MICROCHIP PIC18FXX2 DATA SHEET

PIC18FXX2
Data Sheet
High-Performance, Enhanced Flash
Microcontrollers with 10-Bit A/D
© 2006 Microchip Technology Inc. DS39564C
Note the following details of the code protection feature on Microchip devices:
Microchip products meet the specification contained in their particular Microchip Data Sheet.
Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the intended manner and under normal conditions.
There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data Sheets. Most likely, the person doing so is engaged in theft of intellectual property.
Microchip is willing to work with the customer who is concerned about the integrity of their code.
Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not mean that we are guaranteeing the product as “unbreakable.”
Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.
Information contained in this publication regarding device applications and the like is provided only for your convenience and may be superseded by updates. It is your responsibility to ensure that your application meets with your specifications. MICROCHIP MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL, STATUTORY OR OTHERWISE, RELATED TO THE INFORMATION, INCLUDING BUT NOT LIMITED TO ITS CONDITION, QUALITY, PERFORMANCE, MERCHANTABILITY OR FITNESS FOR PURPOSE. Microchip disclaims all liability arising from this information and its use. Use of Microchip devices in life support and/or safety applications is entirely at the buyer’s risk, and the buyer agrees to defend, indemnify and hold harmless Microchip from any and all damages, claims, suits, or expenses resulting from such use. No licenses are conveyed, implicitly or otherwise, under any Microchip intellectual property rights.
Trademarks
The Microchip name and logo, the Microchip logo, Accuron, dsPIC, K
EELOQ, microID, MPLAB, PIC, PICmicro, PICSTART,
PRO MATE, PowerSmart, rfPIC and SmartShunt are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
AmpLab, FilterLab, Migratable Memory, MXDEV, MXLAB, SEEVAL, SmartSensor and The Embedded Control Solutions Company are registered trademarks of Microchip Technology Incorporated in the U.S.A.
Analog-for-the-Digital Age, Application Maestro, CodeGuard, dsPICDEM, dsPICDEM.net, dsPICworks, ECAN, ECONOMONITOR, FanSense, FlexROM, fuzzyLAB, In-Circuit Serial Programming, ICSP, ICEPIC, Linear Active Thermistor, Mindi, MiWi, MPASM, MPLIB, MPLINK, PICkit, PICDEM, PICDEM.net, PICLAB, PICtail, PowerCal, PowerInfo, PowerMate, PowerTool, REAL ICE, rfLAB, rfPICDEM, Select Mode, Smart Serial, SmartTel, Total Endurance, UNI/O, WiperLock and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.
SQTP is a service mark of Microchip Technology Incorporated in the U.S.A.
All other trademarks mentioned herein are property of their respective companies.
© 2006, Microchip Technology Incorporated, Printed in the U.S.A., All Rights Reserved.
Printed on recycled paper.
Microchip received ISO/TS-16949:2002 certification for its worldwide headquarters, design and wafer fabrication facilities in Chandler and Tempe, Arizona, Gresham, Oregon and Mountain View, California. The Company’s quality system processes and procedures are for its PICmicro EEPROMs, microperipherals, nonvolatile memory and analog products. In addition, Microchip’s quality system for the design and manufacture of development systems is ISO 9001:2000 certified.
®
8-bit MCUs, KEEL
®
OQ
code hopping devices, Serial
DS39564C-page ii © 2006 Microchip Technology Inc.
PIC18FXX2

High Performance RISC CPU:

• C compiler optimized architecture/instruction set
- Source code compatible with the PIC16 and PIC17 instruction sets
• Linear program memory addressing to 32 Kbytes
Linear data memory addressing to 1.5 Kbytes
• Up to 10 MIPs operation:
- DC - 40 MHz osc./clock input
- 4 MHz - 10 MHz osc./clock input with PLL active
• 16-bit wide instructions, 8-bit wide data path
• Priority levels for interrupts
• 8 x 8 Single Cycle Hardware Multiplier

Peripheral Features:

• High current sink/source 25 mA/25 mA
• Three external interrupt pins
• Timer0 module: 8-bit/16-bit timer/counter with 8-bit programmable prescaler
• Timer1 module: 16-bit timer/counter
• Timer2 module: 8-bit timer/counter with 8-bit period register (time-base for PWM)
• Timer3 module: 16-bit timer/counter
• Secondary oscillator clock option - Timer1/Timer3
• Two Capture/Compare/PWM (CCP) modules. CCP pins that can be configured as:
- Capture input: capture is 16-bit,
max. resolution 6.25 ns (T
- Compare is 16-bit, max. resolution 100 ns (T
- PWM output: PWM resolution is 1- to 10-bit,
max. PWM freq. @: 8-bit resolution = 156 kHz
• Master Synchronous Serial Port (MSSP) module, Two modes of operation:
- 3-wire SPI™ (supports all 4 SPI modes)
2
-I
C™ Master and Slave mode
CY/16)
CY)
10-bit resolution = 39 kHz

Peripheral Features (Continued):

• Addressable USART module:
- Supports RS-485 and RS-232
• Parallel Slave Port (PSP) module

Analog Features:

• Compatible 10-bit Analog-to-Digital Converter module (A/D) with:
- Fast sampling rate
- Conversion available during SLEEP
-Linearity ≤ 1 LSb
• Programmable Low Voltage Detection (PLVD)
- Supports interrupt on-Low Voltage Detection
• Programmable Brown-out Reset (BOR)

Special Microcontroller Features:

• 100,000 erase/write cycle Enhanced FLASH program memory typical
• 1,000,000 erase/write cycle Data EEPROM memory
• FLASH/Data EEPROM Retention: > 40 years
• Self-reprogrammable under software control
• Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
• Watchdog Timer (WDT) with its own On-Chip RC Oscillator for reliable operation
• Programmable code protection
• Power saving SLEEP mode
• Selectable oscillator options including:
- 4X Phase Lock Loop (of primary oscillator)
- Secondary Oscillator (32 kHz) clock input
• Single supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins
• In-Circuit Debug (ICD) via two pins

CMOS Technology:

• Low power, high speed FLASH/EEPROM technology
• Fully static design
• Wide operating voltage range (2.0V to 5.5V)
• Industrial and Extended temperature ranges
• Low power cons14.333 p (TJ3ri2asircy oV)
© 2006 Microchip Technology Inc. DS39564C-page 1
PIC18FXX2

Pin Diagrams

PLCC
REF-
/VPP
RA4/T0CKI
RA5/AN4/SS
OSC2/CLKO/RA6
RC0/T1OSO/T1CKI
/LVDIN
RE0/RD
RE1/WR
RE2/CS
OSC1/CLKI
/AN5 /AN6 /AN7
V V
DD SS
NC
RA3/AN3/VREF+
RA2/AN2/V
RA1/AN1
RA0/AN0
MCLR
65432
7 8 9 10
PIC18F442
11 12
PIC18F452
13 14 15 16
181920212223242526
17
RD2/PSP2
RD1/PSP1
RD0/PSP0
RC3/SCK/SCL
RC2/CCP1
RC1/T1OSI/CCP2
*
RC6/TX/CK
RC5/SDO
RC4/SDI/SDA
RD3/PSP3
RD2/PSP2
RD1/PSP1
RD0/PSP0
NC
RB7/PGD
1
44
RC4/SDI/SDA
RD3/PSP3
RC3/SCK/SCL
RB6/PGC
RB5/PGM
42
43
RC5/SDO
RC2/CCP1
RC1/T1OSI/CCP2*NC
RB4
41
27
28
NC
RC6/TX/CK
NC
40 39
38 37 36
35 34 33 32 31 30 29
RB3/CCP2* RB2/INT2 RB1/INT1 RB0/INT0 V
DD
VSS RD7/PSP7 RD6/PSP6 RD5/PSP5 RD4/PSP4 RC7/RX/DT
TQFP
RC7/RX/DT
RD4/PSP4 RD5/PSP5 RD6/PSP6 RD7/PSP7
SS
V
VDD RB0/INT0 RB1/INT1 RB2/INT2
RB3/CCP2
* RB3 is the alternate pin for the CCP2 pin multiplexing.
*
4443424140
1 2 3 4
PIC18F442
5 6
PIC18F452
7 8 9 10
121314
11
NC
RB4
NC
15
16
RB6/PGC
RB5/PGM
38
39
37
1819202122
17
RA0/AN0
MCLR
RB7/PGD
/VPP
363435
RA1/AN1
33 32 31 30 29 28 27 26 25 24
23
RA2/AN2/V
RA3/AN3/VREF+
REF-
NC RC0/T1OSO/T1CKI OSC2/CLKO/RA6 OSC1/CLKI
SS
V VDD RE2/AN7/CS RE1/AN6/WR RE0/AN5/RD RA5/AN4/SS/LVDIN RA4/T0CKI
DS39564C-page 2 © 2006 Microchip Technology Inc.

Pin Diagrams (Cont.’d)

PIC18FXX2
MCLR/VPP
RA0/AN0 RA1/AN1
RA2/AN2/V
RA3/AN3/V
RA5/AN4/SS
OSC2/CLKO/RA6
RC0/T1OSO/T1CKI
RC1/T1OSI/CCP2
RC3/SCK/SCL
RA4/T0CKI
/LVDIN
RE0/RD
RE1/WR
RE2/CS
OSC1/CLKI
RC2/CCP1
RD0/PSP0 RD1/PSP1
REF-
REF+
/AN5 /AN6 /AN7
V VSS
DD
1 2 3 4 5 6 7 8 9 10 11 12 13 14
*
15 16 17 18 19 20
PIC18F442
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
RB7/PGD RB6/PGC RB5/PGM RB4 RB3/CCP2 RB2/INT2
RB1/INT1 RB0/INT0 V
DD
VSS RD7/PSP7 RD6/PSP6
RD5/PSP5 RD4/PSP4 RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA RD3/PSP3 RD2/PSP2
*
MCLR/VPP
RA2/AN2/V
RA3/AN3/V
RA4/T0CKI
RA5/AN4/SS
OSC1/CLKI
OSC2II
RA0/AN0 RA1/AN1
REF-
REF+
/LVDIN
V
1 2 3 4 5 6 7
SS
8 9
10 11
12 13 14
PIC18F242
28 27 26 25 24 23 22 21 20 19 18 17 16 15
© 2006 Microchip Technology Inc. DS39564C-page 3
PIC18FXX2

Table of Contents

1.0 Device Overview .......................................................................................................................................................................... 7
2.0 Oscillator Configurations ............................................................................................................................................................ 17
3.0 Reset .......................................................................................................................................................................................... 25
4.0 Memory Organization ................................................................................................................................................................. 35
5.0 FLASH Program Memory........................................................................................................................................................... 55
6.0 Data EEPROM Memory ............................................................................................................................................................. 65
7.0 8 X 8 Hardware Multiplier........................................................................................................................................................... 71
8.0 Interrupts .................................................................................................................................................................................... 73
9.0 I/O Ports ..................................................................................................................................................................................... 87
10.0 Timer0 Module ......................................................................................................................................................................... 103
11.0 Timer1 Module ......................................................................................................................................................................... 107
12.0 Timer2 Module ......................................................................................................................................................................... 111
13.0 Timer3 Module ......................................................................................................................................................................... 113
14.0 Capture/Compare/PWM (CCP) Modules ................................................................................................................................. 117
15.0 Master Synchronous Serial Port (MSSP) Module .................................................................................................................... 125
16.0 Addressable Universal Synchronous Asynchronous Receiver Transmitter (USART).............................................................. 165
17.0 Compatible 10-bit Analog-to-Digital Converter (A/D) Module................................................................................................... 181
18.0 Low Voltage Detect .................................................................................................................................................................. 189
19.0 Special Features of the CPU.................................................................................................................................................... 195
20.0 Instruction Set Summary .......................................................................................................................................................... 211
21.0 Development Support............................................................................................................................................................... 253
22.0 Electrical Characteristics .......................................................................................................................................................... 259
23.0 DC and AC Characteristics Graphs and Tables ....................................................................................................................... 289
24.0 Packaging Information.............................................................................................................................................................. 305
Appendix A: Revision History ............................................................................................................................................................ 313
Appendix B: Device Differences........................................................................................................................................................ 313
Appendix C: Conversion Considerations........................................................................................................................................... 314
Appendix D: Migration from Baseline to Enhanced Devices ............................................................................................................. 314
Appendix E: Migration from Mid-range to Enhanced Devices ........................................................................................................... 315
Appendix F: Migration from High-end to Enhanced Devices ............................................................................................................ 315
Index .................................................................................................................................................................................................. 317
On-Line Support................................................................................................................................................................................. 327
Reader Response .............................................................................................................................................................................. 328
PIC18FXX2 Product Identification System......................................................................................................................................... 329
DS39564C-page 4 © 2006 Microchip Technology Inc.
PIC18FXX2
TO OUR VALUED CUSTOMERS
It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your Microchip products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and enhanced as new volumes and updates are introduced.
If you have any questions or comments regarding this publication, please contact the Marketing Communications Department via E-mail at docerrors@microchip.com or fax the Reader Response Form in the back of this data sheet to (480) 792-4150. We welcome your feedback.

Most Current Data Sheet

To obtain the most up-to-date version of this data sheet, please register at our Worldwide Web site at:
http://www.microchip.com
You can determine the version of a data sheet by examining its literature number found on the bottom outside corner of any page. The last character of the literature number is the version number, (e.g., DS30000A is version A of document DS30000).

Errata

An errata sheet, describing minor operational differences from the data sheet and recommended workarounds, may exist for current devices. As device/documentation issues become known to us, we will publish an errata sheet. The errata will specify the revision of silicon and revision of document to which it applies.
To determine if an errata sheet exists for a particular device, please check with one of the following:
• Microchip’s Worldwide Web site; http://www.microchip.com
• Your local Microchip sales office (see last page) When contacting a sales office, please specify which device, revision of silicon and data sheet (include literature number) you are
using.

Customer Notification System

Register on our web site at www.microchip.com to receive the most current information on all of our products.
© 2006 Microchip Technology Inc. DS39564C-page 5
PIC18FXX2
NOTES:
DS39564C-page 6 © 2006 Microchip Technology Inc.
PIC18FXX2

1.0 DEVICE OVERVIEW

This document contains device specific information for the following devices:
•PIC18F242 •PIC18F442
•PIC18F252 •PIC18F452
These devices come in 28-pin and 40/44-pin packages. The 28-pin devices do not have a Parallel Slave Port (PSP) implemented and the number of Analog-to­Digital (A/D) converter input channels is reduced to 5. An overview of features is shown in Table 1-1.
The following two figures are device block diagrams sorted by pin count: 28-pin for Figure 1-1 and 40/44-pin for Figure 1-2. The 28-pin and 40/44-pin pinouts are listed in Table 1-2 and Table 1-3, respectively.

TABLE 1-1: DEVICE FEATURES

Features PIC18F242 PIC18F252 PIC18F442 PIC18F452
Operating Frequency DC - 40 MHz DC - 40 MHz DC - 40 MHz DC - 40 MHz
Program Memory (Bytes) 16K 32K 16K 32K
Program Memory (Instructions) 8192 16384 8192 16384
Data Memory (Bytes) 768 1536 768 1536
Data EEPROM Memory (Bytes) 256 256 256 256
Interrupt Sources 17 17 18 18
I/O Ports Ports A, B, C Ports A, B, C Ports A, B, C, D, E Ports A, B, C, D, E
Timers 4 4 4 4
Capture/Compare/PWM Modules 2 2 2 2
MSSP,
Serial Communications
Parallel Communications PSP PSP
10-bit Analog-to-Digital Module 5 input channels 5 input channels 8 input channels 8 input channels
RESETS (and Delays)
Programmable Low Voltage Detect
Programmable Brown-out Reset Yes Yes Yes Yes
Instruction Set 75 Instructions 75 Instructions 75 Instructions 75 Instructions
Packages
Addressable
USART
POR, BOR,
RESET Instruction,
Stack Full,
Stack Underflow
(PWRT, OST)
Yes Ye s Yes Ye s
28-pin DIP
28-pin SOIC
MSSP,
Addressable
USART
POR, BOR,
RESET Instruction,
Stack Full,
Stack Underflow
(PWRT, OST)
28-pin DIP
28-pin SOIC
MSSP,
Addressable
USART
POR, BOR,
RESET Instruction,
Stack Full,
Stack Underflow
(PWRT, OST)
40-pin DIP 44-pin PLCC 44-pin TQFP
MSSP,
Addressable
USART
POR, BOR,
RESET Instruction,
Stack Full,
Stack Underflow
(PWRT, OST)
40-pin DIP 44-pin PLCC 44-pin TQFP
© 2006 Microchip Technology Inc. DS39564C-page 7
PIC18FXX2

FIGURE 1-1: PIC18F2X2 BLOCK DIAGRAM

Data Bus<8>
Address Latch
Program Memory
(up to 2 Mbytes)
Data Latch
OSC2/CLKO OSC1/CLKI
T1OSCI T1OSCO
MCLR
VDD, VSS
Table Pointer
21
8
21
inc/dec logic
21
PCLATH
PCLATU
PCH
PCU
Program Counter
31 Level Stack
16
Table Latch
8
ROM Latch
8
8
PCL
4
Decode
BSR
Data Latch
Data RAM
Address Latch
12
Address<12>
12 4
FSR0 FSR1 FSR2
inc/dec
logic
(2)
Bank0, F
12
PORTA
PORTB
RA0/AN0 RA1/AN1 RA2/AN2/VREF­RA3/AN3/VREF+ RA4/T0CKI RA5/AN4/SS RA6
/LVDIN
RB0/INT0 RB1/INT1 RB2/INT2 RB3/CCP2
(1)
RB4 RB5/PGM RB6/PCG RB7/PGD
RC0/T1OSO/T1CKI RC1/T1OSI/CCP2 RC2/CCP1 RC3/SCK/SCL RC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT
(1)
Instruction
Decode &
Control
Timing
Generation
4X PLL
Precision
Voltage
Reference
Instruction Register
Power-up
Timer
Oscillator
Start-up Timer
Power-on
Reset
Watchdog
Timer
Brown-out
Reset
Low Voltage
Programming
In-Circuit
Debugger
BIT OP
3
8
8 x 8 Multiply
WREG
8
8
ALU<8>
8
PRODLPRODH
8
8
PORTC
8
Timer0 Timer1 Timer2
Master
CCP1
CCP2
Synchronous
Serial Port
Timer3
Addressable
USART
A/D Converter
Data EEPROM
Note 1: Optional multiplexing of CCP2 input/output with RB3 is enabled by selection of configuration bit.
2: The high order bits of the Direct Address for the RAM are from the BSR register (except for the MOVFF instruction). 3: Many of the general purpose I/O pins are multiplexed with one or more peripheral module functions. The multiplexing combinations
are device dependent.
DS39564C-page 8 © 2006 Microchip Technology Inc.

