Congratulations on purchasing this 120W moving Beam Light
Thank you for extending your trust in our technology
Voltage :110V/240V AC, 50/60Hz
Power Consumption:150W
Lamp:2R 120w (DMX on/off)
Lumen output:70000LM/1 0met er
Color Temperature:8000K
Lens:3-layer optic glass le ns
Prism:8 Prism rotation
Gobo:Gobo wheel with 14 gobos
Colors:Color wheel with 13 colors,single rotation rainbow effect
DMX Channel:13CH
Control:Master-slave mode
DMX Mode:Auto mode
Head movement:Pan 540º (16bit) Electric correction
Tilt 270º (16bit) Electric correction
with auto-correction function
Focus :Double automatic f ocusing
Dimmer:Independent dimmer c hannel, 0-100% linear dimmer
Strobe:Ind ependent strobe channel, 1-1 3times/s, speed adjust able
LAMP DMX ON/OFFφLAMP DMX ON/OFF, ignited by inverterθprotect and lengthen the l ifet ime of the bulb
Other functions
Fixture and lamp usage t ime display
Highly Positioning precision
Adjustable fan spe ed
Built-in analyzer for easy fault finding, error messages
Input signal isolating protection
For reasons of safety and approval(CE) the personal reconstruction and/or modification of this product is
prohibited.Please observe that damag e caused by modificati ons per formed ma nual ly to this device is not cov ered by
the warranty.
This product leaves our works in a perfect condition.Please observe all notes in these operating instructions to
warrant this condition and t he saf e operation of hte product !
Any damage caused as a result of the non-co mplian ce with thes e operatin g instruct ions le ads to the exp iration o f any
warranty claim.The manufacturer does not accept liability for any damage to property or for personal injury resulting
from the improper handling of the product, or non-observance of the operating inst ructions.
Store these operat ing instr uctions in a safe pla ce for later refer ence and pas s them to any new holder when selli ng or
lending or leaving this device in the hands of any other party.
Application According to Purpose
This product is a lighting e f fect which cr eates sp ec ila lig ht ef fects with one lamp.Togenerate these ef fect s, the produ ct
must be connected to mains and a DMX-512 compatible controller.
This product is designed f or AC110~240V/ 50~60Hz operation and exclusiv ely for indoor use.
If used for any purpose other than described in these operating instructions,the device may suffer damage and the
warranty expires.Also,any other use is linked with ri sks such as short circuits,fire,electrical shoc k,etc.
The manufacturer's serial number must never be removed as otherwise t he w arrant y expires.
Notes on safety
1. Before Operation
ATTENTION˖
DANGER OF LIFEʽRISKOF FIRE
RISK OF SHORT CIRCUITʽ
Prior to the initial operation of this product,please do the followings
-Read these operating instruct ions w ith great care;
-Study and ob serve all instructions carefully;
-Ensure that everybody and anybody involved in the installation,operation,transport and storage of this product is
2
˖
ʽ
ʽ
˖
ʽ
ʽ
suitably quali fied;
-Verify whether any visible damage was caused during transport.lf the power cord.housing or the light are
damaged,do not operate the dev ice; contact your specializ ed dealer immediately.
2. Supply Volt age,Mains Cord and Connection to Mains
The handling of supply voltage,mains cords and connections to mains calls for particular care considering the risk
from a life-threatening electric shoc k,the ris k of fire and the risk of short circuit spleas e observ e the follo w ing notes i n
particular:
Products operating on supply voltage should be kept out of the reach of children.Therefore ensure the permanent
supervision if children are in the im mediate vicinity of the product!
For commercial facilities the regulations on the prevention of accidents of the respective trade association must be
observed.The operation of this equipment at schools,training facilities,and hobbyorself-help workshops must be
supervised responsibly by t r ained personnel.
Check the product regularly for any damage to the mainsc ord ! Sho uld you di scover any damage t o the malns cord,
do not operate or disconnect this product! Secure the product against accidental operation and contact your
specialized de-alert .
Always separate the product from mains by holding the mains plug by the handling surface .Never disconnect by
holding the line cord ! Be sure to connect t he product exclusively to AC110~127V/59~60Hz!
Always insure during installation,operation, transport and when storing the product that the mains cord is not
exposed to possible mechanic al damage, or damage caused by humidity,fluids,heat or cold!
