PIC18F2X1X/4X1X

Data Sheet

28/40/44-Pin Flash Microcontrollers

with 10-Bit A/D and nanoWatt Technology

 2004 Microchip Technology Inc. Preliminary DS39636A

Note the following details of the code protection feature on Microchip devices:

• Microchip products meet the specification contained in their particular Microchip Data Sheet.

• Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the intended manner and under normal conditions.

• There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data Sheets. Most likely, the person doing so is engaged in theft of intellectual property.

• Microchip is willing to work with the customer who is concerned about the integrity of their code.

• Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not mean that we are guaranteeing the product as “unbreakable.”

Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our products. Attempts to break Microchip’s code protection feature may be a violation of the Digit al Millennium Copyright Act. If suc h a c t s allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.

Information contained in this publication regarding device applications and the like is intended through suggestion only and may be superseded by updates. It is your responsibility to ensure that your application meets with your specifications. No representation or warranty is given and no liability is assumed by Microchip Technology Incorporated with respect to the accuracy or use of such information, or infringement of patents or other intellectual property rights arising from such use or otherwise. Use of Microchip’s products as critical components in life support systems is not authorized except with express written approval by Microchip. No licenses are conveyed, implicitly or otherwise, under any intellectual property rights.

Trademarks

The Microchip name and logo, the Microchip logo, Accuron, dsPIC, K

EELOQ, microID, MPLAB, PIC, PICmicro, PICSTART,

PRO MATE, PowerSmart, rfPIC, and SmartShunt are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.

AmpLab, FilterLab, MXDEV, MXLAB, PICMASTER, SEEVAL, SmartSensor and The Embedded Control Solutions Company are registered trademarks of Microchip Technology Incorporated in the U.S.A.

Analog-for-the-Digital Age, Application Maestro, dsPICDEM, dsPICDEM.net, dsPICworks, ECAN, ECONOMONITOR, FanSense, FlexROM, fuzzyLAB, In-Circuit Serial Programming, ICSP, ICEPIC, Migratable Memory, MPASM, MPLIB, MPLINK, MPSIM, PICkit, PICDEM, PICDEM.net, PICLAB, PICtail, PowerCal, PowerInfo, PowerMate, PowerTool, rfLAB, rfPICDEM, Select Mode, Smart Serial, SmartTel and Total Endurance are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries.

SQTP is a service mark of Microchip Technology Incorporated in the U.S.A.

All other trademarks mentioned herein are property of their respective companies.

Printed on recycled paper.

Microchip received ISO/TS-16949:2002 quality system certification for its worldwide headquarters, design and wafer fabrication facilities in Chandler and Tempe, Arizona and Mountain View, California in October 2003. The Company’s quality system processes and procedures are for its PICmicro devices, Serial EEPROMs, microperipherals, nonvolatile memory and analog products. In addition, Microchip’s quality system for the design and manufacture of development systems is ISO 9001:2000 certified.

8-bit MCUs, KEELOQ

code hopping

DS39636A-page ii Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

28/40/44-Pin Flash Microcontrollers with

10-bit A/D and nanoWatt Technology

Power Managed Modes:

• Run: CPU on, peripheral s on

• Idle: CPU off, peripheral s on

• Sleep: CPU off, peripherals off

• Idle mode currents down to 3.0 µA typical

• Sleep mode currents down to 20 nA typical

• Timer1 Oscillator: 1.8 µA, 32 kHz, 2V

• Watchdog Timer: 2.1 µA

• T wo -Spe ed Os ci ll ator Start-up

Peripheral Highlights:

• High-current sink/source 25 mA/25 mA

• Up to 2 Capture/Compare/PWM (CCP) modules,

one with Auto-Shutdown (28-pin devices)

• Enhanced Capture/Compare/PWM (ECCP)

module (40/44-pin devices only):

- One, two or four PWM outputs

- Selectable polarity

- Programmable dead time

- Auto-Shutdown and Auto-Restart

• Master Synchronous Serial Port (MSSP) module

supporting 3-wire SPI™ (all 4 modes) and I Master and Slave Modes

• Enhanced Addressable USART module:

- Supports RS-485, RS-232 and LIN 1.2

- RS-232 operation using internal oscillator block (no external cryst a l requi red)

- Auto-Wake-up on Start bit

- Auto-Baud Detect

• 10-bit, up to 13-channel Analog-to-Digital Converter module (A/D):

- Auto-acquisition capability

- Conversion available during Sleep

• Dual analog comparators with input multiplexing

• Programmable 16-level High/Low-Voltage Detection (HLVD) module:

- Supports interrupt on High/Low-Voltage

Detection

C™

Flexible Oscillator Structure:

• Four Crystal modes, up to 40 MHz

• 4x Phase Lock Loop (PLL) – available for crystal and internal oscillators

• Two External RC modes, up to 4 MHz

• Two External Clock modes, up to 40 MHz

• Internal oscillat or bloc k:

- 8 user selectable frequencies, from 31 kHz to 8 MHz

- Provides a complete range of clock speeds

from 31 kHz to 32 MHz when used with PLL

- User tunable to c o mp en sa te for frequency drift

• Secondary oscillator using Timer1 @ 32 kHz

• Fail-Safe Clock Monitor:

- Allows for safe shutdown if peripheral clock stops

Special Microcontroller Features:

• C compiler optimized architecture:

- Optional extended instruct ion set designed to

optimize re-entrant code

• 100,000 erase/ write cycl e Flash progra m memo ry typical

• Three programmable external interrupts

• Four input-change interrupts

• Priority levels for interrupts

• 8 x 8 Single-Cycle Hardware Multiplier

• Extended Watchdog Timer (WDT):

- Programmable period from 4 ms to 131s

• Single-supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins

• In-Circuit Debug (ICD) via two pins

• Wide operating voltage range: 2.0V to 5.5V

• Programmable Brown-out Reset (BOR) with software enable option

 2004 Microchip Technology Inc. Preliminary DS39636A-page 1

PIC18F2X1X/4X1X

Program Memory

Device

PIC18F2410 16K 8192 768 25 10 2/0 Y Y 1 2 1/3 PIC18F2510 32K 16384 1536 25 10 2/0 Y Y 1 2 1/3 PIC18F2515 48K 24576 3968 25 10 2/0 Y Y 1 2 1/3 PIC18F2610 64K 32768 3968 25 10 2/0 Y Y 1 2 1/3 PIC18F4410 16K 8192 768 36 13 1/1 Y Y 1 2 1/3 PIC18F4510 32K 16384 1536 36 13 1/1 Y Y 1 2 1/3 PIC18F4515 48K 24576 3968 36 13 1/1 Y Y 1 2 1/3 PIC18F4610 64K 32768 3968 36 13 1/1 Y Y 1 2 1/3

Flash

(bytes)

# Single-Word

Instructions

Data

Memory

SRAM (bytes)

I/O

10-bit

A/D (ch)

CCP/ECCP

(PWM)

SPI™

MSSP

Master

C™

EUSART

Comp.

Timers

8/16-bit

DS39636A-page 2 Preliminary  2004 Microchip Technology Inc.

Pin Diagrams

28-pin SPDIP, SOIC

PIC18F2X1X/4X1X

28-pin QFN

RA2/AN2/V

RA4/T0CKI/C1OUT

RA5/AN4/SS

RC0/T1OSO/T13CKI

RC1/T1OSI/CCP2

RA2/AN2/VREF-/CVREF

RA5/AN4/SS

MCLR/VPP/RE3

RA0/AN0 RA1/AN1

REF-/CVREF

RA3/AN3/VREF+

/HLVDIN/C2OUT

OSC1/CLKI/RA7

OSC2/CLKO/RA6

RC3/SCK/SCL

RA3/AN3/VREF+

RA4/T0CKI/C1OUT

/HLVDIN/C2OUT

OSC1/CLKI/RA7

OSC2/CLKO/RA6

RC2/CCP1

(1)

PIC18F2X1X

RB7/KBI3/PGD

1213 14

28 27 26 25 24 23 22 21 20 19 18 17 16 15

RB6/KBI2/PGC

RB5/KBI1/PGM

RB4KBI0/AN11

232425262728

21 20 19 18 17 16 15

RB7/KBI3/PGD RB6//KBI2/PGC RB5/KBI1/PGM RB4/KBI0/AN11 RB3/AN9/CCP2 RB2/INT2/AN8 RB1/INT1/AN10 RB0/INT0/FLT0/AN12 V

VSS RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA

RB3/AN9/CCP2 RB2/INT2/AN8 RB1/INT1/AN10 RB0/INT0/FLT0/AN12 V

VSS RC7/RX/DT

(1)

1 2 3 4 5 6 7 8 9

10 11

12 13 14

/VPP/RE3

MCLR

RA0/AN0

RA1/AN1

1 2 3

PIC18F2410

PIC18F2510

5 6 7

1011

MCLR/VPP/RE3

RA0/AN0 RA1/AN1

RA2/AN2/V

RA5/AN4/SS

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

REF-/CVREF

RA3/AN3/VREF+

RA4/T0CKI/C1OUT

/HLVDIN/C2OUT

OSC1/CLKI/RA7

OSC2/CLKO/RA6

RC0/T1OSO/T13CKI

RC1/T1OSI/CCP2

RC2/CCP1/P1A

RC3/SCK/SCL

RE0/RD

RE1/WR

RE2/CS

RD0/PSP0 RD1/PSP1

/AN5 /AN6 /AN7

VSS

(1)

RC5/SDO

RC2/CCP1

RC1/T1OSI/CCP2

RC0/T1OSO/T13CKI

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

RC3/SCK/SCL

RC4/SDI/SDA

40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21

RC6/TX/CK

RB7/KBI3/PGD RB6/KBI2/PGC RB5/KBI1/PGM RB4/KBI0/AN11 RB3/AN9/CCP2 RB2/INT2/AN8 RB1/INT1/AN10 RB0/INT0/FLT0/AN12 V

VSS RD7/PSP7/P1D RD6/PSP6/P1C RD5/PSP5/P1B RD4/PSP4 RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA RD3/PSP3 RD2/PSP2

(1)

 2004 Microchip Technology Inc. Preliminary DS39636A-page 3

PIC18F2X1X/4X1X

Pin Diagrams (Cont.’d)

44-pin TQFP

RD5/PSP5/P1B RD6/PSP6/P1C RD7/PSP7/P1D

RB0/INT0/FLT0/AN12

RB1/INT1/AN10

RB3/AN9/CCP2

RC7/RX/DT

RD4/PSP4

VDD

RB2/INT2/AN8

(1)

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

RB5/KBI1/PGM

RB7/KBI3/PGD

RB6/KBI2/PGC

363435

1819202122

RA1/AN1

RA0/AN0

/VPP/RE3

REF-/CVREF

MCLR

33 32 31 30 29 28 27 26 25 24

RA3/AN3/VREF+

NC RC0/T1OSO/T13CKI OSC2/CLKO/RA6 OSC1/CLKI/RA7

V VDD RE2/CS/AN7

/AN6

RE1/WR

/AN5

RE0/RD RA5/AN4/SS RA4/T0CKI/C1OUT

/HLVDIN/C2OUT

4443424140

1 2 3 4

(1)

5 6 7 8 9 10

121314

PIC18F4X1X

RB4/KBI0/AN11

44-pin QFN

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RC7/RX/DT

RD4/PSP4 RD5/PSP5/P1B RD6/PSP6/P1C RD7/PSP7/P1D

RB0/INT0/FLT0/AN12

RB1/INT1/AN10

RB2/INT2/AN8

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

V VDD VDD

4443424140

1 2 3 4 5 6 7 8 9 10 11

121314

(1)

RB3/AN9/CCP2

PIC18F4X1X

RB5/KBI1/PGM

RB4/KBI0/AN11

RD2/PSP2

RB6/KBI2/PGC

RD1/PSP1

RB7/KBI3/PGD

RA2/AN2/V

(1)

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

363435

1819202122

RA1/AN1

RA0/AN0

/VPP/RE3

REF-/CVREF

MCLR

RA2/AN2/V

RC0/T1OSO/T13CKI

33 32 31 30 29 28 27 26 25 24

REF+

RA3/AN3/V

OSC2/CLKO/RA6 OSC1/CLKI/RA7 V

VSS VDD VDD RE2/CS/AN7

/AN6

RE1/WR

/AN5

RE0/RD RA5/AN4/SS RA4/T0CKI/C1OUT

/HLVDIN/C2OUT

DS39636A-page 4 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

1.0 Device Overview.......................................................................................................................................................................... 7

2.0 Oscillator Configurations............................................................................................................................................................ 23

3.0 Power Managed Modes ...................................... .. .. .... .. .. ..... .. .. .... .. .. .. .. ....... .. .. .. .. .. .. ....... .. .. .. ...................................................... 33

4.0 Reset..........................................................................................................................................................................................41

5.0 Memory Organization.................................................................................................................................................................53

6.0 Flash Program Memory............ ................ ................. ................. ................................................................................................75

7.0 8 x 8 Hardware Multiplier............................................................................................................................................................ 79

8.0 Interrupts.................................................................................................................................................................................... 81

9.0 I/O Ports................................................. .................................................................................................................................... 95

10.0 Timer0 Module ......................................................................................................................................................................... 113

11.0 Timer1 Module ......................................................................................................................................................................... 117

12.0 Timer2 Module ......................................................................................................................................................................... 123

13.0 Timer3 Module ......................................................................................................................................................................... 125

14.0 Capture/Compare/PWM (CCP) Modules ................................................................................................................................. 129

15.0 Enhanced Capture/Compare/PWM (ECCP) Module ................................................................................................................ 137

16.0 Master Synchronous Serial Port (MSSP) Module ............................................................................... .....................................151

17.0 Enhanced Universal Synchronous Receiver Transmitter (EUSART)....................................................................................... 191

18.0 10-Bit Analog-to-Digital Converter (A/D) Module .....................................................................................................................211

19.0 Comparator Module.......................................................................................................... ........................................................ 221

20.0 Comparator Voltage Reference Module................................................................................................................................... 227

21.0 High/Low-Voltage Detect (HLVD).......................................................................... .... ......... .... ..................................................231

22.0 Special Features of the CPU.......... ................. ................ ................. ................. ....................................................................... 237

23.0 Instruction Set Summary.......................................................................................................................................................... 257

24.0 Development Support............................................................................................................................................................... 307

25.0 Electrical Characteristics.......................................................................................................................................................... 313

26.0 DC and AC Characteristics Graphs And Tables ......................................................................................................................351

27.0 Packaging Informa tio n. ................................................ ................. ............................................................................................ 353

Appendix A: Revision History............................................................................................................................................................. 361

Appendix B: Device Differences ........................................................................................................................................................ 361

Appendix C: Conversion Considerations ...........................................................................................................................................362

Appendix D: Migration From Baseline to Enhanced Devices ............................................................................................................ 362

Appendix E: Migration From Mid-Range to Enhanced Devices.........................................................................................................363

Appendix F: Migration From High-End to Enhanced Devices............................................................................................................363

Index ................................................................................................................................................................................................. 365

On-Line Support.................................................................................................................................................................................375

Systems Information and Upgrade Hot Line...................................................................................................................................... 375

Reader Response.............................................................................................................................................................................. 376

PIC18F2X1X/4X1X Product Identification System . ............................................................................................................................ 377

 2004 Microchip Technology Inc. Preliminary DS39636A-page 5

PIC18F2X1X/4X1X

TO OUR VALUED CUSTOMERS

It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your Microchip products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and enhanced as new volumes and updates are introduced.

If you have any questions or c omm ents regarding t his publication, p lease c ontact the M arket ing Co mmunications Department via E-mail at docerrors@mail.microchip.com or fax the Reader Response Form in the back of this data sheet to (480) 792-4150. We welcome your feedback.

Most Current Data Sheet

To obtain the most up-to-date version of this data sheet, please register at our Worldwide Web site at:

http://www.microchip.com

You can determine the version of a data sheet by examining its literature number found on the bottom outside corner of any page. The last character of the literature number is the version number, (e.g., DS30000A is version A of document DS30000).

Errata

An errata sheet, describing minor operational differences from the data sheet and recommended workarounds, may exist for current devices. As device/documentation issues become known to us, we will publish an errata sheet. The errata will specify the revision of silicon and revision of document to which it applies.

To determine if an errata sheet exists for a particular device, please check with one of the following:

• Microchip’s Worldwide Web site; http://www.microchip.com

• Your local Microchip sales office (see last page)

• The Microchip Corporate Literature Center; U.S. FAX: (480) 792-7277 When contacting a sales office or the literature center, please specify which device, revision of silicon and data sheet (include

literature number) you are using.

Customer Notification System

DS39636A-page 6 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

1.0 DEVICE OVERVIEW

This documen t conta i ns dev ic e spec if i c in for m at i on fo r the following devices:

• PIC18F2410 • PIC18LF2410

• PIC18F2510 • PIC18LF2510

• PIC18F2515 • PIC18LF2515

• PIC18F2610 • PIC18LF2610

• PIC18F4410 • PIC18LF4410

• PIC18F4510 • PIC18LF4510

• PIC18F4515 • PIC18LF4515

• PIC18F4610 • PIC18LF4610

This family offers the advantages of all PIC18 microcontrollers – namely, high computational performance at an economical price – with the addition of high-endurance, Flash program memory. On top of these features, the PIC18F2X1X/4X1X family introduces design enhancements that make these microcontrollers a logical choice for many high-performance, power sensitive applications.

1.1 New Core Features

1.1.1 nanoWatt TECHNOLOGY

All of the devices in the PIC18F2X1X/4X1X family incorporate a range of features that can significantly reduce power consumption during operation. Key items include:

• Alternate Run Modes: By clocking the controller from the Timer1 source or the internal oscillator block, power consumption during code execution can be reduced by as much as 90%.

• Multiple Idle Modes: The controller can also run with its CPU core disabled but the peripherals still active. In these st ates, powe r consumpt ion can be reduced even further, to as little as 4% of normal operation requirements.

• On-the-fly Mode Switching: The power managed modes a re invo ked b y user code durin g operation, allowing the user to incorporate powersaving ideas into their application’s software design.

• Lower Consumption in Key Modules: The power requirements for both Timer1 and the Watchdog Timer have been minimized. See Section 25.0 “Electrical Characteristics” for values.

1.1.2 MULTIPLE OSCILLATOR OPTIONS AND FEATURES

All of the devices in th e PIC 18F2X1X/ 4X1X fam ily of f er ten different oscillator options, allowing users a wide range of choices in developing application hardware. These include:

• Four Crystal modes, using crystals or ceramic

resonators

• Two External Clock modes, offering the option of

using two pins (oscillator input and a divide-by-4 clock output) or one pin (oscillator input, with the second pin reassigned as general I/O)

• Two External RC Oscillator modes with the same

pin options as the External Clock modes

• An internal oscillator block which provides an

8 MHz clock and an INTRC source (approximately 31 kHz), as well as a range of 6 user selectable cl ock fre quenc ies, be tween 125 kHz to 4 MHz, for a total of 8 clock frequencies. This option frees the two oscillator pins for use as additional general purpose I/O.

• A Phase Lock Loop (PLL) frequency multiplier,

available to both the high-speed crystal and internal oscillator modes, which allows clock speeds of up to 40 MHz. Used with the internal oscillator, the PLL gi ves users a complete sele ction of clock speeds, from 31 kHz to 32 MHz – all without using an external crystal or clock circuit.

Besides its ava ilability as a cloc k source, the intern al oscillator block pro vid es a s t ab le re fere nce source that gives the family additional features for robust operation:

• Fail-Safe Clock Monitor: This option constantly

monitors the main clock source against a reference signal provided by the internal oscillator. If a clock failure occurs, the controller i s switched to the internal oscillator block, allowing for continued low-speed operation or a safe application shutdown.

• Two-Speed Start-up: This option allows the

internal oscillator to serve as the clock source from Power-on Reset, or wake-up from Sleep mode, until the primary clock source is available.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 7

PIC18F2X1X/4X1X

1.2 Other Special Features

• Memory Endurance: The Flas h cells f or prog ram memory are rated to 100,000 erase/write cycles. Data retention without refresh is conservatively estimated to be greater than 40 years.

• Extended Instruction Set: The PIC18F2X1X/ 4X1X family introduces an optional extension to the PIC18 instruction set, which adds 8 new instructions and an Indexed Addressing mode. This extension, en abled as a de vi ce conf igurati on option, has been specifi cally des igned to opt imize re-entrant applica tion cod e origina lly deve loped in high-level languages, such as C.

• Enhanced CCP Module: In PWM mode, this module provides 1, 2 or 4 modulated outputs for controlling half-bridge and full-bridge drivers. Other features include Auto-S hutdown, for disabling PWM output s on interrup t or other selec t conditions and Auto-Rest art, to re activ ate outpu ts once the condition has cleared.

• Enhanced Addressable USART: This serial communication module is capable of standard RS-232 operation an d provides support for th e LIN bus protocol. Other enhancements include automatic baud r ate detection and a 16-bit Baud Rate Generator for improved resolution. When the microcontroller is using the internal oscillator block, the USART provides stable operation for applications that talk to the outside world without using an external crystal (or its accompanying power requirement).

• 10-bit A/D Converter: This module incorporates programmable acquisition time, allowing for a channel to be selected and a conversion to be initiated withou t wai ting for a sampling period and thus, reduce code overhead.

• Extended Watchdog Timer (WDT): This enhanced version in corpora tes a 1 6-bit pre scale r, allowing an extende d time-o ut rang e that is s ta ble across operating voltage and temperature. See Section 25.0 “Electrical Characteristics” for time-out periods.

1.3 Details on Individual Family Members

Devices in the PIC18F2X1X/4X1X family are available in 28-pin and 40/44-pin packages. Block diagrams for the two group s are shown in Figure 1-1 and Figure 1-2.

The devices are differentiated from each other in five ways:

1. Flash program memory

• 16 Kbytes for PIC18F2410/4410 devices

• 32 Kbytes for PIC18F2510/4510 devices

• 48 Kbytes for PIC18F2515/4515 devices

• 64 Kbytes for PIC18F2610/4610 devices

2. A/D channels (10 for 28-pin devices, 13 for

40/44-pin devices).

3. I/O ports (3 bidirectio nal ports on 28-pin devices,

5 bidirectional ports on 40/44-pin devices).

4. CCP and Enhanced CCP implementation (28-pin

devices have 2 s tandard CCP modules; 40/4 4-pin devices have one standard CCP module and one ECCP module).

5. Parallel Slave Port (present only on 40/44-pin

devices).

All other features fo r device s in this family are identi cal. These are summarized in Table 1-1.

The pinouts for all devices are listed in Table 1-3 and Table 1-4.

Like all Microchip PIC18 devices, members of the PIC18F2X1X/4X1X family are available as both standard and low-voltage devices. Standard devices with Flash memory, designated with an “F” in the part number (such as PIC18F2610), accommodate an operating V parts, designated by “LF” (such as PIC18LF2610), function over an extended VDD range of 2.0V to 5.5V.

DD range of 4.2V to 5.5V. Low-voltage

DS39636A-page 8 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

T ABLE 1-1: DEVICE FEATURES (PIC18F2410/2510/2515/2610)

Features PIC18F2410 PIC18F2510 PIC18F2515 PIC18F2610

Operating Frequency DC – 40 MHz DC – 40 MHz DC – 40 MHz DC – 40 MHz Program Memory (Bytes) 16384 32768 49152 65536 Program Memory

(Instructions) Data Memory (Bytes) 768 1536 3968 3968 Interrupt Sources 18 18 18 18 I/O Ports Ports A, B, C, (E) Ports A, B, C, (E) Ports A, B, C, (E) Ports A, B, C, (E) Timers 4444 Capture/Compare/PWM Modules2222 Enhanced

Capture/Compare/PWM Modules Serial Communications MSSP,

Parallel Communications (PSP) No No No No 10-bit Analog-to-Digital Module 10 Input Channels 10 Input Channels 10 Input Channels 10 Input Channels Resets (and Delays) POR, BOR,

Programmable High/Low-Voltage Detect

Programmable Brown-out Reset

Instruction Set 75 Instructions;

Instruction Set enabled

Packages 28-pin SPDIP

8192 16384 24576 32768

0000

Enhanced USART

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

Yes Yes Yes Yes

83 with Extended

28-pin SOIC

28-pin QFN

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

MCLR (optional),

WDT

75 Instructions;

83 with Extended

Instruction Set enabled

28-pin SPDIP

28-pin SOIC

28-pin QFN

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

MCLR (optional),

WDT

75 Instructions;

83 with Extended

Instruction Set enabled

28-pin SPDIP

28-pin SOIC

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

MCLR (optional),

WDT

75 Instructions;

83 with Extended

Instruction Set enabled

28-pin SPDIP

28-pin SOIC

 2004 Microchip Technology Inc. Preliminary DS39636A-page 9

PIC18F2X1X/4X1X

TABLE 1-2: DEVICE FEATURES (PIC18F4410/4510/4515/4610)

Features PIC18F4410 PIC18F4510 PIC18F4515 PIC18F4610

Operating Frequency DC – 40 MHz DC – 40 MHz DC – 40 MHz DC – 40 MHz Program Memory (Bytes) 16384 32768 49152 65536 Program Memory

(Instructions) Data Memory (Bytes) 768 1536 3968 3968 Interrupt Sources 19 19 19 19 I/O Ports Ports A, B, C, D, E Ports A, B, C, D, E Ports A, B, C, D, E Ports A, B, C, D, E Timers 4444 Capture/Compare/PWM Modules 1 1 1 1 Enhanced

Capture/Compare/PWM Modules Serial Communications MSSP,

Parallel Communications (PSP) Yes Yes Yes Yes 10-bit Analog-to-Digital Module 13 Input Channels 13 Input Channels 13 Input Channels 13 Input Channels Resets (and Delays) POR, BOR,

Programmable High/Low-Voltage Detect

Programmable Brown-out Reset

Instruction Set 75 Instructions;

Instruction Set enabled

Packages 40-pin PDIP

8192 16384 24576 32768

1111

Enhanced USART

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

Yes Yes Yes Yes

83 with Extended

44-pin QFN

44-pin T QFP

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

MCLR (optional),

WDT

75 Instructions;

83 with Extended

Instruction Set enabled

40-pin PDIP

44-pin QFN

44-pin TQFP

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

MCLR (optional),

WDT

75 Instructions;

83 with Extended

Instruction Set enabled

40-pin PDIP

44-pin QFN

44-pin TQFP

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

MCLR (optional),

WDT

75 Instructions;

83 with Extended

Instruction Set enabled

40-pin PDIP

44-pin QFN

44-pin TQFP

DS39636A-page 10 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

FIGURE 1-1: PIC1 8F2410/ 2510/ 2515/ 2610 ( 28-PIN) BLOCK DI AGRAM

T able Pointer<21>

inc/dec logic

Address Latch

Program Memory

(16/32/48/64

Kbytes)

Data Latch

Instruction Bus <16>

PCLATH

PCLATU

PCU

Program Counter

31 Level Stack

STKPTR

Table Latch

ROM Latch

Data Bus<8>

PCH PCL

Data Latch

Data Memory

(.7, 1.5, 3.9

Kbytes)

PORTA

Address La t ch

Data Address<12>

BSR

FSR0 FSR1 FSR2

inc/dec

logic

Address

Decode

Access

Bank

PORTB

RA0/AN0 RA1/AN1 RA2/AN2/VREF-/CVREF RA3/AN3/VREF+ RA4/T0CKI/C1OUT RA5/AN4/SS OSC2/CLKO OSC1/CLKI

/HLVDIN/C2OUT

(3)

/RA6

(3)

/RA7

RB0/INT0/FLT0/AN12 RB1/INT1/AN10 RB2/INT2/AN8 RB3/AN9/CCP2

(1)

RB4/KBI0/AN11 RB5/KBI1/PGM RB6/KBI2/PGC RB7/KBI3/PGD

OSC1

OSC2

T1OSI

T1OSO

MCLR

VDD,

BOR

HLVD

Instruction

Decode and

Control

State Machine Control Signals

BITOP

8 x 8 Multiply

(3)

(2)

Internal

Oscillator

Block

INTRC

Oscillator

8 MHz

Oscillator

Single-Supply

Programming

In-Circuit

Debugger

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

Brown-out

Reset

Fail-Safe

Clock Monitor

Precision Band Gap Reference

ALU<8>

PRODLPRODH

PORTC

RC0/T1OSO/T13CKI RC1/T1OSI/CCP2

(1)

RC2/CCP1 RC3/SCK/SCL RC4/SDI/SDA RC5/SDO

RC6/TX/CK RC7/RX/DT

PORTE

MCLR/VPP/RE3

(2)

Timer2Timer1 Timer3Timer0

CCP1

CCP2

MSSP

EUSARTComparator

ADC

10-bit

Note 1: CCP2 is multiplexed with RC1 when configuration bit CCP2MX is set, or RB3 when CCP2MX is not set.

