42199AWIRELESS10/2013

ZigBit 2.4GHz Single chip Wireless Module

ATZB-S1-256-3-0-U / ATZB-S1-256-3-0-UF

DATASHEET

Features

 Ultra compact size (30.0 × 20.0 mm)
 High RX sensitivity (-98 dBm)
 Outperforming link budget (up to 102 dB)
 Up to +4dBm output power
 Very low power consumption:

 17 mA in RX mode
 16.4 mA in TX mode
 0.6 µA in sleep mode

 Ample memory resources (256K Bytes In-System, Self-Programmable Flash

memory, 8K Bytes EEPROM, 32K Bytes SRAM)

 Wide range of interfaces (both analog and digital)

 4- wire SPI, TWI
 ISP, JTAG
 2 Analog comparator Input
 UART, USART
 Timer, PWM
 4 ADC lines
 External Clock Input, Internal Clock Output
 Upto 31 lines configurable as GPIO

 Preassigned Atmel MAC address that can be used on end product
 Capability to use MAC address into the internal EEPROM

 IEEE

®

802.15.4 compliant Transceiver

 2.4GHz ISM band
 Serial bootloader
 High Performance Low power AVR 8-bit Microcontroller
 U.FL Antenna Connector to select approved antennae upto 5dBi
 Small physical footprint and low profile for optimum fit in very small application

boards

 Mesh networking capability
 Easy-to-use low cost development kit
 Single source of support for HW and SW
 Worldwide license-free operation

(1)

(1)

(2)

Note: 1. MCU is in active state with 3V Supply, CPU clock @ 16MHz, RX RPC enabled (for RX current),

PHY_TX_PWR=0x0 (for TX current), All digital outputs pulled high.

2

Note: 2. Controller Sleep Mode – SLEEP_MODE_PWR_DOWN

Table of Contents

1. Introduction ........................................................................................ 3

1.1 Summary ........................................................................................................... 3

1.2 Abbreviations and Acronyms ............................................................................ 3

1.3 Related Documents ........................................................................................... 4

2. ZigBit Module Overview ..................................................................... 5

2.1 Overview ........................................................................................................... 5

3. Specifications ..................................................................................... 7

3.1 Electrical Characteristics ................................................................................... 7

3.1.1 Absolute Maximum Ratings ................................................................ 7

3.1.2 Power Supply ...................................................................................... 7

3.2 RF Characteristics ............................................................................................. 8

3.2.2 Microcontroller Characteristics ............................................................ 8

3.2.3 Module Interfaces Characteristics ....................................................... 9

3.3 Physical/Environmental Characteristics and Outline ......................................... 9

3.4 Pin Configuration ............................................................................................... 9

3.5 Mounting Information ...................................................................................... 11

3.6 List of Approved Antennas .............................................................................. 12

3.7 Soldering Profile .............................................................................................. 13

4. Schematics ................................................................ ...................... 13

4.1 Handling Instructions ....................................................................................... 14

4.2 General Recommendations ............................................................................ 14

5. Persistence Memory ........................................................................ 14

6. Ordering Information ........................................................................ 16

7. Agency Certifications ....................................................................... 17

7.1 United States (FCC) ........................................................................................ 17

7.2 European Union (ETSI) ................................................................................... 17

7.3 Industry Canada (IC) Compliance statements ................................................ 18

8. Revision History ............................................................................... 21

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

3

1. Introduction

1.1 Summary

ATZB-S1-256-3-0-U ZigBit® is an ultra-compact and low-power 2.4GHz IEEE 802.15.4/ZigBee® OEM module from
Atmel®. Based on the innovative mixed-signal hardware platform from Atmel, this module uses the ATmega256RFR2
SoC with the AVR 8-Bit Microcontroller and a high data rate transceiver for the 2.4GHz ISM band. The radio transceiver
provides high data rates from 250kb/s up to 2Mb/s, frame handling, outstanding receiver sensitivity and high transmit
output power enabling a very robust wireless communication. The module is designed for wireless sensing, monitoring,
control, data acquisition applications, to name a few. This ZigBit module eliminates the need for costly and time­consuming RF development, and shortens time-to-market for wireless applications.

