Micromax D303 User Guide

D303

User Guide

www.micromaxinfo.com

Content

KITKAT 4.4.2 ..............................................................................................

Read Me First ...........................................................................................

Disclaimer ..................................................................................................

Understand Your Phone........................................................................

SIM and Memory Card Insertion .......................................................

Handset Keys ............................................................................................

Power Key ..........................................................................................

Volume Keys .......................................................................................

Navigation Keys ................................................................................

Firstouch Launcher ................................................................................

Charge the Battery .................................................................................

Home Screen ............................................................................................

Application Launcher ............................................................................

Account Configuration ..........................................................................

Google Account .................................................................................

Other Accounts ..................................................................................

Notifications .............................................................................................

Gravity Sensor ..........................................................................................

Phone Security .........................................................................................

Unlock the Screen ............................................................................

Phone Unlocking Methods ...........................................................

Google Search .........................................................................................

Using the Touch Screen ......................................................................

Tap and Hold .....................................................................................

Drag an Item .....................................................................................

Scroll ....................................................................................................

Swipe ....................................................................................................

Using the Pinch Zoom ....................................................................

10 10 11

11 11

Double-tap

Using the Onscreen Keyboard

Recent Applications

Make a Call ................................................................................................

Video Call

Contacts

Synchronize Your Contact List

Airplane Mode

Send Message

Camera

Gallery

Music Player

FM Radio

.........................................................................................

...................................................

..............................................................................

..................................................................................................

....................................................................................................

....................................................

........................................................................................

.......................................................................................................

........................................................................................................

............................................................................................

...................................................................................................

Settings, Networks, & Applications

Connect to the Internet Tethering & Portability Pair With Bluetooth Devices Google Maps

Manage Applications Safety Precautions Taking Care of Your Device Battery Recommendations Recycle your Phone Copyright

...................................................................................................

.................................................................

..................................................................

.......................................................

.....................................................................................

.....................................................................

................................................................................

................................................................

..............................................................................

................................................

25 26

18 19 20 21 21

22 22 23 23 24 24

KITKAT 4.4.2

Micromax D303 comes with KITKAT 4.4.2 that is capable of performing

various functions just like your personal computer and can be personalized according to your own needs. For example, you can add and remove applications or upgrade existing applications to improve the functions. At the Google Play Store, an ever-growing range of applications, games, movies, and books are available for you to download.

Read Me First

Please read all safety precautions and this manual carefully before using your device to ensure safe and proper use.

The descriptions in this manual are based on the default settings of your device.

Available features and additional services may vary by device, software, or service provider.

Applications and their functions may vary based on the country, region, software or hardware specifications. Micromax is not liable for performance issues caused by third-party applications.

Disclaimer

32 33 33

The colors, specifications, functions and graphics shown/mentioned in the user manual may differ from the actual product. In such a case, the latter shall govern. Images shown are for representation purpose only. Specifications are subject to change without prior notice. Micromax keeps the right to modify the content in this user guide without prior notice.

Upon first use of your device, your device will send information related to your mobile, IMEI numbers, location details and other software details through SMS* automatically. This information may be used as further specified in Micromax privacy policy**.

Talk and standby times are affected by network preferences, type of SIM cards, connected accessories and individual usage patterns. Services and some features may be dependent on the network, service/content providers, SIM cards, compatibility of the devices used

and the content formats supported. Other product logos and company names mentioned herein may be

trademarks or trade names of their respective owners.

*Operator tariff shall be applicable for SMS. **Micromax privacy policy is available at www.micromaxinfo.com.

Understand Your Phone

SIM and Memory Card Insertion

Your D303 is a dual SIM phone with expandable memory. Switch off your phone before SIM/memory card insertion/removal and insert the card(s) in the slots correctly.

Switch off your phone and remove the rear cover.

Remove the battery (if inserted).

Insert the SIM card in the upper SIM slot, as indicated.

