Microchip Technology Inc 24LC02B-SN, 24LC02B-PN, 24LC01BT-SN Datasheet

 1999 Microchip Technology Inc. DS20071J-page 1

24LC01B/02B

FEATURES

• Single supply with operation down to 2.5V

• Low power CMOS technology

- 1 mA active current typical

- 10 µA standby current typical at 5.5V

- 5 µA standby current typical at 3.0V

• Organized as a single block of
128 bytes (128 x 8 ) -1K or 256 bytes (256 x 8) -2K

• 2-wire serial interface bus, I

2

C™ compatible

• 100 kHz (2.5V) and 400kHz (5.0V) compatibility

• Self-timed write cycle (including auto-e rase)

• Page-write buffer for up to 8 bytes

• 2 ms typical write cycle time for page-write

• Hardware write protect for entire memory

• Can be operated as a serial ROM

• ESD protection > 3,000V

• 1,000,000 E/W cycles guaranteed

• Data retention > 200 years

• 8 pin DIP, SOIC, TSSOP* or SOT-23* package

• Available for temperature ranges

DESCRIPTION

The Microchip Technology Inc. 24LC01B and 24LC 02B
are 1K bit and 2K bit Electrically Er asab le PR OMs. Th e
devices are organi zed as a single bloc k of 128 x 8 bit or
256 x 8 bit memory with a two wire serial interface . Low
voltage desig n p ermits oper ation d own to 2. 5 v olt s with
a standby and active currents of only 5 µA and 1 mA
respectively. The 24LC01B and 24LC02B also have
page-write capability for up to 8 bytes of data. The
24LC01B an d 24LC02B ar e available in the stan dard
8-pin DIP and an 8-pin surface mount SOIC package.
The SOT-23 and TSSOP packag es are av ailab le f or the
24LC01B.

PAC KAGE TYPES

BLOCK DIAGRAM

- Commercial (C): 0°C to +70°C

- Industrial (I): -40°C to +85°C

24LC01B/02B

1
2

3

4

8
7

6

5

A0
A1

A2

Vss

Vcc
WP

SCL

SDA

PDIP, SOIC

TSSOP*

15

4

3

24LC01B

SCL

VSS

SDA

WP

Vcc

2

SOT-23*

* Available for 24LC01B only

24LC01B/02B

A0
A1

A2

V

SS

Vcc
WP
SCL
SDA

1
2
3

4

8
7
6

5

HV GENERATOR

EEPROM

ARRAY

PAGE LATCHES

YDEC

XDEC

SENSE AMP

R/W CONTROL

MEMORY

CONTROL

LOGIC

I/O

CONTROL

LOGIC

WP

SDA SCL

V

CC

VSS

1K/2K 2.5V I2C™ Serial EEPROM

* Available for 24LC01B only

24LC01B/02B

DS20071J-page 2  1999 Microchip Technology Inc.

1.0 ELECTRICAL CHARACTERISTICS

1.1 Maximum Ratings*

VCC...................................................................................7.0V

All inputs and outputs w.r .t. V

SS ............... -0.6V to VCC +1.0V

Storage temperature.....................................-65°C to +150°C

Ambient temp. with power applied ................ - 65°C to +125°C

Soldering temperature of leads (10 seconds).............+300°C

ESD protection on all pins.............................................> 3 kV

*Notice: Stresses above those listed under “Maximum ratings”
may cause permanent damage to the device. This is a stress rat­ing only and functional operation of the device at those or any
other conditions above those indicated in the operational listings
of this specification is not implied. Exposure to maximum rating
conditions for extended periods may affect device reliability.

