PIC32MZ DA FAMILY

STARTER KIT USER’S GUIDE

All documentation becomes dated, and this manual is no exception. Microchip tools and documentation are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document. Please refer to our web site (www.microchip.com) to obtain the latest documentation available.

Documents are identified with a “DS” number. This number is located on the bottom of each page, in front of the page number. The numbering convention for the DS number is “DSXXXXXXXXA”, where “XXXXXXXX” is the document number and “A” is the revision level of the document.

For the most up-to-date information on development tools, see the M PLAB Select the Help menu, and then Topics to open a list of available online help files.

®

X IDE online help.

INTRODUCTION

This chapter contains general information that will be useful to know before using the PIC32MZ DA Family Starter Kit. Items discussed in this chapter include:

• Document Layout

• Conventions Used in this Guide

• Recommended Reading

• The Microchip Web Site

• Development Systems Customer Change Notification Service

• Customer Support

• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the PIC32MZ DA Family Starter Kit (also referred to as “starter kit”) as a development tool to emulate and debug firmware on a target board. This user’s guide is composed of the following chapters:

• Chapter 1. “Introduction” provides a brief overview of the starter kit, highlighting its features and uses.

• Chapter 2. “Hardware” provides the hardware descriptions of the starter kit.

• Appendix A. “Schematics” provides a block diagram, board layouts, and detailed schematics of the starter kit.

• Appendix B. “Bill of Materials” provides the bill of materials for the components used in the design and manufacture of the starter kit.

 2017 Microchip Technology Inc. DS70005311A-page 7

PIC32MZ DA Family Starter Kit User’s Guide

Note 1: This is a note used in a

table.

Note: This is a standard

note box.

CAUTION

This is a caution note.

CONVENTIONS USED IN THIS GUIDE

This manual uses the following docum enta t io n conven tio ns :

DOCUMENTATION CONVENTIONS

Description Represents Examples

Italic characters Referenced books MPLAB X IDE User’s Guide

Emphasized text ...is the only compiler...

Initial caps A window the Output window

A dialog the Setti ngs dialog A menu selection select Enable Program mer

Quotes A field name in a window or

dialog

Underlined, italic text with right angle bracket

Bold characters A dialog button Click OK

Text in angle brackets < > A key on the keyboard Press <Enter>, <F1> Plain Courier New Sample source code #define START

Italic Courier New A variable argument file.o, where file can be any

Square brackets [ ] Optional arguments mcc18 [options] file

Curly brackets and pipe character: { | }

Ellipses... Replaces repeated text var_name [, var_name...]

Notes

A menu path File > Save

A tab Click the Power tab

Filenames autoexec.bat File paths c:\mcc18\h Keywords _asm, _endasm, static Command-line options -Opa+, -Opa- Bit values 0, 1 Constants 0xFF, ‘A’

Choice of mutually exclusive arguments; an OR selection

Represents code supplied by user

A Note presents information that we want to re-emphasize, either to help you avoid a common pitfall or to make you aware of operating di fferences between some device family members. A Note can be in a box, or when used in a table or figure, it is located at the bottom of the table or figure.

“Save project before build”

valid filename

[options] errorlevel {0|1}

void main (void) { ... }

DS70005311A-page 8  2017 Mic rochip Technology Inc.

Chapter 1. Introduction

Thank you for purchasing a Microchip Technology PIC32MZ DA Family Starter Kit. This starter kit provides a low-cost modular development system for Microchip’s line of 32-bit microcontrollers.

The starter kit is available in four versions:

• PIC32MZ Embedded Graphics with External DRAM (DA) Starter Kit (P/N: DM320008)

• PIC32MZ Embedded Graphics with External DRAM (DA) Starter Kit (Crypto) (P/N: DM320008-C)

• PIC32MZ Embedded Graphics with Stacked DRAM (DA) Starter Kit (P/N: DM320010)

• PIC32MZ Embedded Graphics with Stacked DRAM (DA) Starter Kit (Crypto) (P/N: DM320010-C)

The four versions of the starter kit which are facilitated through a common base board (referred to as PIC32MZ DA SK Base Board) and four different CPU Daughter Cards (referred to as PIC32MZ2064DAx288 Daughter Card and PIC32MZ2064DAx169 Daughter Card) are given below:

• DM320008 comes with PIC32MZ2064DAA288 Daughter Card

• DM320008-C comes with PIC32MZ2064DAB288 Daughter Card

• DM320010 comes with PIC32MZ2064DAG169 Daughter Card

• DM320010-C has PIC32MZ2064 DAH1 69 Daug hter Card

Any configur ation o f the PIC32 Em bedded Gr aphics Starte r Kit ca n be us ed in con junction with Multimedia Expansion Board II (MEB-II) at http://www.microchip.com/meb2 to exercise the embedded graphics features.

For a free Microchip demonstration code and additional information, please visit the MPLAB Harmony page at: http://www.microchip.com/MPLABHarmony.

The MPLAB Harmony Integrated Software Framework includes several demonstrations that have configurations for the PIC32MZ DA Starter Kit. These demonstrations are available in the <install-dir>/apps folder of the MPLAB Harmony installation, where <install-dir> is either

C:/microchip/harmony/<version> (for Windows OS) or ~/microchip/harmony/<version> (for MAC or Linux OS).

For additional information on demonstrations and building/running steps, refer to the documents available in the <install-dir>/doc folder.

This chapter covers the following topics:

• Kit Contents

• Starter Kit Functionality and Features

 2017 Microchip Technology Inc. DS70005311A-page 13

PIC32MZ DA Family Starter Kit User’s Guide

+3.3V Power

Supply

(U2)

+5V_EXT (J3)

+5V_CPU (J4)

VBUS_PKOB (J19)

VBUS_ OTG (J6)

+1.8V Power

Supply

(U4)

PIC32MZ2064DAG169

(non -Cry pto an d inter nal DDR)

PIC32 MZ20 64D AH16 9

(Cry pto an d inter nal DD R)

PIC32 MZ20 64D AA28 8

(non-Crypto and ex ter nal DDR)

PIC32 MZ20 64D AB28 8

(non-Crypto and ex ter nal DDR)

USB OT G

(J6)

USB Host

(J7)

Application Board Connector

(J3)

Ether net

PHY

Daug hter

Board

PIC32MZ2064DAxNNN

(1)

Daugh ter Card

10/100 Jack

ME B II fo r Gr ap hic s,

Aud io etc. ,

USB-to-UART/I2C Circuit

(MC P2221 -I/M Q)

Debu gger Circuit

(PIC24FJ256GB 106)

Device

(Type micro-A/B)

Switches

(SW1 , SW 2 and SW3 )

LEDs

(D6, D7 an d D8)

Note 1: NNN=169/288

2: Only applicable to external DRAM version (DM320008 and DM320008-C) of the PIC32MZ DA Starter Kit

40-pi n Ex pansion Conne ctor

(J15)

DDR2-SDRAM

(2)

+5V_EXT

V

DDIO, AVDD

Micro-SD

Slot

(J10)

Device/OT G

(Type micro-A/B)

Host

(Type- A)

Debu g

(Type micro-A/B)

SQI-Flash

(U5)

VDDCORE, VDDR1V8

+3.3V

+5V

+3.3V

+1.8V

1.1 KIT CONTENTS

The PIC32MZ DA Starter Kit contains the following items:

• One PIC32MZ Embedded Graphics (DA) Starter Kit

• One LAN8740A Ethernet PHY Daughter Board

• One Type-A male to Micro-B USB cable (to communicate with the PIC32 DEBUG port)

• One ETH cable

• Information sheet

Note: If you are missing any part of the kit, contact a Microchip sales office for

assistance. A list of Microchip offices for sales and service is provided on the last page of this document.

1.2 BLOCK DIAGRAM

Figure 1-1 illustrates the high-level block diagram of the PIC32MZ DA Starter Kit.

FIGURE 1-1: HIGH-LEVEL BLOCK DIAGRAM OF THE PIC32MZ DA STARTER KIT

DS70005311A-page 14  2017 Microchip Technology Inc.

1.3 STARTER KIT FUNCTIONALITY AND FEATURES

1

2

3

4

5

6

7

8

9

10

11

1.3.1 Development Board

Representations of the layout of the developme nt board incl uded in the PIC32MZ DA Family Starter Kit are shown in Figure 1-2 through Figure 1-7.

The top asse mbl y of t he P IC32 MZ DA SK Base Board includes thes e key fea ture s, as indicated in Figure 1-2.

1. USB Micro-B power supply connector (J4).

2. Headers to connect PIC32MZ2064DAx288/PIC32MZ2064DAx169 CPU Daughter Cards (J2, J3).

3. Micro-SD slot (J10).

4. Headers for flexible Ethernet PHY options (J9).

5. USB Type-A connector for PIC32 USB host based applications (J7).

6. USB Micro-B connector for USB-to-UART communication (J5).

7. Three push button switches for user-defined inputs (S1, S2, and S3).

8. T hree use r -d efined ind ic ato r LED s (D3, D4, and D5).

9. Jumper for using or disconnecting the on-board debugger (J17).

10. Connector for an external debugger, such as MPLAB® REAL ICE or MPLAB ICD 3 (J12).

11. 40-pin expansion connector for adding external boards (J15).

Introduction

Note: When running self-powered USB device applications, open the jumper JP1

to prevent possibly back-feeding voltage onto the V the host to another (or from one host to another).

For details on these features, refer to Chapter 2. “Hardware”.

FIGURE 1-2: PIC32MZ DA SK BASE BOARD LAYOUT (TOP VIEW)

BUS

from one port on

 2017 Microchip Technology Inc. DS70005311A-page 15

PIC32MZ DA Family Starter Kit User’s Guide

1

2

3

4

5

6

The bottom assembly of the PIC32MZ DA SK Base Board includes these key features, as indicated in Figure 1-3.

1. USB Micro-B connector for on-board debugger (J19).

2. USB T ype Micro-AB receptacle for OTG and USB device connectivity for PIC32 OTG/Device-based applications (J6).

3. PIC24FJ256GB106 USB microcontroller for on-board debugging (U7).

4. SS T 26V F032 B SQ I- Flas h Mem or y (U5).

5. 50 MHz Ethernet PHY oscillator (Y1).

6. 168-pin Hirose connector for various application boards, such as MEB-II (J3).

FIGURE 1-3: PIC32MZ DA SK BASE BOARD LAYOUT (BOTTOM VIEW)

DS70005311A-page 16  2017 Microchip Technology Inc.

Introduction

The top assembly of the PIC32MZ2064DAx288 Daughter Card includes these key features, as indicated in Figure 1-4.

1. PIC32MZ2064DAA288 (DM320008) or PIC32MZ2064DAB288 (DM320008-C)

(U1).

2. Micron 1 Gbit DDR2-SDRAM (MT47H64M16NF-25E) (U3).

3. 24 MHz osc illator (Y1).

4. 24 MHz crystal (Y3) and 32.768

Note: Y2 and Y3 are ‘Do Not Populate’ (DNP).

5. 1.8V Regulator (power supply for DDR2-SDRAM, V

(MIC69101) (J7).

6. 3.3V Power LED ( LD2).

FIGURE 1-4: PIC32MZ2064DAx288 DAUGHTER CARD LAYOUT

(TOP VIEW)

k

Hz clock (Y2).

DDR1V8

and V

DDCORE

)

 2017 Microchip Technology Inc. DS70005311A-page 17

PIC32MZ DA Family Starter Kit User’s Guide

The bottom assembly of the PIC32MZ2064DAx288 Daughter Card includes these key features, as indicated in Figure 1-5.

1. Headers to connect the PIC32MZ DA SK Base Board Daughter Cards.

FIGURE 1-5: PIC32MZ2064DAx288 DAUGHTER CARD LAYOUT

(BOTTOM VIEW)

DS70005311A-page 18  2017 Microchip Technology Inc.

Introduction

The top assembly of the PIC32MZ2064DAx169 Daughter Card includes these key features, as indicated in Figure 1-6:

1. PIC32MZ2064DAA169 (DM320010) or PIC32MZ2064DAB169 (DM320010-C)

(U1).

2. 24 MHz osc illator (Y2).

3. 24 MHz crystal (Y3).

Note: Y3 is ‘Do Not Populate’ (DNP).

4. 32.768 kHz crystal (Y1)

Note: Y1 is ‘Do Not Populate’ (DNP).

5. 1.8V Regulator (power supply for DDR2-SDRAM, V

(MIC69101) (J7).

6. 3.3V Power LED ( LD2).

FIGURE 1-6: PIC32MZ2064DAx169 DAUGHTER CARD LAYOUT

(TOP VIEW)

DDR1V8

and V

DDCORE

)

 2017 Microchip Technology Inc. DS70005311A-page 19

PIC32MZ DA Family Starter Kit User’s Guide

The bottom assembly of the PIC32MZ2064DAx169 Daughter Card includes these key features, as indicated in Figure 1-7.

1. Headers to connect the PIC32MZ DA SK Base Board Daughter Cards.

FIGURE 1-7: PIC32MZ2064DAx169 DAUGHTER CARD LAYOUT

(BOTTOM VIEW)

DS70005311A-page 20  2017 Microchip Technology Inc.

Introduction

1.3.2 LAN8740A PHY Daughter Board

Representation of the layout of the daughter board included in the PIC32MZ DA Family Starter Kit is shown in Figure 1-8 and Figure 1-9.

FIGURE 1-8: DAUGHTER BOARD LAYOUT (TOP VIEW)

FIGURE 1-9: DAUGHTER BOARD LAYOUT (BOTTOM VIEW)

 2017 Microchip Technology Inc. DS70005311A-page 21

PIC32MZ DA Family Starter Kit User’s Guide

NOTES:

DS70005311A-page 22  2017 Microchip Technology Inc.

Chapter 2. Hardware

This chapter describes the hardware features of the PIC32MZ DA Starter Kit.

2.1 HARDWARE FE ATURES

The following key features of the starter kit are presented in the order given in

Section 1.3 “Starter Kit Functionality and Features”. You can refer to Figure 1-2

through Figure 1-7 for their locations on the development board.

2.1.1 Processor Support

Depending on the starter kit that you have purchased, the development board comes with a CPU Daughter Card containing a permanently mounted (i.e., soldered) processor as given below:

• PIC32MZ Embedded Graphics External DRAM (DA) Starter Kit (DM320008):

PIC32MZ2064DAA288

• PIC32MZ Embedded Graphics External DRAM (DA) Starter Kit (Crypto)

(DM320008-C): PIC32MZ2064DAB288

• PIC32MZ Embedded Graphics Stacked DRAM (DA) Starter Kit (DM320010):

PIC32MZ2064DAG169

• PIC32MZ Embedded Graphics Stacked DRAM (DA) Starter Kit (Crypto)

(DM320010-C): PIC32MZ2064DAA169

PIC32MZ DA FAMILY

STARTER KIT USER’S GUIDE

2.1.2 Power Supply

There are four ways to supply power to the starter kit:

• Through USB Micro-B connector (J4) – This enables using a wall adapter to

supply more power than traditional USB as needed by the most applications (preferred).

• Through USB Micro-B DEBUG connector (J19). This connector supports

debugging/programming by MPLAB tools through PKOB® interface.

• Through USB Micro-USB connector (J6).

• An external application board with a regulated DC power supply that provides +5V

can be connected to the application board connector that is provided on the bottom side of the board (J3).

One green LED (LD2) on the PIC32MZ2064DAx288 or PIC32MZ2064DAx169 CPU Daughter Card is provided to indicate the power supply to the PIC32 device.

2.1.3 Graphics Connectivity

Multimedia Expansion Board II (MEB-II) is required to exercise embedded graphics features on the PIC32MZ DA devices. MEB-II comes with a 4.3” WQVGA (480” x 272”) PCAP display to showcase graphics. In addition, there is one 5.0” WVGA PACP D isplay Board that can be used to exercise higher resolution (800” x 480”) graphics. Both of these boards provide 24-bit color.

PIC32MZ Embedded Graphics Starter Kit has been designed with a 168-pin modular expansion interface, which allows the extendibility to MEB-II.

 2017 Microchip Technology Inc. DS70005311A-page 23

PIC32MZ DA Family Starter Kit User’s Guide

2.1.4 Debug USB Connectivity

The starter kit includes a PIC24FJ256GB106 USB microcontroller that provides debugger connectivity over USB. The PIC24FJ256GB106 MCU is hard-wired to the PIC32 device to provide protocol translation through the I/O pins of the PIC24FJ256GB106 MCU to the In-Circuit Serial Programming™ (ICSP™) pins of the PIC32 device.

If an external debugger, such as MPLAB REAL ICE or MPLAB ICD3 are used with the starter kit, it is necessary to disconnect the on-board debugger from the PIC32 device, by removing the JP17 jumper. When the on-board debugger is required, replace the JP17 jumper. When the JP17 jumper is installed, pin 1 must be connected to pin 3, and pin 2 must be connected to pin 4.

2.1.5 PIC32 USB Connectivity

Users can connect to the PIC32 USB microcontroller using anyone of the following modes:

• Host Mode – Connect the device to the Type-A connector J7, which is located on

the top of the starter kit. Using this method, a maximum of 400 mA can be supplied from the debug USB port to the host port. If full 500 mA supply is needed, an external supply must be connected to the application board.

• Device Mode – Connect the debug Mini-B USB cable to port J6, and then connect

the starter kit to the host by using a cable with a Type-B micro-connector to the starter kit’s Micro-A/B port J6, which can be located on the bottom of the board. The other end of the cable must have a Type-A connector, to connect it to a USB host.

• OTG Mode – Connect the starter kit to the OTG device by using an OTG Micro-

A/B cable to the Micro-A/B port J6, which is located on the bottom of the board.