2: RE3 is only available when MCLR 3: OSC1/CLKI and OSC2/CLKO are only available in select oscillator modes and when these pins are not being used as digital I/O.

Refer to Section 2.0 “Oscillator Configurations” for additional information.

functionality is disabled.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 11

PIC18F2X1X/4X1X

FIGURE 1-2: PIC18F4410/4510/4515/4610 (40/44-PIN) BLOCK DIAGRAM

T able Pointer<21>

inc/dec logic

Address Latch

Program Memory

(16/32/48/ 64

Data Latch

Instruction Bus <16>

PCLATH

PCLATU

PCU

Program Counter

31 Level Stack

STKPTR

Table Latch

ROM Latch

Instruction

Decode and

Control

Data Bus<8>

PCH PCL

State M achine Control Signals

Data Latch

Data Memory

(.7, 1.5, 3.9

Address La t ch

Data Address<12>

BSR

FSR0 FSR1 FSR2

inc/dec

logic

Address

Access

Bank

PRODLPRODH

8 x 8 Multiply

BITOP

BOR

HLVD

ECCP1

Note 1: CCP2 is multiplexed with RC1 when configuration bit CCP2MX is set, or RB3 when CCP2MX is not set.

2: RE3 is only available when MCLR 3: OSC1/CLKI and OSC2/CLKO are only available in select oscillator modes and when these pins are not being used as digital I/O.

Refer to Section 2.0 “Oscillator Configurations ” for additional information.

CCP2

MSSP

functionality is disabled.

Timer2Timer1 Timer3Timer0

EUSARTComparator

ALU<8>

ADC

10-bit

PORTD

PORTE

RD0/PSP0

RE0/RD/AN5 RE1/WR/AN6 RE2/CS/AN7 MCLR/VPP/RE3

:RD4/PSP4

(2)

DS39636A-page 12 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

T ABLE 1-3: PIC18F2410/2510/2515/2610 PINOUT I/O DESCRIPTIONS

Pin Name

Pin Number

SPDIP,

SOIC

QFN

Type

Buffer

Type

Description

/VPP/RE3

MCLR

MCLR VPP

RE3

OSC1/CLKI/RA7

OSC1 CLKI

RA7

OSC2/CLKO/RA6

OSC2 CLKO RA6

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

126

10 7

I/O

O O

I/O

I I

CMOS

TTL

— —

TTL

Master Clear (input) or programming voltage (input).

Master Clear (Reset) input. This pin is an active-low Reset to the device. Programming voltage input. Digital input.

Oscillator crystal or external clock input.

Oscillator crystal input or external clock source input. ST buffer when configured in RC mode; CMOS otherwise. External clock source input. Always associated with pin function OSC1. (See related OSC1/CLKI, OSC2/CLKO pins.) General purpose I/O pin.

Oscillator crystal or clock output.

Oscillator crystal output. Connects to crystal or resonator in Crystal Oscillator mode. In RC mode, OSC2 pin outputs CLKO, which has 1/4 the frequency of OSC1 and denotes the instruction cycle rate. General purpose I/O pin.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 13

PIC18F2X1X/4X1X

TABLE 1-3: PIC18F2410/2510/2515/2610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Number

Pin Name

RA0/AN0

RA0 AN0

RA1/AN1

RA1 AN1

RA2/AN2/V

RA2 AN2 VREFCV

RA3/AN3/V

RA3 AN3 V

RA4/T0CKI/C1OUT

RA4 T0CKI C1OUT

RA5/AN4/SS C2OUT

RA5 AN4 SS HLVDIN

C2OUT RA6 See the OSC2/CLKO/RA6 pin. RA7 See the OSC1/CLKI/RA7 pin.

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

REF-/CVREF

REF

REF+

/HLVDIN/

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

SPDIP,

SOIC

227

328

QFN

Buffer

Type

I/OITTL

Analog

I/OITTL

Analog

I/O

Analog

I/O

Analog

I/O

Analog I I

Analog

PORTA is a bidirectional I/O port.

Digital I/O. Analog input 0.

Digital I/O. Analog input 1.

TTL

ST ST

—

TTL TTL

—

Digital I/O. Analog input 2. A/D reference voltage (low) input. Comparator r eference voltage output.

Digital I/O. Analog input 3. A/D reference voltage (high) input.

Digital I/O. Timer0 external clock input. Comparator 1 output.

Digital I/O. Analog input 4. SPI™ slave select input. High/Low-Voltage Detect input. Comparator 2 output.

Description

DS39636A-page 14 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

T ABLE 1-3: PIC18F2410/2510/2515/2610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Number

Pin Name

RB0/INT0/FLT0/AN12

RB0 INT0 FLT0 AN12

RB1/INT1/AN10

RB1 INT1 AN10

RB2/INT2/AN8

RB2 INT2 AN8

RB3/AN9/CCP2

RB3 AN9

(1)

CCP2

RB4/KBI0/AN11

RB4 KBI0 AN11

RB5/KBI1/PGM

RB5 KBI1 PGM

RB6/KBI2/PGC

RB6 KBI2 PGC

RB7/KBI3/PGD

RB7 KBI3 PGD

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

SPDIP,

SOIC

21 18

22 19

23 20

24 21

25 22

26 23

27 24

28 25

QFN

Type

I/O

I I I

I/O

I I

I/O

I I

I/O

I I

I/O

Buffer

Type

TTL

ST ST

Analog

TTL

Analog

TTL

Analog

TTL

Analog

TTL TTL

Analog

TTL TTL

Description

PORTB is a bidirectional I/O port. PORTB can be software programmed for internal weak pull-ups on all inputs.

Digital I/O. External interrupt 0. PWM Fault input for CCP1. Analog input 12.

Digital I/O. External interrupt 1. Analog input 10.

Digital I/O. External interrupt 2. Analog input 8.

Digital I/O. Analog input 9. Capture 2 input/Compare 2 output/PWM 2 output.

Digital I/O. Interrupt-on-change pin. Analog input 11.

Digital I/O. Interrupt-on-change pin. Low-Voltage ICSP™ Programming enable pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming clock pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming data pin.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 15

PIC18F2X1X/4X1X

TABLE 1-3: PIC18F2410/2510/2515/2610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Number

Pin Name

RC0/T1OSO/T13CKI

RC0 T1OSO T13CKI

RC1/T1OSI/CCP2

RC1 T1OSI

(2)

CCP2

RC2/CCP1

RC2 CCP1

RC3/SCK/SCL

RC3 SCK SCL

RC4/SDI/SDA

RC4 SDI SDA

RC5/SDO

RC5 SDO

RC6/TX/CK

RC6 TX CK

RC7/RX/DT

RC7 RX DT

RE3 — — — — See MCLR

SS 8, 19 5, 16 P — Ground reference for logic and I/O pins.

V VDD 20 17 P — Positive supply for logic and I/O pins. Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

SPDIP,

SOIC

11 8

12 9

13 10

14 1 1

15 12

16 13

17 14

18 15

QFN

Buffer

Type

I/O

Analog

I/O

I/O I/OSTST

I/O I/O I/O

I/O

I/OOST

I/O

Type

PORTC is a bidirectional I/O port.

—

ST ST

ST ST ST

—

ST ST ST

Digital I/O. Timer1 oscillator output. Timer1/Timer3 external clock input.

Digital I/O. Timer1 oscillator input. Capture 2 input/Compare 2 output/PWM 2 output.

Digital I/O. Capture 1 input/Compare 1 output/PWM 1 output.

Digital I/O. Synchronous serial clock input/output for SPI™ mode. Synchronous serial clock input/output for I

Digital I/O. SPI data in. I2C data I/O.

Digital I/O. SPI data out.

Digital I/O. EUSART asynchronous transmit. EUSART synchronous clock (see related RX/DT).

Digital I/O. EUSART asynchronous receive. EUSART synchronous data (see related TX/CK).

/VPP/RE3 pin.

Description

C™ mode.

DS39636A-page 16 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

T ABLE 1-4: PIC18F4410/4510/4515/4610 PINOUT I/O DESCRIPTIONS

Pin Name

Pin Number

PDIP QFN TQFP

Type

Buffer

Type

Description

/VPP/RE3

MCLR

MCLR VPP

RE3

OSC1/CLKI/RA7

OSC1

CLKI

RA7

OSC2/CLKO/RA6

OSC2 CLKO

RA6

Legend: TTL = TTL compatible input CMOS = CMOS compatib le input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

11818

13 32 30

14 33 31

I/O

O O

I/O

Master Clear (input) or programming voltage (input).

CMOS

TTL

— —

TTL

Master Clear (Reset) input. This pin is an ac tive-low Reset to the device. Programming voltage input. Digital input.

Oscillator crystal or external clock input.

Oscillator crystal input or external clock source input. ST buffer when configured in RC mode; analog otherwise. External clock source input. Always associated with pin function OSC1. (See related OSC1/CLKI, OSC2/CLKO pins.) General purpose I/O pin.

Oscillator crystal or clock output.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 17

PIC18F2X1X/4X1X

TABLE 1-4: PIC18F4410/4510/4515/4610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RA0/AN0

RA0 AN0

RA1/AN1

RA1 AN1

RA2/AN2/V

RA3/AN3/V

RA4/T0CKI/C1OUT

RA5/AN4/SS C2OUT

RA6 See the OSC2/CLKO/RA6 pin. RA7 See the OSC1/CLKI/RA7 pin.

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

REF-/CVREF

RA2 AN2 VREF-

REF

REF+

RA3 AN3

REF+

RA4 T0CKI C1OUT

/HLVDIN/

RA5 AN4 SS HLVDIN C2OUT

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

Pin Number

PDIP QFN TQFP

21919

32020

42121

52222

62323

72424

Buffer

Type

I/OITTL

Analog

I/OITTL

Analog

I/O

TTL

Analog

I/O

TTL

Analog

I/O

TTL

Analog

TTL

Analog

PORTA is a bidirectional I/O port.

Digital I/O. Analog input 0.

Digital I/O. Analog input 1.

Digital I/O. Analog input 2. A/D reference voltage (low) input. Comparator reference voltage output.

Digital I/O. Analog input 3. A/D reference voltage (high) input.

ST ST

—

Digital I/O. Timer0 external clock input. Comparator 1 output.

Digital I/O. Analog input 4. SPI™ slave select input. High/Low-Voltage Detect input. Comparator 2 output.

Description

DS39636A-page 18 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

T ABLE 1-4: PIC18F4410/4510/4515/4610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RB0/INT0/FLT0/AN12

RB0 INT0 FLT0 AN12

RB1/INT1/AN10

RB1 INT1 AN10

RB2/INT2/AN8

RB2 INT2 AN8

RB3/AN9/CCP2

RB3 AN9

(1)

CCP2

RB4/KBI0/AN11

RB4 KBI0 AN11

RB5/KBI1/PGM

RB5 KBI1 PGM

RB6/KBI2/PGC

RB6 KBI2 PGC

RB7/KBI3/PGD

RB7 KBI3 PGD

Legend: TTL = TTL compatible input CMOS = CMOS compatib le input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

Pin Number

PDIP QFN TQFP

33 9 8

34 10 9

35 11 10

36 12 11

37 14 14

38 15 15

39 16 16

40 17 17

Type

I/O

I I I

I/O

I I

I/O

I I

I/O

I I

I/O

Buffer

Type

TTL

ST ST

Analog

TTL

Analog

TTL

Analog

TTL

Analog

TTL TTL

Analog

TTL TTL

Description

PORTB is a bidirectional I/O port. PORTB can be software programmed for internal weak pull-u p s on a ll inputs.

Digital I/O. External interrupt 0. PWM Fault input for Enhanced CCP1. Analog input 12.

Digital I/O. External interrupt 1. Analog input 10.

Digital I/O. External interrupt 2. Analog input 8.

Digital I/O. Analog input 9. Capture 2 input/Compare 2 output/PWM 2 output.

Digital I/O. Interrupt-on-change pin. Analog input 11.

Digital I/O. Interrupt-on-change pin. Low-Voltage ICSP™ Programming enable pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming clock pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming data pin.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 19

PIC18F2X1X/4X1X

TABLE 1-4: PIC18F4410/4510/4515/4610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RC0/T1OSO/T13CKI

RC0 T1OSO T13CKI

RC1/T1OSI/CCP2

RC1 T1OSI

(2)

CCP2

RC2/CCP1/P1A

RC2 CCP1 P1A

RC3/SCK/SCL

RC3 SCK

SCL

RC4/SDI/SDA

RC4 SDI SDA

RC5/SDO

RC5 SDO

RC6/TX/CK

RC6 TX CK

RC7/RX/DT

RC7 RX DT

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

Pin Number

PDIP QFN TQFP

15 34 32

16 35 35

17 36 36

18 37 37

23 42 42

24 43 43

25 44 44

26 1 1

Buffer

Type

I/O

CMOS

I/O

I/O I/O

I/O

I/OOST

I/O

Type

PORTC is a bidirectional I/O port.

—

ST ST

—

ST ST

ST ST ST

—

ST ST ST

Digital I/O. Timer1 oscillator output. Timer1/Timer3 external clock input.

Digital I/O. Timer1 oscillator input. Capture 2 input/Compare 2 output/PWM 2 output.

Digital I/O. Capture1 input/Compare1 output/PWM1 output. Enhanced CCP1 output.

Digital I/O. Synchronous serial clock input/output for SPI™ mode. Synchronous serial clock input/output for I

Digital I/O. SPI data in.

C data I/O.

Digital I/O. SPI data out.

Digital I/O. EUSART asynchronous transmit. EUSART synchronous clock (see related RX/DT).

Digital I/O. EUSART asynchronous receive. EUSART synchronous data (see related TX/CK).

Description

C™ mode.

DS39636A-page 20 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

T ABLE 1-4: PIC18F4410/4510/4515/4610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RD0/PSP0

RD0 PSP0

RD1/PSP1

RD1 PSP1

RD2/PSP2

RD2 PSP2

RD3/PSP3

RD3 PSP3

RD4/PSP4

RD4 PSP4

RD5/PSP5/P1B

RD5 PSP5 P1B

RD6/PSP6/P1C

RD6 PSP6 P1C

RD7/PSP7/P1D

RD7 PSP7 P1D

Legend: TTL = TTL compatible input CMOS = CMOS compatib le input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

Pin Number

PDIP QFN TQFP

19 38 38

20 39 39

21 40 40

22 41 41

27 2 2

28 3 3

29 4 4

30 5 5

Buffer

Type

I/O I/OSTTTL

I/O I/O

Description

PORTD is a bidirectional I/O port or a Parallel Slave Port (PSP) for interfacing to a microprocessor port. These pins have TTL input buffers when PSP module is enabled.

Digital I/O. Parallel Slave Port data.

TTL

—

TTL

—

TTL

—

Digital I/O. Parallel Slave Port data. Enhanced CCP1 output.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 21

PIC18F2X1X/4X1X

TABLE 1-4: PIC18F4410/4510/4515/4610 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RE0/RD/AN5

RE0 RD

AN5

RE1/WR/AN6

RE1 WR

AN6

RE2/CS/AN7

RE2 CS

AN7 RE3 — — — — — See MCLR/VPP/RE3 pin. VSS 12, 31 6, 30, 316, 29 P — Ground reference for logic and I/O pins.

Pin Number

PDIP QFN TQFP

82525

92626

10 27 27

Type

I/O

I I

I/O

I I

I/O

I I

Buffer

Type

TTL

Analog

TTL

Analog

TTL

Analog

Description

PORTE is a bidirectional I/O port.

Digital I/O. Read control for Parallel Slave Port (see also WR Analog input 5.

Digital I/O. Write control for Parallel Slave Port (see CS Analog input 6.

Digital I/O. Chip select control for Parallel Slave Port (see related RD Analog input 7.

and CS pins).

and RD pins).

and WR).

DD 11, 32 7, 8,

28, 29

NC — 13 12, 13,

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O=Output P =Power

Note 1: Default assignment for CCP2 when configuration bit CCP2MX is set.

2: Alternate assignment for CCP2 when configuration bit CCP2MX is cleared.

7, 28 P — Positive supply for logic and I/O pins.

— — No co nne ct.

33, 34

DS39636A-page 22 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

2.0 OSCILLATOR CONFIGURATIONS

2.1 Oscillator Types

PIC18F2X1X/4X1X devices can be operated in ten different oscillator modes. The user can program the configuration bits, FOSC3:FOSC0, in Configuration Register 1H to select one of these ten modes:

1. LP Low-Power Crystal

2. XT Crystal/Resonator

3. HS High-Speed Crystal/Resonator

4. HSPLL High-Speed Crystal/Resonator

with PLL enabled

5. RC External Resistor/Capacitor with

OSC/4 output on RA6

6. RCIO External Resistor/Capacitor with I/O

on RA6

7. INTIO1 Internal Oscillator with F

on RA6 and I/O on RA7

8. INTIO2 Internal Oscillator with I/O on RA6

and RA7

9. EC External Clock with F

10. ECIO External Clock with I/O on RA6

2.2 Crystal Oscilla tor/Ceramic Resonators

In XT, LP, HS or HSPLL Oscillator modes, a crystal or ceramic resonator is connected to the OSC1 and OSC2 pins to establish oscillation. Figure 2-1 shows the pin connections.

The oscillator design requires the use of a parallel cut crystal.

Note: Use of a series cut crystal may give a

frequency out of the crystal manufacturer’s specifications.

OSC/4 output

FIGURE 2-1: CRYSTAL/CERAMIC

RESONATOR OPERATION (XT, LP, HS OR HSPLL CONFIGURATION)

(1)

Note 1: See T able 2-1 and Table 2-2 for initial values of

2: A series resistor (R

3: R

OSC1

XTAL

(2)

OSC2

C1 and C2.

strip cut crystals.

F varies with the oscillator mode chosen.

(3)

Sleep

PIC18FXXXX

S) may be required for AT

Internal Logic

T ABLE 2-1: CAPACITOR SELECTION FOR

CERAMIC RESONATORS

Typical Capacitor Values Used:

Mode Freq OSC1 OSC2

XT 3.58 MHz

4.19 MHz 4 MHz 4 MHz

Capacitor values are for design guidance only. Different cap acitor values may be required to prod uce

acceptable oscillator operation. The user should test the performance of the oscillator over the expected

DD and temperature range for the application.

V See the notes following Table 2-2 for additional

information.

Note: When using resonators with frequencies

above 3.5 MHz, the use of HS mode, rather than XT mode, is recommended. HS mode may be used at any V which the controller is rated. If HS is selected, it is possible that the gain of the oscillator will overdrive the resonator. Therefore, a series resistor should be placed between the OSC2 pin and the resonator. As a good starting point, the recommended value of R

15 pF 15 pF 30 pF 50 pF

DD for

S is 330Ω.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 23

PIC18F2X1X/4X1X

TABLE 2-2: CAPACITOR SELECTION FOR

CRYSTAL OSCILLATOR

Osc T y pe

LP 32 kHz 30 pF 30 pF XT 1 MHz

HS 4 MHz

Capacitor values are for design guidance only. Different capa citor values may be required to produc e

acceptable oscillator operation. The user should test the performance of the oscillator over the expected

DD and temperature range for the application.

V See the notes following this table for additional

information.

Note 1: Higher capacitanc e increases th e stabilit y

Crystal

Freq

4 MHz

10 MHz 20 MHz 25 MHz

of the oscillator but also increases the start-up time.

2: When operating below 3V V

using certain ceramic resonators at any voltage, it may be necessary to use the HS mode or switch to a crystal oscillator.

3: Since each resonator/crystal has its own

characteristics, the user should consult the resonator/crystal manufacturer for appropriate values of external components.

4: Rs may be r equired to av oid overdr iving

crystals with low driv e lev e l spe ci fic ati on.

5: Always verify oscillator perform an ce over

DD and temperature range that is

the V expected for the application.

T ypical Cap acitor V alues

Tested:

C1 C2

15 pF 15 pF

15 pF 15 pF 15 pF 15 pF

15 pF 15 pF

15 pF 15 pF 15 pF 15 pF

DD, or when

An external clock source may also be connected to the OSC1 pin in the HS mode, as shown in Figure 2-2.

FIGURE 2-2: EXTERNAL CLOCK INPUT

OPERATION (HS OSCILLATOR CONFIGURATION)

Clock from Ext. System

Open

OSC1

OSC2

PIC18FXXXX

(HS Mode)

2.3 External Clock Input

The EC and ECIO Oscillator mode s require an externa l clock source to be conn ected to the OSC1 pi n. There is no oscillator start-up time required after a Power-on Reset or after an exit from Sleep mode.

In the EC Oscillator mode, the oscillator frequency divided by 4 is available on the OSC2 pin. This signal may be used f or t e st pu r pos es or t o sy nc hr o n iz e ot he r logic. Figure 2-3 shows the pin connections for the EC Oscillator mode.

FIGURE 2-3: EXTERNAL CLOCK

INPUT OPERATION (EC CONFIGURATION)

Clock from Ext. System

OSC/4

The ECIO Oscillator mo de func tio ns lik e t he EC mod e, except that the OSC2 pin becomes an additional general purpose I/O pin. The I/O pin becomes bit 6 of PORTA (RA6). Figure 2-4 shows the pin connections for the ECIO Oscillator mode.

OSC1/CLKI

PIC18FXXXX

OSC2/CLKO

FIGURE 2-4: EXTERNAL CLOCK

INPUT OPERATION (ECIO CONFIGURATION)

Clock from Ext. System

RA6

DS39636A-page 24 Preliminary  2004 Microchip Technology Inc.

OSC1/CLKI

PIC18FXXXX

I/O (OSC2)

PIC18F2X1X/4X1X

2.4 RC Oscillator

For timing insensitive applications, the “RC” and “RCIO” device options offer additional cost savings. The actual oscillator frequency is a function of several factors:

• supply voltage

• values of the external resistor (R capacitor (C

EXT)

• operating temperature

Given the same device, operating voltage and temperature and component values, there will also be unit-to-unit frequency variations. These are due to factors such as:

• normal manufacturing variation

• difference in lead frame capacitance between package types (especially for low C

• variations within the t olerance of limits of REXT

EXT

and C

In the RC Oscillator mode, the oscillator frequency divided by 4 is available on the OSC2 pin. This signal may be used f or t e st pu r pos es or t o sy nc hr o n iz e ot he r logic. Figure 2-5 shows how the R/C combination is connected.

FIGURE 2-5: RC OSCILLATOR MODE

VDD

REXT

OSC1

CEXT VSS

Recommended values: 3 kΩ ≤ REXT ≤ 100 kΩ

OSC/4

OSC2/CLKO

EXT > 20 pF

The RCIO Oscillator mode (Figure 2-6) functions like the RC mode, except that the OSC2 pin becomes an additional general purpose I/O pin. The I/O pin becomes bit 6 of PORTA (RA6).

FIGURE 2-6: RCIO OSCILLATOR MODE

VDD

REXT

OSC1

EXT) and

EXT values)

Internal

Clock

PIC18FXXXX

Internal

Clock

2.5 PLL Frequency Multiplier

A Phase Locked Loop (PLL) circuit is provided as an option for users who wish to use a lower frequency oscillator circuit or to clock the device up to its highest rated frequency from a crystal oscillator. This may be useful for customers who are concerned with EMI due to high-frequency crystals or users who require higher clock speeds from an internal oscillator.

2.5.1 HSPLL OSCILLATOR MODE

The HSPLL mode make s use of the HS mode osc illator for frequencies up t o 10 MHz. A PLL then multipl ies the oscillator output frequency by 4 to produce an internal clock frequency up to 40 MHz. The PLLEN bit is not available in this oscillator mode.

The PLL is only available to the crystal oscillator when the FOSC3:FOSC0 configu r ati on bi t s are prog ram med for HSPLL mode (= 0110).

FIGURE 2-7: PLL BLOCK DIAGRAM

(HS MODE)

HS Oscillator Enable

PLL Enable

(from Configuration Register 1H)

OSC2

OSC1

HS Mode

Crystal

Osc

F FOUT

÷4

2.5.2 PLL AND INTOSC

The PLL is also ava ilabl e to th e inte rnal os cill ator bl ock in selected oscillator modes. In this configuration, the PLL is enabled in software and generates a clock output of up to 32MHz. The operation of INTOSC with the PLL is describ ed in Section 2.6.4 “PLL in INTOSC Modes”.

Phase

Comparator

Loop Filter

VCO

SYSCLK

MUX

CEXT

VSS

RA6

Recommended values: 3 kΩ ≤ REXT ≤ 100 kΩ

 2004 Microchip Technology Inc. Preliminary DS39636A-page 25

I/O (OSC2)

EXT > 20 pF

PIC18FXXXX

PIC18F2X1X/4X1X

2.6 Internal Oscillator Block

The PIC18F2X1X/4X1X devices include an internal oscillator block which generates two different clock signals; either can be used as the microcontroller’s clock source. This may eliminate the need for external oscillator circuits on the OSC1 and/or OSC 2 pins.

The main output (INTOSC) is an 8 MHz clock source, which can be used to directly drive the device clock. It also drives a postscaler, which can provide a range of clock frequencies from 31 kHz to 4 MHz. The INTOSC output is enabled when a clock fre quency from 12 5 kHz to 8 MHz is selected.

The other clock source is the internal RC oscillator (INTRC), which provides a nominal 31 kHz output. INTRC is enabled if it is selected as the device clock source; it is also ena bled autom atically when an y of the following are enabled:

• Power-up Timer

• Fail-Safe Clock Monitor

• Watchdog Timer

• T wo-Spe ed Start-up These features are discussed in greater detail in

Section 22.0 “Special Features of the CPU”. The clock source frequency (INTOSC direct, INTRC

direct or INTOSC postscaler) is selected by configuring the IRCF bits of the OSCCON register (page30).

2.6.1 INTIO MODES

Using the internal oscillator as the clock source eliminates the need for up to two external oscillator pins, which can then be used for digital I/O. Two distinct configurations are available:

• In INTIO1 mode, the OSC2 pin outputs F while OSC1 functions as RA 7 fo r dig it a l in put a nd output.

• In INTIO2 mode, OSC1 functions as RA7 and OSC2 functions as RA6, both for digital input and output.

2.6.2 INTOSC OUTPUT FREQUENCY

The internal oscillator block is calibrated at the factory to produce an INTOSC output frequency of 8.0MHz.

The INTRC oscillator operates independently of the INTOSC source. Any changes in INTOSC across voltage and temperature are not necessarily reflected by changes in INTRC and vice versa.

2.6.3 OSCTUNE REGISTER

The internal oscillator’s output has been calibrated at the factory but can be adjusted in the user’s application. This is do ne by writi ng to the OSC TUNE regi ster (Register 2-1). The tuning sensitivity is constant throughout the tuning range.

OSC/4,

When the OSCTUNE regis ter is mo di fied , the IN T O SC frequency will begin shifting to the new frequency. The INTRC clock will reach the new frequency within 8 clock cy cles (approximately 8 * 32 µs=256µs). The INTOSC clock will stabilize within 1ms. Code execution conti nues during t his shift. There is no indication that the shift has occurred.

The OSCTUNE register also implements the INTSRC and PLLEN bits, which control certain features of the internal oscillator block. The INTSRC bit allows users to select which internal oscillator provides the clock source when the 31 kHz frequency option is selected. This is covered in greater detail in Section 2.7.1 “Oscillator Control Register”.

The PLLEN bit controls the operation of the frequency multiplier, PLL, in internal oscillator modes.

2.6.4 PLL IN INTOSC MODES

The 4x frequency multiplier can be used with the internal oscillator block to produce faster device clock speeds than are normally possible with an internal oscillator. When enabled, the PLL produces a clock speed of up to 32MHz.

Unlike HSPLL mode, the PLL is controlled through software. The control bit, PLLEN (OSCTUNE<6>), is used to enable or disable its operation.

