Object of Declaration: MCP37X10-200 12-Bit Single-Channel Evaluation Kit

 2016 Microchip Technology Inc. DS50002511A-page 3

MCP37X10-200 12-BIT SINGLE-CHANNEL

EVALUATION KIT USER’S GUIDE

Table of Contents

Preface ...........................................................................................................................5

Introduction............................................................................................................5

Document Layout .................................................................................................. 5

Conventions Used in this Guide............................................................................ 6

Recommended Reading.............................................................. .. ........................7

The Microchip Website.......................................................................................... 7

Customer Support....................... ....................................................... ...................7

Document Revision History................................................................................... 7

Chapter 1. Product Overview

1.1 Introduction .....................................................................................................9

1.2 What is the MCP37X10-200 12-Bit Single-Channel

Evaluation Board (ADM00735)? ...............................................................9

1.3 What is the MCP37XXX High-Speed Pipeline ADC

Data Capture Card (ADM00506)? ..........................................................11

1.4 What is the Pipe line ADC Utility Software? ..... .. ........................................... 13

1.5 MCP37X10-200 12-Bit Single-Channel Evaluation Kit Requirements .........14

Chapter 2. Installation and Operation

2.1 MCP37X10-200 12-Bit Single-Channel Evaluation Kit Featur es ................ ..15

2.2 Getting Sta rted ............................................................................................. 15

2.2.1 Configuration Requirements ......................................................................15

2.2.2 Power Input Connection ............................................................................15

2.2.3 Evaluation Kit Set-Up ................................................................................ 16

2.2.4 Input/Output Optimization .......................................................................... 17

Appendix A. Schematics and Layouts.......................................................................21

Appendix B. Bill of Materials (BOM)...........................................................................23

Worldwide Sales and Service ....................................................................................24

DS50002511A-page 4 2016 Microchip Technology Inc.

MCP37X10-200 12-BIT SINGLE-CHANNEL

EVALUATION KIT USER’S GUIDE

Preface

NOTICE TO CUSTOMERS

All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our website
(www.microchip.com) to obtain the latest documentation available.

Documents are identified with a “DS” number. This number is located on the bottom of each
page, in front of the p age number. The numbering convention for the DS number is
“DSXXXXXXXXA”, where “XXXXXXXX” is the document number and “A” is the revision level
of the document.

For the most up-to-date information on development tools, see the MPLAB
Select the Help menu, and then Topics to open a list of available online help files.

INTRODUCTION

®

IDE online help.

This chapter contains general information that will be useful to know before using the
MCP37X10-200 12-Bit Single-Channel Evaluation Kit. Items discussed in this chapter
include:

• Document Layout

• Conventions Used in this Guide

• Recommended Reading

• The Microchip Website

• Customer Support

• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the MCP37X10-200 12-Bit Single-Channel
Evaluation Kit to demonstrate the performance of the MCP37X10-200 device family.
The manual layout is as follows:

• Chapter 1. “Product Overview” – Important information about the
MCP37X10-200 12-Bit Single-Channel Evaluation Kit.

• Chapter 2. “Installation and Operation” – Includes instructions on how to get
started with the MCP37X10-200 12-Bit Single-Channel Evaluation Kit.

• Appendix A. “Schematics and Layouts” – Refer to the board's web page for
the complete Schematics and Layouts.

• Appendix B. “Bill of Materials (BOM)” – Refer to the board's web page for the
complete Bill of Materials.

 2016 Microchip Technology Inc. DS50002511A-page 5

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

CONVENTIONS USED IN THIS GUIDE

This manual uses the following docum entat io n conven tion s:

DOCUMENTATION CONVENTIONS

Description Represents Examples

Arial font:

Italic chara c ters Referenced books MPLAB

Emphasized text ...is the only compiler...

Initial caps A window the Output window

A dialog the Settings dialog
A menu selection select Enable Programmer

Quotes A field name in a window or

dialog

Underlined, Italic text with
right angle bracket

Bold characters A dialog button Click OK

N‘Rnnnn A number in verilog format,

Text in angle brac kets < > A key on the keyboard Press <Enter>, <F1>

Courier New font:

Plain Courier New Sample source code #define START

Italic Courier New A variable argument file.o, where file can be

Square brackets [ ] Optional arguments mcc18 [options] file

Curly brackets and pipe
character: { | }

Ellipses... Replaces r epeated text var_name [,

A menu path File>Save

A tab Click the Power tab

where N is the tota l number of
digits, R is th e radi x and n is a
digit.

