Microchip Technology DWPCIE83 User Manual

Product Name

:

CONFIDENTIAL FOR

Neutron Engineering Inc.

ONLY

DWPCIe83 Module:

User Manual

half-size mini-PCIe Digital Wireless

Audio Module

Brand Name : SMSC

Model Name : DWPCIe83

Copyright © 2011 SMSC or its subsidiaries. All rights reserved.

Circuit diagrams and other information relating to SMSC pro ducts are included as a means of illustrating typical applications. Consequently, complete information
sufficient for construction purposes is not necessarily given. Although the information has been checked and is believe d to be accurate, no responsibility is assumed for
inaccuracies. SMSC reserves the r ight to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to
obtain the latest sp ecifications before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor
devices any licenses under any patent rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms
and condi tions of the most rec ently dated v ersion of SMSC's standard Terms of Sale Agreement dated befor e the date of your order (the "Terms of Sale Agreement").
The product may contain design defects or errors known as anomalies which may cause the product's functions to deviate from publish ed specifications. Anomaly sheets
are available upon request. SMSC products are not designed, in tended, authorized or warranted for use in any life support or other applicati on where product failure could
cause or contribute to personal injury or severe property damage. Any and all such uses without prior written approval of an Officer of SMSC and furthe r testing and /or
modification will be fully at the risk of the customer. Co pies of this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained b y
visiting SMSC’s website at http ://www.smsc.com. SMSC is a registered trademark of Standar d Microsystems Corporation (“SMSC”). Product na mes and company names
are the trademarks of their respective holders.

SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARR ANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARR ANTIES OF
MERCHANTABILITY, FITNESS FOR A P ARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES
ARISING FROM ANY COURSE OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FO R ANY DIRECT, INCIDENTAL, INDIRECT,
SPECIAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE
FORM OF ACTION, WHETHER BASED ON CONTRACT; TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR
OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

User Manual Page 1 of 12

SMSC CONFIDENTIAL

Revision 0.1 (8.26.2011)

CONFIDENTIAL FOR

Neutron Engineering Inc.

ONLY

1. Product Description

The DWPCIe83 USB module is a wireless audio module (30x26.8mm) with a PCI
Express interface based on the SMSC DARR83. This USB module can be used to build
an uncompressed wireless digital audio transceiver operating in the 2.4GHz, 5.2GHz and

5.8GHz bands.

The wireless audio link supports up to four stereo audio streams and comes together with
additional features such as: data encryption, pairing functionality, bi-directional control
data messages, low power audio snooze mode, WLAN detection and Automatic
Frequency Allocation.

The DARR83 chip itself provides the basic functions of Audio Processing and buffering, Data
Link Layer and Physical Layer. The DWPCIe83 USB module integrates all functionality for a
wireless digital audio connection, comprising:

• DARR83 Wireless Audio Processor

• 2.4GHz/ 5.2GHz/ 5.8 GHz RF Transceiver

• Dual antenna connectors

• USB2.0 through a PCI Express Mini Card System Connector

• Built-in SPI interface Flash

2. DWPCIe83 Module Usage Scenarios

2.1. Headset Mode

When the DWPCIe83 Module is configured into the headset mode the DWPCIe83 module is
able to have an audio input and audio output at the same time. The DWPCIe83 module can
stream audio to a DARR-enabled headset and simultaneously receive the voice channel from
this headset.

2.2. Multiple Stream Mode

In the multiple stream mode the DWPCIe83 Module will act as a multi stereo stream device
so that in Windows Vista and Windows 7 it is possible to play multiple audio sources (iTunes
and medial player) to different speakers.

2.3. Surround Mode

When the DWPCIe83 Module is configured in the surround mode it is possible to transfer

5.1/7.1 audio from a movie to wireless surround speakers.

User Manual Page 2 of 12

SMSC CONFIDENTIAL

Revision 0.1 (8.26.2011)

CONFIDENTIAL FOR

Neutron Engineering Inc.

ONLY

2.4. Customer Specific Applications

An SDK for the DARR83 USB dongle is available at SMSC. For more information on the SDK,
the features and support for application specific developments, please contact SMSC.

2.5. RF measurement

Conducted measurement is through IPEX connectors. For radiated measurements, suitable
external antennas have to be connected to the IPEX connectors.

User Manual Page 3 of 12

SMSC CONFIDENTIAL

Revision 0.1 (8.26.2011)

ID Parameter

Value

Unit

Remarks

RF Characteristics

Air framing

Control

Data

Interference Robustness

CONFIDENTIAL FOR

Neutron Engineering Inc.

ONLY

3. DWPCIe83 Module Specifications

System Specifications

RF frequency range1 2400 - 2483.5

Number of RF channels per

band

Addressing 24 Bit

Data message size 32 Byte Application dependent

CRC 16, 24 and 32 Bit Hybrid

USB 2.0 480 Mbps

Data Bandwidth 100 Kbps Bi-directional wireless

Data latency 5 ms Minimum under good

Fixed frequency devices (e.g.

WLAN, microwave oven)

Frequency hopping devices

(e.g. 5.8GHz cordless phones)

5150 - 5250
5725 - 5875
3

Fully coexistent2

Fully coexistent2

MHz
MHz
MHz

data channel

RF link conditions for
applications that
support the 100kbps
data rate.

1

Country/ Region dependent

2

Laboratory tests have verified coexistence with interference sources collocated. Exact ranges are scenario dependent

(function of latency, output power, audio compression, etc.). A mix of interference sources is allowed. Interference of fixed
frequency devices may result in the loss of one useable RF channel.
