MRF24J40MA/MB PICtail™/PICtail
PLUS DAUGHTER BOARD
USER’S GUIDE
Table of Contents
Preface ...........................................................................................................................5
Chapter 1. Overview
1.1 Introduction ...................................................................................................11
1.2 MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Contents ...............11
1.3 MRF24J40MA/MB PICtail/PICtail Plus Daughter Board ..............................11
Chapter 2. Getting Started
2.1 Introduction ...................................................................................................15
2.2 Plugging into the PIC18 Explorer Board .......................................................15
2.3 Plugging into the Explorer 16 Development Board ......................................16
2.4 Downloading and Running the Demo Program ............................... .. ...........17
Appendix A. MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Schematic
A.1 Introduction ..................................................................................................19
A.2 MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Schematic ............ 20
A.3 MRF24J40MA/MB PICtail/PICtail Plus Daughter Board PCB Layout ..........21
A.4 MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Bill of Materials .....23
Worldwide Sales and Service ....................................................................................24
2009 Microchip Technology Inc. DS51867A-page 3
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
NOTES:
DS51867A-page 4 2009 Microchip Technology Inc.
MRF24J40MA/MB PICtail™/PICtail
PLUS DAUGHTER BOARD
USER’S GUIDE
Preface
NOTICE TO CUSTOMERS
All documentation becomes dated, and this manual is no exception. Microchip tools and documentation are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document. Please refer to our web site (www.microchip.com) to obtain the latest documentation available.
Documents are identified with a “DS” number. This number is located on the bottom of each page, in front of the p age number. The numbering convention for the DS number is “DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the document.
For the most up-to-date information on development tools, see the MPLAB Select the Help menu, and then Topics to open a list of available on-line help files.
®
IDE on-line help.

INTRODUCTION

This chapter contains general information that will be useful to know before using the MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board. Items discussed in this chapter include:
• Document Layout
• Conventions Used in this Guide
• Warranty Registration
• Recommended Reading
• The Microchip Web Site
• Development Systems Customer Change Notification Service
• Customer Support
• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board. The manual layout is as follows:
Chapter 1. “Overview ” This chapter provides an overview of the MRF24J40MA/MB PICtail/PICtail Plus Daughter Board, including board contents and features.
Chapter 2. “Getti ng Started” This chapter describes how to start using your MRF24J40MA/MB PICtail/PICtail Plus Daughter Board.
Appendix A. “MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Sche- matic” This appendix contains the schematics, PCB information and Bill of Materials for the MRF24J40MA/MB PICtail/PICtail Plus Daughter Board.
2009 Microchip Technology Inc. DS51867A-page 5
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide

CONVENTIONS USED IN THIS GUIDE

This manual uses the following docum entat io n conven tion s:
DOCUMENTATION CONVENTIONS
Description Represents Examples
Arial font:
Italic chara c ters Referenced books MPLAB
Emphasized text ...is the only compiler...
Initial caps A window the Output window
A dialog the Settings dialog A menu selection select Enable Programmer
Quotes A field name in a window or
dialog
Underlined, italic text with right angle bracket
Bold characters A dialog button Click OK
N‘Rnnnn A number in verilog format,
Text in angle brac kets < > A key on the keyboard Press <Enter>, <F1>
Courier New font:
Plain Courier New Sample source code #define START
Italic Courier New A variable argument file.o, where file can be
Square brackets [ ] Optional arguments mcc18 [options] file
Curly brackets and pipe character: { | }
Ellipses... Replaces r epeated text var_name [,
A menu path File>Save
A tab Click the Power tab
where N is the tota l number of digits, R is th e radi x and n is a digit.
Filenames autoexec.bat File paths c:\mcc18\h Keywords _asm, _endasm, static Command-line options -Opa+, -Opa- Bit values 0, 1 Constants 0xFF, ‘A’
Choice of mut ually exclus ive arguments; an OR selection
Represents code supplied by user
“Save project before build”
4‘b0010, 2‘hF1
any valid filename
[options] errorlevel {0|1}
var_name...] void main (void)
{ ... }
®
IDE User’s Guide
DS51867A-page 6 2009 Microchip Technology Inc.

