CONTENTS
THE ANDROID ADVANTAGE ........................................................................................... 3
READ ME FIRST .............................................................................................................. 3
DISCLAIMER..................................................................................................................... 3
UNDERSTAND YOUR PHONE ......................................................................................... 5
GETTING STARTED .......................................................................................................... 5
SIM CARD INSERTION.............................................................................................. 5
MEMORY CARD INSERTION ..................................................................................... 6
HANDSET KEYS ......................................................................................................... 7
CHARGING THE BATTERY ......................................................................................... 8
BASIC PHONE FEATURES ............................................................................................... 9
TM
GOOGLE
ACCOUNT............................................................................................... 9
HOME SCREEN ........................................................................................................10
APPLICATION LAUNCHER .......................................................................................10
NOTIFICATIONS........................................................................................................11
GRAVITY SENSOR ....................................................................................................12
PHONE LOCKING TECHNIQUES ..............................................................................12
TM
USE GOOGLE
SEARCH .......................................................................................15
USING THE TOUCH SCREEN .........................................................................................16
TAP AND HOLD........................................................................................................16
DRAG AN ITEM ........................................................................................................16
SCROLL.....................................................................................................................16
SWIPE .......................................................................................................................17
USING THE PINCH ZOOM .......................................................................................17
DOUBLE-TAP ............................................................................................................17
USING THE ONSCREEN KEYBOARD .......................................................................18
RECENT APPLICATIONS ..........................................................................................19
CALLING AND MESSAGING ..........................................................................................20
MAKE A CALL ..........................................................................................................20
1
CONTACTS................................................................................................................20
VIDEO CALL..............................................................................................................21
AIRPLANE MODE ....................................................................................................22
SEND MESSAGE ......................................................................................................22
MULTIMEDIA .................................................................................................................24
CAMERA ...................................................................................................................24
GALLERY ...................................................................................................................24
MUSIC PLAYER ........................................................................................................25
FM RADIO................................................................................................................26
SETTINGS, NETWORKS, AND APPLICATIONS .............................................................27
CONNECT TO THE INTERNET..................................................................................27
TETHERING & PORTABILITY ...................................................................................28
PAIR WITH BT DEVICES .........................................................................................29
CONFIGURING E-MAIL............................................................................................29
TM
GOOGLE
MAPS....................................................................................................30
MANAGE APPLICATIONS ........................................................................................31
SAFETY PRECAUTIONS .................................................................................................32
TAKING CARE OF YOUR DEVICE ....................................................................................33
BATTERY RECOMMENDATIONS .............................................................................34
RECYCLE YOUR PHONE ...........................................................................................34
COPYRIGHT ....................................................................................................................35
2
The Android Advantage
Micromax A093 comes with KITKAT 4.4.2 that is capable of performing
various functions just like your personal computer and can be
personalized according to your own needs. For example, you can add
and remove applications or upgrade existing applications to improve
the functions. At the Android market, an ever growing range of
applications, games, movies, and books are available for you to
download.
Read Me First
Please read all safety precautions and this manual carefully
before using your device to ensure safe and proper use.
The descriptions in this manual are based on the default
settings of your device.
Available features and additional services may vary by
device, software, or service provider.
Applications and their functions may vary based on the
country, region, software or hardware specifications.
Micromax is not liable for performance issues caused by
third-party applications.
Disclaimer
The colors, specifications, functions and graphics
shown/mentioned in the user manual may differ from the
actual product. In such a case, the latter shall govern. Images
shown are for representation purpose only. Specifications are
subject to change without prior notice. Micromax keeps the
right to modify the content in this user guide without prior
3
notice.
Upon first use of your device, your device will send
information related to your mobile, IMEI numbers, location
details and other software details through SMS*
automatically. This information may be used as further
specified in Micromax privacy policy**.
Talk and standby times are affected by network preferences,
type of SIM cards, connected accessories and individual
usage patterns. Services and some features may be
dependent on the network, service/content providers, SIM
cards, compatibility of the devices used and the content
formats supported.
Other product logos and company names mentioned herein
may be trademarks or trade names of their respective
owners.
