1 Introduction

The CX-series module is a single-board networked media player module, based on SMSC’s DM860 and DM870 media processors, and enables fast product developments with Ethernet, USB and optional WiFi connectivity. The module connects to standard legacy components in various audio, video/LCD and control formats.

2 Block Diagram

JukeBlox Networked Media Module – CX Series

RJ-45

Transformer

Type-A

Display

SD-Card

CCIR-656

A/D, D/A

S/PDIF

Host

Controller/

LCD setup

USB

Apple Coprocessor

3.3V

1.2V

1.9V

Reset In

3x6bit RGB

4/8bit MMC

Video Out

Audio I/O

SPI Ctrl.

GPIO

Ethernet

Transceiver

I2C

PWM DAC

UART

I2C

JTAG

RST

RMII

USB LCD

SSM

I2C

DAC

Ports

UART

I2C

JTAG

SPI

GPIO

DM860

DM870

802.11

Flash Mem.

Bus

RF Amp. ANT

Ext.

Antenna

NAND-Flash

256 Mbit

SDRAM

NOR-Flash

2.4 GHz RF transceiver

switch

PCB

Ext.

Antenna

24.000 MHz

PCB

Antenna

Note: Choice of antenna is a build option, see Ordering Guide.

SMSC CX860/CX870 4 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

3 Board Pictures

Please note that all production modules include the RF and top shield. The below top view has the shields temporarily removed to show the components. Also, please note that the 64-pin connector mounted on the module is the male gender.

3.1 Top View of CX870

802.11b/g front-end

PCB antenna

External Antenna

Connectors

SMSC processor

Ethernet PHY

SDRAM

SMSC CX860/CX870 5 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

3.2 Bottom View of CX870

3.2.1 CX870 Bottom View with 64-pin Low Density Connector

LCD connector

Low density connector

3.2.2 CX870 Bottom View with 120-pin Media Connector

FLASH

LCD

connector

FLASH

Media

connector

SMSC CX860/CX870 6 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

3.3 Production Module with Top and RF shields in place – Top View

3.4 Production Module with 64-pin Connector Option – Side View

SMSC CX860/CX870 7 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

3.5 Example Production Module Showing Soldered RF Shield

SMSC CX860/CX870 8 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

4 Ordering Guide

WiFi

(on-module

PCB

Part Number SMSC IC’s

CX870-3A DM870+T6201 X (X)* X X X X X X X CX870-3B DM870+T6201 X X X X X X X CX870-3D DM870+T6201 X X X X X X X CX870-3F DM870+T6201 X X X X X X X CX870-3G DM870+T6201 X X X X X X CX870-3H DM870+T6201 X X X X X X X

CX870-3I DM870+T6201 X X X X X X CX870-3J DM870+T6201 X X X X X X CX870-3K DM870+T6201 X X X X X X X

diversity)

Ext. Diversity

Antennas (UFL

Conn.)+

One

Two

Ant.

Ethernet

USB Host

Low

density 64-

pin Conn.

Media

120-pin

Conn.

LCD

32MByte

Conn.

SDRAM

16MByte

SDRAM

1Gbit

NAND

FLASH

8MByte

NOR

FLASH

Top

Module

Shield

Note: Please note that the Apple Authentication Coprocessor will not be provided on the CX module. The Apple Authentication Coprocessor should be provided on the product motherboard, connected to the SDA, SCL signals from the CX module.

Note: Shaded rows indicate Custom or Obsolete configuration - NOT TO BE USED FOR NEW/STANDARD MP DESIGNS.

* Connector on board, but requires board modification to enable the connector.

+ The position of the X in the One Ant. column indicates that there is one external antenna connector provided. The position of the X in the Two Ant. column indicates that there are two external antenna connectors provided. Do not use a module which has two external antenna connectors with only one external antenna connected. Leaving one antenna socket open will degrade WiFi performance. SMSC recommends always using modules with two external antennas for best performance.

4.1 Part Number Syntax

CX870-3A

Product Family

Revision

1: DVT1 2: DVT2 3: MP

Configuration

SMSC CX860/CX870 9 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

5 Electrical Specifications

Parameter State Model Voltage Symbol min. typ. max. Units

Power Supply Input Voltage

VIN

Logic Input high voltage VIH 1.7 5.5 V Logic Input low voltage VIL -0.3 0.7 V Logic Input threshold voltage VIT 1.29 1.39 1.5 V Schmitt-trigger input low to

high threshold voltage Schmitt-trigger input high to

low threshold voltage

1.58 1.65 1.71 V

IT+

0.95 1.01 1.06 V

IT-

Logic Output high voltage VOH 2.4 V Logic Output low voltage VOL 0.4 V Logic Low-level output

current

=0.4V)

Logic High-level output current

=2.4V)

Reset State

-9.6 -15.6 -19.3 mA

11.1 22.5 35.3 mA

3.3 I3.3 60 78 mA

1.2 I1.2 32 42 mA

1.9 I1.9 18 23 mA

3.3 I3.3 185 241 mA

1.2 I1.2 337 438 mA

Current Consumption

Operating in idle state

CX870

1.9 I1.9 257 334 mA

Playback over WiFi high mips & rate condition

3.3 I3.3 240 312 mA

1.2 I1.2 347 451 mA

1.9 I1.9 258 335 mA

Note: The maximum current values are 30% larger than the typical values. The maximum values are intended to be used for power supply sizing calculations.

3.0

1.08

1.8

3.3

1.2

1.9

3.6

1.32

2.0

V V V

SMSC CX860/CX870 10 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

5.1 Absolute Maximum Ratings

Parameter Component Min Max Units

3.3V Supply Voltage -0.5 4.6 V

1.2V Supply Voltage -0.5 1.8 V

1.9V Supply Voltage -0.5 2.2 V Logic Input Voltage -0.5 6 V Logic Output Voltage

Main

5.2 Operating Conditions

Parameter Min Max Units

Operating Temperature 0 +70 °C Operating Humidity 10 90 (non condensing) %RH Storage Temperature -10 +75 °C Storage Humidity 10 95 (non condensing) %RH Storage Temperature Cycle Test 24 hrs -10 +75 °C

-0.5 4.6 V

SMSC CX860/CX870 11 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

5.3 WiFi Specification (CX870 only)

Feature Description

WLAN Standards IEEE 802.11b

IEEE 802.11g

Frequency Band 2.412 – 2.472 GHz (2.4GHz ISM Band, 13 Channels)

Channel 1 - Channel 13 North America, Japan Telec, Europe ETSI

Modulation 802.11b mode (DS-SS: IEEE 802.11b)

802.11g mode (OFDM: IEEE 802.11g)

Transmission Speed 802.11b mode

11Mbps, 5.5Mbps, 1Mbps

802.11g mode 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps, 6Mbps

Tx Power 802.11b mode: 17.5dBm, +2dB/-3dBm, using nominal MIB settings

802.11g mode: 16.0dBm +/-2.5dBm, using nominal MIB settings Power-on Ramp < 2us RF Carrier Suppression < 15dBc TX EVM < -9dB @ 6MHz

< -25dB @ 54Mbps

Rx Sensitivity (incl. CE2 Mother board)

Throughput Rate (measured for each module)

802.11b mode:

<=-86dBm @ 1Mbps, <=-83dBm @ 5.5Mbps, <=-81dBm @ 11Mbps (<10%PER)

802.11g mode:

<=-86dBm @ 6Mbps, <=-75dBm @ 36Mbps, <=-69dBm @ 54Mbps (<10% PER)

See factory test specification

Note: About Tx Power, different (higher/lower) RF output power settings may be used for specific regions, antennas and/or enclosures, in which case re-certification may be required.