The PLL is available when the device is configured to use the internal oscillator block as its primary clock source (FOSC3:FOSC0 = 1001 or 1000). Additionally, the PLL will only function when the selected output frequency is either 4 MHz or 8 MHz (OSCCON<6:4> = 111 or 110). If both of these conditions are not met, the PLL is disabled.

The PLLEN control bit is only functional in those internal oscillator m ode s w h ere t he PL L is av ai lab le. In all other modes, it is forced to ‘0’ and is effectively unavailable.

2.6.5 INTOSC FREQUENCY DRIFT

The factory calibrates the internal oscillator block output (INTOSC) for 8 MHz. However, this frequency may drift as VDD or temperature changes, which can affect the controller operation in a variety of ways. It is possible to adjust the INTOSC frequency by modifying the value in the OSCTUNE register. This has no effect on the INTRC clock source frequency.

Tuning the INTOSC source requires knowing when to make the adjustment, in which direction it should be made and in some cases, how large a change is needed. Three compensation techniques are discussed in Section 2.6.5.1 “Compensating with

the USART”, Section 2.6.5.2 “Compensating with the Timers” and Section2.6.5.3 “Compensating with the CCP Module in Capture Mode”, but other

techniques may be used.

DS39636A-page 26 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

REGISTER 2-1: OSCTUNE: OSCILLATOR TUNING REGISTER

R/W-0 R/W-0

INTSRC PLLEN

bit 7 bit 0

bit 7 INTSRC: Internal Oscillator Low-Frequency Source Select bit

1 = 31.25 kHz device clock derived from 8 MHz INTOSC source (divide-by-256 enabled) 0 = 31 kHz device clock derived directly from INTRC internal oscillator

bit 6 PLLEN: Frequency Multiplier PLL for INTOSC Enable bit

1 = PLL enabled for INTOSC (4 MHz and 8 MHz only) 0 = PLL disabled

Note 1: Available only in certain oscillator configurations; otherwise, this bit is unavailable

bit 5 Unimplemented: Read as ‘0’ bit 4-0 TUN4:TUN0: Frequency Tuning bits

01111 = Maximum frequency

• •

00001 00000 = Center frequency. Oscillator module is running at the calibrated frequency. 11111

• •

• • 10000 = Minimum frequency

(1)

and reads as ‘0’. See Section 2.6.4 “PLL in INTOSC Modes” for details.

U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— TUN4 TUN3 TUN2 TUN1 TUN0

(1)

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

2.6.5.1 Compensating with the USART

An adjustment may be required when the USART begins to generate frami ng errors or rec eive s dat a with errors while in Asynchronous mode. Framing errors indicate that the device clock frequency is too high; to adjust for this, decrement the value in OSCTUNE to reduce the clock frequency. On the other hand, errors in data may suggest that the clock speed is too low; to compensate, increment OSCTUNE to increase the clock frequency.

2.6.5.2 Compensating with the Timers

This technique compares device clock speed to some reference clock. Two timers may be used; one timer is clocked by the peripheral clock, while the other is clocked by a fixed reference source, such as the Timer1 oscillat or.

Both timers are cleared, but the timer clocked by the reference generates interrupts. When an interrupt occurs, the internally clocked timer is read and both timers are cleared. If the internally clocked timer value is greater than expected, then the internal oscillator block is ru nning too fast. To adjust for t his, decr ement the OSCTUNE register.

2.6.5.3 Compensating with the CCP Module in Capture Mode

A CCP module can use free running Timer1 (or Timer3), cl oc ked by the internal oscillator bl ock and an external event with a known period (i.e., AC power frequency). The time of the first event is capt ured in th e CCPRxH:CCPRxL registers and is recorded for use later. When the second event causes a capture, the time of the first event is su btra cte d fro m the tim e of th e second event. Since the period of the external event is known, the time difference between events can be calculated.

If the measured time is much greater than the calculated time, the internal oscillator block is running too fast; to compensate, decrement the OSCTUNE register. If the measured time is much less than the calculate d time, the internal oscillator block is runn ing t oo slow; to compensate, increment the OSCTUNE register.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 27

PIC18F2X1X/4X1X

2.7 Clock Sources and Oscillator Switching

Like previous PIC18 devices, the PIC18F2X1X/4X1X family includes a feature that allows the device clock source to be switched from the main oscillator to an alternate low-frequency clock source. PIC18F2X1X/4X1X devices offer two alternate clock sources. When an alternate clock source is enabled, the various power managed operating modes are available.

Essentially, there are three clock sources for these devices:

• Primary oscillators

• Secondary oscillators

• Internal oscillator block

The primary oscillators include the Ex ternal Crystal and Resonator modes, the External RC modes, the External Clock modes and the internal oscillator block. The particular mode is defined by the FOSC3:FOSC0 configuration bits. The details of these modes are covered earlier in this chapter.

The s econdary oscillators are those external sources not connected to the OSC1 or OSC2 pins. These sources may continue to operate even after the controller is placed in a power managed mode.

PIC18F2X1X/4X1X devices offer the Timer1 oscillator as a secondary oscillator. This oscillator, in all power managed modes, is often the time base for functions such as a real-time clock.

Most often, a 32.768 kHz watch crystal is connected between the RC0/T1OSO/T13CKI and RC1/T1OSI pins. Like the LP mode oscillator circuit, loading capacitors are also connected from each pin to ground.

The Timer1 oscillator is discussed in greater detail in Section 11.3 “Timer1 Oscillator”.

In addition to being a prim ary clock source, the internal oscillator block is available as a power managed mode clock source. T he IN TR C s ource is also used as the clock source for several special features, such as the WDT and Fail-Safe Clock Monitor.

The clock sources for the PIC18F2X1X/4X1X devices are shown in Figure 2-8. See Section 22.0 “Special

Features of the CPU” for Configuration register details.

FIGURE 2-8: PIC18F2X1X/4X1X CLOCK DIAGRAM

OSC2

OSC1

T1OSO

T1OSI

Primary Oscillator

Sleep

Secondary Oscillator

T1OSCEN Enable Oscillator

OSCCON<6:4>

Internal

Oscillator

Block

8 MHz

Source INTRC

Source

31 kHz (INTRC)

OSCTUNE<6>

8 MHz

(INTOSC)

PIC18F2X1X/4X1X

8 MHz 4 MHz 2 MHz 1 MHz

500 kHz

Postscaler

250 kHz 125 kHz

31 kHz

4 x PLL

OSCCON<6:4>

111

110

101

100

MUX

011

010

001

000

OSCTUNE<7>

LP, XT, HS, RC, EC

HSPLL, INTOSC/PLL

T1OSC

Internal Oscillator

FOSC3:FOSC0

Peripherals

MUX

CPU

Clock

Control

Clock Source Option for other Modules

WDT, PWRT, FSCM and Two-Speed Start-up

IDLEN

OSCCON<1:0>

DS39636A-page 28 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

2.7.1 OSCILLATOR CONTROL REGISTER

The OSCCON register (Register 2-2) controls several aspects of the device clock’s operation, both in full power operation and in power managed modes.

The System Clock Select bits, SCS1:SCS0, select the clock source. The available clock sources are the primary clock (defined by the FOSC3:FOSC0 configuration bits), the secondary clock (Timer1 oscillator) and the internal oscillator block. The clock source changes immediately after one or more of the bits is written to, following a brief clock transition interval. The SCS bits are cleared on all forms of Reset.

The Internal Oscillator Frequency Select bits (IRCF2:IRCF0) select the frequency output of the internal oscillator block to drive the device clock. The choices are the INTRC source, the INTOSC source (8 MHz) or one of the frequencies derived from the INTOSC postscaler (31.25 kHz to 4 MHz). If the internal oscillator block is supplying the device clock, changing the states of these bits will have an immediate change on the internal oscillator’s output. On device Resets, the default output frequency of the internal oscillator block is set at 1 MHz.

When a nominal ou tput frequenc y of 31 kHz is selected (IRCF2:IRCF0 = 000), users may choose which internal oscillator acts as the source. This is done with the INTSRC bit in the OSCTUNE register (OSCTUNE<7>). Setting this bit selects INTOSC as a 31.25 kHz clock source by enabling the divide-by-256 output of the INTOSC postscaler. Clearing INTSRC sel ects INTRC (nominally 31 kHz) as the clock source.

This option allows users to select the tunable and more precise INTOSC as a clock source, while maintaining power savings with a ve ry low clock speed. R egardless of the setting of INTSRC, INTRC always remains the clock source for features such as the Watchdog Timer and the Fail-Safe Clock Monitor.

The OSTS, IOFS and T1RUN bit s ind ic ate wh ich clock source is currently providing the device clock. The OSTS bit indicates that the Oscillator Start-up Timer has timed out and the primary clock is providing the device clock in primary clock modes. The IOFS bit indicates when the internal oscillator block has stabilized and is providing the device clock in RC Clock modes. The T1RUN bit (T1CON<6>) indicates when the Timer1 oscillator is providing the device clock in secondary clock modes. In power managed modes, only one of these three bits will be set at any time. If none of these bits are set, the INTRC is providing the clock or the internal o scillator bloc k has just s tarted and is not yet stable.

The IDLEN bit dete rmines if th e dev ice go es in to Slee p mode or one of the Idle modes when the SLEEP instruction is executed.

The use of the flag and control bits in the OSCCON register is discussed in more detail in Section 3.0

“Power Managed Modes”.

Note 1: The Timer1 oscillator must be enabled to

select the secondary clock source. The Timer1 osc illator is enabled by s etting the T1OSCEN bit in th e T imer1 C ontrol re gister (T1CON<3>). If the Timer1 oscillator is not enabled, then any at tem pt to se lec t a secondary clock source will be ignored.

2: It is recommended that the Timer1

oscillator be operating and stable before selecting the secondary clock source or a very long delay may occur while the Timer1 oscillator starts.

2.7.2 OSCILLATOR TRANSITIONS

PIC18F2X1X/4X1X device s con tai n circ uitry to preve nt clock “glitches” when switch ing between clock sources . A short pause in the device clock occurs during the clock switch. Th e leng th of th is p ause is th e sum of two cycles of the old clock source and three to four cycles of the new clock s ource. Th is formul a assumes that the new clock source is stable.

Clock transitions are discussed in greater detail in Section 3.1.2 “Entering Power Managed Modes”.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 29

PIC18F2X1X/4X1X

REGISTER 2-2: OSCCON: OSCILLATOR CONTROL REGISTER

R/W-0 R/W-1 R/W-0 R/W-0 R

IDLEN IRCF2 IRCF1 IRCF0 OSTS IOFS SCS1 SCS0

bit 7 bit 0

bit 7 IDLEN: Idle Enable bit

1 = Device ent ers Idle mode on SLEEP instruction 0 = Device enters Sleep mo de on SLEEP instruction

bit 6-4 IRCF2:IRCF0: Internal Oscillator Frequency Select bits

111 = 8 MHz (INTOSC drives clock directly) 110 = 4 MHz 101 = 2 MHz 100 = 1 MHz 011 = 500 kHz 010 = 250 kHz 001 = 125 kHz 000 = 31 kHz (from either INTOSC/256 or INTRC directly)

bit 3 OSTS: Oscillator Start-up Time-out Status bit

1 = Oscillator start-up time-out timer has expired; primary oscillator is running 0 = Oscillator start-up time-out timer is running; primary oscillator is not ready

bit 2 IOFS: INTOSC Frequency Stable bit

1 = INTOSC frequency is stable 0 = INTOSC frequency is not stable

bit 1-0 SCS1:SCS0: System Clock Select b its

1x = Internal oscillator block 01 = Secondary (Timer1) oscillator 00 = Primary oscillator

(3)

(1)

(2)

R-0 R/W-0 R/W-0

Note 1: Reset state depends on state of the IESO configuration bit.

2: Source selected by the INTSRC bit (OSCTUNE<7>), see text. 3: Default output frequency of INTOSC on Reset.

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

DS39636A-page 30 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

2.8 Effects of Power Managed Modes on the Various Clock Sources

When PRI_IDLE mode is selected, the designated primary oscillator continues to run without interruption. For all other power managed modes, the oscillator using the OSC1 pin is disabled. The OSC1 pin (and OSC2 pin, if used by the o scillat or) will sto p oscillat ing.

In secondary clock modes (SEC_RUN and SEC_IDLE), the Timer1 oscillator is operating and providing the device clock. The Timer1 oscillator may also run in all power managed modes if required to clock Timer1 or Timer3.

In internal oscillator modes (RC_RUN and RC_IDLE), the internal oscillator block provides the device clock source. The 31kHz INTRC output can be used d irectl y to provide the clock and may be enabled to support various special features, regardless of the power managed mode (see Section 22.2 “Watchdog Timer

(WDT)”, Section 22.3 “Two-Speed Start-up” and Section 22.4 “Fail-Safe Clock Monitor” for more

information on WDT, Fail-Safe Clock Monitor and TwoSpeed St art-up ). The INT OSC out put at 8 MHz may be used directly to clock the device or may be divided down by the posts caler . The INTO SC output is disable d if the clock is provided directly from the INTRC output.

If the Sleep mode is selected, all clock sources are stopped. Since all the transistor switching currents have been stopped, Sleep mode achieves the lowest current consumption of the device (only leakage currents).

Enabling any on-chip feature that will operate during Sleep will increas e the current cons umed during S leep. The INTRC is required to support WDT operation. The Timer1 oscillator may be operating to support a real-

time clock. Ot her features may be operating that do n ot require a device clock source (i.e., SSP slave, PSP, INTn pins and others). Peripherals that may add significant current consumption are listed in

Section 25.2 “DC Characteristics”.

2.9 Power-up Delays

Power-up delays are controlled by two timers, so that no external Rese t circ ui try is re qui red for most applications. The delays ensure that the device is kept in Reset until the device powe r supply i s stable under normal circumstan ces and the pri mary clock is ope rating and stable. For additional information on power-up delays, see Section 4.5 “Device Reset Timers”.

The first timer is the Power-up Timer (PWRT), which provides a fixed delay on power-up (parameter 33, Table 25-10). It is enabled by clearing (= 0) the PWRTEN

The second timer is the Oscillator Start-up Timer (OST), intended to keep the chip in Reset until the crystal oscillator is stable (LP, XT and HS modes). The OST does this by counting 1024 oscillator cycles before allowing the oscillator to clock the device.

When the HSPLL Oscillator mode is selected, the device is kept in Res et for an add iti onal 2ms, following the HS mode OST delay, so the PLL can lock to the incoming clock frequ enc y.

There is a delay of interval T Table 25-10), following POR, while the controller becomes ready to execute instruc tions. This delay runs concurrently with any other delays. This may be the only delay that occurs when an y of the EC, RC or INTIO modes are used as the primary clock source.

configuration bit.

CSD (parameter 38,

TABLE 2-3: OSC1 AND OSC2 PIN STATES IN SLEEP MODE

Oscillator Mode OSC1 Pin OSC2 Pin

RC, INTIO1 Floating, external resistor should pull high At logic low (clock/4 output) RCIO Floating, external resistor should pull high Configured as PORTA, bit 6 INTIO2 Configured as PORTA, bit 7 Configured as PORTA, bit 6 ECIO Floating, pulled by external clock Configured as PORTA, bit 6 EC Floating, pulled by external clock At logic low (clock/4 output) LP, XT and HS Feedback inverter disabled at quiescent

voltage level

Note: See Table 4-2 in Section 4.0 “Reset” for time-outs due to Sleep and MCLR

 2004 Microchip Technology Inc. Preliminary DS39636A-page 31

Feedback inverter disabled at quiescent voltage level

Reset.

PIC18F2X1X/4X1X

NOTES:

DS39636A-page 32 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

3.0 POWER MANAGED MODES

PIC18F2X1X/4X1X devices offer a total of seven op erating modes for more efficient power management. These modes provide a variety of options for selective power conservation in applications where resources may be limited (i.e., battery-powered devices).

There are three categories of power managed modes:

• Run modes

• Idle modes

• Sleep mode

These categories define which portions of the device are clocked and some times , what sp eed. The R un and Idle modes may use any of the three available clock sources (primary, secondary or internal oscillator block); the Sleep mode does not use a clock source.

The power managed modes include several powersaving features offered on previous PICmicro devices. On e is th e clock switchin g featu re, offer ed in other PIC18 devices, allowing the controller to use the Timer1 os cil la tor in pl ac e of the prim ary osc il lato r. Also included is the Sleep mode, offered by all PICmicro devices, where all device clocks are stopped.

3.1 Selecting Power Managed Modes

Selecting a power managed mode requires two decisions: if the CPU is to be clocked or not and the selection of a clock source. The IDLEN bit (OSCCON<7>) controls CPU clocking, while the SCS1:SCS0 bits (OSCCON<1:0>) select the clock source. The individual modes, bit settings, clock sources and affected modules are summariz ed in Table 3-1.

3.1.1 CLOCK SOURCES

The SCS1:SCS0 bits allow the sele ction of one o f three clock sources for power managed modes. They are:

• the primary clock, as defined by the FOSC3:FOSC0 configuration bits

• the secondary clock (the Timer1 oscillator)

• the internal oscillator block (for RC modes)

3.1.2 ENTERING POWER MANAGED

MODES

Switching from one power managed mode to another begins by loading the OSCCON register. The SCS1:SCS0 bits selec t the clock sourc e and determin e which Run or Idle mode is to be used. Changing these bits causes an immediate switch to the new clock source, assuming that it is running. The switch may

also be sub ject to clock tr ansition delays. These are discussed in Section 3.1.3 “Clock Transitions and Status Indicators” and subsequent sections.

Entry to the Power Managed Idle or Sleep modes is triggered by the execution of a SLEEP instruction. The actual mode that results depends on the status of the IDLEN bit.

Depending on the current mode and the mode being switched to, a change to a power managed mode does not always require setting all of these bits. Many

transitions may be done by changing the oscillator s elect

bits, or changing the IDLEN bit, prior to issuing a SLEEP instruction. If the IDLEN bit is already configured

correctly, it may only be necessary to perform a SLEEP

instruction to switch to the desired mode.

TABLE 3-1: POWER MANAGED MODES

OSCCON Bits Module Clocking

Mode

Sleep 0 N/A Off Off None – All clocks are disabled PRI_RUN N/A 00 Clocked Clocked Primary – LP, XT, HS, HSPLL, RC, EC and

SEC_RUN N/A 01 Clocked Clocked Secondary – Timer1 Oscillator RC_RUN N/A 1x Clocked Clocked Internal Oscillator Block PRI_IDLE 100Off Clocked Primary – LP, XT, HS, HSPLL, RC, EC SEC_IDLE 101 Off Clocked Secondary – Timer1 Oscillator RC_IDLE 11x Off Clocked Internal Oscillator Block

Note 1: IDLEN reflects its value when the SLEEP instruction is executed.

2: Includes INTOSC and INTOSC postscaler, as well as the INTRC source.

 2004 Microchip Technology Inc. DS39636A-page 33

IDLEN

<7>

(1)

SCS1:SCS0

<1:0>

CPU Peripherals

Available Clo ck and Os cill ator Source

Internal Oscillator Block This is the normal full power execution mode.

(2)

PIC18F2X1X/4X1X

3.1.3 CLOCK TRANSITIONS AND STATUS INDICATORS

The length of the transition between clock sources is the sum of two cycles o f the old clo ck so urce an d three to four cycl es of the new clock so urce. This formula assumes that the new clock source is stable.

Three bits indicate the current clock source and its status. They are:

• OSTS (OSCCON<3>)

• IOFS (OSCCON<2>)

• T1RUN (T1CON<6>)

In general, only one of these bits will be set while in a given power managed mode. When the OSTS bit is set, the primary clock is providing the device clock. When the IOFS bit is set, the INTOSC output is providing a stable 8 MHz clock source to a divider that actually drives the device clock. When the T1RUN bit is set, the Timer1 oscillator is providing the clock. If none of these bits are set, then either the INTRC clock source is cloc ki ng t he dev ic e, o r th e INTOSC source is not yet stable.

If the internal oscillator block is configured as the primary clock source b y the FOSC 3:FOSC0 co nfiguratio n bits, then both the OSTS and IOFS bits may be set when in PRI_RUN or PRI_IDLE modes. This indicates that the primary clock (INTOSC output) is generatin g a stable 8 MHz output. Entering another RC Power Managed mode at the s am e fre que nc y w ou ld cle ar th e OSTS bit.

Note 1: Caution should be used when modifying a

single IRCF bit. I f V possible to select a higher clock speed than is supported by the low VDD. Improper device operation may result if the VDD/FOSC specifications are violated.

2: Executing a SLEEP instruction does not

necessarily place the device into Sleep mode. It acts as the trigger to place the controller into either the Sleep mode or one of the Idle modes, depending on the setting of the IDLEN bit.

DD is less than 3V, it is

3.1.4 MULTIPLE SLEEP COMMANDS

The power managed mode that is invoked with the SLEEP instruction is determined by the setting of the IDLEN bit at the time the instruction is executed. If another SLEEP instruction is executed, the device will enter the power managed mode specified by IDLEN at that time. If IDLEN has changed, the device will enter the new power managed mode specified by the new setting.

3.2 Run Modes

In the Run modes, clocks to both the core and peripherals are active. The difference between these modes is the clock source.

3.2.1 PRI_RUN MODE

The PRI_RUN mode is the normal, full power execution mode of the microcontroller. This is also the default mode upon a device Reset, un less T wo-Speed S tart-up is enabled (see Section 22.3 “Two-Speed Start-up” for details). In this m ode, the OSTS bi t is set. Th e IOFS bit may be set if the internal oscillator block is the primary clock source (see Section 2.7.1 “Oscillator Control Register”).

3.2.2 SEC_RUN MODE

The SEC_RUN mode is the compatible mode to the “clock switching” feature offered in other PIC18 devices. In this mode, the CPU and peripherals are clocked from the T imer1 os cillator. This gives users the option of lower power consumption while still using a high accuracy clock source.

SEC_RUN mode is en tered by sett ing th e SCS1:SCS 0 bits to ‘01’. The device clock source is switched to the Timer1 oscillator (see Figure 3-1), the primary oscillator is shut down, the T1RUN bit (T1CON<6>) is set and the OSTS bit is cleared.

Note: The Timer1 oscillator should already be

running prior to entering SEC_RU N mode. If the T1OSCEN bit is not set when the SCS1:SCS0 bits are set to ‘01’, entry to SEC_RUN mode will not occur. If the Timer1 oscillator is enabled but not yet

On transitions from SEC_RUN mode to PRI_RUN, the peripherals and CPU continue to be clocked from the Timer1 oscillator while the primary clock is started. When the primary clo ck bec omes r eady, a clock switch back to the primary clock occurs (see Figure 3-2). When the clock switch is complete, the T1RUN bit is cleared, the OSTS bit is set and the primary clock is providing the clock. The IDLEN and SCS bits are not affected by the wake-up; the Timer1 oscillator continues to run.

DS39636A-page 34  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

FIGURE 3-1: TRANSITION TIMING FOR ENTRY TO SEC_RUN MODE

Q4Q3Q2

T1OSI

OSC1

CPU

Clock

Peripheral

Clock

Program

Counter

123 n-1n

Clock Transition

PC + 2PC

FIGURE 3-2: TRANSITION TIMING FROM SEC_RUN MODE TO PRI_RUN MODE (HSPLL)

3.2.3 RC_RUN MODE

In RC_RUN mode, the CPU and peripherals are clocked from the internal oscillator block using the INTOSC multiplexer. In this mode, the primary clock is shut down. When using the INTRC source, this mode provides the best power conservation of all the Run modes, while still executing code. It works well for user applications which are not hi ghl y tim in g sen si tiv e or do

This mode is entered by setting SCS1 to ‘1’. Although it is ignored, it is recommended that SCS0 also be cleared; this is to maintain software compatibility with future devices. When the clock source is switched to the INTOSC multiplexer (see Figure 3-3), the primary oscillator is shut down and the OSTS bit is cleared. The IRCF bits may be modified at any time to immediately

change the clock speed. not require high-speed clocks at all times. If the primary clock source is the internal oscillator

block (either INTRC or INTOSC), there are no distinguishable differences between PRI_RUN and RC_RUN modes during execution. Howeve r, a clock switch delay will occur during entry to and exit from RC_RUN mode. Therefore, if the primary clock source is the internal oscillator block, the use of RC_RUN mode is not recommended.

 2004 Microchip Technology Inc. DS39636A-page 35

PIC18F2X1X/4X1X

If the IRCF bits and the INTSRC bit are all clear, the INTOSC output is not enabled and the IOFS bit will remain clear; there will be no indication of the current clock source. The INTRC source is providing the device clocks.

If the IRCF bits are changed from all clear (thus, enabling the INTOSC output) or if INTSRC is set, the IOFS bit becomes set after the INTOSC output becomes stable. Clocks to the device continue while the INTOSC source stabilizes after an interval of

IOBST.

On transitions from RC_RUN mode to PRI_RUN mode, the device continues to be clocked from the INTOSC multiplexer whil e the prim ary clock is st arted. W hen the primary clock becomes ready, a clock switch to the primary clock occurs (see Figure 3-4). When the clock switch is complete, the IOFS bit is cleared, the OSTS bit is set and the primary clock is providing the device clock. The IDLEN and SCS bits are not af fe cte d by the switch. The INTRC source will continue to run if either the WDT or the Fail-Safe Clock Monitor is enabled.

If the IRCF bits w ere prev io us ly at a no n-z ero val ue, or if INTSRC was set before setting SCS1 and the INTOSC source was already stable, the IOFS bi t will remain set.

FIGURE 3-3: TRANSITION TIMING TO RC_RUN MODE

Q4Q3Q2

INTRC

OSC1

CPU

Clock

Peripheral

Clock

Program

Counter

Note 1: Clock transition typically occurs within 2-4 TOSC.

123 n-1n

Clock Transition

(1)

PC + 2PC

Q4Q3Q2 Q1 Q3Q2

PC + 4

FIGURE 3-4: TRANSITION TIMING FROM RC_RUN MODE TO PRI_RUN MODE

INTOSC

Multiplexer

OSC1

PLL Clock

Output

CPU Clock

Peripheral

Clock

Program

Counter

TOST

SCS1:SCS0 bits changed

(1)

TPLL

OSTS bit set

(1)

12 n-1n

(2)

Clock

Transition

PC + 2

Note 1: TOST = 1024 TOSC; TPLL = 2 ms (approx). These intervals are not shown to scale.

2: C lock transition typically occurs within 2-4 T

OSC.

Q3 Q4

PC + 4

DS39636A-page 36  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

3.3 Sleep Mode

The Power Managed Sleep mode in the PIC18F2X1X/ 4X1X devices is identical to the legacy Sleep mode offered in all other PICmicro devices. It is entered by clearing the IDLEN bit (the default state on device Reset) and executing the SLEEP instruction. Th is shut s down the selected oscillator (Figure 3-5). All clock source status bits are cleared.

Entering the Sleep m ode from any other mo de does not require a clock switch. This is because no clocks are needed once the controller has entered Sleep. If the WDT is selected, the INTRC source will continue to operate. If the Timer1 oscillator is enabled, it will also continue to run.

When a wake ev ent occurs i n Sleep mo de (by int errupt, Reset or WDT time-out), the device wil l not be clocke d until the clock source selected by the SCS1:SCS0 bits becomes ready (see Figure 3-6), or it will be clocked from the internal oscillator block if either the TwoSpeed Start-up or the Fail-Safe Clock Monitor are enabled (s ee Section 22.0 “Special Features of the CPU”). In either case, the OSTS b it is set when t he primary clock is providing the device clocks. The IDLEN and SCS bits are not affected by the wake-up.

3.4 Idle Modes

The Idle modes allow the controller’s CPU to be

selectively shut down while the peripherals continue to

operate. Selecting a particular Idle mode allows users

to further manage power consumption.

If the IDLEN bit i s set to a ‘1’ when a SLEEP inst ruction is

executed, the periph erals will be cl ocked fro m the cloc k

source selected us ing the SCS1:SCS 0 bits; howev er , the

CPU will not be clocked. The clock source status bits are

not affected. Setting IDLEN and executing a SLEEP

instruction pr ovides a quick method of switchi ng from a

given Run mo de to its correspondi ng Id le m od e.

If the WDT is selected, the INTRC source will continue

to operate. If the T imer1 oscill ator is enable d, it will also

continue to run.