The products cable entry must not be e xpos ed to stress from p ull ! Create t he main s co nnect ion on ce th e prod uct ha s
been installed only .Always connect the mains plug la st !
The producct must only be connected to a proper outlet of the public supply grid .Connect the mains cord to suitable
outlets only ! Use entensions cords in compliance with specifications only! Do not allow the mains cord to come into
contact with other cords!
Ensure during installation ,operation,transport and storage that no ne of the cables are freely exposed!
Never touch the mains cord ,mains plug and outlet with wet or damp hands !
When not using the product, and proform to cleaning always disconnect the product from mains! To do so, hold the
mains plug by the handlin g surfa ce and never pull the mains cord!
Never connect the device todimmer packer!
3. Housing
ATTENTION˖
DANGER OF LIFEʽRISKOF FIRE
RISK OF SHORT CIRCUITʽ
Always insure during installation,operation,transport and when storing the product that no shocks or other forces
impact the housing !
The housing must not tou ch onto any other devices or objects during operation!
Easily flammable materials,e.g. decoration material and other surfaces and objects,must maintain a minimum
distance of 3m to the housing !Walls must maintain a minimum distance of 50cm to the housing!The device must be
installed on a fireproof surface only (no carpet)1 Always ensure a propercirculation of air.
Do not touch the housin g during operat ion it w ill hea t up .The ho using is sa fe to touch a pprox .5 minutes follow ing t he
end of operation!
The device must never be carried via the projector anns.Use the caring handles only !
Fluids must not enter the housing as this could reduce the prot ective insulation and may trigger short circuitswhich
may lead to fatal electro shocks !If fluids have entered, disconnect the mains plug immediately and secure the
product against unintentional operation and contact yours specialized dealer! Damage caused as a re-suit of fluids
entering the housing is exempt from warranty .
No metal parts or other items must enter the housing as this may reduce the protective insulation or trigger short
circuits which may lead to fatal electric shocks !If metal parts or other it ems have entered ,disconnect the ma ins plug
immediately,secure the product against unintentional operation and contact your specialized dealer!Damage caused
by metal parts or ot her items in the housing is exem pt warrantably.
4. Operating Environment
ATTENTION˖
DANGER OF LIFEʽRISKOF FIRE
RISK OF SHORT CIRCUITʽ
stored in a dry environment only !
Splash water ,rain,humidity,fog may reduce the protective insulation which may lead to fatal electric shocks!The limit
The product must be operated and
3
˖
ʽ
˖
ʽ
value for relative humidity is 50% at 45䉝㻚㻭㻌㼙㼕㼚㼕㼙㼡㼙㻌㼐㼕㼟㼠㼍㼚㼏㼑㻌㼛㼒㻌㻝㻚㻡㼙㻌㼠㼛㻌㼍㻌㼒㼛㼓㻌㼙㼍㼏㼔㼕㼚㼑㻌㼙㼡㼟㼠㻌㼎㼑㻌㼛㼎㼟㼑㼞㼢㼑㼐㻌㻧㼒㼛㼓 㻌
saturation in the room must not reduce t he visibility to below 10m .
The product must be operated at a temperature range of between -5䉝and 45䉝 only.Protect the product against
direct exposure to sunlight or other heat,such as from radiators! If the product is taken from a cold environment into
a warm environment it must only be taken into operation once it has reached ambient temperature,since the
condensation created by t he di fference in temperatur e may dest r oy the device!
Protect the product against dust!Dust may reduce the protective insulat io n, which may cause fatal electric shocks!
The product must be operated at alt it udes ranging between 20m below and 3000m above sea level only!
The product must not be operated during thunder storms;risk of destruction from surge voltages!
The product must be operated at a minimum distance of 1.5m to l it obj ects only!
5. Installation
ATTENTION˖
RISK OF SHORT CIRCUIT
This product can be operated suspended or as stand-alone sy st em.
Should your lighting effect show any signs of damage,do not install the device!In this case,have your lighting effect
repaired by your specialized dealer.The manufacturer does not accept responsibility or liability for damage to
property or personal injury resulting from an improperly installation!
As a stand-alone system the device must be installed vertically on an absolute planar,firm,fireproof,shock and
vibration-free surface.The installation of this lighting effect must be carried out by trained and professional staff!The
installation of this lighting must only be carried out with t he appropriate materials!