TABLE 1-1: PIN FUNCTION TABLE

FIGURE 1-1: BUS TIMING START/STOP

Name Function

V

SS

SDA
SCL

WP
V

CC

A0, A1, A2

Ground
Serial Address/Data I/O
Serial Clock
Write Protect Input
+2.5V to 5.5V Power Supply

No Internal Connection

TABLE 1-1: DC CHARACTERISTICS

VCC = +2.5V to +5.5V Commercial (C): Tamb = 0°C to +70°C

Industrial (I): Tamb = -40°C to +85°C

Parameter Symbol Min. Max. Units Conditions

WP, SCL and SDA pins:

High level input voltage

V

IH .7 VCC V

Low level input voltage V

IL .3 VCC V

Hysteresis of Schmidt trigger inputs V

HYS .05 VCC — V (Note)

Low level output voltage VOL .40 V IOL = 3.0 mA, VCC = 2.5V
Input leakage current ILI -10 10 µA VIN = .1V to 5.5V
Output leakage current I

LO -10 10 µA VOUT = .1V to 5.5V

Pin capacitance (all inputs/outputs) CIN,

C

OUT

—10pFVCC = 5.0V (Note 1)

Tamb = 25°C, F

CLK = 1 MHz

Operating current I

CC Write — 3 mA VCC = 5.5V, SCL = 400 kHz

ICC Read — 1 mA

Standby current ICCS —30µAVCC = 3.0V, SDA = SCL = VCC

100 µA VCC = 5.5V, SDA = SCL = VCC

WP = VSS

Note: This parameter is periodically sampled and not 100% tested.

SCL

SDA

T

SU:STA

THD:STA

START STOP

VHYS

TSU:STO

24LC01B/02B

 1999 Microchip Technology Inc. DS20071J-page 3

TABLE 1-2: AC CHARACTERISTICS

FIGURE 1-2: BUS TIMING DATA

Parameter Symbol

Standard Mode

Vcc = 4.5 - 5.5V

Fast Mode

Units Remarks

Min. Max. Min. Max.

Clock frequency F

CLK — 100 — 400 kHz

Clock high time THIGH 4000 — 600 — ns
Clock low time T

LOW 4700 — 1300 — ns

SDA and SCL rise time TR — 1000 — 300 ns (Note 1)
SDA and SCL fall time TF — 300 — 300 ns (Note 1)
START condition hold time T

HD:STA 4000 — 600 — ns After this period the first

clock pulse is generated

START condition setup time T

SU:STA 4700 — 600 — ns Only relevant for repeated

START condition

Data input hold time T

HD:DAT 0 — 0 — ns (Note 2)

Data input setup time TSU:DAT 250 — 100 — ns
STOP condition setup time T

SU:STO 4000 — 600 — ns

Output valid from clock TAA — 3500 — 900 ns (Note 2)
Bus free time TBUF 4700 — 1300 — ns Time the bus must be free

before a new transmission
can start

Output fall time from VIH
minimum to VIL maximum

T

OF — 250 20 +0.1

CB

250 ns (Note 1), CB ð 100 pF

Input filter spike suppression
(SDA and SCL pins)

T

SP — 50 — 50 ns (Note 3)

Write cycle time T

WR — 10 — 10 ms Byte or Page mode

Endurance — 1M — 1M — cycles 25°C, Vcc = 5.0V, Block

Mode (Note 4)

Note 1: Not 100% tested. CB = total capacitance of one bus line in pF.

2: As a transmitter, the device must provide an internal minimum delay time to bridge the undefined region

(minimum 300 ns) of the falling edge of SCL to avoid unintended generation of START or STOP conditions.

3: The combined T

SP and VHYS specifications are due to new Schmitt trigger inputs which provide improved

noise spike suppression. This eliminates the need for a TI specification for standard operation.

4: This par am ete r i s no t t ested but guaranteed by characterization. For endurance esti ma tes i n a specific appli-

cation, please consult the Total Endurance Model which can be obtained on our website.

SCL

SDA

IN

SDA
OUT

T

HD:STA

TSU:STA

TF

THIGH

TR

TSU:STOTSU:DATTHD:DAT

TBUFTAA

THD:STA

TAA

TSP

TLOW

24LC01B/02B

DS20071J-page 4  1999 Microchip Technology Inc.

