GPIO EXPANDER KEYPAD
AND LCD DEMO BOARD
USER’S GUIDE
Table of Contents
Preface ........................................................................................................................... 1
Introduction............................................................................................................ 1
Document Layout .................................................................................................. 1
Conventions Used in this Guide ............................................................................ 2
Recommended Reading........................................................................................ 2
The Microchip Web Site ........................................................................................ 3
Customer Support ................................................................................................. 3
Document Revision History ................................................................................... 3
Chapter 1. Product Overview ....................................................................................... 5
1.1 Introduction ..................................................................................................... 5
1.2 What is the GPIO Expander Keypad and LCD Demo Board? ....................... 5
1.3 What The GPIO Expander Keypad and LCD Demo Board Kit Includes ........ 5
Chapter 2. Installation and Operation ......................................................................... 7
2.1 Introduction ..................................................................................................... 7
2.2 Features ......................................................................................................... 7
2.3 Getting Started ............................................................................................... 8
2.4 GPIO Expander Keypad and LCD Demo Board Description ......................... 9
2.5 Firmware Description ................................................................................... 10
Appendix A. Schematics and Board Layouts ........................................................... 15
A.1 Introduction .................................................................................................. 15
A.2 Board Schematic - Page 1 ......................................................................... 16
A.3 Board Schematic - Page 2 ......................................................................... 17
A.4 Board Schematic - Page 3 ......................................................................... 18
A.5 Board - Top Layer (with Silk screen) .......................................................... 19
A.6 Board - Bottom Layer ................................................................................. 19
Appendix B. Bill Of Materials (BOM) ......................................................................... 21
Worldwide Sales and Service .................................................................................... 24
© 2006 Microchip Technology Inc. DS51636A-page iii
GPIO Expander Keypad and LCD Demo Board User’s Guide
NOTES:
DS51636A-page iv © 2006 Microchip Technology Inc.
GPIO EXPANDER KEYPAD
AND LCD DEMO BOARD
USER’S GUIDE

Preface

NOTICE TO CUSTOMERS
All documentation becomes dated, and this manual is no exception. Microchip tools and documentation are constantly evolving to meet customer needs, so some actual dialogs and/or tool descriptions may differ from those in this document. Please refer to our web site (www.microchip.com) to obtain the latest documentation available.
Documents are identified with a “DS” number. This number is located on the bottom of each page, in front of the page number. The numbering convention for the DS number is “DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the document.

INTRODUCTION

This chapter contains general information that will be useful to know before using the GPIO Expander Keypad and LCD Demo Board. Items discussed in this chapter include:
• Document Layout
• Conventions Used in this Guide
• Recommended Reading
• The Microchip Web Site
• Customer Support
• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the GPIO Expander Keypad and LCD Demo Board as a development tool. The manual layout is as follows:
Chapter 1. “Product Overview” – Important information about the GPIO Expander Keypad and LCD Demo Board.
Chapter 2. “Installation and Operation” – Includes instructions on how to get started with this evaluation board.
Appendix A. “Schematics and Board Layouts” – Shows the schematic and layout diagrams for the GPIO Expander Keypad and LCD Demo Board.
Appendix B. “Bill Of Materials (BOM)” – Lists the parts used to build the GPIO Expander Keypad and LCD Demo Board.
© 2006 Microchip Technology Inc. DS51636A-page 1
GPIO Expander Keypad and LCD Demo Board User’s Guide