SMSC CX860/CX870 12 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

6 Regulatory Compliance and Quality

Description Country Compliance Module Versions Passed

Electromagnetic Compatibility (Prescan)

Radio Regulations (CX870 only)

SMSC does not certify all module variants for all countries. Please see above table for those module versions for which certain certifications have already been done.

Please contact your SMSC sales office for the latest information about which modules are certified for which countries, and arranging for additional certification for your chosen module if needed. Any additional certificat ions will need to be paid for by the customer.

Product manufacturers are responsible for the end product certification.

SMSC can help manufacturers to prepare for the WiFi A lliance tests by providing an example test plan and the required commands to enable special test modes. Please contact your SMSC sales office about WiFi Alliance logo certification assistance.

The CX module has received Limited Module Approval (LMA) from FCC. This is because the CX module does not have a built-in +1.9V regulator circuit. SMSC recommends that customers follow the +1.9V supply voltage requirements given in this data sheet, and follow the +1.9V power supply design given in “CX Module Power Supply_V1.1.pdf” document or later version. If the power supply recommendations are followed, then customers will not need to go through formal certification of the product for WiFi related RF behavior for FCC. It is the product manufacturers responsibility to make sure that the power supply recommendations are followed, and that the RF behavior meets the certification requirements when the module is installed in the final product.

Please check the SMSC/BridgeCo Customer Portal at https://portal.bridgeco.net/ certification and recommended interfacing and power supply schematics.

USA Europe

USA Japan Canada Europe New Zealand/Australia China Korea

FCC CFR47 Part15B EN 55022 EN 55024 EN 61000-3-2 EN 61000-3-3 EN 61000-4-2 EN 61000-4-3 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6 EN 61000-4-8 EN 61000-4-11

FCC Part 15C Telec IC RSS-210 CE CE SRRC KCC

for documents about WiFi

B, D, F, H, I, J B B, D, F, H, I, J B

SMSC CX860/CX870 13 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

6.0.1 Antenna Considerations

Here are the antennas used for certification:

CX870-3B

Dipole, WINiZEN, WIE-WO-08, 3.2 dBi for 2.4GHz

CX870-3D

FCC&IC: Inverted-F, Tyco Electronics, 2174241, 2.19 dBi f or 2.4 GHz CE: Wanshih 01S0940-00, dipole, 1.59dBi@2.4GHz, 2.65dBi@2.45GHz, 1.76dBi@2.5GHz

CX870-3F

Printed on PCB, Lite-On, N/A, 3.91 dBi for 2.4 GHz

CX870-3H

Dipole, MAG.LAYERS, EDA-8709-2G4C1-A66, 2 dBi for 2.4GHz

CX870-3I

Dipole, MAG.LAYERS, EDA-8709-2G4C1-A66, 2 dBi for 2.4GHz

CX870-3J

Dipole, MAG.LAYERS, EDA-8709-2G4C1-A66, 2 dBi for 2.4GHz

Notes about antenna changes:

1) Equivalent antennas from other manufacturers may be substituted, and then marketed without a Class II permissive change

2) Equivalent antennas must be of the same type (e.g. dipole, PIFA, etc.), must be of equal or less gain than the antennas listed and previously authorized under the same FCC ID, and must have similar in band and out of band characteristics (consult specification sheet for cutoff frequencies).

3) In case of new antenna types, or higher gain antennas, a Class II permissive change is required and compliance with FCC section 15.203 must be met.

SMSC CX860/CX870 14 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

6.1 RoHS

Uses only RoHS compliant components

6.2 Environmental Test

Withstands 4 hours at 70°C, 90% RH

6.3 ESD and Transient Test (Applies to LAN and

USB external connections only)

ESD: +/- 2kV operation, +/- 4kV no destruction (part of CE test) Fast electrical transients: +/- 500V operation, +/- 1000V no destruction (part of CE test)

6.4 Magnetic Field Test

Passes EN55022 and EN55024 (part of CE test)

6.5 MTBF

>10000 hours

6.6 Mechanical Specifications

Passes drop test according to I.E.C. 68-2-32, height 100 cm, 1 corner, 6 faces. Passes vibration test with sine, vertical, 60 minutes, 600 to 18000 cpm, 1G

6.7 Module Quality

Defect Rate: < 1% AQL CR=0, MA=0.4, MI=0.4

SMSC CX860/CX870 15 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

7 Board Dimensions and Weight

7.1 Top & Bottom View of CX870 Module

7.2 Side View of CX870 module

Note:

1. All dimensions are measured in millimetres (mm).

2. PCB’s thickness: 1.00 +/- 0.10mm

3. Tolerance: +/-0.10mm

4. Outline Tolerance: +/-0.10mm

5. NPTH Hole: +/-0.05mm

6. PTH Hole: +/-0.075mm

7. Connector positions, board dimensions, mounting hole positions and sizes are the s ame for all module variants.

8. Connector position tolerance: +/- 0.38mm

9. The 64-pin connector mounted on the module along one edge is the male gender.

10. Not all module variants have all connectors. Please see the Ordering Guide table for details of connector options.

SMSC CX860/CX870 16 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

7.3 3D View of CX870 Module

7.4 Module Weight

CX860: 20g CX870: 20g

Note: Module weight applies to all versions of the module.

SMSC CX860/CX870 17 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

8 Connectors and Connections

8.1 WLAN UFL Antenna Connector (optional)

The module includes two PCB strip antennas operated in diversity mode. Alternatively, one or two coaxial antenna connectors are provided for connecting external (to the module) antennas. The choice between using the strip antenna or using the coaxial sockets is a build option, determined by the position of surface mount capacitors on the module PCB. If the PCB antennas are chosen, then diversity mode is always used. If external (to the module) antenna sockets are used, then two external antennas should be used to provide 2X diversity operation.