2.0 FUNCTIONAL DESCRIPTION

The 24LC01B/02B supports a bi-directional two wire
bus and data transmission protocol. A device that
sends data onto the bus is defined as transmitter, and
a device receiving data as receiver. The bus has to be
controlled by a master device which generates the
serial clock (SCL), co ntrols th e bu s acce ss, an d gen er­ates the START and STOP conditions, while the
24LC01B/02B works as slave. Both ma ster and slave
can operate as transmitter or receiver but the master
device determines which mode is activated.

3.0 BUS CHARACTERISTICS

The following bus protocol has been defined:

• Data transfer may be initiated only when the bus
is not busy.

• During data transfer, the data line must remain
stable whenever the clock line is HIGH. Changes
in the data line w hil e the clock line is HI GH w ill b e
interpreted as a START or STOP condition.

Accordingly, the following bus conditions have been
defined (F igure 3-1).

3.1 Bus Not Busy (A)

Both data and clock lines remain HIGH.

3.2 Start Data Transfer (B)

A HIGH to LOW transition of the SDA line while the
clock (SCL) is HIGH determines a START condition. All
commands must be preceded by a START condition.

3.3 Stop Data Transfer (C)

A LOW to HIGH trans ition of the SDA line while the
clock (SCL) is HIGH determi n es a STOP con dit i on . A ll
operations must be ended with a STOP condition.

3.4 Data Valid (D)

The state of the data line represents valid data when,
after a START condition, the data line is stable for the
duration of the HIGH period of the clock signal.

The data on the line must be changed during the LOW
period of the clock signal. There is one clock pulse per
bit of data.

Each data transfer is initiated with a START condition
and terminated with a STOP condition. The number of
the data bytes transferred between the START and
STOP conditions is det ermined by the master device
and is theoreti cally unli mited , althoug h only the las t six­teen will be store d wh en doi ng a write ope ratio n. Whe n
an overwrite doe s occur i t will r eplac e data in a fi rst in
first out fashion.

3.5 Acknowledge

Each receiving device, when addressed, is obliged to
generate an acknowledge after the reception of each
byte. The master device must generate an extra clock
pulse which is associated with this acknowledge bit.

The device that acknowledges has to pull down the
SDA line du ring the acknowledge clock pulse in such a
way that the SDA line is stable LOW dur ing the HIGH
period of the acknowledge related clock pulse. Of
course, setup and hold times must be taken into
account. A master must signal an end of data to the
slave by not generating an acknowledge bit on the last
byte that has be en clocke d out of the slav e. In thi s case,
the slave must leave the data li ne HI GH to e nable the
master to generate the STOP condition.

FIGURE 3-1: DATA TRANSFER SEQUENCE ON THE SERIAL BUS

Note: The 24LC01B/02B does not generate any

acknowledge bits if an internal program­ming cycle is in progress .

SCL

SDA

(

A) (B) (D) (D) (C) (A)

START

CONDITION

ADDRESS OR

ACKNOWLEDGE

VALID

DATA

ALLOWED

TO CHANGE

STOP

CONDITION

24LC01B/02B

 1999 Microchip Technology Inc. DS20071J-page 5

3.6 Devise Address

The 24LC01B/02B are software-compatible with older
devices such as 24C01A, 24C02A, 24LC01, and
24LC02. A single 2 4LC02B can be used in place of tw o
24LC01’s, for example, without any modifications to

software. The “c hip select” p ortion of the control byte
becomes a don't care.

After generating a START condition, the bus master
transmits the slave address consisting of a 4-bit device
code (1010) for the 24LC01B/02B, followed by three
don't care bits.

The eighth bit of sla ve address d etermines if the master
device wants to read or write to the 24LC01B/02B
(Figure 3-2).

The 24LC01B/02B monitors th e b us f or its correspon d­ing slave addres s all th e time . It ge nerat es an ack no wl­edge bit if the slave address was true and it is not in a
programming mode.