FIGURE 1-2: PIC18F4X2 BLOCK DIAGRAM

Table Pointer
Address Latch
Program Memory
(up to 2 Mbytes)
Data Latch
OSC2/CLKO OSC1/CLKI
T1OSCI T1OSCO
MCLR
VDD, VSS
21
8
21
16
inc/dec logic
Table Latch
Instruction
Decode &
Control
Timing
Generation
4X PLL
Precision
Voltage
Reference
21
8
PCLATU
PCLATH
PCH PCL
PCU Program Counter
31 Level Stack
ROM Latch
Instruction
Register
Power-up
Timer
Oscillator
Start-up Timer
Power-on
Reset
Watchdog
Timer
Brown-out
Reset
Low Voltage
Programming
In-Circuit
Debugger
8
8
address reach)
12 4
4
BSR
Decode
BIT OP
inc/dec
3
8
Data Bus<8>
Data Latch
Data RAM
(up to 4K
Address Latch
12
Address<12>
Bank0, F
FSR0 FSR1 FSR2
logic
PRODLPRODH
8 x 8 Multiply
WREG
8
8
ALU<8>
8
PIC18FXX2
PORTA
(2)
PORTB
12
PORTC
8
8
8
PORTD
PORTE
RA0/AN0 RA1/AN1 RA2/AN2/VREF- RA3/AN3/VREF+ RA4/T0CKI RA5/AN4/SS RA6
RB0/INT0 RB1/INT1 RB2/INT2 RB3/CCP2 RB4 RB5/PGM RB6/PCG RB7/PGD
RC0/T1OSO/T1CKI RC1/T1OSI/CCP2 RC2/CCP1 RC3/SCK/SCL RC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT
RD0/PSP0 RD1/PSP1 RD2/PSP2 RD3/PSP3 RD4/PSP4 RD5/PSP5 RD6/PSP6 RD7/PSP7
RE0/AN5/RD
RE1/AN6/WR
RE2/AN7/CS
/LVDIN
(1)
(1)
Timer0
CCP1
Note 1: Optional multiplexing of CCP2 input/output with RB3 is enabled by selection of configuration bit.
2: The high order bits of the Direct Address for the RAM are from the BSR register (except for the MOVFF instruction). 3: Many of the general purpose I/O pins are multiplexed with one or more peripheral module functions. The multiplexing combinations
are device dependent.
Timer1 Timer2
Master
CCP2
Synchronous
Serial Port
Timer3
Addressable
USART
Parallel Slave Port
A/D Converter
Data EEPROM
© 2006 Microchip Technology Inc. DS39564C-page 9
PIC18FXX2
TABLE 1-2: PIC18F2X2 PINOUT I/O DESCRIPTIONS
Pin Name
MCLR/VPP
MCLR
VPP
NC These pins should be left unconnected.
OSC1/CLKI
OSC1
CLKI
OSC2/CLKO/RA6
OSC2
CLKO
RA6
RA0/AN0
RA0 AN0
RA1/AN1
RA1 AN1
RA2/AN2/V
RA2 AN2 V
RA3/AN3/VREF+
RA3 AN3 V
RA4/T0CKI
RA4 T0CKI
RA5/AN4/SS
RA5 AN4 SS LVDI N
RA6 See the OSC2/CLKO/RA6 pin.
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
REF-
REF-
REF+
/LVDIN
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP SOIC
11
99
10 10
22
33
44
55
66
77
Pin
Type
Buffer
Type
I
I
I
I
O
O
I/O
I/O
I
I/O
I
I/O
I I
I/O
I I
I/OIST/OD
I/O
I I I
ST
ST
ST
CMOS
TTL
TTL
Analog
TTL
Analog
TTL Analog Analog
TTL Analog Analog
ST
TTL Analog
ST
Analog
DD)
Description
Master Clear (input) or high voltage ICSP programming enable pin.
Master Clear (Reset) input. This pin is an active low RESET to the device. High voltage ICSP programming enable pin.
Oscillator crystal or external clock input.
Oscillator crystal input or external clock source input. ST buffer when configured in RC mode, CMOS otherwise. External clock source input. Always associated with pin function OSC1. (See related OSC1/CLKI, OSC2/CLKO pins.)
Oscillator crystal or clock output.
Oscillator crystal output. Connects to crystal or resonator in Crystal Oscillator mode. In RC mode, OSC2 pin outputs CLKO which has 1/4 the frequency of OSC1, and denotes the instruction cycle rate. General Purpose I/O pin.
PORTA is a bi-directional I/O port.
Digital I/O. Analog input 0.
Digital I/O. Analog input 1.
Digital I/O. Analog input 2. A/D Reference Voltage (Low) input.
Digital I/O. Analog input 3. A/D Reference Voltage (High) input.
Digital I/O. Open drain when configured as output. Timer0 external clock input.
Digital I/O. Analog input 4. SPI Slave Select input. Low Voltage Detect Input.
DS39564C-page 10 © 2006 Microchip Technology Inc.
TABLE 1-2: PIC18F2X2 PINOUT I/O DESCRIPTIONS (CONTINUED)
PIC18FXX2
Pin Name
RB0/INT0
RB0 INT0
RB1/INT1
RB1 INT1
RB2/INT2
RB2 INT2
RB3/CCP2
RB3 CCP2
RB4 25 25 I/O TTL Digital I/O.
RB5/PGM
RB5 PGM
RB6/PGC
RB6 PGC
RB7/PGD
RB7 PGD
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP SOIC
21 21
22 22
23 23
24 24
26 26
27 27
28 28
Pin
Type
I/O
I
I/O
I
I/O
I
I/O I/O
I/O I/O
I/O I/O
I/O I/O
Buffer
Type
PORTB is a bi-directional I/O port. PORTB can be software programmed for internal weak pull-ups on all inputs.
TTL
ST
TTL
ST External Interrupt 1.
TTL
ST
TTL
ST
TTL
ST
TTL
ST
TTL
ST
DD)
Digital I/O. External Interrupt 0.
Digital I/O. External Interrupt 2.
Digital I/O. Capture2 input, Compare2 output, PWM2 output.
Interrupt-on-change pin.
Digital I/O. Interrupt-on-change pin. Low Voltage ICSP programming enable pin.
Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming clock pin.
Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming data pin.
Description
© 2006 Microchip Technology Inc. DS39564C-page 11
PIC18FXX2
TABLE 1-2: PIC18F2X2 PINOUT I/O DESCRIPTIONS (CONTINUED)
Pin Name
RC0/T1OSO/T1CKI
RC0 T1OSO T1CKI
RC1/T1OSI/CCP2
RC1 T1OSI CCP2
RC2/CCP1
RC2 CCP1
RC3/SCK/SCL
RC3 SCK SCL
RC4/SDI/SDA
RC4 SDI SDA
RC5/SDO
RC5 SDO
RC6/TX/CK
RC6 TX CK
RC7/RX/DT
RC7 RX DT
SS 8, 19 8, 19 P Ground reference for logic and I/O pins.
V
DD 20 20 P Positive supply for logic and I/O pins.
V
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP SOIC
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
Pin
Type
I/O
O
I
I/O
I
I/O
I/O I/O
I/O I/O I/O
I/O
I
I/O
I/O
O
I/O
O
I/O
I/O
I
I/O
Buffer
Type
CMOS
DD)
ST
ST
ST
ST
ST ST
ST ST ST
ST ST ST
ST
ST
ST
ST ST ST
Description
PORTC is a bi-directional I/O port.
Digital I/O. Timer1 oscillator output. Timer1/Timer3 external clock input.
Digital I/O. Timer1 oscillator input. Capture2 input, Compare2 output, PWM2 output.
Digital I/O. Capture1 input/Compare1 output/PWM1 output.
Digital I/O. Synchronous serial clock input/output for SPI mode. Synchronous serial clock input/output for I
Digital I/O. SPI Data In.
2
C Data I/O.
I
Digital I/O. SPI Data Out.
Digital I/O. USART Asynchronous Transmit. USART Synchronous Clock (see related RX/DT).
Digital I/O. USART Asynchronous Receive. USART Synchronous Data (see related TX/CK).
2
C mode
DS39564C-page 12 © 2006 Microchip Technology Inc.
TABLE 1-3: PIC18F4X2 PINOUT I/O DESCRIPTIONS
PIC18FXX2
Pin Name
/VPP
MCLR
MCLR
VPP
NC These pins should be left unconnected.
OSC1/CLKI
OSC1
CLKI
OSC2/CLKO/RA6
OSC2
CLKO
RA6
RA0/AN0
RA0 AN0
RA1/AN1
RA1 AN1
RA2/AN2/V
RA2 AN2 V
RA3/AN3/VREF+
RA3 AN3 V
RA4/T0CKI
RA4 T0CKI
RA5/AN4/SS
RA5 AN4 SS LVDI N
RA6 (See the OSC2/CLKO/RA6 pin.)
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
REF-
REF-
REF+
/LVDIN
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP PLCC TQFP
1218
13 14 30
14 15 31
2319
3420
4521
5622
6723
7824
Pin
Type
I
I
I
I
O
O
I/O
I/O
I
I/O
I
I/O
I I
I/O
I I
I/OIST/OD
I/O
I I I
DD)
Buffer
Typ e
ST
ST
ST
CMOS
TTL
TTL
Analog
TTL
Analog
TTL Analog Analog
TTL Analog Analog
ST
TTL Analog
ST
Analog
Description
Master Clear (input) or high voltage ICSP programming enable pin.
Master Clear (Reset) input. This pin is an active low RESET to the device. High voltage ICSP programming enable pin.
Oscillator crystal or external clock input.
Oscillator crystal input or external clock source input. ST buffer when configured in RC mode, CMOS otherwise. External clock source input. Always associated with pin function OSC1. (See related OSC1/CLKI, OSC2/CLKO pins.)
Oscillator crystal or clock output.
Oscillator crystal output. Connects to crystal or resonator in Crystal Oscillator mode. In RC mode, OSC2 pin outputs CLKO, which has 1/4 the frequency of OSC1 and denotes the instruction cycle rate. General Purpose I/O pin.
PORTA is a bi-directional I/O port.
Digital I/O. Analog input 0.
Digital I/O. Analog input 1.
Digital I/O. Analog input 2. A/D Reference Voltage (Low) input.
Digital I/O. Analog input 3. A/D Reference Voltage (High) input.
Digital I/O. Open drain when configured as output. Timer0 external clock input.
Digital I/O. Analog input 4. SPI Slave Select input. Low Voltage Detect Input.
© 2006 Microchip Technology Inc. DS39564C-page 13
PIC18FXX2
TABLE 1-3: PIC18F4X2 PINOUT I/O DESCRIPTIONS (CONTINUED)
Pin Name
RB0/INT0
RB0 INT0
RB1/INT1
RB1 INT1
RB2/INT2
RB2 INT2
RB3/CCP2
RB3 CCP2
RB4 37 41 14 I/O TTL Digital I/O. Interrupt-on-change pin.
RB5/PGM
RB5 PGM
RB6/PGC
RB6 PGC
RB7/PGD
RB7 PGD
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP PLCC TQFP
33 36 8
34 37 9
35 38 10
36 39 11
38 42 15
39 43 16
40 44 17
Type
DD)
Pin
I/O
I
I/O
I
I/O
I
I/O I/O
I/O I/O
I/O I/O
I/O I/O
Buffer
Typ e
PORTB is a bi-directional I/O port. PORTB can be software programmed for internal weak pull-ups on all inputs.
TTL
ST
TTL
ST External Interrupt 1.
TTL
ST
TTL
ST
TTL
ST
TTL
ST
TTL
ST
Digital I/O. External Interrupt 0.
Digital I/O. External Interrupt 2.
Digital I/O. Capture2 input, Compare2 output, PWM2 output.
Digital I/O. Interrupt-on-change pin. Low Voltage ICSP programming enable pin.
Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming clock pin.
Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming data pin.
Description
DS39564C-page 14 © 2006 Microchip Technology Inc.
TABLE 1-3: PIC18F4X2 PINOUT I/O DESCRIPTIONS (CONTINUED)
PIC18FXX2
Pin Name
RC0/T1OSO/T1CKI
RC0 T1OSO T1CKI
RC1/T1OSI/CCP2
RC1 T1OSI CCP2
RC2/CCP1
RC2 CCP1
RC3/SCK/SCL
RC3 SCK
SCL
RC4/SDI/SDA
RC4 SDI SDA
RC5/SDO
RC5 SDO
RC6/TX/CK
RC6 TX CK
RC7/RX/DT
RC7 RX DT
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP PLCC TQFP
15 16 32
16 18 35
17 19 36
18 20 37
23 25 42
24 26 43
25 27 44
26 29 1
Type
DD)
Pin
I/O
O
I
I/O
I
I/O
I/O I/O
I/O I/O
I/O
I/O
I
I/O
I/O
O
I/O
O
I/O
I/O
I
I/O
Buffer
Typ e
ST
ST
ST
CMOS
ST
ST ST
ST ST
ST
ST ST ST
ST
ST
ST
ST ST ST
Description
PORTC is a bi-directional I/O port.
Digital I/O. Timer1 oscillator output. Timer1/Timer3 external clock input.
Digital I/O. Timer1 oscillator input. Capture2 input, Compare2 output, PWM2 output.
Digital I/O. Capture1 input/Compare1 output/PWM1 output.
Digital I/O. Synchronous serial clock input/output for SPI mode. Synchronous serial clock input/output for
2
C mode.
I
Digital I/O. SPI Data In.
2
C Data I/O.
I
Digital I/O. SPI Data Out.
Digital I/O. USART Asynchronous Transmit. USART Synchronous Clock (see related RX/DT).
Digital I/O. USART Asynchronous Receive. USART Synchronous Data (see related TX/CK).
© 2006 Microchip Technology Inc. DS39564C-page 15
PIC18FXX2
TABLE 1-3: PIC18F4X2 PINOUT I/O DESCRIPTIONS (CONTINUED)
Pin Name
RD0/PSP0 19 21 38 I/O ST
RD1/PSP1 20 22 39 I/O ST
RD2/PSP2 21 23 40 I/O ST
RD3/PSP3 22 24 41 I/O ST
RD4/PSP4 27 30 2 I/O ST
RD5/PSP5 28 31 3 I/O ST
RD6/PSP6 29 32 4 I/O ST
RD7/PSP7 30 33 5 I/O ST
RE0/RD
RE1/WR
RE2/CS
V
V
Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output
/AN5 RE0 RD
AN5
/AN6 RE1 WR
AN6
/AN7 RE2 CS
AN7
SS 12, 31 13, 34 6, 29 P Ground reference for logic and I/O pins.
DD 11, 32 12, 35 7, 28 P Positive supply for logic and I/O pins.
ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power OD = Open Drain (no P diode to V
Pin Number
DIP PLCC TQFP
8 9 25 I/O
9 10 26 I/O
10 11 27 I/O
Type
DD)
Pin
Buffer
Typ e
TTL
TTL
TTL
TTL
TTL
TTL
TTL
TTL
ST
TTL
Analog
ST
TTL
Analog
ST
TTL
Analog
Description
PORTD is a bi-directional I/O port, or a Parallel Slave Port (PSP) for interfacing to a microprocessor port. These pins have TTL input buffers when PSP module is enabled.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
Digital I/O. Parallel Slave Port Data.
PORTE is a bi-directional I/O port.
Digital I/O. Read control for parallel slave port (see also WR Analog input 5.
Digital I/O. Write control for parallel slave port (see CS Analog input 6.
Digital I/O. Chip Select control for parallel slave port (see related RD Analog input 7.
and CS pins).
and RD pins).
and WR).
DS39564C-page 16 © 2006 Microchip Technology Inc.
PIC18FXX2

2.0 OSCILLATOR CONFIGURATIONS

2.1 Oscillator Types

The PIC18FXX2 can be operated in eight different Oscillator modes. The user can program three configu­ration bits (FOSC2, FOSC1, and FOSC0) to select one of these eight modes:
1. LP Low Power Crystal
2. XT Crystal/Resonator
3. HS High Speed Crystal/Resonator
4. HS + PLL High Speed Crystal/Resonator
with PLL enabled
5. RC External Resistor/Capacitor
6. RCIO External Resistor/Capacitor with
I/O pin enabled
7. EC External Clock
8. ECIO External Clock with I/O pin
enabled

2.2 Crystal Oscillator/Ceramic Resonators

In XT, LP, HS or HS+PLL Oscillator modes, a crystal or ceramic resonator is connected to the OSC1 and OSC2 pins to establish oscillation. Figure 2-1 shows the pin connections.
The PIC18FXX2 oscillator design requires the use of a parallel cut crystal.
Note: Use of a series cut crystal may give a fre-
quency out of the crystal manufacturers specifications.
FIGURE 2-1: CRYSTAL/CERAMIC
RESONATOR OPERATION (HS, XT OR LP CONFIGURATION)
(1)
C1
C2
(1)
XTAL
(2)
RS
OSC1
OSC2
RF
(3)
To
Internal Logic
SLEEP
PIC18FXXX
TABLE 2-1: CAPACITOR SELECTION FOR
CERAMIC RESONATORS
Ranges Tested:
Mode Freq C1 C2
XT 455 kHz
2.0 MHz
4.0 MHz
HS 8.0 MHz
16.0 MHz
68 - 100 pF
15 - 68 pF 15 - 68 pF
10 - 68 pF 10 - 22 pF
68 - 100 pF
15 - 68 pF 15 - 68 pF
10 - 68 pF 10 - 22 pF
These values are for design guidance only. See notes following this table.
Resonators Used:
455 kHz Panasonic EFO-A455K04B ± 0.3%
2.0 MHz Murata Erie CSA2.00MG ± 0.5%
4.0 MHz Murata Erie CSA4.00MG ± 0.5%
8.0 MHz Murata Erie CSA8.00MT ± 0.5%
16.0 MHz Murata Erie CSA16.00MX ± 0.5%
All resonators used did not have built-in capacitors.
Note 1: Higher capacitance increases the stability
of the oscillator, but also increases the start-up time.
2: When operating below 3V V
using certain ceramic resonators at any voltage, it may be necessary to use high-gain HS mode, try a lower frequency resonator, or switch to a crystal oscillator.
3: Since each resonator/crystal has its own
characteristics, the user should consult the resonator/crystal manufacturer for appro­priate values of external components, or verify oscillator performance.
DD, or when
Note 1: See Table 2-1 and Table 2-2 for
recommended values of C1 and C2.
2: A series resistor (R
AT strip cut crystals.
F varies with the Oscillator mode chosen.
3: R
© 2006 Microchip Technology Inc. DS39564C-page 17
S) may be required for
PIC18FXX2
TABLE 2-2: CAPACITOR SELECTION FOR
CRYSTAL OSCILLATOR
Ranges Tested:
Mode Freq C1 C2
LP 32.0 kHz 33 pF 33 pF
200 kHz 15 pF 15 pF
XT 200 kHz 22-68 pF 22-68 pF
1.0 MHz 15 pF 15 pF
4.0 MHz 15 pF 15 pF
HS 4.0 MHz 15 pF 15 pF
8.0 MHz 15-33 pF 15-33 pF
20.0 MHz 15-33 pF 15-33 pF
25.0 MHz 15-33 pF 15-33 pF
These values are for design guidance only. See notes following this table.
Crystals Used
32.0 kHz Epson C-001R32.768K-A ± 20 PPM
200 kHz STD XTL 200.000KHz ± 20 PPM
1.0 MHz ECS ECS-10-13-1 ± 50 PPM
4.0 MHz ECS ECS-40-20-1 ± 50 PPM
8.0 MHz Epson CA-301 8.000M-C ± 30 PPM
20.0 MHz Epson CA-301 20.000M-C ± 30 PPM
Note 1: Higher capacitance increases the stability
of the oscillator, but also increases the start-up time.
2: Rs may be required in HS mode, as well
as XT mode, to avoid overdriving crystals with low drive level specification.
3: Since each resonator/crystal has its own
characteristics, the user should consult the resonator/crystal manufacturer for appro­priate values of external components., or verify oscillator performance.
An external clock source may also be connected to the OSC1 pin in the HS, XT and LP modes, as shown in Figure 2-2.

2.3 RC Oscillator

For timing-insensitive applications, the “RC” and “RCIO” device options offer additional cost savings. The RC oscillator frequency is a function of the supply voltage, the resistor (R ues and the operating temperature. In addition to this, the oscillator frequency will vary from unit to unit due to normal process parameter variation. Furthermore, the difference in lead frame capacitance between package types will also affect the oscillation frequency, espe­cially for low C
EXT values. The user also needs to take
into account variation due to tolerance of external R and C components used. Figure 2-3 shows how the R/C combination is connected.
In the RC Oscillator mode, the oscillator frequency divided by 4 is available on the OSC2 pin. This signal may be used for test purposes or to synchronize other logic.
Note: If the oscillator frequency divided by 4 sig-
nal is not required in the application, it is recommended to use RCIO mode to save current.

FIGURE 2-3: RC OSCILLATOR MODE

VDD
REXT
CEXT
VSS
F
Recommended values:3 kΩ ≤ REXT 100 kΩ
The RCIO Oscillator mode functions like the RC mode, except that the OSC2 pin becomes an additional gen­eral purpose I/O pin. The I/O pin becomes bit 6 of PORTA (RA6).
EXT) and capacitor (CEXT) val-
OSC1
OSC2/CLKO
OSC/4
EXT > 20pF
C
Internal
Clock
PIC18FXXX
FIGURE 2-2: EXTERNAL CLOCK INPUT
OPERATION (HS, XT OR LP OSC CONFIGURATION)
Clock from Ext. System
Open
DS39564C-page 18 © 2006 Microchip Technology Inc.
OSC1
PIC18FXXX
OSC2
PIC18FXX2

2.4 External Clock Input

The EC and ECIO Oscillator modes require an external clock source to be connected to the OSC1 pin. The feedback device between OSC1 and OSC2 is turned off in these modes to save current. There is no oscilla­tor start-up time required after a Power-on Reset or after a recovery from SLEEP mode.
In the EC Oscillator mode, the oscillator frequency divided by 4 is available on the OSC2 pin. This signal may be used for test purposes or to synchronize other logic. Figure 2-4 shows the pin connections for the EC Oscillator mode.
FIGURE 2-4: EXTERNAL CLOCK INPUT
OPERATION (EC CONFIGURATION)
Clock from Ext. System
OSC/4
F
The ECIO Oscillator mode functions like the EC mode, except that the OSC2 pin becomes an additional gen­eral purpose I/O pin. The I/O pin becomes bit 6 of PORTA (RA6). Figure 2-5 shows the pin connections for the ECIO Oscillator mode.
OSC1
PIC18FXXX
OSC2
FIGURE 2-5: EXTERNAL CLOCK INPUT
OPERATION (ECIO CONFIGURATION)
Clock from Ext. System
RA6
OSC1
PIC18FXXX
I/O (OSC2)

2.5 HS/PLL

A Phase Locked Loop circuit is provided as a program­mable option for users that want to multiply the fre­quency of the incoming crystal oscillator signal by 4. For an input clock frequency of 10 MHz, the internal clock frequency will be multiplied to 40 MHz. This is useful for customers who are concerned with EMI due to high frequency crystals.
The PLL can only be enabled when the oscillator con­figuration bits are programmed for HS mode. If they are programmed for any other mode, the PLL is not enabled and the system clock will come directly from OSC1.
The PLL is one of the modes of the FOSC<2:0> config­uration bits. The Oscillator mode is specified during device programming.
A PLL lock timer is used to ensure that the PLL has locked before device execution starts. The PLL lock timer has a time-out that is called T
PLL.

FIGURE 2-6: PLL BLOCK DIAGRAM

(from Configuration
HS Osc
bit Register)
PLL Enable
OSC2
Phase
Comparator
IN
F
Crystal
Osc
FOUT
OSC1
Loop Filter
Divide by 4
VCO
SYSCLK
MUX
© 2006 Microchip Technology Inc. DS39564C-page 19
PIC18FXX2

2.6 Oscillator Switching Feature

The PIC18FXX2 devices include a feature that allows the system clock source to be switched from the main oscillator to an alternate low frequency clock source. For the PIC18FXX2 devices, this alternate clock source is the Timer1 oscillator. If a low frequency crystal (32 kHz, for example) has been attached to the Timer1 oscillator pins and the Timer1 oscillator has been enabled, the device can switch to a Low Power Execu-

FIGURE 2-7: DEVICE CLOCK SOURCES

PIC18FXXX
OSC2
OSC1
T1OSO
T1OSI
Main Oscillator
SLEEP
Timer1 Oscillator
T1OSCEN Enable Oscillator
tion mode. Figure 2-7 shows a block diagram of the system clock sources. The clock switching feature is enabled by programming the Oscillator Switching Enable (OSCSEN
) bit in Configuration Register1H to a ’0’. Clock switching is disabled in an erased device. See Section 11.0 for further details of the Timer1 oscil­lator. See Section 19.0 for Configuration Register details.
4 x PLL
TOSC
TT1P
TOSC/4
MUX
Clock
Source
TSCLK
Clock Source option for other modules
DS39564C-page 20 © 2006 Microchip Technology Inc.

2.6.1 SYSTEM CLOCK SWITCH BIT

The system clock source switching is performed under software control. The system clock switch bit, SCS (OSCCON<0>) controls the clock switching. When the SCS bit is ’0’, the system clock source comes from the main oscillator that is selected by the FOSC configura­tion bits in Configuration Register1H. When the SCS bit is set, the system clock source will come from the Timer1 oscillator. The SCS bit is cleared on all forms of RESET.
REGISTER 2-1: OSCCON REGISTER
U-0 U-0 U-0 U-0 U-0 U-0 U-0 R/W-1
—SCS
bit 7 bit 0
bit 7-1 Unimplemented: Read as '0' bit 0 SCS: System Clock Switch bit
OSCSEN configuration bit = ’0’ and T1OSCEN bit is set:
When
1 = Switch to Timer1 oscillator/clock pin 0 = Use primary oscillator/clock input pin
OSCSEN and T1OSCEN are in other states:
When bit is forced clear
PIC18FXX2
Note: The Timer1 oscillator must be enabled and
operating to switch the system clock source. The Timer1 oscillator is enabled by setting the T1OSCEN bit in the Timer1 control register (T1CON). If the Timer1 oscillator is not enabled, then any write to the SCS bit will be ignored (SCS bit forced cleared) and the main oscillator will continue to be the system clock source.
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 21
PIC18FXX2

2.6.2 OSCILLATOR TRANSITIONS

The PIC18FXX2 devices contain circuitry to prevent “glitches” when switching between oscillator sources. Essentially, the circuitry waits for eight rising edges of the clock source that the processor is switching to. This ensures that the new clock source is stable and that its pulse width will not be less than the shortest pulse width of the two clock sources.
A timing diagram indicating the transition from the main oscillator to the Timer1 oscillator is shown in Figure 2-8. The Timer1 oscillator is assumed to be run­ning all the time. After the SCS bit is set, the processor is frozen at the next occurring Q1 cycle. After eight syn­chronization cycles are counted from the Timer1 oscil­lator, operation resumes. No additional delays are required after the synchronization cycles.
FIGURE 2-8: TIMING DIAGRAM FOR TRANSITION FROM OSC1 TO TIMER1 OSCILLATOR
Q1
T1OSI
OSC1
Internal System Clock
SCS (OSCCON<0>)
Program Counter
Note 1: Delay on internal system clock is eight oscillator cycles for synchronization.
TOSC
Q1
TDLY
TT1P
21 34 5678
Tsc s
PC + 2PC
Q3Q2Q1Q4Q3Q2
Q4 Q1
Q2 Q3 Q4 Q1
PC + 4
The sequence of events that takes place when switch­ing from the Timer1 oscillator to the main oscillator will depend on the mode of the main oscillator. In addition to eight clock cycles of the main oscillator, additional delays may take place.
If the main oscillator is configured for an external crys­tal (HS, XT, LP), then the transition will take place after an oscillator start-up time (T
OST) has occurred. A timing
diagram, indicating the transition from the Timer1 oscil­lator to the main oscillator for HS, XT and LP modes, is shown in Figure 2-9.
FIGURE 2-9: TIMING FOR TRANSITION BETWEEN TIMER1 AND OSC1 (HS, XT, LP)
Q3 Q4
T1OSI
OSC1
OSC2
Internal System
Clock
SCS
(OSCCON<0>)
Program Counter
Note 1: TOST = 1024 TOSC (drawing not to scale).
PC PC + 2
Q1
TOST
TT1P
1 2 34 567 8
TSCS
TOSC
Q1 Q2 Q3 Q4 Q1 Q2
Q3
PC + 6
DS39564C-page 22 © 2006 Microchip Technology Inc.
PIC18FXX2
If the main oscillator is configured for HS-PLL mode, an oscillator start-up time (T time-out (T
PLL) will occur. The PLL time-out is typically
2 ms and allows the PLL to lock to the main oscillator frequency. A timing diagram indicating the transition from the Timer1 oscillator to the main oscillator for HS-PLL mode is shown in Figure 2-10.
FIGURE 2-10: TIMING FOR TRANSITION BETWEEN TIMER1 AND OSC1 (HS WITH PLL)
OST) plus an additional PLL
Q4 Q1
T1OSI
OSC1
TOST
OSC2
PLL Clock
Input
Internal System
Program Counter
Clock
(OSCCON<0>)
Note 1: TOST = 1024 TOSC (drawing not to scale).
SCS
PC PC + 2
TPLL
If the main oscillator is configured in the RC, RCIO, EC or ECIO modes, there is no oscillator start-up time-out. Operation will resume after eight cycles of the main oscillator have been counted. A timing diagram, indi­cating the transition from the Timer1 oscillator to the main oscillator for RC, RCIO, EC and ECIO modes, is shown in Figure 2-11.
TT1P
TOSC
1 2 3 4 56 78
TSCS
Q1 Q2 Q3 Q4 Q1 Q2
PC + 4
Q3
Q4
FIGURE 2-11: TIMING FOR TRANSITION BETWEEN TIMER1 AND OSC1 (RC, EC)
Q3 Q4
T1OSI
OSC1
OSC2
Internal System
Clock
SCS
(OSCCON<0>)
Program Counter
Note 1: RC Oscillator mode assumed.
PC PC + 2
Q1
TOSC
1
TT1P
23
45678
TSCS
© 2006 Microchip Technology Inc. DS39564C-page 23
Q1 Q2 Q3 Q4 Q1 Q2 Q3
PC + 4
Q4
PIC18FXX2

2.7 Effects of SLEEP Mode on the On-Chip Oscillator

When the device executes a SLEEP instruction, the on-chip clocks and oscillator are turned off and the device is held at the beginning of an instruction cycle (Q1 state). With the oscillator off, the OSC1 and OSC2 signals will stop oscillating. Since all the transistor
switching currents have been removed, SLEEP mode achieves the lowest current consumption of the device (only leakage currents). Enabling any on-chip feature that will operate during SLEEP will increase the current consumed during SLEEP. The user can wake from SLEEP through external RESET, Watchdog Timer Reset, or through an interrupt.