CONVENTIONS USED IN THIS GUIDE

This manual uses the following documentation conventions:
DOCUMENTATION CONVENTIONS
Description Represents Examples
Arial font:
Italic characters Referenced books MPLAB
Emphasized text ...is the only compiler...
Initial caps A window the Output window
A dialog the Settings dialog A menu selection select Enable Programmer
Quotes A field name in a window or
dialog
Underlined, italic text with right angle bracket
Bold characters A dialog button Click OK
N‘Rnnnn A number in verilog format,
Text in angle brackets < > A key on the keyboard Press <Enter>, <F1>
Courier New font:
Plain Courier New Sample source code #define START
Italic Courier New A variable argument file.o, where file can be
Square brackets [ ] Optional arguments mcc18 [options] file
Curly brackets and pipe character: { | }
A menu path File>Save
A tab Click the Power tab
where N is the total number of digits, R is the radix and n is a digit.
Filenames autoexec.bat File paths c:\mcc18\h Keywords _asm, _endasm, static Command-line options -Opa+, -Opa- Bit values 0, 1 Constants 0xFF, ‘A’
Choice of mutually exclusive arguments; an OR selection
“Save project before build”
4‘b0010, 2‘hF1
any valid filename
[options] errorlevel {0|1}
®
IDE User’s Guide

RECOMMENDED READING

For more information regarding the Stand-Alone CAN controller, CAN I/O Expander, and CAN transceiver devices, refer to the appropriate data sheet. Table 1 shows the device and associated Data Sheet literature number. These documents can be found at Microchip’s web site at: www.microchip.com.
TABLE 1: DEVICES AND DATA SHEET LITERATURE NUMBERS
Device Literature # Device Literature #
MCP23X08 DS21919 PIC18F4550 DS39632
MCP23X17 DS21952 MCP1702 DS22008
DS51636A-page 2 © 2006 Microchip Technology Inc.

THE MICROCHIP WEB SITE

Microchip provides online support via our web site at www.microchip.com. This web site is used as a means to make files and information easily available to customers. Accessible by using your favorite Internet browser, the web site contains the following information:
Product Support – Data sheets and errata, application notes and sample programs, design resources, user’s guides and hardware support documents, latest software releases and archived software
General Technical Support – Frequently Asked Questions (FAQs), technical support requests, online discussion groups, Microchip consultant program member listing
Business of Microchip – Product selector and ordering guides, latest Microchip press releases, listing of seminars and events, listings of Microchip sales offices, distributors and factory representatives

CUSTOMER SUPPORT

Users of Microchip products can receive assistance through several channels:
• Distributor or Representative
• Local Sales Office
• Field Application Engineer (FAE)
• Technical Support
• Development Systems Information Line
Customers should contact their distributor, representative or field application engineer for support. Local sales offices are also available to help customers. A listing of sales offices and locations is included in the back of this document.
Technical support is available through the web site at: http://support.microchip.com
Preface

DOCUMENT REVISION HISTORY

Revision A (October 2006)
• Initial Release of this Document.
© 2006 Microchip Technology Inc. DS51636A-page 3
GPIO Expander Keypad and LCD Demo Board User’s Guide
NOTES:
DS51636A-page 4 © 2006 Microchip Technology Inc.
GPIO EXPANDER KEYPAD
AND LCD DEMO BOARD
USER’S GUIDE

Chapter 1. Product Overview

1.1 INTRODUCTION

This chapter provides an overview of the GPIO Expander Keypad and LCD Demo Board and covers the following topics:
• What is the GPIO Expander Keypad and LCD Demo Board?
• What the GPIO Expander Keypad and LCD Demo Board Kit includes

1.2 WHAT IS THE GPIO EXPANDER KEYPAD AND LCD DEMO BOARD?

The GPIO Expander Keypad and LCD Demo Board allows the system designer to evaluate the operation of the MCP23X17 and MCP23X08 General Purpose I/O (GPIO) Expanders. The board demonstrates the GPIO Expanders’ performance in a keypad and LCD example.