FIGURE 3-2: CONTROL BYTE

ALLOCATION

4.0 WRITE OPERATION

4.1 Byte Write

Following the start signal from the master, the device
code (4 bits), the don't care bits (3 bits), and the R/W
bit which is a lo gic low is placed ont o the bus by the
master transmitter. This indicates to the addressed
slave receiver that a byte with a word address will follow
after it has generated an acknowledge bit during the
ninth clock c ycle. There fore t he next byte tran smitted b y
the master is the word address and will be written into
the address pointer of the 24LC01B/02B. After receiv­ing another ackn owledge si gnal from the 24LC0 1B/02B
the master devic e will trans mit the data w ord to be writ­ten into the addressed memory location. The
24LC01B/02B acknowledges again and the master
generates a stop condition. This initiates the internal
write cycle, and during this time the 24LC01B/02B will
not generate acknowledge signals (Figure4-1).

4.2 Page Write

The write control byte, word address and the first data
byte are transmitted to the 24LC01B/02B in the same
way as in a byte write. But instead of generating a stop
condition the master tr ansmi ts up t o eight dat a b ytes to
the 24LC01B/02B which are temporarily stored in the
on-chip page b uff e r and w ill be written into the me mory
after the master has transmitted a stop condition. After
the receipt of each wor d, the th ree lo w er order a ddres s
pointer bits are internally incremented by one. The
higher order five bit s o f the word address remains con­stant. If the master should transmit more than eight
words prior to generating the stop condition, the
address counter will roll over and the previously
received data will be overwritten. As with the byte write
operation, on ce th e sto p co nd i ti o n is rece ived an in te r­nal write cycle will begin (Figure 4-2).

Operation

Control

Code

Chip

Select

R/W

Read
Write

1010
1010

XXX
XXX

1
0

X = Don’t care

R/W A

1 010XXX

READ/WRITE

START

SLAVE ADDRESS

Note: Page write operations are limited to writing

bytes within a si ngle phys ical page, rega rd­less of the number of bytes actually being
written. Physical page boundaries start at
addresses th at a r e i nte ge r mul t ip l es of t he
page buffe r siz e (or ‘pa ge siz e’) and end at
addresses that are integer multiples of
[page size - 1]. If a page write command
attempts to w rite across a physical page
boundary, the result is that the data wraps
around to the beg inning of the curre nt page
(overwriting data previously stored there),
instead of bein g written t o the ne xt page a s
might be expected. It is therefore neces­sary for the application softw are to pre v e nt
page write operations that would attempt
to cross a page boundary.

24LC01B/02B

DS20071J-page 6  1999 Microchip Technology Inc.

FIGURE 4-1: BYTE WRITE

FIGURE 4-2: PAGE WRITE

S P

S
T
A
R
T

S
T
O
P

BUS ACTIVITY
MASTER

SDA LINE

BUS ACTIVITY

A
C
K

A
C
K

A
C
K

CONTROL

BYTE

WORD

ADDRESS

DATA

S P

BUS ACTIVITY
MASTER

SDA LINE

BUS ACTIVITY

S
T
A
R
T

S
T
O
P

CONTROL

BYTE

WORD

ADDRESS (n)

DATA n DATAn + 7

DATAn + 1

A
C
K

A
C
K

A
C
K

A
C
K

A
C
K

24LC01B/02B

 1999 Microchip Technology Inc. DS20071J-page 7

5.0 ACKNOWLEDGE POLLING

Since the device will not acknowledge during a write
cycle, this can be used to determine when the cycle is
complete (this feature can be used to maximize bus
throughput). Once the stop condition for a write com­mand has been issued from the master, the device ini­tiates the internally timed write cycle. ACK polling can
be initiated immedi ately. This involves t he master send­ing a start condition followed by the control byte for a
write command (R/W

= 0). If the device is still busy with
the write cycle, then no ACK will be returned. If the
cycle is complete, then the device will return the ACK
and the master can then proceed with the next read or
write command. See Figure5-1 for flow diagram.

FIGURE 5-1: ACKNOWLEDGE POLLING

FLOW

6.0 WRITE PROTECTION

The 24LC01B/02B can be used as a se rial R O M when
the WP pin is connected to V

CC. Programming will be

inhibited and the enti re memory will be write-p rotected.

7.0 READ OPERATION

Read operations are initiated in the same way as write
operations w ith the exception that the R/W

bit of the
slave addr ess is set to one . There are th ree basic type s
of read operatio ns: curren t address rea d, rando m read,
and sequential read.