TABLE 2-3: OSC1 AND OSC2 PIN STATES IN SLEEP MODE

OSC Mode OSC1 Pin OSC2 Pin
RC Floating, external resistor
should pull high
RCIO Floating, external resistor
should pull high
ECIO Floating Configured as PORTA, bit 6
EC Floating At logic low
LP, XT, and HS Feedback inverter disabled, at
quiescent voltage level
Note: See Table 3-1, in the “Reset” section, for time-outs due to SLEEP and MCLR

2.8 Power-up Delays

Power up delays are controlled by two timers, so that no external RESET circuitry is required for most appli­cations. The delays ensure that the device is kept in RESET, until the device power supply and clock are stable. For additional information on RESET operation, see Section 3.0.
The first timer is the Power-up Timer (PWRT), which optionally provides a fixed delay of 72 ms (nominal) on power-up only (POR and BOR). The second timer is the Oscillator Start-up Timer (OST), intended to keep the chip in RESET until the crystal oscillator is stable.
With the PLL enabled (HS/PLL Oscillator mode), the time-out sequence following a Power-on Reset is differ­ent from other Oscillator modes. The time-out sequence is as follows: First, the PWRT time-out is invoked after a POR time delay has expired. Then, the Oscillator Start-up Timer (OST) is invoked. However, this is still not a sufficient amount of time to allow the PLL to lock at high frequencies. The PWRT timer is used to provide an additional fixed 2 ms (nominal) time-out to allow the PLL ample time to lock to the incoming clock frequency.
At logic low
Configured as PORTA, bit 6
Feedback inverter disabled, at
quiescent voltage level
Reset.
DS39564C-page 24 © 2006 Microchip Technology Inc.
PIC18FXX2

3.0 RESET

Most registers are not affected by a WDT wake-up, since this is viewed as the resumption of normal oper-
The PIC18FXXX differentiates between various kinds of RESET:
a) Power-on Reset (POR) b) MCLR
Reset during normal operation c) MCLR Reset during SLEEP d) Watchdog Timer (WDT) Reset (during normal
operation) e) Programmable Brown-out Reset (BOR) f) RESET Instruction g) Stack Full Reset h) Stack Underflow Reset
Most registers are unaffected by a RESET. Their status
ation. Status bits from the RCON register, RI, TO, PD,
and BOR, are set or cleared differently in different
POR RESET situations, as indicated in Table 3-2. These bits are used in software to determine the nature of the RESET. See Table 3-3 for a full description of the RESET states of all registers.
A simplified block diagram of the On-Chip Reset Circuit is shown in Figure 3-1.
The Enhanced MCU devices have a MCLR in the MCLR
Reset path. The filter will detect and
ignore small pulses.
The MCLR
pin is not driven low by any internal
RESETS, including the WDT.
is unknown on POR and unchanged by all other RESETS. The other registers are forced to a “RESET state” on Power-on Reset, MCLR out Reset, MCLR
Reset during SLEEP and by the
, WDT Reset, Brown-
RESET instruction.

FIGURE 3-1: SIMPLIFIED BLOCK DIAGRAM OF ON-CHIP RESET CIRCUIT

RESET
Instruction
Stack
Pointer
Stack Full/Underflow Reset
noise filter
MCLR
VDD
OSC1
V
Brown-out
OST/PWRT
On-chip
RC OSC
External Reset
WDT
Module
DD Rise
Detect
Reset
OST
PWRT
(1)
SLEEP
WDT Time-out
Reset
Power-on Reset
BOREN
10-bit Ripple Counter
10-bit Ripple Counter
Enable PWRT
Enable OST
S
Chip_Reset
R
(2)
Q
Note 1: This is a separate oscillator from the RC oscillator of the CLKI pin.
2: See Table 3-1 for time-out situations.
© 2006 Microchip Technology Inc. DS39564C-page 25
PIC18FXX2

3.1 Power-On Reset (POR)

A Power-on Reset pulse is generated on-chip when
DD rise is detected. To take advantage of the POR cir-
V cuitry, just tie the MCLR tor) to V
DD. This will eliminate external RC components
pin directly (or through a resis-
usually needed to create a Power-on Reset delay. A minimum rise rate for V
DD is specified
(parameter D004). For a slow rise time, see Figure 3-2.
When the device starts normal operation (i.e., exits the RESET condition), device operating parameters (volt­age, frequency, temperature, etc.) must be met to ensure operation. If these conditions are not met, the device must be held in RESET until the operating conditions are met.
FIGURE 3-2: EXTERNAL POWER-ON
RESET CIRCUIT (FOR SLOW V
DD
V
D
R
C
Note 1: External Power-on Reset circuit is required
only if the V The diode D helps discharge the capacitor quickly when V
2: R < 40 kΩ is recommended to make sure that
the voltage drop across R does not violate the device’s electrical specification.
3: R1 = 100Ω to 1 kΩ will limit any current flow-
ing into MCLR the event of MCLR/ Electrostatic Discharge (ESD) or Electrical Overstress (EOS).
DD power-up slope is too slow.
DD POWE R-U P)
R1
MCLR
PIC18FXXX
DD powers down.
from external capacitor C, in
VPP pin breakdown due to

3.2 Power-up Timer (PWRT)

The Power-up Timer provides a fixed nominal time-out (parameter 33) only on power-up from the POR. The Power-up Timer operates on an internal RC oscillator. The chip is kept in RESET as long as the PWRT is active. The PWRT’s time delay allows V acceptable level. A configuration bit is provided to enable/disable the PWRT.
The power-up time delay will vary from chip-to-chip due
DD, temperature and process variation. See DC
to V parameter D033 for details.
DD to rise to an

3.3 Oscillator Start-up Timer (OST)

The Oscillator Start-up Timer (OST) provides a 1024 oscillator cycle (from OSC1 input) delay after the PWRT delay is over (parameter 32). This ensures that the crystal oscillator or resonator has started and stabilized.
The OST time-out is invoked only for XT, LP and HS modes and only on Power-on Reset or wake-up from SLEEP.

3.4 PLL Lock Time-out

With the PLL enabled, the time-out sequence following a Power-on Reset is different from other Oscillator modes. A portion of the Power-up Timer is used to pro­vide a fixed time-out that is sufficient for the PLL to lock to the main oscillator frequency. This PLL lock time-out
PLL) is typically 2 ms and follows the oscillator
(T start-up time-out (OST).

3.5 Brown-out Reset (BOR)

A configuration bit, BOREN, can disable (if clear/ programmed), or enable (if set) the Brown-out Reset circuitry. If V
DD falls below parameter D005 for greater
than parameter 35, the brown-out situation will reset the chip. A RESET may not occur if VDD falls below parameter D005 for less than parameter 35. The chip will remain in Brown-out Reset until VDD rises above
DD. If the Power-up Timer is enabled, it will be
BV invoked after V
DD rises above BVDD; it then will keep
the chip in RESET for an additional time delay (parameter 33). If VDD drops below BVDD while the Power-up Timer is running, the chip will go back into a Brown-out Reset and the Power-up Timer will be initial­ized. Once V
DD rises above BVDD, the Power-up Timer
will execute the additional time delay.

3.6 Time-out Sequence

On power-up, the time-out sequence is as follows: First, PWRT time-out is invoked after the POR time delay has expired. Then, OST is activated. The total time-out will vary based on oscillator configuration and the status of the PWRT. For example, in RC mode with the PWRT disabled, there will be no time-out at all. Figure 3-3, Figure 3-4, Figure 3-5, Figure 3-6 and Figure 3-7 depict time-out sequences on power-up.
Since the time-outs occur from the POR pulse, if MCLR is kept low long enough, the time-outs will expire. Bringing MCLR (Figure 3-5). This is useful for testing purposes or to synchronize more than one PIC18FXXX device operat­ing in parallel.
Table 3-2 shows the RESET conditions for some Special Function Registers, while Table 3-3 shows the RESET conditions for all the registers.
high will begin execution immediately
DS39564C-page 26 © 2006 Microchip Technology Inc.

TABLE 3-1: TIME-OUT IN VARIOUS SITUATIONS

PIC18FXX2
Oscillator
Configuration
HS with PLL enabled
HS, XT, LP 72 ms + 1024 TOSC 1024 TOSC 72 ms
EC 72 ms 72 ms
External RC 72 ms 72 ms
Note 1: 2 ms is the nominal time required for the 4x PLL to lock.
2: 72 ms is the nominal power-up timer delay, if implemented.
(1)
PWRTE = 0 PWRTE = 1
72 ms + 1024 TOSC
Power-up
+ 2ms
(2)
1024 TOSC
72 ms
+ 2 ms
REGISTER 3-1: RCON REGISTER BITS AND POSITIONS
R/W-0 U-0 U-0 R/W-1 R-1 R-1 R/W-0 R/W-0
IPEN —RITO PD POR BOR
bit 7 bit 0
Note 1: Refer to Section 4.14 (page 53) for bit definitions.
Wake-up from
Brown-out
(2)
+ 1024 TOSC
+ 2 ms
(2)
+ 1024 TOSC 1024 TOSC
(2)
(2)
SLEEP or
Oscillator Switch
1024 T
OSC + 2 ms
TABLE 3-2: STATUS BITS, THEIR SIGNIFICANCE AND THE INITIALIZATION CONDITION FOR
RCON REGISTER
Condition
Power-on Reset 0000h 0--1 1100 1 1 1 0 0 u u
MCLR Reset during normal operation
Software Reset during normal operation
Stack Full Reset during normal operation
Stack Underflow Reset during normal operation
MCLR
Reset during SLEEP 0000h 0--u 10uu u 1 0 u u u u
WDT Reset 0000h 0--u 01uu 1 0 1 u u u u
WDT Wake-up PC + 2 u--u 00uu u 0 0 u u u u
Brown-out Reset 0000h 0--1 11u0 1 1 1 1 0 u u
Interrupt wake-up from SLEEP PC + 2 Legend: u = unchanged, x = unknown, - = unimplemented bit, read as '0' Note 1: When the wake-up is due to an interrupt and the GIEH or GIEL bits are set, the PC is loaded with the
interrupt vector (0x000008h or 0x000018h).
Program
Counter
0000h 0--u uuuu u u u u u u u
0000h 0--0 uuuu 0 u u u u u u
0000h 0--u uu11 u u u u u u 1
0000h 0--u uu11 u u u u u 1 u
(1)
RCON
Register
u--u 00uu u 1 0 u u u u
TO PD POR BOR STKFUL STKUNF
RI
© 2006 Microchip Technology Inc. DS39564C-page 27
PIC18FXX2
TABLE 3-3: INITIALIZATION CONDITIONS FOR ALL REGISTERS
MCLR
Resets
Register Applicable Devices
Power-on Reset, Brown-out Reset
TOSU 242 442 252 452 ---0 0000 ---0 0000 ---0 uuuu
TOSH 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
TOSL 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
STKPTR 242 442 252 452 00-0 0000 uu-0 0000 uu-u uuuu
PCLATU 242 442 252 452 ---0 0000 ---0 0000 ---u uuuu
PCLATH 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
PCL 242 442 252 452 0000 0000 0000 0000 PC + 2
TBLPTRU 242 442 252 452 --00 0000 --00 0000 --uu uuuu
TBLPTRH 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
TBLPTRL 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
TABLAT 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
PRODH 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
PRODL 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
INTCON 242 442 252 452 0000 000x 0000 000u uuuu uuuu
INTCON2 242 442 252 452 1111 -1-1 1111 -1-1 uuuu -u-u
INTCON3 242 442 252 452 11-0 0-00 11-0 0-00 uu-u u-uu
INDF0 242 442 252 452 N/A N/A N/A
POSTINC0 242 442 252 452 N/A N/A N/A
POSTDEC0 242 442 252 452 N/A N/A N/A
PREINC0 242 442 252 452 N/A N/A N/A
PLUSW0 242 442 252 452 N/A N/A N/A
FSR0H 242 442 252 452 ---- xxxx ---- uuuu ---- uuuu
FSR0L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
WREG 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
INDF1 242 442 252 452 N/A N/A N/A
POSTINC1 242 442 252 452 N/A N/A N/A
POSTDEC1 242 442 252 452 N/A N/A N/A
PREINC1 242 442 252 452 N/A N/A N/A
PLUSW1 242 442 252 452 N/A N/A N/A
Legend: u = unchanged, x = unknown, - = unimplemented bit, read as '0', q = value depends on condition.
Shaded cells indicate conditions do not apply for the designated device.
Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).
2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt
vector (0008h or 0018h).
3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are
updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.
4: See Table 3-2 for RESET value for specific condition. 5: Bit 6 of PORTA, LATA, and TRISA are enabled in ECIO and RCIO Oscillator modes only. In all other
Oscillator modes, they are disabled and read ’0’.
6: Bit 6 of PORTA, LATA and TRISA are not available on all devices. When unimplemented, they are read ’0’.
WDT Reset
RESET Instruction
Stack Resets
Wake-up via WDT
or Interrupt
(3)
(3)
(3)
(3)
(2)
(1)
(1)
(1)
DS39564C-page 28 © 2006 Microchip Technology Inc.
PIC18FXX2
TABLE 3-3: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)
MCLR
Resets
Register Applicable Devices
FSR1H 242 442 252 452 ---- xxxx ---- uuuu ---- uuuu
FSR1L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
BSR 242 442 252 452 ---- 0000 ---- 0000 ---- uuuu
INDF2 242 442 252 452 N/A N/A N/A
POSTINC2 242 442 252 452 N/A N/A N/A
POSTDEC2 242 442 252 452 N/A N/A N/A
PREINC2 242 442 252 452 N/A N/A N/A
PLUSW2 242 442 252 452 N/A N/A N/A
FSR2H 242 442 252 452 ---- xxxx ---- uuuu ---- uuuu
FSR2L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
STATUS 242 442 252 452 ---x xxxx ---u uuuu ---u uuuu
TMR0H 242 442 252 452 0000 0000 uuuu uuuu uuuu uuuu
TMR0L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
T0CON 242 442 252 452 1111 1111 1111 1111 uuuu uuuu
OSCCON 242 442 252 452 ---- ---0 ---- ---0 ---- ---u
LVDCON 242 442 252 452 --00 0101 --00 0101 --uu uuuu
WDTCON 242 442 252 452 ---- ---0 ---- ---0 ---- ---u
(4)
RCON
TMR1H 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
TMR1L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
T1CON 242 442 252 452 0-00 0000 u-uu uuuu u-uu uuuu
TMR2 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
PR2 242 442 252 452 1111 1111 1111 1111 1111 1111
T2CON 242 442 252 452 -000 0000 -000 0000 -uuu uuuu
SSPBUF 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
SSPADD 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
SSPSTAT 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
SSPCON1 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
SSPCON2 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
Legend: u = unchanged, x = unknown, - = unimplemented bit, read as '0', q = value depends on condition.
Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).
2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt
3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are
4: See Table 3-2 for RESET value for specific condition. 5: Bit 6 of PORTA, LATA, and TRISA are enabled in ECIO and RCIO Oscillator modes only. In all other
6: Bit 6 of PORTA, LATA and TRISA are not available on all devices. When unimplemented, they are read ’0’.
242 442 252 452 0--q 11qq 0--q qquu u--u qquu
Shaded cells indicate conditions do not apply for the designated device.
vector (0008h or 0018h).
updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.
Oscillator modes, they are disabled and read ’0’.
Power-on Reset,
Brown-out Reset
WDT Reset
RESET Instruction
Stack Resets
Wake-up via WDT
or Interrupt
© 2006 Microchip Technology Inc. DS39564C-page 29
PIC18FXX2
TABLE 3-3: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)
MCLR
Resets
Register Applicable Devices
ADRESH 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
ADRESL 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
ADCON0 242 442 252 452 0000 00-0 0000 00-0 uuuu uu-u
ADCON1 242 442 252 452 00-- 0000 00-- 0000 uu-- uuuu
CCPR1H 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
CCPR1L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
CCP1CON 242 442 252 452 --00 0000 --00 0000 --uu uuuu
CCPR2H 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
CCPR2L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
CCP2CON 242 442 252 452 --00 0000 --00 0000 --uu uuuu
TMR3H 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
TMR3L 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
T3CON 242 442 252 452 0000 0000 uuuu uuuu uuuu uuuu
SPBRG 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
RCREG 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
TXREG 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
TXSTA 242 442 252 452 0000 -010 0000 -010 uuuu -uuu
RCSTA 242 442 252 452 0000 000x 0000 000x uuuu uuuu
EEADR 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
EEDATA 242 442 252 452 0000 0000 0000 0000 uuuu uuuu
EECON1 242 442 252 452 xx-0 x000 uu-0 u000 uu-0 u000
EECON2 242 442 252 452 ---- ---- ---- ---- ---- ----
Legend: u = unchanged, x = unknown, - = unimplemented bit, read as '0', q = value depends on condition.
Shaded cells indicate conditions do not apply for the designated device.
Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).
2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt
vector (0008h or 0018h).
3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are
updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.
4: See Table 3-2 for RESET value for specific condition. 5: Bit 6 of PORTA, LATA, and TRISA are enabled in ECIO and RCIO Oscillator modes only. In all other
Oscillator modes, they are disabled and read ’0’.
6: Bit 6 of PORTA, LATA and TRISA are not available on all devices. When unimplemented, they are read ’0’.
Power-on Reset, Brown-out Reset
WDT Reset
RESET Instruction
Stack Resets
Wake-up via WDT
or Interrupt
DS39564C-page 30 © 2006 Microchip Technology Inc.
PIC18FXX2
TABLE 3-3: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)
MCLR
Resets
Register Applicable Devices
Power-on Reset,
Brown-out Reset
IPR2 242 442 252 452 ---1 1111 ---1 1111 ---u uuuu
PIR2 242 442 252 452 ---0 0000 ---0 0000 ---u uuuu
PIE2 242 442 252 452 ---0 0000 ---0 0000 ---u uuuu
IPR1
PIR1
PIE1
242 442 252 452 1111 1111 1111 1111 uuuu uuuu
242 442 252 452 -111 1111 -111 1111 -uuu uuuu
242 442 252 452 0000 0000 0000 0000 uuuu uuuu
242 442 252 452 -000 0000 -000 0000 -uuu uuuu
242 442 252 452 0000 0000 0000 0000 uuuu uuuu
242 442 252 452 -000 0000 -000 0000 -uuu uuuu
TRISE 242 442 252 452 0000 -111 0000 -111 uuuu -uuu
TRISD
242 442 252 452 1111 1111 1111 1111 uuuu uuuu
TRISC 242 442 252 452 1111 1111 1111 1111 uuuu uuuu
TRISB 242 442 252 452 1111 1111 1111 1111 uuuu uuuu
TRISA
(5,6)
242 442 252 452 -111 1111
(5)
LATE 242 442 252 452 ---- -xxx ---- -uuu ---- -uuu
LATD 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
LATC 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
LATB 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
LATA
(5,6)
242 442 252 452 -xxx xxxx
(5)
PORTE 242 442 252 452 ---- -000 ---- -000 ---- -uuu
PORTD 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
PORTC 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
PORTB 242 442 252 452 xxxx xxxx uuuu uuuu uuuu uuuu
PORTA
(5,6)
242 442 252 452 -x0x 0000
(5)
Legend: u = unchanged, x = unknown, - = unimplemented bit, read as '0', q = value depends on condition.
Shaded cells indicate conditions do not apply for the designated device.
Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).
2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt
vector (0008h or 0018h).
3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are
updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.
4: See Table 3-2 for RESET value for specific condition. 5: Bit 6 of PORTA, LATA, and TRISA are enabled in ECIO and RCIO Oscillator modes only. In all other
Oscillator modes, they are disabled and read ’0’.
6: Bit 6 of PORTA, LATA and TRISA are not available on all devices. When unimplemented, they are read ’0’.
WDT Reset
RESET Instruction
Stack Resets
-111 1111
-uuu uuuu
-u0u 0000
(5)
(5)
(5)
Wake-up via WDT
or Interrupt
-uuu uuuu
-uuu uuuu
-uuu uuuu
(1)
(1)
(1)
(5)
(5)
(5)
© 2006 Microchip Technology Inc. DS39564C-page 31
PIC18FXX2

FIGURE 3-3: TIME-OUT SEQUENCE ON POWER-UP (MCLR TIED TO VDD)

VDD
MCLR
INTERNAL POR
TPWRT
PWRT TIME-OUT
OST TIME-OUT
INTERNAL RESET
TOST
FIGURE 3-4: TIME-OUT SEQUENCE ON POWER-UP (MCLR
VDD
MCLR
INTERNAL POR
PWRT TIME-OUT
OST TIME-OUT
INTERNAL RESET
TPWRT
NOT TIED TO VDD): CASE 1
TOST
FIGURE 3-5: TIME-OUT SEQUENCE ON POWER-UP (MCLR
VDD
MCLR
INTERNAL POR
TPWRT
PWRT TIME-OUT
OST TIME-OUT
INTERNAL RESET
DS39564C-page 32 © 2006 Microchip Technology Inc.
NOT TIED TO VDD): CASE 2
TOST

FIGURE 3-6: SLOW RISE TIME (MCLR TIED TO VDD)

5V
VDD
MCLR
INTERNAL POR
0V
PWRT
T
1V
PIC18FXX2
PWRT TIME-OUT
OST TIME-OUT
INTERNAL RESET
TOST
FIGURE 3-7: TIME-OUT SEQUENCE ON POR W/ PLL ENABLED (MCLR
VDD
MCLR
IINTERNAL POR
TPWRT
PWRT TIME-OUT
OST TIME-OUT
PLL TIME-OUT
TOST
TPLL
TIED TO VDD)
INTERNAL RESET
Note: TOST = 1024 clock cycles.
T
PLL 2 ms max. First three stages of the PWRT timer.
© 2006 Microchip Technology Inc. DS39564C-page 33
PIC18FXX2
NOTES:
DS39564C-page 34 © 2006 Microchip Technology Inc.

4.0 MEMORY ORGANIZATION

There are three memory blocks in Enhanced MCU devices. These memory blocks are:
• Program Memory
• Data RAM
• Data EEPROM
Data and program memory use separate busses, which allows for concurrent access of these blocks.
Additional detailed information for FLASH program memory and Data EEPROM is provided in Section 5.0 and Section 6.0, respectively.

4.1 Program Memory Organization

A 21-bit program counter is capable of addressing the 2-Mbyte program memory space. Accessing a location between the physically implemented memory and the 2-Mbyte address will cause a read of all ’0’s (a NOP instruction).
The PIC18F252 and PIC18F452 each have 32 Kbytes of FLASH memory, while the PIC18F242 and PIC18F442 have 16 Kbytes of FLASH. This means that PIC18FX52 devices can store up to 16K of single word instructions, and PIC18FX42 devices can store up to 8K of single word instructions.
The RESET vector address is at 0000h and the interrupt vector addresses are at 0008h and 0018h.
Figure 4-1 shows the Program Memory Map for PIC18F242/442 devices and Figure 4-2 shows the Program Memory Map for PIC18F252/452 devices.
PIC18FXX2
© 2006 Microchip Technology Inc. DS39564C-page 35
PIC18FXX2
FIGURE 4-1: PROGRAM MEMORY MAP
AND STACK FOR PIC18F442/242
PC<20:0>
CALL,RCALL,RETURN RETFIE,RETLW
Stack Level 1
Stack Level 31
RESET Vector
High Priority Interrupt Vector
Low Priority Interrupt Vector
On-Chip
Program Memory
Read '0'
21
0000h
0008h
0018h
3FFFh 4000h
User Memory Space
FIGURE 4-2: PROGRAM MEMORY MAP
AND STACK FOR PIC18F452/252
PC<20:0>
CALL,RCALL,RETURN RETFIE,RETLW
Stack Level 1
Stack Level 31
RESET Vector
High Priority Interrupt Vector
Low Priority Interrupt Vector
On-Chip
Program Memory
21
0000h
0008h
0018h
7FFFh
8000h
User Memory Space
1FFFFFh 200000h
Read '0'
1FFFFFh 200000h
DS39564C-page 36 © 2006 Microchip Technology Inc.
PIC18FXX2

4.2 Return Address Stack

The return address stack allows any combination of up to 31 program calls and interrupts to occur. The PC (Program Counter) is pushed onto the stack when a CALL or RCALL instruction is executed, or an interrupt is acknowledged. The PC value is pulled off the stack on a RETURN, RETLW or a RETFIE instruction. PCLATU and PCLATH are not affected by any of the RETURN or CALL instructions.
The stack operates as a 31-word by 21-bit RAM and a 5-bit stack pointer, with the stack pointer initialized to 00000b after all RESETS. There is no RAM associated with stack pointer 00000b. This is only a RESET value. During a CALL type instruction, causing a push onto the stack, the stack pointer is first incremented and the RAM location pointed to by the stack pointer is written with the contents of the PC. During a RETURN type instruction, causing a pop from the stack, the contents of the RAM location pointed to by the STKPTR are transferred to the PC and then the stack pointer is decremented.
The stack space is not part of either program or data space. The stack pointer is readable and writable, and the address on the top of the stack is readable and writ­able through SFR registers. Data can also be pushed to, or popped from, the stack using the top-of-stack SFRs. Status bits indicate if the stack pointer is at, or beyond the 31 levels provided.