WARRANTY REGISTRATION

Please complete the enclosed Warranty Registration Card and mail it promptly. Sending in the Warranty Registration Card entitles users to receive new product updates. Interim software releases are available at the Microchip web site.

RECOMMENDED READING

This user's guide describes how to use the MRF24J40MA/MB PICtail/PICtail Plus Daughter Board. Other useful documents are listed below. The following Microchip documents are available and recommended as supplemental reference resources.
MRF24J40 IEEE 802.15.4 2.4™ GHz RF Transceiver Data Sheet (DS39776) MRF24J40MA IEEE 802.15.4 2.4 GHz RF Transceiver Module Data Sheet
(DS70329) MRF24J40MB 2.4 GHz IEEE 802.15.4 20 dBm RF Transceiver Data Sheet
(DS70599) PICDEM™ PIC18 Explorer Demonstration Board User’s Guide (DS51721) Explorer 16 Development Board User’s Guide (DS51589) 2K SPI Bus Serial EEPROM with EUI-48™ Node Identity Data Sheet (DS22123)
Preface
2009 Microchip Technology Inc. DS51867 A-page 7
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide

THE MICROCHI P WEB SITE

Microchip provides online support via our web site at www.microchip.com. This web site is used as a means to make files and information easily available to customers. Accessible by using your favorite Internet browser, the web site contains the following information:
Product Support – Data sheets and errata, application notes and sample programs, design resources, user’s guides and hardware support documents, latest software releases and archived software
General Technical Support – Frequently Asked Questions (FAQs), technical support requests, online discussion groups, Microchip consultant program member listin g
Business of Microchip – Product selector and ordering guides, latest Microchip press releases, listing of seminars and events, listings of Microchip sales offices, distributors and factory representatives

DEVELOPMENT SYSTEMS CUSTOMER CHANGE NOTIFICATION SERVICE

Microchip’s customer notification service helps keep customers current on Microchip products. Subscribers will receive e-mail notification whenever there are changes, updates, revisions or errata related to a specified product family or development tool of interest.
To register, access the Microchip web site at www.microchip.com, click on Customer Change Notification and follow the registration instructions.
The Development Systems product group categories are:
Compilers – The latest information on Microchip C compilers and other language tools. These include the MPLAB C18 and MPLAB C30 C compilers; MPASM™ and MPLAB ASM30 assemblers; MPLINK™ and MPLAB LINK30 object linkers; and MPLIB™ and MPLAB LIB30 object librarians.
Emulators – The latest information on Microchip in-circuit emulators.This includes the MPLAB ICE 2000 and MPLAB ICE 4000.
In-Circuit Debuggers – The latest information on the Microchip in-circuit debugger, MPLAB ICD 2.
MPLAB Integrated Development Environment for development systems tools. This list is focused on the MPLAB IDE, MPLAB SIM simulator, MPLAB IDE Project Manager and general editing and debugging features.
Programmers – The latest information on Microchip programmers. These include the MPLAB PM3 and PRO MATE II device programmers and the PICSTART Plus and PICkit™ 1, 2, and 3 development programmers.
®
IDE – The latest information on Microchip MPLAB IDE, the Windows®
®
DS51867A-page 8 2009 Microchip Technology Inc.

CUSTOMER SUPPORT

Users of Microchip products can receive assistance through several channels:
• Distributor or Representative
• Local Sales Office
• Field Application Engineer (FAE)
• Technical Support Customers should contact their distributor, representative or field application engineer
(FAE) for support. Local sales offices are also available to help customers. A listing of sales offices and locations is included in the back of this document.
Technical support is available through the web site at: http://support.microchip.com

DOCUMENT REVISION HISTORY

Revision A (October 2009)
• Initial Release of this Document.
Preface
2009 Microchip Technology Inc. DS51867 A-page 9
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
NOTES:
DS51867A-page 10 2009 Microchip Technology Inc.