If external antenna is used, please choose the proper part number indicating two external antenna sockets. Do not use a module which has two external antenna sockets with only one external antenna connected; this will res ult in reduced WiFi performance.

Please see ordering guide for build option details.

The surface-mount antenna socket used in the CX module is:

UF.L type Ultra Small Surface Mount Coaxial Connector

8.2 Module Connectors

The CX860/870 module uses 3 board-to-board connectors as interfaces to the product main board. The part numbers for the connectors needed on the product main board, which mate with the connectors on the CX module, are shown in the table below.

Connector Number

J1 LCD 30 2 x 15 x 0.5mm 14-5046-030-145-829+ (Kyocera) J2 Media 120 2 x 60 x 0.5mm 14-5046-120-145-829+ (Kyocera) J3 Low Density

Connector Purpose

Connector Type

B2B

Connector

Number of Pins

64 2 x 32 x 2.54mm CSHA201-3202A001A1AB

Pin Configuration

Mating Connector Part Numbers

SMSC CX860/CX870 18 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series Datasheet

The pinout and signal names are shown on the next page. The following table provides an overview for the most important control and interface signals.

8.2.1 Pin Descriptions

Signal(s) Type Description

POWER

VIN(+3.3V) P Power supply input ; +3.3V. VIN (+1.2V) P Power supply input ; +1.2V. VIN (+1.9V) P Power Supply input; +1.9V for powering RF section. Make sure this is a clean supply. 3V3RTC P The RTC function is no longer supported. This pin should be left open. GND P Ground (GND) connection for power supply 0V, signal returns and shielding.

SPI

SPI_DOUT O SPI data from DM870 to host controller. SPI_DIN I SPI data from host controller to DM870. SPI_CLK I SPI clock from host controller to DM870. Maximum recommended frequency is 2MHz,

SPI_NCS0 I SPI chip select from host controller to DM870. PDOUT1 O T his signal is used as SPI_REQ, SPI request signal, from DM870 to host controller for

SPI_NCS1 I Not used. Leave open.

UART

RXD1 I UART1 input to the DM870, used for shell access. SMSC recommends providing a

TXD1 O UART1 output from the DM870, used for shell access. SMSC recommends providing a

RXD0 I UART0 input. Optionally used for controlling an iPod via UART. TXD0 O UART0 output. Optionally used for controlling an iPod via UART.

typical frequency is 1MHz. See Note 2 below.

eDMP applications. Logic 1 indicates that t her e is an SPI messag e waiting t o be read, t h e host controller should start the SPI clock and read any changed registers. Logic 0 indicates that all changed register messages hav e been read and the message buffer is empty. Also GPIO-06.

connection to an external RS-232 transceiver and DB9 connector to connect to a PC COM port. Such a connection can be used for product development debugging, and for module programming control on the product manufacturing line and for module control during certification procedures.

SMSC CX860/CX870 19 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

AUDIO

AV2DATA0 O I2S or left justified audio data output. Typicall y connected to external D/A converter input

AV2CTRL0 O LRCK, audio data word clock at the audio sample rate (Fs). Maximum currently supported

AV2CTRL1 O MCLK, audio master clock at 256Fs. This can be used to clock an external D/ A converter

AV2CLK O SCLK, audio data bit clock at 64Fs. Allows for up to 32 audio data bits per sample word. AV4DATA1 O SPDIF format output. Can support samples rates up to 192kHz, so the maximum

AV4DATA0 I SPDIF input. Not used at present. Leave open. AV2DATA1 O I2S or left justified audio data output. Not used at present. Leave open. AOUTLP/AOUTLN,

AOUTRP/AOUTRN

AV2DATA2 I I2S or left justified audio data input. Can be driven from an optional external A/D

AV2DATA3 I I2S or left justified audio data input. Not used at present. Leave open.

CONTROL

NCS3 I This signal is configured as GPIO-17 and is currently n ot used. DM870-internal pull-up.

PDOUT0 I Factory Reset. GPIO-04. Return the CnE to factory settings. High-active input, DM870-

VCO0 I Infrared sensor input. GPIO-05. This is a Schmitt-Trigger input and can handle inputs with

AV3CLK O ETH_NRESET Low-active reset for the on-board ethernet PHY. This output is driven by

AV3CTRL0, AV3CTRL1

NRESET_MOD I Low-active input to reset the module. This signal must be driven by an external reset

NPD_RF I Active low input to shut down the power for th e 802.11 RF section. Internal 10kohm pull-

or to external DSP for further audio processing. Used for main left and right channel audio output data. See Note 3.

frequency is 192kHz.

or DSP.

instantaneous frequency on this pin is 24.576MHz.

O Differential stereo output from PWM-DAC, right and left channels. These signals require

analog low pass filtering. SMSC is not recommending using the PWM-DAC outputs because of the potential for high out-of-ban d noise and uncharacterized audio quality. SMSC recommends using an external D/A converter connected to AV2DATA0.

converter used to interface to iPod analog output or other analog audio sources. If not used, leave open.

Leave this pin open.

internal pull-down. Pull to GND with a 10kohm resistor, unless return to factory settings from a hardware control is needed. Normally, return to factory settings is controlled from the host controller via SPI register. This pin is only mon itored during the boot up process.

slow slopes. Used for aDMP firmware builds for infrared remote control sensor output connection to DM870. For applications with a host controller, pull this pin to +3.3V via a 10kohm resistor.

the DM870. GPIO-12. Leave this pin open.

I/O I2C_SCL, I2C_SDA bus created by GPIO-13 and GPIO-14.

No internal pull-ups; Use 4.7kohm pull up resistor on each pin to +3.3V. Maximum frequency is 400kHz.

generator, or by a GPIO output from a host controll er. See the application section of this data sheet for the timing requirements for NRESET_MOD. Includes internal 10K pull-up resistor to +3.3V.

up resistor to +3.3V. Leave open if powering down the RF section is not required.

SMSC CX860/CX870 20 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

ETHERNET

ETH_RXN, ETH_RXP, ETH_TXN, ETH_TXP

ETH_LED_SPEED, ETH_LED_ACT

M Ethernet signals between the PHY on the module and the external magnetics

(transformer). See Note 4. Maximum bit rate is 100Mbps.

3.3V push-pull outputs (max. ±12mA) to drive the ethernet LEDs. 100Mbps speed mode and activity are indicated by the outputs being low. Connect to

LEDs through 220ohm resistors.

USB

USB_DN, USB_DP M USB data signals, normally connected to type A connector, USB switch or iPod dock

USB_VBUS M Analog input for monitoring USB type A connector power. Connect to the +5V power which

USBVBUSDRV O Logic output to control an external MOSFET that is in series with USB type A connector

JTAG

TMS,TCK,TDI, TDO I/O JTAG port for DM870. Leave open.

