PIC18F2525/2620/4525/4620

28/40/44-Pin Enhanced Flash Microcontrollers with

10-Bit A/D and nanoWatt Technology

Power Management Features:

• Run: CPU on, Peripherals on

• Idle: CPU off, Peripherals on

• Sleep: CPU off, Peripherals off

• Ultra Low 50nA Input Leakage

• Run mode Currents Down to 11 μA Typical

• Idle mode Currents Dow n to 2.5μA Typical

• Sleep mode Current Down to 100 nA Typical

• Timer1 Oscillator: 900 nA, 32 kHz, 2V

• Watchdog Timer: 1.4 μA, 2V Typical

• Two-Speed Oscillator Start-up

Flexible Oscillator Struc ture:

• Four Crystal modes, up to 40 MHz

• 4x Phase Lock Loop (PLL) – Available for Crystal and Internal Oscillators

• Two External RC modes, up to 4 MHz

• Two External Clock modes, up to 40 MHz

• Internal Oscillator Block:

- Fast wake from Sleep and Idle, 1 μs typical

- 8 use-selectable frequencies, from 31kHz to

8MHz

- Provides a complete range of clock speeds

from 31 kHz to 32 MHz when used with PLL

- User-tunable to compensate for frequency drift

• Secondary Oscillator using Timer1 @ 32 kHz

• Fail-Safe Clock Monitor:

- Allows for safe shutdown if peripheral clock stops

Peripheral Highlights:

• High-Current Sink/Source 25 mA/25 mA

• Three Programmable External Interrupts

• Four Input Change Interrupts

• Up to 2 Capture/Compare/PWM (CCP) modules, one with Auto-Shutdown (28-pin devices)

• Enhanced Capture/Compare/PWM (ECCP) module (40/44-pin devices only):

- One, two or four PWM outputs

- Selectable polarity

- Programmable dead time

- Auto-shutdown and auto-restart

Program Memory Data Memory

Device

PIC18F2525 48K 24576 3968 1024 25 10 2/0 Y Y 1 2 1/3 PIC18F2620 64K 32768 3968 1024 25 10 2/0 Y Y 1 2 1/3 PIC18F4525 48K 24576 3968 1024 36 13 1/1 Y Y 1 2 1/3 PIC18F4620 64K 32768 3968 1024 36 13 1/1 Y Y 1 2 1/3

Flash

(bytes)

# Single-Word

Instructions

SRAM (bytes)

EEPROM

(bytes)

Peripheral Highlight s (Continued):

• Master Synchronous Serial Port (MSSP) module Supporting 3-Wire SPI (all 4 modes) and I Master and Slave modes

• Enhanced Addressable USART module:

- Supports RS-485, RS-232 and LIN/J2602

- RS-232 operation using internal oscillator

block (no external crystal required)

- Auto-wake-up on Start bit

- Auto-Baud Detect

• 10-Bit, up to 13-Channel Analog-to-Digital (A/D) Converter module:

- Auto-acquisition capability

- Conversion available during Sleep

• Dual Analog Comparators with Input Multiplexing

• Programmable 16-Level High/Low-Voltage Detection (HLVD) module:

- Supports interrupt on High/Low-Voltage Detection

Special Microcontroller Features:

• C Compiler Optimized Arch itecture:

- Optional extended in struction set des igned to

optimize re-entrant code

• 100,000 Erase/Write Cycle Enhanced Flash Program Memory Typical

• 1,000,000 Erase/Write Cycle Data EEPROM Memory Typical

• Flash/Data EEPROM Retention: 100 Years Typical

• Self-Programmable under Software Control

• Priority Levels for Interrupts

• 8 x 8 Single-Cycle Hardware Multiplier

• Extended Watchdog Timer (WDT):

- Programmable period from 4 ms to 131s

• Single-Supply 5V In-Circuit Serial Programming™ (ICSP™) via Two Pins

• In-Circuit Debug (ICD) via Two Pins

• Wide Operating Voltage Range: 2.0V to 5.5V

• Programmable Brown-out Reset (BOR) with Software Enable Option

I/O

10-Bit

A/D (ch)

CCP/

ECCP

(PWM)

SPI

MSSP

Master

C™

EUSART

Comp.

C™

Timers

8/16-Bit

PIC18F2525/2620/4525/4620

RB7/KBI3/PGD RB6/KBI2/PGC

RB5/KBI1/PGM RB4/KBI0/AN11 RB3/AN9/CCP2

(1)

RB2/INT2/AN8 RB1/INT1/AN10

RB0/INT0/FLT0/AN12 V

VSS RD7/PSP7/P1D RD6/PSP6/P1C

RD5/PSP5/P1B RD4/PSP4 RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA RD3/PSP3 RD2/PSP2

MCLR/VPP/RE3

RA0/AN0 RA1/AN1

RA2/AN2/V

REF-/CVREF

RA3/AN3/VREF+

RA4/T0CKI/C1OUT

RA5/AN4/SS

/HLVDIN/C2OUT

RE0/RD

/AN5

RE1/WR

/AN6

RE2/CS

/AN7

VSS

OSC1/CLKI/RA7

OSC2/CLKO/RA6

RC0/T1OSO/T13CKI

RC1/T1OSI/CCP2

(1)

RC2/CCP1/P1A

RC3/SCK/SCL

RD0/PSP0 RD1/PSP1

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21

PIC18F4620

PIC18F2620

10 11

2 3 4 5 6

12 13 14

22 21

MCLR/VPP/RE3

RA0/AN0 RA1/AN1

RA2/AN2/V

REF-/CVREF

RA3/AN3/VREF+

RA4/T0CKI/C1OUT

RA5/AN4/SS

/HLVDIN/C2OUT

OSC1/CLKI/RA7

OSC2/CLKO/RA6

RC0/T1OSO/T13CKI

RC1/T1OSI/CCP2

(1)

RC2/CCP1

RC3/SCK/SCL

RB7/KBI3/PGD RB6/KBI2/PGC RB5/KBI1/PGM RB4/KBI0/AN11 RB3/AN9/CCP2

(1)

RB2/INT2/AN8 RB1/INT1/AN10 RB0/INT0/FLT0/AN12 V

VSS RC7/RX/DT RC6/TX/CK RC5/SDO RC4/SDI/SDA

40-Pin PDIP

28-Pin SPDIP, SOIC

PIC18F4525

PIC18F2525

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

Pin Diagrams

Pin Diagrams (Cont.’d)

10 11

2 3 4 5 6

1819202122

121314

4443424140

363435

PIC18F4525

RA3/AN3/V

REF+

RA2/AN2/V

REF-/CVREF

RA1/AN1

RA0/AN0

MCLR

/VPP/RE3

RB3/AN9/CCP2

(1)

RB7/KBI3/PGD

RB6/KBI2/PGC

RB5/KBI1/PGM

RB4/KBI0/AN11

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

(1)

RC0/T1OSO/T13CKI

OSC2/CLKO/RA6 OSC1/CLKI/RA7 V

VSS VDD VDD RE2/CS/AN7 RE1/WR

/AN6

RE0/RD

/AN5

RA5/AN4/SS

/HLVDIN/C2OUT

RA4/T0CKI/C1OUT

RC7/RX/DT

RD4/PSP4

RD5/PSP5/P1B RD6/PSP6/P1C RD7/PSP7/P1D

VDD VDD

RB0/INT0/FLT0/AN12

RB1/INT1/AN10

RB2/INT2/AN8

44-Pin QFN

(2)

PIC18F4620

10 11

2 3 4 5 6

1819202122

121314

4443424140

363435

PIC18F4525

RA3/AN3/VREF+

RA2/AN2/V

REF-/CVREF

RA1/AN1

RA0/AN0

MCLR

/VPP/RE3

RB7/KBI3/PGD

RB6/KBI2/PGC

RB5/KBI1/PGM

RB4/KBI0/AN11

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1/P1A

RC1/T1OSI/CCP2

(1)

NC RC0/T1OSO/T13CKI OSC2/CLKO/RA6 OSC1/CLKI/RA7 V

VDD RE2/CS/AN7 RE1/WR

/AN6

RE0/RD

/AN5

RA5/AN4/SS

/HLVDIN/C2OUT

RA4/T0CKI/C1OUT

RC7/RX/DT

RD4/PSP4

RD5/PSP5/P1B RD6/PSP6/P1C RD7/PSP7/P1D

VDD

RB0/INT0/FLT0/AN12

RB1/INT1/AN10

RB2/INT2/AN8

RB3/AN9/CCP2

(1)

44-Pin TQFP

PIC18F4620

Note 1: RB3 is the alternate pin for CCP2 multiplexing.

2: For the QFN package, it is recommended that the bottom pad be connected to V

SS.

PIC18F2525/2620/4525/4620

1.0 Device Overview..........................................................................................................................................................................7

2.0 Oscillator Configurations............................................................................................................................................................ 23

3.0 Power-Managed Modes ............................................................................................ .. .... ........................................................... 33

4.0 Reset.......................................................................................................................................................................................... 41

5.0 Memory Organization.................................................................................................................................................................53

6.0 Data EEPROM Memory............................................................................................................................................................. 73

7.0 Flash Program Memory............... .............................................................................. ................................................................. 79

8.0 8 x 8 Hardware Multiplier.................................... ........................................ ................................................................................ 89

9.0 I/O Ports...................... ...............................................................................................................................................................91

10.0 Interrupts..................................................................................................................................................................................109

11.0 Timer0 Module ......................................................................................................................................................................... 123

12.0 Timer1 Module ......................................................................................................................................................................... 127

13.0 Timer2 Module ......................................................................................................................................................................... 133

14.0 Timer3 Module ......................................................................................................................................................................... 135

15.0 Capture/Compare/PWM (CCP) Modules ................................................................................................................................. 139

16.0 Enhanced Capture/Compare/PWM (ECCP) Module................................................................................................................147

17.0 Master Synchronous Serial Port (MSSP) Module ..................... ..................... .......................................................................... 161

18.0 Enhanced Universal Synchronous Receiver Transmitter (EUSART)....................................................................................... 201

19.0 10-Bit Analog-to-Digital Converter (A/D) Module ..................................................................................................................... 223

20.0 Comparator Module................................................................................................. .. .... ...........................................................233

21.0 Comparator Voltage Reference Module................................ ......... .. .... .. .... ......... .. .... .... .. ......... .... . ........................................... 239

22.0 High/Low-Voltage Detect (HLVD)............................................................................................................................................. 243

23.0 Special Features of theCPU............................................... .................................................. ................................................... 249

24.0 Instruction Set Summary..........................................................................................................................................................267

25.0 Development Support. .............................................................................................................................................................. 317

26.0 Electrical Characteristics.......................................................................................................................................................... 321

27.0 DC and AC Characteristics Graphs and Tables.......................................................................................................................361

28.0 Packaging Information..... .................................................... .....................................................................................................383

Appendix A: Revision History............................................................................................................................................................. 393

Appendix B: Device Differences......................................................................................................................................................... 394

Appendix C: Conversion Considerations ............................................................... ....... .... .... .. .... ....................................................... 395

Appendix D: Migration from Baseline to Enhanced Devices.............................................................................................................. 395

Appendix E: Migration from Mid-Range TO Enhanced Devices ........................................................................................................ 396

Appendix F: Migration from High-End to Enhanced Devices............................................................................................................. 396

Index .................................................................................................................................................................................................. 397

The Microchip Web Site.................. ................................................................................................................................................... 407

Customer Change Notification Service .............................................................................................................................................. 407

Customer Support..............................................................................................................................................................................407

Reader Response..............................................................................................................................................................................408

PIC18F2525/2620/4525/4620 Product Identification System ............................................................................................................ 409

PIC18F2525/2620/4525/4620

TO OUR VALUED CUSTOMERS

It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your Microchip products. To this end, we will continue to improve our publications to better suit your needs. Our publications will be refined and enhanced as new volumes and updates are introduced.

If you have any questions or c omm ents regarding t his publication, please contact the Marketing Communications Department via E-mail at docerrors@microchip.com or fax the Reader Response Form in the back of this data sheet to (480) 792-4150. We welcome your feedback.

Most Current Data Sheet

To obtain the most up-to-date version of this data sheet, please register at our Worldwide Web site at:

http://www.microchip.com

You can determine the version of a data sheet by examining its literature number found on the bottom outside corner of any page. The last character of the literature number is the version number, (e.g., DS30000A is version A of document DS30000).

Errata

An errata sheet, describing minor operational differences from the data sheet and recommended workarounds, may exist for current devices. As device/documentation issues become known to us, we will publish an errata sheet. The errata will specify the revision of silicon and revision of document to which it applies.

To determine if an errata sheet exists for a particular device, please check with one of the following:

• Microchip’s Worldwide Web site; http://www.microchip.com

• Your local Microchip sales office (see last page) When contacting a sales office, please specify which device, revision of silicon and data sheet (include literature number) you are

using.

Customer Notification System

PIC18F2525/2620/4525/4620

NOTES:

PIC18F2525/2620/4525/4620

1.0 DEVICE OVERVIEW

This document cont a ins dev ice -specific information for the following devices:

• PIC18F2525 • PIC18LF2525

• PIC18F2620 • PIC18LF2620

• PIC18F4525 • PIC18LF4525

• PIC18F4620 • PIC18LF4620

This family offers the advantages of all PIC18 microcontrollers – namely, high computational performance at an economical price – with the addition of high-endurance, Enhanced Flash program memory. On top of these features, the PIC18F2525/2620/4525/ 4620 family introduces design enhancements that make these microcontrollers a logical choice for many high-performance, power sensitive applications.

1.1 New Core Features

1.1.1 nanoWatt TECHNOLOGY

All of the devices in the PIC18F2525/2620/4525/4620 family incorporate a range of features that can significantly reduce power consumption during operation. Key items include:

• Alternate Run Modes: By clocking the controller from the Timer1 source or the internal oscillator block, power consumption during code execution can be reduced by as much as 90%.

• Multiple Idle Modes: The controller can also run with its CPU core disabled but the peripherals still active. In these st ates, powe r consumpt ion can be reduced even further, to as little as 4%, of normal operation requirements.

• On-the-Fly Mode Switching: The power- managed modes a re invo ked b y user code durin g operation, allowing the user to incorporate power-saving ideas into their application’s software design.

• Low Consumption in Key Modules: The power requirements for both Timer1 and the Watchdog Timer are minimized. See Section 26.0 “Electrical Characteristics” for values.

1.1.2 MULTIPLE OSCILLATOR OPTIONS AND FEATURES

All of the devices in the PIC18F2525/2620/4525/4620 family offer ten different oscillator options, allowing users a wide range o f choices i n develo ping applica tion hardware. These include:

• Four Crystal modes, using crystals or ceramic

resonators

• Two External Clock modes, offering the option of

using two pins (oscillator input and a divide-by-4 clock output) or one pin (oscillator input, with the second pin reassigned as general I/O)

• Two External RC Oscillator modes with the same

pin options as the External Clock modes

• An internal oscillator block which provides

an 8 MHz clock and an INTRC source (approximately 31 kHz), as well as a range of 6 user-selectable clock freq uen cies, between 125 kHz to 4 MHz, for a total of 8 clock frequencies. This option f ree s th e t w o os ci ll at or pins for use a s additional general purpose I/O.

• A Phase Lock Loop (PLL) frequency multiplier ,

available to both the High-Speed C rystal and Internal Oscillator modes, which allows clock speeds of up to 40 MHz. Used with the internal oscillator, the PLL gives users a complete selection of clock speeds, from 31 kHz to 32 MHz – all without using an external crystal or clock circuit.

Besides its ava ilability as a cloc k source, the intern al oscillator block pro vid es a s t ab le re ference source that gives the family additional features for robust operation:

• Fail-Safe Clock Monitor: This option constantly

monitors the main clock source against a reference signal provided by the internal oscillator. If a clock failure occurs, the controller is switched to the internal oscillator block, allowing for continued low-speed operation or a safe application shutdown.

• T wo-Speed Start-up: This option allows the

internal oscillator to serve as the clock source from Power-on Reset, or wake-up from Sleep mode, until the primary clock source is available.

PIC18F2525/2620/4525/4620

1.2 Other Special Features

• Memory Endurance: The Enhanced Flash cells for both program memory and data EEPROM are rated to last for many thousands of erase/write cycles – up to 100,000 for program memory and 1,000,000 for EEPROM. Data retention without refresh is conservatively estimated to be greater than 40 years.

• Self-Programmability: These devices can write to their own program memory spaces under internal software control . By using a bootloader rout ine located in the protected Boot Block at the top of program memory, it becomes possible to create an application that can update itself in the field.

• Extended Instruction Set: The PIC18F2525/ 2620/4525/4620 family introduces an optional extension to the PIC18 ins truction set, whic h adds 8 new instructions and an Indexed Addressing mode. This extension, enabled as a device configuration option, has been specifically designed to optimize re-entrant application code originally developed in high-level languages, such as C.

• Enhanced CCP Module: In PWM mode, this module provides 1, 2 or 4 modulated outputs for controlling half-bridge and full-bridge drivers. Other features include auto- sh ut d ow n, for disabling PWM output s on interrup t or other selec t conditions and auto-restart, to reactivate outputs once the condition has cleared.

• Enhanced Addressable USART: This serial communication module is capable of standard RS-232 operation an d provides support for th e LIN bus protocol. Other enhancements include automatic baud rate detection and a 16-bit Baud Rate Generator for improved resolu tion. When the microcontroller is using the internal oscillator block, the EUSART provides stable operation for applications that talk to the outside world without using an external crystal (or its accompanying power requirement).

• 10-Bit A/D Converter: This module incorporates programmable acquisition time, allowing for a channel to be selected and a conversion to be initiated withou t wai ting for a sampling perio d and thus, reducing code overhead.

• Extended Watchdog Timer (WDT): This enhanced version in corpora tes a 1 6-bit pre scale r, allowing an exte nded time-o ut rang e that is s ta ble across operating voltage and temperature. See Section 26.0 “Electrical Characteristics” for time-out periods.

1.3 Details on Individual Family Members

Devices in the PIC18F 2525/2620 /4525/4620 famil y are available in 28-pin and 40/44-pin packages. Block diagrams for the two groups are shown in Figure 1-1 and Figure 1-2.

The devices are differentiated from each other in five ways:

1. Flash program memory (48Kbytes for

PIC18FX525 devices, 64Kbytes for PIC18FX620 devices).

2. A/D channels (10 for 28-pin devices, 13 for

40/44-pin devices).

3. I/O ports (3 bidirectio nal ports on 28 -pin devices,

5 bidirectional ports on 40/44-pin devices).

4. CCP and Enhanced CCP implementation

(28-pin devices have 2 standard CCP mod ules, 40/44-pin devices have one standard CCP module and one ECCP module).

5. Parallel Slave Port (present only on 40/44-pin

devices).

All other features fo r device s in this family are identi cal. These are summarized in Table1-1.

The pinouts for all devices are listed in Table 1-2 and Table 1-3.

Like all Microchip PIC18 devices, members of the PIC18F2525/2620/4525/4620 family are available as both standard and low-voltage devices. Standard devices with Enhan ced Flas h memory, designated with an “F” in the part number (such as PIC18F2620), accommodate an ope rati ng V Low-voltage parts, designated by “LF” (such as PIC18LF2620), func tion over an e xtended VDD range of 2.0V to 5.5V.

DD range of 4.2V to 5.5V.

PIC18F2525/2620/4525/4620

TABLE 1-1: DEVICE FEATURES

Features PIC18F2525 PIC18F2620 PIC18F4525 PIC18F4620

Operating Frequency DC – 40 MHz DC – 40 MHz DC – 40 MHz DC – 40 MHz Program Memory (Bytes) 49152 65536 49152 65536 Program Memory (Instruction s) 24576 32768 24576 32768 Data Memory (Bytes) 3968 3968 3968 3968 Data EEPROM Memory (Bytes) 1024 1024 1024 1024 Interrupt Sources 19 19 20 20 I/O Ports Ports A, B, C, (E) Ports A, B, C, (E) Ports A, B, C, D, E Ports A, B, C, D, E Timers 4 4 4 4 Capture/Compare/PWM Modules 2 2 1 1 Enhanced Capture/Compare/

PWM Modules Serial Communications MSSP,

Enhanced USART Parallel Communications (PSP) No No Yes Yes 10-Bit Analog-to-Digital Module 10 Input Channels 10 Input Channels 13 Input Channels 13 Input Channels Resets (and Delays) POR, BOR,

RESET Instruction,

Stac k U nde rflo w

MCLR

Programmable Low-Voltage Detect

Programmable Brown-out Reset Yes Yes Yes Yes Instruction Set 75 Instructions;

83 with Extended

Packages 28-Pin SPDIP

0011

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

(PWRT, OST),

(optiona l),

WDT

Yes Yes Yes Yes

Instruction Set

Enabled

28-Pin SOIC

Stack Full,

Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

75 Instructions;

83 with Extended

Instruction Set

Enabled

28-Pin SPDIP

28-Pin SOIC

MSSP,

Enhanced USART

POR, BOR,

RESET Instruction,

Stack Full,

Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

75 Instructions;

83 with Extended

Instruction Set

Enabled

40-Pin PDIP

44-Pin QFN

44-Pin TQFP

MSSP,

Enhanced USART

POR, BOR,

RESET Instructi on,

Stack Full,

Stack Underflow

(PWRT, OST),

(optional),

MCLR

WDT

75 Instructions;

83 with Extended

Instruction Set

Enabled

40-Pin PDIP

44-Pin QFN

44-Pin TQFP

PIC18F2525/2620/4525/4620

Instruction

Decode &

Control

PORTA

PORTB

PORTC

RA4/T0CKI/C1OUT RA5/AN4/SS

/HLVDIN/C2OUT

RB0/INT0/FLT0/AN12

RC0/T1OSO/T13CKI RC1/T1OSI/CCP2

(1)

RC2/CCP1 RC3/SCK/SCL RC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT

RA3/AN3/VREF+

RA2/AN2/VREF-/CVREF

RA1/AN1

RA0/AN0

RB1/INT1/AN10

Data Latch

Data Memory

(3.9 Kbytes)

Address Lat ch

Data Address<12>

Access

BSR

FSR0 FSR1 FSR2

inc/dec

logic

Address

PCH PCL

PCLATH

31 Level Stack

Program Counter

PRODLPRODH

8 x 8 Multiply

BITOP

ALU<8>

Address Latch

Program Memory

(48/64Kbytes)

Data Latch

T able Pointer<21>

inc/dec logic

Data Bus<8>

Table Latch

ROM Latch

RB2/INT2/AN8 RB3/AN9/CCP2

(1)

PCLATU

PCU

OSC2/CLKO

(3)

/RA6

Note 1: CCP2 is multiplexed with RC1 when Configuration bit, CCP2MX, is set, or RB3 when CCP2MX is not set.

2: RE3 is only available when MCLR

functionality is disabled.

3: OSC1/CLKI and OSC2/CLKO are only available in select oscillator modes and when these pins are not being used as digital I/O.

Refer to Section 2.0 “Oscillator Configurations” for additional information.

RB4/KBI0/AN11 RB5/KBI1/PGM RB6/KBI2/PGC RB7/KBI3/PGD

EUSARTComparator

MSSP

10-Bit

ADC

Timer2Timer1 Timer3Timer0

CCP2

LVD

CCP1

BOR

Data

EEPROM

Instruction Bus <16>

STKPTR

Bank

State Machine Control Signals

Decode

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

OSC1

(3)

OSC2

(3)

VDD,

Brown-out

Reset

Internal

Oscillator

Fail-Safe

Clock Monitor

Precision

Reference

Band Gap

MCLR

(2)

Block

INTRC

Oscillator

8 MHz

Oscillator

Single-Supply Programming

In-Circuit

Debugger

T1OSO

OSC1/CLKI

(3)

/RA7

T1OSI

PORTE

MCLR/VPP/RE3

(2)

FIGURE 1-1: PIC18F2525/2620 (28-PIN) BLOCK DIAGRAM

PIC18F2525/2620/4525/4620

Instruction Decode &

Control

Data Latch

Data Memory

(3.9 Kbytes)

Address Lat ch

Data Address<12>

Access

BSR

FSR0 FSR1 FSR2

inc/dec

logic

Address

PCH PCL

PCLATH

31 Level Stack

Program Counter

PRODLPRODH

8 x 8 Multiply

BITOP

ALU<8>

Address Latch

Program Memory

(48/64Kbytes)

Data Latch

T able Pointer<21>

inc/dec logic

Data Bus<8>

Table Latch

ROM Latch

PORTD

RD0/PSP0

PCLATU

PCU

PORTE

MCLR/VPP/RE3

(2)

RE2/CS/AN7

RE0/RD/AN5 RE1/WR/AN6

Note 1: CCP2 is multiplexed with RC1 when Configuration bit, CCP2MX, is set, or RB3 when CCP2MX is not set.

2: RE3 is only available when MCLR

functionality is disabled.

3: OSC1/CLKI and OSC2/CLKO are only available in select oscillator modes and when these pins are not being used as digital I/O.

Refer to Section 2.0 “Oscillator Configurations” for additional information.

:RD4/PSP4

EUSARTComparator

MSSP

10-Bit

ADC

Timer2Timer1 Timer3Timer0

CCP2

LVD

ECCP1

BOR

Data

EEPROM

Instruction Bus <16>

STKPTR

Bank

State Machine Control Signals

Decode

Power-up

Timer

Oscillator

Start-up Timer

Power-on

Reset

Watchdog

Timer

OSC1

(3)

OSC2

(3)

VDD,

Brown-out

Reset

Internal

Oscillator

Fail-Safe

Clock Monitor

Precision

Reference

Band Gap

MCLR

(2)

Block

INTRC

Oscillator

8 MHz

Oscillator

Single-Supply

Programming

In-Circuit

Debugger

T1OSI

T1OSO

RD5/PSP5/P1B RD6/PSP6/P1C RD7/PSP7/P1D

PORTA

PORTB

PORTC

RA4/T0CKI/C1OUT RA5/AN4/SS

/HLVDIN/C2OUT

RB0/INT0/FLT0/AN12

RC0/T1OSO/T13CKI RC1/T1OSI/CCP2

(1)

RC2/CCP1/P1A RC3/SCK/SCL RC4/SDI/SDA RC5/SDO RC6/TX/CK RC7/RX/DT

RA3/AN3/VREF+

RA2/AN2/VREF-/CVREF

RA1/AN1

RA0/AN0

RB1/INT1/AN10 RB2/INT2/AN8 RB3/AN9/CCP2

(1)

OSC2/CLKO

(3)

/RA6

RB4/KBI0/AN11 RB5/KBI1/PGM RB6/KBI2/PGC RB7/KBI3/PGD

OSC1/CLKI

(3)

/RA7

FIGURE 1-2: PIC18F4525/4620 (40/44-PIN) BLOCK DIAGRAM

PIC18F2525/2620/4525/4620

TABLE 1-2: PIC18F2525/2620 PINOUT I/O DESCRIPTIONS

Pin Name

Number

SPDIP,

SOIC

Type

Buffer

Type

Description

/VPP/RE3

MCLR

MCLR VPP

RE3

OSC1/CLKI/RA7

OSC1 CLKI

RA7

OSC2/CLKO/RA6

OSC2 CLKO RA6

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared.

I/O

O O

I/O

Master Clear (input) or programming voltage (input).

CMOS

TTL

— —

TTL

Master Clear (Reset) input. This pin is an active-low Reset to the device. Programming voltage input. Digital input.

Oscillator crystal or external clock input.

Oscillator crystal input or external clock source input. ST buffer when configured in RC mode; CMOS otherwise. External clock source input. Always associated with pin function OSC1. (See related OSC1/CLKI, OSC2/CLKO pins.) General purpose I/O pin.

Oscillator crystal or clock output.

Oscillator crystal output. Connects to crystal or resonator in Crystal Oscillator mode. In RC mode, OSC2 pin outputs CLKO which has 1/4 the frequency of OSC1 and denotes the instruction cycle rate. General purpose I/O pin.

PIC18F2525/2620/4525/4620

TABLE 1-2: PIC18F2525/2620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RA0/AN0

RA0 AN0

RA1/AN1

RA1 AN1

RA2/AN2/V

RA2 AN2 VREFCV

RA3/AN3/V

RA3 AN3 V

RA4/T0CKI/C1OUT

RA4 T0CKI C1OUT

RA5/AN4/SS C2OUT

RA5 AN4 SS HLVDIN

C2OUT RA6 See the OSC2/CLKO/RA6 pin. RA7 See the OSC1/CLKI/RA7 pin.

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

REF-/CVREF

REF

REF+

/HLVDIN/

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared.

Number

SPDIP,

SOIC

Buffer

Type

I/OITTL

Analog

I/OITTL

Analog

I/O

Analog

I/O

Analog

I/O

Analog I I

Analog

PORTA is a bidirectional I/O port.

Digital I/O. Analog input 0.

Digital I/O. Analog input 1.

TTL

ST ST

—

TTL TTL

—

Digital I/O. Analog input 2. A/D reference voltage (low) input. Comparator reference voltage output.

Digital I/O. Analog input 3. A/D reference voltage (high) input.

Digital I/O. Timer0 external clock input. Comparator 1 output.

Digital I/O. Analog input 4. SPI slave select input. High/Low-Voltage Detect input. Comparator 2 output.

Description

PIC18F2525/2620/4525/4620

TABLE 1-2: PIC18F2525/2620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RB0/INT0/FLT0/AN12

RB0 INT0 FLT0 AN12

RB1/INT1/AN10

RB1 INT1 AN10

RB2/INT2/AN8

RB2 INT2 AN8

RB3/AN9/CCP2

RB3 AN9

(1)

CCP2

RB4/KBI0/AN11

RB4 KBI0 AN11

RB5/KBI1/PGM

RB5 KBI1 PGM

RB6/KBI2/PGC

RB6 KBI2 PGC

RB7/KBI3/PGD

RB7 KBI3 PGD

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared.

Number

SPDIP,

SOIC

Type

I/O

I I I

I/O

I I

I/O

I I

I/O

I I

I/O

Buffer

Type

TTL

ST ST

Analog

TTL

Analog

TTL

Analog

TTL

Analog

TTL TTL

Analog

TTL TTL

Description

PORTB is a bidirectional I/O port. PORTB can be software programmed for internal weak pull-ups on all inputs.

Digital I/O. External interrupt 0. PWM Fault input for CCP1. Analog input 12.

Digital I/O. External interrupt 1. Analog input 10.