Pull out the SIM tray with the notch, as indicated.

Place the SIM card on the SIM tray and push the tray back to

position, as indicated.

Insert the memory card in the memory card slot.

Please keep the SIM Card out of the reach of children. The card and the contacts are vulnerable to damage due to

scratching or bending. Therefore, be careful when using, inserting or removing the cards.

Use only compatible memory cards with this device. Incompatible

memory cards may damage the card or the device and corrupt the data stored in the card.

Handset Keys

Power Key

Turn On : Turn your phone on by pressing

the Power key for 3-4 seconds. Wake up t he Screen : Firmly press the

Power key to wake up the screen or to turn off the screen.

Turn Off : Wake up the screen first. Now, long press the Power key then tap "Power off" to turn off the phone.

Quick Options : Wake up the screen first. Now, press the Power key for 2 seconds to view quick options to turn off the phone, reboot, switch to airplane mode, or adjust the sound profiles.

Volume Keys

Adjust the in-call, media, and ringtone volume from the volume keys available on the left side of the device.

Handset Keys

Navigation Keys

Opens a menu with items that affect the current screen or application.

While you are on the home screen, tap to view

Menu Key

Home Key

Back Key

quick access options. Long tap to open the list of most recently used

applications.

Opens the Home screen. If you are viewing any of the extended Home screens, opens the default Home screen.

Long tap to open Google Now.

Takes you to the previously opened screen until the Home screen appears.

If the onscreen keyboard is open, closes the keyboard.

Firstouch Launcher

By default, Firstouch launcher is enabled in your handset. Firstouch is a Smartphone Operating System built on Android. This launcher is designed to simplify your smartphone experience and enhance accessibility by giving basic feature shortcuts. All the application icons are available on the home screen.

All screens and navigation shortcuts used in this User Manual are

based on the basic Android launcher.

You may turn on/off Firstouch launcher.

Turn Off Firstouch Launcher To turn off Firstouch launcher, go to the Settings section and select

Android as the Launcher.

Turn On Firstouch Launcher To turn on Firstouch Launcher, go to the Settings Home and select

Firsttouch Launcher.

You may configure Firstouch launcher settings from Firstouch Settings.

76432

Charge the Battery

Before using the device for the first time, we recommend you to use the power adapter to fully charge the battery.

Connect the power adapter to the power outlet and the USB cable, as

illustrated in the following image:

When turned on, the battery level and charging status gets displayed in the upper-right corner of the screen.

Use only Micromax chargers and cables. Other chargers or cables can

cause the battery to explode or damage your device. This may invalidate your phone warranty.

Home Screen

You can personalize your home screen with shortcuts, widgets, and wallpapers. To view quick options to change wallpaper, add widgets, or open settings section, tap the key. You can add extensions to the home screen by dragging an item to the right edge of the screen until a new screen appears. Your D303 will show only those extended home screens that have some shortcut/widget placed on them. Swipe left or right on the home screen to view the next extended home screen.

In the bottom pane, there will be five launcher icons for you to open different sections in the phone. Except the application launcher in the middle of the pane, you can rearrange and manage the other four icons. Tap and hold to select a launcher icon and then you can rearrange, change, or remove them with ease.

Know More About Widgets…

Widgets allow placing application shortcuts on your home screen. You can place analog clock, your recent call logs, and other such sections of your phone on the home page and access them directly! View all available widgets by tapping the key and then tapping Widgets.

Application Launcher

Application launcher or Application menu is available right in the middle of the home screen bottom pane.

Tap to view all inbuilt and installed applications. In the application menu, tap and hold any application to take it to the home screen; release the hold to place at any desired location on the home screen.

Account Configuration

Google Account

Some applications and services of your smartphone may require you to sign in to your Gmail account. If you do not have an existing Gmail account, you can easily sign up and create a new account from the Gmail app in your phone.