SSM

SSMD4, SSMD5, SSMD6, SSMD7

SSMD0, SSMD1, SSMD2, SSMD3, SSMCLK, SSMCP, SSMCMD, SSMWP

VIDEO

AV0CLK, AV0CTRL0, AV0CTRL1, AV0CTRL2, AV0DATA0, AV0DATA1, AV0DATA2, AV0DATA3,

AV1DATA0, AV1DATA1, AV1DATA2, AV1DATA3

connector. Maximum bit rate is USB High Speed at 480Mbps.

is driving the USB type A connector power pins. If this pin drops below 4.6V, then the DM870 will drive the USBVBUSDRV signal low to control an external power MOSFET to disconnect +5V power from the USB type A connector. See Note 5.

power. See USB_VBUS above and Note 5.

I/O Can be used to drive external shift registers to make extended GPIO signals (see Note 6),

or as individual GPIO signals, or to make an SD card interface. SD card firmware is not supported at present in JB2. Can be mapped to GPIO #s 08,09,10,11. Leave open if not used.

I/O Used to make an SD card interface. SD card firmware is not supported at present in JB2.

Leave open.

O ITU-R BT.656 digital video output signals. Optionally used to make a TVout menu display,

or to display decoded album art. Can be connected to video D/A converter (see Note 7), or connected to a video DSP.

SMSC CX860/CX870 21 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

GPIO (not already mentioned elsewhere in this table)

A22 O GPIO18 Reserved for NOR flash address A22. Leave open. A23 O GPIO-16 Reserved for NOR flash address A23. Leave open. NWAIT I/O GPIO-15 Not currently assigned. Leave open. NCS2 I GPIO-19 Assigned to iPod dock connector iPod NDETECT. See Note 8. VCO1 I/O GPIO-07 Not currently ass igned. Leave open. MMIICRS I/O GPIO-00 Not currently assigned. Leave open. MIICOL I/O GPIO-01 Not currently ass igned. Leave open. MIITXER I/O GPIO-02 Not currently assigned. Leave open. MIITXCLK I/O GPIO-03 iPod dock connector Accessory Power signal. See Note 8.

MII

MIITXD0, MIITXD1, MIIRXD0, MIIRXD1

LCD

LCDD0, LCDD1, LCDD2, LCDD3, LCDD4, LCDD5, LCDD6, LCDD7, LCDD8, LCDD9, LCDD10, LCDD11, LCDD12, LCDD13, LCDD14, LCDD15, LCD16, LCDD17, LCDCLK, LCDCTRL0, LCDCTRL1, LCDCTRL2, LCDCTRL3

I/O Can be used, with GPIO signals above, to drive an external ethernet PHY. This is not

supported by JB2 firmware. Leave open.

O Uses optional J1 LCD connector. Connect to local LCD display. See Note 9. Leave open if

not used.

SMSC CX860/CX870 22 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Notes:

1. Signal type codes: I – 3.3V level Digital Logic Input into the DM870 O – 3.3V level Digital Logic Output from the DM870 IO – 3.3V level Digital Logic Input and Output (bi-directional) signal M – Miscellaneous, see text for description P – Power Supply

2. For SPI timing diagram for eDMP applications, please see:

BridgeCo_JB2x - DeviceControlProtocol_Registers_v_2_1.pdf, or later version.

For detailed setup and hold timing details, see DM870 IC data sheet:

dat_DM870_16_datasheet.pdf, or later version.

3. For audio port timing diagrams, and for detailed setup and hold timing, please see DM870 IC data

sheet:

dat_DM870_16_datasheet.pdf, or later version.

4. For example ethernet external schematic, see:

CX Module Ethernet (RJ45 + Ext.Magnetics)_V1.2.pdf, or later version.

5. For example USB schematics, see:

CX Module USB_V1.2.pdf, or later version.

6. For example use of extended GPIO shift registers, see CE2 schematic:

A EVMCE2-4_schematic.pdf, or later version.

7. For example connection to a video D/A converter, see CE2 schematic:

A EVMCE2-4_schematic.pdf, or later version.

8. iPod dock connector pin and GPIO assignments are under discussion. Please contact SMSC for

recommendations for iPod dock connections to CX870 module.

9. For example connection to an LCD display, see CE2 schematic:

A EVMCE2-4_schematic.pdf, or later version.

10. All the above signals are brought out to J2 pins. Not all the above signals are brought out to J3, the

64-pin low density connector. The J3 pin assignments table shows which signals are brought out to the J3 pins.

11. SMSC has a set of example motherboard schematics that shows example external circuitry that is

typically connected to the module. Please check the SMSC/BridgeCo customer portal at

https://portal.bridgeco.net/

12. Please check the SMSC/BridgeCo Customer Portal

SMSC documents. Go to https://portal.bridgeco.net/ SMSC.

for a copy of these example schematics.

Download area for the latest version of the

. If you do not have an account, please contact

SMSC CX860/CX870 23 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

8.2.2 Connector PIN Assignments

J2 – Media Connector

Function GPIO IC PIN Signal Signal IC PIN GPIO Function

GND 1 2 GND VIN (+3.3V) 3 4 VIN (+3.3V) VIN (+3.3V) 5 6 VIN (+3.3V)

GND 7 8 GND VIN (+1.2V) 9 10 VIN (+1.2V) VIN (+1.2V) 11 12 VIN (+1.2V)

GND 13 14 GND VIN (+1.9V) 15 16 VIN (+1.9V)

F4 3V3RTC 19 20 GND

SPI

Debug UART

SPI_E_NCS GPIO-11 C16 SSMD7 41 42 SSMD1 C14 SPI_E_SDI GPIO-09 A16 SSMD5 43 44 SSMCMD A14

USB

GPIO-16 K20 A23 69 70

GPIO-18 K19 A22 71 72 I2C SDA GPIO-14 V1 AV 3CTRL1 73 74 AV0CTRL0 M3 I2C SCL GPIO-13 V2 AV3CTRL0 75 76 AV1DATA3 P3

Video Output

LRCK T2 AV2CTRL0 93 94 AV4DATA1 W2 SPDIF output A/D data 1 T3 AV2DATA3 95 96 AV4DATA0 Y1 SPDIF input A/D data 0 T4 AV2DATA2 97 98 GND D/A data 1 U1 AV2DATA1 99 100 ETH_LED_ACT D/A data 0 U2 AV2DATA0 101 102 ETH_LED_SPEED

Ethernet

GPIO-15 N18 NWAIT 117 118 MIIRXD1 Y12

E17 SPI_DOUT 25 26 TDI B19 F17 SPI_DIN 27 28 TDO A19 D17 SPI_CLK 29 30 SPI_NCS0 D16 C17 TXD0 31 32 SPI_NCS1 D15 A18 RXD0 33 34 NRESET_MOD Module reset input B17 RXD1 35 36 SSMD6 B16 GPIO-10 SPI_E_CLK A17 TXD1 37 38 SSMD4 C15 GPIO-08 SPI_E_SDO