1.3 WHAT THE GPIO EXPANDER KEYPAD AND LCD DEMO BOARD KIT INCLUDES

This GPIO Expander Keypad and LCD Demo Board Kit includes:
• One GPIO Expander Keypad and LCD Demo Board (102-00116)
- MCP23008 GPIO Expander with I
- MCP23S08 GPIO Expander with SPI interface (installed)
- MCP23017 GPIO Expander with I
- MCP23S17 GPIO Expander with SPI interface (installed)
• Analog and Interface Products Demonstration Boards CD-ROM (DS21912)
- GPIO Expander Keypad and LCD Demo Board User’s Guide (DS51636)
®
-PIC
-PCB Gerber Files
Microcontroller Firmware
2
C™ interface (installed)
2
C™ interface (installed)
© 2006 Microchip Technology Inc. DS51636A-page 5
GPIO Expander Keypad and LCD Demo Board User’s Guide
NOTES:
DS51636A-page 6 © 2006 Microchip Technology Inc.

Chapter 2. Installation and Operation

2.1 INTRODUCTION

This chapter discusses the setup and operation of the GPIO Expander Keypad and LCD Demo Board.
The GPIO Expander Keypad and LCD Demo Board is designed to demonstrate using GPIO expanders in a keypad and LCD example. The MCP23X17 interfaces to a 2x16 LCD module and the MCP23X08 interfaces to a 4x4 keyed matrix.
Both the I interfaces.

2.2 FEATURES

The GPIO Expander Keypad and LCD Demo Board has the following features:
• Two (2) 8-bit GPIO Expanders
- MCP23008 with I
- MCP23S08 with SPI interface
• Two (2) 16-bit GPIO Expanders
- MCP23017 with I
- MCP23S17 with SPI interface
• 4X4 keypad layout (16 momentary buttons)
- Numbers 0 - 9
- Six special function buttons
• A 2X16 LCD module
• Headers for the MCP23X08 and MCP23X17 pins
• Header for programming the PIC18F4550
GPIO EXPANDER KEYPAD
AND LCD DEMO BOARD
USER’S GUIDE
2
C™ and SPI versions are included on the board to demonstrate both serial
2
C™ interface
2
C™ interface
© 2006 Microchip Technology Inc. DS51636A-page 7
GPIO Expander Keypad and LCD Demo Board User’s Guide

2.3 GETTING STARTED

The GPIO Expander Keypad and LCD Demo Board is a fully functional, assembled and tested board for demonstrating the MCP23008 and MCP23017 (I
2
C interface) and MCP23S08 and MCP23S17 (SPI interface) general purpose I/O expanders. The following describes the basic setup and operation (see Figure 2-1):
1. Either connect a 9V power supply into the power jack (J2) or connect a 5 V power
supply to the V
and GND test points.
DD
2. The green power LED will illuminate.
3. The LCD will display the startup splash screen.
4. The appropriate LEDs (I
2
C or SPI) will illuminate to indicate the current serial
mode.
5. Pressing buttons:
- 0 - 9, #, *: will be reflected on the LCD
- M: switches modes (I
2
C and SPI) to communicate with the MCP23X17 and MCP23X08; B: backspace; R: carriage return, and screen clear (2nd press); S: space
FIGURE 2-1: BOARD LAYOUT
2 X 16 LCD
Not Populated
USB
USB
9V
EXT
+5V
Keypad/LCD Demo
GND
16-bit HEADER
MCP23017
LED
LED
7 8 9 M
GPIO Expander
4 5 6 B
1 2 3 R
* 0 # S
PIC18F2550
MCP23008
8-bit HEADER
MCP23S17
LED
LED
I2C/SPI
ICSP
MCP23S08
M
DS51636A-page 8 © 2006 Microchip Technology Inc.
Installation and Operation