4.2.1 TOP-OF-STACK ACCESS

The top of the stack is readable and writable. Three register locations, TOSU, TOSH and TOSL hold the contents of the stack location pointed to by the STKPTR register. This allows users to implement a software stack if necessary. After a CALL, RCALL or interrupt, the software can read the pushed value by reading the TOSU, TOSH and TOSL registers. These values can be placed on a user defined software stack. At return time, the software can replace the TOSU, TOSH and TOSL and do a return.
The user must disable the global interrupt enable bits during this time to prevent inadvertent stack operations.

4.2.2 RETURN STACK POINTER (STKPTR)

The STKPTR register contains the stack pointer value, the STKFUL (stack full) status bit, and the STKUNF (stack underflow) status bits. Register 4-1 shows the STKPTR register. The value of the stack pointer can be 0 through 31. The stack pointer increments when val­ues are pushed onto the stack and decrements when values are popped off the stack. At RESET, the stack pointer value will be 0. The user may read and write the stack pointer value. This feature can be used by a Real Time Operating System for return stack maintenance.
After the PC is pushed onto the stack 31 times (without popping any values off the stack), the STKFUL bit is set. The STKFUL bit can only be cleared in software or by a POR.
The action that takes place when the stack becomes full depends on the state of the STVREN (Stack Over­flow Reset Enable) configuration bit. Refer to Section 20.0 for a description of the device configura­tion bits. If STVREN is set (default), the 31st push will push the (PC + 2) value onto the stack, set the STKFUL bit, and reset the device. The STKFUL bit will remain set and the stack pointer will be set to ‘0’.
If STVREN is cleared, the STKFUL bit will be set on the 31st push and the stack pointer will increment to 31. Any additional pushes will not overwrite the 31st push, and STKPTR will remain at 31.
When the stack has been popped enough times to unload the stack, the next pop will return a value of zero to the PC and sets the STKUNF bit, while the stack pointer remains at 0. The STKUNF bit will remain set until cleared in software or a POR occurs.
Note: Returning a value of zero to the PC on an
underflow has the effect of vectoring the program to the RESET vector, where the stack conditions can be verified and appropriate actions can be taken.
© 2006 Microchip Technology Inc. DS39564C-page 37
PIC18FXX2
REGISTER 4-1: STKPTR REGISTER
R/C-0 R/C-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
STKOVF STKUNF
bit 7 bit 0
SP4 SP3 SP2 SP1 SP0
(1)
bit 7
(1)
bit 6
bit 5 Unimplemented: Read as '0' bit 4-0 SP4:SP0: Stack Pointer Location bits
STKOVF: Stack Full Flag bit
1 = Stack became full or overflowed 0 = Stack has not become full or overflowed
STKUNF: Stack Underflow Flag bit
1 = Stack underflow occurred 0 = Stack underflow did not occur
Note 1: Bit 7 and bit 6 can only be cleared in user software or by a POR.
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
FIGURE 4-3: RETURN ADDRESS STACK AND ASSOCIATED REGISTERS
Return Address Stack
11111 11110
TOSLTOSHTOSU
0x340x1A0x00
Top of Stack
0x001A34
0x000D58
11101
00011 00010 00001 00000
STKPTR<4:0>
00010

4.2.3 PUSH AND POP INSTRUCTIONS

Since the Top-of-Stack (TOS) is readable and writable, the ability to push values onto the stack and pull values off the stack without disturbing normal program execu­tion is a desirable option. To push the current PC value onto the stack, a PUSH instruction can be executed. This will increment the stack pointer and load the cur­rent PC value onto the stack. TOSU, TOSH and TOSL can then be modified to place a return address on the stack.
The ability to pull the TOS value off of the stack and replace it with the value that was previously pushed onto the stack, without disturbing normal execution, is achieved by using the POP instruction. The POP instruc- tion discards the current TOS by decrementing the stack pointer. The previous value pushed onto the stack then becomes the TOS value.
DS39564C-page 38 © 2006 Microchip Technology Inc.

4.2.4 STACK FULL/UNDERFLOW RESETS

These resets are enabled by programming the STVREN configuration bit. When the STVREN bit is disabled, a full or underflow condition will set the appro­priate STKFUL or STKUNF bit, but not cause a device RESET. When the STVREN bit is enabled, a full or underflow will set the appropriate STKFUL or STKUNF bit and then cause a device RESET. The STKFUL or STKUNF bits are only cleared by the user software or a POR Reset.
PIC18FXX2

4.3 Fast Register Stack

A “fast interrupt return” option is available for interrupts. A Fast Register Stack is provided for the STATUS, WREG and BSR registers and are only one in depth. The stack is not readable or writable and is loaded with the current value of the corresponding register when the processor vectors for an interrupt. The values in the registers are then loaded back into the working regis­ters, if the FAST RETURN instruction is used to return from the interrupt.
A low or high priority interrupt source will push values into the stack registers. If both low and high priority interrupts are enabled, the stack registers cannot be used reliably for low priority interrupts. If a high priority interrupt occurs while servicing a low priority interrupt, the stack register values stored by the low priority inter­rupt will be overwritten.
If high priority interrupts are not disabled during low pri­ority interrupts, users must save the key registers in software during a low priority interrupt.
If no interrupts are used, the fast register stack can be used to restore the STATUS, WREG and BSR registers at the end of a subroutine call. To use the fast register stack for a subroutine call, a FAST CALL instruction must be executed.
Example 4-1 shows a source code example that uses the fast register stack.

4.4 PCL, PCLATH and PCLATU

The program counter (PC) specifies the address of the instruction to fetch for execution. The PC is 21-bits wide. The low byte is called the PCL register. This reg­ister is readable and writable. The high byte is called the PCH register. This register contains the PC<15:8> bits and is not directly readable or writable. Updates to the PCH register may be performed through the PCLATH register. The upper byte is called PCU. This register contains the PC<20:16> bits and is not directly readable or writable. Updates to the PCU register may be performed through the PCLATU register.
The PC addresses bytes in the program memory. To prevent the PC from becoming misaligned with word instructions, the LSB of PCL is fixed to a value of ’0’. The PC increments by 2 to address sequential instructions in the program memory.
The CALL, RCALL, GOTO and program branch instructions write to the program counter directly. For these instructions, the contents of PCLATH and PCLATU are not transferred to the program counter.
The contents of PCLATH and PCLATU will be trans­ferred to the program counter by an operation that writes PCL. Similarly, the upper two bytes of the pro­gram counter will be transferred to PCLATH and PCLATU by an operation that reads PCL. This is useful for computed offsets to the PC (see Section 4.8.1).
EXAMPLE 4-1: FAST REGISTER STACK
CODE EXAMPLE
CALL SUB1, FAST ;STATUS, WREG, BSR
SUB1
RETURN FAST ;RESTORE VALUES SAVED
;SAVED IN FAST REGISTER ;STACK
;IN FAST REGISTER STACK
FIGURE 4-4: CLOCK/INSTRUCTION CYCLE
Q2 Q3 Q4
OSC1
Q1
Q2
Q3
Q4
PC
OSC2/CLKO
(RC mode)
Q1
PC
Execute INST (PC-2)
Fetch INST (PC)
Q1
Execute INST (PC) Fetch INST (PC+2)
4.5 Clocking Scheme/Instruction
Cycle
The clock input (from OSC1) is internally divided by four to generate four non-overlapping quadrature clocks, namely Q1, Q2, Q3 and Q4. Internally, the pro­gram counter (PC) is incremented every Q1, the instruction is fetched from the program memory and latched into the instruction register in Q4. The instruc­tion is decoded and executed during the following Q1 through Q4. The clocks and instruction execution flow are shown in Figure 4-4.
Q2 Q3 Q4
PC+2
Q2 Q3 Q4
Q1
PC+4
Execute INST (PC+2)
Fetch INST (PC+4)
Internal Phase Clock
© 2006 Microchip Technology Inc. DS39564C-page 39
PIC18FXX2

4.6 Instruction Flow/Pipelining

An “Instruction Cycle” consists of four Q cycles (Q1, Q2, Q3 and Q4). The instruction fetch and execute are pipelined such that fetch takes one instruction cycle, while decode and execute takes another instruction cycle. However, due to the pipelining, each instruction effectively executes in one cycle. If an instruction causes the program counter to change (e.g., GOTO)
A fetch cycle begins with the program counter (PC) incrementing in Q1.
In the execution cycle, the fetched instruction is latched into the “Instruction Register” (IR) in cycle Q1. This instruction is then decoded and executed during the Q2, Q3, and Q4 cycles. Data memory is read during Q2 (operand read) and written during Q4 (destination write).
then two cycles are required to complete the instruction (Example 4-2).
EXAMPLE 4-2: INSTRUCTION PIPELINE FLOW
TCY0TCY1TCY2TCY3TCY4TCY5
1. MOVLW 55h
2. MOVWF PORTB
3. BRA SUB_1
4. BSF PORTA, BIT3 (Forced NOP)
5. Instruction @ address SUB_1
All instructions are single cycle, except for any program branches. These take two cycles since the fetch instruction is “flushed” from the pipeline while the new instruction is being fetched and then executed.
Fetch 1 Execute 1
Fetch 2 Execute 2
Fetch 3 Execute 3
Fetch 4 Flush (NOP)
Fetch SUB_1 Execute SUB_1

4.7 Instructions in Program Memory

The program memory is addressed in bytes. Instruc­tions are stored as two bytes or four bytes in program memory. The Least Significant Byte of an instruction word is always stored in a program memory location with an even address (LSB =’0’). Figure 4-5 shows an example of how instruction words are stored in the pro­gram memory. To maintain alignment with instruction boundaries, the PC increments in steps of 2 and the LSB will always read ’0’ (see Section 4.4).
The CALL and GOTO instructions have an absolute pro­gram memory address embedded into the instruction. Since instructions are always stored on word bound­aries, the data contained in the instruction is a word address. The word address is written to PC<20:1>, which accesses the desired byte address in program memory. Instruction #2 in Figure 4-5 shows how the instruction “GOTO 000006h’ is encoded in the program memory. Program branch instructions which encode a relative address offset operate in the same manner. The offset value stored in a branch instruction repre­sents the number of single word instructions that the PC will be offset by. Section 20.0 provides further details of the instruction set.

FIGURE 4-5: INSTRUCTIONS IN PROGRAM MEMORY

LSB = 1 LSB = 0
0Fh 55h 000008h EFh 03h 00000Ah F0h 00h 00000Ch C1h 23h 00000Eh F4h 56h 000010h
Instruction 1: Instruction 2:
Instruction 3:
Program Memory Byte Locations
MOVLW 055h GOTO 000006h
MOVFF 123h, 456h
Word Address
000000h 000002h 000004h 000006h
000012h 000014h
DS39564C-page 40 © 2006 Microchip Technology Inc.
PIC18FXX2

4.7.1 TWO-WORD INSTRUCTIONS

The PIC18FXX2 devices have four two-word instruc­tions: MOVFF, CALL, GOTO and LFSR. The second word of these instructions has the 4 MSBs set to 1’s and is a special kind of NOP instruction. The lower 12 bits of the second word contain data to be used by the instruction. If the first word of the instruction is exe­cuted, the data in the second word is accessed. If the
second word of the instruction is executed by itself (first word was skipped), it will execute as a NOP. This action is necessary when the two-word instruction is preceded by a conditional instruction that changes the PC. A pro­gram example that demonstrates this concept is shown in Example 4-3. Refer to Section 20.0 for further details of the instruction set.
EXAMPLE 4-3: TWO-WORD INSTRUCTIONS
CASE 1: Object Code Source Code
0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0?
1100 0001 0010 0011 MOVFF REG1, REG2 ; No, execute 2-word instruction
1111 0100 0101 0110 ; 2nd operand holds address of REG2
0010 0100 0000 0000 ADDWF REG3 ; continue code
CASE 2: Object Code Source Code
0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0?
1100 0001 0010 0011 MOVFF REG1, REG2 ; Yes
1111 0100 0101 0110 ; 2nd operand becomes NOP
0010 0100 0000 0000 ADDWF REG3 ; continue code

4.8 Lookup Tables

Lookup tables are implemented two ways. These are:
• Computed GOTO
• Table Reads

4.8.1 COMPUTED GOTO

A computed GOTO is accomplished by adding an offset to the program counter (ADDWF PCL).
A lookup table can be formed with an ADDWF PCL instruction and a group of RETLW 0xnn instructions. WREG is loaded with an offset into the table before executing a call to that table. The first instruction of the called routine is the ADDWF PCL instruction. The next instruction executed will be one of the RETLW 0xnn instructions, that returns the value 0xnn to the calling function.
The offset value (value in WREG) specifies the number of bytes that the program counter should advance.
In this method, only one data byte may be stored in each instruction location and room on the return address stack is required.
Note: The ADDWF PCL instruction does not
update PCLATH and PCLATU. A read operation on PCL must be performed to update PCLATH and PCLATU.

4.8.2 TABLE READS/TABLE WRITES

A better method of storing data in program memory allows 2 bytes of data to be stored in each instruction location.
Lookup table data may be stored 2 bytes per program word by using table reads and writes. The table pointer (TBLPTR) specifies the byte address and the table latch (TABLAT) contains the data that is read from, or written to program memory. Data is transferred to/from program memory, one byte at a time.
A description of the Table Read/Table Write operation is shown in Section 3.0.
© 2006 Microchip Technology Inc. DS39564C-page 41
PIC18FXX2

4.9 Data Memory Organization

The data memory is implemented as static RAM. Each register in the data memory has a 12-bit address, allowing up to 4096 bytes of data memory. Figure 4-6 and Figure 4-7 show the data memory organization for the PIC18FXX2 devices.
The data memory map is divided into as many as 16 banks that contain 256 bytes each. The lower 4 bits of the Bank Select Register (BSR<3:0>) select which bank will be accessed. The upper 4 bits for the BSR are not implemented.
The data memory contains Special Function Registers (SFR) and General Purpose Registers (GPR). The SFRs are used for control and status of the controller and peripheral functions, while GPRs are used for data storage and scratch pad operations in the user’s appli­cation. The SFRs start at the last location of Bank 15 (0xFFF) and extend downwards. Any remaining space beyond the SFRs in the Bank may be implemented as GPRs. GPRs start at the first location of Bank 0 and grow upwards. Any read of an unimplemented location will read as ’0’s.
The entire data memory may be accessed directly or indirectly. Direct addressing may require the use of the BSR register. Indirect addressing requires the use of a File Select Register (FSRn) and a corresponding Indi­rect File Operand (INDFn). Each FSR holds a 12-bit address value that can be used to access any location in the Data Memory map without banking.
The instruction set and architecture allow operations across all banks. This may be accomplished by indirect addressing or by the use of the MOVFF instruction. The MOVFF instruction is a two-word/two-cycle instruction that moves a value from one register to another.
To ensure that commonly used registers (SFRs and select GPRs) can be accessed in a single cycle, regardless of the current BSR values, an Access Bank is implemented. A segment of Bank 0 and a segment of Bank 15 comprise the Access RAM. Section 4.10 provides a detailed description of the Access RAM.

4.9.1 GENERAL PURPOSE REGISTER FILE

The register file can be accessed either directly or indi­rectly. Indirect addressing operates using a File Select Register and corresponding Indirect File Operand. The operation of indirect addressing is shown in Section 4.12.
Enhanced MCU devices may have banked memory in the GPR area. GPRs are not initialized by a Power-on Reset and are unchanged on all other RESETS.
Data RAM is available for use as GPR registers by all instructions. The top half of Bank 15 (0xF80 to 0xFFF) contains SFRs. All other banks of data memory contain GPR registers, starting with Bank 0.

4.9.2 SPECIAL FUNCTION REGISTERS

The Special Function Registers (SFRs) are registers used by the CPU and Peripheral Modules for control­ling the desired operation of the device. These regis­ters are implemented as static RAM. A list of these registers is given in Table 4-1 and Table 4-2.
The SFRs can be classified into two sets; those asso­ciated with the “core” function and those related to the peripheral functions. Those registers related to the “core” are described in this section, while those related to the operation of the peripheral features are described in the section of that peripheral feature.
The SFRs are typically distributed among the peripherals whose functions they control.
The unused SFR locations will be unimplemented and read as '0's. See Table 4-1 for addresses for the SFRs.
DS39564C-page 42 © 2006 Microchip Technology Inc.
FIGURE 4-6: DATA MEMORY MAP FOR PIC18F242/442
PIC18FXX2
BSR<3:0>
= 0000
= 0001
= 0010
= 0011
= 1110
= 1111
When a = 1, the BSR is used to specify the RAM location that the instruction uses.
Bank 0
Bank 1
Bank 2
Bank 3
to
Bank 14
Bank 15
Data Memory Map
00h
Access RAM
FFh 00h
FFh 00h
FFh
00h
FFh
GPR
GPR
GPR
Unused
Read ’00h’
Unused
SFR
000h 07Fh 080h
0FFh
100h
1FFh
200h
2FFh 300h
EFFh F00h
F7Fh
F80h FFFh
Access Bank
Access RAM low
Access RAM high
(SFRs)
When a = 0, the BSR is ignored and the Access Bank is used. The first 128 bytes are General Purpose RAM (from Bank 0). The second 128 bytes are Special Function Registers (from Bank 15).
00h
7Fh
80h
FFh
© 2006 Microchip Technology Inc. DS39564C-page 43
PIC18FXX2
FIGURE 4-7: DATA MEMORY MAP FOR PIC18F252/452
BSR<3:0>
= 0000
= 0001
= 0010
= 0011
= 0100
= 0101
= 0110
= 1110
= 1111
When a = 1, the BSR is used to specify the RAM location that the instruction uses.
Bank 0
Bank 1
Bank 2
Bank 3
Bank 4
Bank 5
Bank 6
to
Bank 14
Bank 15
Data Memory Map
00h
Access RAM
FFh
00h
FFh
00h
FFh
00h
FFh
00h
FFh
00h
FFh
GPR
GPR
GPR
GPR
GPR
GPR
Unused
Read ’00h’
Unused
SFR
000h 07Fh
080h 0FFh
100h
1FFh 200h
2FFh
300h
3FFh 400h
4FFh 500h
5FFh 600h
EFFh F00h
F7Fh F80h
FFFh
Access Bank
Access RAM low
Access RAM high
(SFR’s)
When a = 0, the BSR is ignored and the Access Bank is used. The first 128 bytes are General Purpose RAM (from Bank 0). The second 128 bytes are Special Function Registers (from Bank 15).
00h
7Fh
80h
FFh
DS39564C-page 44 © 2006 Microchip Technology Inc.
PIC18FXX2
TABLE 4-1: SPECIAL FUNCTION REGISTER MAP
Address Name Address Name Address Name Address Name
(3)
FFFh TOSU FDFh INDF2
FFEh TOSH FDEh POSTINC2
FFDh TOSL FDDh POSTDEC2
FFCh STKPTR FDCh PREINC2
FFBh PCLATU FDBh PLUSW2
FFAh PCLATH FDAh FSR2H FBAh CCP2CON F9Ah
FF9h PCL FD9h FSR2L FB9h F99h
FF8h TBLPTRU FD8h STATUS FB8h F98h
FF7h TBLPTRH FD7h TMR0H FB7h F97h
FF6h TBLPTRL FD6h TMR0L FB6h F96h TRISE
FF5h TABLAT FD5h T0CON FB5h F95h TRISD
FF4h PRODH FD4h FB4h F94h TRISC
FF3h PRODL FD3h OSCCON FB3h TMR3H F93h TRISB
FF2h INTCON FD2h LVDCON FB2h TMR3L F92h TRISA
FF1h INTCON2 FD1h WDTCON FB1h T3CON F91h
FF0h INTCON3 FD0h RCON FB0h F90h
(3)
FEFh INDF0
FEEh POSTINC0
FEDh POSTDEC0
FECh PREINC0
FEBh PLUSW0
FCFh TMR1H FAFh SPBRG F8Fh
(3)
FCEh TMR1L FAEh RCREG F8Eh
(3)
FCDh T1CON FADh TXREG F8Dh LATE
(3)
FCCh TMR2 FACh TXSTA F8Ch LATD
(3)
FCBh PR2 FABh RCSTA F8Bh LATC
FEAh FSR0H FCAh T2CON FAAh F8Ah LATB
FE9h FSR0L FC9h SSPBUF FA9h EEADR F89h LATA
FE8h WREG FC8h SSPADD FA8h EEDATA F88h
(3)
FE7h INDF1
FE6h POSTINC1
FE5h POSTDEC1
FE4h PREINC1
FE3h PLUSW1
FC7h SSPSTAT FA7h EECON2 F87h
(3)
FC6h SSPCON1 FA6h EECON1 F86h
(3)
FC5h SSPCON2 FA5h F85h
(3)
FC4h ADRESH FA4h F84h PORTE
(3)
FC3h ADRESL FA3h F83h PORTD
FE2h FSR1H FC2h ADCON0 FA2h IPR2 F82h PORTC
FE1h FSR1L FC1h ADCON1 FA1h PIR2 F81h PORTB
FE0h BSR FC0h FA0h PIE2 F80h PORTA
FBFh CCPR1H F9Fh IPR1
(3)
FBEh CCPR1L F9Eh PIR1
(3)
FBDh CCP1CON F9Dh PIE1
(3)
FBCh CCPR2H F9Ch
(3)
FBBh CCPR2L F9Bh
(2) (2)
(2) (2)
(2) (2)
Note 1: Unimplemented registers are read as ’0’.
2: This register is not available on PIC18F2X2 devices. 3: This is not a physical register.
© 2006 Microchip Technology Inc. DS39564C-page 45
PIC18FXX2
TABLE 4-2: REGISTER FILE SUMMARY
File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
TOSU
TOSH Top-of-Stack High Byte (TOS<15:8>) 0000 0000 37
TOSL Top-of-Stack Low Byte (TOS<7:0>) 0000 0000 37
STKPTR STKFUL STKUNF Return Stack Pointer 00-0 0000 38
PCLATU
PCLATH Holding Register for PC<15:8> 0000 0000 39
PCL PC Low Byte (PC<7:0>) 0000 0000 39
TBLPTRU
TBLPTRH Program Memory Table Pointer High Byte (TBLPTR<15:8>) 0000 0000 58
TBLPTRL Program Memory Table Pointer Low Byte (TBLPTR<7:0>) 0000 0000 58
TABLAT Program Memory Table Latch 0000 0000 58
PRODH Product Register High Byte xxxx xxxx 71
PRODL Product Register Low Byte xxxx xxxx 71
INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 0000 000x 75
INTCON2 RBPU INTEDG0 INTEDG1 INTEDG2
INTCON3 INT2IP INT1IP
INDF0 Uses contents of FSR0 to address data memory - value of FSR0 not changed (not a physical register) n/a 50
POSTINC0 Uses contents of FSR0 to address data memory - value of FSR0 post-incremented (not a physical register) n/a 50
POSTDEC0 Uses contents of FSR0 to address data memory - value of FSR0 post-decremented (not a physical register) n/a 50
PREINC0 Uses contents of FSR0 to address data memory - value of FSR0 pre-incremented (not a physical register) n/a 50
PLUSW0 Uses contents of FSR0 to address data memory - value of FSR0 (not a physical register).
FSR0H
FSR0L Indirect Data Memory Address Pointer 0 Low Byte xxxx xxxx 50
WREG Working Register xxxx xxxx n/a
INDF1 Uses contents of FSR1 to address data memory - value of FSR1 not changed (not a physical register) n/a 50
POSTINC1 Uses contents of FSR1 to address data memory - value of FSR1 post-incremented (not a physical register) n/a 50
POSTDEC1 Uses contents of FSR1 to address data memory - value of FSR1 post-decremented (not a physical register) n/a 50
PREINC1 Uses contents of FSR1 to address data memory - value of FSR1 pre-incremented (not a physical register) n/a 50
PLUSW1 Uses contents of FSR1 to address data memory - value of FSR1 (not a physical register).
FSR1H
FSR1L Indirect Data Memory Address Pointer 1 Low Byte xxxx xxxx 50
BSR
INDF2 Uses contents of FSR2 to address data memory - value of FSR2 not changed (not a physical register) n/a 50
POSTINC2 Uses contents of FSR2 to address data memory - value of FSR2 post-incremented (not a physical register) n/a 50
POSTDEC2 Uses contents of FSR2 to address data memory - value of FSR2 post-decremented (not a physical register) n/a 50
PREINC2 Uses contents of FSR2 to address data memory - value of FSR2 pre-incremented (not a physical register) n/a 50
PLUSW2 Uses contents of FSR2 to address data memory - value of FSR2 (not a physical register).
FSR2H
FSR2L Indirect Data Memory Address Pointer 2 Low Byte xxxx xxxx 50
STATUS
TMR0H Timer0 Register High Byte 0000 0000 105
TMR0L Timer0 Register Low Byte xxxx xxxx 105
T0CON TMR0ON T08BIT T0CS T0SE PSA T0PS2 T0PS1 T0PS0 1111 1111 103
Legend: x = unknown, u = unchanged, - = unimplemented, q = value depends on condition
Note 1: RA6 and associated bits are configured as port pins in RCIO and ECIO Oscillator mode only and read '0' in all other Oscillator modes.
2: Bit 21 of the TBLPTRU allows access to the device configuration bits. 3: These registers and bits are reserved on the PIC18F2X2 devices; always maintain these clear.
Top-of-Stack upper Byte (TOS<20:16>) ---0 0000 37
Holding Register for PC<20:16> ---0 0000 39
—bit21
Offset by value in WREG.
Indirect Data Memory Address Pointer 0 High Byte ---- 0000 50
Offset by value in WREG.
Indirect Data Memory Address Pointer 1 High Byte ---- 0000 50
Bank Select Register ---- 0000 49
Offset by value in WREG.
Indirect Data Memory Address Pointer 2 High Byte ---- 0000 50
—NOVZDCC---x xxxx 52
(2)
Program Memory Table Pointer Upper Byte (TBLPTR<20:16>) --00 0000 58
—TMR0IP—RBIP1111 -1-1 76
INT2IE INT1IE INT2IF INT1IF 11-0 0-00 77
Value on
POR, BOR
n/a 50
n/a 50
n/a 50
Details
on page:
DS39564C-page 46 © 2006 Microchip Technology Inc.
TABLE 4-2: REGISTER FILE SUMMARY (CONTINUED)
PIC18FXX2
File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
OSCCON —SCS---- ---0 21
LVDCON
WDTCON
RCON IPEN
TMR1H Timer1 Register High Byte xxxx xxxx 107
TMR1L Timer1 Register Low Byte xxxx xxxx 107
T1CON RD16
TMR2 Timer2 Register 0000 0000 111
PR2 Timer2 Period Register 1111 1111 112
T2CON
SSPBUF SSP Receive Buffer/Transmit Register xxxx xxxx 125
SSPADD SSP Address Register in I
SSPSTAT SMP CKE D/A
SSPCON1 WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 127
SSPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 137
ADRESH A/D Result Register High Byte xxxx xxxx 187,188
ADRESL A/D Result Register Low Byte xxxx xxxx 187,188
ADCON0 ADCS1 ADCS0 CHS2 CHS1 CHS0 GO/DONE
ADCON1 ADFM ADCS2
CCPR1H Capture/Compare/PWM Register1 High Byte xxxx xxxx 121, 123
CCPR1L Capture/Compare/PWM Register1 Low Byte xxxx xxxx 121, 123
CCP1CON
CCPR2H Capture/Compare/PWM Register2 High Byte xxxx xxxx 121, 123
CCPR2L Capture/Compare/PWM Register2 Low Byte xxxx xxxx 121, 123
CCP2CON
TMR3H Timer3 Register High Byte xxxx xxxx 113
TMR3L Timer3 Register Low Byte xxxx xxxx 113
T3CON RD16 T3CCP2 T3CKPS1 T3CKPS0 T3CCP1 T3SYNC
SPBRG USART1 Baud Rate Generator 0000 0000 168
RCREG USART1 Receive Register 0000 0000 175, 178,
TXREG USART1 Transmit Register 0000 0000 173, 176,
TXSTA CSRC TX9 TXEN SYNC
RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 167
EEADR Data EEPROM Address Register 0000 0000 65, 69
EEDATA Data EEPROM Data Register 0000 0000 69
EECON2 Data EEPROM Control Register 2 (not a physical register) ---- ---- 65, 69
EECON1 EEPGD CFGS
Legend: x = unknown, u = unchanged, - = unimplemented, q = value depends on condition
Note 1: RA6 and associated bits are configured as port pins in RCIO and ECIO Oscillator mode only and read '0' in all other Oscillator modes.
2: Bit 21 of the TBLPTRU allows access to the device configuration bits. 3: These registers and bits are reserved on the PIC18F2X2 devices; always maintain these clear.
I RVS T LVD EN LVDL3 LVDL2 LV DL1 LVD L0 --00 0101 191
—SWDTE---- ---0 203
—RITO PD POR BOR 0--1 11qq 53, 28, 84
T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR1CS TMR1ON 0-00 0000 107
TOUTPS3 TOUTPS2 TOUTPS1 TOUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 111
2
C Slave mode. SSP Baud Rate Reload Register in I2C Master mode. 0000 0000 134
PSR/WUA BF 0000 0000 126
—ADON0000 00-0 181
PCFG3 PCFG2 PCFG1 PCFG0 00-- 0000 182
DC1B1 DC1B0 CCP1M3 CCP1M2 CCP1M1 CCP1M0 --00 0000 117
DC2B1 DC2B0 CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 117
TMR3CS TMR3ON 0000 0000 113
BRGH TRMT TX9D 0000 -010 166
FREE WRERR WREN WR RD xx-0 x000 66
Value on
POR, BOR
Details
on page:
180
179
© 2006 Microchip Technology Inc. DS39564C-page 47
PIC18FXX2
TABLE 4-2: REGISTER FILE SUMMARY (CONTINUED)
File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Value on
POR, BOR
Details
on page:
IPR2 EEIP BCLIP LVDIP TMR3IP CCP2IP ---1 1111 83
PIR2
PIE2
IPR1 PSPIP
PIR1 PSPIF
PIE1 PSPIE
(3)
TRISE
(3)
TRISD
EEIF BCLIF LVDIF TMR3IF CCP2IF ---0 0000 79
EEIE BCLIE LVDIE TMR3IE CCP2IE ---0 0000 81
(3)
ADIP RCIP TXIP SSPIP CCP1IP TMR2IP TMR1IP 1111 1111 82
(3)
ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 78
(3)
ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 80
IBF OBF IBOV PSPMODE Data Direction bits for PORTE 0000 -111 98
Data Direction Control Register for PORTD 1111 1111 96
TRISC Data Direction Control Register for PORTC 1111 1111 93
TRISB Data Direction Control Register for PORTB 1111 1111 90
TRISA
LATE
—TRISA6
(3)
Read PORTE Data Latch,
(1)
Data Direction Control Register for PORTA -111 1111 87
---- -xxx 99
Write PORTE Data Latch
(3)
LATD
Read PORTD Data Latch, Write PORTD Data Latch xxxx xxxx 95
LATC Read PORTC Data Latch, Write PORTC Data Latch xxxx xxxx 93
LATB Read PORTB Data Latch, Write PORTB Data Latch xxxx xxxx 90
LATA
PORTE
PORTD
—LATA6
(3)
Read PORTE pins, Write PORTE Data Latch ---- -000 99
(3)
Read PORTD pins, Write PORTD Data Latch xxxx xxxx 95
(1)
Read PORTA Data Latch, Write PORTA Data Latch
(1)
-xxx xxxx 87
PORTC Read PORTC pins, Write PORTC Data Latch xxxx xxxx 93
PORTB Read PORTB pins, Write PORTB Data Latch xxxx xxxx 90
PORTA
—RA6
(1)
Read PORTA pins, Write PORTA Data Latch
(1)
-x0x 0000 87
Legend: x = unknown, u = unchanged, - = unimplemented, q = value depends on condition
Note 1: RA6 and associated bits are configured as port pins in RCIO and ECIO Oscillator mode only and read '0' in all other Oscillator modes.
2: Bit 21 of the TBLPTRU allows access to the device configuration bits. 3: These registers and bits are reserved on the PIC18F2X2 devices; always maintain these clear.
DS39564C-page 48 © 2006 Microchip Technology Inc.
PIC18FXX2