B15 SSMD3 45 46 SSMWP C11 B14 SSMD0 47 48 NCS3 M18 G PI O-17 BIST activate C13 SSMCLK 49 50 NCS2 L18 GPIO-19 iPod NDETECT C12 SSMCP 51 52 GND

A1 USB_DN 55 56 GND B1 USB_DP 57 58 AOUTRN K2

USBVBUSDRV 59 60 AOUTRP J2

H3 AOUTLP 63 64 PDOUT1 L1 GPIO-06 SPI_REQ J3 AOUTLN 65 66 VCO1 L2 GPIO-07

K3 AV0CTRL2 77 78 AV1DATA2 R1 L3 AV0CTRL1 79 80 AV1DATA1 R2 N1 AV0CLK 81 82 AV1DATA0 R3 N2 AV0DATA3 83 84 GND N3 AV0DATA2 85 86 AV2CTRL1 T1 MCLK P1 AV0DATA1 87 88 GND P2 AV0DATA0 89 90 AV2CLK R4 SCLK

GND 17 18 GND

GND 21 22 TMS B20 GND 23 24 TCK A20

GND 39 40 SSMD2 A15

GND 53 54 USB_VBUS

GND 61 62 GND

GND 67 68 PDOUT0 M1 GPIO-04 Factory reset

GND 91 92 GND

GND 103 104 MIICRS Y14 GPIO-00 ETH_RXN 105 106 MIICOL W14 GPIO-01 ETH_RXP 107 108 MIITXER V10 GPIO-02

ETH_TXN 111 112 MIITXD0 W10

ETH_TXP 113 114 MIITXD1 Y10

GND 115 116 MIIRXD0 W12

NPD_RF 119 120 GND

Note: The IC PIN column indicates the pin number on the DM860 or DM870 integrated circuit. This allows for easy cross-reference to the DM860 or DM870 data sheet information.

PIN Number

JTAG

SPI

USB

CO0 M2 GPIO-05 IR input V3CLK U3 GPIO-12 ETH NRESET

Video Output

Ethernet

109 110 MIITXCLK V11 GPIO-03 iPod Access Power

SMSC CX860/CX870 24 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

J1 – LCD Connector

Function GPIO IC PIN Signal Signal IC PIN GPIO Function

GND

Y7 LCDD0 V7 LCDD2

W6 LCDD4 U6 LCDD6

LCD Interface

W5 LCDD8 U5 LCDD10 W4 LCDD12 U4 LCDD14 W3 LCDD16

GND

Y9 LCDCLK Y8 LCDCTRL1 V8 LCDCTRL3

GND

PIN Number

12 34 56 78

910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

GND LCDD1 W7 LCDD3 Y6 LCDD5 V6 LCDD7 Y5 LCDD9 V5 LCDD11 Y4 LCDD13 V4 LCDD15 Y3 LCDD17 Y2 GND LCDCTRL0 W9 LCDCTRL2 W8 GND GND

LCD Interface

Note: The IC PIN column indicates the pin number on the DM860 or DM870 integrated circuit. This

allows for easy cross-reference to the DM860 or DM870 data sheet information.

J3 – Low Density Connector

Function GPIO IC PIN Signal Signal IC PIN GPIO Function

GND 12GND VIN (+3.3) 34RXD0 VIN (+3.3) 56TXD0 GND 78GND VIN (+1.9) 910VIN (+1.2) VIN (+1.9) 11 12 VIN (+1.2)

GND 13 14 GND Free GPIO-15 iPod NDETECT GPIO-19

SPI

Free GPIO-17 D15 NCS3 33 34 AV4DATA0 Y1 SPDIF input

E-GPIO_NCS/TBA GPIO-11 I2C SDA GPIO-14 I2C SCL GPIO-13 V2 AV3CTRL0 41 42 USBVBUSDRV

SPI_REQ GPIO-06 L1 PDOUT1 Factory Reset GPIO-04 M1 PDOUT0 47 48 SSMD5 K20 IR input GPIO-05 M2 VCO0 49 50 SSMD4 C15 GPIO-08

iPod Access Power

Ethernet

Free GPIO-00 MMIICRS 61 62 MIICOL

GPIO-03 V11 MIITXCLK 55 56 SSMD6 B16 GPIO-10

N18 NWAIT 15 16 RXD1 B17 L18 NCS2 17 18 TXD1 A17

NRESET 19 20 GND

F4 3V3RTC

GND 23 24 AV2CTRL0 T2 LRCK

F17 SPI_DIN 25 26 AV2CLK R4 SCLK E17 SPI_DOUT 27 28 AV2DATA2 T4 A/D data 0 D17 SPI_CLK 29 30 AV2DATA0 U2 D/A data 0 D16 SPI_NCS0 31 32 AV4DATA1 W2 SPDIF output

GND 35 36 GND

C16 SSMD7 37 38 USB_DN A1

V1 AV3CTRL1 39 40 USB_DP B1

GND 43 44 USB_VBUS

GND 51 52 GND

ETH_LED_SPEED 53 54 ETH_LED_ACT

ETH_RXN 57 58 ETH_RXP

ETH_TXN 59 60 ETH_TXP

GND

PIN Number

21 22

45 46

63 64

Debug UART

AV2CTRL1 T1 MCLK

USB

GND

E-GPIO_SDI/TBA

GPIO-09

E-GPIO_SDO/TBA

EthernetEthernet

E-GPIO_CLK/TBA

Ethernet

GPIO-01 Free

Note: The IC PIN column indicates the pin number on the DM860 or DM870 integrated circuit. This allows for easy cross-reference to the DM860 or DM870 data sheet information.

SMSC CX860/CX870 25 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

8.2.3 GPIO Assignments

GPIO Assignments for J3 64-pin Low Density Connector

GPIO PIN Name PIN Number Function

00 MMIICRS 61 Free 01 MIICOL 62 Free 03 MIITXCLK 55 iPOD Access Power 04 PDOUT0 47 Factory Reset 05 VCO0 49 IR Input 06 PDOUT1 45 Host NIREQ 08 SSMD4 50 E_GPIO_SDO/TBA 09 SSMD5 48 E_GPIO_SDI/TBA 10 SSMD6 56 E_GPIO_CLK/TBA 11 SSMD7 37 E_GPIO_NCS/TBA 13 AV3CTRL0 41 I2C_SCL 14 AV3CTRL1 39 I2C_SDA 15 NWAIT 15 Free 17 NCS3 33 Free 19 NCS2 17 IPOD NDETECT

Note: Not all 20 GPIO signals are brought out to J3 64-pin low density connector.