The module has an U.FL RF connector that can be used to connect any of the approved antenna – cable assembly.
This give freedom to applications to choose the external antenna1 that can be mounted on an end product.

The ZigBit module is compatible with robust IEEE 802.15.4/ZigBee stack that supports a self-healing, self-organizing
mesh network, while optimizing network traffic and minimizing power consumption.

For detailed Software support information, please visit www.atmel.com/wireless
The applications include, but are not limited to:

 Building automation & monitoring

o Lighting controls
o Wireless smoke- and CO-detectors
o Structural integrity monitoring

 HVAC monitoring & control
 Inventory management
 Environmental monitoring
 Security
 Water metering
 Industrial monitoring

o Machinery condition and performance monitoring
o Monitoring of plant system parameters such as temperature, pressure, flow, tank level, humidity, vibration, etc.

 Automated meter reading (AMR)

1.2 Abbreviations and Acronyms

ADC Analog-to-Digital Converter
API Application Programming Interface
DC Direct Current
DTR Data Terminal Ready
EEPROM Electrically Erasable Programmable Read-Only Memory
ESD Electrostatic Discharge
GPIO General Purpose Input/Output
HAF High Frequency
HVAC Heating, Ventilating, and Air Conditioning

Notes: 1. External antenna must be selected from a list of approved antennae.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

4

HW Hardware

I2C Inter-Integrated Circuit
IEEE Institute of Electrical and Electronics Engineers
IRQ Interrupt Request
ISM Industrial, Scientific and Medical radio band
JTAG Digital interface for debugging of embedded device, also known as IEEE 1149.1 standard

interface
MAC Medium Access Control layer
MCU Microcontroller Unit. In this document it also means the processor, which is the core of a ZigBit

module
NRE Network layer
OEM Original Equipment Manufacturer
OTA Over-The-Air upgrade
PA Power Amplifier
PCB Printed Circuit Board
PER Package Error Ratio
RAM Random Access Memory
RF Radio Frequency
RTS/CTS Request to Send/ Clear to Send
RX Receiver
SMA Surface Mount Assembly
SoC System on Chip
SPI Serial Peripheral Interface
SW Software
TTM Time-To-Market
TX Transmitter
UART Universal Asynchronous Receiver/Transmitter
USART Universal Synchronous/Asynchronous Receiver/Transmitter
USB Universal Serial Bus
ZigBee, ZigBee PRO Wireless networking standards targeted at low-power applications

802.15.4 The IEEE 802.15.4-2003 standard applicable to low-rate wireless Personal Area Network

1.3 Related Documents

[1] ATmegaAllRFR2 8-bit AVR Microcontroller with 2.4GHz Transceiver for ZigBee and IEEE 802.15.4
[2] IEEE Std 802.15.4-2003 IEEE Standard for Information technology - Part 15.4 Wireless Medium Access Control

(MAC) and Physical Layer (PHY) Specifications for Low-Rate Wireless Personal Area Networks (LR-WPANs)

[3] ZigBee Specification. ZigBee Document 053474r17, October 19, 2007

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

5

2. ZigBit Module Overview

2.1 Overview

The ATZB-S1-256-3-0-U ZigBit is an ultra compact, low-power, high sensitivity IEEE 802.15.4/ZigBee OEM module.
Based on a solid combination of the latest Atmel MCU Wireless hardware platform, 2.4GHz ISM band transceiver and
Atmel Studio Wireless Composer - the ZigBit offers an unmatched combination of superior radio performance, ultra-low
power consumption and exceptional ease of integration.

Figure 2-1. ATZB-S1-256-3-0-U Block Diagram.

This ZigBit module contains the Atmel ATmega256RFR2 Microcontroller and a 2.4GHz ISM band Transceiver for
ZigBee and IEEE 802.15.4 [1]. The module features 256KB In-System Self-Programmable flash memory, 32KB SRAM
and 8KB EEPROM.