1.1 INTRODUCTION

The MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board is a demonstration and development daughter board for the:
• MRF24J40MA IEEE 802.15.4 2.4 GHz RF Transceiver module, or
• MRF24J40MB 2.4 GHz IEEE 802.15.4 20 dBm RF Transceiver module The daughter board can plug into multiple Microchip Technology demonstration and
development boards. For example, for 8-bit microcontroller development using the PIC18 Explorer Board (DM183032) or for 16-bit microcontroller development using the Explorer 16 Development Board (DM240001).
Supporting software stacks and application notes may be downloaded from the Microchip website http://www.microchip.com/wireless
This chapter discusses:
• MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Contents
• MRF24J40MA/MB PICtail/PICtail Plus Daughter Board
MRF24J40MA/MB PICtail™/PICtail
PLUS DAUGHTER BOARD
USER’S GUIDE

Chapter 1. Overview

.

1.2 MRF24J40MA/MB PICtail/PICtail PLUS DAUGHTER BOARD CONTENTS

Depending on the development tool ordered, package contents will contain one of the following development boards listed in Table 1-1.

TABLE 1-1: MRF49XA PICtail™/PICtail PLUS DAUGHTER BOARD

Description Part Number
MRF24J40MA PICtail™/PICtail Plus Daughter Board AC164134-1 MRF24J40MB PICtail/PICtail Plus Daughter Board AC164134-2

1.3 MRF24J40MA/MB PICtail/PICtail PLUS DAUGHTER BOARD

The MRF24J40MA/MB PICtail/PICtail Plus Daughter Board is a complete IEEE
802.15.4 2.4 GHz wireless transceiver. The features are shown in Figure 1-1 and 1-2.
CAUTION
Power to the MRF24J40MA/MB PICtail/PICtail Plus Daughter Board should be in the range of 2.4-3.6V. Ensure that the development/demonstration board that the daugh­ter board is plugged into meets this voltage requirement; otherwise, damage to the MRF24J40 may occur.
2009 Microchip Technology Inc. DS51867A-page 11
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
MRF24J40MA Module
INT2 Jumper
PICtail™ and PICtail Plus Connectors
Power Disconnect/Current Measure Jumpers
25AA02E48 EUI Node Identity Serial EEPROM
MRF24J40MB Module
INT2 Jumper
PICtail™ and PICtail Plus Connectors
Power Disconnect/Current Measure Jumpers
25AA02E48 EUI Node Identity Serial EEPROM

FIGURE 1-1: MRF24J40MA PICtail™/PICtail PLUS DAUGHTER BOARD

FIGURE 1-2: MRF24J40MB PICtail™/PICtail PLUS DAUGHTER BOARD

DS51867A-page 12 2009 Microchip Technology Inc.
Overview
PICtail Plus Connector ( P1) – 30-pin card edge connector for connecting into 16 and
32-bit development boards’ PICtail Plus connector. PICtail Connector (P2) – 28-pin right angle connector to connect to 8-bit development
boards’ PICtail connector.
MRF24J40MA (U1) – IEEE 802.15.4 2.4 GHz Transceiver. MRF24J40MB (U2) – IEEE 802.15.4 2.4 GHz 20 dBm Transceiver.
Note: Only one MRF24J40 module, U1 or U2, will be populated on the
PICtail/PICtail Plus Daughter Board depending on the development tool ordered.
Power Disconnect/Current Measure Jumpers (JP1/JP2) – Two 2-pin headers are connected in parallel. A shunt connects power to the MRF24J40 module. A current meter can be placed on the header and the shunt removed to measure current consumption.
TIP: To prevent power interruption to the MRF24J40 module, keep the shunt on the header while connecting the current meter. Once connected, remove the shunt to measure current.
INT2 Jumper (JP3) – Jumpering JP3 with a shunt allows the connection of RA5 to RB2/INT2 to allow push button switch S2 to trigger an interrupt. See Section 2.1.1
Configuring Push Button Switch S2 to RB2/INT2 for more information. EUI Node Identity Serial EEPROM (U3) – Contains a unique IEEE EUI address. For
more information, refer to “2K SPI Bus Serial EEPROM with EUI-48™ Node Identity Data Sheet” (DS22123).
2009 Microchip Technology Inc. DS51867A-page 13
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
NOTES:
DS51867A-page 14 2009 Microchip Technology Inc.
MRF24J40MA/MB PICtail™/PICtail
PLUS DAUGHTER BOARD

