MCP9800 Temperature

Data Logger Demo Board 2

User’s Guide

Note the following details of the code protection feature on Microchip devices:

• Microchip products meet the specification contained in their particular Microchip Data Sheet.

• Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the intended manner and under normal conditions.

• There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data Sheets. Most likely, the person doing so is engaged in theft of intellectual property.

• Microchip is willing to work with the customer who is concerned about the integrity of their code.

• Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not mean that we are guaranteeing the product as “unbreakable.”

Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our products. Attempts to break Microchip’s code protection feature may be a violation of the Digit al Millennium Copyright Act. If suc h a c t s allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.

Information contained in this publication regarding device applications and t he lik e is provided only for your convenience and may be su perseded by upda t es . It is y our responsibility to ensure that your application meets with your specifications. MICROCHIP MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, STATUTORY OR OTHERWISE, RELATED TO THE INFORMATION, INCLUDING BUT NOT LIMITED TO ITS CONDITION, QUALITY, PERFORMANCE, MERCHANTABILITY OR FITNESS FOR PURPOSE. Microchip disclaims all liability arising from this information and its use. Use of Microchip devices in life supp ort and/or safety ap plications is entir ely at the buyer’s risk, and the buyer agrees to defend, indemnify and hold harmless M icrochip from any and all dama ges, claims, suits, or expenses re sulting from such use. No licens es are conveyed, implicitly or otherwise, under any Microchip intellectual property rights.

Trademarks

The Microchip name and logo, the Microchip logo, Accuron, dsPIC, K

EELOQ, microID, MPLAB, PIC, PICmicr o, PICST A RT,

PRO MATE, PowerSmart, rfPIC, and SmartShunt are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.

AmpLab, FilterLab, Migratable Memory, MXDEV, MXLAB, SEEVAL, SmartSensor and The Embedded Control Solutions Company are registered trademarks of Microchip Technology Incorporated in the U.S.A.

Analog-for-the-Digital Age, Application Maestro, CodeGuard, dsPICDEM, dsPICDEM.net, dsPICworks, ECAN, ECONOMONITOR, FanSense, FlexROM, fuzzy LAB, In-Circuit Serial Programming, ICSP, ICEPIC, Linear Active Thermistor, Mindi, MiWi, MPASM, MPLIB, MPLINK, PICkit, PICDEM, PICDEM.net, PICLAB, PICtail, PowerCal, PowerInfo, PowerMate, PowerTool, REAL ICE, rfLAB, rfPICDEM, Select Mode, Smart Serial, SmartTel, Total Endurance, UNI/O, WiperLock and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.

SQTP is a service mark of Microchip T echnology Incorporated in the U.S.A.

All other trademarks mentioned herein are property of their respective companies.

Printed on recycled paper.

Microchip received ISO/TS-16949:2002 certification for its worldwide headquarters, design and wafer fabrication facilities in Chandler and Tempe, Arizona, Gresham, Oregon and Mountain View, California. The Company’s quality system processes and procedures are for its PIC MCUs and dsPIC DSCs, KEELOQ EEPROMs, microperipherals, nonvolatile memory and analog products. In addition, Microchip’s quality system for the design and manufacture of development systems is ISO 9001:2000 certified.

code hopping devices, Serial

MCP9800 TEMPERATURE DATA LOGGER

DEMO BOARD 2 USER’S GUIDE

Table of Contents

Preface........................................................................................................................... 1

Chapter 1. Product Overview

1.1 Introduction..................................................................................................... 5

1.2 What is the MCP9800 Temperature Data Logger Demo Board 2?................ 5

1.3 What does the MCP9800 Temperature Data Logger Demo Board 2

Kit Include?........................ ............................................................................ 5

Chapter 2. Installation and Operation

2.1 Introduction .................................................................................................... 7

2.2 Features .......................................... .. .. ........................... .. .. ............................ 7

2.3 Getting Started............................................................................................... 7

2.3.1 Programming the PIC10F202.......................................................... 8

2.3.2 Reading Data from the MCP9800 Temperature Data Logger

Demo Board 2.................................................................................. 9

2.3.3 Storing yo u r Da ta.............. ............................................................. 10

2.3.4 Displaying Temperature Data........................................................ 10

2.4 Functional Description............. ......................................................................11

2.4.1 The MCP9800 Temperature Data Logger Demo Board 2............. 11

2.5 I

C™ Subroutin e s ............. ........................................................................... 11

