Micanan PRO-T, PRO-TB Instruction Manual

INSTALLATION AND INSTRUCTION MANUAL

MODELS: PRO-T, PRO-TB

AUG, 2010

2

TABLE OF CONTENTS

PAGE:

VERIFICATION OF OPERATOR AND HARDWARE ___________________________ 3

SPECIFICATIONS ___________________________________________________________ 4

SAFETY INSTRUCTIONS ____________________________________________________ 5

INSTALLATION_____________________________________________________________ 6

ELECTRICAL CONNECTIONS AND SETTINGS________________________________ 10

LIMIT SWITCH ADJUSTMENT _______________________________________________ 24

MICANAN PHOTOBEAM INSTALLATION INSTRUCTIONS_____________________ 25

CLUTCH ADJUSTMENT______________________________________________________ 28

BRAKE ADJUSTMENT_______________________________________________________ 28

EMERGENCY MANUAL OPERATION _________________________________________ 29

OPERATOR MAINTENANCE _________________________________________________ 30

MECHANICAL DRAWINGS AND PARTS LISTS ________________________________ 31

ELECTRICAL DIAGRAMS ___________________________________________________ 33

WARRANTY ________________________________________________________________ 41

OPTIONS

MP00041-44

#40 Drive Chain

MP00023

Double V-belt reduction

MP00045

Cast-iron Pillow block bearings on drive

MP00039

High Cycle modification

PRO-TW/TBW____

Waterproof modification

PRO-T4X/TB4X____

Corrosionproof modification

PRO-TX/TBX____

Explosion proof modification

MP00007 *

115 Volt control circuit

MK00061 **

1.5 sec time delay on reverse

MP00001 **

Timer to Close

PRO-PL____

Separate control panel

MP00024

Trolley hoist Disconnect

MP00030,78-80

Dual Trolley Assembly

MP00035

Minimum Depth modification

* Not available for logic board controls

** Standard feature with logic board controls

WARNING

DO NOT CONNECT TO ELECTRICAL

POWER DURING INSTALLATION

OR SERVICING OF OPERATOR

3

Upon delivery of your MICANAN SYSTEMS heavy-duty trolley door operator, please inspect the unit carefully for damage.
Verify that operator horsepower, voltage, phase and amperage correspond to available power supply and door application.
Check that along with your operator you have received the following standard hardware.

1 x OPEN /CLOSE/STOP 3-button control station:

1 x Set of trolley tracks (door height + 2’6”)

1 x Drive chain package (door height x 2 + 5’ 6” (1.65m) c/w connecting link

1 x Trolley carriage and 3/8 take-up bolt assembly

1 x Trolley track end bracket

1 x Front idler

2 x Trolley spreader bars

1 x Trolley arm assembly

1 x Warning sign

1 set of Micanan photocells (supplied when operator ordered
with interface module or logic board controls)

VERIFICATION OF OPERATOR AND HARDWARE

IMPORTANT

FOR ANY QUESTIONS CONCERNING THE SAFETY OR OPERATION

OF THIS OPERATOR PLEASE CONTACT MICANAN SYSTEMS AT

1-877-888-1116

SAVE THESE INSTRUCTIONS

4

1 x Set of Warning signs

PRO-T and PRO-TB heavy-duty trolley operators are designed for standard lift overhead sectional garage doors. Model PRO­TB is essentially the same as model PRO-T with the exception that the PRO-TB operator has a solenoid operated braking
system.

STANDARD OPERATOR WEIGHT: 50-70 Lbs

MOTOR: Continuous duty 1725 RPM industrial type motor.

- Built-in overload protection (3-phase) or separate full overload protection (1-phase).

- Horsepower: 1/3HP, 1/2HP, 3/4HP, 1HP (TB only)

- Voltage: 115V 1-phase (60Hz) 230V 3-phase (60 Hz) 220V 1-phase (50Hz)
230V 1-phase (60Hz) 460V 3-phase (60Hz) 380V 3-phase (50Hz)

575V 3-phase (60Hz)

REDUCTION: Primary: (5L) V-belt and pulleys (2” to 9” diameter). Secondary: #41 chain and sprockets

OUTPUT SHAFT SPEED: 120 RPM DOOR SPEED: 12”/second

BRAKE (Model PRO-TB): Solenoid actuated drum and brake shoe braking system to prevent coasting and maintain door

position.

