Micromax Q5fb User Guide

Contents

1. For your Safety……………………………….5

2. Mobile Phone Profile……………………..9

2.1 Technical Specification .......... 10

3. Preparation before Use…………………..11

3.1 Installing SIM Card ................. 11

3.2 Install Memory card revamp.. 13

3.3 Install Battery ........................ 14

3.4 Charge Battery ....................... 15

3.5 Notice on using the battery ... 16

3.6 PIN code ................................. 18

4. General Instructions……………………..20

4.1 Dial key ...................................... 20

4.2 Switch-on/off key /End key .... 20

4.3 Standard keypad .................... 20

4.4 AM/FM function key .............. 21

4.5 Keypad lock ............................ 22

4.6 Icons in Standby State............ 22

4.7 Language and Input Mode .... 23

4.8 Services .................................. 23

4.9 Caller group ........................... 24

5. Terms Description…………………………..24

5.1 Dial domestic calls ................. 24

5.2 Dial international calls ........... 24

5.3 Dial extension ........................ 25

5.4 Emergency calls ..................... 26

5.5 IMEIE r r o r! B o o k ma rk n o t

d e f i n e d .

6. Basic operation………………………………...26

6.1 Switch on ............................... 26

6.2 Switch off ............................... 27

6.3 Dial a Call ............................... 27

6.4 Adjust Receiver Volume ......... 28

6.5 Answer a Call ......................... 28

6.6 Send DTMF Signal .................. 29

6.7 Dial Hold ................................ 29

6.8 Fast Read SMS ....................... 30

6.9 Missed Calls ........................... 30

6.10Connect to Voice mail ............... 31

7. Use of Menu Functions……………………..31

7.1 Messaging…… ……………… ..31

7.2 Phonebook…………………….39

7.3 IM………………………………….42

7.4 Facebook………… ………… ….43

7.5 Opera mini…………………… .43

7.6 Call History…………………….43

7.7 Settings………………………….46

7.8 Organizer……………………….59

7.9 Multimedia…………………….62

7.10 Fun & Games………………….75

7.11 Tools……………………… ………77

7.12 Service………… …………… ……79

8. Editor Operation……………………………….82

8.1.1 Basic letter input ............... 82

8.1.2 Number input .................... 82

8.1.3 Symbol input ..................... 83

9. Use of USB………………………………………..83

10. Maintenance…………………………………..84

10.1.1 After sales service ............. 84

10.2.2 Charger Safety .................. 84

10.2.3 Battery Information .......... 84

10.2.4 General Notice .................. 85

10.2.5 Troubleshooting ................ 86

11. Abbreviations………………………………….90

1. For your Safety

For your safety and proper use of the mobile phone, please read the following guidelines carefully: Do not switch the mobile phone on when close to a chemical factory, gas station or other explosive objects.

While driving, please use a headset for safety purpose; unless otherwise in emergency, always stop the car by the roadside to have a call conversation.

 Because the use of the mobile phone can

cause interference in the aircraft, never use the mobile phone in aircraft. The use of the mobile phone is dangerous and illegal; do switch off the mobile phone before boarding.

 Pay special attention to the use of the

mobile phone near a heart pacemaker, deaf-aid and some other medical equipments, because the mobile phone can cause interference with them.

 Non-original factory’s accessories and parts

will lose guarantee.

 Do not dismantle the mobile phone without

permission. In case of failure, please contact the supplier as soon as possible.

 Do not plug the charger into the mobile

phone and charge without battery. Always power off the mobile phone when taking out the battery; otherwise the memory of the phone may be damaged.

 When charging the mobile phone, always

keep it in the place with good ventilation, heat sink and away from flammable and explosive objects.

 In order to avoid demagnetization, always

keep the mobile phone away from magnetic objects such as CD, credit card etc.

 Ensure the mobile phone does not come in

contact with any liquid; once such case occurs, remove the battery and contact the supplier immediately.

 Do not use the mobile phone in an

environment at too high or too low a temperature, never expose the mobile phone under strong sunshine or too wet an

environment. The suitable temperature for the phone and accessories is 0℃-40℃. The height to use the phone shall be less than 2,000m.

 Do not use a wet cloth with strong cleanser

to clean the mobile phone.