Filenames autoexec.bat
File paths c:\mcc18\h
Keywords _asm, _endasm, static
Command-line options -Opa+, -Opa-
Bit values 0, 1
Constants 0xFF, ‘A’

Choice of mut ually exclus ive
arguments; an OR selection

Represents code supplied by
user

“Save project before build”

4‘b0010, 2‘hF1

any valid filename

[options]
errorlevel {0|1}

var_name...]
void main (void)

{ ...
}

®

IDE User’s Guide

DS50002511A-page 6 2016 Microchip Technology Inc.

RECOMMENDED READING

This user's guide describes how to use the MCP37X10-200 12-Bit Single-Channel
Evaluation Kit. Other useful documents are listed below. The following Microchip
documents are available and recommended as supplemental reference resources.

• MCP37210-D10 Data Sheet – “200 Msps, 12-Bit Low-Power Single-Channel
ADC” (DS20005395)

THE MICROCHIP WEBSITE

Microchip provides online support via our website at www.microchip.com. This website is
used as a means to make files and information easily available to customers. Accessible
by using your favorite Internet browser, the website contains the following information:

• Product Support – Data sheets and errata, application notes and sample
programs, design resources, user’s guides and hardware support documents,
latest software releases and archived software

• General Technical Support – Frequently Asked Questions (FAQs), technical
support requests, online discussion groups, Microchip consultant program
member listing

• Business of Microchip – Product selector and ordering guides, latest Microchip
press releases, listing of seminars and events, listings of Microchip sales offices,
distributors and factory representatives

Preface

CUSTOMER SUPPORT

Users of Microchip products can receive assistance through several channels:

• Distributor or Representative

• Local Sales Office

• Field Application Engineer (FAE)

• Technical Support

Customers should contact their distributor, representative or field application engineer
(FAE) for support. Local sales offices are also available to help customers. A listing of
sales offices and locations is included in the back of this document.

Technical support is available through the website at:

http://www.microchip.com/support.

DOCUMENT REVISION HISTORY

Revision A (August 2016)

• Initial release of this document.

 2016 Microchip Technology Inc. DS50002511A-page 7

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

NOTES:

DS50002511A-page 8 2016 Microchip Technology Inc.

MCP37X10-200 12-BIT SINGLE-CHANNEL

5V Power Supply

5V Power Supply

USB

MCP37X10-200

Evaluation Board

(Note 1)

MCP37XXX

Data Capture

Card Board

(Note 2)

PC GUI

(Pipeline ADC

Utility Software)

(Note 3)

Note 1: The ADC part is available on this board.

2: This board collects ADC data from the evaluation board and passes it to the PC GUI.
3: This GUI allows the user to test the performance of the MCP37X10-200 device.

Clock Source

Signal
Input

EVALUATION KIT USER’S GUIDE

Chapter 1. Product Overview

1.1 INTRODUCTION

This chapter provides an overview of the MCP37X10-200 12-Bit Single-Channel
Evaluation Board (ADM00735) and covers the following topics:

• What is the MCP37X10-200 12-Bit Single-Channel Evaluation Board
(ADM00735)?

• What is the MCP37XXX High-S peed Pipeline ADC Dat a Capt ure Card (ADM0050 6)?

• What is the Pipeline ADC Utility Software?

• MCP37X10-200 12-Bit Single-Channel Evaluation Kit Requirements

1.2 WHAT IS THE MCP37X10-200 12-BIT SINGLE-CHANNEL EVALUATION BOARD (ADM00735)?

The MCP37X10-200 12-Bit Single-Channel Evaluation Board (ADM00735) is intended
to demonstrate the performance of the MCP37X10-200 device family . This evaluation
board is used together with:

• MCP37XXX High-Speed Pipeline ADC Data Capture Card (ADM00506)

• Pipeline ADC Utility Software
Refer to Figure 1-1 for the system setup.