The compact all-in-one integration of MCU and Radio Transceiver inside the chip along with very minimal components
on the RF path to Antenna dramatically improves the ZigBit's compact size, range performance on signal transmission
and increases its sensitivity. This ensures stable connectivity within a larger coverage area, and helps develop
applications on smaller footprint.

ZigBit Module contains a complete RF/MCU design with all the necessary passive components included. The module
can be easily mounted on a simple 2-layer PCB with a minimum of required external connection. The ZigBit Module
Evaluation kit containing the ZigBit Extension board for the Atmel Xplained PRO HW Evaluation platform can be used to
develop FW using the Atmel Studio and evaluate using the Wireless Composer. Compared to a custom RF/MCU
solution, a module-based solution offers considerable savings in development time and NRE cost per unit during the
HW/FW design, prototyping, and mass production phases of product development.

All ZigBits are preloaded with a Bootloader when they are sold as Modules, either in Single units or T&R.
Depending on end-user design requirements, the ZigBit can operate as a self-contained sensor node, where it would

function as a single MCU, or it can be paired with a host processor driving the module over a serial interface.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

6

The MAC stack running on the host processor can then control data transmission and manages module peripherals.
Thus very minimal firmware customization is required for a successful module design-in. Third-party sensors can then
be connected directly to the module, thus expanding the existing set of peripheral interfaces.

Every ZigBit Module come pre loaded with Atmel assigned 64-bit MAC address stored in the signature bytes of the
device. This unique IEEE MAC address can be used as the MAC address of the end product, so there is no need to buy
a MAC address separately for the product using the ZigBit.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

7

Parameter

Minimum

Maximum

Voltage on any pin, except RESET with respect to ground

-0.3V

3.6V (VDD

max

)

Input RF level

+14dBm

Voltage on any Analog configured pin

-0.3V

2.0V

Voltage on Aref (pin 24)

-0.3V

2.0V

Parameter

Range

Unit

Supply voltage, VDD

1.8 to 3.6

V

Active Current consumption: RX mode - RX_ON – Listening state

17.0

mA

Active Current consumption: TX mode

(1)

– BUSY_TX – Transmit state

16.3

mA

Active Current consumption: TX mode – PLL_ON

9.9

mA

Active Current consumption: TRX_OFF

4.7

mA

Sleep Current consumption: Power-save mode

(2)

0.62

µA

Sleep Current consumption: Power-down mode

(2)

0.6

µA

Sleep Current consumption: Standby

(2)

2.4

mA

Sleep Current consumption: Idle

(2)

4.9

mA

Sleep Current consumption: Ext_Standby

(2)

0.9

mA

3. Specifications

3.1 Electrical Characteristics

3.1.1 Absolute Maximum Ratings

Table 3-1. Absolute maximum ratings

(1)(2)

.

1. Absolute Maximum Ratings are the values beyond which damage to the device may occur. Under no circumstances must the absolute

maximum ratings given in this table be violated. Stresses beyond those listed under "Absolute Maximum Ratings" may cause permanent
damage to the device.
This is a stress rating only. Functional operation of the device at these or other conditions, beyond those indicated in the operational
sections of this specification, is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device
reliability.

2. Attention! The ZigBit is an ESD-sensitive device. Precaution should be taken when handling the device in order to prevent permanent

damage.

3.1.2 Power Supply

Table 3-2. Test conditions (unless otherwise stated), F = 2.45GHz, VDD = 3V, T

= 25°C.

amb

Note 1:

a) Output TX power (when measuring consumption in TX mode) is +3 dBm.