 This mobile phone has shooting, videoing

and audio recording functions, which shall be used as per the related laws and regulations.

 Always keep the mobile phone out of

children’s reach. Do not throw or vibrate

the mobile phone because violent treatment to the mobile phone may damage the inner circuits and precise structures.

 Please do not discard the waste battery into

general household garbage. Please deal with the waste battery according to provisions where they are made.

Disclaimer: Micromax will not bear any responsibility for any

incompliance with the above mentioned guidelines or improper usage of the mobile phone. Micromax keeps the right to make modifications to any of the content here in this user guide without public announcement in advance. The content of this

manual may vary from the actual content displayed in the mobi le phone. In such case, the latter shall govern.

7 8 9

4 5 6

2. Mobile Phone Profile

Speaker 7.

Back key

LCD 8.

Retreat key

Track Ball / OK key

MSN shortcuts

Call key 10.

QWERTY keypad

Main menu key

11.

Speaker

Face book shortcuts

12.

Camera

2.1 Technical Specification

Network

GSM/GPRS: 900/1800 dual On, dual standby

Battery

3.7V 1000mAh lithium-ion battery

Charger

Input: 100-240V ~ 50/60Hz Output: 5VDC, 750mA

Size

115 x 62 x 12.5mm

LCD

2.2 inch, TFT, QVGA(240x 320)

GPRS

Class 12

Multimedia

MP3 Player, Camera, Radio, Audio Recorder, Video

External memory

Slot Available

3. Preparation before Use

3.1 Installing the SIM Card

When registering the mobile phone number, you can apply for two different phone numbers, two different mobile phone network service providers and thus obtain two SIM (Subscriber Identification Module) cards.

With these two SIM cards, you can use all functions of your mobile phone. The SIM cards save the parameters needed for communications and personal data, including PIN (Personal Identification Number) code, phonebook, short

message and other extra system services. Warning: Do not distort or scratch the SIM card

nor let it come in contact with dust or moisture. If it is lost, please immediately contact your network operator for help.

Before SIM card installation, please switch off the mobile phone. The SIM card is installed on the back of the mobile phone.

Follow the following diagram to install the SIM card. Please insert the host SIM card into the SIM1 slot and the slave SIM card into the SIM2 slot.

Note: If SIM card is inserted only into the SIM1 slot, then only the host works; similarly, If SIM card is inserted only into the SIM2 slot, then only the slave works. When two SIM cards are inserted into the SIM1 slot and SIM2 slot respectively, you can choose work mode freely as

you wish. Note: As the SIM card is a small object, keep it

out of children’s touch.

SIM2

SIM1

3.2 Installing the Memory card revamp

As the mobile phone does not have enough storage space, to use some functions, you need to install a memory card (This mobile phone uses T-FLASH card.)

Installing the T-FLASH card: Open the back cover to take out the battery, release the T-Flash card lock, insert the T-Flash card into its slot, and restore the lock and the battery before restarting the mobile phone.

Memory card

Note: As the T-FLASH card is a small object, keep it out of children’s touch.

3.3 Installing the Battery

The mobile phone is suitable for original battery and accessories. When the battery is idle, it is recommended to put it into the protection box.

Follow the following diagram to install the battery.

Note: Do install the battery as per the diagram so as to prevent the battery contact patch from being damaged.

Battery

3.4 Charging the Battery

The new battery cannot reach the optimal efficiency level unless it has undergone several continuous complete charges and discharges.

When the battery is used up, charge it in time. Over-discharge can damage the battery. After the battery is charged fully, cut off the

connection of the charger with the AC power supply and the connection with the mobile phone.

Follow the following diagram to connect the charger.

Charger port / USB

Earphone

During charging, the battery capacity icon on the screen flickers from the right to the left. After the battery is charged fully, the icon is full of bars. Slight heat during charging is normal.

Warning: When a travel charger and its accessories are used to charge the battery, please firstly check if they are original or recognized by the original manufacturer. The use of other accessories may damage your mobile phone and cause risks! Always use them indoor and near dry places.

3.5 Notice on using the battery

The performance of the battery is affected by many factors, including radio barrier network settings, signal strength, work temperature, chosen and used functions or settings as well as phone accessories, tone, data or other applications.