Digital I/O. External interrupt 2. Analog input 8.

Digital I/O. Analog input 9. Capture 2 input/Compare 2 output/PWM2 output.

Digital I/O. Interrupt-on-change pin. Analog input 11.

Digital I/O. Interrupt-on-change pin. Low-Voltage ICSP™ Programming enable pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming clock pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming data pin.

PIC18F2525/2620/4525/4620

TABLE 1-2: PIC18F2525/2620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RC0/T1OSO/T13CKI

RC0 T1OSO T13CKI

RC1/T1OSI/CCP2

RC1 T1OSI

(2)

CCP2

RC2/CCP1

RC2 CCP1

RC3/SCK/SCL

RC3 SCK SCL

RC4/SDI/SDA

RC4 SDI SDA

RC5/SDO

RC5 SDO

RC6/TX/CK

RC6 TX CK

RC7/RX/DT

RC7 RX DT

RE3 — — — See MCLR

SS 8, 19 P — Ground reference for logi c and I/O pins .

V VDD 20 P — Positive supply for logic and I/O pins. Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared.

Number

SPDIP,

SOIC

Type

I/O

I/O I/O

I/O I/O I/O

I/O

Buffer

Type

—

Analog

ST ST

ST ST ST

—

ST ST ST

Description

PORTC is a bidirectional I/O port.

Digital I/O. Timer1 oscilla tor outp ut. Timer1/Timer3 external clock input.

Digital I/O. Timer1 oscilla tor inpu t. Capture 2 input/Compare 2 output/PWM2 output.

Digital I/O. Capture 1 input/Compare 1 output/PWM1 output.

Digital I/O. Synchronous serial clock input/output for SPI mode. Synchronous serial clock input/output for I

Digital I/O. SPI data in. I2C data I/O.

Digital I/O. SPI data out.

Digital I/O. EUSART asynchronous transmit. EUSART synchronous clock (see related RX/DT).

Digital I/O. EUSART asynchronous receive. EUSART synchronous data (see related TX/CK).

/VPP/RE3 pin.

C™ mode.

PIC18F2525/2620/4525/4620

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS

Pin Name

Pin Number

PDIP QFN TQFP

Type

Buffer

Type

Description

/VPP/RE3

MCLR

MCLR VPP

RE3

OSC1/CLKI/RA7

OSC1

CLKI

RA7

OSC2/CLKO/RA6

OSC2 CLKO

RA6

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared. 3: For the QFN package, it is recommended that the bottom pad be connected to V

11818

13 32 30

14 33 31

I/O

O O

I/O

CMOS

TTL

— —

TTL

Master Clear (input) or programming voltage (input).

Master Clear (Reset) input. This pin is an ac tive-low Reset to the device. Programming voltage input. Digital input.

Oscillator crystal or external clock input.

Oscillator crystal input or external clock source input. ST buffer when configured in RC mode; analog otherwise. External clock source input. Always associated with pin function OSC1. (See related OSC1/CLKI, OSC2/CLKO pins.) General purpose I/O pin.

Oscillator crystal or clock output.

SS.

PIC18F2525/2620/4525/4620

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RA0/AN0

RA0 AN0

RA1/AN1

RA1 AN1

RA2/AN2/V

RA3/AN3/V

RA4/T0CKI/C1OUT

RA5/AN4/SS C2OUT

RA6 See the OSC2/CLKO/RA6 pin. RA7 See the OSC1/CLKI/RA7 pin.

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

REF-/CVREF

RA2 AN2

REF-

V CV

REF

REF+

RA3 AN3

REF+

RA4 T0CKI C1OUT

/HLVDIN/

RA5 AN4 SS HLVDIN C2OUT

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared. 3: For the QFN package, it is recommended that the bottom pad be connected to V

Pin Number

PDIP QFN TQFP

21919

32020

42121

52222

62323

72424

Buffer

Type

I/OITTL

Analog

I/OITTL

Analog

I/O

Analog

I/O

Analog

I/O

Analog I I

Analog

PORTA is a bidirectional I/O port.

Digital I/O. Analog input 0.

Digital I/O. Analog input 1.

TTL

ST ST

—

TTL TTL

—

Digital I/O. Analog input 2. A/D reference voltage (low) input. Comparator reference voltage output.

Digital I/O. Analog input 3. A/D reference voltage (high) input.

Digital I/O. Timer0 external clock input. Comparator 1 output.

Digital I/O. Analog input 4. SPI slave select input. High/Low-Voltage Detect input. Comparator 2 output.

Description

SS.

PIC18F2525/2620/4525/4620

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RB0/INT0/FLT0/AN12

RB0 INT0 FLT0 AN12

RB1/INT1/AN10

RB1 INT1 AN10

RB2/INT2/AN8

RB2 INT2 AN8

RB3/AN9/CCP2

RB3 AN9

(1)

CCP2

RB4/KBI0/AN11

RB4 KBI0 AN11

RB5/KBI1/PGM

RB5 KBI1 PGM

RB6/KBI2/PGC

RB6 KBI2 PGC

RB7/KBI3/PGD

RB7 KBI3 PGD

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared. 3: For the QFN package, it is recommended that the bottom pad be connected to V

Pin Number

PDIP QFN TQFP

33 9 8

34 10 9

35 11 10

36 12 11

37 14 14

38 15 15

39 16 16

40 17 17

Type

I/O

I I I

I/O

I I

I/O

I I

I/O

I I

I/O

Buffer

Type

TTL

ST ST

Analog

TTL

Analog

TTL

Analog

TTL

Analog

TTL TTL

Analog

TTL TTL

Description

PORTB is a bidirectional I/O port. PORTB can be software programmed for internal weak pull-ups on all inputs.

Digital I/O. External interrupt 0. PWM Fault input for Enhanced CCP1. Analog input 12.

Digital I/O. External interrupt 1. Analog input 10.

Digital I/O. External interrupt 2. Analog input 8.

Digital I/O. Analog input 9. Capture 2 input/Compare 2 outpu t/PWM 2 outp ut.

Digital I/O. Interrupt-on-change pin. Analog input 11.

Digital I/O. Interrupt-on-change pin. Low-Voltage ICSP™ Programming enable pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming clock pin.

Digital I/O. Interrupt-on-change pin. In-Circuit Debugger and ICSP programming data pin.

SS.

PIC18F2525/2620/4525/4620

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RC0/T1OSO/T13CKI

RC0 T1OSO T13CKI

RC1/T1OSI/CCP2

RC1 T1OSI

(2)

CCP2

RC2/CCP1/P1A

RC2 CCP1 P1A

RC3/SCK/SCL

RC3 SCK

SCL

RC4/SDI/SDA

RC4 SDI SDA

RC5/SDO

RC5 SDO

RC6/TX/CK

RC6 TX CK

RC7/RX/DT

RC7 RX DT

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared. 3: For the QFN package, it is recommended that the bottom pad be connected to V

Pin Number

PDIP QFN TQFP

15 34 32

16 35 35

17 36 36

18 37 37

23 42 42

24 43 43

25 44 44

26 1 1

Buffer

Type

I/O

CMOS

I/O

I/O I/O

I/O

I/OOST

I/O

Type

PORTC is a bidirectional I/O port.

—

ST ST

—

ST ST

ST ST ST

—

ST ST ST

Digital I/O. Timer1 oscillator output. Timer1/Timer3 external clock input.

Digital I/O. Timer1 oscillator input. Capture 2 input/Compare 2 outpu t/PWM 2 outp ut.

Digital I/O. Capture 1 input/Compare 1 outpu t/PWM 1 outp ut. Enhanced CCP1 output.

Digital I/O. Synchronous serial clock input/output for SPI mode. Synchronous serial clock input/output for I mode.

Digital I/O. SPI data in.

C data I/O.

Digital I/O. SPI data out.

Digital I/O. EUSART asynchronous transmit. EUSART synchronous clock (see related RX/DT).

Digital I/O. EUSART asynchronous receive. EUSART synchronous data (see related TX/CK).

Description

SS.

C™

PIC18F2525/2620/4525/4620

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RD0/PSP0

RD0 PSP0

RD1/PSP1

RD1 PSP1

RD2/PSP2

RD2 PSP2

RD3/PSP3

RD3 PSP3

RD4/PSP4

RD4 PSP4

RD5/PSP5/P1B

RD5 PSP5 P1B

RD6/PSP6/P1C

RD6 PSP6 P1C

RD7/PSP7/P1D

RD7 PSP7 P1D

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared. 3: For the QFN package, it is recommended that the bottom pad be connected to V

Pin Number

PDIP QFN TQFP

19 38 38

20 39 39

21 40 40

22 41 41

27 2 2

28 3 3

29 4 4

30 5 5

Buffer

Type

I/O I/OSTTTL

I/O I/O

Description

PORTD is a bidirectional I/O port or a Parallel Slave Port (PSP) for interfacing to a microprocessor port. These pins have TTL input buffers when the PSP module is enabled.

Digital I/O. Parallel Slave Port data.

TTL

—

TTL

—

TTL

—

Digital I/O. Parallel Slave Port data. Enhanced CCP1 output.

SS.

PIC18F2525/2620/4525/4620

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS (CONTINUED)

Pin Name

RE0/RD

RE1/WR/AN6

RE2/CS

RE3 — — — — — See MCLR VSS 12, 31 6, 30, 316, 29 P — Ground reference for logic and I/O pins.

/AN5 RE0 RD

AN5

RE1 WR

AN6

/AN7 RE2 CS

AN7

Pin Number

PDIP QFN TQFP

82525

92626

10 27 27

Type

I/O

I I

I/O

I I

I/O

I I

Buffer

Type

TTL

Analog

TTL

Analog

TTL

Analog

Description

PORTE is a bidirectional I/O port.

Digital I/O. Read control for Parallel Slave Port (see also WR Analog input 5.

Digital I/O. Write control for Parallel Slave Port (see CS Analog input 6.

Digital I/O. Chip select control for Parallel Slave Port (see related RD Analog input 7.

and CS pins).

and RD pins).

and WR).

/VPP/RE3 pin.

DD 11, 32 7, 8,

28, 29

NC — 13 12, 13,

Legend: TTL = TTL compatible input CMOS = CMOS compatible input or output

ST = Schmitt Trigger input with CMOS levels I = Input O = Output P = Power

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is cleared. 3: For the QFN package, it is recommended that the bottom pad be connected to V

7, 28 P — Positive supply for logic and I/O pins.

— — No connect.

33, 34

SS.

PIC18F2525/2620/4525/4620

NOTES:

PIC18F2525/2620/4525/4620

Note 1: See Table 2-1 and T able 2-2 for initial values of

C1 and C2.

2: A series resistor (R

S) may be required for AT

strip cut crystals.

3: R

F varies with the oscillator mode chosen.

(1)

XTAL

OSC2

OSC1

(3)

Sleep

Logic

PIC18FXXXX

(2)

Internal

2.0 OSCILLATOR CONFIGURATIONS

2.1 Oscillator Types

PIC18F2525/2620/4525/4620 devices can be operated in ten different oscillator modes. The user can program the Configuration bits, FOSC3:FOSC0, in Configuration Register 1H to select one of these ten modes:

1. LP Low-Power Crystal

2. XT Crystal/Resonator

3. HS High-Speed Crystal/Resonator

4. HSPLL High-Speed Crystal/Resonator

with PLL Enabled

5. RC External Resistor/Capacitor with

OSC/4 Output on RA6

6. RCIO External Resi stor/Capacitor with I/O

on RA6

7. INTIO1 Internal Oscillator with F

on RA6 and I/O on RA7

8. INTIO2 Internal Oscillator with I/O on RA6

and RA7

9. EC External Clock with F

10. ECIO External Clock with I/O on RA6

2.2 Crystal Oscil lator/Ceramic Resonators

In XT, LP, HS or HSPLL Oscillator modes, a crystal or ceramic resonator is connected to the OSC1 and OSC2 pins to establish oscillation. Figure 2-1 shows the pin connections.

The oscillator design requires the use of a parallel cut crystal.

Note: Use of a series cut crystal may give a fre-

quency out of the crystal manufacturer’s specifications.

OSC/4 Output

FIGURE 2-1: CRYSTAL/CERAMIC

RESONATOR OPERATION (XT, LP, HS OR HSPLL CONFIGURATION)

T ABLE 2-1: CAPACITOR SELECTION FOR

CERAMIC RESONATORS

Typical Capacitor Values Used:

Mode Freq OSC1 OSC2

XT 3.58 MHz

4.19 MHz 4 MHz 4 MHz

Capacitor values are for design guidance only. Different cap acitor values may be required to prod uce

acceptable oscillator operation. The user should test the performance of the oscillator over the expected

DD and temperature range for the application.

V See the notes following Table 2-2 for additional

information.

15 pF 15 pF 30 pF 50 pF

PIC18F2525/2620/4525/4620

OSC1

OSC2

Open

Clock from Ext. System

PIC18FXXXX

(HS Mode)

OSC1/CLKI

OSC2/CLKO

OSC/4

Clock from Ext. System

PIC18FXXXX

OSC1/CLKI

I/O (OSC2)

RA6

Clock from Ext. System

PIC18FXXXX

TABLE 2-2: CAPACITOR SELECTION FOR

CRYSTAL OSCILLATOR

Osc T y pe

LP 32 kHz 30 pF 30 pF XT 1 MHz

HS 4 MHz

Capacitor values are for design guidance only. Different capa citor values may be required to produc e

acceptable oscillator operation. The user should test the performance of the oscillator over the expected VDD and temperature range for the application.

See the notes following this table for additional information.

Note 1: Higher capacita nce increase s the st ability

Crystal

Freq

4 MHz

10 MHz 20 MHz 25 MHz

of the oscillator but also increases the start-up time.

2: When operating below 3V V

using certain ceramic resonators at any voltage, it may be necessary to use the HS mode or switch to a crystal oscillator.

3: Since each resonator/crystal has its own

characteristics, the user should consult the resonator/crystal manufacturer for appropriate values of external components.

4: Rs may be r equired to av oid overdr iving

crystals with low driv e lev e l spe ci fic ati on.

5: Always verify oscillator perform an ce over

DD and temperature range that is

the V expected for the application.

T ypical Cap acitor V alues

Tested:

C1 C2

15 pF 15 pF

15 pF 15 pF 15 pF 15 pF

15 pF 15 pF

15 pF 15 pF 15 pF 15 pF

DD, or when

An external clock source may also be connected to the OSC1 pin in the HS mode, as shown in Figure 2-2.

FIGURE 2-2: EXTERNAL CLOCK

INPUT OPERATION (HS OSCILLATOR CONFIGURATION)

2.3 External Clock Input

The EC and ECIO Oscillator mode s require an externa l clock source to be conn ected to the OSC1 pi n. There is no oscillator start-up time required after a Power-on Reset or after an exit from Sleep mode.

In the EC Oscillator mode, the oscillator frequency divided by 4 is available on the OSC2 pin. This signal may be used f or t est pu r pos es or t o sy nc hr o niz e o t he r logic. Figure 2-3 shows the pin connections for the EC Oscillator mode.

FIGURE 2-3: EXTERNAL CLOCK

INPUT OPERATION (EC CONFIGURATION)

The ECIO Oscillator mo de func tio ns lik e t he EC mod e, except that the OSC2 pin becomes an additional general purpose I/O pin. The I/O pin becomes bit 6 of PORTA (RA6). Figure 2-4 shows the pin connections for the ECIO Oscillator mode.

FIGURE 2-4: EXTERNAL CLOCK

INPUT OPERATION (ECIO CONFIGURATION)

PIC18F2525/2620/4525/4620

OSC2/CLKO

CEXT

REXT

PIC18FXXXX

OSC1

OSC/4

Internal

Clock

VDD

VSS

Recommended values: 3 kΩ ≤ REXT ≤ 100 kΩ

EXT > 20 pF

CEXT

REXT

PIC18FXXXX

OSC1

Internal

Clock

VDD

VSS

Recommended values: 3 kΩ ≤ REXT ≤ 100 kΩ

EXT > 20 pF

I/O (OSC2)

RA6

MUX

VCO

Loop Filter

Crystal

Osc

OSC2

OSC1

PLL Enable

FOUT

SYSCLK

Phase

Comparator

HS Oscillator Enable

÷4

(from Configuration Register 1H)

HS Mode

2.4 RC Oscillator

For timing insensitive applications, the “RC” and “RCIO” device options offer additional cost savings. The actual oscillator frequency is a function of several factors:

• supply voltage

• values of the external resistor (R capacitor (C

EXT)

• operating temperature

Given the same device, operating voltage and temperature and component values, there will also be unit-to-unit frequency variations. These are due to factors such as:

• normal manufacturing variation

• difference in lead frame capacitance between package types (especially for low C

• variati ons within th e tolerance of limits of R

EXT

and C

In the RC Oscillator mode, the oscillator frequency divided by 4 is available on the OSC2 pin. This signal may be used f or t est pu r pos es or t o sy nc hr o niz e o t he r logic. Figure 2-5 shows how the R/C combination is connected.

FIGURE 2-5: RC OSCILLATOR MODE

EXT) and

EXT values)

EXT

2.5 PLL Frequency Multiplier

A Phase Locked Loop (PLL) circuit is provided as an option for users who wish to use a lower frequency oscillator circuit or to clock the device up to its highest rated frequency from a crystal oscillator. This may be useful for customers who are concerned with EMI due to high-frequency crystals or users who require higher clock speeds from an internal oscillator.

2.5.1 HSPLL OSCILLATOR MODE

The HSPLL mode makes use of the HS Oscillator mode for frequencies up to 10 MHz. A PLL then multiplies the oscilla tor outpu t frequen cy by 4 to produ ce an internal clock frequency up to 40 MHz. The PLLEN bit is not available in this oscillator mode.

The PLL is only available to the crystal oscillator when the FOSC3:FOSC0 Con figuration bit s are prog rammed for HSPLL mode (= 0110).

FIGURE 2-7: PLL BLOCK DIAGRAM

(HS MODE)

The RCIO Oscillator mode (Figure 2-6) functions like the RC mode, except that the OSC2 pin becomes an additional general purpose I/O pin. The I/O pin becomes bit 6 of PORTA (RA6).

FIGURE 2-6: RCIO OSCILLATOR MODE

2.5.2 PLL AND INTOSC

The PLL is also ava ilabl e to th e inte rnal os cill ator bl ock in selected oscillator modes. In this configuration, the PLL is enabled in software and generates a clock output of up to 32MHz. The operation of INTOSC with the PLL is describ ed in Sec tion 2.6.4 “PLL in INTOSC

Modes”.

PIC18F2525/2620/4525/4620

2.6 Internal Oscillator Block

The PIC18F2525/2620/4525/4620 devices include an internal oscillator block which generates two different clock signals; either can be used as the microcontroller’s clock source. This may eliminate the need for external oscillator circuits on the OSC1 and/or OSC2 pins.

The main output (INTOSC) is an 8MHz clock source, which can be used to directly drive the device clock. It also drives a postscaler, which can provide a range of clock frequencies from 31 kHz to 4 MHz. The INTOSC output is enabled when a clock fre quency from 12 5 kHz to 8 MHz is selected.

The other clock source is the Internal RC oscillator (INTRC), which provides a nominal 31 kHz output. INTRC is enabled if it is selected as the device clock source; it is also ena bled autom atically when an y of the following are enabled:

• Power-up Timer

• Fail-Safe Clock Monitor

• Watchdog Timer

• Two-Speed Start-up These features are discussed in greater detail in

Section 23.0 “Special Features of the CPU”. The clock source frequency (INTOSC direct, INTRC

direct or INTOSC postscaler) is selected by configuring the IRCF bits of the OSCCON register (page 30).

2.6.1 INTIO MODES

Using the internal oscillator as the clock source eliminates the need for up to two external oscillator pins, which can then be used for digital I/O. Two distinct configurations are available:

• In INTIO1 mode, the OSC2 pin outputs F while OSC1 functions as RA 7 fo r dig it a l in put and output.

• In INTIO2 mode, OSC1 functions as RA7 and OSC2 functions as RA6, both for digital input and output.

2.6.2 INTOSC OUTPUT FREQUENCY

The internal oscillator block is calibrated at the factory to produce an INTOSC output frequency of 8.0 MHz.

The INTRC oscillator operates independently of the INTOSC source. Any changes in INTOSC across voltage and temperature are not necessarily reflected by changes in INTRC and vice versa.

2.6.3 OSCTUNE REGISTER

The internal oscillator’s output has been calibrated at the factory but can be adjusted in the user’s application. This is do ne by writi ng to the OSCT UNE regist er (Register 2-1). The tuning sensitivity is constant throughout the tuning range.

OSC/4,

When the OSCTUNE regis ter is mo di fied , the IN T O SC frequency will begin shifting to the new frequency. The INTRC clock will reach the new frequency within 8 clock cycles (approxima tely 8 * 32 μs=256μs). The INTOSC clock will stabilize within 1 ms. Code execution continues during this shift. There is no indication that the shift has occurred.

The OSCTUNE register also implements the INTSRC and PLLEN bits, which control certain features of the internal oscillator block. The INTSRC bit allows users to select which internal oscillator provides the clock source when the 31 kHz frequency option is selected. This is covered in greater detail in Section 2.7.1 “Oscillator Control Register”.

The PLLEN bit controls the operation of the frequency multiplier, PLL, in internal oscillator modes.

2.6.4 PLL IN INTOSC MODES

The 4x frequency multiplier can be used with the internal oscillator block to produce faster device clock speeds than are normally possible with an internal oscillator. When enabled, the PLL produces a clock speed of up to 32MHz.

Unlike HSPLL mode, the PLL is controlled through software. The control bit, PLLEN (OSCTUNE<6>), is used to enable or disable its operation.

The PLL is available when the device is configured to use the internal oscillator block as its primary clock source (FOSC3:FOSC0 = 1001 or 1000). Additionally, the PLL will only function when the selected output frequency is either 4 MHz or 8 MHz (OSCCON<6:4> = 111 or 110). If both of these conditions are not met, the PLL is disabled.

The PLLEN control bit is only functional in those internal oscillator modes where the PLL is available. In all other modes, it is forced to ‘0’ and is effectively unavailable.

2.6.5 INTOSC FREQUENCY DRIFT

The factory calibrates the internal oscillator block output (INTOSC) for 8 MHz. However, this frequency may drift as V affect the controller operation in a variety of ways. It is possible to adjust the INTOSC frequency by modifying the value in the OSCTUNE register. This has no effect on the INTRC clock source frequency.

Tuning the INTOSC source requires knowing when to make the adjustment, in which direction it should be made, and in some cases, how large a change is needed. Three compensation techniques are discussed in Section 2.6.5.1 “Compensating with

the EUSART”, Section 2.6.5.2 “Compensating with the Timers” and Section2.6.5.3 “Compensating with the CCP Module in Capture Mode”, but other

techniques may be used.

DD or temperature changes, which can

PIC18F2525/2620/4525/4620

REGISTER 2-1: OSCTUNE: OSCILLATOR TUNING REGISTER

R/W-0 R/W-0

INTSRC PLLEN

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 INTSRC: Internal Oscillator Low-Frequ enc y Sour ce Sele ct bit

1 = 31.25 kHz device clock derived from 8 MHz INTOSC source (divide-by-256 enabled) 0 = 31 k Hz device clock derived directly from INTRC internal oscillator

bit 6 PLLEN: Frequency Multiplier PLL for INTOSC Enable bit

1 = PLL enabled for INTOSC (4 MHz and 8 MHz only) 0 = PLL disabled

bit 5 Unimplemented: Read as ‘0’ bit 4-0 TUN4:TUN0: Frequency Tuning bits

011111 = Maximum frequency

• •

000001 000000 = Center frequency. Oscillator module is running at the calibrated frequency. 111111

• •

• • 100000 = Minimum frequency

(1)

U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

— TUN4 TUN3 TUN2 TUN1 TUN0

(1)

Note 1: Available only in certain oscillator configurations; otherwise, this bit is unavailable and reads as ‘0’. See

Section 2.6.4 “PLL in INTOSC Modes” for details.

2.6.5.1 Compensating with the EUSART

An adjustment may be required when the EUSART begins to generate frami ng errors or rec eive s dat a with errors while in Asynchronous mode. Framing errors indicate that the device clock frequency is too high; to adjust for this, decrement the value in OSCTUNE to reduce the clock frequency. On the other hand, errors in data may suggest that the clock speed is too low; to compensate, increment OSCTUNE to increase the clock frequency.

2.6.5.2 Compensating with the Timers

This technique compares device clock speed to some reference clock. Two timers may be used; one timer is clocked by the peripheral clock, while the other is clocked by a fixed reference source, such as the Timer1 oscillat or.

Both timers are cleared, but the timer clocked by the reference generates interrupts. When an interrupt occurs, the internally clocked timer is read and both timers are cleared. If the internally clocked timer value is greater than expected, then the internal oscillator block is ru nning too fast. To adjust for this, decr ement the OSCTUNE register.

2.6.5.3 Compensating with the CCP Module in Capture Mode

A CCP module can use free-running Timer1 (or Timer3), cl oc ked by the internal oscillator block and an external event with a known period (i.e., AC power frequency). The ti me of the first ev ent is capt ured in the CCPRxH:CCPRxL registers and is recorded for use later. When the second event causes a capture, the time of the first event is su btra cte d fro m the tim e of th e second event. Since the period of the external event is known, the time difference between events can be calculated.

If the measured time is much greater than the calculated time, the internal oscillator block is running too fast; to compensate, decrement the OSCTUNE register. If the measured time is much less than the calculated time, the internal oscillator block is running too slow; to compensate, increment the OSCTUNE register.

PIC18F2525/2620/4525/4620

4 x PLL

FOSC3:FOSC0

Secondary Oscillator

T1OSCEN Enable Oscillator

T1OSO

T1OSI

Clock Source Option for Other Modules

OSC1

OSC2

Sleep

HSPLL, INTOSC/PLL

LP, XT, HS, RC, EC

T1OSC

CPU

Peripherals

IDLEN

Postscaler

MUX

8 MHz 4 MHz 2 MHz 1 MHz

500 kHz

125 kHz

250 kHz

OSCCON<6:4>

111 110 101 100

011 010 001 000

31 kHz

INTRC

Source

Internal

Oscillator

Block

WDT, PWRT, FSCM

8 MHz

Internal Oscillator

(INTOSC)

OSCCON<6:4>

Clock

Control

OSCCON<1:0>

Source

8 MHz

31 kHz (INTRC)

OSCTUNE<6>

OSCTUNE<7>

and Two-Speed Start-up

Primary Oscillator

2.7 Clock Sources and Oscillator Switching

Like previous PIC18 devices, the PIC18F2525/2620/ 4525/4620 family includes a feature that allows the device clock source to be switched from the main oscillator to an alternate, low-frequency clock source. PIC18F2525/2620/4525/4620 devices offer two alternate clock sources. When an alternate clock source is enabled, the various power-managed operating modes are available.

Essentially, there are three clock sources for these devices:

• Primary oscillators

• Secondary oscillators

• Internal oscillator block

The primary oscillators include the Ex ternal Crystal and Resonator modes, the External RC modes, the External Clock modes and the internal oscillator block. The particular mode is defined by the FOSC3:FOSC0 Configuration bits. The details of these modes are covered earlier in this chapter.

The s econdary oscillators are those external sources not connected to the OSC1 or OSC2 pins. These sources may continue to operate even after the controller is placed in a power-managed mode.

PIC18F2525/2620/452 5/46 20 d ev ic es o f fe r the Timer1 oscillator as a secon dary oscilla tor . This osc illator , in all power-managed modes, is often the time base for functions such as a Real-Time Clock (RTC).

Most often, a 32.768 kHz watch crystal is connected between the RC0/T1OSO/T13CKI and RC1/T1OSI pins. Like the LP Oscillator mode circuit, loading capacitors are also connected from each pin to ground.

The Timer1 oscillator is discussed in greater detail in Section 12.3 “Timer1 Oscillator”.

In addition to being a prim ary clock source, the internal oscillator block is available as a power-managed mode clock source. T he IN TR C s ource is also used as the clock source for several special features, such as the WDT and Fail-Safe Clock Monitor.

The clock sources for the PIC18F2525/2620/4525/4620 devices are shown in Figure 2-8. See Section 23.0 “Special Features of the CPU” for Configuration register details.

FIGURE 2-8: PIC18F2525/2620/4525/4620 CLOCK DIAGRAM

PIC18F2525/2620/4525/4620

2.7.1 OSCILLA TOR CONTROL REGISTER

The OSCCON register (Register 2-2) controls several aspects of the device clock’s operation, both in full-power operation and in power-managed modes.

The System Clock Select bits, SCS1:SCS0, select the clock source. The available clock sources are the primary clock (defined by the FOSC3:FOSC0 Configuration bits), the secondary clock (Timer1 oscillator) and the internal oscillator block. The clock source changes immediately after one or more of the bits is written to, following a brief clock transition interval. The SCS bits are cleared on all forms of Reset.

The Internal Oscillator Frequency Select bits (IRCF2:IRCF0) select the frequency output of the internal oscillator block to drive the device clock. The choices are the INTRC source, the INTOSC source (8 MHz) or one of the frequencies derived from the INTOSC postscaler (31.25 kHz to 4 MHz). If the internal oscillator block is supplying the device clock, changing the states of these bits will have an immediate change on the internal oscillator’s output. On device Resets, the default output frequency of the internal oscillator block is set at 1 MHz.

When a nominal ou tput frequenc y of 31 kHz is selected (IRCF2:IRCF0 = 000), users may choose which internal oscillator acts as the source. This is done with the INTSRC bit in the OSCTUNE register (OSCTUNE<7>). Setting this bit selects INTOSC as a 31.25 kHz clock source by enabling the divide-by-256 output of the INTOSC postscaler. Clearing INTSRC sel ects INTRC (nominally 31 kHz) as the clock source.

This option allows users to select the tunable and more precise INTOSC as a clock source, while maintaining power savings with a ve ry low clock speed. R egardless of the setting of INTSRC, INTRC always remains the clock source for features such as the Watchdog Timer and the Fail-Safe Clock Monitor.

The OSTS, IOFS and T1RUN bits indicate which cl ock source is currently providing the device clock. The OSTS bit indicates that the Oscillator Start-up Timer (OST) has timed out and the prim ary clock is providing the device clock in primary clock modes. The IOFS bit indicates when the internal oscillator block has stabilized and is providing the device clock in RC Clock modes. The T1RUN bit (T1CON<6>) indicates when the Timer1 oscillator is providing the device clock in secondary clock modes. In power-managed modes, only one of these three bits will be set at any time. If none of these bits are set, the INTRC is providing the clock or the internal o scillator bl ock has just s tarted and is not yet stable.