Chapter 2. Getting Started

2.1 INTRODUCTION

The MRF24J40MA/MB PICtail/PICtail Plus Daughter Board can be plugged into multi­ple Microchip T echnology demonstration and development boards. This allows the developer to choose the microcontroller that best suits the customer’s development environment.
The PICtail connector right angle header, P2, can plug into 8-bit demonstration and development boards, such as the PIC18 Explorer Board (DM183032). The PICtail Plus card edge connector, P1, can plug into Explorer 16 Development Board (DM240001).
This chapter shows how the daughter board is plugged into the PIC18 Explorer and Explorer 16 Development Boards.

2.2 PLUGGING INTO THE PIC18 EXPLORER BOARD

The MRF24J40MA/MB PICtail/PICtail Plus Daughter Board can be plugged into the PIC18 Explorer Board PICtail connector, J3, as shown in Figure 2-1. Make sure to align pin 1 to RE2 as shown.
USER’S GUIDE
CAUTION
Ensure that the PIC18F87J11 PIM is plugged into the PIC18 Explorer Board. This sets the system V PICtail/PICtail Plus Daughter Board.

2.2.1 Configuring Push Button Switch S2 to RB2/INT2

On the PIC18 Explorer Board, push button switch S2 is normally connected to I/O port pin RA5. RA5 is not a change on interrupt or external interrupt capable I/O pin. Jum­pering JP3 with a shunt allows the connection of RA5 to RB2/INT2 to allow push button switch S2 to trigger an interrupt. Keep in mind that RB2 also connects to pin 10 (input) of U6 (RS232 level shifter) which is a Clear-to-Send (CTS) signal on P2 pin 8 (DE9 receptacle).
DD voltage to 3.3 volts, which is required by the MRF24J40MA/MB
2009 Microchip Technology Inc. DS51867A-page 15
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
Align Pin 1 to RE2
FIGURE 2-1: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER BOARD
PLUGGED INTO PIC18 EXPLORER BOARD

2.3 PLUGGING INTO THE EXPLORER 16 DEVELOPMENT BOARD

The MRF24J40MA/MB PICtail/PICtail Plus Daughter Board can be plugged into the Explorer 16 Development Board as shown in Figure 2-2.
The Daughter Board 30-pin card edge connector can be plugged into the top section of the PICtail Plus connector. This will connect to the SPI Port 1 on the PIC troller plugged into the PIM socket. If the Daughter Board is plugged into the mid-section of the PICtail Plus connector, this will connect to SPI Port 2 on the PIC microcontroller.
FIGURE 2-2: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER BOARD
PLUGGED INTO EXPLORER 16 DEVELOPMENT BOARD
®
microcon-
DS51867A-page 16 2009 Microchip Technology Inc.
Getting Started

2.4 DOWNLOADING AND RUNNING THE DEMO PROGRAM

Sample source code is available from the Microchip Wireless Design Environment, MiMAC and MiApp. Each is described in application notes AN1283 and AN1284, respectively. A Quick Start Guide is included in the software installation package that explains the installation and operation of the demostration program. It may be downloaded from the Microchip website http://www.microchip.com/wireless
.
2009 Microchip Technology Inc. DS51867A-page 17
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
NOTES:
DS51867A-page 18 2009 Microchip Technology Inc.
MRF24J40MA/MB PICtail™/PICtail
PLUS DAUGHTER BOARD
USER’S GUIDE
Appendix A. MRF24J40MA/MB PICtail/PICtail Plus
Daughter Board Schematic

