Microchip Technology MPLAB XC16 C Compiler User guide

MPLAB® XC16 C Compiler
User’s Guide
2012 Microchip Technology Inc. DS52071B
Note the following details of the code protection feature on Microchip devices:
YSTEM
CERTIFIED BY DNV
== ISO/TS 16949 ==
Microchip products meet the specification contained in their particular Microchip Data Sheet.
Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the intended manner and under normal conditions.
There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data Sheets. Most likely, the person doing so is engaged in theft of intellectual property.
Microchip is willing to work with the customer who is concerned about the integrity of their code.
Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not mean that we are guaranteeing the product as “unbreakable.”
Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.
Information contained in this publication regarding device applications and t he lik e is provided only for your convenience and may be su perseded by upda t es . It is y our responsibility to ensure that your application meets with your specifications. MICROCHIP MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, STATUTORY OR OTHERWISE, RELATED TO THE INFORMATION, INCLUDING BUT NOT LIMITED TO ITS CONDITION, QUALITY, PERFORMANCE, MERCHANTABILITY OR FITNESS FOR PURPOSE. Microchip disclaims all liability arising from this information and its use. Use of Microchip devices in life supp ort and/or safety ap plications is entir ely at the buyer’s risk, and the buyer agrees to defend, indemnify and hold harmless M icrochip from any and all dama ges, claims, suits, or expenses re sulting from such use. No licens es are conveyed, implicitly or otherwise, under any Microchip intellectual property rights.
Trademarks
The Microchip name and logo, the Microchip logo, dsPIC, K
EELOQ, KEELOQ logo, MPLAB, PIC, PICmicro, PICSTART,
32
PIC
logo, rfPIC and UNI/O are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
FilterLab, Hampshire, HI-TECH C, Linear Active Thermistor, MXDEV, MXLAB, SEEVAL and The Embedded Control Solutions Company are registered trademarks of Microchip Technology Incorporated in the U.S.A.
Analog-for-the-Digital Age, Application Maestro, chipKIT, chipKIT logo, CodeGuard, dsPICDEM, dsPICDEM.net, dsPICworks, dsSPEAK, ECAN, ECONOMONITOR, FanSense, HI-TIDE, In-Circuit Serial Programming, ICSP, Mindi, MiWi, MPASM, MPLAB Certified logo, MPLIB, MPLINK, mTouch, Omniscient Code Generation, PICC, PICC-18, PICDEM, PICDEM.net, PICkit, PICtail, REAL ICE, rfLAB, Select Mode, Total Endurance, TSHARC, UniWinDriver, WiperLock and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
SQTP is a service mark of Microchip Technology Incorporated in the U.S.A.
All other trademarks mentioned herein are property of their respective companies.
© 2012, Microchip Technology Incorporated, Printed in the U.S.A., All Rights Reserved.
Printed on recycled paper.
QUALITY MANAGEMENT S
DS52071B-page 2 2012 Microchip Technology Inc.
ISBN: 978-1-62076-467-1
Microchip received ISO/TS-16949:2009 certification for its worldwide headquarters, design and wafer fabrication facilities in Chandler and Tempe, Arizona; Gresham, Oregon and design centers in California and India. The Company’s quality system processes and procedures are for its PIC devices, Serial EEPROMs, microperipherals, nonvolatile memory and analog products. In addition, Microchip’s quality system for the design and manufacture of development systems is ISO 9001:2000 certified.
®
MCUs and dsPIC® DSCs, KEELOQ
®
code hopping
MPLAB® XC16 C COMPILER
USER’S GUIDE

Table of Contents

Preface .........................................................................................................................11
Chapter 1. Compiler Overview
1.1 Introduction ...................................................................................................17
1.2 Device De s cr ip t io n .............. ......................................................................... 17
1.3 Compiler Des c ription and Do cu mentation ......... ... ............. .. .. .............. .. ....... 17
1.3.1 ANSI C Standard .......................................................................................17
1.3.2 Optimization ..............................................................................................17
1.3.3 ANSI Standard Library Support .................................................................18
1.3.4 Flexible Memory Models ............................................................................18
1.3.5 Attributes and Qualifiers ............................................................................18
1.3.6 Compiler Driver ......................................................................................... 18
1.3.7 Documentation ..........................................................................................18
1.4 Compiler and Other Development Tools ......................................................19
Chapter 2. Common C Interface
2.1 Introduction ...................................................................................................21
2.2 Background – The Desire for Portable Code ...............................................21
2.2.1 The ANSI Standard ...................................................................................22
2.2.2 The Common C Interface ..........................................................................23
2.3 Using the CC I .. .. .. ......................................................................................... 24
2.4 ANSI Standard Refinement ..........................................................................25
2.4.1 Source File Encoding ................................................................................ 25
2.4.2 The Prototype for main ..............................................................................25
2.4.3 Header File Specification ..........................................................................25
2.4.4 Include Search Paths ................................................................................ 26
2.4.5 The number of Significant Initial Characters in an Identifier ......................27
2.4.6 Sizes of Types ...........................................................................................27
2.4.7 Plain char Types ........................................................................................28
2.4.8 Signed Integer Representation .................................................................. 28
2.4.9 Integer conversion .....................................................................................29
2.4.10 Bit-wise Operations on Signed Values ....................................................29
2.4.11 Right-shifting Signed Values ................................................................... 29
2.4.12 Conversion of Union Member Accessed Using Member
With Different Type .. ....... ...... ...... ....... ...... ....... ...... ....... ..........................30
2.4.13 Default Bit-field int Type ......................................... ....... ...... ....... ...... ....... 30
2.4.14 Bit-fields Straddling a Storage Unit Boundary .........................................31
2.4.15 The Allocation Order of Bits-field ............................................................. 31
2.4.16 The NULL macro ..................................................................................... 32
2.4.17 Floating-point sizes .......... .......................................................................32
2012 Microchip Technology Inc. DS52071B-page 3
MPLAB® XC16 C Compiler User’s Guide
2.5 ANSI Standard Extensions ...........................................................................33
2.5.1 Generic Header File ...................................................................................33
2.5.2 Absolute addressing ..................................................................................33
2.5.3 Far Objects and Functions .........................................................................34
2.5.4 Near Objects ..............................................................................................35
2.5.5 Persistent Objects ......................................................................................36
2.5.6 X and Y Data Objects ................................................................................37
2.5.7 Banked Data Objects .................................................................................37
2.5.8 Alignment of Objects ..................................................................................38
2.5.9 EEPROM Objects ......................................................................................39
2.5.10 Interrupt Functions ........................................... ....... ...... ...........................3 9
2.5.11 Packing Objects .......................................................................................42
2.5.12 Indicating Antiquated Objects ....................................... ....... ...... ....... ...... . 4 3
2.5.13 Assigning Objects to Sections .................................................................43
2.5.14 Specifying Configuration Bits ...................................................................45
2.5.15 Manifest Macros ............... ....... ...... ...........................................................46
2.5.16 In-line Assembly ............... ........................................................................47
2.6 Compiler Fe a tu r e s . .. ..................................................................................... 48
2.6.1 Enabling the CCI ........................................................................................48
Chapter 3. Compiler Command-Line Driver
3.1 Introduction ................................................................................................... 49
3.2 Invoking th e C o m p ile r .. ................................................................................. 50
3.2.1 Drive Command-Line Format .....................................................................50
3.2.2 Environment Variables ...............................................................................50
3.2.3 Input File Types .........................................................................................51
3.3 The Compilation Sequence ..........................................................................52
3.3.1 The Compiler Applications .........................................................................52
3.3.2 Single-Step Compilation ............................................................................54
3.3.3 Multi-Step Compilation ...............................................................................55
3.3.4 Assembly Compilation ...............................................................................56
3.4 Runtime File s ........................................................ ....................................... 5 7
3.4.1 Library Files ...............................................................................................57
3.4.2 Startup and Initialization .............................................................................57
3.5 Compiler Ou t p u t ............... .. .......................................................................... 58
3.5.1 Output Files ................................................................................................58
3.5.2 Diagnostic Files ..........................................................................................58
3.6 Compiler Messages ...................................................................................... 59
DS52071B-page 4 2012 Microchip Technology Inc.
3.7 Driver Option Descriptions ........................................................................... 60
3.7.1 Options Specific to 16-Bit Devices ............................................................60
3.7.2 Options for Controlling the Kind of Output ................................................. 62
3.7.3 Options for Controlling the C Dialect .........................................................63
3.7.4 Options for Controlling Warnings and Errors .............................................64
3.7.5 Options for Debugging ..............................................................................70
3.7.6 Options for Controlling Optimization .......................................................... 71
3.7.7 Options for Controlling the Preprocessor ..................................................76
3.7.8 Options for Assembling .............................................................................79
3.7.9 Options for Linking .................................................................................... 79
3.7.10 Options for Directory Search ................................................................... 82
3.7.11 Options for Code Generation Conventions ............................................. 82
3.8 MPLAB IDE Toolsuite Equivalents ............................................................... 83
Chapter 4. Device-Related Features
4.1 Introduction ...................................................................................................85
4.2 Device Support .............................................................................................85
4.3 Device Header Files .....................................................................................85
4.3.1 Register Definition Files ............................................................................85
4.4 Stack . .......................................... ................................................................. 86
4.5 Configur ation Bit Access ............................................... .. .. ............. .. ... ......... 86
4.6 Using SFRs ......... .. ....................................................................................... 87
4.7 Bit-Reversed and Modulo Addressing ..........................................................89
Table of Contents
Chapter 5. Differences Between MPLAB XC16 and ANSI C
5.1 Divergence from the ANSI C Standard ................................ ........................91
5.2 Extensions to the ANSI C Standard .............................................................91
5.2.1 Keyword Differences .................................................................................91
5.2.2 Expression Differences .............................................................................91
5.3 Implementation-Defined Behavior ................................................................91
Chapter 6. Supported Data Types and Variables
6.1 Introduction ...................................................................................................93
6.2 Identifiers ......................................................................................................93
6.3 Integer Data Types .......................................................................................94
6.3.1 Double-Word Integers ...............................................................................94
6.3.2 char Types .................................................................................................95
6.4 Floating- P o in t D a ta T ype s ............................................................................ 95
6.5 Structures and Unions ..................................................................................96
6.5.1 Structure and Union Qualifiers ..................................................................96
6.5.2 Bit-Fields in Structures ..............................................................................96
6.6 Pointer Typ e s ........ .......................................... ............................................. 98
6.6.1 Combining Type Qualifiers and Pointers ...................................................98
6.6.2 Data Pointers .............................................................................................99
6.6.3 Function Pointers ......................................................................................99
6.6.4 Special Pointer Targets .............................................................................99
6.7 Complex Data Types .................................................................................. 100
6.8 Literal Constant Types and Formats .................................................... .. ....101
2012 Microchip Technology Inc. DS52071 B-page 5
MPLAB® XC16 C Compiler User’s Guide
6.9 Standard Type Qualifiers ............................................................................103
6.9.1 Const Type Qualifier ................................................................................103
6.9.2 Volatile Type Qualifier ..............................................................................103
6.10 Compile r -S p e c ific type Qualifie rs ............... ... ............... ............................ 104
6.10.1 __psv__ Type Qualifier .................................... ....... ...... .........................10 4
6.10.2 __prog__ Type Qualifier ..................... ....... ...... ......................................104
6.10.3 __eds__ Type Qualifier ..........................................................................105
6.10.4 __pack_upper_byte Type Quali fi er ......................... ...... ....... ...... ....... .....105
6.10.5 __pmp__ Type Qualifier .........................................................................105
6.10.6 __external__ Type Qualifier ...................................................................106
6.11 Variab le Attributes .............. ...................................................................... 107
Chapter 7. Memory Allocation and Access
7.1 Introduction .................................................................................................117
7.2 Address Sp a ce s ............... .......................................................................... 117
7.3 Variables in Data Space Memory ............................................................... 118
7.3.1 Non-Auto Variable Allocation and Access ...............................................118
7.3.2 Auto Variable Allocation and Access .......................................................121
7.3.3 Changing Auto Variable Allocation ..........................................................124
7.4 Variables in Pr o g ra m Sp a ce . ...................................................................... 125
7.4.1 Allocation and Access of Program Memory Objects ................................125
7.4.2 Access of objects in Program Memory ....................................................127
7.4.3 Size Limitations of Program Memory Variables .......................................128
7.4.4 Changing Program Memory Variable Allocation ......................................129
7.5 Parallel Master Port Access ....................................................................... 130
7.5.1 Initialize PMP ...........................................................................................130
7.5.2 Declare a New Memory Space ................................................................131
7.5.3 Define Variables within PMP Space ........................................................131
7.6 External Me m o r y A c ce s s .. ....................................... ... .. .............................. 132
7.6.1 Declare a New Memory Space ................................................................132
7.6.2 Define Variables Within an External Space .............................................132
7.6.3 Define How to Access Memory Spaces ...................................................133
7.6.4 An External Example ...............................................................................135
7.7 Extended Data Space Access ....................................................................136
7.8 Packing Da ta S to re d in Fl as h .... .. ............. .. .. .............................................. 137
7.8.1 Packed Example ......................................................................................137
7.8.2 Usage Considerations ..............................................................................137
7.8.3 Addressing Information ............................................................................138
7.9 Allocatio n of V a ria b les to Registers ............................................................ 139
7.10 Variables in EEPROM .......................................... .. ........................... ....... 139
7.10.1 Accessing EEDATA via User Managed PSV .........................................139
7.10.2 Accessing EEDATA Using TBLRDx Instructions ...................................140
7.10.3 Accessing EEDATA Using Managed Access ........................................141
7.10.4 Additional Sources of Information ..........................................................141
7.11 Dynamic Memory Allo ca t io n ...... ..................................................... .. .. ...... 141
7.12 Memory M o d el s ....... ....................................................... .......................... 1 4 2
7.12.1 Near or Far Data ....................................................................................143
DS52071B-page 6 2012 Microchip Technology Inc.
Chapter 8. Operators and Statements
8.1 Introduction .................................................................................................145
8.2 Built-In Fu n ct io n s .......... .......................................... .................................... 145
8.3 Integral Pr o mo tion ...................................................................................... 145
Chapter 9. Register Usage
9.1 Introduction .................................................................................................147
9.2 Register V a ri a bl e s . ..................................................... ... .. ........................... 147
9.3 Changing R e g is te r Co n t en ts ......................................... .. .. ............. .. .......... 148
Chapter 10. Functions
10.1 Introd uc t io n ............................................................................................... 149
10.2 Writing F u nc t i on s ...................................................................................... 149
10.2.1 Function Specifiers ................................................................................ 149
10.2.2 Function Attributes .... ....... ...... ...... ....... ...... ....... ...... ....... ........................149
10.3 Functi o n Siz e Li m it s .......................................................................... .. .. ...1 5 6
10.4 Allocation of Function Code .....................................................................156
10.5 Changing the Default Function Allocation ................................................157
10.6 Inline F u nc t io n s ............................................................... .. .. ..................... 158
10.7 Memory M o d el s . ....................................................... ................................ 159
10.7.1 Near or Far Code .................................................................................. 160
10.8 Function Call Conventions ....................................................................... 161
10.8.1 Function Parameters ........ ...... ...... ....... ...... ....... ...... ....... ...... ....... ...... ..... 16 1
10.8.2 Return Value .................... ...... ............................................. ..................163
10.8.3 Preserving Registers Across Function Calls .........................................163
Table of Contents
Chapter 11. Interrupts
11.1 Introd uc t io n ............................................................................................... 165
11.2 Interru p t O p e ra t io n ......... ... ....................................................................... 166
11.3 Writing an Interrupt Service Routine ........................................................166
11.3.1 Guidelines for Writing ISRs ................................................................... 166
11.3.2 Syntax for Writing ISRs .......................................... ....... ........................167
11.3.3 Coding ISRs ........................................ ...... ....... ...... ....... ...... ....... ...........167
11.3.4 Using Macros to Declare Simple ISRs ..................................................168
11.4 Specifying the Interrupt Vector ................................................................. 169
11.4.1 Non-SMPS dsPIC30F DSCs Interrupt Vectors ......................................170
11.4.2 SMPS dsPIC30F DSCs Interrupt Vectors .............................................172
11.4.3 PIC24F MCUs Interrupt Vectors ............................................................174
11.4.4 dsPIC33F DSCs/PIC24H MCUs Interrupt Vectors ................................ 177
11.5 Interru p t S e rv ic e R o utine Context S aving . .......................... ... .. ............. .. . 180
11.6 Nesting In te rrupts ......... ............................................................................ 180
11.7 Enabling/Disabling Interrupts ...................................................................181
11.8 ISR Considerations ............... .. .. ........................................ .. ... .................. 182
11.8.1 Sharing Memory with Mainline Code ..................................................... 182
11.8.2 PSV Usage with Interrupt Service Routines ..........................................186
11.8.3 Latency ......... ....... ...... ....... ...... ...... ....... ...... ....... ..................................... 18 6
2012 Microchip Technology Inc. DS52071 B-page 7
MPLAB® XC16 C Compiler User’s Guide
Chapter 12. Main, Runtime Startup and Reset
12.1 Introd uc t io n ..... .......................................................................................... 18 7
12.2 The main F u n c tion ............ .. ...................................................................... 187
12.3 Runtime Startup and Initialization ............................................................. 187
Chapter 13. Mixing C and Assembly Code
13.1 Introd uc t io n ..... .......................................................................................... 18 9
13.2 Mixing Assembly Language and C Variables and Functions ...................189
13.3 Using Inline Assembly Language ............................................................. 192
13.4 Predefined Assembly Macros ...................................................................196
Chapter 14. Library Routines Chapter 15. Optimizations
15.1 Introd uc t io n ..... .......................................................................................... 19 9
Chapter 16. Preprocessing
16.1 Introd uc t io n ..... .......................................................................................... 20 1
16.2 C Language Comments ........................................................................... 201
16.3 Preprocessing Directives .......................................................................... 201
16.4 Predefined Macro Names .........................................................................202
16.4.1 Compiler Version Macro ........................................................................202
16.4.2 Output Types Macros .............................................................................203
16.4.3 Target Device Macros ............................................................................203
16.4.4 Device Features Macros ........................................................................203
16.4.5 Other Macros .........................................................................................204
16.5 Pragma s vs . A tt rib u tes ..... .. .. .................................................................... 2 0 5
Chapter 17. Linking Programs
17.1 Introd uc t io n ..... .......................................................................................... 20 7
17.2 Defau lt Me m o r y Sp a c e s ....... ... .. ............................................................... 207
17.3 Repla ci n g L ib rary Symbols ... .............. .. .. ............. .. ... ............. .. .. ............... 209
17.4 Linker-Defined Symbols ...........................................................................209
17.5 Defau lt L in k e r Script .. ... ............................................................................ 21 0
DS52071B-page 8 2012 Microchip Technology Inc.
Appendix A. Implementation-Defined Behavior
A.1 Introduction ................................................................................................211
A.2 Translati o n .......... .. ..................................................................................... 212
A.3 Environme n t ........................................................................................ .. .. ... 212
A.4 Identifiers ...................................................................................................213
A.5 Character s ............ ................ ..................................................................... 213
A.6 Integers ......................................................................................................214
A.7 Floating Po in t .. ....................................................... .................................... 215
A.8 Arrays and P o in te r s ............ ............................ ...........................................2 1 5
A.9 Register s ............. .. ........................................................ ............................. 216
A.10 Structures, Unions, Enumerations and Bit Fields ....................................216
A.11 Qualifiers .................................................................. ................................ 216
A.12 Declara to r s .......... .............. .. .. ..................................................... .. .. .......... 216
A.13 Stateme nt s ............... ................................................................................ 217
A.14 Preproce s s in g Di re c tives ......................................................................... 217
A.15 Library F u n ct io n s .............. ....................................... ... .. ........................... 218
A.16 Signals .....................................................................................................219
A.17 Streams and Files ....................................................................................220
A.18 tmpfile ...................................................................................................... 221
A.19 errno ......................................................................................................... 221
A.20 Memory .. .. .................................................................................. .............. 221
A.21 abort ................ .................................................................... ..................... 221
A.22 exit ................ .. .. ..................................................... .. ... ............................. 221
A.23 getenv ........ ... ........................................................................................... 221
A.24 system ........... .. ......................................................................................... 221
A.25 strerror .......... ............. .. .. ................................................................... .. .. ... 222
Table of Contents
Appendix B. Diagnostics
B.1 Introduction ................................................................................................223
B.2 Errors ........... .............................................................................................. 223
B.3 Warnings ....................................................... .......................................... ... 242
Appendix C. GNU Free Documentation License
C.1 Preamble ............ ........................... .. .. ........................................................ 263
C.2 Applicability and Definitions .......................................................................263
C.3 Verbatim C op y i ng ........ .. ....................................................... ..................... 265
C.4 Copying in Quantity ...................................................................................265
C.5 Modifica tio n s .............. .. ............................. ................................................. 266
C.6 Combining D o c um e nts ....... ....................................................................... 267
C.7 Collectio n s of D o cu ments ....... ................................................................... 267
C.8 Aggregation with Independent Works ........................................................267
C.9 Translati o n ... ... ....................................................... .................................... 268
C.10 Terminat io n .............. ................................................................................ 268
C.11 Future Re visions of this Lic e nse ...... .. ............. ... .. ............. .. ... ............. .. .. . 268
C.12 Relicens in g ......... ..................................................................................... 269
Appendix D. ASCII Character Set ............................................................................271
2012 Microchip Technology Inc. DS52071 B-page 9
MPLAB® XC16 C Compiler User’s Guide
Appendix E. Deprecated Features
E.1 Introduction ................................................................................................ 273
E.2 Predefined Constants ................................................................................ 273
E.3 Variable s in Sp ecified Regist e rs ............ .. .................................................. 274
E.3.1 Defining Global Register Variables ..........................................................274
E.3.2 Specifying Registers for Local Variables .................................................275
E.4 Changing Non-Auto Variable Allocation ..................................................... 275
Appendix F. Built-in Functions
F.1 Introduction ................................................................................................277
F.2 Built-In Fu n ct io n Description s ..... .. ..................................................... .. .. .... 279
Appendix G. XC16 Configuration Settings
G.1 Introduction ................................................................................................305
Glossary .....................................................................................................................307
Index ...........................................................................................................................327
Worldwide Sales and Service ...................................................................................338
DS52071B-page 10 2012 Microchip Technology Inc.
MPLAB® XC16 C COMPILER
USER’S GUIDE

Preface

NOTICE TO CUSTOMERS
All documentation becomes dated, and this manual is no exception. Microchip tools and documenta­tion are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document.
For the most up-to-date information on development tools, see the MPLAB Help. Select the Help menu and then “Topics” or “Help Contents” to open a list of available Help files.
For the most current PDFs, please refer to our web site (http://www.microchip.com). Documents are identified by “DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the document. This number is located on the bottom of each page, in front of the page number.