FIGURE 1-1: Evaluation Kit System Setup.

This evaluation board supports the following Microchip high-speed ADC device families:

• The MCP37210-200, which is Microchip Technology Inc.’s baseline

• The MCP37D10-200 device family, which features digital down-conversion, in

 2016 Microchip Technology Inc. DS50002511A-page 9

The MCP37X10-200 12-Bit Single-Channel Evaluation Board (ADM00735) comes with
the MCP37D10-200 device on board. All conditions and features can be evaluated using
this device. Refer to Figure 1-3 for close-up photos of the evaluation board.

single-channel 12-bit 200 Msps pipelined Analog-to-Digital Converter (ADC)
device family, featuring a built-in high-order digital decimation filter, gain and offset
adjustment, and a noise-shaping requa nti ze r, which improv es SNR with in a spec­ified frequency band.

addition to the features offered by the baseline device family.

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

(a) Top View

(b) Bottom View

MCP37D10-200

FIGURE 1-2: MCP37X10-200 12-Bit 200 Msps ADC BGA Evaluation Board (ADM00735).

DS50002511A-page 10  2016 Microchip Technology Inc.

1.3 WHAT IS THE MCP37XXX HIGH-SPEED PIPELINE ADC DATA CAPTURE CARD (ADM00506)?

The MCP37XXX High-Speed Pipeline ADC Data Capture Card (ADM00506) is an
FPGA-based memory buffer for the digital data received from the Analog-to-Digital
Converter (ADC) evaluation board. Figure 1-1 shows the connection of the data
capture card directly between the evaluation board and the PC GUI.

The data capture card connects to the PC through a USB cable, providing the user with
two functionalities:

• The ability to send user commands directly to the device from the PC GUI.

• The ability to collect data from the evaluation board and send it to the PC GUI.
Refer to Figure 1-3 for close-up photos of the data capture card.

 2016 Microchip Technology Inc. DS50002511A-page 11

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

(b) Bottom View

(a) Top View

FIGURE 1-3: MCP37XXX High-Speed Pipeline ADC Data Capture Card (ADM00506).

DS50002511A-page 12  2016 Microchip Technology Inc.

1.4 WHAT IS THE PIPELINE ADC UTILITY SOFTWARE?

The Pipeline ADC Utility software is the graphical user interface (GUI) used to
communicate with and to configure the operating parameters of the device. The
software communicates with the part through the data capture card via a USB cable,
allowing the user to program the internal ADC registers. When the user interacts with
the software (for example, by updating the registers), the user’s commands are passed
to the MCP37D10-200 device via the data capture card. Once the commands are
executed by the evaluation board, the software receives the requested data from the
data capture card. The software will then analyze the data, perform a FFT or other
analysis, and display the results. Refer to Figure 1-1 for a diagram of the system setup.

Figure 1-4 shows a screen shot of the graphical interface.

FIGURE 1-4: Pipeline ADC Utility Software Displaying a Typical FFT Waveform.

The Pipeline ADC Utility software is available for download on Microchip’s website. For
instructions on using the GUI, refer to the software’s supporting documentation
included with the installation file, as well as within the application Help menu.

 2016 Microchip Technology Inc. DS50002511A-page 13

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

1.5 MCP37X10-200 12-BIT SINGLE-CHANNEL EV ALUATION KIT REQUIREMENTS

The evaluation kit requires the following:

• MCP37X10-200 12-Bit Single-Channel Evaluation Board (ADM00735)

• MCP37XXX High-Speed Pipeline ADC Data Capture Card (ADM00506)

-Sold separately

• Two 5V Power Supplies

- Included with the evaluation board and data capture card

• USB-A to USB Mini-B Cable

- Included with the data capture card

• External Clock Source or Crystal Oscillator

- Supplied by the user

• External Signal Input

- Supplied by the user

• Pipeline ADC Utility Software

- Available on the Microchip website

DS50002511A-page 14  2016 Microchip Technology Inc.

MCP37X10-200 12-BIT SINGLE-CHANNEL

EVALUATION KIT USER’S GUIDE

Chapter 2. Installation and Operation

2.1 MCP37X10-200 12-BIT SINGLE-CHANNEL EV ALUATION KIT FEATURES

This MCP37X10-200 12-Bit Single-Channel Evaluation Kit is a fully assembled, pro­grammed and tested solution (with the exception of a clock source) to evaluate and
demonstrate the MCP37X10-200 operating performance.