9 Application Guidelines

9.1 Power Supply sequencing and Reset Timing

There are strict power sequencing and reset timing require ments.

 Power up the I/O voltage (3.3V) first and hold NRESET_MOD low.  The core voltage (1.2V) must never be higher than (I/O voltage +0.5 V).  The core voltage (1.2V) must be within the specified core voltage limits less than 300ms after the I/O voltage

(3.3V) reaches the specified I/O voltage limits.

 Throughout the power down process, the 3.3V supply must maintain a higher voltage than the 1.2V supply,

until both have reached ground potential.

 To assure a proper IC reset, the power supplies must be present for a minimum time of 2ms before

NRESET_MOD is de-asserted.

Please see the power and reset timing figure in Section 9.1.1 below.

About 1.9V, the arrival of 1.9V supply should lag behind the arrival of the 3.3V. The delay between the 1.9V and the

3.3V is not critical. Typical delay is approximately 10ms, for example using 10kohm resistor and 0.1uF capacitor on the enable pin of a 1.9V dc-to-dc converter.

SMSC CX860/CX870 26 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

9.1.1 Power up, Reset and Power Down Timing

Voltage

Power Up Power Down

+3.3V

+1.2V

< 300ms

NRESET_MOD

>= 2ms

Time

9.2 RF Considerations

Note that overall system, RF and WiFi performance is significantly affected by the product design, environment and the application. It is the responsibility of the product designer to ensure proper system level shielding (if required) and to verify performance and fitness for the given product features and applications.

The WiFi performance will be affected by the RF environment surrounding the CX module. Please ensure that the CX module is positioned in a “quiet” RF environment, as far away as possible from high frequency clock signals and any other sources of RF energy. Also, make sure the antenna is not shielded by any metal objects, for example loudspeakers or other metal parts. Please make sure that the power supplies, in particular the +1.9V supply, are quiet and free from noise.

SMSC recommends that systems implementing AirPlay should use a module configuration that includes on-module shielding, as well as paying particular attention to system configuration and shielding.

SMSC CX860/CX870 27 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

10 Revision Control

Revision Date / Author Details of Chan ge Reason for Change

V2.2 (110811)

V2.1 (100711)

V2.0 (100211)

V2.0 (092611)

November 8, 2011 / SHs

October 7, 2011 / SHs

October 2, 2011 / SHs

Sept. 26, 2011 / SHs

Added CX870-3K option to Section 4 Ordering Guide.

Updated title of Section 6.1 from “1 RoHS” to “RoHS”.

In Section 10 Revision Control table, updated an entry for V2.0 b in the Reason for Change column from “RTV” to “RTC”

Removed “Preliminary Datasheet” from the footer.

Removed the word “Preliminary” from the title page.

Updated Section 5.3 WiFi Specification “TX Power” entry for 802.11g

Updated Section 6.0.1 Antenna Considerations with updated module numbering scheme

Updated Section 6.7 Module Quality with new Defect Rate

Updated Section 4.1 Part Number Syntax with removal of Antenna Configuration number and Note

Updated Section 10 Revision Control with new Reason for Change column

Change from BridgeCo logos and disclaimer text to SMSC logos and disclaimer text

Updated location of red boxes in Section 3.2.1 CX870 Bottom View with 64-pin Low density connector

Updated location of red boxes in Section 3.2.2 CX870 Bottom View with 120-pin Media connector

Moved Section 5.3 WiFi Specification on to one page

Updated Customer Portal information in Section 6 Regulatory Compliance and Quality

Reverted Antenna Considerations back to Section 6.0.1; subsequently all subsections in Section 6 reverted back to original numbering

Updated Notes 11 & 12 in Section 8.2.1 Pin Descriptions with updated Customer Portal information

Updated Table of Contents Keep TOC aligned with actual content.

Added -3K option.

Correcting typo.

CX module is in production, so the datasheet is no longer preliminary.

Correspond to actual production test limits.

Revert to original module numbering scheme.

Data is now available.

Revert to original part numbering scheme.

Corporate standard.

Improve alignment of red box to photo.

Improve readability.

Easier to access URL directly.

Decided to keep original part numbering scheme to avoid unnecessary paper work and the need to redo certifications.

Easier to access URL directly.

SMSC CX860/CX870 28 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Revision Date / Author Details of Chan ge Reason for Change

V2.0 c Sept. 14,

2011 / SHs

V2.0 b Sept. 10,

2011 / SHs

V2.0 a August 22,

2011 / SHs

V2.0 August 12,

2011 / SHs

V1.9 c August 2,

2011 / SHs

Updated font styling of Table of Contents Easier to read. Update Section 2 Block Diagram : moved

RJ45+Transformer & USB Type A boxes inside the drawing boundary

Updated Section 5.3 WiFi Specification (CX870 only) TX Power Description entry

Updated Section 5.3 WiFi Specification (CX870 only) Rx Sensitivity Description entry

Updated Section 5.3 WiFi Specification (CX870 only) : add a Note underneath the table

Updated Section 4 Ordering Guide : changed CX870-3D row Two Ant entry from (X)* to X

Updated Section 4 Ordering Guide : removed the two blank rows

Updated the Description for pin NCS3 in Section

8.2.1 Pin Descriptions Updated Section 4 Ordering Guide : added gray

background to CX870-3F & CX870-3G Updated Section 4 Ordering Guide : removed

the 2 from A, H, I & J version Part Numbers

Updated Section 4 Ordering Guide : split Ext. Diversity Antennas column into two, added two sub-columns “One Ant.” & “Two Ant.”, moved Xs to correspond with correct sub-column

Updated Section 4 Ordering Guide : CX870-3D : removed X from WiFi column

Updated Section 4 Ordering Guide : updated + Note text

Updated Section 4 Ordering Guide : moved the + from Part Numbers column to Ext. Diversity Antennas column

Updated Section 4 Ordering Guide : removed # Note completely

Updated Section 4.1 Part Number Syntax : Updated graphic

Updated Section 4.1 Part Number Syntax : Updated Note text

Updated text in Section 8.1 WLAN UFL Antenna Connector

Removed RTC elements from Section 2 Block Diagram

Updated the Description for pin 3V3RTC in Section 8.2.1 Pin Descriptions

Added Section 3.5 Example Production Module Showing Soldered RF Shield

Updated Note Section 4.1 Part number syntax Highlighted that CX870-3D does not follow the

Updated all Section 3 Board Pictures to new versions + inserted new Sections 3.2.1 & 3.2.2 which show two different bottom views

 Updated Key Features on Title page:

removed (optional) from “WiFi-certified

Improve accuracy of drawing.

Align data with test limits.

Clarification of the possible effect of changing the TX Power setting.

Change to match final CX870-3D configuration.

Improve readability.

