UTC2000
Evaluation Kit
User’s Guide
2015 Microchip Technology Inc. DS50002399B
Note the following details of the code protection feature on Microchip devices:
YSTEM
CERTIFIE DBYDNV
== ISO/TS16949==
• Microchip products meet the specification contained in their particular Microchip Data Sheet.
• Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the
intended manner and under normal conditions.
• There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our
knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data
Sheets. Most likely, the person doing so is engaged in theft of intellectual property.
• Microchip is willing to work with the customer who is concerned about the integrity of their code.
• Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not
mean that we are guaranteeing the product as “unbreakable.”
Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our
products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts
allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.
Information contained in this publication regarding device applications and the like is provided only for your convenience and may be
superseded by updates. It is your responsibility to ensure that your application meets with your specifications. MICROCHIP MAKES NO
REPRESENTATIONS OR WARRANTIES OF ANY KIND WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, STATUTORY OR
OTHERWISE, RELATED TO THE INFORMATION, INCLUDING BUT NOT LIMITED TO ITS CONDITION, QUALITY, PERFORMANCE,
MERCHANTABILITY OR FITNESS FOR PURPOSE. Microchip disclaims all liability arising from this information and its use. Use of Microchip devices in life support and/or safety applications is entirely at the buyer’s risk, and the buyer agrees to defend, indemnify and hold
harmless Microchip from any and all damages, claims, suits, or expenses resulting from such use. No licenses are conveyed, implicitly or
otherwise, under any Microchip intellectual property rights unless otherwise stated.
Trademarks
The Microchip name and logo, the Microchip logo, dsPIC, FlashFlex, flexPWR, JukeBlox, K
MediaLB, MOST, MOST logo, MPLAB, OptoLyzer, PIC, PICSTART, PIC
UNI/O are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
The Embedded Control Solutions Company and mTouch are registered trademarks of Microchip Technology Incorporated in the U.S.A.
Analog-for-the-Digital Age, BodyCom, chipKIT, chipKIT logo, CodeGuard, dsPICDEM, dsPICDEM.net, ECAN, In-Circuit Serial
Programming, ICSP, Inter-Chip Connectivity, KleerNet, KleerNet logo, MiWi, motorBench, MPASM, MPF, MPLAB Certified logo,
MPLIB, MPLINK, MultiTRAK, NetDetach, Omniscient Code Generation, PICDEM, PICDEM.net, PICkit, PICtail, RightTouch logo, REAL
ICE, SQI, Serial Quad I/O, Total Endurance, TSHARC, USBCheck, VariSense, ViewSpan, WiperLock, Wireless DNA, and ZENA are
trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
SQTP is a service mark of Microchip Technology Incorporated in the U.S.A.
Silicon Storage Technology is a registered trademark of Microchip Technology Inc. in other countries.
GestIC is a registered trademark of Microchip Technology Germany II GmbH & Co. KG, a subsidiary of Microchip Technology Inc., in
other countries.
All other trademarks mentioned herein are property of their respective companies.
© 2015, Microchip Technology Incorporated, Printed in the U.S.A., All Rights Reserved.
ISBN: 978-1-5224-0025-7
32
logo, RightTouch, SpyNIC, SST, SST Logo, SuperFlash and
EELOQ, KEELOQ logo, Kleer, LANCheck,
QUALITYMANAGEMENTS
DS50002399B-page 2 2015 Microchip Technology Inc.
Microchip received ISO/TS-16949:2009 certification for its worldwide
headquarters, design and wafer fabrication facilities in Chandler and
Tempe, Arizona; Gresham, Oregon and design centers in California
and India. The Company’s quality system processes and procedures
are for its PIC
devices, Serial EEPROMs, microperipherals, nonvolatile memory and
analog products. In addition, Microchip’s quality system for the design
and manufacture of development systems is ISO 9001:2000 certified.
®
MCUs and dsPIC® DSCs, KEELOQ
®
code hopping
Object of Declaration: UTC2000
2015 Microchip Technology Inc. DS50002399B-page 3
UTC2000 Evaluation Kit User’s Guide
NOTES:
DS50002399B-page 4 2015 Microchip Technology Inc.
UTC2000
EVALUATION KIT
USER’S GUIDE
Table of Contents
Preface ........................................................................................................................... 7
Introduction............................................................................................................ 7
Document Layout EVK-UTC2000 ......................................................................... 7
Conventions Used in this Guide ............................................................................ 8
Warranty Registration............................................................................................ 9
The Microchip Website.......................................................................................... 9
Customer Support ................................................................................................. 9
Document Revision History ................................................................................. 10
Chapter 1. Overview
1.1 UTC2000 Evaluation Kit Overview and Features ......................................... 11
1.2 Features ....................................................................................................... 11
1.3 General Description ...................................................................................... 12
1.4 References ................................................................................................... 13
1.5 Definition ...................................................................................................... 13
Chapter 2. Getting Started
2.1 Contents of the Kit ........................................................................................ 15
2.2 Bring-Up and Testing ................................................................................... 15
2.2.1 Setup and Requirements ........................................................................... 15
2.2.2 EVB-UTC2000-DFP Legacy Charging Operation ..................................... 15
2.2.3 1.5A Charging Operation ........................................................................... 15
2.2.4 3.0A Charging Operation ........................................................................... 16
Chapter 3. Hardware Configuration
3.1 Hardware Description ................................................................................... 17
3.1.1 Power Source ............................................................................................ 17
3.1.2 LED Indicators for EVB-UTC2000-DFP ..................................................... 18
3.1.3 Switches on EVB-UTC2000-DFP .............................................................. 19
3.1.4 Connector Descriptions for EVB-UTC2000-DFP ....................................... 20
3.1.5 Test Points on EVB-UTC2000-DFP .......................................................... 20
3.1.6 LED Indicators for EVB-UTC2000-UFP ..................................................... 20
3.1.7 Switches on EVB-UTC2000-UFP .............................................................. 21
3.1.8 Connector Descriptions for EVB-UTC2000-UFP ....................................... 21
3.1.9 Test Points on EVB-UTC2000-UFP .......................................................... 22
Appendix A. UTC2000 Schematics
A.1 Introduction .................................................................................................. 23
Appendix B. EVK-UTC2000 BOM
B.1 Introduction .................................................................................................. 27
Appendix C. EVK-UTC2000 PCB Silk Screens
2015 Microchip Technology Inc. DS50002399B-page 5
UTC2000 Evaluation Kit User’s Guide
C.1 Introduction .................................................................................................. 31
Worldwide Sales and Service .....................................................................................34
DS50002399B-page 6 2015 Microchip Technology Inc.
UTC2000
EVALUATION KIT
USER’S GUIDE
Preface
NOTICE TO CUSTOMERS
All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our website
(www.microchip.com) to obtain the latest documentation available.