INTRODUCTION

MPLAB XC16 C Compiler documentation and support information is discussed in the sections below:
• Document Layout
• Conventions Used
• Recommended Reading
• myMicrochip Personalized Notification Service
• The Microchip Web Site
• Microchip Forums
• Customer Support
®
IDE or MPLAB X I DE
2012 Microchip Technology Inc. DS52071B-page 11
MPLAB® XC16 C Compiler User’s Guide

DOCUMENT LAYOUT

This document describes how to use GNU language tools to write code for 16-bit applications. The document layout is as follows:
Chapter 1. “Compiler Overvie w ” – describes the compiler, development tools and feature set.
Chapter 3. “Compiler Command-Line Driver” – describes how to use the compiler from the command line.
Chapter 5. “Differences Between MPLAB XC16 and ANSI C” – describes the differences between the C language supported by the compiler syntax and the standard ANSI-89 C.
Chapter 4. “Device-Re lat ed Fea tures” – describes the compiler header and register definition files, as well as how to use with SFRs.
Chapter 6. “Supported Data Types and Variables” – describes the compiler integer, floating point and pointer data types.
Chapter 7. “Memory Allocation and Access” – describes the compiler run-time model, including information on sections, initialization, memory models, the software stack and much more.
Chapter 8. “Operators and Statements” – discusses operators and statements.
Chapter 9. “Registe r Usage” – explains how to access and use SFRs.
Chapter 10. “Functions” – details available functions.
Chapter 11. “Interrupts” – describes how to use interrupts.
Chapter 12. “Main, Runtime Startup and Reset” – describes important elements of C code.
Chapter 14. “Libr ary Routi nes” – explains how to use libraries.
Chapter 13. “Mixing C and Assembly Code” – provides guidelines to using the compiler with 16-bit assembly language modules.
Chapter 15. “Opt imizat ion s” – describes optimization options.
Chapter 16. “Prep r oces sin g” – details preprocessing operation.
Chapter 17. “Linki ng Pr ogr ams” – explains how linking works.
Appendix A. “Implementation-Defined Behavior” – details compiler-specific parameters described as implementation-defined in the ANSI standard.
Appendix B. “Diagnostics” – lists error and warning messages generated by the compiler.
Appendix C. “MPLAB XC16 vs. MPLAB XC8” – contains the ASCII character set.
Appendix C. “GNU Free Documentation License” – usage license for the Free Software Foundation.
Appendix E. “Deprecated Features” – details features that are considered obsolete.
Appendix F. “Built-in Functions” – lists the built-in functions of the C compiler.
Appendix G. “XC16 Configuration Settings” – information about configuration settings macros.
DS52071B-page 12 2012 Microchip Technology Inc.

CONVENTIONS USED

DD
The following conventions may appear in this documentation:
DOCUMENTATION CONVENTIONS
Arial font:
Italic chara c ters Referenced books MPLAB
Initial caps A window the Output window
Quotes A field name in a window or
Underlined, italic text with right angle bracket
Bold characters A dialog button Click OK
Text in angle brackets < > A key on the keyboard Press <Enter>, <F1>
Courier font:
Plain Courier Sample source code #define START
Italic Courier A variable argument file.c, where file can be
Square brackets [ ] Optional arguments mpasmwin [options]
Curly brackets and pipe character: { | }
Ellipses... Replaces r epeated text var_name [,
Sidebar T e xt
Preface
Description Represents Examples
®
IDE User’s Guide
Emphasized text ...is the only compiler...
A dialog the Settings dialog A menu selection select Enable Programmer
“Save project before build”
dialog A menu path File>Save
A tab Click the Power tab
File names autoexec.bat File paths c:\mcc18\h Keywords _asm, _endasm, static Command-line options -Opa+, -Opa- Bit values 0, 1 Constants 0xFF, ’A’
any valid file name
file [options]
Choice of mut ually exclus ive arguments; an OR selection
Represents code supplied by user
Device Dependent. This feature is not supported on all devices. Devices sup­ported will be listed in the title or text.
errorlevel {0|1}
var_name...] void main (void)
{ ... }
xmemory attribute
2012 Microchip Technology Inc. DS52071B-page 13
MPLAB® XC16 C Compiler User’s Guide

RECOMMENDED READING

This documentation describes how to use the MPLAB XC16 C Compiler. Other useful documents are listed below. The following Microchip documents are available and recommended as supplemental reference resources.
Release Notes (Readme Files)
For the latest information on Microchip tools, read the associated Release Notes (HTML files) included with the software.
MPLAB User’s Guide (DS51317)
A guide to using the 16-bit assembler, object linker, object archiver/librarian and various utilities.
16-Bit Language Tools Libraries (DS51456)
A descriptive listing of libraries available for Microchip 16-bit devices. This includes standard (including math) libraries and C compiler built-in functions. DSP and 16-bit peripheral libraries are described in Release Notes provided with each peripheral library type.
Device-Specific Documentation
The Microchip website contains many documents that describe 16-bit device functions and features. Among these are:
• Individual and family data sheets
• Family reference manuals
• Programmer’s reference manuals
C Standards Information
®
Assembler, Linker and Utilities for PIC24 MCUs and dsPIC® DSCs
American National Standard for Information Systems – Programming Language – C.
American National Standards Institute (ANSI), 11 West 42nd. Street, New York, New York, 10036.
This standard specifies the form and establishes the interpretation of programs expressed in the programming language C. Its purpose is to promote portability, reliability, maintainability and efficient execution of C language program s on a variety of computing systems.
C Reference Manuals
Harbison, Samuel P . and Steele, Guy L., C A Reference Manual, Fourth Edition,
Prentice-Hall, Englewood Cliffs, N.J. 07632.
Kernighan, Brian W. and Ritchie, Dennis M., The C Programming Language, Secon d
Edition. Prentice Hall, Englewood Cliffs, N.J. 07632.
Kochan, Steven G., Programming In ANSI C, Revised Edition. Hayden Books,
Indianapolis, Indiana 46268. Plauger, P.J., The Standard C Library, Prentice-Hall, Englewood Cliffs, N.J. 07632. Van Sickle, Ted., Programming Microcontrollers in C, First Edition. LLH Technology
Publishing, Eagle Rock, Virginia 24085.
DS52071B-page 14 2012 Microchip Technology Inc.

myMICROCHIP PERSONALIZED NOTIFICATION SERVICE

Microchip's personal notification service helps keep customers current on their
Microchip products of interest. Subscribers will receive e-mail notification whenever
there are changes, updates, revisions or errata related to a specified product family or
development tool.
Please visit http://www.microchip.com/pcn to begin the registration process and select
your preferences to receive personalized notifications. A FAQ and registration details
are available on the page, which can be opened by selecting the link above.
When you are selecting your preferences, choosing “Development Systems” will pop-
ulate the list with available development tools. The main categories of tools are listed
below:
Compilers – The latest info rmatio n on Microc hip C comp ilers, as semblers , linker s and other language tools. These include all MPLAB C compilers; all MPLAB assemblers (including MPASM™ assembler); all MPLAB linkers (including MPLINK™ object linker); and all MPLAB librarians (including MPLIB™ object librarian).
Emulators – The latest information on Microchip in-circuit emulators.These include the MPLAB REAL ICE™ and MPLAB ICE 2000 in-circuit emulators
In-Circuit Debuggers – The latest information on Microchip in-circuit debuggers. These include the MPLAB ICD 2 and 3 in-circuit debuggers and PICkit™ 2 and 3 debug express.
MPLAB the Windows source, cross-platform Integrated Development Environment. These lists focus on the IDE, Project Manager, Editor and Simulator, as well as general editing and debugging features.
Programmers – The latest information on Microchip programmers. These include the device (production) programmers MPLAB REAL ICE in-circuit emulator, MPLAB ICD 3 in-circuit debugger, MPLAB PM3 and development (nonproduction) programmers MPLAB ICD 2 in-circuit debugger, PICSTART and 3.
Starter/Demo Boards – These include MPLAB Starter Kit boards, PICDEM demo boards, and various other evaluation boards.
®
IDE/MPLAB X IDE – The latest information on Microchip MPLAB IDE,
®
Integrated Development Environment, or MPLAB X IDE, the open
Preface
®
Plus and PICkit 2

THE MICROCHIP WEB SITE

Microchip provides online support via our web site at http://www.microchip.com. This web site is used as a means to make files and information easily available to customers. Accessible by using your favorite Internet browser, the web site contains the following information:
Product Support – Data sheets and errata, application notes and sample programs, design resources, user’s guides and hardware support documents, latest software releases and archived software
General Technical Support – Frequently Asked Questions (FAQs), technical support requests, online discussion groups, Microchip consultant program member listing
Business of Microchip – Product selector and ordering guides, latest Microchip press releases, listing of seminars and events, listings of Microchip sales offices, distributors and factory representatives
2012 Microchip Technology Inc. DS52071B-page 15
MPLAB® XC16 C Compiler User’s Guide

MICROCHIP FORUMS

Microchip provides additional online support via our web forums at http://www.microchip.com/forums. Currently available forums are:
• Development Tools
•8-bit PIC MCUs
• 16-bit PIC MCUs
• 32-bit PIC MCUs

CUSTOMER SUPPORT

Users of Microchip products can receive assistance through several channels:
• Distributor or Representative
• Local Sales Office
• Field Application Engineer (FAE)
• Technical Support Customers should contact their distributor, representative or field application engineer
(FAE) for support. Local sales offices are also available to help customers. A listing of sales offices and locations is included in the back of this document. See our web site for a complete, up-to-date listing of sales offices.
Technical support is available through the web site at http://support.microchip.com. Documentation errors or comments may be emailed to docerrors@microchip.com.

DOCUMENT REVISION HISTORY

Revision A (April 2012)
Initial release of this document.
Revision B (July 2012)
Chapter 2. “Common C Interface” was added.
• Figure 3-1 "Software Development Tools Data Flow" was updated.
• Table 3-16 "Linking Options" now includes the -fill option.
• Added the -pack_upper_byte qualifier information in
Section 6.10.4 “__pack_upper_byte Type Qualifier” and Section 7.8 “Packing Data Stored in Flash”.
• Added DBRPAG/PSVP AG preservation bullet under Section 10.8 “Funct ion C all
Conventions”
• Fixed code syntax in Section 11.4 “Specifying the Interrupt Vector”.
• Fixed Eval Edition descri pti on unde r Chapter 15. “Optimizations”.
• Added "volatile" to SFR registers in Appendix F . “Built-in Functions”.
• Added built-in functions __builtin_write_CRYOTP and __builtin_write_NVM_secure in Appendix F. “Built-in Functions”.
DS52071B-page 16 2012 Microchip Technology Inc.

Chapter 1. Compiler Overview

1.1 INTRODUCTION

The MPLAB XC16 C compiler is defined and described in the following topics:
• Device Description
• Compiler Description and Documentation
• Compiler and Other Development Tools

1.2 DEVICE DESCRIPTION

The MPLAB XC16 C compiler fully supports all Microchip 16-bit devices:
®
• The dsPIC required in digital signal processor (DSP) applications with standard microcon­troller (MCU) features need ed for embedded app li cat ion s.
• The PIC24 family of MCUs are identical to the dsPIC DSCs with the exception that they do not have the digital signal controller module or that subset of instructions. They are a subset, and are high-performance MCUs intended for applications that do not require the power of the DSC capabilities.
family of digital signal controllers combines the high performance
MPLAB® XC16 C COMPILER
USER’S GUIDE

1.3 COMPILER DESCRIPTION AND DOCUMENTATION

The MPLAB XC16 C compiler is a full-featured, optimizing compiler that translates standard ANSI C programs into 16-bit device assembly language source. The compiler also supports many command-line options and language extensions that allow full access to the 16-bit device hardware capabilities, and affords fine control of the com­piler code generator.
The compiler is a port of the GNU Compiler Collection (GCC) compiler from the Free Software Foundation
This key features of the compiler are discussed in the following sections.

1.3.1 ANSI C Standard

The compiler is a fully validated compiler that conforms to the ANSI C standard as defined by the ANSI specification (ANSI x3.159-1989) and described in Kernighan and Ritchie’s The C Programming Language (second edition). The ANSI standard includes extensions to the original C definition that are now standard features of the language. These extensions enhance portability and offer increased capability. In addition, language extensions for dsPIC DSC embedded-control applications are included.

1.3.2 Optimization

The compiler uses a set of sophisticated optimization passes that employ many advanced techniques for generating efficient, compact code from C source. The optimization passes include high-level optimizations that are applicable to any C code, as well as 16-bit device-speci fic op timi zat ion s that take adva ntag e of the particular features of the device architecture.
For more on optimizations, see Chapter 15. “Optimizations”.
2012 Microchip Technology Inc. DS52071B-page 17
MPLAB® XC16 C Compiler User’s Guide

1.3.3 ANSI Standard Library Support

The compiler is distributed with a complete ANSI C standard library. All library functions have been validated, and conform to the ANSI C library standard. The library includes functions for string manipulation, dynamic memory allocation, data conversion, time­keeping and math functions (trigonometric, exponential and hyperbolic). The standard I/O functions for file handling are also included, and, as distributed, they support full access to the host file system using the command-line simulator. The fully functional source code for the low-level file I/O functions is provided in the compiler distribution, and may be used as a starting point for applications that require this capability.

1.3.4 Flexible Memory Models

The compiler supports both large and small code and data models. The small code model takes advantage of more efficient forms of call and branch instructions, while the small data model supports the use of compact instructions for accessing data in SFR space.
The compiler supports two models for accessing constant data. The “constants in data” model uses d ata memory, which is initiali ze d b y t h e ru n -t ime li brary. The “constants in code” model uses program memory, which is accessed through the Program Space Visibility (PSV) window.

1.3.5 Attributes and Qualifiers

The compiler keyword __attribute__ allows you to specify special attributes of variables, structure fields or functions. This keyword is followed by an attribute specification inside double parentheses, as in:
int last_mode __attribute__ ((persistent));
In other compilers, qualifiers are used to create qualified types:
persistent int last_mode;
The MPLAB XC16 C Compiler does have some non-standard qualifiers described in Section 6.10 “Compiler-Specific type Qualifiers”.
Generally speaking, qualifiers indicate how an object should be accessed, whereas attributes indicate where objects are to be located. Attributes also have many other purposes.

1.3.6 Compiler Driver

The compiler includes a powerful command-line driver program. Using the driver program, application programs can be compiled, assembled and linked in a single step.

1.3.7 Documentation

The compiler is supported under both the MPLAB IDE v8.xx and above, and the MPLAB X IDE. For simplicity, both IDEs are referred to throughout the book as simply MPLAB IDE.
Features that are unique to specific devices, and therefore specific compilers, are noted with a “DD” icon next to the section and text that identifies the specific devices to which the information applies (see the Preface).
DS52071B-page 18 2012 Microchip Technology Inc.

1.4 COMPILER AND OTHER DEVELOPMENT TOOLS

The compiler works with many other Microchip tools including:
• MPLAB XC16 Assembler and Linker - see the MPLAB Assembler, Linker and Util- ities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
• MPLAB IDE v8.xx and MPLAB X IDE
• The MPLAB SIM Simulator and MPLAB X Simulator
• All Microchip debug tools and programmers
• Demonstration boards and Starter kits that support 16-bit devices
Compiler Overview
2012 Microchip Technology Inc. DS52071B-page 19
MPLAB® XC16 C Compiler User’s Guide
NOTES:
DS52071B-page 20 2012 Microchip Technology Inc.

Chapter 2. Common C Interface

2.1 INTRODUCTION

The Common C Interface (CCI) is available with all MPLAB XC C compilers and is designed to enhance code portability between these compilers. For example, CCI-conforming code would make it easier to port from a PIC18 MCU using the MPLAB XC8 C compiler to a PIC24 MCU using the MPLAB XC16 C compiler.
The CCI assumes that your source code already conforms to the ANSI Standard. If you intend to use the CCI, it is your responsibility to write code that conforms. Legacy proj­ects will need to be migrated to achieve conformance. A compiler option must also be set to ensure that the operation of the compiler is consistent with the interface when the project is built.
The following topics are examined in this chapter of the MPLAB XC16 C Compiler User’s Guide:
• ANSI Standard Extensions
• Using the CCI
• ANSI Standard Refinement
• ANSI Standard Extensions
MPLAB® XC16 C COMPILER
USER’S GUIDE

2.2 BACKGROUND – THE DESIRE FOR PORTABLE CODE

All programmers want to write portable source code. Portability means that the same source code can be compiled and run in a different
execution environment than that for which it was written. Rarely can code be one hun­dred percent portable, but the more tolerant it is to change, the less time and effort it takes to have it running in a new environment.
Embedded engineers typically think of code portability as being across target devices, but this is only part of the situation. The same code could be compiled for the same target but with a different compiler. Differences between those compilers might lead to the code failing at compile time or runtime, so this must be considered as well.
Y ou may only write code for one target device and only use one brand of compiler, but if there is no regulation of the compiler’s operation, simply updating your compiler version may change your code’s behavior.
Code must be portable across targets, tools, and time to be truly flexible. Clearly, this portability cannot be achieved by the programmer alone, since the com-
piler vendors can base their products on different technologies, implement different fea­tures and code syntax, or improve the way their product works. Many a great compiler optimization has broken many an unsuspecting project.
Standards for the C language have been developed to ensure that change is managed and code is more portable. The American National Standards Institute (ANSI) pub­lishes standards for many disciplines, including programming languages. The ANSI C Standard is a universally adopted standard for the C programming language.
2012 Microchip Technology Inc. DS52071B-page 21
MPLAB® XC16 C Compiler User’s Guide

2.2.1 The ANSI Standard

The ANSI C Standard has to reconcile two opposing goals: freedom for compilers ven­dors to target new devices and improve code generation, with the known functional operation of source code for programmers. If both goals can be met, source code can be made portable.
The standard is implemented as a set of rules which detail not only the syntax that a conforming C program must follow, but the semantic rules by which that program will be interpreted. Thus, for a compiler to conform to the standard, it must ensure that a conforming C program functions as described by the standard.
The standard describes implementation, the set of tools and the runtime environment on which the code will run. If any of these change, e.g., you build for, and run on, a dif­ferent target device, or if you update the version of the compiler you use to build, then you are using a different implementation.
The standard uses the term behavior to mean the external appearance or action of the program. It has nothing to do with how a program is encoded.
Since the standard is trying to achieve goals that could be construed as conflicting, some specifications appear somewhat vague. For example, the standard states that an int type must be able to hold at least a 16-bit value, but it does not go as far as saying what the size of an int actually is; and the action of right-shifting a signed integer can produce different results on different implementations; yet, these different results are still ANSI C compliant.
If the standard is too strict, device architectures may not allow the compiler to conform. But, if it is too weak, programmers would see wildly differing results within different compilers and architectures, and the standard would loose its effectiveness.
The standard organizes source code whose behavior is not fully defined into groups that include the following behaviors:
Implementation-defined behavior
This is unspecified behavior where each implementation documents how the choice is made.
Unspecified behavior The standard provides two or more possibilities and imposes no further requirements
on which possibility is chos en in any part ic ula r ins ta nc e. Undefined behavior This is behavior for which the standard imposes no requirements.
1
Code that strictly conforms to the standard does not produce output that is dependent on any unspecified, undefined, or implementation-defined behavior. The size of an int, which we used as an example earlier, falls into the category of behavior that is defined by implementation. That is to say, the size of an int is defined by which com­piler is being used, how that compiler is being used, and the device that is being tar­geted.
All the MPLAB XC compilers conform to the ANS X3.159-1989 Standard for program­ming languages (with the exception of the XC8 compiler’s inability to allow recursion, as mentioned in the footnote). This is commonly called the C89 Standard. Some fea­tures from the later standard, C99, are also supported.
1. Case in point: The mid-range PIC® microcontrollers do not have a data stack. Because a compiler
targeting this device cannot implement recursion, it (strictly speaking) cannot conform to the ANSI C Standard. This example illustrate a situation in which the standard is too strict for mid-range devices and tools.
DS52071B-page 22 2012 Microchip Technology Inc.
Common C Interface
For freestanding implementations – or for what we typically call embedded applications – the standard allows non-standard extensions to the language, but obviously does not enforce how they are specified or how they work. When working so closely to the device hardware, a programmer needs a means of specifying device setup and inter­rupts, as well as utilizing the often complex world of small-device memory architectures. This cannot be offered by the standard in a consistent way.
While the ANSI C Standard provides a mutual understanding for programmers and compiler vendors, programmers need to consider the implementation-defined behavior of their tools and the probability that they may need to use extensions to the C language that are non-standard. Both of these circumstances can have an impact on code por­tability.

2.2.2 The Common C Interface

The Common C Interface (CCI) supplements the ANSI C Standard and makes it easier for programmers to achieve consistent outcomes on all Microchip devices when using any of the MPLAB XC C compilers.
It delivers the following improvements, all designed with portability in mind.
Refinement of the ANSI C Standard The CCI documents specific behavior for some code in which actions are implemen-
tation-defined behavior under the ANSI C Standard. For example, the result of right-shifting a signed integer is fully defined by the CCI. Note that many implementation-defined items that closely couple with device characteristics, such as the size of an int, are not defined by the CCI.
Consistent syntax for non-standard extensions The CCI non-standard extensions are mostly implemented using keywords with a uni-
form syntax. They replace keywords, macros and attributes that are the native com­piler implementation. The interpretation of the keyword may differ across each com­piler, and any arguments to the keywords may be device specific.
Coding guidelines The CCI may indicate advice on how code should be written so that it can be ported
to other devices or compilers. While you may choose not to follow the advice, it will not conform to the CCI.
2012 Microchip Technology Inc. DS52071B-page 23
MPLAB® XC16 C Compiler User’s Guide

2.3 USING THE CCI

The CCI allows enhanced portability by refining implementation-defined behavior and standardizing the syntax for extensions to the language.
The CCI is something you choose to follow and put into effect, thus it is relevant for new projects, although you may choose to modify existing projects so they conform.
For your project to conform to the CCI, you must do the following things.
Enable the CCI Select the MPLAB IDE widget Use CCI Syntax
command-line option that is equivalent. Include <xc.h> in every module
Some CCI features are only enabled if this header is seen by the compiler. Ensure ANSI compliance
Code that does not conform to the ANSI C Standard does not confirm to the CCI. Observe refinements to ANSI by the CCI
Some ANSI implementation-defined behavior is defined explicitly by the CCI. Use the CCI extensions to the language
Use the CCI extensions rather than the native language extensions
in your project, or use the
The next sections detail specific items associated with the CCI. These items are seg­regated into those that refine the standard, those that deal with the ANSI C Standard extensions, and other miscellaneous compiler options and usage. Guidelines are indi­cated with these item s.
If any implementation-defined behavior or any non-standard extension is not discussed in this document, then it is not part of the CCI. For example, GCC case ranges, label addresses and 24-bit short long types are not part of the CCI. Programs which use these features do not conform to the CCI. The compiler may issue a warning or error to indicate when you use a non-CCI feature and the CCI is enabled.
DS52071B-page 24 2012 Microchip Technology Inc.