Update to align with actual use.

Internal antenna versions are not available until performance issues are resolved.

Decided to keep original part numbering scheme to avoid unnecessary paper work and the need to redo certifications.

Show the number of external antenna connections.

CX870-3D is not configured for internal antenna.

Explained about one or two external antenna options.

Proper link for "+" Note.

Content now covered by "+" Note

Explain antenna configuration field

Explain about one or two antenna configuration.

Remove references to part numbering scheme which includes the number of antennas, and repeat advice to use two external antennas.

Support for RTC is removed.

Photo shows that RF shield is soldered, needed for Japan Telec certification.

new part numbering scheme. This Note was subsequently deleted, so this is not relevant any more.

Improve accuracy of data sheet photos.

SMSC CX860/CX870 29 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Revision Date / Author Details of Chan ge Reason for Change

802.11b/g” entry

 Updated Antenna Configuration entry in

Section 4.1 Part number syntax

V1.9 b July 28, 2011

/ SHs

V1.9 a July 25, 2011

/ SHs

V1.8 a July 10, 2011

/ SHs

V1.8 July 5, 2011 /

SHs

SMSC CX860/CX870 30 Revision 2.2 (11-08-11)

 Updated Section 4.1 Part number syntax

o Updated graphic o Added a Note

 Changed intro text in Section 3 Board

Pictures

 Updated Section 4 Ordering Guide

o Changed CX870-3B1 to CX870-

o Updated the text for + note o Added a note to CX870-3B Ext.

Diversity Antenna column

o Added a new # note

 Added Section 6.0.1 Antenna

Considerations

 Inserted new photo for Section 3.1 Top

View of CX870

 Inserted new photo for Section 3.2 Bottom

View of CX870

 Added new Section 3.3 Production Module

with Top & RF shields

 Added new Section 3.4 Production Module

with 64-pin Connector Option

 Updated Section 4 Ordering Guide

o Added gray background to

CX870-3D

o Changed CX870-3A to CX870-

3A2

o Changed CX870-3B to CX870-

3B1

o Changed CX870-3H to CX870-

3H2

o Changed CX870-3I to CX870-

3I2

o Changed CX870-3J to CX870-

3J2

o Added a Note to the Part

Number title

 Updated Section 8.1 WLAN UFL Antenna

Connector with new text

 Updated Section 5.3 WiFi Specification TX

EVM entry to

-9dB@6MHz

 Updated Section 6 Regulatory Compliance

& Quality with Module Versions Passed for Radio Regulations entries

 Replaced the Note in Section 6 to be main

body text and updated the text.

 Added new Section 4.1 Part number

syntax

 Updated module weight to 20g  Update section 8.1 WLAN UFL Antenna

Connector

 Deleted section 8.1.1 Coaxial antenna

connector dimensions

 Updated the acceptable surface-mount

receptacle parts in Section 8.1 WLAN UFL

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Revision Date / Author Details of Chan ge Reason for Change

Antenna Connector

 Added Appendix 1: Certification Notices

V1.7 c May 13, 2011

/ SHs

V1.7 b May 11, 2011

/ SHs

V1.7 a May 6, 2011 /

SHs

V1.7 May 4, 2011 /

SHs

V1.6 d March 3,

2011 / SHs

V1.6 c February 24,

2011 / SHs

SMSC CX860/CX870 31 Revision 2.2 (11-08-11)

 Updated “Module Quality” Defect Rate

field entry

 Updated “Board Dimensions & Weight”

drawings

 Updated the “Electrical Specifications”

table

 Added another Note to the “Pin

Descriptions” section

 Updated Note 8 in “Pin Descriptions” table  Re-imported “Board Dimensions &

Weight” drawings

 Updated “Board Pictures” images  Updated board photo on Cover page  Updated the Feature list on Cover page  Updated J1, J2 & J3 “Connector PIN

Assignments” tables: removed Power column & re-organised columns

 Changed “Application Notes” title to

“Application Guidelines”

 Re-imported Block Diagram as a wmf file  Updated “Power up, Reset & Power down

Timing” figure

 Updated “Pin Descriptions” table  Re-organised text in “Power Supply

sequencing & Reset Timing”

 Re-imported J2 & J3 Connector PIN

Assignment tables

 Added note to Module Weight section  Updated the Ordering Guide – Part

Numbers & added new J version

 Added new text to the Board Pictures

section

 Updated all Mechanical Drawings and

added & removed Notes

 Updated the J3 Low Density Connector

table

 Updated the GPIO Assignment table  Added new Power Supply & Timing figure  Updated the text in the “Power Supply

sequencing and Reset Timing” section

 Updated the Key Connections table  Updated “Key Connections” section title to

“Pin Descriptions”

 Updated “Detailed Connector PIN

Descriptions” section title to “Connector PIN Assignments”

 Updated J2 Media Connector table  Updated J3 Low Density Connector table

 Update GPIO Assignments section and

table

 Updated all mechanical drawings in

“Board Dimensions and Weights” section

 Deleted warning note in “Board

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Revision Date / Author Details of Chan ge Reason for Change

Dimensions and Weights” section

V1.6 b February 23,

2011 / SHs

V1.6 February 11,

2011 / SHs

V1.5 b January 27,

2011 / SHs

V1.5 a January 24,

2011 / SHs

V1.5 January 22,

2011 / SHs

V1.4 b January 11,

2011 / SHs

V1.4 January 3,

2011 / SHs

V1.3 December 23,

2010 / SHs

V1.2 December 19,

2010 / SHs

 Updated “J3-Low density connector” pin

 Updated “GPIO Assignments” table  Entirely updated the “Ordering Guide”

 Added a Note to the “Ordering Guide”  Updated the subsection titles for the

 Updated the Block Diagram – changed

 Added Note to “Board Dimensions and

 Updated the “Ordering Guide” – removed

 Updated the Header to reflect Preliminary

 Updated the datasheet to be a Preliminary

 Added new feature to Summary on Front

 Updated “J3 - Low Density Connector”

 Updated “GPIO Assignments” table  Added note to “Board Dimensions &

 Updated text in “Application Notes –

 Updated “Block Diagram”  Updated text in “Connectors &

 Updated the Application Notes, RF

 Updated the module photo on the Title

 Updated the Application Notes, RF

 Updated Ordering Guide  Added Notes to Ordering Guide  Updated Block Diagram  Updated “J3 – Low Density Connector”

 Updated “Electrical Specifications” table  Added Power Consumption data to

 Updated the Board Dimensions and

 Updated the “GPIO Assignments” table  Added another Application Note  Added titles to Application Notes

 Inserted CX860 and CX870 Module

 Updated module image on Front Page

description table

“Board Pictures” section

‘WiFi Antenna’ to ‘Ext. Antenna’

