Please read these user manual carefully before use
USER MANUAL
PROFESSIONAL SHOW LIGHTING
M
I
C
R
O
H
Ultra Trinity330
Congratulations on choosing our company product! We thank you for your custom.
◆Please note that this product, as all the others in the rich my company range, has
been designed and made with total quality to ensure excellent performance and
best meet your expe ctations and requirements.
◆Carefully read this user manual in its entirety and keep it safe for future refer ence.
It is essential to know the information and comply with the instructions give n in this
manual to ensure the fitting is installed, used and serviced correctly and sa fely.
◆My company disclaims all liability for damage to the fitting or to other property or
persons deriving from installation, use and maintenance that have not been carried
out in conformity with this user manual, which must always accompany the fitting.
◆My company reserves the right to modify the characteristics stated in this user
manual at any time and without prior notice.
Contents
1. Safety information....................................................................................................2
2.Technical information...............................................................................................3
3.Attachment ........... .............................................................................5
4.Installation and connecting............................................................................... ........6
5. Control panel............................................................................................................7
6. Menu setting.............................................................................................................8
7.Channel function.................................................................... .................................10
8. ........... ..........................................................................15
9. ........... ..........................................................................16
10. ................... ................... .................................... ..........................16
11. ........... ................................................17
and body size
Circuit connecting diagram
Duty exonerative and copyright protection
Cleaning and maintenances
Tro ubeshooting
1
• Installation
Make sure all parts for fixing the projector are in a good state of repair.
Make sure the point of anchorage is stable before positioning the projector.
The safety chain must be properly hooked onto the fitting and secured to the framework, so that,
if the primary support system fails,the fitting falls as little as possible.
If the safety chain gets used, it needs to be replaced with a genuine spare.
• MINIMUM DISTANCE OF ILLUM INATED OBJECTS
The projector needs to be positioned so that the objects hit by the beam of light are at least
12 metres from the lens of the projector.
• Minimum distance from flammable materials
The projector must be posit
every point on the surface of the fitting.
Ioned so that any flammable materials are at least 0.2 metres from
• Mounting surfaces
It is permissible to mount the fitting on normally flammable surfaces.
• Maximum ambient temperature
Do not operate the fixt ℃ure if the ambient temperature (Ta) exceeds 38 .
•Protection against electrical shock
Connection must be made to a power supply system fitted with efficient earthing (Class I appliance
according to standard EN 60598-1).
It is,moreover, recommended to protect the supply lines of the projectors from indirect contact and/or
shorting to earth by using appropriately sized residual current devices.
• Connection to mains supply
Connection to the electricit
Check that the mains frequency and voltage correspond to those for which the projector is designed
as given on the electrical data label.
This label also gives the input power to which you need to refer to evaluate the maximum number
of fittings to connect to the electricity line, in order to avoid overloading.
Don't use the power cable when the insulation is damaged.
It must be the manufacturer or distributor or the professional person to change the damaged power
cable in order to avoid any dangerous.
y mains must be carried out by a qualified electrical installer.
• Temperature of the external surface
The maximum temperature that can be reached on the external surface of the fitting, in a thermally
steady state, is 100℃.
• Maintenance
Before starting any maintenance work or cleaning the projector, cut off power from the mains
After switching off, do not remove any parts of the fitting, to avoid getting burnt for at least 30 minutes.
After this time the likelihood of the lamp exploding is virtually nill.
The fitting is designed to hold in any splinters produced by a lamp exploding. The lenses must be
mounted and, if visibly Damaged, they have to be replaced with genuine spares.
supply.
• Lamp
The fit
apparatus.
-Carefully read the "operating instructions" provided by the lamp manufacturer.