2.4 ANSI STANDARD REFINEMENT

The following topics describe how the CCI refines the implementation-defined behaviors outlined in the ANSI C Standard.

2.4.1 Source File Encoding

Under the CCI, a source file must be written using characters from the 7-bit ASCII set. Lines may be terminated using a line feed ('\n') or carriage return ('\r') that is immedi­ately followed by a line feed. Escaped characters may be used in character constants or string literals to represent extended characters not in the basic character set.
2.4.1.1 EXAMPLE
The following shows a string constant being defined that uses escaped characters.
const char myName[] = "Bj\370rk\n";
2.4.1.2 DIFFERENCES
All compilers have used this character set.
2.4.1.3 MIGRATION TO THE CCI
No action required.
Common C Interface

2.4.2 The Prototype for main

The prototype for the main() function is
int main(void);
2.4.2.1 EXAMPLE
The following shows an example of how main() might be defined
int main(void) {
while(1)
process();
}
2.4.2.2 DIFFERENCES
The 8-bit compilers used a void return type for this function.
2.4.2.3 MIGRATION TO THE CCI
Each program has one definition for the main() function. Confirm the return type for main() in all projects previously compiled for 8-bit targets.

2.4.3 Header File Specification

Header file specifications that use directory separators do not conform to the CCI.
2.4.3.1 EXAMPLE
The following example shows two confor mi ng incl ude dir ect ive s.
#include <usb_main.h> #include "global.h"
2012 Microchip Technology Inc. DS52071B-page 25
MPLAB® XC16 C Compiler User’s Guide
2.4.3.2 DIFFERENCES Header file specifications that use directory separators have been allowed in previous
versions of all compilers. Compatibility problems arose when Windows-style separa­tors “\” were used and the code compiled under other host operating systems. Under the CCI, no directory specifiers should be used.
2.4.3.3 MIGRATION TO THE CCI Any #include directiv es that use di rectory sep arators in the header fil e specifica tions
should be changed. Remove all but the header file name in the directive. Add the direc­tory path to the compiler’s include search path or MPLAB IDE equivalent. This will force the compiler to search the directories specified with this option.
For example, the following code:
#include <inc/lcd.h>
should be changed to:
#include <lcd.h>
and the path to the inc directory added to the compiler’s header search path in your MPLAB IDE project properties, or on the command-line as follows:
-Ilcd

2.4.4 Include Search Paths

When you include a header file under the CCI, the file should be discoverable in the paths searched by the compiler detailed below.
For any header files specified in angle bracket delimiters < >, the search paths should be those specified by -I options (or the equivalent MPLAB IDE option), then the stan­dard compiler include directories. The -I options are searched in the order in which they are specified.
For any file specified in quote characters " ", the search paths should first be the cur­rent working directory . In the case of an MPLAB X project, the current working directory is the directory in which the C source file is located. If unsuccessful, the search paths should be the same directories searched when the header files is specified in angle bracket delimiters.
Any other options to specify search paths for header files do not conform to the CCI.
2.4.4.1 EXAMPLE If including a header file as in the following directive
#include "myGlobals.h"
The header file should be locatable in the current working directory, or the paths spec­ified by any -I options, or the standard compiler directories. If it is located elsewhere, this does not conform to the CCI.
2.4.4.2 DIFFERENCES The compiler operation under the CCI is not changed. This is purely a coding guide line.
2.4.4.3 MIGRATION TO THE CCI Remove any option that specifies header file search paths other than the -I option (or
the equivalent MPLAB IDE option), and use the -I option in place of this. Ensure the header file can be found in the directories specified in this section.
DS52071B-page 26 2012 Microchip Technology Inc.
Common C Interface

2.4.5 The number of Significant Initial Characters in an Identi fier

At least the first 255 characters in an identifier (internal and external) are significant. This extends upon the requirement of the ANSI C Standard which states a lower num­ber of significant characters are used to identify an object.
2.4.5.1 EXAMPLE
The following example shows two poorly named variables, but names which are considered unique under the CCI.
int stateOfPortBWhenTheOperatorHasSelectedAutomaticModeAndMotorIsRunningFast; int stateOfPortBWhenTheOperatorHasSelectedAutomaticModeAndMotorIsRunningSlow;
2.4.5.2 DIFFERENCES
Former 8-bit compilers used 31 significant characters by default, but an option allowed this to be extended.
The 16- and 32-bit compilers did not impose a limit on the number of significant char­acters.
2.4.5.3 MIGRATION TO THE CCI
No action required. You may take advantage of the less restrictive naming scheme.

2.4.6 Sizes of Types

The sizes of the basic C types, for example char, int and long, are not fully defined by the CCI. These types, by design, reflect the size of registers and other architectural features in the target device. They allow the device to efficiently access objects of this type. The ANSI C Standard does, however, indicate minimum requirements for these types, as specified in <limits.h>.
If you need fixed-size types in your project, use the types defined in <stdint.h>, e.g., uint8_t or int16_t. These types are consistently defined across all XC compilers, even outside of the CCI.
Essentially, the C language offers a choice of two groups of types: those that offer sizes and formats that are tailored to the device you are using; or those that have a fixed size, regardless of the target.
2.4.6.1 EXAMPLE
The following example shows the definition of a variable, native, whose size will allow efficient access on the target device; and a variable, fixed, whose size is cle a rl y i n di ­cated and remains fixed, even though it may not allow efficient access on every device.
int native; int16_t fixed;
2.4.6.2 DIFFERENCES
This is consistent with previous types implemented by the compiler.
2.4.6.3 MIGRATION TO THE CCI
If you require a C type that has a fixed size, regardless of the target device, use one of the types defined by <stdint.h>.
2012 Microchip Technology Inc. DS52071B-page 27
MPLAB® XC16 C Compiler User’s Guide

2.4.7 Plain char Types

The type of a plain char is unsigned char. It is generally recommended that all def­initions for the char type explicitly state the signedness of the object.
2.4.7.1 EXAMPLE The following example
char foobar;
defines an unsigned char object called foobar.
2.4.7.2 DIFFERENCES The 8-bit compilers have always treated plain char as an unsigned type.
The 16- and 32-bit compilers used signed char as the default plain char type. The
-funsigned-char option on those compilers changed the default type to be unsigned char.
2.4.7.3 MIGRATION TO THE CCI Any definition of an object defined as a plain char and using the 16- or 32-bit compilers
needs review. Any plain char that was intended to be a signed quantity should be replaced with an explicit definition, for example.
signed char foobar;
You may use the -funsigned-char option on XC16/32 to change the type of plain char, but since this option is not supported on XC8, the code is not strictly conforming.

2.4.8 Signed Integer Representation

The value of a signed integer is determined by taking the two’s complement of the inte­ger.
2.4.8.1 EXAMPLE The following shows a variable, test, that is assigned the value -28 decimal.
signed char test = 0xE4;
2.4.8.2 DIFFERENCES All compilers have represented signed integers in the way described in this section.
2.4.8.3 MIGRATION TO THE CCI No action required.
DS52071B-page 28 2012 Microchip Technology Inc.
Common C Interface

2.4.9 Integer conversion

When converting an integer type to a signed integer of insufficient size, the original value is truncated from the most-significant bit to accommodate the target size.
2.4.9.1 EXAMPLE
The following shows an assignment of a value that will be truncated.
signed char destination; unsigned int source = 0x12FE; destination = source;
Under the CCI, the value of destination after the alignment will be -2 (i.e., the bit pattern 0xFE).
2.4.9.2 DIFFERENCES
All compilers have performed integer conversion in an identical fashion to that described in this section.
2.4.9.3 MIGRATION TO THE CCI
No action required.

2.4.10 Bit-wise Operations on Signed Values

Bitwise operations on signed values act on the two’s complement representation, including the sign bit. See also Section 2.4.11 “Right-shifting Signed Values”.
2.4.10.1 EXAMPLE
The following shows an example of a negative quantity involved in a bitwise AND oper­ation.
signed char output, input = -13; output = input & 0x7E;
Under the CCI, the value of output after the assignment will be 0x72.
2.4.10.2 DIFFERENCES
All compilers have performed bitwise operations in an identical fashion to that described in this section.
2.4.10.3 MIGRATION TO THE CCI
No action required.

2.4.11 Right-shifting Signed Values

Right-shifting a signed value will involve sign extension. This will preserve the sign of the original value.
2.4.11.1 EXAMPLE
The following shows an example of a negative quantity involved in a bitwise AND operation.
signed char input, output = -13; output = input >> 3;
Under the CCI, the value of output after the assignment will be -2 (i.e., the bit pattern 0xFE).
2012 Microchip Technology Inc. DS52071B-page 29
MPLAB® XC16 C Compiler User’s Guide
2.4.11.2 DIFFERENCES All compilers have performed right shifting as described in this section.
2.4.11.3 MIGRATION TO THE CCI No action required.

2.4.12 Conversion of Union Member Accessed Using Member With Different Type

If a union defines several members of different types and you use one member identi­fier to try to access the contents of another (whether any conversion is applied to the result) is implementation-defined behavior in the standard. In the CCI, no conversion is applied and the bytes of the union object are interpreted as an object of the type of the member being accessed, without regard for alignment or other possible invalid condi­tions.
2.4.12.1 EXAMPLE
The following shows an example of a union defining several members.
union {
signed char code; unsigned int data; float offset;
} foobar;
Code that attempts to extract offset by reading data is not guaranteed to read the correct value.
float result; result = foobbar.data;
2.4.12.2 DIFFERENCES
All compilers have not converted union members accessed via other members.
2.4.12.3 MIGRATION TO THE CCI
No action required.

2.4.13 Default Bit-field int Type

The type of a bit-field specified as a plain int will be identical to that of one defined using unsigned int. This is quite different to other objects where the types int, signed and signed int are synonymous. It is recommended that the signedness of the bit-field be explicitly stated in all bit-field definitions.
2.4.13.1 EXAMPLE
The following shows an example of a structure tag containing bit-fields which are unsigned integers and with the size specified.
struct OUTPUTS {
int direction :1; int parity :3; int value :4;
};
DS52071B-page 30 2012 Microchip Technology Inc.
Common C Interface
2.4.13.2 DIFFERENCES The 8-bit compilers have previously issued a warning if type int was used for bit-fields,
but would implement the bit-field with an unsigned int type. The 16- and 32-bit compilers have implemented bit-fields defined using int as having
a signed int type, unless the option -funsigned-bitfields was specified.
2.4.13.3 MIGRATION TO THE CCI Any code that defines a bit-field with the plain int type should be reviewed. If the inten-
tion was for these to be signed quantities, then the type of these should be changed to
signed int, for example, in:
struct WAYPT {
int log :3; int direction :4;
};
the bit-field type should be changed to signed int, as in:
struct WAYPT {
signed int log :3; signed int direction :4;
};

2.4.14 Bit-fields Straddling a Storage Unit Boundary

Whether a bit-field can straddle a storage unit boundary is implementation-defined behavior in the standard. In the CCI, bit-fields will not straddle a storage unit boundary; a new storage unit will be allocated to the structure, and padding bits will fill the gap.
Note that the size of a storage unit differs with each compiler as this is based on the size of the base data type (e.g., int) from which the bit-field type is derived. On 8-bit compilers this unit is 8-bits in size; for 16-bit compilers, it is 16 bits; and for 32-bit com­pilers, it is 32 bits in size.
2.4.14.1 EXAMPLE The following shows a structure containing bit-fields being defined.
struct { unsigned first : 6; unsigned second :6; } order;
Under the CCI and using XC8, the storage allocation unit is byte sized. The bit-field second, will be allocated a new storage unit since there are only 2 bits remaining in the first storage unit in which first is allocated. The size of this structure, order, will be 2 bytes.
2.4.14.2 DIFFERENCES This allocation is identical with that used by all previous compilers.
2.4.14.3 MIGRATION TO THE CCI No action required.

2.4.15 The Allocation Order of Bits-field

The memory ordering of bit-fields into their storage unit is not specified by the ANSI C Standard. In the CCI, the first bit defined will be the least significant bit of the storage unit in which it will be allocated.
2012 Microchip Technology Inc. DS52071B-page 31
MPLAB® XC16 C Compiler User’s Guide
2.4.15.1 EXAMPLE
The following shows a structure containing bit-fields being defined.
struct { unsigned lo : 1; unsigned mid :6; unsigned hi : 1; } foo;
The bit-field lo will be assigned the least significant bit of the storage unit assigned to the structure foo. The bit-field mid will be assigned the next 6 least significant bits, and hi, the most significant bit of that same storage unit byte.
2.4.15.2 DIFFERENCES
This is identical with the previous operation of all compilers.
2.4.15.3 MIGRATION TO THE CCI
No action required.

2.4.16 The NULL macro

The NULL macro is defined in <stddef.h>; however, its definition is implementa­tion-defined behavior. Under the CCI, the definition of NULL is the expression (0).
2.4.16.1 EXAMPLE
The following shows a pointer being assigned a null pointer constant via the NULL macro.
int * ip = NULL;
The value of NULL, (0), is implicitly cast to the destination type.
2.4.16.2 DIFFERENCES
The 32-bit compilers previously assigned NULL the expression ((void *)0).
2.4.16.3 MIGRATION TO THE CCI
No action required.

2.4.17 Floating-point sizes

Under the CCI, floating-point types must not be smaller than 32 bits in size.
2.4.17.1 EXAMPLE
The following shows the definition for outY, which will be at least 32-bit in size.
float outY;
2.4.17.2 DIFFERENCES
The 8-bit compilers have allowed the use of 24-bit float and double types.
2.4.17.3 MIGRATION TO THE CCI
When using 8-bit compilers, the float and double type will automatically be made 32 bits in size once the CCI mode is enabled. Review any source code that may have assumed a float or double type and may have been 24 bits in size.
No migration is required for other compilers.
DS52071B-page 32 2012 Microchip Technology Inc.

2.5 ANSI STANDARD EXTENSIONS

The following topics describe how the CCI provides device-specific extensions to the standard.

2.5.1 Generic Header File

A single header file <xc.h> must be used to declare all compiler- and device-specific types and SFRs. You must include this file into every module to conform with the CCI. Some CCI definitions depend on this header being seen.
2.5.1.1 EXAMPLE The following shows this header file being included, thus allowing conformance with the
CCI, as well as allowing access to SFRs.
#include <xc.h>
2.5.1.2 DIFFERENCES Some 8-bit compilers used <htc.h> as the equivalent header. Previous versions of
the 16- and 32-bit compilers used a variety of headers to do the same job.
2.5.1.3 MIGRATION TO THE CCI Change:
#include <htc.h>
used previously in 8-bit compiler code, or family-specific header files as in the following examples:
#include <p32xxxx.h> #include <p30fxxxx.h> #include <p33Fxxxx.h> #include <p24Fxxxx.h> #include "p30f6014.h"
to:
#include <xc.h>
Common C Interface

2.5.2 Absolute addressing

Variables and functions can be placed at an absolute address by using the __at() construct.qualifier Note that XC16/32 may require the variable or function to be placed in a special section for absolute addressing to work. Stack-based (auto and parame­ter) varia bles cannot use the __at() specifier.
2.5.2.1 EXAMPLE The following shows two variables and a function being made absolute.
int scanMode __at(0x200); const char keys[] __at(123) = { ’r’, ’s’, ’u’, ’d’};
int modify(int x) __at(0x1000) {
return x * 2 + 3;
}
2.5.2.2 DIFFERENCES The 8-bit compilers have used an @ symbol to specify an absolute address.
The 16- and 32-bit compilers have used the address attribute to specify an object’s address.
2012 Microchip Technology Inc. DS52071B-page 33
MPLAB® XC16 C Compiler User’s Guide
2.5.2.3 MIGRATION TO THE CCI
Avoid making objects and functions absolute if possible. In XC8, change absolute object definitions such as the following example:
int scanMode @ 0x200;
to:
int scanMode __at(0x200);
In XC16/32, change code such as:
int scanMode __attribute__(address(0x200)));
to:
int scanMode __at(0x200);
2.5.2.4 CAVEATS
If the __at() and __section() specifiers are both applied to an object when using XC8, the __section() specifier is currently ignored.

2.5.3 Far Objects and Functions

The __far qualifier may be used to indicate that variables or functions may be located in ‘far memory’. Exactly what constitutes far memory is dependent on the target device, but it is typically memory that requires more complex code to access. Expressions involving far-qualified objects may generate slower and larger code.
Use the native keywords discussed in the Differences section to look up information on the semantics of this qualifier.
Some devices may not have such memory implemented, in which case, use of this qualifier will be ignored. Stack-based (auto and parameter) variables cannot use the __far specifier.
2.5.3.1 EXAMPLE
The following shows a variable and function qualified using __far.
__far int serialNo; __far int ext_getCond(int selector);
2.5.3.2 DIFFERENCES
The 8-bit compilers have used the qualifier far to indicate this meaning. Functions could not be qualified as far.
The 16-bit compilers have used the far attribute with both variables and functions. The 32-bit compilers have used the far attribute with functions, only.
DS52071B-page 34 2012 Microchip Technology Inc.
Common C Interface
2.5.3.3 MIGRATION TO THE CCI For 8-bit compilers, change any occurrence of the far qualifier, as in the following
example:
far char template[20];
to __far, i.e., __far char template[20]; In the 16- and 32-bit compilers, change any occurrence of the far attribute, as in the
following
void bar(void) __attribute__ ((far)); int tblIdx __attribute__ ((far));
to
void __far bar(void); int __far tblIdx;
2.5.3.4 CAVEATS None.

2.5.4 Near Objects

The __near qualifier may be used to indicate that variables or functions may be located in ‘near memory’. Exactly what constitutes near memory is dependent on the target device, but it is typically memory that can be accessed with less complex code. Expressions involving near-qualified objects may be faster and result in smaller code.
Use the native keywords discussed in the Differences section to look up information on the semantics of this qualifier.
Some devices may not have such memory implemented, in which case, use of this qualifier will be ignored. Stack-based (auto and parameter) variables cannot use the __near specifier.
2.5.4.1 EXAMPLE The following shows a variable and function qualified using __near.
__near int serialNo; __near int ext_getCond(int selector);
2.5.4.2 DIFFERENCES The 8-bit compilers have used the qualifier near to indicate this meaning. Functions
could not be qualified as near. The 16-bit compilers have used the near attribute with both variables and functions. The 32-bit compilers have used the near attribute for functions, only.
2012 Microchip Technology Inc. DS52071B-page 35
MPLAB® XC16 C Compiler User’s Guide
2.5.4.3 MIGRATION TO THE CCI
For 8-bit compilers, change any occurrence of the near qualifier, as in the following example:
near char template[20];
to __near, i.e., __near char template[20]; In 16- and 32-bit compilers, change any occurrence of the near attribute, as in the fol-
lowing
void bar(void) __attribute__ ((near)); int tblIdx __attribute__ ((near));
to
void __near bar(void); int __near tblIdx;
2.5.4.4 CAVEATS
None.

2.5.5 Persistent Objects

The __persistent qualifier may be used to indicate that variables should not be cleared by the runtime startup code.
Use the native keywords discussed in the Differences section to look up information on the semantics of this qualifier.
2.5.5.1 EXAMPLE
The following shows a variable qualified using __persistent.
__persistent int serialNo;
2.5.5.2 DIFFERENCES
The 8-bit compilers have used the qualifier, persistent, to indicate this meaning. The 16- and 32-bit compilers have used the persistent attribute with variables to
indicate they were not to be cleared.
2.5.5.3 MIGRATION TO THE CCI
With 8-bit compilers, change any occurrence of the persistent qualifier, as in the fol­lowing example:
persistent
char template[20];
to __persistent, i.e., __persistent char template[20]; For the 16- and 32-bit compilers, change any occurrence of the persistent attribute,
as in the following
int tblIdx __attribute__ ((persistent));
to
int __persistent tblIdx;
2.5.5.4 CAVEATS
None.
DS52071B-page 36 2012 Microchip Technology Inc.
Common C Interface

2.5.6 X and Y Data Objects

The __xdata and __ydata qualifiers may be used to indicate that variables may be located in special memory regions. Exactly what constitutes X and Y memory is depen­dent on the target device, but it is typically memory that can be accessed independently on separate buses. Such memory is often required for some DSP instructions.
Use the native keywords discussed in the Differences section to look up information on the semantics of these qualifiers.
Some devices may not have such memory implemented; in which case, use of these qualifiers will be ignored.
2.5.6.1 EXAMPLE The following shows a variable qualified using __xdata, as well as another variable
qualified with __ydata.
__xdata char data[16]; __ydata char coeffs[4];
2.5.6.2 DIFFERENCES The 16-bit compilers have used the xmemory and ymemory space attribute with
variables. Equivalent specifiers have never been defined for any other compiler.
2.5.6.3 MIGRATION TO THE CCI For 16-bit compilers, change any occurrence of the space attributes xmemory or
ymemory, as in the following example:
char __attribute__((space(xmemory)))template[20];
to __xdata, or __ydata, i.e., __xdata char template[20];
2.5.6.4 CAVEATS None.

2.5.7 Banked Data Objects

The __bank(num) qualifier may be used to indicate that variables may be located in a particular data memory bank. The number, num, represents the bank number. Exactly what constitutes banked memory is dependent on the target device, but it is typically a subdivision of data memory to allow for assembly instructions with a limited address width field.
Use the native keywords discussed in the Differences section to look up information on the semantics of these qualifiers.
Some devices may not have banked data memory implemented, in which case, use of this qualifier will be ignored. The number of data banks implemented will vary from one device to another.
2.5.7.1 EXAMPLE The following shows a variable qualified using __bank().
__bank(0) char start; __bank(5) char stop;
2012 Microchip Technology Inc. DS52071B-page 37
MPLAB® XC16 C Compiler User’s Guide
2.5.7.2 DIFFERENCES
The 8-bit co mpile rs hav e used the fo ur qua lifie rs bank0, bank1, bank2 and bank3 to indicate the same, albeit more limited, memory placement.
Equivalent specifiers have never been defined for any other compiler.
2.5.7.3 MIGRATION TO THE CCI
For 8-bit compilers, change any occurrence of the bankx qualifiers, as in the following example:
bank2 int logEntry;
to __bank(, i.e., __bank(2) int logEntry;
2.5.7.4 CAVEATS
None.