2.5.1 The MCP9800................................................................................ 13

2.5.2 The 24LC16B................................................................................. 13

2.5.3 The MCP1 0 1..... .. ........................................................................... 13

Appendix A. Schematic and Bill of Materials (BOM) ............................................... 15

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

NOTES:

MCP9800 TEMPERATURE DATA LOGGER

DEMO BOARD 2 USER’S GUIDE

Preface

NOTICE TO CUSTOMERS

All documentation becomes dated, and this manual is no exception. Microchip tools and documentation are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document. Please refer to our web site (www.microchip.com) to obtain the latest documentation available.

Documents are identified with a “DS” number. This number is located on the bottom of each page, in front of the page number. The numbering convention for the DS number is “DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the document.

For the most up-to-date information on development tools, see the MPLAB Select the Help menu, and then Topics to open a list of available on-line help files.

INTRODUCTION

IDE on-line help.

This chapter contains general information that will be useful to know before using the MCP9800 Temperature Data Logger Demo Board 2. Items discussed in this chapter include:

• Document Layout

• Conventions Used in this Guide

• Recommended Reading

• The Microchip Web Site

• Customer Support

• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the MCP9800 Temperature Data Logger Demo Board 2. The manual layout is as follows:

• Chapter 1. “Product Overview” – Important information about the MCP9800 Temperature Data Logger Demo Board 2.

• Chapter 2. “Installation and Operation” – Demonstrates what programs need to be installed and how to program the microcontroller on the PCB, as well as reading the data out and displaying the data in an Excel

• Appendix A. – “Schematic and Bill of Materials (BOM)”

spreadsheet.

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

CONVENTIONS USED IN THIS GUIDE

This manual uses the following docum entat io n conven tion s:

DOCUMENTATION CONVENTIONS

Description Represents Examples

Arial font:

Italic characters Referenced books MPLAB

Emphasized text ...is the only comp ile r...

Initial caps A window the Output window

A dialog the Settings dialog A menu selection select Enable Programmer

Quotes A field name in a window or

dialog

Underlined, italic text with right angle bracket

Bold characters A dialog button Click OK

N‘Rnnnn A number in verilog format,

Text in angle brackets < > A key on the keyboard Press <Enter>, <F1>

Courier New font:

Plain Courier New Sam ple source code #define START

Italic Courier New A variable argument file.o, where file can be

Square brackets [ ] Optional arguments mcc18 [options] file

Curly brackets and pipe character: { | }

Ellipses... Replaces r epeated text var_name [,

A menu path File>Save

A tab Click the Power tab

where N is the tota l number of digits, R is th e radi x and n is a digit.

Filenames autoexec.bat File paths c:\mcc18\h Keywords _asm, _endasm, static Command-line options -Opa+, -Opa- Bit values 0, 1 Constants 0xFF, ‘A’

Choice of mutually exclusive arguments; an OR selection

Represents code supplied by user

“Save project before build”

4‘b0010, 2‘hF1

any valid filename

[options] errorlevel {0|1}

var_name...] void main (void)

{ ... }

IDE User’s Guide

Chapter 1. Product Overview

1.1 INTRODUCTION

This chapter contains an overview of the MCP9800 Temperature Data Logger Demo Board 2 and covers the following topics:

• What is the MCP9800 Temperature Data Logger Demo Board 2?

• What does the MCP9800 Temperature Data Logger Demo Board 2 include?

1.2 WHAT IS THE MCP9800 TEMPERATURE DATA LOGGER DEMO BOARD 2?

The MCP9800 Temperature Data Logger Demo Board 2 is a PCB assembly that uses a PIC10F202 to read temperature data using I MCP9800 temperature sensor, and stores that data, also using I a 24LC16B Serial EEPROM. The board can then be placed into a SEEVAL EEPROM Evaluation tool and the content can be read and stored into a .hex file. We have also provided an Excel spreadsheet that can be used to import the .hex file so that the data may be graphed on your computer screen.