2.1.6 External Memory Connectivity

The following three external memory interfaces are available through hardware:

• DDR2-SDRAM – 128 MB of DDR2-SDRAM is mounted on the

PIC32MZ2064DAx288 Daughter Card for the External DRAM version of the starter kits (DM320008, DM320008-C). Whereas 32 MB of DDR2-SDRAM is available within the package for the s tacke d DRAM vers io n of the starter kits (DM320010, DM320010-C).

• Micro-SD slot – Supports SD, SDHC, and SDXC cards at default speed (12.5

MB/s) and high speed (25 MB/s).

• SQI Flash – 4 MB of SST26VF032B Serial Quad Flash is mounted on the bottom

of the PIC32MZ DA SK Base Board.

2.1.7 Switches

Push-button switches provide the following functionalities:

• SW1: Active-low switch connected to RB13

• SW2: Active-low switch connected to RB12

• SW3: Active-low switch connected to RB14

The push-button switches do not have any debounce circuitry and require the use of internal pull-up resistors. This enables the user to investigate software debounce techniques. When Idle, the switches are pulled high (+3.3V), and when pressed, they are grounded.

DS70005311A-page 24  2017 Microchip Technology Inc.

Hardware

2.1.8 LEDs

The LEDs, RH0 through RH2, are connected to PORTH of the processor. The LATH pins are set high to light the LEDs.

2.1.9 Oscillator Options

A 24 MHz oscillator circuit is connected to the on-board microcontroller and this oscillator circuit functions as the controller’s primary oscillator. Depending on which is populated on the starter kit board, a 24 MHz crystal may be used instead of the 24 MHz oscillator circuit.

Use of an external crystal is required to develop USB applications. The USB-specification dictates a frequency tolerance of ±0.25% for high speed, and non-USB applications can use the internal oscillators.

The starter kit also has provisions for an external secondary 32 kHz oscillator; however, it is not populated. A suitable oscillator, ECS-3X8, can be obtained from Digi-Key: P/N-X801-ND CMR200TB32.768KDZFTR.

The PIC24FJ256GB106 is independently clocked and has its own 12 MHz crystal.

2.1.10 168-pin Modular Expansion Connector

The PIC32MZ DA Family Starter Kit has been designed with a 168-pin modular expansion interface, which allows the board to provide basic generic functionality and easy extendability to new technologies as they become available. Refer to

Table 2-1 for starter kit connector part numbers.

TABLE 2-1: STARTER KIT CONNECTOR PART NUMBERS

Connector HIROSE Electric PN

Starter Kit Connector FX10A-168P-SV1(71) Application Board Connector FX10A-168S-SV

2.1.11 Ethernet PHY

The Microchip LAN8740A PHY Daughter Board is populated with a low-power, smallfootprint, 10/100 Fast Ethernet LAN8740A PHY, which features Energy Efficient Ethernet (IEEE 802.3az) and Wake-on-LAN functionality. This daughter board is designed for easy development of RMII Ethernet control applications when it is connected into a compatible PIC32 starter kit.

To use a differ ent Eth ern et PH Y, other th an wha t i s of fe red, vis it t he micr oc hi pDIR ECT website (www.microchipdirect.com) for a list of alternate options.

2.1.12 USB-to-UART/I2C Communication

T o facilitate application debug and development, a MCP2221 USB-to-UART/I2C device (U1) is available. The MCP2221 creates a virtual COM port on the personal computer when a mi ni-USB ca ble is con nected be tween J11 and the host computer . To download the driver for the MCP2221, visit the MCP2221 product page (www.microchip.com/MCP2221).

 2017 Microchip Technology Inc. DS70005311A-page 25

PIC32MZ DA Family Starter Kit User’s Guide

Table 2-2 lists the MCP2221 UART and I2C pins that are connected to the PIC32MZ

DA device.

TABLE 2-2: MCP2221 UART PIN CONNECTIONS

MCP2221 (Note 1) PIC32MZ DA Device PIC32MZ Device

Pin # Function Pin # Full Pin Name

4 RX 61 EBIA2/AN23/C2INC/RPG9/PMA2/RG9 U2TX 5 TX 14 PGED1/AN0/RPB0/CTED2/RB0 U2RX 9 SCL 16 RPF8/SCL3/RF8 SCL3

10 SDA 15 RPF2/SDA3/RF2 SDA3

Note 1: The CTS and RTS functions ar e not requ ired, but are avail able if de sired.

The MCP2221 configuration utility can be used to turn those functions on and off.

2.1.13 40-pin Expansion Connector

On the bac k of the starte r kit i s a 40-p in (2 x 20) he ader (J 15) wh ich can be use d to add expansion boards to the starter kit. The header provides 2-pin UART (through UART4 or UART6), I provides the pins and the functions availa ble throu gh them .

2

C (through I2C2), SPI (through SPI1) and GPIO capabilities. Table 2-3

UART/I

Function

2

C

TABLE 2-3: J15 CONNECTIONS

Function 1 Function 2 Pin # Pin # Function 2 Function 1

— +3V3 1 2 +5V — RF2 SDA2 3 4 +5V — RF8 SCL2 5 6 GND —

RE4 GPIO 7 8 UxTX RC3

— GND 9 10 UxRX RE8

RE7 GPIO 11 12 GPIO RH3 RB8 GPIO 13 14 GND — RA9 GPIO 15 16 GPIO RB4

— +3V3 17 18 GPIO RH4

RG8 MOSI 19 20 GND — RD7 MISO 21 22 GPIO RH6

RG6/SCK2 SCLK 23 24 CE0 RD0

— GND 25 26 CE1 RD14

RB2 GPIO 27 28 No Connect — RK1 GPIO 29 30 GND — RK2 GPIO 31 32 GPIO RJ2 RG9 GPIO 33 34 GND — RB0 GPIO 35 36 GPIO RB15 RH7 GPIO 37 38 GPIO RH12

— GND 39 40 GPIO RD15

DS70005311A-page 26  2017 Microchip Technology Inc.

A.1 SCHEMATICS

The PIC32MZ DA Family Starter Kit schematics are as follows:

• PIC32MZ2064DAx288 Daughter Card (Figure A-1 through Figure A-4)

• PIC32MZ2064DAx169 Daughter Card (Figure A-5 through Figure A-7)

• PIC32MZ DA SK Base Board (Figure A-8 through Figure A-12)

• LAN8740 PHY Daughter Card (Figure A-13)

Schematics

Appendix A. Schematics

 2017 Microchip Technology Inc. DS70005311A-page 27

PIC32MZ DA Family Starter Kit User’s Guide

PIC32MZ DA 288 CPU Card

Project Title

Designed with

Drawn By:

Serban Morea

Sheet Title

CLK - IO - CONN

Engineer:

Purnachander Mangu

Size

10492

PartNumber:

10k

R2

+3.3V

OSCI/SCKI/RC12

SOSCI/RC13

OSCO/CLKO/RC15

EBID1/AN39/PMD1/RE1

+3.3V +3.3V

24MHz

EN

1

GND

2

OUT

3

VDD

4

Y1

24MHz

Y3

8.0pF

C3

8.0pF

C4

Only Oscillator or Crystal Configuration

should be populated.

Please check PCB/BOM to determine

which configuration is populated

OSCI/SCKI/RC12

SOSCI/RC13

OSCO/CLKO/RC15

DNP

TC25L5I32K7680

EN

1

GND2OUT

3

VDD

4

Y2

32.768 kHz

1V8_PWRGD

OSCI/SCKI/RC12

SOSCI/RC13

OSCO/CLKO/RC15

i Crystal

1.5k

R14

+3.3V

2.2k

R15

+3.3V+3.3V

+3.3V

DF40HC(3.0)-100DS-0.4V(58)

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

3

4

5

6

7

8

9

10

11

12

13

15

16

1

18

19

20

21

22

23

24

25

26

2

28

29

30

31

32

33

34

35

36

3

38

39

0

43

4

4546

47

8

49

50

5152

53

54

5556

57

8

59

60

61

62

63

64

65

66

6

68

6970

7172

7

4

75

76

77

78

79

80

81 82

83 84

85 86

87 88

89 90

91 92

93 94

95 96

97 98

99 100

J1

1M

R1

0.1μF

C2

0.1μF

C1

TMS/SDCD/RA0

SQICS1/CS/RD5

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

SDDATA0/SQID0/RG13

SDDATA1/SQID1/RG12

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

USB_N

USB_P

VBUS

USBID

SOSCO/RPC14/T1CK/RC14

TCK/AN24/RA1

AN22/RPD14/RD14

AN29/SCK3/RB14

AN35/RH3

EBIRDY2/AN37/RH11

EBIA1/AN38/PMA1/PSPA1/RK1

EBIA3/AN11/PMA3/RK2

SCL2/RA2

EBIRDY1/SDA2/RA3

RPA14/SCL1/RA14 RPA15/SDA1/RA15

EBID3/RPE3/PMD3/RE3

SCK4/RD10

EBID2/PMD2/RE2

RTCC/RPD0/RD0

MCLR

RPF8/SCL3/RF8

SDWP/RH2

EBIA5/AN7/PMA5/RA5

VREF-/CVREF-/AN27/RA9

VREF+/CVREF+/AN28/RA10

PGED1/AN0/RPB0/CTED2/RB0 PGEC1/AN9/RPB1/CTED1/RB1 AN1/CTCMP/C2INB/RPB2/RB2

AN8/RPB3/RB3

AN2/C1INB/RB4

RPB5/RB5 PGEC2/RB6 PGED2/RB7 EBID10/AN4/RPB8/PMD10/RB8 EBIA7/LVDIN/RPB9/PMA7/RB9 CVREFOUT/AN5/RPB10/RB10

AN49/RB11

AN6/RB12 AN48/CTPLS/RB13

AN3/C2INA/RPB15/OCFB/RB15

EBID5/AN12/RPC1/PMD5/RC1

EBID12/AN10/RPC2/PMD12/RC2

EBIWE/AN34/RPC3/PMWR/RC3

EBIOE/AN19/RPC4/PMRD/RC4

SCK1/RD1

AN33/SCK6/RD15

EBID0/PMD0/RE0

EBID4/AN18/PMD4/RE4 EBIA6/RPE5/PMA6/RE5 EBID6/AN16/PMD6/RE6 EBID7/AN15/PMD7/RE7

AN25/RPE8/RE8

AN26/RPE9/RE9

RPF2/SDA3/RF2

TDO/AN31/RPF12/RF12

TDI/AN17/SCK5/RF13

AN14/C1IND/SCK2/RG6 AN13/C1INC/RPG7/SDA4/RG7 AN30/C2IND/RPG8/SCL4/RG8 EBIA2/AN23/C2INC/RPG9/PMA2/RG9

AN21/RG15

AN20/RH4

EBIA4/AN36/PMA4/RH7

INT0/RH14

EBIRDY3/AN32/RJ2

EBIA0/PMA0/RJ15

EBIA6/RPE5/PMA6/RE5

INT0/RH14

SCK1/RD1

EBID4/AN18/PMD4/RE4

RPF2/SDA3/RF2

EBID0/PMD0/RE0

AN21/RG15

AN20/RH4

AN14/C1IND/SCK2/RG6

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

TDI/AN17/SCK5/RF13

AN13/C1INC/RPG7/SDA4/RG7

AN30/C2IND/RPG8/SCL4/RG8

AN25/RPE8/RE8

EBID6/AN16/PMD6/RE6

AN26/RPE9/RE9

TDO/AN31/RPF12/RF12

EBID7/AN15/PMD7/RE7

EBID5/AN12/RPC1/PMD5/RC1

EBIWE/AN34/RPC3/PMWR/RC3

EBIOE/AN19/RPC4/PMRD/RC4EBID12/AN10/RPC2/PMD12/RC2

PGEC2/RB6

PGEC1/AN9/RPB1/CTED1/RB1

AN48/CTPLS/RB13

VREF+/CVREF+/AN28/RA10

AN3/C2INA/RPB15/OCFB/RB15 EBID10/AN4/RPB8/PMD10/RB8

EBIA7/LVDIN/RPB9/PMA7/RB9

AN8/RPB3/RB3

VREF-/CVREF-/AN27/RA9 AN2/C1INB/RB4

EBIA5/AN7/PMA5/RA5

AN6/RB12PGED2/RB7

PGED1/AN0/RPB0/CTED2/RB0

RPB5/RB5

CVREFOUT/AN5/RPB10/RB10

EBIA4/AN36/PMA4/RH7

AN33/SCK6/RD15

AN1/CTCMP/C2INB/RPB2/RB2

EBIRDY3/AN32/RJ2

EBIA0/PMA0/RJ15

EBIA7/LVDIN/RPB9/PMA7/RB9

PIC32MZ2064DAx288-I/4J

NC

A1

INT0/RH14

A6

RPF2/SDA3/RF2

A7

AN21/RG15

A8

AN14/C1IND/SCK2/RG6

A9

TDI/AN17/SCK5/RF13

A10

TDO/AN31/RPF12/RF12

A11

EBID5/AN12/RPC1/PMD5/RC1

A12

EBIOE/AN19/RPC4/PMRD/RC4

A13

PGEC1/AN9/RPB1/CTED1/RB1

A14

EBID10/AN4/RPB8/PMD10/RB8

A15

AN8/RPB3/RB3

A16

VREF-/CVREF-/AN27/RA9

A17

NC

A18

NC

B1

EBID4/AN18/PMD4/RE4

B6

EBID0/PMD0/RE0

B7

AN20/RH4

B8

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

B9

AN26/RPE9/RE9

B10

EBID7/AN15/PMD7/RE7

B11

NC

B12

EBIWE/AN34/RPC3/PMWR/RC3

B13

PGEC2/RPB6/RB6

B14

AN48/CTPLS/RB13

B15

AN3/C2INA/RPB15/OCFB/RB15

B16

AN2/C1INB/RB4

B17

EBIA5/AN7/PMA5/RA5

B18

NC

C8

AN30/C2IND/RPG8/SCL4/RG8

C9

AN25/RPE8/RE8

C10

EBID6/AN16/PMD6/RE6

C11

EBID12/AN10/RPC2/PMD12/RC2

C13

AN49/RB11

C14

VREF+/CVREF+/AN28/RA10

C15

AN1/CTCMP/C2INB/RPB2/RB2

C17

AN6/RB12

C18

NC

D6

EBID1/AN39/PMD1/RE1

D8

AN13/C1INC/RPG7/SDA4/RG7

D9

PGED2/C1INA/AN46/RPB7/RB7

D17

PGED1/AN0/RPB0/CTED2/RB0

D18

NC

E5

NC

E6

NC

E7

NC

E8

NC

E9

NC

E10

NC

E11

NC

E12

NC

E13

NC

E14

CVREFO/AN5/RPB10/RB10

E18

NC

F5

NC

F14

NC

F17

NC

F18

NC

G5

NC

G14

NC

G16

OSCI/CLKI/RC12

G17

OSCO/CLKO/RC15

G18

NC

H5

NC

H14

TCK/AN24/RA1

H16

SOSCI/RPC13/RC13

H17

SOSCO/RPC14/T1CK/RC14

H18

NC

J2

NC

J5

NC

J14

AN33/SCK6/RD15

J16

AN29/SCK3/RB14

J17

AN22/RPD14/RD14

J18

EBIA6/RPE5/PMA6/RE5

K3

NC

K5

NC

K14

EBIRDY3/AN32/RJ2

K16

SCK1/RD1

M4

NC

L5

NC

L14

NC

M5

NC

M14

NC

N5

NC

N14

EBIA4/AN36/PMA4/RH7

N15

EBIA0/PMA0/RJ15

N17

NC

P5

NC

P6

NC

P7

NC

P8

NC

P9

NC

P10

NC

P11

NC

P13

NC

P14

EBIRDY2/AN37/RH11

P17

AN35/RH3

P18

NC

P12

MCLR#

R5

EBIA3/AN11/PMA3/RK2

R17

EBIA1/AN38/PMA1/PSPA1/RK1

R18

EBID3/RPE3/PMD3/RE3

T9

NC

T14

RPA14/SCL1/RA14

T16

RPF8/SCL3/RF8

P4

RPA15/SDA1/RA15

U16

EBIRDY1/SDA2/RA3

U17

SCL2/RA2

U18

NC

V1

RTCC/RPD0/RD0

V5

SCK4/RD10

V6

EBID2/PMD2/RE2

V10

NC

V18

C

I

2

A

5

A

TDO

EBIO

C4

1

AN8/

V

/CV

9

C

E

0

4

G9

A

E

7

C

EBIWE/

C3

PGEC

6

3

A

5

C

G8

A

8

E

1

V

0

AN6/

C

E

1

G7

C

CV

C

OSCI/C

2

OSCO/CLKO/RC

C

1

SOSCI/RPC13/RC

SOSCO/RPC14/T1CK/RC14

C

5

A

E

C

J2

SC

1

C

E

7

5

C

1

C

#

E

1

E

C

/SCL1/

4

8

E

SC

2

C

CC/

0

SCK4/

2

C

EBIA7/AN47/LVDIN/RPB9/PMA7/RB9

E16

AN45/RPB5/RB5

E17

NC

T5

NC

C12

U1A

FIGURE A-1: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (1 OF 4)

N N N N N

N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N N

N N N

MCLR

TCK/AN24/RA

L2/RA

BIRDY1/SDA2/RA3

EBIA5/AN7/PMA5/RA

REF-

REF-/AN27/RA

REF+/CVREF+/AN28/RA1

RPA14 RPA15/SDA1/RA15

PGED1/AN0/RPB0/CTED2/RB0 PGEC1/AN9/RPB1/CTED1/RB AN1/CTCMP/C2INB/RPB2/RB2

PGED2/C1INA/AN46/RPB7/RB7

EBID10/AN4/RPB8/PMD10/RB8

AN3/C2INA/RPB15/OCFB/RB15

EBID5/AN12/RPC1/PMD5/RC1

EBID12/AN10/RPC2/PMD12/RC2

AN13/C1INC/RPG7/SDA4/R AN30/C2IND/RPG8/SCL4/R

EBIA2/AN23/C2INC/RPG9/PMA2/R

EBIA1/AN38/PMA1/PSPA1/RK

RPB3/RB3

N2/C1INB/RB4

2/RPB6/RB

REFO/AN5/RPB10/RB10

AN49/RB1

AN48/CTPLS/RB1

N29/SCK3/RB14

AN34/RPC3/PMWR/R

E/AN19/RPC4/PMRD/R

LKI/RC1

RT

RPD0/RD

K1/RD

AN22/RPD14/RD14

AN33/SCK6/RD1

EBID0/PMD0/RE

BID1/AN39/PMD1/RE

EBID2/PMD2/RE BID3/RPE3/PMD3/RE3 BID4/AN18/PMD4/RE4 BIA6/RPE5/PMA6/RE5 BID6/AN16/PMD6/RE6 BID7/AN15/PMD7/RE

N25/RPE8/RE

N26/RPE9/RE9

RPF2/SDA3/RF

RPF8/SCL3/RF

/AN31/RPF12/RF12

TDI/AN17/SCK5/RF13

N14/C1IND/SCK2/RG6

N21/RG1

AN35/RH3 AN20/RH

BIA4/AN36/PMA4/RH

EBIRDY2/AN37/RH1

NT0/RH14

EBIRDY3/AN32/R

EBIA0/PMA0/RJ1

BIA3/AN11/PMA3/RK2

RA1

RB12

15 13

RD10

7

4

1 4

4

5

7

3 7

DS70005311A-page 28  2017 Microchip Technology Inc.