7.1 Current Address Read

The 24LC01B/02B contains an address counter that
maintains the addr ess o f t he last word accessed, inter­nally incremented by one. Therefore, if the previous
access (either a read or write operation) was to
address n, the next current address read operation
would access da ta from a ddre ss n + 1. Upon receipt of
the slave address with R/W

bit set to one, the
24LC01B/02B issues an acknowledge and transmits
the eight bit data word. The master will not acknowl­edge the transfer but does generate a stop condition
and the 24LC01B/02B discontinues transmission
(Figure 7-1).

7.2 Random Read

Random read operations allow the master to access
any memory location in a random manner. To perform
this type of read operation, first the word address must
be set. This is done b y se nding the word add ress to th e
24LC01B/02B as part of a write operation. After the
word address is se nt, the master ge nerates a start con­dition following t he acknowledge. This ter minates the
write operation, but not before the internal address
pointer is set. Then the master issues the control byte
again but with the R/W

bit set to a one. The 24LC01B/
02B will then issue an acknowledge and transmits the
eight bit data word. The master will not acknowledge
the transfe r bu t does g enerate a s top con dition and the
24LC01B/02B discontinues transmission (Figure 7-2).

7.3 Sequential Read

Sequential reads are initiat ed in the same w ay as a r an­dom read exc ep t th at a fte r the 24LC01B/02B transmits
the first data byte, the master issues an acknowledge
as opposed to a stop condition in a random read. This
directs the 24LC01B/02B to transmit the next sequen­tially addressed 8-bit word (Figure 7-3).

T o provide sequential reads the 24LC01B/02B contains
an internal address pointer which is incremented by
one at the completion of each operation. This address
pointer allows th e entire memory conten ts to be serially
read during one operation.

7.4 Noise Protection

The 24LC01B/02B employs a VCC threshold detector
circuit which dis ables the int ernal erase/write l ogic if the
VCC is below 1.5 volts at nominal conditions.

The SCL and SD A inputs h av e Schm itt trigger and filter
circuits which suppress noise spikes to assure proper
device operation even on a noisy bus.

Send

Write Command

Send Stop

Condition to

Initiate Write Cycle

Send Start

Send Control Byte

with R/W = 0

Did Device

Acknowledge

(ACK = 0)?

Next

Operation

NO

YES

24LC01B/02B

DS20071J-page 8  1999 Microchip Technology Inc.

FIGURE 7-1: CURRENT ADDRESS READ

FIGURE 7-2: RANDOM READ

FIGURE 7-3: SEQUENTIAL READ

8.0 PIN DESCRIPTIONS

8.1 SDA Serial Address/Data Input/Output

This is a bi-directional pin used to transfer addresses
and data into and data out of the device. It is an open
drain terminal, therefore the SDA bus requires a pull-up
resistor to V

CC (typical 10K¾ for 100 kHz, 2 K¾ for

400 kHz).
For normal data tra nsf er SD A is allo wed to c hange onl y

during SCL low. Changes during SCL high are
reserved for indicating the START and STOP condi­tions.

8.2 SCL Serial Clock

This input is used to sy nchro niz e the data t ra nsf e r from
and to the device.

8.3 WP

This pin must be connected to either VSS or VCC.
If tied to V

SS, normal memory operation is enabled

(read/write the entire memory).
If tied to V

CC, WRITE operations are inhibited. The

entire memory will be write-pro tected. R ead oper ations
are not affected.

SP

BUS ACTIVITY
MASTER

SDA LINE

BUS ACTIVITY

S
T
A
R
T

CONTROL

BYTE

DATA n

A
C
K

N
O

A
C
K

S
T
O
P

S P

S

BUS ACTIVITY
MASTER

SDA LINE

BUS ACTIVITY

S
T
A
R
T

S
T
O
P

CONTROL

BYTE

WORD

ADDRESS (n)

DATA n

A
C
K

A
C
K

N
O

A
C
K

CONTROL

BYTE

A
C
K

S
T
A
R
T

P

SDA LINE

BUS ACTIVITY

S
T
O
P

CONTROL

BYTE

DATA n

A
C
K

N
O

A
C
K

A
C
K

A
C
K

A
C
K

DATA n + 1 DATA n + 2 DATA n + X

BUS ACTIVITY
MASTER

24LC01B/02B

 1999 Microchip Technology Inc. DS20071J-page 9

NOTES:

24LC01B/02B

DS20071J-page 10  1999 Microchip Technology Inc.

