Microhard Systems 17PDDL900 User Manual

Operating Manual

pDDL900

1W Dual Frequency 900MHz/2.4GHz Digital Data Link

Revision 0.35, April 11, 2017

www.microhardcorp.com

Microhard Systems Inc.

Warranty

Microhard Systems Inc. warrants that each product will be free of defects in material and workmanship for a period of one (1)
year for its products. The warranty commences on the date the product is shipped by Microhard Systems Inc. Microhard Systems
Inc.’s sole liability and responsibility under this warranty is to repair or replace any product which is returned to it by the Buyer
and which Microhard Systems Inc. determines does not conform to the warranty. Product returned to Microhard Systems Inc. for

warranty service will be shipped to Microhard Systems Inc. at Buyer’s expense and will be returned to Buyer at Microhard
Systems Inc.’s expense. In no event shall Microhard Systems Inc. be responsible under this warranty for any defect which is

caused by negligence, misuse or mistreatment of a product or for any unit which has been altered or modified in any way. The
warranty of replacement shall terminate with the warranty of the product.

Warranty Disclaims

Microhard Systems Inc. makes no warranties of any nature of kind, expressed or implied, with respect to the hardware, software,
and/or products and hereby disclaims any and all such warranties, including but not limited to warranty of non-infringement,
implied warranties of merchantability for a particular purpose, any interruption or loss of the hardware, software, and/or product,
any delay in providing the hardware, software, and/or product or correcting any defect in the hardware, software, and/or product,
or any other warranty. The Purchaser represents and warrants that Microhard Systems Inc. has not made any such warranties to
the Purchaser or its agents MICROHARD SYSTEMS INC. EXPRESS WARRANTY TO BUYER CONSTITUTES

MICROHARD SYSTEMS INC. SOLE LIABILITY AND THE BUYER’S SOLE REMEDIES. EXCEPT AS THUS

PROVIDED, MICROHARD SYSTEMS INC. DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PROMISE.

MICROHARD SYSTEMS INC. PRODUCTS ARE NOT DESIGNED OR INTENDED TO BE USED IN
ANY LIFE SUPPORT RELATED DEVICE OR SYSTEM RELATED FUNCTIONS NOR AS PART OF

ANY OTHER CRITICAL SYSTEM AND ARE GRANTED NO FUNCTIONAL WARRANTY.

Indemnification

The Purchaser shall indemnify Microhard Systems Inc. and its respective directors, officers, employees, successors
and assigns including any subsidiaries, related corporations, or affiliates, shall be released and discharged from any
and all manner of action, causes of action, liability, losses, damages, suits, dues, sums of money, expenses
(including legal fees), general damages, special damages, including without limitation, claims for personal injuries,
death or property damage related to the products sold hereunder, costs and demands of every and any kind and
nature whatsoever at law.

IN NO EVENT WILL MICROHARD SYSTEMS INC. BE LIABLE FOR ANY INDIRECT, SPECIAL,
CONSEQUENTIAL, INCIDENTAL, BUSINESS INTERRUPTION, CATASTROPHIC, PUNITIVE OR OTHER
DAMAGES WHICH MAY BE CLAIMED TO ARISE IN CONNECTION WITH THE HARDWARE,
REGARDLESS OF THE LEGAL THEORY BEHIND SUCH CLAIMS, WHETHER IN TORT, CONTRACT OR
UNDER ANY APPLICABLE STATUTORY OR REGULATORY LAWS, RULES, REGULATIONS,
EXECUTIVE OR ADMINISTRATIVE ORDERS OR DECLARATIONS OR OTHERWISE, EVEN IF
MICROHARD SYSTEMS INC. HAS BEEN ADVISED OR OTHERWISE HAS KNOWLEDGE OF THE
POSSIBILITY OF SUCH DAMAGES AND TAKES NO ACTION TO PREVENT OR MINIMIZE SUCH
DAMAGES. IN THE EVENT THAT REGARDLESS OF THE WARRANTY DISCLAIMERS AND HOLD
HARMLESS PROVISIONS INCLUDED ABOVE MICROHARD SYSTEMS INC. IS SOMEHOW HELD
LIABLE OR RESPONSIBLE FOR ANY DAMAGE OR INJURY, MICROHARD SYSTEMS INC.'S LIABILITY
FOR ANYDAMAGES SHALL NOT EXCEED THE PROFIT REALIZED BY MICROHARD SYSTEMS INC.
ON THE SALE OR PROVISION OF THE HARDWARE TO THE CUSTOMER.