2.5.8 Alignment of Objects

The __align(alignment) specifier may be used to indicate that variables must be aligned on a memory address that is a multiple of the alignment specified. The align­ment term must be a power of two. Positive values request that the object’s start address be aligned; negative values imply the object’s end address be aligned.
Use the native keywords discussed in the Differences section to look up information on the semantics of this specifier.
2.5.8.1 EXAMPLE
The following shows variables qualified using __align() to ensure they end on an address that is a multiple of 8, and start on an address that is a multiple of 2, respectively.
__align(-8) int spacer; __align(2) char coeffs[6];
2.5.8.2 DIFFERENCES
An alignment feature has never been implemented on 8-bit compilers. The 16- and 32-bit compilers used the aligned attribute with variables.
2.5.8.3 MIGRATION TO THE CCI
For 16- and 32-bit compilers, change any occurrence of the aligned attribute, as in the following example:
char __attribute__((aligned(4)))mode;
to __align, i.e., __align(4) char mode;
2.5.8.4 CAVEATS
This feature is not yet implemented on XC8.
DS52071B-page 38 2012 Microchip Technology Inc.
Common C Interface

2.5.9 EEPROM Objects

The __eeprom qualif ier may be us ed to indi cate that variable s should be positio ned in EEPROM.
Use the native keywords discussed in the Differences section to look up information on the semantics of this qualifier.
Some devices may not implement EEPROM. Use of this qualifier for such devices will generate a warning. Stack-based (auto and parameter) variables cannot use the __eeprom specifier.
2.5.9.1 EXAMPLE The following shows a variable qualified using __eeprom.
__eeprom int serialNos[4];
2.5.9.2 DIFFERENCES The 8-bit compilers have used the qualifier, eeprom, to indicate this meaning for some
devices. The 16-bit compilers have used the space attribute to allocate variables to the memory
space used for EEPROM.
2.5.9.3 MIGRATION TO THE CCI For 8-bit compilers, change any occurrence of the eeprom qualifier, as in the following
example:
eeprom
to __eeprom, i.e., __eeprom char title[20]; For 16-bit compilers, change any occurrence of the eedata space attribute, as in the
following
int mainSw __attribute__ ((space(eedata)));
to
int __eeprom mainSw;
2.5.9.4 CAVEATS XC8 does not implement the __eeprom qualifiers for any PIC18 devices; this qualifier
will work as expected for other 8-bit devices.
char title[20];

2.5.10 Interrupt Functions

The __interrupt(type) specifier may be used to indicate that a function is to act as an interrupt service routine. The type is a comma-separated list of keywords that indicate information about the interrupt function.
The current interrupt types are:
<empty> Implement the default interrupt function
low_priority The interrupt function corresponds to the low priority interrupt source (XC8 – PIC18
only) high_priority
The interrupt function corresponds to the high priority interrupt source (XC8)
2012 Microchip Technology Inc. DS52071B-page 39
MPLAB® XC16 C Compiler User’s Guide
save(symbol-list)
Save on entry and restore on exit the listed symbols (XC16) irq(irqid)
Specify the interrupt vector associated with this interrupt (XC16) altirq(altirqid)
Specify the alternate interrupt vector associated with this interrupt (XC16) preprologue(asm)
Specify assembly code to be executed before any compiler-generated interrupt code (XC16)
shadow Allow the ISR to utilise the shadow registers for context switching (XC16)
auto_psv The ISR will set the PSVPAG register and restore it on exit (XC16)
no_auto_psv The ISR will not set the PSVPAG register (XC16)
Use the native keywords discussed in the Differences section to look up information on the semantics of this specifier.
Some devices may not implement interrupts. Use of this qualifier for such devices will generate a warning. If the argument to the __interrupt specifier does not make sense for the target device, a warning or error will be issued by the compiler.
2.5.10.1 EXAMPLE
The following shows a function qualified using __interrupt.
__interrupt(low_priority) void getData(void) {
if (TMR0IE && TMR0IF) {
TMR0IF=0; ++tick_count;
}
}
2.5.10.2 DIFFERENCES
The 8-bit compilers have used the interrupt and low_priority qualifiers to indi­cate this meaning for some devices. Interrupt routines were by default high priority.
The 16- and 32-bit compilers have used the interrupt attribute to define interrupt functions.
DS52071B-page 40 2012 Microchip Technology Inc.
Common C Interface
2.5.10.3 MIGRATION TO THE CCI For 8-bit compilers, change any occurrence of the interrupt qualifier, as in the
following examples:
void interrupt myIsr(void) void interrupt low_priority myLoIsr(void)
to the following, respectively
void __interrupt(high_priority) myIsr(void) void __interrupt(low_priority) myLoIsr(void)
For 16-bit compilers, change any occurrence of the interrupt attribute, as in the fol­lowing example:
void __attribute__((interrupt,auto_psv,(irq(52)))) myIsr(void);
to
void __interrupt(auto_psv,(irq(52)))) myIsr(void);
For 32-bit compilers, the __interrupt() keyword takes two parameters, the vector number and the (optional) IPL value. Change code which uses the interrupt attri­bute, similar to these examples:
void __attribute__((vector(0), interrupt(IPL7AUTO), nomips16)) myisr0_7A(void) {}
void __attribute__((vector(1), interrupt(IPL6SRS), nomips16)) myisr1_6SRS(void) {}
/* Determine IPL and context-saving mode at runtime */ void __attribute__((vector(2), interrupt(), nomips16)) myisr2_RUNTIME(void) {}
to
void __interrupt(0,IPL7AUTO) myisr0_7A(void) {}
void __interrupt(1,IPL6SRS) myisr1_6SRS(void) {}
/* Determine IPL and context-saving mode at runtime */ void __interrupt(2) myisr2_RUNTIME(void) {}
2.5.10.4 CAVEATS None.
2012 Microchip Technology Inc. DS52071B-page 41
MPLAB® XC16 C Compiler User’s Guide

2.5.11 Packing Objects

The __pack specifier may b e us ed to i n di ca t e th at s tr uc t ur es sh ou ld n ot u se m emo r y gaps to align structure members, or that individual structure members should not be aligned.
Use the native keywords discussed in the Differences section to look up information on the semantics of this specifier.
Some compilers may not pad structures with alignment gaps for some devices and use of this specifier for such devices will be ignored.
2.5.11.1 EXAMPLE
The following shows a structure qualified using __pack as well as a structure where one member has been explicitly packed.
__pack struct DATAPOINT {
unsigned char type;
int value; } x-point; struct LINETYPE {
unsigned char type;
__pack int start;
long total; } line;
2.5.11.2 DIFFERENCES The __pack specifier is a new CCI specifier available with XC8. This specifier has no
apparent effect since the device memory is byte addressable for all data objects. The 16- and 32-bit compilers have used the packed attribute to indicate that a struc-
ture member was not aligned with a memory gap.
2.5.11.3 MIGRATION TO THE CCI No migration is required for XC8.
For 16- and 32-bit compilers, change any occurrence of the packed attribute, as in the following example:
struct DOT {
char a;
int x[2] __attribute__ ((packed)); };
to:
struct DOT {
char a;
__pack int x[2]; };
Alternatively, you may pack the entire structure, if required.
2.5.11.4 CAVEATS None.
DS52071B-page 42 2012 Microchip Technology Inc.
Common C Interface

2.5.12 Indicating Antiquated Objects

The __deprecate specifier may be used to indicate that an object has limited longev-
ity and should not be used in new designs. It is commonly used by the compiler vendor
to indicate that compiler extensions or features may become obsolete, or that better
features have been developed and which should be used in preference.
Use the native keywords discussed in the Differences section to look up information on
the semantics of this specifier.
2.5.12.1 EXAMPLE
The following shows a function which uses the __deprecate keyword.
void __deprecate getValue(int mode)
{
//...
}
2.5.12.2 DIFFERENCES
No deprecate feature was implemented on 8-bit compilers.
The 16- and 32-bit compilers have used the deprecated attribute (note different spell-
ing) to indicate that objects should be avoided if possible.
2.5.12.3 MIGRATION TO THE CCI
For 16- and 32-bit compilers, change any occurrence of the deprecated attribute, as
in the following example:
int __attribute__(deprecated) intMask;
to:
int __deprecate intMask;
2.5.12.4 CAVEATS
None.

2.5.13 Assigning Objects to Sections

The __section() specifier may be used to indicate that an object should be located
in the named section (or psect, using the XC8 terminology). This is typically used when
the object has special and unique linking requirements which cannot be addressed by
existing compiler features.
Use the native keywords discussed in the Differences section to look up information on
the semantics of this specifier.
2.5.13.1 EXAMPLE
The following shows a variable which uses the __section keyword.
int __section("comSec") commonFlag;
2012 Microchip Technology Inc. DS52071B-page 43
MPLAB® XC16 C Compiler User’s Guide
2.5.13.2 DIFFERENCES The 8-bit compilers have used the #pragma psect directive to redirect obje cts to a
new section, or psect. The operation of the __section() specifier is different to this pragma in several ways, described below.
Unlike with the pragma, the new psect created with __section() does not inherit the flags of the psect in which the object would normally have been allocated. This means that the new psect can be linked in any memory area, including any data bank. The compiler will also make no assumptions about the location of the object in the new sec­tion. Objects redirected to new psects using the pragma must always be linked in the same memory area, albeit at any address in that area.
The __section() specifier allows objects that are initialized to be placed in a different psect. Initialization of the object will still be performed even in the new psect. This will require the automatic allocation of an additional psect (whose name will be the same as the new psect prefixed with the letter i), which will contain the initial values. The pragma cannot be used with objects that are initialized.
Objects allocated a different psect with __section() will be cleared by the runtime startup code, unlike objects which use the pragma.
Y ou must reserve memory, and locate via a linker option, for any new psect created with a __section() specifier in the current XC8 compiler implementation.
The 16- and 32-bit compilers have used the section attribute to indicate a different destination section name. The __section() specifier works in a similar way to the attribute.
2.5.13.3 MIGRATION TO THE CCI For XC8, change any occurrence of the #pragma psect directive, such as
#pragma psect text%%u=myText int getMode(int target) { //... }
to the __section() specifier, as in
int __section ("myText") getMode(int target) { //... }
For 16- and 32-bit compilers, change any occurrence of the section attribute, as in the following example:
int __attribute__((section("myVars"))) intMask;
to:
int __section("myVars") intMask;
2.5.13.4 CAVEATS With XC8, the __section() specifier cannot be used with any interrupt function.
DS52071B-page 44 2012 Microchip Technology Inc.
Common C Interface

2.5.14 Specifying Configuration Bits

The #pragma config directive may be used to program the configuration bits for a
device. The pragma has the form:
#pragma config setting = state|value
#pragma config register = value
where setting is a configuration setting descriptor (e.g., WDT), state is a de scriptive
value (e.g., ON) and value is a numerical value. The register token may represent a
whole configuration word register, e.g., CONFIG1L.
Use the native keywords discussed in the Differences section to look up information on
the semantics of this directive.
2.5.14.1 EXAMPLE
The following shows configuration bits being specified using this pragma.
#pragma config WDT=ON, WDTPS = 0x1A
2.5.14.2 DIFFERENCES
The 8-bit compilers have used the __CONFIG() macro for some targets that did not
already have support for the #pragma config.
The 16-bit compilers have used a number of macros to specify the configuration set-
tings.
The 32-bit compilers supported the use of #pragma config.
2.5.14.3 MIGRATION TO THE CCI
For the 8-bit compilers, change any occurrence of the __CONFIG() macro, such as
__CONFIG(WDTEN & XT & DPROT)
to the #pragma config directive, as in
#pragma config WDTE=ON, FOSC=XT, CPD=ON
No migration is required if the #pragma config was already used.
For the 16-bit compilers, change any occurrence of the _FOSC() or _FBORPOR()
macros attribute, as in the following example:
_FOSC(CSW_FSCM_ON & EC_PLL16);
to:
#pragma config FCKSMEM = CSW_ON_FSCM_ON, FPR = ECIO_PLL16
No migration is required for 32-bit code.
2.5.14.4 CAVEATS
None.
2012 Microchip Technology Inc. DS52071B-page 45
MPLAB® XC16 C Compiler User’s Guide

2.5.15 Manifest Macros

The CCI defines the general form for macros that manifest the compiler and target device characteristics. These macros can be used to conditionally compile alternate source code based on the compiler or the target device.
The macros and macro families are details in Table 2-1.
TABLE 2-1: MANIFEST MACROS DEFINED BY THE CCI
Name Meaning if defined Example
__XC__ Compiled with an MPLAB XC compiler __XC__
__CCI__ Compiler is CCI compliant and CCI enforce-
ment is enabled
__XC##__ The specific XC comp iler u sed (## c an be 8,
16 or 32)
__DEVICEFAMILY__ The family of the selected target device __dsPIC30F__
__DEVICENAME__ The selected target device name __18F452__
2.5.15.1 EXAMPLE The following shows code which is conditionally compiled dependent on the device
having EEPROM memory.
#ifdef __XC16__ void __interrupt(__auto_psv__) myIsr(void) #else void __interrupt(low_priority) myIsr(void) #endif
__CCI__
__XC8__
2.5.15.2 DIFFERENCES Some of these CCI macros are new (for example __CCI__), and others have different
names to previous symbols with identical meaning (for example __18F452 is now __18F452__).
2.5.15.3 MIGRATION TO THE CCI Any code which uses compiler-defined macros will need review. Old macros will con-
tinue to work as expected, but they are not compliant with the CCI.
2.5.15.4 CAVEATS None.
DS52071B-page 46 2012 Microchip Technology Inc.
Common C Interface

2.5.16 In-line Assembly

The asm() statement may be used to insert assembly code in-line with C code. The
argument is a C string literal which represents a single assembly instruction. Obviously,
the instructions contained in the argument are device specific.
Use the native keywords discussed in the Differences section to look up information on
the semantics of this statement.
2.5.16.1 EXAMPLE
The following shows a MOVLW instruction being inserted in-line.
asm("MOVLW _foobar");
2.5.16.2 DIFFERENCES
The 8-bit compilers have used either the asm() or #asm ... #endasm constructs to
insert in-line assembly code.
This is the same syntax used by the 16- and 32-bit compilers.
2.5.16.3 MIGRATION TO THE CCI
For 8-bit compilers change any instance of #asm ... #endasm so that each instruction
in this #asm block is placed in its own asm() statement, for example:
#asm
MOVLW 20 MOVWF _i CLRF Ii+1
#endasm
to
asm("MOVLW20");
asm("MOVWF _i");
asm("CLRFIi+1");
No migration is required for the 16- or 32-bit compilers.
2.5.16.4 CAVEATS
None.
2012 Microchip Technology Inc. DS52071B-page 47
MPLAB® XC16 C Compiler User’s Guide

2.6 COMPILER FEATURES

The following items detail compiler options and features that are not directly associated with source code that

2.6.1 Enabling the CCI

It is assumed you are using the MPLAB X IDE to build projects that use the CCI. The widget in the MPLAB X IDE Project Properties to enable CCI conformance is Use CCI Syntax in the Compiler category. A widget with the same name is available in MPLAB IDE v8 under the Compiler tab.
If you are not using this IDE, then the command-line options are --CCI for XC8 or
-mcci for XC16/32.
2.6.1.1 DIFFERENCES This option has never been implemented previously.
2.6.1.2 MIGRATION TO THE CCI Enable the option.
2.6.1.3 CAVEATS None.
DS52071B-page 48 2012 Microchip Technology Inc.

Chapter 3. Compiler Command-Line Driver

3.1 INTRODUCTION

The compiler command-line driver (xc16-gcc ) is the application that invokes the oper-
ation of the MPLAB XC16 C Compiler. The driver compiles, assembles and links C and
assembly language modules and library archives. Most of the compiler command-line
options are common to all implementations of the GCC toolset. A few are specific to
the compiler and will be discussed below.
The compiler driver also may be used with MPLAB IDE. Compiler options are selected
in the GUI and passed to the compiler driver for execution.
Topics concerning the command-line use of the driver are discussed below. For more
on how to use the compiler with MPLAB IDE, please refer to the MPLAB Assembler,
Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
• Invoking the Compiler
• The Compilation Sequence
• Runtime Files
• Compiler Output
• Compiler Messages
• Driver Option Descriptions
• MPLAB IDE Toolsuite Equivalents
MPLAB® XC16 C COMPILER
USER’S GUIDE
2012 Microchip Technology Inc. DS52071B-page 49
MPLAB® XC16 C Compiler User’s Guide

3.2 INVOKING THE COMPILER

The compiler is invoked and run on the command line as specified in the next section. Additionally, environmental variables and input files used by the compiler are discussed in the following sections.

3.2.1 Drive Command-Line Format

The basic form of the compiler command line is:
xc16-gcc [options] files
where:
options: See Section 3.7 “Driver Option Descriptions” for available options. files: See Section 3.2.3 “Input File Types” for details.
Note: Command line options and file name extensions are case-sensitive.
It is assumed in this manual that the compiler applications are either in the console’s search path, see Section 3.2.2 “Environment Variables”, or the full path is specified when executing any application.
It is conventional to supply options (identified by a leading dash “-”) before the file names, although this is not mandatory.
The files may be any mixture of C and assembler source files, and precompiled inter­mediate files, such as relocatable object (.o) files. The order of the files is not impor­tant, except that it may affect the order in which code or data appears in memory.
For example, to compile, assemble and link the C source file hello.c, creating a relo­catable object output, hello.out.
xc16-gcc -mcpu=30f2010 -o hello.out hello.c

3.2.2 Environment Variables

The variables in this section are optional, but, if defined, they will be used by the compiler. The compiler driver, or other subprogram, may choose to determine an appropriate value for some of the following environment variables if they are unset. The driver, or other subprogram, takes advantage of internal knowledge about the installation of the compiler. As long as the installation structure remains intact, with all subdirectories and executables remaining in the same relative position, the driver or subprogram will be able to determine a usable value.
TABLE 3-1: COMPILER-RELATED ENVIRONMENTAL VARIABLES
Variable Definition
XC16_C_INCLUDE_P ATH PIC30_C_INCLUDE_ PATH
XC16_COMPILER_ PATH PIC30_COMPILER_ PATH
This variable’ s val ue is a sem icolo n-sep arate d list of dir ect ories, muc h like PATH. When the compiler searches for header files, it tries the directories listed in the variable, after the directories specified with -I but before the standard header file directories. If the environment vari able is und efined , the p reproce ssor choos es an appropriate value based on the standard installation. By default, the following directories are searched for include files:
<install-path>\include and <install-path>\support\h
The value of the variable is a semicolon-separated list of directories, much like PATH. The compiler tries the di rectori es th us sp ecifi ed when searching for subprograms, if it can’t find the subprograms using PIC30_EXEC_PREFIX.
DS52071B-page 50 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-1: COMPILER-RELATED ENVIRONMENTAL VARIABLES
Variable Definition
XC16_EXEC_ PREFIX PIC30_EXEC_ PREFIX
XC16_LIBRARY_ PATH PIC30_LIBRARY_ PATH
XC16_OMF PIC30_OMF
TMPDIR If the variable is set, it specifies the directory to use for temporary files.
If the environment variable is set, it specifies a prefix to use in the names of subprograms executed by the compiler. No directory delimiter is added when this prefix is combined with the name of a subprogram, but you can specify a prefix that ends with a slash if you wish. If the compiler cannot find the subprogram using the specified prefix, it tries looking in your PATH environment variable. If the environment variable is not set or set to an empty value, the compiler driver chooses an appropriate value based on the standard installation. If the installation has not been modified, this will result in the driver being able to locate the required subprograms. Other prefixes specified with the -B command line option take precedence over the user- or driver-defined value of the variable. Under normal circumstances it is best to leave this value undefined and let the driver locate subprograms itself.
This variable’ s value i s a sem icolo n-sep arate d list of dir ectorie s, muc h like PATH. This variable specifies a list of directories to be passed to the linker. The driver’s default evaluation of this variable is: <install-path>\lib; <install-path>\support\gld.
Specif ies the OMF (Object Module Format) to be used by the compiler . By default, the tools create ELF object files. If the environment variable has the value coff, the tools will create COFF object files.
The compiler uses temporary files to hold the output of one stage of compilation that is to be used as input to the next stage: for example, the output of the preprocessor, which is the input to the compiler proper.

3.2.3 Input File Types

The compilation driver distinguishes source files, intermediate files and library files
solely by the file type, or extension. It recognizes the following file extensions, which
are case-sensitive.
TABLE 3-2: FILE NAMES
Extensions Definition
file.c A C source file that must be preprocessed. file.h A header file (not to be compiled or linked). file.i A C source file that should not be preprocessed. file.o An object file. file.p A pre procedural-abstraction assembly language file. file.s Assembler code. file.S Assembler code that must be preprocessed.
other A file to be passed to the linker.
There are no compiler restrictions imposed on the names of source files, but be aware
of case, name-length and other restrictions imposed by your operating system. If you
are using an IDE, avoid assembly source files whose basename is the same as the
basename of any project in which the file is used. This may result in the source file
being overwritten by a temporary file during the build process.
The terms “source file” and “module” are often used when talking about computer
programs. They are often used interchangeably, but they refer to the source code at
different points in the compilation sequence.
2012 Microchip Technology Inc. DS52071B-page 51
MPLAB® XC16 C Compiler User’s Guide
A source file is a file that contains all or part of a program. Source files are initially passed to the preprocessor by the driver.
A module is the output of the preprocessor, for a given source file, after inclusion of any header files (or other source files) which are specified by #include preprocessor directives. These modules are then passed to the remainder of the compiler applica­tions. Thus, a module may consist of several source and header files. A module is also often referred to as a translation unit. These terms can also be applied to assembly files, as they too can include other header and source files.

3.3 THE COMPILATION SEQUENCE

How the compiler operates with other applications and how to perform different types of compilations is discussed in the following sections.