Weight” section

Mfg column and consolidated into one table

nature of datasheet

Datasheet

Page

table

Weight – Side Views of CX870 module” section

Power Supply Sequencing & Reset Timing” section

Connections – WLAN UFL Antenna Connector” section

Considerations section

page

Considerations section

table

“Electrical Specifications” table

Weight images

Weights

SMSC CX860/CX870 32 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Revision Date / Author Details of Chan ge Reason for Change

V1.1 December 13,

2010 / SHs

V1.0 October 18,

2010 / SHs

 Added the Ordering Guide.  Updated the Block Diagram.  Updated the “Electrical Specifications”

 Updated the “Absolute Maximum Ratings”

 Updated the Notes for “Regulatory

 Updated “Key Connections” table  Updated “J2 – Media Connector” table  Updated “J3 – Low Density Connector”

 Updated “GPIO Assignments” table  Added Board Pictures  Replaced Mechanical Drawings in “Board

 Initial Version

table

Compliance and Quality” section

table

Dimensions and Weight” section

SMSC CX860/CX870 33 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

11 Appendix 1: Certification Notices

Federal Communications Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will no t occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/ TV technician for help.

CAUTION:

Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment.

Labeling requirements

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) t his device must accept any interference received, including interference that may cause undesired operation.

RF exposure warning

This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

Information for the OEMs and Integrators

The following statement must be included with all versions of this document supplied to an OEM or integrator, but should not be distributed to the end user.

This device is intended for OEM integrators only. Please see the full Grant of Equipment document for other restrictions. This device must be operated and used with a locally approved access point.

Information To Be Supplied to the End User by the OEM or Integrator

The following regulatory and safety notices must be published in documentation supplied to the end user of the product or system incorporating an adapter in compliance with local regulations.

Host system must be labeled with "Contains FCC ID:ZQO-CX870-3”X”“, FCC ID displayed on the label. The label text should be updated according to the table shown in Ordering Guide section of this document. The proper letter shown in Ordering Guide Part Number column should be substituted for “X”. For example, for the CX870-3B module, the label text should be “Contains FCC ID:ZQO-CX870-3B“.

SMSC CX860/CX870 34 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

JukeBlox Networked Media Modules – CX Series

Datasheet

Canada, Industry Canada (IC) Notices

This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device

must accept any interference, including interference that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Information

The radiated output power of the Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized.

This device has also been evaluated and shown compliant with the IC RF Exposure limits under mobile exposure conditions. (antennas are greater than 20cm from a person's body).

This device has been certified for use in Canada. Status of the listing in the Industry Canada’s REL (Radio Equipment List) can be found at the following web address:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng

Additional Canadian information on RF exposure also can be found at the following web address:

http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Canada, avis d'Industry Canada (IC)

Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-210. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d'interférence et

(2) cet appareil doit accepter toute interférence, notamment les interférences qui peuvent affecter son fonctionnement.

Informations concernant l'exposition aux fréquences radio (RF)

La puissance de sortie émise par l’appareil de sans fil Dell est inférieure à la limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez l’appareil de sans fil Dell de façon à minimiser les contacts humains lors du fonctionnement normal.

Ce périphérique est homologué pour l'utilisation au Canada. Pour consulter l'entrée correspondant à l’appareil dans la liste d'équipement radio (REL - Radio Equipment List) d'Industry Canada rendez-vous sur:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng Pour des informations supplémentaires concernant l'exposition aux RF au Canada rendez-vous sur: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

SMSC CX860/CX870 35 Revision 2.2 (11-08-11)

SMSC CONFIDENTIAL

FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection aga inst harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/ TV technician for help.

CAUTION:

Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment.

Labeling requirements

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RF exposure warning

Information for the OEMs and Integrators

The following statement must be included with all versions of this document supplied to an OEM or integrator, but should not be distributed to the end user.

This device is intended for OEM integrators only. Please See the full Grant of Equipment document for other restrictions. This device must be operated and used with a locally approved access point.

Information To Be Supplied to the End User by the OEM or Integrator

The following regulatory and safety notices must be published in documentation supplied to

the end user of the product or system incorporating an adapter in compliance with local regulations. Host system must be labeled with "Contains FCC ID: ZQO-CX8703x “, FCC ID displayed on label.

The “x“is for different versions of CX870-3 serial modules, the label text should be updated according to the table shown in Chapter

4.The proper letter shown in Chapter 4 should be substituted for X. For example, The FCC ID:ZQO -CX8703B is for model CX870-3B.

Canada, Industry Canada (IC) Notices This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Radio Frequency (RF) Exposure Information The radiated output power of the Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized.

This device has also been evaluated and shown compliant with the IC RF Exposure limits under mobile exposure conditions. (antennas are greater than 20cm from a person's body).

This device has been certified for use in Canada. Status of the listing in the Industry Canada’s REL (Radio Equipment List) can be found at the following web address:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng

Additional Canadian information on RF exposure also can be found at the following web address:

http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Canada, avis d'Industry Canada (IC) Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-210. Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d'interférence et (2) cet appareil doit accepter toute interférence, notamment les interférences qui peuvent affecter son fonctionnement.

Informations concernant l'exposition aux fréquences radio (RF) La puissance de sortie émise par l’appareil de sans fil Dell est inférieure à la limite d'exposition aux fréquences radio d'Industry Canada (IC). Utilisez l’appareil de sans fil Dell de façon à minimiser les contacts humains lors du fonctionnement normal.

Ce périphérique a également été évalué et démontré conforme aux limites d'exposition aux RF d'IC dans des conditions d'exposition à des appareils mobiles (les antennes se situent à moins de 20 cm du corps d'une personne). Ce périphérique est homologué pour l'utilisation au Canada. Pour consulter l'entrée correspondant à l’appareil dans la liste d'équipement radio (REL - Radio Equipment List) d'Industry Canada rendez-vous sur:

http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng

Pour des informations supplémentaires concernant l'exposition aux RF au Canada rendez-vous sur :

http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html

Information To Be Supplied to the End User by the OEM or Integrator

The following regulatory and safety notices must be published in documentation supplied to the end user of the product or system incorporating an

adapter in compliance with local regulations. Host system must be labeled with "Contains IC: 2581A-CX8703x “, IC ID displayed on label.

The “x“is for different versions of CX870-3 serial modules, the label text should be updated according to the table shown in Chapter 4.The proper letter

shown in Chapter 4 should be substituted for x. For example, The IC: 2581A-CX8703B is for model CX870-3B.

This radio transmitter IC: 2581A-CX8703K has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

Antenna List No Manufacturer Part No. Antenna Type Peak Gain 1 MAG. LAYERS MSA-3612-2G4C1-A1 PIFA 2.1 dBi for 2.4GHz

Microchip Technology CX8703K User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