Configuring Gmail account will not only allow you to access your emails but will also enable you to sync your phone calendar and contacts with your Gmail account. Changing your handset and taking contact list backup cannot get easier. In addition to this, your Gmail account lets you take full advantage of applications and services offered by Google on your Android phone. Configure your Google account on this handset to get an ease-of-access and sync your preferences and data on some applications rendered by Google.

Network connection is required for a successful Gmail account configuration.

Other Accounts

In addition to Gmail, you can configure other email accounts from:

Add account

Also, you can download desired email application from the Play Store and access emails from the respective application.

119 1210

Notifications

When you receive a notification, its icon appears in the status bar, along with a brief summary. You may clear each notification separately by swiping it towards left or right.

Open

Notification Panel

Open

Toolkit Quick Access Panel

Notification Panel

Toolkit provides you shortcuts to manage basic phone features, such as Airplane Mode, Wi-Fi, Display Brightness, and many more.

Gravity Sensor

Your phone has gravity sensor to detect gravity and display correct orientation based on the motion.

Clear

All Notifications

13 14 15

You can enable/disable the auto-rotate feature by dragging down the notification panel, tapping , and then select AUTO ROTATION. Or You can enable/disable the auto-rotate feature from:

Display Auto-rotate screen

Phone Security

Unlock the Screen

By default, Slide Unlock is your unlocking technique.

To unlock:

Wake up the screen by firmly pressing the Power key.

1. Place your finger on the lock icon and drag it towards the unlock icon

2. to unlock the screen.

Phone Unlocking Methods

Protect your phone from unauthorized access. Once locked, the phone can be unlocked by providing the unlocking password set while choosing the unlocking technique.

Choose and set a screen unlocking technique from:

Security Screen lock

It is important to remember the passwords and commands, which you set for your phone. A forgotten password cannot be retrieved.

Slide Unlock

Place your finger on the lock icon and drag towards the unlock icon.

Face Unlock

Set your face as the screen unlock password. The front facing camera recognizes your face and unlocks the device.

Face unlock feature may recognize photographs and thus may be less secure as compared to other unlock methods.

Voice Unlock

Set voice commands to unlock the phone. Also, you can set wake up commands to unlock and launch dialpad/messaging/camera directly.

Set a PIN of atleast four digits as the password to unlock.

Pattern

Connect the dots to form a pattern and use the same to unlock.

Password

Set and use an alphanumeric password of atleast 4 characters to unlock the phone.

Google Search

Search anything in your phone or in the outside world from Google Search. You can type your search keywords or can even speak it up as your search

supports voice recognition also. Use voice commands to access various

useful sections on your handset. Google Search is available on the home screen and in the application menu

too.

Using the Touch Screen

Tap and Hold

Tap and hold an item to view the list of actions based on the selected item and condition. Also, you can move an item from the Apps screen to the home screen using this method.

Drag an Item

Tap and hold an item and move your finger on the screen until you reach the target position. The item follows your finger.

16 17

You can generally drag items from one location to another on the home screen. Also, you can delete items from the home screen by holding the item and dragging it to the Remove label that becomes available only when you hold the item on the Home screen.

Scroll

To scroll a list, slide your finger across the surface of the screen upwards or downwards (without dragging an item).

Swipe

Place a finger on the screen and steadily slide your finger in the desired direction.

Play Store

For example, when you are viewing a picture, to view the next picture, swipe left.

Using the Pinch Zoom

You can open any image or web page and then use your thumb and index finger to zoom the display through the pinch gesture.

Double-tap

Tap quickly twice on a webpage, map, or other screen to zoom. For example, double-tap a section of a webpage in the browser to zoom that section.

Using the Onscreen Keyboard

Some applications display the keyboard by default. In others, you will be required to tap a text field, where you want to enter text, to open the keyboard.

18 19 2725 28262423222120 29 30 31 32 33

QWERTY touch

pad

Tap to change the

sentence casing Tap to switch to

numerical

keyboard with

punctuation

marks

After typing, tap key to close the keyboard.