Note 2:

a) All interfaces are set to the default state (see Pin Assignment Table).
b) JTAG is not connected.
c) CPU Clock configured when doing this measurement – 16MHz for all modes except Power save and Power down modes

Current consumption depends on multiple factors, including but not limited to, the board design and materials, Protocol
settings, network activity, EEPROM read/write operations. It also depends on MCU load and/or peripherals used by an
application.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

8

Parameter

Condition

Range

Unit

Frequency band

2.4000 to 2.4835

GHz

Numbers of channels

16

Channel spacing

5 MHz

Transmitter output power

Adjusted in 16 steps

-16.5 to +3.5

dBm

Receiver sensitivity

PER = 1%

-97

dBm

On-air data rate

250, upto 2000

kbps

TX output/ RX input nominal impedance

Unbalanced

50

Ω

PHY_TX_PWR 3:0
Register value

Power register setting [dBm]

Typical Output power [dBm] (at RF connector)

0

+3.5

+3.79

1

+3.3

+3.40

2

+2.8

+3.41

3

+2.3

+2.43

4

+1.8

+2.41

5

+1.2

+1.21

6

+0.5

+0.58

7

-0.5

-0.11

8

-1.5

-1.02

9

-2.5

-1.97

10

-3.5

-3.12

11

-4.5

-4.48

12

-6.5

-6.28

13

-8.5

-8.52

14

-11.5

-11.64

15

-16.5

-16.26

Parameters

Condition

Range

Unit

On-chip flah memory size

256K

Bytes

On-chip SRAM size

32K

Bytes

On-chip EEPROM size

8K

Bytes

Maximum Operation frequency

16

MHz

3.2 RF Characteristics

Table 3-3. RF characteristics.

Table 3-4. TX power settings

3.2.2 Microcontroller Characteristics

Table 3-5. ATmega256RFR2 characteristics.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

9

Parameters

Condition

Range

Unit

UART maximum baud rate

115.2

Kbps

ADC resolution conversion time

Free running conversion

3 - 240

µs

ADC input resistance

Static load resistor of
input signal

100

MΩ
ADC reference voltage (VREF)

AVDD=1.8V

1.5V to AVDD

V

ADC input voltage

AVDD=1.8V

0 - AVDD

V

TWI maximum clock

400

kHz

GPIO High level input voltage

Except nRST

Min 0.7 VDD

V

GPIO Low level input voltage

Except nRST

Max 0.3 VDD

V

GPIO High level input voltage

nRST

Min 0.9 VDD

V

GPIO Low level input voltage

nRST

Max 0.1 VDD

V

GPIO High level output voltage VOH

I

OH

= -12mA, VDD = 3.6V

I

OH

= -6mA, VDD = 1.8V

Min V

DD

– 0.4

V

GPIO Low level output voltage VOL

I

OL

= 16mA, VDD = 3.6V

I

OL

= 10mA, VDD = 1.8V

Max 0.4

V

Real-time oscillator frequency

32.768

kHz

Parameters

Value

Comments

Size

30.0 x 20.0 mm

Operating temperature range

-40°C to +85°C

-40°C to +85°C operational,
ATZB-S1-256-3-0-U

Operating temperature range

-40°C to +125°C

-40°C to +125°C operational,
ATZB-S1-256-3-0-UF

Pinout

Pin descriptions

Function

1

AVSS

Analog Ground

2

AVSS

Analog Ground

3.2.3 Module Interfaces Characteristics

Table 3-6. Module interfaces characteristics.

3.3 Physical/Environmental Characteristics and Outline

Table 3-7. Physical characteristics.