Documents are identified with a “DS” number. This number is located on the bottom of each
page, in front of the page number. The numbering convention for the DS number is
“DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the
document.
For the most up-to-date information on development tools, see the MPLAB
Select the Help menu, and then Topics to open a list of available online help files.
®
IDE online help.
INTRODUCTION
This chapter contains general information that will be useful to know before using the
UTC2000 Evaluation Kit User’s Guide. Items discussed in this chapter include:
• Document Layout EVK-UTC2000
• Conventions Used in this Guide
• Warranty Registration
• The Microchip Website
• Customer Support
• Document Revision History
DOCUMENT LAYOUT EVK-UTC2000
This document describes how to use the UTC2000 Evaluation Kit as a demonstration
platform optimized for portable applications. The manual layout is as follows:
• Chapter 1. “Overview” – Shows a brief description of the UTC2000 Evaluation
Kit
• Chapter 2. “Getting Started” – Provides information about set-up and operation
of the UTC2000 Evaluation Kit.
• Chapter 3. “Hardware Configuration” – Includes information about the
hardware configuration of the UTC2000 Evaluation Kit.
• Appendix A. “UTC2000 Schematics”
• Appendix B. “EVK-UTC2000 BOM”
• Appendix C. “EVK-UTC2000 PCB Silk Screens”
Note: USB Type-C™ USB-C™ are trademarks of USB Implementation Forum.
2015 Microchip Technology Inc. DS50002399B-page 7
UTC2000 Evaluation Kit User’s Guide
CONVENTIONS USED IN THIS GUIDE
This manual uses the following documentation conventions:
DOCUMENTATION CONVENTIONS
Description Represents Examples
Arial font:
Italic characters Referenced books MPLAB
Initial caps A window the Output window
Quotes A field name in a window or
Underlined, italic text with
right angle bracket
Bold characters A dialog button Click OK
N‘Rnnnn A number in verilog format,
Text in angle brackets < > A key on the keyboard Press <Enter>, <F1>
Courier New font:
Plain Courier New Sample source code #define START
Italic Courier New A variable argument file.o, where file can be
Square brackets [ ] Optional arguments mcc18 [options] file
Curly brackets and pipe
character: { | }
Ellipses... Replaces repeated text var_name [,
®
IDE User’s Guide
Emphasized text ...is the only compiler...
A dialog the Settings dialog
A menu selection select Enable Programmer
“Save project before build”
dialog
A menu path File>Save
A tab Click the Power tab
4‘b0010, 2‘hF1
where N is the total number of
digits, R is the radix and n is a
digit.
Filenames autoexec.bat
File paths c:\mcc18\h
Keywords _asm, _endasm, static
Command-line options -Opa+, -Opa-
Bit values 0, 1
Constants 0xFF, ‘A’
any valid filename
[options]
Choice of mutually exclusive
arguments; an OR selection
Represents code supplied by
user
errorlevel {0|1}
var_name...]
void main (void)
{ ...
}
DS50002399B-page 8 2015 Microchip Technology Inc.
WARRANTY REGISTRATION
Please complete the enclosed Warranty Registration Card and mail it promptly.
Sending the Warranty Registration Card entitles users to receive new product updates.
Interim software releases are available at the Microchip website.
THE MICROCHIP WEBSITE
Microchip provides online support via our website at www.microchip.com. This website
is used as a means to make files and information easily available to customers. Accessible by using your favorite Internet browser, the website contains the following information:
• Product Support – Data sheets and errata, application notes and sample
programs, design resources, user’s guides and hardware support documents,
latest software releases and archived software
• General Technical Support – Frequently Asked Questions (FAQs), technical
support requests, online discussion groups, Microchip consultant program
member listing
• Business of Microchip – Product selector and ordering guides, latest Microchip
press releases, listing of seminars and events, listings of Microchip sales offices,
distributors and factory representatives
Preface
CUSTOMER SUPPORT
Users of Microchip products can receive assistance through several channels:
• Distributor or Representative
• Local Sales Office
• Field Application Engineer (FAE)
• Technical Support
Customers should contact their distributor, representative or field application engineer
(FAE) for support. Local sales offices are also available to help customers. A listing of
sales offices and locations is included in the back of this document.
Technical support is available through the website at:
http://www.microchip.com/support
2015 Microchip Technology Inc. DS50002399B-page 9
UTC2000 Evaluation Kit User’s Guide
DOCUMENT REVISION HISTORY
Revision Section/Figure/Entry Correction
DS50002399A (07-30-15) Initial Release of Document
DS50002399B (11-20-15) Section 2.1 “Contents of the
Kit”
Section 2.2.2 “EVB-UTC200
0-DFP Legacy Charging
Operation”
Section 2.2.4 “3.0A
Charging Operation”
Figure 3-3 Updated image to remove black square in middle of
Figure 3-6 Added trademark symbol to USB Type-C™.
Figure 3-7 Replaced incorrect image.
Figure 3-8 Added trademark symbol to USB Type-C™.
Appendix A. “UTC2000
Schematics”
Appendix B. “EVK-UTC2000
BOM”
Updated grammar.
Updated first paragraph to replace 56 k? with 56 kΩ.
Updated steps to reflect correct information.
the diagram.
Updated all images to remove extraneous information.
Fixed inconsistent text size.
DS50002399B-page 10 2015 Microchip Technology Inc.
EVALUATION KIT
Chapter 1. Overview
1.1 UTC2000 EVALUATION KIT OVERVIEW AND FEATURES
The UTC2000 Evaluation Kit is intended to demonstrate the form factor and reversibility of the USB Type-C™ cable operation as enabled by the UTC2000 basic Type-C
controller. The kit includes a downstream facing port board, an upstream facing port
board, and a USB Type-C cable, as shown in Figure 1-1. A basic USB Type-C connection can be demonstrated with a standard USB 2.0 or USB 3.1* host port, the UTC2000
EVK and any USB 2.0 or USB 3.1 device. See Section 1.2 “Features” for more information.
Note: EVK-UTC2000 is enabled with a USB 3.1 Gen 1 switch. USB 3.1 Gen 2 can
be supported by using a compliant USB 3.1 Gen 2 switch.