Since the CPU is not executing instructions, the only

exits from any of the Idle modes are by interrupt, WDT

time-out or a Reset. When a wak e even t occur s, CPU

execution is delayed by an interval of T

(parameter 38, Table 25-10) while it becomes ready to

execute code. When the CPU begins executing code,

it resumes with the same clock source for the current

Idle mode. For example, when waking from RC_IDLE

mode, the internal oscillator block will clock the CPU

and peripherals (in other words, RC_RUN mode). The

IDLEN and SCS bits are not affected by the wake-up.

While in any Idle mode or the Sleep mode, a WD T time-

out will result in a WDT wake-up to the Run mode

currently specified by the SCS1:SCS0 bits.

CSD

FIGURE 3-5: TRANSITION TIMING FOR ENTRY TO SLEEP MODE

Q4Q3Q2

Q1Q1

OSC1

CPU

Clock

Peripheral

Clock Sleep

Program

Counter

PC + 2PC

FIGURE 3-6: TRANSITION TIMING FOR WAKE FROM SLEEP (HSPLL)

Q1 Q2 Q3 Q4 Q1 Q2

OSC1

(1)

PLL Clock

Output

CPU Clock

Peripheral

Clock

Program

Counter

Wake Event

OST = 1024 TOSC; TPLL = 2 ms (approx). These intervals are not shown to scale.

Note 1: T

TOST

(1)

TPLL

OSTS bit set

Q3 Q4 Q1 Q2

PC + 2

Q3 Q4

PC + 4

Q1 Q2 Q3 Q4

PC + 6

 2004 Microchip Technology Inc. DS39636A-page 37

PIC18F2X1X/4X1X

3.4.1 PRI_IDLE MODE

This mode is uni que among the thre e low-power Idle modes, in that it does not disable the primary device clock. For timing sensitive applications, this allows for the fastest resump tion of devic e operation with its more accurate pri mary clock source, si nce the cl ock source does not have to “warm up” or transition from another oscillator.

PRI_IDLE mode is entered from PRI_RUN mode by setting the IDLEN bit and executing a SLEEP instruction. If the device is in another Run mode, set IDLEN first, then clear the SCS bits and execute SLEEP. Although the CPU is disab led, th e peri pherals c ontinu e to be clocked from the primary clock source specified by the FOSC3:FOSC0 config uration bit s. The OSTS bit remains set (see Figure3-7).

When a wake event occurs, the CPU is clocked from the primary clock source. A delay of interval T required between the wake event and when code execution starts. This is required to allo w the CPU to become ready to execute instructions. A fter the wakeup, the OSTS bit remains set. The IDLEN and SCS bits are not affected by the wake-up (see Figure 3-8).

CSD is

3.4.2 SEC_IDLE MODE

In SEC_IDLE mode, the CPU is disabled but the peripherals continue to be clocked from the Timer1 oscillator. This mode is entered from SEC_RUN by setting the IDLEN bit and executing a SLEEP instructio n. If the devic e is in another Run mode, set IDLEN first, then set SCS1:SCS0 to ‘01’ and ex ecute SLEEP. When the clock source is switched to the Timer1 oscillator, the primary oscillator is shut down, the OSTS bit is cleared and the T1RUN bit is set.

When a wake event occ urs, the pe ripherals continue to be clocked from the Timer1 oscillator. After an interval

CSD following the wake event, the CPU begi ns ex e-

of T cuting code being cloc ked by the T im er1 oscil lator . Th e IDLEN and SCS bits are not affected by the wake-up; the Timer1 oscillator continues to run (see Figure 3-8).

Note: The Timer1 oscillator should already be

running prior to entering SEC_IDLE mod e. If the T1OSCEN bit is not set when the SLEEP instruction is executed, the SLEEP instruction will be ignored and entry to SEC_IDLE mode will not occur. If the Timer1 oscillator is enabled but not yet running, peripheral clocks will be delayed until the oscillator has started. In such situations, initial oscillator operation is far from stable and unpredictable operation may result.

FIGURE 3-7: TRANSITION TIMING FOR ENTRY TO IDLE MODE

OSC1

CPU Clock

Peripheral

Clock

Program

Counter

PC PC + 2

FIGURE 3-8: TRANSITION TIMING FOR WAKE FROM IDLE TO RUN MODE

OSC1

CPU Clock

Peripheral

Clock

Program

Counter

Q1 Q3 Q4

TCSD

Wake Event

DS39636A-page 38  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

3.4.3 RC_IDLE MODE

In RC_IDLE mode, t he C PU is d isabled but the peripherals continue to b e c loc ke d fro m t he internal oscillator block using the INTOSC multiplexer. This mode allows for controllable power cons ervation during Idl e periods .

From RC_RUN, this mode is entered by setting the IDLEN bit and executing a SLEEP instruction. If the device is in a nother Run mode, first s et IDLEN, th en set the SCS1 bit and execute SLEEP. Although its value is ignored, it is reco mmended that SCS0 also be cle ared; this is to maintain software compatibility with future devices. The INTOSC multiplexer may be used to select a higher clock frequency by modifying the IRCF bits before exec uti ng th e SLEEP instruction. When the clock source is switched to the IN TOSC mult iplexer , the primary oscillator is shut down and the OSTS bit is cleared.

If the IRCF bits are set to any non-zero value, or the INTSRC bit is set, the INTOSC output is enabled. The IOFS bit becomes set, after the INTOSC output becomes stable, after an interval of T (parameter 39, Table 25-10). Clocks to the peripherals continue while the INTOSC source stabilizes. If the IRCF bits were previously at a non-zero value, or INTSRC was set before the SLEEP instr uction was ex ecuted and the INTOSC source was already stable, the IOFS bit will remain set. If the IRCF bits and INTSRC are all clear , the INT OSC output will n ot be enabled, the IOFS bit will remain c lear and there will be no ind ication of the current clock source .

When a wake event occ urs, the pe ripherals co ntinue to be clocked from the INTOSC multiplexer. After a delay

CSD following the wake event, the CPU begins

of T executing code being clocked by the INTOSC multiplexer . The IDLEN and SCS bit s are not affect ed by the wake-up. The INTRC source will continue to run if either the WDT or the Fail-Safe Clock Monitor is enabled.

IOBST

On all exits from Idl e or Sleep modes by interrupt, code

execution branches to the interrupt vector if the GIE/

GIEH bit (INTCON<7>) is set. Otherwise, code execu-

tion continues or resumes without branching (see

Section 8.0 “Interrupts”).

A fixed delay of interval T

is required when leaving Sleep and Idle modes. This

delay is required for the CPU to prepar e for execution.

Instructio n execution r esumes on th e first clock c ycle

following this delay.

CSD following th e wak e ev en t

3.5.2 EXIT BY WDT TIME-OUT

A WDT time-out will cause different actions depending

on which power managed mode the device is in when

the time-out occurs.

If the device i s not exec uti ng code (al l Idle mode s and

Sleep mode), the time-out will res ul t in a n ex it fro m the

power managed mode (see Sec tion 3.2 “Run Modes”

and Section 3.3 “Sleep Mode”). If the device is

executing code (a ll b11.3 tl1rr(-1.213t)-1(e6(i)-14.x(i)-14.x3r)-9.6 TD0.3725 T7p0.0867 -3.4(t)-mh7 (aTT

3.5 Exiting Idle and Sleep Modes

An exit from Sleep mode or any of the Idle modes is triggered b y an interrupt , a Reset or a WDT time-out. This section discusses the triggers that cause exits from power managed modes. The clocking subsystem actions are discussed in each of the power managed modes (see Section 3.2 “Run Modes”, Section 3.3 “Sleep Mode” and Section 3.4 “Idle Modes”).

3.5.1 EXIT BY INTERRUPT

Any of the available interrupt sources can cause the device to exit from an Idle mode or the Sleep mode to a Run mode. To enable this functionality, an interrupt source must be enab led by s etti ng i t s en able bit in one of the INTCON or PIE registers. The exit sequence is initiated when the c orresponding interrupt flag bit is set.

 2004 Microchip Technology Inc. DS39636A-page 39

PIC18F2X1X/4X1X

3.5.4 EXIT WITHOUT AN OSCILLATOR START-UP DELAY

Certain exits from power managed modes do not invoke the OST at all. There are two cases:

• PRI_IDLE mode, where the primary clock source

is not stopped; and

• the primary clock source is not any of the LP, XT,

HS or HSPLL modes.

In these instances, the primary clock source either does not require an oscillator start-up delay since it is already running (PRI_IDLE), or normally does not require an oscillator start-up delay (RC, EC and INTIO Oscillator modes). However, a fixed delay of interval

CSD following the wake event is still required when

T leaving Sleep and Idle modes to allow the CPU to prepare for execution. Instruction execution resumes on the first clock cycle following this delay.

TABLE 3-2: EXIT DELAY ON WAKE-UP BY RESET FROM SLEEP MODE OR ANY IDLE MODE

(BY CLOCK SOURCES)

Clock Source

before Wake-up

Primary Device Clo ck

(PRI_IDLE mode)

T1OSC or INTRC

INTOSC

None

(Sleep mode)

Note 1: In this instance, refers specifically to the 31 kHz INTRC clock source.

2: TCSD (parameter 38) is a requir ed delay w hen wa king from Sl eep an d all Idle modes and runs conc urr ently

with any other required delays (see Section 3.4 “Idle Modes”). On Reset, INTOSC defaults to 1 MHz. 3: Includes both the INTOSC 8 MHz source and postscaler derived frequencies. 4: T

OST is the Oscillator Start-up Timer (parameter 32). t

also designated as T

5: Execution continues during T

(1)

(3)

PLL.

Clock Source

after Wake-up

Exit Delay

LP, XT, HS

HSPLL

(2)

EC, RC

(1)

INTRC

INTOSC

(3)

LP, XT, HS TOST

HSPLL T

EC, RC TCSD

INTOSC

(2)

LP, XT, HS TOST

HSPLL T

EC, RC TCSD

INTOSC

(2)

LP, XT, HS T

HSPLL T

EC, RC TCSD

INTOSC

IOBST (parameter 39), the INTOSC stabilization period.

(2)

is the PLL Lock-out Timer (p aram eter F12); it is

CSD

(4)

(2)

(5)

(2)

(5)

(4)

OST + t

TIOBST

OST + t

None IOFS

(4)

OST

(2)

(5)

(4)

OST + t

TIOBST

Clock Ready Status

bit (OSCCON)

OSTS

—

IOFS

OSTS

IOFS

OSTS

IOFS

DS39636A-page 40  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

4.0 RESET

A simplified block di agram of the On-Chip Reset Circu it is shown in Figure 4-1.

The PIC18F2X1X/4X1X devices differentiate between various kinds of Reset:

a) Power-on Reset (POR) b) MCLR

Reset during normal operation c) MCLR Reset during power managed modes d) Watchdog Timer (WDT) Reset (during

execution) e) Programmable Brown-out Reset (BOR) f) RESET Instruction g) Stack Full Reset h) Stack Underflow Reset

This section discusses Resets generated by MCLR POR and BOR and covers the ope rati on o f the various start-up timers. Stack Reset events are covered in Section 5.1.2.4 “Stack Full and Underflow Resets”. WDT Resets are co v ere d i n Section 22.2 “Watchdog

4.1 RCON Register

Device Reset events are tracked through the RCON register (Register 4-1). The lower five bits of the register indicate that a specific Reset event has occurred. In most cases, th ese bit s can on ly be cl eared by the event and must be set by the application after the event. The state of these flag bits, taken together, can be read to indicate the type of Reset that just occurred. This is described in more detail in Section 4.6 “Reset State of Registers”.

The RCON register also has control bits for setting interrupt priority (IPEN) and software control of the BOR (SBOREN). Interrupt priority is discussed in

Section 8.0 “Interrupts”. BOR is covered in Section 4.4 “Brown-out Reset (BOR)”.

Timer (WDT)”.

FIGURE 4-1: SIMPLIFIED BLOCK DIAGRAM OF ON-CHIP RESET CIRCUIT

RESET

Instruction

Stack

Pointer

Stack Full/Underflow Reset

MCLR

VDD

OSC1

( )_IDLE

Sleep

WDT

Time-out

DD Rise

Detect

Brown-out

Reset

OST/PWRT

32 µs

(1)

INTRC

External Reset

MCLRE

POR Pulse

BOREN

OST

PWRT

1024 Cycles

10-bit Ripple Counter

65.5 ms

11-bit Ripple Counter

Chip_Reset

Enable PWRT

Enable OST

(2)

Note 1: This is the INTRC source from the internal oscillator block and is separate from the RC oscillator of the CLKI pin.

2: See Table 4-2 for time-out situations.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 41

PIC18F2X1X/4X1X

REGISTER 4-1: RCON: RESET CONTROL REGISTER

R/W-0 R/W-1

IPEN SBOREN

bit 7 bit 0

bit 7 IPEN: Interrupt Priority Enable bit

1 = Enable priority levels on interrupts 0 = Disable priority levels on interrupts (PIC16CXXX Compatibility mode)

bit 6 SBOREN: BOR Software Enable bit

If BOREN1:BOREN0 = 01:

1 = BOR is enabled 0 = BOR is disabled

If BOREN1:BOREN0 =

Bit is disabled and read as ‘0’. bit 5 Unimplemented: Read as ‘0’ bit 4 RI: RESET Instruction Flag bit

1 = The RESET instruction was not executed (set by firmware only)

0 = The RESET instruction was executed causing a device Reset (must be set in software after

a Brown-out Reset occur s)

bit 3 TO: Watchdog Time-out Flag bit

1 = Set by power-up, CLRWDT instruction or SLEEP instruction

0 = A WDT time-out occurred

bit 2 PD

bit 1 POR

bit 0 BOR

: Power-down Detection Flag bit

1 = Set by power-up or by the CLRWDT instruction

0 = Set by execution of th e SLEEP instruction

: Power-on Reset Status bit

1 = A Power-on Reset has not occurred (set by firmware only)

0 = A Power-on Reset occurred (must be set in software after a Power-on Reset occurs)

: Brown-out Reset Status bit

1 = A Brown-out Reset has not occurred (set by firmware only)

0 = A Brown-out Reset occurred (must be set in software after a Brown-out Reset occurs)

(1)

00, 10 or 11:

U-0 R/W-1 R-1 R-1 R/W-0

—RITO PD POR BOR

(1)

(2)

R/W-0

Note 1: The SBOREN bit is only available when the BOREN1:BOREN0 configuration

bits = 01; otherwise, it is disabled and reads as ‘0’. See Section 4.4 “Brown-out

Reset (BOR)”.

2: The actual Reset val ue o f POR

notes following this register and Section 4.6 “Reset State of Registers” for additional information.

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

Note 1: It is recommended that the POR bit be set after a Power-on Reset has been

detected so that subsequent Power-on Resets may be detected.

2: Brown-out Reset is said to have occurred when BOR

that POR

DS39636A-page 42 Preliminary  2004 Microchip Technology Inc.

was set to ‘1’ by software immediately after POR).

is determined by the t ype of device Reset. See the

is ‘0’ and POR is ‘1’ (assumin g

PIC18F2X1X/4X1X

4.2 Master Clear (MCLR)

The MCLR pin provides a method for triggering an external Reset of the device. A Reset is generated by holding the pin low. These devi ces have a noise fi lter in the MCLR

Reset path which detects and ignores small

pulses. The MCLR

pin is not drive n low by any inter nal Reset s,

including the WDT. In PIC18F2X1X/4X1X devi ces , th e M CLR

input can be disabled with the MCLRE configuration bit. When MCLR is disabled, the pin becom es a dig ita l input. See

Section 9.5 “PORTE, TRISE and LATE Registers”

for more information.

4.3 Power-on Reset (POR)

A Power-on Reset pulse is generated on-chip whenever V allows the device to start in the initialized state when VDD is adequate for operation.

To take advantage of the POR circuitry, tie the MCLR pin throug h a resis tor (1 kΩ to 10 kΩ) to VDD. T his w ill eliminate external RC components usually needed to create a Power-on Re set delay. A minimum rise rate for

DD is specified (parameter D004). For a slow rise

V time, see Figure 4-2.

When the device st arts normal operation (i.e ., ex its the Reset condition), device operating parameters (voltage, frequency, temperature, etc.) must be met to ensure operation. If these conditions are not met, the device must be held in Reset until the operating conditions are met.

POR events are captured by the POR The state of the bit is set to ‘0’ whe never a POR occurs; it does not change for any other Reset event. POR is not reset to ‘1’ by any hardware event. To capture multiple events, the user manually resets the bit to ‘1’ in software following any POR.

DD rises above a certain threshold. This

bit (RCON<1>).

FIGURE 4-2: EXTERNAL POWER-ON

RESET CIRCUIT (FOR SLOW V

VDD

Note 1: External Power-on Reset circuit is required

only if the V The diode D helps discharge the capacitor quickly when V

2: R < 40 kΩ is recommended to make sure that

the voltage drop across R does not violate the device’s electrical specification.

3: R1 ≥ 1 kΩ will limit any current flowing into

MCLR of MCLR Electrostatic Discharge (ESD) or Electrical Overstress (EOS).

DD power-up slope is too slow.

from external capacitor C, in the event

/VPP pin breakdown, due to

DD POWER-UP)

MCLR

PIC18FXXXX

DD powers down.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 43

PIC18F2X1X/4X1X

4.4 Brown-out Reset (BOR)

PIC18F2X1X/4X1X devices implement a BOR circuit that provides the user with a number of configuration and power-saving options. The BOR is controlled by the BORV1:BOR V0 and BOREN1:BO REN0 conf igur ation bits. There are a total of four BOR configurations which are summarized in Table 4-1.

The BOR threshold is set by t he BOR V1:BOR V0 bit s. If BOR is enabled (any values of BOREN1:BOREN0, except ‘00’), any drop of V D005) for greater than T the device. A Reset may or may not occur if V below V Brown-out Reset until V

If the Power-up T imer is enabl ed, it will be inv oked after VDD rises above VBOR; it then will keep the chip in Reset for an additional time delay, T (parameter 33). If VDD drops below VBOR while the Power-up Timer is running, the chip will go back into a Brown-out Reset and the Power-up Timer will be initialized. Once V Timer will execute the additional time delay.

BOR and the Power-on Timer (PWRT) are independently configured. Enabling BOR Reset does not automatically enable the PWRT.

BOR for less than TBOR. The chip will remain in

DD rises above VBOR, the Power-up

4.4.1 SOFTWARE ENABLED BOR

When BOREN1:BOREN0 = 01, the BOR can be enabled or disabled by the user in software. This is done with the control bit, SBOREN (RCON<6>). Setting SBOREN enables the BOR to function as previously described. Clearing SBOREN disables the BOR entirely. The SBOREN bit operates only in this mode; otherwise it is read as ‘0’.

DD below VBOR (parameter

BOR (parameter 35 ) will reset

DD falls

DD rises above VBOR.

PWRT

Placing the BOR under software control gives the user the additional flexibility of tailoring the application to its environment withou t ha vi ng to reprogram the device to change BOR configuration. It also allows the user to tailor device power consumption in software by eliminating the incremental current that the BOR consumes. While the BOR current is typically very small, it may have some impact in low-power applications.

Note: Even when BOR is under s oftware contro l,

the BOR Reset voltage level is still set by the BORV1:BORV0 configuration bits. It cannot be changed in software.

4.4.2 DETECTING BOR

When BOR is enab led, the BO R bit always resets to ‘0’ on any BOR or P OR event. This makes it diff icult to determine if a BOR event has occurre d jus t by rea ding the state of BOR simultaneously check the state of both POR This assumes th at the POR immediately after any POR event. If BOR POR

is ‘1’, it can be reliably assum ed that a BOR event

has occurred.

alone. A more reliable method is to

and BOR.

bit is reset to ‘1’ in softwa re

is ‘0’ while

4.4.3 DISABLING BOR IN SLEEP MODE

When BOREN1:BOREN0 = 10, the BOR remains under hardware control and operates as previously described. Whenever the device enters Sleep mode, however , the BOR is au tom ati ca lly dis abl ed . When the device returns to any other operating mode, BOR is automatically re-enabled.

This mode allows for applications to recover from brown-out situations, while actively executing code, when the device requires BOR protection the most. At the same time, it save s additional po wer in Sleep mod e by eliminating the small incremental BOR current.

TABLE 4-1: BOR CONFIGURATIONS

BOR Configuration Status of

BOREN1 BOREN0

00Unavailable BOR disabled; must be enabled by reprogramming the configuration bits. 01Available BOR enabled in software; operation controlled by SBOREN. 10Unavailable BOR enabled in hardware in Run and Idle modes, disabled during

11Unavailable BOR enabled in hardware; must be disabled by reprogramming the

DS39636A-page 44 Preliminary  2004 Microchip Technology Inc.

SBOREN

(RCON<6>)

Sleep mode.

configuration bits.

BOR Operation

PIC18F2X1X/4X1X

4.5 Device Reset Timers

PIC18F2X1X/4X1X devices inc orporate three sep arate on-chip timers that help regulate the Power-on Reset process. Their main function is to ensure that the device clock is stable before code is executed. These timers are:

• Power-up Timer (PWRT)

• Oscillator Start-up Timer (OST)

• PLL Lock Time-out

4.5.1 POWER-UP TIMER (PWRT)

The Power-up Timer (PWRT) of PIC18F2X1X/4X1X devices is an 11-bit counter which uses the INTRC source as t he clock i nput. Thi s yields a n approxim a(t)-10.72 asse-15.58r.T10.7( T) e-T

 2004 Microchip Technology Inc. Preliminary DS39636A-page 45

PIC18F2X1X/4X1X

FIGURE 4-3: TIME-OUT SEQUENCE ON POWER-UP (MCLR TIED TO VDD, VDD RISE < TPWRT)

VDD

MCLR

INTERNAL POR

TPWRT

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

TOST

FIGURE 4-4: TIME-OUT SEQUENCE ON POWER-UP (MCLR

VDD

MCLR

INTERNAL POR

PWRT TI ME-OUT

OST TIME-OUT

INTERNAL RESET

TPWRT

NOT TIED TO VDD): CASE 1

TOST

FIGURE 4-5: TIME-OUT SEQUENCE ON POWER-UP (MCLR

VDD

MCLR

INTERNAL POR

TPWRT

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

DS39636A-page 46 Preliminary  2004 Microchip Technology Inc.

NOT TIED TO VDD): CASE 2

TOST

PIC18F2X1X/4X1X

FIGURE 4-6: SLOW RISE TIME (MCLR TIED TO VDD, VDD RISE > TPWRT)

VDD

MCLR

INTERNAL POR

PWRT

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

TOST

FIGURE 4-7: TIME-OUT SEQUENCE ON POR W/PLL ENABLED (MCLR TIED TO VDD)

VDD

MCLR

INTERNAL POR

TPWRT

PWRT TIME-OUT

OST TIME-OUT

PLL TIME-OUT

TOST

TPLL

INTERNAL RESET

Note: TOST = 1024 clock cycles.

PLL ≈ 2 ms max. First three stages of the PWRT timer.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 47

PIC18F2X1X/4X1X

4.6 Reset State of Registers

Most registers are unaffected by a Reset. Their status is unknown on POR and unchanged by all other

Table 4-4 describes the Reset states for all of the Special Function Registers. These are categorized by Power-on and Brown-out Resets, Master Clear and WDT Resets and WDT wake-ups.

Resets. The other registers are forced to a “Reset state” depending on the type of Reset that occurred.

Most registers are not affected by a WDT wake-up, since this is viewed as the resumption of normal operation. Status bits from the RCON register, RI POR

and BOR, are set or cleare d dif ferently i n differe nt

, TO, PD,

Reset situations, as indicated in Table 4-3. These bits are used in software to determine the nature of the Reset.

TABLE 4-3: STATUS BITS, THEIR SIGNIFICANCE AND THE INITIALIZATION CONDITION

FOR RCON REGISTER

Condition

Program

Counter

SBOREN RI TO PD POR BOR STKFUL STKUNF

Power-on Reset 0000h 1 11100 0 0 RESET Instruction 0000h u

Brown-out Reset 0000h u

during Power Managed

MCLR

0000h u

(2) (2) (2)

Run Modes MCLR during Power Managed

0000h u

(2)

Idle Modes and Sleep Mode WDT Time-ou t during Full Power

0000h u

(2)

or Power Managed Run Mode MCLR during Full Power

0000h u

(2)

Execution Stack Full Reset (STVREN = 1) 0000h u Stack Underflow Reset

0000h u

(2) (2)

(STVREN = 1) Stack Underflow Error (not an

0000h u

(2)

actual Reset, STVREN = 0) WDT Time-out during Power

PC + 2 u

(2)

Managed Idle or Sleep Modes Interrupt Exit from Power

PC + 2

(1)

(2)

Managed Modes

Legend: u = unchanged Note 1: When the wake-up is due to an interrupt and the GIEH or GIEL bits are set, the PC is loaded with the

interrupt vector (008h or 0018h).

2: Reset state is ‘1’ for POR and unchanged for all other Resets when software BOR is enabled

(BOREN1:BOREN0 configuration bits = 01 and SBOREN = 1). Otherwise, the Re set state is ‘0’.

RCON Register STKPTR Register

0uuuu u u

111u0 u u

u1uuu u u

u10uu u u

u0uuu u u

uuuuu u u

uuuuu 1 u

uuuuu u 1

u00uu u u

uu0uu u u

DS39636A-page 48 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS

Resets,

MCLR

Power-on Reset,

Brown-out

Reset

WDT Reset,

RESET

Instruction,

Stack Resets

TOSU 2410 2510 2515 2610 4410 4510 4515 4610 ---0 0000 ---0 0000 ---0 uuuu TOSH 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu TOSL 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu STKPTR 2410 2510 2515 2610 4410 4510 4515 4610 00-0 0000 uu-0 0000 uu-u uuuu PCLATU 2410 2510 2515 2610 4410 4510 4515 4610 ---0 0000 ---0 0000 ---u uuuu PCLATH 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu PCL 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 PC + 2 TBLPTRU 2410 2510 2515 2610 4410 4510 4515 4610 --00 0000 --00 0000 --uu uuuu TBLPTRH 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu TBLPTRL 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu TABLAT 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu PRODH 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu PRODL 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu INTCON 2410 2510 2515 2610 4410 4510 4515 4610 0000 000x 0000 000u uuuu uuuu INTCON2 2410 2510 2515 2610 4410 4510 4515 4610 1111 -1-1 1111 -1-1 uuuu -u-u INTCON3 2410 2510 2515 2610 4410 4510 4515 4610 11-0 0-00 11-0 0-00 uu-u u-uu INDF0 2410 2510 2515 2610 4410 4510 4515 4610 N/ A N/A N/A POSTINC0 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A POSTDEC0 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A PREINC0 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A PLUSW0 2410 2510 2515 2610 4410 4510 4515 4610 N/ A N/A N/A FSR0H 2410 2510 2515 2610 4410 4510 4515 4610 ---- 0000 ---- 0000 ---- uuuu FSR0L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu WREG 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu INDF1 2410 2510 2515 2610 4410 4510 4515 4610 N/ A N/A N/A POSTINC1 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A POSTDEC1 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A PREINC1 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A PLUSW1 2410 2510 2515 2610 4410 4510 4515 4610 N/ A N/A N/A Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Shaded cells indicate conditions do not apply for the designated device.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

(0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LAT A and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

PORTA pins, they are disabled and read ‘0’.