NOTES:

24LC01B/02B

 1999 Microchip Technology Inc. DS20071J-page 11

24LC01B/02B PRODUCT IDENTIFICATION SYSTEM

To order or obtain information, e.g., on pricing or delivery, refer to the factory or the listed sales office.

Sales and Support

24LC01B/02B — /P

Package:

P = Plastic DIP (300 mil Body), 8-lead

SN = Plastic SOIC (150 mil Body), 8-lead

SM = Plastic SOIC (207 mil Body), 8-lead

OT = SOT-23, 5-lead (24LC01B only)

ST = TSSOP, 8-lead (24LC01B only)

Temperature Blank = 0°C to +70°C

Range: I = -40°C to +85°C

Device:

24LC01B 1K I2C Serial EEPROM

24LC01BT 1K I

2

C Serial EEPROM (Tape and Reel)

24LC02B 2K I

2

C Serial EEPROM

24LC02BT 2K I

2

C Serial EEPROM (Tape and Reel)

Data Sheets

Products supported by a preliminary Data Sheet may have an errata sheet describing minor operational differences and recom­mended workarounds. To determine if an errata sheet exists for a particular device, please contact one of the following:

1. Your local Microchip sales office

2. The Microchip Corporate Literature Center U.S. FAX: [phone]

3. The Microchip Worldwide Site (www.microchip.com)
Please specify which device, revision of silicon and Data Sheet (include Literature #) you are using.

New Customer Notification System

Register on our web site (www.microchip.com/cn) to receive the most current information on our products.

Information contained in this publication regarding device applications and the like is i ntended for suggestion only and may be superseded by updates. No representation or warranty is given and no liability is assumed
by Microchip T echnology Incorporated with respect to the accuracy or use of such information, or infringeme nt of patents or othe r intellec tual property ri ghts arising from such use or otherwis e. Use of Microchi p’s produc ts
as critical components in life support systems is not authorized except with expres s written approval by Microchip. No licenses are conveyed, implicitly or otherwise, under any in te llectual property rights. The Microchip
logo and name are registered trademarks of Mi cr ochip Technology Inc. in the U.S.A. and other countries. All rights reserved. All other tradem arks mentioned herein are the property of their respective compani es.

 1999 Microchip Technology Inc.

All rights reserved. © 1999 Microchip Technology Incorporated. Printed in the USA. 11/99 Printed on recycled paper.

AMERICAS

Corporate Office

Microchip Technology Inc.
2355 West Chandler Blvd.
Chandler, AZ 85224-6199
Tel: [phone] Fax: [phone]
Technical Support: 480-786-7627
Web Address: http://www.microchip.com

Atlanta

Microchip Technology Inc.
500 Sugar Mill Road, Suite 200B
Atlanta, GA 30350
Tel: [phone] Fax: [phone]

Boston

Microchip Technology Inc.
5 Mount Royal Avenue
Marlborough, MA 01752
Tel: [phone] Fax: [phone]

Chicago

Microchip Technology Inc.
333 Pierce Road, Suite 180
Itasca, IL 60143
Tel: [phone] Fax: [phone]

Dallas

Microchip Technology Inc.
4570 Westgrove Drive, Suite 160
Addison, TX 75248
Tel: [phone] Fax: [phone]

Dayton

Microchip Technology Inc.
Two Prestige Place, Suite 150
Miamisburg, OH 45342
Tel: [phone] Fax: [phone]

Detroit

Microchip Technology Inc.
Tri-Atria Office Building
32255 Northwestern Highway, Suite 190
Farmington Hills, MI 48334
Tel: [phone] Fax: [phone]