The IDLEN bit dete rmines if th e dev ice go es in to Slee p mode or one of the Idle modes when the SLEEP instruction is executed.

The use of the flag and control bits in the OSCCON register is discussed in more detail in Section 3.0

“Power-Managed Modes” .

Note 1: The Timer1 oscillator must be enabled to

select the secondary clock source. The Timer1 osc illator is enabled by s etting the T1OSCEN bit in th e T imer1 C ontrol re gister (T1CON<3>). If the Timer1 oscillator is not enabled, then any at tem pt to se lec t a secondary clock source will be ignore d.

2: It is recommended that the Timer1

oscillator be operating and stable before selecting the secondary clock source or a very long delay may occur while the Timer1 oscillator starts.

2.7.2 OSCILLATOR TRANSITIONS

PIC18F2525/2620/4525/4620 devices contain circuitry to prevent clock “glitches” when switching between clock sources. A short p ause in the device cl ock occurs during the clock switch. The length of this pause is the sum of two cycles of the old clock source and three to four cycles of the new clock source. This formula assumes that the new clock source is stable.

Clock transitions are discussed in greater detail in Section 3.1.2 “Entering Power-Managed Modes”.

PIC18F2525/2620/4525/4620

REGISTER 2-2: OSCCON: OSCILLATOR CONTROL REGISTER

R/W-0 R/W-1 R/W-0 R/W-0 R IDLEN IRCF2 IRCF1 IRCF0 OSTS IOFS SCS1 SCS0

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 IDLEN: Idle Enable bit

1 = Device enters Idle mode on SLEEP instruction 0 = Device enters Sleep mode on SLEEP instruction

bit 6-4 IRCF2:IRCF0: Internal Oscillator Frequency Select bits

111 = 8 MHz (INTOSC drives clock directly) 110 = 4 MHz 101 = 2 MHz 100 = 1 MHz 011 = 500 kHz 010 = 250 kHz 001 = 125 kHz 000 = 31 kHz (from either INTOSC/256 or INTRC directly)

bit 3 OSTS: Oscillator Start-up Timer Time-out Status bit

1 = Oscillator Start-up Timer (OST) time-out has expired; primary oscillator is running 0 = Oscillator Start-up Timer (OST) time-out is running; primary oscillator is not ready

bit 2 IOFS: INTOSC Frequency Stable bit

1 = INTOSC frequency is stable 0 = INTOSC frequency is not stable

bit 1-0 SCS1:SCS0: System Clock Select bits

1x = Internal oscillator block 01 = Secondary (Timer1) oscillator 00 = Primary oscillator

(3)

(1)

R-0 R/W-0 R/W-0

(2)

(1)

Note 1: Reset state depends on state of the IESO Configuration bit.

2: Source selected by the INTSRC bit (OSCTUNE<7>), see text. 3: Default output frequency of INTOSC on Reset.

PIC18F2525/2620/4525/4620

2.8 Effects of Power-Managed Modes on the Various Clock Sources

When PRI_IDLE mode is selected, the designated primary oscillator continues to run without interruption. For all other power-managed modes, the oscillator using the OSC1 pin is disabled. The OSC1 pin (and OSC2 pin, if used by the o scillat or) will sto p oscil lating.

In secondary clock modes (SEC_RUN and SEC_IDLE), the Timer1 oscillator is operating and providing the device clock. The Timer1 oscillator may also run in all power-managed modes if required to clock Timer1 or Timer3.

In internal oscillator modes (RC_RUN and RC_IDLE), the internal oscillator block provides the device clock source. The 31kHz INTRC output can be used d irectl y to provide the clock and may be enabled to support various special features, regardless of the powermanaged mode (see Section 23.2 “Watchdog Timer

(WDT)”, Section 23.3 “Two-Speed Start-up” and Section 23.4 “Fail-Safe Clock Monitor” for more

information on WDT, Fail-Safe Clock Monitor and TwoSpeed Start-up). The IN TOSC output at 8 MHz may be used directly to clock the device or may be divided down by the posts caler . The INTO SC output is disable d if the clock is provided directly from the INTRC output.

If the Sleep mode is selected, all clock sources are stopped. Since all the transistor switching currents have been stopped, Sleep mode achieves the lowest current consumption of the device (only leakage currents).

Enabling any on-chip feature that will operate during Sleep will increas e the current cons umed during S leep. The INTRC is required to support WDT operation. The Timer1 oscillator may be operating to support a Real-

Time Clock. Other features may be operating that do not require a device clock source (i.e., MSSP slave, PSP, INTx pins and others). Peripherals that may add significant current consumption are listed in

Section 26.2 “DC Characteristics”.

2.9 Power-up Delays

Power-up delays are controlled by two tim ers, so that no external Reset circuitry is required for most applications. The delays ensure that the device is kept in Reset until the device power supply is stable under normal circumstances and the primary clock is operating and stable. For additional information on power-up delays, see Section 4.5 “Device Reset Timers”.

The first timer is the Power-up Timer (PWRT), which provides a fixed delay on power-up (parameter 33, Table 26-10). It is enabled by clearing (= 0) the PWRTEN

The second timer is the Oscillator Start-up Timer (OST), intended to keep the chip in Reset until the crystal oscillator is stable (LP, XT and HS modes). The OST does this by counting 1024 oscillator cycles before allowing the oscillator to clock the device.

When the HSPLL Oscillator mode is selected, the device is kept in Res et for an add iti onal 2ms, following the HS mode OST delay, so the PLL can lock to the incoming clock frequ enc y.

There is a delay of interval, T Table 26-10), following POR, while the controller becomes ready to execute instruc tions. This delay runs concurrently with any other delays. This may be the only delay that occurs when an y of the EC, RC or INTIO modes are used as the primary clock source.

Configuration bit.

CSD (parameter 38,

TABLE 2-3: OSC1 AND OSC2 PIN STATES IN SLEEP MODE

OSC Mode OSC1 Pin OSC2 Pin

RC, INTIO1 Floating, external resistor should pull high At logic low (clock/4 output) RCIO Floating, external resistor should pull high Configured as PORTA, bit 6 INTIO2 Configured as PORTA, bit 7 Configured as PORTA, bit 6 ECIO Floating, pulled by external clock Configured as PORTA, bit 6 EC Floating, pulled by external clock At logic low (clock/4 output) LP, XT and HS Feedback inverter disabled at quiescent

voltage level

Note: See Table 4-2 in Section 4.0 “Reset” for time-outs due to Sleep and MCLR

Feedback inverter disabled at quiescent voltage level

Reset.

PIC18F2525/2620/4525/4620

NOTES:

PIC18F2525/2620/4525/4620

3.0 POWER-MANAGED MODES

PIC18F2525/2620/4525/4620 devices offer a total of seven operating modes for more efficient power management. These modes provide a variety of options for selective p ower conservation i n applications where resources may be limited (i.e., battery-powered devices).

There are three categories of power-managed modes:

• Run modes

• Idle modes

• Sleep mode

These categories define which portions of the device are clocked and some times , what sp eed. The R un and Idle modes may use any of the three available clock sources (primary, secondary or internal oscillator block); the Sleep mode does not use a clock source.

The power-managed modes include several powersaving features of fered on p reviou s PIC is the clock switching feature, offered in other PIC18 devices, allowing the controller to use the Timer1 oscillator in place of the primary oscillator. Also included is the Sleep mode, offered by all PIC devices, where all device clocks are stopped.

3.1 Selecting Power-Managed Modes

Selecting a power-managed mode requires two decisions: if the CPU is to be clocked or not and the selection of a clock source. The IDLEN bit (OSCCON<7>) controls CPU clocking, while the SCS1:SCS0 bits (OSCCON<1:0>) select the clock source. The individual modes, bit settings, clock sources and affected modules are summarized in Table 3-1.

devices. One

3.1.1 CLOCK SOURCES

The SCS1:SCS0 bits allow the sele ction of one o f three clock sources for power-managed modes. They are:

• the primary clock, as defined by the FOSC3:FOSC0 Configuration bits

• the secondary clock (the Timer1 oscillator)

• the internal oscillator block (for RC modes)

3.1.2 ENTERING POWER-MANAGED

MODES

Switching from one power-managed mode to another begins by loading the OSCCON register. The SCS1:SCS0 bits selec t the clock sourc e and determin e which Run or Idle mode is to be used. Changing these bits causes an immediate switch to the new clock source, assuming that it is running. The switch may also be sub ject to clock tr ansition delays. T hese are discussed in Section 3.1.3 “Clock Transitions and Status Indicators” and subsequent sections.

Entry to the power-managed Idle or Sleep modes is triggered by the execution of a SLEEP instruction. The actual mode that results depends on the status of the IDLEN bit.

Depending on the current mode and the mode being switched to, a change to a power-managed mode does not always require setting all of these bits. Many transitions may be done by changing the oscillator s elect bits, or changing the IDLEN bit, prior to issuing a SLEEP instruction. If the IDLEN bit is already configured correctly, it may only be necessary to perform a SLEEP instruction to switch to the desired mode.

TABLE 3-1: POWER-MANAGED MODES

Mode

Sleep 0 N/A Off Off None – All clocks are disabled PRI_RUN N/A 00 Clocked Clocked Primary – LP, XT, HS, HSPLL, RC, EC and

SEC_RUN N/A 01 Clocked Clocked Secondary – Timer1 Oscillator RC_RUN N/A 1x Clocked Clocked Internal Oscillator Block PRI_IDLE 100Off Clocked Primary – LP, XT, HS, HSPLL, RC, EC SEC_IDLE 101Off Clocked Secondary – Timer1 Oscillator RC_IDLE 11xOff Clocked Internal Oscillator Block

Note 1: IDLEN reflects its value when the SLEEP instruction is executed.

2: Includes INTOSC and INTOSC postscaler, as well as the INTRC source.

OSCCON Bits<7,1:0> Module Clocking

(1)

IDLEN

SCS1:SCS0 CPU Peripherals

Available Clo ck and Os cill ator Source

(2)

Internal Oscillator Block This is the normal full-power execut ion mode.

(2)

PIC18F2525/2620/4525/4620

3.1.3 CLOCK T RANSITIONS AND S TAT US INDICATORS

The length of the transition between clock sources is the sum of two cycles o f the old clo ck so urce an d three to four cycles of the ne w clock source. Thi s formula assumes that the new clock source is stable.

Three bits indicate the current clock source and its status. They are:

• OSTS (OSCCON<3>)

• IOFS (OSCCON<2>)

• T1RUN (T1CON<6>)

In general, only one of these bits will be set while in a given power-managed mode. When the OSTS bit is set, the primary clock is providing the device clock. When the IOFS bit is set, the INTOSC output is providing a stab le, 8 MHz clock source to a divider that actually drives the device clock. When the T1RUN bit is set, the Timer1 oscillator is providing the clock. If none of these bits are set, then either the INTRC clock source is cloc ki ng t he dev ic e, o r th e INTOSC source is not yet stable.

If the internal oscillator block is configured as the primary clock source by the FOSC3:FOSC0 Configuration bits, then both the OSTS and IOFS bits may be set when in PRI_RUN or PRI_IDLE modes. This indicates that the primary clock (INTOSC output) is generating a stable, 8 MHz output. Entering another power-managed RC mode at the same frequency would clear the OSTS bit.

Note 1: Caution should be used when modi fying a

single IRCF bit. I f V possible to select a higher clock speed than is supported by the low VDD. Improper device operation may result if

DD/FOSC specifications are violated.

the V

2: Executing a SLEEP instruction does not

necessarily place the device into Sleep mode. It acts as the trigger to place the controller into either the Sleep mode or one of the Idle modes, depending on the setting of the IDLEN bit.

DD is less than 3V, it is

3.1.4 MULTIPLE SLEEP COMMANDS

The power-managed mode that is invoked with the SLEEP instruction is determined by the setting of the IDLEN bit at the time the instruction is executed. If another SLEEP instruction is executed, the device will enter the power-ma nag ed mo de s pe ci fie d by ID L EN at that time. If IDLEN has changed, the device will enter the new power-managed mode specified by the new setting.

3.2 Run Modes

In the Run modes, clocks to both the core and peripherals are active. The difference between these modes is the clock source.

3.2.1 PRI_RUN MODE

The PRI_RUN mode is the normal, full-power execution mode of the micr ocontroll er . Th is is also t he defau lt mode upon a devi ce Res et unless Two-Speed Start-up is enabled (see Section 23.3 “Two-Speed Start-up” for details). In this m ode, the OSTS bi t is set. Th e IOFS bit may be set if the internal oscillator block is the primary clock source (see Section 2.7.1 “Oscillator Control Register”).

3.2.2 SEC_RUN MODE

The SEC_RUN mode is the compatible mode to the “clock switching” feature offered in other PIC18 devices. In this mode, the CPU and peripherals are clocked from the T imer1 os cillator. This gives users the option of lower power consumption w hile still u sing a high-accuracy clock source.

SEC_RUN mode is entered by setting the SCS1:SCS0 bits to ‘01’. The device clock source is switched to the Timer1 oscillator (see Figure3-1), the primary oscillator is shut down, the T1RUN bit (T1CON<6>) is set and the OSTS bit is cleared.

Note: The Timer1 oscillator should already be

running prior to entering SEC_RU N mode. If the T1OSCEN bit is not set when the SCS1:SCS0 bits are set to ‘01’, entry to SEC_RUN mode will not occur. If the Timer1 oscillator is enabled, but not yet running, devic e cloc ks will be de layed u ntil the oscillator has started. In such situations, initial oscillator operation is far from stable and unpredictable operation may result.

On transitions from SEC_RUN mode to PRI_RUN, the peripherals and CPU continue to be clocked from the Timer1 oscillator while the primary clock is started. When the primary clo ck bec omes r eady, a clock switch back to the primary clock occurs (see Figure 3-2). When the clock switch is complete, the T1RUN bit is cleared, the OSTS bit is set and the primary clock is providing the clock. The IDLEN and SCS bits are not affected by the wake-up; the Timer1 oscillator continues to run.

PIC18F2525/2620/4525/4620

Q4Q3Q2

OSC1

Peripheral

Program

T1OSI

Counter

Clock

CPU

Clock

PC + 2PC

123 n-1n

Clock Transition

(1)

Q4Q3Q2 Q1 Q3Q2

PC + 4

Note 1: Clock transition typically occurs within 2-4 TOSC.

Q1 Q3 Q4

OSC1

Peripheral

Program

T1OSI

PLL Clock

PC + 4

Output

Q3 Q4 Q1

CPU Clock

PC + 2

Clock

Counter

Q2 Q2 Q3

Note 1: TOST = 1024 TOSC; TPLL = 2 ms (approx). These intervals are not shown to scale.

2: Clock transition typically occurs within 2-4 T

OSC.

SCS1:SCS0 bits Changed

TPLL

(1)

12 n-1n

Clock

OSTS bit Set

Transition

(2)

TOST

(1)

FIGURE 3-1: TRANSITION TIMING FOR ENTRY TO SEC_RUN MODE

FIGURE 3-2: TRANSITION TIMING FROM SEC_RUN MODE TO PRI_RUN MODE (HSPLL)

3.2.3 RC_RUN MODE

In RC_RUN mode, the CPU and peripherals are clocked from the internal oscillator block using the INTOSC multiplexer. In this mode, the primary clock is shut down. When using the INTRC source, this mode provides the best power conservation of all the Run modes, while still executing code. It works well for user applications which are not hi ghly timing sensitive or do not require high-speed clocks at all times.

If the primary clock source is the internal oscillator block (either INTRC or INTOSC), there are no distinguishable differences between PRI_RUN and RC_RUN modes during execution. However, a clock switch delay will occur during entry to and exit from RC_RUN mode. Therefore, if the primary clock source is the internal oscillator block, the use of RC_RUN mode is not recommended.

This mode is entered by setting the SCS1 bit to ‘1’. Although it is ignored, it is rec ommended that the SCS0 bit also be cleared; this is to maintain software compatibility with future devices. When the clock source is switched to the INTOSC multiplexer (see Figure 3-3), the primary oscillator is shut down and the OSTS bit is cleared. The IRCF bits may be modified at any time to immediately change the clock speed.

Note: Caution should be used when modifying a

single IRCF bit. If V

DD is less than 3V, it is

possible to select a higher clock speed than is supported by the low V

DD.

Improper device operation may result if the V

DD/FOSC specifications are violated.

PIC18F2525/2620/4525/4620

Q4Q3Q2

OSC1

Peripheral

Program

INTRC

Counter

Clock

CPU

Clock

PC + 2PC

123 n-1n

Clock Transition

(1)

Q4Q3Q2 Q1 Q3Q2

PC + 4

Note 1: Clock transition typically occurs within 2-4 TOSC.

Q3 Q4

OSC1

Peripheral

Program

INTOSC

PLL Clock

PC + 4

Output

CPU Clock

PC + 2

Clock

Counter

Note 1: TOST = 1024 TOSC; TPLL = 2 ms (approx). These intervals are not shown to scale.

2: Clock transition typically occurs within 2-4 TOSC.

SCS1:SCS0 bits Changed

TPLL

(1)

12 n-1n

Clock

OSTS bit Set

Transition

(2)

Multiplexer

TOST

(1)

If the IRCF bits and the INTSRC bit are all clear, the INTOSC output is not enabled and the IOFS bit will remain clear; there will be no indication of the current clock source. The INTRC source is providing the device clocks.

If the IRCF bits are changed from all clear (thus, enabling the INTOSC output), or if INTSRC is set, the IOFS bit becomes set after the INTOSC output becomes stable. Clocks to the device continue while the INTOSC source stabilizes after an interval of

IOBST.

On transitions from RC_RUN mode to PRI_RUN mode, the device continues to be clocked from the INTOSC multiplexer whil e the prim ary clock is st arted. W hen the primary clock becomes ready, a clock switch to the primary clock occurs (see Figure 3-4). When the clock switch is complete, the IOFS bit is cleared, the OSTS bit is set and the primary clock is providing the device clock. The IDLEN and SCS bits are not af fe cte d by the switch. The INTRC source will continue to run if either the WDT or the Fail-Safe Clock Monitor is enabled.

If the IRCF bits w ere prev io us ly at a no n-z ero val ue, or if INTSRC was set before setting SCS1 and the INTOSC source was already stable, the IOFS bi t will remain set.

FIGURE 3-3: TRANSITION TIMING TO RC_RUN MODE

FIGURE 3-4: TRANSITION TIMING FROM RC_RUN MODE TO PRI_RUN MODE

PIC18F2525/2620/4525/4620

Q4Q3Q2

OSC1

Peripheral

Sleep

Program

Q1Q1

Counter

Clock

CPU

Clock

PC + 2PC

Q3 Q4 Q1 Q2

OSC1

Peripheral

Program

PLL Clock

Q3 Q4

Output

CPU Clock

Q1 Q2 Q3 Q4 Q1 Q2

Clock

Counter

PC + 6

PC + 4

Q1 Q2 Q3 Q4

Wake Event

Note 1: T

OST = 1024 TOSC; TPLL = 2 ms (approx). These intervals are not shown to scale.

TOST

(1)

TPLL

(1)

OSTS bit Set

PC + 2

3.3 Sleep Mode

The power-managed Sleep mode in the PIC18F2525/ 2620/4525/4620 devices is identical to the legacy Sleep mode offered in all other PIC devices. It is entered by clearing the IDLEN bit (the default state on device Reset) and executing the SLEEP instruction. This shuts down the selected oscillator (Figure 3-5). All clock source status bits are cleared.

Entering the Sleep m ode from any other mo de does not require a clock switch. This is because no clocks are needed once the controller has entered Sleep. If the WDT is selected, the INTRC source will continue to operate. If the Timer1 oscillator is enabled, it will also continue to run.

When a wake ev ent occurs i n Sleep mo de (by int errupt, Reset or WDT time-out), the device will not be clocked until the clock source selected by the SCS1:SCS0 bits becomes ready (see Figure 3-6), or it will be clocked from the internal osc illator block if e ither the T wo-S peed Start-up or the Fail-Safe Clock Monitor are enabled (see Sec tion 23.0 “Special Features of the CPU”). In either case, the OS TS bit i s set wh en the p rimary cloc k is providing the device cl ocks. The IDLEN and SCS bit s are not affected by the w ake-up.

3.4 Idle Modes

The Idle modes allow the controller’s CPU to be selectively shut down while the peripherals continue to operate. Selecting a particular Idle mode allows users to further manage power consumption.

If the IDLEN bit i s set to a ‘1’ when a SLEEP inst ruction is executed, the periph erals will be cloc ked fro m the cloc k source selected us ing the SCS1:SCS 0 bits; howev er , the CPU will not be clocked. The clock source status bits are not affected. Setting IDLEN and executing a SLEEP instruction pr ovides a quick method of switchi ng from a given Run mo de to its correspon ding Idle mode.

If the WDT is selected, the INTRC source will continue to operate. If the T imer1 oscill ator is enable d, it will also continue to run.

Since the CPU is not executing instructions, the only exits from any of the Idle modes are by interrupt, WDT time-out or a Reset. When a wa ke even t occur s, CPU execution is delayed by an interval of T (parameter 38, Table 26-10) while it becomes ready to execute code. When the CPU begins executing code, it resumes with the same clock source for the current Idle mode. For example, when waking from RC_IDLE mode, the internal oscillator block will clock the CPU and peripherals (in other words, RC_RUN mode). The IDLEN and SCS bits are not affected by the wake-up.

While in any Idle mode or Sl eep mode, a WD T timeout will result in a WDT wake-up to the Run mode currently specified by the SCS1:SCS0 bits.

CSD

FIGURE 3-5: TRANSITION TIMING FOR ENTRY TO SLEEP MODE

FIGURE 3-6: TRANSITION TIMING FOR WAKE FROM SLEEP (HSPLL)

PIC18F2525/2620/4525/4620

Peripheral

Program

PC PC + 2

OSC1

CPU Clock

Clock

Counter

OSC1

Peripheral

Program

CPU Clock

Q1 Q3 Q4

Clock

Counter

Wake Event

TCSD

3.4.1 PRI_IDLE MODE

This mode is uni que among the thre e low-power Idle modes, in that it does not disable the primary device clock. For timing sensitive applications, this allows for the fastest resump tion of devic e operation w ith its mo re accurate pri mary clock source, si nce the cl ock source does not have to “warm-up” or transition from another oscillator.

PRI_IDLE mode is entered from PRI_RUN mode by setting the IDLEN bit and executing a SLEEP instruction. If the device is in another Run mode, set IDLEN first, then clear the SCS bits and execute SLEEP. Although the CPU i s disab led, th e peri pherals cont inue to be clocked from the primary clock source specified by the FOSC3:FOSC0 Configuration bits. The OSTS bit remains set (see Figure3-7).

When a wake event occurs, the CPU is clocked from the primary clock source. A delay of interval T

CSD is

required between the wake event and when code execution starts. This is required to allo w the CPU to become ready to execut e instructions. After the wakeup, the OSTS bit remains set. The IDLEN and SCS bits are not affected by the wake-up (see Figure 3-8).

3.4.2 SEC_ID LE MO DE

In SEC_IDLE mode, the CPU is disabled but the peripherals continue to be clocked from the Timer1 oscillator. This mode is entered from SEC_RUN by

setting the IDLEN bit and executing a SLEEP instruction. If the device is in another Run mode, set the IDLEN bit first, then set the SCS1:SCS0 bits to ‘01’ and execute SLEEP. When the clock source is switched to the Timer1 oscillator, the primary oscillator is shut down, the OSTS bit is cleared and the T1RUN bit is set.

When a wake event occurs, the peripherals continue to be clocked from the Timer1 oscillator. After an interval

CSD following the wake event, the CPU b egins exe-

of T cuting code being cloc ked by the T im er1 oscil lator . Th e IDLEN and SCS bits are not affected by the wake-up; the Timer1 oscillator continues to run (see Figure3-8).

Note: The Timer1 oscillator should already be

running prior to entering SEC_IDLE mod e. If the T1OSCEN bit is not set when the SLEEP instruction is executed, the SLEEP instruction will be ignored and entry to SEC_IDLE mode will not occur. If the Timer1 oscillator is enabled but not yet running, peripheral clocks will be delayed until the oscillator has started. In such situations, initial oscillator operation is far from stable and unpredictable operation may result.

FIGURE 3-7: TRANSITION TIMING FOR ENTRY TO IDLE MODE

FIGURE 3-8: TRANSITION TIMING FOR WAKE FROM IDLE TO RUN MODE

PIC18F2525/2620/4525/4620

3.4.3 RC_IDLE MODE

In RC_IDLE mode, t he C PU is d is abl ed but th e p erip herals continue to b e c loc ke d fro m the internal oscilla t or block using the INTOSC multiplexer. This mode allows for controllable power cons ervation during Idl e periods .

From RC_RUN, this mode is entered by setting the IDLEN bit and executing a SLEEP instruction. If the device is in a nother Run mode, first s et IDLEN, th en set the SCS1 bit and execute SLEEP. Although its value is ignored, it is reco mmended that SCS0 also be cle ared; this is to maintain software compatibility with future devices. The INTOSC multiplexer may be used to select a higher clock frequency by modifying the IRCF bits before exec uti ng th e SLEEP instruction. When the clock source is switched to the INTOSC mult iplexer , the primary oscillator is shut down and the OSTS bit is cleared.

If the IRCF bits are set to any non-zero value, or the INTSRC bit is set, the INTOSC output is enabled. The IOFS bit becomes set, after the INTOSC output becomes stable, after an interval of T (parameter 39, Table 26-10). Clocks to the peripherals continue while the INTOSC source stabilizes. If the IRCF bits were previously at a non-zero value, or INTSRC was set before the SLEEP instruction was executed and the INTOSC source was already stable, the IOFS bit will remain set. If the IRCF bits and INTSRC are all clear, the INTOSC output will not be enabled, the IOF S bit will remain c lear and t here will b e no indication of the current clock source.

When a wake event occurs, the peripherals continue to be clocked from the INTOSC multiplexer . After a delay of

CSD following the wake event, the CPU begins execut-

T ing code being clocked by the INTOSC multiplexer. The IDLEN and SCS bits are not affected by the wake-up. The INTRC source will continue to run if either the WDT or the Fail-Safe Clock Monitor is enabled.

IOBST

3.5 Exiting Idle and Sleep Modes

An exit from Sleep mode or any of the Idle modes is triggered b y an interrupt , a Reset or a WDT time-out. This section discusses the triggers that cause exits from power-managed modes. The clocking subsystem actions are discussed in each of the power-managed modes (see Section 3.2 “Run Modes”, Section 3.3 “Sleep Mode” and Section 3.4 “Idle Modes”).

3.5.1 EXIT BY INTERRUPT

Any of the available interrupt sources can cause the device to exit from an Idle mode or Sleep mode to a Run mode. To enable this functionality, an interrupt source must be enab led by s etti ng i t s en able bit in one of the INTCON or PIE registers. The exit sequence is initiated when the c orresponding interrupt flag bit is set.

On all exits fr om Idl e or Slee p mod es b y int erru pt, code execution branches to the interrupt vector if the GIE/ GIEH bit (INTC ON<7>) is set. Otherwise, code execut ion continues or resumes without branching (see Section 10.0 “Interrupts”).

A fixed delay of inter val T is required when leaving Sleep and Idle modes. This delay is required for the CPU to prepare for execution. Instructio n execution r esumes on th e first clock c ycle following this delay.

CSD following th e wake event

3.5.2 EXIT BY WDT TIME-OUT

A WDT time-out will cause different actions depending on which power-managed mode the device is in when the time-out occurs.

If the device i s not exec uti ng code (al l Idle mode s and Sleep mode), the time-out will res ul t in a n ex it fro m th e power-managed mode (see Section 3.2 “Run Modes” and Section 3.3 “Sleep Mode”). If the device is executing code (all Run modes), the time-out will result in a WDT Reset (see Section 23.2 “Watchdog Timer (WDT)”).

The WDT timer and postscaler are cleared by executing a SLEEP or CLRWDT ins tru ction, the loss of a currently selected clock source (if the Fail-Safe Clock Monitor is enabled) and modifying the IRCF bits in the OSCCON register if the internal oscillator block is the device clock source.

3.5.3 EXIT BY RESET

Normally, the device is held in Reset by the Oscillator Start-up Timer (OST) until the primary clock becomes ready. At that time, the OSTS bit is set and the device begins executing code. If the internal osc il lat or bl oc k i s the new clock source, the IOFS bit is set instead.

The exit delay time from Reset to the start of code execution depends on both the clock sources before and after the wake-up and the type of oscillator if the new clock source is the primary clock. Exit delays are summarized in Table 3-2.

Code execution can begin before the primary clock becomes ready. If either the Two-Speed Start-up (see Section 23.3 “Two-Speed Start-up”) or Fail-Safe Clock Monitor (see Section 23.4 “Fail-Safe Clock Monitor”) is enabled, the device may begin execution as soon as the Reset source ha s cle are d. Execution is clocked by the INTOSC multiplexer driven by the internal oscillator block. Execution is clocked by the internal oscillator block until either the primary clock becomes ready or a power-managed mode is entered before the primary clock becomes ready; the primary clock is then shut down.

PIC18F2525/2620/4525/4620

3.5.4 EXIT WITHOUT AN OSCILLATOR START-UP DELAY

Certain exits from power-managed modes do not invoke the OST at all. There are two cases:

• PRI_IDLE mode, where the primary clock source

is not stopped; and

• the primary clock source is not any of the LP, XT,

HS or HSPLL modes.

In these instances, the primary clock source either does not require an oscillator start-up delay since it is already running (PRI_IDLE), or normally does not require an oscillator start-up delay (RC, EC and INTIO Oscillator modes). However, a fixed delay of interval

CSD following the wake event is still required when

T leaving Sleep and Idle modes to allow the CPU to prepare for execution. Instruction execution resumes on the first clock cycle following this delay.

TABLE 3-2: EXIT DELAY ON WAKE-UP BY RESET FROM SLEEP MODE OR ANY IDLE MODE

(BY CLOCK SOURCES)

Clock Source

Before Wake-up

Primary Device Clo ck

(PRI_IDLE mode)

T1OSC

INTOSC

(Sleep mode)

Note 1: TCSD (p arame ter 38 ) is a requir ed delay w hen wa king from Sl eep an d all Idle modes and runs c oncurr ently

with any other required delays (see Section 3.4 “Idle Modes”). On Reset, INTOSC defaults to 1 MHz.