4.10 Access Bank

The Access Bank is an architectural enhancement which is very useful for C compiler code optimization. The techniques used by the C compiler may also be useful for programs written in assembly.
This data memory region can be used for:
• Intermediate computational values
• Local variables of subroutines
• Faster context saving/switching of variables
• Common variables
• Faster evaluation/control of SFRs (no banking)
The Access Bank is comprised of the upper 128 bytes in Bank 15 (SFRs) and the lower 128 bytes in Bank 0. These two sections will be referred to as Access RAM High and Access RAM Low, respectively. Figure 4-6 and Figure 4-7 indicate the Access RAM areas.
A bit in the instruction word specifies if the operation is to occur in the bank specified by the BSR register or in the Access Bank. This bit is denoted by the ’a’ bit (for access bit).
When forced in the Access Bank (a = 0), the last address in Access RAM Low is followed by the first address in Access RAM High. Access RAM High maps the Special Function registers, so that these registers can be accessed without any software overhead. This is useful for testing status flags and modifying control bits.

4.11 Bank Select Register (BSR)

The need for a large general purpose memory space dictates a RAM banking scheme. The data memory is partitioned into sixteen banks. When using direct addressing, the BSR should be configured for the desired bank.
BSR<3:0> holds the upper 4 bits of the 12-bit RAM address. The BSR<7:4> bits will always read ’0’s, and writes will have no effect.
A MOVLB instruction has been provided in the instruction set to assist in selecting banks.
If the currently selected bank is not implemented, any read will return all '0's and all writes are ignored. The STATUS register bits will be set/cleared as appropriate for the instruction performed.
Each Bank extends up to FFh (256 bytes). All data memory is implemented as static RAM.
A MOVFF instruction ignores the BSR, since the 12-bit addresses are embedded into the instruction word.
Section 4.12 provides a description of indirect address­ing, which allows linear addressing of the entire RAM space.

FIGURE 4-8: DIRECT ADDRESSING

Direct Addressing
BSR<3:0> 7
Bank Select
Note 1: For register file map detail, see Table 4-1.
(2)
2: The access bit of the instruction can be used to force an override of the selected bank (BSR<3:0>) to the
registers of the Access Bank.
3: The MOVFF instruction embeds the entire 12-bit address in the instruction.
Location Select
From Opcode
Data Memory
(3)
(1)
(3)
0
00h 01h 0Eh 0Fh
000h
0FFh
100h
1FFh
E00h
EFFh
Bank 0 Bank 1 Bank 14 Bank 15
F00h
FFFh
© 2006 Microchip Technology Inc. DS39564C-page 49
PIC18FXX2

4.12 Indirect Addressing, INDF and FSR Registers

Indirect addressing is a mode of addressing data mem­ory, where the data memory address in the instruction is not fixed. An FSR register is used as a pointer to the data memory location that is to be read or written. Since this pointer is in RAM, the contents can be modified by the program. This can be useful for data tables in the data memory and for software stacks. Figure 4-9 shows the operation of indirect addressing. This shows the moving of the value to the data memory address specified by the value of the FSR register.
Indirect addressing is possible by using one of the INDF registers. Any instruction using the INDF register actually accesses the register pointed to by the File Select Register, FSR. Reading the INDF register itself, indirectly (FSR = 0), will read 00h. Writing to the INDF register indirectly, results in a no operation. The FSR register contains a 12-bit address, which is shown in Figure 4-10.
The INDFn register is not a physical register. Address­ing INDFn actually addresses the register whose address is contained in the FSRn register (FSRn is a pointer). This is indirect addressing.
Example 4-4 shows a simple use of indirect addressing to clear the RAM in Bank1 (locations 100h-1FFh) in a minimum number of instructions.
EXAMPLE 4-4: HOW TO CLEAR RAM
(BANK1) USING INDIRECT ADDRESSING
LFSR FSR0 ,0x100 ;
NEXT CLRF POSTINC0 ; Clear INDF
; register and ; inc pointer
BTFSS FSR0H, 1 ; All done with
; Bank1?
GOTO NEXT ; NO, clear next
CONTINUE ; YES, continue
There are three indirect addressing registers. To address the entire data memory space (4096 bytes), these registers are 12-bit wide. To store the 12-bits of addressing information, two 8-bit registers are required. These indirect addressing registers are:
1. FSR0: composed of FSR0H:FSR0L
2. FSR1: composed of FSR1H:FSR1L
3. FSR2: composed of FSR2H:FSR2L
In addition, there are registers INDF0, INDF1 and INDF2, which are not physically implemented. Reading or writing to these registers activates indirect address­ing, with the value in the corresponding FSR register being the address of the data. If an instruction writes a value to INDF0, the value will be written to the address pointed to by FSR0H:FSR0L. A read from INDF1 reads
the data from the address pointed to by FSR1H:FSR1L. INDFn can be used in code anywhere an operand can be used.
If INDF0, INDF1 or INDF2 are read indirectly via an FSR, all '0's are read (zero bit is set). Similarly, if INDF0, INDF1 or INDF2 are written to indirectly, the operation will be equivalent to a NOP instruction and the STATUS bits are not affected.

4.12.1 INDIRECT ADDRESSING OPERATION

Each FSR register has an INDF register associated with it, plus four additional register addresses. Perform­ing an operation on one of these five registers deter­mines how the FSR will be modified during indirect addressing.
When data access is done to one of the five INDFn locations, the address selected will configure the FSRn register to:
• Do nothing to FSRn after an indirect access (no
change) - INDFn
• Auto-decrement FSRn after an indirect access
(post-decrement) - POSTDECn
• Auto-increment FSRn after an indirect access
(post-increment) - POSTINCn
• Auto-increment FSRn before an indirect access
(pre-increment) - PREINCn
• Use the value in the WREG register as an offset
to FSRn. Do not modify the value of the WREG or the FSRn register after an indirect access (no change) - PLUSWn
When using the auto-increment or auto-decrement fea­tures, the effect on the FSR is not reflected in the STATUS register. For example, if the indirect address causes the FSR to equal '0', the Z bit will not be set.
Incrementing or decrementing an FSR affects all 12 bits. That is, when FSRnL overflows from an increment, FSRnH will be incremented automatically.
Adding these features allows the FSRn to be used as a stack pointer, in addition to its uses for table operations in data memory.
Each FSR has an address associated with it that per­forms an indexed indirect access. When a data access to this INDFn location (PLUSWn) occurs, the FSRn is configured to add the signed value in the WREG regis­ter and the value in FSR to form the address before an indirect access. The FSR value is not changed.
If an FSR register contains a value that points to one of the INDFn, an indirect read will read 00h (zero bit is set), while an indirect write will be equivalent to a NOP (STATUS bits are not affected).
If an indirect addressing operation is done where the target address is an FSRnH or FSRnL register, the write operation will dominate over the pre- or post-increment/decrement functions.
DS39564C-page 50 © 2006 Microchip Technology Inc.
FIGURE 4-9: INDIRECT ADDRESSING OPERATION
Instruction Executed
Opcode Address
12
File Address = access of an indirect addressing register
RAM
PIC18FXX2
0h
FFFh
BSR<3:0>
Instruction Fetched
Opcode
12
4
File
FIGURE 4-10: INDIRECT ADDRESSING
Indirect Addressing
FSR Register11
Location Select
Data Memory
(1)
12
8
FSR
0
0000h
0FFFh
Note 1: For register file map detail, see Table 4-1.
© 2006 Microchip Technology Inc. DS39564C-page 51
PIC18FXX2

4.13 STATUS Register

The STATUS register, shown in Register 4-2, contains the arithmetic status of the ALU. The STATUS register can be the destination for any instruction, as with any other register. If the STATUS register is the destination for an instruction that affects the Z, DC, C, OV, or N bits, then the write to these five bits is disabled. These bits are set or cleared according to the device logic. There­fore, the result of an instruction with the STATUS register as destination may be different than intended.
REGISTER 4-2: STATUS REGISTER
U-0 U-0 U-0 R/W-x R/W-x R/W-x R/W-x R/W-x
—NOVZDCC
bit 7 bit 0
bit 7-5 Unimplemented: Read as '0' bit 4 N: Negative bit
This bit is used for signed arithmetic (2’s complement). It indicates whether the result was negative (ALU MSB = 1).
1 = Result was negative 0 = Result was positive
bit 3 OV: Overflow bit
This bit is used for signed arithmetic (2’s complement). It indicates an overflow of the 7-bit magnitude, which causes the sign bit (bit7) to change state.
1 = Overflow occurred for signed arithmetic (in this arithmetic operation) 0 = No overflow occurred
bit 2 Z: Zero bit
1 = The result of an arithmetic or logic operation is zero 0 = The result of an arithmetic or logic operation is not zero
bit 1 DC: Digit carry/borrow
For ADDWF, ADDLW, SUBLW, and SUBWF instructions
1 = A carry-out from the 4th low order bit of the result occurred 0 = No carry-out from the 4th low order bit of the result
Note: For borrow,
complement of the second operand. For rotate (RRF, RLF) instructions, this bit is loaded with either the bit 4 or bit 3 of the source register.
bit 0 C: Carry/borrow bit
For ADDWF, ADDLW, SUBLW, and SUBWF instructions
1 = A carry-out from the Most Significant bit of the result occurred 0 = No carry-out from the Most Significant bit of the result occurred
Note: For borrow,
complement of the second operand. For rotate (RRF, RLF) instructions, this bit is loaded with either the high or low order bit of the source register.
bit
the polarity is reversed. A subtraction is executed by adding the two’s
the polarity is reversed. A subtraction is executed by adding the two’s
For example, CLRF STATUS will clear the upper three bits and set the Z bit. This leaves the STATUS register as 000u u1uu (where u = unchanged).
It is recommended, therefore, that only BCF, BSF, SWAPF, MOVFF and MOVWF instructions are used to alter the STATUS register, because these instructions do not affect the Z, C, DC, OV, or N bits from the STATUS register. For other instructions not affecting any status bits, see Table 20-2.
Note: The C and DC bits operate as a borrow and
digit borrow
bit respectively, in subtraction.
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
DS39564C-page 52 © 2006 Microchip Technology Inc.
PIC18FXX2

4.14 RCON Register

The Reset Control (RCON) register contains flag bits that allow differentiation between the sources of a device RESET. These flags include the TO BOR
and RI bits. This register is readable and writable.
REGISTER 4-3: RCON REGISTER
R/W-0 U-0 U-0 R/W-1 R-1 R-1 R/W-0 R/W-0
IPEN —RITO PD POR BOR
bit 7 bit 0
bit 7 IPEN: Interrupt Priority Enable bit
1 = Enable priority levels on interrupts 0 = Disable priority levels on interrupts (16CXXX Compatibility mode)
bit 6-5 Unimplemented: Read as '0' bit 4 RI
bit 3 TO
bit 2 PD
bit 1 POR
bit 0 BOR
: RESET Instruction Flag bit
1 = The RESET instruction was not executed 0 = The RESET instruction was executed causing a device RESET
(must be set in software after a Brown-out Reset occurs)
: Watchdog Time-out Flag bit
1 = After power-up, CLRWDT instruction, or SLEEP instruction 0 = A WDT time-out occurred
: Power-down Detection Flag bit
1 = After power-up or by the CLRWDT instruction 0 = By execution of the SLEEP instruction
: Power-on Reset Status bit
1 = A Power-on Reset has not occurred 0 = A Power-on Reset occurred
(must be set in software after a Power-on Reset occurs)
: Brown-out Reset Status bit
1 = A Brown-out Reset has not occurred 0 = A Brown-out Reset occurred
(must be set in software after a Brown-out Reset occurs)
, PD, POR,
Note 1: If the BOREN configuration bit is set
(Brown-out Reset enabled), the BOR ’1’ on a Power-on Reset. After a Brown­out Reset has occurred, the BOR bit will be cleared, and must be set by firmware to indicate the occurrence of the next Brown-out Reset.
2: It is recommended that the POR
after a Power-on Reset has been detected, so that subsequent Power-on Resets may be detected.
bit is
bit be set
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 53
PIC18FXX2
NOTES:
DS39564C-page 54 © 2006 Microchip Technology Inc.
PIC18FXX2

5.0 FLASH PROGRAM MEMORY

The FLASH Program Memory is readable, writable, and erasable during normal operation over the entire VDD range.
A read from program memory is executed on one byte at a time. A write to program memory is executed on blocks of 8 bytes at a time. Program memory is erased in blocks of 64 bytes at a time. A bulk erase operation may not be issued from user code.
Writing or erasing program memory will cease instruc­tion fetches until the operation is complete. The pro­gram memory cannot be accessed during the write or erase, therefore, code cannot execute. An internal pro­gramming timer terminates program memory writes and erases.
A value written to program memory does not need to be a valid instruction. Executing a program memory location that forms an invalid instruction results in a NOP.

5.1 Table Reads and Table Writes

In order to read and write program memory, there are two operations that allow the processor to move bytes between the program memory space and the data RAM:
• Table Read (TBLRD)
• Table Write (TBLWT)
The program memory space is 16-bits wide, while the data RAM space is 8-bits wide. Table Reads and Table Writes move data between these two memory spaces through an 8-bit register (TABLAT).
Table Read operations retrieve data from program memory and places it into the data RAM space. Figure 5-1 shows the operation of a Table Read with program memory and data RAM.
Table Write operations store data from the data mem­ory space into holding registers in program memory. The procedure to write the contents of the holding reg­isters into program memory is detailed in Section 5.5, '”Writing to FLASH Program Memory”. Figure 5-2 shows the operation of a Table Write with program memory and data RAM.
Table operations work with byte entities. A table block containing data, rather than program instructions, is not required to be word aligned. Therefore, a table block can start and end at any byte address. If a Table Write is being used to write executable code into program memory, program instructions will need to be word aligned.

FIGURE 5-1: TABLE READ OPERATION

Table Pointer
TBLPTRU
Note 1: Table Pointer points to a byte in program memory.
TBLPTRH TBLPTRL
(1)
Program Memory (TBLPTR)
Instruction: TBLRD*
Program Memory
Table Latch (8-bit)
TABLAT
© 2006 Microchip Technology Inc. DS39564C-page 55
PIC18FXX2

FIGURE 5-2: TABLE WRITE OPERATION

Instruction: TBLWT*
Program Memory
Table Pointer
TBLPTRU
Note 1: Table Pointer actually points to one of eight holding registers, the address of which is determined by
TBLPTRL<2:0>. The process for physically writing data to the Program Memory Array is discussed in Section 5.5.
TBLPTRH TBLPTRL
(1)
Program Memory (TBLPTR)
Holding Registers
Table Latch (8-bit)
TABLAT

5.2 Control Registers

Several control registers are used in conjunction with the TBLRD and TBLWT instructions. These include the:
• EECON1 register
• EECON2 register
• TABLAT register
• TBLPTR registers

5.2.1 EECON1 AND EECON2 REGISTERS

EECON1 is the control register for memory accesses.
EECON2 is not a physical register. Reading EECON2 will read all '0's. The EECON2 register is used exclusively in the memory write and erase sequences.
Control bit EEPGD determines if the access will be a program or data EEPROM memory access. When clear, any subsequent operations will operate on the data EEPROM memory. When set, any subsequent operations will operate on the program memory.
Control bit CFGS determines if the access will be to the configuration registers or to program memory/data EEPROM memory. When set, subsequent operations will operate on configuration registers, regardless of EEPGD (see “Special Features of the CPU”, Section 19.0). When clear, memory selection access is determined by EEPGD.
The FREE bit, when set, will allow a program memory erase operation. When the FREE bit is set, the erase operation is initiated on the next WR command. When FREE is clear, only writes are enabled.
The WREN bit, when set, will allow a write operation. On power-up, the WREN bit is clear. The WRERR bit is set when a write operation is interrupted by a MCLR Reset or a WDT Time-out Reset during normal opera­tion. In these situations, the user can check the WRERR bit and rewrite the location. It is necessary to reload the data and address registers (EEDATA and EEADR), due to RESET values of zero.
Control bit WR initiates write operations. This bit cannot be cleared, only set, in software. It is cleared in hard­ware at the completion of the write operation. The inability to clear the WR bit in software prevents the accidental or premature termination of a write operation.
Note: Interrupt flag bit EEIF, in the PIR2 register,
is set when the write is complete. It must be cleared in software.
DS39564C-page 56 © 2006 Microchip Technology Inc.
REGISTER 5-1: EECON1 REGISTER (ADDRESS FA6h)
R/W-x R/W-x U-0 R/W-0 R/W-x R/W-0 R/S-0 R/S-0
EEPGD CFGS
bit 7 bit 0
bit 7 EEPGD: FLASH Program or Data EEPROM Memory Select bit
1 = Access FLASH Program memory 0 = Access Data EEPROM memory
bit 6 CFGS: FLASH Program/Data EE or Configuration Select bit
1 = Access Configuration registers 0 = Access FLASH Program or Data EEPROM memory
bit 5 Unimplemented: Read as '0' bit 4 FREE: FLASH Row Erase Enable bit
1 = Erase the program memory row addressed by TBLPTR on the next WR command
(cleared by completion of erase operation)
0 = Perform write only
bit 3 WRERR: FLASH Program/Data EE Error Flag bit
1 = A write operation is prematurely terminated
(any RESET during self-timed programming in normal operation)
0 = The write operation completed Note: When a WRERR occurs, the EEPGD and CFGS bits are not cleared. This allows
tracing of the error condition.
FREE WRERR WREN WR RD
PIC18FXX2
bit 2 WREN: FLASH Program/Data EE Write Enable bit
1 = Allows write cycles 0 = Inhibits write to the EEPROM
bit 1 WR: Write Control bit
1 = Initiates a data EEPROM erase/write cycle or a program memory erase cycle or write cycle.
(The operation is self timed and the bit is cleared by hardware once write is complete. The WR bit can only be set (not cleared) in software.)
0 = Write cycle to the EEPROM is complete
bit 0 RD: Read Control bit
1 = Initiates an EEPROM read
(Read takes one cycle. RD is cleared in hardware. The RD bit can only be set (not cleared) in software. RD bit cannot be set when EEPGD = 1.)
0 = Does not initiate an EEPROM read
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 57
PIC18FXX2

5.2.2 TABLAT - TABLE LATCH REGISTER

The Table Latch (TABLAT) is an 8-bit register mapped into the SFR space. The Table Latch is used to hold 8-bit data during data transfers between program memory and data RAM.