FIGURE 1-1: UTC2000 EVALUATION KIT
UTC2000
USER’S GUIDE
1.2 FEATURES
• EVB-UTC2000-DFP converts any USB Type-A port to a USB Type-C port
• EVB-UTC2000-UFP converts any USB device to a USB Type-C device
• Compatible with USB 2.0 and USB 3.1 host ports and devices
• Supports basic USB Type-C 5V charging at:
- Legacy 500mA (USB 2.0)/900mA (USB 3.1)
-1.5A
-3.0A
• LED status indicators on the downstream facing port (DFP) board include:
- 5V board supply indicators
- “Overcurrent” and “Fault” indicators
- Plug orientation
2015 Microchip Technology Inc. DS50002399B-page 11
UTC2000 Evaluation Kit User’s Guide
UTC2000
(DFP Mode)
USB Type-C
TM
Connector
5V@4A
Port Power
Controller
VBUS
USB 3.1
Gen 1
Switch
PLUG_ORIENTATION#
USB
PPC_EN
USB
USB
CC1
CC2
VCONN2_OUT#
VCONN1_OUT#
5V
5V
RpRp
OCS#
USB 3.1 Gen 1
Type-A Plug
ENABLE
5V
5V
VMON
5V
3.3V
5V to 3.3V
Regulator
3.3V
VDD
5V
VDD
5V
VDD
VBUS
5V
0ё
• LED status indicators on the upstream facing port (UFP) board include:
- 5 V board supply indicator
- Legacy, 1.5A, 3.0A charging detecting indicators
• DP3T switch on DFP board for legacy, 1.5A, 3.0A charging mode selection
• Reversible USB Type-C receptacle
• USB 3.1 passive Type-C Cable
1.3 GENERAL DESCRIPTION
FIGURE 1-2: EVB-UTC2000-DFP BLOCK DIAGRAM
DS50002399B-page 12 2015 Microchip Technology Inc.
FIGURE 1-3: EVB-UTC2000-UFP BLOCK DIAGRAM
UTC2000
(UFPMode)
USB3.1
Gen1
Switch
USB
USB
CC1
CC2
RpRp
USB
CONNECTED#
VBUS
VBUS
LEGACY_IND#
1.5A_IND#
3.0A_IND#
VMON
PLUG_ORIENTATION#
Type‐A
Receptacle
5V
3.3V
5Vto3.3V
Regulator
5V
VDD
3.3V
VDD
Overview
1.4 REFERENCES
• USB Type-C™ Specification
• UTC2000 Data Sheet
• Introduction to USB Type-C™ Application Note
(http://ww1.microchip.com/downloads/en/AppNotes/00001953A.pdf)
• Basic USB Type-C™ Upstream Facing Port Implementation
(http://ww1.microchip.com/downloads/jp/AppNotes/jp574170.pdf)
1.5 DEFINITION
• DFP - Downstream Facing Port
• EVB - Evaluation Board
• EVK - Evaluation Kit
• UFP - Upstream Facing Port
2015 Microchip Technology Inc. DS50002399B-page 13
UTC2000 Evaluation Kit User’s Guide
NOTES:
DS50002399B-page 14 2015 Microchip Technology Inc.
Chapter 2. Getting Started
2.1 CONTENTS OF THE KIT
The UTC2000 Evaluation kit includes the basic equipment necessary for evaluation.
The items included in the kit are:
1. EVB-UTC2000-DFP Evaluation Board
2. EVB-UTC2000-UFP Evaluation Board
3. USB Type-C Cable
2.2 BRING-UP AND TESTING
2.2.1 Setup and Requirements
• EVB-UTC2000-DFP: Before use, slide SW1 to the legacy charging mode. To use,
simply insert the device into any USB Type-A USB 2.0 or USB 3.1 host port. Any
USB Type-C device may now be connected to the USB Type-C port. The reversibility of the USB Type-C cable can be demonstrated by connecting it in the opposite direction.
• EVB-UTC2000-UFP: To use, connect to any USB Type-C host or hub port. If
there is no native USB Type-C host available, the EVB-UTC2000-DFP board may
be used. Insert a USB 2.0 or USB 3.1 device into the Type-A receptacle (J2) of the
EVB-UTC2000-UFP. The device may then be used normally.
UTC2000
EVALUATION KIT
2.2.2 EVB-UTC2000-DFP Legacy Charging Operation
The EVB-UTC2000-DFP board is configured to Legacy 500mA (USB2.0)/900mA
(USB3.1 Gen1) charging mode by default. Ensure that SW1 is in the “Lgcy” position.
The switch will select 56 kΩ CC1/CC2 Rp pull-up resistors and set the CFG_SEL voltage to the appropriate level.
When connecting the EVB-UTC2000-DFP board to the EVB-UTC2000-UFP while in
Legacy charging mode, the “Legacy” charging capability LED indicator (D4) on the
EVB-UTC2000-UFP will be illuminated.
2.2.3 1.5A Charging Operation
The EVB-UTC2000-DFP is designed to plug in and operate from any legacy USB
Type-A port. To protect your computer from possible overcurrent issues, 1.5A and 3.0A
modes have been disabled by default.
To test 1.5A charging mode, perform the following steps:
1. Remove R15 and R17 56k Rp pull-up resistors.
2. Populate R18 and R23 with 22k, 0402 footprint resistors.
3. Set SW1 to the “1.5A” position.
4. Remove R3 to isolate the 5V domain on the EVB-UTC200-DFP from the 5V
domain on your host PC.
5. Connect an external power supply as shown in Section 3.1.1 “Power Source”.
2015 Microchip Technology Inc. DS50002399B-page 15
UTC2000 Evaluation Kit User’s Guide
When connecting the EVB-UTC2000-DFP board to the EVB-UTC2000-UFP while in
1.5A charging mode, the “1.5A” charging capability LED (D3) indicator on the
EVB-UTC2000-UFP will be illuminated.
2.2.4 3.0A Charging Operation
The EVB-UTC2000-DFP is designed to plug in and operate from any legacy USB
Type-A port. To protect your computer from possible overcurrent issues, 1.5A and 3.0A
modes have been disabled by default.
To test 3.0A charging mode, perform the following steps:
1. Remove R15 and R17 56k Rp pull-up resistors.
2. Populate R24 and R27 with 10k, 0402 footprint resistors.
3. Set SW1 to the “3.0A” position.
4. Remove R3 to isolate the 5V domain on the EVB-UTC200-DFP from the 5V
domain on your host PC.
5. Connect an external power supply as shown in Section 3.1.1 “Power Source”.
When connecting the EVB-UTC2000-DFP board to the EVB-UTC2000-UFP while in
3.0A charging mode, the “3.0A” charging capability LED indicator (D2) on the
EVB-UTC2000-UFP will be illuminated.
DS50002399B-page 16 2015 Microchip Technology Inc.
Chapter 3. Hardware Configuration
3.1 HARDWARE DESCRIPTION
FIGURE 3-1: EVB-UTC2000-UFP (TOP-SIDE)
UTC2000
EVALUATION KIT
USER’S GUIDE
FIGURE 3-2: EVB-UTC2000-DFP (TOP-SIDE)
3.1.1 Power Source
The EVB-UTC2000-DFP can be powered in one of two ways:
1. Host/Hub Port VBUS: The board can be powered by 5V VBUS sourced from
the connected host port. Do not operate with SW1 in the 1.5A or 3.0A modes and
attempt to draw 1.5A or 3.0A when connected in this way, as Legacy USB Type-A
host ports typically cannot support this amount of current draw.