WIRING TYPE (3 OPTIONS):
Option 1: Full Feature logic board Smart 10.0 (UL325 (2010) compliant). Note: Micanan compatible primary entrapment

device must be connected for B2, T or TS (momentary or timer activation on close) feature.

Option 2: Relay logic controls with Interface Module (UL325 (2010) compliant). C2 Standard factory wiring (constant

pressure on close, momentary contact on open and stop). If momentary contact on close (B2) wiring is desired,
move “white” wire from terminal #6 to terminal #3. Note: Micanan compatible primary entrapment device must be
connected for B2 (momentary activation on close) or for T (timer to close) feature.

Option 3: Standard relay logic controls (not UL325 2010 compliant, not available in US) C-2 Wiring constant pressure

on close, momentary contact on open and stop. NOTE: If momentary contact on close (B2) wiring is desired, move
“white” wire from terminal #5 to terminal #3.

TRANSFORMER: 24VAC control circuit, supplies power to drive control relays with 15VA power available for external

devices.

LIMIT ADJUSTMENT: 4 micro switches that control door travel. These limit switches are activated by fully adjustable screw

type cams.

EMERGENCY DISCONNECT: Quick release disconnect door arm to allow person to disengage operator drive chain from

door for manual operation.

CLUTCH: Adjustable friction clutch to minimize damage to door operator, door or vehicles when obstruction occurs.

OPERATOR DIMENSIONS:

PRO-T, PRO-TB SPECIFICATIONS

5

-

READ AND FOLLOW ALL INSTRUCTIONS

- Never allow children to operate or play with door controls. Keep the remote control (where provided) away from children.

- Personnel should keep away from a door in motion and keep the moving door in sight until it is completely closed or opened.
NO ONE SHOULD CROSS THE PATH OF A MOVING DOOR.

- Test the door’s safety features at least once a month. After adjusting the limit of travel, retest the door operator’s safety
features. Failure to adjust the operator properly may cause severe injury or death.

- For products having a manual release, if possible, use the manual release only when the door is closed. Use caution when
using this release when the door is open. Weak or broken springs may cause the door to fall rapidly, causing severe injury or
death.

- KEEP DOORS PROPERLY OPERATING AND BALANCED. See Door Manufacturer’s Owner’s Manual. An improperly operating or
balanced door could cause severe injury or death. Have trained door systems technician make repairs to cables, spring
assemblies, and other hardware.

- Press the “OPEN” device or use emergency disconnect mechanism if a person is trapped under the door.

- SAVE THESE INSTRUCTIONS. The owner or users must understand the safety and operation of door system. Insure that this
installation manual be located close to the door system.

- READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS

- Commercial door operators are never to be installed on a residential installation

- Install only on a properly operating and balanced door. A door that is operating improperly could cause severe injury. Have
qualified service personnel make repairs to cables, spring assemblies, and other hardware before installing the operator.

- Remove all pull ropes and remove, or make inoperative, all locks (unless mechanically and/or electrically interlocked to the
power unit) that are connected to the door before installing the operator.

- Install the door operator at least 8 feet or more above the floor if the operator has exposed moving parts.

- Do not connect the operator to the source of power until instructed to do so.

- Locate the control station: (a) within sight of the door, (b) at a minimum height of 5 feet so that small children cannot reach it,
and (c) away from all moving parts of the door.

- Install the Entrapment Warning Placard next to the control station in a prominent location.

- For products having a manual release, instruct the end user on the operation of the manual release.

- Install non-contact entrapment protection devices (photocells) and/or contact entrapment protection devices (reversing
edges). Note: photocells should be installed at no more than 6” from the floor. Edges should be installed on the leading edge
of the door.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

TO REDUCE THE RISK OF INJURY OR DEATH:

IMPORTANT INSTALLATION INSTRUCTIONS

6

Note: Installation of operator must be done by a qualified installer. Door must be properly installed and

working smoothly. Remove all door locks prior to installation.

1. Install control station away from all moving door parts, within sight of the door and a minimum of 5 ft (1.5 m) from

the ground.

2. Install entrapment warning sign next to control station.

3. Do not remove emergency release tag attached to disconnect handle.

INSTALLATION INSTRUCTIONS

WARNING

DO NOT INSTALL THIS OPERATOR

BEFORE READING THIS MANUAL CAREFULLY.