5.2.3 TBLPTR - TABLE POINTER REGISTER

The Table Pointer (TBLPTR) addresses a byte within the program memory. The TBLPTR is comprised of three SFR registers: Table Pointer Upper Byte, Table Pointer High Byte and Table Pointer Low Byte (TBLPTRU:TBLPTRH:TBLPTRL). These three regis­ters join to form a 22-bit wide pointer. The low order 21 bits allow the device to address up to 2 Mbytes of pro­gram memory space. The 22nd bit allows access to the Device ID, the User ID and the Configuration bits.
The table pointer, TBLPTR, is used by the TBLRD and TBLWT instructions. These instructions can update the TBLPTR in one of four ways based on the table opera­tion. These operations are shown in Table 5-1. These operations on the TBLPTR only affect the low order 21 bits.

5.2.4 TABLE POINTER BOUNDARIES

TBLPTR is used in reads, writes, and erases of the FLASH program memory.
When a TBLRD is executed, all 22 bits of the Table Pointer determine which byte is read from program memory into TABLAT.
When a TBLWT is executed, the three LSbs of the Table Pointer (TBLPTR<2:0>) determine which of the eight program memory holding registers is written to. When the timed write to program memory (long write) begins, the 19 MSbs of the Table Pointer, TBLPTR (TBLPTR<21:3>), will determine which program mem­ory block of 8 bytes is written to. For more detail, see Section 5.5 (“Writing to FLASH Program Memory”).
When an erase of program memory is executed, the 16 MSbs of the Table Pointer (TBLPTR<21:6>) point to the 64-byte block that will be erased. The Least Significant bits (TBLPTR<5:0>) are ignored.
Figure 5-3 describes the relevant boundaries of TBLPTR based on FLASH program memory operations.
TABLE 5-1: TABLE POINTER OPERATIONS WITH TBLRD AND TBLWT INSTRUCTIONS
Example Operation on Table Pointer
TBLRD* TBLWT*
TBLRD*+ TBLWT*+
TBLRD*­TBLWT*-
TBLRD+* TBLWT+*
TBLPTR is incremented after the read/write
TBLPTR is decremented after the read/write
TBLPTR is incremented before the read/write
TBLPTR is not modified
FIGURE 5-3: TABLE POINTER BOUNDARIES BASED ON OPERATION
21 16 15 87 0
TBLPTRU
ERASE - TBLPTR<21:6>
TBLPTRH
WRITE - TBLPTR<21:3>
TBLPTRL
READ - TBLPTR<21:0>
DS39564C-page 58 © 2006 Microchip Technology Inc.
PIC18FXX2

5.3 Reading the FLASH Program Memory

The TBLRD instruction is used to retrieve data from pro- gram memory and place into data RAM. Table Reads from program memory are performed one byte at a time.
TBLPTR points to a byte address in program space. Executing TBLRD places the byte pointed to into TABLAT. In addition, TBLPTR can be modified automatically for the next Table Read operation.
The internal program memory is typically organized by words. The Least Significant bit of the address selects between the high and low bytes of the word. Figure 5-4 shows the interface between the internal program memory and the TABLAT.

FIGURE 5-4: READS FROM FLASH PROGRAM MEMORY

Program Memory
(Even Byte Address)
(Odd Byte Address)
TBLPTR = xxxxx1
Instruction Register
(IR)
FETCH
TBLRD
EXAMPLE 5-1: READING A FLASH PROGRAM MEMORY WORD
MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base MOVWF TBLPTRU ; address of the word MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW
READ_WORD
MOVWF TBLPTRL
TBLRD*+ ; read into TABLAT and increment MOVF TABLAT, W ; get data MOVWF WORD_EVEN TBLRD*+ ; read into TABLAT and increment MOVF TABLAT, W ; get data MOVWF WORD_ODD
TBLPTR = xxxxx0
TAB LAT
Read Register
© 2006 Microchip Technology Inc. DS39564C-page 59
PIC18FXX2

5.4 Erasing FLASH Program memory

The minimum erase block is 32 words or 64 bytes. Only through the use of an external programmer, or through ICSP control can larger blocks of program memory be bulk erased. Word erase in the FLASH array is not supported.
When initiating an erase sequence from the micro­controller itself, a block of 64 bytes of program memory is erased. The Most Significant 16 bits of the TBLPTR<21:6> point to the block being erased. TBLPTR<5:0> are ignored.
The EECON1 register commands the erase operation. The EEPGD bit must be set to point to the FLASH pro­gram memory. The WREN bit must be set to enable write operations. The FREE bit is set to select an erase operation.
For protection, the write initiate sequence for EECON2 must be used.

5.4.1 FLASH PROGRAM MEMORY ERASE SEQUENCE

The sequence of events for erasing a block of internal program memory location is:
1. Load table pointer with address of row being
erased.
2. Set EEPGD bit to point to program memory,
clear CFGS bit to access program memory, set WREN bit to enable writes, and set FREE bit to enable the erase.
3. Disable interrupts.
4. Write 55h to EECON2.
5. Write AAh to EECON2.
6. Set the WR bit. This will begin the row erase
cycle.
7. The CPU will stall for duration of the erase
(about 2 ms using internal timer).
8. Re-enable interrupts.
A long write is necessary for erasing the internal FLASH. Instruction execution is halted while in a long write cycle. The long write will be terminated by the internal programming timer.
EXAMPLE 5-2: ERASING A FLASH PROGRAM MEMORY ROW
MOVLW CODE_ADDR_UPPER ; load TBLPTR with the base MOVWF TBLPTRU ; address of the memory block MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW
ERASE_ROW
Required MOVWF EECON2 ; write 55h Sequence MOVLW AAh
MOVWF TBLPTRL
BSF EECON1,EEPGD ; point to FLASH program memory BCF EECON1,CFGS ; access FLASH program memory BSF EECON1,WREN ; enable write to memory BSF EECON1,FREE ; enable Row Erase operation BCF INTCON,GIE ; disable interrupts MOVLW 55h
MOVWF EECON2 ; write AAh BSF EECON1,WR ; start erase (CPU stall) BSF INTCON,GIE ; re-enable interrupts
DS39564C-page 60 © 2006 Microchip Technology Inc.
PIC18FXX2

5.5 Writing to FLASH Program Memory

The minimum programming block is 4 words or 8 bytes. Word or byte programming is not supported.
Table Writes are used internally to load the holding reg­isters needed to program the FLASH memory. There are 8 holding registers used by the Table Writes for programming.
Since the Table Latch (TABLAT) is only a single byte, the TBLWT instruction has to be executed 8 times for each programming operation. All of the Table Write
operations will essentially be short writes, because only the holding registers are written. At the end of updating 8 registers, the EECON1 register must be written to, to start the programming operation with a long write.
The long write is necessary for programming the inter­nal FLASH. Instruction execution is halted while in a long write cycle. The long write will be terminated by the internal programming timer.
The EEPROM on-chip timer controls the write time. The write/erase voltages are generated by an on-chip charge pump rated to operate over the voltage range of the device for byte or word operations.

FIGURE 5-5: TABLE WRITES TO FLASH PROGRAM MEMORY

TAB LAT
Write Register
8 8 8
TBLPTR = xxxxx2
Holding Register
TBLPTR = xxxxx0
Holding Register
8
TBLPTR = xxxxx1
Holding Register
TBLPTR = xxxxx7
Holding Register
Program Memory
5.5.1 FLASH PROGRAM MEMORY WRITE
SEQUENCE
The sequence of events for programming an internal program memory location should be:
1. Read 64 bytes into RAM.
2. Update data values in RAM as necessary.
3. Load Table Pointer with address being erased.
4. Do the row erase procedure.
5. Load Table Pointer with address of first byte
being written.
6. Write the first 8 bytes into the holding registers
with auto-increment (TBLWT*+ or TBLWT+*).
7. Set EEPGD bit to point to program memory,
clear the CFGS bit to access program memory, and set WREN to enable byte writes.
8. Disable interrupts.
9. Write 55h to EECON2.
10. Write AAh to EECON2.
11. Set the WR bit. This will begin the write cycle.
12. The CPU will stall for duration of the write (about 2 ms using internal timer).
13. Re-enable interrupts.
14. Repeat steps 6-14 seven times, to write 64 bytes.
15. Verify the memory (Table Read).
This procedure will require about 18 ms to update one row of 64 bytes of memory. An example of the required code is given in Example 5-3.
Note: Before setting the WR bit, the table pointer
address needs to be within the intended address range of the 8 bytes in the holding registers.
© 2006 Microchip Technology Inc. DS39564C-page 61
PIC18FXX2
EXAMPLE 5-3: WRITING TO FLASH PROGRAM MEMORY
MOVLW D'64 ; number of bytes in erase block MOVWF COUNTER MOVLW BUFFER_ADDR_HIGH ; point to buffer MOVWF FSR0H MOVLW BUFFER_ADDR_LOW MOVWF FSR0L MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base MOVWF TBLPTRU ; address of the memory block MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL
READ_BLOCK
MODIFY_WORD
ERASE_BLOCK
WRITE_BUFFER_BACK
PROGRAM_LOOP
WRITE_WORD_TO_HREGS
TBLRD*+ ; read into TABLAT, and inc MOVF TABLAT, W ; get data MOVWF POSTINC0 ; store data DECFSZ COUNTER ; done? BRA READ_BLOCK ; repeat
MOVLW DATA_ADDR_HIGH ; point to buffer MOVWF FSR0H MOVLW DATA_ADDR_LOW MOVWF FSR0L MOVLW NEW_DATA_LOW ; update buffer word MOVWF POSTINC0 MOVLW NEW_DATA_HIGH MOVWF INDF0
MOVLW CODE_ADDR_UPPER ; load TBLPTR with the base MOVWF TBLPTRU ; address of the memory block MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL BSF EECON1,EEPGD ; point to FLASH program memory BCF EECON1,CFGS ; access FLASH program memory BSF EECON1,WREN ; enable write to memory BSF EECON1,FREE ; enable Row Erase operation BCF INTCON,GIE ; disable interrupts MOVLW 55h MOVWF EECON2 ; write 55h MOVLW AAh MOVWF EECON2 ; write AAh BSF EECON1,WR ; start erase (CPU stall) BSF INTCON,GIE ; re-enable interrupts TBLRD*- ; dummy read decrement
MOVLW 8 ; number of write buffer groups of 8 bytes MOVWF COUNTER_HI MOVLW BUFFER_ADDR_HIGH ; point to buffer MOVWF FSR0H MOVLW BUFFER_ADDR_LOW MOVWF FSR0L
MOVLW 8 ; number of bytes in holding register MOVWF COUNTER
MOVF POSTINC0, W ; get low byte of buffer data MOVWF TABLAT ; present data to table latch TBLWT+* ; write data, perform a short write
; to internal TBLWT holding register. DECFSZ COUNTER ; loop until buffers are full BRA WRITE_WORD_TO_HREGS
DS39564C-page 62 © 2006 Microchip Technology Inc.
EXAMPLE 5-3: WRITING TO FLASH PROGRAM MEMORY (CONTINUED)

5.5.2 WRITE VERIFY

PIC18FXX2
© 2006 Microchip Technology Inc. DS39564C-page 63
PIC18FXX2
NOTES:
DS39564C-page 64 © 2006 Microchip Technology Inc.
PIC18FXX2

6.0 DATA EEPROM MEMORY

The Data EEPROM is readable and writable during normal operation over the entire V memory is not directly mapped in the register file space. Instead, it is indirectly addressed through the Special Function Registers (SFR).
There are four SFRs used to read and write the program and data EEPROM memory. These registers are:
• EECON1
• EECON2
• EEDATA
• EEADR
The EEPROM data memory allows byte read and write. When interfacing to the data memory block, EEDATA holds the 8-bit data for read/write and EEADR holds the address of the EEPROM location being accessed. These devices have 256 bytes of data EEPROM with an address range from 0h to FFh.
The EEPROM data memory is rated for high erase/ write cycles. A byte write automatically erases the loca­tion and writes the new data (erase-before-write). The write time is controlled by an on-chip timer. The write time will vary with voltage and temperature, as well as from chip to chip. Please refer to parameter D122 (Electrical Characteristics, Section 22.0) for exact limits.
DD range. The data

6.1 EEADR

The address register can address up to a maximum of 256 bytes of data EEPROM.

6.2 EECON1 and EECON2 Registers

EECON1 is the control register for EEPROM memory accesses.
EECON2 is not a physical register. Reading EECON2 will read all '0's. The EECON2 register is used exclusively in the EEPROM write sequence.
Control bits RD and WR initiate read and write opera­tions, respectively. These bits cannot be cleared, only set, in software. They are cleared in hardware at the completion of the read or write operation. The inability to clear the WR bit in software prevents the accidental or premature termination of a write operation.
The WREN bit, when set, will allow a write operation. On power-up, the WREN bit is clear. The WRERR bit is set when a write operation is interrupted by a MCLR Reset, or a WDT Time-out Reset during normal opera­tion. In these situations, the user can check the WRERR bit and rewrite the location. It is necessary to reload the data and address registers (EEDATA and EEADR), due to the RESET condition forcing the contents of the registers to zero.
Note: Interrupt flag bit, EEIF in the PIR2 register,
is set when write is complete. It must be cleared in software.
© 2006 Microchip Technology Inc. DS39564C-page 65
PIC18FXX2
REGISTER 6-1: EECON1 REGISTER (ADDRESS FA6h)
R/W-x R/W-x U-0 R/W-0 R/W-x R/W-0 R/S-0 R/S-0
EEPGD CFGS FREE WRERR WREN WR RD
bit 7 bit 0
bit 7 EEPGD: FLASH Program or Data EEPROM Memory Select bit
1 = Access FLASH Program memory 0 = Access Data EEPROM memory
bit 6 CFGS: FLASH Program/Data EE or Configuration Select bit
1 = Access Configuration or Calibration registers 0 = Access FLASH Program or Data EEPROM memory
bit 5 Unimplemented: Read as '0' bit 4 FREE: FLASH Row Erase Enable bit
1 = Erase the program memory row addressed by TBLPTR on the next WR command
(cleared by completion of erase operation)
0 = Perform write only
bit 3 WRERR: FLASH Program/Data EE Error Flag bit
1 = A write operation is prematurely terminated
(any MCLR
0 = The write operation completed Note: When a WRERR occurs, the EEPGD or FREE bits are not cleared. This allows tracing
or any WDT Reset during self-timed programming in normal operation)
of the error condition.
bit 2 WREN: FLASH Program/Data EE Write Enable bit
1 = Allows write cycles 0 = Inhibits write to the EEPROM
bit 1 WR: Write Control bit
1 = Initiates a data EEPROM erase/write cycle or a program memory erase cycle or write cycle.
(The operation is self-timed and the bit is cleared by hardware once write is complete. The WR bit can only be set (not cleared) in software.)
0 = Write cycle to the EEPROM is complete
bit 0 RD: Read Control bit
1 = Initiates an EEPROM read
(Read takes one cycle. RD is cleared in hardware. The RD bit can only be set (not cleared) in software. RD bit cannot be set when EEPGD = 1.)
0 = Does not initiate an EEPROM read
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
DS39564C-page 66 © 2006 Microchip Technology Inc.
PIC18FXX2

6.3 Reading the Data EEPROM Memory

To read a data memory location, the user must write the address to the EEADR register, clear the EEPGD con­trol bit (EECON1<7>), clear the CFGS control bit
EXAMPLE 6-1: DATA EEPROM READ
MOVLW DATA_EE_ADDR ; MOVWF EEADR ; Data Memory Address to read BCF EECON1, EEPGD ; Point to DATA memory BCF EECON1, CFGS ; Access program FLASH or Data EEPROM memory BSF EECON1, RD ; EEPROM Read MOVF EEDATA, W ; W = EEDATA

6.4 Writing to the Data EEPROM Memory

To write an EEPROM data location, the address must first be written to the EEADR register and the data writ­ten to the EEDATA register. Then the sequence in Example 6-2 must be followed to initiate the write cycle.
The write will not initiate if the above sequence is not exactly followed (write 55h to EECON2, write AAh to EECON2, then set WR bit) for each byte. It is strongly recommended that interrupts be disabled during this code segment.
Additionally, the WREN bit in EECON1 must be set to enable writes. This mechanism prevents accidental writes to data EEPROM due to unexpected code exe-
(EECON1<6>), and then set control bit RD (EECON1<0>). The data is available for the very next instruction cycle; therefore, the EEDATA register can be read by the next instruction. EEDATA will hold this value until another read operation, or until it is written to by the user (during a write operation).
cution (i.e., runaway programs). The WREN bit should be kept clear at all times, except when updating the EEPROM. The WREN bit is not cleared by hardware.
After a write sequence has been initiated, EECON1, EEADR and EDATA cannot be modified. The WR bit will be inhibited from being set unless the WREN bit is set. The WREN bit must be set on a previous instruc­tion. Both WR and WREN cannot be set with the same instruction.
At the completion of the write cycle, the WR bit is cleared in hardware and the EEPROM Write Complete Interrupt Flag bit (EEIF) is set. The user may either enable this interrupt, or poll this bit. EEIF must be cleared by software.
EXAMPLE 6-2: DATA EEPROM WRITE
MOVLW DATA_EE_ADDR ; MOVWF EEADR ; Data Memory Address to read MOVLW DATA_EE_DATA ; MOVWF EEDATA ; Data Memory Value to write BCF EECON1, EEPGD ; Point to DATA memory BCF EECON1, CFGS ; Access program FLASH or Data EEPROM memory BSF EECON1, WREN ; Enable writes
Required MOVLW 55h ; Sequence MOVWF EECON2 ; Write 55h
BCF INTCON, GIE ; Disable interrupts
MOVLW AAh ; MOVWF EECON2 ; Write AAh BSF EECON1, WR ; Set WR bit to begin write BSF INTCON, GIE ; Enable interrupts
. ; user code execution . .
BCF EECON1, WREN ; Disable writes on write complete (EEIF set)
© 2006 Microchip Technology Inc. DS39564C-page 67
PIC18FXX2

6.5 Write Verify

Depending on the application, good programming practice may dictate that the value written to the mem­ory should be verified against the original value. This should be used in applications where excessive writes can stress bits near the specification limit.

6.6 Protection Against Spurious Write

There are conditions when the device may not want to write to the data EEPROM memory. To protect against spurious EEPROM writes, various mechanisms have been built-in. On power-up, the WREN bit is cleared. Also, the Power-up Timer (72 ms duration) prevents EEPROM write.
The write initiate sequence and the WREN bit together help prevent an accidental write during brown-out, power glitch, or software malfunction.

6.7 Operation During Code Protect

Data EEPROM memory has its own code protect mechanism. External Read and Write operations are disabled if either of these mechanisms are enabled.
The microcontroller itself can both read and write to the internal Data EEPROM, regardless of the state of the code protect configuration bit. Refer to “Special Features of the CPU” (Section 19.0) for additional information.

6.8 Using the Data EEPROM

The data EEPROM is a high endurance, byte address­able array that has been optimized for the storage of frequently changing information (e.g., program vari­ables or other data that are updated often). Frequently changing values will typically be updated more often than specification D124. If this is not the case, an array refresh must be performed. For this reason, variables that change infrequently (such as constants, IDs, cali­bration, etc.) should be stored in FLASH program memory.
A simple data EEPROM refresh routine is shown in Example 6-3.
Note: If data EEPROM is only used to store con-
stants and/or data that changes rarely, an array refresh is likely not required. See specification D124.
EXAMPLE 6-3: DATA EEPROM REFRESH ROUTINE
clrf EEADR ; Start at address 0 bcf EECON1,CFGS ; Set for memory bcf EECON1,EEPGD ; Set for Data EEPROM bcf INTCON,GIE ; Disable interrupts
Loop ; Loop to refresh array
bsf EECON1,WREN ; Enable writes
bsf EECON1,RD ; Read current address movlw 55h ; movwf EECON2 ; Write 55h movlw AAh ; movwf EECON2 ; Write AAh bsf EECON1,WR ; Set WR bit to begin write btfsc EECON1,WR ; Wait for write to complete bra $-2 incfsz EEADR,F ; Increment address bra Loop ; Not zero, do it again
bcf EECON1,WREN ; Disable writes bsf INTCON,GIE ; Enable interrupts
DS39564C-page 68 © 2006 Microchip Technology Inc.

TABLE 6-1: REGISTERS ASSOCIATED WITH DATA EEPROM MEMORY

PIC18FXX2
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
FF2h INTCON GIE/
FA9h EEADR EEPROM Address Register 0000 0000 0000 0000
FA8h EEDATA EEPROM Data Register 0000 0000 0000 0000
FA7h EECON2 EEPROM Control Register2 (not a physical register)
FA6h EECON1 EEPGD CFGS FREE WRERR WREN WR
FA2h IPR2
FA1h PIR2
FA0h PIE2
Legend: x = unknown, u = unchanged, r = reserved, - = unimplemented, read as '0'.
Shaded cells are not used during FLASH/EEPROM access.
GIEH
EEIP BCLIP LV DIP TMR3IP CCP2IP ---1 1111 ---1 1111
—EEIFBCLIF LVDI F TMR3IF CCP2IF ---0 0000 ---0 0000
EEIE BCLIE LV DIE TMR3IE CCP2IE ---0 0000 ---0 0000
PEIE/ GIEL
T0IE INTE RBIE T0IF INTF RBIF 0000 000x 0000 000u
RD xx-0 x000 uu-0 u000
Value on:
POR, BOR
Value on
All Other
RESETS
© 2006 Microchip Technology Inc. DS39564C-page 69
PIC18FXX2
NOTES:
DS39564C-page 70 © 2006 Microchip Technology Inc.
PIC18FXX2

7.0 8 X 8 HARDWARE MULTIPLIER

7.1 Introduction

An 8 x 8 hardware multiplier is included in the ALU of the PIC18FXX2 devices. By making the multiply a hardware operation, it completes in a single instruction cycle. This is an unsigned multiply that gives a 16-bit result. The result is stored into the 16-bit product regis­ter pair (PRODH:PRODL). The multiplier does not affect any flags in the ALUSTA register.