-Immediately replace the lamp if damaged or deformed by heat.
ting mounts a high-pressure lamp that needs an external igniter. This igniter is fitted onto the
• Battery
This product contains a rechargeable lead-acid battery. To preserve the environment, please d
the battery at the end of its life according to the regulation in force.
ispose
SAFETY INFORMATION
The products referred to in this manual conform to the European Community Directives to which
they are subject:
•Low Voltage 2006/95/CE
•Electromagnetic Compatibility 2004/108/CE
Pb
12m
t 100℃
c
2
t 38℃
a
3
TECHNICAL INFORMATION
●
●Power
440W(220V/50Hz)
●Lamp
- Brand:SIRIUS HRI 330W OSRAM
- Power:330W
- Colour temperature:7500K
- Average life 1500h
●Motors
12PCS mute sound motor,2PCS three phase motor,
16bit driver.
●Channels
Standard 16 control channels
●
°
●Inputs
DMX 512/WIRELESS DMX 512(Apolegamic)
●Strobe
Double lens strobe(0.5-14 times/second)
●Dimmer
0-100% linear adjustment
●Prism
One bilateral rotation prism
●Lens
High presision optical lens
●Wash effect
Adjustable wash effects angle
●Travel
- PAN = 540°
- TILT = 239°
●Maximum speeds
- PAN = 2.6s/540°
- TILT = 1.24s/239°
●Resolution
- PAN = 2.11°
- PAN FINE = 0.008°
- TILT = 0.94°
- TILT FINE = 0.004°
Power supplies available
AC90-240V/50-60Hz
Beam angle
Parallel beam angel 0
●
Automatic charging battery,IP could be set
without electricity.
●Features
Remote control lamp’s switch function,
display light and lamp’s using time,
automaticallay adjust cooling-fan’s speed,
Drop 60W power when strobe lens.
●IP20 protection rating
- Protected against the entry of solid bodies
larger than 12mm.
- No protection against the entry of liquids.
●Safety Devices
- Bipolar circuit breaker with thermal protection.
- Automatic break in power supply in case of
overheating or failed operation of cooling
system.
●Cooling
Forced ventilation with axial fans.
●Structure
Heat-proof plastic+module pressing alloy materials.
●CE Marking
- In conformity with the European Union Low Voltage.
- Directive 2006/95/CE and Electromagnetic
compatibility Directive 2004/108/CE.
●Two side handles for transportation.
●Device locking PAN and TILT mechanisms for
transportation and maintenance.
●Weights and size
Box Size:
450x430x530(mm)
N.W.:18kg G.W.:21.3kg
Flycase Size:
2PCS:900x580x715(mm)
N.W.:36kg G.W.:76kg
IP set
~20°
4
Photometric Date:
Gobo Wheel(1 white + 12 gobo)
(please refer to the actual material)
Color Wheel:(please refer to the actual material)
White
Orang e
Light bl ue
Dark
green
Purpl e
Pink
Whi te
1
2
3
4
5
6
7
8
9
10
11
Dark red
Green
CTO 2
CTO 1
CTB
Blue
2
3
4
5
6
7
8
9
10
11
1
12
Distan ce m
Diamet er m( ft in)
0
1
2
3
1
2
3
7m(23 )
5.3m(1 7 4 )
3.5m(11 5 )
1m(3 3 )
1.8m(5 9 )
20m15m
10m
5m
3m
0m
0m
925 00(85 97)
1150 00(1 0688 )
550 000(5 1115)
600 000(5 5762)
700 00(65 06)
Lux(fc)
20
°
4
4
Attachmentcontents- Fig. 1
2
Body Size---Fig 2
ATTACHMENT AND BODY SIZE
LAMP
1
SAFETY CORD
DMX CABLE
WARRANTY CARD
USER MANUAL
BRACKET
(fitted into projector)
5
3 67
3 77
2 10
421
522
380
2 40
210
3 33
469
3 29
1 14
364
194
150
Installing the projector- Fig. 3
The projector can be installe
WARNING:with the exception of when the projector is positioned on the floor, the safety cable must be fitted.
This must be securely fixed to the support structure of the projector and then connected to the fixing point at
the centre of the base.
d on the floor resting on special rubber feet, on a truss or on the ceiling or wall.