The suspended installation of this lighting effect necessitates a suitable suspension system!The lighting effect must
never be fixed swinging freely in the room.No individuals should linger underneath the lighting effect during
suspended installation!
It is a must to install this device with a second independent fixture.Such second fixture must guarantee in the event
of failure of the main fixture that no assembly parts will fa ll down.Use the fixture on t he undersurface only.
The light effect unit must be attached via two certified hooks and omega bracket to a tie-bar system.Use the screw
threads on the undersurface only.
It must be ensured that an expert inspect s the mech anical an d safet y- relev ant inst a llat io n prior t o the init i al oper ation
and following major modifications,prior to the renewed operation.It must be ensured that an expert inspects the
mechanical and safety-relevant installation at least once a year.It must be ensured that an expert inspects the
mechanical installation and the installation of relevance to safety within the framework of an acceptance test at least
every four years.
The installation fixture must be as such that it can withstand for a period of 60minutes 10 times the load capacity
without harmful deformation.
It is prohibited for any individual to unnecessarily stay or pass beneath the installation during any type of assembly
work
.
The light effect unit must be secured by a safety arrester cabl e if fly-mounted.The cable must withstand 12 times the
weigh of the light effect unit Use arrester cables equipped with quick closing links.The dropping distance must not
exceed 20 cm.Defect arrester cables or arrester cables that have already been exposed to stress must not be used.
6. Operation
ATTENTION˖
RISK OF SHORT CIRCUIT
Controls
Link all DMX devices with a DMX-512 controller by using a standard,3-pin DMX cable.Connect the output of the first
4
˖
ʽ
ʽ
˖
ʽ
ʽ
˖
ʽ
ʽ
˖
device with the input of the second device and the output of the second device with the input of the third device and
so on.
Connect the mains plug t o an outlet.
Operating the product for the first time may generate smoke and odour,this is not a defect.Avoid dis/connecting the
product repeatedly and quickly from/with mains!Always wait 15 minutes prior to t he next dis/ connection!
The device starts not until a self-testing and starting time.If the moving head is ready to start,push and roll the
function wheel.The LCD display shows the options,as below:
7. Lamps
ATTENTION˖
DANGER OF LIFEʽRISKOF FIRE
RISK OF SHORT CIRCUITʽ
O
During operation,the lamps will reach temperatures of up to 600
C.Touching the lamps may cause serious
burns!Objects coming int o contact with the lamps d uring and shortly after oper at ionmay catch fire!
Disconnect the product from mains prior to installing or before changing a lamp!Allow a lamp to cool for
approx.15minutes before exchanging it!
Never touch a lamp with bare hands!If damaged or deformed,a lamp must be exchanged!
When exchanging the lamp be sure to use suitable lamps only.Lamps with greater performance generate excessive
heat for the product;risk of fire !Da ma ge resulting from the use of an unsuitable lamp is exempt fro m warranty!
Never connect the lighting effect to the mains prior w ith opened housing.
8. Fuse
ATTENTION˖
DANGER OF LIFEʽRISKOF FIRE
RISK OF SHORT CIRCUITʽ
Disconnect the product from the
mains prior before changing a
fuse.
Only replace the fuse by a fuse of same type and rating! An incorrect fuse could damage of destruct the lighting
effect.
Replace a fuse by levering the fuse holder cover with an appropriate screwdriver.Remove the old fuse and place the
fuse inside the holder.Replace the fuse holder and insert it.
Never connect the lighting effect to the mains prior wit h opened housing.
9. Cleaning
ATTENTION˖
DANGER OF LIFEʽRISKOF FIRE
RISK OF SHORT CIRCUITʽ
The product must be freed regularly from dust,other deposits and contamination as this may reduce the protective
insulation,which may lead to a fatal electric shock!
Before cleaning,alway s di sconnect the product from mains!
This product should be cleaned with a moist cloth only; never use aggressive cleaning agents,solvents or benzine for
cleaning.
Ensure that the product is co mp let ely dry before operating it again again after cleaning!
ATTENTION˖
FRAGILE!
To avoid damage caused during
transport,wrap the productin its original packaging only and ha ndle it with great care during transport!