3.3.1 The Compiler Applications

The MPLAB XC16 C Compiler compiles C source files, producing assembly language files. These compiler-generated files are assembled and linked with other object files and libraries to produce the final application program in executable ELF or COFF file format. The ELF or COFF file can be loaded into the MPLAB IDE, where it can be tested and debugged, or the conversion utility can be used to convert the ELF or COFF file to Intel programmer. See Figure 3-1 for an overview of the software development data flow.
®
hex format, suitable for loading into the command-line simulator or a device
DS52071B-page 52 2012 Microchip Technology Inc.
Compiler Command-Line Driver
Object File Libraries
(*.a)
Assembler
Linker
C Source Files
(*.c)
C Compiler
Assembly Source
Files (*.S)
Debug File (*.cof,*.elf)
Archiver (Librarian)
Compiler Driver Program
MPLAB® X IDE Debug T ool
Source Files (*.s)
Object Files
(*.o)
Command-Line
Simulator
Linker Script File
(1)
(*.ld)
Executable File
(*.hex)
MPLAB X IDE Programmer
bin2hex Utility
Output File
(*.out)
Note 1: The linker can choose the correct linker script file for your project.
FIGURE 3-1: SOFTWARE DEVELOPMENT TOOLS DATA FLOW
The driver program will call the required internal compiler applications. These applica-
tions are shown as the smaller boxes inside the large driver box. The temporary file pro-
duced by each application can also be seen in this diagram.
Table 3-3 lists the compiler applications. The names shown are the names of the exe-
cutables, which can be found in the bin directory under the compiler’s installation
directory. Your PATH environment variable should include this directory.
2012 Microchip Technology Inc. DS52071B-page 53
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-3: COMPILER APPLICATION NAMES
Name Description
xc16-gcc Command line driver; the interface to the compiler xc16-cc1 Code generator (elf by default) xc16-as Assembler (based on the target device) xc16-ld Linker xc16-bin2hex Conversion utility to create HEX files xc16-strings String extractor utility
xc16-strip xc16-nm
xc16-ar Archiver/Librarian xc16-objdump Object file display utility xc16-ranlib Archive indexer utility

3.3.2 Single-Step Compilation

A single command-line instruction can be used to compile one file or multiple files.
3.3.2.1 COMPILING A SINGLE FILE This section demonstrates how to compile and link a single file. For the purpose of this
discussion, it is assumed the compiler is installed in the standard directory location and that your P A TH or other enviro nment variab les (see Section 3.2.2 “Environment Vari- ables”) are set up in such a way that the full compiler path need not be specified when you run the compiler.
The following is a simple C program that adds two numbers. Create the following program with any text editor and save it as ex1.c.
#include <xc.h> int main(void); unsigned int Add(unsigned int a, unsigned int b); unsigned int x, y, z; int main(void) { x = 2; y = 5; z = Add(x,y); return 0; } unsigned int Add(unsigned int a, unsigned int b) { return(a+b); }
The first line of the program includes the header file xc.h, which will include the appro­priate header files that provides definitions for all special function registers on the target device. For more information on header files, see Section 4.3 “Device Header Files”.
Compile the program by typing the following at the prompt in your favorite terminal.
xc16-gcc -mcpu=30f2010 -o ex1.out ex1.c
The command-line option -o ex1.out names the output executable file (if the -o option is not specified, then the output file is named a.out). The executable file may be loaded into the MPLAB IDE.
Symbol stripper utility Symbol list utility
DS52071B-page 54 2012 Microchip Technology Inc.
Compiler Command-Line Driver
If a hex file is required, for example, to load into a device programmer, then use the
following command:
xc16-bin2hex ex1.out
This creates an Intel hex file named ex1.hex.
3.3.2.2 COMPILING MULTIPLE FILES
Move the Add() function into a file called add.c to demonstrate the use of multiple
files in an application. That is:
File 1
/* ex1.c */
#include <xc.h>
int main(void);
unsigned int Add(unsigned int a, unsigned int b);
unsigned int x, y, z;
int main(void)
{
x = 2;
y = 5;
z = Add(x,y);
return 0;
}
File 2
/* add.c */
#include <xc.h>
unsigned int
Add(unsigned int a, unsigned int b)
{
return(a+b);
}
Compile both files in the one command by typing the following in your terminal program.
xc16-gcc -mcpu=30f2010 -o ex1.out ex1.c add.c
This command compiles the modules ex1.c and add.c. The compiled modules are
linked with the compiler libraries and the executable file ex1.out is created.

3.3.3 Multi-Step Compilation

Make utilities and integrated development environments, such as MPLAB IDE, allow
for an incremental build of projects that contain multiple source files. When building a
project, they take note of which source files have changed since the last build and use
this information to speed up compilation.
For example, if compiling two source files, but only one has changed since the last
build, the intermediate file corresponding to the unchanged source file need not be
regenerated.
If the compiler is being invoked using a make utility, the make file will need to be con-
figured to recognized the different intermediate file format and the options used to gen-
erate the intermediate files. Make utilities typically call the compiler multiple times: once
for each source file to generate an intermediate file, and once to perform the second
stage compilation.
You may also wish to generate intermediate files to construct your own library files,
although xc16-gcc is capable of constructing libraries so this is typically not neces-
sary. See MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs
User’s Guide (DS5 131 7) for more information on library creation.
2012 Microchip Technology Inc. DS52071B-page 55
MPLAB® XC16 C Compiler User’s Guide
For exampl e, the files ex1.c and add.c are to be compiled using a make utility. The command lines that the make utility should use to compile these files might be some­thing like:
xc16-gcc -mcpu=30f6014 -c ex1.c xc16-gcc -mcpu=30f6014 -c add.c xc16-gcc -mcpu=30f6014 -o ex1 ex1.o add.o
The -c option will compile the named file into the intermediate (object) file format, but not link. Once all files are compiled as specified by the make, then the resultant object files are linked in the final step to create the final output ex1. The above example uses the command-line driver, xc16-gcc, to perform the final link step. You can explicitly call the linker application, xc16-ld, but this is not recommended. When driving the linker application, you must specify linker options, not driver options. For more on using the linker, see MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS5 131 7) .
When compiling debug code, the object module format (OMF) must be consistent for compilation, assembly and linking. The ELF/DWARF format is used by default but the COFF format may also be selected using -omf=coff or the environmental variable XC16_OMF.

3.3.4 Assembly Compilation

A mix of C and assembly code can be compiled together using the compiler (Figure 3-1). For more details, see Chapter 13. “Mixing C and Assembly Code”.
Additionally, the compiler may be used to generate assembly code (.s) from C code (.c) using the -S option. The assembly output may then be used in subsequent com­pilation using the command-line driver.
DS52071B-page 56 2012 Microchip Technology Inc.

3.4 RUNTIME FILES

The compiler uses the following files in addition to source, linker and header files.

3.4.1 Library Files

The compiler may include library files into the output per Figure 3-1.
By default, xc16-gcc will search directories under the compiler installation directory
for library files that are required during compilation.
3.4.1.1 STANDARD LIBRARIES
The C standard libraries contain a standardized collection of functions, such as string,
math and input/output routines. The range of these functions are described in the
16-Bit Language Tool Libraries” (DS5145 6 ).
3.4.1.2 USER-DEFINED LIBRARIES
Users may create their own libraries. Libraries are useful for bundling and precompiling
selected functions so that application file management is easier and application com-
pilation times are shorter.
Libraries can be created manually using the compiler and the librarian. To create files
that may then be used as input to the 16-bit librarian (xc16-ar), use the -c compiler
option to stop compilation before the linker stage. For information on using the librarian,
see the MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs
User’s Guide (DS5 131 7) .
User-created libraries that should be searched when building a project can be listed on
the command line along with the source files.
As with Standard C library functions, any functions contained in user-defined libraries
should have a declaration added to a header file. It is common practice to create one
or more header files that are packaged with the library file. These header files can then
be included into source code when required.
Library files specified on the command line are scanned first for unresolved symbols,
so these files may redefine anything that is defined in the C standard libraries.
Compiler Command-Line Driver

3.4.2 Startup and Initialization

Two startup modules are available to initialize the C runtime environment:
• The primary startup module (crt0.o) which is linked by default (or the -Wl,
--data-init option.)
• The alternate startup module (crt1.o) which is linked when the -Wl,
--no-data-init option is specified (no data initialization.)
These modules are included in the libpic30-omf.a archive/library . Mult iple versions
of these modules exist in order to support architectural differences between device
families. The compiler automatically uses the correct module.
For more information on the startup modules, see Section 12.3 “Runtime Startup
and Initialization”.
2012 Microchip Technology Inc. DS52071B-page 57
MPLAB® XC16 C Compiler User’s Guide

3.5 COMPILER OUTPUT

There are many files created by the compiler during the compilation. A large number of these are intermediate files are deleted after compilation is complete, but many remain and are used for programming the device or for debugging purposes.

3.5.1 Output Files

The compilation driver can produce output files with the following extensions, which are case-sensitive.
TABLE 3-4: FILE NAMES
Extensions Definition
file.hex Executable file file.cof COF debug file (default) file.elf ELF debug file file.o Object file (intermediate file) file.S Assembly code file (required preprocessing) file.s Assembly code file (intermediate file) file.i Preprocessed file (intermediate file) file.p Preprocedure abstraction assembly language file (intermediate file) file.map Map file
The names of many output files use the same base name as the source file from which they were derived. Fo r examp le the sour ce file input.c will create an object file called input.o when the -c option is used.
The default output file is a ELF file called a.out, unless you override that name using the -o option.
If you are using an IDE, such as MPLAB IDE, to specify options to the compiler, there is typically a project file that is created for each application. The name of this project is used as the base name for project-wide output files, unless otherwise specified by the user. However check the manual for the IDE you are using for more details.
Note: Throughout this manual, the term project name will refer to the name of the
project created in the IDE.
The compiler is able to directly produce a number of the output file formats which are used by Microchip develop men t tools .
The default behavior of xc16-gcc is to produce a ELF output. T o make changes to the files output or the file names, see Section 3.7 “Driver Optio n Descr ip tions ”.

3.5.2 Diagnostic Files

Two valuable files produced by the compiler are the assembly list file, produced by the assembler, and the map file, produced by the linker.
The assembly list file contains the mapping between the original source code and the generated assembly code. It is useful for information such as how C source was encoded, or how assembly source may have been optimized. It is essential when con­firming if compiler-produced code that accesses objects is atomic, and shows the region in which all objects and code are placed.
The option to create a listing file in the assembler is -a. There are many variants to this option, which may be found in the MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317). To pass the option from the compiler, see Section 3.7.8 “Options for Assembling”.
DS52071B-page 58 2012 Microchip Technology Inc.
There is one list file produced for each build. Thus, if you require a list file for each
source file, these files must be compiled separately, see Section 3.3.3 “Multi-Step
Compilation”. This is the case if you build using MPLAB IDE. Each list file will be
assigned the module name and extension .lst.
The map file shows in formatio n relati ng to wh ere obje cts were positio ned in me mory. It
is useful for confirming if user-defined linker options were correctly processed, and for
determining the exact placement of objects and functions.
The linker option to create a map file in the linker application is -Map file, which may
be found in the MPLAB As se mbl er, Linker and Utilities for PIC24 M CUs and dsPIC
DSCs User’s Guide (DS51317). To specify the option from the command-line driver,
see Section 3.7.9 “Options for Linking”.
There is one map file produced when you build a project, assuming the linker was exe-
cuted and ran to completion.

3.6 COMPILER MESSAGES

Compiler output messages for errors, warnings or comments as discussed in Appen-
dix B. “Diagnostics”.
For information on options that control compiler output of errors, warnings or com-
ments, see Section 3.7.4 “Options for Controlling Warnings and Errors”.
There are no pragmas that directly control messages issued by the compiler.
Compiler Command-Line Driver
2012 Microchip Technology Inc. DS52071B-page 59
MPLAB® XC16 C Compiler User’s Guide

3.7 DRIVER OPTION DESCRIPTIONS

The compiler has many options for controlling compilation, all of which are case-sensitive. They have been grouped, as shown below, according to their function. Remember, these are options for the command-line driver; options for the linker, assembler or any other application can be found in the MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
• Options Specific to 16-Bit Devices
• Options for Controlling the Kind of Output
• Options for Controlling the C Dialect
• Options for Controlling Warnings and Errors
• Options for Debugging
• Options for Controlling Optimization
• Options for Controlling the Preprocessor
• Options for Assembling
• Options for Linking
• Options for Directory Search
• Options for Code Generation Conventions

3.7.1 Options Specific to 16-Bit Devices

For more information on the memory models, see Section 7.12 “Memory Models”. TABLE 3-5: 16-BIT DEVICE-SPECIFIC OPTIONS
Option Definition
-mconst-in-code Put const qualified variables in the auto_psv space. The compiler will access these variables using the PSV window. (This is the
default.)
-mconst-in-data Put const qualified variables in the data memory space.
-mconst-in-
auxflash
-merrata=
id[,id]*
-mfillupper Specif y the up per byte of variab les st ored into space(prog) sections.
Note 1: The procedure abstractor behaves as the inverse of inlining f unctions. The pass is
designed to extract common code sequences from multiple sites throughout a translation unit and place them into a common area of code. Although this option generally does no t im pro ve the run -tim e p erformance of the gene rate d c ode , it ca n reduce the code size significantly. Programs compiled with -mpa can be harder to debug; it is not recommended that this option be used while debugging using the COFF object format. The procedure abstractor is invoked as a separate phase of compilation, after the production of an assembly file. This phase does not optimize across translation units. When the proc edure-opti mizing ph ase is enabl ed, inline as sembly cod e must be limited to valid machine instructions. Invalid machine instructions or instruction sequences, or assemb ler dire ct ive s (se cti oni ng directives, macros, include f ile s, etc.) must not be used, or the procedure abstraction phase will fail, inhibiting the creation of an output file.
When combined with -mconst-in-code, put call const qualified file scope variables i nto auxil iary FLASH. Al l modules with auxil iary FLASH should be compiled with this option; otherwise a link error may occur.
This option enabl es sp ec ific er rat a work arounds identified by id. Valid values for id change from time to time and may not be required for a particular variant. An id of list will display the currently supported errata identifiers along with a brief description of the errata. An id of all will enable all currently supported errata work arounds.
The fillupper attribute will perform the same function on individual variables.
DS52071B-page 60 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-5: 16-BIT DEVICE-SPECIFIC OPTIONS (CONTINUED)
Option Definition
-mlarge-arrays Specifies that arrays may be larger than the default maximum size of 32K. See Section 4.7 “Bit-Reversed and Modulo Addressing” for more information.
-mlarge-code Compile using the large code model. No assumptions are made about the locality of called functions. When this option is chosen, single functions that are larger than 32k are not supported and may cause assembly-time errors since all branches inside of a function are of the short form.
-mlarge-data Compile using the large data model. No assumptions are made about the location of static and external variables.
-mcpu=
target
(1)
-mpa
-mpa=n
-mno-pa
-mno-isr-warn By default the compiler will produce a warning if the
-omf Selects the OMF (Object Module Format) to be used by the compiler.
-msmall-code Compile using the small code model. Called functions are assumed to
Note 1: The procedure abstractor behaves as the inverse of inlining f unctions. The pass is
(1)
(1)
designed to extract common code sequences from multiple sites throughout a translation unit and place them into a common area of code. Although this option generally does no t im pro ve the run -tim e p erformance of the gene rate d c ode , it ca n reduce the code size significantly. Programs compiled with -mpa can be harder to debug; it is not recommended that this option be used while debugging using the COFF object format. The procedure abstractor is invoked as a separate phase of compilation, after the production of an assembly file. This phase does not optimize across translation units. When the proc edure-opti mizing pha se is enabl ed, inline as sembly cod e must be limited to valid machine instructions. Invalid machine instructions or instruction sequences, or assemb ler dire ct ive s (se cti oni ng directives, macros, include files, etc.) must not be used, or the procedure abstraction phase will fail, inhibiting the creation of an output file.
This option selects the target processor ID (and communicates it to the assembler and linker if tho se tools are invo ked). This optio n affect s how some predefined constants are set; see Section 16.4 “Predefined Macro Names” for more info rmation. A full list of accepted t arg et s can be seen in the Readme.htm file that came with the release.
Enable the procedure abstraction optimization. There is no limit on the nesting level. Optimization levels depend on the compiler edition (see Chapter
15. “Optimizations”.) Enable the procedure ab straction optimiza tion up to lev el n. If n is zero,
the optimization is disabled. If n is 1, first level of abs traction is allowed; that is, instruction sequences in the source code may be abstracted into a subroutine. If n is 2, a second level of abs tracti on is allow ed; tha t is, instructions that were put into a subroutine in the first level may be abstracted into a subroutin e one lev el dee per. This pattern continues for larger values of n. The net effect is to limit the subroutine call nest­ing depth to a maximum of n. Optimization levels depend on the compiler edition (see Chapter
15. “Optimizations”.) Do not enable the procedure abstraction optimization.
(This is the default.)
__interrupt__
is not attached to a recognized interrupt vector name. This option will disable that feature.
The omf specifier can be one of the following:
elf Produce ELF object files. (This is the default.) coff Produce COFF object files.
The debugging format used for ELF object files is DWARF 2.0.
be proximate (within 32 Kwords of the caller). (This is the default.)
2012 Microchip Technology Inc. DS52071B-page 61
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-5: 16-BIT DEVICE-SPECIFIC OPTIONS (CONTINUED)
Option Definition
-msmall-data Compile using the small data model. All static and external variables are assumed to be located in the lower 8 KB of data memory space.
(This is the default.)
-msmall-scalar Like -msmall-data, except that only static and external scalars are assumed to be in the lower 8 KB of data memory space. (This is the
default.)
-mtext=name Specifying -mtext=name will cause text (program code) to be placed in a section named name rather than the default .text section. No white spaces should appear around the =.
-mauxflash Place all code from the current translation unit into auxiliary FLASH. This option is only available on devices that have auxiliary FLASH.
-msmart-io
[=0|1|2]
Note 1: The procedure abstractor behaves as the inverse of inlining f unctions. The pass is
designed to extract common code sequences from multiple sites throughout a translation unit and place them into a common area of code. Although this option generally does no t im pro ve the run -tim e p erformance of the gene rate d c ode , it ca n reduce the code size significantly. Programs compiled with -mpa can be harder to debug; it is not recommended that this option be used while debugging using the COFF object format. The procedure abstractor is invoked as a separate phase of compilation, after the production of an assembly file. This phase does not optimize across translation units. When the proc edure-opti mizing ph ase is enabl ed, inline as sembly cod e must be limited to valid machine instructions. Invalid machine instructions or instruction sequences, or assemb ler dire ct ive s (se cti oni ng directives, macros, include f ile s, etc.) must not be used, or the procedure abstraction phase will fail, inhibiting the creation of an output file.
This option attempts to statically analyze format strings passed to printf, scanf and the ‘f’ and ‘v’ variati ons of thes e function s. Uses of nonfloating point format arguments will be converted to use an integer-only variation of the library functions.
-msmart-io=0 disables this op tion, whi le -msmart-io=2 causes the compiler to be optimistic and convert function calls with variable or unknown format argument s . -msmart-io=1 is the default and will only convert the literal values it can prove.

3.7.2 Options for Controlling the Kind of Output

The following options control the kind of output produced by the compiler.
TABLE 3-6: KIND-OF-OUTPUT CONTROL OPTIONS
Option Definition
-c Compile or assemble the source files, but do not link. The default file extension
is .o.
-E Stop after the prepro cess ing st age, i .e., before runnin g the comp iler pro per. The
default output file is stdout.
-o file Place the output in file.
-S Stop after compilation proper (i.e., before invoking the assembler). The default
output file extension is .s.
-v Print the commands executed during each stage of compilation.
DS52071B-page 62 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-6: KIND-OF-OUTPUT CONTROL OPTIONS (CONTINUED)
Option Definition
-x You can specify the input language explicitly with the -x option:
-x
language
Specify explicitly the language for the following input files (rather than letting the compiler choose a default based on the file name suffix). This option applies to all following input files until the next -x option. The following values are supported by the compiler:
c c-header cpp-output assembler assembler-with-cpp
-x none Turn off any specification of a language, so that subsequent files are handled according to their file name s uff ixes. This is the defaul t beh avior but is neede d if another -x option has been used. For example:
xc16-gcc -x assembler foo.asm bar.asm -x none main.c mabonga.s
Without the -x none, the compiler will assume all the input files are for the assembler.
--help Print a description of the command line options.

3.7.3 Options for Controlling the C Dialect

The following options define the kind of C dialect used by the compiler.
TABLE 3-7: C DIALECT CONTROL OPTIONS
Option Definition
-ansi Support all (and only) ANSI-standard C programs.
-aux-info filename Output to the gi ven file n ame prototy ped d eclara tio ns for a ll
functions declared and/or defined in a translation unit, including those in header files. This option is silently ignored in any language other than C. Besides declarations, the file indicate s, in com m ents, the origin of each declaration (source fi le and lin e), whe ther the declar a­tion was implicit, prototyped or unprototyped (I, N for new or O for old, respectively, in the first character after the line number and the colon), and whether it came from a declaration or a definition (C or F, respectively, in the following character). In the case of function definitions, a K&R-style list of argum ents followed by their dec larations is also provided, inside comment s , af ter the dec la rati on.
-ffreestanding Assert that compilation takes place in a freestanding environment. This implies -fno-builtin. A freestanding environment is one in which the standard library may not exist, and program sta rtup may not nec essari ly be at mai n. The most obvious example is an OS kernel. This is equivalent to -fno-hosted.
-fno-asm Do not recognize asm, inline or typeof as a keyword, so that code can use these words as identifiers. You can use the keywords
__typeof__ instead.
-ansi implies -fno-asm.
-fno-builtin
-fno-builtin-function
-fsigned-char Let the type char be signed, like signed char.
Don’t recognize built-in functions that do not begin with
__builtin_ as prefix.
(This is the default.)
__asm__, __inline__ and
2012 Microchip Technology Inc. DS52071B-page 63
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-7: C DIALECT CONTROL OPTIONS (CONTINUED)
Option Definition
-fsigned-bitfields
-funsigned-bitfields
-fno-signed-bitfields
-fno-unsigned-bitfields
-funsigned-char Let the type char be unsigned, like unsigned char.