The evaluation kit has the following features:

• Programmable Full-Scale Analog Input Range

• Dynamic Performance Monitoring

• Evaluation of Performance Metrics, such as: SNR, SFDR, INL, DNL, etc.

• User-Programmable Registers

• Real-Time Monitoring of Power Consumption

• Digital Post Processing Options: Decimation Filter, Digital Down-Conversion,
Noise-Shaping Requantizer, etc.

• Ability to Save and Load Software Configurations

• Ability to Save and Load Raw Data for User Post-Processing

The evaluation kit features a sample rate of up to 200 Msps.For information about the
device features, refer to the MCP37X10-200 Data Sheet – “200 Msps, 12-Bit

Low-Power Single-Channel ADC” (DS20005395).

2.2 GETTING STARTED

2.2.1 Configuration Requirements

To power-up and run the evaluation kit, the following are required:

• Pipeline ADC Utility Software

• MCP37X10-200 12-Bit Single-Channel Evaluation Board (ADM00735)

• MCP37XXX High-Speed Pipeline ADC Data Capture Card (ADM00506)

• Two 5V Power Supplies

• A USB-A to USB Mini-B Cable

• External Clock Source or Crystal Oscillator (see Section 2.2.4.1 “Optimizing the

Clock Connection”)

• External Signal Input (see Section 2.2.4.2 “Optimizing the Analog Input

Connection”)

2.2.2 Power Input Connection

This evaluation kit comes with two switching power supplies (Mean Well:
GS06U-1P1J): one for each of the boards. These power supplies are able to provide a
5V, 1A maximum output. They can be connected to an AC wall outlet rated between
90V AC and 264V AC, at a frequency of 47 Hz to 63 Hz. The other end of the power
supply is a 2.1 mm barrel plug that connects to both the evaluation board and the data
capture c ard (see Figure 2-1). If the user chooses to connect a different external power
supply, a minimum output of 750 mA is required.

 2016 Microchip Technology Inc. DS50002511A-page 15

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

The evaluation board’s power supplies can also be supplied by external voltages
directly to the power domains. This can be done by disabling the desired regulator
using the dip switch SW2 - Regulator Enable on the silkscreen. Then, a DC voltage can
be driven directly into the appropriate pin of header J16. Note that the even pins of the
J16 header are GND.

The power domains on the evaluation board may be merged, if needed. Specifically,
the 1.2VA and 1.2VD power domains may be merged by populating a ferrite bead on
FB10. Similarly, the 1.8V A and 1.8VD power domains may be merged by populating a
ferrite bead on FB11. In both cases, the digital regulators should be disabled using the
appropriate switches.

WARNING

Avoid connecting a power supply with a voltage greater than 5V. Doing so can damage
the voltage regulators, requiring them to be replaced.

2.2.3 Evaluation Kit Set-Up

1. Connect the evaluation board and the data capture card as shown in Figure 2-1.

2. Power up both boards using the supplied 5V Power Supplies.

3. Ensure that a clock input is connected or that a crystal oscillator is installed
correctly. Follow instructions in section Section 2.2.4.1 “Optimizing the Clock

Connection”.

1: Note: If this is done correctly, the CAL DONE LED will be ON. Otherwise,

the user should check the clock input or crystal oscillator for issues.

4. Connect the data capture card to a computer using the provided USB cable.

5. Press the Reset button on both boards.

6. Run the Pipeline ADC Utility Software.

For help with troubleshooting the boards and operating the GUI, please refer to the
software’s supporting documentation.

WARNING

Avoid applying an input signal while the board is powered off. This may damage the input
baluns! If a high second harmonic is seen, it is likely that these baluns need to be replaced.

DS50002511A-page 16  2016 Microchip Technology Inc.