 2017 Microchip Technology Inc. DS70005311A-page 29

Drawn By

Serban M

Sheet Titl

ETH -

Engineer:

Purnach

Size

C

10492

PartNumb

ETXCLK/RPD7

ERXCLK/RJ11

ECOL/RH10

ERXERR/RPF3

ECRS/RH12

EMDIO/RJ1

EMDC/RPD11

ERXDV/RH13

ETXERR/RJ0

ETXEN/RPD6

ETXD0/RJ8

ETXD1/RJ9

ETXD2/RH0

ETXD3/RH1

ERXD0/RH8

ERXD1/RH5

ERXD2/RH6

ERXD3/RH9

+3.3V

VSYNC/EBISC0/RJ4

HSYNC/EBICS1/RJ5

GCLK/CLKIN/EBICS2/RJ6

GEN/DEN/EBICS3/RJ7

GD0/R0/EBID13/RJ13

GD1/R1/EBID14/RA4

GD2/R2/EBID15/RD9

GD3/R3/EBIA8/RG0

GD4/R4/EBIA9/RG1

GD5/R5/EBIA10/RF1

GD6/R6/EBIA11/RF0

GD7/R7/EBIA12/RD12

GD8/G0/EBID11/RJ14

GD9/G1/EBIBS0/RJ12

GD10/G2/EBIA14/RD2

GD11/G3/EBIA15/RD3

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

GD15/G7/EBIA20/RK6

GD16/B0/EBID8/RF5

GD17/B1/EBID9/RF4

GD18/B2/EBIBS1/RJ10

GD19/B3/EBIA21/RK7

GD20/B4/EBIA22/RJ3

GD21/B5/EBIA23/RH15

GD22/B6/EBIA13/RD13

GD23/B7/EBIA16/RK0

+3.3V

USB_P

USB_N

USBID

+5V+5V

ETXCLK/

ERXCLK/

ECOL/

E

ECRS/

E

EMDC/

E

3

E

J0

E

J8

E

J9

E

0

E

8

E

USB_

US

i ETH

i SQI/SD

i USB

VSYNC/

4

5

GCLK/C

6

GEN/

7

GD0/R0/

3

GD1/R1/

4

GD2/R2/

9

0

GD4/R4/

G1

GD5/R5/

1

GD6/R6/

0

GD7/R7/

2

GD8/G0/

4

GD9/G1/

2

G

2

G

3

G

3

G

4

G

5

G

6

G

5

G

4

G

0

G

7

G

3

G

5

G

3

G

0

iLCD

TMS/SDCD/RA0

GCLK/CLKIN/EBICS2/RJ6

DF40HC(3.0)-100DS-0.4V(58)

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

3

4

5

6

7

8

9

10

11

12

13

15

16

1

18

19

20

23

2

25

26

2

28

29

30

313

33

3

35

36

37

38

39

0

43

44

4546

4

48

49

50

51

52

53

54

55

56

57

58

59

60

616

63

6

65

66

6

68

69

7

717

737

7576

77

7

79

80

81 82

83 84

85 86

87 88

89 90

91 92

93 94

95 96

97 98

99 100

J2

SQICS1/CS/RD5

SDCK/SQICLK/RA6

SDDATA3/SQID3/RA7

SDDATA1/SQID1/RG12

SDDATA0/SQID0/RG13

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

VBUS

SQICS1/CS/RD5

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

SDDATA0/SQID0/RG13

SDDATA1/SQID1/RG12

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

TMS/SDCD/RA0

ECOL/RH10

ERXERR/RPF3

ERXD2/RH6

ERXD1/RH5

ECRS/RH12

ERXDV/RH13

ERXD0/RH8

ERXD3/RH9

ERXCLK/RJ11

ETXD2/RH0

EMDIO/RJ1

ETXD0/RJ8

EMDC/RPD11

ETXERR/RJ0

ETXEN/RPD6 GD15/G7/EBIA20/RK6

GD16/B0/EBID8/RF5

GD17/B1/EBID9/RF4

GD18/B2/EBIBS1/RJ10

GD19/B3/EBIA21/RK7

GD20/B4/EBIA22/RJ3

GD21/B5/EBIA23/RH15

GD22/B6/EBIA13/RD13

GD23/B7/EBIA16/RK0

GD7/R7/EBIA12/RD12

GD8/G0/EBID11/RJ14

GD9/G1/EBIBS0/RJ12

GD10/G2/EBIA14/RD2

GD11/G3/EBIA15/RD3

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

GEN/DEN/EBICS3/RJ7

GD0/R0/EBID13/RJ13

GD1/R1/EBID14/RA4

GD2/R2/EBID15/RD9

GD3/R3/EBIA8/RG0

GD4/R4/EBIA9/RG1

GD5/R5/EBIA10/RF1

GD6/R6/EBIA11/RF0

VSYNC/EBISC0/RJ4

HSYNC/EBICS1/RJ5

USB_N

USB_P

VBUS

USBID

ETXD1/RJ9

ETXCLK/RPD7

ETXD3/RH1

SOSCO/RPC14/T1CK/RC14

TCK/AN24/RA1

AN22/RPD14/RD14

AN29/SCK3/RB14

AN35/RH3

EBIRDY2/AN37/RH11

EBIA1/AN38/PMA1/PSPA1/RK1

EBIA3/AN11/PMA3/RK2

SCL2/RA2

EBIRDY1/SDA2/RA3

RPA14/SCL1/RA14

RPA15/SDA1/RA15

MCLR

EBID3/RPE3/PMD3/RE3

SCK4/RD10

EBID2/PMD2/RE2

RTCC/RPD0/RD0

RPF8/SCL3/RF8

SDWP/RH2

1V8_PWRGD

SDWP/RH2

AN49/RB11

TP TAB Silver

TP1

PIC32MZ2064DAx288-I/4J

TMS/SDCD/RA0

D4

TRCLK/SDCK/SQICLK/RA6

E4

TRD3/SDDATA3/SQID3/RA7

F4

TRD1/SDDATA1/SQID1/RG12

G4

TRD0/SDDATA0/SQID0/RG13

H4

TRD2/SDDATA2/SQID2/RG14

J4

SDCMD/SQICS0/RPD4/RD4

K4

SQICS1/RPD5/RD5

L4

SDWP/EBIRP/RH2

N16

ERXD2/RH6

T10

ECOL/RH10

T11

ETXD3/RH1

T12

ETXD1/RJ9

T13

ETXCLK/RPD7/RD7

T15

ERXERR/RPF3/RF3

U8

ERXD1/RH5

U10

ERXD0/RH8

U12

ERXCLK/RJ11

U13

EMDIO/RJ1

U14

EMDC/RPD11/RD11

U15

ECRS/RH12

U11

ERXDV/RH13

V11

ERXD3/RH9

V12

ETXD2/RH0

V13

ETXD0/RJ8

V14

ETXERR/RJ0

V15

ETXEN/RPD6/RD6

V16

VBUS

C5

D-

A4

D+

B4

VUSB3V3

C4

USBID

C6

VUSB3V3

D5

0

T

7

2

3

SDW

2

6

0

E

1

E

J9

3

8

1

E

J1

EMDC

2

E

3

E

0

E

J8

J0

6

VBUS

D

VUSB3V3

USBID

VUS

3

U1B

PIC32MZ2064DAx288-I/4J

GD20/EBIA22/RJ3

K17

VSYNC/EBICS0/RJ4

K18

GEN/EBICS3/RJ7

L16

GCLK/EBICS2/RJ6

L17

HSYNC/EBICS1/RJ5

L18

GD0/EBID13/PMD13/RJ13

M16

GD9/EBIBS0/RJ12

M17

GD18/EBIBS1/RJ10

M18

GD8/EBID11/PMD11/RJ14

N18

GD13/EBIA18/RK4

P15

GD23/EBIA16/RK0

P16

GD10/EBIA14/RPD2/PMA14/PMCS1/RD2

R6

GD14/EBIA19/RK5

R15

GD12/EBIA17/RK3

R16

GD22/EBIA13/PMA13/RD13

N4

GD11/EBIA15/RPD3/PMA15/PMCS2/RD3

T6

GD16/EBID8/RPF5/SCL5/PMD8/RF5

T7

GD4/EBIA9/RPG1/PMA9/RG1

T8

GD19/EBIA21/RK7

T17

GD15/EBIA20/RK6

T18

GD7/EBIA12/RPD12/PMA12/RD12

U5

GD2/EBID15/RPD9/PMD15/RD9

U6

GD5/EBIA10/RPF1/PMA10/RF1

U7

GD17/EBID9/RPF4/SDA5/PMD9/RF4

U9

GD6/EBIA11/RPF0/PMA11/RF0

V7

GD21/EBIA23/RH15

V8

GD3/EBIA8/RPG0/PMA8/RG0

V9

GD1/EBID14/PMD14/RA4

V17

G

J3

VSYNC

G

J7

GCLK/

J6

HSYNC/

G

GD9/

2

G

GD8/

G

3

G

3

G

/SCL5/

G

G1

G

7

G

GD7/

2

G

4

G

0

G

U1C

FIGURE A-2: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (2 OF 4)

ETXCLK/RPD7/RD7

ERXERR/RPF3/RF

ETXEN/RPD6/RD

SQICS1/RPD5/RD5

RCLK/SDCK/SQICLK/RA6

RD3/SDDATA3/SQID3/RA

TRD1/SDDATA1/SQID1/RG1

TRD0/SDDATA0/SQID0/RG1

SDCMD/SQICS0/RPD4/RD4

TRD2/SDDATA2/SQID2/RG14

ERXCLK/RJ1

ECOL/RH1

ECRS/RH1

MDIO/R

/RPD11/RD11

RXDV/RH1

ETXERR/R

TXD0/R

TXD1/R

TXD2/RH

TXD3/RH

ERXD0/RH

ERXD1/RH5

ERXD2/RH

ERXD3/RH9

P/EBIRP/RH

TMS/SDCD/RA

-

+

B3V

RXERR/RPF3

MDIO/RJ1

RXDV/RH1

TXERR/R

TXEN/RPD6

TXD0/R

TXD1/R

TXD2/RH

TXD3/RH1

RXD0/RH

RXD1/RH5

RXD2/RH6

RXD3/RH9

RPD7

RJ11

RH10

RH12

RPD11

N

P

BID

7

1

2

4

7

2

4

7

2

4

7

0

2

4

8

EBISC0/RJ

HSYNC/EBICS1/RJ

LKIN/EBICS2/RJ

DEN/EBICS3/RJ

EBID13/RJ1

EBID14/RA

EBID15/RD

GD3/R3/EBIA8/RG

EBIA9/R

EBIA10/RF

EBIA11/RF

EBIA12/RD1

EBID11/RJ1

EBIBS0/RJ1

D10/G2/EBIA14/RD

D11/G3/EBIA15/RD

D12/G4/EBIA17/RK

D13/G5/EBIA18/RK

D14/G6/EBIA19/RK

D15/G7/EBIA20/RK

D16/B0/EBID8/RF

D17/B1/EBID9/RF

D18/B2/EBIBS1/RJ1

D19/B3/EBIA21/RK

D20/B4/EBIA22/RJ

D21/B5/EBIA23/RH1

D22/B6/EBIA13/RD1

D23/B7/EBIA16/RK

/EBICS0/RJ4

EBICS1/RJ5

EBICS2/R

EN/EBICS3/R

D0/EBID13/PMD13/RJ13

D1/EBID14/PMD14/RA4

D2/EBID15/RPD9/PMD15/RD9

D3/EBIA8/RPG0/PMA8/RG0

D4/EBIA9/RPG1/PMA9/R

D5/EBIA10/RPF1/PMA10/RF1

D6/EBIA11/RPF0/PMA11/RF

EBIA12/RPD12/PMA12/RD1

EBID11/PMD11/RJ14

EBIBS0/RJ1

D10/EBIA14/RPD2/PMA14/PMCS1/RD2

D11/EBIA15/RPD3/PMA15/PMCS2/RD

D12/EBIA17/RK3

D13/EBIA18/RK4

D14/EBIA19/RK5

D15/EBIA20/RK6

D16/EBID8/RPF5

D17/EBID9/RPF4/SDA5/PMD9/RF

D18/EBIBS1/RJ10

D19/EBIA21/RK

D20/EBIA22/R

D21/EBIA23/RH15

D22/EBIA13/PMA13/RD1

D23/EBIA16/RK0

PMD8/RF5

Schematics

DS70005311A-page 30  2017 Microchip Technology Inc.

Drawn By:

Serban Morea

Engineer:

Purnachander Mangu

NC

A2

UDQS

A8

DQ14

B1

UDM

B3

UDQS

B7

DQ15

B9

DQ9

C2

DQ8

C8

DQ12

D1

DQ11

D3

DQ10

D7

DQ13

D9

NC

E2

LDQS

E8

DQ6

F1

LDM

F3

LDQS

F7

DQ7

F9

DQ1

G2

DQ0

G8

DQ4

H1

DQ3

H3

DQ2

H7

DQ5

H9

CK

J8

CKE

K2

WE

K3

RAS

K7

CK

K8

ODT

K9

BA2

L1

BA0

L2

BA1

L3

CAS

L7

CS

L8

A10

M2

A1

M3

A2

M7

A0

M8

A3

N2

A5

N3

A6

N7

A4

N8

A7

P2

A9

P3

A11

P7

A8

P8

A12

R2

RFU

R3

RFU

R7

RFU

R8

MT47H64M16HR-3:H TR

U3A

Vdd

A1

Vss

A3

VssQ

A7

VddQ

A9

VssQ

B2

VssQ

B8

VddQ

C1

VddQ

C3

VddQ

C7

VddQ

C9

VssQ

D2

VssQ

D8

Vdd

E1

Vss

E3

VssQ

E7

VddQ

E9

VssQ

F2

VssQ

F8

VddQ

G1

VddQ

G3

VddQ

G7

VddQ

G9

VssQ

H2

VssQ

H8

VddL

J1

VREF

J2

Vss

J3

VssDL

J7

Vdd

J9

Vdd

M9

Vss

N1

Vss

P9

Vdd

R1

MT47H64M16HR-3:H TR

U3B

DDR2_nRAS DDR2_nWE

DDR2_nCAS

DDR2_nCS

DDR2_ODT

DDR2_CKE

DDR2_UDM

DDR2_LDM

DDR2_UDQS_P

DDR2_UDQS_N

DDR2_LDQS_N DDR2_LDQS_P

DDR2_BA0

DDR2_BA1

DDR2_BA2

DDR2_CK_N

DDR2_CK_P

100R

R5

DDR2_nRAS

DDR2_nWE

DDR2_nCAS

DDR2_nCS

DDR2_ODT

DDR2_CKE

DDR2_UDM DDR2_LDM

DDR2_UDQS_P DDR2_UDQS_N

DDR2_LDQS_N

DDR2_LDQS_P

DDR2_BA0 DDR2_BA1 DDR2_BA2

DDR2_CK_N DDR2_CK_P

+1.8V

VddQ

VssQ

+1.8V

VssQ

VddQ

+1.8V VddQ

VssQ

Vref

See Technical DDR2 Note for Best Routing

0.1uFC80.1uFC90.1uF

C10

0.1uF

C11

0.1uF

C12

0.1uF

C14

0.1uF

C15

0.1uF

C16

0.1uF

C17

0.1uF

C18

0.1uF

C19

0.1uF

C20

0.1uF

C21

0.1uF

C13

0R

R6

0R

R7

0R

R10

Vref

0.1uF

C24

0.1uF

C25

0.1uF

C26

0.1uF

C27

0.1uF

C28

0.1uF

C29

0.1uF

C30

0.1uF

C31

0.1uF

C23

0.1uF

C32

+1.8V

TP18 TP19

TP17

TP4

TP13

TP12

TP5 TP6

TP10

TP11

TP15 TP16

TP14

TP21 TP22

TP20

D

S

DDR2

E

D

S

D

S

D

T

D

DDR2

M

D

_P

D

_N

D

_N

D

_P

DDR2_BA0

D

_N

D

100

R5

TP18

TP19

TP17

TP5

TP6

0

11

TP15

TP16

TP22

TP20

C

E2

A10

2

A1

3

M7

0

8

A3

N2

A5

N3

A6

N7

N8

A7

A9

3

A11

P7

A8

8

A

2

TP4

i

DDR Address

4

1

5

9

DQ9

C2

DQ8

C8

2

1

3

0

D7

3

9

DQ6

1

DQ7

9

DQ1

G2

DQ0

G8

DQ4

1

DQ3

3

DQ2

H7

DQ5

9

TP13

i

DDR Data

i

DDR CTRL

1k

R8

1k

R9

0R

R13

DDR_GND

0R

R12

DDR_GND

DDR_GND DDR_GND DDR_GND

DDR_GND

0.1uF

C97

0.1uF

C22

DQ0 DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7 DQ8 DQ9 DQ10 DQ11 DQ12 DQ13 DQ14 DQ15