C™ communication from a Microchip

C communication, to

32 Serial

1.3 WHAT DOES THE MCP9800 TEMPERATURE DATA LOGGER DEMO BOARD 2 KIT INCLUDE?

This MCP9800 Temperature Data Logger Demo Board 2 Kit includes:

• Two MCP9800 Temperature Data Logger Demo Boards. On the data CD provided:

• MCP9800 Temperature Data Logger Demo Board 2 User’s Guide (DS22027)

•SEEVAL

• PIC10F202 Firmware (SEEVALDM_DL.asm)

• Excel Spreadsheet (Temperature Graph.xls)

32 Quick Start User’s Guide (DS51338)

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

NOTES:

Chapter 2. Installation and Operation

2.1 INTRODUCTION

The MCP9800 Temperature Data Logger Demo Board 2, once programmed, will log temperature measurements for a predetermined amount of time until the 24LC16B is fully programmed with temperature data (i.e., 2,048 temperature readings). Each sample uses one byte of memory. The intervals can be changed in the firmware we have provided by changing the TIMEOUTVAL variable. The firmware will take measurements for approximately 45 minutes (approx. 1 sample/sec).

2.2 FEATURES

The MCP9800 Temperature Data Logger Demo Board 2 has the following features:

• Small PCB layout. Can be placed virtually anywhere you need to measure temperature.

• Standard ICSP™ pinout so the firmware can be modified using a PICkit™ 2 programmer or any of Microchip’s programming tools using the ICSP programming adapter.

• Standard Two-Wire 8-pin pinout (inverted) for easy reading of the 24LC16B into the SEEVAL

MCP9800 TEMPERATURE DATA LOGGER

DEMO BOARD 2 USER’S GUIDE

32 evaluation tool software.

2.3 GETTING STARTED

This section describes how to get your MCP9800 Temperature Data Logger Demo Board 2 programmed and ready to take temperature readings. The boards have been pre-programmed at the factory with the default settings, so it is not necessary to program them unless the firmware has been modified. It will also show how to read the logged data from the board into the SEEVAL show how to export that data from the SEEVAL 32 evaluation tool software and also how to import and display the data on an Excel spreadsheet.

32 evaluation tool software. Then it will

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

FIGURE 1-1: MCP9800 Temperature Data Logger Demo Board 2 Functional Block Diagram

Status LED

(D2)

MCP101

Voltage Supervisor

(U5)

PIC10F202

(U3)

PICkit™ 2

Programmer

Header (J1)

MCP9800

Temp. Sensor

(U4)

24LC16B

Serial EEPROM

(U2)

SEEVAL® 32

Evaluation Tool

Header (U1)

3.3 VDC

(Battery)

Power

Supply

Battery Jumper

(JP1)

2.3.1 Programming the PIC10F202

1. Download and Install the PICkit™ 2 programmer software onto your PC.

2. Copy the SEEVALDM-DL.hex file (supplied on the CD that came with this kit) onto your PC.

3. When the PICkit™ 2 programmer software is started the main window will be displayed on the PC, as indicated in Figure1-2.

4. Be sure that the battery (BT1) is installed and the jumper for Power is connected (JP1).

5. Connect the MCP9800 T emperature Data Logger Demo Board 2 to the PICkit™ 2 programmer (both programmer and board should be face up when connecting).

6. PICkit™ 2 programmer should have a green led on the front indicating that no errors have occurred.

Installation and Operation

FIGURE 1-2: PICkit™ 2 Programmer GUI Window on the PC

7. Select Device Family>Baseline

8. Select PIC10F202 from the Device pull-down menu.

9. Select File>Import Hex

Locate, select, and open SEEVALDM-DL.hex from your PC.

10. Click on the Write Device Button in the PICkit™ 2 Programme r wind ow. The

PIC10F202 will be written to with the SEEVALDM-DL.hex firmware. Once completed, the status bar in the middle of the window will indicate Write Successful.

11. Disconnect the MCP9800 Temperature Data Logger Demo Board 2 from the

PICkit™ 2 programmer. Remove and replace the Power Header (JP1). Led should begin flashing indicating that the PIC10F202 is reading temperature from the MCP9800 and storing the data into the 24LC16B.

12. LED will flash indicating that measurements are being taken until the 24LC16B

has reached its storage limit (2,048 bytes).

from the File pull-down menu. A file window will appear.

2.3.2 Reading Data from the MCP9800 Temperature Data Logger

Demo Board 2 board

1. Download and install the SEEVAL® 32 evaluation tool software using the

SEEVAL

2. When th e SEEVAL

displayed on the PC, as indicated in Figure1-3.