7

PREPARATION:

1. Lay out operator and trolley tracks on ground in front of door with door operator motor facing away from door.

2. Install track spacers evenly to track assembly.

3. Install 3/8” take-up bolt to carriage using two 3/8” hex nuts and lock washer provided.

4. Slide trolley carriage through end of tracks towards operator with take-up bolt facing operator.

5. Install front idler assembly to the second set of holes end of trolley tracks.

6. Bolt rail assembly to operator frame using four 3/8” x ¾” bolts and 3/8” serrated hex nuts provided.

7. Attach one end of drive chain to carriage using connecting link provided. Run chain around front idler, over the

track spacers, around drive sprocket and connect to take-up-bolt using connecting link provided. Adjust take-up­bolt so that chain sags approximately 3” (7.5 cm) at midpoint of tracks. Remove links from drive chain if necessary
to make proper adjustment.

8

WALL MOUNTING BRACKET AND OPERATOR INSTALLATION:

NOTE: Trolley type operators should generally be mounted directly over the center of the door and the trolley tracks should
clear the tracks by 2-1/2” (6.5 cm). However, if interfering structures or other reasons do not allow for centered mounting, it
is possible to install it up to 18” off-center for torsion spring doors.

1. Locate the center of door by measuring door width and mark a vertical line above the door.

2. Determine the highest point of door travel by manually opening the door. Using a carpenter’s level, project a line from
where the top section of door reaches its highest point. Mark the spot where this line (high arc) intersects with the
vertical line drawn earlier.

3. Mount a wood block or angle iron to the wall above the door opening as shown below. The wall mounting bracket has
3 holes for anchoring to wood block or angle iron. Bracket should be centered with door and positioned so that these
holes are 2-1/2” (6.5 cm) above the high arc line of door. Secure wall mounting bracket using suitable hardware.

4. While allowing motor to rest on floor, raise front end of track assembly and secure (but not tighten) to wall mounting
brackets with 3/8” bolts and nuts provided.

5. Swing the operator and track assembly above the level of the door tracks and temporarily secure in place with rope or
chain. Carefully open door. Align operator and rails with center of door. Using the door as support, shim the operator so
that there is 3” (7.5cm) clearance between door and bottom of operator. Tighten wall mounting bracket bolts.

9

6. Install hanging brackets (braces) from ceiling or structure to any of the five 3/8” holes located on operator frame. For
tracks
over 14’ long it is recommended to install braces to the tracks at 4’(1.2m) to 5’ (1.5m) from operator.

TROLLEY ARM INSTALLATION

1. Manually close door to fully closed position. Slide trolley carriage towards front idler and latch trolley arm to carriage
spring pin by pulling on rope. When installed the open side of notch should face the door.

2. Using 3/8” bolts and nuts provided, align the mounting holes of straight arm and curved arm so that pivot bolt on door
bracket is in line with the top rollers of the door. Align door bracket with centerline of door and secure to door using
suitable hardware.

3. When properly installed the door arm should lean slightly away from door when door is fully closed.

4. At this time, check all bolts for tightness.

5.

10

THERE ARE 3 POSSIBLE ELECTRICAL CONTROL CONFIGURATIONS FOR THIS OPERATOR:

A) Standard relay logic controls (not UL325 2010 compliant, not available in US). Refer to Section A for electrical
connections. Refer to electrical drawings inside your operator control box or generic drawings MS100-WW or

MS300-WW in the electrical drawings section at the end of this manual.

B) Relay logic controls with Interface Module (UL325 (2010) compliant. Refer to Section B for electrical
connections. Refer to electrical drawings inside your operator control box or generic drawings MS100-IM-WW or
MS300-IM-WW in the electrical drawings section at the end of this manual.

C) Full Feature logic board Smart 10.0 (UL325 (2010) compliant). Refer to Section C for electrical
Connections and logic board instructions. Refer to electrical drawings inside your operator control box or generic
drawings MSL100-110V-WW, MSL100-220V-WW, MSL300-WW or MSLC300-WW in the electrical drawings
section at the end of this manual.

Refer to electrical diagrams inside control box cover or at the end of this manual prior to connection of power supply or
control station.

WARNING

TO REDUCE THE RISK OF INJURY OR DEATH:

ALL ELECTRICAL CONNECTIONS SHOULD BE MADE BY A QUALIFIED SERVICE PERSON

DO NOT ATTEMPT TO MAKE ELECTRICAL CONNECTIONS TO OPERATOR UNLESS POWER SUPPLY HAS

BEEN DISCONNECTED AT FUSE BOX

OPERATOR MUST BE CONNECTED IN ACCORDANCE TO LOCAL ELECTRICAL CODES AND GROUNDED

WARNING

COMPARE AVAILABLE POWER SUPPLY VOLTAGE TO OPERATOR NAMEPLATE PRIOR TO ELECTRICAL

CONNECTION. FAILURE TO CONNECT APPROPRIATE POWER SUPPLY VOLTAGE MAY CAUSE SERIOUS

DAMAGE TO OPERATOR.