2. External 5V Supply: An external 5V supply may be connected to TP1 to test
1.5A and 3.0A charging. Be sure to remove the R3 zero-ohm resistor to prevent
voltage back drive to the host/hub port, as shown in Figure 3-3.
2015 Microchip Technology Inc. DS50002399B-page 17
UTC2000 Evaluation Kit User’s Guide
EVB-UTC2000-DFP
h^Type-A
Plug
TP2
GND
TP1
EXT5V
R3
h^
Type-CΡ
Recept acle
Host
Port
h^
Type-CΡ
Device
Bench Voltage Supply
V+ V-
TP
TP
EXT5V
V
+
R3 Removed
FIGURE 3-3: EVB-UTC2000-DFP EXTERNAL 5V SUPPLY
The EVB-UTC2000-UFP is always powered from VBUS supplied by the downstream
facing port it is attached to.
3.1.2 LED Indicators for EVB-UTC2000-DFP
Ta bl e 3 -1 describes the LED indicators included on the EVB-UTC2000-DFP.
TABLE 3-1: LED INDICATOR DESCRIPTIONS
REF.
DES.
D2 “VBUS IN” Indicates that 5V board power is present.
D3 “VBUS ON” Indicates 5V is being supplied to VBUS on the Type-C port.
D4 “FAULT” Indicates an overvoltage or overcurrent event has occurred. This
D5 “OVRCUR” Indicates an overcurrent event is occurring. This signal is driven by
D6 “PLUG ORIENT” Indicates the state of the PLUG_ORIENTATION# signal. When illu-
LABEL DESCRIPTION
indicator will reset with a power cycle of the board.
the 5V port power controller.
minated, PLUG_ORIENTATION is being driven low by the
UTC2000.
DS50002399B-page 18 2015 Microchip Technology Inc.
Hardware Configuration
VBUS ONVBUS IN
Fault
Indicator
Over-current
Indicator
Plug Orientation
Indicator
SW1
Figure 3-4 shows their location on the PCB.
FIGURE 3-4: EVB-UTC2000-DFP LED INDICATOR LOCATIONS
3.1.3 Switches on EVB-UTC2000-DFP
Ta bl e 3 -2 describes the switches included on the EVB-UTC2000-DFP.
TABLE 3-2: SWITCH DESCRIPTIONS
REF. DES. LABEL DESCRIPTION
SW1 “Lgcy -- 1.5A --
3A”
Note: The EVB-UTC2000-DFP is configured for Legacy mode of operation by
default. See Section 2.2.3 “1.5A Charging
Operation”/Section 2.2.4 “3.0A Charging Operation” for information on
testing 1.5A/3.0A modes respectively.
Figure 3-5 shows their location on the PCB.
FIGURE 3-5: EVB-UTC2000-DFP SWITCH LOCATIONS
Selects between the DFP modes of operation: “Lgcy”, “1.5A”,
“3.0A”
2015 Microchip Technology Inc. DS50002399B-page 19
UTC2000 Evaluation Kit User’s Guide
USB Type-A Plug
USB Type-A Plug
USB
Type-C™
USB
Type-C™
1x5 Debug Header
1x5 Debug Header
3.1.4 Connector Descriptions for EVB-UTC2000-DFP
Ta bl e 3 -3 describes the connectors included on the EVB-UTC2000-DFP.
TABLE 3-3: CONNECTOR DESCRIPTIONS
REF. DES. TYPE LABEL DESCRIPTION
J1 1x5 Header - 5-pin debug header (internal MCHP use only)
J2 USB 3.1
Type-A Plug
J3 USB 3.1
Type- C
Receptacle
FIGURE 3-6: EVB-UTC2000-DFP CONNECTOR LOCATIONS
- Type-A male plug
- Type-C receptacle
3.1.5 Test Points on EVB-UTC2000-DFP
Ta bl e 3 -4 describes the test points included on the EVB-UTC2000-DFP. A header may
be permanently installed on the through-hole test points if needed.
TABLE 3-4: EVB-UTC2000-DFP TEST POINT DESCRIPTIONS
REF. DES. TYPE DESCRIPTION
TP1 Thru-Hole 5V probe point or external 5V supply point
TP2 Thru-Hole GND
3.1.6 LED Indicators for EVB-UTC2000-UFP
Ta bl e 3 -5 describes the LED indicators included on the EVB-UTC2000-UFP.
TABLE 3-5: EVB-UTC2000-UFP LED INDICATOR DESCRIPTIONS
REF.
DES.
D1 “VBUS IN” Indicates that a valid VBUS (5.5V-4.0V) is being supplied to the
D2 “3A” Indicates when a 3.0 A capable DFP connection is detected.
D3 “1.5A” Indicates when a 1.5 A capable DFP connection is detected.
D4 “Legacy” Indicates when legacy 500 mA (USB 2.0)/900 mA (USB 3.1) capa-
LABEL DESCRIPTION
EVB-UTC2000-UFP from the USB Type-C™ connection and that
5V is being passed to the USB Type-A receptacle.
ble DFP connection is detected.
DS50002399B-page 20 2015 Microchip Technology Inc.
Hardware Configuration
Legacy
VBUS IN
1.5A
3.0A
Figure 3-7 shows their location on the PCB.
FIGURE 3-7: EVB-UTC2000-UFP LED INDICATOR LOCATIONS
3.1.7 Switches on EVB-UTC2000-UFP
There are no switches present on the EVB-UTC2000-UFP.
3.1.8 Connector Descriptions for EVB-UTC2000-UFP
Ta bl e 3 -6 describes the connectors included on the EVB-UTC2000-UFP.
TABLE 3-6: EVB-UTC2000-UFP CONNECTOR DESCRIPTIONS
REF. DES. TYPE LABEL DESCRIPTION
J1 1x5 Header - 5-pin debug header
(internal Microchip use only)
J2 USB 3.1
Type-A Plug
J3 USB 3.1
Type- C
Receptacle
J4 Load Loop - An external load may be connected between
- USB Type-A receptacle
- USB Type-C™ receptacle
this load loop and GND (pin 3 of J1)
2015 Microchip Technology Inc. DS50002399B-page 21
UTC2000 Evaluation Kit User’s Guide
USB
Type‐C™
USB
Type‐C™
USB
Type‐A
Receptacle
USB
Type‐A
Receptacle
1x5DebugHeader
1x5DebugHeader
ExternalLoadLoop
ExternalLoadLoop
FIGURE 3-8: EVB-UTC2000-UFP CONNECTOR LOCATIONS
3.1.9 Test Points on EVB-UTC2000-UFP
There are no test points available on the EVB-UTC2000-UFP.
DS50002399B-page 22 2015 Microchip Technology Inc.
Appendix A. UTC2000 Schematics
A.1 INTRODUCTION
This appendix shows the UTC2000 Evaluation Kit Schematic.
