USER MANUAL
Please read this user manual before using this product
OMNI HZR
Introduction
Thank you for purchasing the MICROH OMNI HZR xture. For your own safety
and knowledge, please read this manual before installing or operating this device.
This manual covers the important information on installation and applications.
Please install and operate the xture according to instructions. Meanwhile, please
keep this manual for future reference.
The OMNI HZR can be operated it through the three buttons (Mode, Up, Down).
At the same time , you can adjust the focus through the distance of the lens. It can
stock running mode when it is off. You can nd the last running mode when it is
powered on next. This product has a temperature protected function. When it is
on, it will power off automatically when the temperature is beyond 85°C, this wont
impact other combined xtures. When you re-start it can run correctly within 85°C.
Please check whether the following items are included in the box:
Item Name Quantity
OMNI HZR xture 1
Manual Remote 1
User manual 1
Power Cord 1
Safety Instructions
CAUTION!
ELECTRIC SHOCK WARNING!
USE EXTREME CAUTION WHEN HANDLING WIRES.
Safety Notes
Read all the following Safety Notes before working with this product. These notes
include important information about the installation, usage, and maintenance of
this product. This product contains no user-serviceable parts. Any reference to
servicing in this User Manual will only apply to properly trained MICROH certied
technicians. Do not open the housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.
Personal Safety
• Always disconnect this product from its power source before servicing.
• Always connect this product to a grounded circuit to avoid the risk of
electrocution.
• Do not touch this product’s housing during operation because it may be very hot.
• Do not drink or become in contact with the fog uid. If you do, call your local
emergency service (911 in the CAN/US) for help.
• Mount this product in a location with adequate ventilation, at least 20 in (50cm)
from adjacent surfaces.
• Make sure there are no ammable materials close to this product while it is
operating.
• When hanging this product, always secure to a fastening device using a safety
cable (not included).
Power and Wiring
• Make sure the power cord is not crimped or damaged.
• Always make sure you are connecting this product to the proper voltage
in accordance with the specications in this manual or on the product’s
specication label.
• Never connect this product to a dimmer pack or rheostat.
• Never disconnect this product by pulling or tugging on the power cable.
Operation
• Do not operate this product if you see damage to the housing, uid tank, or
cables. Have the damaged parts replaced by an authorized technician at once.
• Be sure that no ventilation slots on the product’s housing are blocked.
• The fog exits the nozzle at a very high temperature. Keep a minimum distance
of 6.5ft (2m) from the nozzle to the nearest object.
• The product’s nozzle is very hot during operation and it remains hot for a long
time after operation has stopped.
• The maximum ambient temperature is 104°F (40°C). Do not operate this
product at a higher temperature.
• In the event of a serious operating problem, stop using this product immediately!
• Do not add perfume, alcohol, gasoline, or any other ammables to the fog uid.
• Operates best with MICROH’s ‘MAXIMUM’ water-based High Density Fog
Fluid (HDF).
CAUTION!
Never touch the device during operation!
The housing may heat up!
CAUTION!
The electric connection must only be carried out by a qualied electrician
When you rst turn on the OMNI HZR it may take a few minutes to warm up. When
the warm up has been completed you will have access to various options if the
manual remote is not connected.
Press menu to scroll through the various options listed below. Use the Up and
Down keys to set the secondary function.
Display Function
d001-d512 DMX Address
P 000-100 Manual haze output 0=off, 1=1%, 100=100%
Flash Fluid-less protection, please add uid
S E 0= Set uid sensor off, 1 = Fluid sensor on
NOTE: P (pump) is setting continuos stand-alone operation and will override any manual remote
control of the OMNI HZR.
Mounting and Installation
Caution: For added protection, mount the xtures in areas outside walking paths,
seating areas, or in areas were the xture might be reached by unauthorized
personnel. Before mounting the xture to any surface, make sure that the
installation area can hold a minimum point load of 10 times the device’s weight.
Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable. Never stand directly below the device when
mounting, removing, or servicing the xture.
Whether installing inverted on a truss / ceiling or set on a at level surface (see
illustration below). Be sure this xture is kept at least 0.5m (1.5 ft.) away from any
ammable materials (decoration etc.). Always use and install the supplied safety
cable as a safety measure to prevent accidental damage and/or injury in the event
the clamp fails.