Tap and hold the text field to open a menu and to cut/copy/paste text.

Backspace to

erase the

entered text

Tap once for

speech-to-text recognition and long tap for input options.

Recent Applications

Tap and hold the key to view the list of recent applications. You can easily remove items from the list to free some memory and make your phone work faster.

There are two ways to remove items from the list

Drag an item towards left

or right

Tap and hold an item and them

select Remove from list

Make a Call

Tap on the menu screen or the home screen to open the dial pad for making calls.

By default, the dialer will display a list of contacts on which calls have been made very often and the contacts which have been marked as favorites. You can show the dialer by tapping or view the call history by tapping

Video Call

Your handset supports video calling using which you can talk face-to-face with your friends via real-time video streaming.

To make a video call:

Open the contact details of the call recipient from the contacts list and then tap to make a video call

Or Dial a number on the dialer, tap the icon and then select Video Call.

To make a video call, you need to enable 3G on your SIM card. Please contact your service provider for 3G data pack details.The video call recipient also needs to have a 3G connection.

Contacts

Go to

Store, use, and synchronize contact details in your contact list. You can now

create contact groups or mark contacts as favorites in your phonebook. Use

tabs or swipe through to view the list of contact groups, contacts, and favorite contacts list.

Favorite

Contacts

Contacts List Contact Groups

Add a new contact to the contacts list by tapping icon and then entering the contact name, number and details in the respective fields.

Synchronize Your Contact List

You can synchronize the contact list with any of your accounts configured on this device.

To synchronize your contact list:

1. Tap the key on the contacts screen and then tap Accounts.

2. Select the account(s) with which contact list is to be synchronized.

You can auto-sync contacts by selecting the Auto-sync app data option.

Your contacts synchronization will be complete in a few seconds.

To synchronize contacts, you need to have Internet connectivity via your SIM or Wi-Fi. If your Sync does not proceed as expected, check network connectivity.

Airplane Mode

Some locations may require you to disable all the network-related functions of your mobile. The Airplane Mode enables you to disable all incoming and outgoing calls, Wi-Fi, and Bluetooth connections.

To activate the airplane mode:

Press and hold the Power button and then select Airplane mode.

Drag down the notification panel, tap , and then select AIRPLANE

MODE.

Send Message

To send a message:

Tap on the menu screen or the home screen to go to the messaging section and then tap to compose a message.

Tap the icon to view the types of files that can be attached and select the desired type of multimedia file.

Tap to select the composition text box and enter your message body in it.

Enter the contact name (if it exists) or enter the phone number. You can also tap the icon to view and select contact(s) from the contact list.

Tap to send the multimedia message.

Camera

Go to

Switch to

Normal mode

Switch to

Panorama capture

HDR mode

Manage

camera

flashlight

Swap between front and back camera

Camera settings

Open picture gallery

Capture

Shoot video

Gallery

Go to

You can use the Gallery to view pictures and play videos and share files. Tap an album to open and view its contents.

Music Player

Go to

Open Music

Library

Play previously

played song

Play/Pause song

Press the phone’s volume up/down keys on the left side of the phone to adjust the volume.

You can use an SD card to enhance the storage capacity for your multimedia files such as music, photos, emails, and so on.

Open options list

Open the playlist Turn on/off songs shuffle

Turn on/off repeat songs

Adjust volume

Play next song in the playlist

FM Radio

Go to

You can listen to your favorite FM channels using the inbuilt FM receiver of your phone. Before starting the FM, you need to plug-in the headset as it

works as antenna for the FM radio. Use the intuitive buttons and icons on

the phone in the radio interface to enjoy the features of your inbuilt FM radio.

Press the phone’s volume up/down keys on the left side of the phone to adjust the volume.

Settings, Networks, & Applications

Your phone can connect to networks and devices, including Internet, Wi-Fi, GPRS, Bluetooth, and devices, such as headsets. You can also transfer files to/from your PC through the data cable.