2: Includes both the INTOSC 8 MHz source and postscaler derived frequencies. 3: T

also designated as T

4: Execution continues during T

(3)

None

OST is the Oscillator Start-up Timer (parameter 32). t

PLL.

Clock Source

After Wake-up

Exit Delay

LP, XT, HS

(1)

EC, RC

INTOSC

(2)

LP, XT, HS TOST

EC, RC TCSD

INTOSC

(2)

LP, XT, HS TOST

EC, RC TCSD

INTOSC

(2)

LP, XT, HS TOST

EC, RC TCSD

INTOSC

IOBST (parameter 39), the INTOSC stabilization period.

(2)

is the PLL Lock-out Timer (p aram eter F12); it is

CSD

(3)

(1)

(4)

TIOBST

(3)

(1)

None IOFS

(3)

(1)

(4)

TIOBST

Clock Ready Status

Bit (OSCCON)

OSTSHSPLL

IOFS

OSTSHSPLL TOST + t

IOFS

OSTSHSPLL TOST + t

IOFS

PIC18F2525/2620/4525/4620

External Reset

MCLR

VDD

OSC1

WDT

Time-out

DD Rise

Detect

OST/PWRT

INTRC

(1)

POR Pulse

OST

10-bit Ripple Counter

PWRT

11-bit Ripple Counter

Enable OST

(2)

Enable PWRT

Note 1: This is the INTRC source from the internal oscillator block and is separate from the RC oscillator of the CLKI pin.

2: See Table 4-2 for time-out situations.

Brown-out

Reset

BOREN

RESET

Instruction

Stack

Pointer

Stack Full/Underflow Reset

Sleep

( )_IDLE

1024 Cycles

65.5 ms

32 μs

MCLRE

Chip_Reset

4.0 RESET

A simplified block di agram of the On-Chip Reset Circu it is shown in Figure 4-1.

The PIC18F2525/2620/4525/4620 devices differentiate between various kinds of Reset:

a) Power-on Reset (POR) b) MCLR

Reset during normal operation c) MCLR Reset during power-managed modes d) Watchdog Timer (WDT) Reset (during

execution) e) Programmable Brown-out Reset (BOR) f) RESET Instruction g) Stack Full Reset h) Stack Underflow Reset

This section discusses Resets generated by MCLR POR and BOR and covers the ope rati on o f the various start-up timers. Stack Reset events are covered in Section 5.1.2.4 “Stack Full and Underflow Resets”. WDT Resets are co v ere d i n Section 23.2 “Watchdog

4.1 RCON Register

Device Reset events are tracked through the RCON register (Register 4-1). The lower five bits of the register indicate that a specif ic Reset eve nt has occu rred. In most cases, thes e bits c an only be cl eared by the e vent and must be set by the ap pli ca tio n af ter the event. The state of these flag bits, taken together, can be read to indicate the type of Reset that just occurred. This is described in more detail in Section 4. 6 “Reset State of Registers”.

The RCON register also has control bits for setting interrupt priority (IPEN) and software control of the BOR (SBOREN). Interrupt priority is discussed in

Section 10.0 “Interrupts”. BOR is covered in Section 4.4 “Brown-out Reset (BOR)”.

Timer (WDT)”.

FIGURE 4-1: SIMPLIFIED BLOCK DIAGRAM OF ON-CHIP RESET CIRCUIT

PIC18F2525/2620/4525/4620

REGISTER 4-1: RCON: RESET CONTROL REGISTER

R/W-0 R/W-1

IPEN SBOREN

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 IPEN: Interrupt Priority Enable bit

1 = Enable priority levels on interrupts 0 = Disable priority levels on interrupts (PIC16CXXX Compatibility mode)

bit 6 SBOREN: BOR Software Enable bit

If BOREN1:BOREN0 =

1 = BOR is enabled 0 = BOR is disabled

If BOREN1:BOREN0 =

Bit is disabled and read as ‘0’. bit 5 Unimplemented: Read as ‘0’ bit 4 RI: RESET Instruction Flag bit

1 = The RESET instruction was not executed (set by firmware only)

0 = The RESET instruction was executed causing a device Reset (must be set in software after a

bit 3 TO: Watchdog Time-out Flag bit

1 = Set by power-up, CLRWDT instruction or SLEEP instruction

0 = A WDT time-out occurred

bit 2 PD

1 = Set by power-up or by the CLRWDT instruction

0 = Set by execution of the SLEEP instruction

bit 1 POR

1 = A Power-on Reset has not occurred (set by firmware only)

0 = A Power-on Reset occurred (must be set in software after a Power-on Reset occurs)

bit 0 BOR

1 = A Brown-out Reset has not occurred (set by firmware only)

0 = A Brown-out Reset occurred (must be set in software after a Brown-out Reset occurs)

(1)

Brown-out Reset occurs)

: Power-Down Detection Flag bit

: Power-on Reset Status bit

: Brown-out Reset Status bit

U-0 R/W-1 R-1 R-1 R/W-0

—RITO PD POR BOR

01:

00, 10 or 11:

(1)

(2)

R/W-0

Note 1: If SBOREN is enabled, its Reset state is ‘1’; otherwise, it is ‘0’.

2: The actual Reset value of POR

Note 1: It is recommended that the POR bit be se t af te r a Pow er-o n Res et ha s been detected so that sub seq ue nt

Power-on Resets may be detected.

2: Brown-out Reset is sa id to have occurred when BOR

‘1’ by software immediately after Power-on Reset).

is determined by the type of device Reset. See the notes following this

is ‘0’ and POR is ‘1’ (assuming that POR was set to

PIC18F2525/2620/4525/4620

Note 1: External Power-on Reset circuit is r equired

only if the V

DD power-up slope is too slow.

The diode D helps discharge the capacitor quickly when V

DD powers down.

2: R < 40 kΩ is recommended to make sure that

the voltage drop across R does not violate the device’s electrical specification.

3: R1 ≥ 1 kΩ will limit any current flowing into

MCLR

from external capacitor C, in the event

of MCLR

/VPP pin breakdown, due to Electrostatic Discharge (ESD) or Electrical Overstress (EOS).

MCLR

PIC18FXXXX

VDD

4.2 Master Clear (MCLR)

The MCLR pin provides a method for triggering an external Reset of the device. A Reset is generated by holding the pin low. Thes e device s have a no ise filter i n the MCLR

Reset path which detects and ignores small

pulses. The MCLR

pin is not drive n low by any inter nal Reset s,

including the WDT. In PIC18F2525/2620/4525/4620 devices, the MCLR

input can be disabled with the MCLRE Configuration bit. When MCLR

is disabled, the pin becomes a digital

input. See Section 9.5 “PORTE, TRISE and LATE

Registers” for more information.

4.3 Power-on Reset (POR)

A Power-on Reset pulse is generated on-chip whenever V allows the device to start in the initialized state when VDD is adequate for operation.

To take advantage of the POR circuitry, tie the MCLR pin throug h a resis tor (1 k Ω to 10 kΩ) to VDD. This wi ll eliminate external RC components usually needed to create a Power-on Re set delay. A minimum rise rate for

DD is specified (parameter D004). For a slow rise

V time, see Figure 4-2.

When the device st arts normal operati on (i.e ., ex its the Reset condition), device operating parameters (voltage, frequency, temperature, etc.) must be met to ensure operation. If these conditions are not met, the device must be held in Reset until the operating conditions are met.

POR events are captured by the POR The state of the bit is set to ‘0’ whe never a POR occurs; it does not change for any other Reset event. POR is not reset to ‘1’ by any hardware event. To capture multiple events, the user manually resets the bit to ‘1’ in software following any POR.

DD rises above a certain threshold. This

bit (RCON<1>).

FIGURE 4-2: EXTERNAL POWER-ON

RESET CIRCUIT (FOR SLOW V

DD POWER-UP)

PIC18F2525/2620/4525/4620

4.4 Brown-out Reset (BOR)

PIC18F2525/2620/4525/4620 devices implement a BOR circuit that provides the user with a number of configuration and power-saving options. The BOR is controlled by the BORV1:BORV0 and BOREN1:BOREN0 Configuration bits. There a re a total of four BOR configurations which are summarized in Table 4-1.

The BOR threshold is set by t he BOR V1:BOR V0 bit s. If BOR is enabled (any values of BOREN1:BOREN0, except ‘00’), any drop of V D005) for greater than T the device. A Reset may or may not occur if V below V Brown-out Reset until V

If the Power-up T imer is enab led, it will be inv oked after V Reset for an additional time delay, T (parameter 33). If VDD drops below VBOR while the Power-up Timer is running, the chip will go back into a Brown-out Reset and the Power-up Timer will be initialized. Once V Timer will execute the additional time delay.

BOR and the Power-on Timer (PWRT) are independently configured. Enabling BOR Reset does not automat ically enable the PWRT.

BOR for less than TBOR. The chip will remain in

DD rises above VBOR; it then will keep the chip in

DD rises above VBOR, the Power-up

4.4.1 SOFTWARE ENABLED BOR

When BOREN1:BOREN0 = 01, the BOR can be enabled or disabled by the user in software. This is done with the control bit, SBOREN (RCON<6>). Setting SBOREN enables the BOR to function as previously described. Clearing SBOREN disables the BOR entirely. The SBOREN bit operates only in this mode; otherwise it is read as ‘0’.

DD below VBOR (parameter

BOR (parameter 35 ) will reset

DD falls

DD rises above VBOR.

PWRT

Placing the BOR under software control gives the user the additional flexibility of tailoring the application to its environment withou t ha vi ng to reprogram the devi ce to change BOR configuration. It also allows the user to tailor device power consumption in software by eliminating the incremental current that the BOR consumes. While the BOR current is typically very small, it may have some impact in low-power applications.

Note: Even when BOR is under softw are control,

the BOR Reset voltage level is still set by the BORV1:BORV0 Configuration bits. It cannot be changed in software.

4.4.2 DETECTING BOR

When BOR is enab led, the BO R bit always resets to ‘0’ on any BOR or P OR event. This makes it d ifficult to determine if a BOR event has occurre d jus t by reading the state of BOR simultaneously check the state of both POR This assumes that th e POR immediately after any POR event. If BOR POR

is ‘1’, it can be reliably assum ed that a BOR event

has occurred.

alone. A more reliable method is to

and BOR.

bit is reset to ‘1’ in s oftware

is ‘0’ while

4.4.3 DISABLING BOR IN SLEEP MODE

When BOREN1:BOREN0 = 10, the BOR remains under hardware control and operates as previously described. Whenever the device enters Sleep mode, however , the BOR is au tom ati ca lly dis abl ed . When the device returns to any other operating mode, BOR is automatically re-enabled.

This mode allows for applications to recover from brown-out situations, while actively executing code, when the device requires BOR protection the most. At the same time, it save s additional po wer in Sleep mod e by eliminating the small incremental BOR current.

TABLE 4-1: BOR CONFIGURATIONS

BOR Configuration Status of

BOREN1 BOREN0

00Unavailable BOR disabled; must be enabled by reprogramming the Configuration bits. 01Available BOR enabled in software; operation controlled by SBOREN. 10Unavailable BOR enabled in hardware in Run and Idle modes, disabled during

11Unavailable BOR enabled in hardware; must be disabled by reprogramming the

SBOREN

(RCON<6>)

Sleep mode.

Configuration bit s.

BOR Operation

PIC18F2525/2620/4525/4620

4.5 Device Reset Timers

PIC18F2525/2620/4525/4620 devices incorporate three separate on-chip timers that help regulate the Power-on Reset process. Their main function is to ensure that the device clock is stable before code is executed. These timers are:

• Power-up Timer (PWRT)

• Oscillator Start-up Timer (OST)

• PLL Lock Time -out

4.5.1 POWER-UP TIMER (PWRT)

The Power-up Timer (PWRT) of PIC18F2525/2620 / 4525/4620 devices is an 11-bit counter which uses the INTRC source as the clock input. This yields an approximate time interval of 2048 x 32 μs=65.6ms. While the PWRT is counting, the device is held in Reset.

The power-up time delay depe nd s on the INTRC cl oc k and will vary from chip to chip due to temperature and process variation. See DC parameter 33 for details.

The PWRT is enabled by clearing the PWRTEN Configuration bit.

4.5.2 OSCILLA TOR START-UP TIMER (OST)

The Oscillator Start-up Timer (OST) provides a 1024 oscillator cycle (from OSC1 input) delay after the PWRT delay is ov er (par a me t er 3 3 ). T h is en su re s t ha t the crystal oscillator or resonator has started and stabilized.

The OST time-out is invoked only for XT, LP, HS and HSPLL modes and only on Power-on Reset, or on exit from most power-managed modes.

4.5.3 PLL LOCK TIME-OUT

With the PLL enabled in its PLL mode, the time-out sequence following a Power-on Reset is slightly different from other oscillator modes. A separate timer is used to provide a fixed time-out tha t i s su f f i cient for the PLL to lock to the main oscillator frequency. This PLL lock time-o ut (T oscillator start-up time-out.

PLL) is typically 2 ms and follows the

4.5.4 TIME-OUT SEQUENCE

On power-up, the time-out sequence is as follows:

1. After the POR pulse has cleared, PWRT time-out is invoked (if enabled).

2. Then, the OST is activated.

The total time-out will vary based on oscillator configuration and the status of the PWRT. Figure 4-3, Figure 4-4, Figure 4-5, Figure 4-6 and Figure 4-7 all depict time-out sequences on power-up, with the Power-up Timer enabled and the device operating in HS Oscillator mode. Figures 4-3 through 4-6 also apply to devices operating in XT or LP modes. For devices in RC mode and with the PWRT di sabled, ther e will be no time-out at all.

Since the time-outs occur from the POR pulse, if MC LR is kept low long e nough, all ti me -out s will e xpire. Brin ging MCLR (Figure 4-5). This is useful for testing purposes or to synchronize more than one PIC18FXXXX device operating in parallel.

high will begin execution immediately

TABLE 4-2: TIME-OUT IN VARIOUS SITUATIONS

(1) (1) (1)

(2)

and Brown-out Reset

(2)

1024 TOSC + 2 ms

Exit from

Power-Managed Mode

(2)

—— —— ——

1024 TOSC + 2 ms

(2)

Oscillator

Configuration

HSPLL 66 ms HS, XT, LP 66 ms EC, ECIO 66 ms RC, RCIO 66 ms INTIO1, INTIO2 66 ms

Note 1: 66 ms (65.5 ms) is the nominal Power-up Timer (PWRT) delay.

2: 2 ms is the nominal time required for the PLL to lock.

(1)

Power-up

PWRTEN = 0 PWRTEN = 1

+ 1024 TOSC + 2 ms

(1)

+ 1024 TOSC 1024 TOSC 1024 TOSC

PIC18F2525/2620/4525/4620

TPWRT

TOST

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

TPWRT

TOST

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

TPWRT

TOST

FIGURE 4-3: TIME-OUT SEQUENCE ON POWER-UP (MCLR TIED TO VDD, VDD RISE < TPWRT)

FIGURE 4-4: TIME-OUT SEQUENCE ON POWER-UP (MCLR

FIGURE 4-5: TIME-OUT SEQUENCE ON POWER-UP (MCLR

NOT TIED TO VDD): CASE 1

NOT TIED TO VDD): CASE 2

PIC18F2525/2620/4525/4620

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

PWRT

TOST

TPWRT

TOST

VDD

MCLR

INTERNAL POR

PWRT TIME-OUT

OST TIME-OUT

INTERNAL RESET

PLL TIME-OUT

TPLL

Note: TOST = 1024 clock cycles.

PLL ≈ 2 ms max. First three stages of the PWRT timer.

FIGURE 4-6: SLOW RISE TIME (MCLR TIED TO VDD, VDD RISE > TPWRT)

FIGURE 4-7: TIME-OUT SEQUENCE ON POR W/PLL ENABLED (MCLR

TIED TO VDD)

PIC18F2525/2620/4525/4620

4.6 Reset State of Registers

Most registers are unaffected by a Reset. Their status is unknown on POR and unchanged by all other

Table 4-4 describes the Reset states for all of the Special Function Registers. These are categorized by Power-on and Brown-out Resets, Master Clear and WDT Resets and WDT wake-ups.

Resets. The other registers are forced to a “Reset state” depending on the type of Reset that occurred.

Most registers are not affected by a WDT wake-up, since this is viewed as the resumption of normal operation. Status bits from the RCON register, RI POR

and BOR, are set or cleare d dif ferently i n dif ferent

, TO, PD,

Reset situations, as indicated in Table4-3. These bits are used in software to determine the nature of the Reset.

TABLE 4-3: STATUS BITS, THEIR SIGNIFICANCE AND THE INITIALIZATION CONDITION

FOR RCON REGISTER

Condition

Program

Counter

SBOREN RI TO PD POR BOR STKFUL STKUNF

Power-on Reset 0000h 1 11100 0 0 RESET Instruction 0000h u

Brown-out Reset 0000h u

during power-managed

MCLR

0000h u

(2) (2) (2)

Run Modes MCLR during power-managed

0000h u

(2)

Idle modes and Sleep mode WDT time-out during full power

0000h u

(2)

or power-managed Run mode MCLR during full-power

0000h u

(2)

execution Stack Full Reset (STVREN = 1) 0000h u Stack Underflow Reset

0000h u

(2) (2)

(STVREN = 1) Stack Underflow Error (not an

0000h u

(2)

actual Reset, STVREN = 0) WDT time-out during

PC + 2 u

(2)

power-managed Idle or Sleep modes

Interrupt exit from

PC + 2

(1)

(2)

power-managed modes

Legend: u = unchanged Note 1: When the wake-up is due to an interrupt and the GIEH or GIEL bits are set, the PC is loaded with the

interrupt vector (008h or 0018h).

2: Reset state is ‘1’ for POR and unchanged for all other Resets when software BOR is enabled

(BOREN1:BOREN0 Configuration bits = 01 and SBOREN = 1); otherwise, the Reset state is ‘0’.

RCON Register STKPTR Register

0uuuu u u 111u0 u u u1uuu u u

u10uu u u

u0uuu u u

uuuuu u u

uuuuu 1 u uuuuu u 1

uuuuu u 1

u00uu u u

uu0uu u u

PIC18F2525/2620/4525/4620

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS

Resets,

MCLR

Power-on Reset,

Brown-out Reset

TOSU 2525 2620 4525 4620 ---0 0000 ---0 0000 ---0 uuuu TOSH 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu TOSL 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu STKPTR 2525 2620 4525 4620 00-0 0000 uu-0 0000 uu-u uuuu PCLATU 2525 2620 4525 4620 ---0 0000 ---0 0000 ---u uuuu PCLATH 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu PCL 2525 2620 4525 4620 0000 0000 0000 0000 PC + 2 TBLPTRU 2525 2620 4525 4620 --00 0000 --00 0000 --uu uuuu TBLPTRH 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu TBLPTRL 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu TABLAT 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu PRODH 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu PRODL 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu INTCON 2525 2620 4525 4620 0000 000x 0000 000u uuuu uuuu INTCON2 2525 2620 4525 4620 1111 -1-1 1111 -1-1 uuuu -u-u INTCON3 2525 2620 4525 4620 11-0 0-00 11-0 0-00 uu-u u-uu INDF0 2525 2620 4525 4620 N/A N/A N/A POSTINC0 2525 2620 4525 4620 N/A N/A N/A POSTDEC0 2525 2620 4525 4620 N/A N/A N/A PREINC0 2525 2620 4525 4620 N/A N/A N/A PLUSW0 2525 2620 4525 4620 N/A N/A N/A FSR0H 2525 2620 4525 4620 ---- 0000 ---- 0000 ---- uuuu FSR0L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu WREG 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu INDF1 2525 2620 4525 4620 N/A N/A N/A POSTINC1 2525 2620 4525 4620 N/A N/A N/A POSTDEC1 2525 2620 4525 4620 N/A N/A N/A PREINC1 2525 2620 4525 4620 N/A N/A N/A PLUSW1 2525 2620 4525 4620 N/A N/A N/A Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Shaded cells indicate conditions do not apply for the designated dev ic e.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-u p is due to an in terrupt and the GIEL or GIEH bi t is set, the PC is loaded wit h the interrup t

vector (0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are

updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LATA and TRISA are enabled, depending on the oscillator mode selected. When

not enabled as PORTA pins, they are disabled and read ‘0’.

WDT Reset,

RESET Instruction,

Stack Resets

Wake-up via WDT

or Interrupt

(3) (3) (3) (3)

(2)

(1) (1) (1)

PIC18F2525/2620/4525/4620

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

Resets,

MCLR

FSR1H 2525 2620 4525 4620 ---- 0000 ---- 0000 ---- uuuu FSR1L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu BSR 2525 2620 4525 4620 ---- 0000 ---- 0000 ---- uuuu INDF2 2525 2620 4525 4620 N/A N/A N/A POSTINC2 2525 2620 4525 4620 N/A N/A N/A POSTDEC2 2525 2620 4525 4620 N/A N/A N/A PREINC2 2525 2620 4525 4620 N/A N/A N/A PLUSW2 2525 2620 4525 4620 N/A N/A N/A FSR2H 2525 2620 4525 4620 ---- 0000 ---- 0000 ---- uuuu FSR2L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu STATUS 2525 2620 4525 4620 ---x xxxx ---u uuuu ---u uuuu TMR0H 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu TMR0L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu T0CON 2525 2620 4525 4620 1111 1111 1111 1111 uuuu uuuu OSCCON 2525 2620 4525 4620 0100 q000 0100 q000 uuuu uuqu HLVDCON 2525 2620 4525 4620 0-00 0101 0-00 0101 u-uu uuuu WDTCON 2525 2620 4525 4620 ---- ---0 ---- ---0 ---- ---u

(4)

RCON TMR1H 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu TMR1L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu T1CON 2525 2620 4525 4620 0000 0000 u0uu uuuu uuuu uuuu TMR2 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu PR2 2525 2620 4525 4620 1111 1111 uuuu uuuu uuuu uuuu T2CON 2525 2620 4525 4620 -000 0000 -000 0000 -uuu uuuu SSPBUF 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu SSPADD 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu SSPSTAT 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu SSPCON1 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu SSPCON2 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-u p is due to a n interrupt an d the GIEL or GIEH bit is set, the PC is loaded w ith the inte rrupt

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LATA and TRISA are enabled, depending on the oscillator mode selected. When

2525 2620 4525 4620 0q-1 11q0 0q-q qquu uq-u qquu

Shaded cells indicate conditions do not apply for the designated dev ic e.

vector (0008h or 0018h).

updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

not enabled as PORTA pins, they are disabled and read ‘0’.

Power-on Reset,

Brown-out Reset

WDT Reset,

RESET Instruction,

Stack Rese ts

Wake-up via WDT

or Interrupt

PIC18F2525/2620/4525/4620

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

Resets,

MCLR

ADRESH 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu ADRESL 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu ADCON0 2525 2620 4525 4620 --00 0000 --00 0000 --uu uuuu ADCON1 2525 2620 4525 4620 --00 0qqq --00 0qqq --uu uuuu ADCON2 2525 CCPR1H 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu CCPR1L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu CCP1CON

CCPR2H 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu CCPR2L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu CCP2CON 2525 2620 4525 4620 --00 0000 --00 0000 --uu uuuu BAUDCON 2525 2620 4525 4620 0100 0-00 0100 0-00 uuuu u-uu PWM1CON 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu ECCP1AS

CVRCON 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu CMCON 2525 2620 4525 4620 0000 0111 0000 0111 uuuu uuuu TMR3H 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu TMR3L 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu T3CON 2525 2620 4525 4620 0000 0000 uuuu uuuu uuuu uuuu SPBRGH 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu SPBRG 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu RCREG 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu TXREG 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu TXSTA 2525 2620 4525 4620 0000 0010 0000 0010 uuuu uuuu RCSTA 2525 2620 4525 4620 0000 000x 0000 000x uuuu uuuu EEADRH 2585 2680 4585 4680 ---- --00 ---- --00 ---- --uu EEADR 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu EEDATA 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu EECON2 2525 2620 4525 4620 0000 0000 0000 0000 0000 0000 EECON1 2525 2620 4525 4620 xx-0 x000 uu-0 u000 uu-0 u000 Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Shaded cells indicate conditions do not apply for the designated dev ic e.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-u p is due to an in terrupt and the GIEL or GIEH bi t is set, the PC is loaded wit h the interrup t

vector (0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are

updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LATA and TRISA are enabled, depending on the oscillator mode selected. When

not enabled as PORTA pins, they are disabled and read ‘0’.

2620 4525 4620 0-00 0000 0-00 0000 u-uu uuuu

2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu 2525 2620

2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu 2525 2620 4525 4620 0000 00-- 0000 00-- uuuu uu--

4525 4620 --00 0000 --00 0000 --uu uuuu

Power-on Reset,

Brown-out Reset

WDT Reset,

RESET Instruction,

Stack Resets

Wake-up via WDT

or Interrupt

PIC18F2525/2620/4525/4620

TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED)

Resets,

MCLR

Power-on Reset,

Brown-out Reset

IPR2 2525 2620 4525 4620 11-1 1111 11-1 1111 uu-u uuuu PIR2 2525 2620 4525 4620 00-0 0000 00-0 0000 uu-u uuuu PIE2 2525 2620 4525 4620 00-0 0000 00-0 0000 uu-u uuuu IPR1 2525 2620 4525 4620 1111 1111 1111 1111 uuuu uuuu

2525 2620 4525 4620 -111 1111 -111 1111 -uuu uuuu

PIR1

2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu 2525 2620 4525 4620 -000 0000 -000 0000 -uuu uuuu

PIE1 2525 2620 4525 4620 0000 0000 0000 0000 uuuu uuuu

2525 2620

4525 4620 -000 0000 -000 0000 -uuu uuuu OSCTUNE 2525 2620 4525 4620 00-0 0000 00-0 0000 uu-u uuuu TRISE 2525 2620 4525 4620 0000 -111 0000 -111 uuuu -uuu TRISD

2525 2620 4525 4620 1111 1111 1111 1111 uuuu uuuu TRISC 2525 2620 4525 4620 1111 1111 1111 1111 uuuu uuuu TRISB 2525 2620 4525 4620 1111 1111 1111 1111 uuuu uuuu TRISA

(5)

2525 2620 4525 4620 1111 1111

(5)

LATE 2525 2620 4525 4620 ---- -xxx ---- -uuu ---- -uuu LATD 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu LATC 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu LATB 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu LATA

(5)

2525 2620 4525 4620 xxxx xxxx

(5)

PORTE 2525 2620 4525 4620 ---- xxxx ---- uuuu ---- uuuu

2525 2620 4525 4620 ---- x--- ---- u--- ---- u--- PORTD 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu PORTC 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu PORTB 2525 2620 4525 4620 xxxx xxxx uuuu uuuu uuuu uuuu PORTA

(5)

2525 2620 4525 4620 xx0x 0000

(5)

Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition.

Shaded cells indicate conditions do not apply for the designated dev ic e.

Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up).

2: When the wake-u p is due to a n interrupt an d the GIEL or GIEH bit is set, the PC is loaded w ith the inte rrupt

vector (0008h or 0018h).

3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are

updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack.

4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LATA and TRISA are enabled, depending on the oscillator mode selected. When

not enabled as PORTA pins, they are disabled and read ‘0’.

WDT Reset,

RESET Instruction,

Stack Rese ts

1111 1111

uuuu uuuu

uu0u 0000

(5)

Wake-up via WDT

or Interrupt

uuuu uuuu

(1)

(1) (1)

(5)

PIC18F2525/2620/4525/4620

PC<20:0>

Stack Level 1

•

Stack Level 31

Reset Vector

Low-Priority Interrupt Vector

•

CALL,RCALL,RETURN

RETFIE,RETLW

0000h

0018h

On-Chip

Program Memory

High-Priority Interrupt Vector

0008h

User Memory Space

1FFFFFh

C000h

BFFFh

Read ‘0’

200000h

PC<20:0>

Stack Level 1

•

Stack Level 31

Reset Vector

Low-Priority Interrupt Vector

•

CALL,RCALL,RETURN RETFIE,RETLW

0000h

0018h

10000h

FFFFh

On-Chip

Program Memory

High-Priority Interrupt Vector

0008h

User Memory Space

Read ‘0’

1FFFFFh 200000h

PIC18FX525

PIC18FX620

5.0 MEMORY ORGANIZATION

There are three types of memory in PIC18 enhanced microcontroller devices:

• Program Memory

• Data RAM

• Data EEPROM As Harvard architecture dev ices, the dat a and progra m

memories use separate busses; this allows for concurrent access of the two memory spaces. The data EEPROM, for practical purposes, can be regarded as a peripheral device, since it is addresse d and accessed through a set of control registers.

Additional detailed information on the operation of the Flash program memory is provided in Section 7.0 “Flash Program Memory”. Data EEPROM is discussed s eparately in Section 6.0 “Data EEPROM

Memory”.

5.1 Program Memory Organization

PIC18 microcontrollers implement a 21-bit program counter, which is capable of addressing a 2-Mbyte program memory sp ace. Accessi ng a loca tion betwee n the upper boundary of the physically implemented memory and the 2-Mbyte address will return all ‘0’s (a NOP instruction).

The PIC18F2525 and PIC18F4525 each have 48 Kbytes of Flash memory and can store up to 24,57 6 single-word instructions. The PIC18F2620 and PIC18F4620 each have 64 Kbytes of Flash memory and can store up to 32,768 single-word instructions.

PIC18 devices have two interrupt vectors. The Reset vector address is at 0000h and the interrupt vector addresses are at 0008h and 0018h.

The program memory maps for PIC18FX525 and PIC18FX620 devices are shown in Figure 5-1.

FIGURE 5-1: PROGRAM MEMORY MAP AND STA CK FOR PIC18F2525/2620 /4525/4620 DEVICES

PIC18F2525/2620/4525/4620

00011

001A34h

11111 11110 11101

00010 00001 00000

00010

Return Address Stack <20:0>

Top-of-Stack

000D58h

TOSLTOSHTOSU

34h1Ah00h

STKPTR<4:0>

T op -of-Stack Registers Stack Pointer

5.1.1 PROGRAM COUNTER

The Program Counter (PC ) specifies the address of th e instruction to fetch for execu tion. The PC is 21 bits wide and is contained in three separate 8-bit registers. The low byte, known as the PCL register, is both readable and writable. The high byt e, or PCH re gister, contains the PC<15:8> bits; i t is not directly re adable or writ able. Updates to the PCH register are perfo rmed through the PCLATH register. The upper byte is called PCU. This register contains the PC<20:16> bits; it is also not directly readable or writable. Updates to the PCU register are performed through the PCLATU register.