3
Mains
4
Connecting to the mains supp ply --- Fig 4
INSTALLATION AND CONNECTING
L
N
6
SCREEN
1
3
2
DMX 512
3 PIN
SIGNAL
SIGNAL
6
Connecting to the control si gnal li ne (DMX ) - Fig. 5
◎ Please use the round 3 or 5-pin XLR plu gs & so ck et s of fe re d by m en u fa ct ure to connect the first
projector's output to the second pr oj ec to r' i np ut and connect the second projector 's o ut pu t to t he
th ird projector's input. And in the same way for the rest,ev en tu al ly c on ne ct the last projector's
output,all the projectors are tog et he r.
◎The projectors's control signal o ut pu t or i np ut b y using the 3 or 5-pin XLR pug and socket .I f ne ed t o
lengthen the communication cabl e, pl ea se m ak e sure the both side of 3 or 5-pin plug is on e to o ne .
(one to one,two to two,three to three ). Ot he rw is e, the communication cable will be i nt er ru pt ed .The
communicate cable is 2-cord scree ne d ca bl e 75Ω r es istance with each core is at least a 0.5m m
diameter.(Caution: Al l th e in si de l eading wire of 3 or 5-pin XLR plug coul dn 't t ou ch e ac h ot her or
plinth).
◎Recommend to use the DMX signal termi na to r fo r th e in stallation to avoid the electro ni c no is e da ma
-ge the digital control signal.Si mp ly s pe ak in g,DMX terminator is an XLR connec to r wi th a 1 20Ω 1 /2 W
resistor connected across pin 2 and 3 .W hi ch i s th en p lugged into the output socket on the la st p ro je c
-tor in the chain.Refer to the connec ti on .
CONTROL PANEL
SIGNAL
SCREEN
DMX
512
5 PIN
1
2
3
4
5
SIGNAL
UP ARROWHEAD:Page up or incre ase；
DOWN ARROW HEAD: Page do wn or reduce；
ENTER:OK Function
RETURE:Exit (In the choice s creen )
Press the switch. The projec tor sta rts res etting the effects. At the same t ime, th e follo wing
information scrolls on the d ispla y:
DMX 512
5
ENT ER
Mini mum dis tance t o flamm able ma teria l=12m .
Mini mum dis tance t o illum inate d surfa ce=
12m
WAR NING: HOT!
Maxi mum amb ient te mpera ture t = 38℃.
a
Alwa ys disc onnec t from ma ins bef ore rep lacin g the lam p.
Caut ion:H ot lamp . Allow to c ool for 3 0 minut es
befo re open ing.
Exte rior su rface t emper ature u nder
stea dy stat e condi tion =1 00 .
Prol onged e xposu re to
unsh ielde d lamp ca n
caus e eye and s kin bur ns.
℃
7
(please refer to the
actual material)
MENU SETTING(V1.0)
8
Setup
DMX
Address
Option
Information
Manual
Control
Factory
default
1 2
Option
Display
Reversal
BackLight
Off
On
Open
Auto
Close（15S）
Invert
Invert Pan
Off
On
Off
On
Invert Tilt
return
(ESC)
return
(ESC)
return
(ESC)
System
Version
Information
3
XY:V .
MCU1:V .
MCU2:V .
MCU3:V .
Fans
Fixture
Hours
Lamp
Hours
Monitor
Fan1: RPM
Total: (hrs)
Total: (hrs)
Cur: (hrs)
Cur: (hrs)
Fan2: RPM
Fan3: RPM
DMX
Monitor
Color( )
Strobe( )
Dimmer( )
Gobo( )
Gobo Rota ( )
.
Prism Rot ( )
Frost( )
Focus( )
Pan( )
PanFine( )
.
