange N06022 stub 37.5
554 DN80 PN40 EN 1092-1 F304/F304L Lap joint flange Type B1, N06022
Description Dim A
inch
(mm)
(914)
(953)
(934)
(953)
36.5
stub
(926)
Weight
lb (kg)
167
(76)
159
(72.5)
167
(76)
154
(70)
145
(66)
32 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
Namur NE132 compliant flanges
Sensor ETO# Description Dim A
inch
(mm)
F025S999 13998 DN15 PN40 EN 1092-1 F316/F316L Weld neck
flange
F050S999 20589 DN15 PN40 EN 1092-1 F316/F316L Weld neck
flange
F050S999 17157 DN25 PN40 EN 1092-1 F316/F316L Weld neck
flange
F100S999 13999 DN25 PN40 EN 1092-1 F316/F316L Weld neck
flange
F200S999 14000 DN50 PN40 EN 1092-1 F316/F316L Weld neck
flange
F300S999 17159 DN80 PN40 EN 1092-1 F316/F316L Weld neck
flange
F300S999 17158 DN100 PN40 EN 1092-1 F316/F316L Weld neck
flange
F300S999 20590 DN100 PN16 EN 1092-1 F316/F316L Weld neck
flange
FormB120.1
(510)
FormB120.1
(510)
FormB123.6
(600)
FormB123.6
(600)
FormB128.2
(715)
FormB136.0
(915)
FormB139.7
(1000)
FormB139.7
(1000)
Weigh
t lb
(kg)
11.7
(5.8)
13.4
(6.1)
13.9
(6.3)
23.8
(11.3)
48.4
(22.9)
11 (5)
171
(77.8)
162.8
(74)
www.emerson.com 33
F-Series Coriolis Flow and Density Meters January 2019
34 www.emerson.com
January 2019 F-Series Coriolis Flow and Density Meters
www.emerson.com 35
PS-001864
Rev. E
January 2019
Emerson Automation Solutions
Worldwide Headquarters
7070 Winchester Circle
Boulder, Colorado USA 80301
T: +1 800-522-6277
T: +1 303-527-5200
F: +1 303-530-8459
Mexico: 52 55 5809 5300
Argentina: 54 11 4837 7000
Brazil: 55 15 3413 8147
Chile: 56 2 2928 4800
Emerson Automation Solutions
Central Europe: +41 41 7686 111
Eastern Europe: +41 41 7686 111
Dubai: +971 4 811 8100
Abu Dhabi: +971 2 697 2000
Austria: +43 2236 607-0
France: 0800 917 901
Germany: +49 (0) 2173 3348 0
Italy: 8008 77334
The Netherlands: +31 (0) 70 413 6666
Belgium: +32 2 716 77 11
Spain: 900 901 986
U.K.: 0870 240 1978
Russian/CIS: +7 495 981 9811
©
2019 Micro Motion, Inc. All rights reserved.
The Emerson logo is a trademark and service mark of Emerson Electric Co. Micro Motion, ELITE,
ProLink, MVD and MVD Direct Connect marks are marks of one of the Emerson Automation
Solutions family of companies. All other marks are property of their respective owners.
Emerson Automation Solutions
Australia: (61) 3 9721 0200
China: (86) 21 2892 9000
India: (91) 22 6662 0566
Japan: (81) 3 5769 6803
South Korea: (82) 31 8034 0000
Singapore: (65) 6 363 7766
Loading...