*Operator tariff shall be applicable for SMS.
**Micromax privacy policy is available at www.micromaxinfo.com.
4
Understand Your Phone
Getting Started
SIM Card Insertion
Your A093 is a dual SIM phone with one standard SIM slot and another
micro SIM slot. Switch off your phone before SIM insertion/removal
and insert the SIM card in the SIM slots correctly.
1. Remove back cover.
2. Remove battery.
3. Insert SIM card.
5
Please keep the SIM Card out of the reach of children.
The card and the contacts are vulnerable to damage due
to scratching or bending. Therefore, be careful when
using, inserting or removing the cards
Memory Card Insertion
To store additional multimedia files, you must insert a memory card.
1. Remove back cover.
Use only compatible memory cards approved by
Micromax with this device. Incompatible memory cards
may damage the card or the device and corrupt the data
stored in the card.
2. Remove battery.
6
3. Insert memory
card.
Handset Keys
Keys Functions
Long press to switch on or
switch off the phone.
Press once to turn off the screen
or to wake up the screen.
Press for 2 seconds to view quick
options to turn off the phone,
reboot the device, switch to
airplane mode, or adjust the
sound profiles.
Adjust the phone volume from
the volume keys available on the
right side of the device.
Opens a menu with items that
affect the current screen or
application.
If tapped when on the home
screen, opens options to
personalize the home screen.
On long tap, opens the most
recently used applications.
Opens the Home screen.
On long tap, opens GoogleTM
Now.
7
Opens the previous screen you
were working on.
If the onscreen keyboard is open,
closes the keyboard.
Charging the Battery
Before using the device for the first time, you must charge the battery.
You can charge the device with a travel adapter or connecting the
device to a PC with a USB cable.
You can also use a compatible USB charger to charge your
battery.
Use only Micromax approved chargers and cables.
Unapproved chargers or cables can cause battery to
explode or damage your device.
We suggest you charge the battery for 4 hours
continuously for the first time.
8
Basic Phone Features
TM
Google
Account
Your GoogleTM Account lets you take full
advantage of applications and services offered
by GoogleTM Android market. Configure your
GoogleTM account on this handset to get access
to your GoogleTM mails, GoogleTM Play Store,
GoogleTM Maps, and much more.
GoogleTM account setup will be prompted when you turn on your
handset for the first time.
Network connection will be required for the GoogleTM
account setup step to appear.
However, you may configure your GoogleTM account at any later stage
from → → Add account → Google. Follow the registration
steps to successfully configure your mail account on the device.
If you do not have an existing GoogleTM account, you may
create one from the account configuring step.
You may add various other accounts, depending on your
applications.
9
Home Screen
You can personalize your home screen with shortcuts, widgets,
wallpapers and other items. To view quick options to change
wallpaper, add widgets, or open settings section, tap the key. You
can add extensions to the home screen by placing widgets or
application shortcuts on the extended home screen. Your A093 will
show only those extended home screens which have some
shortcut/widget placed on them. Swipe left or right on the home
screen to view the next extended home screen.
In the bottom pane, there will be five launcher icons for you to open
different sections in the phone. Except the application launcher in the
middle of the pane, you can rearrange and manage the other four
icons. Tap and hold to select a launcher icon and then you can
rearrange, change, or remove them with ease.
Know More About Widgets…
Widgets allow placing application shortcuts on your home screen. You
can place analog clock, your recent call logs, and other such sections
of your phone on the home page and access them directly! View all
available widgets by tapping the key and then tapping Widgets.
Application Launcher
Application launcher or Application menu is available right in the
middle of the home screen bottom pane.
10
Tap to view all inbuilt and installed applications. In the application
Open Notification Panel
Close Notification Panel
menu, tap and hold any application to take it to the home screen;
release the hold to place at any desired location on the home screen.
Notifications
Notification icons inform you of new messages and events as and
when it appears in the device.
Open the Toolkit
Clear all Notifications
When you receive a notification, its icon appears in the status bar,
along with a brief summary. You may clear each notification
11
separately by swiping it towards left or right.
.