3. Select “I2C” from the Protocol pull-down menu.

4. Select “24AA16/24LC16B” from the Device Name pull-down menu.

32 Quick Start User’s Guide.

32 evaluation tool software is started the main window will be

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

5. Insert the MCP9800 Temperature Data Logger Demo Board 2 into to SEEVAL 32 evaluation board. To do this, flip the board upside down making sure the ICSP pins are facing the right side of the SEEVAL

32 evaluation board. Place the 8

header pins in the rear (right side) of the ZIF socket. Close the socket.

6. Select Read>Entire Device

7. Your data (hexadecimal) will be displayed on the SEEVAL

to read the 24LC16B.

32 evaluation tool

software GUI.

FIGURE 1-3: SEEVAL

32 Evaluation Tool GUI Window on the PC

2.3.3 Storing your Data

Select File>Export>Hex File and store your data to your PC (filename.hex).

2.3.4 Displaying Temperature Data

1. Open file Temperature Graph.xls (Provided on the CD). Choose enable macros if prompted. (May need to adjust security settings here if you are unable

to launch the file.)

2. Press the Import Data button.

3. Find your data file on your PC (filename.hex), Press Open Button.

4. Enter “1” for sample period when asked and press OK. If you have changed the sample period in the firmware you will need to adjust the sample period here, default is approximately 1 sample/sec.

5. Temperatures both positive and negative will be displayed on the graph. Tabs at the bottom of the graph will show either °F or °C.

2.4 FUNCTIONAL DESCRIPTION

2.4.1 The MCP9800 Temperature Data Logger Demo Board 2

Installation and Operation

This demo board was originally developed for the use in a class to teach people the basics of the I read and modify should one need to. Table 1-1 and T able 1-2 show some of the basic subroutines and constant definitions used in the code. The TIMEOUTVAL variable may be modified to put longer delays between measurements. Any value between 1 (default) and 255 may be used to vary the sample rate. The higher the number, the slower the sample rate. The TIMEOUTVAL variable is approximately the number of seconds delay between measurements.

2.5 I2C™ SUBROUTINES

The following subroutines provide low-level I2C support:

TABLE 1-1: I2C™ SUBROUTINES

Subroutine Description

BSTART BSTOP SEND_ACK SEND_NACK BYTEOUT BYTEIN

The following constants have been defined for communicating with the 24LC16B and MCP9800:

C™ protocol. The code is formatted in such a manner that it is easy to

Generate an I2C™ bus Start condition. Generate an I2C™ bus Stop condition. Generate an I2C™ bus Acknowledge condition. Generate an I2C™ bus Not Acknowledge condition. Output an entire byte to the I2C™ bus. Input an entire byte from the I2C™ bus.

TABLE 1-2: CONSTANT DEFINITIONS

Constant Value Description

MEM_WRITE b’10100000’ MEM_READ b’10100001’ TEMP_WRITE b’10010000’ TEMP_READ b’10010001’ TEMP_REG 0x00 CONFIG_REG 0x01 SHUTDOWN b’00000001’ ONESHOT b’10000001’

Control byte for EEPROM write operation Control byte for EEPROM read operation Control byte for temp. sensor write operation Control byte for temp. sensor read operation Temperature register address for temp. sensor Configuration register address for temp. sensor Configuration value for Shutdown mode Configuration value for One-Shot mode

Subroutine Descriptions

BSTART

Description: Generate an I2C bus Start condition. Arguments: None. Output: None. Return Value: 0 Code Example:

call BSTART ; Generate Start

BSTOP

Description: Generate an I2C bus Stop condition. Arguments: None.

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

BSTOP

Output: None. Return Value: 0 Code Example:

SEND_ACK

Description: Generate an I2C bus Acknowledge condition. Arguments: None. Output: None. Return Value: 0 Code Example:

SEND_NACK

Description: Generate an I2C bus Not Acknowledge condition. Arguments: None. Output: None. Return Value: 0 Code Example:

call BSTOP ; Generate Stop

call SEND_ACK ; Send ACK to continue reading

call SEND_NACK ; Send NACK to end operation

BYTEOUT

Description: Output an entire byte to the I2C bus. Arguments: WREG

Data byte to be transmitted to the I

pollflag<0>

Flag indicating whether or not currently polling (1 if polling, 0 otherwise).