UTC2000
EVALUATION KIT
USER’S GUIDE
2015 Microchip Technology Inc. DS50002399B-page 23
DS50002399B-page 24 2015 Microchip Technology Inc.
VBUS
SS
RX-
D
FIGURE A-1: UTC2000 EVALUATION KIT SCHEMATICS
A Plug
SS Mux
DNP
3.3V
C7
10uF
6.3V
0603
RXM_N
RXM_P
TXM_N
TXM_P
PLUG_ORIENTATION#
C8
C6
0.1uF
0.1uF
16V
16V
0402
0402
USB 3.0 A PLUG
J2
VBUS
D-
-
D+
+
GND
SSRX-
SSRX+
GND_D
SSTX-
SSTX+
Shield
0
5Vin
1
2
3
4
5
6
7
8
9
D2
R2
1k
0402
D_N
D_P
"VBUS In"
Br Grn
C9
0.1uF
16V
0402
R13
330R
U4
7
D-
6
D+
5
RX-
4
RX+
2
TX-
1
TX+
8
USB_ID
SS_SEL10D-B
32
HS_SEL
3
VDD
9
VDD
12
VDD
16
VDD
20
VDD
29
VDD
11
OE
21
GND
28
GND
33
GNDFLAG
PI3USB3102ZLE
RX-A
RX+A
TX-A
TX+A
USB-IDA
USB_IDB
TX-B
TX+B
RX-B
RX+B
UTC2000 Evaluation Kit User’s Guide
C Connector
J3
TXM_A_P
TXM_A_N
RXM_A_P
RXM_A_N
RXM_B_N
RXM_B_P
TXM_B_P
TXM_B_N
D_P
D_N
R12
330R
A4
VBUS
A9
VBUS
B4
VBUS
B9
VBUS
A2
TX1+
A3
TX1-
B11
RX1+
B10
RX1-
A10
RX2-
A11
RX2+
B2
TX2+
B3
TX2-
A6
D+
A7
D-
B6
D+
B7
D-
A5
CC1
B5
CC2
A8
RFU1
B8
RFU2
A1
GND
A12
GND
B1
GND
B12
SHLD
GND
USB Type-C_ACON_Hybri d
0
VBUS_C
18
D-A
19
D+A
26
RXM_A_N
27
RXM_A_P
30
TXM_A_N
31
TXM_A_P
17
14
15
+/- are intentionally
D+B
swapped for
simplified routing
13
24
TXM_B_P
25
TXM_B_N
22
RXM_B_N
23
RXM_B_P
**Note: CC1/CC2 intentionally swapped
to facilitate cleaner USB3.0
signal routing
**Note: Route CC traces
50Ohm Single-Ended
R4
1k
0402
D3
Br Grn
"VBUS Out"
C1
47μF
16V
CC2
CC1
C12
0.1uF
16V
0402
5V PPC
5Vin
TP1
TP LOOP Red
TP2
TP LOOP Black
5V Source Selector
[Pos 1] VBUS Pass Thru
[Pos 2] External 5V
R3
0R
0805
DNP
DNP
ISET is configured for >3.35A Overcurrent
PPC_EN
5V
C13
1.0μF
3.3V
R6
5.1k
1%
U3
9
IN
12
IN
4
ON
3
SEL
7
ISET
2
NC
8
NC
11
NC
MAX1563ETC+
MAX1563ETC+
R22
100k
0402
1%
6
FAULT
GND
5
1
OUT
10
OUT
C10
EP
13
C11
4.7uF
10V
0603
0.1uF
16V
0402
VMON
C2
0.1uF
16V
0402
OCS#
VBUS_C
5V
R1
35.7K
0402
D1
1%
2
3
1
BAV99
R5
5.1k
1%
2015 Microchip Technology Inc. DS50002399B-page 25
FIGURE A-1: UTC2000 EVALUATION KIT SCHEMATICS (CONTINUED)
UTC2000
5V
C14
5V
0.1uF
16V
0402
R14
10k
0402
Configuration Selection
CFG_SEL = 0.00V : Legacy 500mA/900mA Mode
CFG_SEL = 0.75V : 1.5A Mode
CFG_SEL = 1.25V : 3.0A Mode
5V
R21
56k
0402
1%
Q5A
6
PMDXB600UNE
2
1.5A_SEL 3A_SEL
1
R19
100k
0402
1%
CFG_SEL
ENABLE
CFG_SEL
16
13
17
3
2
15
14
5V
R25
30k
0402
1%
Q5B
3
PMDXB600UNE
4
R28
10k
0402
1%
U2
VDD
VSS
EPAD
ENABLE
CFG_SEL
NC
NC
UTC2000
5
R29
100k
0402
1%
VMON
VCONN1_OUT#/1.5A_IND#
VCONN2_OUT#/LEGACY_IND#
OCS#
FAULT_IND
PLUG_ORIENTATION#
PPC_EN/3.0A_IND#
AUDIO_ADPT/CONNECTED#
CC Pins
5V 5V
R7
100k
0402
5
VCONN1#
26Q1B
CC1
CC2
3
4
1
12
7
CC1
CC2
6
9
VCONN1#
8
VCONN2#
1
4
11
PLUG_ORIENTATION#
10
PPC_EN
5
R8
100k
0402
Q1A
CMLDM8005
VCONN2#
CMLDM8005
Debug Header (Internal Use Only)
VMON
5V
3.3V
5
4
C4
C3
1.0μF
0.1uF
16V
UTC2000 Schematics
Debug Header
J1
ENABLE
5V
"OverCurrent"
VMON
R10
0402
D4
1k
Br Red
3
Q2A
5
CMLDM8005
4
1
2
Q2B
CMLDM8005
6
CC2
CC1
R9
1k
0402
D5
Br Red
OCS#
"Fault"
PLUG_ORIENTATION# indicates the Type-C cable.
insertion orientation.
HIGH = not connected or connected or unflipped
i.e.: CC >> CC1
LOW = connected and flipped
i.e.: CC >> CC2
Current Capability Marker Selector
Pos 1 - Legacy USB (900mA)
Pos 2 - 1.5A Capable
Pos 3 - 3.0A Capable
5V
R15
56k
0402
1%
1
Q3A
2
R16
6
100k
0402
1%
R18/R23, R24/R27 are not populated by default because
this EVB is designed to plug into any legacy USB port.