A.1 INTRODUCTION

This appendix provides the MRF24J40MA/MB PICtail/PICtail Plus Daughter Board schematics, PCB layout and Bill of Materials (BOM).
• MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Schematic
• MRF24J40MA/MB PICtail/PICtail Plus Daughter Board PCB Layout
• MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Bill of Materials
2009 Microchip Technology Inc. DS51867A-page 19
DS51867A-page 20 2009 Microchip Technology Inc.
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide

A.2 MRF24J40MA/MB PICtail/PICtail PLUS DAUGHTER BOARD SCHEMATIC

FIGURE A-1: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER BOARD SCHEMATIC

MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Schematic

A.3 MRF24J40MA/MB PICtail/PICtail PLUS DAUGHTER BOARD PCB LAYOUT

The MRF24J40MA/MB PICtail/PICtail Plus Daughter Board is a 2-layer, FR4, 0.062 inch, plated through hole PCB construction.
FIGURE A-2: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER BOARD
SILKSCREEN
FIGURE A-3: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER BOARD
TOP COPPER
2009 Microchip Technology Inc. DS51867A-page 21
MRF24J40MA/MB PICtail™/PICtail Plus Daughter Board User’s Guide
FIGURE A-4: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER
BOARD BOTTOM COPPER
FIGURE A-5: MRF24J40MA/MB PICtail™/PICtail PLUS DAUGHTER
BOARD BOTTOM SILKSCREEN
DS51867A-page 22 2009 Microchip Technology Inc.
MRF24J40MA/MB PICtail/PICtail Plus Daughter Board Schematic
A.4 MRF24J40MA/MB PICtail/PICtail PLUS DAUGHTER BOARD BILL OF
MATERIALS

