Microelectronics Technology RU 835 User Manual

MTI Group Proprietary Information

Any unauthorized use, duplication, reproduction, reverse engineering,
decompilation, or disclosure of this document may be considered as

infringement of MTI Group’s intellectual property rights, the infringer may

be accused and liable applicable legal penalties.

Copyright, Microelectronics Technology Inc.. All rights reserved.

MTI RFID ME User Manual

Version 1.6

July 9, 2014

MTI RFID ME User Manual

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.

- 2 - Jul 9, 2014

MTI RFID ME User Manual

Radiation Exposure Statement:
The product comply with the FCC portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as described in this manual. The further RF exposure
reduction can be achieved if the product can be kept as far as possible from the user body or set the
device to lower output power if such function is available.

The USB dongle transmitter is approved for use in typical laptop computers. To comply with FCC
RF exposure requirements, it should not be used in other devices or certain laptop and tablet computer
configurations where the USB connectors on the host computer are unable to provide or ensure the
necessary operating configurations intended for the device and its users or bystanders to satisfy RF
exposure compliance requirements.

- 3 - Jul 9, 2014

MTI RFID ME User Manual

No part of this publication may be reproduced or used in any form, or by any electrical or mechanical
means, without permission in writing from Microelectronics Technology, Inc. This includes electronic
or mechanical means, such as photocopying, recording, or information storage and retrieval systems.
The material in this manual is subject to change without notice.

The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the
user is on a licensed basis. Microelectronics Technology, Inc. grants to the user non-transferable and
non-exclusive license to use each software or firmware program delivered hereunder (licensed
program). Except as noted below, such license may not be assigned, sublicensed, or otherwise
transferred by the user without prior written consent of Microelectronics Technology, Inc. No right to
copy a licensed program in whole or in part is granted, except as permitted under copyright law. The
user shall not modify, merge, or incorporate any form or portion of a licensed program with other
program material, create a derivative work from a licensed program, or use a licensed program in a
network without written permission from Microelectronics Technology, Inc.

The user agrees to maintain Microelectronics Technology, Inc. copyright notice on the licensed
programs delivered hereunder, and to include the same on any authorized copies it makes, in whole or
in part. The user agrees not to decompile, disassemble, decode, or reverse engineer any hardware,
firmware or software (licensed program) delivered to the user or any portion thereof.

Microelectronics Technology, Inc. reserves the right to make changes to any software or product to
improve reliability, function, or design.

Microelectronics Technology, Inc. does not assume any product liability arising out of, or in
connection with, the application or use of any product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise under any
Microelectronics Technology, Inc. intellectual property rights. An implied license only exists for
equipment, circuits, and subsystems contained in Microelectronics Technology, Inc. products.

- 4 - Jul 9, 2014

Version

Description

Time

1.0

Release

2010.12.08

1.1

Release

2011.04.21

1.2

Release

2011.12.09

1.3

Release

2011.12.23

1.4

Release

2011.12.30

1.5

Update

2012.04.26

1.6

1. Update figures to MTI RFID ME v1.0.20.

2. Add support RFID module section.

3. Modify and correct descriptions.

2014.06.09

MTI RFID ME User Manual

History

Contact Information：

Microelectronics Technology, Inc.
No. 1 Innovation Road II,
Hsinchu Science Park,
Hsinchu 300, Taiwan, R.O.C.

http://www.mti.com.tw

- 5 - Jul 9, 2014

MTI RFID ME User Manual

Index

1. GETTING STARTED ............................................................................................................................................................... 7

1.1. INTRODUCTION .................................................................................................................................................................. 7

1.2. SUPPORT MODULE ........................................................................................................................................................... 7

1.3. CONTACT INFORMATION ................................................................................................................................................... 7

2. SETUP ....................................................................................................................................................................................... 8

2.1. SOFTWARE INSTALLATION ................................................................................................................................................ 8

2.2. START MTI RFID ME ..................................................................................................................................................... 12

3. READER SETTINGS ............................................................................................................................................................. 13

3.1. INTRODUCTION ................................................................................................................................................................ 13

3.2. ADVANCED READER SETTINGS ................................ ................................................................ ...................................... 15

4. INVENTORY RUN ................................................................................................................................................................. 20

5. TAG SETTINGS ..................................................................................................................................................................... 22

5.1. TAG SETTING FUNCTION ................................................................................................................................................. 24

5.2. MEMORY BANK ............................................................................................................................................................... 28

6. TROUBLESHOOTING/ FAQS ............................................................................................................................................. 30

6.1. INITIAL SETUP/ SOFTWARE ............................................................................................................................................. 30

6.2. READING TAGS ............................................................................................................................................................... 30

6.3. WRITING TAGS ................................................................................................................................................................ 30

- 6 - Jul 9, 2014

Index

RFID Module

Index

RFID Module

1

RU-827

5

RU-888

2

RU-862

6

RU-835

3

RU-865

4

RU-865-P

MTI RFID ME User Manual

1. Getting Started

1.1. Introduction

This manual provides you with the information needed to install and operate the MTI RFID ME. A
description on how to install the MTI RFID ME is provided in Section 2. Section 3, presents
information on how to configure the MTI RFID ME to read and write tags and discusses advanced
RFID configuration settings. Section 4 describes how to read tags (scanning and inventory runs).
Section 5 presents information on Advanced Tag Settings including changing EPC, Kill, Lock and
advanced feature settings.

1.2. Support Module

This user manual can be referred for below RFID reader modules.

1.3. Contact Information

Contact “[e-mail]” for any questions regarding MTI RFID ME and hardware
support issues.

- 7 - Jul 9, 2014

MTI RFID ME User Manual

2. Setup

2.1. Software Installation

2.1.1. Double-click “MTI RFID ME.exe” in the installation disk, then click “Next” to continue the

installation, or click “Cancel” to exit the setup as shown in Figure 1.

Figure 1

2.1.2. Read the license agreement and select “I accept the agreement” as shown in Figure 2 to
accept.

Figure 2

- 8 - Jul 9, 2014

MTI RFID ME User Manual

2.1.3. Select a Destination Folder. To select a different folder, click “Browse” and choose one of the

available options as shown in Figure 3.

Figure 3

2.1.4. Select a destination for the program’s shortcut. To select a different folder, click “Browse”
and choose one of the available options as shown in Figure 4.

Figure 4
