Microchip Technology WINC3400U User Manual
Regulatory Compliance Information
ATWINC3400-MR210UA
Regulatory Compliance Information
Revision 0.2
June’ 2018
Revision 0.2 (06/2018)
Preliminary
1
Regulatory Compliance Information
This document covers the Regulatory Compliance information which
will be part of the ATWINC3400-MR210UA Module datasheet and
related documents shared with customers.
Revision 0.2 (06/2018)
Preliminary
2
2.4GHz Band
1 W3525B039
Pulse Electronics Corporation
2 dBi
PCB
2 RN-SMA
-4
Microchip
2.2 dBi
Dipole
3 RFDPA870920IMLB301
WALSIN
1.84 dBi
Dipole
-DB
4 RFPCA381013IMAB701
WALSIN
4.50 dBi
PCB
5 RFPCA381035IMAB701
WALSIN
2.7 dBi
PCB
6 RFA-02-3-C5H1
Aristotle
3 dBi
Dipole
7 RFA-02-5-C7H1
Aristotle
5 dBi
Dipole
-
Long
8 RFA-02-P33 Aristotle
2 dBi
PCB
9 1461530100
Molex
3 dBi
PCB/Flexi
10 RN-SMA
-S
Microchip
0.56 dBi
Dipole
-
short
11 RN-SMA
-7
Microchip
5 dBi
Dipole
-
Long
12 RFA-02-5-F7H1
Aristotle
5 dBi
Dipole
-
Long
13 RFA-02-D3 Aristotle
2 dBi
Dipole
-
no encl.
14 RFA-02-L2H1
Aristotle
2 dBi
Dipole
15 RFA-02-P05 Aristotle
2 dBi
PCB
16 RFA-02-C2M2
Aristotle
2 dBi
Dipole
Regulatory Compliance Information
1.1 Antenna Considerations:
Table 1-1 provides the list of Approved antennas along with the manufacturer and part number
details.
Slno. P/N Vendor Antenna Gain @
Antenna type
1.2 ATWINC3400-MR210UA Usage Instructions under Modular Approval
Table 1-2: Features and supported modes of operation
Frequency Range
Number of Channels WiFi: 11 for North America
WiFi: 2.400 GHz ~ 2.4835 GHz (2.4 GHz ISM Band)
BLE: 2.402 GHz to 2.480 GHz
BLE: 40
The availability of some specific channels and/or operational frequency bands are country dependent and
should be programmed at the Host product factory to match the intended destination. Regulatory bodies
prohibit exposing the settings to the end user. This requirement needs to be taken care of via Host
implementation.
The Host product manufacturer must ensure that the RF behavior adheres to the certification (e.g. FCC,
ISED) requirements when the module is installed in the final Host product.