3.7.4 Options for Controlling Warnings and Errors

Warnings are diagnostic messages that report constructions that are not inherently erroneous but that are risky or suggest there may have been an error.
You can request many specific warnings with options beginning -W, for example,
-Wimplicit, to request warnings on implicit declarations. Each of these specific warning options also has a negative form beginning -Wno- to turn off warnings, for example, -Wno-implicit. This manual lists only one of the two forms, whichever is not the default.
The following options control the amount and kinds of warnings produced by the compiler.
TABLE 3-8: WARNING/ERROR OPTIONS IMPLIED BY -WALL
Option Definition
-fsyntax-only Check the code for syntax, but don’t do anything beyond that.
-pedantic Issue all the warnings demanded by strict ANSI C; reject all
-pedantic-errors Like -pedantic, except that errors are produced rather than
-w Inhibit all warning messages.
-Wall All of the -W options listed in this table combined. This enables
-Wchar-subscripts Warn if an array subscript has type char.
-Wcomment
-Wcomments
-Wdiv-by-zero Warn about compile-time integer division by zero. To inhibit the
-Werror-implicit­ function-declaration
-Wformat Check calls to printf and scanf, etc., to make sure that the
-Wimplicit Equivalent to specifying both -Wimplicit-int and
-Wimplicit-function­ declaration
-Wimplicit-int Warn when a declaration does not specify a type.
These options control whether a bit field is signed or unsigned, when the declaration does not use either signed or unsigned. By default, such a bit field is signed, unless
-traditional is used, in which case bi t fields are alw ays unsigned.
programs that use forbidden extensions.
warnings.
all the warnings about constructions that some users consider questionable, and that are easy to avoid (or modify to prevent the warning), even in conjunction with macros.
Warn whenever a comment-start sequence /* appears in a /* comment, or whenever a Backslash-Newline appears in a // comment.
warning messages, use -Wno-div-by-zero. Floating point division by zero is not warned about, as it can be a legitimate way of obtaining infinities and NaNs.
(This is the default.)
Give an error whenever a function is used before being declared.
arguments supplied have types appropriate to the format string specified.
-Wimplicit-function-declaration. Give a warning whenever a function is used before being
declared.
DS52071B-page 64 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-8: WARNING/ERROR OPTIONS IMPLIED BY -WALL (CONTINUED)
Option Definition
-Wmain Warn if the type of main is suspicious. main should be a func-
tion with external linkage, re turn ing int, taking either zero, two or three arguments of appropriate types.
-Wmissing-braces Warn if an aggregat e or un ion i nit ializer i s no t fully brac keted . In
the following example, the initializer for a is not fully bracketed, but that for b is fully bracketed.
int a[2][2] = { 0, 1, 2, 3 }; int b[2][2] = { { 0, 1 }, { 2, 3 } };
-Wmultichar
-Wno-multichar
-Wparentheses Warn if parentheses are omitted in certain contexts, such as
-Wreturn-type Warn whenever a function is defined with a return-type that
Warn if a multi-character character constant is used. Usually, such constants are typographical errors. Since they have implementati on-define d values, they sho uld not be used in portable code. The following example illustrates the use of a multi-character character constant:
char xx(void) { return('xx'); }
when there is an assign me nt in a context where a truth val ue i s expected, or when operators are nested whose precedence people often find confusing.
defaults to int. Also w arn about any return st atement with no return-value in a function whose return-type is not void.
2012 Microchip Technology Inc. DS52071B-page 65
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-8: WARNING/ERROR OPTIONS IMPLIED BY -WALL (CONTINUED)
Option Definition
-Wsequence-point Warn about code that may have undefined semantics because of violations of sequence point rules in the C standard. The C standard defines the order in which expressions in a C program are evaluated in terms of sequence points, which rep­resent a partial ordering between the execution of parts of the program: those executed before the sequence point and those executed after it. These occur after the evaluation of a full expression (one which is not part of a larger expression), after the evaluation of the first operand of a &&, ||, ? : or , (comma) operator, before a function is called (but after the eva l­uation of its arguments and the expression denoting the called function), and in certain other places. Other than as expressed by the sequence point rules, the order of evaluation of subex­pressions of an expression is not specified. All these rules describe only a partial order rather than a total order, since, for example, if two functions are called within one expression with no sequence point between them, the order in which the func­tions are called is not specified. However, the standards com­mittee has ruled that function calls do not overlap. It is not specified, when, between sequence points modifications to the values of objects take effect. Programs whose behavior depends on this have undefined behavior; the C standard specifies that “Between the previous and next sequence point, an object shall have its stored value modified, at most once, by the evaluation of an expres si on. Furt herm ore , the prior value shall be read only to determine the value to be stored.” If a program breaks these rules, the results on any par­ticular implementati on are enti rel y unpre di ct a ble. Examples of code with undefined behavior are a = a++;, a[n] = b[n++] and a[i++] = i;. Some more complicated cases are not diagnosed by this option, and it may give an occasional fals e posi tive re sult, b ut in g eneral it has been f ound fairly effective at detecting this sort of problem in programs.
-Wswitch Warn whenever a switch statement has an index of enumeral type and lacks a case for one or more of the named codes of that enumeration. (Th e pres ence of a de fault l abel p revents this warning.) case labels outside the enumeration range also pro­voke warn ings when this option is used.
-Wsystem-headers Print warning messages for constructs found in system header files. Warnings from system headers are normally suppressed, on the assumption that they usually do not indicate real prob­lems and would only make the compiler output harder to read. Using this command line option tells the compiler to emit warn­ings from system headers as if they occurred in user code. However, note that using -Wall in conjunction with this option will not warn about unknown pragmas in system headers; for that, -Wunknown-pragmas must also be used.
-Wtrigraphs Warn if any trigraphs are encountered (assuming they are enabled).
DS52071B-page 66 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-8: WARNING/ERROR OPTIONS IMPLIED BY -WALL (CONTINUED)
Option Definition
-Wuninitialized Warn if an automatic variable is used without first being initialized. These warnings are pos sible only wh en optimizat ion is enable d, because they require data flow information that is computed only when optimizing. These warnings occur only for variables that are candidates for register allocation . Therefore, they do not occur for a v ariable that is declared volatile, or whose address is taken, or whose size is other than 1, 2, 4 or 8 bytes. Also, they do not occur for structures, unions or arrays, even when they are in registers. Note that there may be no warn ing abo ut a v ariable that i s use d only to compute a value that itself is never used, because such computations may be deleted by data flow analysis before the warnings are printed.
-Wunknown-pragmas Warn when a #pragma directive is encountered which is not understood by the compi ler. If this command line option is used, warnings will even be issued for unknown pragmas in system header files. This is not the case if the warnings were only enabled by the -Wall command line option.
-Wunused Warn whenever a variable is unused aside from its declaration, whenever a function is declared static but never defined, when­ever a label is declared but not used, and whenever a state­ment computes a result that is explicitly not used. In order to get a warning about an unused function parameter, both -W and -Wunused must be specified. Casting an expression to void suppresses this warning for an expression. Similarly, the unused attribute suppresses this warning for unused var iables, para meters and labels.
-Wunused-function Warn whene ver a st atic func tion is d eclare d but not defin ed or a non-inline static fun cti on is unu sed.
-Wunused-label Warn whenever a label is declared but not used. To suppress this warning, use the unused attribute (see Section 6.11 “Variable Attributes”).
-Wunused-parameter Warn whenever a function parameter is unused aside from its declaration. To suppress this warning, use the unused attribute (see Section 6.11 “Variable Attributes”).
-Wunused-variable Warn whenever a local variable or non-constant static variable is unused aside from its declaration. To suppress this warning, use the unused attribute (see Section 6.11 “Variable Attri- butes”).
-Wunused-value Warn whenever a statement computes a result that is explicitly not used. To suppress this warning, cast the expression to void.
The following -W options are not implied by -Wall. Some of them warn about construc­tions that users generally do not consider questionable, but which occasionally you might wish to check for. Others warn about constructions that are necessary or hard to avoid in some cases, and there is no simple way to modify the code to suppress the warning.
2012 Microchip Technology Inc. DS52071B-page 67
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-9: WARNING/ERROR OPTIONS NOT IMPLIED BY -WALL
Option Definition
-W Print extra warning messages for these events:
• A nonvolatile automatic variable might be changed by a call to longjmp. These warnings are possible only in optimizing compilation. The compiler sees only the calls to setjmp. It can not know where longjmp will be called; in fact, a signal handler could call it at any point in the code. As a result, a warning may be generated even when there is in fact no problem, because longjmp cannot in fact be called at the place that would cause a problem.
• A function could exit both via return value; and return;. Completing the function body without passing any return statement is treated as return;.
• An expression-statement or the left-hand side of a comma expression contains no side effects. To suppress the warning, cast the unused expression to void. For example, an expression such as x[i,j] will cause a warning, but x[(void)i,j] will not.
• An unsigned value is compared against zero with < or <=.
• A comparison like x<=y<=z appe ars; thi s is equiv alent to (x<=y ? 1 : 0) <= z, which is a different interpretation from that of ordinary mathematical notation.
• Storage-class specifiers like static are not the first things in a declaration. According to the C Standard, this usage is obsolescent.
•If -Wall or -Wunused is also specified, warn about unused arguments .
• A comparison between s igned and uns igned value s could produce an incorrect result when the signed value is converted to unsigned. (But don’t warn if
-Wno-sign-compare is also specified.)
• An aggregate has a partly bracketed initializer. For example, the follow ing code w ould ev oke such a warning, because braces are mi ss ing around the initiali zer for x.h:
struct s { int f, g; }; struct t { struct s h; int i; }; struct t x = { 1, 2, 3 };
• An aggregate has an initializer that does not initialize all members. For example, the following code would cause such a warnin g, because x.h would be implicitly initialized to zero:
struct s { int f, g, h; }; struct s x = { 3, 4 };
-Waggregate-return Warn if any functions that return structures or unions are
defined or called.
-Wbad-function-cast Warn whenev er a fu nc tio n call is cast to a non-ma tch ing type. For example, warn if int foof() is cast to anything *.
-Wcast-align Warn whenever a pointer is cast, such tha t the required alignment of the target is increased. For example, warn if a
char * is cast to an int * .
-Wcast-qual Warn whenever a pointer is cast, so as to remove a type
qualifier from the target type. For example, warn if a const char * is cast to an ordinary char *.
DS52071B-page 68 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-9: WARNING/ERROR OPTIONS NOT IMPLIED BY -WALL
Option Definition
-Wconversion Warn if a prototype causes a type conversion that is different from what would happen to the same argument in the absence of a prototype. This includes conversions of fixed point to floating an d vic e versa, a nd con versi ons ch angin g th e width or signedness of a fixed point argument, except when the same as the default promotion. Also, warn if a negative integer co nstant expres sion is implicitly converted to an unsigned type. For example, warn about the assignment x = -1 if x is unsigned. But do not warn about explicit casts like (unsigned) -1.
-Werror Make all warnings into errors.
-Winline Warn if a function can not be inlined, and either it was
declared as inline, or else the -finline-functions option was given.
-Wlarger-than-len Warn whene ver an obj ec t of larger than len bytes is defined.
-Wlong-long
-Wno-long-long
-Wmissing-declarations Warn if a global function is defined without a previous
-Wmissing-
format-attribute
-Wmissing-noreturn Warn about functions that might be candidates for attribute
-Wmissing-prototypes Warn if a global function is defined without a previous
-Wnested-externs Warn if an extern declaration is encountered within a
-Wno-deprecated-
declarations
-Wpadded Warn if padding is included in a structure, either to align an
-Wpointer-arith Warn about anything that depends on the size of a function
-Wredundant-decls Warn if anything is declared more than once in the same
-Wshadow Warn whenever a local variable shadows another local
Warn if long long type is used. This is default. To inhibit the warning messages, use -Wno-long-long. Flags
-Wlong-long and -Wno-long-long are taken into ac count only when -pedantic flag is used.
declaration. Do so even if the definition itself provides a prototype.
If -Wformat is enabled, also warn about functions that might be candidates for format attributes. Note these are only possi­ble candidates, not absolute ones. This option has no effect unless -Wformat is enabled.
noreturn. These are only possible candidates, not absolute ones. Care should be taken to manually verify functions. Actually, do not ever return before adding the noreturn attri- bute; otherwise subtle code generation bugs could be intro­duced.
prototype declaration. This warning is issued even if the definition itse lf pro vi des a prot oty pe. (This opti on can be us ed to detect global fu nctions t hat are not d eclared i n heade r files .)
function. Do not warn about uses of functions, variables and types
marked as deprecated by using the deprecated attribute.
element of the structure or to align the whole structure.
type or of void. The compiler assigns these types a siz e of 1, for convenience in calculations with void * pointers and pointers to functions.
scope, even in cases where multiple declaration is valid and changes nothing.
variable.
2012 Microchip Technology Inc. DS52071B-page 69
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-9: WARNING/ERROR OPTIONS NOT IMPLIED BY -WALL
Option Definition
-Wsign-compare
-Wno-sign-compare
-Wstrict-prototypes Warn if a func tion i s decla red or defi ned wi thout s peci fying the
-Wtraditional Warn about certain constructs that behave differently in
-Wundef Warn if an undefined identifier is evaluated in an #if
-Wwrite-strings Give string constants the ty pe const char[length] so tha t
Warn when a comparison between signed and unsigned values could produce an incorre ct resu lt w hen the signe d value is converted to unsigned. This warning is also enabled by -W; to get the other warnings of -W without this warning, use -W -Wno-sign-compare.
argument types. (An old-style function definition is permitted without a warning i f preced ed by a decl aration which s peci fies the argument types.)
traditional and ANSI C.
• Macro arguments occurring within string constants in the macro body. These would substitute the argument in traditio nal C, but ar e part of the constant in ANSI C.
• A function declared external in one block and then used after the end of the block.
• A switch statement has an operand of type long.
• A nonstatic function declaration follows a static one. This construct is not accepted by some traditional C compilers.
directive.
copying the address of one into a non-const char * pointer will get a warning. The se warnings will help you find at compile time code that you can try to write into a string constant, but only if you have been very careful about using const in declarations and prototype s. Otherwise, it will just be a nuisance, which is why -Wall does not request these warnings.

3.7.5 Options for Debugging

The following options are used for debugging.
TABLE 3-10: DEBUGGING OPTIONS
Option Definition
-g Produce debugging information. The compiler suppor t s the use of -g with -O making it possibl e to debug opti- mized code. The shortcuts taken by optimized code may occasionally pro­duce surprising results:
• Some declared variables may not exist at all;
• Flow of control may briefly move unexpectedly;
• Some statements may not be executed because they com pu te constant
results or their values were already at hand;
• Some statements may execute in different places because they were
moved out of loops.
Nevertheless it proves possible to debug optimized output. This makes it reasonable to use the optimizer for programs that might have bugs.
-Q Makes the compiler print out each function name as it is compiled, and print some statistics about each pass when it finishes.
DS52071B-page 70 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-10: DEBUGGING OPTIONS (CONTINUED)
Option Definition
-save-temps Don’t delete intermedi ate fil es. Place them in the current di rec tory an d name them based on the source file. Thus, compiling foo.c with -c
-save-temps would produce the following files: foo.i (preprocessed file) foo.p (pre procedure abstraction assembly language file) foo.s (assembly language file) foo.o (object file)

3.7.6 Options for Controlling Optimization

The following options control compiler optimizations. Optimization levels available depend
on the compiler edition (see Chapter 15. “Optimizations”.)
TABLE 3-11: GENERAL OPTIMIZATION OPTIONS
Option Edition Definition
-O0 All Do not optimize. (This is the default.)
Without -O, the compiler’s goal is to reduce the cost of compilation and to make debugging produce the expected results. Statements are independent: if you sto p the pro gra m w ith a bre ak poi nt bet we en statements, you can then assign a new value to any variable or change the program counter to any other statement in the function and get exactly the results you would expect from the source code. The compiler only allocates variables declared register in regis­ters.
-O
-O1
-O2 STD, PRO Optimize even more. The compiler performs nearly all supported
-O3 PRO Optimize yet more. -O3 turns on all optimizations specified by -O2
All Optimize. Optimizing compilation takes somewhat longer, and a lot
more host memory for a large function. With -O, the compiler tries to reduce code size and execution time. When -O is specified, the compiler turns on -fthread-jumps and
-fdefer-pop. The compiler turns on -fomit-frame-pointer.
optimizations that do not inv ol ve a space-speed trade-off. -O2 turns on all optional optimizations except for loop unrolling (-fun- roll-loops), function inlining ( -finline-functions), and strict aliasing optimizations (-fstrict-aliasing). It also turns on Frame Pointer elimination (-fomit-frame-pointer). As com­pared to -O, this option increases both compilation time and the performance of the generated code.
and also turns on the inline-functions option.
-Os PRO Optimize for size. -Os enables all -O2 optimizations that do no t typi-
cally increase code size. It also performs further optimizations designed to reduce code size.
The following options control specific optimizations. The -O2 option turns on all of these optimizations except -funroll-loops, -funroll-all-loops and
-fstrict-aliasing.
2012 Microchip Technology Inc. DS52071B-page 71
MPLAB® XC16 C Compiler User’s Guide
Y ou can use the following flags in the rare cases when “fine-tuning” of optimizations to be performed is desired.
TABLE 3-12: SPECIFIC OPTIMIZATION OPTIONS
Option Definition
-falign-functions
-falign-functions=n
-falign-labels
-falign-labels=n
-falign-loops
-falign-loops=n
-fcaller-saves Enabl e values to be allo cated in registe rs that will be cl obbered by
-fcse-follow-jumps In common subexpres sion elimination, sca n th rou gh jum p ins truc -
-fcse-skip-blocks This is similar to -fcse-follow-jumps, but causes CSE to fol-
-fexpensive­ optimizations
-ffunction-sections
-fdata-sections
-fgcse Perform a global common subexpression elimination pass. This
Align the start of functions to the next power-of-two greater than n, skipping up to n bytes. For instance,
-falign-functions=32 aligns functions to the next 32-byte boundary, but -falign-functions=24 would align to the next 32-byte boundary onl y i f this ca n be don e by sk ipp ing 23 by tes or less.
-fno-align-functions and -falign-functions=1 are equivalent and mean that functions will not be aligned. The assembler only supports this flag when n is a power of two; so n is rounded up. If n is not spe cified, use a machi ne-dependent default.
Align all branch targets to a power-of-two boundary, skipping up to n bytes like -falign-functions. This option can easily make code slower, because it must insert dummy operations for when the branch target is reached in the usual flow of the code. If -falign-loops or -falign-jumps are applicable and are greater than this value, then their values are used instead. If n is not specified, use a machine-dependent default which is very likely to be 1, meani ng no alignment.
Align loops to a power-of-two boundary, skipping up to n bytes like -falign-functions. The hope is that the loop will be exe­cuted many times, which will make up for any execution of the dummy operations. If n is not specified, use a machine-dependent default.
function calls, by emitting extra instructions to save and restore the registers around suc h calls. Such alloc ation is done only when it seems to result in better code than would otherwise be pro­duced.
tions when the target of the jump is not reached by any other path. For example, when CSE encounters an if statement with an else clause, CSE will follow the jump when the condition tested is false.
low jumps which conditionally skip over blocks. When CSE encounters a simple if statement with no else clause,
-fcse-skip-blocks causes CSE to follow the jum p around the body of the if.
Perform a number of minor optimizations that are relatively expensive.
Place each function or data item into its own sec tio n in th e output file. The name of the function or the name of the data item deter­mines the section’ s name in the out put fil e. Only use these options when there are significant benefits for doing so. When you specify these options, the assembler and linker may create larger object and executable files and will also be slower.
pass also performs global constant and copy propagation.
DS52071B-page 72 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-12: SPECIFIC OPTIMIZATION OPTIONS (CONTINUED)
Option Definition
-fgcse-lm When -fgcse-lm is enabled, global common subexpression
elimination will attempt to move loads which are only killed by stores into themselv es. This allows a loop con taining a load/store sequence to be changed to a load outside the loop, and a copy/store within the loop.
-fgcse-sm When -fgcse-sm is enabled, a store motion pass is run after
global common subexpression elimination. This pass will attempt to move stores out of loops. When used in conjunction with
-fgcse-lm, loops containing a load/store sequence can be changed to a load before the loop and a store after the loop.
-fno-defer-pop Always pop the arguments to each function call as soon as that
function returns. The compiler normally lets arguments accumu­late on the stack for several function calls and pops them all at once.
-fno-peephole
-fno-peephole2
-foptimize-
register-move
-fregmove
-frename-registers Attempt to avoid false dependencies in scheduled code by mak-
-frerun-cse-after-
loop
-frerun-loop-opt Run the loop optimizer twice.
-fschedule-insns Attempt to reorder instructions to eliminate dsPIC® DSC
-fschedule-insns2 Similar to -fschedule-insns, but requests an additional pas s
-fstrength-reduce Perform the optimizations of loop strength reduction and
Disable machine specific peephole optimizations. Peephole opti­mizations occur at various points during the compilation.
-fno-peephole disables peephole optimization on machine instructions, while -fno-peephole2 disables high level peep­hole optimizatio ns . To disable peephole e nti rely, use both options.
Attempt to reassign r egi ste r num be rs i n m ov e in stru ctions and as operands of other simple instructions in order to maximize the amount of register tying.
-fregmove and -foptimize-register-moves are th e same optimization.
ing use of registers left over after register allocation. This optimi­zation will most benefit processors with lots of registers. It can, however, make debugging impo ss ib le, si nce variables will no lon­ger stay in a “home register”.
Rerun common subexpression elimination after loop optimizations has been performed.
Read-After-Write stalls (see the “dsPIC30F Family Reference Manual” (DS70046) for more details). Typically improves performance with no impact on code size.
of instruction scheduling after register allocation has been done.
elimination of iteration variables.
2012 Microchip Technology Inc. DS52071B-page 73
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-12: SPECIFIC OPTIMIZATION OPTIONS (CONTINUED)
Option Definition
-fstrict-aliasing Allows the compiler to assume the strictest aliasing rules applica­ble to the language being compiled. For C, this activates optimizations based on the type of expressions. In par­ticular, an object of one type is assumed never to reside at the same address as an object of a different type, unless the types are almost the same. For example, an unsigned int can alias an int, but not a void* or a double. A character type may a lias any other type. Pay special attention to code like this:
union a_union { int i; double d; };
int f() { union a_union t; t.d = 3.0; return t.i; }
The practice of reading from a different union member than the one most recently written to (called “type-punning”) is common. Even with -fstrict-aliasing, type-punning is allowed, pro­vided the memory is accessed through the union type. So, the code above will work as expected. However, this code might not:
int f() { a_union t; int* ip; t.d = 3.0; ip = &t.i; return *ip; }
-fthread-jumps Perform optimizations where a check is made to see if a jump
branches to a location where another comparison subsumed by the first is found. If so, the first branch is redirected to either the destination of the second branch or a point immediately following it, depending on whether the condition is known to be true or false.
-funroll-loops Perform the optimization of loop unrolling. This is only done for loops whose number of iterations can be determined at compile time or run time. -funroll-loops implies both
-fstrength-reduce and -frerun-cse-after-loop.
-funroll-all-loops Perform the optimization of loop unrolling. This is done for all
loops and usually makes programs run more slowly.
-funroll-all-loops implies -fstrength-reduce, as well as -frerun-cse-after-loop.
DS52071B-page 74 2012 Microchip Technology Inc.
Compiler Command-Line Driver
Options of the form -fflag specify machine-independent flags. Most flags have both positive and negative forms; the negative form of -ffoo would be -fno-foo. In the table below, only one of the forms is listed (the one that is not the default.)
TABLE 3-13: MACHINE-INDEPENDENT OPTIMIZATION OPTIONS
Option Definition
-finline-functions Integrate all simple func tions into th eir calle rs. The comp iler heuristically decides which functions are simple enough to be worth integrating in this way. If all calls to a given func­tion are integrated, and the function is declared static, then the function is normally not output as assembler code in its own right.
-finline-limit=n By default, the compiler limits the size of functions that can be inlined. This flag allows the control of this limit for func­tions that are explicitly marked as inline (i.e., marked with the inline keyword). n is the size of functions that can be inlined in number of pseudo instructions (not counting parameter handling). The default value of n is 10000. Increasing this value can result in more inlined code at the cost of compilation time and memory consumption. Decreasing usually makes the compilation faster and less code will be inlined (which presumably means slower programs). This option is particularly useful for programs that use inlining.
Note: Pseudo instruction represents, in this particular con­text, an abstract measurement of function’s size. In no way does it represent a count of assembly instructions and as such, its exact meaning might change from one release of the compiler to an another.
-fkeep-inline-functions Even if all calls to a given function are integrated, and the function is declared static, output a separate run time callable version of the function. This switch does not affect
extern inline functions.
-fkeep-static-consts Emit variables declared static const when optimization isn’t
turned on, even if the variables aren’t referenced. The compiler enables this option by default. If you want to force the compiler to check if the variable was referenced, regardless of whether or not optimization is turned on, use the -fno-keep-static-consts option.
-fno-function-cse Do not put function addresses in registers; make each instruction that calls a constant function contain the function’s addres s exp lic itl y. This option results in less efficient code, but some strange hacks that alter the ass embler output may be confu sed by the optimizations performed when this option is not used.
-fno-inline Do not pay attention to the inline keyword. Normally this option is used to keep the compiler from expanding any functions inline. If optimization is not enabled, no functions can be expanded inline.
-fomit-frame-pointer Do not keep the Frame Pointer in a register for functions that don’t need one. Thi s avoids the inst ructions to sav e, set up and restore Frame Pointers; it also makes an extra reg­ister available in many functions.
-foptimize-sib-
ling-calls
Optimize sibling and tail recursive calls.
2012 Microchip Technology Inc. DS52071B-page 75
MPLAB® XC16 C Compiler User’s Guide