For optimal performances, please follow the rules below:

 New battery or the battery having been idle

for long need charging for long. The standard voltage scope for the battery is

3.6V-4.2V.

 During charging, keep the battery at room

temperature or similar temperature.

 With time passing by, the battery will

gradually be worn and thus needs a longer time to charge. This is normal. However, after normal charging, if call duration decreases but charging time increases, you need to buy another battery from the original manufacturer or authorized by the original manufacturer. The battery of interior quality can damage your mobile phone and cause danger!

 If the phone is overused at low battery

when charging, it may take the charge indicator a longer time to show up on the screen.

Note: Please dispose the battery according to the local regulations. Try to recycle the battery as possible. Do not treat the waste battery as common waste.

Warning: Do not throw the battery into fire so as

to prevent an explosion.

Warning: Charging the mobile phone by improper means can cause an explosion. Always refer to the related regulations for the disposal of the battery

3.6 PIN code

PIN1 Code: It is the personal identification number used to enter SIM and able to prevent others using SIM1 without permission. If the mobile phone has activated the PIN1 code protection, when the mobile phone is switched

on, the screen will display “Input PIN”. In the

process of inputting PIN1 code, the screen will use ‘*’ to represent the input content. While obtaining SIM, you can obtain its PIN1 code.

PIN2 Code: It is the personal identification number used for some special functions such as paid call etc.

PUK Code and PUK2 Code(8-digit) To change the locked PIN code, you need to use

PUK (Personal Unblocking Key) code. To change the locked PIN2 code, you need to use PUK2 code. If these two codes are not provided together with the SIM cards, ask the local service provider for

them. Warning: If the PIN code is input wrongly for

successively three times, the SIM card will be locked. Please contact the network operator immediately for help. Attempt to unlock the code may make the SIM card ineffective forever!

4. General Instructions

4.1 Dial key

It is used to dial a call (with phone number entered or in phonebook state) or receive an incoming call. In standby state, press this key to display the latest call register (SIM1 and SIM2 support respectively 20 call entries, including received calls, missed calls and dialed calls). In dual-SIM standby mode, press this key to have an option menu on which you can choose to operate via SIM1 or via SIM2.

4.2 Switch-on/off key /End key

In call state, it is used to interrupt a call; in call conversation state, it is used to end a call or exit from the current menu and back to the standby state. Hold this key for 4~5s to switch on/off the mobile phone.

4.3 Standard keypad

On the keypad, you can see A-Z 0-9 number keys number keys, * key and # key, totally 42 keys.

Press these keys to input phone number,

password, English letters, symbols or choose menus.

In different states or different functional menus, ‘+’ key and ‘-‘key have different functions:

 Press “SPEAKER” key long to start or exit

from the silence mode.

 In music player state, ‘+’ and ‘-‘ are used to

adjust volume.

Tip: The difference between ‘W’ and ‘P’ is that ‘P’ will directly send DTMF after 3s pause while ‘W’ will eject a window asking whether the user

wants to send DTMF.

4.4 AM/FM function key

 OK key: In radio state, press the key to stop  In search state, press the left/right key to

search channels forward and backward, press the OK key until you find an effective channel.

 1-9 number keys: If they are pressed

shortly, you can switch to the corresponding channels saved in the channel list; if they are pressed long, you can save the current frequency to the corresponding channel.

 +, - key: Adjust volume.

4.5 Keypad lock

Indicates signal strength

Indicate the battery level

Alarm clock is active

Keypad is locked

There is new message(s)

Host line 1

There is missed call(s)

Host line 2 In normal mode

Slave line 1

Vibrate then ring

Slave line 2

Ring

MMS

Vibrate

Inbox PUSH

When in standby interface, if the mobile phone is idle for certain time, it will be locked automatically. Press the Unlock key and “*”to release. After the mobile phone is locked, the keypad cannot be activated easily; in case of incoming call, likewise, press the answer key to receive it; after that, the keypad will be locked automatically.

4.6 Icons in Standby State

Ring and vibrate

GPRS

Call divert

4.7 Language and Input Mode

The mobile phone has abc as the default input mode. For different areas, there are different languages and corresponding input modes.