Prism ( )
Tilt( )
TiltFine( )
Function( )
Lamp( )
return
(ESC)
return
(ESC)
return
(ESC)
Time Clear
Clear PWRON Time
Clear LAMP Time
return
(ESC)
Zoom( )
Reset
9
4
Lamp
Manual
Control
Off
On
return
(ESC)
5
Pan/Tilt Reset
SystemReset
Reset
Effect Reset
return
(ESC)
Restor e the facto ry parame ters
6
Factory
default
Password Input:
2222
Password Input:
1111
Color Adj ust
Valu e:0 00-2 55
Valu e:0 00-2 55
Valu e:0 00-2 55
Valu e:0 00-2 55
Valu e:0 00-2 55
Valu e:0 00-2 55
Valu e:0 00-2 55
Valu e:0 00-2 55
Gobo Adju st
Shutte r Adj ust
Focus Adj ust
Zoom Adju st
Pan Adjust
Til t Ad just
Fan M axSP Adj ust
return
(ESC)
return
(ESC)
When the dmx signal is fine, it sh ows " DMX I nput OK".
When no dmx signal, it shows " DMX I nput Fa il".
1.
2.
CHANNEL FUNCTION
CHANNEL
10
CHANNEL
CHANNEL MODE
COLOUR WHEEL
STOP/STROBE
DIMMER
STATIC GOBO CHANGE
PRISM
GOBO ROTATION
FROST
FOCUS
PAN
PAN FINE
TILT
TILT FINE
FUNCTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PRISM ROTATION
ZOOM
LAMP CONTROL
11
242-255
227-241
212-226
198-211
183-197
168-182
154-167
139-153
124-138
110-123
95-109
80-94
72-79
67-71
61-66
56-60
50-55
45-49
39-44
34-38
28-33
23-27
17-22
12-16
6-11
0-5
255
128
123-127
118-122
112-117
107-111
102-106
96-101
91-95
86-90
80-85
75-79
70-74
64-69
59-63
54-58
48-53
43-47
38-42
32-37
27-31
22-26
16-21
11-15
6-10
0-5
250 - 255
0 - 3
152 - 155
181 - 205
206 - 209
210 - 249
156 - 180
4 - 7
97
98 - 101
102
127 - 151
126
255
0
•COLOUR WHEEL - channel 1
BIT
EFFECT
BLUE+WHITE
BLUE
CTB+BLUE
CTB(7200K)
CTO1+CTB
CTO1(2700K)
CTO2 + CTO1
CTO2
PINK+CTO2
PINK
PURPLE+PINK
PURPLE
GREEN+PURPLE
GREEN
DARK GREEN+GREEN
DARK GREEN
LIGHT BLUE+DARK GREEN
LIGHT BLUE
ORANGE+LIGHT BLUE
ORANGE
DARK RED+ORANGE
DARK RED
WHITE+DARK RED
WHITE
• STOP/STROBE- channel 2
BIT
EFFECT
MACRO
OPEN
CLOSED
STROBE SLOW
STROBE FAST
OPEN
OPEN
OPENING PULSE STROBE FROM SLOW TO FAST
• DIMMER- channel 3
BIT
EFFECT
Dimmer intensity
from 0% to 100%
• STATIC GOBO CHANGE - channel 4
BIT
EFFECT
GOBO12 SWING SLOW-FAST
GOBO11 SWING SLOW-FAST
GOBO10 SWING SLOW-FAST
GOBO9 SWING SLOW-FAST
GOBO8 SWING SLOW-FAST
GOBO7 SWING SLOW-FAST
GOBO6 SWING SLOW-FAST
GOBO5 SWING SLOW-FAST
GOBO4 SWING SLOW-FAST
GOBO3 SWING SLOW-FAST
GOBO2 SWING SLOW-FAST
GOBO1 SWING SLOW-FAST
WHITE
GOBO 12
GOBO 11
GOBO 10
GOBO 9
GOBO 8
GOBO 7
GOBO 6
GOBO 5
GOBO 4
GOBO 3
GOBO 2
GOBO 1
WHITE
MACRO
8
OPEN
OPEN
RANDOM STROBE SLOW - FAST
1
RANDOM CLOSING STROBE SLOW - FASTPULSE
RANDOM OPENING STROBE SLOW - FASTPULSE
FORWARD S ROTATI ON
FROM SLO W TO FAST
CLOSING PULSE STROBE FROM SLOW TO FAST
CLOSED
Whi te
2
3
4
5
6
7
8
9
10
11
1
12
12
255
0
540°
255
0
• FOCUS-channel 10
BIT
EFFECT
NEAR
DISTANT
• PAN-channel 11
BIT
EFFECT
SWING FROM SLOW TO FAST (
SWING FROM SLOW TO FAST(180°
SWING FROM SLOW TO FAST(120°
SWING FROM SLOW TO FAST(60°
FORWARDS ROTATION FROM
SLOW TO FAST