2.4 GPIO EXPANDER KEYPAD AND LCD DEMO BOARD DESCRIPTION

2.4.1 Major Board Components

The functional block diagram is shown in Figure 2-2.
FIGURE 2-2: FUNCTIONAL BLOCK DIAGRAM
Header
Input Output
GPIO
OUTIN
2 X 16 LCD
Control
Power
Programming
1. The GPIO BLOCK contains the MCP23X17 and MCP23X08 GPIO Expanders. Two (2) MCP23X17 devices are connected to the LCD module and two (2) MCP23X08 devices are connected to the keypad matrix. A button on the keypad toggles between I
2
C and SPI mode. When in I2C mode, the MCP23017 and MCP23008 are controlled by the PIC MCU. When in SPI mode, the MCP23S17 and MCP23S08 are controlled. Only one (1) MCP23X08 and one (1) MCP23X17 is on the bus at a time.
2. The CONTROL BLOCK contains the PIC18F4550 and is the main intelligence in the system.
3. The INPUT BLOCK contains the 4x4 keypad matrix. The MCP23X08 devices are used to scan the keys.
4. The OUTPUT BLOCK contains the 2x16 LCD. The MCP23X17 devices control the display.
5. The MCP23X17 and MCP23X08 I/O and serial lines are routed to the HEADER BLOCK to allow the pins to be probed.
6. The PROGRAMMING BLOCK contains the ICSP™ header for program­ming/debugging the PIC18F4550.
7. The POWER BLOCK contains the MCP1702 5V voltage regulator. The board can be powered by a 9V supply (connected through the power jack) or by applying 5V directly to the power points.
© 2006 Microchip Technology Inc. DS51636A-page 9
GPIO Expander Keypad and LCD Demo Board User’s Guide

2.5 FIRMWARE DESCRIPTION

See Figure 2-3 for the main firmware flow diagram.
Main Function:
1. The firmware first configures the PIC MCU.
2. The MCP23X08 and MCP23X17 devices are configured. I selected first by default. The SPI devices I/O are held in reset.
3. The LCD splash screen is shown.
4. Wait for an interrupt from the MCP23X08. An interrupt will occur when a button is pressed. Four (4) inputs are configured to interrupt on falling edge. These inputs are for the “columns” of the keypad matrix.
5. After the interrupt occurs, the firmware calls the Scan_Buttons routine.
6. Then the Update_LCD routine.
Scan_Buttons Function:
1. Read INTCAP register. This register contains a snapshot of the port condition when the interrupt occurred.
2. Swap inputs and outputs so the rows can be read.
3. Read GPIO register and merge with variable containing INTCAP value.
4. The pressed key is determined by looking up the result in a lookup table.
2
C Devices are
Update_LCD Function:
1. The LCD is updated based on which button was pressed.
DS51636A-page 10 © 2006 Microchip Technology Inc.
Installation and Operation
FIGURE 2-3: MAIN FIRMWARE FLOW
Start
Init_MCU
Init_MCP
Splash
GPIO INT Flag
Set?
YES
Scan_Buttons
Update_LCD
NO
The MCP23X08 is configured to interrupt on falling edge for the columns (4 inputs)
After the interrupt, the column location of the button is known and is contained in INTCAP. Need to read GPIO to get the Row location.
Buttons: 0-9, #, * : Copied to the LCD
M: Toggle mode (SPI and I B: Backspace R: Carriage Return S: Space
2
C™)
© 2006 Microchip Technology Inc. DS51636A-page 11
GPIO Expander Keypad and LCD Demo Board User’s Guide
FIGURE 2-4: KEYPAD SCAN
Scan_Buttons
One nibble is set to input and the other nibble is output (to read the columns) (already configured before entering function).
Read INTCAP
Swap inputs and
outputs
Read INTCAP and place in a variable.
To read the rows.
Merge with variable containing INTCAP value.
The result can be looked up in a table (switch statement) to determine which key was pressed.
Read GPIO
Determine key
press from lookup
table
Set I/O back to
default so it is
correct the next
time the function is
called
END
DS51636A-page 12 © 2006 Microchip Technology Inc.
FIGURE 2-5: LCD UPDATE
Installation and Operation
Update_LCD
The pressed button result comes from the variable in the Scan_Buttons function
1 - 9
M
Toggle Serial
Mode
(I2C or SPI)
Button Press?
B
S
R
Backspace Space
Carriage Return Display *
#
*
Display #Display
END
© 2006 Microchip Technology Inc. DS51636A-page 13
GPIO Expander Keypad and LCD Demo Board User’s Guide
NOTES:
DS51636A-page 14 © 2006 Microchip Technology Inc.