Proprietary Rights

The Buyer hereby acknowledges that Microhard Systems Inc. has a proprietary interest and intellectual property rights in the
Hardware, Software and/or Products. The Purchaser shall not (i) remove any copyright, trade secret, trademark or other evidence
of Microhard Systems Inc.’s ownership or proprietary interest or confidentiality other proprietary notices contained on, or in, the
Hardware, Software or Products, (ii) reproduce or modify any Hardware, Software or Products or make any copies thereof, (iii)
reverse assemble, reverse engineer or decompile any Software or copy thereof in whole or in part, (iv) sell, transfer or otherwise
make available to others the Hardware, Software, or Products or documentation thereof or any copy thereof, except in accordance
with this Agreement.

ii PDDL2450 Operating Manual

pDDL900 Regulatory Requirements - PLEASE READ THIS SECTION

Contains:
FCC ID: NS917PDDL900 IC: 3143A-17PDDL900

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received including interference
that may cause undesired operation.

CAREFULLY

WARNING:

To satisfy FCC/IC RF exposure requirements for mobile transmitting devices, a separation distance of 36 cm or more should be
maintained between the antenna of this device and persons during device operation. To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this transmitter must not be co-located in conjunction with any other antenna or
transmitter.

WARNING:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

WARNING:

Changes or modifications not expressly approved by Microhard Systems Inc. could void the user’s authority to operate the equipment.
This device has been tested with UFL to Reverse Polarity SMA connectors with the antennas listed in Appendix A When integrated in
OEM products, fixed antennas require installation preventing end-users from replacing them with non-approved antennas. Antennas not
listed in the tables must be tested to comply with FCC Section 15.203 (unique antenna connectors) and Section 15.247 (emissions).

WARNING:

MAXIMUM EIRP
FCC Regulations allow up to 36 dBm equivalent isotropically radiated power (EIRP). Therefore, the sum of the transmitted power
(in dBm), the cabling loss and the antenna gain cannot exceed 36 dBm.

WARNING:

EQUIPMENT LABELING
The FCC and IC numbers depend on the model of the radio module. Do NOT use the Marketing Name of the product but the Model
to distinguish the Certifications Numbers. This device has been modularly approved. The manufacturer, product name, and FCC
and ISED identifiers of this product must appear on the outside label of the end-user equipment.

WARNING:

This device complies with ISED license-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause
undesired operation of the device.

SAMPLE LABEL REQUIREMENT for Model: pDDL900:

iii

pDDL900 Exigences Réglementaires

Contains:
FCC ID: NS917PDDL900 IC : 3143A-17PDDL900

Cet appareil est conforme à la partie 15 des règles de la FCC.
Son fonctionnement est soumis aux deux conditions suivantes :
( 1 ) ce dispositif ne doit pas causer d'interférences nuisibles et
( 2) cet appareil doit accepter toute interférence reçue, incluant
les interférences qui peuvent provoquer un fonctionnement
indésirable .

WARNING:

Pour satisfaire aux exigences de la FCC/IC d'exposition RF pour la base et mobiles sur une distance de séparation de 36 cm ou plus
doit être maintenue entre l'antenne de cet appareil et des personnes lors de fonctionnement du dispositif. Pour assurer la conformité
des opérations au plus près que cette distance n'est pas recommandée. L'antenne utilisée pour ce transmetteur ne doit pas être co­localisés en conjonction avec toute autre antenne ou transmetteur.

WARNING:

Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) ce dispositif ne doit pas causer d'interférences nuisibles et ( 2) cet
appareil doit accepter toute interférence reçue, incluant les interférences qui peuvent provoquer un fonctionnement indésirable .

WARNING:

Les changements ou modifications non expressément approuvés par Microhard Systems Inc. pourraient annuler l'autorité de
l'utilisateur à utiliser l'équipement . Ce dispositif a été testé avec MCX et connecteurs SMA à polarité inverse sur les antennes
répertoriées à l'annexe A Lorsqu'il est intégré dans les produits OEM , antennes fixes nécessitent une installation empêchant les
utilisateurs finaux de les remplacer par des antennes non approuvées . Antennes ne figurant pas dans les tableaux doivent être testés
pour se conformer à la Section 15.203 (connecteurs d'antenne uniques ) et à la Section 15.247 ( émissions ) .

WARNING:

MAXIMUM EIRP
Règlement FCC permettent jusqu'à 36 dBm puissance isotrope rayonnée équivalente (EIRP) . Par conséquent, la somme de la puissance
émise ( en dBm ), la perte de câblage et le gain d'antenne ne peut pas dépasser 36 dBm.

WARNING:

ÉQUIPEMENT DE MARQUAGE
Les numéros FCC et IC dépendent du modèle du module radio . Ne pas utiliser le nom marketing du produit, mais le modèle de
distinguer les numéros Certifications . Ce dispositif a été approuvé de façon modulaire . Le fabricant , nom du produit, et les
identificateurs de la FCC et ISED de ce produit doivent figurer sur l'étiquette à l'extérieur de l'équipement de l'utilisateur final .