The contents of PCLATH and PCLATU are transferred to the program counter by any operation that writes PCL. Similarly, the upper two bytes of the program counter are transferred to P CLATH and PCLATU by an operation that reads PCL. This is useful for computed offsets to the PC (see Section 5.1.4.1 “Computed GOTO”).

The PC addresses bytes in the program memory. To prevent the PC from becoming misaligned with word instructions, the Least Significant bit of PCL is fixed to a value of ‘0’. The PC increments by 2 to address sequential instructions in the program memory.

The CALL, RCALL, GOTO and program branch instructions write to the program counter directly. For these instructions, the contents of PCLATH and PCLATU are not transferred to the program counter.

5.1.2 RETURN ADDRESS STACK

The return address s tack allows any co mb ination of up to 31 program calls and interrupts to occur. The PC is pushed onto th e stac k when a CALL or RCALL instruction is executed or an interrupt is Acknowledged. The PC value is pulled off the stack on a RETURN, RETLW or a RETFIE instruction. PCLATU and PCLATH are not affected by any of the RETURN or CALL instructions.

The stack operates as a 31-word by 21-bit RAM and a 5-bit Stack Pointer, STKPTR. The stac k space is not part of either program or da ta sp ace. The Stack Point er is readable and writable and the address on the top of the stack is readable and writable through the top-ofstack Special File Registers. Data can also be pushed to, or popped from the stack, using these registers.

A CALL type instru ctio n cau ses a pu sh ont o the stack; the Stack Pointer is first incremented and the location pointed to by the Stack Pointer is written with the contents of the PC (already pointing to the instruction following the CALL). A RETURN type instruction causes a pop from the stack; the contents of the location pointed to by the STKPTR are transferred to the PC and then the Stack Pointer is decremented.

The Stack Pointer is initialized to ‘00000’ after all Resets. There is no RAM associated with the location corresponding to a Stack Pointer value of ‘00000’; this is only a Reset value. Stat us bit s in dic ate if the stack is full or has overflowed or has underflowed.

5.1.2.1 Top-of-Stack Access

Only the top of the return address stack (TOS) is readable and writable. A set of three registers, TOSU:TOSH:TOSL, hold the contents of the stack location pointed to by the STKPTR register (Figure 5-2). This allows users to implement a software stack if necessary. After a CALL, RCALL or interrupt, the software can read the pushed value by reading the TOSU:TOSH:TOSL registers. These values can be placed on a user-defined sof tware stack. At return time, the software can return these values to TOSU:TOSH:TOSL and do a return.

The user must disable the global interrupt enable bits while accessing the stack to prevent inadvertent stack corruption.

FIGURE 5-2: RETURN ADDRESS STACK AND ASSOCIATED REGISTERS

PIC18F2525/2620/4525/4620

5.1.2.2 Return Stack Pointer (STKPTR)

The STKPTR register (Register5-1) contains the S tac k Pointer value, the STKFUL (Stack Full) status bit and the STKUNF (Stack Underflow) status bits. The value of the Stack Pointer can be 0 through 31. The Stack Pointer increments before values are pushed onto the stack and decrements after values are popped off the stack. On Reset, the Stack Pointer value will be zero. The user may read and write the Stack Pointer value. This feature can be used by a Real-Time Operating System (RTOS) for return stack maintenance.

After the PC is pu sh ed ont o the s ta ck 31 time s (witho ut popping any values off the stack), the STKFUL bit is set. The STKFUL bit is cleared by software or by a POR.

The action that takes place when the stack becomes full depends on the state of the STVREN (Stack Overflow Reset Enable) Configuration bit. (Refer to Section 23.1 “Configuration Bits” for a description of the device Configuration bits.) If STVREN is set (default), the 31st push will push the (PC + 2) value onto the stack, set the STKFUL bit and reset the device. The STKFUL bit will remain set and the Stack Pointer will be set to zero.

If STVREN is cleared, the STKFUL bi t will be set on the 31st push and the Stack Pointer will increment to 31. Any additional pushes will not overwrite the 31st push and STKPTR will remain at 31.

When the stack has been popped enough times to unload the stac k, the next pop will ret urn a value of zero to the PC and sets the STKUNF bit, while the Stack Pointer remains at zero. The STKUNF bit will remain set until cleared by software or until a POR occurs.

Note: Returning a value of zero to the PC on an

underflow has the effect of vectoring the program to the Reset vector, where the stack conditions can be verified and appropriate actions can be taken. This is not the same as a Reset, as the contents of the SFRs are not affected.

5.1.2.3 PUSH and POP Instructions

Since the Top-of-Stack is readable and writable, the ability to push value s on to the st ac k an d pul l values off the stack without disturbing normal program execution is a desirable feature. The PIC18 instruction set includes two instructions, PUSH and POP, that permit the TOS to be manipulated under software control. TOSU, TOSH and T OS L can be m odifie d to plac e dat a or a return address on the stack.

The PUSH instruction places the current PC value onto the stack. This increments the Stack Pointer and loads the current PC value onto the stack.

The POP instruction discards the current TOS by decrementing the Stack Pointer. The previous value pushed onto the stack then becomes the TOS value.

REGISTER 5-1: STKPTR: STACK POINTER REGISTER

R/C-0 R/C-0 U-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0

STKFUL

bit 7 bit 0

Legend: C = Clearable only bit R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 STKFUL: Sta ck Full Fla g bit

bit 6 STKUNF: Stack Underflow Flag bit

bit 5 Unimplemented: Read as ‘0’ bit 4-0 SP4:SP0: Stack Pointer Location bits

Note 1: Bit 7 and bit 6 are cleared by user software or by a POR.

(1)

STKUNF

1 = Stack became full or overflowed 0 = Stack has not become f ull or overflowed

1 = Stack underflow occurred 0 = Stack underflow did not occur

(1)

— SP4 SP3 SP2 SP1 SP0

(1)

PIC18F2525/2620/4525/4620

CALL SUB1, FAST ;STATUS, WREG, BSR

;SAVED IN FAST REGISTER ;STACK

•

SUB1 •

•

RETURN, FAST ;RESTORE VALUES SAVED

;IN FAST REGISTER STACK

MOVF OFFSET, W

CALL TABLE ORG nn00h TABLE ADDWF PCL

RETLW nnh

5.1.2.4 Stack Full and Underflow Resets

Device Resets on stack overflow and stack underflow conditions are enabled by setting the STVREN bit in Configuration Register 4L. When STVREN is set, a ful l or underflow will set the appropriate STKFUL or STKUNF bit and then cause a device Reset. When STVREN is cleared, a full or underflow condi tion will set the appropriate STKFUL or STKUNF bit but not cause a device Reset. The STKFUL or STKUNF bits are cleared by the user software or a Power-on Reset.

5.1.3 FAST REGISTER STACK

A Fast Register Stack is provided for the STATUS, WREG and BSR registers, to provide a “fast return” option for interrupts. The stack for each register is onl y one level deep and is neith er readable no r writable. It is loaded with the curre nt val ue of the corres pondi ng register when the processor vectors for an interrupt. All interrupt so urces wi ll pu sh val ues int o the stack r egisters. The values in the registers are then loaded back into their associated registers if the RETFIE, FAST instruction is used to return from the interrupt.

If both low and high-priority interrupts are enabled, the stack registers cannot be used reliably to return from low-priority interrupts. If a high-priority interrupt occurs while servicing a low-priority interrupt, the stack register values stored by the low-priority interrupt will be overwritten. In these cases, users must save the key registers in software during a low-priority interrupt.

If interrupt priority is not used, all interrupts ma y use the Fast Register Stack for returns from interrupt. If no interrupts are used, the Fast Register Stack can be used to restore the STATUS, WREG and BSR registers at the end of a subroutin e call. To use the Fast Register Stack for a subroutine call, a CALL label, FAST instruction must be executed to save the STATUS, WREG and BSR registers to the Fast Re gister S tack. A RETURN, FAST instruction is then executed to resto re these registers from the Fast Register Stack.

Example 5-1 shows a source code example that uses the Fast Register Stack during a subroutine call and return.

EXAMPLE 5-1: FAST REGISTER STACK

CODE EXAMPLE

5.1.4 LOOK-UP TABLES IN PROGRAM MEMORY

There may be programming situations that require the creation of data structures, or look-up tables, in program memory. For PIC18 devices, look-up tables can be implemented in two ways:

• Computed GOTO

• Table Reads

5.1.4.1 Computed GOTO

A computed GOTO is accompli shed by adding an offset to the program counter. An example is shown in Example 5-2.

A look-up table can be formed with an ADDWF PCL instruction and a group of RETLW nn instructions. The W register is loaded with an of fs et into the table before executing a call to tha t t a ble . The first instruction o f th e called routine is the ADDWF PCL instruction. The next instruction executed will be one of the RETLW nn instructions that returns the value ‘nn’ to the calling function.

The offset value (in WREG) specifies the number of bytes that the program counter should advance and should be multiples of 2 (LSb = 0).

In this method, only one data byte may be stored in each instruction location and room on the return address stack is required.

EXAMPLE 5-2: COMP UTED GOTO USING

AN OFFSET VALUE

5.1.4.2 Table Reads and Table Writes

A better method of storing data in program memory allows two bytes of dat a to be stored in each instruction location.

Look-up table data may be stored two bytes per program word by using table reads and writes. The Table Pointer (TBLPTR) register specifies the byte address and the Table Latch (TABLAT) register contains the da ta that is read from o r written to program memory. Data is transferred to or from program memory one byte at a time.

Table read and table write operations are discussed further in Section 7.1 “Table Reads and Table

Writes”.

PIC18F2525/2620/4525/4620

Q2 Q3 Q4

OSC1

Q1 Q2 Q3 Q4

OSC2/CLKO

(RC mode)

PC PC + 2 PC + 4

Fetch INST (PC)

Execute INST (PC – 2)

Fetch INST (PC + 2)

Execute INST (PC)

Fetch INST (PC + 4)

Execute INST (PC + 2)

Internal Phase Clock

All instructions are single cycle, except for any program branche s. These tak e two cycles since the fetch instruct ion is “flushed” from the pipeline while the new instruction is being fetched and then executed.

TCY0TCY1TCY2TCY3TCY4TCY5

1. MOVLW 55h

Fetch 1 Execute 1

2. MOVWF PORTB

Fetch 2 Execute 2

3. BRA SUB_1

Fetch 3 Execute 3

4. BSF PORTA, BIT3 (Forced NOP)

Fetch 4 Flush (NOP)

5. Instruction @ address SUB_1

Fetch SUB_1 Execute SUB_1

5.2 PIC18 Instruction Cycle

5.2.1 CLOCKING SCHEME

The microcontroller clock input, whether from an internal or external source, is internally divided by four to generate four non-overlapping quadrature clocks (Q1, Q2, Q3 and Q 4). Internall y, the pro gram counte r is incremented on every Q1; the instruction is fetched from the program memory and latched into the instruction register during Q4. The instruction is decoded and execute d during the followin g Q1 throug h Q4. The clocks and instruction execution flow are shown in Figure 5-3.

FIGURE 5-3: CLOCK/INSTRUCTION CYCLE

5.2.2 INSTRUCTION FLOW/PIPELINING

An “Instruction Cycle” consists of four Q cycles: Q1 through Q4. The instruction fetch and execute are pipelined in such a manner that a fetch takes one instruction cycle, while the decode and execute take another instruction cycle. However, due to the pipelining, each instruction effectively executes in one cycle. If a n instruc tion caus es the pro gram coun ter to change (e.g., GOTO), then two cycles are required to complete the instruction (Example 5-3).

A fetch cycle begins with the Program Counter (PC) incrementing in Q1.

In the execution cy cle, the fetch ed instruction i s latched into the Instruction Register (IR) in cycle Q1. This instruction is then decoded and executed during the Q2, Q3 and Q4 cycle s. D ata memory is re ad dur ing Q 2 (operand read) and written during Q4 (destination write).

EXAMPLE 5-3: INSTRUCTION PIPELINE FLOW

PIC18F2525/2620/4525/4620

Word Address

LSB = 1 LSB = 0 ↓ Program Memory Byte Locations

→

000000h 000002h 000004h

000006h Instruction 1: MOVLW 055h 0Fh 55h 000008h Instruction 2: GOTO 0006h EFh 03h 00000Ah

F0h 00h 00000Ch

Instruction 3: MOVFF 123h, 456h C1h 23h 00000Eh

F4h 56h 000010h

000012h

000014h

5.2.3 INSTRUCTIONS IN PROGRAM MEMORY

The program memory is addressed in bytes. Instructions are stored as two bytes or four bytes in program memory. The Least Significant Byte of an instruction word is always stored in a program memory location with an even address (LSb = 0). To maintain alignment with instruction bo undaries , the PC incr ements in step s of 2 and the LSb wi ll always read ‘0’ (see Section 5.1.1 “Program Counter”).

Figure 5-4 shows an example of how inst ruct ion word s are stored in the program memory.

The CALL and GOTO instructions have the absolute program memory address embedded into the instruction. Since instructions are always stored on word boundaries, the data contained in the instruction is a word address. The word address is written to PC<20:1>, which accesses the desired byte address in program memory. Instruction #2 in Figure 5-4 shows how the instruction GOTO 0006h is encoded in the program memory. Program branch instructions, which encode a relative address offset, operate in the same ma nner. The offset value stored in a branch instruction represents the number of single-word instructions that the PC will be offset by. Section 24.0 “Instruction Set Summary” provides further details of the instruction set.

FIGURE 5-4: INSTRUCTIONS IN PROGRAM MEMORY

5.2.4 TWO-WORD INSTRUCTIONS

The standard PIC18 instruction set has four two-word instructions: CALL, MOVFF, GOTO and LSFR. In all cases, the second word of the in struc tion s always has ‘1111’ as its four M ost Signi fican t bit s; the other 12 bit s are literal data, usually a data memory address.

The use of ‘1111’ in the 4 MSbs of an instruction specifies a special form of NOP. If the instruction is executed in proper sequence – immed iate ly af ter the first word – the data in the s econd w ord is ac cessed an d used by

the instruction seq ue nce . If the first word is skipped for some reason and the se cond word is ex ecuted by itsel f, a NOP is executed instead. This is necessary for cases when the two-word instruction is preceded by a conditional instruction that changes the PC. Example 5-4 shows how this works.

Note: See Section 5.6 “PIC18 Instruction

Execution and the Extended Instruction Set” for information on two-word

instructions in the extended instruction set.

EXAMPLE 5-4: TWO- WORD INSTRUCTIONS

CASE 1: Object Code Source Code

0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0? 1100 0001 0010 0011 MOVFF REG1, REG2 ; No, skip this word 1111 0100 0101 0110 ; Execute this word as a NOP 0010 0100 0000 0000 ADDWF REG3 ; continue code

CASE 2: Object Code Source Code

0110 0110 0000 0000 TSTFSZ REG1 ; is RAM location 0? 1100 0001 0010 0011 MOVFF REG1, REG2 ; Yes, execute this word 1111 0100 0101 0110 ; 2nd word of instruction 0010 0100 0000 0000 ADDWF REG3 ; continue code

PIC18F2525/2620/4525/4620

5.3 Data Memory Organization

Note: The operation of some aspects of data

memory are changed when the PIC18 extended instruction set is enabled. See

Section 5.5 “Data Memory and the Extended Instruction Set” for more

information.

The data memory in PIC18 devices is implemented as static RAM. Each register in the data memory has a 12-bit address, allowing up to 4096 bytes of data memory . The m emory sp ace is div ided into as many as 16 banks that contain 256 bytes each; PIC18F2525/ 2620/4525/4620 devices implement all 16 banks. Figure 5-5 shows the data memory organ ization for the PIC18F2525/2620/4525/4620 devices.

The data memory contains Special Function Registers (SFRs) and General Purpose Registers (GPRs). The SFRs are used for control and status of the controller and peripheral functio ns, while GPRs are us ed for data storage and scratchpad operations in the user’s application. Any re ad of an unimpl emented location will read as ‘0’s.

The instruction set and architecture allow operations across all banks. The entire data memory may be accessed by Direct, Indirect or Indexed Addressing modes. Addressing modes are discussed later in this subsection.

To ensure that commonly used registers (SFRs and select GPRs) c an b e ac cess ed i n a si ngle cycle, PI C18 devices impl em ent an Ac ce ss Ba nk . Th is i s a 256-byte memory space that pr ovid es fa st acc ess to SFRs a nd the lower portion of GPR Bank 0 without using the BSR. Section 5.3.2 “Access Bank” provides a detailed description of the Access RAM.

5.3.1 BANK SELECT REGISTER (BSR)

Large areas of data memory require an efficient addressing scheme to make rapid access to any address possible. Ideally, this means that an entire address does not need to be provided for each read or write operation. For PIC18 devices, this is accomplished with a RAM banking scheme. This divides the memory space into 16 contiguous banks of 256 bytes. Depending on the instruction, each location can be addressed directly by its full 12-bit address, or an 8-bit low-order address and a 4-bit Bank Pointer.

Most instruct ions in th e PIC18 in struct ion set ma ke us e of the Bank Pointer , known as the Ba nk Select Reg ister (BSR). This SFR holds the four Most Significant bit s of a location’s address; the instruction itself includes the 8 Least Significant bits. Only the four lower bits of the BSR are implemented (BSR3:BSR0). The upper four bits are unused; the y will always read ‘ 0’ and cannot be written to. The BSR can be l oaded direc tly b y using the MOVLB instruction.

The value of the BSR indicates the bank in data memory; the 8 bits in the instruction show the location in the bank and can be thought of as an offset from th e bank’s lower boundary. The relationship between the BSR’s value and the bank division in data memory is shown in Figure 5-6.

Since up to 16 reg isters m ay sh are the same l ow-ord er address, the user must alway s be careful to ensure that the proper bank is selected before performing a data read or write. For example, writing what should be program data to an 8-bit addre ss of F9 h, while the BSR is 0Fh, will end up resetting the program counter.

While any bank can be s el ec ted, only those banks th at are actually implemented can be read or written to. Writes to unimplemented banks are ignored, while reads from unimplemented banks will return ‘0’s. Even so, the STATUS register will still be affected as if the operation was successful. The data memory map in Figure 5-5 indicates which banks are implemented.

In the core PIC18 instruction set, only the MOVFF instruction fully specifies the 12-bit address of the source and target registers. This i nstruction ig nores the BSR completely when it ex ecutes. All o ther instruction s include only the low-order address as an operand and must use either the BSR or the Access Bank to locate their target registers.

PIC18F2525/2620/4525/4620

Bank 0

Bank 1

Bank 14

Bank 15

Data Memory Map

BSR<3:0>

= 0000

= 0001

= 1111

080h

07Fh

F80h FFFh

00h

7Fh

80h

FFh

Access Bank

When a = 0:

The BSR is ignored an d the Access Bank is used.

The first 128 bytes are general purpose RAM (from Bank 0).

The second 128 bytes are Special Function Registers (from Bank 15).

When a = 1:

The BSR specifies the Ban k used by the instruction.

F7Fh

F00h

EFFh

1FFh

100h

0FFh

000h

Access RAM

FFh

00h

FFh

00h

FFh

00h

GPR

SFR

GPR

Access RAM High

Access RAM Low

Bank 2

= 0110

= 0010

(SFRs)

2FFh

200h

3FFh

300h

4FFh

400h

5FFh

500h

6FFh

600h

7FFh

700h

8FFh

800h

9FFh

900h

AFFh

A00h

BFFh

B00h

CFFh

C00h

DFFh

D00h

E00h

Bank 3

Bank 4

Bank 5

Bank 6

Bank 7

Bank 8

Bank 9

Bank 10

Bank 11

Bank 12

Bank 13

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

FFh

00h

GPR

FFh

00h

= 0011

= 0100

= 0101

= 0111

= 1000

= 1001

= 1010

= 1011

= 1100

= 1101

= 1110

FIGURE 5-5: DATA MEMORY MAP FOR PIC18F2525/2620/4525/4620 DEVICES

PIC18F2525/2620/4525/4620

Note 1: The Access RAM bit of the instruction can be used to force an override of the selected bank (BSR<3:0>) to

the registers of the Access Bank.

2: The MOVFF instruction embeds the entire 12-bit address in the instruction.

Data

Memory

Bank Select

(2)

From Opcode

(2)

0000

000h

100h

200h

300h

F00h

E00h

FFFh

Bank 0 Bank 1

Bank 2

Bank 14

Bank 15

00h FFh

00h

FFh

Bank 3

through

Bank 13

0011

11111111

BSR

(1)

FIGURE 5-6: USE OF THE BANK SELECT REGISTER (DIRECT ADDRESSING)

5.3.2 ACCESS BANK

While the use of the BSR with an embedded 8-bit address allows users to address the entire range of data memory, it also means th at the user must a lways ensure that the correct bank is selected. Otherwise, data may be read from or written to the wrong location. This can be disastrous if a GPR is the intended target of an operation, but an SFR is written to instead. Verifying and/or changing the BSR for each read or write to data memory can become very inefficient.

T o stre amline acces s for the most commonl y used data memory locations, the data memory is configured with an Access Bank, which allows users to access a mapped block of memory without specifying a BSR. The Access Bank consists of the first 128 bytes of memory (00h-7Fh) in Bank 0 and the last 128 bytes of memory (80h-FFh) in Block 15 . The lower half is known as the “Access RAM” and is composed of GPRs. This upper half is also where the device’s SFRs are mapped. These two areas are mapped contiguously in the Access Bank and can be addressed in a linear fashion by an 8-bit address (Figure 5-5).

The Access Bank is used by core PIC18 instructions that include the Access RAM bit (the ‘a’ parameter in the instruction). When ‘a’ is equal to ‘1’, the instru ct ion uses the BSR and the 8-bit address included in the opcode for the data memory address. When ‘a’ is ‘0’,

however, the instruction is forced to use the Access Bank address map; the current value of the BSR is ignored entirely.

Using this “forced” addressing allows the instruction to operate on a data address in a single cycle, without updating the BSR first. For 8-bit addresses of 80h and above, this means th at use rs can ev aluate an d operate on SFRs more efficiently. The Access RAM below 80h is a good place for da ta values that the user might need to access rapidly, such as immediate computational results or common program variables. Access RAM also allows for faster and more code efficient context saving and switching of variables.

The mapping of the Access Bank is slightly different when the extended instruction set is enabled (XINST Configuration bit = 1). This is discussed in more d etail in Section 5.5.3 “Mapping the Access Bank in Indexed Literal Offset Addressing Mode”.

5.3.3 GENERAL PURPOSE REGISTER FILE

PIC18 devices may have banked memory in the GPR area. This is data RAM, which is available for use by all instructions. GPRs start at the bottom of Bank 0 (address 000h) and grow upwards towards the bottom of the SFR area. GPRs are not initialized by a Power-on Reset and are unchanged on all other Resets.

PIC18F2525/2620/4525/4620

5.3.4 SPECIAL FUNCTION REGISTERS

The Special Function Registers (SFRs) are registers used by the CPU and p eripheral modul es for controllin g the desired operation of the device. These reg isters are implemented as static RAM. SFRs start at the top of data memory (FF Fh) an d extend downw ard to oc cupy the top half of Bank 15 (F80h to FFFh). A list of these registers is given in Table 5-1 and Table 5-2.

The SFRs can be classified into two sets: those associated with the “core” device functionality (ALU, Resets and interrupts) and those related to the peripheral functions. The reset and interrupt registers are described in their respective chapters, while the ALU’s STATUS register is described later in this section. Registers related to the operation of a peripheral feature are described in the chapter for that peripheral.

The SFRs are typically distributed among the peripherals whose fun cti ons th ey c ontr ol. U nus ed SFR locations are unimplemented and read as ‘0’s.

TABLE 5-1: SPECIAL FUNCTION REGIST ER MAP FOR PIC18F 2525 /2620/45 25/46 20 DEVIC ES

Address Name Address Name Address Name Address Name

FFFh TOSU FDFh INDF2

FFEh TOSH FDEh POSTINC2 FFDh TOSL FDDh POSTDEC2 FFCh STKPTR FDCh PREINC2

FFBh PCLATU FDBh PLUSW2

FFAh PCLATH FDAh FSR2H FBAh CCP2CON F9Ah — FF9h PCL FD9h FSR2L FB9h — FF8h TBLPTRU FD8h STATUS FB8h BAUDCON F98h — FF7h TBLPTRH FD7h TMR0H FB7h PWM1CON FF6h TBLPTRL FD6h TMR0L FB6h ECCP1AS FF5h TABLAT FD5h T0CON FB5h CVRCON F95h TRISD FF4h PRODH FD4h — FF3h PRODL FD3h OSCCON FB3h T MR3H F93h TRISB FF2h INTCON FD2h HLVDCON FB2h TMR3L F92h TRISA FF1h INTCON2 FD1h WDTCON FB1h T3CON F91h FF0h INTCON3 FD0h RCON FB0h SPBRGH F90h —

FEFh INDF0 FEEh POSTINC0 FEDh POSTDEC0 FECh PREINC0 FEBh PLUSW0

(1)

FCFh TMR1H FAFh SPBRG F8Fh —

(1)

FCEh TMR1L FAEh RCREG F8Eh — FCDh T1CON FADh TXREG F8Dh LATE FCCh TMR2 FACh TXSTA F8Ch LATD FCBh PR2 FABh RCSTA F8Bh LATC

FEAh FSR0H FCAh T2CON FAAh EEADRH F8Ah LATB

FE9h FSR0L FC9h SSPBUF FA9h EEADR F89h LATA FE8h WREG FC8h SSPADD FA8h EEDATA F88h FE7h INDF1 FE6h POSTINC1 FE5h POSTDEC1 FE4h PREINC1 FE3h PLUSW1

(1)

FC7h SSPST AT FA7h EECON2 FC6h SSPCON1 FA6h EECON1 F86h — FC5h SSPCON2 FA5h — FC4h ADRESH FA4h —

FC3h ADRESL FA3h — FE2h FSR1H FC2h ADCON0 FA2h IPR2 F82h PORTC FE1h FSR1L FC1h ADCON1 FA1h PIR2 F81h PORTB FE0h BSR FC0h ADCON2 FA0h PIE2 F80h PORTA

(1)

FBFh CCPR1H F9Fh IPR1

(1)

(2)

FBEh CCPR1L F9Eh PIR1 FBDh CCP1CON F9Dh PIE1 FBCh CCPR2H F9Ch —

FBBh CCPR2L F9Bh OSCTUNE

(2)

(3)

F99h —

F97h — F96h TRISE

FB4h CMCON F94h TRISC

(1)

(2) (2) (2)

F87h —

F85h — F84h PORTE F83h PORTD

—

(2)

(2) (2) (2) (2)

(3) (3)

(3)

Note 1: This is not a physical register.

2: Unimplemented registers are read as ‘0’. 3: This register is not available on 28-pin devices.

PIC18F2525/2620/4525/4620

T ABLE 5-2: REGISTER FILE SUMMARY (PIC18F2525/2620/4525/4620)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TOSU TOSH Top-of-Stack High Byte (TOS<15:8>) 0000 0000 49, 54 TOSL Top-of-Stack Low Byte (TOS<7:0>) 0000 0000 49, 54 STKPTR STKFUL PCLATU PCLATH Holding Register for PC<15:8> 0000 0000 49, 54 PCL PC Low Byte (P C<7:0 > ) 0000 0000 49, 54 TBLPTRU TBLPTRH Program Memory Table Pointer High Byte (TBLPTR<15:8>) 0000 0000 49, 82 TBLPTRL Program Memory Table Pointer Low Byte (TBLPTR<7:0>) 0000 0000 49, 82 TABLAT Program Memory Table Latch 0000 0000 49, 82 PRODH Product Register High Byte xxxx xxxx 49, 89 PRODL Product Register Low Byte xxxx xxxx 49, 89 INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 0000 000x 49, 111 INTCON2 RBPU INTCON3 INT2IP INT1IP INDF0 Uses contents of FSR0 to address data memory – value of FSR0 not changed (not a physical register) N/A 49, 68 POSTINC0 Uses contents of FSR0 to address data memory – value of FSR0 post-incremented (not a physical register) N/A 49, 68 POSTDEC0 Uses contents of FSR0 to address data memory – value of FSR0 post-decremented (not a physical register) N/A 49, 68 PREINC0 Uses contents of FSR0 to address data memory – value of FSR0 pre-incremented (not a physical register) N/A 49, 68 PLUSW0 Uses contents of FSR0 to address data memory – value of FSR0 pre-incremented (not a physical register) –

FSR0H FSR0L Indirect Data Memory Address Pointer 0 Low Byte xxxx xxxx 49, 68 WREG Working Register xxxx xxxx 49 INDF1 Uses contents of FSR1 to address data memory – value of FSR1 not changed (not a physical register) N/A 49, 68 POSTINC1 Uses contents of FSR1 to address data memory – value of FSR1 post-incremented (not a physical register) N/A 49, 68 POSTDEC1 Uses contents of FSR1 to address data memory – value of FSR1 post-decremented (not a physical register) N/A 49, 68 PREINC1 Uses contents of FSR1 to address data memory – value of FSR1 pre-incremented (not a physical register) N/A 49, 68 PLUSW1 Uses contents of FSR1 to address data memory – value of FSR1 pre-incremented (not a physical register) –

FSR1H FSR1L Indirect Data Memory Address Pointer 1 Low Byte xxxx xxxx 50, 68 BSR INDF2 Uses contents of FSR2 to address data memory – value of FSR2 not changed (not a physical register) N/A 50, 68 POSTINC2 Uses contents of FSR2 to address data memory – value of FSR2 post-incremented (not a physical register) N/A 50, 68 POSTDEC2 Uses contents of FSR2 to address data memory – value of FSR2 post-decremented (not a physical register) N/A 50, 68 PREINC2 Uses contents of FSR2 to address data memory – value of FSR2 pre-incremented (not a physical register) N/A 50, 68 PLUSW2 Uses contents of FSR2 to address data memory – value of FSR2 pre-incremented (not a physical register) –

FSR2H FSR2L Indirect Data Memory Address Pointer 2 Low Byte xxxx xxxx 50, 68 STATUS

Legend: x = unknown , u = unchanged, — = unimplemented, q = value depends on condition Note 1: The SBOREN bit is only available when the BOREN1:BOREN0 Configuration bits = 01; otherwise, it is disabled and reads as ‘0’. See

2: These registers and/or bits are not implemented on 28-pin devices and are read as ‘0’. Reset values are shown for 40/44-pin devices; 3: The PLLEN bit is only available in specific oscillator configurations; otherwise, it is disabled and reads as ‘0’. See Section 2.6.4 “PLL in 4: The RE3 bit is only available when Master Clear Reset is disabled (MCLRE Configuration bit = 0); otherwise, RE3 reads as ‘0’. This bit is 5: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes. 6: Bit 7 and bit 6 are cleared by user software or by a POR.