Output: None. Return Value: 0 if an Acknowledge was received.

-1 if an Acknowledge was not received and pollflag<0> is set.

Remarks: If an Acknowledge was not received and pollflag<0> is cleare d, t his s ub -

routine sets the current state to ERR1_STATE and goes to sleep. This state is used to indicate that an Acknowledge error occurred.

Code Example:

movlw 0x7F ; Load 0x7F into WREG

C bus.

call BYTEOUT ; Output byte

BYTEIN

Description: Input an entire byte from the I2C bus. Arguments: None. Output: buffer

Data byte read from the I

Return Value: 0 Code Example:

call BYTEIN ; Input byte call SEND_NACK ; Send NACK to end operation movfw buffer ; Copy data to WREG

C bus.

Installation and Operation

2.5.1 The MCP9800

The MCP9800 comes with user-programmable registers that provide flexibility for temperature-sensing applications. The register settings allow user-selectable 9-bit to 12-bit temperature measurement resolution, configuration of the power-saving Shutdown and One-Shot (single conversion on command while in Shutdown) modes and the specification of both temperature alert output and hysteresis limits. When the temperature changes beyond the specified limits, the MCP9800 outputs an alert signal. The user has the option of setting the alert output signal polarity as an active-low or active-high comparator output for thermostat operation, or as a temperature event interrupt output for microprocessor-based systems.

This device has I sheet (DS21909) for further details).

2.5.2 The 24LC16B

The 24LC16B is a 16 Kbit Electrically Erasable PROM. This device has

C/SMBus-compatible serial interface. Low-voltage design permits operation down to

1.8V with standby and active currents of only 1μa and 1mA, respectively. The device also has a page write capability for up to 16 bytes of data.

2.5.3 The MCP101

C/SMBus-compatible serial interface (refer to the MCP9800 data

The MCP101 is a voltage supervisory device designed to keep a microcontroller in Reset until the system voltage has reached the proper level and stabilized. It also operates as protection from brown-out conditions when the supply voltage drops below a safe operating level.

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

NOTES:

MCP9800 TEMPERATURE DATA LOGGER

DEMO BOARD 2 USER’S GUIDE

Appendix A. Schematic and Bill of Materials (BOM)

FIGURE 1-1: MCP9800 Temp Sensor SEEVAL® 32 Data Logger Schematic

MCP9800 Temperature Data Logger Demo Board 2 User’s Guide

FIGURE 1-2: MCP9800 Temp Sensor SEEVAL® 32 Data Logger BOM

S PL Type

C C

2 N N N LBL

1YNNP

P10.0KHCT-ND Y

P243HCT-ND Y

Digi-Key

ERJ-3EKF2430V

1YNNP

103 Digi-Key 103K-ND

rawing

Part

CS: Consign BOM

PL: Pack List

CR: Cross

: Label

Bill of Materials

RoHS: Lead Free

RoH

1NNND

S Rev

- -

108-00004

113-00128

105-00128

104-00128-D

103-00128

102-00128-D

1YNNP

399-1096-1-ND Y

PCC13495CT-ND Y

MA2YD2600LCT-ND

- -

Digi-Key

LTST-C170CKT Digi-Key 160-1176-1-ND

104-00128

MA2YD2600L

1YNNP

153700 Y

Jameco

1YNNP

108338 Y

Jameco

1YNNP

117560 Y

Jameco

1YNNP

P189-ND Y

Digi-Key

CR2032

2355 W. Chandler Blvd.

Chandler, AZ 85224-6199

Microchip Technology Incorporated KE

102-00128 REV: 1 Part No: MCP9800DM-DL2

MCP9800 SEEVAL Based Temperature Data Logger

Description

PCB FABRICATION DRAWING, MCP9800 SEEVAL Based

Temperature Data Logger

Gerber Files, 105-00128R1.ZIP

MCP9800 SEEVAL Based Temperature Data Logger

PCB ASSY DWG, MCP9800 SEEVAL Based Temperature Data Logger

SCHEMATIC, MCP9800 SEEVAL Based Temperature Data Logger

- -

MCP9800 SEEVAL Based Temperature Data Logger Test Procedure

- -

Qty Reference Mfgr. Part Number Distributor Vendor/Part Number

ASSEMBLY NUMBER:

ASSEMBLY NAME:

Kemet C0603C104K4RACTU

Panasonic -

ECG ECJ-1VBFJ475K

Panasonic -

SSG

Panasonic -

ECG ERJ-3EKF1002V

Panasonic -

ECG

Keystone Elect

JAMECO

VALUEPRO JS1109-6-R

JAMECO

Lite-On

Trading USA

DIODE SCHOTTKY 60V 800MA MINI-2P

LED RED CLEAR 0805 SMD

RES 10.0K OHM 1/10W 1% 0603 SMD

RoHS Compliant Bare PCB, MCP9800 SEEVAL Based Temperature

Data Logger

CAP .10UF 16V CERAMIC X7R 0603

Label, AIPD Assembly and Serial Numbers, Very Small

CAP 4.7UF 6.3V CERAMIC X5R 0603

PCB

5,C6

10 1

C1,C3,C4,C

11 1

RES 243 OHM 1/10W 1% 0603 SMD

R1,R2,R4

12 3

13 1

VALUEPRO 7000-1X2SG-R

HOLDER BATTERY COIN 20MM 1-CELL

HEADER,.1"ST MALE,1RW,6PIN,

HEADER,.1",2PIN,GOLDTAIL

JP1

14 1 BT1

15 1

16 1

JAMECO

VALUEPRO JS-1109-4-R

Panasonic -

BSG

HEADER,.1"MALE,4PIN, GOLDTAIL

BATTERY LITHIUM COIN 3V 20MM

BT1

17 2

18 1

Appendix A. Schematic and Bill of Materials (BOM)

FIGURE 1-3: MCP9800 Temp Sensor SEEVAL® 32 Data Logger BOM (Continued)

S PL Type

C C

1 NY NP

rawing

Part

CS: Consign BOM

PL: Pack List

CR: Cross

: Label

Bill of Materials

RoHS: Lead Free

RoH

S Rev

2355 W. Chandler Blvd.

Chandler, AZ 85224-6199

Microchip Technology Incorporated KE

Microchip 24LC16BT-I/OT Microchip 24LC16BT-I/OT

Microchip PIC10F202T-E/OT Microchip PIC10F202T-E/OT

Microchip MCP9800A0T-M/OTG Microchip MCP9800A0T-M/OTG

Microchip MCP101T-450I/TT Microchip MCP101T-450I/TT

MCP9800 SEEVAL Based Temperature Data Logger

102-00128 REV: 1 Part No: MCP9800DM-DL2

Description

6-Pin, 8-Bit Flash Microcontrollers

Microcontroller Supervisory Circuit with Push-Pull Output

2-Wire High-Accuracy Temperature Sensor

16K I2C™ Serial EEPROM

20 1

21 1

22 1

Qty Reference Mfgr. Part Number Distributor Vendor/Part Number

ASSEMBLY NUMBER:

ASSEMBLY NAME:

19 1

WORLDWIDE SALES AND SERVICE

AMERICAS

Corporate Office

2355 West Chandler Blvd. Chandler, AZ 85224-6199 Tel: 480-792-7200 Fax: 480-792-7277 Technical Support: http://support.microchip.com Web Address: www.microchip.com

Atlanta

Duluth, GA Tel: 678-957-9614 Fax: 678-957-1455

Boston

Westborough, MA Tel: 774-760-0087 Fax: 774-760-0088

Chicago

Itasca, IL Tel: 630-285-0071 Fax: 630-285-0075

Dallas

Addison, TX Tel: 972-818-7423 Fax: 972-818-2924

Detroit

Farmington Hills, MI Tel: 248-538-2250 Fax: 248-538-2260

Kokomo

Kokomo, IN Tel: 765-864-8360 Fax: 765-864-8387

Los Angeles

Mission Viejo, CA Tel: 949-462-9523 Fax: 949-462-9608

Santa Clara

Santa Clara, CA Tel: 408-961-6444 Fax: 408-961-6445

Toronto

Mississauga, Ontario, Canada Tel: 905-673-0699 Fax: 905-673-6509

ASIA/PACIFIC

Asia Pacific Office

Suites 3707-14, 37th Floor Tower 6, The Gateway Habour City, Kowloon Hong Kong Tel: 852-2401-1200 Fax: 852-2401-3431