ELECTRICAL CONNECTIONS

IMPORTANT

- MICANAN HIGHLY RECOMMENDS THAT EACH INDIVIDUAL COMMERCIAL DOOR OPERATOR
HAVE IT’S OWN DEDICATED POWER SUPPLY

- MICANAN HIGHLY RECOMMENDS THAT EACH INDIVIDUAL COMMERCIAL DOOR OPERATOR
HAVE AN EXTERNAL CIRCUIT BREAKER OR FUSED DISCONNECT

11

SECTION A: PRO-T, PRO-TB Standard relay logic controls (not UL325 2010
compliant, not available in US)

POWER WIRING: Use 1-1/8” (2.85 cm) diameter holes for all power wiring.

1. Single phase: Connect single phase power supply to terminals L/L1 (line) and N/L2 on three-pole
power terminal strip.

2. Three-phase: Connect three phase power supply to terminals L1, L2 and L3 on three-pole power
terminal strip.

CONTROL WIRING: Use 7/8” (2.22 cm) diameter holes for all control wiring.
Note: Do not run control wires and power wires in same conduit.

- Install control station within clear sight of door but away from all moving parts of door or hardware.

Install Entrapment warning sign next to control station. Connect 3-button (open/close/stop) push button
station to terminals 2, 3, 4 and 5. Refer to electrical diagram for connection of two 3-button stations.

NOTE: After electrical connections are made, manually move door to mid-position and, using the control station press the

“Open” button for several seconds and then press the “Stop” button. If door did not move in correct direction verify
wiring control station. For 3-phase operators, if door still moves in wrong direction reverse any two of the three
incoming power supply leads to correct rotation.

- Adjust Limit switches as explained in the “Limit switch adjustment section” further in this manual

CONNECTION OF POWER SUPPLY AND CONTROL STATION

LIMIT SWITCH ADJUSTMENT

12

1. Reversing Edge device (must be normally open contact):

Note: If the door is controlled by any device or wired in such a manner that the door is not controlled by constant

pressure on close then an appropriate reversing edge must be installed.

2. External interlock: Remove jumper between terminals 1 and 2 and wire interlock between these two

terminals.

3. Radio control receiver: Wire standard radio receiver to separate radio strip on side of control box or to terminals 7, 8

and 9 on control terminal strip inside control box.

4. Single button open/close device: Wire to terminals 7 and 8 on control terminal strip.

5. Loop detectors, standard photocells (with a N.O. contact) and other reversing devices: Wire to terminals 3 and 6

on control terminal strip. IMPORTANT: PHOTOCELLS MUST BE MOUNTED NO HIGHER THAN 6” OFF THE FLOOR.

6. 24 Volt power: Wire to terminals 1 and 9 on control terminal strip

CONNECTION OF A REVERSING EDGE DEVICE AND CONTROL ACCESSORIES

13

SECTION B: PRO-T(M), PRO-TB(M) Relay logic controls with Interface Module
(UL325 2010 compliant)

Operator electrical connections and start-up instructions

Important: Follow these steps carefully and in the order shown

1) Connect Power supply:

Single phase: Connect single phase power supply to terminals L/L1 and N/L2 on the 3-pole power terminals strip.
3-phase: Connect 3-phase power supply to terminals L1, L2 and L3 on the 3-pole power terminal strip.

2) Connect Push-button station for installation purposes (single phase or 3-phase):

Connect open/close/stop push button station to terminals T2 (stop), T3 (common), T4 (open) and T6 (temporary CP on
close).

NOTE: THIS OPERATOR COMES WITH AN INTERFACE MODULE INTEGRATED INTO THE CONTROL CIRCUIT.

THE PURPOSE OF THE INTERFACE MODULE IS TO ALLOW FOR FAILSAFE MONITORING OF A MICANAN

COMPATIBLE SAFETY DEVICE AS PER UL 325 (2010) REQUIREMENTS.