TABLE A-1: MRF24J40MA PICtail™/PICtail PLUS DAUGHTER BOARD BILL OF MATERIALS

Reference Value Description Vendor Vendor P/N Comments
C1, C2, C3, C5, C6
JP1, JP2, JP3
Shunt Connector, Shunt, 0.100”
P2 Connector, Header, 2x14,
U1 MRF24J40MA MRF24J40MA RF
U2 MRF24J40MB MRF24J40MA 20 dBm RF
U3 25AA02E48 EUI-48 Node Identity
0.1 uF Capacitor, Ceramic, 50V, C0G, SMT 0603
Connector, Header, 1x2,
0.100” pitch, 0.025” sq post
pitch
0.100” pitch, right angle
0.390/0.230
Transceiver Module
Transceiver Module
Serial EEPROM
Panasonic ECJ-1VB1C104K Bypass capacitor
SPC TECH­NOLOGY
Sullins Con­nector Sol u­tions
Sullins Con­nector Sol u­tions
Microchip Technology
Microchip Technology
Microchip Technology
SPC20481
STC02SYAN Shunts for JP1 and
JP3
GBC14DBDN
MRF24J40MA- I/RM Populated only on
MRF24J40MA PICtail/PICtail Plus Daughter Board
MRF24J40MB- I/RM Populated only on
MRF24J40MB PICtail/PICtail Plus Daughter Board
25AA02E48-I/SN
2009 Microchip Technology Inc. DS51867A-page 23
WORLDWIDE SALES AND SERVICE
AMERICAS
Corporate Office
2355 West Chandler Blvd. Chandler, AZ 85224-6199 Tel: 480-792-7200 Fax: 480-792-7277 Technical Support: http://support.microchip.com Web Address: www.microchip.com
Atlanta
Duluth, GA Tel: 678-957-9614 Fax: 678-957-1455
Boston
Westborough, MA Tel: 774-760-0087 Fax: 774-760-0088
Chicago
Itasca, IL Tel: 630-285-0071 Fax: 630-285-0075
Cleveland
Independence, OH Tel: 216-447-0464 Fax: 216-447-0643
Dallas
Addison, TX Tel: 972-818-7423 Fax: 972-818-2924
Detroit
Farmington Hills, MI Tel: 248-538-2250 Fax: 248-538-2260
Kokomo
Kokomo, IN Tel: 765-864-8360 Fax: 765-864-8387
Los Angeles
Mission Viejo, CA Tel: 949-462-9523 Fax: 949-462-9608
Santa Clara
Santa Clara, CA Tel: 408-961-6444 Fax: 408-961-6445
Toronto
Mississauga, Ontario, Canada Tel: 905-673-0699 Fax: 905-673-6509
ASIA/PACIFIC
Asia Pacific Office
Suites 3707-14, 37th Floor Tower 6, The Gateway Harbour City, Kowloon Hong Kong Tel: 852-2401-1200 Fax: 852-2401-3431
Australia - Sydney
Tel: 61-2-9868-6733 Fax: 61-2-9868-6755
China - Beijing
Tel: 86-10-8528-2100 Fax: 86-10-8528-2104
China - Chengdu
Tel: 86-28-8665-5511 Fax: 86-28-8665-7889
China - Hong Kong SAR
Tel: 852-2401-1200 Fax: 852-2401-3431
China - Nanjing
Tel: 86-25-8473-2460 Fax: 86-25-8473-2470
China - Qingdao
Tel: 86-532-8502-7355 Fax: 86-532-8502-7205
China - Shanghai
Tel: 86-21-5407-5533 Fax: 86-21-5407-5066
China - Shenyang
Tel: 86-24-2334-2829 Fax: 86-24-2334-2393
China - Shenzhen
Tel: 86-755-8203-2660 Fax: 86-755-8203-1760
China - Wuhan
Tel: 86-27-5980-5300 Fax: 86-27-5980-5118
China - Xiamen
Tel: 86-592-2388138 Fax: 86-592-2388130
China - Xian
Tel: 86-29-8833-7252 Fax: 86-29-8833-7256
China - Zhuhai
Tel: 86-756-3210040 Fax: 86-756-3210049
ASIA/PACIFIC
India - Bangalore
Tel: 91-80-3090-4444 Fax: 91-80-3090-4080
India - New Delhi
Tel: 91-11-4160-8631 Fax: 91-11-4160-8632
India - Pune
Tel: 91-20-2566-1512 Fax: 91-20-2566-1513
Japan - Yokohama
Tel: 81-45-471- 6166 Fax: 81-45-471-6122
Korea - Daegu
Tel: 82-53-744-4301 Fax: 82-53-744-4302
Korea - Seoul
Tel: 82-2-554-7200 Fax: 82-2-558-5932 or 82-2-558-5934
Malaysia - Kuala Lumpur
Tel: 60-3-6201-9857 Fax: 60-3-6201-9859
Malaysia - Penang
Tel: 60-4-227-8870 Fax: 60-4-227-4068
Philippines - Manila
Tel: 63-2-634-9065 Fax: 63-2-634-9069
Singapore
Tel: 65-6334-8870 Fax: 65-6334-8850
Tai wan - Hsin Chu
Tel: 886-3-6578-300 Fax: 886-3-6578-370
Taiwan - Kaohsiung
Tel: 886-7-536-4818 Fax: 886-7-536-4803
Taiwan - Taipei
Tel: 886-2-2500-6610 Fax: 886-2-2508-0102
Thailand - Bangkok
Tel: 66-2-694-1351 Fax: 66-2-694-1350
EUROPE
Austria - Wels
Tel: 43-7242-2244-39 Fax: 43-7242-2244-393
Denmark - Copenhagen
Tel: 45-4450-2828 Fax: 45-4485-2829
France - Paris
Tel: 33-1-69-53-63-20 Fax: 33-1-69-30-90-79
Germany - Munich
Tel: 49-89-627-144-0 Fax: 49-89-627-144-44
Italy - Milan
Tel: 39-0331-742611 Fax: 39-0331-466781
Netherlands - Drunen
Tel: 31-416-690399 Fax: 31-416-690340
Spain - Madrid
Tel: 34-91-708-08-90 Fax: 34-91-708-08-91
UK - Wokingham
Tel: 44-118-921-5869 Fax: 44-118-921-5820
03/26/09
DS51867A-page 24 2009 Microchip Technology Inc.
Loading...