Australia - Sydney

Tel: 61-2-9868-6733 Fax: 61-2-9868-6755

China - Beijing

Tel: 86-10-8528-2100 Fax: 86-10-8528-2104

China - Chengdu

Tel: 86-28-8665-5511 Fax: 86-28-8665-7889

China - Fuzhou

Tel: 86-591-8750-3506 Fax: 86-591-8750-3521

China - Hong Kong SAR

Tel: 852-2401-1200 Fax: 852-2401-3431

China - Qingdao

Tel: 86-532-8502-7355 Fax: 86-532-8502-7205

China - Shanghai

Tel: 86-21-5407-5533 Fax: 86-21-5407-5066

China - Shenyang

Tel: 86-24-2334-2829 Fax: 86-24-2334-2393

China - Shenzhen

Tel: 86-755-8203-2660 Fax: 86-755-8203-1760

China - Shunde

Tel: 86-757-2839-5507 Fax: 86-757-2839-5571

China - Wuhan

Tel: 86-27-5980-5300 Fax: 86-27-5980-5118

China - Xian

Tel: 86-29-8833-7250 Fax: 86-29-8833-7256

ASIA/PACIFIC

India - Bangalore

Tel: 91-80-4182-8400 Fax: 91-80-4182-8422

India - New Delhi

Tel: 91-11-4160-8631 Fax: 91-11-4160-8632

India - Pune

Tel: 91-20-2566-1512 Fax: 91-20-2566-1513

Japan - Yokohama

Tel: 81-45-471- 6166 Fax: 81-45-471-6122

Korea - Gumi

Tel: 82-54-473-4301 Fax: 82-54-473-4302

Korea - Seoul

Tel: 82-2-554-7200 Fax: 82-2-558-5932 or 82-2-558-5934

Malaysia - Penang

Tel: 60-4-646-8870 Fax: 60-4-646-5086

Philippines - Manila

Tel: 63-2-634-9065 Fax: 63-2-634-9069

Singapore

Tel: 65-6334-8870 Fax: 65-6334-8850

Taiwan - Hsin Chu

Tel: 886-3-572-9526 Fax: 886-3-572-6459

Taiwan - Kaohsiung

Tel: 886-7-536-4818 Fax: 886-7-536-4803

Taiwan - Taipei

Tel: 886-2-2500-6610 Fax: 886-2-2508-0102

Thailand - Bangkok

Tel: 66-2-694-1351 Fax: 66-2-694-1350

EUROPE

Austria - Wels

Tel: 43-7242-2244-39 Fax: 43-7242-2244-393

Denmark - Copenhagen

Tel: 45-4450-2828 Fax: 45-4485-2829

France - Paris

Tel: 33-1-69-53-63-20 Fax: 33-1-69-30-90-79

Germany - Munich

Tel: 49-89-627-144-0 Fax: 49-89-627-144-44

Italy - Milan

Tel: 39-0331-742611 Fax: 39-0331-466781

Netherlands - Drunen

Tel: 31-416-690399 Fax: 31-416-690340

Spain - Madrid

Tel: 34-91-708-08-90 Fax: 34-91-708-08-91

UK - Wokingham

Tel: 44-118-921-5869 Fax: 44-118-921-5820

12/08/06

Microchip Technology MCP9800 Temperature Data Logger Demo Board 2 User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Chapter 1. Product Overview

1.1 INTRODUCTION

1.2 WHAT IS THE MCP9800 TEMPERATURE DATA LOGGER DEMO BOARD 2?

1.3 WHAT DOES THE MCP9800 TEMPERATURE DATA LOGGER DEMO BOARD 2 KIT INCLUDE?

Chapter 2. Installation and Operation

2.1 INTRODUCTION

2.2 FEATURES

2.3 GETTING STARTED

FIGURE 1-1: MCP9800 Temperature Data Logger Demo Board 2 Functional Block Diagram

FIGURE 1-2: PICkit™ 2 Programmer GUI Window on the PC

2.4 FUNCTIONAL DESCRIPTION

2.5 I2C™ SUBROUTINES

Appendix A. Schematic and Bill of Materials (BOM)

FIGURE 1-1: MCP9800 Temp Sensor SEEVAL® 32 Data Logger Schematic

FIGURE 1-2: MCP9800 Temp Sensor SEEVAL® 32 Data Logger BOM

FIGURE 1-3: MCP9800 Temp Sensor SEEVAL® 32 Data Logger BOM (Continued)

WORLDWIDE SALES AND SERVICE