A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12

TP23

MIC69101-1.8YML-TR

1A

FLG

1

NC

2

GND

3

NC4NC

5

EN

6

VIN

7

NC

8

VOUT

9

SNS

10

PAD

11

U2

2.2uF

C5

+3.3V +1.8V

4.7uF

C6

100k

R3

0.01uF

C7

0.1μF

C35

+1.8V

0.01uF

C36

0.1μF

C60

+1.8V

0.01uF

C61

0.1μF

C62

+1.8V

PIC32MZ2064DAx288-I/4J

DDRDQ9

C3

DDRDM1

A3

DDRUDQS

B2

DDRDQ14

B3

DDRDQ8

C1

DDRDQ15

C2

DDRUDQS

A2

DDRDQ13

D1

DDRDQ10

D2

DDRLDQS

E2

DDRDM0

G3

DDRDQ12

E3

DDRDQ0

F1

DDRDQ7

F2

DDRDQ11

F3

DDRDQ3

G1

DDRDQ4

G2

DDRLDQS

E1

DDRDQ2

H1

DDRDQ5

H2

DDRDQ6

H3

DDRVREF

J1

DDRDQ1

J3

DDRCK

K1

DDRCK

K2

DDRWEN

L1

DDRCKE

L2

DDRRAS

M1

DDRODT

N1

DDRBA1

M3

DDRA1

L3

DDRBA0

M2

DDRCS0

N2

DDRA2

N3

DDRA7

T2

DDRA10

P1

DDRCAS

P2

DDRA9

R3

DDRBA2

U4

DDRA0

R1

DDRA3

R2

DDRA12

T3

DDRA5

T1

DDRA4

P3

DDRA11

V2

DDRA6

U1

DDRA8

U2

DDRA13

U3

DDRA14

T4

DDRA15

V3

D

1

DDRUDQS

D

4

D

Q8

D

QS

D

QS

D

0

D

DDRLDQS

Q

D

Q2

D

DDRVREF

D

DDRC

DDRWEN

DDRC

DDRO

D

A1

D

A0

DDRCS

DDRA2

DDRA7

DDRA10

CAS

DDRA

DDRA3

DDRA

DDRA6

D

8

DDRA13

DDRA14

DDRA15

U1D

PIC32MZ2064DAx288-I/4J

VSS1V8

D3

VSS1V8

F6

VSS1V8

F7

VSS1V8

F8

VSS1V8

G6

VSS1V8

G7

VSS1V8

G8

VSS1V8

G9

VDDR1V8

H6

VDDR1V8

H7

VDDR1V8

H8

VSS1V8

H9

VDDR1V8

J6

VDDR1V8

J7

VDDR1V8

J8

VDDR1V8

K6

VDDR1V8

K7

VDDR1V8

K8

VSS1V8

K9

VDDR1V8

L6

VDDR1V8

L7

VDDR1V8

L8

VSS1V8

L9

VSS1V8

M6

VSS1V8

M7

VSS1V8

M8

VSS1V8

M9

VSS1V8

N6

VSS1V8

N7

VSS1V8

N8

VSS1V8

N9

VSS1V8

R4

VSS1V

V

1V8

V

1V8

V

1V8

VSS1V

V

1V8

V

1V8

V

1V8

V

1V8

V

1V8

V

1V8

VSS1V8V

1V8

V

1V8

V

1V8

VSS1V

VSS1V8

J9

VDDCORE

D14

VDDCORE

D7

VDDCORE

R11

VDDCORE

V4

U1E

DDR_GND

DDR_GND DDR_GND

FIGURE A-3: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (3 OF 4)

PIC32MZ DA Family Starter Kit User’s Guide

DR2_CK_P DR2_CK

TP1

TP

R

TP21

DR2_LDM

_UD

DR2_LDQS DR2_LDQS

DR2_UDQS DR2_UDQS

DR2_OD

DR2_nRA

_nW

DR2_CKE

DR2_nC DR2_nCA

DR2_BA1

DR2_BA2

DQ1 DQ1 DQ1 DQ1 DQ1 DQ1

DDR DDRRAS

DRB DRB DRB

DRDM DRDM

DRUD

DRLD

8 8 8 8 8 8 8 8 8

8 8 8 8 8 8 8 8 8 8

DT

0

2

K K

KE

N N

M

A

M

A4

P P P M

R

12

H H H F F

D D D B B

0

DR

1

DRA4

5

DRA

9

11

DR

12

DRDQ0 DRDQ1 DRD DRDQ3 DRDQ4 DRDQ5 DRDQ6 DRDQ7 DRD DRDQ9 DRDQ10 DRDQ11 DRDQ12 DRDQ13 DRDQ1 DRDQ15

DDR DDR DDR DDR DDR DDR DDR DDR DDR DDR DDR DDR

Schematics

Drawn By:

Serban Morea

Engineer:

Purnachander M

0.01uF

C47

0.1μF

C37

+3.3V

0.01uF

C48

0.1μF

C38

+3.3V

0.01uF

C49

0.1μF

C39

+3.3V

0.01uF

C50

0.1μF

C40

+3.3V

0.01uF

C51

0.1μF

C41

+3.3V

0.01uF

C52

0.1μF

C42

+3.3V

0.01uF

16V

C53

0.1μF

C43

+3.3V

0.01uF

C54

0.1μF

C44

+3.3V

0.01uF

C55

0.1μF

C45

+3.3V

0.01uF

C56

0.1μF

C46

+3.3V

0.01uF

C34

0.01uF

C67

0.1μF

C57

+3.3V

0.01uF

C69

0.1μF

C59

+3.3V

0.1μF

C33

+3.3V

TP24

TP25

+3.3V

GREEN

LD2

470R

R11

BLM15HB121SN1D

L1

PIC32MZ2064DAx288-I/4J

Vss

A5

Vss

B5

Vss

C7

VDDIO

E15

VDDIO

C16

Vss

D10

Vss

D11

Vss

D12

Vss

D13

VDDIO

D15

VDDIO

D16

Vss

F9

Vss

F10

VDDIO

F11

AVss

F12

AVdd

F13

VDDIO

F15

VBAT

F16

Vss

G10

VDDIO

G11

AVss

G12

AVdd

G13

Vss

H10

VDDIO

H11

VDDIO

H12

VDDIO

H13

VDDIO

H15

VDDIO

J10

Vss

J11

Vss

J12

Vss

J13

VDDIO

J15

VDDIO

K10

Vss

K11

Vss

K12

Vss

K13

Vss

K15

Vss

V

O

V

Vss

V

O

Vss

V

O

AVssAVdd

V

VBA

Vss

V

O

AV

AVdd

Vss

V

O

V

O

V

O

V

O

V

O

Vss

V

O

V

O

Vss

L10

VDDIO

L11

VDDIO

L12

Vss

L13

Vss

L15

Vss

M10

Vss

M11

VDDIO

M12

VDDIO

M13

VDDIO

M15

Vss

N10

Vss

N11

VDDIO

N12

VDDIO

N13

Vss

R7

Vss

R8

VDDIO

R9

VDDIO

R10

VDDIO

R12

VDDIO

R13

VDDIO

R14

VDDIO

G15

U1F

FIGURE A-4: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (4 OF 4)

DDIO DDIO DDI DDI DDI DDIO DDI

DDI DDI DDI DDI DDI DDI DDI

T

ss

 2017 Microchip Technology Inc. DS70005311A-page 31

PIC32MZ DA 169pin CPU DC

Project Title

Designed with

Drawn By:

Serban Morea

Sheet Title

CLK - IO - CONN

Engineer:

Purnachander Mangu

Size

10626

PartNumber:

10k

R2

+3.3V

OSCI/SCKI/RC12

SOSCI/RC13

OSCO/CLKO/RC15

EBID1/AN39/PMD1/RE1

+3.3V +3.3V

Only Oscillator or Crystal Configuration

should be populated.

Please check PCB/BOM to determine

which configuration is populated

OSCI/SCKI/RC12

SOSCI/RC13

OSCO/CLKO/RC15

DNP

TC25L5I32K7680

EN

1

GND2OUT

3

VDD

4

Y2

32.768 kHz

1V8_PWRGD

1.5k

R14

+3.3V

2.2k

R15

+3.3V+3.3V

+3.3V

DF40HC(3.0)-100DS-0.4V(58)

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

1

234

5

678

9

0

13

1516

1

18

19

20

232526

2

2829303132333435363738

0

4344546

47

84950

515253545556

575859

60616263646566

6

68

6970

7172

7374

7576

7778

79

80

81 82

83 84

85 86

87 88

89 90

91 92

93 94

95 96

97 98

99 100

J1

TMS/SDCD/RA0

SQICS1/CS/RD5

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

SDDATA0/SQID0/RG13

SDDATA1/SQID1/RG12

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

USB_N

USB_P

VBUS

USBID

SOSCO/RPC14/T1CK/RC14

TCK/AN24/RA1

AN22/RPD14/RD14

AN29/SCK3/RB14

AN35/RH3

EBIRDY2/AN37/RH11

EBIA1/AN38/PMA1/PSPA1/RK1

EBIA3/AN11/PMA3/RK2

SCL2/RA2

EBIRDY1/SDA2/RA3

RPA14/SCL1/RA14 RPA15/SDA1/RA15

EBID3/RPE3/PMD3/RE3

SCK4/RD10

EBID2/PMD2/RE2

RTCC/RPD0/RD0

MCLR

RPF8/SCL3/RF8

EBIA5/AN7/PMA5/RA5

VREF-/CVREF-/AN27/RA9

VREF+/CVREF+/AN28/RA10

PGED1/AN0/RPB0/CTED2/RB0 PGEC1/AN9/RPB1/CTED1/RB1

AN1/CTCMP/C2INB/RPB2/RB2 AN8/RPB3/RB3 AN2/C1INB/RB4

RPB5/RB5 PGEC2/RB6 PGED2/RB7 EBID10/AN4/RPB8/PMD10/RB8 EBIA7/LVDIN/RPB9/PMA7/RB9 CVREFOUT/AN5/RPB10/RB10

AN49/RB11

AN6/RB12 AN48/CTPLS/RB13

AN3/C2INA/RPB15/OCFB/RB15

EBID5/AN12/RPC1/PMD5/RC1

EBID12/AN10/RPC2/PMD12/RC2

EBIWE/AN34/RPC3/PMWR/RC3

EBIOE/AN19/RPC4/PMRD/RC4

SCK1/RD1

AN33/SCK6/RD15

EBID0/PMD0/RE0

EBID4/AN18/PMD4/RE4

EBIA6/RPE5/PMA6/RE5

EBID6/AN16/PMD6/RE6

EBID7/AN15/PMD7/RE7

AN25/RPE8/RE8

AN26/RPE9/RE9

RPF2/SDA3/RF2

TDO/AN31/RPF12/RF12

TDI/AN17/SCK5/RF13

AN14/C1IND/SCK2/RG6 AN13/C1INC/RPG7/SDA4/RG7

AN30/C2IND/RPG8/SCL4/RG8

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

AN21/RG15

AN20/RH4

EBIA4/AN36/PMA4/RH7

INT0/RH14

EBIRDY3/AN32/RJ2

EBIA0/PMA0/RJ15

EBIA6/RPE5/PMA6/RE5

INT0/RH14

SCK1/RD1

EBID4/AN18/PMD4/RE4

RPF2/SDA3/RF2

EBID0/PMD0/RE0

AN21/RG15

AN20/RH4

AN14/C1IND/SCK2/RG6

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

TDI/AN17/SCK5/RF13

AN13/C1INC/RPG7/SDA4/RG7

AN30/C2IND/RPG8/SCL4/RG8

AN25/RPE8/RE8

EBID6/AN16/PMD6/RE6

AN26/RPE9/RE9

TDO/AN31/RPF12/RF12

EBID7/AN15/PMD7/RE7

EBID5/AN12/RPC1/PMD5/RC1

EBIWE/AN34/RPC3/PMWR/RC3

EBIOE/AN19/RPC4/PMRD/RC4EBID12/AN10/RPC2/PMD12/RC2

PGEC2/RB6

PGEC1/AN9/RPB1/CTED1/RB1

AN48/CTPLS/RB13

VREF+/CVREF+/AN28/RA10

AN3/C2INA/RPB15/OCFB/RB15 EBID10/AN4/RPB8/PMD10/RB8

EBIA7/LVDIN/RPB9/PMA7/RB9

AN8/RPB3/RB3

VREF-/CVREF-/AN27/RA9 AN2/C1INB/RB4

EBIA5/AN7/PMA5/RA5

AN6/RB12PGED2/RB7

PGED1/AN0/RPB0/CTED2/RB0

RPB5/RB5

CVREFOUT/AN5/RPB10/RB10

EBIA4/AN36/PMA4/RH7

AN33/SCK6/RD15

AN1/CTCMP/C2INB/RPB2/RB2

EBIRDY3/AN32/RJ2

EBIA0/PMA0/RJ15

EBIA7/LVDIN/RPB9/PMA7/RB9

OSCI/SCKI/RC12

SOSCI/RC13

OSCO/CLKO/RC15

EBIO

E/AN19/RPC4

i Crystal

NC

A1

RPF2/SDA3/RF2

A3

EBID1/AN39/PMD1/RE1

A4

AN21/RG15

A5

TDI/AN17/SCK5/RF13

A6

EBIWE/AN34/RPC3/PMWR/RC3

A7

EBID12/AN10/RPC2/PMD12/RC2

A8

EBID10/AN4/RPB8/PMD10/RB8

A9

AN8/RPB3/RB3

A10

EBIA5/AN7/PMA5/RA5

A11

AN2/C1INB/RB4

A12

AN1/C2INB/RB2

A13

EBID4/AN18/PMD4/RE4

B3

AN30/C2IND/RPG8/SCL4/RG8

B5

EBID5/AN12/RPC1/PMD5/RC1

B7

EBIOE/AN19/RPC4/PMRD/RC4

B8

PGEC1/AN9/RPB1/CTED1/RB1

B9

AN3/C2INA/RPB15/OCFB/RB15

B10

VREF-/CVREF-/AN27/RA9

B11

EBIA7/AN47/LVDIN/RPB9/PMA7/RB9

B12

AN6/RB12

B13

SCK1/RD1

G1

MCLR

K1

INT0/RH14

C3

EBID0/PMD0/RE0

C4

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

C5

TDO/AN31/RPF12/RF12

C6

EBID7/AN15/PMPD7/RE7

C7

VREF+/CVREF+/AN28/RA10

C10

CVREFOUT/AN5/RPB10/RB10

C11

PGED1/AN0/RPB0/CTED2/RB0

C12

SOSCI/RPC13/RC13

C13

AN20/RH4

D4

AN13/C1INC/RPG7/SDA4/RG7

D5

AN26/RPE9/RE9

D6

PGEC2/RPB6/RB6

D7

AN45/RPB5/RB5

D11

PGED2/C1INA/AN46/RPB7/RB7

D12

SOSCO/RPC14/T1CK/RC14

D13

AN14/C1IND/SCK2/RG6

E5

AN25/RPE8/RE8

E6

AN49/RB11

E7

AN22/RPD14/RD14

E9

AN29/SCK3/RB14

E10

TCK/AN24/RA1

E11

OSC1/CLKI/RC12

E12

OSC2/CLKO/RC15

E13

EBIA6/RPE5/PMA6/RE5

F3

EBID6/AN16/PMD6/RE6

F6

AN48/CTPLS/RB13

F7

EBIRDY3/AN32/RJ2

F10

AN33/SCK6/RD15

F11

SCK4/RD10

H2

RTCC/RPD0/RD0

H3

EBIA3/AN11/PMA3/RK2

H11

EBIA0/PMA0/RJ15

H13

RPF8/SCL3/RF8

J3

EBIA1/AN38/PMA1/RK1

J11

EBIA4/AN36/PMA4/RH7

J12

AN35/RH3

J13

EBIRDY2/AN37/RH11

K13

SCL2/RA2

L12

EBID3/RPE3/PMD3/RE3

M3

RPA14/SCL1/RA14

M11

EBID2/PMD2/RE2

N3

RPA15/SDA1/RA15

N11

EBIRDY1/SDA2/RA3

N12

NC

N13

U1A

PIC32MZ2064DAB169_Rev2

ETXD3/RH1

24MHz

Y3

1M

R1

8pF

50V

C3

8pF

50V

C4

Gnd

2

Vdd4nc

1

Out

3

Gnd

VddncOut

24MHz

Y1

0.1uF

C1

0.1uF

C2

PIC32MZ DA Family Starter Kit User’s Guide

FIGURE A-5: PIC32MZ2064DAX169 DAUGHTER CARD SCHEMATICS (1 OF 3)

DS70005311A-page 32  2017 Microchip Technology Inc.