Appendix A. Schematics and Board Layouts

A.1 INTRODUCTION

This appendix contains the schematic and PCB layout for the GPIO Expander Keypad and LCD Demo Board. Diagrams included:
• Board Schematics - Pages 1 - 3.
• Board - Top Layer (with silk screen)
• Board - Bottom Layer
GPIO EXPANDER KEYPAD
AND LCD DEMO BOARD
USER’S GUIDE
© 2006 Microchip Technology Inc. DS51636A-page 15
GPIO Expander Keypad and LCD Demo Board User’s Guide
A.2 BOARD SCHEMATIC - PAGE 1
M
DS51636A-page 16 © 2006 Microchip Technology Inc.
Schematics and Board Layouts
A.3 BOARD SCHEMATIC - PAGE 2
M
© 2006 Microchip Technology Inc. DS51636A-page 17
GPIO Expander Keypad and LCD Demo Board User’s Guide
A.4 BOARD SCHEMATIC - PAGE 3
M
DS51636A-page 18 © 2006 Microchip Technology Inc.
Schematics and Board Layouts
A.5 BOARD - TOP LAYER (WITH SILK SCREEN)
A.6 BOARD - BOTTOM LAYER
© 2006 Microchip Technology Inc. DS51636A-page 19
GPIO Expander Keypad and LCD Demo Board User’s Guide
NOTES:
DS51636A-page 20 © 2006 Microchip Technology Inc.
GPIO EXPANDER KEYPAD
AND LCD DEMO BOARD
USER’S GUIDE

Appendix B. Bill Of Materials (BOM)