Wake-up via

WDT

or Interrupt

(3) (3) (3) (3)

(2)

(1) (1) (1)

 2004 Microchip Technology Inc. Preliminary DS39636A-page 49

PIC18F2X1X/4X1X

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

FSR1H 2410 2510 2515 2610 4410 4510 4515 4610 ---- 0000 ---- 0000 ---- uuuu FSR1L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu BSR 2410 2510 2515 2610 4410 4510 4515 4610 ---- 0000 ---- 0000 ---- uuuu INDF2 2410 2510 2515 2610 4410 4510 4515 4610 N/ A N/A N/A POSTINC2 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A POSTDEC2 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A PREINC2 2410 2510 2515 2610 4410 4510 4515 4610 N/A N/A N/A PLUSW2 2410 2510 2515 2610 4410 4510 4515 4610 N/ A N/A N/A FSR2H 2410 2510 2515 2610 4410 4510 4515 4610 ---- 0000 ---- 0000 ---- uuuu FSR2L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu STATUS 2410 2510 2515 2610 4410 4510 4515 4610 ---x xxxx ---u uuuu ---u uuuu TMR0H 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu TMR0L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu T0CON 2410 2510 2515 2610 4410 4510 4515 4610 1111 1111 1111 1111 uuuu uuuu OSCCON 2410 2510 2515 2610 4410 4510 4515 4610 0100 q000 0100 q000 uuuu uuqu HLVDCON 2410 2510 2515 2610 4410 4510 4515 4610 0-00 0101 0-00 0101 u-uu uuuu WDTCON 2410 2510 2515 2610 4410 4510 4515 4610 ---- ---0 ---- ---0 ---- ---u

(4)

RCON TMR1H 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu TMR1L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu T1CON 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 u0uu uuuu uuuu uuuu TMR2 2410 2510 2515 2 610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu PR2 2410 2510 2515 2610 4410 4510 4515 4610 1111 1111 1111 1111 1111 1111 T2CON 2410 2510 2515 2610 4410 4510 4515 4610 -000 0000 -000 0000 -uuu uuuu SSPBUF 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu SSPADD 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu SSPSTAT 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu SSPCON1 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu SSPCON2 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LAT A and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

2410 2510 2515 2610 4410 4510 4515 4610 0q-1 11q0 0q-q qquu uq-u qquu

Shaded cells indicate conditions do not apply for the designated device.

(0008h or 0018h).

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

PORTA pins, they are disabled and read ‘0’.

Power-on Reset,

Brown-out

Reset

Resets,

WDT Reset,

RESET

Instruction,

Stack Resets

Wake-up via

WDT

or Interrupt

DS39636A-page 50 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

ADRESH 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu ADRESL 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu ADCON0 2410 2510 2515 2610 4410 4510 4515 4610 --00 0000 --00 0000 --uu uuuu ADCON1 2410 2510 2515 2610 4410 4510 4515 4610 --00 0qqq --00 0qqq --uu uuuu ADCON2 2410 2510 2515 2610 4410 4510 4515 4610 0-00 0000 0-00 0000 u-uu uuuu CCPR1H 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu CCPR1L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu CCP1CON

CCPR2H 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu CCPR2L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu CCP2CON 2410 2510 2515 2610 4410 4510 4515 4610 --00 0000 --00 0000 --uu uuuu BAUDCON 2410 2510 2515 2610 4410 4510 4515 4610 01-0 0-00 01-0 0-00 --uu uuuu PWM1CON 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu ECCP1AS

CVRCON 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu CMCON 2410 2510 2515 2610 4410 4510 4515 4610 0000 0111 0000 0111 uuuu uuuu TMR3H 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu TMR3L 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu T3CON 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 uuuu uuuu uuuu uuuu SPBRGH 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu SPBRG 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu RCREG 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu TXREG 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu TXSTA 2410 2510 2515 2610 4410 4510 4515 4610 0000 0010 0000 0010 uuuu uuuu RCSTA 2410 2510 2515 2610 4410 4510 4515 4610 0000 000x 0000 000x uuuu uuuu

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu 2410 2510 2515 2610

Shaded cells indicate conditions do not apply for the designated device.

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

(0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LAT A and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

PORTA pins, they are disabled and read ‘0’.

4410 4510 4515 4610 --00 0000 --00 0000 --uu uuuu

4410 4510 4515 4610 0000 00-- 0000 00-- uuuu uu--

Power-on Reset,

Brown-out

Reset

Resets,

WDT Reset,

RESET

Instruction,

Stack Resets

Wake-up via

WDT

or Interrupt

 2004 Microchip Technology Inc. Preliminary DS39636A-page 51

PIC18F2X1X/4X1X

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

MCLR

Brown-out

Reset

IPR2 2410 2510 2515 2610 4410 4510 4515 4610 11-- 1111 11-- 1111 uu-- uuuu PIR2 2410 2510 2515 2610 4410 4510 4515 4610 00-- 0000 00-- 0000 uu-- uuuu PIE2 2410 2510 2515 2610 4410 4510 4515 4610 00-- 0000 00-- 0000 uu-- uuuu

Power-on Reset,

IPR1

PIR1

2410 2510 2515 2610 4410 4510 4515 4610 1111 1111 1111 1111 uuuu uuuu 2410 2510 2515 2610

4410 4510 4515 4610 -111 1111 -111 1111 -uuu uuuu 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu 2410 2510 2515 2610 4410 4510 4515 4610 -000 0000 -000 0000 -uuu uuuu

PIE1 2410 2510 2515 2610 4410 4510 4515 4610 0000 0000 0000 0000 uuuu uuuu

2410 2510 2515 2610

4410 4510 4515 4610 -000 0000 -000 0000 -uuu uuuu

OSCTUNE 2410 2510 2515 2610 4410 4510 4515 4610 00-0 0000 00-0 0000 uu-u uuuu TRISE TRISD

2410 2510 2515 2610 4410 4510 4515 4610 0000 -111 0000 -111 uuuu -uuu 2410 2510 2515 2610 4410 4510 4515 4610 1111 1111 1111 1111 uuuu uuuu

TRISC 2410 2510 2515 2610 4410 4510 4515 4610 1111 1111 1111 1111 uuuu uuuu TRISB 2410 2510 2515 2610 4410 4510 4515 4610 1111 1111 1111 1111 uuuu uuuu TRISA

(5)

2410 2510 2515 2610 4410 4510 4515 4610 1111 1111

(5)

LATE 2410 2510 2515 2610 4410 4510 4515 4610 ---- -xxx ---- -uuu ---- -uuu LATD

2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu

LATC 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu LATB 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu LATA

(5)

2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx

(5)

PORTE 2410 2510 2515 2610 4410 4510 4515 4610 ---- x000 ---- x000 ---- uuuu PORTD

2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu

PORTC 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu PORTB 2410 2510 2515 2610 4410 4510 4515 4610 xxxx xxxx uuuu uuuu uuuu uuuu PORTA

(5)

2410 2510 2515 2610 4410 4510 4515 4610 xx0x 0000

(5)

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Shaded cells indicate conditions do not apply for the designated device.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector

(0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with

the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LAT A and TRISA are enabled, depending on the oscillator mode selected. When not enabled as

PORTA pins, they are disabled and read ‘0’.

Resets,

WDT Reset,

RESET

Instruction,

Stack Resets

1111 1111

uuuu uuuu

uu0u 0000

(5)

Wake-up via

WDT

or Interrupt

uuuu uuuu

(1)

(1) (1)

(5)

DS39636A-page 52 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

5.0 MEMORY ORGANIZATION

There are two types of memory in PIC18F2X1X/4X1X microcontroller devices:

• Program Memory

• Data RAM As Harvard architecture dev ices, the dat a and progra m

memories use separate busses; this allows for concurrent access of the two memory spaces.

Additional detailed information on the operation of the Flash program memory is provided in Section 6.0

“Flash Program Memory”.

5.1 Program Memory Organization

PIC18 microcontrollers implement a 21-bit program counter, which is capable of addressing a 2-Mbyte program memory sp ace. Accessi ng a loca tion betwee n the upper boundary of the physically implemented memory and the 2-Mbyte address will return all ‘0’s (a NOP instruction).

The PIC18F2410/4410 and PIC18F2510 each have 16 Kbytes of Flash memory and can store up to 8,192 single-word instructions. The PIC18F2510/4510 each have 32 Kbytes of Flash memory and can store up to 16,384 single-word instructions. The PIC18F2515/4515 each have 48 Kbytes of Flash memory and can store up to 24,576 single-word instructions. The PIC18F2610/ 4610 each have 64 Kbytes of Flash memory and can store up to 32,768 single-word instructions.

PIC18 devices have two interrupt vectors. The Reset vector address is at 0000h and the interrupt vector addresses are at 0008h and 0018h.

The program memory map for PIC18F2X1X/4X1X devices is shown in Figure 5-1.

FIGURE 5-1: PROGRAM MEMORY MAP AND STACK FOR

PIC18F2X1X/4X1X DEVICES

On-Chip

Program Memory

(16 Kbytes)

03FFFh

04000h

Read ‘0’

PC<20:0>

CALL,RCALL,RETURN RETFIE,RETLW

Stack Level 1

Stack Level 31

Reset Vector High Priority Interrupt Vector Low Priority Interrupt Vector

On-Chip

Program Memory

(32 Kbytes) (48 Kbytes)

07FFFh

08000h

Read ‘0’

•

On-Chip

Program Memory

0BFFFh

0C000h

Read ‘0’

On-Chip

Program Memory

(64 Kbytes)

0FFFFh

10000h

Read ‘0’

00000h 00008h

00018h

User Memory Space

1FFFFFh

PIC18F2410/4410

 2004 Microchip Technology Inc. Preliminary DS39636A-page 53

PIC18F2510/4510

PIC18F2515/4515

PIC18F2610/4610

200000h

PIC18F2X1X/4X1X

5.1.1 PROGRAM COUNTER

The Program Counter (PC) specifies the address of the instruction to fetch for execu tion. The PC is 21 bits wide and is contained in three separate 8-bit registers. The low byte, known as the PCL register, is both readable and writable. The high byt e, or PCH re gister, contains the PC<15:8> bits; i t is not directly re adable or writ able. Updates to the PCH register are perfo rmed through the PCLATH register. The upper byte is called PCU. This register contains the PC<20:16> bits; it is also not directly readable or writable. Updates to the PCU register are performed through the PCLATU register.

The contents of PCLATH and PCLATU are transferred to the program counter by any operation that writes PCL. Similarly, the upper two bytes of the program counter are transferred to P CLATH and PCLATU by an operation that reads PCL. This is useful for computed offsets to the PC (see Section 5.1.4.1 “Computed GOTO”).

The PC addresses bytes in the program memory. To prevent the PC from becoming misaligned with word instructions, the Least Significant bit of PCL is fixed to a value of ‘0’. The PC increments by 2 to address sequential instructions in the program memory.

The CALL, RCALL, GOTO and program branch instructions write to the program counter directly. For these instructions, the contents of PCLATH and PCLATU are not transferred to the program counter.

5.1.2 RETURN ADDRESS STACK

The return address s tack allows any combination of up to 31 program calls and interrupts to occur. The PC is pushed onto th e stac k when a CALL or RCALL instruction is executed or an interrupt is Acknowledged. The PC value is pulled of f the stack o n a RETURN, RETLW or a RETFIE ins truction. PCLATU and PCLATH are not affected by any of the RETURN or CALL instructions.

The stack operates as a 31-word by 21-bit RAM and a 5-bit Stack Pointer, STKPTR. The stack space is not part of either program or da ta sp ace. The Stack Pointer is readable and writable and the address on the top of the stack is readable and writable through the top-ofstack Special File Registers. Data can also be pushed to, or popped from the stack, using these registers.

A CALL type instru ctio n caus es a pus h ont o the stac k; the Stack Pointer is first incremented and the location pointed to by the Stack Pointer is written with the contents of the PC (already pointing to the instruction following the CALL). A RETURN ty pe ins truc ti on c au se s a pop from the stack; the contents of the location pointed to by the STKPTR are transferred to the PC and then the Stack Pointer is decremented.

The Stack Pointer is initialized to ‘00000’ after all Resets. There is no RAM associated with the location corresponding to a Stack Pointer value of ‘00000’; this is only a Reset value. Status bit s in dic ate if the stack is full or has overflowed or has underflowed.

5.1.2.1 Top-of-Stack Access

Only the top of the return address stack (TOS) is

readable and writable. A set of three registers,

TOSU:TOSH:TOSL, hold th e contents of the stack location pointed to by the STKPTR register (Figure 5-2). This allows users to implement a software stack if necessary. After a CALL, RCALL or interrupt, the software can read the pushed value by reading the TOSU:TOSH:TOSL registers. These values can be placed on a use r defined software stack. At return time, the software can return these values to TOSU:TOSH:TOSL and do a return.

The user must disable the global interrupt enable bits while accessing the stack to prevent inadvertent stack corruption.

FIGURE 5-2: RETURN ADDRESS STACK AND ASSOCIATED REGISTERS

Return Address Stack <20:0>

11111

T op -of-Stack Registers Stack Pointer

TOSLTOSHTOSU

34h1Ah00h

Top-of-Stack

DS39636A-page 54 Preliminary  2004 Microchip Technology Inc.

001A34h

000D58h

11110 11101

STKPTR<4:0>

00010

00011 00010 00001 00000

PIC18F2X1X/4X1X

5.1.2.2 Return Stack Pointer (STKPTR)

The STKPTR register (Reg ister 5-1) contains the Stack Pointer value, the STKFUL (Stack Full) status bit and the STKUNF (Stack Underflow) status bits. The value of the Stack Pointer can be 0 through 31. The Stack Pointer increments before values are pushed onto the stack and decrements after values are popped off the stack. On Reset, the Stack Pointer value will be zero. The user may read and write the Stack Pointer value. This feature can be used by a Real-Time Operating System (RTOS) for return stack maintenance.

After the PC is pus hed o nto the st ack 31 times (wi thout popping any values off the stack), the STKFUL bit is set. The STKFUL bit is cleared by software or by a POR.

The action that takes place when the stack becomes full depends on the state of the STVREN (Stack Overflow Reset Enable) configuration bit. (Refer to Section 22.1 “Configuration Bits” for a de scription of the device configuration bits.) If STVREN is set (default), the 31st push will push the (PC + 2) value onto the stack, set the STKFUL bit and reset the device. The STKFUL bit will remain set and the Stack Pointer will be set to zero.

If STVREN is cleared, the STKFUL bi t will be set on the 31st push and the Stack Pointer will increment to 31. Any additional pushes will not overwrite the 31st push and STKPTR will remain at 31.

When the stack has been popped enough times to unload the stac k, the next pop will ret urn a value of zero to the PC and sets the STKUNF bit, while the Stack Pointer remains at zero. The STKUNF bit will remain set until cleared by software or until a POR occurs.

Note: Returning a value of zero to the PC on an

underflow has the effect of vectoring the program to the Reset vector, where the stack conditions can be verified and appropriate actions can be taken. This is not the same as a Reset, as the contents of the SFRs are not affected.

5.1.2.3 PUSH and POP Instruction s

Since the Top-of-Stack is readable and writable, the ability to push value s on to the st ac k an d pul l va lues off the stack without disturbing normal program execution is a desirable feature. The PIC18 instruction set includes two instructions, PUSH and POP, that permit the TOS to be manipulated under software control. TOSU, TOSH and T OS L can be m odifie d to plac e dat a or a return address on the stack.

The PUSH instruction places the current PC value onto the stack. This increments the Stack Pointer and loads the current PC value onto the stack.

The POP instruction discards the current TOS by decrementing the Stack Pointer. The previous value pushed onto the stack then becomes the TOS value.

REGISTER 5-1: STKPTR: STACK POINTER REGISTER

R/C-0 R/C-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

STKFUL

bit 7 bit 0

bit 7 STKFUL: Stack Full Flag bit

1 = Stack became full or overflowed 0 = Stack has not become full or overflowed

bit 6 STKUNF: Stack Underflow Flag bit

1 = Stack underflow occurred 0 = Stack underflow did not occur

bit 5 Unimplemented: Read as ‘0’ bit 4-0 SP4:SP0: Stack Pointer Location bits

Legend:

R = Readable bit W = Writable bit U = Unimplemented C = Clearable only bit

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

(1)

STKUNF

Note 1: Bit 7 and bit 6 are cleared by user software or by a POR.

(1)

— SP4 SP3 SP2 SP1 SP0

(1)

 2004 Microchip Technology Inc. Preliminary DS39636A-page 55

PIC18F2X1X/4X1X

5.1.2.4 Stack Full and Underflow Resets

Device Resets on stack overflow and stack underflow conditions are enabled by setting the STVREN bit in Configuration Regist er 4L. When STVREN is set, a full or underflow will set the appropriate STKFUL or STKUNF bit and then cause a device Reset. When STVREN is cleared, a full or underflow condi tion will set the appropriate STKFUL or STKUNF bit but not cause a device Reset. The STKFUL or STKUNF bits are cleared by the user software or a Power-on Reset.

5.1.3 FAST REGISTER STACK

DS39636A-page 56 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

5.2 PIC18 Instruction Cycle

5.2.1 CLOCKING SCHEME

The microcontroller clock input, whether from an internal or external source, is internally divided by four to generate four non-overlapping quadrature clocks (Q1, Q2, Q3 and Q 4). Internall y, the program cou nter is incremented on every Q1; the instruction is fetched from the program memory and latched into the instruction register during Q4. The ins truc tion is decoded and executed during the following Q1 through Q4. The clocks and instruction execution flow are shown in Figure 5-3.

FIGURE 5-3: CLOCK/ INSTRUCTION CYCLE

OSC1

Q1 Q2 Q3 Q4 PC

OSC2/CLKO

(RC mode)

Q2 Q3 Q4

PC PC + 2 PC + 4

Execute INST (PC – 2)

Fetch INST (PC)

Q2 Q3 Q4

Execute INST (PC)

Fetch INST (PC + 2)

5.2.2 INSTRUCTION FLOW/PIPELINING

An “Instruction Cycle” consists of four Q cycles: Q1 through Q4. The instruction fetch and execute are pipelined in such a manner that a fetch takes one instruction cycle, while the decode and execute take another instruction cycle. However, due to the pipelining, each instruction effectively executes in one cycle. If a n instruc tion caus es the pro gram coun ter to change (e.g., GOTO), then two cycles are required to complete the instruction (Example 5-3).

A fetch cycle begins with the Program Counter (PC) incrementing in Q1.

In the execution cy cle, the fetch ed instruction i s latched into the Instruction Register (IR) in cycle Q1. This instruction is then decoded and executed during the Q2, Q3 and Q4 cycle s. D ata memory is re ad dur ing Q 2 (operand read) and written during Q4 (destination write).

Q2 Q3 Q4

Internal Phase Clock

Execute INST (PC + 2)

Fetch INST (PC + 4)

EXAMPLE 5-3: INSTRUCTION PIPELINE FLOW

TCY0TCY1TCY2TCY3TCY4TCY5

1. MOVLW 55h

2. MOVWF PORTB

3. BRA SUB_1

4. BSF PORTA, BIT3 (Forced NOP)

5. Instruction @ address SUB_1

All instructions are single cycle, except for any program branche s. These take tw o cycles since the fetch instruction is “flushed” from the pipeline while the new instruction is being fetched and then executed.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 57

Fetch 1 Execute 1

Fetch 2 Execute 2

Fetch 3 Execute 3

Fetch 4 Flush (NOP)

Fetch SUB_1 Execute SUB_1

PIC18F2X1X/4X1X

5.2.3 INSTRUCTIONS IN PROGRAM MEMORY

The program memory is addressed in bytes. Instructions are stored as two bytes or four bytes in program memory. The Least Significant Byte of an instruction word is always stored in a program memory location with an even address (LSb = 0). To maintain alignment with instruction bo undaries , the PC incr ements in step s of 2 and the LSb wi ll always read ‘0’ (see Section 5.1.1 “Program Counter”).

Figure 5-4 shows an exam ple of h ow in st ruc tion w ord s are stored in the program memory.

The CALL and GOTO instructions have the absolute

program memory address embedded into the instruc-

tion. Since instructions are always stored on word boundaries, the data contained in the instruction is a word address. The word address is written to PC<20:1>, which accesses the desired byte address in program memory. Instruction #2 in Figure 5-4 shows how the instruction GOTO 0006h is encoded in the program memory. Program branch instructions, which encode a relative address offset, operate in the same ma nner. The offset value stored in a br anch instruction represent s the number of single-word instructions that the PC will be offset by. Section 23.0 “Instruction Set Summary” provides further details of the instruction set.

FIGURE 5-4: INSTRUCTIONS IN PROGRAM MEMORY

LSB = 1 LSB = 0 ↓

0Fh 55h 000008h EFh 03h 00000Ah F0h 00h 00000Ch C1h 23h 00000Eh F4h 56h 000010h

Instruction 1: Instruction 2:

Instruction 3:

Program Memory Byte Locations

MOVLW 055h GOTO 0006h

MOVFF 123h, 456h

→

Word Address

000000h 000002h 000004h 000006h

000012h 000014h

5.2.4 TWO-WORD INSTRUCTIONS

The standard PIC18 instruction set has four two-word instructions: CALL, MOVFF, GOTO and LSFR. In all cases, the second word of the in struc tion s always has ‘1111’ as its four M ost Si gnifican t bit s; the other 12 bit s are literal data, usually a data memory address.

The use of ‘1111’ in the 4 MSbs of an instruction specifies a special form of NOP. If the instruction is executed in proper sequence – immediately after the first wor d – the data in the s econd word is ac cessed an d used by

some reason and the se cond word is ex ecuted by itsel f, a NOP is executed instead. This is necessary for cases when the two-word instruction is preceded by a conditional instruction that changes the PC. Example 5-4 shows how this works.

Note: See Section 5.6 “PIC18 Instruction

Execution and the Extended Instruction Set” for information on two-word

instructions in the extended instruction set.

the instruction se quence. If the first word is skipped for

EXAMPLE 5-4: TWO-WORD INSTRUCTIONS

CASE 1: Object Code Source Code

0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0? 1100 0001 0010 0011 MOVFF REG1, REG2 ; No, skip this word 1111 0100 0101 0110 ; Execute this word as a NOP 0010 0100 0000 0000 ADDWF REG3 ; continue code

CASE 2: Object Code Source Code

0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0? 1100 0001 0010 0011 MOVFF REG1, REG2 ; Yes, execute this word 1111 0100 0101 0110 ; 2nd word of instruction 0010 0100 0000 0000 ADDWF REG3 ; continue code

DS39636A-page 58 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

5.3 Data Memory Organization

Note: The operation of some aspects of data

memory are changed when the PIC18 extended instruction set is enabled. See

Section 5.5 “Data Memory and the Extended Instruction Set” for more

information.

The data memory in PIC18 devices is implemented as static RAM. Figures 5-5, 5-6 and 5-7 show the data memory organization for the PIC18F2X1X/4X1X devices.

The data memory contains Special Function Registers (SFRs) and General Purpose Registers (GPRs). The SFRs are used for control and status of the controller and peripheral functio ns, while GPRs are us ed for data storage and scratchpad operations in the user’s application. Any re ad of an unimpl emented location will read as ‘0’s.

The instruction set and architecture allow operations across all banks. The entire data memory may be accessed by Direct, Indirect or Indexed Addressing modes. Addressing modes are discussed later in this subsection.

To ensure that commonly used registers (SFRs and select GPRs) c an b e ac cess ed i n a si ngle cycle, PI C18 devices impl em ent an Ac ce ss Ba nk . Th is i s a 256-byte memory space that pr ovid es fa st acces s to SFRs a nd the lower portion of GPR Bank 0 without using the BSR. Section 5.3.2 “Access Bank” provides a detailed description of the Access RAM.

5.3.1 BANK SELECT REGISTER (BSR)

Large areas of data memory require an efficient addressing scheme to make rapid access to any address possible. Ideally, this means that an entire address does not need to be provided for each read or write operation. For PIC18 devices, this is accomplished with a RAM banking scheme. This divides the memory space into 16 contiguous banks of 256 bytes. Depending on the instruction, each location can be addressed directly by its full 12-bit address, or an 8-bit low-order address and a 4-bit bank pointer.

Most instruct ions in th e PIC18 in struct ion set ma ke use of the bank poin ter, known as the Bank Select Reg ister (BSR). This SFR holds the 4 Most Significant bits of a location’s address; the instruction itself includes the 8 Least Significant bits. Only the four lower bits of the BSR are implemented (BSR3:BSR0). The upper four bits are unused; the y will always read ‘ 0’ and cannot be written to. The BSR can be l oaded direc tly by using the MOVLB instruction.

The value of the BSR indicates the bank in data memory; the 8 bits in the instruction show the location in the bank and can be thought of as an offset from the bank’s lower boundary. The relationship between the BSR’s value and the bank division in data memory is shown in Figure 5-8.

Since up to 16 regis ters m ay share the s ame l ow-order address, the user must alway s be careful to ensure that the proper bank is selected before performing a data read or write. For example, writing what should be program data to an 8-bit addre ss of F9 h, while the BSR is 0Fh, will end up resetting the program counter.

While any bank can be s el ec ted, only those banks that are actually implemented can be read or written to. Writes to unimplemented banks are ignored, while reads from unimplemented banks will return ‘0’s. Even so, the Status register will still be affected as if the operation was successful. The data memory map in Figure 5-5 indicates which banks are implemented.

In the core PIC18 instruction set, only the MOVFF instruction fully specifies the 12-bit address of the source and target registers. This i nstruction ig nores the BSR completely when it ex ecutes. All o ther instruction s include only the low-order address as an operand and must use either the BSR or the Access Bank to locate their target registers.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 59

PIC18F2X1X/4X1X

FIGURE 5-5: DATA MEMORY MAP FOR PIC18F2410/4410 DEVICES

BSR<3:0>

= 0000

= 0001

= 0010

= 0011

= 0100

= 0101

= 0110

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

= 1111

Bank 0

Bank 1

Bank 2

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

Bank 14

Bank 15

Data Memory Map

00h

FFh 00h

FFh

Access RAM

Unused

Read 00h

Unused

GPR

SFR

000h 07Fh 080h 0FFh 100h

1FFh 200h

2FFh 300h

3FFh 400h

4FFh 500h

5FFh 600h

6FFh 700h

7FFh 800h

8FFh 900h

9FFh A00h

AFFh B00h

BFFh C00h

CFFh D00h

DFFh E00h

EFFh F00h F7Fh

F80h FFFh

When ‘a’ = 0:

The BSR is ignored an d the Access Bank is used.

The first 128 bytes are general purpose RAM (from Bank 0).

The second 128 bytes are Special Function Registers (from Bank 15).

When ‘a’ = 1:

The BSR specifies the Ban k used by the instruction.

Access Bank

Access RAM Low

Access RAM High

(SFRs)

00h

7Fh 80h

FFh

DS39636A-page 60 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

FIGURE 5-6: DATA MEMORY MAP FOR PIC18F2510/4510 DEVICES

BSR<3:0>

= 0000

= 0001

= 0010

= 0011

= 0100

= 0101

= 0110

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

= 1111

Bank 0

Bank 1

Bank 2

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

Bank 14

Bank 15

Data Memory Map

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

Access RAM

Unused

Read 00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh 00h

FFh

Unused

GPR

SFR

000h 07Fh 080h 0FFh 100h

1FFh 200h

2FFh 300h

3FFh 400h

4FFh 500h

5FFh 600h

6FFh 700h

7FFh 800h

8FFh 900h

9FFh A00h

AFFh B00h

BFFh C00h

CFFh D00h

DFFh E00h

EFFh F00h

F7Fh

F80h FFFh

When ‘a’ = 0:

The BSR is ignored an d the Access Bank is used.

The first 128 bytes are general purpose RAM (from Bank 0).

The second 128 bytes are Special Function Registers (from Bank 15).

When ‘a’ = 1:

The BSR specifies the Ban k used by the instruction.

Access Bank

Access RAM Low

Access RAM High

(SFRs)

00h

7Fh 80h

FFh

 2004 Microchip Technology Inc. Preliminary DS39636A-page 61

PIC18F2X1X/4X1X

FIGURE 5-7: DATA MEMORY MAP FOR PIC18F2515/2610/4515/4610 DEVICES

BSR<3:0>

= 0000

= 0001

= 0010

= 0011

= 0100

= 0101

= 0110

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

= 1111

Bank 0

Bank 1

Bank 2

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

Bank 14

Bank 15

Data Memory Map

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh 00h

FFh

Access RAM

GPR

SFR

000h 07Fh 080h 0FFh 100h

1FFh 200h

2FFh 300h

3FFh 400h

4FFh 500h

5FFh 600h

6FFh 700h

7FFh 800h

8FFh 900h

9FFh A00h

AFFh B00h

BFFh C00h

CFFh D00h

DFFh E00h

EFFh F00h F7Fh

F80h FFFh

When a = 0:

The BSR is ignor ed and the Access Bank is used.

The first 128 bytes are general purpose RAM (from Bank 0).

The second 128 bytes are Special Function Registers (from Bank 15).

When a = 1:

The BSR specifie s th e Ba nk used by the instruction.