1

7

394

1 4

4

7

 2017 Microchip Technology Inc. DS70005311A-page 33

ETXCLK/RPD7

ERXCLK/RJ11

ECOL/RH10

ERXERR/RPF3

ECRS/RH12

EMDIO/RJ1

EMDC/RPD11

ERXDV/RH13

ETXERR/RJ0

ETXEN/RPD6

ETXD0/RJ8

ETXD1/RJ9

ETXD2/RH0

ETXD3/RH1

ERXD0/RH8

ERXD1/RH5

ERXD2/RH6

ERXD3/RH9

+3.3V

VSYNC/EBISC0/RJ4

HSYNC/EBICS1/RJ5

GCLK/CLKIN/EBICS2/RJ6

GEN/DEN/EBICS3/RJ7

GD0/R0/EBID13/RJ13

GD1/R1/EBID14/RA4

GD2/R2/EBID15/RD9

GD3/R3/EBIA8/RG0

GD4/R4/EBIA9/RG1

GD5/R5/EBIA10/RF1

GD6/R6/EBIA11/RF0

GD7/R7/EBIA12/RD12

GD8/G0/EBID11/RJ14

GD9/G1/EBIBS0/RJ12

GD10/G2/EBIA14/RD2

GD11/G3/EBIA15/RD3

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

GD15/G7/EBIA20/RK6

GD16/B0/EBID8/RF5

GD17/B1/EBID9/RF4

GD18/B2/EBIBS1/RJ10

GD19/B3/EBIA21/RK7

GD20/B4/EBIA22/RJ3

GD21/B5/EBIA23/RH15

GD22/B6/EBIA13/RD13

GD23/B7/EBIA16/RK0

+3.3V

USB_P

USB_N

USBID

+5V+5V

7

0

3

2

1

3

0

6

8

9

0

1

8

5

6

9

P

N

D

i ETH

i SQI/SD

i USB

TMS/SDCD/RA0

GCLK/CLKIN/EBICS2/RJ6

DF40HC(3.0)-100DS-0.4V(58)

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

1

2

3

5

6

7

8

9

10

11

1

13

15

16

17

18

19

20

1

2

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

43

5

46

7

48

9

50

51

5

53

5

55

56

7

58

9

60

61

6

63

6

65

66

67

68

69

70

1

72

3

74

75

76

77

78

9

80

81 82

83 84

85 86

87 88

89 90

91 92

93 94

95 96

97 98

99 100

J2

SQICS1/CS/RD5

SDCK/SQICLK/RA6

SDDATA3/SQID3/RA7

SDDATA1/SQID1/RG12

SDDATA0/SQID0/RG13

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

VBUS

SQICS1/CS/RD5

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

SDDATA0/SQID0/RG13

SDDATA1/SQID1/RG12

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

TMS/SDCD/RA0

ECOL/RH10

ERXERR/RPF3

ERXD2/RH6

ERXD1/RH5

ECRS/RH12

ERXDV/RH13

ERXD0/RH8

ERXD3/RH9

ERXCLK/RJ11

ETXD2/RH0

EMDIO/RJ1

ETXD0/RJ8

EMDC/RPD11

ETXERR/RJ0

ETXEN/RPD6 GD15/G7/EBIA20/RK6

GD16/B0/EBID8/RF5

GD17/B1/EBID9/RF4

GD18/B2/EBIBS1/RJ10

GD19/B3/EBIA21/RK7

GD20/B4/EBIA22/RJ3

GD21/B5/EBIA23/RH15

GD22/B6/EBIA13/RD13

GD23/B7/EBIA16/RK0

GD7/R7/EBIA12/RD12

GD8/G0/EBID11/RJ14

GD9/G1/EBIBS0/RJ12

GD10/G2/EBIA14/RD2

GD11/G3/EBIA15/RD3

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

GEN/DEN/EBICS3/RJ7

GD0/R0/EBID13/RJ13

GD1/R1/EBID14/RA4

GD2/R2/EBID15/RD9

GD3/R3/EBIA8/RG0

GD4/R4/EBIA9/RG1

GD5/R5/EBIA10/RF1

GD6/R6/EBIA11/RF0

VSYNC/EBISC0/RJ4

HSYNC/EBICS1/RJ5

USB_N

USB_P

VBUS

USBID

ETXD1/RJ9

ETXCLK/RPD7

SOSCO/RPC14/T1CK/RC14

TCK/AN24/RA1

AN22/RPD14/RD14

AN29/SCK3/RB14

AN35/RH3

EBIRDY2/AN37/RH11

EBIA1/AN38/PMA1/PSPA1/RK1

EBIA3/AN11/PMA3/RK2

SCL2/RA2

EBIRDY1/SDA2/RA3

RPA14/SCL1/RA14

RPA15/SDA1/RA15

MCLR

EBID3/RPE3/PMD3/RE3

SCK4/RD10

EBID2/PMD2/RE2

RTCC/RPD0/RD0

RPF8/SCL3/RF8

SDWP/RH2

1V8_PWRGD

SDWP/RH2

AN49/RB11

VSYNC/

SC0/RJ4

J5

GCLK/C

J6

GEN/

7

GD0/R0/

3

GD1/R1/

4

GD2/R2/

9

GD3/R3/

G0

GD4/R4/

G1

GD5/R5/

1

GD6/R6/

0

GD7/R7/

2

GD8/G0/

4

GD9/G1/

2

G

2

G

3

G

3

GD13/G5/

4

G

/G6/

5

G

6

GD16/B0/

5

G

4

GD18/B2/

0

GD19/B3/

7

GD20/B4/

J3

G

5

G

0

iLCD

1k

R8

1k

R9

+1.8V

DDR_GND

VBUS

A2

D-

B1

VBUS3V3

B2

D+

C1

TRD3/SDDATA3/SQID3/RA7

D1

TRD2/SDDATA2/SQID2/RG14

E1

SDCMD/SQICS0/RPD4/RD4

F1

TMS/SDCD/RA0

D2

USBID

D3

TRDO/SSDATA0/SQID0/RG13

E2

TRD1/SDDATA1/SQID1/RG12

E3

TRCLK/SDCK/SQICLK/RA6

E4

SQICS1/RPD5/RD5

F2

DDRVREF

F4

SDWP/EBIRP/RH2

H12

EMDIO/RJ1

K10

ETXEN/RPD6/RD6

K11

ERXERR/RPF3/RF3

M1

EXTERR/RJ0

L10

ERXD1/RH5

M4

ERXDV/ECRSDV/RH13

M5

ECOL/RH10

M6

ETXD3/RH1

M7

ETXD2/RH0

M8

ETXD1/RJ9

M9

ETXCLK/RD7/RD7

M10

ERXD2/RH6

N4

ECRS/RH12

N5

ERXD3/RH9

N6

ERXD0/RH8

N7

ERXCLK/EREFCLK/RJ11

N8

ETXD0/RJ8

N9

EMDC/RPD11/RD11

N10

U1B

PIC32MZ2064DAB169_Rev2

GD2/EBIS15/RPD9/PMPD15/RD9

H1

GD7/EBIA12/RPD12/PMPA12/RD12

J1

GD6/EBIA11/RPF0/PMA11/RF0

L1

GD20/EBIA22/RJ3

E8

GD18/EBIBS1/RJ10

F8

GD9/EBIBS0/RJ12

F9

HSYNC/EBICS1/RJ5

F12

VSYNC/EBICS0/RJ4

F13

GD10/EBIA14/RPD2/PMA14/PMCS1/RD2

G2

GD11/EBIA15/RPD3/PMA14/PMCS2/RD3

G3

GD8/EBID11/PMPD11/RJ14

G10

GCLK/EBICS2/RJ6

G11

GD0/EBID13/PMPD13/RJ13

G12

GEN/EBICS3/RJ7

G13

GD13/EBIA18/RK4

H10

GD22/EBIA13/PMPA13/RD13

J2

GD14/EBIA19/RK5

J10

GD16/EBID8/RPF5/SCL5/PMD8/RF5

K2

GD5/EBIA10/RPF1/PMA10/RF1

K3

GD23/EBIA16/RK0

K12

GD21/EBIA23/RH15

L2

GD17/EBID9/RPF4/SDA5/PMD9/RF4

L3

GD1/EBID14/PMD14/RA4

L11

GD12/EBIA17/RK3

L13

GD4/EBIA9/RPG1/PMA9/RG1

M2

GD19/EBIA21/RK7

M12

GD15/EBIA29/RK6

M13

GD3/EBIA8/RPG0/PMA9/RG0

N2

U1C

PIC32MZ2064DAB169_Rev2

SDWP/RH2

ETXD3/RH1

+1.8V

0R

R17

FIGURE A-6: PIC32MZ2064DAX169 DAUGHTER CARD SCHEMATICS (2 OF 3)

2

4

ETXCLK/RPD

ERXCLK/RJ11

ECOL/RH1

ERXERR/RPF

ECRS/RH1

EMDIO/RJ

EMDC/RPD1

ERXDV/RH1

ETXERR/RJ

ETXEN/RPD

ETXD0/RJ

ETXD1/RJ

ETXD2/RH

ETXD3/RH

ERXD0/RH

ERXD1/RH

ERXD2/RH

ERXD3/RH

USB_

USBI

2

234

4

5

7

2

4

2

4

EBI

HSYNC/EBICS1/R

LKIN/EBICS2/R

DEN/EBICS3/RJ

EBID13/RJ1

EBID14/RA

EBID15/RD

EBIA8/R

EBIA9/R

EBIA10/RF

EBIA11/RF

EBIA12/RD1

EBID11/RJ1

EBIBS0/RJ1

D10/G2/EBIA14/RD

D11/G3/EBIA15/RD

D12/G4/EBIA17/RK

EBIA18/RK

D14

EBIA19/RK

D15/G7/EBIA20/RK

EBID8/RF

D17/B1/EBID9/RF

EBIBS1/RJ1

EBIA21/RK

EBIA22/R

D21/B5/EBIA23/RH1

D22/B6/EBIA13/RD13

D23/B7/EBIA16/RK

Schematics

PIC32MZ DA Family Starter Kit User’s Guide

0.1uFC80.1uFC90.1uF

C10

0.1uF

C11

0.1uF

C12

0.1uF

C13

DDR_GND

0R

R12

DDR_GND

+1.8V

0.01uF

C47

0.01uF

C48

+3.3V

0.01uF

C49

+3.3V

0.01uF

C50

+3.3V

0.01uF

C51

+3.3V

0.01uF

C52

+3.3V

0.01uF

C53

+3.3V

0.01uF

C54

+3.3V

0.01uF

C55

0.01uF

C56

+3.3V

0.01uF

C67

+3.3V

0.01uF

C34

+3.3V

TP24

TP25

+3.3V

GREEN

LD2

+1.8V

DDR_GND

2.2uF

C6

VSS1V8

G4

VSS1V8

H4

VDDR1V8

H5

VDDR1V8

H6

VSS1V8

J4

VDDR1V8

J5

VDDR1V8

J6

VSS1V8

K4

VDDR1V8

K5

VDDR1V8

K6

VSS1V8

L4

VSS1V8

L5

VDD1V8

C9

VDD1V8

B4

VDD1V8

L8

VDD1V8

N1

U1D

PIC32MZ2064DAB169_Rev2

VDDB6VSS

C2

AVSS

C8

AVSS

D8

AVDD

D9

VBAT

D10

VSS

F5

VSS

G5

VSS

G6

VSS

G7

VSS

G8

VDD

G9

VSS

H7

VSS

H8

VDD

H9

VSS

J7

VSS

J8

VDD

J9

VSS

K7

VSS

K8

VDD

K9

VDD

L6

VDD

L7

VDD

L9

U1E

PIC32MZ2064DAB169_Rev2

DNP

+1.8V

+3.3V

VDD1V8

VDD1V8 VDD1V8

0.01uF

C58

0.01uF

C59

VDD1V8VDD1V8

VDDR1V8

100 Ohm

L2

100 Ohm

L3

100 Ohm

L4

100 Ohm

L1

+1.8V

TP1

DDR_GND

TP2

0.1uF

C33

0.1uF

C57

0.1uF

C38

0.1uF

C39

0.1uF

C40

0.1uF

C41

0.1uF

C42

0.1uF

C43

0.1uF

C44

0.1uF

C46

0.1uF

C37

0.1uF

C45

0.1uF

C61

0.1uF

C60

470R

R11

FIGURE A-7: PIC32MZ2064DAX169 DAUGHTER CARD SCHEMATICS (3 OF 3)

DS70005311A-page 34  2017 Microchip Technology Inc.

PIC32MZ DA - Base Board

Project Title

Drawn By:

Serban Morea

Engineer:

Purnachander Mangu

10491

PartNumber:

POWER IN (+5V, 1A min)

UART_USB_N UART_USB_P

+3.3V_UART

USB to UART/I2C Bridge

VDD

1

GP0

2

GP1

3

RST

4

UART RX

5

UART TX

6

GP27GP3

8

SDA

9

SCL

10

VUSB

11

D-

12

D+

13

VSS

14

VDD

G

RS

UA

GP2GP3

SDA

SCL

VUSB

VSS

MCP2221

U1

4.7k

R2

TYPE MICRO A/B

DEVICE/OTG PORT

HOST TYPE - TYPE A

UART_USB_N

UART_USB_P

VBUS

1

GND

4

D-

2

D+

3

VBUS

GND

D

0

USB-A Female

J7

USB_N USB_P USBID

100k

R10

VIN

1

VIN

2

SHDN

3

GND

4

PWRGD

5

CDELAY

6

SENSE

7

VOUT

8

MCP1727/3.3V

U2

0.1uF

C6

GREEN

D4

+3.3V

USB_N USB_P

USBID

USB_N USB_P

RPF2/SDA3/RF2

RPF8/SCL3/RF8EBIA2/AN23/C2INC/RPG9/PMA2/RG9

PGED1/AN0/RPB0/CTED2/RB0

MH1

330R

R6

2.2uF

C5

0.1uF

C1

0.1uF

C2

+5V_CPU

GND

1

VIN

3

VOUT

2

MCP1700/3.3V

U6

1uF

C4

VBUS_OTG

NC7SB3157P6X

VCC

5

B0

3

B1

1

GND

2

A

4

SEL

6

U9

10k

R9

+3.3V

+5V_CPU

0.1uF

C15

+5V_CPU

0.1uF

C16

+5V_CPU

PIC32_VBUS

EBID6/AN16/PMD6/RE6

+5V_EXT

MBR230LSFT1G 430mV @ 2A

D3

2.2uF 10V

C3

EN

4

IN

5

GND

2

OC

3

OUT

1

N

IN

G

OC

OUT

U11

TPS2041

10k

R83

10k

R67

VBUS_OTG

MBR230LSFT1G 430mV @ 2A

D13

OTG Host PWR Jumper

1 2

HDR-2.54 Male 1x2

J8

TP2

+3.3V

TP3

GND

TP1

+5V

10uF

C7

100uF

C9

100uF

C10

MIC69101-1.8YML-TR

1A

FLG

1

NC

2

GND

3

NC4NC

5

EN

6

VIN

7

NC

8

VOUT

9

SNS

10

PAD

11

U4

2.2uF

C17

+3.3V +1.8V

4.7uF

C30

100k

R3

ID

4

VBUS

1

GND

5

D-

2

D+

3

0

USB2.0 MICRO-B FEMALE

J4

ID

4

VBUS

1

GND

5

D-

2

D+

3

0

USB2.0 MICRO-B FEMALE

J5

ID

4

VBUS

1

GND

5

D-

2

D+

3

0

USB2.0 MICRO-B FEMALE

J6

 2017 Microchip Technology Inc. DS70005311A-page 35

FIGURE A-8:

PIC32MZ DA SK BASE BOARD SCHEMATICS (1 OF 5)

-

D

P0 P1

-

T

RT RX

ND

E

RT TX

Schematics

DS70005311A-page 36  2017 Microchip Technology Inc.