In order to test higher current modes, ensure to do the following:
R17
56k
0402
1%
4
Q3B
5
3
PMDXB600UNE
PMDXB600UNE
3.3V
3.3V
R11
1k
0402
R30
1%
"Plug Orientation"
10k
0402
D6
YELLOW
PLUG_ORIENTATION#
1. Remove R15 and R17
2. Populate R18/R23 for 1.5A mode, or R24/R27 for 3.0A
3. Set SW1 in the corresponding position
4. Remove R3 to isolate 5V from the host PC
5. Connect an external high currect bench supply to TP1/TP2
> 5.5V is recommended if testing 3A mode
R27
R23
R18
DNP
2
R20
100k
0402
1%
DNP
22k
22k
0402
0402
1%
1%
1
4
Q4A
Q4B
5
6
3
PMDXB600UNE
PMDXB600UNE
R24
DNP
10k
10k
0402
0402
1%
1%
1
4
Q6A
Q6B
2
R26
6
3
100k
0402
1%
PMDXB600UNE
PMDXB600UNE
DNP
5
SW1
1
2
C1
C1
3
AYZ0203AGRLC
3.3V Supply
5V
12345
DNP
PLUG_ORIENTATION#
5V
4
5
C2
C2
6
C5
1.0μF
1.5A_SEL
3A_SEL
CC2
CC1
U1
MCP1755T-3302E/OT
1
VIN
3
SHDN
VOUT
GND
PWRGD
2
DS50002399B-page 26 2015 Microchip Technology Inc.
VBUS
SS
D-
D+
FIGURE A-1: UTC2000 EVALUATION KIT SCHEMATICS (CONTINUED)
UTC2000 Evaluation Kit User’s Guide
C Connector
J3
SHLD
USB Type-C_ACON_Hybrid
0
UTC2000
5V
C2
0.1uF
5V
R8
1k
0603
R9
DNP
0R
0402
Profile: UFP
CFG_SEL = VDD
5V
R6
10k
0402
CFG_SEL
VBUS
VBUS
VBUS
VBUS
TX1+
RX1+
RX1-
RX2RX2+
TX2+
RFU1
RFU2
TX1-
TX2-
D+
D-
D+
D-
CC1
CC2
GND
GND
GND
GND
A4
A9
B4
B9
A2
A3
B11
B10
A10
A11
B2
B3
A6
A7
B6
B7
A5
B5
A8
B8
**Note: Route CC traces
A1
A12
B1
B12
ENABLE
DNP
5V
R2
1k
0402
TXM_A_P
TXM_A_N
RXM_A_P
RXM_A_N
RXM_B_N
RXM_B_P
TXM_B_P
TXM_B_N
CC2
CC1
VMON
D_P
D_N
**Note: CC1/CC2 intentionally swapped
to facilitate cleaner USB3.0
signal routing
50Ohm Single-Ended
R16
C10
330R
0.1uF
U2
16
VDD
13
VSS
17
EPAD
VCONN1_OUT#/1.5A_IND#
VCONN2_OUT#/LEGACY_IND#
3
ENABLE
2
CFG_SEL
15
NC
14
NC
UTC2000
Debug Header
J1
ENABLE
12345
VMON
PLUG_ORIENTATION#
AUDIO_ADPT/CONNECTED#
D1
"VBUS In"
Br Grn
R4
35.7K
0402
1%
3
C1
R5
0.1uF
5.1k
10V
1%
0402
R10
5.1k
1%
VMON
OCS#
FAULT_IND
PLUG_ORIENTATION#
PPC_EN/3.0A_IND#
D7
BAV99
CC1
CC2
R11
5.1k
1%
5V
2
1
12
VMON
7
6
1.5A_IND#
9
LEGACY_IND#
8
1
4
11
PLUG_ORIENTATION#
10
3.0A_IND#
5
CONNECTED#
SS Mux
RXM_A_N
RXM_A_P
TXM_A_N
TXM_A_P
TXM_B_N
TXM_B_P
RXM_B_N
RXM_B_P
R12
0402
1k
U3
18
19
26
27
30
31
17
14
15
13
24
25
22
23
PI3USB3102
PI3USB3102ZLE
"Fault"
D5
Br Red
D-A
D+A
RX-A
RX+A
TX-A
TX+A
USB-IDA
D-B
D+B
USB_IDB
TX-B
TX+B
RX-B
RX+B
R17
USB_ID
SS_SEL
HS_SEL
GNDFLAG
0R
R14
DNP
Q1
1,2,3
5,6,7,8
100k
7
D-
6
D+
5
RX-
4
RX+
2
TX-
1
TX+
8
10
32
3
VDD
9
VDD
12
VDD
16
VDD
20
VDD
29
VDD
11
OE
21
GND
28
GND
33
C11
BSO080P03NS3E G
4
0603
0.1uF
CONNECTED#
RXM_N
RXM_P
TXM_N
TXM_P
PLUG_ORIENTATION#
3.3V
C3
C4
0.1uF
0.1uF
10V
10V
0402
0402
10kR19
R20
10k
C12
0.1uF
PLUG_ORIENTATION# indicates the Type-C cable.
insertion orientation.
HIGH = not connected or connected or unflipped
i.e.: CC >> CC1
LOW = connected and flipped
i.e.: CC >> CC2
A Receptacle
J4
1
TP LOOP Tin
J2
USB 3.0 A RCPT
5V_OUT
1
VBUS
D_N
D_P
2
D-
3
D+
4
GND
5
SSRX-
RX
6
SSRX+
7
GND_D
8
SSTX-
9
SSTX+
Shield
0
C9
0.1uF
10V
R15
330R
LEGACY_IND#
1.5A_IND#
3.0A_IND#
5V
D4
BLUE
"Legacy"
R7
1k
0402
5V
D3
BLUE
R3
"1.5A"
1k
0402
5V
D2
BLUE
R1
1k
"3.0A"
0402
3.3V Reg
CC1
CC2
3.3V
3.3V
R13
1k
R18
0402
10k
0402
"Plug Orientation"
D6
YELLOW
5V
C5
1uF
10V
0402
C6
0.1uF
U1
MCP1755T-3302E/OT
1
VIN
3
SHDN
3.3V
5
VOUT
4
GND
PWRGD
2
C7
C8
1uF
0.1uF
10V
0402
Appendix B. EVK-UTC2000 BOM
B.1 INTRODUCTION
This appendix shows the EVK-UTC2000 Evaluation Bill of Materials.
UTC2000
EVALUATION KIT
USER’S GUIDE
2015 Microchip Technology Inc. DS50002399B-page 27
DS50002399B-page 28 2015 Microchip Technology Inc.