Toolkit provides you shortcuts to manage basic phone features, such
as Airplane Mode, Wi-Fi, Display Brightness, and many more.
Gravity Sensor
Your phone has gravity sensor to detect gravity and display correct
orientation based on the motion.
You can enable/disable the auto-rotate feature by dragging down the
notification panel, tapping , and then select AUTO ROTATION.
Or
You can enable/disable the auto-rotate feature from → →
Display → Auto-rotate screen
Phone Locking Techniques
You may need to provide PIN, password, draw a pattern, take your face
in front of the phone screen, speak something for voice recognition, or
simply slide to unlock your phone.
Slide unlock will be the default unlocking method in the phone. To
12
unlock the screen:
1. Press the power key to wake up the phone.
2. Hold and drag the lock icon towards the unlock icon.
Face Recognition
Allowing you to keep
your face as screen
unlocking password. You
just need to look at your
Look at your phone to unlock it!
Voice Recognition
Speak your password to unlock!
phone to unlock it.
Allowing you to provide
your voice as the screen
unlocking password. You
need to speak something
for the phone to
recognize your voice and
unlock the screen.
PIN
You may enter a PIN and
set it as your screen
unlocking password.
Enter your PIN to unlock your phone!
13
Pattern
Set and draw your desired pattern!
Password
Enter your password to unlock!
Slide
Slide from lock icon to unlock icon!
You may set any desired locking technique from →
→ Security → Screen lock.
It is important to remember your screen lock
password/pattern/PIN.
14
You can set your own
pattern by connecting
the dots to prevent your
phone from unauthorized
access.
You may enter any
desired password and
set it as your screen
unlocking password.
Just wake up the screen
and slide the lock icon
towards the unlock icon
to unlock your phone.
You can disable all unlocking methods from your handset by selecting
the None option.
Use Google TM Search
Search anything in your phone or in the outside world from GoogleTM
Search. You can type your search keywords or can even speak it up as
your search supports voice recognition also. Use voice commands to
access various useful sections on your handset.
GoogleTM Search is available on the home screen and in the
application menu too.
15
Using the Touch Screen
Tap and Hold
Tap and hold an item to view
the list of actions based on the
selected item and condition.
Also, you can move an item
from the Apps screen to the
home screen using this
method.
Drag an Item
Tap and hold an item and move your finger on the screen until you
reach the target position. The item follows your
finger.
You can generally drag items from one location
to another on the home screen. Also, you can
delete items from the home screen by holding
the item and dragging it to the Remove label that
becomes available only when you hold the item
on the Home screen.
Scroll
To scroll a list, slide your finger across the
surface of the screen upwards or downwards
(without dragging an item).
16
Swipe
Place a finger on the screen and steadily slide your
finger in the desired direction.
For example, when you are viewing a picture, to
view the next picture, swipe left.
Using the Pinch Zoom
You can open any image or
web page and then use your
thumb and index finger to
zoom the display through
the pinch gesture.
Double-tap
Tap quickly twice on a webpage, map, or other
screen to zoom. For example, double-tap a section
of a webpage in the browser to zoom that section.
17
Using the Onscreen Keyboard
numerical keyboard
Some applications display the keyboard by default. In others, you will
be required to tap a text field, where you want to enter text, to open
the keyboard.
Tap to
change the
sentence
casing.
Tap to switch to
with punctuation
symbols.
After typing, tap key to close the keyboard.
Tap and hold the text field to open a menu and to
cut/copy/paste text.
18
QWERTY touch
pad.
Backspace to
erase the
entered text.
Long tap for input
options.
Recent Applications
Tap and hold the key on the home screen to view the list of recent
applications. You can easily remove items from the list to free some
memory and make your phone work faster.
There are two ways to remove items from the list.
Drag an item towards left or right.
Tap and hold an item and
then select “Remove from
19
list”.
Calling and Messaging
View list of
View list of
View list of
Make a Call
To make a call:
Tap on the menu screen or the home screen to open the dial pad
for making calls.
By default, the dialer will display a list of contacts on which calls have
been made very often and the contacts which have been marked as
favorites.
You can show/hide the dialer by tapping or view the call history by
tapping .