2 of 5

PIC32MZ DA - Base Board

3/29/2017 9:47:11 AM

Project Title

Sch #: Date:

Revision: Sheet

Designed with

Drawn By:

Serban Morea

Sheet Title

SQI/ETH/SD/LED/SW/JTAG/ICSP

Engineer:

Purnachander Mangu

03-10491

2.0

Size

B

10491

PartNumber:

Altium.com

CLK_IN

PHY_RST

LED1

LED2 SW1

SW2

SW3LED3

USER LED'S USER'S SWITCH

Phy Daughter Board HDR

+3.3V

SDCD

TMS

SDCD/RA0 TMS/RA0

+3.3V

CE#

1

SO/SIO1

2

SIO2

3

VSS

4

SI/SIO0

5

SCK

6

SIO3

7

VDD

8

T-PAD

9

SST26VF032BT-104I/MF

U5

SQI Memory

SD CD/JTAG TMS Selection SLIDER

ICSP HDR

SQICS1/CS/RD5

SDDATA1/SQID1/RG12

SDDATA0/SQID0/RG13

SDDATA2/SQID2/RG14

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

TMS/SDCD/RA0

EBIA0/PMA0/RJ15

ERXD1/RH5

ERXD0/RH8

ERXERR/RPF3

EMDC/RPD11

EMDIO/RJ1

ETXEN/RPD6

ETXD0/RJ8

ETXD1/RJ9

ERXCLK/RJ11

PGEC2/RB6

PGED2/RB7

MCLR

+3.3V

C

N

PHY_

Phy Daugh

HDR

V

E

5

8

E

1

E

ETXEN/RPD6

E

J9

3.3V

i

PHY

+3.3V

1 2

3 4

5 6

7 8

9 10

111312

14

J11

DNP

TMS

JTAG_nRST

Lauterbach JTAG - DNP

33R

R70

TDI/AN17/SCK5/RF13

TDO/AN31/RPF12/RF12

TCK/AN24/RA1

MCLR

D11

+3.3V

AN49/RB11

C

N

1

i

PHY CLK

ERXDV/RH13

0.1uF

C11

0.1uF

C13

0.01uF

C12

GREEN

D7

YELLOW

D8

RED

D6

0R

R12

0R

R13

33R

R14

33R

R15

330R

R16

330R

R28

330R

R29

0R

R33

33R

R71

10k

R68

10k

R69

10k

R89

10k

R88

+3.3V

0R

R840RR87

0R

R11

DNP

1 2 3 4 5 6

J12

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

3026282927

25

J3011G21DNL

J9 2 HDR/MB

Gnd

2

Vdd4Stby

1

Out

3

Gnd

Vdd

Stby O

50.000MHz

Y1

1.5k

R22

1.5k

R23

1.5k

R24

1.5k

R25

1.5k

R26

1.5k

R27

S1

S2

S3

10k

R17

0.1uF

C14

10k

R18

10k

R19

10k

R20

10k

R21

SD CARD

+3.3V

SDCD

10k

R30

SDDATA0/SQID0/RG13

SDDATA1/SQID1/RG12

SDDATA2/SQID2/RG14

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

SDCMD/SQICS0/RD4

10k

uF

4

10k

18

10k

19

10k

R20

10k

SD CA

3.3V

SDCD

10k

30

S

/SQ

ID0/RG

13

S

/SQ

ID1/RG

1

S

/SQ

ID2/RG

1

S

/SQ

7

SDCK/SQ

ICLK/

SDCMD/SQ

CS0/RD4

i

SD/SQI

microSD™

SD

DAT2

1

CD/DAT3

2

CMD

3

VDD

4

CLK

5

VSS

6

DAT0

7

DAT1

8

GND

0

GND

0

GND

0

GND

0

POL

10

DET

9

J10

100uF

C32

FIGURE A-9:

PIC32MZ DA SK BASE BOARD SCHEMATICS (2 OF 5)

PIC32MZ DA Family Starter Kit User’s Guide

micro

C1

0.1

R

ETXD0/RJ8

ETXD1/R

3.3

ut

R

DDATA2

DDATA0

DDATA1

DDATA3

4

ID3/RA

I

RA6

2

ter Board

LK_I

ERXCLK/RJ1

LK_I

RXD1/RH

ERXD0/RH

RXERR/RPF3

EMDC/RPD1

EMDIO/RJ1

BIA0/PMA0/RJ15

RST

Schematics

PIC32MZ DA - Base Board

3/29/2017 9:47:11 AM

Project Title

Sch #: Date:

Designed with

Drawn By:

Serban Morea

Sheet Title

168 MEB2 Conn / CPU DB HDR

Engineer:

Purnachander Mangu

03-10491

Size

C

10491

PartNumber:

LCD_R0

LCD_R1

LCD_R2

LCD_R3

LCD_R4

LCD_R5

LCD_R6

LCD_R7

LCD_G4

LCD_G1

LCD_G0

LCD_G2

LCD_G3

LCD_G5

LCD_G6

LCD_G7

LCD_B0

LCD_B1

LCD_B4

LCD_B3

LCD_B2

LCD_B7

LCD_B6

LCD_B5

LCD_PCLK

LCD_DE

LCD_VSYNC

LCD_HSYNC

+5V_EXT

PGD2

PGC2

LED1

LED2

LED3

SW2

Debug

Graphics

SPI_SDSPI_SD

BUTTONS

LEDs

GD19/B3/EBIA21/RK7

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

GD15/G7/EBIA20/RK6

GD23/B7/EBIA16/RK0

GCLK

I/O1

SPI_MOSI

SPI_CE0_N

TXD0

I/O2

I/O3

I/O4

I/O5

RXD0

I/O9

I/O10

I/O11

I/O12

I/O13

I/O14

I/O15

SPI_CE1_N

I/O16

SPI_MISOSPI_SCLK

GEN/DEN/EBICS3/RJ7

VSYNC/EBISC0/RJ4

HSYNC/EBICS1/RJ5

GCLK/CLKIN/EBICS2/RJ6

GD7/R7/EBIA12/RD12

GD8/G0/EBID11/RJ14

GD9/G1/EBIBS0/RJ12

GD10/G2/EBIA14/RD2

GD11/G3/EBIA15/RD3

GD0/R0/EBID13/RJ13

GD1/R1/EBID14/RA4

GD2/R2/EBID15/RD9

GD3/R3/EBIA8/RG0

GD4/R4/EBIA9/RG1

GD5/R5/EBIA10/RF1

GD6/R6/EBIA11/RF0

GD16/B0/EBID8/RF5

GD17/B1/EBID9/RF4

GD18/B2/EBIBS1/RJ10

GD19/B3/EBIA21/RK7

GD20/B4/EBIA22/RJ3

GD21/B5/EBIA23/RH15

GD22/B6/EBIA13/RD13

GD23/B7/EBIA16/RK0

GD15/G7/EBIA20/RK6

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

0

1

2

4

5

6

7

0

G2

G5

7

0

4

2

7

6

5

K

GCLK/C

J6

2

GD9/G1/

S0/RJ12

3

GD0/R0/

3

4

9

GD3/R3/

G0

GD5/R5/

1

GD6/R6/

0

G

GD18/B2/EBIBS1/RJ10

G

GD20/B4/

J3

GD21/B5/EBIA23/RH15

5

GD22/B6/EBIA13/RD13

3

GD23/B7/

0

G

6

G

3

G

/G6/

5

LCD_RESET

0R

R78

0R

R79

0R

R80

0R

R81

+3.3V

0R

R82

+3.3V_EXT

4.7k

R85

+3.3V

4.7k

R86

+3.3V +3.3V

TMS/SDCD/RA0

SQICS1/CS/RD5

SDCMD/SQICS0/RD4

SDDATA2/SQID2/RG14

SDDATA0/SQID0/RG13

SDDATA1/SQID1/RG12

SDDATA3/SQID3/RA7

SDCK/SQICLK/RA6

USB_N

USB_P

USBID

SDWP/RH2

EBIA6/RPE5/PMA6/RE5

INT0/RH14

SCK1/RD1

EBID4/AN18/PMD4/RE4

RPF2/SDA3/RF2

EBID0/PMD0/RE0

AN21/RG15

AN20/RH4

AN14/C1IND/SCK2/RG6

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

TDI/AN17/SCK5/RF13

AN13/C1INC/RPG7/SDA4/RG7

AN30/C2IND/RPG8/SCL4/RG8

AN25/RPE8/RE8

EBID6/AN16/PMD6/RE6

AN26/RPE9/RE9

TDO/AN31/RPF12/RF12

EBID7/AN15/PMD7/RE7

EBID5/AN12/RPC1/PMD5/RC1

EBIWE/AN34/RPC3/PMWR/RC3

EBIOE/AN19/RPC4/PMRD/RC4EBID12/AN10/RPC2/PMD12/RC2

PGEC2/RB6

PGEC1/AN9/RPB1/CTED1/RB1

AN48/CTPLS/RB13

VREF+/CVREF+/AN28/RA10

AN3/C2INA/RPB15/OCFB/RB15 EBID10/AN4/RPB8/PMD10/RB8

EBIA7/LVDIN/RPB9/PMA7/RB9

AN8/RPB3/RB3

VREF-/CVREF-/AN27/RA9 AN2/C1INB/RB4

EBIA5/AN7/PMA5/RA5

AN6/RB12PGED2/RB7

PGED1/AN0/RPB0/CTED2/RB0

RPB5/RB5

CVREFOUT/AN5/RPB10/RB10

EBIA4/AN36/PMA4/RH7

AN33/SCK6/RD15

AN1/CTCMP/C2INB/RPB2/RB2

EBIRDY3/AN32/RJ2

EBIA0/PMA0/RJ15

INT0/RH14

EBID4/AN18/PMD4/RE4

RPF2/SDA3/RF2

EBID0/PMD0/RE0

AN21/RG15 AN20/RH4

AN14/C1IND/SCK2/RG6

EBIA2/AN23/C2INC/RPG9/PMA2/RG9

AN26/RPE9/RE9

EBID7/AN15/PMD7/RE7EBID5/AN12/RPC1/PMD5/RC1

EBIWE/AN34/RPC3/PMWR/RC3

EBIOE/AN19/RPC4/PMRD/RC4

PGEC2/RB6

PGEC1/AN9/RPB1/CTED1/RB1

AN48/CTPLS/RB13

EBID10/AN4/RPB8/PMD10/RB8

AN8/RPB3/RB3

EBIA7/LVDIN/RPB9/PMA7/RB9

AN2/C1INB/RB4

EBIA5/AN7/PMA5/RA5

AN6/RB12

AN13/C1INC/RPG7/SDA4/RG7

AN30/C2IND/RPG8/SCL4/RG8

AN25/RPE8/RE8

EBID6/AN16/PMD6/RE6

EBID12/AN10/RPC2/PMD12/RC2

AN3/C2INA/RPB15/OCFB/RB15

VREF-/CVREF-/AN27/RA9

PGED2/RB7

PGED1/AN0/RPB0/CTED2/RB0

I/O7

RPB5/RB5

CVREFOUT/AN5/RPB10/RB10

EBIA4/AN36/PMA4/RH7

AN33/SCK6/RD15

AN1/CTCMP/C2INB/RPB2/RB2

EBIRDY3/AN32/RJ2

EBIA0/PMA0/RJ15

VREF+/CVREF+/AN28/RA10

EBIA6/RPE5/PMA6/RE5

SCK1/RD1

EBID1/AN39/PMD1/RE1

DF40C-100DP-0.4V(51)

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

5

6

7

8

9

10

11

12

13

1516

17

8

19

20

21

22

23

24

2526

27

28

29

30

31

32

33

34

3536

7

38

39

40

41

42

43

45

46

8

49

50

51

52

53

54

5556

7

58

9

60

61

62

63

64

6566

67

68

69

70

4

7576

7778

79

80

81 82

83 84

85 86

87 88

89 90

91 92

93 94

95 96

97 98

99 100

J1

I/O6

DF40C-100DP-0.4V(51)

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

1

2

3

4

5

6

7

8

9

10

13

14

15

16

17

18

19

20

212

23

25

26

27

28

29

30

313

33

34

35

36

37

38

39

40

3

4

45

46

47

48

49

0

515

53

54

5556

7

58

9

60

61

62

63

6

65

66

67

68

69

7071

72

73

74

75767778

79

80

81 82

83 84

85 86

87 88

89 90

91 92

93 94

95 96

97 98

99 100

J2

GCLK/CLKIN/EBICS2/RJ6

GD15/G7/EBIA20/RK6

GD16/B0/EBID8/RF5

GD17/B1/EBID9/RF4

GD18/B2/EBIBS1/RJ10

GD19/B3/EBIA21/RK7

GD20/B4/EBIA22/RJ3

GD21/B5/EBIA23/RH15

GD22/B6/EBIA13/RD13

GD23/B7/EBIA16/RK0

GD7/R7/EBIA12/RD12

GD8/G0/EBID11/RJ14

GD9/G1/EBIBS0/RJ12

GD10/G2/EBIA14/RD2

GD11/G3/EBIA15/RD3

GD12/G4/EBIA17/RK3

GD13/G5/EBIA18/RK4

GD14/G6/EBIA19/RK5

GEN/DEN/EBICS3/RJ7

GD0/R0/EBID13/RJ13

GD1/R1/EBID14/RA4

GD2/R2/EBID15/RD9

GD3/R3/EBIA8/RG0

GD4/R4/EBIA9/RG1

GD5/R5/EBIA10/RF1

GD6/R6/EBIA11/RF0

VSYNC/EBISC0/RJ4

HSYNC/EBICS1/RJ5

SOSCO/RPC14/T1CK/RC14

TCK/AN24/RA1

AN22/RPD14/RD14

AN29/SCK3/RB14

AN35/RH3

EBIRDY2/AN37/RH11

EBIA1/AN38/PMA1/PSPA1/RK1

EBIA3/AN11/PMA3/RK2

SCL2/RA2

EBIRDY1/SDA2/RA3

RPA14/SCL1/RA14

RPA15/SDA1/RA15

MCLR

EBID3/RPE3/PMD3/RE3

SCK4/RD10

EBID2/PMD2/RE2

RTCC/RPD0/RD0

RPF8/SCL3/RF8AN49/RB11

AN49/RB11

EBID3/RPE3/PMD3/RE3

RPA14/SCL1/RA14

RPA15/SDA1/RA15

EBIRDY1/SDA2/RA3

SCL2/RA2

EBIA3/AN11/PMA3/RK2

RPF8/SCL3/RF8

EBIA1/AN38/PMA1/PSPA1/RK1

RTCC/RPD0/RD0

MCLR

SCK4/RD10

EBID2/PMD2/RE2

EBIRDY2/AN37/RH11

AN35/RH3

AN29/SCK3/RB14

AN22/RPD14/RD14

SOSCO/RPC14/T1CK/RC14

I/O8

SDWP/RH2

USB_N

USB_P

USBID

RPB5/RB5

ERXD1/RH5

ERXD0/RH8

ERXERR/RPF3

ECRS/RH12

EMDC/RPD11

EMDIO/RJ1

ETXD0/RJ8

ETXD1/RJ9

ERXCLK/RJ11

ECOL/RH10

ERXDV/RH13

ERXD3/RH9

ETXD2/RH0

ETXERR/RJ0

ETXD3/RH1

ETXCLK/RPD7

ERXD3/RH9

ETXD2/RH0

ETXD3/RH1

ETXERR/RJ0

ETXCLK/RPD7

+1.8V +3.3V

SW1

SW3

33R

R4

33R

R31

33R

R32

ETXEN/RPD6

i

Graphics

ERXD2/RH6

117 118

111 112

105 106

99 100

93 94

87 88

81 82

75 76

69 70

57 58

51 52

45 46

39 40

33 34

27 28

21 22

15 16

9 10

3 4

119 120

107 108

109 110

113 114

115 116

95 96

97 98

101 102

103 104

83 84

85 86

89 90

91 92

71 72

73 74

77 78

79 80

59 60

61 62

65 66

67 68

47 48

49 50

53 54

55 56

35 36

37 38

41 42

43 44

25 26

29 30

23 24

19 20

13 14

17 18

11 12

7 8

1 2

5 6

31 32

63 64

121 122

123 124

125 126

127 128

129 130

135 136

137 138

131 132

133 134

139 140

141 142

143 144

145

148

149 150

151 152

153 154

159 160

161 162

155 156

157 158

163 164

165 166

167 168

146

147

J3

FX10A-168P-SV1(71)

ECRS/RH12

+5V_CPU+5V_CPU

USB_168_N

USB_168_P

USB_

_N

USB_

i USB_168

PIC32_VBUS

+5V_EXT

+5V_EXT +5V_EXT

TC7W66FU,LF

OUT/IN1

2

GND

4

OUT/IN2

6

CONT1

7

VCC

8

IN/OUT1

1

IN/OUT2

5

CONT2

3

U3

AN33/SCK6/RD15

EBIOE/AN19/RPC4/PMRD/RC4

+3.3V

0.1uF

C8

EBIWE/AN34/RPC3/PMWR/RC3

RH0

RH1

RH2

0R

R1

FIGURE A-10:

 2017 Microchip Technology Inc. DS70005311A-page 37

3 4

1

3

474

5

71 72

737

PIC32MZ DA SK BASE BOARD SCHEMATICS (3 OF 5)

1

2

4

2

4

5

2

5

4

LCD_R

GD1/R1/EBID14/RA

LCD_R

GD2/R2/EBID15/RD

LCD_R

LCD_R3

GD4/R4/EBIA9/RG1

LCD_R

GD7/R7/EBIA12/RD1

LCD_R

GD8/G0/EBID11/RJ14

LCD_G

LCD_G1

GD10/G2/EBIA14/RD2

LCD_

GD11/G3/EBIA15/RD

LCD_G3

LKIN/EBICS2/R

LCD_PCL

EBID13/RJ1

EBIA8/R

EBIA10/RF

EBIA11/RF

EBIB

168_P

168

EBIA16/RK

EBIA22/R

D19/B3/EBIA21/RK7

D17/B1/EBID9/RF4

D16/B0/EBID8/RF5

D15/G7/EBIA20/RK

D14

EBIA19/RK

D13/G5/EBIA18/RK4

D12/G4/EBIA17/RK

LCD_B

LCD_B3

LCD_B

LCD_B1

LCD_B

LCD_G

LCD_G6

LCD_

LCD_G4

DS70005311A-page 38  2017 Microchip Technology Inc.

SERIAL EEPROM (25LC256)

CS1SO

2

WP

3

VSS

4

SI

5

SCK

6

HOLD

7

VCC

8

25LC256

U8

1 2 3 4 5 6

J18

PGC_PKOB

PGD_PKOB

+3.3V_PKOB

ICSP_MCLR_VPP_PICKIT3

UTIL_SDI

UTIL_SDO

UTIL_SCK

+3.3V_PKOB

UTIL_CS

UTIL_WP

(Local Vdd/Vss bypass/decoupling.)