Go to

Connect to the Internet

To configure Internet go to Dual SIM Setting Data connection and select the SIM on which data connection is to be enabled.

You may also need to configure the access point name for the data connection to work.

To configure the access point name, go to More Mobile networks A ccess Point Names and select the SIM for which access point name is to be configured. Select the access point name from the list.

By default, the access point name gets configured once you insert the SIM or your network provider sends the access point name settings via SMS. You may need to install these settings. If the access point names are not listed by default, please contact your network provider for the same.

Tethering & Portability

You can use your D303 as a modem and connect your PC or laptop to the Internet, when required. Start using your SIM data pack on your PC or Laptop now!

Go to More Tethering & portable hotspot.

USB Tethering

Connect your phone with your PC/Laptop

via USB cable.

Select the USB tethering option.

2. Select your phone network as the network

3. connection in your PC/laptop and get access to the Internet.

Bluetooth Tethering

Pair your phone with the Bluetooth

1. enabled PC/laptop via Bluetooth pairing option.

Select the Bletooth tethering option in

2. your phone.

On the paired PC/laptop, select the

3. Bluetooth device (your phone) and choose to connect to the Internet.

Wi-Fi Hotspot

Turn on the Wi-Fi hotspot option in your

1. phone.

On the other Wi-Fi enabled

2. PC/laptop/handset, choose your phone as a Wi-Fi network to connect with it.

View and configure Wi-Fi hotspot settings

3. by tapping the Wi-Fi hotspot option.

Your mobile operator will charge you based on your data usage.

Pair With Bluetooth Devices

Go to Bluetooth

To pair your D303 with some other Bluetooth device:

If Bluetooth is off, turn it on and then tap Bluetooth. Your phone scans

1. and displays the list of Bluetooth devices in range.

Tap the ID of the other device in the list to pair with it.

2. You will be prompted to confirm passkey on both devices. Tap Pair to

3. confirm the passkey and pair the devices. On successful pairing, your phone connects to the device.

If the device you want to pair with is not in the list, make it discoverable and then search. If your phone stops scanning before you make the other device discoverable, tap SEARCH FOR DEVICES.

Tap Micromax D303 at the top of the scanned device list to make your D303 visible on other devices.

Google Maps

Google Maps is an app from Google that gives you access to various map-related services. You can view your location on a map, search for different landmarks, find directions to locations, and even view Street View photos from around the world. The built-in navigation works with GPS to give step-by-step route guidance while driving or walking. You can download maps to use offline, when you don't have an Internet connection. For the best experience with Google Maps, configure the following settings:

Enable location access from Location.

Go to to start using Google Maps.

Internet connection is required for using Google Maps. When you use the map, you use your Internet connection to transfer data to and from your phone.

The Google Maps application may not be available in every street, country or region.

Micromax does not guarantee the accuracy of any directional services

Manage Applications

Your phone comes with a host of applications to make your life easier and more convenient. The Android phones offer users access to unlimited entertainment sources. You can download applications, games, movies, and books from the ever-increasing Google Play Store. New items get added almost daily to the Play Store to give users a never-ending fun experience.

To view and manage the list of all inbuilt, downloaded, and running applications, go to Apps.

To download applications, games, movies, and books from the Google Play Store, go to to access the Google Play Store. View the details and download items, as desired.

Not all items are free of cost in the Google Play Store.

You need to have an Internet connection and be signed in to your Google Account to use the Google Play Store.

Safety Precautions

Switch off your device in any area with potential explosive atmosphere. Sparks arising out of radio frequency may cause fire or explosion. Therefore switch off your device at refueling stations, fuel depots, chemical plants or places where blasting operation is in progress. Remember to comply with legal requirements and local restrictions when using the phone.

Your Phone’s radio waves may interfere with inadequately shielded medical devices. Consult a physician or manufacturer of the medical device to know whether they are adequately shielded from external Radio Frequency. Switch off your device when regulations require you to do so.