Contacts
Go to →
Store, use, and synchronize contact details in your contact list. You can
now create contact groups or mark contacts as favorites in your
phonebook. Use tabs or swipe through to view the list of contact
groups, contacts, and favorite contacts list.
favorite contacts
contacts
contact groups
20
Search for your desired contacts under any of the three
tabs by tapping icon.
Add a new contact in the contacts list by tapping .
You can synchronize your contacts list with any of your accounts
configured on this device.
To synchronize your contacts list:
1. Tap the button from the contacts screen and then tap
Accounts.
2. Select the account(s) with which contacts list is to be
synchronized. You can auto-sync contacts by selecting the
Auto-sync app data option.
Your contacts synchronization will be complete in a few seconds.
For synchronize contacts, you need to have Internet
connectivity via your SIM or Wi-Fi. If your Sync does not
proceed as expected, check whether data option is set to
ON.
Video Call
Your Handset supports video calling using which you can talk face to
face with your friends via real time video streaming. You need to fulfill
the following conditions for video calling:
You need to enable 3G on your SIM card. Please contact your
service provider to enable 3G on your SIM card.
21
The video call recipient also needs to have a 3G enabled SIM
card.
To make a video call, open the contact details of the call recipient
from the contacts list and then tap to make a video call or type a
number on the dialer, tap the icon and then select Video Call.
Airplane Mode
Some locations may require you to disable all the wireless features of
your mobile. The Airplane Mode enables you to disable all incoming
and outgoing calls, Wi-Fi, and BT connections.
To activate the airplane mode:
1. Press and hold the Power button and then select Airplane
mode.
Or
Drag notification panel down, tap , and then select
AIRPLANE MODE.
Send Message
To send a message:
1. Tap on the menu screen or the home screen to go to
the messaging section and then tap to compose a
message.
2. Tap the icon to view the types of files that can be
attached and select the desired type of multimedia file.
22
3. Tap to select the composition text box and enter your
message body in it.
4. Enter the contact name (if it exists) or enter the phone
number. You can also tap the icon to view and select
contact(s) from the contact list.
5. Tap to send the multimedia message.
23
Multimedia
Capturing
Start Video
Camera settings
Open picture
Swap between front
Manage
camera flash
HDR
mode
Camera
Go to →
modes
You can share/copy/move/delete images and videos
from the gallery.
Gallery
Go to →
You can use the Gallery to view pictures and play videos and share
files. Tap an album to open and view its contents.
light
and back camera
gallery
Capture
Recording
24
Music Player
Open the
playlist Turn on/off repeat
Play previously
Play next song in the
Turn on/off songs
Go to →
shuffle
songs
Adjust volume
Play/Pause song
played song
Press the phone’s volume up/down keys on the right side
of the mobile phone to adjust the volume.
You can use an SD card to enhance the storage capacity
for your multimedia files such as music, photos, emails,
and so on.
playlist
25
FM Radio
Go to →
You can listen to your favorite FM channels using the inbuilt FM
receiver of your phone. Before starting the FM, you need to plug-in the
headset as it works as antenna for the FM radio. Use the intuitive
buttons and icons on the phone in the radio interface to enjoy the
features of your inbuilt FM radio.
Press the phone’s volume up/down keys on the right side
of the mobile phone to adjust the volume.
26
Settings, Networks, and Applications
Your phone can connect to a variety of networks and devices,
including Internet, Wi-Fi, GPRS, BT, devices, such as headsets. You can
also transfer files to/from your PC through the data cable.
Connect to the Internet
To configure Internet:
1. Go to → → More → Mobile networks → Access
Point Names and select the SIM for which access point
name is to be configured. Select the access point name or
change the access point name for your Internet
connectivity as provided by the service provider of your SIM
card.
2. After you have selected or configured the access point
name, go to → → Dual SIM management → Data
connection and select the SIM on which data connection is
to be enabled.
By default, your network provider sends the access point
name settings via SMS, or it comes with your SIM card.
You may need to install these settings. After this, you can
choose from the listed access point names. If the access
point names are not listed by default, please contact your
network provider for the same.