10. Menu settings:
5
System Setting
Information
Reset
Manual Control
Dmx Address
Lamp Control
Lamp power
No signal
Pan Reverse
Tilt Reverse
Microphone level
Factory Setting
Current Hours
Life Hours
Last Run Hours
Timer Password
Clear Time
Temperature
Reset All
Reset Scan
Reset Other
Manual DMX
Fix Position
A001~AXXX
ON/OFF
ON/OFF
Close//Hold /Sound Mode /Auto
ON/OFF
ON/OFF
XX%
ON/OFF
XXXX(Hours)
XXXX(Hours)
XXXX(Hours)
Password=XXX
ON/OFF
XXc
PAN =XXX
:
Password =XXX
PAN=XXX
:
DMX Channel
DMX Chart
Mode/
Channel
St
1
2
3
4
5
6
Value Function
0-255 Pan Movement
0-255 Fine control of Pan movement
0-255 Tilt Movement
0-255 Fine control of Tilt mov em ent
0-245 max to min speed
246-255 no function
0-4 Open / white
5-9 RED
10-14 RED - YELLOW
15-19 YELLOW - CYAN
20-24 CYAN
25-29 CYAN - GREEN
PAN Movement 8bit
Pan Fine 16bit
TILT Movement 8bit
Tilt Fine 16bit
Speed pan/tilt movement
Color Wheel
6
30-34 GREEN
35-39 GREEN – LIGHT YELLOW
40-44 LIGHT YELLO W
45-49 LIGHT YELLO W - PINK
50-54 PINK
55-59 PINK - YELLOW
60-64 YELLOW 2
65-69 YELLOW - MAGENTIA
70-74 MAGENTIA - BLUE
75-79 BLUE
80-84 BLUE – CCT 3200K
85-89 CCT 3200K
90-94 CCT 3200K – CCT 4200K
95-99 CCT 4200K
100-114 CCT 4200K - 5200K
115-119 CCT 5200K
120-124 CCT 5200K - UV
125-127 UV
128-189 Forwards Rainbow effect from fast to slow
190-193 No Rotation Stop Rainbow
194-255 Backwards Rainbow effect from slow to fast
Fixed gobos, cont. rotation
0-7 Open
8-15 Rot. gobo 1
16-23 Rot. gobo 2
24-31 Rot. gobo 3
32-39 Rot. gobo 4
40-47 Rot. gobo 5
48-55 Rot. gobo 6
56-63 Rot. gobo 7
64-71 Rot. gobo 8
72-79 Rot. gobo 9
80-87 Rot. gobo 10
7
88-95 Rot. gobo 11
96-103 Rot. gobo 12
104-111 Rot. gobo 13
112-119 Rot. gobo 14
120-126 Rot. gobo 1 shake
127-133 Rot. gobo 2 shake
124-140 Rot. gobo 3 shake
141-147 Rot. gobo 4 shake
148-154 Rot. gobo 5 shake
155-161 Rot. gobo 6 shake
162-168 Rot. gobo 7 shake
169-175 Rot. gobo 8 shake
176-182 Rot. gobo 9 shake
183-189 Rot. gobo 10 shake
7
10
11
12
13
190-196 Rot. gobo 11 shake
197-203 Rot. gobo 12 shake
204-210 Rot. gobo 13 shake
211-217 Rot. gobo 14 shake
218-255 Fixed gobo wheel cont. rotation slow to fast
Rotating prism, Prism / Gobo macros:
8
9
0-127 Open
128-255 8 facet prism
Rotating prism:
0-7 No rotation
8-127 Forwards prism rotation from fast to slow
128-135 No rotation
136-255 Backwards prism rotation from slow to fast
Focus :
0-255 Continuous adjustment from far to near
Shutter, strobe:
0-31 Shutter closed
32-63 No function (shutter open)
64-95 Strobe effect slow to fast
96-127 No function (shutter open)
Dimmer intensity:
0-255 Intensity 0 to 100%
Lamp on/off, reset, internal programs:
0-15 No function
16-31 Lamp on
32-47 Lamp switch off
48-63 All motor reset
64-79 scan motor reset
80-95 Other motor reset
96-111 Color change to any position
1 12-127 gobo change to any position
128-143 Internal program 1
144-159 Internal program 2
160-175 Internal program 3
176-191 Internal program 4
192-207 Internal program 5
208-223 Internal program 6
224-239 Internal program 7
240-255 No function
Total Power: 150W
Fuse:
3A/240V
Step Motor: 13 PCS
Body Size:
45*31*25cm
Net Weight: 10Kg
8
Loading...