TABLE B-1: EVK-UTC2000-DFP BILL OF MATERIALS
Item Qty
1 1 1 C1 CAP CER, 47uF, 16V, 20%, X5R, 1206 TDK Corporation C3216X5R1C476M160AB
2 8 8 C2, C3, C6, C8,
3 3 3 C4, C5, C13 CAP CER, 1uF, 16V, 10%, X5R, 0402 TDK Corporation C1005X5R1C105K050BC
4 1 1 C7 CAP CER, 10uF, 6.3V, 20%, X5R SMD, 0603 AVX 06036D106MAT2A
5 1 1 C11 CAP CER, 4.7uF, 10V, 10%, X5R SMD, 0603 Taiyo Yuden LMK107BJ475KA-T
6 1 1 D1 DIO RECTARR, BAV99, 1.25V, 200mA, 70V, SOT-23-3 Fairchild BAV99
7 2 2 D2, D3 LED, Bright Green, 0603 Lite-On LTST-C191KGKT
8 2 2 D4, D5 LED, Bright Red, 0603 Lite-On LTST-C191KRKT
9 1 1 D6 DIO LED YELLOW 2V 25mA 162.5mcd Diffuse SMD 0603 OSRAM LY Q976-P1S2-36
10 1 1 J1 CON HDR-2.54 Male 1x5 Gold 5.84MH TH VERT Samtec TSW-105-07-S-S
11 1 1 J2 CON USB 3.1 Gen 1 STD-A PLUG SMD R/A Wurth Electronics Inc 692112030100
12 1 1 J3 CON USB 3.1 Gen 1 Hybrid Type-C ACON
13 2 2 Q1, Q2 MOSFET SMD- Small Signal P-Channel Mosfet Central Semiconductor CMLDM8005 TR
14 4 4 Q3, Q4, Q5, Q6 MOSFET TRENCH 2N-CH 20V 600MA SOT-1216 NXP Semiconductors PMDXB600UNE
15 1 1 R1 RES SMD 35.7K OHM 1% 1/10W 0402 Panasonic ERJ-2RKF3572X
16 5 5 R2, R4, R9,
17 1 1 R3 RES TKF 0R 1/8W SMD 0805 Panasonic ERJ-6GEY0R00V
18 2 2 R5, R6 RES SMD 5.1K OHM 1% 1/10W 0402 Panasonic ERJ-2RKF5101X
19 8 8 R7, R8, R16,
20 2 2 R12, R13 RES TKF 330R 1% 1/10W SMD 0603 ROHM MCR03EZPFX3300
21 3 3 R14, R28, R30 RES TKF 10k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1002X
22 3 3 R15, R17, R21 RES TKF 56k 1% 1/16W SMD 0402 ROHM MCR01MZPF5602
23 1 1 R25 RES SMD 30K OHM 1% 1/10W 0402 Panasonic ERJ-2RKF3002X
24 1 1 SW1 SW SLIDE DP3T 12VDC 100MA SMT C&K Components AYZ0203AGRLC
Qty
Pop'd
Reference
Designator(s)
C9, C10, C12,
C14
R10, R11
R19, R20, R22,
R26, R29
Description Manufacturer
CAP CER, 0.1uF, 16V, 80%, SMD, 0402 Yageo CC0402ZRY5V7BB104
RES TKF 1k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1001X
RES TKF 100k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1003X
Manufacturer
Part Number
UTC2000 Evaluation Kit User’s Guide
2015 Microchip Technology Inc. DS50002399B-page 29
TABLE B-1: EVK-UTC2000-DFP BILL OF MATERIALS (CONTINUED)
Item Qty
25 1 1 TP1 MISC, TEST POINT MULTI PURPOSE MINI RED Keystone 5000
26 1 1 TP2 MISC, TEST POINT MULTI PURPOSE MINI BLACK Keystone 5001
27 1 1 U1 IC REG LDO 3.3V 0.3A SOT23-5 Microchip Technology MCP1755T-3302E/OT
28 1 1 U2 UTC2000 TYPEC CONTROLLER 16QFN Microchip Technology UTC2000/MG
29 1 1 U3 IC CURR-LIM SW SNGL PROG 12-TQFN Maxim Integrated MAX1563ETC+
30 1 1 U4 IC USB 3.1 Gen 1 & USB 2.0 SWITCH 32TQFN Pericom PI3USB3102ZLE
Qty
Pop'd
Reference
Designator(s)
Description Manufacturer
Manufacturer
Part Number
TABLE B-2: EVK-UTC2000-UFP BILL OF MATERIALS
Item Qty
1 8 8 C1, C2, C3, C4,
2 2 2 C5, C7 CAP CER 1uF 10V 10% X5R 0402 Murata Electronics North
3 1 1 D1 LED, Bright Green, 0603 Lite-On LTST-C191KGKT
4 3 3 D2, D3, D4 DIO LED BLUE 2.8V 20mA 15mcd Clear SMD 0603 Lite-On LTST-C193TBKT-5A
5 1 1 D5 LED, Bright Red, 0603 Lite-On LTST-C191KRKT
6 1 1 D6 DIO LED YELLOW 2V 25mA 162.5mcd Diffuse SMD 0603 OSRAM LY Q976-P1S2-36
7 1 1 D7 DIO RECTARR BAV99 1.25V 200mA 70V SOT-23-3 Fairchild BAV99
8 1 1 J1 CON HDR-2.54 Male 1x5 Gold 5.84MH TH VERT Samtec TSW-105-07-S-S
9 1 1 J2 CON USB 3.1 Gen 1 STD-A RCPT TH R/A Wurth Electronics Inc 692121030100
10 1 1 J3 CON USB 3.1 Gen 1 Hybrid Type-C ACON
11 1 1 J4 CON TP LOOP Tin SMD Harwin Inc S1751-46R
12 1 1 Q1 MOSFET P-CH 30V 12A 8DSO Infineon Technologies BSO080P03NS3E G
13 6 6 R1, R2, R3, R7,
14 1 1 R4 RES SMD 35.7K OHM 1% 1/10W 0402 Panasonic ERJ-2RKF3572X
15 3 3 R5, R10, R11 RES SMD 5.1K OHM 1% 1/10W 0402 Panasonic ERJ-2RKF5101X
16 2 2 R6, R18 RES TKF 10k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1002X
17 1 1 R8 RES TKF 1k 1% 1/10W SMD 0603 Yageo RC0603FR-071KL
Qty
Pop'd
Reference
Designator(s)
C6, C8, C9, C10
R12, R13
Description Manufacturer
CAP CER 0.1uF 10V 10% X5R SMD 0402 KEMET C0402C104K8PACTU
America
RES TKF 1k 1% 1/10W SMD 0402 Panasonic ERJ-2RKF1001X
Manufacturer
Part Number
GRM155R61A105KE15D
EVK-UTC2000 BOM
DS50002399B-page 30 2015 Microchip Technology Inc.