WARNING:

Cet appareil est conforme aux CNR exempts de licence ISED . Son fonctionnement est soumis aux deux conditions suivantes : ( 1 ) Ce
dispositif ne peut causer des interférences ; et ( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent
causer un mauvais fonctionnement de l'appareil.

SAMPLE LABEL REQUIREMENT for Model: pDDL900:

iv PDDL2450 Operating Manual

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

RF exposure Statement

The equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 36cm between the radiator and your body.

End Product Labeling
The Final end product must be labeled in a visible area with the following: “Contains FCC ID: NS917PDDL900,

IC: 3143A-17PDDL900”.

The end product that integrated with this module must be tested to comply with unintentional radiators pursuant
to FCC Part 15B and IC ICES-003.

IMPORTANT NOTE

In the event that these condition can not be met (for example certain laptop configurations or co-location with
another transmitter), then the FCC/IC authorization is no longer considered valid and FCC ID/IC can not be used on
the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC/IC authorization.

NOTE IMPORTANTE

Dans le cas où ces conditions ne peuvent être respectées (par exemple certaines configurations d'ordinateurs
portables ou de co-implantation avec un autre émetteur), l'autorisation de la FCC / IC n’est plus considéré comme
valide et la FCC ID / IC ne peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera
responsable de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation distincte de la FCC /
IC.

v

Co-Location with Cellular Modems

FCC: The maximum calculated MPE ratio for the EUT with 2.5 dBi dipole antenna is 0.398 (evaluated at 36 cm),
this configuration can be co-located with other antennas provided the sum of the MPE ratios for all the other
simultaneous transmitting antennas incorporated in a host device is < 1.0 - 0.398 < 0.602. The following co-location
were evaluated for mobile configurations:

Innovation, Science and Economic Development Canada: The maximum calculated MPE ratio for the EUT with 2.5
dBi dipole antenna is 0.398 (evaluated at 36 cm), this configuration can be co-located with other antennas provided
the sum of the MPE ratios for all the other simultaneous transmitting antennas incorporated in a host device is < 1.0

- 0.398 < 0.602. The following co-location were evaluated for mobile configurations:

1) EUT with 2.5 dBi dipole antenna co-located with Data Card Module
(FCC ID RI7LN930, IC: 5131A-LN930)

2) EUT with 2.5 dBi dipole antenna co- located with LTE Data Transmitter Module
( FCC ID R5QTOBYL201 , IC: 8595B-TOBYL201 )

3) EUT with 2.5 dBi dipole antenna co- located with GSM/UMTS/LTE Data Module
( FCC ID RI7LE910NAV2, IC: 5131A-LE910NAV2 )

4) EUT with 2.5 dBi dipole antenna co- located with LTE Data Module

( FCC ID SRQ-ME3630)

Co - localisation avec Cellular Modem

FCC : Le maximum calculé rapport EMT pour l'EST avec antenne dipôle 2.5 dBi est de 0,398 (évalué à 36 cm),
cette configuration peut être co- située avec d'autres antennes à condition que la somme des rapports MPE pour tous
les autres antennes de transmission simultanées incorporés dans un dispositif hôte est < 1,0 - 0,398 < 0,602 . Le co­emplacement suivant ont été évalués pour les configurations mobiles :

Innovation, Sciences et Développement économique Canada: Le maximum calculé rapport EMT pour l'EST avec
antenne dipôle 2.5 dBi est de 0,398 (évalué à 36 cm), cette configuration peut être co- située avec d'autres antennes à
condition que la somme des rapports MPE pour tous les autres antennes de transmission simultanées incorporés dans
un dispositif hôte est < 1.0 - 0.398 < 0.602. Le co- emplacement suivant ont été évalués pour les configurations
mobiles :

1 ) EUT avec 2.5 dBi antenne dipôle co-localisé avec module de carte de données

( FCC ID RI7LN930 , IC : 5131A - LN930)

2 ) EUT avec 2.5 dBi antenne dipôle co- localisé avec LTE données Module émetteur

( FCC ID R5QTOBYL201 , IC : 8595B–TOBYL201 )

3 ) EUT avec 2.5 dBi antenne dipôle situé coopération avec les réseaux GSM / UMTS / LTE du module de

données ( FCC ID RI7LE910NAV2, IC : 5131A-LE910NAV2 )

4 ) EUT avec 2.5 dBi antenne dipôle co- localisé avec LTE données Module émetteur
( FCC ID SRQ-ME3630)

vi PDDL2450 Operating Manual