TABLE B-1: BILL OF MATERIALS
Qty
23 C1, C5, C6
1 C3 CAP CER .33UF 16V Y5V 0805 Murata Electronics
2 C16, C17 CAP 22PF 50V CERM CHIP 0805 SMD
1 C18 CAP .22UF 16V CERAMIC X7R 0805 Panasonic - ECG ECJ-2VB1C224K
4 D1, D2, D3, D4 LED 636NM SUPER RED 0805 SMD LITE-ON INC SML-LX0805SIC-TR
2 D5, D6 DIODE SCHOTTKY 20V 0.5A SOD123 ON Semiconductor
2 D7, D8 LED THIN 565NM GRN DIFF 0805
1 D9 RECT SCHOTTKY 1A 20V DO-214AA Micro Commercial Co. SMB5817-TP
4 EA Corner BUMPON X-TALL TAPER SQ
1 J1 *Do Not Populate*
1 J2 CONN POWER JACK 2.5MM PCB
1 J3 *Do Not Populate*
1 J4 *Do Not Populate*
2 J5, J10 *Do Not Populate*
1 J9 CONN USB RTANG FEMALE TYPE B
1 LCD1 LCD_2x16 Fema CG1626-SGR1
6 R1, R2, R3,
2 R4, R5 RES 270 OHM 1/8W 5% 0805 SMD Panasonic - ECG ERJ-6GEYJ271V
1 R6 RES 523 OHM 1/8W 1% 0805 SMD Yageo
2 R7, R54 RES 4.70K OHM 1/8W 1% 0805 SMD Yageo Corporation RC0805FR-074K7L
3 R24, R25, R35 RES 1.00K OHM 1/10W 1% 0805 SMD Panasonic - ECG ERJ-6ENF1001V
2 R29, R30 RES 0.0 OHM 1/8W 5% 0805 SMD Panasonic - ECG ERJ-6GEY0R00V
Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM
Reference
Designator
CAP 1UF 16V CERAMIC Y5V 0805 Panasonic C15, C25, C30, C31, C32, C33, C34, C35, C36, C37, C38, C39, C40, C41, C42, C43, C44, C45, C 4 6 , C 4 7 , C48
*Do Not Populate*
SMD
.81X.30BK
CIRC
PCB *Do Not Populate*
RES 10.0K OHM 1/10W 1% 0805 SMD Panasonic - ECG ERJ-6ENF1002V R8, R9, R53
used in manufacturing uses all RoHS-compliant components.
Description Manufacturer Part Number
®
- ECG ECJ-2VF1C105Z
®
GRM219F51C334ZA01D
North America
Panasonic - ECG ECJ-2VC1H220J
®
MBR0520LT1G
Optoelectronics SML-LXT0805GW-TR
3M/ESM SJ-5523 (BLACK)
CUI Inc PJ-102B
Assmann Electronics Inc
®
Corporation RC0805FR-07523RL
AU-Y1007-R
© 2006 Microchip Technology Inc. DS51636A-page 21
GPIO Expander Keypad and LCD Demo Board User’s Guide
TABLE B-1: BILL OF MATERIALS (CONTINUED)
Qty
16 R32, R33, R34,
1 R49 RES 33.2K OHM 1/8W 1% 0805 SMD Yageo
2 R50, R52 RES 475 OHM 1/10W 1% 0603 SMD Panasonic - ECG ERJ-3EKF4750V
1 R51 RES 100K OHM 1/8W 5% 0805 SMD Panasonic - ECG ERJ-6GEYJ104V
17 S11, S12, S13,
1 TP1 TEST POINT PC MULTI PURPOSE
1 TP2 TEST POINT PC MULTI PURPOSE
1 U1 16 Bit I/O Expander with Serial Interface Microchip Technology
1 U2 8-Bit I/O Expander with SPI Interface Microchip Technology
1 U3 16 Bit I/O Expander with Serial Interface Microchip Technology
1 U4 8-Bit I/O Expander with I
1 U5 44-Pin, High-Performance, Enhanced
1U6 2 μA Low Dropout Positive Voltage
1 U7 MOSFET P-CH 20V 850MA SSOT3 Fairchild
1 Y1 CRYSTAL 20.0000 MHZ SERIES RES
Note 1: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM
Reference
Designator
Description Manufacturer Part Number
RES 100 OHM 1/10W 3900PPM
R36, R37, R38,
5%0805 R39, R40, R41, R42, R43, R44, R45, R46, R47, R48
SWITCH TACT 6MM SMD MOM 160GF Omron Electronics Inc B3S-1000 S14, S15, S16, S17, S18, S19, S20, S21, S22, S23, S24, S25, S26, S27
BLK
RED
2
C Interface Microchip Technology
Flash, USB Microcontroller
Regulator
*Do Not Populate*
used in manufacturing uses all RoHS-compliant components.
Panasonic - ECG ERA-S39J101V
®
Corporation RC0805FR-0733K2L
®
Keystone Electronics
5011
Keystone Electronics 5010
MCP23S17-E/SS
Inc
MCP23S08-E/SS
Inc
MCP23017-E/SS
Inc
MCP23008-E/SS
Inc
Microchip Technology
PIC18F4550
Inc
Microchip Technology
MCP1702T-5002I/CB
Inc
NDS352P
ATS200
Semiconductor
CTS-Frequency
®
Controls
DS51636A-page 22 © 2006 Microchip Technology Inc.
NOTES:
Bill Of Materials (BOM)
© 2006 Microchip Technology Inc. DS51636A-page 23