3.4 Pin Configuration

Table 3-8. ATZB-S1-256-3-0-U Pinout description

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

10

Pinout

Pin descriptions

Function

3

DEVDD

Digital Power input pin

4

DEVDD

Digital Power input pin

5

RSTN

RESET

6

PB0/SSN/PCINT0

SPI 7 PB2/MOSI/PDI/PCINT2

SPI/ ISP Prog

8

PB3/MISO/PDO/PCINT3

SPI/ ISP Prog

9

PB1/SCK/PCINT1

SPI/ ISP Prog

10

PE2/AINO

GPIO/AINO

11

PE3/AIN1/OC3A

GPIO/AIN1/PWM out

12

DVSS

Digital Ground

13

PD2/RXD1/INT2

UART

14

PD3/TXD1/INT3

UART

15

PD5/XCK1

USART

16

PD4/ICP1

TIMER counter input trigger

17

PD6/T1

TC

18

PG2/AMR

GPIO/TC

19

PB4/OC2A/PCINT4

PWM/PCINT4

20

PB6/OC1B/PCINT6

PWM/PCINT6

21

PB7/OC0A/OC1C/PCINT7

PWM/PCINT/GPIO

22

PE0:RXD0:PCINT8

GPIO/PCINT8/RXD0

23

PE1:TXD0

GPIO/TXD0

24

AREF

Adc ref

25

PF0/ADC0

ADC/ GPIO

26

PF1/ADC1

ADC/ GPIO

27

PF2/ADC2/DIG2

ADC/ GPIO

28

PF3/ADC3/DIG4

ADC/ GPIO

29

DVSS

Digital Ground

30

PF4/ADC4/TCK

JTAG

31

PF5/ADC5/TMS

JTAG

32

PF6/ADC6/TDO

JTAG

33

PF7/ADC7/TDI

JTAG

34

PG5/OC0B

pwm output timer

35

PE4/OC3B/INT4

Wakeup INT

36

PD0/SCL/INT0

TWI/INT/GPIO

37

PD1/SDA/INT1

TWI/INT/GPIO

38

CLKI

Ext CLKI/ ISP Programming

39

PE7/ICP3/INT7/CLKO

Clock out put

40

PD7/T0

TC

41

DVSS

Digital Ground

42

DVSS

Digital Ground

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

11

3.5 Mounting Information

The Figure below shows the PCB layout recommended for a ZigBit module. Neither via-holes nor wires are allowed on
the PCB upper layer in the area occupied by the module. As a critical requirement, RF_GND pins should be grounded
via several via-holes to be located right next to the pins thus minimizing inductance and preventing both mismatch and
losses.

Figure 3-1. ATZB-S1-256-3-0-U Dimensions

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

12

Figure 3-2. ATZB-S1-256-3-0-U Pinout

Figure 3-3. ATZB-S1-256-3-0-U Foot Print Dimensions

3.6 List of Approved Antennas

The ATZB-S1-256-3-0-U Module has been tested and approved by Certification body to use any of the antenna listed
below or similar antenna with lesser gain

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

13

Description

Manufacturer Partnumber

Antenna gain

2.4GHz Miniature Pigtail Antenna from RF
Solutions

ANT-24G-S21-P5FL

0dBi

2.4GHz 5dBi Rubber Antenna with pigtail cable
(Flying Lead) from Tekfun

M07-FL

5dBi

Profile feature

Green package

Average ramp-up rate (217°C to peak)

3°C/s max

Preheat temperature 175°C ±25°C

180s max

Temperature maintained above 217°C

60s to 150s

Time within 5°C of actual peak temperature

20s to 40s

Peak temperature range

260°C

Ramp-down rate

6°C/s max

Time within 25°C to peak temperature

8 minutes

3.7 Soldering Profile

The J-STD-020C-compliant soldering profile is recommended according to Table 3-9.

Table 3-9. Soldering Profile

Note: 1. The package is backward compatible with PB/Sn soldering profile.

4. Schematics

The following schematic drawings for the ATZB-S1-256-3-0-U are in the following order:

 Top level schematics
 Connector schematics
 ATmega256RFR2 schematics
 ATmega256RFR2 RF antenna schematics

(1)

.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

14

Data

Size

Structure Revision

2 bytes

MAC address

(1)

8 bytes

Board information overall

49 bytes

Board information – PCBA Name

30 bytes

Board information – PCBA Serial number

10 bytes

Board information – PCBA Atmel Part Number

8 bytes

Board information – PCBA Revision

1 byte

Resereved

3 bytes

Xtal Calibration Value

1 byte

Reserved

7 bytes

Reserved

4 bytes

CRC

1 byte

4.1 Handling Instructions

The ZigBit Modules are fixed with an EMI Shield to ensure compliance to Emission and Immunity rules. This shield is
galvanic and NOT air tight. So cleaning of the module with IPA / other similar agents is not advised. Humidity protection
coating (conformal) will cause deviated RF behavior and coating material being trapped inside EMI Shield. So this
should be avoided. For products requiring conformal coating, it is advised to suitably mask the ZigBit before applying
the coating to rest of the ZigBit carrier board. To protect ZigBit from humidity, the housing of the product should ensure
suitable Ingress Protection standards are complied with.