+3.3V_PKOB

SCK

SDI

SDO

VDD_SENSE

VPP_GND

VPP_ON

VPP_SENSE

+3.3V_PKOB

1

3

2

MMBT3904

Q3

1

2

3

MMBT3906

Q2

1

3

2

MMBT3904

Q4

+3.3V_PKOB

ASSEMBLY_ID_0

ASSEMBLY_ID_1

ICSP_MCLR_VPP_PICKIT3

POWER_GOOD_PICKIT3

SCK

SDI

SDO

USB_D-

USB_D+

UTIL_SCK

UTIL_SDI

UTIL_SDO

VDD_SENSE

VPP_GND

VPP_ON

VPP_SENSE

VREF_2.5V

PGC_PKOB

PGD_PKOB

VBUS_DEVICE_SWITCHED_SENSE

TARGET_POWER_ENABLE

UTIL_CS

UTIL_WP

12MHz

Y2

DNP

R61

DNP

R59

0.1uF

C27

0.1uF

C19

0.1uF

C20

0.1uF

C21

0.1uF

C22

0.1uF

C23

0.1uF

C29

330R

R46

330R

R35

330R

R38

330R

R39

10k

R62

10k

R43

10k

R37

10k

R42

10k

R44

10k

R57

10k

R60

10k

R47

10k

R52

100k

R49

0R

R55

200K

R41

1k

R50

100R

R51

4.7k

R36

4.7k

R40

2.2k

R53

2.2k

R54

2.2k

R45

3.92k

R48

PKOB Mode

REAL ICE Mode

pins 1-2: Shorted pins 1-2: Open

pins 3-4: Shorted pins 3-4: Open

JP17 Jumper Positions

1 2

3 4

J17

1uF

C24

1uF

C28

PGD2

PGC2

YELLOW GREEN

D9

+3.3V_PKOB

3.16k

R56

8.2pF

C25

8.2pF

C26

MCLR

USB2_N

USB2_P

330R

R66

100R

R58

USB_DUSB_D+

VBUS_PKOB

1

3

2

MMBT2222

Q1

+3.3V

0.1uF

C31

330R

R90

VBUS_PKOB

PKOB USB INTERFACE

(BUS POWERED)

MBR230LSFT1G 430mV @ 2A

D14

+5V_CPU

AVDD

19

PMPD2/RE2

62

PMA7/AN9/RB9

22

RF1

59

VSS

25

Vcap/VDDCORE

56

PMA10/AN13/RB13

28

PMRD/RD5

53

PMA9/SDA2/RF4

31

DHP/RD2

50

AN2/RB2

14

AN5/RB5

11

PMA2/RG9

8

PMA4/RG7

5

PMD6/SCL3/RE6

2

Vusb

35

VDD

38

VSS

41

SCL1/PMCS2/RD10

44

SOSCI/RC13

47

AN1/RB1

15

USBOENAN4/RB4

12

AN0/RB0

16

AN3/RB3

13

VSS

9

PMA3/RG8

6

VDD

10

MCLR

7

PMD7/SDA3/RE7

3

PMA5/RG6

4

AN6/RB617AVSS

20

AN7/RB718AN8/RB8

21

PMPD4/RE464PMPD1/RE1

61

PMPD3/RE363PMPD0/RE0

60

PMA13/AN10/RB10

23

VDD

26

PMA12/AN11/RB1124PMA11/AN12/RB12

27

RF0

58

RD7

55

ENVREG

57

RD6

54

PMA1/AN14/RB1429PMA8/SCL2/RF5

32

PMA0/AN15/RB15

30

PMWR/RD4

52

VCPCON/RD1

49

PMBE/RD3

51

Vbus

34

D+/RG2

37

USBID/RF3

33

D-/RG3

36

OSC2/CLKO/RC15

40

SDA1/RD9

43

OSC1/CLKIN/RC12

39

RTCC/RD8

42

INT0/RD0

46

PMCS1/RD11

45

SOSCO/RC14

48

PMD5/CN63/RE5

1

N

p

N

2

5

G9

G7

/SCL3/RE6

V

VDD

VSS

SCL1/PMCS2/

0

SOSCI/RC13

1

USBO

4

0

3

VSS

G8

VDD

7

G6

NRN

N

NRN

N

N4N

N

Vbus

D+

/RG

US

G3

OSC2/CLKO/RC15

S

9

OSC1/C

RTCC/

I

1

SOSCO/RC14

5

U7

10uF

C18

ID

4

VBUS

1

GND

5

D-

2

D+

3

0

USB2.0 MICRO-B FEMALE

J19

FIGURE A-11 :

PIC32MZ DA SK BASE BOARD SCHEMATICS (4 OF 5)

PIC32MZ DA Family Starter Kit User’s Guide

R

RE

RD

RD R

NT0/RD0

PMCS1/RD1

4 R

LKIN/RC12

RD1

DA1/RD

RD8

D-/R

BID/RF3

2

usb

RE

D

PMD5/CN63/RE

PMD6

PMD7/SDA3/RE

PMA5/R

PMA4/R

PMA3/R

MCLR

PMA2/R

AN5/RB

ENAN4/RB

AN3/RB

AN2/RB

AN1/RB

AN0/RB

Schematics

+3.3V

GCLK

I/O1

SPI_MOSI

SPI_CE0_N

TXD0

I/O2 I/O3

SPI_MISO

SPI_SCLK

I/O4 I/O5 I/O6 I/O7 I/O8

RXD0

I/O9

I/O10 I/O11

I/O12

I/O13

I/O14 I/O15

+5V

+3.3V

SPI_CE1_N

I/O16

RPF2/SDA3/RF2

RPF8/SCL3/RF8

AN1/CTCMP/C2INB/RPB2/RB2

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

22

21 23

24

25

26

27

28

29

30

31

32

33

34

35

36 38 40

37 39

HDR-2.54 Male 2x20

J15

FIGURE A-12:

PIC32MZ DA SK BASE BOARD SCHEMATICS (5 OF 5)

 2017 Microchip Technology Inc. DS70005311A-page 39

DS70005311A-page 40  2017 Microchip Technology Inc.

RXD1

RXD0

RX_ER

MDIO

MDC

TX_EN

TXD0

TXD1

CRS_DV

nRST

+3.3V

CLK_IN

0.1uF

C6

nINT

VDD2A

1

LED2/nINT/nPME/nINTSEL

2

LED1/nINT/nPME/REGOFF

3

XTAL2

4

XTAL1/CLKIN

5

VDDCR

6

RXCLK/PHYAD1

7

RXD3/PHYAD2

8

RXD2/nPME/RMIISEL

9

RXD1/MODE1

10

RXD0/MODE0

11

VDDIO

12

RXER/RXD4/PHYAD0

13

CRS

14

COL/CRS_DV/MODE2

15

MDIO

16

MDC

17

nINT/TXER/TXD4

18

nRST

19

TXCLK

20

TXEN

21

TXD0

22

TXD1

23

TXD2

24

TXD3

25

RXDV

26

VDD1A

27

TXN

28

TXP

29

RXN

30

RXP

31

RBIAS

32

PAD

33

/IN/

/

IN

S

LED

1/nINT/n

PME/RE

G

O

FF

XTAL1

/

C

K

IN

C

/

RX

D

3

/

PHYAD2

/

R

SE

RXD1

/

O

DE1

0

/

O

0

RX

ER/RXD4/PHYA

D

0

CRS

CO

L

/

CRS_ D

V/MO

DE2

MD

O

C

nINT/TXER/TXD

4

RST

T

X

C

K

TXE

N

TXD

0

TXD

2

3

RX

DVT

X

N

TXP

RX

N

RX

P

S

U1

*SMSC LAN8740

RXD1

RXD0

RX_ER

MDIO

MDC

TX_EN

TXD0

TXD1

CRS_DV

nRST

CLK_IN nINT

LED_ACT

TXP

TXN

RXP

RXN

LED_LINK

49.9R

R17

49.9R

R18

49.9R

R19

49.9R

R20

249R

R21

249R

R22

12pF

C10

12pF

C11

12pF

C12

12pF

C13

For EMI Purposes

(DNP)

VDDA

0.022uF

C14

0R

R23

EGND

Create EGND copper pour

around RJ-45 Conn

VDDA

J3011G21DNL

2

12

8

4

11

1

7

6

NC

9

10

3

5

SHIELD

14

SHIELD

13

J7

J6

J4

J3

J1

J5

J8

J2

4X75ê

Yel

Grn

1000pF 2KV

J2

TXN

TXP

RXP

RXN

TX_P

TX_N

RX_N

RX_P

LED_ACT

LED_LINK

12.1k

R15

1.0uF

C3

1.0uF

C7

0.1uF

C4

0.1uF

C5

FB1

VDDA+3.3V

1.0uF

C1

0.1uF

C2

+3.3V

10K

R5

10K

R16

+3.3V

1.5K

R7

4.7K

R1

4.7KR24.7K

R3

MODE[2:0] = 111

Default

+3.3V

RMII

EN

4.7K

R6

4.7K

R4

4.7K

R8

PHYAD[2:0] = 000

Default

REGOFF=0

(Regulator ON)

1.0uF

C8

470pF

C9

CLK_IN

33RR12

33R

R13

33R

R14

33R

R11

Place close to U1

1

2

3

4

5

6

7

8

9

10

11

12

13

15

16

17

18

19

20

21

22

23

24

14

S9014E-12-ND

EGND

25

EGND

25

J1

2 HDR/DB

EGND

(DNP)R24

FIGURE A-13: LAN8740 PHY DAUGHTER CARD

PIC32MZ DA Family Starter Kit User’s Guide

O

I

M

L

R

MII

E

BI

PIC32MZ DA FA MILY STARTER

KIT USER’S GUIDE

Appendix B. Bill of Materials

B.1 PIC32MZ2064DAx288 DAUGHTE R CARD BILL OF MATERIALS

T ABLE B-1: PIC32MZ2064DAx288 DAUGHTER CARD BILL OF MATERIALS

Quantity Reference Description Manufacturer Part No.

44 C1, C2, C8, C9,

C10, C11, C12, C13, C14, C15, C16, C17, C18, C19, C20, C21, C22, C23, C24, C25, C26, C27, C28, C29, C30, C31, C32, C33, C35, C37, C38, C39, C40, C41, C42, C43, C44, C45, C46, C57, C59, C60, C62, C97

16 C7, C34, C36,

C47, C48, C49, C50, C51, C52, C53, C54, C55, C56, C61, C67,

C69 1 C6 CAP CER 4.7uF 6.3V 20% X5R SMD 0402 Murata GRM155R60J475ME47D 1 C5 CAP CER 2.2uF 10V 10% X5R 0402 Murata GRM155R60J475ME47D 1 L1 FILTER CHIP 120 OHM 300MA 0402 Murata BLM15HB121SN1D 1 LD2 DIO LED GREEN 1.7V 20mA SMD 0603 OSRAM LG L29K-G2J1-24-Z 1 R2 RES TKF 10k 5% 1/10W SM D 0402 Panasonic ERJ-2GEJ103X 1 R3 RES TKF 100k 1% 1/10W SM D 0402 Panasonic ERJ-2RKF1003X 1 R5 RES TKF 100R 5% 1/16W SMD 0402 Yageo RC0402JR-07100RL 5 R6, R7, R10,

R12, R13 2 R8, R9 RES SMD 1K OHM 1% 1/16W 0402 St ackpole Inc. RMCF0402FT1K00 1 R11 RES 470 OHM 1/16W 1% 0402 SMD Rohm Semiconductor MCR01MRTF4700 1 R14 RES TKF 1.5k 5% 1/16W SMD 0402 Rohm Semiconductor MCR01MRTJ152 1 R15 RES TKF 2.2k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF2201X 1 Y1 ASDMB-24.000MHZ -LC-T Abracon LLC ASDMB-24.000MHZ-LC-T 1 U2 IC REG LDO 1.8V 1A 10MLF Microchip Technology MIC69101-1.8YML-TR 1 TP24 TEST POINT PC MINI .040"D RED Keystone Electronics 5000 1 TP25 TEST POINT PC MINI .040"D BLACK Keystone Electronics 5001 1 TP1 CON TP TAB Silver Mini 3.8x2.03 SMD Keystone Electronics 5019 2 J1, J2 CONN RCPT 100POS 0.4MM SMD GOLD Hirose Electric Co Ltd DF40HC(3.0)-100DS- 0.4V(58) 1 U3 IC DDR2 SDRAM 1GBIT 3NS 84FBGA Micron Technology MT47H64M16HR-3:H TR 1 U1 288 pin PIC32 BGA Non-Cr ypt o Microchip Technology PIC32MZ2064DAB288-I/4J

CAP CER 0.1uF 16V 10% X7R SMD 0402 Murata GRM155R71C104KA88D

CAP CER 0.01uF 16V 10% X7R SMD 0402

RES TKF 0R SMD 0402 Panasonic ERJ-2GE0R00X

KEMET C0402C103K4RACTU

 2017 Microchip Technology Inc. DS70005311A-page 41

PIC32MZ DA Family Starter Kit User’s Guide

TABLE B-1: PIC32MZ2064DAx288 DAUGHTER CARD BI LL OF MATERIALS (CONTINUED)

Quantity Reference Description Manufacturer Part No.

DNP TP 4, TP5, TP6,

DNP C3, C4 CAP CER 8PF 50V NP0 0603 TDK Corporation C1608C0G1H080D080AA DNP R1 RES SMD 1M OHM 1% 1/10W 0402 Panasonic ERJ-2RKF1004X DNP Y3 CRYSTAL 24.000MHZ 8PF SMD AVX Corp/Kyocera

DNP Y2 OSCILLATOR 32.768KHZ 3.3V SMD CTS-Frequency

TP10, TP11, TP12, TP13, TP14, TP15, TP16, TP17, TP18, TP19, TP20, TP21, TP22, TP23

CX3225GA24000D0PTVZ1

Corp

TC25L5I32K7680

Controls

DS70005311A-page 42  2017 Microchip Technology Inc.

Bill of Materials

B.2 PIC32MZ2064DAx169 DAUGHTER CARD BILL OF MATERIALS

T ABLE B-2: PIC32MZ2064DAx169 DAUGHTER CARD BILL OF MATERIALS

Quantity Reference Description Manufacturer Part No.

22 C1, C2, C8,

C9, C10, C11, C12, C13, C33, C37, C38, C39, C40, C41, C42, C43, C44, C45, C46, C57, C60, C61

14 C34, C47, C48,

C49, C50, C51, C52, C53, C54, C55, C56, C58,

C59, C67 1 C6 CAP CER 2.2uF 10V 10% X5R SMD 0402 Murata GRM155R61A225K E95D 2 J1, J2 100 pin Recpt, Center Strip SMD (P0.4mm) Hirose Electric Co Ltd DF40HC(3.0)-100DS-0.4V(58) 3 L1, L2, L3 FERRITE CHIP 100 OHM 2A 0603 TDK Corporation MPZ1608Y101B 1 LD2 DIO LED GREEN 1.7V 20mA SMD 0603 OSRAM LG L29K-G2J1-24-Z 1 R2 RES TKF 10k 5% 1/10W SMD 0402 Panasonic ERJ-2GEJ103X-T 2 R8, R9 RES SMD 1K OHM 1% 1/16W 0402 Stackpole Inc. RMCF0402FT1K00 1 R11 RES TKF 470R 5% 1/16W SMD 0402 Panasonic ERJ-2GEJ471X 2 R12, R17 RES TKF 0R SMD 0402 Panasonic ERJ-2GE0R00X 1 R14 RES TKF 1.5k 5% 1/16W SMD 0402 Rohm Semiconductor MCR01MRTJ 152 1 R15 RES TKF 2.2k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF2201X 1 Y1 OSC MEMS 24.000 MHZ SMD Abracon Corporation ASDMB-24.000MHZ-LC-T 1 U1 PIC32MZ 169BGA Non-crptyo Microchip Technology PIC32MZ2064DAH169-I/BG

CAP CER 0.1uF 16V 10% X7R SMD 0402 Murata GRM155R71C104KA88D

CAP CER 0.01uF 16V 10% X7R SMD 0402 KEMET C0402C103K4RACTU

DNP C3, C4 CAP CER 8pF 50V 0.5pF C0G SMD 0603 Murata GRM1885C1H8R0DZ01D DNP L4 FERRITE CHIP 100 OHM 2A 0603 TDK Corporation MPZ1608Y101B DNP R1 RE S TKF 1M 1% 1/16W SMD 0402 Yageo RC0402FR-071ML DNP Y3 CRYSTAL 24MHz 18pF SMD ABM 7 Abracon LLC ABM7-24.000MHZ-D2Y-T DNP TP24 TEST POINT PC MINI .040"D RED Keystone Electronics 5000 DNP TP25 TEST POINT PC MINI .040"D BLACK Keystone Electronics 5001 DNP Y2 OSC XO 32.768KHZ CMOS SMD CTS-Frequency

Controls

DNP TP1, TP2 CON TP TAB Silver Mini 3.8x2.03 SMD Keystone Electronics 5019

TC25L5I32K7680

 2017 Microchip Technology Inc. DS70005311A-page 43

PIC32MZ DA Family Starter Kit User’s Guide

B.3 PIC32MZ DA SK BASE BOARD BILL OF MATERIALS

TABLE B-3: PIC32MZ DA SK BASE BOARD BILL OF MATERIALS

Quantity Reference Description Manufacturer Part No.

1 C12 CAP CER 0.01uF 16V 10% X7R SMD 0402 KEMET C0402C103K4RACTU

17 C1, C2, C6, C8,

C11, C13, C14, C15, C16, C19, C20, C21, C22, C23, C27, C29,

C31 3 C4, C24, C28 CAP CER 1uF 10V 10% X5R 0402 Murata GRM155R61A105KE15D 2 C7, C18 CAP CER 10uF 10V 20% X5R SMD 0603 Panasonic ECJ-1VB1A106M 3 C9, C10, C32 CAP CER 100uF 10V 20% X5R SMD 1206 TDK Corporation C3216X5R1A107M160AC 1 C30 CAP CER 4.7uF 6.3V 20% X5R SMD 0402 Murata GRM155R60J475ME47D 3 C3, C5, C17 CAP CER 2.2uF 10V 10% X5R 0402 Murata GRM155R61A225KE95D 2 C25, C26 CAP CER 8.2pF 50V 0.25pF NP0 0402 Johanson Technol-

2 J1, J2 CONN HDR 100POS 0.4MM SMD GOLD Hirose Electric Co Ltd DF 40C-100DP-0.4V(51) 1 J3 CONN HEADER 168POS W/POST SMD Hirose Electric Co Ltd FX10A-168P-SV1(71) 4 J4, J5, J6, J19 CON USB2.0 MICRO-B FEMALE

1 J7 CON USB USB-A Female SMD R/A ASSMANN Electronic AU-Y1006-R 1 J8 CON HDR-2.54 Male 1x2 Gold 5.84MH

2 J9 MOD LAN8740 PHY Daughter Board Sullins Connector

2 @J9 3 Position Header Connector 0.050"

1 J10 MICRO SD PUSH/PUSH SMALL 8C Molex, LLC 5033981892 1 J17 HDR_JMPR_2X2_TH_0.05" Samtec FTS-102-01-F-D 1 @J17 CONN JUMPER SHORTING 1.27MM

3 D4, D7, D9 DIO LED GREEN 2.1V 20mA 2.4mcd

1 D8 DI O LED YELLO W 2.2V 25mA 3.4mcd

1 D6 DI O LED RED 1.7V 25mA 11.7mcd

3 D3, D13, D14 DI ODE SCHOT TKY 30V 2A SO D123L ON Semiconductor MBR230LSFT1G 3 S1, S2, S3 SWITCH TACTILE SPST-NO 0.05A 12V C&K Components PTS63 5SK25SMTR LFS 1 TP3 MISC, TEST POINT MULTI PURPOSE

2 TP1, TP2 MISC, TEST POINT MULTI PUR PO SE

1 Y2 CRYSTAL 12MHz 8pF SM D NX3225SA NDK NX3225SA-12.000000MHZ 1 Y1 OSC MEMS 50.000 MHz_1 .8V~3 .3V SMD A bracon Corporation ASEMB-50.000MHZ-LC-T 3 R3, R10, R49 RES TKF 100k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1003X 1 R50 RES TKF 1k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1001X 3 R45, R53, R54 RES TKF 2.2k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF2201X

CAP CER 0.1uF 16V 10% X7R SMD 0402 Murata GRM155R71C104KA88D

500R07S8R2CV4T

ogy Inc

TH/SMD R/A

TH VERT

(1.27mm) Through Hole Gold

GOLD

Diffuse SMD 0603

MINI BLACK

MINI RED

FCI 10118194-0001LF

FCI 77311-118-02LF

LPPB121NFFN-RC

Solutions Sullins Connector

Solutions

Sullins Connector Solutions

Stanley Electric Co BG1111C-TR

Stanley Electric Co AY1111C-TR

Stanley Electric Co BR1111C-TR

Keystone 5001

Keystone 5000

LPPB031NFFN-RC

NPB02DVFN-RC

DS70005311A-page 44  2017 Microchip Technology Inc.