TABLE 7-1: PERFORMANCE COMPARISON

Program
Routine Multiply Method
8 x 8 unsigned
8 x 8 signed
16 x 16 unsigned
16 x 16 signed
Without hardware multiply 13 69 6.9 μs27.6 μs69 μs
Hardware multiply 1 1 100 ns 400 ns 1 μs
Without hardware multiply 33 91 9.1 μs36.4 μs91 μs
Hardware multiply 6 6 600 ns 2.4 μs6 μs
Without hardware multiply 21 242 24.2 μs96.8 μs242 μs
Hardware multiply 24 24 2.4 μs9.6 μs24 μs
Without hardware multiply 52 254 25.4 μs 102.6 μs254 μs
Hardware multiply 36 36 3.6 μs14.4 μs36 μs
Memory (Words)
Making the 8 x 8 multiplier execute in a single cycle gives the following advantages:
• Higher computational throughput
• Reduces code size requirements for multiply algorithms
The performance increase allows the device to be used in applications previously reserved for Digital Signal Processors.
Table 7-1 shows a performance comparison between enhanced devices using the single cycle hardware mul­tiply, and performing the same function without the hardware multiply.
Cycles
(Max)
@ 40 MHz @ 10 MHz @ 4 MHz
Time

7.2 Operation

Example 7-1 shows the sequence to do an 8 x 8 unsigned multiply. Only one instruction is required when one argument of the multiply is already loaded in the WREG register.
Example 7-2 shows the sequence to do an 8 x 8 signed multiply. To account for the sign bits of the arguments, each argument’s Most Significant bit (MSb) is tested and the appropriate subtractions are done.
EXAMPLE 7-1: 8 x 8 UNSIGNED
MULTIPLY ROUTINE
MOVF ARG1, W ; MULWF ARG2 ; ARG1 * ARG2 -> ; PRODH:PRODL
EXAMPLE 7-2: 8 x 8 SIGNED MULTIPLY
ROUTINE
MOVF ARG1, W MULWF ARG2 ; ARG1 * ARG2 -> ; PRODH:PRODL BTFSC ARG2, SB ; Test Sign Bit SUBWF PRODH, F ; PRODH = PRODH ; - ARG1 MOVF ARG2, W BTFSC ARG1, SB ; Test Sign Bit SUBWF PRODH, F ; PRODH = PRODH ; - ARG2
Example 7-3 shows the sequence to do a 16 x 16 unsigned multiply. Equation 7-1 shows the algorithm that is used. The 32-bit result is stored in four registers, RES3:RES0.
EQUATION 7-1: 16 x 16 UNSIGNED
MULTIPLICATION ALGORITHM
RES3:RES0 = ARG1H:ARG1L ARG2H:ARG2L
= (ARG1H ARG2H 2
(ARG1H ARG2L 2 (ARG1L ARG2H 2 (ARG1L ARG2L)
16
) +
8
) +
8
) +
© 2006 Microchip Technology Inc. DS39564C-page 71
PIC18FXX2
EXAMPLE 7-3: 16 x 16 UNSIGNED
MULTIPLY ROUTINE
MOVF ARG1L, W MULWF ARG2L ; ARG1L * ARG2L ->
MOVFF PRODH, RES1 ; MOVFF PRODL, RES0 ;
;
MOVF ARG1H, W MULWF ARG2H ; ARG1H * ARG2H ->
MOVFF PRODH, RES3 ; MOVFF PRODL, RES2 ;
;
MOVF ARG1L, W MULWF ARG2H ; ARG1L * ARG2H ->
MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;
;
MOVF ARG1H, W ; MULWF ARG2L ; ARG1H * ARG2L ->
MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;
; PRODH:PRODL
; PRODH:PRODL
; PRODH:PRODL
; PRODH:PRODL
Example 7-4 shows the sequence to do a 16 x 16 signed multiply. Equation 7-2 shows the algorithm used. The 32-bit result is stored in four registers, RES3:RES0. To account for the sign bits of the argu­ments, each argument pairs Most Significant bit (MSb) is tested and the appropriate subtractions are done.
EQUATION 7-2: 16 x 16 SIGNED
MULTIPLICATION ALGORITHM
RES3:RES0
=ARG1H:ARG1L • ARG2H:ARG2L = (ARG1H ARG2H 2
(ARG1H ARG2L 2 (ARG1L ARG2H 2 (ARG1L ARG2L) + (-1 ARG2H<7> ARG1H:ARG1L 216) + (-1 ARG1H<7> ARG2H:ARG2L 2
16
) +
8
) +
8
) +
16
)
EXAMPLE 7-4: 16 x 16 SIGNED
MULTIPLY ROUTINE
MOVF ARG1L, W MULWF ARG2L ; ARG1L * ARG2L ->
; PRODH:PRODL MOVFF PRODH, RES1 ; MOVFF PRODL, RES0 ;
;
MOVF ARG1H, W MULWF ARG2H ; ARG1H * ARG2H ->
; PRODH:PRODL MOVFF PRODH, RES3 ; MOVFF PRODL, RES2 ;
;
MOVF ARG1L, W MULWF ARG2H ; ARG1L * ARG2H ->
; PRODH:PRODL MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;
;
MOVF ARG1H, W ; MULWF ARG2L ; ARG1H * ARG2L ->
; PRODH:PRODL MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;
;
BTFSS ARG2H, 7 ; ARG2H:ARG2L neg? BRA SIGN_ARG1 ; no, check ARG1 MOVF ARG1L, W ; SUBWF RES2 ; MOVF ARG1H, W ; SUBWFB RES3
; SIGN_ARG1
BTFSS ARG1H, 7 ; ARG1H:ARG1L neg? BRA CONT_CODE ; no, done MOVF ARG2L, W ; SUBWF RES2 ; MOVF ARG2H, W ; SUBWFB RES3
; CONT_CODE :
DS39564C-page 72 © 2006 Microchip Technology Inc.
PIC18FXX2

8.0 INTERRUPTS

The PIC18FXX2 devices have multiple interrupt sources and an interrupt priority feature that allows each interrupt source to be assigned a high priority level or a low priority level. The high priority interrupt vector is at 000008h and the low priority interrupt vector is at 000018h. High priority interrupt events will over­ride any low priority interrupts that may be in progress.
There are ten registers which are used to control interrupt operation. These registers are:
• RCON
•INTCON
• INTCON2
• INTCON3
• PIR1, PIR2
• PIE1, PIE2
• IPR1, IPR2
It is recommended that the Microchip header files sup­plied with MPLAB names in these registers. This allows the assembler/ compiler to automatically take care of the placement of these bits within the specified register.
Each interrupt source, except INT0, has three bits to control its operation. The functions of these bits are:
• Flag bit to indicate that an interrupt event occurred
• Enable bit that allows program execution to branch to the interrupt vector address when the flag bit is set
• Priority bit to select high priority or low priority
The interrupt priority feature is enabled by setting the IPEN bit (RCON<7>). When interrupt priority is enabled, there are two bits which enable interrupts glo­bally. Setting the GIEH bit (INTCON<7>) enables all interrupts that have the priority bit set. Setting the GIEL bit (INTCON<6>) enables all interrupts that have the priority bit cleared. When the interrupt flag, enable bit and appropriate global interrupt enable bit are set, the interrupt will vector immediately to address 000008h or 000018h, depending on the priority level. Individual interrupts can be disabled through their corresponding enable bits.
®
IDE be used for the symbolic bit
When the IPEN bit is cleared (default state), the inter­rupt priority feature is disabled and interrupts are com­patible with PICmicro Compatibility mode, the interrupt priority bits for each source have no effect. INTCON<6> is the PEIE bit, which enables/disables all peripheral interrupt sources. INTCON<7> is the GIE bit, which enables/disables all interrupt sources. All interrupts branch to address 000008h in Compatibility mode.
When an interrupt is responded to, the Global Interrupt Enable bit is cleared to disable further interrupts. If the IPEN bit is cleared, this is the GIE bit. If interrupt priority levels are used, this will be either the GIEH or GIEL bit. High priority interrupt sources can interrupt a low priority interrupt.
The return address is pushed onto the stack and the PC is loaded with the interrupt vector address (000008h or 000018h). Once in the Interrupt Service Routine, the source(s) of the interrupt can be deter­mined by polling the interrupt flag bits. The interrupt flag bits must be cleared in software before re-enabling interrupts to avoid recursive interrupts.
The “return from interrupt” instruction, RETFIE, exits the interrupt routine and sets the GIE bit (GIEH or GIEL if priority levels are used), which re-enables interrupts.
For external interrupt events, such as the INT pins or the PORTB input change interrupt, the interrupt latency will be three to four instruction cycles. The exact latency is the same for one or two-cycle instructions. Individual interrupt flag bits are set, regardless of the status of their corresponding enable bit or the GIE bit.
Note: Do not use the MOVFF instruction to modify
any of the Interrupt control registers while any interrupt is enabled. Doing so may cause erratic microcontroller behavior.
®
mid-range devices. In
© 2006 Microchip Technology Inc. DS39564C-page 73
PIC18FXX2

FIGURE 8-1: INTERRUPT LOGIC

Peripheral Interrupt Flag bit Peripheral Interrupt Enable bit Peripheral Interrupt Priority bit
TMR1IF TMR1IE TMR1IP
XXXXIF XXXXIE XXXXIP
High Priority Interrupt Generation
Low Priority Interrupt Generation
Peripheral Interrupt Flag bit Peripheral Interrupt Enable bit Peripheral Interrupt Priority bit
TMR1IF TMR1IE TMR1IP
XXXXIF XXXXIE XXXXIP
Additional Peripheral Interrupts
Additional Peripheral Interrupts
TMR0IF
TMR0IE TMR0IP
RBIF RBIE
RBIP
INT1IF INT1IE
INT1IP
INT2IF INT2IE
INT2IP
IPE
TMR0IF TMR0IE TMR0IP
INT0IF INT0IE
INT1IF INT1IE INT1IP INT2IF INT2IE INT2IP
IPEN
GIEL/PEIE
RBIF RBIE RBIP
IPEN
Wake-up if in SLEEP mode
Interrupt to CPU Vector to location
0008h
GIEH/GIE
Interrupt to CPU Vector to Location 0018h
GIEL/PEIE
GIE/GIEH
DS39564C-page 74 © 2006 Microchip Technology Inc.
PIC18FXX2

8.1 INTCON Registers

The INTCON Registers are readable and writable reg­isters, which contain various enable, priority and flag bits.
REGISTER 8-1: INTCON REGISTER
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-x
GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF
bit 7 bit 0
bit 7 GIE/GIEH: Global Interrupt Enable bit
When IPEN = 0:
1 = Enables all unmasked interrupts 0 = Disables all interrupts
When IPEN = 1:
1 = Enables all high priority interrupts 0 = Disables all interrupts
bit 6 PEIE/GIEL: Peripheral Interrupt Enable bit
When IPEN = 0:
1 = Enables all unmasked peripheral interrupts 0 = Disables all peripheral interrupts
When IPEN = 1:
1 = Enables all low priority peripheral interrupts 0 = Disables all low priority peripheral interrupts
bit 5 TMR0IE: TMR0 Overflow Interrupt Enable bit
1 = Enables the TMR0 overflow interrupt 0 = Disables the TMR0 overflow interrupt
bit 4 INT0IE: INT0 External Interrupt Enable bit
1 = Enables the INT0 external interrupt 0 = Disables the INT0 external interrupt
bit 3 RBIE: RB Port Change Interrupt Enable bit
1 = Enables the RB port change interrupt 0 = Disables the RB port change interrupt
bit 2 TMR0IF: TMR0 Overflow Interrupt Flag bit
1 = TMR0 register has overflowed (must be cleared in software) 0 = TMR0 register did not overflow
bit 1 INT0IF: INT0 External Interrupt Flag bit
1 = The INT0 external interrupt occurred (must be cleared in software) 0 = The INT0 external interrupt did not occur
bit 0 RBIF: RB Port Change Interrupt Flag bit
1 = At least one of the RB7:RB4 pins changed state (must be cleared in software) 0 = None of the RB7:RB4 pins have changed state
Note: A mismatch condition will continue to set this bit. Reading PORTB will end the
mismatch condition and allow the bit to be cleared.
Note: Interrupt flag bits are set when an interrupt
condition occurs, regardless of the state of its corresponding enable bit or the global enable bit. User software should ensure the appropriate interrupt flag bits are clear prior to enabling an interrupt. This feature allows for software polling.
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 75
PIC18FXX2
REGISTER 8-2: INTCON2 REGISTER
R/W-1 R/W-1 R/W-1 R/W-1 U-0 R/W-1 U-0 R/W-1
RBPU INTEDG0 INTEDG1 INTEDG2 —TMR0IP—RBIP
bit 7 bit 0
bit 7 RBPU
bit 6 INTEDG0:External Interrupt0 Edge Select bit
bit 5 INTEDG1: External Interrupt1 Edge Select bit
bit 4 INTEDG2: External Interrupt2 Edge Select bit
bit 3 Unimplemented: Read as '0' bit 2 TMR0IP: TMR0 Overflow Interrupt Priority bit
bit 1 Unimplemented: Read as '0' bit 0 RBIP: RB Port Change Interrupt Priority bit
: PORTB Pull-up Enable bit
1 = All PORTB pull-ups are disabled 0 = PORTB pull-ups are enabled by individual port latch values
1 = Interrupt on rising edge 0 = Interrupt on falling edge
1 = Interrupt on rising edge 0 = Interrupt on falling edge
1 = Interrupt on rising edge 0 = Interrupt on falling edge
1 = High priority 0 = Low priority
1 = High priority 0 = Low priority
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
Note: Interrupt flag bits are set when an interrupt condition occurs, regardless of the state
of its corresponding enable bit or the global enable bit. User software should ensure the appropriate interrupt flag bits are clear prior to enabling an interrupt. This feature allows for software polling.
DS39564C-page 76 © 2006 Microchip Technology Inc.
REGISTER 8-3: INTCON3 REGISTER
R/W-1 R/W-1 U-0 R/W-0 R/W-0 U-0 R/W-0 R/W-0
INT2IP INT1IP INT2IE INT1IE INT2IF INT1IF
bit 7 bit 0
bit 7 INT2IP: INT2 External Interrupt Priority bit
1 = High priority 0 = Low priority
bit 6 INT1IP: INT1 External Interrupt Priority bit
1 = High priority 0 = Low priority
bit 5 Unimplemented: Read as '0' bit 4 INT2IE: INT2 External Interrupt Enable bit
1 = Enables the INT2 external interrupt 0 = Disables the INT2 external interrupt
bit 3 INT1IE: INT1 External Interrupt Enable bit
1 = Enables the INT1 external interrupt 0 = Disables the INT1 external interrupt
bit 2 Unimplemented: Read as '0' bit 1 INT2IF: INT2 External Interrupt Flag bit
1 = The INT2 external interrupt occurred (must be cleared in software) 0 = The INT2 external interrupt did not occur
bit 0 INT1IF: INT1 External Interrupt Flag bit
1 = The INT1 external interrupt occurred (must be cleared in software) 0 = The INT1 external interrupt did not occur
PIC18FXX2
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
Note: Interrupt flag bits are set when an interrupt condition occurs, regardless of the state
of its corresponding enable bit or the global enable bit. User software should ensure the appropriate interrupt flag bits are clear prior to enabling an interrupt. This feature allows for software polling.
© 2006 Microchip Technology Inc. DS39564C-page 77
PIC18FXX2

8.2 PIR Registers

The PIR registers contain the individual flag bits for the peripheral interrupts. Due to the number of peripheral interrupt sources, there are two Peripheral Interrupt Flag Registers (PIR1, PIR2).
Note 1: Interrupt flag bits are set when an interrupt
condition occurs, regardless of the state of its corresponding enable bit or the global enable bit, GIE (INTCON<7>).
2: User software should ensure the appropriate
interrupt flag bits are cleared prior to enabling an interrupt, and after servicing that interrupt.
REGISTER 8-4: PIR1: PERIPHERAL INTERRUPT REQUEST (FLAG) REGISTER 1
R/W-0 R/W-0 R-0 R-0 R/W-0 R/W-0 R/W-0 R/W-0
(1)
PSPIF
bit 7 bit 0
bit 7 PSPIF
bit 6 ADIF: A/D Converter Interrupt Flag bit
bit 5 RCIF: USART Receive Interrupt Flag bit
bit 4 TXIF: USART Transmit Interrupt Flag bit (see Section 16.0 for details on TXIF functionality)
bit 3 SSPIF: Master Synchronous Serial Port Interrupt Flag bit
bit 2 CCP1IF: CCP1 Interrupt Flag bit
bit 1 TMR2IF: TMR2 to PR2 Match Interrupt Flag bit
bit 0 TMR1IF: TMR1 Overflow Interrupt Flag bit
(1)
1 = A read or a write operation has taken place (must be cleared in software) 0 = No read or write has occurred
1 = An A/D conversion completed (must be cleared in software) 0 = The A/D conversion is not complete
1 = The USART receive buffer, RCREG, is full (cleared when RCREG is read) 0 = The USART receive buffer is empty
1 = The USART transmit buffer, TXREG, is empty (cleared when TXREG is written) 0 = The USART transmit buffer is full
1 = The transmission/reception is complete (must be cleared in software) 0 = Waiting to transmit/receive
Capture mode:
1 = A TMR1 register capture occurred (must be cleared in software) 0 = No TMR1 register capture occurred
Compare mode:
1 = A TMR1 register compare match occurred (must be cleared in software) 0 = No TMR1 register compare match occurred
PWM mode: Unused in this mode
1 = TMR2 to PR2 match occurred (must be cleared in software) 0 = No TMR2 to PR2 match occurred
1 = TMR1 register overflowed (must be cleared in software) 0 = MR1 register did not overflow
ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF
: Parallel Slave Port Read/Write Interrupt Flag bit
Note 1: This bit is reserved on PIC18F2X2 devices; always maintain this bit clear.
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
DS39564C-page 78 © 2006 Microchip Technology Inc.
PIC18FXX2
REGISTER 8-5: PIR2: PERIPHERAL INTERRUPT REQUEST (FLAG) REGISTER 2
U-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
EEIF BCLIF LVDIF TMR3IF CCP2IF
bit 7 bit 0
bit 7-5 Unimplemented: Read as '0' bit 4 EEIF: Data EEPROM/FLASH Write Operation Interrupt Flag bit
1 = The Write operation is complete (must be cleared in software) 0 = The Write operation is not complete, or has not been started
bit 3 BCLIF: Bus Collision Interrupt Flag bit
1 = A bus collision occurred (must be cleared in software) 0 = No bus collision occurred
bit 2 LVDIF: Low Voltage Detect Interrupt Flag bit
1 = A low voltage condition occurred (must be cleared in software) 0 = The device voltage is above the Low Voltage Detect trip point
bit 1 TMR3IF: TMR3 Overflow Interrupt Flag bit
1 = TMR3 register overflowed (must be cleared in software) 0 = TMR3 register did not overflow
bit 0 CCP2IF: CCPx Interrupt Flag bit
Capture mode:
1 = A TMR1 register capture occurred (must be cleared in software) 0 = No TMR1 register capture occurred
Compare mode:
1 = A TMR1 register compare match occurred (must be cleared in software) 0 = No TMR1 register compare match occurred
PWM mode: Unused in this mode
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 79
PIC18FXX2

8.3 PIE Registers

The PIE registers contain the individual enable bits for the peripheral interrupts. Due to the number of periph­eral interrupt sources, there are two Peripheral Inter­rupt Enable Registers (PIE1, PIE2). When IPEN = 0, the PEIE bit must be set to enable any of these peripheral interrupts.
REGISTER 8-6: PIE1: PERIPHERAL INTERRUPT ENABLE REGISTER 1
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
(1)
PSPIE
bit 7 bit 0
bit 7 PSPIE
bit 6 ADIE: A/D Converter Interrupt Enable bit
bit 5 RCIE: USART Receive Interrupt Enable bit
bit 4 TXIE: USART Transmit Interrupt Enable bit
bit 3 SSPIE: Master Synchronous Serial Port Interrupt Enable bit
bit 2 CCP1IE: CCP1 Interrupt Enable bit
bit 1 TMR2IE: TMR2 to PR2 Match Interrupt Enable bit
bit 0 TMR1IE: TMR1 Overflow Interrupt Enable bit
(1)
1 = Enables the PSP read/write interrupt 0 = Disables the PSP read/write interrupt
1 = Enables the A/D interrupt 0 = Disables the A/D interrupt
1 = Enables the USART receive interrupt 0 = Disables the USART receive interrupt
1 = Enables the USART transmit interrupt 0 = Disables the USART transmit interrupt
1 = Enables the MSSP interrupt 0 = Disables the MSSP interrupt
1 = Enables the CCP1 interrupt 0 = Disables the CCP1 interrupt
1 = Enables the TMR2 to PR2 match interrupt 0 = Disables the TMR2 to PR2 match interrupt
1 = Enables the TMR1 overflow interrupt 0 = Disables the TMR1 overflow interrupt
ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE
: Parallel Slave Port Read/Write Interrupt Enable bit
Note 1: This bit is reserved on PIC18F2X2 devices; always maintain this bit clear.
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
DS39564C-page 80 © 2006 Microchip Technology Inc.
PIC18FXX2
REGISTER 8-7: PIE2: PERIPHERAL INTERRUPT ENABLE REGISTER 2
U-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
EEIE BCLIE LVDIE TMR3IE CCP2IE
bit 7 bit 0
bit 7-5 Unimplemented: Read as '0' bit 4 EEIE: Data EEPROM/FLASH Write Operation Interrupt Enable bit
1 = Enabled 0 = Disabled
bit 3 BCLIE: Bus Collision Interrupt Enable bit
1 = Enabled 0 = Disabled
bit 2 LVDIE: Low Voltage Detect Interrupt Enable bit
1 = Enabled 0 = Disabled
bit 1 TMR3IE: TMR3 Overflow Interrupt Enable bit
1 = Enables the TMR3 overflow interrupt 0 = Disables the TMR3 overflow interrupt
bit 0 CCP2IE: CCP2 Interrupt Enable bit
1 = Enables the CCP2 interrupt 0 = Disables the CCP2 interrupt
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 81
PIC18FXX2

8.4 IPR Registers

The IPR registers contain the individual priority bits for the peripheral interrupts. Due to the number of periph­eral interrupt sources, there are two Peripheral Inter­rupt Priority Registers (IPR1, IPR2). The operation of the priority bits requires that the Interrupt Priority
DS39564C-page 82 © 2006 Microchip Technology Inc.
PIC18FXX2
REGISTER 8-9: IPR2: PERIPHERAL INTERRUPT PRIORITY REGISTER 2
U-0 U-0 U-0 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1
EEIP BCLIP LVDIP TMR3IP CCP2IP
bit 7 bit 0
bit 7-5 Unimplemented: Read as '0' bit 4 EEIP: Data EEPROM/FLASH Write Operation Interrupt Priority bit
1 = High priority 0 = Low priority
bit 3 BCLIP: Bus Collision Interrupt Priority bit
1 = High priority 0 = Low priority
bit 2 LVDIP: Low Voltage Detect Interrupt Priority bit
1 = High priority 0 = Low priority
bit 1 TMR3IP: TMR3 Overflow Interrupt Priority bit
1 = High priority 0 = Low priority
bit 0 CCP2IP: CCP2 Interrupt Priority bit
1 = High priority 0 = Low priority
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
© 2006 Microchip Technology Inc. DS39564C-page 83
PIC18FXX2

8.5 RCON Register

The RCON register contains the bit which is used to enable prioritized interrupts (IPEN).
REGISTER 8-10: RCON REGISTER
R/W-0 U-0 U-0 R/W-1 R-1 R-1 R/W-0 R/W-0
IPEN
bit 7 bit 0
bit 7 IPEN: Interrupt Priority Enable bit
1 = Enable priority levels on interrupts 0 = Disable priority levels on interrupts (16CXXX Compatibility mode)
bit 6-5 Unimplemented: Read as '0' bit 4 RI
bit 3 TO: Watchdog Time-out Flag bit
bit 2 PD: Power-down Detection Flag bit
bit 1 POR: Power-on Reset Status bit
bit 0 BOR: Brown-out Reset Status bit
: RESET Instruction Flag bit
For details of bit operation, see Register 4-3
For details of bit operation, see Register 4-3
For details of bit operation, see Register 4-3
For details of bit operation, see Register 4-3
For details of bit operation, see Register 4-3
—RITO PD POR BOR
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
DS39564C-page 84 © 2006 Microchip Technology Inc.
PIC18FXX2

8.6 INT0 Interrupt

External interrupts on the RB0/INT0, RB1/INT1 and RB2/INT2 pins are edge triggered: either rising, if the corresponding INTEDGx bit is set in the INTCON2 reg­ister, or falling, if the INTEDGx bit is clear. When a valid edge appears on the RBx/INTx pin, the corresponding flag bit INTxF is set. This interrupt can be disabled by clearing the corresponding enable bit INTxE. Flag bit INTxF must be cleared in software in the Interrupt Ser­vice Routine before re-enabling the interrupt. All exter­nal interrupts (INT0, INT1 and INT2) can wake-up the processor from SLEEP, if bit INTxE was set prior to going into SLEEP. If the global interrupt enable bit GIE is set, the processor will branch to the interrupt vector following wake-up.
Interrupt priority for INT1 and INT2 is determined by the value contained in the interrupt priority bits, INT1IP (INTCON3<6>) and INT2IP (INTCON3<7>). There is no priority bit associated with INT0. It is always a high priority interrupt source.

8.7 TMR0 Interrupt

In 8-bit mode (which is the default), an overflow (FFh 00h) in the TMR0 register will set flag bit TMR0IF. In 16-bit mode, an overflow (FFFFh → 0000h) in the TMR0H:TMR0L registers will set flag bit TMR0IF. The interrupt can be enabled/disabled by setting/ clearing enable bit T0IE (INTCON<5>). Interrupt prior­ity for Timer0 is determined by the value contained in the interrupt priority bit TMR0IP (INTCON2<2>). See Section 10.0 for further details on the Timer0 module.

8.8 PORTB Interrupt-on-Change

An input change on PORTB<7:4> sets flag bit RBIF (INTCON<0>). The interrupt can be enabled/disabled by setting/clearing enable bit, RBIE (INTCON<3>). Interrupt priority for PORTB interrupt-on-change is determined by the value contained in the interrupt priority bit, RBIP (INTCON2<0>).