Los Angeles

Microchip Technology Inc.
18201 Von Karman, Suite 1090
Irvine, CA 92612
Tel: [phone] Fax: [phone]

New York

Microchip Technology Inc.
150 Motor Parkway, Suite 202
Hauppauge, NY 11788
Tel: [phone] Fax: [phone]

San Jose

Microchip Technology Inc.
2107 North First Street, Suite 590
San Jose, CA 95131
Tel: [phone] Fax: [phone]

AMERICAS (continued)

Toro nt o

Microchip Technology Inc.
5925 Airpor t Road, Suite 200
Mississauga, Ontario L4V 1W1, Canada
Tel: [phone] Fax: [phone]

ASIA/PACIFIC

Hong Kong

Microchip Asia Pacific
Unit 2101, Tower 2
Metroplaza
223 Hing Fong Road
Kwai Fong, N.T., Hong Kong
Tel: [phone] Fax: [phone]

Beijing

Microchip Technology, Beijing
Unit 915, 6 Chaoyangmen Bei Dajie
Dong Erhuan Road, Dongcheng District
New China Hong Kong Manhattan Building
Beijing 100027 PRC
Tel: [phone] Fax: [phone]

India

Microchip Technology Inc.
India Liaison Office
No. 6, Legacy, Convent Road
Bangalore 560 025, India
Tel: [phone] Fax: [phone]

Japan

Microchip Technology Intl. Inc.
Benex S-1 6F
3-18-20, Shinyokohama
Kohoku-Ku, Yokohama-shi
Kanagawa 222-0033 Japan
Tel: [phone] Fax: [phone]

Korea

Microchip Technology Korea
168-1, Youngbo Bldg. 3 Floor
Samsung-Dong, Kangnam-Ku
Seoul, Korea
Tel: [phone] Fax: [phone]

Shanghai

Microchip Technology
RM 406 Shanghai Golden Bridge Bldg.
2077 Yan’an Road West, Hong Qiao District
Shanghai, PRC 200335
Tel: [phone] Fax: [phone]

ASIA/PACIFIC (continued)

Singapore

Microchip Technology Singapore Pte Ltd.
200 Middle Road
#07-02 Prime Centre
Singapore 188980
Tel: [phone] Fax: [phone]

Taiwan, R.O.C

Microchip Technology Taiwan
10F-1C 207
Tung Hua North Road
Taip e i , Ta i w a n, RO C
Tel: [phone] Fax: [phone]

EUROPE

United Kingdom

Arizona Microchip Technology Ltd.
505 Eskdale Road
Winnersh Triangle
Wokingham
Berkshire, England RG41 5TU
Tel: [phone] Fax: [phone]

Denmark

Microchip Technology Denmark ApS
Regus Business Centre
Lautrup hoj 1-3
Ballerup DK-2750 Denmark
Tel: [phone] Fax: [phone]

France

Arizona Microchip Technology SARL
Parc d’Activite du Moulin de Massy
43 Rue du Saule Trapu
Batiment A - ler Etage
91300 Massy, France
Tel: [phone] Fax: [phone]

Germany

Arizona Microchip Technology GmbH
Gustav-Heinemann-Ring 125
D-81739 München, Germany
Tel: [phone] Fax: [phone]

Italy

Arizona Microchip Technology SRL
Centro Direzionale Colleoni
Palazzo Taurus 1 V. Le Colleoni 1
20041 Agrate Brianza
Milan, Italy
Tel: [phone] Fax: [phone]

11/15/99

WORLDWIDE SALES AND SERVICE

Microchip received QS-9000 quality system
certification for its worldwide headquarters,
design and wafer fabrication facilities in
Chandler and Tempe, Arizona in July 1999. The
Company’s quality system processes and
procedures are QS-9000 compliant for its
PICmicro

®

8-bit MCUs, KEELOQ

®

code hopping
devices, Serial EEPROMs and microperipheral
products. In addition, Microchip’s quality
system for the design and manufacture of
development systems is ISO 9001 cer tified.