BACKWARDS ROTATION FROM FAST
TO SLOW
ANGLE ADJUSTMENT (ORIENTATION)
360°
GOBO ROTATION-channel 5
240-255
224-239
208-223
192-207
128-191
64-127
0-63
BIT
EFFECT
)
)
)
)
130 - 255
0 - 129
• PRISM - channel 6
BIT
EFFECT
PRISM INSERTED
180°
0°
• PRISM ROTATION - channel 7
STOP
SWING FROM SLOW TO FAST 360°
SWING FROM SLOW TO FAST(180°
SWING FROM SLOW TO FAST(120°
SWING FROM SLOW TO FAST(60°
BACKWARDS ROTATION FROM
SLOW TO FAST
STOP
FORWARDS ROTATION FROM
FAST TO SLOW
ROTATION(0-360°ORIENTATION
(
240-255
224-239
208-223
192-207
129-191
127-128
64-126
0-63
BIT
EFFECT
)
)
)
)
)
• ZOOM-channel 9
BIT
EFFECT
255
0
• FROST-channel 8
BIT
EFFECT
FROST
PRISM EXCLUDED
255
0
Zoom from Max . to Mi n. be am angle
13
239°
255
0
255
0
• P
AN FINE-c
hannel 12
BIT
EFFECT
• TILT- channel 13
255
0
BIT
EFFECT
• TILT FINE- channel 14
BIT
EFFECT
•FUNCTION- channel 15
212-255
206-211
199-205
192-198
185-191
178-184
171-177
164-170
157-163
146-156
135-145
124-134
113-123
102-112
91-101
80-90
69-79
58-68
47-57
36-46
25-35
14-24
0-13
EFFECT
BIT
UNUSED RANGE
COMPLETE RESET(5S)
ALL MOTOR OF HEAD RESET(5S)
FROST MOTOR RESET(5S)
FOCUS AND ZOOM MOTOR RESET(5S)
PRISM MOTOR RESET(5S)
COLOUR MOTOR RESET(5S)
GOGO MOTOR RESET(5S)
STROBE MOTOR RESET(5S)
UNUSED RANGE
LCD POSITIVE(5S)
LCD REVERSE(5S)
LCD TURN OFF(5S)
LCD TURN ON(5S)
UNUSED RANGE
GOBO,COLOUR, PRISM,FROST, HEAD
FUNCTION CHANGEING BLACKOUT
XY,GOBO, COLOUR,PRISM,FROST
CHANGING BLACKOUT
FROST SELECTING BLACKOUT
PRISM SELECTING BLACKOUT
COLOUR CHANGING BLACKOUT
GOGO CHANGING BLACKOUT
XY MOVING BLACKOUT
UNUSED RANGE
14
ON
ON
OFF
OFF
LAMP OFF(5S)
LAMP ON(5S)
•LAMP CONTROL - channel 16
BIT
EFFECT
224-255
192-223
160-191
64-159
32-63
0-31
UNUSED RANGE
UNUSED RANGE
UNUSED RANGE
LAMP RED UCIN G
POWER ( IN STANT
ACTION )
Ci rc uit connect ing diagram
15
J14
J7
J5
J3
J2
J6
J4
J12
J8
J10
J13
J1
J11
WX
DPY
GND
VCC
DMX
MT-Y
MT- X
OP-Y
OP-X
B
AT
BU
S
LAMPWK
PRIS M R
GOBO R
PRIS M
GOB O
FRO ST
COLO R
STRO BE
ZOO M
FOC US
BUS
28V
GND
MCU 3
MCU 2
+ -
FAN
MCU1
STRO BE
J7
J13
XH-2A
J10
J16
J3
J24
J1
J4
J2
J12
J5
J6
J31
MCU
L
N
LAMP
GND
VCC
J11J23
J22
J21
J27
J26
J19
J9
J8
Electronic ballas t
Switched pow er supply
Fus e 5A
Power in put
AC90~2 40V
50~60H z
X Y Dri ve boa rd
Pow er inpu t
X axi s motor
Y axis m otor
Prog ramme r port
Lith ium bat tery po rt
Pow er
inp ut
out put
Conn ect the
LCD di splay l ine
Sig nal lin e
Electr onic ba llast
contro l line
Therm ostat
CLEANING AND M AINTENANCE S
●In orde r to en sure the projec tor c ould work norma lly.It sh oul d be kept clean alw ays . It is recommended th at the
fans an d ven tilation in let s hou ld be cleaned eve ry 15 d ays.The lens and dic hroic colour filte rs should also be reg
-ular ly cl eaned to mainta in an o ptimum light ou tpu t.Do not use any type of s olvent on dichroic c olour filters.It w ill
damag e the p rojector.
