Object of Declaration: EVB-USB5744 Evaluation Board

 2015 Microchip Technology Inc. DS50002306B-page 3

EVB-USB5744 Evaluation Board User’s Guide

NOTES:

DS50002306B-page 4  2015 Microchip Technology Inc.

EVB-USB5744

EVALUATION BOARD

USER’S GUIDE

Table of Contents

Preface ........................................................................................................................... 6

Introduction............................................................................................................ 6

Document Layout .................................................................................................. 6

Conventions Used in this Guide ............................................................................ 7

The Microchip Web Site ........................................................................................ 8

Development Systems Customer Change Notification Service ............................ 8

Customer Support ................................................................................................. 8

Document Revision History ................................................................................... 9

Chapter 1. Overview

1.1 Introduction ................................................................................................... 10

Chapter 2. Getting Started

2.1 Configuration ................................................................................................ 11

2.1.1 External SPI Flash ..................................................................................... 11

2.1.2 SMBus ....................................................................................................... 12

2.1.3 Configuration Source - Internal Default ..................................................... 12

2.1.4 Strapping Option ....................................................................................... 12

2.1.5 Port Power Options: Port Enable and Port Disable Select ........................ 13

2.2 Power Source - Self-Powered ...................................................................... 14

2.3 Downstream Port Power Control .................................................................. 14

Appendix A. EVB-USB5744 Evaluation Board

A.1 Introduction .................................................................................................. 15

Appendix B. EVB-USB5744 Evaluation Board Schematics

B.1 Introduction .................................................................................................. 16

Appendix C. Bill of Materials (BOM)

C.1 Introduction .................................................................................................. 19

Appendix D. EVB-USB5744 Silk Screens

D.1 Introduction .................................................................................................. 22

Worldwide Sales and Service .................................................................................... 24

 2015 Microchip Technology Inc. DS50002306B-page 5

EVB-USB5744

EVALUATION BOARD

USER’S GUIDE

Preface

NOTICE TO CUSTOMERS

All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our web site
(www.microchip.com) to obtain the latest documentation available.

Documents are identified with a “DS” number. This number is located on the bottom of each
page, in front of the page number. The numbering convention for the DS number is
“DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the
document.

For the most up-to-date information on development tools, see the MPLAB
Select the Help menu, and then Topics to open a list of available online help files.

®

IDE online help.

INTRODUCTION

This chapter contains general information that will be useful to know before using the
EVB-USB5744 Evaluation Board. Items discussed in this chapter include:

• Document Layout

• Conventions Used in this Guide

• The Microchip Web Site

• Development Systems Customer Change Notification Service

• Customer Support

• Document Revision History

DOCUMENT LAYOUT

This document describes how to use the EVB-USB5744 Evaluation Board as a
development tool for the USB5744 4 port USB 3.1 Gen 1 hub with battery charging
features.

• Chapter 1. “Overview” – Shows a brief description of the EVB-USB5744 Evalua-

tion Board.

• Chapter 2. “Getting Started” – Includes instructions on how to get started with

the EVB-USB5744 Evaluation Board.

• Appendix A. “EVB-USB5744 Evaluation Board” – This appendix shows the

EVB-USB5744 Evaluation Board.

• Appendix B. “EVB-USB5744 Evaluation Board Schematics” – This appendix

shows the EVB-USB5744 Evaluation Board schematics.

• Appendix C. “Bill of Materials (BOM)” – This appendix includes the

EVB-USB5744 Evaluation Board Bill of Materials (BOM).

• Appendix D. “EVB-USB5744 Silk Screens” – This appendix includes the

EVB-USB5744 Evaluation Board silk screens.