— — — Top-of-Stack Upper Byte (TOS<20:16>) ---0 0000 49, 54

(6)

— — — Holding Register for PC<20:16> ---0 0000 49, 54

— — bit 21 Program Memory Table Pointer Upper Byte (TBLPTR<20:16>) --00 0000 49, 82

value of FS R0 offset by W

— — — — Indirect Data Memory Address Pointer 0 High Byte ---- 0000 49, 68

value of FS R1 offset by W

— — — — Indirect Data Memory Address Pointer 1 High Byte ---- 0000 50, 68

— — — — Bank Select Register ---- 0000 50, 59

value of FS R2 offset by W

— — — — Indirect Data Memory Address Pointer 2 High Byte ---- 0000 50, 68

— — —NOVZDCC---x xxxx 50, 66

Section 4.4 “Brown-out Reset (BOR)”. individual unimplemented bits should be interpreted as ‘-’. INTOSC Modes”. read-only. When disabled, these bits read as ‘0’.

(6)

STKUNF

INTEDG0 INTEDG1 INTEDG2 —TMR0IP —RBIP1111 -1-1 49, 112

— SP4 SP3 SP2 SP1 SP0 00-0 0000 49, 55

— INT2IE INT1IE — INT2IF INT1IF 11-0 0-00 49, 113

Value on

POR, BOR

N/A 49, 68

N/A 50, 68

Details on

page:

PIC18F2525/2620/4525/4620

TABLE 5-2: REGISTER FILE SUMMARY (PIC18F2525/2620/4525/4620) (CONTINUED)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TMR0H Timer0 Register High Byte 0000 0000 50, 125 TMR0L Timer0 Register Low Byte xxxx xxxx 50, 125 T0CON TMR0ON T08BIT T0CS T0SE PSA T0PS2 T0PS1 T0PS0 1111 1111 50, 123 OSCCON IDLEN IRCF2 IRCF1 IRCF0 OSTS IOFS SCS1 SCS0 0100 q000 30, 50 HLVDCON VDIRMAG WDTCON

RCON IPEN SBOREN TMR1H Timer1 Register High Byte xxxx xxxx 50, 131 TMR1L Timer1 Register Low Byte xxxx xxxx 50, 131 T1CON RD16 T1RUN T1CKPS1 T1CKPS0 T1OSCEN T1SYNC TMR2 Timer2 Regist er 0000 0000 50, 134 PR2 Timer2 Period Register 1111 1111 50, 134 T2CON SSPBUF MSSP Receive Buffer/Transmit Register xxxx xxxx 50, 169,

SSPADD MSSP Address Register in I SSPSTAT SMP CKE D/A

SSPCON1 WCOL SSPOV SSPEN CKP SSPM3 SSPM2 SSPM1 SSPM0 0000 0000 50, 163,

SSPCON2 GCEN ACKSTAT ACKDT ACKEN RCEN PEN RSEN SEN 0000 0000 50, 173 ADRESH A/D Result Register High Byte xxxx xxxx 51, 232 ADRESL A/D Result Register Low Byte xxxx xxxx 51, 232 ADCON0 ADCON1 ADCON2 ADFM CCPR1H Capture/Compare/PWM Register 1 High Byte xxxx xxxx 51, 140 CCPR1L Capture/Compare/PWM Register 1 Low Byte xxxx xxxx 51, 140 CCP1CON P1M1

CCPR2H Capture/Compare/PWM Register 2 High Byte xxxx xxxx 51, 140 CCPR2L Capture/Compare/PWM Register 2 Low Byte xxxx xxxx 51, 140 CCP2CON BAUDCON ABDOVF RCIDL RXDTP TXCKP BRG1 6 PWM1CON PRSEN PDC6 ECCP1AS ECCPASE ECCPAS2 ECCPAS1 ECCPAS0 PSSAC1 PSSAC0 PSSBD1 CVRCON CVREN CVROE CVRR CVRSS CVR3 CVR2 CVR1 CVR0 0000 0000 51, 239 CMCON C2OUT C1OUT C2INV C1INV CIS CM2 CM1 CM0 0000 0111 51, 233 TMR3H Timer3 Register High Byte xxxx xxxx 51, 137 TMR3L Timer3 Register Low Byte xxxx xxxx 51, 137 T3CON RD16 T3CCP2 T3CKPS1 T3CKPS0 T3CCP1 T3SYNC

— — — — — — —SWDTEN--- ---0 50, 259

— T2OUTPS3 T2OUTPS2 T2OUTPS1 T2OUTPS0 TMR2ON T2CKPS1 T2CKPS0 -000 0000 50, 133

— — CHS3 CHS2 CHS1 CHS0 GO/DONE ADON --00 0000 51, 223 — — VCFG1 VCFG0 PCFG3 PCFG2 PCFG1 PCFG0 --00 0qqq 51, 224

(2)

— — DC2B1 DC2B0 CCP2M3 CCP2M2 CCP2M1 CCP2M0 --00 0000 51, 139

Section 4.4 “Brown-out Reset (BOR)”. individual unimplemented bits should be interpreted as ‘-’. INTOSC Modes”. read-only. When disabled, these bits read as ‘0’.

— IRVST HLVDEN HLVDL3 HLVDL2 HLVDL1 HLVDL0 0-00 0101 50, 243

(1)

—RITO PD POR BOR 0q-1 11q0 42, 48, 120

TMR1CS TMR1ON 0000 0000 50, 127

C™ Slave Mode. MSSP Baud Rate Reload Register in I2C Master Mode. 0000 0000 50, 170

PSR/WUA BF 0000 0000 50, 162,

— ACQT2 ACQT1 ACQT0 ADCS2 ADCS1 ADCS0 0-00 0000 51, 225

P1M0

(2)

DC1B1 DC1B0 CCP1M3 CCP1M2 CCP1M1 CCP1M0 0000 0000 51, 139,

(2)

PDC5

(2)

PDC4

(2)

PDC3

(2)

— WUE ABDEN 0100 0-00 51, 204

PDC2

(2)

PDC1

TMR3CS TMR3ON 0000 0000 51, 135

(2)

PDC0

PSSBD0

Value on

POR, BOR

(2)

0000 0000 51, 156

(2)

0000 0000 51, 157

Details on

page:

170

171

172

147

PIC18F2525/2620/4525/4620

T ABLE 5-2: REGISTER FILE SUMMARY (PIC18F2525/2620/4525/4620) (CONTINUED)

File Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Value on

POR, BOR

SPBRGH EUSART Baud Rate Generator Register High Byte 0000 0000 51, 206 SPBRG EUSART Baud Rate Generator Register Low Byte 0000 0000 51, 206 RCREG EUSART Receive Register 0000 0000 51, 213 TXREG EUSART Transmit Register 0000 0000 51, 211 TXSTA CSRC TX9 TXEN SYNC SENDB BRGH TRMT TX9D 0000 0010 51, 202 RCSTA SPEN RX9 SREN CREN ADDEN FERR OERR RX9D 0000 000x 51, 203 EEADRH

— — — — — — EEPROM Addr Register High ---- --00 51, 73 EEADR EEPROM Address Register 0000 0000 51, 80, 73 EEDATA EEPROM Data Register 0000 0000 51, 80, 73 EECON2 EEPROM Control Register 2 (not a physical register) 0000 0000 51, 80, 73 EECON1 EEPGD CFGS IPR2 OSCFIP CMIP PIR2 OSCFIF CMIF PIE2 OSCFIE CMIE IPR1 PSPIP PIR1 PSPIF PIE1 PSPIE

(2)

ADIP RCIP TXIP SSPIP CCP1IP TMR2IP TMR1IP 1111 1111 52, 118

(2)

ADIF RCIF TXIF SSPIF CCP1IF TMR2IF TMR1IF 0000 0000 52, 114

(2)

ADIE RCIE TXIE SSPIE CCP1IE TMR2IE TMR1IE 0000 0000 52, 116

OSCTUNE INTSRC PLLEN

(2)

TRISE TRISD

(2)

IBF OBF IBOV PSPMODE — TRISE2 TRISE1 TRISE0 0000 -111 52, 104

PORTD Data Direction Control Register 1111 1111 52, 100

(3)

— FREE WRERR WREN WR RD xx-0 x000 51, 81, 74 — EEIP BCLIP HLVDIP TMR3IP CCP2IP 11-1 1111 52, 119 — EEIF BCLIF HLVDIF TMR3IF CCP2IF 00-0 0000 52, 115 — EEIE BCLIE HLVDIE TMR3IE CCP2IE 00-0 0000 52, 117

— TUN4 TUN3 TUN2 TUN1 TUN0 00-0 0000 27, 52

TRISC PORTC Data Direction Control Register 1111 1111 52, 97 TRISB PORTB Data Direction Control Register 1111 1111 52, 94 TRISA TRISA7

(2)

LATE

— — — — — PORTE Data Latch Register

(5)

TRISA6

(5)

Data Direction Control Register for PORTA 1111 1111 52, 91

---- -xxx 52, 103

(Read and Write to Data Latch)

(2)

LATD

PORTD Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 100 LATC PORTC Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 97 LATB PORTB Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 94 LATA LATA7 PORTE PORTD

(2)

— — — —RE3

RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 xxxx xxxx 52, 100

(5)

LATA6

(5)

PORTA Data Latch Register (Read and Write to Data Latch) xxxx xxxx 52, 91

(4)

RE2

(2)

RE1

(2)

RE0

(2)

---- xxxx 52, 103

PORTC RC7 RC6 RC5 RC4 RC3 RC2 RC1 RC0 xxxx xxxx 52, 97 PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 xxxx xxxx 52, 94 PORTA RA7

(5)

RA6

(5)

RA5 RA4 RA3 RA2 RA1 RA0 xx0x 0000 52, 91

Section 4.4 “Brown-out Reset (BOR)”.

2: These registers and/or bits are not implemented on 28-pin devices and are read as ‘0’. Reset values are shown for 40/44-pin devices;

individual unimplemented bits should be interpreted as ‘-’.

3: The PLLEN bit is only available in specific oscillator configurations; otherwise, it is disabled and reads as ‘0’. See Section 2.6.4 “PLL in

INTOSC Modes”.

4: The RE3 bit is only available when Master Clear Reset is disabled (MCLRE Configuration bit = 0); otherwise, RE3 reads as ‘0’. This bit is

read-only.

5: RA6/RA7 and their associated latch and direction bits are individually configured as port pins based on various primary oscillator modes.

When disabled, these bits read as ‘0’.

6: Bit 7 and bit 6 are cleared by user software or by a POR.

Details on

page:

PIC18F2525/2620/4525/4620

5.3.5 STATUS REGISTER

The STATUS register, shown in Register 5-2, contains the arithmetic status of the ALU. As wi th any other SFR, it can be the operand for any instruction.

If the ST ATUS register is the destination for an instruction that affects the Z, DC, C, OV or N bits, the results of the instruction are not written; instead, the STATUS register is updated according to the instruction performed. Therefore, the result of an instruction with the STATUS register as its destination may be different than intended. As an example, CLRF STATUS will set the Z bit and leave the remaining Status bits unchanged (‘000u u1uu’).

It is recommended that only BCF, BSF, SWAPF , MOVFF and MOVWF instructions are used to alter the STATUS register , b ecaus e thes e ins tructi ons d o not af fect t he Z, C, DC, OV or N bits in the STATUS register.

For other instructions that do not aff ect Status bi t s , se e the instruction set summaries in Table 24-2 and Table 24-3.

Note: The C and DC bits operate as the borrow

and digit borrow bits, respectively, in subtraction.

REGISTER 5-2: STATUS REGISTER

U-0 U-0 U-0 R/W-x R/W-x R/W-x R/W-x R/W-x

— — —NOVZDC

bit 7 bit 0

Legend:

R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

(1)

(2)

bit 7-5 Unimplemented: Read as ‘0’ bit 4 N: Negative bit

This bit is used for signed arithmetic (2’s complement). It indicates whether the result was negative

(ALU MSB = 1).

1 = Result was negative

0 = Result was positive

bit 3 OV: Overflow bit

This bit is used for signed arithmetic (2’s complement). It indicates an overflow of the 7-bit magnitude

which causes the sign bit (bit 7) to change state.

1 = Overflow occurred for signed arit hmetic (in this arithmetic operati on)

0 = No overflow occurred

bit 2 Z: Zero bit

1 = The result of an arithmetic or logic operation is zero

0 = The result of an arithmetic or logic operation is not zero

(1)

bit

bit 1 DC: Digit Carry/borrow

For ADDWF, ADDLW, SUBLW and SUBWF instructions:

1 = A carry-out from the 4th low-order bit of the result occurred

0 = No carry-out from the 4th low-order bit of the result

(2)

bit 0 C: Carry/borrow

For ADDWF, ADDLW, SUBLW and SUBWF instructions:

1 = A carry-out from the Most Significant bit of the result occurred

0 = No carry-out from the Most Significant bit of the result occurred

Note 1: For borrow,

operand. For rotate (RRF, RLF) instructions, this bit is loaded with either bit 4 or bit 3 of the source register.

2: For borrow ,

operand. For rotate (RRF, RLF) instructions, this bit is loaded with either the high or low-order bit of the source register.

the polarity is reversed. A subtraction is executed by adding the 2’scomplement of the second

the polarity is reve rsed. A subt raction is ex ecuted by adding the 2 ’s complement of the secon d

bit

PIC18F2525/2620/4525/4620

LFSR FSR0, 100h ;

NEXT CLRF POSTINC0 ; Clear INDF

; register then ; inc pointer

BTFSS FSR0H, 1 ; All done with

; Bank1?

BRA NEXT ; NO, clear next

CONTINUE ; YES, continue

5.4 Data Addressing Modes

Note: The execution of some instructions in the

core PIC18 instruction set are changed when the PIC18 extended instruction set is enabled. See Section 5.5 “Data Memory and the Extended Instruction Set” for more information.

The data memory space can be addr essed in se veral ways. For most instructions, the addressing mode is fixed. Other instructions may use up to three modes, depending on whic h operands are used and whe ther or not the extended instruction set is enabled.

The addressing modes are:

• Inherent

• Literal

•Direct

•Indirect An additional addressing mode, Indexed Literal Offset,

is available when the extended instruction set is enabled (XINST Configuration bit = 1). Its operation is discussed in greater detail in Section 5.5.1 “Indexed Addressing with Literal Offset”.

5.4.1 INHEREN T AND LITERAL ADDRESSING

Many PIC18 control instructions do not need any argument at all; they either perform an operation that globally affects the device or they operate implicitly on one register. This addressing mode is know n as Inherent Addressing. Examples include SLEEP, RESET and DAW.

Other instructions work in a similar way but require an additional explicit argument in the opcode. This is known as Literal Addressing mode because they require some literal value as an argument. Examples include ADDLW and MOVLW, which respectively, add or move a literal value to the W register. Other examples include CALL and GOTO, which include a 20-bit program memory address.

5.4.2 DIRECT ADDRESSING

Direct Addressing specifies all or part of the source and/or destination address of the operation within the opcode itself. The options are specified by the arguments accompanying the instruction.

In the core PIC18 inst ruct ion se t, bit-ori ented and by teoriented instructions use some version of Direct Addressing by default. All of these instructions include some 8-bit literal address as their Least Significant Byte. This address spec ifies either a re gister address in one of the banks of d ata RAM ( Section 5.3.3 “General Purpose Register File”) or a location in the Access Bank (Section 5.3.2 “Access Bank”) as the data source for the instruction.

The Access RA M bit, ‘a ’, deter mine s how the address is interpreted. When ‘a’ is ‘1’, the contents of the BSR (Section 5.3.1 “Bank Select Register (BSR)”) are used with the address t o determin e the comple te 12-bit address of the reg ister. When ‘a’ is ‘0’, the address is interpreted as being a register in the Access Bank. Addressing that uses the Access RAM is sometimes also known as Direct Forced Addressing mode.

A few instructions, such as MOVFF, include the entire 12-bit address (either source or destination) in their opcodes. In these cases, the BSR is ignored entirely.

The destination of the operati on’s results is determined by the destination bit, ‘d ’. When ‘d’ is ‘1’, the re sult s a re stored back in th e s o ur c e re g is ter, overw rit i n g i ts or i ginal contents. When ‘d’ is ‘0’, the results are stored in the W register. Instructions without the ‘d’ argument have a destin ation tha t is i mplicit in the inst ruction; their destination is either the target register being operated on or the W register.

5.4.3 INDIRECT ADDRESSING

Indirect Addressin g allows the u ser to access a l ocation in data memory without giving a fixed address in the instruction. This is done by using File Select Registers (FSRs) as pointers to the location s to be read or written to. Since the FSRs are themselves located in RAM as Special Function Registers, they can also be directly manipulated under program control. This makes FSRs very useful in implementing data structures, such as tables and arrays in data memory.

The registers for Indirect Addressing are also implemented with Indirect File Operands (INDFs) that permit automatic mani pulati on of the poi nter value with auto-incrementing, auto-decrementing or offsetting with another va lue . Th is al lo ws f or e fficient code, us ing loops, such as the example of clearing an entire RAM bank in Example5-5.

EXAMPLE 5-5: HOW TO CLEAR RAM

(BANK 1) USING INDIRECT ADDRESSING

PIC18F2525/2620/4525/4620

FSR1H:FSR1L

Data Memory

000h

100h

200h

300h

F00h

E00h

FFFh

Bank 0 Bank 1

Bank 2

Bank 14

Bank 15

Bank 3

through

Bank 13

ADDWF, INDF1, 1

Using an instruction with one of the indirect addressing registers as the

operand....

...uses the 12-bit address stored in the FSR pair associated with that

...to determine the data memory location to be used in that operation.

In this case, the FSR1 pair contains ECCh. This means the contents of location ECCh will be added to that of the W register and stored back in ECCh.

xxxx1110 11001100

5.4.3.1 FSR Registers and the INDF Operand

At the core of Indirect Addressing are three sets of registers: FSR0, FSR1 and FSR2. Each represents a pair of 8-bit registers, FSRnH and FSRnL. The four upper bits of the FSRnH register are not used so each FSR pair holds a 12-bi t va lue. T his repre sen ts a val ue that can address the entire range of the data memory in a linear fashion. The FSR register pairs, then, serve as pointers to data memory locations.

Indirect Addressing is accomplished with a set of Indirect File Operands, INDF0 through INDF2. These can be thought of as “virtual” registers: they are mapped in the SFR space but are not physically implemented. Reading or writin g to a particular INDF reg ister actually accesses its corresponding FSR register pair. A read from INDF1, for example, reads the data at the address indi cated by FSR 1H:FSR1L. Instructi ons that use the IND F registers a s operands actu ally use the contents of th eir co rrespon ding FS R as a poin ter to th e instruction’s target. The INDF operand is just a convenient way of using the pointer.

Because Indirect Ad dressing uses a fu ll 12-bit addr ess, data RAM banking is not necessary. Thus, the current contents of the BSR and the Access RAM bit have no effect on determining the target address.

5.4.3.2 FSR Registers and POSTI NC, POSTDEC, PREINC and PLUSW

In addition to the IND F operand, eac h FSR register pair also has four additional indirect operands. Like INDF, these are “virtual” registers that cannot be indirectly read or written to. Accessing these registers actually accesses the associated FSR register pair, but also performs a specifi c action on it s stored v alue. They ar e:

• POSTDEC: accesses the FSR value, then

automatically decrements it by 1 afterwards

• POSTINC: accesses the FSR value, then

automatically increments it by 1 afterwards

• PREINC: increments the FSR value by 1, then

uses it in the operation

• PLUSW: adds the signed value of the W register

(range of -127 to 128) t o that of th e FSR and uses the new value in the operation.

In this context, accessing an INDF register uses the value in the FSR registers with out changing the m. Similarly , acces sing a PLUSW register giv es the FSR v alue offset by that in the W registe r; neit her value is ac tuall y changed in the operation. Accessing the other virtual registers changes the value of the FSR registers.

Operations on the FSRs with POSTDEC, POSTINC and PREINC affect the entire register pair; that is, rollovers of the FSRnL register from FFh to 00h ca rry over to the FSRnH register. On the other hand, results of these operations do not change the value of any flags in the STATUS register (e.g., Z, N, OV, etc.).

FIGURE 5-7: INDIRECT ADDRESSING

PIC18F2525/2620/4525/4620

The PLUSW register can be used to implement a form of Indexed Addressing in the data memory space. By manipulating the value in the W register, users can reach addresses that are fixed offsets from pointer addresses. In some applications, this can be used to implement some powerful program control structure, such as software stacks, inside of data memory.

5.4.3.3 Operations by FSRs on FSRs

Indirect Addressing operations that target other FSRs or virtual registers represent special cases. For example, using an FSR to point to on e of the virtual regis ters will not result in successful operations. As a specific case, assume that FSR0H:FSR0L contains FE7h, the address of INDF1. Attempts to read the value of the INDF1 using INDF0 as an operand will return 00h. Attempts to write to INDF1 using I NDF0 as the operan d will result in a NOP.

On the other ha nd, u sing the v irtual reg isters to w rite to an FSR pair may n ot oc cur as plan ned. I n t hese cases , the value will be written to the FSR p air bu t withou t an y incrementing or decrementing. Thus, writing to INDF2 or POSTDEC2 will write the same value to the FSR2H:FSR2L.

Since the FSRs are physical registers mapped in the SFR space, they can be manipulated through all direct operations. Users should proceed cautiously when working on these registers, particularly if their code uses Indirect Addressing.

Similarly, operations by Indirect Addressing are generally permitted on all other SFRs. Users should exercise the appropriate caution that they do not inadvertently change settings that might affect the operation of the device.

5.5 Data Memory and the Extended Instruction Set

Enabling the PIC18 extended instruction set (XINST Configuration bit = 1) significantly changes certain aspects of data me mory and it s addres sing. Specifically, the use of the Access Bank for many of the core PIC18 instructions is different; this is due to the introduction of a new addressing mode for the data memory spac e.

What does not change is just as im po rtant. The size of the data memory space is unchanged, as well as its linear addressing. The SFR map remains the same. Core PIC18 instructions can still operate in both Direct and Indirect Addressing mode; inherent and literal instructions do not change at all. Indirect Addressing with FSR0 and FSR1 also remains unchanged.

5.5.1 INDEXED ADDRESSING WITH LITERAL OFFSET

Enabling the PIC18 extended instruction set changes the behavior of Indirect Addressing using the FSR2 register pair within Access RAM. Under the proper conditions, instructions that use the Access Bank – that is, most bit-oriented and byte-oriented instructions – can invoke a form of Indexed Addressing using an offset specified in the instruction. This special addressing mode is known as Indexed Addressing with Literal Offset, or Indexed Literal Offse t mode.

When using the extended instruction set, this addressing mode requires the following:

• The use of the Access Bank is forced (‘a’ = 0);

and

• The file address arg um ent is less than or equal to

5Fh.

Under these conditions, the file address of the instruction is not interpreted as the lower byte of an address (used with the BSR in Direct Addres sing), or as an 8-bit address in the Access Bank. Instead, the value is interpreted as an offset value to an Address Pointer, specified by FSR2. The offset and the contents of FSR2 are added to obtain the target address of the operation.

5.5.2 INSTRUCTIONS AFFECTED BY INDEXED LITERAL OFFSET MODE

Any of the core PIC18 instructions that can use Direct Addressing are potentially affected by the Indexed Literal Offset Addressing mode. This includes all byte-oriented and bit-oriented instructions, or almost one-half of the standard PIC18 instruction set. Instructions that onl y use Inherent or Literal Addr essing modes are unaffecte d.

Additionally, byte-oriented and bit-oriented instructions are not affected if they do not use the Access Bank (Access RAM bit is ‘1’), or include a fi le ad dres s of 60 h or above. Instructions meeting these criteria will continue to execute as be fore. A comp aris on of the di fferent possible addressing modes when the extended instruction set is enabled is shown in Figure 5-8.

Those who desire to use bit-oriented or byte-oriented instructions in the Indexed Literal Offset mode should note the changes to assembler syntax for this mode. This is described in more detail in Section 24.2.1 “Extended Instruction Syntax”.

PIC18F2525/2620/4525/4620

EXAMPLE INSTRUCTION: ADDWF, f, d, a (Opcode: 0010 01da ffff ffff)

When ‘a’ = 0 and f ≥ 60h:

The instruction executes in Direct Forced mode. ‘f’ is interpreted as a location in the Access RAM between 060h and 0FFh. This is the sam e as locations 060h to 07Fh (Bank 0) and F80h to FFFh (Bank 15) of data memory.

Locations below 60h are not available in this addressing mode.

When ‘a’ = 0 and f ≤ 5Fh:

The instruction executes in Indexed Literal Offset mode. ‘f’ is interpreted as an offset to the address value in FSR2. The two are added together to obtain the address of the target register for the instruction. The address can be anywhere in the data memory space.

Note that in this mode, the correct syntax is now:

ADDWF [k], d

where ‘k’ is the same as ‘f’.

When ‘a’ = 1 (all values of f):

The instruction executes in Direct mode (also known as Direct Long mode). ‘f’ is interpreted as a location in one of the 16 banks of the data memory space. The bank is designated by the Bank Sel ect Register (BSR). The address can be in any implemented bank in the data memory space.

000h 060h

100h

F00h

F80h

FFFh

Valid range

00h 60h

80h

FFh

Data Memory

Access RAM

Bank 0

Bank 1 through

Bank 14

Bank 15

SFRs

000h

080h

100h

F00h

F80h

FFFh

Data Memory

Bank 0

Bank 1 through

Bank 14

Bank 15

SFRs

FSR2H FSR2L

ffffffff001001da

000h

080h

100h

F00h

F80h

FFFh

Data Memory

Bank 0

Bank 1 through

Bank 14

Bank 15

SFRs

for ‘f’

BSR

00000000

080h

FIGURE 5-8: COMPARING ADDRESSING OPTIONS FOR BIT-ORIENTED AND

BYTE-ORIENTED INSTRUCTIONS (EXTENDED INSTRUCTION SET ENABLED)

PIC18F2525/2620/4525/4620

Data Memory

000h

100h

200h

F80h

F00h

FFFh

Bank 1

Bank 15

Bank 2

through

Bank 14

SFRs

05Fh

ADDWF f, d, a

FSR2H:FSR2L = 120h

Locations in the region from the FSR2 Pointer (120h) to the pointer plus 05Fh (17Fh) are mapped to the bottom of the Access RAM (000h-05Fh).

Locations in Bank 0 from 060h to 07Fh are mapped, as usual, to the middle of the Access Bank.

Special Function Registers at F80h through FFFh are mapped to 80h through FFh, as usual.

Bank 0 addresses below 5Fh can still be addressed by using the BSR.

Access Bank

00h

80h

FFh

7Fh

Bank 0

SFRs

Bank 1 “Window”

Bank 0

Window

Example Situation:

07Fh

120h 17Fh

5Fh

Bank 1

5.5.3 MAPPING THE ACCESS BANK IN INDEXED LITERAL OFFSET ADDRESSING MODE

The use of Indexed Literal Offset Addressing mode effectively chan ges how the first 96 locati ons of Access RAM (00h to 5Fh) are m ap ped . R at her tha n c on taining just the contents of the bottom half of Bank 0, this mode maps the contents from Bank 0 and a user-defined “window” that can be located anywhere in the data memory space. The value of FSR2 establishes the lower boundary of the addresses mapped into the window, while the upper boundary is defined by FSR2

Remapping of the Access Bank applies only to operations using the Indexed Literal Offset Addressing mode. Operations that us e the BSR (Access RAM bit is ‘1’) will continue to use Direct Addressing as before.

5.6 PIC18 Instruction Execution and the Extended Instruction Set

Enabling the extended instruction set adds eight additional commands to the existing PIC18 instruction set. These instructions are executed as described in Section 24.2 “Extended Instruction Set”.

plus 95 (5Fh). Addresses in the Access RAM above 5Fh are mapped as previously described (see Section 5.3.2 “Access Bank”). An example of Access Bank remapping in this addressing mode is shown in Figure 5-9.

FIGURE 5-9: REMAPPING THE ACCESS BANK WITH INDEXED LITERAL OFFSET

ADDRESSING MODE

PIC18F2525/2620/4525/4620

NOTES:

PIC18F2525/2620/4525/4620

6.0 DATA EEPROM MEMORY

The data EEPROM is a nonvolatile memory array, separate from the dat a RAM and program memory, that is used for long-term storage of program data. It is not directly mapped in either the register file or program memory space but is indirectly addressed through the Special Function Registers (SFRs). The EEPROM is readable and writab le during no rmal operati on over the entire V

Five SFRs are used to read and write to the data EEPROM as well as the program memory. They are:

• EECON1

• EECON2

• EEDATA

• EEADR

• EEADRH The data EEPROM allows byte read and write. When

interfaci ng to the data mem ory block, EEDATA holds the 8-bit data for read/write and the EEADRH:EEADR register pair holds the address of the EEPROM loc ation being accessed.

The EEPROM data memory is rated for high erase/write cycle endurance. A byte write automatically erases the location and writes the new data (erase-before-write). The write time is controlled by an on-chip timer; it will vary with voltage and temperature as well as from chip to chip. Please refer to parameter D122 (Table 26-1 in Section 26.0 “Electrical Characteristics”) for exact limits.

6.1 EEADR and EEADRH Registers

The EEADRH:EEADR register pair is used to address the data EEPROM for read and write operations. EEADRH holds the two MSbits of the address; the upper 6 bits are i gnored. The 10- bit range of the pair can address a memory range of 1024 bytes (00h to 3FFh).

6.2 EECON1 and EECON2 Registers

DD range.