●Sugge sti on:The contin ue us age of the light do n't e xceed 4 hours.Or it wi ll shorter the usage o f the lamp.Please
use the a lte rnative opera tio n to solve this pro ble ms.
●Pleas e dis connect the pow er su pply when begin t o mai ntenaceor tak edo wn the light.Pleas e let the parts cool
down 10 m inu te at least then be gin t o install.If ne ed to r eplace the lamp,pl ease wait 10 minute ag ain at least to
let the l amp c ool down comple tel y or which maybe bu rne d down.
●Pleas e ins pect the lens or ot her m oving parts tim ing a nd keep them clear and s tatic.If find anyt hing damaged or
losse nes s,must change a l amp o r fix the lamp in ord er to a void the accident.
●The lig ht us e the strong cool s yst em. It is easy for the dir ty to be collected .Pl ease do clear the hot- sak o ne time
two wee k at le ast.
●After y ou us e the light,ple ase c heck the intake p lac e whether there are so me wastepaper,ple ase clean it up,or
the win dmi ll will break dow n and c ausing fire.
TROUBES HOOTING
It is rec omm ended some solu tio n for some normal trou ble shooting.Any u nsolutioned prob lems should always
be hand le by t he profession al pe rson.Discon nec t the power suppl y bef ore maintenance th e light.
■Lamp of f：
◎Pleas e che ck if install the s uit able lamp.
◎Pleas e che ck the connecti on of t he power supply o r swi tch is ok.
◎Pleas e che ck whether the la mp wi ll reach the end of t hei r life can explode ,pl ease replace a same de scription
lamp.
◎Pleas e mea sure if the power s upp ly is enough.
◎Pleas e che ck if the operati on is c orrect.Plea se wa it 30 minutes at least t ill the lamp cool down e nough,then
could t he co nnect the power s upp ly,w hic h could be normal w ork .
◎Pleas e che ck whether the DM X 512 c ontroller pas s the " turn on" order.
◎Pleas e che ck the connecti on of t he trigger circuit i s loose contact.
◎Pleas e che ck whether the co nne cted point of the t rig ger point is loose con tact ,faster the con nec t cable .
◎
◎Please check if t he sw itc h of th e tem per atu re is d amaged.
◎
■The lig ht be am is dark,not inhom ogeneou:
◎When th e lam p is to the usage lif e,t he light is not eno ugh ,please change a new o ne for the same descri ption .
◎Pleas e che ck the reflecto r par ts is dirty.Keep them clea r.
◎Pleas e mea sure if the power s upp ly is enough.
◎Small a dju sting is suitab le fo r change height o r scr ew system till get a ide al light beam.
◎
Check m enu I NFORMATION FANS MONITOR FAN1,FAN2 ,FAN 3 , Whether the fan s pee d in
500RP M abo ve, below 500RP M the l amp does not ligh t, re place with the speci fications of the fan .