The UFL connector should never be exposed to Varnish / similar conformal coating material which will affect electrical
connection on the surfaces of connector.

4.2 General Recommendations

 Metal enclosure should not be used. Using low profile enclosure might also affect antenna tuning
 Placing high profile components next to antenna should be avoided
 Having holes/vias punched around the periphery of the board eliminates parasitic radiation from the board edges

also distorting antenna pattern

 ZigBit module should not be placed next to consumer electronics which might interfere with ZigBit's RF frequency

band

5. Persistence Memory

A dedicated memory space is allocated to store product specific information and called the Persistence Memory. The
organization of the persistence memory is as follows:

Table 5-1. Persistence Memory

In ATZB-S1-256-3-0-U persistence memory is stored in the User Signature Data (Page 1) of Atmega256RFR2 SoC with
starting address 0x0100. User Signature Data is isolated from the main flash and will not be cleared by Chip erase
Command.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

15

Special commands are available to erase and write data to user signature pages via the JTAG interface (see section
on "Programming via the JTAG Interface" in Atmega256RFR2 datasheet [1] for details). User signature rows can
be read from software in the same way as the device and JTAG identifiers (see section "Reading the Signature Row
from Software" of Atmega256RFR2 datasheet[1]).

Note: 1 The MAC address stored inside the MCU is a uniquely assigned ID for each ZigBit and owned by Atmel.
User of the ZigBit application can use this unique MAC ID to address the ZigBit in end-applications. The MAC ID
can be read from the ZigBit using the Performance Analyzer Application that can be downloaded from

www.atmel.com/wireless.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

16

Part number

Description

ATZB-S1-256-3-0-U

2.4GHz IEEE802.15.4/ZigBee OEM module based on ATmega256RFR2 SoC with UFL Antenna
connector, Single unit

ATZB-S1-256-3-0-UR

2.4GHz IEEE802.15.4/ZigBee OEM module based on ATmega256RFR2 SoC with UFL Antenna
connector, tape and reel

ATZB-S1-256-3-0-UF

2.4GHz IEEE802.15.4/ZigBee OEM module based on ATmega256RFR2 SoC with UFL Antenna
connector, Single unit, Extended temperature

ATZB-S1-256-3-0-UFR

2.4GHz IEEE802.15.4/ZigBee OEM module based on ATmega256RFR2 SoC with UFL Antenna
connector, tape and reel, Extended temperature

6. Ordering Information

Note: Tape and reel quantity: 200.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

17

7. Agency Certifications – ATZB-S1-256-3-0-U

7.1 United States (FCC)

This equipment complies with Part 15 of the FCC rules and regulations. To fulfill FCC Certification requirements, an
OEM manufacturer must comply with the following regulations:

1. The ATZB-S1-256-3-0-U modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID

is not visible when the module is installed inside another device, then the outside of the device into which the
module is installed must also display a label referring to the enclosed module. This exterior label can use
wording such as the following:

IMPORTANT: Contains FCC ID : VW4A092074. This equipment complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation (FCC

15.19).

The antenna used for this mobile transmitter must provide a separation distance of at least 20 cm from all persons and
must not be colocated or operating in conjunction with any other antenna or transmitter.

Installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF
exposure compliance. This device is approved as a mobile device with respect to RF exposure compliance, and may
only be marketed to OEM installers. Use in portable exposure conditions (FCC 2.1093) requires separate equipment
authorization.