Call hint

The mobile phone is inbuilt with vibration motor and buzzer and provides several incoming call modes:

4.8 Services

Services are provided with SIM kit. The mobile phone support service function. The detailed menu items depend on SIM card and the network. When the network provides such function and your SIM card supports such function, the service menu will automatically be posted in the services of the mobile phone.

Ring Vibration Ring and vibration Ring after vibration

4.9 Caller group

The caller group in the mobile phone includes friends, family, VIP, colleagues and others etc. You can set different call tone and photo for different callers’ group.

5. Terms Description

5.1 Dial domestic calls

 The simplest method to dial a domestic call

is to input phone number via the number keypad, then press dial key to dial call. To

change phone number, press “del key”.

During dialing, the screen will display a cartoon. If SIM card 1 call, "SIM1-" occurs; if SIM card 2 call, "SIM2-" occurs. When the other party is connected, the screen will display the corresponding information.

 Press end key to end the call.  To dial a domestic call, input area code +

phone number and then press the dial key.

5.2 Dial international calls

 If you want to make an international call,

you can press * key continuously until the international dialing prefix ‘+’ is seen on the screen. This will allow you to make an

international call from any country without knowing the dialing prefix (for example, +62 represents Indonesia).

 After inputting the prefix, you need to input

the Country number and complete telephone number. You can input the Country number according to the common practice, such as, 49 for Germany, 44 for Britain, 46 for Sweden, etc.

 Dial international telephone number as

following: ‘+’ Country number +Complete telephone number + Dial key.

5.3 Dial extension

 Some fixed-line telephone extensions may

not directly get through, so you need to connect to the switchboard at first then put through extension number. The mobile phone can automatically dial extension number if you input ‘P’ between the switchboard and extension number. Method for input ‘P’ as following: hold press or continually short press three times ‘*’ key (‘P’ will be shown on the display).

 Dial fixed-line telephone extension as

following: phone number + ‘P’ + extension

number + dialing key.

5.4 Emergency calls

If your phone is under the network coverage (you can know this by checking the signal bar at the up left corner on the screen), you can make emergency calls. If your network supplier does not provide roaming service in this area, Emergency will be shown on the screen. That means you can only make these kind of calls. If your phone is under the network coverage, you can even make emergency calls without the SIM card.

* In some areas, 112 (emergency call) service is provided by the network operator. In case of failure, consult the network operator.

6. Basic operation

6.1 Switch on

Press the switch-on/off key to start the mobile phone, then the screen will display switch-on image. Then you can enter Settings menu to set phone modes, including SIM1 & SIM2 On, Only SIM1 On, Only SIM2 On and Flight. The default one is Only SIM1 On.

After inserting the SIM card, the mobile phone will automatically check the SIM card availability,

and then it will show information as following on the display:  Input phone password——If you have set

the password.

 Input PIN —— If you set SIM card password.  No service—Indicates fail to make register

and cannot make any calls.

 Emergency calls only—indicates has

registered to other network and only can make call to 112.

 Searching—the mobile phone is searching

network until find appropriate network;

 Operator name—Indicates network

successfully registered.

Note: If you do not know PIN code, please contact the network service provider. The default phone password “0000”.

6.2 Switch off

To switch off the mobile phone, press the end key. When the screen displays switch-off cartoon, the host and the slave will be off at the same time. Do not take out the battery to switch off the mobile phone. If so, the SIM card can be damaged easily and some data will be lost.

6.3 Dial a Call

 With the number keypad, you can enter

phone numbers (if wrong characters are

input, press the clear key to delete them). Press the dial key to dial the phone number. In SIM1 and SIM2 On state, you can choose to dial a call via SIM1 or SIM2. To end a call, press the end key; or to cancel a dial, press the Cancel key or the switch-on/off key. After the call is connected, you can see the call timer on the screen.

 Dial a call via phonebook: Enter the

phonebook and search the desired name/phone number, and then press dial key to dial call.

 Redial latest dialed number: In standby

state, press dial key to view the list of the latest dialed 20 phone number or names. Roll to the desired phone number or name and press dial key to dial call.

6.4 Adjust Receiver Volume

In call conversation, press the “+”and “-” to adjust the volume of the receiver.

6.5 Answer a Call

When there is a call, as per the settings of the mobile phone, you will be alerted with ring, vibration, vibration and ring as well as ring after vibration.

+ 63 hidden pages