14

3) Verify motor direction:

After the electrical power connections are made and push button station is connected, manually move the door to mid­position. Press Close button for several seconds and then press stop button. If door did not move in correct direction (or if
limit cams not moving in correct direction towards the close limit switch) see below:

Single phase operators: The operators leave the factory with correct motor and limit shaft direction according to standard
door installations. However, for special fire door, thru- wall mounting or other special door applications, the motor direction
and limit switch direction may need to be reversed. To reverse the motor rotation, interchange black and white wires going
to motor on the reversing contactor.

3-phase operators: If door moves in wrong direction, turn off incoming power and reverse any two of the three incoming
power supply leads to correct rotation. Press the open button and then activate the open limit to ensure door stops. If door
does not stop, interchange grey and red wires on open and close limits. Interchange white and grey wires on advanced
open and advanced close limits. Remove blue wire from advanced open limit and place it on N.O pin of advanced close
limit.

4) Adjust limit switch cams:

Using the open/close/stop push button station move door to fully closed and fully open oppositions and set limit cams to
correct position. (See Limit adjustment section D further in this manual for complete detail on the end of travel limit
adjustments).

5) Activate Interface module:

After adjusting the open and close limits and verifying the motor rotation, open the door to the full-open position using the
open push button (Figure below on left).
At this point the close pushbutton wire must now be moved from terminal T6 to T5. Now connect the black wire (with blue
label) to terminal T1 as shown in figure below on right.
Note: Ensure the door is in the full open position before connecting the black wire. If door is not in full open position and

monitored photo-eyes or safety edge are not connected and operational then door will immediately move in the open
direction.

15

6) Connect safety devices

Failsafe feature: A monitored failsafe safety feature is built into the operator. The operator has provisions to connect one
primary monitored safety device as well as one or more non-monitored safety device(s).

Primary monitored safety device:

MICANAN monitored failsafe photo beams or MICANAN compatible monitored failsafe devices must be connected to
terminals P1 and P2 if momentary close on pushbutton is required (B2 mode). If not connected, door can only be closed by
constant pressure on close pushbutton. If constant pressure on close pushbutton is removed before door reaches full
closed position, then door reverses to full open.

Note: Only one monitored failsafe safety device can be connected across terminals P1 and P2.
Note: See section E for complete installation instructions for the Micanan N-1 or N-4 photocells.

Secondary non-monitored safety device(s):

A standard 2-wire safety edge, non-monitored reflective or thru-beam photo eye or any other non-monitored reversing
devices with a N.O dry contact can be connected to terminals S1 and S2.

Note: More than one secondary non-monitored safety device can be connected to terminals S1 and S2.
Important: Do not remove resistor that is factory installed across terminals S1 and S2 unless installing a 4-wire electric edge.

4-wire electric edge Connection

A standard 4-wire electric edge can be connected across S1 and S2 terminals as a secondary safety device. Remove the
factory installed resistor across terminals S1 and S2 and install resistor across the black and white pair of wires from the
electric edge and connect the remaining black and white wire to the S1 and S2 terminals.

7) Select Mode of Operation:

C2 mode of operation (momentary on open, constant pressure on close):

The operator is wired at the factory for momentary on open and constant pressure on close. For commercial operators,
white wire is connected to terminal T6.

B2 mode of operation (momentary on open, momentary on close):

If momentary on close is required: For commercial operators, remove the white wire from terminal T6 and place it on
terminal T3.
The operator functions in B2 mode only when the primary monitored safety device is connected and functioning properly. If
it is not connected, operator will go into fault mode and door can only be closed by constant pressure on close and if
constant pressure on close is removed before door reaches full close position, door reverses to full open.

16

SECTION C: PRO-T(E), PRO-TB(E) Full feature logic board Smart 10.0 (UL325
2010 compliant)

Note: The operator is shipped from the factory in the D1 mode setting (constant pressure open and close). The operator
should remain in this mode until all connections and limit switch adjustments are completed.

POWER WIRING INSTRUCTIONS:

Connect primary power supply directly to the separate power terminal strip supplied using any of the 1-1/8” (2.85 cm)
diameter holes provided on control box. Do not connect power supply directly to the circuit board.

1. Single phase: Connect single-phase power supply to terminals L/L1 and N/L2 on three-pole power terminal strip

(110V or 220V 1-phase).

2. Three-phase: Connect three-phase power supply to terminals L1, L2 and L3 on three-pole power terminal strip

(208V, 230V, 380V, 460V or 575V).