WORLDWIDE SALES AND SERVICE

AMERICAS
Corporate Office
2355 West Chandler Blvd. Chandler, AZ 85224-6199 Tel: 480-792-7200 Fax: 480-792-7277 Technical Support: http://support.microchip.com Web Address: www.microchip.com
Atlanta
Alpharetta, GA Tel: 770-640-0034 Fax: 770-640-0307
Boston
Westborough, MA Tel: 774-760-0087 Fax: 774-760-0088
Chicago
Itasca, IL Tel: 630-285-0071 Fax: 630-285-0075
Dallas
Addison, TX Tel: 972-818-7423 Fax: 972-818-2924
Detroit
Farmington Hills, MI Tel: 248-538-2250 Fax: 248-538-2260
Kokomo
Kokomo, IN Tel: 765-864-8360 Fax: 765-864-8387
Los Angeles
Mission Viejo, CA Tel: 949-462-9523 Fax: 949-462-9608
Santa Clara
Santa Clara, CA Tel: 408-961-6444 Fax: 408-961-6445
Toronto
Mississauga, Ontario, Canada Tel: 905-673-0699 Fax: 905-673-6509
ASIA/PACIFIC
Asia Pacific Office
Suites 3707-14, 37th Floor Tower 6, The Gateway Habour City, Kowloon Hong Kong Tel: 852-2401-1200 Fax: 852-2401-3431
Australia - Sydney
Tel: 61-2-9868-6733 Fax: 61-2-9868-6755
China - Beijing
Tel: 86-10-8528-2100 Fax: 86-10-8528-2104
China - Chengdu
Tel: 86-28-8665-5511 Fax: 86-28-8665-7889
China - Fuzhou
Tel: 86-591-8750-3506 Fax: 86-591-8750-3521
China - Hong Kong SAR
Tel: 852-2401-1200 Fax: 852-2401-3431
China - Qingdao
Tel: 86-532-8502-7355 Fax: 86-532-8502-7205
China - Shanghai
Tel: 86-21-5407-5533 Fax: 86-21-5407-5066
China - Shenyang
Tel: 86-24-2334-2829 Fax: 86-24-2334-2393
China - Shenzhen
Tel: 86-755-8203-2660 Fax: 86-755-8203-1760
China - Shunde
Tel: 86-757-2839-5507 Fax: 86-757-2839-5571
China - Wuhan
Tel: 86-27-5980-5300 Fax: 86-27-5980-5118
China - Xian
Tel: 86-29-8833-7250 Fax: 86-29-8833-7256
ASIA/PACIFIC
India - Bangalore
Tel: 91-80-4182-8400 Fax: 91-80-4182-8422
India - New Delhi
Tel: 91-11-4160-8631 Fax: 91-11-4160-8632
India - Pune
Tel: 91-20-2566-1512 Fax: 91-20-2566-1513
Japan - Yokohama
Tel: 81-45-471- 6166 Fax: 81-45-471-6122
Korea - Gumi
Tel: 82-54-473-4301 Fax: 82-54-473-4302
Korea - Seoul
Tel: 82-2-554-7200 Fax: 82-2-558-5932 or 82-2-558-5934
Malaysia - Penang
Tel: 60-4-646-8870 Fax: 60-4-646-5086
Philippines - Manila
Tel: 63-2-634-9065 Fax: 63-2-634-9069
Singapore
Tel: 65-6334-8870 Fax: 65-6334-8850
Taiwan - Hsin Chu
Tel: 886-3-572-9526 Fax: 886-3-572-6459
Taiwan - Kaohsiung
Tel: 886-7-536-4818 Fax: 886-7-536-4803
Taiwan - Taipei
Tel: 886-2-2500-6610 Fax: 886-2-2508-0102
Thailand - Bangkok
Tel: 66-2-694-1351 Fax: 66-2-694-1350
EUROPE
Austria - Wels
Tel: 43-7242-2244-39 Fax: 43-7242-2244-393
Denmark - Copenhagen
Tel: 45-4450-2828 Fax: 45-4485-2829
France - Paris
Tel: 33-1-69-53-63-20 Fax: 33-1-69-30-90-79
Germany - Munich
Tel: 49-89-627-144-0 Fax: 49-89-627-144-44
Italy - Milan
Tel: 39-0331-742611 Fax: 39-0331-466781
Netherlands - Drunen
Tel: 31-416-690399 Fax: 31-416-690340
Spain - Madrid
Tel: 34-91-708-08-90 Fax: 34-91-708-08-91
UK - Wokingham
Tel: 44-118-921-5869 Fax: 44-118-921-5820
10/19/06
DS51636A-page 24 © 2006 Microchip Technology Inc.
Loading...