3.7.7 Options for Controlling the Preprocessor

The following options control the compiler preprocessor.
TABLE 3-14: PREPROCESSOR OPTIONS
Option Definition
-Aquestion (answer) Assert the answer answer for question question, in ca se it is tested with a preprocessing conditional such as #if #question(answer). -A- disables the standard assertions that normally describe the target machine. For example, the function prototype for main might be declared as follows:
#if #environ(freestanding) int main(void); #else int main(int argc, char *argv[]); #endif
A -A command-line option could then be used to select between the two prototypes. For example, to select the first of the two, the following command-line option could be used:
-Aenviron(freestanding)
-A -predicate =answer Cancel an assertion with the p redi cate predicate and answer
answer.
-A predicate =answer Make an assertion with the predicate predicate and answer answer. This form is preferred to the older form
-A predicate(answer), which is still supported, because it does not use shell special characters.
-C Tell the preprocessor not to discard comments. Used with the
-E option.
-dD Tell the preprocessor to not remove macro definitions into the
output, in their proper sequence.
-Dmacro Define macro macro with the string 1 as its definition.
-Dmacro=defn Define macro macro as defn. All instances of -D on the command line are processed before any -U options.
-dM Tell the preprocessor to output only a list of the macro
definitions that are in effect at the end of preprocessing. Used with the -E option.
-dN Like -dD except that the macro arguments and contents are omitted. Only #define name is included in the output.
-fno-show-column Do not print column numbers in diagnostics. This may be necessary if diagnostics are being scanned by a program that does not understand the column numbers, such as dejagnu.
-H Print t he nam e o f e ac h h ead er fi le us ed, in addition to oth er n or­mal activities.
DS52071B-page 76 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-14: PREPROCESSOR OPTIONS (CONTINUED)
Option Definition
-I- Any directories you specify with -I options before the -I- options are searched only for the case of #include "file"; they are not searched for #include <file>. If additional directories are specified with -I options after the
-I-, these directories are searched for all #include directives. (Ordinarily all -I directories are used this way.) In addition, the -I- option inhibits the use of the current directory (where the current input file came from) as the first search directory for #include "file". There is no way to override this effect of -I-. With -I. you can speci fy se ar c hin g the directory that was current when the compiler was invoked. That is not exactly the same as what the preprocessor does by default, but it is often satisfactory.
-I- does not inhibit the use of the standard system directories for header files. Thus, -I- and -nostdinc are independent.
-Idir Add the directory dir to the head of the list of directories to be searched for header files. This can be used to override a system header file, substituting your own version, since these directories are searched before the system header file directories. If you use more than one -I option, the directories are scanned in left-to-right order; the standard system directories come after.
-idirafter dir Add the directory dir to the second include path. The directories on the second include path are searched when a header file is not found in any of the directories in the main include path (the one that -I adds to).
-imacros file Process file as input, discard ing the res ulting output, be fore pro- cessing the regular input file. Because the output generated from the file is discarded, the only effect of -imacros file is to make the macros defined in file available for use in the main input. Any -D and -U options on the command line are always processed before -imacros file, regardless of the order in which they are written. All the -include and -imacros options are processed in the order in which they are written.
-include file Process file as input before processing the regular input file. In effect, the contents of file are compiled first. Any -D and -U options on the command line are always processed before
-include file, rega rdless of the orde r in which they are writ- ten. All the -include and -imacros op tio ns are processed in the order in which they are written.
-iprefix prefix Specify prefix as the prefix for subsequent -iwithprefix options.
-isystem dir Add a directory to the beginning of the second include path, marking it as a system directory, so that it gets the same special treatment as is applied to the standard system directories.
-iwithprefix dir Add a directory to the second include path. The directory’s name is made by concatenating prefix and dir, where prefix was specified previously with -iprefix. If a prefix has not yet been specified, the directory containing the installed passes of the compiler is used as the default.
-iwithprefixbefore
dir
Add a directory to the main include path. The directory’s name is made by concatenating prefix and dir, as in the case of
-iwithprefix.
2012 Microchip Technology Inc. DS52071B-page 77
MPLAB® XC16 C Compiler User’s Guide
TABLE 3-14: PREPROCESSOR OPTIONS (CONTINUED)
Option Definition
-M Tell the preprocessor to output a rule suitable for make describ- ing the dependencies of each object file. For each source file, the preprocessor outputs one make-rule whose target is the object file name for that source file and whose dependencies are all the #include header files it uses. This rule may be a single line or may be continued with \-newline if it is long. The list of rules is printed on standard output instead of the prepro­cessed C program.
-M implies -E (see Section 3.7.2 “Options for Controlling the Kind of Output”).
-MD Like -M but the dependency information is written to a file and compilation contin ues . The file contai nin g th e dependency infor­mation is given the same name as the source file with a .d extension.
-MF file When us ed with -M or -MM, specifies a file in which to write the dependencies. If no -MF switch is given, the preprocessor sends the rules to the same place it would have sent preprocessed output. When used with the driver options, -MD or -MMD, -MF, overrides the default dependency output file.
-MG Treat missi ng hea der file s as gen erated files and assume they live in the same directory as the source file. If -MG is specified, then either -M or -MM must also be specified. -MG is not supported with -MD or -MMD.
-MM Like -M but the output mentions only the user header files included with #include “file”. System header files included with #include <file> are omitted.
-MMD Like -MD except mention only user header files, not system header files.
-MP This option instructs CPP to add a phony ta rget for ea ch depen­dency other than the main file, causing eac h to depend on noth­ing. These dummy rules work around errors make gives if you remove header files without updating the make-file to match. This is typical output:
test.o: test.c test.h test.h:
-MQ Same as -MT, but it quotes any characters which are special to make.
-MQ '$(objpfx)foo.o' gives foo.c
The default target is automatically quoted, as if it were given with -MQ.
-MT target Change the target of the rule emitted by dependency generation. By default, CPP takes the name of the main input file, incl uding any path, deletes any file suffix such as .c, and appends the platform’s usual object suffix. The result is the target. An -MT option will set the target to be exactly the string you specify. If you want mul tiple targets, you can specify them as a single argument to -MT, or use multiple -MT options. For example:
-MT '$(objpfx)foo.o' might give $(objpfx)foo.o: foo.c
$$(objpfx)foo.o:
DS52071B-page 78 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-14: PREPROCESSOR OPTIONS (CONTINUED)
Option Definition
-nostdinc Do not search the standard system directories for header files. Only the direct ories you ha ve s pecifi ed w ith -I options (and the current directory, if appropriate) are searched. (See Section 3.7.10 “Options for Directory Search”) for information on -I. By using both -nostdinc and -I-, the inclu de-file search path can be limited to only those directories explicitly specified.
-P Tell the preprocessor not to generate #line directives. Used with the -E option (see Section 3.7.2 “Options for Controlling the Kind of Output”).
-trigraphs Support ANSI C trigraphs. The -ansi option also has this effect.
-Umacro Undefine macro macro. -U options are evaluated after all -D options, but before any -include and -imacros options.
-undef Do not predefine any nonstandard macros (inclu din g architecture flags).

3.7.8 Options for Assembling

The following options control assembler operations. For more on available options, see the MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
TABLE 3-15: ASSEMBLY OPTIONS
Option Definition
-Wa,option Pass option as an option to the assembler. If option contains
commas, it is split into multiple options at the commas. For example, to generate an assembly list file, use -Wa,-a.

3.7.9 Options for Linking

2012 Microchip Technology Inc. DS52071B-page 79
MPLAB® XC16 C Compiler User’s Guide
If any of the options -c, -S or -E are used, the linker is not run and object file names should not be used as arguments. For more on available options, see the MPLAB
Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
TABLE 3-16: LINKING OPTIONS
Option Definition
--fill=options Fill unused program memory. The format is:
--fill=[wn:]expression[@address[:end_address] | unused]
address and end_address will spec ify the rang e of prog ram memor y
addresses to fill. If end_address is not pro vided the n the expression will be written to the spec ific m emory loc ation a t addres s address. T he optional literal value unused may be specified to indicate that all unused memory will be filled. If non e of the lo cation parameters are pro­vided, all unused memory will be filled. expression will describe how to fill the specified memory. The following options are available: A single value
xc16-ld --fill=0x12345678@unused
Range of values
xc16-ld --fill=1,2,3,4,097@0x9d000650:0x9d000750
An incrementing value
xc16-ld --fill=7+=911@unused
By default, the linker will fill using data that is instruction-word length. For 16-bit devices, the default fill width is 24 bits. However, you may specify the value wid th using [wn:], where n is the fill valu e's wid th and n belongs to [1, 3].
Multiple fill optio ns ma y be s pecif ied on the comm and li ne; the lin ker wil l always process fill options at specific locations first.
--gc-sections Remove dead functions from code at link time. Support is for ELF projects only. In order to make the best use of this feature, add the -ffunction-sections option to the compiler command line.
-Ldir Add directo ry dir to the list of directories to be searched for libraries specified by the command-line option -l.
-legacy-libc Use legacy include files and libraries (v3.24 and before). The format of include file and libraries changed in v3.25 to match HI-TECH C compiler format.
DS52071B-page 80 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-16: LINKING OPTIONS (CONTINUED)
Option Definition
-llibrary Search the library named library when linking. The linker searches a standard list of directories for the library, which is actually a file nam ed liblibrary.a. The linker then uses this file as if it had been specified precisely by name. It makes a difference where in the command you write this option; the linker processes librarie s and obj ect file s in the order they are spec ified. Thus, foo.o -lz bar.o sea rch es li brary z after file foo.o but before bar.o. If bar.o refers to functions in libz.a, those functions may not be loaded. The directories searched include several standard system directories, plus any that you specify with -L. Normally the files found this way are library files (archive files whose members are object file s). The linke r handles an arch ive file by sca nning through it for members which define symbols that have so far been referenced but not defined. But if the file that is found is an ordinary object file, it is linked in the usual fashion. The only difference between using an -l option (e.g., -lmylib) and specifying a file name (e.g., libmylib.a) is that -l searches several directories, as specified. By default the linker is directed to search:
<install-path>\lib
for libraries specified with the -l option. This behavior can be overridden using the environment variables defined in Section 16.4 “Predefined Macro Names”.
-nodefaultlibs Do not use the standard syst em lib raries w hen li nking . Only the libr arie s you specify will be pas sed to the linker. The compiler may generate ca lls to memcmp, memset and memcpy. These entries are usua lly res olve d by entries in the standard compiler libraries. These entry points should be supplied through some other mechanism when this option is specified.
-nostdlib Do not use the standard system st artup files or librari es when linking. No startup files and only the libraries you specify will be passed to the linker. The compiler may generate calls to memcmp, memset and memcpy. These entries are usually resolved by entries in standard compiler libraries. These entry points should be supplied through some other mechanism when this option is specified.
-s Remove all symbol table and relocation information from the executable.
-T script Speci fy th e linker script file, script, to be us ed at link tim e. This opt ion is translated into the equivalent -T linke r option.
-u symbol Pretend symbol is undefined to force linking of library modules to define the symbol. It is legitimate to use -u multiple times with different symbols to force loading of additional library modules.
-Wl,option Pass option as an option to the linker. If option contains commas, it is split into multiple options at the commas. For example, to generate a map file, use
-Xlinker option Pass option as an option to the linker. You can use this to supply system-specific linker options that the compiler does not know how to recognize.
-W1, -Map=Project.map.
2012 Microchip Technology Inc. DS52071B-page 81
MPLAB® XC16 C Compiler User’s Guide

3.7.10 Options for Directory Search

The following options specify to the compiler where to find directories and files to search.
TABLE 3-17: DIRECTORY SEARCH OPTIONS
Option Definition
-specs=file Process file after the compiler read s in t he standard specs file, in order to override the defaults that the xc16-gcc driver program uses when determining what switches to pass to xc16-cc1, xc16-as, xc16-ld, etc. More than one -specs=file can be specified on the command line, and they are processed in order, from left to right.

3.7.11 Options for Code Generation Conventions

Options of the form -fflag specify machine-independent flags. Most flags have both positive and negative forms; the negative form of -ffoo would be -fno-foo. In the table below, only one of the forms is listed (the one that is not the default.)
TABLE 3-18: CODE GENERATION CONVENTION OPTIONS
Option Definition
-fargument-alias
-fargument-noalias
-fargument-
noalias-global
-fcall-saved-reg Treat the register named reg as an allocatable register save d by
-fcall-used-reg Treat the register named reg as an allocatable register that is
-ffixed-reg Treat the register named reg as a fixed register; generated code
-fno-ident Ignore the #ident directive.
Specif y the poss ible relations hips among p arameters and b etween parameters and global data.
-fargument-alias specifies that arguments (parameters) may alias each other and may alias global storage.
-fargument-noalias specifies that arguments do not alias each other, but may alias global storage.
-fargument-noalias-global specifies th at a r gum en t s do n ot alias each other and do not alias global storage. Each language will automatically use whatever option is required by the language standard. You should not need to use these options yourself.
functions. It may be allocated even for temporaries or variables that live across a call. Functions compiled this way will save and restore the register reg if they use it. It is an error to used this flag with the Frame Pointer or Stack Pointer. Use of this flag for other registers that have fixed perva­sive roles in the machine’s execution model will produce disas­trous results. A different sort of disaster will result from the use of this flag for a register in which function values may be returned. This flag should be used consistently through all modules.
clobbered by function calls. It may be allocated for temporaries or variables that do not live across a cal l. Functions com piled this wa y will not save and restore the register reg. It is an error to use this flag with the Frame Pointer or Stack Pointer. Use of this flag for other registers that have fixed perva­sive roles in the machine’s execution model will produce disas­trous results. This flag should be used consistently through all modules.
should never refer to it (except perhaps as a Stack Pointer, Frame Pointer or in some other fixed role). reg must be the name of a register, e.g., -ffixed-w3.
DS52071B-page 82 2012 Microchip Technology Inc.
Compiler Command-Line Driver
TABLE 3-18: CODE GENE RATION CONVENTION OPTIONS (CONTINUED)
Option Definition
-fpack-struct Pack all structure members together without holes. Usually you would not want to use this option, since it makes the code sub-optimal, and t he offs ets o f struct ure membe rs won’t agree wit h system libraries. The dsPIC® DSC device requires that words be aligned on even byte boundaries, so care must be taken when using the packed attribute to avoid run time addressing errors.
-fpcc-struct-
return
-fno-short-double By default, the c om pil er u ses a double type equivalent to float.
-fshort-enums Allocate to an enum type only as many bytes as it needs for the
-fverbose-asm
-fno-verbose-asm
-fvolatile Consider all memory references through pointers to be volatile.
-fvolatile-global Consider all memory references to external and global data items
-fvolatile-static Consider all memory references to static data to be volatile.
Return short struct and union values in memory like longer ones, rather than in registers. This convention is less efficient, but it has the advantage of allowing capability between the 16-bit com­piler compiled files and files compiled with other compilers. Short structures and unions are those whose size and alignment match that of an integer type.
This option makes double equivalent to long double. Mixing this option across modules can have unexpected results if modules share double data either directly through argument passage or indirectly through shared buffer space. Libraries provided with the product function with either switch setting.
declared range of possible values. Specifically, the enum type will be equivalent to the smallest integer type which has enough room.
Put extra commenta ry informa tion in the generated assembly c ode to make it more readable.
-fno-verbose-asm, the default, causes the extra information to be omitted and is useful when comparing two assembler files.
to be volatile. The use of this switch has no effect on static data.

3.8 MPLAB IDE TOOLSUITE EQUIVALENTS

For information on related compiler options in MPLAB IDE, see the MPLAB Assembler , Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
2012 Microchip Technology Inc. DS52071B-page 83
MPLAB® XC16 C Compiler User’s Guide
DS52071B-page 84 2012 Microchip Technology Inc.

Chapter 4. Device-Related Features

4.1 INTRODUCTION

The MPLAB XC16 C Compiler provides some features that are purely device-related.
• Device Support
• Device Header Files
•Stack
• Configuration Bit Access
• Using SFRs in MCUs
• Bit-Reversed and Modulo Addressing

4.2 DEVICE SUPPORT

As discussed in Chapter 1. “Compiler Overview”, the compiler supports all Microchip 16-bit devices; dsPIC30/33 digital signal controls (DSCs) and PIC24 microcontrollers (MCUs).
To determine the device support for your version of the compiler, consult the release notes file, README.html, in the installation folder. For MPLAB IDE users, select
Help>Release Notes
MPLAB® XC16 C COMPILER
USER’S GUIDE
.

4.3 DEVICE HEADER FILES

One header file that is typically included in each C source file you will write is xc.h, a generic header file that will include other device- and architecture-specific header files when you build your project.
Inclusion of this file will allow access to SFRs via special variables, as well as macros which allow special memory access or inclusion of special instructions.
Avoid including chip-specific header files into your code, as this will reduce portability. However, device-specific compiler header files are stored in the support\family\h directory for reference.
For information about assembly include files (*.inc), see the assembler documentation.

4.3.1 Register Definition Files

The processor header files described in Section 4.5 “Configuration Bit Access” name all SFRs for each part, but they do not define the addresses of the SFRs. A sep­arate set of device-specific linker script files, one per part, is distributed in the support\family\gld directory. These linker script files define the SFR addresses. To use one of these files, specify the linker command-line option:
-T p30fxxxx.gld
where xxxx corresponds to the device part number. For example, assuming that there is a file named app2010.c that contains an appli-
cation for the dsPIC30F2010 part, then it may be compiled and linked using the following command line:
xc16-gcc -mcpu=30f2010 -o app2010.out -T p30f2010.gld app2010.c
2012 Microchip Technology Inc. DS52071B-page 85
MPLAB® XC16 C Compiler User’s Guide
The -o command-line option names the output executable file, and the -T option gives the linker script name for the dsPIC30F2010 part. If p30f2010.gld is not found in the current directory , the linker searches in its known library paths. The default search path includes all locations of preinst alled libraries and linker scripts.
You should copy the appropriate linker script file (supplied with the compiler) into your project directory before any project-specific modifications are made.

4.4 STACK

The 16-bit devices use what is referred to in this user’s guide as a “software stack”. This is the typical stack arrangement employed by most computers and is ordinary data memory accessed by a push-and-pop type instruction and a stack pointer register. The term “hardware stack” is used to describe the stack employed by Microchip 8-bit devices, which is only used for storing function return addresses.
The 16-bit devices dedicate register W15 for use as a software Stack Pointer. All processor stack operations, including function calls, interrupts and exceptions, use the software stack. The stack grows upward, towards higher memory addresses.
The dsPIC DSC device also supports stack overflow detection. If the Stack Pointer Limit register, SPLIM, is initialized, the device will test for overflow on all stack opera­tions. If an overfl ow shoul d occ ur , the proc esso r will in itia te a st ack er ror ex cepti on. By default, this will result in a processor Reset. Applications may also install a stack error exception handler by defining an interrupt function named _StackError. See Chap- ter 11. “Interrupts” for details.
The C run-time startup module initializes the Stack Pointer (W15) and the Stack Pointer Limit register during the startup and initialization sequence. The initial values are normally provided by the linker, which allocates the largest stack possible from unused data memory. The location of the stack is reported in the link map output file. Applications can ensure that at least a minimum-sized stack is available with the
--stack linker command-line option. See the MPLAB Assembl er, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317) for details.
Alternatively, a stack of specific size may be allocated with a user-defined section from an assembly source file. In the following example, 0x100 bytes of data memory are reserved for the stack:
.section *,data,stack .space 0x100
The linker will allocate an appropriately sized section and initialize __SP_init and __SPLIM_init so that the run-time startup code can properly initialize the stack. Note
that since this is a normal assembly code section, attributes such as address may be used to further define the stack. Please see the MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317) for more information.

4.5 CONFIGURATION BIT ACCESS

Microchip devices have several locations which contain the configuration bits or fuses. These bits specify fundamental device operation, such as the oscillator mode, watch­dog timer, programming mode and code protection. Failure to correctly set these bits may result in code failure or a non-running device.
Configuration settings macros are provided that can be used to set configuration bits. For details, see Appendix G. “XC16 Configuration Settings”.
DS52071B-page 86 2012 Microchip Technology Inc.