Access Bank

Access RAM Low

Access RAM High

(SFRs)

00h

7Fh

80h

FFh

DS39636A-page 62 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

FIGURE 5-8: USE OF THE BANK SELECT REGISTER (DIRECT ADDRESSING)

Memory

0000

Bank Select

(2)

(1)

BSR

0011

000h

100h

200h

300h

Data

Bank 0 Bank 1

Bank 2

Bank 3

through

Bank 13

00h FFh

00h

From Opcode

111 11 111

(2)

E00h

F00h

FFFh

Note 1: The Access RAM bit of the instruction can be used to force an override of the selected bank (BSR<3:0>) to

the registers of the Access Bank.

2: The MOVFF instruction embeds the entire 12-bit address in the instruction.

Bank 14

Bank 15

5.3.2 ACCESS BANK

While the use of the BSR with an embedded 8-bit address allows users to address the entire range of data memory, it also means th at the user must a lways ensure that the correct bank is selected. Otherwise, data may be read from or written to the wrong location. This can be disastrous if a GPR is the intended target of an operation, but an SFR is written to instead. Verifying and/or changing the BSR for each read or write to data memory can become very inefficient.

T o stre amline acces s for the most commonl y used data memory locations, the data memory is configured with an Access Bank, which allows users to access a mapped block of memory without specifying a BSR. The Access Bank consists of the first 128 bytes of memory (00h-7Fh) in Bank 0 and the last 128 bytes of memory (80h-FFh) in Block 15 . The lower half is known as the “Access RAM” and is composed of GPRs. This upper half is also where the device’s SFRs are mapped. These two areas are mapped contiguously in the Access Bank and can be addressed in a linear fashion by an 8-bit address (Figure 5-5).

The Access Bank is used by core PIC18 instructions that include the Access RAM bit (the ‘a’ parameter in

FFh 00h

FFh

Using this “forced” addressing allows the instruction to operate on a data address in a single cycle, without updating the BSR first. For 8-bit addresses of 80h and above, this means th at use rs can ev aluate an d operate on SFRs more efficiently. The Access RAM below 80h is a good place for da ta values that the user might need to access rapidly, such as immediate computational results or common program variables. Access RAM also allows for faster and more code efficient context saving and switching of variables.

The mapping of the Access Bank is slightly different when the extended instruction set is enabled (XINST configuration bit = 1). This is discussed in more detail in Section 5.5.3 “Mapping the Access Bank in Indexed Literal Offset Addressing Mode”.

5.3.3 GENERAL PURPOSE REGISTER FILE

PIC18 devices may have banked memory in the GPR area. This is data RAM, which is available for use by all instructions. GPRs start at the bottom of Bank 0 (address 000h) and grow upwards towards the bottom of the SFR area. GPRs are not initialized by a Power-on Reset and are unchanged on all other Resets.

the instruction). When ‘a’ is equal to ‘1’, the inst ru ct i on uses the BSR and the 8-bit address included in the opcode for the data memory address. When ‘a’ is ‘0’, however, the instruction is forced to use the Access Bank address map; the current value of the BSR is ignored entirely.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 63

PIC18F2X1X/4X1X

5.3.4 SPECIAL FUNCTION REGISTERS

The Special Function Registers (SFRs) are registers used by the CPU and p eripheral modul es for controllin g the desired operation of the device. These reg isters are implemented as static RAM. SFRs start at the top of data memory (FF Fh) and extend downw ard to oc cupy the top half of Bank 15 (F80h to FFFh). A list of these registers is given in Table 5-1 and Table 5-2.

The SFRs can be classified into two sets: those associated with the “ core” de vice functi onali ty (ALU, R eset s and interrupts) a nd those relate d to the periphe ral functions. The reset a nd in terrupt reg isters ar e d escribed in their respective c hap ters , wh ile the ALU’s S tatus register is described later in this s ection. Register s related to the operation of a peripheral feature are described in the chapter for that peripheral.

The SFRs are typically distributed among the peripherals whose fun cti ons th ey c ontr ol. U nus ed SFR locations are unimplemented and read as ‘0’s.

TABLE 5-1: SPECIAL FUNCTION REGISTER MAP FOR PIC18F2X1X/4X1X DEVICES

Address Name Address Name Address Name Address Name

FFFh TOSU FDFh INDF2

FFEh TOSH FDEh POSTINC2 FFDh TOSL FDDh POSTDEC2 FFCh STKPTR FDCh PREINC2

FFBh PCLATU FDBh PLUSW2

FFAh PCLATH FDAh FSR2H FBAh CCP2CON F9Ah — FF9h PCL FD9h FSR2L FB9h — FF8h TBLPTRU FD8h STATUS FB8h BAUDCON F98h — FF7h TBLPTRH FD7h TMR0H FB7h PWM1CON FF6h TBLPTRL FD6h TMR0L FB6h ECCP1AS FF5h TABLAT FD5h T0CON FB5h CVRCON F95h TRISD FF4h PRODH FD4h — FF3h PRODL FD3h OSCCON FB3h TMR3H F93h TRISB FF2h INTCON FD2h HLVDCON FB2h TMR3L F92h TRISA FF1h INTCON2 FD1h WDTCON FB1h T3CON F91h FF0h INTCON3 FD0h RCON FB0h SPBRGH F90h —

FEFh INDF0 FEEh POSTINC0 FEDh POSTDEC0 FECh PREINC0 FEBh PLUSW0

(1)

FCFh TMR1H FAFh SPBRG F8Fh —

(1)

FCEh TMR1L FAEh RCREG F8Eh — FCDh T1CON FADh TXREG F8Dh LATE FCCh TMR2 FACh TXSTA F8Ch LATD FCBh PR2 FABh RCSTA F8Bh LATC

FEAh FSR0H FCAh T2CON FAAh

FE9h FSR0L FC9h SSPBUF FA9h — FE8h WREG FC8h SSPADD FA8h — FE7h INDF1 FE6h POSTINC1 FE5h POSTDEC1 FE4h PREINC1 FE3h PLUSW1

(1)

FC7h SSPSTAT FA7h — FC6h SSPCON1 FA6h — FC5h SSPCON2 FA5h — FC4h ADRESH FA4h —

FC3h ADRESL FA3h — FE2h FSR1H FC2h ADCON0 FA2h IPR2 F82h PORTC FE1h FSR1L FC1h ADCON1 FA1h PIR2 F81h PORTB FE0h BSR FC0h ADCON2 FA0h PIE2 F80h PORTA

(1)

FBFh CCPR1H F9Fh IPR1

(1)

(2)

FBEh CCPR1L F9Eh PIR1 FBDh CCP1CON F9Dh PIE1 FBCh CCPR2H F9Ch —

FBBh CCPR2L F9Bh OSCTUNE

(2)

(3)

F99h —

F97h — F96h TRISE

FB4h CMCON F94h TRISC

(2)

—

(2) (2) (2) (2) (2) (2) (2)

F8Ah LATB

F89h LATA F88h — F87h — F86h — F85h — F84h PORTE F83h PORTD

—

(2)

(2) (2) (2) (2)

(3) (3)

Note 1: This is not a physical register.

2: Unimplemented registers are read as ‘0’. 3: This register is not available on 28-pin devices.

DS39636A-page 64 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2X1X/4X1X)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TOSU TOSH Top-of-Stack High Byte (TOS<15:8>) 0000 0000 49, 54 TOSL Top-of-Stack Low Byte (TOS<7:0>) 0000 0000 49, 54 STKPTR STKFUL PCLATU PCLATH Holding Register for PC<15:8> 0000 0000 49, 54 PCL PC Low Byte (PC<7:0>) 0000 0000 49, 54 TBLPTRU TBLPTRH Program Memory Table Pointer High Byte (TBLPTR<15:8>) 0000 0000 49, 77 TBLPTRL Program Memory Table Pointer Low Byte (TBLPTR<7:0>) 0000 0000 49, 77 TABLAT Program Memory Table Latch 0000 0000 49, 77 PRODH Product Register High Byte xxxx xxxx 49, 79 PRODL Product Register Low Byte xxxx xxxx 49, 79 INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 0000 000x 49, 83 INTCON2 RBPU INTCON3 INT2IP INT1IP INDF0 Uses contents of FSR0 to address data memory – value of FSR0 not changed (not a physical register) N/A 49, 70 POSTINC0 Uses contents of FSR0 to addres s data memory – value of FSR0 post-incremented (not a physical register) N/A 49, 70 POSTDEC0 Uses contents of FSR0 to address data memory – value of FSR0 post-decremented (not a physical register) N/A 49, 70 PREINC0 Uses contents of FSR0 to address data memory – value of FSR0 pre-incremented (not a physical register) N/A 49, 70 PLUSW0 Uses contents of FSR0 to address data memory – value of FSR0 pre-incremented (not a physical register) –

FSR0H FSR0L Indirect Data Memory Address Pointer 0 Low Byte xxxx xxxx 49, 70 WREG Working Register xxxx xxxx 49 INDF1 Uses contents of FSR1 to address data memory – value of FSR1 not changed (not a physical register) N/A 49, 70 POSTINC1 Uses contents of FSR1 to addres s data memory – value of FSR1 post-incremented (not a physical register) N/A 49, 70 POSTDEC1 Uses contents of FSR1 to address data memory – value of FSR1 post-decremented (not a physical register) N/A 49, 70 PREINC1 Uses contents of FSR1 to address data memory – value of FSR1 pre-incremented (not a physical register) N/A 49, 70 PLUSW1 Uses contents of FSR1 to address data memory – value of FSR1 pre-incremented (not a physical register) –

FSR1H FSR1L Indirect Data Memory Address Pointer 1 Low Byte xxxx xxxx 50, 70 BSR INDF2 Uses contents of FSR2 to address data memory – value of FSR2 not changed (not a physical register) N/A 50, 70 POSTINC2 Uses contents of FSR2 to addres s data memory – value of FSR2 post-incremented (not a physical register) N/A 50, 70 POSTDEC2 Uses contents of FSR2 to address data memory – value of FSR2 post-decremented (not a physical register) N/A 50, 70 PREINC2 Uses contents of FSR2 to address data memory – value of FSR2 pre-incremented (not a physical register) N/A 50, 70 PLUSW2 Uses contents of FSR2 to address data memory – value of FSR2 pre-incremented (not a physical register) –

FSR2H FSR2L Indirect Data Memory Address Pointer 2 Low Byte xxxx xxxx 50, 70 STATUS

Legend: x = unknown , u = unchanged, — = unimplemented, q = value depends on condition Note 1: The SBOREN bit is only available when the BOREN1:BOREN0 configuration bits = 01; otherwise, it is disabled and reads as ‘0’. See

2: These registers and/or bits are not implemen ted on 28-pin devices and are read as 3: The PLLEN bit is only available in specific oscillator configuration; otherwise it is disabled and reads as 4: The RE3 bit is only available when Master Clear Reset is disabled (MCLRE configuration bit = 0). Otherwise, RE3 reads as 5: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes. 6: Bit 7 and bit 6 are cleared by user software or by a POR.

— — — Top-of-Stack Upper Byte (TOS<20:16>) ---0 0000 49, 54

(6)

— — — Holding Regi st er for PC<20:16> ---0 0000 49, 54

— — bit 21 Program Memory Table Pointer Upper Byte (TBLPTR<20:16>) --00 0000 49, 77

value of FSR0 offset by W

— — — — Indirect Data Memory Address Pointer 0 High ---- 0000 49, 70

value of FSR1 offset by W

— — — — Indirect Data Memory Address Pointer 1 High ---- 0000 50, 70

— — — — Bank Select Register ---- 0000 50, 59

value of FSR2 offset by W

— — — — Indirect Data Memory Address Pointer 2 High ---- 0000 50, 70

— — —NOVZDCC---x xxxx 50, 68

Section 4.4 “Brown-out Reset (BOR)”.

(6)

STKUNF

INTEDG0 INTEDG1 INTEDG2 —TMR0IP—RBIP1111 -1-1 49, 84

— SP4 SP3 SP2 SP1 SP0 00-0 0000 49, 55

—INT2IEINT1IE— INT2IF INT1IF 11-0 0-00 49, 85

‘0’. Reset values are shown for 40/44-pin devices;

individual unimplemented bits should be interpreted as ‘-’. INTOSC Modes”. read-only. When disabled, these bits read as ‘0’.

‘0’. See Section 2.6.4 “PLL in

Value on

POR, BOR

N/A 49, 70

N/A 50, 70

Details

on page:

‘0’. This bit is

 2004 Microchip Technology Inc. Preliminary DS39636A-page 65

PIC18F2X1X/4X1X

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2X1X/4X1X) (CONTINUED)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TMR0H Timer0 Register High Byte 0000 0000 50, 115 TMR0L Timer0 Register Low Byte xxxx xxxx 50, 115 T0CON TMR0ON T08BIT T0CS T0SE PSA T0PS2 T0PS1 T0PS0 1111 1111 50, 113 OSCCON IDLEN IRCF2 IRCF1 IRCF0 OSTS IOFS SCS1 SCS0 0100 q000 30, 50 HLVDCON VDIRMAG WDTCON RCON IPEN SBOREN TMR1H Timer1 Register High Byte xxxx xxxx 50, 121 TMR1L Timer1 Register Low Bytes xxxx xxxx 50, 121 T1CON R D16 T1RUN T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR2 Timer2 Register 0000 0000 50, 124 PR2 Timer2 Period Register 1111 1111 50, 124 T2CON SSPBUF SSP Receive Buffer/Transmit Regis ter xxxx xxxx 50, 159,

SSPADD SSP Address Register in I SSPSTAT SMP CKE D/A

SSPCON1 WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 50, 153,

SSPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 50, 163 ADRESH A/D Result Register High Byte xxxx xxxx 51, 220 ADRESL A/D Result Register Low Byte xxxx xxxx 51, 220 ADCON0 ADCON1 ADCON2 ADFM CCPR1H Captur e/C o mpar e/P WM R egis t er 1 High Byte xxxx xxxx 51, 130 CCPR1L Capture/Compare/PWM Register 1 Low Byte xxxx xxxx 51, 130 CCP1CON P1M1

CCPR2H Captur e/C o mpar e/P WM R egis t er 2 High Byte xxxx xxxx 51, 130 CCPR2L Capture/Compare/PWM Register 2 Low Byte xxxx xxxx 51, 130 CCP2CON BAUDCON ABDOVF RCIDL PWM1CON PRSEN PDC6 ECCP1AS ECCPASE ECCPAS2 ECCPAS1 ECCPAS0 PSSAC1 PSSAC0 PSSBD1 CVRCON CVREN CVROE CVRR CVRSS CVR3 CVR2 CVR1 CVR0 0000 0000 51, 227 CMCON C2OUT C1OUT C2INV C1INV CIS CM2 CM1 CM0 0000 0111 51, 221 TMR3H Timer3 Register High Byte xxxx xxxx 51, 127 TMR3L Timer3 Register Low Byte xxxx xxxx 51, 127 T3CON RD16 T3CCP2 T3CKPS1 T3CKPS0 T3CCP1 T3SYNC

— — — — — — —SWDTEN--- ---0 50, 247

— T2OUTPS3 T2OUTPS2 T2OUTPS1 T2OUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 50, 123

— — CHS3 CHS2 CHS1 CHS0 GO/DONE ADON --00 0000 51, 211 — — VCFG1 VCFG0 PCFG3 PCFG2 PCFG1 PCFG0 --00 0qqq 51, 212

(2)

— — DC2B1 DC2B0 CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 51, 129

Section 4.4 “Brown-out Reset (BOR)”. individual unimplemented bits should be interpreted as ‘-’. INTOSC Modes”. read-only. When disabled, these bits read as ‘0’.

— IRVST HLVDEN HLVDL3 HLVDL2 HLVDL1 HLVDL0 0-00 0101 50, 231

(1)

—RITO PD POR BOR 0q-1 11q0 42, 48, 92

TMR1CS T MR1ON 0000 0000 50, 117

C Slave Mode. SSP Baud Rate Reload Register in I2C Master Mode. 0000 0000 50, 160

PSR/WUA BF 0000 0000 50, 152,

— ACQT2 ACQT 1 ACQT0 ADCS2 ADCS1 ADCS0 0-00 0000 51, 213

P1M0

(2)

DC1B1 DC1B0 CCP1M3 CCP1M2 CCP1M1 CCP1M0 0000 0000 51, 129,

(2)

— SCKP BRG16 — WUE ABDEN 01-0 0-00 51, 194

PDC5

(2)

PDC4

(2)

PDC3

(2)

PDC2

(2)

PDC1

TMR3CS T MR3ON 0000 0000 51, 125

(2)

PDC0

PSSBD0

‘0’. Reset values are shown for 40/44-pin devices;

‘0’. See Section 2.6.4 “PLL in

Value on

POR, BOR

(2)

0000 0000 51, 146

(2)

0000 0000 51, 147

Details

on page:

160

161

162

137

‘0’. This bit is

DS39636A-page 66 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2X1X/4X1X) (CONTINUED)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Value on

POR, BOR

SPBRGH EUSART Baud Rate Generator Register High Byte 0000 0000 51, 195 SPBRG EUSART Baud Rate Generator Register Low Byte 0000 0000 51, 195 RCREG EUSART Receive Register 0000 0000 51, 202 TXREG EUSART Transmit Register 0000 0000 51, 200 TXSTA CSRC TX9 TXEN SYNC SENDB BRGH TRMT TX9D 0000 0010 51, 192 RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 51, 193 IPR2 OSCFIP CMIP PIR2 OSCFIF CMIF PIE2 OSCFIE CMIE IPR1 PSPIP PIR1 PSPIF PIE1 PSPIE

(2)

ADIP RCIP TXIP SSPIP CCP1IP TMR2IP TMR1IP 1111 1111 52, 90

(2)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 52, 86

(2)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 52, 88

OSCTUNE INTSRC PLLEN

(2)

TRISE TRISD

(2)

IBF OBF IBOV PSPMODE — TRISE2 TRISE1 TRISE0 0000 -111 52, 108

PORTD Data Direction Control Register 1111 1111 52, 104

(3)

— — BCLIP HLVDIP TMR3IP CCP2IP 11-- 1111 52, 91 — — BCLIF HLVDIF TMR3IF CCP2IF 00-- 0000 52, 87 — — BCLIE HLVDIE TMR3IE CCP2IE 00-- 0000 52, 89

— TUN4 TUN3 TUN2 TUN 1 TUN0 0q-0 0000 27, 52

TRISC PORTC Data Direction Control Register 1111 1111 52, 101 TRISB PORTB Data Direction Control Register 1111 1111 52, 98 TRISA TRISA7

(2)

LATE

— — — — — PORTE Data Latch Register

(5)

TRISA6

(5)

Data Direction Control Register for PORTA 1111 1111 52, 95

---- -xxx 52, 107

(Read and Write to Data Latch)

(2)

LATD

PORTD Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 104 LATC PORTC Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 101 LATB PORTB Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 98 LATA LATA7 PORTE PORTD

(2)

— — — —RE3

RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 xxxx xxxx 52, 104

(6)

LATA6

(6)

PORTA Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 95

(4)

RE2

(2)

RE1

(2)

RE0

(2)

---- xxxx 52, 107

PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0 xxxx xxxx 52, 101 PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 xxxx xxxx 52, 98 PORTA RA7

(5)

RA6

(5)

RA5 RA4 RA3 RA2 RA1 RA0 xx0x 0000 52, 95

Legend: x = unknown , u = unchanged, — = unimplemented,

Details

on page:

 2004 Microchip Technology Inc. Preliminary DS39636A-page 67

PIC18F2X1X/4X1X

5.3.5 STATUS REGISTER

The St atus register , s hown in Register5-2, contains the arithmetic status of the ALU. As with any other SFR, it can be the operand for any instruction.

If the St atus regis ter is the dest ination for an instructio n that affect s the Z, DC, C, OV or N bit s, the re sults of the instruction are not written; instead, the status is updated according to t he i nstruc tion pe rformed . Therefore, the result of an instru cti on w i th the Status register as its destinatio n may be dif ferent than intended . As an example, CLRF STATUS will set the Z bit and leave the remaining status bits unchanged (‘000u u1uu’).

REGISTER 5-2: STATUS REGISTER

U-0 U-0 U-0 R/W-x R/W-x R/W-x R/W-x R/W-x

— — —NOVZDCC

bit 7 bit 0

bit 7-5 Unimplemented: Read as ‘0’ bit 4 N: Negative bit

This bit is used for signed arithmetic (2’s complement). It indicates whether the result was negative (ALU MSB = 1).

1 = Result was negative 0 = Result was positive

bit 3 OV: Overflow bit

This bit is used for signed arithmetic (2’s complement). It indicates an overflow of the 7-bit magnitude which causes the sign bit (bit 7 of the result) to change state.

1 = Overflow occurred for signed arithmetic (in this arithmetic operation) 0 = No overflow occurred

bit 2 Z: Zero bit

1 = The result of an arithmetic or logic operation is zero 0 = The result of an arithmetic or logic operation is not zero

bit 1 DC: Digit carry/bor row

For ADDWF, ADDLW, SUBLW and SUBWF instructions:

1 = A carry-out from the 4th low-order bit of the result occurred 0 = No carry-out from the 4th low-order bit of the result

Note: For borrow,

2’s complement of the second operand. For rotate (RRF, RLF) instructions, this bit is loaded with either bit 4 or bit 3 of the source register.

bit 0 C: Carry/borrow bit

For ADDWF, ADDLW, SUBLW and SUBWF instructions:

1 = A carry-out from the Most Significant bit of the result occurred 0 = No carry-out from the Most Significant bit of the result occurred

Note: For borrow,

2’s complement of the second operand. For rotate (RRF, RLF) instructions, this bit is loaded with either the high or low-order bit of the source register.

bit

the polarity is reversed. A subtraction is executed by adding the

It is recommended that only BCF, BSF, SWAPF, MOVFF and MOVWF instructions are used to alter the Status register , b ecaus e thes e ins tructi ons d o not af fect t he Z, C, DC, OV or N bits in the Status register.

For other instructions that do not affect status bits, see the instruction set summaries in Table 23-2 and Table 23-3.

Note: The C and DC bits operate as the borrow

and digit borrow bits, respectively, in subtraction.

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

DS39636A-page 68 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

5.4 Data Addressing Modes

Note: The execution of some instructions in the

core PIC18 instruction set are changed when the PIC18 extended instruction set is enabled. See Section 5.5 “Data Memory and the Extended Instruction Set” for more information.

The data memory space can be addr essed in se veral ways. For most instructions, the addressing mode is fixed. Other instructions may use up to three modes, depending on whic h operands are used and whe ther or not the extended instruction set is enabled.

The addressing modes are:

• Inherent

• Literal

•Direct

•Indirect An additional addressing mode, Indexed Literal Offset,

is available when the extended instruction set is enabled (XINST configuration bit = 1). Its operation is discussed in greater detail in Section 5.5.1 “Indexed Addressing with Literal Offset”.

5.4.1 INHERENT AND LITERAL ADDRESSING

Many PIC18 control instructions do not need any argument at all; they either perform an operation that globally affects the device or they operate implicitly on one register. This addressing mode is known as Inherent Addressing. Exa mp les includ e SLEEP, RESET and DAW.

Other instructions work in a similar way but require an additional explicit argument in the opcode. This is known as Literal Addressing mode because they require some literal value as an argument. Examples include ADDLW and MOVLW which, respectively, add or move a literal value to the W register. Other examples include CALL and GOTO, which include a 20-bit program memory address.

5.4.2 DIRECT ADDRESSING

Direct addressing specifies all or part of the source and/or destination address of the operation within the opcode itself. The options are specified by the arguments accompanying the instruction.

In the core PIC18 inst ruct ion se t, bit-ori ented and by teoriented instructions use some version of direct addressing by default. All of these instructions include some 8-bit literal address as their Least Significant Byte. This address spec ifies either a re gister address in one of the banks of d ata RAM ( Section 5.3.3 “General Purpose Register File”) or a location in the Access Bank (Section 5.3.2 “Access Bank”) as the data source for the instruction.

The Access RAM bit ‘a’ determines how the addre ss i s interpreted. When ‘a’ is ‘1’, the contents of the BSR (Section 5.3.1 “Bank Select Register (BSR)”) are used with the address t o determin e the comple te 12-bit address of the reg ister. When ‘a’ is ‘0’, the address is interpreted as being a register in the Access Bank. Addressing that uses the Access RAM is sometimes also known as Direct Forced Addressing mode.

A few instructions, such as MOVFF, include the entire 12-bit address (either source or destination) in their opcodes. In these cases, the BSR is ignored entirely.

The destination of the operati on’s results is determined by the destination bit ‘d ’. Wh en ‘d’ is ‘1’, the results are stored back in t he s o ur c e re g is ter, over wr iti n g i ts or i gi nal contents. When ‘d’ is ‘0’, the results are stored in the W register. Instructions without the ‘d’ argument have a destin ation tha t is i mplicit in the inst ruction; their destination is either the target register being operated on or the W register.

5.4.3 INDIRECT ADDRESSING

Indirect addressi ng allows the user to acces s a locatio n in data memory without giving a fixed address in the instruction. This is done by using File Select Registers (FSRs) as pointers to the location s to be read or written to. Since the FSRs are themselves located in RAM as Special File Reg isters , they can also be directl y mani pulated under program control. This makes FSRs very useful in imp lem ent ing data str uct ures , s uch as tabl es and arrays in data memory.

The registers for indirect addressing are also implemented with Indirect File Operands (INDFs) that permit automatic mani pulati on of the poi nter val ue wi th auto-incrementing, auto-decrementing or offsetting with another va lue . Th is al lo ws f or e fficient code, usin g loops, such as the example of clearing an entire RAM bank in Example 5-5.

EXAMPLE 5-5: HOW TO CLEAR RAM

(BANK 1) USING INDIRECT ADDRESSING

LFSR FSR0, 100h ;

NEXT CLRF POSTINC0 ; Clear INDF

; register then ; inc pointer

BTFSS FSR0H, 1 ; All done with

; Bank1?

BRA NEXT ; NO, clear next

CONTINUE ; YES, continue

 2004 Microchip Technology Inc. Preliminary DS39636A-page 69

PIC18F2X1X/4X1X

5.4.3.1 FSR Registers and the INDF Operand

At the core of indirect addressing are three sets of registers: FSR0, FSR1 and FSR2. Each represents a pair of 8-bit registers, FSRnH and FSRnL. The four upper bits of the FSRnH register are not used so each FSR pair holds a 12-bi t va lue. T his repre sen ts a value that can address the entire range of the data memory in a linear fashion. The FSR register pairs, then, serve as pointers to data memory locations.

Indirect addressing is accomplished with a set of Indirect File Operands, INDF0 through INDF2. These can be thought of as “virtual” registers: they are mapped in the SFR space but are not physically implemented. Reading or writin g to a particular INDF reg ister actually accesses its corresponding FSR register pair. A read from INDF1, for example, reads the data at the address indi cated by FSR 1H:FSR1L. Instructi ons that use the IND F registers as operands actual ly use the contents of th eir co rrespon ding FS R as a poin ter to th e instruction’s target. The INDF operand is just a convenient way of using the pointer.

Because indirec t addre ssing us es a full 1 2-bit a ddress , data RAM banking is not necessary. Thus, the current contents of the BSR and the Access RAM bit have no effect on determining the target address.

5.4.3.2 FSR Registers and POSTI NC, POSTDEC, PREINC and PLUSW

In addition to the IND F operand, eac h FSR register pair also has four additional indirect operands. Like INDF, these are “virtual” registers that cannot be indirectly read or written to. Accessing these registers actually accesses the associated FSR register pair, but also performs a specifi c action on it s stored v alue. They ar e:

• POSTDEC: accesses the FSR value, then

automatically decrements it by 1 afterwards

• POSTINC: accesses the FSR valu e, then

automatically increments it by 1 afterwards

• PREINC: increments the FSR value by 1, then

uses it in the operation

• PLUSW: adds the signed value of the W register

(range of -127 to 128) t o that of th e FSR and uses the new value in the operation.

In this context, accessing an INDF register uses the value in the FSR registers with out changing the m. Similarly , acces sing a PLUSW register giv es the FSR v alue offset by that in the W registe r; neit her value is ac tuall y changed in the operation. Accessing the other virtual registers changes the value of the FSR registers.