8.9 Context Saving During Interrupts

During an interrupt, the return PC value is saved on the stack. Additionally, the WREG, STATUS and BSR regis­ters are saved on the fast return stack. If a fast return from interrupt is not used (See Section 4.3), the user may need to save the WREG, STATUS and BSR regis­ters in software. Depending on the user’s application, other registers may also need to be saved. Equation 8-1 saves and restores the WREG, STATUS and BSR registers during an Interrupt Service Routine.
EXAMPLE 8-1: SAVING STATUS, WREG AND BSR REGISTERS IN RAM
MOVWF W_TEMP ; W_TEMP is in virtual bank MOVFF STATUS, STATUS_TEMP ; STATUS_TEMP located anywhere MOVFF BSR, BSR_TEMP ; BSR located anywhere ; ; USER ISR CODE ; MOVFF BSR_TEMP, BSR ; Restore BSR MOVF W_TEMP, W ; Restore WREG MOVFF STATUS_TEMP,STATUS ; Restore STATUS
© 2006 Microchip Technology Inc. DS39564C-page 85
PIC18FXX2
NOTES:
DS39564C-page 86 © 2006 Microchip Technology Inc.
PIC18FXX2

9.0 I/O PORTS

Depending on the device selected, there are either five ports or three ports available. Some pins of the I/O ports are multiplexed with an alternate function from the peripheral features on the device. In general, when a peripheral is enabled, that pin may not be used as a general purpose I/O pin.
Each port has three registers for its operation. These registers are:
• TRIS register (data direction register)
• PORT register (reads the levels on the pins of the device)
• LAT register (output latch)
The data latch (LAT register) is useful for read-modify­write operations on the value that the I/O pins are driving.
9.1 PORTA, TRISA and LATA
Registers
PORTA is a 7-bit wide, bi-directional port. The corre­sponding Data Direction register is TRISA. Setting a TRISA bit (= 1) will make the corresponding PORTA pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISA bit (= 0) will make the corresponding PORTA pin an output (i.e., put the contents of the output latch on the selected pin).
Reading the PORTA register reads the status of the pins, whereas writing to it will write to the port latch.
The Data Latch register (LATA) is also memory mapped. Read-modify-write operations on the LATA register reads and writes the latched output value for PORTA.
The RA4 pin is multiplexed with the Timer0 module clock input to become the RA4/T0CKI pin. The RA4/ T0CKI pin is a Schmitt Trigger input and an open drain output. All other RA port pins have TTL input levels and full CMOS output drivers.
The other PORTA pins are multiplexed with analog inputs and the analog V operation of each pin is selected by clearing/setting the control bits in the ADCON1 register (A/D Control Register1).
Note: On a Power-on Reset, RA5 and RA3:RA0
are configured as analog inputs and read as ‘0’. RA6 and RA4 are configured as digital inputs.
REF+ and VREF- inputs. The
EXAMPLE 9-1: INITIALIZING PORTA
CLRF PORTA ; Initialize PORTA by
CLRF LATA ; Alternate method
MOVLW 0x07 ; Configure A/D MOVWF ADCON1 ; for digital inputs MOVLW 0xCF ; Value used to
MOVWF TRISA ; Set RA<3:0> as inputs
; clearing output ; data latches
; to clear output ; data latches
; initialize data ; direction
; RA<5:4> as outputs
FIGURE 9-1: BLOCK DIAGRAM OF
RA3:RA0 AND RA5 PINS
RD LATA
Data Bus
WR LATA or PORTA
WR TRISA
TRIS Latch
RD PORTA
SS Input (RA5 only)
To A/D Converter and LVD Modules
Note 1: I/O pins have protection diodes to VDD and VSS.
CK
Data Latch
CK
QD
Q
QD
Q
RD TRISA
VDD
P
N
V
SS
Analog Input Mode
QD
EN
I/O pin
TTL Input Buffer
(1)
The TRISA register controls the direction of the RA pins, even when they are being used as analog inputs. The user must ensure the bits in the TRISA register are maintained set when using them as analog inputs.
© 2006 Microchip Technology Inc. DS39564C-page 87
PIC18FXX2
FIGURE 9-2: BLOCK DIAGRAM OF
RA4/T0CKI PIN
Data Bus
WR LATA or PORTA
WR TRISA
RD PORTA
RD LATA
QD
Q
CK
Data Latch
QD
Q
CK
TRIS Latch
RD TRISA
N
SS
V
Schmitt Trigger Input Buffer
QD
EN
EN
I/O pin
FIGURE 9-3: BLOCK DIAGRAM OF
RA6 PIN
ECRA6 or RCRA6 Enable
Data Bus
(1)
WR LATA or PORTA
WR TRISA
ECRA6 or RCRA6
Enable
RD LATA
D
CK
Data Latch
D
CK
TRIS Latch
RD TRISA
Q
Q
Q
Q
VDD
P
N
V
SS
QD
I/O pin
TTL Input Buffer
(1)
TMR0 Clock Input
Note 1: I/O pin has protection diode to V
SS only.
EN
RD PORTA
Note 1: I/O pins have protection diodes to VDD and VSS.
DS39564C-page 88 © 2006 Microchip Technology Inc.

TABLE 9-1: PORTA FUNCTIONS

Name Bit# Buffer Function
RA0/AN0 bit0 TTL Input/output or analog input.
RA1/AN1 bit1 TTL Input/output or analog input.
RA2/AN2/V
RA3/AN3/VREF+ bit3 TTL Input/output or analog input or VREF+.
RA4/T0CKI bit4 ST Input/output or external clock input for Timer0.
RA5/SS/
OSC2/CLKO/RA6 bit6 TTL OSC2 or clock output or I/O pin.
Legend: TTL = TTL input, ST = Schmitt Trigger input
REF- bit2 TTL Input/output or analog input or VREF-.
Output is open drain type.
AN4/LVDIN bit5 TTL Input/output or slave select input for synchronous serial port or analog
input, or low voltage detect input.
PIC18FXX2

TABLE 9-2: SUMMARY OF REGISTERS ASSOCIATED WITH PORTA

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PORTA
LATA
TRISA
ADCON1
Legend: x = unknown, u = unchanged, - = unimplemented locations read as '0'. Shaded cells are not used by PORTA.
RA6 RA5 RA4 RA3 RA2 RA1 RA0 -x0x 0000 -u0u 0000
LATA Data Output Register -xxx xxxx -uuu uuuu
PORTA Data Direction Register -111 1111 -111 1111
ADFM ADCS2 PCFG3 PCFG2 PCFG1 PCFG0 00-- 0000 00-- 0000
Value on
POR,
BOR
Value on
All Other
RESETS
© 2006 Microchip Technology Inc. DS39564C-page 89
PIC18FXX2

9.2 PORTB, TRISB and LATB Registers

PORTB is an 8-bit wide, bi-directional port. The corre­sponding Data Direction register is TRISB. Setting a TRISB bit (= 1) will make the corresponding PORTB pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISB bit (= 0) will make the corresponding PORTB pin an output (i.e., put the contents of the output latch on the selected pin).
The Data Latch register (LATB) is also memory mapped. Read-modify-write operations on the LATB register reads and writes the latched output value for PORTB.
EXAMPLE 9-2: INITIALIZING PORTB
CLRF PORTB ; Initialize PORTB by
CLRF LATB ; Alternate method
MOVLW 0xCF ; Value used to
MOVWF TRISB ; Set RB<3:0> as inputs
Each of the PORTB pins has a weak internal pull-up. A single control bit can turn on all the pull-ups. This is per­formed by clearing bit RBPU weak pull-up is automatically turned off when the port pin is configured as an output. The pull-ups are disabled on a Power-on Reset.
Note: On a Power-on Reset, these pins are
configured as digital inputs.
Four of the PORTB pins, RB7:RB4, have an interrupt­on-change feature. Only pins configured as inputs can cause this interrupt to occur (i.e., any RB7:RB4 pin configured as an output is excluded from the interrupt­on-change comparison). The input pins (of RB7:RB4) are compared with the old value latched on the last read of PORTB. The “mismatch” outputs of RB7:RB4 are OR’ed together to generate the RB Port Change Interrupt with flag bit, RBIF (INTCON<0>).
This interrupt can wake the device from SLEEP. The user, in the Interrupt Service Routine, can clear the interrupt in the following manner:
a) Any read or write of PORTB (except with the
MOVFF instruction). This will end the mismatch condition.
b) Clear flag bit RBIF.
A mismatch condition will continue to set flag bit RBIF. Reading PORTB will end the mismatch condition and allow flag bit RBIF to be cleared.
; clearing output ; data latches
; to clear output ; data latches
; initialize data ; direction
; RB<5:4> as outputs ; RB<7:6> as inputs
(INTCON2<7>). The
The interrupt-on-change feature is recommended for wake-up on key depression operation and operations where PORTB is only used for the interrupt-on-change feature. Polling of PORTB is not recommended while using the interrupt-on-change feature.
RB3 can be configured by the configuration bit CCP2MX as the alternate peripheral pin for the CCP2 module (CCP2MX=’0’).
FIGURE 9-4: BLOCK DIAGRAM OF
RB7:RB4 PINS
DD
TTL Input Buffer
EN
RD PORTB
EN
DD and VSS.
V
P
Weak Pull-up
I/O pin
Buffer
Q1
Q3
(1)
ST
(2)
RBPU
Data Bus
WR LATB or PORTB
WR TRISB
Set RBIF
From other RB7:RB4 pins
RB7:RB5 in Serial Programming mode
Note 1: I/O pins have diode protection to V
2: To enable weak pull-ups, set the appropriate TRIS bit(s)
Data Latch
QD
CK
TRIS Latch
QD
CK
RD TRISB
RD LATB
RD PORTB
and clear the RBPU
Latch
QD
QD
bit (INTCON2<7>).
Note 1: While in Low Voltage ICSP mode, the
RB5 pin can no longer be used as a gen­eral purpose I/O pin, and should be held low during normal operation to protect against inadvertent ICSP mode entry.
2: When using Low Voltage ICSP program-
ming (LVP), the pull-up on RB5 becomes disabled. If TRISB bit 5 is cleared, thereby setting RB5 as an output, LATB bit 5 must also be cleared for proper operation.
DS39564C-page 90 © 2006 Microchip Technology Inc.

FIGURE 9-5: BLOCK DIAGRAM OF RB2:RB0 PINS

(2)
RBPU
Data Bus
WR Port
WR TRIS
Data Latch
CK
TRIS Latch
CK
RD TRIS
QD
QD
TTL Input Buffer
QD
V
P
DD
Weak Pull-up
I/O pin
PIC18FXX2
(1)
RD Port
RB0/INT
Schmitt Trigger Buffer
Note 1: I/O pins have diode protection to V
2: To enable weak pull-ups, set the appropriate TRIS bit(s) and clear the RBPU
DD and VSS.

FIGURE 9-6: BLOCK DIAGRAM OF RB3 PIN

(2)
RBPU
CCP2MX
CCP Output
(3)
(3)
Enable CCP Output
Data Bus
WR LATB or WR PORTB
WR TRISB
Data Latch
QD
CK
TRIS Latch
D
CK
Q
1
0
EN
RD Port
bit (OPTION_REG<7>).
DD
V
Weak
P
Pull-up
DD
V
P
N
VSS
TTL Input Buffer
I/O pin
(1)
RD TRISB
RD LATB
D
Q
RD PORTB
RD PORTB
CCP2 Input
Note 1: I/O pin has diode protection to VDD and VSS.
2: To enable weak pull-ups, set the appropriate DDR bit(s) and clear the RBPU 3: The CCP2 input/output is multiplexed with RB3 if the CCP2MX bit is enabled (=’0’) in the configuration register.
(3)
Schmitt Trigger Buffer
CCP2MX = 0
EN
bit (INTCON2<7>).
© 2006 Microchip Technology Inc. DS39564C-page 91
PIC18FXX2

TABLE 9-3: PORTB FUNCTIONS

Name Bit# Buffer Function
RB0/INT0 bit0 TTL/ST
RB1/INT1 bit1 TTL/ST
RB2/INT2 bit2 TTL/ST
RB3/CCP2
(3)
bit3 TTL/ST
RB4 bit4 TTL Input/output pin (with interrupt-on-change).
RB5/PGM
(5)
bit5 TTL/ST
RB6/PGC bit6 TTL/ST
RB7/PGD bit7 TTL/ST
Legend: TTL = TTL input, ST = Schmitt Trigger input
Note 1: This buffer is a Schmitt Trigger input when configured as the external interrupt.
2: This buffer is a Schmitt Trigger input when used in Serial Programming mode. 3: A device configuration bit selects which I/O pin the CCP2 pin is multiplexed on. 4: This buffer is a Schmitt Trigger input when configured as the CCP2 input. 5: Low Voltage ICSP Programming (LVP) is enabled by default, which disables the RB5 I/O function. LVP
must be disabled to enable RB5 as an I/O pin and allow maximum compatibility to the other 28-pin and 40-pin mid-range devices.
(1)
Input/output pin or external interrupt input0. Internal software programmable weak pull-up.
(1)
Input/output pin or external interrupt input1. Internal software programmable weak pull-up.
(1)
Input/output pin or external interrupt input2. Internal software programmable weak pull-up.
(4)
Input/output pin or Capture2 input/Compare2 output/PWM output when CCP2MX configuration bit is enabled. Internal software programmable weak pull-up.
Internal software programmable weak pull-up.
(2)
Input/output pin (with interrupt-on-change). Internal software programmable weak pull-up. Low voltage ICSP enable pin.
(2)
Input/output pin (with interrupt-on-change). Internal software programmable weak pull-up. Serial programming clock.
(2)
Input/output pin (with interrupt-on-change). Internal software programmable weak pull-up. Serial programming data.

TABLE 9-4: SUMMARY OF REGISTERS ASSOCIATED WITH PORTB

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 xxxx xxxx uuuu uuuu
LATB LATB Data Output Register xxxx xxxx uuuu uuuu
TRISB PORTB Data Direction Register 1111 1111 1111 1111
INTCON
INTCON2 RBPU INTEDG0 INTEDG1 INTEDG2
INTCON3 INT2IP INT1IP
Legend: x = unknown, u = unchanged. Shaded cells are not used by PORTB.
DS39564C-page 92 © 2006 Microchip Technology Inc.
GIE/
GIEH
PEIE/
GIEL
TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 0000 000x 0000 000u
TMR0IP —RBIP1111 -1-1 1111 -1-1
INT2IE INT1IE INT2IF INT1IF 11-0 0-00 11-0 0-00
Value on
POR, BOR
Value on All Other
RESETS
PIC18FXX2

9.3 PORTC, TRISC and LATC Registers

PORTC is an 8-bit wide, bi-directional port. The corre­sponding Data Direction register is TRISC. Setting a TRISC bit (= 1) will make the corresponding PORTC pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISC bit (= 0) will make the corresponding PORTC pin an output (i.e., put the contents of the output latch on the selected pin).
The Data Latch register (LATC) is also memory mapped. Read-modify-write operations on the LATC register reads and writes the latched output value for PORTC.
PORTC is multiplexed with several peripheral functions (Table 9-5). PORTC pins have Schmitt Trigger input buffers.
When enabling peripheral functions, care should be taken in defining TRIS bits for each PORTC pin. Some peripherals override the TRIS bit to make a pin an out­put, while other peripherals override the TRIS bit to make a pin an input. The user should refer to the corre­sponding peripheral section for the correct TRIS bit settings.
Note: On a Power-on Reset, these pins are
configured as digital inputs.
The pin override value is not loaded into the TRIS reg­ister. This allows read-modify-write of the TRIS register, without concern due to peripheral overrides.
RC1 is normally configured by configuration bit, CCP2MX, as the default peripheral pin of the CCP2 module (default/erased state, CCP2MX = ’1’).
EXAMPLE 9-3: INITIALIZING PORTC
CLRF PORTC ; Initialize PORTC by
; clearing output ; data latches
CLRF LATC ; Alternate method
; to clear output ; data latches
MOVLW 0xCF ; Value used to
; initialize data ; direction
MOVWF TRISC ; Set RC<3:0> as inputs
; RC<5:4> as outputs ; RC<7:6> as inputs

FIGURE 9-7: PORTC BLOCK DIAGRAM (PERIPHERAL OUTPUT OVERRIDE)

Port/Peripheral Select
Peripheral Data Out
RD LATC
Data Bus
WR LATC or WR PORTC
WR TRISC
RD TRISC
Peripheral Output
(3)
Enable
RD PORTC
Peripheral Data In
Note 1: I/O pins have diode protection to VDD and VSS.
2: Port/Peripheral 3: Peripheral Output Enable is only active if peripheral select is active.
Select signal selects between port data (input) and peripheral output.
(2)
Data Latch
CK
TRIS Latch
CK
VDD
0
QD
Q
QD
Q
1
D
Q
EN
P
N
VSS
I/O pin
Schmitt
Trig ge r
(1)
© 2006 Microchip Technology Inc. DS39564C-page 93
PIC18FXX2

TABLE 9-5: PORTC FUNCTIONS

Name Bit# Buffer Type Function
RC0/T1OSO/T1CKI bit0 ST Input/output port pin or Timer1 oscillator output/Timer1 clock input.
RC1/T1OSI/CCP2 bit1 ST Input/output port pin, Timer1 oscillator input, or Capture2 input/
Compare2 output/PWM output when CCP2MX configuration bit is set.
RC2/CCP1 bit2 ST Input/output port pin or Capture1 input/Compare1 output/PWM1
output.
2
2
C mode).
C
RC3/SCK/SCL bit3 ST RC3 can also be the synchronous serial clock for both SPI and I
modes.
RC4/SDI/SDA bit4 ST RC4 can also be the SPI Data In (SPI mode) or Data I/O (I
RC5/SDO bit5 ST Input/output port pin or Synchronous Serial Port data output.
RC6/TX/CK bit6 ST Input/output port pin, Addressable USART Asynchronous Transmit, or
Addressable USART Synchronous Clock.
RC7/RX/DT bit7 ST Input/output port pin, Addressable USART Asynchronous Receive, or
Addressable USART Synchronous Data.
Legend: ST = Schmitt Trigger input

TABLE 9-6: SUMMARY OF REGISTERS ASSOCIATED WITH PORTC

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0 xxxx xxxx uuuu uuuu
LATC LATC Data Output Register xxxx xxxx uuuu uuuu
TRISC PORTC Data Direction Register 1111 1111 1111 1111
Legend: x = unknown, u = unchanged
POR, BOR
Value on
Value on All Other
RESETS
DS39564C-page 94 © 2006 Microchip Technology Inc.
PIC18FXX2

9.4 PORTD, TRISD and LATD Registers

This section is applicable only to the PIC18F4X2 devices.
PORTD is an 8-bit wide, bi-directional port. The corre­sponding Data Direction register is TRISD. Setting a TRISD bit (= 1) will make the corresponding PORTD pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISD bit (= 0) will make the corresponding PORTD pin an output (i.e., put the contents of the output latch on the selected pin).
The Data Latch register (LATD) is also memory mapped. Read-modify-write operations on the LATD register reads and writes the latched output value for PORTD.
PORTD is an 8-bit port with Schmitt Trigger input buff­ers. Each pin is individually configurable as an input or output.
Note: On a Power-on Reset, these pins are
configured as digital inputs.
PORTD can be configured as an 8-bit wide micropro­cessor port (parallel slave port) by setting control bit PSPMODE (TRISE<4>). In this mode, the input buffers are TTL. See Section 9.6 for additional information on the Parallel Slave Port (PSP).
FIGURE 9-8: PORTD BLOCK DIAGRAM
IN I/O PORT MODE
Data Bus
WR LATD or PORTD
WR TRISD
RD PORTD
Note 1: I/O pins have diode protection to V
RD LATD
CK
Data Latch
QD
CK
TRIS Latch
RD TRISD
QD
Schmitt Trigger Input Buffer
QD
EN
EN
DD and VSS.
I/O pin
(1)
EXAMPLE 9-4: INITIALIZING PORTD
CLRF PORTD ; Initialize PORTD by ; clearing output ; data latches CLRF LATD ; Alternate method
; to clear output
MOVLW 0xCF ; Value used to
MOVWF TRISD ; Set RD<3:0> as inputs
; data latches
; initialize data ; direction
; RD<5:4> as outputs ; RD<7:6> as inputs
© 2006 Microchip Technology Inc. DS39564C-page 95
PIC18FXX2

TABLE 9-7: PORTD FUNCTIONS

Name Bit# Buffer Type Function
RD0/PSP0 bit0 ST/TTL
RD1/PSP1 bit1 ST/TTL
RD2/PSP2 bit2 ST/TTL
RD3/PSP3 bit3 ST/TTL
RD4/PSP4 bit4 ST/TTL
RD5/PSP5 bit5 ST/TTL
RD6/PSP6 bit6 ST/TTL
RD7/PSP7 bit7 ST/TTL
Legend: ST = Schmitt Trigger input, TTL = TTL input
Note 1: Input buffers are Schmitt Triggers when in I/O mode and TTL buffer when in Parallel Slave Port mode.
(1) (1) (1) (1) (1) (1) (1) (1)
Input/output port pin or parallel slave port bit0.
Input/output port pin or parallel slave port bit1.
Input/output port pin or parallel slave port bit2.
Input/output port pin or parallel slave port bit3.
Input/output port pin or parallel slave port bit4.
Input/output port pin or parallel slave port bit5.
Input/output port pin or parallel slave port bit6.
Input/output port pin or parallel slave port bit7.

TABLE 9-8: SUMMARY OF REGISTERS ASSOCIATED WITH PORTD

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PORTD RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 xxxx xxxx uuuu uuuu
LATD LATD Data Output Register xxxx xxxx uuuu uuuu
TRISD PORTD Data Direction Register 1111 1111 1111 1111
TRISE Legend: x = unknown, u = unchanged, - = unimplemented, read as '0'. Shaded cells are not used by PORTD.
IBF OBF IBOV PSPMODE PORTE Data Direction bits 0000 -111 0000 -111
Value on
POR, BOR
Value on
All Other
RESETS
DS39564C-page 96 © 2006 Microchip Technology Inc.
PIC18FXX2

9.5 PORTE, TRISE and LATE Registers

This section is only applicable to the PIC18F4X2 devices.
PORTE is a 3-bit wide, bi-directional port. The corre­sponding Data Direction register is TRISE. Setting a TRISE bit (= 1) will make the corresponding PORTE pin an input (i.e., put the corresponding output driver in a Hi-Impedance mode). Clearing a TRISE bit (= 0) will make the corresponding PORTE pin an output (i.e., put the contents of the output latch on the selected pin).
The Data Latch register (LATE) is also memory mapped. Read-modify-write operations on the LATE register reads and writes the latched output value for PORTE.
PORTE has three pins (RE0/RD and RE2/CS
/AN7) which are individually configurable as inputs or outputs. These pins have Schmitt Trigger input buffers.
Register 9-1 shows the TRISE register, which also controls the parallel slave port operation.
PORTE pins are multiplexed with analog inputs. When selected as an analog input, these pins will read as '0's.
TRISE controls the direction of the RE pins, even when they are being used as analog inputs. The user must make sure to keep the pins configured as inputs when using them as analog inputs.
Note: On a Power-on Reset, these pins are
configured as analog inputs.
/AN5, RE1/WR/AN6
FIGURE 9-9: PORTE BLOCK DIAGRAM
IN I/O PORT MODE
Data Bus
WR LATE or PORTE
WR TRISE
RD PORTE
Note 1: I/O pins have diode protection to VDD and VSS.
RD LATE
QD
CK
Data Latch
QD
CK
TRIS Latch
RD TRISE
To Analog Converter
Schmitt Trigger Input Buffer
QD
EN
EN
I/O pin
(1)
EXAMPLE 9-5: INITIALIZING PORTE
CLRF PORTE ; Initialize PORTE by
CLRF LATE ; Alternate method
MOVLW 0x07 ; Configure A/D MOVWF ADCON1 ; for digital inputs MOVLW 0x05 ; Value used to
MOVWF TRISE ; Set RE<0> as inputs
; clearing output ; data latches
; to clear output ; data latches
; initialize data ; direction
; RE<1> as outputs ; RE<2> as inputs
© 2006 Microchip Technology Inc. DS39564C-page 97
PIC18FXX2
REGISTER 9-1: TRISE REGISTER
R-0 R-0 R/W-0 R/W-0 U-0 R/W-1 R/W-1 R/W-1
IBF OBF IBOV PSPMODE
bit 7 bit 0
bit 7 IBF: Input Buffer Full Status bit
1 = A word has been received and waiting to be read by the CPU 0 = No word has been received
bit 6 OBF: Output Buffer Full Status bit
1 = The output buffer still holds a previously written word 0 = The output buffer has been read
bit 5 IBOV: Input Buffer Overflow Detect bit (in Microprocessor mode)
1 = A write occurred when a previously input word has not been read
(must be cleared in software)
0 = No overflow occurred
bit 4 PSPMODE: Parallel Slave Port Mode Select bit
1 = Parallel Slave Port mode 0 = General purpose I/O mode
bit 3 Unimplemented: Read as '0' bit 2 TRISE2: RE2 Direction Control bit
1 = Input 0 = Output
bit 1 TRISE1: RE1 Direction Control bit
1 = Input 0 = Output
bit 0 TRISE0: RE0 Direction Control bit
1 = Input 0 = Output
TRISE2 TRISE1 TRISE0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
- n = Value at POR ’1’ = Bit is set ’0’ = Bit is cleared x = Bit is unknown
DS39564C-page 98 © 2006 Microchip Technology Inc.
Loading...