IMPORTANT: Modifications not expressly approved by this company could void the user's authority to operate this
equipment (FCC section 15.21).

IMPORTANT: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense
(FCC section 15.105).

7.2 European Union (ETSI)

The ATZB-S1-256-3-0-U Module has been certified for use in European Union countries. If these modules are
incorporated into a product, the manufacturer must ensure compliance of the final product to the European harmonized
EMC and lowvoltage/safety standards. A Declaration of Conformity must be issued for each of these standards and
kept on file as described in Annex II of the R&TTE Directive.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

18

Furthermore, the manufacturer must maintain a copy of the modules' documentation and ensure the final product does
not exceed the specified power ratings, antenna specifications, and/or installation requirements as specified in the user
manual. If any of these specifications are exceeded in the final product, a submission must be made to a notified body
for compliance testing to all required standards.

IMPORTANT: The 'CE' marking must be affixed to a visible location on the OEM product. The CE mark shall
consist of the initials "CE" taking the following form:

The CE marking must have a height of at least 5mm except where this is not possible on account of the nature of the
apparatus.

The CE marking must be affixed visibly, legibly, and indelibly.
More detailed information about CE marking requirements you can find at "DIRECTIVE 1999/5/EC OF THE

EUROPEAN PARLIAMENT AND OF THE COUNCIL" on 9 March 1999 at section 12.

7.3 Industry Canada (IC) Compliance statements

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.

This equipment complies with radio frequency exposure limits set forth by Industry Canada for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm between the device and
the user or bystanders.

Cet équipement est conforme aux limites d'exposition aux radiofréquences définies par Industrie Canada pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre le
dispositif et l'utilisateur ou des tiers

CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

The OEM integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
This Module is labelled with its own IC ID. If the IC ID Certification Number is not visible while installed inside another
device, then the device should display the label on it referring the enclosed module. In that case, the final end product
must be labelled in a visible area with the following:
“Contains Transmitter Module IC:11019A-092074”
OR
“Contains IC: 11019A-092074”

Ce module est étiqueté avec son propre ID IC. Si le numéro de certification IC ID n'est pas visible lorsqu'il est installé à
l'intérieur d'un autre appareil, l'appareil doit afficher l'étiquette sur le module de référence ci-joint. Dans ce cas, le
produit final doit être étiqueté dans un endroit visible par le texte suivant:
“Contains Transmitter Module IC: 11019A-092074”
OR
“Contains IC: 11019A-092074”

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

19

8. Agency Certifications – ATZB-S1-256-3-0-UF

8.1 United States (FCC)

This equipment complies with Part 15 of the FCC rules and regulations. To fulfill FCC Certification requirements, an
OEM manufacturer must comply with the following regulations:

1. The ATZB-S1-256-3-0-UF modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID

is not visible when the module is installed inside another device, then the outside of the device into which the
module is installed must also display a label referring to the enclosed module. This exterior label can use
wording such as the following:

IMPORTANT: Contains FCC ID : VW4A092107. This equipment complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation (FCC

15.19).

The antenna used for this mobile transmitter must provide a separation distance of at least 20 cm from all persons and
must not be colocated or operating in conjunction with any other antenna or transmitter.

Installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF
exposure compliance. This device is approved as a mobile device with respect to RF exposure compliance, and may
only be marketed to OEM installers. Use in portable exposure conditions (FCC 2.1093) requires separate equipment
authorization.

IMPORTANT: Modifications not expressly approved by this company could void the user's authority to operate this
equipment (FCC section 15.21).

IMPORTANT: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense
(FCC section 15.105).

8.2 European Union (ETSI)

The ATZB-S1-256-3-0-UF Module has been certified for use in European Union countries. If these modules are
incorporated into a product, the manufacturer must ensure compliance of the final product to the European harmonized
EMC and lowvoltage/safety standards. A Declaration of Conformity must be issued for each of these standards and
kept on file as described in Annex II of the R&TTE Directive.