2016 Microchip Technology Inc. DS50002511A-page 17

Supply
Input (5V)

USB
Input

External
Clock
Input

Unpopulated

Board

ADC Device

Under Test

Connectors

Power

Header

Power

Power

Supply

Input (5V)

Data Capture
Card Reset
Switch

Xilinx
FPGA

MCP37XXX High-Speed Pipeline
ADC Data Capture Card (ADM00506)

MCP37X10-200 12-Bit Single-Channel
Evaluation Board (ADM00735)

Eval. Board
Reset Switch

Analog
Input

Regulator
Switches

Trace (Y1/Y2)

Crystal Oscillator

FB10 and FB11

Ferrite Locations

CAL DONE LED

FIGURE 2-1: Evaluation Kit - The evaluation board connected to the data capture card.

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

2.2.4 Input/Output Optimization

2.2.4.1 OPTIMIZING THE CLOCK CONNECTION

The evaluation board does not come with a clock source for the device. The user must
provide a clock source in order to run this evaluation board. The user has the following
options:

• Using Microchip’s 200 MHz Clock Source Evaluation Boards:

- Microchip’s ADM00725 or ADM00791 evaluation boards may be connected to
the external clock SMA input (See Figure 2-1). These boards were developed
as an optimized clock source for Microchip’s High-Speed ADCs. For more
information, refer to the board web page.

• Using a signal generator:

- A clean and low-jitter clock signal can be connected to the external clock SMA
input. For the signal generation, Rohde & Schwarz
T echnologies HP8644B signal generators can be used. T o ensure that a clean
and low-jitter clock signal is provided, the user should interpose a band-pass
filter to reduce the harmonics coming from the signal source. A 200 MHz
band-pass filter, such as KC4T-200M-10P-50-3A from TTE
recommended. A high-jitter or unfiltered clock source will reduce achievable
SNR at higher input frequencies.

• Using a Crystal Oscillator on the board:

- An unpopulated footprint is available on the board where the user can place a
crystal oscillator. For a single-ended clock, refer to the instructions in Example

1. For a differential clock, refer to the instructions in Example 2. The user may
also choose to place another type of clock as well. Note that the component
values given below are for example only and may vary depending on the
exact clock source used.

®

SMA100A or Agilent

®

Inc., is

Example 1

A clock oscillator with a single-ended output may be populated on Y2. The use of a
Microchip oscillator is recommended, such as the MXT573ABC200M000 for a 200
MHz clock. In this case, proceed to make the following modifications:

1. Remove R36

2. Populate R89 with a 499 resistor

3. Populate C106 with a 15 pF capacitor.

Example 2

A clock oscillator with a differential LVPECL output may be populated on Y2. The use
of a Microchip oscillator is recommended, such as the MXT575ABA200M000 for a 200
MHz clock. In this case, proceed to make the following modifications:

1. Remove R36 and R136

2. Populate R89 and R90 with a 210 resistor

3. Populate C105 and C106 with a 22 pF capacitor.

2.2.4.2 OPTIMIZING THE ANALOG INPUT CONNECTION
The best way to evaluate the MCP37X10-200 device is to use a clean analog input

signal with as little noise as possible. The signal can be provided using a signal
generator, such as Rohde & Schwarz SMA100A or Agilent Technologies HP8644B,
and can be used along with a bandpass filter. The filter will help with filtering the
harmonic tones of the fundamental, as well as with reducing the phase noise of the
source. Two such filters that can be used are:

DS50002511A-page 18  2016 Microchip Technology Inc.

• KC4T-70M-15P-50-69A, TTE Inc.’s 70 MHz filter

• KC4T-20M-15P-50-69A, TTE Inc.’s 20 MHz filter

Note: If one of the analog inputs appears to not work properly, exhibiting issues

such as a high 2nd harmonic or substantially lower fundamental power, it is
likely that the baluns on that input network are damaged. Replacing them
should resolve these issues.

2.2.4.3 OUTPUT DATA CONFIGURATION
The MCP37X10-200 device is able to provide both LVDS and CMOS outputs. However,

this evaluation kit is designed for L VDS outputs only. The user can modify various other
output data properties using the GUI, with the exception of the LVDS/CMOS output
mode.

2016 Microchip Technology Inc. DS50002511A-page 19

MCP37X10-200 12-Bit Single-Channel Evaluation Kit User’s Guide

NOTES:

DS50002511A-page 20  2016 Microchip Technology Inc.