Check t he bo ttom box driver b oar d "WK" socket if the res istance 0 between th e two line.
TO enter the menu FA NCTORY DEFAULT in put 2222 enter the COL OR an d GOBO regulati on,
until t he op tical center.
16
■The lig ht sh adow is fogging:
◎Pleas e che ck the data on the DM X 512 c ontroller is su ita ble for the electric f ocus.
◎Pleas e che ck the machenic al pa rts is jamging. Aft er cleaning,plea se add some temperat ure -durable juice .
■The lig ht wo rks interrupt ly:
◎Pleas e che ck if the fan works n orm ally or mote clog gin g.
◎Pleas e che ck whether the ab str act heat have the mote c logging.
◎Pleas e che ck if the lamp is to th e usa ge life.
◎Pleas e che ck if the power sup ply i s enough,the co nne ction of the power sup ply or the circuit are g ood.
◎Pleas e che ck if the switch of t he su p-temperature is g ood.
■Thoug h the l ight is lighting,b ut it couldn't accep t the c ontrol order:
◎Pleas e che ck the start code a ddr ess and the function o ption are correct.
◎Pleas e che ck whether the co mmu nicate contro l cab le is ongood connect ion or the cable is too lo ng or interrupt.
◎Pleas e che ck the control sy ste m is not valid,check t he singal amplifie r of chain connected i s val id.
◎Pleas e che ck whether the co mmu nicate cable is t oo lo ng or the other equipm ent is mutually conj ugate.
◎Pleas e arr ange the wire wel l ,,S horter the sign al ca ble ,put the high volt age cable and low volt age cable separ
-atel y .
◎Add the s ign al amplify isol ato r.
◎Signa l cab le is used the exce lle nt screening do ubl et (Resistance 75 Ω ）
◎The end o f the l ight end and the en d res istance.
◎When th e lam p don't cool down e nou gh but do the incor rec t operation will let t he trigger up to super - high
volta ge le ak.It will dama ge th e electric circuit a nd communicate IC or C PU .Under this condi tio n,please
chang e the P CB board.
■the lig ht ca n't move:
◎Pleas e che ck if the power sup ply i s suitable for th e lig ht voltage data.
◎Pleas e che ck the fuse of inpu t vol tage is defective.
◎Pleas e che ck the light if the y are d eformating,ins ide parts is broken, become wet...etc w ill l ead the loose con tac t.
◎Pleas e che ck if the inside le ad wi re and the connec tor i s loose.
◎Pleas e che ck the electric p art s (such as the switch, transformer,bal last,electric ca pac ity,p iezoresistor, fil ter,
PCB boa rd, controller to m oto r) is short-circui t or burn down.
■
◎
◎
◎
◎
◎
■
◎
◎
◎
◎Re-pr oje ctor reset.
Part of t he pr ojector could n't b e responsled to the co ntr olling order:
Pleas e che ck the order is cor rec t to the moving.
Pleas e che ck the mechanic alp art is deformat ion o r loose.
Pleas e che ck the function t o the m otor socket is loose o r drive chip is burn dow n.
Pleas e che ck the wire of the mo tor i s cut at zig point.
Pleas e che ck these functi on to t he motor is damag ed.
On work ing ,the pan &tilt could n't work normally:
Pleas e che ck according to t he ab ove step by step.
Pleas e che ck the belt of the X. Y is broke n.
Pleas e che ck the X/Y direction data t o the r eceiver is dama ge.
17
DUTY EXONERATIVE AND COPYRIGHT PROTECTION
◇The lam p bel ongs to consump tio n products that i s not g uaran to keep i t in go od repair
◇Any pro duc ts broken that di dn' t according to th e ins truction is not guar antee to keep it in good r epair.
◇The com men tary for all the in str uction belong s to th e supplier in final.
◇No auth ori ze can't copy.
◇
tee .
The inf orm ation in this man ual m ay be changed in th e fut ure,the company re serve the right to cha nge
the dat a wit hout any advise .
Loading...