The EECON1 register (Register 6-1) is the control register for data and program memory access. Control bit EEPGD determines if the acce ss wi ll be to program or data EEPROM memory. When clear, operations will access the data EEPROM memory . When set, program memory is accessed.

Control bit, CFGS, determines if the access will be to the Configuration reg ist ers or to pro gram m em ory/data EEPROM memory. When set, subsequent operations access Configuration registers. When CFGS is clear, the EEPGD bit selects either Flash program or data EEPROM memory.

The WREN bit, when set, will allow a write operation. On power-up, the WREN bit is c lear . Th e WRERR bit is set in hardware when the WREN bit is set and cleared when the internal programming timer expires and the write operation is complete.

Note: Dur ing normal operatio n, the WRERR is

read as ‘1’. This can indicate that a write operation was prematurely terminated by a Reset, or a write operation was attempted improperly.

The WR control bit initiates write operations. The bit cannot be cleared, only set, in software; it is cleared in hardware at the completion of the write operation.

Note: The EEIF interrupt flag bit (PIR2<4>) is set

when the write is complete. It must be cleared in software.

Control bits, RD and WR, start read and erase/write operations, respec tively . These bits a re set by firmwa re and cleared by hardware at the completion of the operation.

The RD bit cannot be set when accessing program memory (EEPGD = 1). Program memory is read using table read instructions. See Section 7.1 “Tabl e Reads and Table Writes” regarding table reads.

The EECON2 register is not a physical register. It is used exclusively in the memory write and erase sequences. Reading EECON2 will read all ‘0’s.

Access to the data EEPROM is controlled by two registers: EECON1 and EECO N2. These are the same registers which control access to the program memory and are used in a similar manner for the data EEPROM.

PIC18F2525/2620/4525/4620

REGISTER 6-1: EECON1: EEPROM CONTROL REGISTER 1

R/W-x R/W-x U-0 R/W-0 R/W-x R/W-0 R/S-0 R/S-0

EEPGD CFGS

bit 7 bit 0

Legend: S = Set only bit (cannot be cleared in software) R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 EEPGD: Flash Program or Data EEPROM Memory Select bit

1 = Access Flash program memory 0 = Access data EEPROM memory

bit 6 CFGS: Flash Program/Data EEPROM or Configuration Select bit

1 = Access Configuration registers 0 = Access Flash program or data EEPROM memory

bit 5 Unimplemented: Read as ‘0’ bit 4 FREE: Flash Row Erase Enable bit

1 = Erase the program memory row addressed by TBLPTR on the next WR command (cleared by

completion of erase operation)

0 = Perform write only

bit 3 WRERR: Flash Program/Data EEPROM Error Flag bit

1 = A write operation is prematurely terminated (any Reset during self-timed programming in normal

operation, or an improper write attempt)

0 = The write operation completed

bit 2 WREN: Flash Program/Data EEPROM Write Enable bit

1 = Allows write cycles to Flash program/data EEPROM 0 = Inhibits write cycles to Flash program/data EEPROM

bit 1 WR: Write Control bit

1 = Initiates a data EEPROM erase/write cycle or a program memory erase cycle or write cycle

(The operation is self-timed and the bit is c le ared by ha rdw are on ce w rite is c om ple te. The WR b it can only be set (not cleared) in software.)

0 = Write cycle to the EEPROM is complete

bit 0 RD: Read Control bit

1 = Initiates an EEPROM read (Read takes one cycle. RD is cleared in hardware. The RD bit can only

be set (not cleared) in software. RD bit cannot be set when EEPGD = 1 or CFGS = 1.)

0 = Does not initiate an EEPROM read

— FREE WRERR

(1)

WREN WR RD

(1)

Note 1: When a WRERR occurs, the EEPGD and CFGS bits are not cleared. This allows tracing of the error

condition.

PIC18F2525/2620/4525/4620

MOVLW DATA_EE_ADDRH ; MOVWF EEADRH ; Upper bits of Data Memory Address to read MOVLW DATA_EE_ADDR ; MOVWF EEADR ; Lower bits of Data Memory Address to read BCF EECON1, EEPGD ; Point to DATA memory BCF EECON1, CFGS ; Access EEPROM BSF EECON1, RD ; EEPROM Read MOVF EEDATA, W ; W = EEDATA

MOVLW DATA_EE_ADDRH ; MOVWF EEADRH ; Upper bits of Data Memory Address to write MOVLW DATA_EE_ADDR ; MOVWF EEADR ; Lower bits of Data Memory Address to write MOVLW DATA_EE_DATA ; MOVWF EEDATA ; Data Memory Value to write BCF EECON1, EPGD ; Point to DATA memory BCF EECON1, CFGS ; Access EEPROM BSF EECON1, WREN ; Enable writes

BCF INTCON, GIE ; Disable Interrupts MOVLW 55h ;

Required MOVWF EECON2 ; Write 55h Sequence MOVLW 0AAh ;

MOVWF EECON2 ; Write 0AAh BSF EECON1, WR ; Set WR bit to begin write BSF INTCON, GIE ; Enable Interrupts

; User code execution

BCF EECON1, WREN ; Disable writes on write complete (EEIF set)

6.3 Reading the Data EEPROM Memory

T o read a d ata memory loca tion, the user must write the address to the EEADRH:EEADR register pair , clear the EEPGD control bit (EECON1<7>) and then set control bit, RD (EECON1<0>). The data is available on the very next instruction cycle; therefore, the EEDATA register can be read by the next instruction. EEDATA will hold this valu e un til another read operation, or until it is written to by the user (during a write operation).

The basic process is shown in Example 6-1.

6.4 Writing to the Data EEPROM Memory

To write an EEPROM data location, the address must first be written to the EEADRH:EEADR register pair and the data written to the EEDATA register. The sequence in Example6-2 must be followed to initiate the write cycle.

The write will not begin if this sequence is not exactly followed (write 55h to EECON2, write 0AAh to EECON2, then set WR bit) for each byte. It is strongly recommended that interrupts be disabled during this code segment.

Additionally, the WREN bit in EECON1 must be set to enable writes. This mechanism prevents accidental writes to data EEPROM due to unexpected code execution (i.e., runaway programs). The WREN bit should be kept clear at all times , exc ept whe n u pdatin g the EEPROM. The WREN bit is not cleared by hardware.

After a write sequence has been initiated, EECON1, EEADRH:EEADR and EEDATA cannot be modified. The WR bit will be inhibited from being set unless the WREN bit is set. The WREN bit must be set on a previous instruction. Both WR and WREN cannot be set with the same instruction.

At the completion of the write cycle, the WR bit is cleared in hardware and the EEPROM Interrupt Flag bit, EEIF, is set. The user may either enable this interrupt, or poll this bit. EEIF must be cleared by software.

6.5 Write Verify

Depending on the application, good programming practice may dictate that the value written to the memory should be verified against the original value. This should be used in applications where excessive writes can stress bits near the specification limit.

EXAMPLE 6-1: DATA EEPROM READ

EXAMPLE 6-2: DATA EEPROM WRITE

PIC18F2525/2620/4525/4620

CLRF EEADR ; Start at address 0 CLRF EEADRH ; BCF EECON1, CFGS ; Set for memory BCF EECON1, EEPGD ; Set for Data EEPROM BCF INTCON, GIE ; Disable interrupts BSF EECON1, WREN ; Enable writes

Loop ; Loop to refresh array

BSF EECON1, RD ; Read current address MOVLW 55h ; MOVWF EECON2 ; Write 55h MOVLW 0AAh ; MOVWF EECON2 ; Write 0AAh BSF EECON1, WR ; Set WR bit to begin write BTFSC EECON1, WR ; Wait for write to complete BRA $-2 INCFSZ EEADR, F ; Increment address BRA LOOP ; Not zero, do it again INCFSZ EEADRH, F ; Increment the high address BRA LOOP ; Not zero, do it again

BCF EECON1, WREN ; Disable writes BSF INTCON, GIE ; Enable interrupts

6.6 Operation During Code-Protect

Data EEPROM memory has its own code-protect bits in Configuration Words. External read and write operations are disabled if code protection is enabled.

The microcontroller i tself can both re ad and wr ite to the internal data EEPROM, regardless of the state of the code-protect Configuration bit. Refer to Section 23.0 “Special Features of the CPU” for additional information.

6.7 Protection Against Spur ious Write

6.8 Using the Data EEPROM

The data EEPROM is a high-e ndurance, byte-a ddressable array that has been optimized for the storage of frequently changing information (e.g., program variables or other data that are updated often). Frequently changing values will typically be updated more often than specification D124. If this is not the case, an array refresh must be performed. For this reason, variables that change infrequently (such as constants, IDs, calibration, etc.) should be stored in Flash program memory.

A simple data EEPROM refresh routine is shown in

There are conditions when the device may not want to

Example 6-3.

write to the data EEPROM memory. To protect against spurious EEPROM writes, various mechanisms have been implemented. On power-up, the WREN bit is cleared. In addition, writes to the EEPROM are b locked during the Power-up Timer period (T

PWRT,

parameter 33). The write initiate se quence and the WREN bit tog eth er

help prevent an accidental write during Brown-out Reset, power glitch or software malfunction.

EXAMPLE 6-3: DATA EEPROM REFRESH ROUTINE

Note: If data EEPROM is only used to store

constants and/or data that changes often, an array refresh is likely not required. See specification D124.

PIC18F2525/2620/4525/4620

T ABLE 6-1: REGISTERS ASSOCIATED WITH DATA EEPROM MEMORY

Reset

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

INTCON GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 49 EEADRH

EEADR EEPRO M Address Register 51 EEDATA EEPROM Data Register 51 EECON2 EEPROM Control Register 2 (not a physical register) 51 EECON1 EEPGD CFGS IPR2 OSCFIP CMIP PIR2 OSCFIF CMIF — EEIF BCLIF HLVDIF TMR3IF CCP2IF 52 PIE2 OSCFIE CMIE — EEIE BCLIE HLVDIE TMR3IE CCP2IE 52 Legend: — = unimplemented, read as ‘0’. Shaded cells are not used during Flash/EEPROM access.

— — — — — — EEPROM Address Register

High Byte

— FREE WRERR WREN WR RD 51 — EEIP BCLIP HLVDIP TMR3IP CCP2IP 52

Values

on page

PIC18F2525/2620/4525/4620

NOTES:

PIC18F2525/2620/4525/4620

Table Pointer

(1)

Table Latch (8-bit)

Program Memory

TBLPTRH TBLPTRL

TABLAT

TBLPTRU

Instruction: TBLRD*

Note 1: Table Pointer register points to a byte in program memory.

Program Memory (TBLPTR)

7.0 FLASH PROGRAM MEMORY

The Flash program memory is readable, writable and erasable during normal operation over the entire V range.

A read from program memory is executed on one byte at a time. A write to program memory is executed on blocks of 64 bytes at a time. Program memory is erased in blocks of 64 bytes at a time. A bulk erase operation may not be issued from user code.

Writing or erasing program memory will cease instruction fetches until the operation is complete. The program memory cannot be accessed during the write or erase, therefore, code cannot execute. An internal programming timer terminates program memory writes and erases.

A value written to progra m memory does not nee d to be a valid instruction. Executing a program memory location that forms an invalid instruction results in a NOP.

7.1 Table Reads and Table Writes

In order to read and write program memory, there are two operations that allow the processor to move bytes between the program memory sp ace and the dat a RAM:

• Table Read (TBLRD)

• Table Write (TBLWT) The program memory space is 16 bits wide, while the

data RAM space is 8 bits wide. Table reads and table writes move data between these two memory spaces through an 8-bit register (TABLAT).

Table read operations retrieve data from program memory and place it into the data RAM space. Figure 7-1 shows the operation of a table read with program memory and data RAM.

Table write opera tions s tor e data from t he da ta memo ry space into holding registers in program memory. The procedure to write the contents of the holding registers into program memory is detailed in Section 7.5 “Writing to Flash Program Memory”. Figure7-2 shows the operation of a table write with program memory and data RAM.

Table operations work with byte entities. A table block containing data, rather than program instructions, is not required to be word aligned. Therefore, a table block can start and end at any byte address. If a t able write is being used to write executable code into program memory, program instructions will need to be word-aligned.

FIGURE 7-1: TABLE READ OPERATION

PIC18F2525/2620/4525/4620

Table Pointer

(1)

Table Latch (8-bit)

TBLPTRH TBLPTRL

TABLAT

Program Memory (TBLPTR)

TBLPTRU

Instruction: TBLWT*

Note 1: Table Pointer actually points to one of 64 holding registers, the address of which is determined by

TBLPTRL<5:0>. The process for physically writing data to the program memor y array is discusse d in Section 7.5 “Writing to Flash Pr ogr am Memory”.

Holding Registers

Program Memory

FIGURE 7-2: TABLE WRITE OPERATION

7.2 Control Registers

Several control registers are used in conjunction with the TBLRD and TBLWT instructions. These include the:

• EECON1 register

• EECON2 register

• TABLAT register

• TBLPTR registers

7.2.1 EECON1 AND EECON2 REGISTERS

The EECON1 register (Register 7-1) is the control register for memory acce sses. The EECO N2 register is not a physical register; it is used exclusively in the memory write and erase sequences. Reading EECON2 will read all ‘0’s.

The EEPGD control bit determines if th e access will be a program or data EEPROM memory access. When clear, any subsequent operations will operate on the data EEPROM memory. When set, any subsequent operations will operate on the program memory.

The CFGS control bit determines if the access will be to the Configuration/C alib ration re giste rs or to pro gram memory/data EEPROM memory. When set, subsequent operations will operate on Configuration registers regardless of EEPGD (see Section 23.0 “Special Features of the CPU”). When clear, memory selection access is determined by EEPGD.

The FREE bit, when set, will allow a program memory erase operation. When FREE is set, the erase operation is initiated on the next WR command. When FREE is clear , only wr ite s are enab led .

The WREN bit, when set, will allow a write operation. On power-up, the WREN bit is c lear . The WRERR bit is set in hardware when the WR bit is set and cleared when the internal programming timer expires and the write operation is complete.

Note: During normal operation, the WRERR

may read as ‘1’. This can indicate that a write operation was prematurely terminated by a Reset, or a write operation was attempted improperly.

The WR control bit initiates write operations. The bit cannot be cleared, only set, in software; it is cleared in hardware at the completion of the write operation.

Note: The EEIF interrupt flag bit (PIR2<4>) is set

when the write is complete. It must be cleared in software.

PIC18F2525/2620/4525/4620

REGISTER 7-1: EECON1: DATA EEPROM CONTROL REGISTER 1

R/W-x R/W-x U-0 R/W-0 R/W-x R/W-0 R/S-0 R/S-0

EEPGD CFGS

bit 7 bit 0

Legend: S = Set only bit (cannot be cleared in software) R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’

-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown

bit 7 EEPGD: Flash Program or Data EEPROM Memory Select bit

1 = Access Flash program memory 0 = Access data EEPROM memory

bit 6 CFGS: Flash Program/Data EEPROM or Configuration Select bit

1 = Access Configuration registers 0 = Access Flash program or data EEPROM memory

bit 5 Unimplemented: Read as ‘0’ bit 4 FREE: Flash Row Erase Enable bit

1 = Erase the program memory row addressed by TBLPTR on the next WR command (cleared by

completion of erase operation)

0 = Perform write only

bit 3 WRERR: Flash Program/Data EEPROM Error Flag bit

1 = A write operation is prematurely terminated (any Reset during self-timed programming in normal

operation, or an improper write attempt)

0 = The write operation completed

bit 2 WREN: Flash Program/Data EEPROM Write Enable bit

1 = Allows write cycles to Flash program/data EEPROM 0 = Inhibits write cycles to Flash program/data EEPROM

bit 1 WR: Write Control bit

1 = Initiates a data EEPROM erase/write cycle or a program memory erase cycle or write cycle

(The operation is self-timed and the bit is c le ared by ha rdw are on ce w rite is c om ple te. The WR b it can only be set (not cleared) in software.)

0 = Write cycle to the EEPROM is complete

bit 0 RD: Read Control bit

1 = Initiates an EEPROM read (Read takes one cycle. RD is cleared in hardware. The RD bit can only

be set (not cleared) in software. RD bit cannot be set when EEPGD = 1 or CFGS = 1.)

0 = Does not initiate an EEPROM read

— FREE WRERR

(1)

WREN WR RD

Note 1: When a WRERR occurs, the EEPGD and CFGS bits are not cleared. This allows tracing of the error

condition.

PIC18F2525/2620/4525/4620

21 16 15 87 0

TABLE ERASE/WRITE TABLE WRITE

TABLE READ – TBLPTR<21:0>

TBLPTRL

TBLPTRH

TBLPTRU

TBLPTR<5:0>TBLPTR<21:6>

7.2.2 TABLAT – TABLE LATCH REGISTER

The Table Latch (TABLAT) is an 8-bit register mapped into the SFR space. The Table Latch register is used to hold 8-bit data during data transfers between program memory and data RAM.

7.2.3 TBLPTR – TABLE POINTER REGISTER

The Table Poin ter (T BLPTR ) re gis ter add res se s a byte within the program memory. The TBLPTR is comprised of three SFR registers : Table Pointer Upper Byte, Table Pointer High Byte and Table Pointer Low Byte (TBLPTRU:TBLPTRH:TBLPTRL). These three registers join to form a 22-bit wide po inter. The low-o rder 21 bits allow the device to address up to 2 Mbytes of program memory sp ace. Th e 22nd b it allow s acce ss to the Device ID, the user ID and the Configuration bits.

The Table Pointer register, TBLPTR, is used by the TBLRD and TBLWT instructi ons . T hes e i ns truc tio ns ca n update the TBLPTR in one of four ways based on the table operation. These operations are shown in T abl e 7-1. These operations on the TBLPTR only af fect the low-order 21 bits.

7.2.4 TABLE POINTER BOUNDARIES

TBLPTR is used in reads, writes and erases of the Flash program memory.

When a TBLRD is executed, al l 22 bits of th e T BLPT R determine which byte is read from program memory into TABL AT.

When a TBLWT is executed, the six LSbs of the Table Pointer register (TBLPTR<5 :0>) determine which o f the 64 program memory holding registers is written to. When the timed write to program memory begins (via the WR bit), the 16 MSbs of the TBLPTR (TBLPTR<21:6>) determine which program memory block of 64 bytes is written to. For more detail, see Section 7.5 “Writing to Flash Program Memory”.

When an erase of program memory is executed, the 16 MSbs of the T able Pointer reg ister (TBLPTR<21:6 >) point to the 64-byte block that will be erased. The Least Significant bits (TBLPTR<5:0>) are ignored.

Figure 7-3 describes the relevant boundaries of TBLPTR based on Flash program memory operations.

TABLE 7-1: TABLE POINTER OPERATIONS WITH TBLRD AND TBLWT INSTRUCTIONS

Example Operation on Table Pointer

TBLRD* TBLWT*

TBLRD*+ TBLWT*+

TBLRD*TBLWT*-

TBLRD+* TBLWT+*

TBLPTR is incremented after the read/write

TBLPTR is decremented after the read/write

TBLPTR is incremented before the read/write

TBLPTR is not modified

FIGURE 7-3: TABLE POINTER BOUNDARIES BASED ON OPERATION

PIC18F2525/2620/4525/4620

(Even Byte Address)

Program Memory

(Odd Byte Address)

TBLRD

TABLAT

TBLPTR = xxx xx1

FETCH

Instruction Register

(IR)

Read Register

TBLPTR = xxxxx0

MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base MOVWF TBLPTRU ; address of the word MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL

READ_WORD

TBLRD*+ ; read into TABLAT and increment MOVF TABLAT, W ; get data MOVWF WORD_EVEN TBLRD*+ ; read into TABLAT and increment MOVF TABLAT, W ; get data MOVWF WORD_ODD

7.3 Reading the Flash Program Memory

The TBLRD instruction is used to retrieve data from program memory and places it into data RAM. Table reads from program memory are pe rformed one by te at a time.

TBLPTR poi nts to a byte address in pro gram space. Executing TBLRD places the byte pointed to into TABLAT. In addition, TBLPTR can be modified automatically for the next table read operation.

The internal program memory is typically organize d by words. The Least Sig nificant b it of th e address selects between the high and low bytes of the word. Figure 7-4 shows the interface between the internal program memory and the TABLAT.

FIGURE 7-4: READS FROM FLASH PROGRAM MEMORY

EXAMPLE 7-1: READING A FLASH PROGRAM MEMORY WORD

PIC18F2525/2620/4525/4620

MOVLW CODE_ADDR_UPPER ; load TBLPTR with the base MOVWF TBLPTRU ; address of the memory block MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL

ERASE_ROW

BSF EECON1, EEPGD ; point to Flash program memory BCF EECON1, CFGS ; access Flash program memory BSF EECON1, WREN ; enable write to memory BSF EECON1, FREE ; enable Row Erase operation BCF INTCON, GIE ; disable interrupts

Required MOVLW 55h Sequence MOVWF EECON2 ; write 55h

MOVLW 0AAh MOVWF EECON2 ; write 0AAh BSF EECON1, WR ; start erase (CPU stall) BSF INTCON, GIE ; re-enable interrupts

7.4 Erasing Flash Program Memory

The minimum eras e block is 32 wo rds or 64 b ytes. Only through the use of an external programmer, or through ICSP control, can larger blocks of program memory be bulk erased. Word erase in the Flash array is not supported.

When initiating an erase sequence from the microcontroller itself, a blo ck of 64 bytes of program memo ry is erased. The Most Significant 16 bits of the TBLPTR<21:6> point to the block being erased. TBLPTR<5:0> are ignored.

The EECON1 register comma nds the erase operation. The EEPGD bit must be set to point to the Flash program memory. The WREN bit must be set to enable write operations. The F REE bit is set to select an erase operation.

For protection, the wri te i ni tiat e s equ enc e f or EECO N2 must be used.

A long write is nec essa ry for erasin g the i nternal Flash. Instruction execution is halted while in a long write

7.4.1 FLASH PROGRAM MEMORY ERASE SEQUENCE

The sequence of events for erasing a block of internal program memory location is:

1. Load Table Pointer register with address of row

being erased.

2. Set the EECON1 register for the erase operation:

• set EEPGD bit to point to program memory;

• clear the CFGS bit to access program memory;

• set WREN bit to enable writes;

• set FREE bit to enable the erase.

3. Disable interrupts.

4. Write 55h to EECON2.

5. Write 0AAh to EECON2.

6. Set the WR bit. This will begin the row erase

cycle.

7. The CPU will stall for duration of the erase

(about 2 ms using internal timer).

8. Re-enable interrupts.

cycle. The long write will be terminated by the internal programming timer.

EXAMPLE 7-2: ERASING A FLASH PROGRAM MEMORY ROW

PIC18F2525/2620/4525/4620

TABLAT

TBLPTR = xxxx3FTBLPTR = xxxxx1TBLPTR = xxxxx0

Write Register

TBLPTR = xxxx x2

Program Memory

Holding Register Holding Register Holding Register Holding Register

8 8 8

7.5 Writing to Flash Program Memory

The minimum programming block is 32 words or 64 bytes. Word or byte programming is not supported.

Table writes are used internally to load the holding registers needed to program the Flash memory. There are 64 holding registers used by the table writes for programming.

Since the Table Latch (TABLAT) is only a single byte, the TBLWT instruction may need to be executed 64 times for each programming operation. All of the table write operations will essentially be short writes because only t he holding registers are writt en. At the end of updating the 64 holding registers, the EECON1 register must be written to in order to start the programming op eration with a l on g w rit e.

The long write is necessary for programming the internal Flash. Instructio n execu tion is halted wh ile in a long write cycle. The long write will be terminated by the internal programming timer.

The EEPROM on-chip timer controls the write time. The write/erase voltages are generated by an on-chip charge pump, rated to operate over the voltage range of the device.

Note: The default value of the holding registers on

device Resets and aft er write op eratio ns is FFh. A write of FFh to a holding register does not modify that byte. T his mea ns th at individual bytes of program memory may be modified, provided that the change does not attempt to chang e any bi t from a ‘0’ to a ‘1’. When modifying individual bytes, it is not necessary to load all 64 holding registers before executing a write ope ration.

FIGURE 7-5: TABLE WRITES TO FLASH PROGRAM MEMORY

7.5.1 FLASH PROGRAM MEMORY WRITE SEQUENCE

The sequence of events for programming an internal program memory location should be:

1. Read 64 bytes into R AM.

2. Update data values in RAM as necessary.

3. Load Table Pointer register with address being

erased.

4. Execute the row erase procedure.

5. Load Table Pointer register with address of first

byte being written.

6. Write the 64 by tes in to the hold ing reg isters wi th

auto-increment.

7. Set the EECON1 register for the w rite operation:

• set EEPGD bit to point to program memory;

• clear the CFGS bit to access program memory;

• set WREN to enable byte writes.

8. Disable interrupts.

9. Write 55h to EECON2.

10. Write 0AAh to EECON2. 1 1. Set the WR bit. This will begin the write cycl e.

12. The CPU will stall for dura tion of t he write (a bout 2 m s using internal timer).

13. Re-enable interrupts.

14. Verify the memory (table read).

This procedure will require about 6 ms to update one row of 64 bytes of memory. An example of the required code is given in Example 7-3.

Note: Before setting the WR bit, the Table

Pointer address needs to be within the intended address range of the 64 bytes in the holding register.

PIC18F2525/2620/4525/4620

MOVLW D'64 ; number of bytes in erase block MOVWF COUNTER MOVLW BUFFER_ADDR_HIGH ; point to buffer MOVWF FSR0H MOVLW BUFFER_ADDR_LOW MOVWF FSR0L MOVLW CODE_ADDR_UPPER ; Load TBLPTR with the base MOVWF TBLPTRU ; address of the memory block MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL

READ_BLOCK

TBLRD*+ ; read into TABLAT, and inc MOVF TABLAT, W ; get data MOVWF POSTINC0 ; store data DECFSZ COUNTER ; done? BRA READ_BLOCK ; repeat

MODIFY_WORD

MOVLW DATA_ADDR_HIGH ; point to buffer MOVWF FSR0H MOVLW DATA_ADDR_LOW MOVWF FSR0L MOVLW NEW_DATA_LOW ; update buffer word MOVWF POSTINC0 MOVLW NEW_DATA_HIGH MOVWF INDF0

ERASE_BLOCK

MOVLW CODE_ADDR_UPPER ; load TBLPTR with the base MOVWF TBLPTRU ; address of the memory block MOVLW CODE_ADDR_HIGH MOVWF TBLPTRH MOVLW CODE_ADDR_LOW MOVWF TBLPTRL BSF EECON1, EEPGD ; point to Flash program memory BCF EECON1, CFGS ; access Flash program memory BSF EECON1, WREN ; enable write to memory BSF EECON1, FREE ; enable Row Erase operation BCF INTCON, GIE ; disable interrupts MOVLW 55h

Required MOVWF EECON2 ; write 55h Sequence MOVLW 0AAh

MOVWF EECON2 ; write 0AAh BSF EECON1, WR ; start erase (CPU stall) BSF INTCON, GIE ; re-enable interrupts TBLRD*- ; dummy read decrement MOVLW BUFFER_ADDR_HIGH ; point to buffer MOVWF FSR0H MOVLW BUFFER_ADDR_LOW MOVWF FSR0L

WRITE_BUFFER_BACK

MOVLW D’64 ; number of bytes in holding register MOVWF COUNTER

WRITE_BYTE_TO_HREGS

MOVFF POSTINC0, WREG ; get low byte of buffer data MOVWF TABLAT ; present data to table latch TBLWT+* ; write data, perform a short write

; to internal TBLWT holding register. DECFSZ COUNTER ; loop until buffers are full BRA WRITE_WORD_TO_HREGS

EXAMPLE 7-3: WRITING TO FLASH PROGRAM MEMORY

PIC18F2525/2620/4525/4620

PROGRAM_MEMORY

BSF EECON1, EEPGD ; point to Flash program memory BCF EECON1, CFGS ; access Flash program memory BSF EECON1, WREN ; enable write to memory BCF INTCON, GIE ; disable interrupts MOVLW 55h

Required MOVWF EECON2 ; write 55h Sequence MOVLW 0AAh

MOVWF EECON2 ; write 0AAh BSF EECON1, WR ; start program (CPU stall) BSF INTCON, GIE ; re-enable interrupts BCF EECON1, WREN ; disable write to memory

EXAMPLE 7-3: WRITING TO FLASH PROGRAM MEMORY (CONTINUED)

7.5.2 WRITE VERIFY

7.5.3 UNEXPECTED TERMINATION OF WRITE OPERATION

If a write is termin ate d b y a n u npl anned event, such as loss of power or an unexpected Reset, the memory location just pr ogrammed shou ld be verifi ed and repr ogrammed if needed. If the wr ite operatio n is interrupte d by a MCLR normal operation, the user can check the WRERR bit and rewrite the location(s) as needed.

Reset or a WDT Time-out Reset during

7.5.4 PROTECTION AGAINST SPURIOUS WRITES

To protect against spurious writes to Flash program memory, the write initiate sequence must also be followed. See Section23.0 “Special Features of

the CPU” for more detail.

7.6 Flash Program Operation During

Code Protection

See Section 23.5 “Program Verification and Code Protection” for details on code protection of Flash

program memory.

TABLE 7-2: REGISTERS ASSOCIATED WITH PROGRAM FLASH MEMORY

Reset

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TBLPTRU TBPLTRH Program Memory Table Pointer High Byte (TBLPTR<15:8>) 49 TBLPTRL Program Memory Table Pointer Low Byte (TBLPTR<7:0>) 49 TABLAT Program Memory Table Latch 49 INTCON GIE/GIEH PEIE/GIEL EECON2 EEPROM Control Register 2 (not a physical register) 51 EECON1 EEPGD CFGS IPR2 PIR2 PIE2 Legend: — = unimplemented, read as ‘0’. Shaded cells are not used during Flash/EEPROM access.