27
Tethering & Portability
You can use your A093 as a modem and connect your PC or laptop to
the Internet, when required. Start using your SIM data pack on your PC
or Laptop now!
Go to → → More → Tethering & portable hotspot.
USB Tethering
1. Connect your phone with your PC/Laptop via USB cable.
2. Select the USB tethering option.
3. Select your phone network as the network connection in
your PC/laptop and get access to the Internet.
BT Tethering
1. Pair your phone with the BT enabled PC/laptop via BT
pairing option.
2. Select the BT tethering option in your phone.
3. On the paired PC/laptop, select the BT device (your phone)
and choose to connect to the internet.
Wi-Fi Hotspot
1. Turn on the Wi-Fi hotspot option in your phone.
2. On the other Wi-Fi enabled PC/laptop/handset, choose your
phone as a Wi-Fi network to connect with it.
3. View and configure Wi-Fi hotspot settings by tapping the
Wi-Fi hotspot option.
Your mobile operator will charge you based on your
GPRS data usage.
28
Pair With BT Devices
Go to → → BT.
To pair your A093 with some other BT device:
1. If BT is off, turn it on and then tap BT. Your phone scans and
displays the BT devices in range.
2. Tap the ID of the other device in the list to pair with it.
3. You will be prompted to confirm passkey on both devices.
Tap Pair to confirm the passkey and pair the devices. On
successful pairing, your phone connects to the device.
If the device you want to pair with is not in the list, make
it discoverable and then search. If your phone stops
scanning before you make the other device discoverable,
tap SEARCH FOR DEVICES.
Tap Micromax A093 at the top of the scanned device list
to make your A093 visible on other devices.
Configuring E-Mail
You can check and reply to your emails from your A093 from
anywhere and at anytime. Apart from the Gmail account, you can
configure other accounts too on this device.
To set up an email account:
1. Go to → → Add account → Corporate.
2. Type the email address and password in the respective
fields and tap Next.
29
3. Set account settings, as required and tap Next.
4. Provide your account name and your name and then tap
Next to successfully finish account configuration.
The server will check for online settings automatically and your
account will be set up. If not, please check your Internet settings
before proceeding.
Tap the button of the phone and then tap Refresh to
refresh your emails manually.
GoogleTM Maps
GoogleTM Maps is a web based service offered by Google Inc. which
offers you access to various map based services. You can view various
streets, landmarks and can even plan your routes with the help of
GoogleTM Maps. It comes with a navigation system (GPS required)
which gives step-by-step route guidance while driving or walking. You
can even download maps for offline usage. This serves as a useful
application for your day-to-day usage.
Settings required for GoogleTM map access include:
Enable location access from → → Location.
Go to → to start using GoogleTM Maps.
Internet connection is required for using GoogleTM Maps.
When you use the map, you use your Internet connection
to transfer data to and from your phone.
TM
The Google
Maps application may not be available in
30
every street, country or region.
Micromax does not guarantee the accuracy of any
directional services
Manage Applications
Your phone comes with a host of applications to make your life easier
and more convenient. The Android phones offer users access to
unlimited entertainment sources. You can download applications,
games, movies, and books from the ever increasing Android market.
New items get added almost daily to the market to give users a never
ending fun experience.
To view and manage the list of all inbuilt, downloaded, and running
applications, go to → → Apps.
To download applications, games, movies, and books from the Android
Market, go to → to access the GoogleTM Android Market. View
the details and download items, as desired.
Not all items are free of cost in the Android Market.
You need to enable internet connection and configure
TM
Google
account on your device to get access to the
Android Market.
31
Safety Precautions
Remember to comply with legal requirements and local
restrictions when using the phone.
Your Phone’s radio waves may interfere with inadequately
shielded medical devices. Consult a physician or manufacturer of
the medical device to know whether they are adequately shielded
from external Radio Frequency. Switch off your device when
regulations require you to do so.
Always keep the phone and accessories out of reach of small
children. Small parts such as the SIM card, dust cap, lens ring and
lens cap as well as the microSD card can be dismantled and
swallowed by small children.
Do not place the phone near electromagnetic data carriers such
as credit/Debit cards. Information stored on them could be lost.