4.6 USING SFRS

The Special Function Registers (SFRs) are registers which control aspects of the MCU operation or that of peripheral modules on the device. These registers are device mem­ory mapped, which means that they appear at, and can be accessed using, specific addresses in the device’s data memory space. Individual bits within some registers control independent features. Some registers are read-only; some are write-only . See your device data sheet for more information.
Memory-mapped SFRs are accessed by special C variables that are placed at the address of the r egister. These vari ab le s ca n be ac ce sse d like an y or di na ry C var ia b le so that no special syntax is required to access SFRs.
The SFR variable identifiers are predefined in header files and are accessible once you have included the <xc.h> header file (see Section 4.3 “Device Header Files”) into your source code. Structures with bit-fields are also defined so you may access bits within a register in your source code.
A linker script file for the appropriate device must be linked into your project to ensure the SFR variable identifiers are linked to the correct address. MPLAB IDE will link in a default linker script, but a linker script file must be explicitly specified if you are driving the command-line toolchain. Linker scripts have a .gld extension (e.g. p30F6014.gld) and basic files are provided with the compiler.
The convention in the processor header files is that each SFR is named, using the same name that appears in the data sheet for the part – for example, CORCON for the Core Control register. If the register has individual bits that might be of interest, then there will also be a structure defined for that SFR, and the name of the structure will be the same as the SFR name, with “bits” appended. For example, CORCONbits for the Core Control register. The individual bits (or bit fields) are named in the structure using the names in the data sheet – for example PSV for the PSV bit of the CORCON register.
Here is the complete definition of CORCON (subject to change):
/* CORCON: CPU Mode control Register */ extern volatile unsigned int CORCON typedef struct tagCORCONBITS { unsigned IF :1; /* Integer/Fractional mode */ unsigned RND :1; /* Rounding mode */ unsigned PSV :1; /* Program Space Visibility enable */ unsigned IPL3 :1; unsigned ACCSAT :1; /* Acc saturation mode */ unsigned SATDW :1; /* Data space write saturation enable */ unsigned SATB :1; /* Acc B saturation enable */ unsigned SATA :1; /* Acc A saturation enable */ unsigned DL :3; /* DO loop nesting level status */ unsigned :4; } CORCONBITS; extern volatile CORCONBITS CORCONbits __attribute__((__sfr__));
Device-Related Features
__attribute__((__sfr__));
Note: The symbols CORCON and CORCONbits refer to the same register and will
resolve to the same address at link time.
See MPLAB Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317) for more information on using linker scripts.
For example, the following is a sample real-time clock. It uses an SFR, e.g. TMR1, as well as bits within an SFR, e.g. T1CONbits.TCS. Descriptions for these SFRs are found in the p30F6014.h file (this file will automatically be included by <xc.h> so you do not need to include this into your source code). This file would be linked with the device specific linker script which is p30F6014.gld.
2012 Microchip Technology Inc. DS52071B-page 87
MPLAB® XC16 C Compiler User’s Guide
EXAMPLE 4-1: SAMPLE REAL-TIME CLOCK
/* ** Sample Real Time Clock for dsPIC ** ** Uses Timer1, TCY clock timer mode ** and interrupt on period match */
#include <xc.h>
/* Timer1 period for 1 ms with FOSC = 20 MHz */ #define TMR1_PERIOD 0x1388
struct clockType { unsigned int timer; /* countdown timer, milliseconds */ unsigned int ticks; /* absolute time, milliseconds */ unsigned int seconds; /* absolute time, seconds */ } volatile RTclock;
void reset_clock(void) { RTclock.timer = 0; /* clear software registers */ RTclock.ticks = 0; RTclock.seconds = 0;
TMR1 = 0; /* clear timer1 register */ PR1 = TMR1_PERIOD; /* set period1 register */ T1CONbits.TCS = 0; /* set internal clock source */ IPC0bits.T1IP = 4; /* set priority level */ IFS0bits.T1IF = 0; /* clear interrupt flag */ IEC0bits.T1IE = 1; /* enable interrupts */
SRbits.IPL = 3; /* enable CPU priority levels 4-7*/ T1CONbits.TON = 1; /* start the timer*/ }
__attribute__((__interrupt__,__auto_psv__)) _T1Interrupt(void)
void { static int sticks=0;
if (RTclock.timer > 0) /* if countdown timer is active */ RTclock.timer -= 1; /* decrement it */ RTclock.ticks++; /* increment ticks counter */ if (sticks++ > 1000) { /* if time to rollover */ sticks = 0; /* clear seconds ticks */ RTclock.seconds++; /* and increment seconds */ }
IFS0bits.T1IF = 0; /* clear interrupt flag */ return; }
DS52071B-page 88 2012 Microchip Technology Inc.
Device-Related Features

4.7 BIT-REVERSED AND MODULO ADDRESSING

Bit-reversed and modulo addressing is supported on all dsPIC devices. Bit-reversed addressing is used for simplifying and speeding-up the writes to X-space
data arrays in FFT (Fast Fourier Transform) algorithms. When enabled, pre-increment or post-increment addressing modes will reverse the lower order address bits used by instructions.
Modulo, or circular, addressing provides an automated means to support circular data buffers using the dsPIC hardware. When used, software no longer needs to perform data address boundary checks on arrays.
The compiler does not directly support the use of bit-reversed and modulo addressing; that is, it cannot generate code from C source that assumes these addressing modes are enabled when accessing memory. If either of these addressing modes are set up on the target device, then it is the programmer’s responsibility to ensure that the com­piler does not use those registers that are specified to use either modulo or bit-reversed addressing as pointers. Particular care must be exercised if interrupts can occur while one of these addressing modes is enabled.
It is possible to define arrays in C that will be suitably aligned in memory for modulo addressing by hand-written assembly language functions. The aligned attribute may be used to define arrays that are positioned for use as incrementing modulo buffers. Initialization of the start and end addresses, as well as the registers that modulo address is applied must be written by hand to match the array specification. The reverse attribute may be used to define arrays that are positioned for use as decre­menting modulo buffers. For more information on these attributes, see Section 10.2.1 “Function Specifiers”. For more information on bit-reversed or mod­ulo addressing, see Chapter 3 of the “dsPIC30F Family Reference Manual” (DS70046).
2012 Microchip Technology Inc. DS52071B-page 89
MPLAB® XC16 C Compiler User’s Guide
NOTES:
DS52071B-page 90 2012 Microchip Technology Inc.
MPLAB® XC16 C COMPILER
USER’S GUIDE

Chapter 5. Differences Between MPLAB XC16 and ANSI C

This compiler conforms to the ANS X3.159-1989 Standard for programming languages. This is commonly called the C89 Standard. It is referred to as the ANSI C Standard in this manual. Some features from the later standard C99 are also supported.
• Divergence from the ANSI C Standard
• Extensions to the ANSI C Standard
• Implementation-Defined Behavior

5.1 DIVERGENCE FROM THE ANSI C STANDARD

There are no divergences from the ANSI C standard.

5.2 EXTENSIONS TO THE ANSI C STANDARD

The MPLAB XC16 C Compiler provides extensions to the ANSI C standard in these areas: keywords and expressions.

5.2.1 Keyword Differences

The new keywords are part of the base GCC implementation and the discussions in the referenced sections are based on the standard GCC documentation, tailored for the specific syntax and semantics of the 16-bit compiler port of GCC.
• Specifying Attributes of Variables – Section 6.11 “Variable Attributes”
• Specifying Attributes of Functions – Section 10.2.1 “Function Specifiers”
• Inline Functions – Section 10.6 “Inline Functions”
• Variables in Specified Registers – Section 7.9 “Allocation of Variables to Reg-
isters”
• Complex Numbers – Section 6.7 “Complex Data Types”

5.2.2 Expression Differences

Expression differences are:
• Binary Constants – Section 6.8 “Literal Constant Types and Formats”.

5.3 IMPLEMENTATION-DEFINED BEHAVIOR

Certain features of the ANSI C standard have implementation-defined behavior. This means that the exact behavior of some C code can vary from compiler to compiler.
The exact behavior of the MPLAB XC16 C Compiler is detailed throughout this documentation, and is fully summarized in Appendix A. “Implementation-Defined Behavior”.
2012 Microchip Technology Inc. DS52071B-page 91
MPLAB® XC16 C Compiler User’s Guide
NOTES:
DS52071B-page 92 2012 Microchip Technology Inc.

Chapter 6. Supported Data Ty pe s and Variables

6.1 INTRODUCTION

The MPLAB XC16 C Compiler supports a variety of data types and qualifiers (attri­butes). These data types and variables are discussed here. For information on where variables are stored in memory, see Chapter 7. “Memory Allocation and Access”.
• Identifiers
• Integer Data Types
• Floating-Point Data Types
• Structures and Unions
• Pointer Types
• Complex Data Types
• Literal Constant Types and Formats
• Standard Type Qualifiers
• Compiler-Specific type Qualifiers
• Variable Attributes
MPLAB® XC16 C COMPILER
USER’S GUIDE

6.2 IDENTIFIERS

A C variable identifier (as well as a function identifier) is a sequence of letters and digits where the underscore character, “_”, counts as a letter. Identifiers cannot start with a digit. Although they may start with an underscore, such identifiers are reserved for the compiler’s use and should not be defined by your programs. Such is not the case for assembly domain identifiers, which often begin with an underscore, see the MPLAB
Assembler, Linker and Utilities for PIC24 MCUs and dsPIC DSCs User’s Guide (DS51317).
Identifiers are case sensiti ve , so main is different from Main. All characters are significant in an identifier, although identifiers longer than 31
characters in length are less portable.
2012 Microchip Technology Inc. DS52071B-page 93
MPLAB® XC16 C Compiler User’s Guide

6.3 INTEGER DATA TYPES

Table 6-1 shows integer data types that are supported in the compiler. All unspecified or signed integer data types are arithmetic type signed integer. All unsigned integer data types are arithmetic type unsigned integer.
TABLE 6-1: INTEGER DATA TYPES
Type Bits Min Max
char, signed char 8 -128 127 unsigned char 80255 short, signed short 16 -32768 32767 unsigned short 16 0 65535 int, signed int 16 -32768 32767 unsigned int 16 0 65535 long, signed long 32 -2 unsigned long 32 0 2 long long*, signed long long* 64 -2 unsigned long long* 64 0 2
* ANSI-89 extension
31
63
231 - 1
32
- 1
263 - 1
64
- 1
There is no type for storing single bit quantiti es. All integer values are specified in little endian format, which means:
• The least significant byte (LSB) is stored at the lowest address
• The least significant bit (LSb) is stored at the lowest-numbered bit position As an example, the long value of 0x12345678 is stored at address 0x100 as follows:
0x100 0x101 0x102 0X103
0x78 0x56 0x34 0x12
As another example, the long value of 0x12345678 is stored in registers w4 and w5:
w4 w5
0x5678 0x1234
Signed values are stored as a two’s complement integer value. Preprocessor macros that specify integer minimum and maximum values are available
after including <limits.h> in your source code, located by default in:
<install directory>\include
As the size of data types is not fully specified by the ANSI Standard, these macros allow for more portable code which can check the limits of the range of values held by the type on this implementation.
For information on implementation-defined behavior of integers, see
Section A.6 “Integers”.

6.3.1 Double-Word Integers

The compiler supports data types for integers that are twice as long as long int. Simply write long long int for a signed integer, or unsigned long long int for an unsigned integer. To make an integer constant of type long long int, add the suffix LL to the integer. To make an integer constant of type unsigned long long int, add the suffix ULL to the integer.
You can use these types in arithmetic like any other integer types.
DS52071B-page 94 2012 Microchip Technology Inc.
Supported Data Types and Variables

6.3.2 char Types

The compiler supports data types for char, which defaults to signed char. An option can be used to use unsigned char as the defaul t, see Section 3.7.3 “Options for Controlling the C Dialect”.
It is a common misconception that the C char types are intended purely for ASCII char­acter manipulation. This is not true; indeed, the C language makes no guarantee that the default character representation is even ASCII (however, this implementation does use ASCII as the character representation). The char types are simp ly the s malle st of the multi-bit integer sizes, and behave in all respects like integers. The reason for the name “char” is historical and does not mean that char can only be used to represent characters. It is possible to freely mix char values with values of other types in C expressions. With the MPLAB XC16 C Compiler, the char types will commonly be used for a number of purposes: as 8-bit integers, as storage for ASCII characters, and for access to I/O locations.

6.4 FLOATING-POINT DATA TYPES

The compiler uses the IEEE-754 format. Table 6-2 shows floating point data types that are supported. All floating point data types are arithmetic type real.
TABLE 6-2: FLOATING POINT DATA TYPES
Type Bits E Min E Max N Min N Max
float 32 -126 127 2 double* 32 -126 127 2 long double 64 -1022 1023 2
E = Exponent N = Normalized (approximate) * double is equivalent to long double if -fno-short-double is used.
-126
-126
-1022
2 2
2
128 128
1024
All floating point values are specified in little endian format, which means:
• The least significant byte is stored at the lowest address
• The least significant bit is stored at the lowest-numbered bit position As an example, the double value of 1.2345678 is stored at address 0x100 as follows:
0x100 0x101 0x102 0X103
0x51 0x06 0x9E 0x3F
As another example, the long value of 1.2345678 is stored in registers w4 and w5:
w4 w5
0x0651 0x3F9E
Floating-point types are always signed and the unsigned keyword is illegal when specifying a floating-point type.
Preprocessor macros that specify valid ranges are available after including
<float.h> in your source code
.
For information on implementation-defined behavior of floating point numbers, see section Section A.7 “Floating Point”.
2012 Microchip Technology Inc. DS52071B-page 95
MPLAB® XC16 C Compiler User’s Guide

6.5 STRUCTURES AND UNIONS

MPLAB XC16 C Compiler supports struct and union types. Structures and union s only differ in the memory offset applied to each member.
These types will be at least 1 byte wide. Bit-fields are fully supported in structures. Structures and unions may be passed freely as function arguments and function return
values. Pointers to structures and unions are fully supported. Implementation-defined behavior of structures, unions and bit-fields is described in
Section A.10 “Structures, Unions, Enumerations and Bit Fields”.

6.5.1 Structure and Union Qualifiers

The MPLAB XC16 C Compiler supports the use of type qualifiers on structures. When a qualifier is applied to a structure, all of its members will inherit this qualification. In the following example, the structure is qualified const.
const struct foo { int number; int *ptr; } record = { 0x55, &i };
In this case, the entire structure may be placed into the program space where each member will be read-only. Remember that all members are usually initialized if a structure is const as they cannot be initialized at runtime.
If the members of the structure were individually qualified const, but the structure was not, then the structure would be positioned into RAM, but each member would be still be read-only. Compare the following structure with the one above.
struct { const int number; int * const ptr; } record = { 0x55, &i};

6.5.2 Bit-Fields in Structures

The MPLAB XC16 C Compiler fully supports bit-fields in structures. Bit-fields are, by default, signed int. They may be made an unsigned int bit field
by using a command line option, see Section 3.7.3 “Options for Controlling the C Dialect”.
The first bit defined will be the LSb of the word in which it will be stored. The compiler supports bit fields with any bit size, up to the size of t he underlying type.
Any integral type can be made into a bit field. The allocation does not normally cross a bit boundary natural to the underlying type.
For example:
struct foo { long long i:40; int j:16; char k:8; } x;
struct bar { long long I:40; char J:8; int K:16; } y;
DS52071B-page 96 2012 Microchip Technology Inc.
Supported Data Types and Variables
struct foo will have a size of 10 bytes using the c ompiler. i will be allocated at bit offset 0 (through 39). There will be 8 bits of padding before j, allocated at bit offset 48. If j were allocated at the next available bit offset, 40, it would cross a storage boundary for a 16 bit integer. k will be allocated after j, at bit offset 64. The structure will contain 8 bits of padding at the end to maintain the required alignment in the case of an array. The alignment is 2 bytes because the largest alignment in the structure is 2 bytes.
struct bar will have a size of 8 bytes using the compiler. I will be allocated at bit offset 0 (through 39). There is no need to pad before J because it will not cross a storage boundary for a char. J is allocated at bit offset 40. K can be allocated starting at bit offset 48, completing the structure without wasting any space.
Unnamed bit-fields may be declared to pad out unused space between active bits in control registers. For example:
struct foo { unsigned lo : 1; unsigned : 6; unsigned hi : 1; } x;
A structure with bit-fields may be initialized by supplying a comma-separated list of ini­tial values for each field. For example:
struct foo { unsigned lo : 1; unsigned mid : 6; unsigned hi : 1; } x = {1, 8, 0};
Structures with unnamed bit fields may be initialized. No initial value should be supplied for the unnamed members, for example:
struct foo { unsigned lo : 1; unsigned : 6; unsigned hi : 1; } x = {1, 0};
will initialize the members lo and hi correctly.
2012 Microchip Technology Inc. DS52071B-page 97
MPLAB® XC16 C Compiler User’s Guide

6.6 POINTER TYPES

There are two basic pointer types supported by the MPLAB XC16 C Compiler: data pointers and function pointers. Data pointers hold the addresses of variables which can be indirectly read, and possibly indirectly written, by the program. Function pointers hold the address of an executable function which can be called indirectly via the pointer.

6.6.1 Combining Type Qualifiers and Pointers

It is helpful to first review the ANSI C standard conventions for definitions of pointer types.
Pointers can be qualified like any other C object, but care must be taken when doing so as there are two quantities associated with pointers. The first is the actual pointer itself, which is treated like any ordinary C variable and has memory reserved for it. The second is the target, or targets, that the pointer references, or to which the pointer points. The general form of a pointer definition looks like the following:
target_type_&_qualifiers * pointer’s_qualifiers pointer’s_name;
Any qualifiers to the right of the * (i.e., next to the pointer’s name) relate to the pointer variable itself. The type and any qualifiers to the left of the * relate to the pointer’s tar­gets. This makes sense since it is also the * operator that dereferences a pointer, which allows you to get from the pointer variable to its current target.
Here are three examples of pointer definitions using the volatile qualifier. The fields in the definitions have been highlighted with spacing:
volatile int * vip ; int * volatile ivp ; volatile int * volatile vivp ;
The first example is a pointer called vip. It contains the address of int objects that are qualified volatile. The pointer itself – the variable that holds the address – is not volatile; however, the objects that are accessed when the pointer is dereferenced are treated as being volatile. In other words, the target objects accessible via the pointer may be externally modified.
The second example is a pointer called ivp which also contains the address of int objects. In this example, the pointer itself is volatile, that is, the address the pointer contains may be externally modified; however, the objects that can be accessed when dereferencing the pointer are not volatile.
The last example is of a pointer called vivp which is itself qualified volatile, and which also holds the address of volatile objects.
Bear in mind that one pointer can be assigned the addresses of many objects; for example, a pointer that is a parameter to a function is assigned a new object address every time the function is called. The definition of the pointer must be valid for every target address assigned.
Note: Care must be taken when describing pointers. Is a “const pointer” a pointer
that points to const objects, or a poi nter t hat is const itself? You can talk about “pointers to const” and “const pointers” to help clarify the definition, but such terms may not be universally understood.
DS52071B-page 98 2012 Microchip Technology Inc.
Supported Data Types and Variables

6.6.2 Data Pointers

All standard data pointers are 16 bits wide. This is sufficient to access the full data memory space.
These pointers are also able to access const-qualified objects, although in the pro­gram memory space, const-qualified objects appear in a unique memory range in the data space using the PSV window. In this case, the -mconst-in-data option should not be in force (see Section 3.7.1 “Options Specific to 16-Bit Devices”.)
Pointers which access the managed PSV space are 32-bits wide. The extra space allows these pointers to access any PSV page.
A set of special purpose, 32-bit data pointers are also available. See Chapter
7. “Memory Allocation and Acce ss” for more information.

6.6.3 Function Pointers

The MPLAB XC16 C Compiler fully supports pointers to functions, which allows func­tions to be called indirectly. Function pointers are always 16 bits wide.
In the small code model (up to 32 kWords of code), 16-bit wide function pointers can access any function location. In the large code model, which supports more than 32 kWords of code, pointers hold the address of a GOTO instruction in a lookup table. These instructions are able to reach any memory location, but the lookup table itself is located in the lower program memory, thus allowing the pointers themselves to remain as 16-bit wide variables.
As function pointers are only 16-bits wide, these pointers cannot point beyond the first 64K of FLASH. Should the address of a function that is allocated beyond the first 64K of FLASH be taken, the linker will arrange for a handle section to be generated. The handle section will always be allocated within the first 64K. Each handle provides a level of indirection which allows 16-bit pointers to access the full range of FLASH. This operation may be disable with the --no-handles linker opti o n .

6.6.4 Special Pointer Targets

Pointers and integers are not interchangeable. Assigning an integer value to a pointer will generate a warning to this effect. For example:
const char * cp = 0x123; // the compiler will flag this as bad code
There is no information in the integer, 0x123, relating to the type, size or memory loca­tion of the destination. Avoid assigning an integer (whether it be a constant or variable) to a pointer at all times. Addresses assigned to pointers should be derived from the address operator “
In instances where you need to have a pointer reference a seemingly arbitrary address or address range, consider defining an object or label at the desired location. If the object is defined in assembly code, use a C declaration (using the extern keyword) to create a C object which links in with the external object and whose address can be taken.
&“ that C provides.
2012 Microchip Technology Inc. DS52071B-page 99
MPLAB® XC16 C Compiler User’s Guide
Take care when comparing (subtracting) pointers. For example:
if(cp1 == cp2) ; take appropriate action
The ANSI C standard only allows pointer comparisons when the two pointer targets are the same object. The address may extend to one element past the end of an array.
Comparisons of pointers to integer constants are even more risky, for example:
if(cp1 == 0x246) ; take appropriate action
A NULL pointer is the one instance where a constant value can be safely assigned to a pointer. A NULL pointer is numerically equal to 0 (zero), but since they do not guarantee to point to any valid object and should not be dereferenced, this is a special case imposed by the ANSI C standard. Comparisons with the macro NULL are also allowed.

6.7 COMPLEX DATA TYPES

The compiler supports complex data types. You can declare both complex integer types and complex floating types, using the keyword __complex__.
For example, __complex__ float x; declares x as a variable whose real part and imaginary part are both of type float. __complex__ short int y; declares y to have real and imaginary parts of type short int.
To write a constant with a complex data type, use the suffix ‘i’ or ‘j’ (either one; they are equivalent). For example, 2.5fi has type __complex__ float and 3i has type __complex__ int. Such a constant is a purely imaginary value, but you can form any complex value you like by adding one to a real constant.
To extract the real part of a complex-valued expression exp, write __real__ exp. Similarly, use _ _imag__ to extract the imaginary part. For example;
__complex__ float z; float r; float i;
r = i =
__real__ z; __imag__ z;
The operator, ~, performs complex conjugation when used on a value with a complex type.
The compiler can allocate complex automatic variables in a noncontiguous fashion; it’s even possible for the real part to be in a register while the imaginary part is on the stack (or vice-versa). The debugging information format has no way to represent noncontig­uous allocations like these, so the compiler describes noncontiguous complex variables as two separate variables of noncomplex type. If the variable’s actual name is foo, the two fictitious variables are named foo$real and foo$imag.