— — bit 21 Program Memory Table Pointer Upper Byte (TBLPTR<20:16>) 49

TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 49

— FREE WRERR WREN WR RD 51 OSCFIP CMIP — EEIP BCLIP HLVDIP TMR3IP CCP2IP 52 OSCFIF CMIF — EEIF BCLIF HLVDIF TMR3IF CCP2IF 52 OSCFIE CMIE — EEIE BCLIE HLVDIE TMR3IE CCP2IE 52

Values on

page

PIC18F2525/2620/4525/4620

NOTES:

PIC18F2525/2620/4525/4620

MOVF ARG1, W ; MULWF ARG2 ; ARG1 * ARG2 ->

; PRODH:PRODL

MOVF ARG1, W MULWF ARG2 ; ARG1 * ARG2 ->

; PRODH:PRODL BTFSC ARG2, SB ; Test Sign Bit SUBWF PRODH, F ; PRODH = PRODH

; - ARG1 MOVF ARG2, W BTFSC ARG1, SB ; Test Sign Bit SUBWF PRODH, F ; PRODH = PRODH

; - ARG2

8.0 8 x 8 HARDWARE MULTIPLIER

8.1 Introduction

All PIC18 devices include an 8 x 8 hardware multiplier as part of the ALU. The multiplier pe rforms an unsigned operation and yields a 16-bit result that is stored in the product register pair, PRODH:PRODL. The multiplier’s operation does not affect any flags in the STATUS register.

Making multiplication a hardware operation allows it to be completed in a single instructi on cy cl e. This has the advantages of higher computational throughput and reduced code size for multiplication algorithms and allows the PIC18 devices to be used in many applications previously reserved for digital signal processors. A comparison of various hardware and software multiply operations, along with the savings in memory and execution time, is shown in Table 8-1.

8.2 Operation

Example 8-1 shows the instruction seq uence for an 8 x 8 unsigned multiplication. Only one instruction is required when one of the arguments is already loaded in the WREG register.

Example 8-2 shows the sequence to do an 8 x 8 signe d multiplication. To account for the sign bits of the arguments, e ach argume nt’s Most Signi ficant b it (MSb) is tested and the appropriate subtractions are done.

EXAMPLE 8-1: 8 x 8 UNSIGNED

MULTIPLY ROUTINE

EXAMPLE 8-2: 8 x 8 SIGNED MULTIPLY

ROUTINE

TABLE 8-1: PERFORMANCE COMPARISON FOR VARIOUS MULTIPLY OPERATIONS

Routine Multiply Method

8 x 8 unsigned

8 x 8 signed

16 x 16 unsigned

16 x 16 signed

Program

Memory (Words)

Without hardware multiply 13 69 6.9 μs27.6 μs69 μs

Hardware multiply 1 1 100 ns 400 ns 1 μs

Without hardware multiply 33 91 9.1 μs36.4 μs91 μs

Hardware multiply 6 6 600 ns 2.4 μs6 μs

Without hardware multiply 21 242 24.2 μs96.8 μs242 μs

Hardware multiply 28 28 2.8 μs 11.2 μs28 μs

Without hardware multiply 52 254 25.4 μs 102.6 μs254 μs

Hardware multiply 35 40 4.0 μs16.0 μs40 μs

Cycles

(Max)

@ 40 MHz @ 10 MHz @ 4 MHz

Time

PIC18F2525/2620/4525/4620

RES3:RES0 = ARG1H:ARG1L • ARG2H:ARG2L

= (ARG1H • ARG2H • 2

) +

(ARG1H • ARG2L • 2

) +

(ARG1L • ARG2H • 2

) +

(ARG1L • ARG2L)

MOVF ARG1L, W MULWF ARG2L ; ARG1L * ARG2L->

; PRODH:PRODL MOVFF PRODH, RES1 ; MOVFF PRODL, RES0 ;

;

MOVF ARG1H, W MULWF ARG2H ; ARG1H * ARG2H->

; PRODH:PRODL MOVFF PRODH, RES3 ; MOVFF PRODL, RES2 ;

;

MOVF ARG1L, W MULWF ARG2H ; ARG1L * ARG2H->

; PRODH:PRODL MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;

;

MOVF ARG1H, W ; MULWF ARG2L ; ARG1H * ARG2L->

; PRODH:PRODL MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;

RES3:RES0 = ARG1H:ARG1L • ARG2H:ARG2L

= (ARG1H • ARG2H • 2

) +

(ARG1H • ARG2L • 2

) +

(ARG1L • ARG2H • 2

) + (ARG1L • ARG2L) + (-1 • ARG2H<7> • ARG1H:ARG1L • 2

) +

(-1 • ARG1H<7> • ARG2H:ARG2L • 2

)

MOVF ARG1L, W MULWF ARG2L ; ARG1L * ARG2L ->

; PRODH:PRODL MOVFF PRODH, RES1 ; MOVFF PRODL, RES0 ;

;

MOVF ARG1H, W MULWF ARG2H ; ARG1H * ARG2H ->

; PRODH:PRODL MOVFF PRODH, RES3 ; MOVFF PRODL, RES2 ;

;

MOVF ARG1L, W MULWF ARG2H ; ARG1L * ARG2H ->

; PRODH:PRODL MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;

;

MOVF ARG1H, W ; MULWF ARG2L ; ARG1H * ARG2L ->

; PRODH:PRODL MOVF PRODL, W ; ADDWF RES1, F ; Add cross MOVF PRODH, W ; products ADDWFC RES2, F ; CLRF WREG ; ADDWFC RES3, F ;

;

BTFSS ARG2H, 7 ; ARG2H:ARG2L neg? BRA SIGN_ARG1 ; no, check ARG1 MOVF ARG1L, W ; SUBWF RES2 ; MOVF ARG1H, W ; SUBWFB RES3

; SIGN_ARG1

BTFSS ARG1H, 7 ; ARG1H:ARG1L neg? BRA CONT_CODE ; no, done MOVF ARG2L, W ; SUBWF RES2 ; MOVF ARG2H, W ; SUBWFB RES3

; CONT_CODE :

Example 8-3 shows the sequence to do a 16 x 16 unsigned multiplication. Equation 8-1 shows the algorithm that is used . The 32-bit re sult is st ored in four registers (RES3:RES0).

EQUATION 8-1: 16 x 16 UNSIGNED

MULTIPLICATION ALGORITHM

EXAMPLE 8-3: 16 x 16 UNSIGNED

MULTIPLY ROUTINE

Example 8-4 shows the sequence to do a 16 x 16 signed multiply. Equation 8-2 shows the algorithm used. The 32-bit result is stored in four registers (RES3:RES0). To account for the sign bits of the arguments, the MSb for each argument pair is tested and the appropriate subtractions are done.

EQUATION 8-2: 16 x 16 SIGNED

MULTIPLICATION ALGORITHM

EXAMPLE 8-4: 16 x 16 SIGNED

MULTIPLY ROUTINE

PIC18F2525/2620/4525/4620

Data Bus

WR LAT

WR TRIS

RD Port

Data Latch

TRIS Latch

RD TRIS

Input Buffer

I/O pin

(1)

RD LAT

Port

Note 1: I/O pins have diode protection to V

DD and VSS.

CLRF PORTA ; Initialize PORTA by

; clearing output ; data latches

CLRF LATA ; Alternate method

; to clear output

; data latches MOVLW 07h ; Configure A/D MOVWF ADCON1 ; for digital inputs MOVWF 07h ; Configure comparators MOVWF CMCON ; for digital input MOVLW 0CFh ; Value used to

; initialize data

; direction MOVWF TRISA ; Set RA<7:6,3:0> as inputs

; RA<5:4> as outputs

9.0 I/O PORTS

Depending on the device selected and features enabled, there are up to five ports available. Some pins of the I/O ports are multiplexed with an alternate function from the peripheral features on the device. In general, when a periphe ral is ena bled, that pi n may not be used as a general purpose I/O pin.

Each port has three registers for its operation. These registers are:

• TRIS register (data direction register)

• PORT register (reads the lev els on the pin s of the device)

• LAT register (output latch)

The Data Latch (LAT register) is useful for read-modifywrite operations on the value that the I/O pins are driving.

A simplified model of a generic I/O port, without the interfaces to other peripherals, is shown in Figure 9-1.

FIGURE 9-1: GENERIC I/O PORT

OPERATION

Reading the PORTA register reads the status of the pins, whereas writing to it, will write to the port latch.

The Data Latch (LA TA) register is also me mory mapped. Read-modify-write operations on the LA TA register read and write the latched output value for PORTA.

The RA4 pin is multiplexed with the Timer0 module clock input and one of the comparator outputs to become the RA4/T0CKI/C1OUT pin. Pins RA6 and RA7 are multiplexed with the main oscillator pins; they are enabled as oscillator or I/O pins by the selection of the main oscillator in the Configuration register (see Section 23.1 “Configuration Bits” for details). When they are not used as port pins, RA6 and RA7 and their associated TRIS and LAT bits are read as ‘0’.

The other PORTA pins are multiplexed with analog inputs, the analog V

REF+ and VREF- inputs and the

comparator voltage reference output. The op eration of pins RA3:RA0 and RA5 as A/D converter inputs is selected by clearing or setting the control bits in the ADCON1 register (A/D Control Register 1).

Pins RA0 through RA5 may also be used as comparator inputs or outputs by setting the appropriate bits in the CMCON re giste r . To use RA3:RA0 as digital inputs , it is also necessary to turn off the comparators.

Note: On a Power-on Reset, RA5 and RA3:RA0

are configured as analog inputs and read as ‘0’. RA4 is configured as a digital input.

The RA4/T0 CK I /C 1O UT pi n is a S c hm itt Trigg e r in p ut . All other PORTA pins hav e TTL input level s. All PORTA pins have full CMOS output drivers.

The TRISA register co ntrols the di rection of the PO RTA pins, even when they a re be ing used as analog input s . The user must ensure the bit s in the TRISA registe r are maintained set when using them as analog inputs.

9.1 PORTA, TRISA and LATA Registers

PORTA is a 8-bit wide, bidirectional port. The corresponding Data Direction register is TRISA. Setting a TRISA bit (= 1) will make the correspondi ng PORT A pin an input (i.e., put the corresponding output driver in a high-impedance mode). Clearing a TRISA bit (= 0) will make the correspondin g POR TA pin an output (i .e., put the contents of the output latch on the selected pin).

EXAMPLE 9-1: INITIA LI ZING PORTA

PIC18F2525/2620/4525/4620

TABLE 9-1: PORTA I/O SUMMARY

Pin Function

RA0/AN0 RA0 0 O DIG LATA<0> data output; not affected by analog input.

AN0 1 I ANA A/D input channel 0 and Comparator C1- input. Default input

RA1/AN1 RA1 0 O DIG LATA<1> data output; not affected by analog input.

AN1 1 I ANA A/D input channel 1 and Comparator C2- input. Default input

RA2/AN2/

REF-/CVREF

RA3/AN3/V

RA4/T0CKI/C1OUT RA4 0 O DIG LATA<4> data output.

RA5/AN4/SS HLVDIN/C2OUT

OSC2/CLKO/RA6 RA6 0 O DIG LATA<6> data output. Enabled in RCIO, INTIO2 and ECIO modes only.

OSC1/CLKI/RA7 RA7 0 O DIG LATA <7> data output. Disabled in external oscillator modes.

Legend: DIG = Digital level output; TTL = TTL input buffer; ST = Schmitt Trigger input buffer; ANA = Analog level input/output;

REF+RA30 O DIG LATA<3> data output; not affected by analog input.

x = Don’t care (TRIS bit does not affect port direction or is overridden for this option).

RA2 0 O DIG LAT A<2> data output; not affected by analog input. Disabled when

AN2 1 I ANA A/D input channel 2 and Comparator C2+ input. Default input

REF- 1 I ANA A/D and comparator voltage reference low input.

REF x O ANA Comparator voltage reference output. Enabling this feature disables

AN3 1 I ANA A/D input channel 3 and Comparator C1+ input. Default input

REF+ 1 I ANA A/D and comparator voltage reference high input.

T0CKI 1 I ST Timer0 clock input.

C1OUT 0 O DIG Comparator 1 output; takes priority over port data.

RA5 0 O DIG LATA<5> data output; not affected by analog input.

AN4 1 I ANA A/D input channel 4. Default configuration on POR.

HLVDIN 1 I ANA High/Low-Voltage Detect external trip point input.

C2OUT 0 O DIG Comparator 2 output; takes priority over port data.

OSC2 x O ANA Main oscillator feedback output connection (XT, HS and LP modes). CLKO x O DIG System cycle clock output (F

OSC1 x I ANA Main oscillator input connection.

CLKI x I ANA Main clock input connection.

TRIS

Setting

1 I TTL PORTA<0> data input; disabled when analog input enabled.

1 I TTL PORTA<1> data input; disabled when analog input enabled.

1 I TTL PORTA<2> data input. Disabled when analog functions enabled;

1 I TTL PORTA<3> data input; disabled when analog input enabled.

1 I ST PORTA<4> data input; default configuration on POR.

1 I TTL PORTA<5> data input; disabled when analog input enabled.

1 I TTL Slave Select input for MSSP module.

1 I TTL PORTA<6> data input. Enabled in RCIO, INTIO2 and ECIO modes only.

1 I TTL PORTA<7> data input. Disabled in external oscillator modes.

I/O

Type

configuration on POR; does not affect digital output.

REF output enabled.

disabled when CV

configuration on POR; not affected by analog output.

digital I/O.

configuration on POR.

modes.

REF output enabled.

Description

OSC/4) in RC, INTIO1 and EC Oscillator

PIC18F2525/2620/4525/4620

TABLE 9-2: SUMMARY OF REGISTERS ASSOCIATED WITH PORTA

Reset

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PORTA RA7 LATA LATA7 TRISA TRISA7 ADCON1 — — VCFG1 VCFG0 PCFG3 PCFG2 PCFG1 PCFG0 51 CMCON CVRCON CVREN CVROE CVRR CVRSS CVR3 CVR2 CVR1 CVR0 51

Legend: — = unimplemented, read as ‘0’. Shaded cells are not used by PORTA. Note 1: RA7:RA6 and their associated latch and data direction bits are enabled as I/O pins based on oscillator

configuration; otherwise, they are read as ‘0’.

(1)

C2OUT C1OUT C2INV C1INV CIS CM2 CM1 CM0 51

RA6

LATA6

TRISA6

(1)

RA5 RA4 RA3 RA2 RA1 RA0 52

(1)

PORTA Data Latch Register (Read and Write to Data Latch) 52

(1)

PORTA Data Direction Control Register 52

Values

on page

PIC18F2525/2620/4525/4620

CLRF PORTB ; Initialize PORTB by

; clearing output ; data latches

CLRF LATB ; Alternate method

; to clear output

; data latches MOVLW 0Fh ; Set RB<4:0> as MOVWF ADCON1 ; digital I/O pins

; (required if config bit

; PBADEN is set) MOVLW 0CFh ; Value used to

; initialize data

; direction MOVWF TRISB ; Set RB<3:0> as inputs

; RB<5:4> as outputs

; RB<7:6> as inputs

9.2 PORTB, TRISB and LATB Registers

PORTB is an 8-bit wide, bidirectional port. The corresponding Data Direction register is TRISB. Setting a TRISB bit (= 1) will make the corresponding PORTB pin an input (i.e., put the corresponding output driver in a high-imped ance mode). Cl earing a TRISB bit (= 0) will make the c orrespond ing POR TB pi n an out put (i.e., put the contents of the outpu t latch on the selected pi n).

The Data Latch register (LATB) is also memory mapped. Read-modify-write operations on the LATB register read and write the latched output value for PORTB.

EXAMPLE 9-2: INITIALIZI NG PORTB

Four of the PORTB pins (RB7:RB4) have an interrupton-change feature. Only pins configured as inputs can cause this interrupt to occur (i.e., any RB7:RB4 pin configured as an output is excluded from the interrupton-change comparison). The input pins (of RB7:RB4) are compared with the old value latched on the last read of PORTB. The “mismatch” outputs of RB7:RB4 are ORed together to generate the RB Port Change Interrupt with Flag bit, RBIF (INTCON<0>).

This interrupt can wake the device from the Sleep mode, or any of the Idle modes. The user, in the Interrupt Service Routine, can clear the interrupt in the following manner:

a) Any read or write of PORTB (except with the

MOVFF (ANY), PORTB instruction).

b) 1 T

CY.

c) Clear flag bit, RBIF. A mismatch condition wil l contin ue to set flag bit , RBIF.

Reading PORTB and waiting 1 T

CY will end the

mismatch condition and allow flag bit, RBIF, to be cleared.

The interrupt-on-change feature is recommended for wake-up on key depression operation and operations where PORTB is only used for the interrupt-on-change feature. Polling of PORTB is not recommended while using the interrupt-on-change feature.

RB3 can be configured by the Configuration bit, CCP2MX, as the alternate peripheral pin for the CCP2 module (CCP2MX = 0).

Each of the PORTB pi ns has a w eak i nternal pul l-up. A single cont rol bit can turn on a ll the pull-ups. This is performed by clearing bit, RBPU weak pull-up is automatically turned off when the port pin is configured as an output. The pull-ups are disabled on a Power-on Reset.

Note: On a Power-on Reset, RB4:RB0 are

configured as analo g inputs by default and read as ‘0’; RB7:RB5 are configured as digital inputs.

By programming the Configuration bit, PBADEN, RB4:RB0 will alternatively be configured as digital inputs on POR.

(INTCON2<7>). The

PIC18F2525/2620/4525/4620

TABLE 9-3: PORTB I/O SUMMARY

Pin Function

RB0/INT0/FLT0/ AN12

RB0 0 O DIG LATB<0> data output; not affected by analog input.

TRIS

Setting

I/O

1 I TTL PORTB<0> data input; weak pull-up when RBPU

INT0 1 I ST External interrupt 0 input. FLT0 1 I ST Enhanced PWM Fault input (ECCP1 module); enabled in software.

AN12 1 I ANA A/D input channel 12.

RB1/INT1/AN10 RB1 0 O DIG LATB<1> data output; not affected by analog input.

1 I TTL PORTB<1> data input; weak pull-up when RBPU

INT1 1 I ST External interrupt 1 input.

AN10 1 I ANA A/D input channel 10.

RB2/INT2/AN8 RB2 0 O DIG LATB<2> data output; not affected by analog input.

1 I TTL PORTB<2> data input; weak pull-up when RBPU

INT2 1 I ST External interrupt 2 input.

AN8 1 I ANA A/D input channel 8.

RB3/AN9/CCP2 RB3 0 O DIG LATB<3> data output; not affected by analog input.

1 I TTL PORTB<3> data input; weak pull-up when RBPU

AN9 1 I ANA A/D input channel 9.

(2)

CCP2

0 O DIG CCP2 compare and PWM output. 1 I ST CCP2 capture input.

RB4/KBI0/AN11 RB4 0 O DIG LATB<4> data output; not affected by analog input.

1 I TTL PORTB<4> data input; weak pull-up when RBPU

KBI0 1 I TTL Interrupt on pin change.

AN11 1 I ANA A/D input channel 11.

RB5/KBI1/PGM RB5 0 O DIG LATB<5> data output.

1 I TTL PORTB<5> data input; weak pull-up when RBPU KBI1 1 I TTL Interrupt on pin change. PGM x I ST Single-Supply Programm ing mode entry (ICSP™). Enabled by LVP

RB6/KBI2/PGC RB6 0 O DIG LATB<6> data output.

1 I TTL PORTB<6> data input; weak pull-up when RBPU KBI2 1 I TTL Interrupt on pin change. PGC x I ST Serial execution (ICSP™) clock input for ICSP and ICD operation.

RB7/KBI3/PGD RB7 0 O DIG LATB<7> data output.

1 I TTL PORTB<7> data input; weak pull-up when RBPU KBI3 1 I TTL Interrupt on pin change. PGD x O DIG Serial execution data output for ICSP and ICD operation.

x I ST Serial execution data input for ICSP and ICD operation.

Legend: DIG = Digital level output; TTL = TTL input buffer; ST = Schmitt Trigger input buffer; ANA = Analog level input/output;

x = Don’t care (TRIS bit does not affect port direction or is overridden for this option).

Note 1: Configuration on POR is determined by the PBADEN Configuration bit. Pins are configured as analog inputs by default

when PBADEN is set and digital inputs when PBADEN is cleared.

2: Alternate assignment for CCP2 when the CCP2MX Configuration bit is ‘0’. Default assignment is RC1. 3: All other pin functions are disabled when ICSP or ICD is enabled.

I/O

Type

Description

Disabled when analog input enabled.

(1)

Disabled when analog input enabled.

(1)

Disabled when analog input enabled.

(1)

Disabled when analog input enabled.

(1)

Disabled when analog input enabled.

(1)

Configuration bit; all other pin functions disabled.

bit is cleared.

(3)

bit is cleared.

(3)

PIC18F2525/2620/4525/4620

TABLE 9-4: SUMMARY OF REGISTERS ASSOCIATED WITH PORTB

Reset

Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PORTB RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 52 LATB PORTB Data Latch Register (Read and Write to Data Latch) 52 TRISB PORTB Data Direction Control Register 52 INTCON

INTCON2 RBPU INTCON3 INT2IP INT1IP ADCON1 — — VCFG1 VCFG0 PCFG3 PCFG2 PCFG1 PCFG0 51 Legend: — = unimplemented, read as ‘0’. Shaded cells are not used by PORTB.

GIE/GIEH PEIE/GIEL TMR0IE INT0IE RBIE TMR0IF INT0IF RBIF 49

INTEDG0 INTEDG1 INTEDG2 — TMR0IP —RBIP49

—INT2IEINT1IE— INT2IF INT1IF 49

Values

on page

PIC18F2525/2620/4525/4620

CLRF PORTC ; Initialize PORTC by

; clearing output ; data latches

CLRF LATC ; Alternate method

; to clear output ; data latches

MOVLW 0CFh ; Value used to

; initialize data ; direction

MOVWF TRISC ; Set RC<3:0> as inputs

; RC<5:4> as outputs ; RC<7:6> as inputs

9.3 PORTC, TRISC and LATC Registers

PORTC is an 8-bit wide, bidirectional port. The corresponding Data Direction register is TRISC. Setting a TRISC bit (= 1) will make the corresponding PORTC pin an i npu t (i .e., put the corresp on din g o utp ut driver in a high-impedance mode). Clearing a TRISC bit (= 0) will make the corresponding PORTC pin an output (i.e., put the contents of the output latch on the selected pi n).

The Data Latch register (LATC) is also memory mapped. Read-modify-write operations on the LATC register read and write the latched output value for PORTC.

PORTC is mul tiplexed with s everal peri pheral function s (Table 9-5). The pins have Schmitt Trigger input buffers. RC1 is normally configured by Configuration bit, CCP2MX, as the de fault peri pheral pin of the CC P2 module (default/erased state, CCP2MX = 1).

When enabling peripheral functions, care should be taken in defining TRIS bits for each PORTC pin. Some peripherals override the TRIS bit to make a pin an output, while other peripherals override the TRIS bit to make a pin an input. The user should refer to the corresponding peripheral sectio n for additi onal informati on.

Note: On a Power-on Reset, these pins are

configured as digital inputs.

The contents of the TRISC register are affected by peripheral overrides. Reading TRISC always returns the current contents, even though a peripheral device may be overriding one or more of the pins.

EXAMPLE 9-3: INITIALIZING PORTC

PIC18F2525/2620/4525/4620

TABLE 9-5: PORTC I/O SUMMARY

Pin Function

RC0/T1OSO/ T13CKI

RC1/T1OSI/CCP2 RC1 0 O DIG LATC<1> data output.

RC2/CCP1/P1A RC2 0 O DIG LATC<2> data output.

RC3/SCK/SCL RC3 0 O DIG LATC<3> data output.

RC4/SDI/SDA RC4 0 O DIG LATC<4> data output.

RC5/SDO RC5 0 O DIG LATC<5> data output.

RC6/TX/CK RC6 0 O DIG LATC<6> data output.

RC7/RX/DT RC7 0 O DIG LATC<7> data output.

Legend: DIG = Digital level output; TTL = TTL input buffer; ST = Schmitt Trigger input buffer; ANA = Analog level input/output;

Note 1: Default assignment for CCP2 when the CCP2MX Configuration bit is set. Alternate assignment is RB3.

C/SMB = I2C/SMBus input buffer; x = Don’t care (TRIS bit does not affect port direction or is overridden for this option).

2: Enhanced PWM output is available only on PIC18F4525/4620 devices.

RC0 0 O DIG LATC<0> data output.

T1OSO x O ANA Timer1 oscillator output; enabled when Timer1 oscillator enabled.

T13CKI 1 I ST Timer1/Timer3 counter input.

T1OSI x I ANA Timer1 oscillator input; enabled when Timer1 oscillator enabled.

CCP2

CCP1 0 O DIG ECCP1 compare or PWM output; takes priority over port data.

P1A

SCK 0 O DIG SPI clock output (MSSP module); takes priority over port data.

SCL 0 ODIGI

SDI 1 I ST SPI data input (MSSP module).

SDA 0 ODIGI

SDO 0 O DIG SPI data output (MSSP module); takes priority over port data.

TX 0 O DIG Asynchronous serial transmit data output (EUSART module);

CK 0 O DIG Synchronous serial clock output (EUSART module); takes priority

RX 1 I ST Asynchronous serial receive data input (EUSART module). DT 0 O DIG Synchronous serial data output (EUSART module); takes priority over

TRIS

Setting

(1)

(2)

I/O

1 I ST PORTC<0> data input.

1 I ST PORTC<1> data input.

0 O DIG CCP2 compare and PWM output; takes priority over port data. 1 I ST CCP2 capture input.

1 I ST PORTC<2> data input.

1 I ST ECCP1 capture input. 0 O DIG ECCP1 Enhanced PWM output, channel A. May be configured for

1 I ST PORTC<3> data input.

1 I ST SPI clock input (MSSP module).

1 II

1 I ST PORTC<4> data input.

1 II

1 I ST PORTC<5> data input.

1 I ST PORTC<6> data input.

1 I ST Synchronous serial clock input (EUSART module).

1 I ST PORTC<7> data input.

1 I ST Synchronous serial data input (EUSART module). User must

I/O

Type

Disables digital I/O.

tri-state during Enhanced PWM shutdown events. Takes priority over port data.

C/SMB I2C clock input (MSSP module); input type depends on module setting.

C/SMB I2C data input (MSSP module); input type depends on module setting.

C™ clock output (MSSP module); takes priority over port data.

C data output (MSSP module); takes priority over port data.

takes priority over port data. User must configure as output.

over port data.

port data.

configure as an input.

Description

MICROCHIP PIC18F2525, PIC18F2620, PIC18F4525, PIC18F4620 Technical data

Specifications and Main Features

Frequently Asked Questions

User Manual

Power Management Features:

Flexible Oscillator Struc ture:

Peripheral Highlights:

Peripheral Highlight s (Continued):

Special Microcontroller Features:

Pin Diagrams

Pin Diagrams (Cont.’d)

Table of Contents

Most Current Data Sheet

Errata

Customer Notification System

1.0 DEVICE OVERVIEW

1.1 New Core Features

1.1.1 nanoWatt TECHNOLOGY

1.1.2 MULTIPLE OSCILLATOR OPTIONS AND FEATURES

1.2 Other Special Features

1.3 Details on Individual Family Members

TABLE 1-1: DEVICE FEATURES

FIGURE 1-1: PIC18F2525/2620 (28-PIN) BLOCK DIAGRAM

FIGURE 1-2: PIC18F4525/4620 (40/44-PIN) BLOCK DIAGRAM

TABLE 1-2: PIC18F2525/2620 PINOUT I/O DESCRIPTIONS

TABLE 1-3: PIC18F4525/4620 PINOUT I/O DESCRIPTIONS

2.0 OSCILLATOR CONFIGURATIONS

2.1 Oscillator Types

2.2 Crystal Oscil lator/Ceramic Resonators

2.3 External Clock Input

2.4 RC Oscillator

FIGURE 2-5: RC OSCILLATOR MODE

2.5 PLL Frequency Multiplier

2.5.1 HSPLL OSCILLATOR MODE

FIGURE 2-6: RCIO OSCILLATOR MODE

2.5.2 PLL AND INTOSC

2.6 Internal Oscillator Block

2.6.1 INTIO MODES

2.6.2 INTOSC OUTPUT FREQUENCY

2.6.3 OSCTUNE REGISTER

2.6.4 PLL IN INTOSC MODES

2.6.5 INTOSC FREQUENCY DRIFT

REGISTER 2-1: OSCTUNE: OSCILLATOR TUNING REGISTER

2.7 Clock Sources and Oscillator Switching

FIGURE 2-8: PIC18F2525/2620/4525/4620 CLOCK DIAGRAM

2.7.1 OSCILLA TOR CONTROL REGISTER

2.7.2 OSCILLATOR TRANSITIONS

REGISTER 2-2: OSCCON: OSCILLATOR CONTROL REGISTER

2.8 Effects of Power-Managed Modes on the Various Clock Sources

2.9 Power-up Delays

TABLE 2-3: OSC1 AND OSC2 PIN STATES IN SLEEP MODE

3.0 POWER-MANAGED MODES

3.1 Selecting Power-Managed Modes

3.1.1 CLOCK SOURCES

TABLE 3-1: POWER-MANAGED MODES

3.1.3 CLOCK T RANSITIONS AND S TAT US INDICATORS

3.1.4 MULTIPLE SLEEP COMMANDS

3.2 Run Modes

3.2.1 PRI_RUN MODE

3.2.2 SEC_RUN MODE

FIGURE 3-1: TRANSITION TIMING FOR ENTRY TO SEC_RUN MODE

FIGURE 3-2: TRANSITION TIMING FROM SEC_RUN MODE TO PRI_RUN MODE (HSPLL)

3.2.3 RC_RUN MODE

FIGURE 3-3: TRANSITION TIMING TO RC_RUN MODE

FIGURE 3-4: TRANSITION TIMING FROM RC_RUN MODE TO PRI_RUN MODE

3.3 Sleep Mode

3.4 Idle Modes

FIGURE 3-5: TRANSITION TIMING FOR ENTRY TO SLEEP MODE

FIGURE 3-6: TRANSITION TIMING FOR WAKE FROM SLEEP (HSPLL)

3.4.1 PRI_IDLE MODE

3.4.2 SEC_ID LE MO DE

FIGURE 3-7: TRANSITION TIMING FOR ENTRY TO IDLE MODE

FIGURE 3-8: TRANSITION TIMING FOR WAKE FROM IDLE TO RUN MODE

3.4.3 RC_IDLE MODE

3.5 Exiting Idle and Sleep Modes

3.5.1 EXIT BY INTERRUPT

3.5.2 EXIT BY WDT TIME-OUT

3.5.3 EXIT BY RESET

3.5.4 EXIT WITHOUT AN OSCILLATOR START-UP DELAY

4.0 RESET