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

20

Furthermore, the manufacturer must maintain a copy of the modules' documentation and ensure the final product does
not exceed the specified power ratings, antenna specifications, and/or installation requirements as specified in the user
manual. If any of these specifications are exceeded in the final product, a submission must be made to a notified body
for compliance testing to all required standards.

IMPORTANT: The 'CE' marking must be affixed to a visible location on the OEM product. The CE mark shall
consist of the initials "CE" taking the following form:

The CE marking must have a height of at least 5mm except where this is not possible on account of the nature of the
apparatus.

The CE marking must be affixed visibly, legibly, and indelibly.
More detailed information about CE marking requirements you can find at "DIRECTIVE 1999/5/EC OF THE

EUROPEAN PARLIAMENT AND OF THE COUNCIL" on 9 March 1999 at section 12.

8.3 Industry Canada (IC) Compliance statements

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.

This equipment complies with radio frequency exposure limits set forth by Industry Canada for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20 cm between the device and
the user or bystanders.

Cet équipement est conforme aux limites d'exposition aux radiofréquences définies par Industrie Canada pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre le
dispositif et l'utilisateur ou des tiers

CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

The OEM integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
This Module is labelled with its own IC ID. If the IC ID Certification Number is not visible while installed inside another
device, then the device should display the label on it referring the enclosed module. In that case, the final end product
must be labelled in a visible area with the following:
“Contains Transmitter Module IC:11019A-092107”
OR
“Contains IC: 11019A-092107”

Ce module est étiqueté avec son propre ID IC. Si le numéro de certification IC ID n'est pas visible lorsqu'il est installé à
l'intérieur d'un autre appareil, l'appareil doit afficher l'étiquette sur le module de référence ci-joint. Dans ce cas, le
produit final doit être étiqueté dans un endroit visible par le texte suivant:
“Contains Transmitter Module IC: 11019A-092107”
OR
“Contains IC: 11019A-092107”

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

21

Doc. Rev.

Date

Comments

42199A

10/2013

Initial revision.

02/2014

Removed footnote for Table 3-8
Updated Title
Updated Table 3-7
Updated Section 6 Ordering information
Added Section 8 Agency Certication – ATZB-S1-256-3-0-UF

9. Revision History

ATZB-S1-256-3-0-U ZigBit 2.4GHz Single chip Wireless Module [DATASHEET]

42199AWIRELESS10/2013

Atmel Corporation

1600 Technology Drive
San Jose, CA 95110
USA

Tel: [phone]
Fax: [phone]

www.atmel.com

Atmel Asia Limited

Unit 01-5 & 16, 19F
BEA Tower, Millennium City 5
418 Kwun Tong Road
Kwun Tong, Kowloon
HONG KONG

Tel: [phone]
Fax: [phone]

Atmel Munich GmbH

Business Campus
Parkring 4
D-85748 Garching b. Munich
GERMANY

Tel: [phone]
Fax: [phone]

Atmel Japan G.K.

16F Shin-Osaki Kangyo Building
1-6-4 Osaki
Shinagawa-ku, Tokyo 141-0032
JAPAN

Tel: [phone]
Fax: [phone]

© 2013 Atmel Corporation. All rights reserved. / Rev.: 42199AWIRELESS10/2013

Atmel®, Atmel logo and combinations thereof, Enabling Unlimited Possibilities®, AVR®, ZigBit®, and others are registered trademarks or trademarks of Atmel
Corporation or its subsidiaries. Other terms and product names may be trademarks of others.

Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this
document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND CONDITIONS OF SALES LOCATED ON THE ATMEL WEBSITE, ATMEL ASSUMES
NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL ATMEL BE LIABLE FOR ANY DIRECT, INDIRECT,
CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS AND PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF ATMEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no
representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and products descriptions at any time
without notice. Atmel does not make any commitment to update the information contained herein. Unless specifically provided otherwise, Atmel products are not suitable for, and shall not be used in,
automotive applications. Atmel products are not intended, authorized, or warranted for use as components in applications intended to support or sustain life.