Operations on the FSRs with POSTDEC, POSTINC and PREINC affect the entire register pair; that is, rollovers of the FSRnL register from FFh to 00h ca rry over to the FSRnH register. On the other hand, results of these operations do not change the value of any flags in the Status register (e.g., Z, N, OV, etc.).

FIGURE 5-9: INDIRECT ADDRESSING

Using an instruction with one of the indirect addressing registers as the

operand....

...uses the 12-bit address stored in the FSR pair associated with that

xxxx111 0 11001 100

...to determine the data memory location to be used in that operation.

In this case, the FSR1 pair contains ECCh. This means the contents of location ECCh will be added to that of the W register and stored back in ECCh.

ADDWF, INDF1, 1

FSR1H:FSR1L

000h

Bank 0

100h

200h

300h

E00h

F00h

FFFh

Bank 1

Bank 2

Bank 3

through

Bank 13

Bank 14

Bank 15

Data Memory

DS39636A-page 70 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

The PLUSW register can be used to implement a form of indexed addressing in t he data memory space. By manipulating the value in the W register, users can reach addresses that are fixed offsets from pointer addresses. In some applications, this can be used to implement some powerful program control structure, such as softw are stacks, insi de of data memory.

5.4.3.3 Operations by FSRs on FSRs

Indirect addressing operations that target other FSRs or virtual registers represent special cases. For example, using an FSR to point to on e of the virtual regis ters will not result in successful operations. As a specific case, assume that FSR0H:FSR0L contains FE7h, the address of INDF1. Attempts to read the value of the INDF1 using INDF0 as an operand will return 00h. Attempts to write to INDF1 using I NDF0 as the operan d will result in a NOP.

On the other ha nd, u sing the v irtual reg isters to w rite to an FSR pair may n ot oc cur as plan ned. I n t hese cases , the value will be written to the FSR p air bu t withou t any incrementing or decrementing. Thus, writing to INDF2 or POSTDEC2 will write the same value to the FSR2H:FSR2L.

Since the FSRs are physical registers mapped in the SFR space, they can be manipulated through all direct operations. Users should proceed cautiously when working on these registers, particularly if their code uses indirect addressing.

Similarly, operations by indirect addressing are generally permitted on all other SFRs. U sers shoul d exercise the appropriate caution that they do not inadvertently change settings that might affect the operation of the device.

5.5 Data Memory and the Extended Instruction Set

Enabling the PIC18 extended instruction set (XINST configuration bit = 1) significantly changes certain aspects of data memory and its addressing. Specifically, the use of the Access Bank for many of the core PIC18 instructions is different; this is due to the introduction of a new addressing mode for the data memory space.

What does not change is just as im po rtant. The size of the data memory space is unchanged, as well as its linear addressing. The SFR map remains the same. Core PIC18 instructions can still operate in both Direct and Indirect Addressing mode; inherent and literal instructions do not change at all. Indirect addressing with FSR0 and FSR1 also remain unchanged.

5.5.1 INDEXED ADDRESSING WITH LITERAL OFFSET

Enabling the PIC18 extended instruction set changes the behavior of indirect addressing using the FSR2 register pair within access RAM. Under the proper conditions, instruc tions that us e the Access Ban k – that is, most bit-oriented and byte-oriented instructions – can invoke a form of indexed addressing using an offset specified in the in structi on. Thi s spe cial addr ess ing mode is known as Indexed Addressing with Literal Offset, or Indexed Literal Offset mode.

When using the extended instruction set, this addressing mode requires the following:

• The use of the Access Bank is forced (‘a’ = 0);

and

• The file addres s arg um ent is less than or equa l to

5Fh.

Under these conditions, the file address of the instruction is not interpreted as the lower byte of an address (used with the BSR in direct addre ssing), or as an 8-bit address in the Access Bank. Instead, the value is interpreted as an offset value to an address pointer, specified by FSR2. The offset and the contents of FSR2 are added to obtain the target address of the operation.

5.5.2 INSTRUCTIONS AFFECTED BY INDEXED LITERAL OFFSET MODE

Any of the core PIC18 instructions that can use direct addressing are potentially affected by the Indexed Literal Offset Addressing mode. This includes all byte-oriented and bit-oriented instructions, or almost one-half of the standard PIC18 instruction set. Instructions that only use Inherent or Literal Addressing modes are unaffected.

Additionally, byte-oriented and bit-oriented instructions are not affected if they do not use the Access Bank (Access RAM bit is ‘1’), or include a fi le ad dres s of 60 h or above. Instructions meeting these criteria will continue to execute as before. A comparison of the different possible addressing modes when the extended instruction set is enabled is shown in Figure 5-10.

Those who desire to use bit-oriented or byte-oriented instructions in the Indexed Literal Offset mode should note the changes to assembler syntax for this mode. This is described in more detail in Section 23.2.1 “Extended Instruction Syntax”.

 2004 Microchip Technology Inc. Preliminary DS39636A-page 71

PIC18F2X1X/4X1X

FIGURE 5-10: COMPARING ADDRESSING OPTIONS FOR BIT-ORIENTED AND

BYTE-ORIENTED INSTRUCTIONS (EXTENDED INSTRUCTION SET ENABLED)

EXAMPLE INSTRUCTION: ADDWF, f, d, a (Opcode: 0010 01da ffff ffff)

When ‘a’ = 0 and f ≥ 60h:

The instruction executes in Direct Forced mode. ‘f’ is interpreted as a location in the Access RAM between 060h and 0FFh. This is the sam e as locations 060h to 07Fh (Bank 0) and F80h to FFFh (Bank 15) of data memory.

Locations below 60h are not available in this addressing mode.

When ‘a’ = 0 and f ≤ 5Fh:

The instruction executes in Indexed Literal Offset mode. ‘f’ is interpreted as an offset to the address value in FSR2. The two are added together to obtain the address of the target register for the instruction. The address can be anywhere in the data memory space.

Note that in this mode, the correct syntax is now:

ADDWF [k], d

where ‘k’ is the same as ‘f’.

000h 060h

080h

100h

F00h

F80h

FFFh

000h

080h

100h

F00h

F80h

FFFh

Bank 0

Bank 1 through

Bank 14

Bank 15

SFRs

Data Memory

Bank 0

Bank 1 through

Bank 14

Bank 15

SFRs

Data Memory

00h 60h

80h

Access RAM

FSR2H FSR2L

FFh

ffffffff001001da

Valid range

for ‘f’

BSR

00000000

ffffffff001001da

When ‘a’ = 1 (all values of f):

The instruction executes in Direct mode (also known as Direct Long mode). ‘f’ is interpreted as a location in one of the 16 banks of the data memory space. The bank is designated by the Bank Sel ect

000h

080h

100h

Bank 0

Bank 1 through

Bank 14

DS39636A-page 72 Preliminary  2004 Microchip Technology Inc.

F00h

F80h

FFFh

Bank 15

SFRs

Data Memory

PIC18F2X1X/4X1X

5.5.3 MAPPI NG THE ACCESS BANK IN INDEXED LITERAL OFFSET ADDRESSING MODE

The use of Indexed Literal Offset Addressing mode effectively changes how the first 96 locations of access RAM (00h to 5Fh) are m ap ped . R at her tha n c on t ai nin g just the contents of the bottom half of Bank 0, this mode maps the contents from Bank 0 and a user defined “window” that can be located anywhere in the data memory space. The value of FSR2 establishes the lower boundary of the addresses mapped into the window, while the upper boundary is defined by FSR2

Remapping of the Access Bank applies only to operations using the Indexed Literal Offset Addressing mode. Operations that us e the BSR (Access RAM bit is ‘1’) will continue to use direct addressing as before.

5.6 PIC18 Instruction Execution and the Extended Instruction Set

Enabling the extended instruction set adds eight

additional commands to the existing PIC18 instruction

set. These instructions are executed as described in Section 23.2 “Extended Instruction Set”.

plus 95 (5Fh). Addresses in the Access RAM above 5Fh are mapped as previously described (see Section 5.3.2 “Access Bank”). An example of Access Bank remapping in this addressing mode is shown in Figure 5-11.

FIGURE 5-11: REMAPPING THE ACCESS BANK WITH INDEXED LITERAL OFFSET

ADDRESSING

Example Situation:

ADDWF f, d, a

FSR2H:FSR2L = 120h

Locations in the region from the FSR2 pointer (120h) to the pointer plus 05Fh (17Fh) are mapped to the bottom of the Access RAM (000h-05Fh).

Locations in Bank 0 from 060h to 07Fh are mapped, as usual, to the middle of the Access Bank.

Special File Registers at F80h through FFFh are mapped to 80h through FFh, as usual.

Bank 0 addresses below 5Fh can still be addressed by using the BSR.

000h

05Fh 07Fh

100h 120h

17Fh

200h

F00h

F80h

FFFh

Bank 0

Bank 0 Bank 1

Window

Bank 1

Bank 2 through

Bank 14

Bank 15

SFRs

Data Memory

Bank 1 “Window”

Bank 0

SFRs

Access Bank

00h

5Fh 7Fh

80h

FFh

 2004 Microchip Technology Inc. Preliminary DS39636A-page 73

PIC18F2X1X/4X1X

NOTES:

DS39636A-page 74 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

6.0 FLASH PROGRAM MEMORY

In PIC18F2X1X/4X1X devices , the program me mory i s implemented as read-o nly Flas h memory. It is read able over the entire VDD range during normal operation. A read from program memory is exec uted on one byte at a time.

6.1 Table Reads

For PIC18 devices, there are two operations that allow the processor to move bytes between the program memory space and the data RAM: table read (TBLRD) and table write (TBLWT).

Table read operations retrieve data from program memory and place it into the data RAM space. Figure 6-1 shows the operation of a table read with program memory and dat a RAM.

The program memory space is 16 bits wide, while the data RAM space is 8 bits wide. Table reads and table writes move data between these two memory spaces through an 8-bit register, TABLAT.

FIGURE 6-1: TABLE READ OPERATION

Table reads work with byte entities. A table block

containing data, rather than program instructions, is not

required to be word-aligned. Therefore, a table block can start and end at any byte address.

Because the program memory cannot be written to or erased under normal operation, the TBLWT operation is not discussed here.

Note 1: Although it cannot be used in

PIC18F2X1X/4X1X devices in normal operation, the TBLWT instruction is still implemented in the instruction set. Executing the instruction takes two instruction cycles, but effectively results in a NOP.

2: The TBLWT instruction is available only in

programming modes and is used during In-Circuit Serial Programming™ (ICSP™).

Instruction: TBLRD*

Table Pointer

TBLPTRU

Note 1: Table Pointer register points to a byte in program memory.

TBLPTRH TBLPTRL

(1)

Program Memory (TBLPTR)

Program Memory

Table Latch (8-bit)

TABLAT

 2004 Microchip Technology Inc. Preliminary DS39636A-page 75

PIC18F2X1X/4X1X

6.2 Control Registers

Two control registers are used in conjunction with the TBLRD instruction: the TABLAT register and the TBLPTR register set.

6.2.1 TABLAT – TABLE LATCH REGISTER

The Table Latch (TABLAT) is an 8-bit register mapped into the SFR space. The Table Latch register is used to hold 8-bit data during data transfers between program memory and data RAM.

6.2.2 TBLPTR – TABLE POINTER REGISTER

The Table Pointer regi st er (TBL PTR) addresses a byte within the program memory. It is comprised of three SFR registers: Table Pointer Upper Byte, T a ble Poin ter High Byte and Table Pointer Low Byte (TBLPTRU:TBLPTRH:TBLPTRL). Only the lower six bits of TBLPTRU are used with TBLPTRH and TBLPTRL, to form a 22-bit wide pointer.

The contents of TBLP TR indic ate a locat ion in progra m memory space. The low-order 21 bits allow the device to address the full 2 Mbyte s of program memory sp ace. The 22nd bit allows access to the configuration space, including the device ID, user ID locations and the configuration bit s.

The TBLPTR register set is updated when executing a TBLRD in one of four ways, based on the instruction’s arguments. These are detailed in Table 6-1. These operations on the TBLPTR only affect the low-order 21 bits.

When a TBLRD is executed, all 22 bits of the TBLPTR determine which byte is read from program memory into T AB LAT.

TABLE 6-1: TABLE POINTER

OPERATIONS WITH TBLRD INSTRUCTIONS

Example Operation on Table Pointer

TBLRD* TBLPTR is not modified TBLRD*+ TBLPTR is incremented after the read TBLRD*- TBLPTR is decremented after the read TBLRD+* TBLPTR is increm ent ed be fore th e read

6.3 Reading the Flash Program Memory

The TBLRD instruction is used to retrieve data from program memory and place it into data RAM. Table reads from program memory are performed one byte at a time.

TBLPTR points to a byte address in program space. Executing TBLRD places the byte pointed to into TABLAT. In addition, TBLPTR can be modified automatically for the next table read operation.

The internal program memory is typically organize d by words. The Least Significant b it of th e address selects between the high and low bytes of the word. Figure 6-2 shows the interface between the internal program memory and the TABLA T.

A typical method for reading data from program memory is shown in Example 6-1.

FIGURE 6-2: READS FROM FLASH PROGRAM MEMORY

Program Memory

(Even Byte Address)

Instruction Register

(IR)

DS39636A-page 76 Preliminary  2004 Microchip Technology Inc.

FETCH

(Odd Byte Address)

TBLPTR = xxxxx1

TBLRD

TBLPTR = xxxxx0

TABLAT

Read Register

PIC18F2X1X/4X1X

EXAMPLE 6-1: READING A FLASH PROGRAM MEMORY WORD

MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base MOVWF TBLPTRU ; address of the word MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL

READ_WORD

TBLRD*+ ; read into TABLAT and increment MOVF TABLAT, W ; get data MOVWF WORD_EVEN TBLRD*+ ; read into TABLAT and increment MOVF TABLAT, W ; get data MOVF WORD_ODD

TABLE 6-2: REGISTERS ASSOCIATED WITH READING PROGRAM FLASH MEMORY

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TBLPTRU — — bit 21 Program Memory Table Pointer Upper Byte

(TBLPTR<20:16>) TBPLTRH Program Memory Table Pointer High Byte (TBLPTR<15:8>) 49 TBLPTRL Program Memory Table Pointer Low Byte (TBLPTR<7:0>) 49 TABLAT Program Memory Table Latch 49

Legend: — = unimplemented, read as ‘0’. Shaded cells are not used during Flash access.

Reset

Values on

Page

 2004 Microchip Technology Inc. Preliminary DS39636A-page 77

PIC18F2X1X/4X1X

NOTES:

DS39636A-page 78 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

7.0 8 x 8 HARDWARE MULTIPLIER

7.1 Introduction

All PIC18 devices include an 8 x 8 hardware multiplier as part of the ALU. The multiplier pe rforms an unsigned operation and yields a 16-bit result that is stored in the product register pair, PRODH:PRODL. The multiplier’s operation does not affect any flags in the Status register.

Making multiplication a hardware operation allows it to be completed in a s ingle instruction cycle. This has the advantages of higher computational throughput and reduced code size for multiplication algorithms and allows the PIC18 devices to be used in many applications previously reserved for digital signal processors. A comparison of various hardware and software multiply operations, along with the savings in memory and execution time, is shown in Table 7-1.

7.2 Operation

Example 7-1 shows the instruction sequence for an 8 x 8 unsigned multiplication. Only one instruction is required when one of the arguments is already loaded in the WREG register.

Example 7-2 shows the s equence to d o an 8 x 8 si gned multiplication. To account for the sign bits of the arguments, each argument’s Most Significant bit (MSb) is tested and the appropriate subtractions are done.

EXAMPLE 7-1: 8 x 8 UNSIGNED

MULTIPLY ROUTINE

MOVF ARG1, W ; MULWF ARG2 ; ARG1 * ARG2 ->

; PRODH:PRODL

EXAMPLE 7-2: 8 x 8 SIGNED MULTIPLY

ROUTINE

MOVF ARG1, W MULWF ARG2 ; ARG1 * ARG2 ->

; PRODH:PRODL BTFSC ARG2, SB ; Test Sign Bit SUBWF PRODH, F ; PRODH = PRODH

; - ARG1 MOVF ARG2, W BTFSC ARG1, SB ; Test Sign Bit SUBWF PRODH, F ; PRODH = PRODH

; - ARG2

TABLE 7-1: PERFORMANCE COMPARISON FOR VARIOUS MULTIPLY OPERATIONS

Routine Multiply Method

8 x 8 unsigned

8 x 8 signed

16 x 16 unsigned

16 x 16 signed

Without hardware multiply 13 69 6.9 µs27.6 µs69 µs

Hardware multiply 1 1 100 ns 400 ns 1 µs

Without hardware multiply 33 91 9.1 µs36.4 µs91 µs

Hardware multiply 6 6 600 ns 2.4 µs6 µs

Without hardware multiply 21 242 24.2 µs96.8 µs 242 µs

Hardware multiply 28 28 2.8 µs 11.2 µs28 µs

Without hardware multiply 52 254 25.4 µs 102.6 µs 254 µs

Hardware multiply 35 40 4.0 µs16.0 µs40 µs

Program

Memory (Words)

Cycles

(Max)

@ 40 MHz @ 10 MHz @ 4 MHz

Time

 2004 Microchip Technology Inc. Preliminary DS39636A-page 79

PIC18F2X1X/4X1X

Example 7-3 shows the sequence to do a 16 x 16 unsigned multiplication. Equation 7-1 shows the algorithm that is used . The 32-bit re sult is st ored in four registers (RES3:RES0).

EQUATION 7-1: 16 x 16 UNSIGNED

DS39636A-page 80 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

8.0 INTERRUPTS

The PIC18F2X1X/4X1X devic es have multiple in terrupt sources and an interrupt priority feature that allows most interrupt sources to be assigned a high priority level or a low priority level. The high priority interrupt vector is at 0008h and the lo w priority interrup t vector is at 0018h. High priority interrupt event s will int errupt any low priority interrupts that may be in progress.

There are ten registers which are used to control interrupt operation. These registers are:

• RCON

•INTCON

• INTCON2

• INTCON3

• PIR1, PIR2

• PIE1, PIE2

• IPR1, IPR2 It is recommended that the Microchip header files

supplied with MPLAB names in these registers. This allows the assembler/ compiler to automatical ly ta ke care of the pla ceme nt of these bits within the specified register.

In genera l, int errupt sour ces h ave th ree bits to cont rol their operation. They are:

• Flag bit to indicate that an interrupt event occurred

• Enable bit that allows program execution to branch to the interrupt vector address when the flag bit is set

• Priority bit to select high priority or low priority

The interrupt priority feature is enabled by setting the IPEN bit (RCON<7>). When interrupt priority is enabled, there are two bits which enable interrupts globally . Setti ng the GIEH bit (INTC ON<7>) enable s all interrupts that have the priority bit set (high priority). Setting the GIEL bit (INTCON<6>) enables all interrupts that have the prio rity bit cleared ( low priority ). When the interrupt flag, enable bit and appropriate global interrupt enable bit are set, the interrupt wi ll vector immediately to addres s 000 8h or 0018h, depen ding on the priority bit setting. Individual interrupts can be disabled through their corresponding enable bits.

IDE be used for the symb olic bit

When the IPEN bit is cleared (default state), the interrupt priority feature is disabled and interrupts are compatible with PICmicro Compatibilit y mode, the in terrupt prior ity bits for each source have no effect. INTCON<6> is the PEIE bit, which enables/disab les all periph eral interrupt s ources. INTCON<7> is the GIE bit, which enables/disables all interrupt sources. All interrupts branch to address 0008h in Compatibility mode.

When an interrupt is responded to, the global interrupt enable bit is cleared to disable further interrupts. If the IPEN bit is cleared, this is the GIE bit. If interru pt priority levels are used, this wi ll be either the GIEH or G IEL bit. High priority interrupt sources can interrupt a low priority interrupt. Low priority interrupts are not processed while high priority interrupts are in progress.

The return address is pushed onto the stack and the PC is loaded with the interrupt vector address (0008h or 0018h). Once in the Interrupt Service Routine, the source(s) of the interrupt can be determined by polling the interrupt flag bits. The interrupt flag bits must be cleared in software before re-enabling interrupts to avoid recursive interrupts.

The “return from interrupt” instruction, RETFIE, exits the interrupt routine and set s the GIE bit (GIEH or GI EL if priority levels are used), which re-enables interrupts.

For external interrupt events, such as the INT pins or the PORTB input chang e interrupt, the i nterrupt latenc y will be three to four instruction cycles. The exact latency is the same for one or two-cycle instructions. Individual interrupt flag bits are set, regardless of the status of their corresponding enable bit or the GIE bit.

Note: Do not use the MOVFF instruction to modify

any of the interrupt control registers while any interrupt is enabled. Doing so may cause erratic microcontroller behavior.

mid-range devices. In

 2004 Microchip Technology Inc. Preliminary DS39636A-page 81

PIC18F2X1X/4X1X

FIGURE 8-1: PIC18 INTERRUPT LOGIC

SSPIF SSPIE SSPIP

ADIF ADIE ADIP

RCIF RCIE RCIP

Additional Peripheral Interrupts

High Priority Interrupt Generation

Low Priority Interrupt Generation

SSPIF SSPIE SSPIP

ADIF ADIE ADIP

RCIF RCIE RCIP

Additional Peripheral Interrupts

IPEN

TMR0IF TMR0IE

TMR0IP

RBIF

RBIE RBIP

INT1IF INT1IE

INT1IP

INT2IF INT2IE

INT2IP

TMR0IF TMR0IE TMR0IP

INT0IE

INT1IE INT1IP

INT2IE INT2IP

IPEN

GIEL/PEIE

RBIF RBIE RBIP

INT0IF

INT1IF

INT2IF

IPEN

GIEH/GIE GIEL/PEIE

Wake-up if in

Idle or Sleep modes

Interrupt to CPU Vector to Location

0008h

GIEH/GIE

Interrupt to CPU Vector to Location 0018h

DS39636A-page 82 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

8.1 INTCON Registers

The INTCON registers are readable and writable registers, which contain various enable, priority and flag bits.

REGISTER 8-1: INTCON REGISTER

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-x

GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF

bit 7 bit 0

bit 7 GIE/GIEH: Global Interrupt Enable bit

When IPEN =

1 = Enables all unmasked interrupts 0 = Disables all interr upts

When IPEN =

1 = Enables all high priority interrupts 0 = Disables all interrupts

bit 6 PEIE/GIEL: Peripheral Interrupt Enable bit

When IPEN =

1 = Enables all unmasked peripheral interrupts 0 = Disables all peripheral interr upts

When IPEN =

1 = Enables all low priority peripheral interrupts 0 = Disables all low priority peripheral interrupts

bit 5 TMR0IE: TMR0 Overflow Interrupt Enable bit

1 = Enables the TMR0 overflow interrupt 0 = Disables the TMR0 overflow interrupt

bit 4 INT0IE: INT0 External Interrupt Enable bit

1 = Enables the INT0 external interrupt 0 = Disables the INT0 external interrupt

bit 3 RBIE: RB Port Change Interrupt Enable bit

1 = Enables the RB port change interrupt 0 = Disables the RB port change inte rrupt

bit 2 TMR0IF: TMR0 Overflow Interrupt Flag bit

1 = TMR0 register has ov erflowed (must be clear ed in software) 0 = TMR0 register did not overflow

bit 1 INT0IF: INT0 External Interrupt Flag bit

1 = The INT0 external interrupt occurred (must be cleared in software) 0 = The INT0 external interrupt did not occur

bit 0 RBIF: RB Port Change Interrupt Flag bit

1 = At least one of the RB7:RB4 pins changed state (must be cleared in software) 0 = None of the RB7:RB4 pins have changed state

Note: A mismatch condition will continue to set this bit. Reading PORTB will end the

mismatch condition and allow the bit to be cleared.

Note: Interrupt flag bits are s et when an i nterr upt

condition occurs regardless of the state of its corresponding enable bit or the global interrupt enable bit. User software should ensure the appropriate interrupt flag bits are clear prior to enabling an interrupt. This feature allows for software polling.

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘ 1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

 2004 Microchip Technology Inc. Preliminary DS39636A-page 83

PIC18F2X1X/4X1X

REGISTER 8-2: INTCON2 REGISTER

R/W-1 R/W-1 R/W-1 R/W-1 U-0 R/W-1 U-0 R/W-1

RBPU

bit 7 bit 0

INTEDG0 INTEDG1 INTEDG2 —TMR0IP—RBIP

bit 7 RBPU

bit 6 INTEDG0: External Interrupt 0 Edge Select bit

bit 5 INTEDG1: External Interrupt 1 Edge Select bit

bit 4 INTEDG2: External Interrupt 2 Edge Select bit

bit 3 Unimplemented: Read as ‘0’ bit 2 TMR0IP: TMR0 Overflow Interrupt Priority bit

bit 1 Unimplemented: Read as ‘0’ bit 0 RBIP: RB Port Change Interrupt Priority bit

: PORTB Pull-up Enable bit

1 = All PORTB pull-ups are disabled 0 = PORTB pull-ups are enabled by individual port latch values

1 = Interrupt on rising edge 0 = Interrupt on falling edge

1 = High priority 0 = Low priority

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

Note: Inter ru pt f l ag bi ts a r e s et w h en an i nt e rr up t co ndi t io n o cc urs r eg a rdl es s o f th e state

of its corresponding enable bit or the global interrupt enable bit. User software should ensure the appropriate interrupt flag bits are clear prior to enabling an interrupt. This feature allows for software polling.

DS39636A-page 84 Preliminary  2004 Microchip Technology Inc.

REGISTER 8-3: INTCON3 REGISTER

R/W-1 R/W-1 U-0 R/W-0 R/W-0 U-0 R/W-0 R/W-0

INT2IP INT1IP

bit 7 bit 0

bit 7 INT2IP: INT2 External Interrupt Priority bit

1 = High priority 0 = Low priority

bit 6 INT1IP: INT1 External Interrupt Priority bit

1 = High priority 0 = Low priority

bit 5 Unimplemented: Read as ‘0’ bit 4 INT2IE: INT2 External Interrupt Enable bit

1 = Enables the INT2 external interrupt 0 = Disables the INT2 external interrupt

bit 3 INT1IE: INT1 External Interrupt Enable bit

1 = Enables the INT1 external interrupt 0 = Disables the INT1 external interrupt

bit 2 Unimplemented: Read as ‘0’ bit 1 INT2IF: INT2 External Interrupt Flag bit

1 = The INT2 external interrupt occurred (must be cleared in software) 0 = The INT2 external interrupt did not occur

bit 0 INT1IF: INT1 External Interrupt Flag bit

1 = The INT1 external interrupt occurred (must be cleared in software) 0 = The INT1 external interrupt did not occur

—INT2IEINT1IE— INT2IF INT1IF

PIC18F2X1X/4X1X

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

Note: Interrupt flag bits are set when an interr upt c ond iti on oc curs , rega rdle ss of the st a te

 2004 Microchip Technology Inc. Preliminary DS39636A-page 85

PIC18F2X1X/4X1X

8.2 PIR Registers

The PIR registers conta in the ind ividu al flag bi ts fo r the peripheral interrupts. Due to the number of peripheral interrupt sources, there are two Peripheral Interrupt Request (Flag) registers (PIR1 and PIR2).

Note 1: Interrupt flag bits are set when an interrupt

condition occurs rega rdless of the st ate of its corresponding enable bit or the Global Interrupt Enable bit, GIE (INTCON<7>).

2: User software sh ould ensure the ap propri-

ate interrupt flag bits are cleared prior to enabling an interrupt and after servicing that interrupt.