Bill of Materials

Quantity Reference Description Manufacturer Part No.

10 R6, R16, R28,

R29, R35, R38, R39, R46, R66,

R90 1 R41 RES TKF 200k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF2003X 5 R4, R14, R15,

R31, R32 5 R2, R36, R40,

R85, R86

22 R9, R17, R18,

R19, R20, R21,

R30, R37, R42,

R43, R44, R47,

R52, R57, R60,

R62, R68, R69,

R67, R83, R88,

R89 2 R51, R58 RES TKF 100R 5% 1/16W SMD 0402 Yageo RC0402JR-07100RL

11 R1, R12, R13,

R33, R55, R78,

R79, R80, R81,

R82, R84 1 R56 RES SMD 3.16K OHM 1% 1/10W 0402 Panasonic ERJ-2RKF3161X 1 R48 RES TKF 3.92K 1% 1/16W SMD 0402 Yageo RC0402FR-073K92L 1 U3 IC BILATERAL SWITCH DUAL SM8 Toshiba +E14 1 U9 IC SWITCH SPDT SC70-6 Fairchild Semiconduc-

1 U11 IC PWR DIST SWITCH SNGL SOT23-5 Texas Instruments TPS2041BDBVRG4 2 Q3, Q4 TRANS BJT NPN MMBT3904 40V 200mA

1 Q2 TRANS BJT PNP MMBT3906 -40V -200mA

1 Q1 TRANS BJT NPN MMBT2222 30V 600mA

1 Rubber Foot BUMPER SQUARE BLK

1 U8 MCHP MEMORY SERIAL EEPROM 256k

1 U6 MCHP ANALOG LDO 3.3V

1 U2 MCHP ANALOG LDO 3.3V

1 U5 IC FLASH 32MBIT 8QFN_Modified Pads Microchip Technology SST26 VF 032BT-104I/SM 1 U7 PI C® IC 16-Bit 32MHz 256KB 64-TQF P

1 U4 LDO 1.8V 1A_10MLF (3x3) Microchip Technology MIC69101-1.8YML-TR 1 U1 MCHP INTERFACE USB I2C UART

RES TKF 330R 5% 1/10W SMD 0402 Panasonic ERJ-2GEJ331X

RES TKF 33R 1% 1/16W SMD 0402 Rohm Semiconductor MCR01MRTF33R0

RES TKF 4.7k 5% 1/10W SMD 0402 Panasonic ERJ-2GEJ472X

RES TKF 10k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1002X

RES TKF 0R 1/16W SMD 0402 Yageo RC0402JR-070RL

NC7SB3157P6X

tor

310mW SOT-23-3

300mW SOT-23-3

350mW SOT-23-3

(L10.5xW10.5xH2.5mm)

SPI 25LC256-I/SN SOIC-8

MCP1700T-3302E/TT SOT-23-3

MCP1727-3302E/SN SOIC-8

(10x10)

MCP2221-I/ST TSSOP-14

Diodes Incorporated MMBT3904-7

Central Semiconductor

Fairchild Semiconductor

3M SJ-5007

Microchip Technology 25LC256T-I/SN

Microchip Technology MCP1700T-3302E/TT

Microchip Technology MCP1727-3302E/SN

Microchip Technology PIC24FJ256GB106-I/PT

Microchip Technology MCP2221-I/ST

CMPT3906-PST-LEADFREE

MMBT2222

DNP R 11, R59, R61,

R87, R70, R84,

R71

DNP R 22, R23, R24,

 2017 Microchip Technology Inc. DS70005311A-page 45

R25, R26, R27

PIC32MZ DA Family Starter Kit User’s Guide

Quantity Reference Description Manufacturer Part No.

DNP D11 DIODE GEN PURP 75V 150MA 0402 Comchip Technology CDSQR4148-HF DNP J11 Terminal Strip, Dual Row Horizontal,

Surface Mount, 0.100" Pitch, 14 Pins

DNP J15 CON HDR-2.54 Male 2x20 Gold 5.84MH

TH VERT

DNP J12, J18 CON HDR-1.27 Female 1x6 Gold TH VERT Samtec SLM-106-01-G-S

Samtec TSW-120-07-G-D

DS70005311A-page 46  2017 Microchip Technology Inc.

Bill of Materials

B.4 LAN8740A PHY DAUGHTER BOARD BILL OF MATERIALS

TABLE B-4: LAN8740A PHY DAUGHTER BOARD BILL OF MATERIALS

Quantity Reference Description Manufacturer Part No.

4 C1, C3, C7, C8 Cap, Ceramic, 1 µF, 16V X5R TDK Corporation C1608X5R1C105K 4 C2, C4, C5, C6 Cap, Ceramic, 0.1 µF, 50V X7R TDK Corporation C1608X7R1H104M 1 C9 CAP 470 µF 50V CERAMI C X7R 0603 Yageo CC0603KRX7R9BB471 1 C14 CAP CER 0.022 µF 50V 20% X7R 0603 Murata GRM188R71H223MA01D 1 FB1 FERRITE CHIP 600 OHM 500 mA 0805 TDK Corporation MMZ2012Y601B 2 J1 TWO CONN HEADER .050" 12 POS PCB

GOLD

2 @J1 TWO CONN HEADER .050" 3 POS PCB

GOLD 1 J2 CONN MAGJACK 1 PORT 100 BASE -T X Pulse J3011G21DNL 6R1, R2, R3,

R4, R6, R8 2 R5, R16 RES 10K OHM 1/10W 1% 0603 SMD Stackpole Inc. RMCF0603FT10K0 1 R7 RES 1.50K OHM 1/10W 1% 0603 SMD Vishay Dale CRCW06031K50F KEA 4 R11, R12,

R13, R14 1 R15 RES 12.1K OHM 1/10W 1% 0603 SMD Stackpole Inc. RMCF0603FT12K1 4 R17, R18,

R19, R20 2 R21, R22 RES TF 1/10W 249 OHM 1% 0603 Stackpole Inc. RMCF0603FG249R 1 R23 RES 0.0 OHM 1/4W 0805 SMD Yageo RC0805JR-070RL 1 U1 TX/ RX Ethernet 32-pin QFN Microchip Technology LAN8740A-EN

RES 4.70K OHM 1/10W 1% 0603 SMD P anasonic - ECG ERJ-3E KF 4701V

RES 33 OHM 1/10W 1% 0603 SMD Stackpole Inc. RMCF0603FT33R0

RES TF 1/10W 49.9 OHM 1% 0603 Stackpole Inc. RMCF0603FG49R9

Sullins Connector GRPB121VWVN-RC

Sullins Connector GRPB031VWVN-RC

DNP C10, C11,

C12, C13

DNP R24 DNP (0603 pads)

CAP CER 12 µF 50V 5% NPO 0603 Yageo CC0603JRNP O9B N120

 2017 Microchip Technology Inc. DS70005311A-page 47

Worldwide Sales and Service

AMERICAS

Corporate Office

2355 West Chandler Blvd. Chandler, AZ 85224-6199 Tel: 480-792-7200 Fax: 480-792-7277 Technical Support:

http://www.microchip.com/ support

Web Address:

www.microchip.com

Atlanta

Duluth, GA Tel: 678-957-9614 Fax: 678-957-1455

Austin, TX

Tel: 512-257-3370

Boston

Westborough, MA Tel: 774-760-0087 Fax: 774-760-0088

Chicago

Itasca, IL Tel: 630-285-0071 Fax: 630-285-0075

Cleveland

Independence, OH Tel: 216-447-0464 Fax: 216-447-0643

Dallas

Addison, TX Tel: 972-818-7423 Fax: 972-818-2924

Detroit

Novi, MI Tel: 248-848-4000

Houston, TX

Tel: 281-894-5983

Indianapolis

Noblesville, IN Tel: 317-773-8323 Fax: 317-773-5453

Los Angeles

Mission Viejo, CA Tel: 949-462-9523 Fax: 949-462-9608

New York, NY

Tel: 631-435-6000

San Jose, CA

Tel: 408-735-9110

Canada - Toronto

Tel: 905-673-0699 Fax: 905-673-6509

ASIA/PACIFIC

Asia Pacific Office

Suites 3707-14, 37th Floor Tower 6, The Gateway Harbour City, Kowloon

Hong Kong

Tel: 852-2943-5100 Fax: 852-2401-3431

Australia - Sydney

Tel: 61-2-9868-6733 Fax: 61-2-9868-6755

China - Beijing

Tel: 86-10-8569-7000 Fax: 86-10-8528-2104

China - Chengdu

Tel: 86-28-8665-5511 Fax: 86-28-8665-7889

China - Chongqing

Tel: 86-23-8980-9588 Fax: 86-23-8980-9500

China - Dongguan

Tel: 86-769-8702-9880

China - Guangzhou

Tel: 86-20-8755-8029

China - Hangzhou

Tel: 86-571-8792-8115 Fax: 86-571-8792-8116

China - Hong Kong SAR

Tel: 852-2943-5100 Fax: 852-2401-3431

China - Nanjing

Tel: 86-25-8473-2460 Fax: 86-25-8473-2470

China - Qingdao

Tel: 86-532-8502-7355 Fax: 86-532-8502-7205

China - Shanghai

Tel: 86-21-3326-8000 Fax: 86-21-3326-8021

China - Shenyang

Tel: 86-24-2334-2829 Fax: 86-24-2334-2393

China - Shenzhen

Tel: 86-755-8864-2200 Fax: 86-755-8203-1760

China - Wuhan

Tel: 86-27-5980-5300 Fax: 86-27-5980-5118

China - Xian

Tel: 86-29-8833-7252 Fax: 86-29-8833-7256

ASIA/PACIFIC

Asia Pacific Office

Suites 3707-14, 37th Floor Tower 6, The Gateway Harbour City, Kowloon

Hong Kong

Tel: 852-2943-5100 Fax: 852-2401-3431

Australia - Sydney

Tel: 61-2-9868-6733 Fax: 61-2-9868-6755

China - Beijing

Tel: 86-10-8569-7000 Fax: 86-10-8528-2104

China - Chengdu

Tel: 86-28-8665-5511 Fax: 86-28-8665-7889

China - Chongqing

Tel: 86-23-8980-9588 Fax: 86-23-8980-9500

China - Dongguan

Tel: 86-769-8702-9880

China - Guangzhou

Tel: 86-20-8755-8029

China - Hangzhou

Tel: 86-571-8792-8115 Fax: 86-571-8792-8116

China - Hong Kong SAR

Tel: 852-2943-5100 Fax: 852-2401-3431

China - Nanjing

Tel: 86-25-8473-2460 Fax: 86-25-8473-2470

China - Qingdao

Tel: 86-532-8502-7355 Fax: 86-532-8502-7205

China - Shanghai

Tel: 86-21-3326-8000 Fax: 86-21-3326-8021

China - Shenyang

Tel: 86-24-2334-2829 Fax: 86-24-2334-2393

China - Shenzhen

Tel: 86-755-8864-2200 Fax: 86-755-8203-1760

China - Wuhan

Tel: 86-27-5980-5300 Fax: 86-27-5980-5118

China - Xian

Tel: 86-29-8833-7252 Fax: 86-29-8833-7256

EUROPE

Austria - Wels

Tel: 43-7242-2244-39 Fax: 43-7242-2244-393

Denmark - Copenhagen

Tel: 45-4450-2828 Fax: 45-4485-2829

Finland - Esp oo

Tel: 358-9-4520-820

France - Paris

Tel: 33-1-69-53-63-20 Fax: 33-1-69-30-90-79

France - Saint Cloud

Tel: 33-1-30-60-70-00

Germany - Garching

Tel: 49-8931-9700

Germany - Haan

Tel: 49-2129-3766400

Germany - Heilbronn

Tel: 49-7131-67-3636

Germany - Karlsruhe

Tel: 49-721-625370

Germany - Munich

Tel: 49-89-627-144-0 Fax: 49-89-627-144-44

Germany - Rosenheim

Tel: 49-8031-354-560

Israel - Ra’anana

Tel: 972-9-744-7705

Italy - Milan

Tel: 39-0331-742611 Fax: 39-0331-466781

Italy - Padova

Tel: 39-049-7625286

Netherlands - Drunen

Tel: 31-416-690399 Fax: 31-416-690340

Norway - Trondheim

Tel: 47-7289-7561

Poland - Wars a w

Tel: 48-22-3325737

Romania - Bucharest

Tel: 40-21-407-87-50

Spain - Madrid

Tel: 34-91-708-08-90 Fax: 34-91-708-08-91

Sweden - Gothenberg

Tel: 46-31-704-60-40

Sweden - Stockholm

Tel: 46-8-5090-4654

UK - Wokingham

Tel: 44-118-921-5800 Fax: 44-118-921-5820

11/07/16

DS70005311A-page 48  2017 Microchip Technology Inc.

Mouser Electronics

Authorized Distributor

Click to View Pricing, Inventory, Delivery & Lifecycle Information:

Microchip: DM320010 DM320008 DM320008-C DM320010-C

Microchip Technology PIC32MZ User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Chapter 1. Introduction

1.1 KIT CONTENTS

1.2 BLOCK DIAGRAM

FIGURE 1-1: HIGH-LEVEL BLOCK DIAGRAM OF THE PIC32MZ DA STARTER KIT

1.3 STARTER KIT FUNCTIONALITY AND FEATURES

1.3.1 Development Board

FIGURE 1-2: PIC32MZ DA SK BASE BOARD LAYOUT (TOP VIEW)

FIGURE 1-3: PIC32MZ DA SK BASE BOARD LAYOUT (BOTTOM VIEW)

1.3.2 LAN8740A PHY Daughter Board

FIGURE 1-8: DAUGHTER BOARD LAYOUT (TOP VIEW)

FIGURE 1-9: DAUGHTER BOARD LAYOUT (BOTTOM VIEW)

Chapter 2. Hardware

2.1 HARDWARE FE ATURES

2.1.1 Processor Support

2.1.2 Power Supply

2.1.3 Graphics Connectivity

2.1.4 Debug USB Connectivity

2.1.5 PIC32 USB Connectivity

2.1.6 External Memory Connectivity

2.1.7 Switches

2.1.8 LEDs

2.1.9 Oscillator Options

2.1.10 168-pin Modular Expansion Connector

TABLE 2-1: STARTER KIT CONNECTOR PART NUMBERS

2.1.11 Ethernet PHY

2.1.12 USB-to-UART/I2C Communication

TABLE 2-2: MCP2221 UART PIN CONNECTIONS

2.1.13 40-pin Expansion Connector

TABLE 2-3: J15 CONNECTIONS

A.1 SCHEMATICS

Appendix A. Schematics

FIGURE A-1: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (1 OF 4)

FIGURE A-2: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (2 OF 4)

FIGURE A-3: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (3 OF 4)

FIGURE A-4: PIC32MZ2064DAX288 DAUGHTER CARD SCHEMATICS (4 OF 4)

FIGURE A-5: PIC32MZ2064DAX169 DAUGHTER CARD SCHEMATICS (1 OF 3)

FIGURE A-6: PIC32MZ2064DAX169 DAUGHTER CARD SCHEMATICS (2 OF 3)

FIGURE A-7: PIC32MZ2064DAX169 DAUGHTER CARD SCHEMATICS (3 OF 3)

FIGURE A-13: LAN8740 PHY DAUGHTER CARD

Appendix B. Bill of Materials

B.1 PIC32MZ2064DAx288 DAUGHTE R CARD BILL OF MATERIALS

T ABLE B-1: PIC32MZ2064DAx288 DAUGHTER CARD BILL OF MATERIALS

B.2 PIC32MZ2064DAx169 DAUGHTER CARD BILL OF MATERIALS

T ABLE B-2: PIC32MZ2064DAx169 DAUGHTER CARD BILL OF MATERIALS

B.3 PIC32MZ DA SK BASE BOARD BILL OF MATERIALS

TABLE B-3: PIC32MZ DA SK BASE BOARD BILL OF MATERIALS

B.4 LAN8740A PHY DAUGHTER BOARD BILL OF MATERIALS

TABLE B-4: LAN8740A PHY DAUGHTER BOARD BILL OF MATERIALS

AMERICAS

ASIA/PACIFIC

ASIA/PACIFIC

EUROPE