Mounting Points: Overhead mounting requires extensive experience, including
calculating working load limits. A knowledge of the installation material being
used and periodic safety inspection of all installation material and the xture are
all imperative and should only be performed by a qualied technician. Improper
installation can result in bodily injury and damage.
Be sure to complete all rigging and installation procedures before connecting the
main power cord to the appropriate wall outlet.
Clamp Mounting: The MICROH OMNI HZR provides a unique mounting bracket
assembly that integrates 2 brackets to be used to mount on a truss or the oor.
When mounting this xture to truss, be sure to secure an appropriately rated clamp
to the included bracket tted through the center hole. As an added safety measure,
be sure to attach at least one properly rated safety cable to the xture.
Regardless of the rigging option you choose for your MICROH OMNI HZR, always
be sure to secure your xture with a safety cable. The xture provides a built-in
rigging point for a safety cable on the hanging bracket. Be sure to only use the
designated rigging point for the safety cable and never secure a safety cable to a
carrying handle.
Set Up
Be sure the unit is unplugged from the power source, remove the cap from the
tank, and add the `MAXIMUM` fog uid up to the uid line. Be sure to not over ll
the tank. Replace the cap and plug unit in.
Turn the power switch on; you will notice the tank lights up red. Once the unit
is ready for use, the illuminated tank will change to blue. Heat up will take 3-5
minutes.
Remote
The OMNI HZR can be operated manually with the included remote control.
Manual Remote
When the green LED lights up the unit is ready for operation. Press the red button to manually fog.
Timer Controller
The timer controller can be used to control the OMNI HZR remotely. Please note
Haze output (h) must be set to 0 for the remote timer controller to operate.
DMX -512 Control Connections
This xture complies with international USITT DMX standards and can be used
with a 3 pin DMX connector. Plug in the provided 3 pin XLR cable to the female 3
pin XLR output of your controller and the other side to the male 3 pin XLR input
or the OMNI HZR. To connect the units to DMX, you must daisy chain the xtures
together as a referred in the diagram below. Always end your DMX-512 connection
with a DMX terminator.
For installations where the DMX cable has to run for a long distance, or as an
electrically noisy environment, it is recommended to use a DMX terminator. This
helps in preventing corruption of the digital control signal by electrical noise. The
DMX terminator is simply an XLR plug with a 120 resistor connected between pins
two and three, which is then plugged into the output XLR socket of the last xture
in the chain.
DMX Mode
When in DMX mode there are 2 channels with the following functions:
Channel Value Function
CH1 000-255 0-100% Fan output
CH2 000-255 0-100% Haze output
Features
• Timer control
• DMX-512
• Fluid-less protection
• Digital display
Specications
Voltage: AC 120-240V 60Hz
Power: 900W
Fuse: 250V 5A
Pre-heating time: 2.5 min
Working time: 200 min/L (30%)
120 min/L (100%)
Haze output: 3500Cu ft/min
Tank: 2.5L
Dimensions (mm): 410 x 320 x 390
Weight: 8 Kg
Maintenance and Cleaning
The following points have to be considered during the inspection:
1. All screws for installing the device, or parts of the device must be tightly
connected, and must not be corroded.
2. There must not be any deformations on the housing, colour lenses, xations or
installation spots (ceiling, suspension, trussing).
3. Mechanically moved parts must not show any traces of wearing and must not
rotate with unbalances.
4. The electric power supply cables must not show any damage, material fatigue
or sediments.
Further instructions depending on the installation spot and usage must be handled
by a skilled installer or technician. Any safety issues must be resolved.
CAUTION!
Disconnect xture before servicing.
In order to keep the xture in good condition and extend the life, we suggest regular
cleaning to the xture.
1. Clean the inside and outside lens each week to avoid the light output from
darkening due to accumulation of dust, dirt, etc.
2. Clean the fan each week.
3. A detailed electrical check by an approved technician every three months is
advised. Ensure the circuit contacts are in good condition, and prevent from
overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint-free
cloth. Never use alcohol solvents.
There are no serviceable parts inside the device. Please refer to the instructions
under “Installation Instructions.”
Should you need any spare parts, please order genuine MICROH parts from your
local dealer.
CAUTION!
Take care using this equipment! High voltage risk of electric shock!
PLEASE NOTE:
All information for this product is subject to change without notice!
For more information please contact:
www.microhpro.com
info@microhpro.com
905.428.9062