Always keep the phone and accessories out of reach of small children. Small parts such as the SIM card or microSD card can be dismantled and swallowed by small children.

Do not place the phone near electromagnetic data carriers such as credit/Debit cards. Information stored on them could be lost.

Permanent damage to hearing may occur if you use earphones at high volume for prolonged periods. Set your volume to a safe level. If you experience discomfort in your ears, reduce the volume or discontinue the use of your earphones.

Manufacturers of medical devices recommend a minimum distance of 15.3 cm (6 inches) between a wireless device and an implanted medical device such as pacemaker or cardiverter defibrillator to avoid issues arising out of radio frequency interference.

The mains voltage (V) specified on the power supply unit must not be exceeded to prevent damage to the charging device. The power supply must be plugged into an easily accessible AC power socket when charging the battery.

You may only open the phone to replace the battery (if not inbuilt), SIM card and micro SD card. You must not open the battery under any circumstances. All other changes to this device are strictly prohibited and will invalidate the warranty.

The phone may cause interference in the vicinity of TV sets, radios and PCs.

Only use Micromax specified batteries and charging devices. The battery may cause damage, injury or burns if a conductive material closes the circuit of the terminals. Exercise care in handling any charged battery, particularly when placing it inside your pocket, purse or other container with metal objects. Do not dispose of batteries in fire as they may explode.

Do not use the phone while driving. When you have to use the phone, please use the earpiece. Please put the phone safely in the phone stand. Do not put it onto any passenger seat or any place from which it may fall down during collision or emergency braking.

Flight is influenced by interference caused by the phone. It is illegal to use a phone on the airplane. Please turn off your phone during a flight.

The phone must be repaired by Micromax authorized personnel only. Repairing this phone by yourself other than our authorized service agents/centers goes against the warranty rules.

Taking Care of Your Device

Your device is a product of superior design and craftsmanship and should be handled with care. The following suggestions will help you protect your phone.

• Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can rust the electronic circuits. If your device gets wet, remove the battery, wipe it with a dry cloth and take it to an authorized service

center.

• Do not store the device in high or cold temperature. Extreme temperatures can shorten the life of electronic devices and damage batteries.

• Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can get damaged.

• Do not attempt to open the device other than as instructed in this guide.

• Do not drop, knock, or shake the device. Rough handling can break

internal circuit boards and fine mechanics.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the device. Only use a soft, clean, dry cloth to clean the surface of the device.

• Do not store your device near magnetic fields or allow your device to

come in contact with magnetic fields for extended period of time.

Battery Recommendations

• Please put the battery in a cool and well-ventilated place out of direct

sunlight. We recommend you to charge the battery at room temperature range.

• Batteries have life cycles. After a full charge, if the power reserve of the battery tend to deplete inordinately faster than usual, the battery life is at an end. Replace the battery with a new battery of the same make and specification.

• Use manufacturer approved batteries, chargers, accessories and supplies.

Micromax will not be held responsible for user’s safety when using unapproved accessories or supplies.

• Do not discard the battery with household trash. Please dispose of used

battery according to your local environmental laws and guidelines.

Recycle your Phone

The WEEE logo (shown at the left) appears on the product (battery, handset, and charger) to indicate that this product must not be disposed off or dumped with your other household wastes. You are liable to dispose of all your electronic or electrical waste equipment by relocating over to the specified collection point for recycling of such hazardous waste.

Collection and proper recovery of your electronic waste equipments at the time of disposal will allow us to help preserve the environment. Recycling of the electronic waste equipment will ensure safety of human health and environment. For more information on best practices for disposal of electronic and electrical waste, please visit to our web site: www.micromaxinfo.com/weee.php.

Note: Micromax will not bear any responsibility for any incompliance with the above mentioned guidelines or improper usage of the mobile phone.

All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Micromax is strictly prohibited.