REGISTER 8-4: PIR1: PERIPHERAL INTERRUPT REQUEST (FLAG) REGISTER 1

R/W-0 R/W-0 R-0 R-0 R/W-0 R/W-0 R/W-0 R/W-0

(1)

PSPIF

bit 7 bit 0

bit 7 PSPIF: Parallel Slave Port Read/Write Interrupt Flag bit

1 = A read or a write operation has taken place (must be cleared in software) 0 = No read or write has occurred

Note 1: This bit is unimplemented on 28-pin devices and is read as ‘0’.

bit 6 ADIF: A/D Converter Interrupt Flag bit

1 = An A/D conversion completed (must be cleared in software) 0 = The A/D conversion is not complete

bit 5 RCIF: EUSART Receive Interrupt Flag bit

1 = The EUSART receive buffer, RCREG, is full (cleared when RCREG is read) 0 = The EUSART receive buffer is empty

bit 4 TXIF: EUSART Transmit Interrupt Flag bit

1 = The EUSART transmit buffer, TXREG, is empty (cleared when TXREG is written) 0 = The EUSART transmit buffer is full

bit 3 SSPIF: Master Synchronous Serial Port Interrupt Flag bit

1 = The transmission/reception is complete (must be cleared in software) 0 = Waiting to transmit/receive

bit 2 CCP1IF: CCP1 Interrupt Flag bit

Capture mode:

1 = A TMR1 register capture occurred (must be cleared in softwar e) 0 = No TMR1 register capture occurred

Compare mode:

1 = A TMR1 register compare match occurred (must be cleared in software) 0 = No TMR1 register compare match occurred

PWM mode: Unused in this mode.

bit 1 TMR2IF: TMR2 to PR2 Match Interrupt Flag bit

1 = TMR2 to PR2 match occurred (must be cleared in software) 0 = No TMR2 to PR2 match occurred

bit 0 TMR1IF: TMR1 Overflow Interrupt Flag bit

1 = TMR1 register overflowed (must be cleared in software) 0 = TMR1 register did not overflow

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF

(1)

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

DS39636A-page 86 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

REGISTER 8-5: PIR2: PERIPHERAL INTERRUPT REQUEST (FLAG) REGISTER 2

R/W-0 R/W-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0

OSCFIF CMIF — — BCLIF HLVDIF TMR3IF CCP2IF

bit 7 bit 0

bit 7 OSCFIF: Oscillator Fail Interrupt Flag bit

1 = Device oscillator failed, clock input has changed to INTOSC (must be cleared in software) 0 = Device clock operating

bit 6 CMIF: Comparator Interrupt Flag bit

1 = Comparator input has changed (must be cleared in software) 0 = Comparator input has not changed

bit 5-4 Unimplemented: Read as ‘0’ bit 3 BCLIF: Bus Collision Interrupt Flag bit

1 = A bus collision occurred (must be cleared in software) 0 = No bus collision occurred

bit 2 HLVDIF: High/Low-Voltage Detect Interrupt Flag bit

1 = A low-voltage condition occurred (must be cleared in software) 0 = The device voltage is above the High/Low-Voltage Detect trip point

bit 1 TMR3IF: TMR3 Overflow Interrupt Flag bit

1 = TMR3 register overflowed (must be cleared in software) 0 = TMR3 register did not overflow

bit 0 CCP2IF: CCPx Interrupt Flag bit

Capture mode:

1 = A TMR1 register capture occurred (must be cleared in software) 0 = No TMR1 register capture occurred

Compare mode:

1 = A TMR1 register compare match occurred (must be cleared in software) 0 = No TMR1 register compare match occurred

PWM mode: Unused in this mode.

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

 2004 Microchip Technology Inc. Preliminary DS39636A-page 87

PIC18F2X1X/4X1X

8.3 PIE Registers

The PIE registers contain the individual enable bits for the peripheral interrupts. Due to the number of peripheral interrupt sources, there are two Peripheral Interrupt Enable registers (PIE1 and PIE2). When IPEN = 0, the PEIE bit must be set to enable any of these peripheral interrupts.

REGISTER 8-6: PIE1: PERIPHERAL INTERRUPT ENABLE REGISTER 1

R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

(1)

PSPIE

bit 7 bit 0

bit 7 PSPIE: Parallel Slave Port Read/ W ri te Interru pt Enab le bit

1 = Enables the PSP read/write interrupt 0 = Disables the PSP read/write interrupt

Note 1: This bit is unimplemented on 28-pin devices and is read as ‘0’.

bit 6 ADIE: A/D Converter Interrupt Enable bit

1 = Enables the A/D interrupt 0 = Disables the A/D interrupt

bit 5 RCIE: EUSART Receive Interrupt Enable bit

1 = Enables the EUSART receive interrupt 0 = Disables the EUSART receive interrupt

bit 4 TXIE: EUSART Transmit Interrupt Enable bit

1 = Enables the EUSART transmit interrupt 0 = Disables the EUSART transmit interrupt

bit 3 SSPIE: Master Synchronous Serial Port Interrupt Enable bit

1 = Enables the MSSP interrupt 0 = Disables the MSSP interrupt

bit 2 CCP1IE: CCP1 Interrupt Enable bit

1 = Enables the CCP1 interrupt 0 = Disables the CCP1 interrupt

bit 1 TMR2IE: TMR2 to PR2 Match Interrupt Enable bit

1 = Enables the TMR2 to PR2 match interrupt 0 = Disables the TMR2 to PR2 match interrupt

bit 0 TMR1IE: TMR1 Overflow Interrupt Enable bit

1 = Enables the TMR1 overflow interrupt 0 = Disables the TMR1 overflow interrupt

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE

(1)

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

DS39636A-page 88 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

REGISTER 8-7: PIE2: PERIPHERAL INTERRUPT ENABLE REGISTER 2

R/W-0 R/W-0 U-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0

OSCFIE CMIE — — BCLIE HLVDIE TMR3IE CCP2IE

bit 7 bit 0

bit 7 OSCFIE: Oscillator Fail Interrupt Enable bit

1 = Enabled 0 =Disabled

bit 6 CMIE: Comparator Interrupt Enable bit

1 = Enabled 0 =Disabled

bit 5-4 Unimplemented: Read as ‘0’ bit 3 BCLIE: Bus Collision Interrupt Enable bit

1 = Enabled 0 =Disabled

bit 2 HLVDIE: High/Low-Voltage Detect Interrupt Enable bit

1 = Enabled 0 =Disabled

bit 1 TMR3IE: TMR3 Overflow Interrupt Enable bit

1 = Enabled 0 =Disabled

bit 0 CCP2IE: CCP2 Interrupt Enable bit

1 = Enabled 0 =Disabled

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

 2004 Microchip Technology Inc. Preliminary DS39636A-page 89

PIC18F2X1X/4X1X

8.4 IPR Registers

The IPR registers contain the individual priority bits for the peripheral interrupts. Due to the number of peripheral interrupt sources, there are two Peripheral Interrupt Priority registers (IPR1 and IPR2). Using the priority bits requires that the Interrupt Priority Enable (IPEN) bit be set.

REGISTER 8-8: IPR1: PERIPHERAL INTERRUPT PRIORITY REGISTER 1

R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1 R/W-1

(1)

PSPIP

bit 7 bit 0

bit 7 PSPIP: Parallel Slave Port Read/Write Interrupt Priority bit

1 =High priority 0 = Low priority

Note 1: This bit is unimplemented on 28-pin devices and is read as ‘0’.

bit 6 ADIP: A/D Converter Interrupt Priority bit

1 =High priority 0 = Low priority

bit 5 RCIP: EUSART Receive Interrupt Priority bit

1 =High priority 0 = Low priority

bit 4 TXIP: EUSART Transmit Interrupt Priority bit

1 =High priority 0 = Low priority

bit 3 SSPIP: Master Synchronous Serial Port Interrupt Priority bit

1 =High priority 0 = Low priority

bit 2 CCP1IP: CCP1 Interrupt Priority bit

1 =High priority 0 = Low priority

bit 1 TMR2IP: TMR2 to PR2 Match Interrupt Priority bit

1 =High priority 0 = Low priority

bit 0 TMR1IP: TMR1 Overflow Interrupt Priority bit

1 =High priority 0 = Low priority

ADIP RCIP TXIP SSPIP CCP1IP TMR2IP TMR1IP

(1)

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

DS39636A-page 90 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

REGISTER 8-9: IPR2: PERIPHERAL INTERRUPT PRIORITY REGISTER 2

R/W-1 R/W-1 U-0 U-0 R/W-1 R/W-1 R/W-1 R/W-1

OSCFIP CMIP — — BCLIP HLVDIP TMR3IP CCP2IP

bit 7 bit 0

bit 7 OSCFIP: Oscillator Fail Interrupt Priority bit

1 =High priority 0 = Low priority

bit 6 CMIP: Comparator Interrupt Priority bit

1 =High priority 0 = Low priority

bit 5-4 Unimplemented: Read as ‘0’ bit 3 BCLIP: Bus Collision Interrupt Priority bit

1 =High priority 0 = Low priority

bit 2 HLVDIP: High/Low-Voltage Detect Interrupt Priority bit

1 =High priority 0 = Low priority

bit 1 TMR3IP: TMR3 Overflow Interrupt Priority bit

1 =High priority 0 = Low priority

bit 0 CCP2IP: CCP2 Interrupt Priority bit

1 =High priority 0 = Low priority

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

 2004 Microchip Technology Inc. Preliminary DS39636A-page 91

PIC18F2X1X/4X1X

8.5 RCON Register

The RCON register co ntains flag bit s which a re used to determine the cause of the last R eset or wa ke -up from Idle or Sleep modes. R CO N als o co ntains the IPEN bit which enables interrupt priorities.

REGISTER 8-10: RCON REGISTER

R/W-0 R/W-1

IPEN SBOREN

bit 7 bit 0

bit 7 IPEN: Interrupt Priority Enable bit

1 = Enable priority levels on interrupts 0 = Disable priority levels on interrupts (PIC16XXX Compatibility mode)

bit 6 SBOREN: Software BOR Enable bit

For details of bit operation, see Register4-1.

Note 1: Actual Reset values are determined by device configuration and the nature of the

bit 5 Unimplemented: Read as ‘0’ bit 4 RI

bit 3 TO: Watchdog Time-out Flag bit

bit 2 PD: Power-down Detection Flag bit

bit 1 POR: Power-on Reset Status bit

bit 0 BOR: Brown-out Reset Status bit

: RESET Instruction Flag bit

For details of bit operation, see Register 4-1.

(1)

device Reset. See Register 4-1 for additional information.

U-0 R/W-1 R-1 R-1 R/W-0

—RITO PD POR BOR

The operation of the SBOREN bit and the Reset flag bits is discussed in more detail in Section 4.1 “RCON

(1)

R/W-0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

DS39636A-page 92 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

8.6 INTn Pin Interrupts

External interrupts on the RB0/INT0, RB1/INT1 and RB2/INT2 pins are edge-trig gered. If the correspon ding INTEDGx bit in the INTCON2 register is set (= 1), the interrupt is triggered by a rising edge; if the bit is clear, the trigger is on the falling edge. When a valid edge appears on the RBx/INTx pin, the corresponding flag bit INTxF is set. This interrup t can be disabled by cle aring the corresponding ena ble bi t INTx E. Fla g bi t IN Tx F must be cleared in software in the Interrupt Service Routine before re-enabling the interrupt.

All external interrupt s (INT0, INT1 an d INT2) can wakeup the processor from Idle or Sleep modes if bit INTxE was set prior to going into those modes. If the Global Interrupt Enable bit, GIE, is set, the processor will branch to the interrupt vector following wake-up.

Interrupt priority for INT1 and INT2 is determ ined by the value contained in the interrupt priority bits, INT1IP (INTCON3<6>) and INT2IP (INTCON3<7>). There is no priority bit associated with INT0. It is always a high priority interrupt source.

8.7 TMR0 Interrupt

In 8-bit mod e (whic h is the de faul t), an ov erfl ow in the TMR0 register (FFh → 00h) will set flag bit TMR0IF. In 16-bit mode, an overflow in the TMR0H:TMR0L register pair (FFFFh → 0000h) will set TMR0 IF . The interrupt can be enabled/disabled by setting/clearing enable bit, TMR0IE (INTCON<5>). Interrupt priority for Timer0 is determined by the value contained in the interrupt priority bit, TMR0IP (INTCON2<2>). See Section10.0 “Timer0 Module” for further details on the Timer0 module.

8.8 PORTB Interrupt-on-Change

An input change on PORTB<7:4> sets flag bit, RBIF (INTCON<0>). The interrupt can be enabled/disabled by setting/clearing enable bit, RBIE (INTCON<3>). Interrupt priority for PORTB interrupt-on-change is determined by the value contained in the interrupt priority bit, RBIP (INTCON2<0>).

8.9 Context Saving During Interrupts

During interrupts, the return PC address is saved on the stack. Additionally, the WREG, Status and BSR registers ar e saved on the fas t return stack. If a f ast return from interrupt is not used (see Section 5.3 “Data Memory Organization”), the user may need to save the WREG, Status and BSR registers on entry to the Interrupt Servic e Ro uti ne. D epe nd ing on th e u se r’s application, othe r regist ers ma y a lso ne ed to be save d. Example 8-1 saves and restores the WREG, Status and BSR registers during an In terrupt Serv ice Rou tine.

EXAMPLE 8-1: SAVING STATUS, WREG AND BSR REGISTERS IN RAM

MOVWF W_TEMP ; W_TEMP is in virtual bank MOVFF STATUS, STATUS_TEMP ; STATUS_TEMP located anywhere MOVFF BSR, BSR_TEMP ; BSR_TMEP located anywhere ; ; USER ISR CODE ; MOVFF BSR_TEMP, BSR ; Restore BSR MOVF W_TEMP, W ; Restore WREG MOVFF STATUS_TEMP, STATUS ; Restore STATUS

 2004 Microchip Technology Inc. Preliminary DS39636A-page 93

PIC18F2X1X/4X1X

NOTES:

DS39636A-page 94 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

9.0 I/O PORTS

Depending on the device selected and features enabled, there are up to five ports available. Some pins of the I/O ports are multiplexed with an alternate function from the peripheral features on the device. In general, when a periphe ral is ena bled, that pi n may not be used as a general purpose I/O pin.

Each port has three registers for its operation. These registers are:

• TRIS register (data direction register)

• PORT register (rea ds the level s on the pins of the device)

• LAT register (output latch)

The Data Latch (LAT register) is useful for read-modifywrite operations on the value that the I/O pins are driving.

A simplified model of a generic I/O port, without the interfaces to other peripherals, is shown in Figure 9-1.

FIGURE 9-1: GENERIC I/O PORT

OPERATION

RD LAT Data

Bus WR LAT

Port

WR TRIS

RD TRIS

RD Port

Note 1: I/O pins have diode protection to V

9.1 PORTA, TRISA and LATA Registers

PORTA is a 8-bit wide, bidirectional port. The corresponding data direction register is TRISA. Setting a TRISA bit (= 1) will make the correspondi ng PORT A pin an input (i.e., put the corresponding output driver in a high-impedance mode). Clearing a TRISA bit (= 0) will make the correspondin g POR TA pin an output (i.e., put the contents of the output latch on the selected pin).

Data Latch

TRIS Latch

DD and VSS.

I/O pin

Input

Buffer

(1)

Reading the PORTA register reads the status of the pins, whereas writing to it will write to the port latch.

The Data Latch (LA TA) register is also memory mapped. Read-modify-write operations on the LA TA register read and write the latched output value for PORTA.

The RA4 pin is multiplexed with the Timer0 module clock input and one of the comparator outputs to become the RA4/T0CKI/C1OUT pin. Pins RA6 and RA7 are multiplexed with the main oscillator pins; they are enabled as oscillator or I/O pins by the selection of the main oscillator in the configuration register (see Section 22.1 “Configuration Bits” for details). When they are not used as port pins, RA6 and RA7 and their associated TRIS and LAT bits are read as ‘0’.

The other PORTA pins are multiplexed with analog inputs, the analog V

REF+ and VREF- inputs and the com-

parator voltage reference out put . T he op erati on o f pi ns RA3:RA0 and RA5 as A/D converter inputs is sel ected by clearing or setting the cont rol bits in the ADCON1 register (A/D Control Register 1).

Pins RA0 through RA5 may also be used as comparator inputs or outputs by setting the appropriate bits in the CMCON re gist er . To use RA3:RA0 as digital inputs , it is also necessary to turn off the comparators.

Note: On a Power-on Reset, RA5 and RA3:RA0

are configured as analog inputs and read as ‘0’. RA4 is configured as a digital input.

The RA4/T0 CK I /C 1O U T pi n is a S c hm it t Trigg e r inp ut . All other PORTA pins have TTL input levels and full CMOS output drivers.

The TRISA register co ntrols the di rection of the PO RTA pins, even when they a re being used as analog input s . The user must ensure the bit s in the TRISA registe r are maintained set when using them as analog inputs.

EXAMPLE 9-1: INITIALIZING PORTA

CLRF PORTA ; Initialize PORTA by

CLRF LATA ; Alternate method

MOVLW 07h ; Configure A/D MOVWF ADCON1 ; for digital inputs MOVWF 07h ; Configure comparators MOVWF CMCON ; for digital input MOVLW 0CFh ; Value used to

MOVWF TRISA ; Set RA<3:0> as inputs

; clearing output ; data latches

; to clear output ; data latches

; initialize data ; direction

; RA<5:4> as outputs

 2004 Microchip Technology Inc. Preliminary DS39636A-page 95

PIC18F2X1X/4X1X

TABLE 9-1: PORTA I/O SUMMARY

Pin Function

RA0/AN0 RA0 0 O DIG LATA<0> data output; not affected by analog input.

AN0 1 I ANA A/D input channel 0 and Comparator C1- input. Default input

RA1/AN1 RA1 0 O DIG LATA<1> data output; not affected by analog input.

AN1 1 I ANA A/D input channel 1 and comparator C2- input. Default input

RA2/AN2/

REF-/CVREF

RA3/AN3/V

RA4/T0CKI/C1OUT RA4 0 O DIG LAT A<4> dat a output.

RA5/AN4/SS HLVDIN/C2OUT

OSC2/CLKO/RA6 R A6 0 O DIG LATA<6> data out put. Enabled in RCIO, INTIO2 and ECIO modes only .

OSC1/CLKI/RA7 RA7 0 O DIG LATA<7> data output. Disabled in external oscillator modes.

Legend: DIG = Digital level output; TTL = TTL input buffer; ST = Schmitt Trigger input buffer; ANA = Analog level input/output;

REF+RA30 O DIG LATA<3> data output; not affected by analog input.

x = Don’t care (TRIS bit does not affect port direction or is overridden for this option).

RA2 0 O DIG LATA<2> data output; not affected by analog input. Disabled when

AN2 1 I ANA A/D input channel 2 and comparator C2+ input. Default input

REF- 1 I ANA A/D and comparator voltage reference low input.

REF x O ANA Comparator voltage reference output. Enabling this feature disables

AN3 1 I ANA A/D input channel 3 and comparator C1+ input. Default input

REF+ 1 I ANA A/D and comparator voltage reference high input.

T0CKI 1 I ST Timer0 clock input.

C1OUT 0 O DIG Comparator 1 output; takes priority over port data.

RA5 0 O DIG LATA <5> data output; not affected by analog input.

AN4 1 I ANA A/D input channel 4. Default configuration on POR.

HLVDIN 1 I ANA High/Low-Voltage Detect external trip point input.

C2OUT 0 O DIG Comparator 2 output; takes priority over port data.

OSC2 x O ANA Main oscillator feedback output connection (XT, HS and LP modes). CLKO x O DIG System cycle clock output (F

OSC1 x I ANA Main oscillator input connection.

CLKI x I ANA Main clock input connection.

TRIS

Setting

1 I TTL PORTA<0> data input; disabled when analog input enabled.

1 I TTL PORTA<1> data input; disabled when analog input enabled.

1 I TTL PORTA<2> data input. Disabled when analog functions enabled;

1 I TTL PORTA<3> data input; disabled when analog input enabled.

1 I ST PORTA<4> data input; default configuration on POR.

1 I TTL PORTA<5> data input; disabled when analog input enabled.

1 I TTL Slave select input for SSP (MSSP module).

1 I TTL PORTA<6> data input. Enabled in RCIO, INTIO2 and ECIO modes only.

1 I TTL PORTA<7> data input. Disabled in external oscillator modes.

I/O

Type

configuration on POR; does not affect digital output.

REF output enabled.

disabled when CV

configuration on POR; not affected by analog output.

digital I/O.

configuration on POR.

modes.

REF output enabled.

Description

OSC/4) in RC, INTIO1 and EC Oscillator

DS39636A-page 96 Preliminary  2004 Microchip Technology Inc.

PIC18F2X1X/4X1X

TABLE 9-2: SUMMARY OF REGISTERS ASSOCIATED WITH PORTA

Reset

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PORTA RA7 LATA LATA7 TRISA TRISA7 ADCON1 — — VCFG1 VCFG0 PCFG3 PCFG2 PCFG1 PCFG0 51 CMCON CVRCON CVREN CVROE CVRR CVRSS CVR3 CVR2 CVR1 CVR0 51

Legend: — = unimplemented, read as ‘0’. Shaded cells are not used by PORTA. Note 1: RA7:RA6 and their associated latch and data direction bits are enabled as I/O pins based on oscillator

configuration; otherwise, they are read as ‘0’.

(1)

C2OUT C1OUT C2INV C1INV CIS CM2 CM1 CM0 51

RA6

LATA6

TRISA6

(1)

RA5 RA4 RA3 RA2 RA1 RA0 52

(1)

PORTA Data Latch Register (Read and Write to Data Latch) 52

(1)

PORTA Data Direction Control Register 52

Values

on page

 2004 Microchip Technology Inc. Preliminary DS39636A-page 97

PIC18F2X1X/4X1X

9.2 PORTB, TRISB and LATB Registers

PORTB is an 8-bit wide, bidirectional port. The corresponding data direction register is TRISB. Se ttin g a TRISB bit (= 1) will make the corresponding PORTB pin an input (i.e., put the corresponding output driver in a high-imped ance mode). Cl earing a TRISB bit (= 0) will make the c orrespond ing POR TB pi n an out put (i.e., put the contents of the outpu t latch on the selected pi n).

The Data Latch register (LATB) is also memory mapped. Read-modify-write operations on the LATB register read and write the latched output value for PORTB.

EXAMPLE 9-2: INITIALIZING PORTB

CLRF PORTB ; Initialize PORTB by

; clearing output ; data latches

CLRF LATB ; Alternate method

; to clear output

; data latches MOVLW 0Fh ; Set RB<4:0> as MOVWF ADCON1 ; digital I/O pins

; (required if config bit

; PBADEN is set) MOVLW 0CFh ; Value used to

; initialize data

; direction MOVWF TRISB ; Set RB<3:0> as inputs

; RB<5:4> as outputs

; RB<7:6> as inputs

Four of the PORTB pins (RB7:RB4) have an interrupton-change feature. Only pins configured as inputs can cause this interrupt to occur (i.e., any RB7:RB4 pin configured as an output is excluded from the interrupton-change comparison). The input pins (of RB7:RB4) are compared with the old value latched on the last read of PORTB. The “mismatch” outputs of RB7:RB4 are ORed together to generate the RB Port Change Interrupt with Flag bit, RBIF (INTCON<0>).

This interrupt can wake the device from the Sleep mode, or any of the Idle modes. The user, in the Interrupt Service Routine, can clear the interrupt in the following manner:

a) Any read or write of PORTB (except with the

MOVFF (ANY), PORTB instructi on).

b) Clear flag bit RBIF. A mismatch c ond it i on wi ll cont i n ue to s et f lag bi t RB IF.

Reading PORTB will end the mismatch condition and allow flag bit RBIF to be cleared.

The interrupt-on-change feature is recommended for wake-up on key depression operation and operations where PORTB is only used for the interrupt-on-change feature. Polling of PORTB is not recommended while using the interrupt-on-change feature.

RB3 can be configured by the configuration bit CCP2MX as the alternate peripheral pin for the CCP2 module (CCP2MX = 0).

Each of the PORTB pi ns has a w eak i nternal pul l-up. A single cont rol bit can turn on a ll the pull-ups. This is performed by clearing bit, RBPU

(INTCON2<7>). The weak pull-up is automatically turned off when the port pin is configured as an output. The pull-ups are disabled on a Power-on Reset.

Note: On a Power-on Reset, RB4:RB0 are

configured as analo g inputs by default and read as ‘0’; RB7:RB5 are configured as digital inputs.

By programming the configuration bit, PBADEN, RB4:RB0 will alternatively be configured as digital inputs on POR.

DS39636A-page 98 Preliminary  2004 Microchip Technology Inc.

MICROCHIP PIC18F2X1X, PIC18F4X1X DATA SHEET

Specifications and Main Features

Frequently Asked Questions

User Manual

Power Managed Modes:

Peripheral Highlights:

Flexible Oscillator Structure:

Special Microcontroller Features:

Pin Diagrams

Pin Diagrams (Cont.’d)

Table of Contents

1.0 DEVICE OVERVIEW

1.1 New Core Features

1.1.1 nanoWatt TECHNOLOGY

1.1.2 MULTIPLE OSCILLATOR OPTIONS AND FEATURES

1.2 Other Special Features

1.3 Details on Individual Family Members

T ABLE 1-1: DEVICE FEATURES (PIC18F2410/2510/2515/2610)

TABLE 1-2: DEVICE FEATURES (PIC18F4410/4510/4515/4610)

FIGURE 1-1: PIC1 8F2410/ 2510/ 2515/ 2610 ( 28-PIN) BLOCK DI AGRAM

FIGURE 1-2: PIC18F4410/4510/4515/4610 (40/44-PIN) BLOCK DIAGRAM

2.0 OSCILLATOR CONFIGURATIONS

2.1 Oscillator Types

2.2 Crystal Oscilla tor/Ceramic Resonators

2.3 External Clock Input

2.4 RC Oscillator

FIGURE 2-5: RC OSCILLATOR MODE

FIGURE 2-6: RCIO OSCILLATOR MODE

2.5 PLL Frequency Multiplier

2.5.1 HSPLL OSCILLATOR MODE

2.5.2 PLL AND INTOSC

2.6 Internal Oscillator Block

2.6.1 INTIO MODES

2.6.2 INTOSC OUTPUT FREQUENCY

2.6.3 OSCTUNE REGISTER

2.6.4 PLL IN INTOSC MODES

2.6.5 INTOSC FREQUENCY DRIFT

REGISTER 2-1: OSCTUNE: OSCILLATOR TUNING REGISTER

2.7 Clock Sources and Oscillator Switching

FIGURE 2-8: PIC18F2X1X/4X1X CLOCK DIAGRAM

2.7.1 OSCILLATOR CONTROL REGISTER

2.7.2 OSCILLATOR TRANSITIONS

REGISTER 2-2: OSCCON: OSCILLATOR CONTROL REGISTER

2.8 Effects of Power Managed Modes on the Various Clock Sources

2.9 Power-up Delays

TABLE 2-3: OSC1 AND OSC2 PIN STATES IN SLEEP MODE

3.0 POWER MANAGED MODES

3.1 Selecting Power Managed Modes

3.1.1 CLOCK SOURCES

TABLE 3-1: POWER MANAGED MODES

3.1.3 CLOCK TRANSITIONS AND STATUS INDICATORS

3.1.4 MULTIPLE SLEEP COMMANDS

3.2 Run Modes

3.2.1 PRI_RUN MODE

3.2.2 SEC_RUN MODE

FIGURE 3-1: TRANSITION TIMING FOR ENTRY TO SEC_RUN MODE

FIGURE 3-2: TRANSITION TIMING FROM SEC_RUN MODE TO PRI_RUN MODE (HSPLL)

3.2.3 RC_RUN MODE

FIGURE 3-3: TRANSITION TIMING TO RC_RUN MODE

FIGURE 3-4: TRANSITION TIMING FROM RC_RUN MODE TO PRI_RUN MODE

3.3 Sleep Mode

3.4 Idle Modes

FIGURE 3-5: TRANSITION TIMING FOR ENTRY TO SLEEP MODE

FIGURE 3-6: TRANSITION TIMING FOR WAKE FROM SLEEP (HSPLL)

3.4.1 PRI_IDLE MODE

3.4.2 SEC_IDLE MODE

FIGURE 3-7: TRANSITION TIMING FOR ENTRY TO IDLE MODE

FIGURE 3-8: TRANSITION TIMING FOR WAKE FROM IDLE TO RUN MODE

3.4.3 RC_IDLE MODE

3.5.2 EXIT BY WDT TIME-OUT

3.5 Exiting Idle and Sleep Modes

3.5.1 EXIT BY INTERRUPT

3.5.4 EXIT WITHOUT AN OSCILLATOR START-UP DELAY

4.0 RESET

4.1 RCON Register

FIGURE 4-1: SIMPLIFIED BLOCK DIAGRAM OF ON-CHIP RESET CIRCUIT

REGISTER 4-1: RCON: RESET CONTROL REGISTER

4.2 Master Clear (MCLR)

4.3 Power-on Reset (POR)

4.4 Brown-out Reset (BOR)