TABLE B-2: EVK-UTC2000-UFP BILL OF MATERIALS (CONTINUED)
Item Qty
18 1 1 R14 RES TKF 0R 1/3W SMD 1210 Vishay CRCW12100000Z0EA
19 2 2 R15, R16 RES TKF 330R 1% 1/10W SMD 0603 ROHM MCR03EZPFX3300
20 1 1 R17 RES TKF 100k 1% 1/10W SMD 0603 Panasonic ERJ-3EKF1003V
21 1 1 U1 IC REG LDO 3.3V 0.3A SOT23-5 Microchip Technology MCP1755T-3302E/OT
22 1 1 U2 UTC2000 TYPEC CONTROLLER 16QFN Microchip Technology EVK-UTC2000-UFP
23 1 1 U3 IC USB 3.1 Gen 1 & USB 2.0 SWITCH 32TQFN Pericom PI3USB3102ZLE
Qty
Pop'd
Reference
Designator(s)
Description Manufacturer
Manufacturer
Part Number
UTC2000 Evaluation Kit User’s Guide
EVALUATION KIT
USER’S GUIDE
Appendix C. EVK-UTC2000 PCB Silk Screens
C.1 INTRODUCTION
This appendix shows the EVK-UTC2000 Top and Bottom Silk Screen Images.
FIGURE C-1: EVB-UTC2000-DFP TOP AND BOTTOM SILK SCREEN IMAGES
UTC2000
2015 Microchip Technology Inc. DS50002399B-page 31
UTC2000 Evaluation Kit User’s Guide
FIGURE C-2: EVB-UTC2000-UFP TOP AND BOTTOM SILK SCREEN IMAGES
DS50002399B-page 32 2015 Microchip Technology Inc.
NOTES:
EVK-UTC2000 PCB Silk Screens
2015 Microchip Technology Inc. DS50002399B-page 33
Worldwide Sales and Service
AMERICAS
Corporate Office
2355 West Chandler Blvd.
Chandler, AZ 85224-6199
Tel: 480-792-7200
Fax: 480-792-7277
Technical Support:
http://www.microchip.com/
support
Web Address:
www.microchip.com
Atlanta
Duluth, GA
Tel: 678-957-9614
Fax: 678-957-1455
Austin, TX
Tel: 512-257-3370
Boston
Westborough, MA
Tel: 774-760-0087
Fax: 774-760-0088
Chicago
Itasca, IL
Tel: 630-285-0071
Fax: 630-285-0075
Cleveland
Independence, OH
Tel: 216-447-0464
Fax: 216-447-0643
Dallas
Addison, TX
Tel: 972-818-7423
Fax: 972-818-2924
Detroit
Novi, MI
Tel: 248-848-4000
Houston, TX
Tel: 281-894-5983
Indianapolis
Noblesville, IN
Tel: 317-773-8323
Fax: 317-773-5453
Los Angeles
Mission Viejo, CA
Tel: 949-462-9523
Fax: 949-462-9608
New York, NY
Tel: 631-435-6000
San Jose, CA
Tel: 408-735-9110
Canada - Toronto
Tel: 905-673-0699
Fax: 905-673-6509
ASIA/PACIFIC
Asia Pacific Office
Suites 3707-14, 37th Floor
Tower 6, The Gateway
Harbour City, Kowloon
Hong Kong
Tel: 852-2943-5100
Fax: 852-2401-3431
Australia - Sydney
Tel: 61-2-9868-6733
Fax: 61-2-9868-6755
China - Beijing
Tel: 86-10-8569-7000
Fax: 86-10-8528-2104
China - Chengdu
Tel: 86-28-8665-5511
Fax: 86-28-8665-7889
China - Chongqing
Tel: 86-23-8980-9588
Fax: 86-23-8980-9500
China - Dongguan
Tel: 86-769-8702-9880
China - Hangzhou
Tel: 86-571-8792-8115
Fax: 86-571-8792-8116
China - Hong Kong SAR
Tel: 852-2943-5100
Fax: 852-2401-3431
China - Nanjing
Tel: 86-25-8473-2460
Fax: 86-25-8473-2470
China - Qingdao
Tel: 86-532-8502-7355
Fax: 86-532-8502-7205
China - Shanghai
Tel: 86-21-5407-5533
Fax: 86-21-5407-5066
China - Shenyang
Tel: 86-24-2334-2829
Fax: 86-24-2334-2393
China - Shenzhen
Tel: 86-755-8864-2200
Fax: 86-755-8203-1760
China - Wuhan
Tel: 86-27-5980-5300
Fax: 86-27-5980-5118
China - Xian
Tel: 86-29-8833-7252
Fax: 86-29-8833-7256
ASIA/PACIFIC
China - Xiamen
Tel: 86-592-2388138
Fax: 86-592-2388130
China - Zhuhai
Tel: 86-756-3210040
Fax: 86-756-3210049
India - Bangalore
Tel: 91-80-3090-4444
Fax: 91-80-3090-4123
India - New Delhi
Tel: 91-11-4160-8631
Fax: 91-11-4160-8632
India - Pune
Tel: 91-20-3019-1500
Japan - Osaka
Tel: 81-6-6152-7160
Fax: 81-6-6152-9310
Japan - Tokyo
Tel: 81-3-6880- 3770
Fax: 81-3-6880-3771
Korea - Daegu
Tel: 82-53-744-4301
Fax: 82-53-744-4302
Korea - Seoul
Tel: 82-2-554-7200
Fax: 82-2-558-5932 or
82-2-558-5934
Malaysia - Kuala Lumpur
Tel: 60-3-6201-9857
Fax: 60-3-6201-9859
Malaysia - Penang
Tel: 60-4-227-8870
Fax: 60-4-227-4068
Philippines - Manila
Tel: 63-2-634-9065
Fax: 63-2-634-9069
Singapore
Tel: 65-6334-8870
Fax: 65-6334-8850
Taiwan - Hsin Chu
Tel: 886-3-5778-366
Fax: 886-3-5770-955
Taiwan - Kaohsiung
Tel: 886-7-213-7828
Taiwan - Taipei
Tel: 886-2-2508-8600
Fax: 886-2-2508-0102
Thailand - Bangkok
Tel: 66-2-694-1351
Fax: 66-2-694-1350
EUROPE
Austria - Wels
Tel: 43-7242-2244-39
Fax: 43-7242-2244-393
Denmark - Copenhagen
Tel: 45-4450-2828
Fax: 45-4485-2829
France - Paris
Tel: 33-1-69-53-63-20
Fax: 33-1-69-30-90-79
Germany - Dusseldorf
Tel: 49-2129-3766400
Germany - Karlsruhe
Tel: 49-721-625370
Germany - Munich
Tel: 49-89-627-144-0
Fax: 49-89-627-144-44
Italy - Milan
Tel: 39-0331-742611
Fax: 39-0331-466781
Italy - Venice
Tel: 39-049-7625286
Netherlands - Drunen
Tel: 31-416-690399
Fax: 31-416-690340
Poland - Warsaw
Tel: 48-22-3325737
Spain - Madrid
Tel: 34-91-708-08-90
Fax: 34-91-708-08-91
Sweden - Stockholm
Tel: 46-8-5090-4654
UK - Wokingham
Tel: 44-118-921-5800
Fax: 44-118-921-5820
07/14/15
DS50002399B-page 34 2015 Microchip Technology Inc.
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Microchip:
EVK-UTC2000
Loading...