Permanent hearing loss may occur if you use earphones at high
volume for prolonged periods. Set your volume to a safe level. If
you experience discomfort in your ears, reduce the volume or
discontinue the use of your earphones.
Ring tones, info tones and hands-free talking are reproduced
through the loudspeaker. Do not hold the phone to the ear when it
rings or when you have switched on the hands-free function.
The mains voltage (V) specified on the power supply unit must not
be exceeded to prevent damage to the charging device. The
power supply must be plugged into an easily accessible AC power
socket when charging the battery.
You may only open the phone to replace the battery, SIM and
micro SD card. You must not open the battery under any
circumstances. All other changes to this device are strictly
prohibited and will invalidate the warranty.
32
The phone may cause interference in the vicinity of TV sets, radios
and PCs.
Only use Micromax specified batteries and charging devices.
All batteries can cause property damage, injury or burns if a
conductive material Tap the exposed terminals. Exercise care in
handling any charged battery, particularly when placing it inside
your pocket, purse or other container with metal objects. Do not
dispose of batteries in fire as they may explode.
Do not use the phone while driving. When you have to use the
phone, please use the personal hands-free kit$.
Please put the phone safely in the phone stand. Do not put it onto
any passenger seat or any place from which it may fall down in
case of vehicular collision or emergency braking.
Flight is influenced by interference caused by the phone. It is
illegal to use a phone on the airplane. Please turn off your phone
during a flight.
Professional service: The phone must be installed or repaired by
Micromax authorized personnel. You are likely to suffer a huge
risk when you install or repair this phone by yourself, which also
goes against the warranty rules.
Taking Care of your device
Your device is a product of superior design and craftsmanship and should be handled
with care. The following suggestions will help you protect your phone.
Keep the device dry. Precipitation, humidity, and all types of liquids or
moisture can rust the electronic circuits. If your device gets wet, remove
the battery, wipe it with a dry cloth and take it to an authorized service
center.
Do not store the device in high or cold temperature. High temperatures
can shorten the life of electronic devices and damage batteries.
33
Do not use or store the device in dusty, dirty areas. Its moving parts and
electronic components can get damaged.
Do not attempt to open the device other than as instructed in this guide.
Repairing this phone by yourself other than our authorized service
agents/centers goes against the warranty rules.
Do not drop, knock, or shake the device. Rough handling can break
internal circuit boards and fine mechanics.
Do not use harsh chemicals, cleaning solvents, or strong detergents to
clean the device. Only use a soft, clean, dry cloth to clean the surface of
the device.
Do not store your device near magnetic fields or allow your device to
come in contact with magnetic fields for extended period of time.
Battery Recommendations
Please put the battery in a cool and well-ventilated place out of direct
sunlight. We recommend you to charge the battery at room temperature
range.
Batteries have life cycles. If the time that the battery powers equipment
becomes much shorter than usual, the battery life is at an end. Replace
the battery with a new battery of the same make and specification.
Use manufacturer approved batteries, chargers, accessories and supplies.
Micromax will not be held responsible for user’s safety when using
unapproved accessories or supplies.
Do not discard the battery with household trash. Please dispose of used
battery according to your local environmental laws and guidelines.
Recycle your Phone
The WEEE logo (shown at the left) appears on the product (battery,
handset, and charger) to indicate that this product must not be
disposed off or dumped with your other household wastes. You are
liable to dispose of all your electronic or electrical waste
equipment by relocating over to the specified collection point for
34
recycling of such hazardous waste.
Collection and proper recovery of your electronic waste equipments at the time of
disposal will allow us to help preserve the environment. Recycling of the electronic
waste equipment will ensure safety of human health and environment. For more
information on best practices for disposal of electronic and electrical waste, please
visit to our web site: www.micromaxinfo.com/weee.php.
Note: Micromax will not bear any responsibility for any incompliance with the above
mentioned guidelines or improper usage of the mobile phone.
Copyright
All rights reserved. Reproduction, transfer, distribution or storage of part or all of the
contents in this document in any form without the prior written permission of
Micromax is strictly prohibited.
35
Loading...