ON BOARD O/C/S PBS INSTRUCTIONS:

On-board Open, Close and Stop buttons are provided directly on the board for installation and troubleshooting purposes. In
order to operate unit by on-board Open, Close, Stop buttons, the factory installed jumper (#1) between the COM and STOP
terminals on the terminal strip must remain connected.

MOTOR DIRECTION VERIFICATION:

Make sure the mode of operation is selected to D1.
After electrical power connections are made, manually move door to mid-position. Using the on-board buttons press the
“Open” button for several seconds and then press the “Stop” button. If door did not move in correct direction (or if limit
cams not moving in correct direction towards the open limit switch) see below:

For single-phase operators: The operators leave the factory with correct motor and limit shaft direction according to
standard door installations. However, for special fire door, through wall mounting or other special door applications, the
motor direction and limit switch direction may need to be reversed. A dipswitch (Dip #1) is provided to reverse direction of
motor and limit switch direction. If motor direction is reversed, the open and close limit switches are automatically reversed.
However, the advanced close limit switch needs to be manually changed. Disconnect the 2 wires from the advanced closed
limit switch and re-connect to the auxiliary limit switch provided.

Note: Ensure that when the on-board open button is depressed and the door moves in the correct open direction that
activation of the open limit switch illuminates the ‘’OPEN LIMIT” L.E.D and stops the door.

17

For 3-phase operators: If door moves in wrong direction, turn off incoming power and reverse any two of the three
incoming power supply leads to correct rotation. Press the on board open button again. If door is going in the correct open
direction, activate the open limit switch to ensure door stops. If door does not stop, turn off incoming power and
interchange any two incoming power lines once again and slide dipswitch #1 to reverse motor direction. If motor direction
is reversed, the open and close limit switches are automatically reversed. However, the advanced close limit switch needs to
be manually changed. To do this, disconnect the 2 wires from the advanced limit switch and re-connect to the auxiliary limit
switch provided.

Note: Ensure that when the on-board open button is depressed and the door moves in the correct open direction that
activation of the open limit switch illuminates the “OPEN LIMIT’’ L.E.D and stops the door.

LIMIT SWITCH ADJUSTMENTS:

Once the motor rotation and limit cam direction have been verified, adjust the limit cam settings. Please note that when
each limit switch is activated the corresponding LED will light up. Refer to operator installation manual for complete limit
switch adjustment instructions.

CONNECTION OF EXTERNAL O/C/S PBS:

Connect O/C/S PBS as shown in diagram.
Note: Jumper #1 must be removed after the external O/C/S PBS has been installed.

FAILSAFE FEATURE

A safety device failsafe feature is built into the logic board. The logic board has provisions to connect one primary
monitored safety device as well as 1 or more secondary non-monitored safety device(s).

Primary monitored safety device:

MICANAN monitored failsafe photo beams or MICANAN compatible monitored failsafe devices must be connected to
terminals P1 and P2 as primary monitored safety device. Primary monitored safety device must be connected if momentary
activation on close is required in B2, T and TS modes. If it is not connected in B2, T and Ts modes, door can only be closed by
constant pressure on close and if constant pressure is removed before door reaches full close position, door reverses to full
open.
Note: Only one monitored failsafe device can be connected to terminals P1 and P2.

18

Secondary non-monitored safety device(s):

A standard 2-wire safety edge, non-monitored photo beams or any other non-monitored reversing devices with a
N.O contact can be connected to terminals S1 and S2 as secondary non-monitored safety device.
Note: More than one secondary non-monitored safety device can be connected to terminals S1 and S2.
Important: Do not remove the resistor that is factory installed across terminals S1 and S2 unless installing a 4-wire electric
edge.

4-wire electric edge:

A standard 4-wire electric edge can be connected across S1 and S2 terminals as a secondary safety device.
Remove the factory-installed resistor across terminals S1 and S2 when using a 4-wire electric edge

CONNECTION OF EXTERNAL SINGLE-BUTTON DEVICE

Connect an external single-button as shown in diagram. Please refer to ‘’Modes of operation’’ for the functionality of single­button.

MODES OF OPERATION

All operators leave the factory in the D1 mode setting; please read all modes of Operation and determine which operational
mode is desired

B2: (Momentary on open and close)

• Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door (OPEN

OVERRIDE). Momentary contact from mid-stop opens the door to full open position. Constant activation when door is
opening, bypass mid-stop if enabled.

• Close button: Momentary on close.

• Stop button: Momentary activation stops the door.

• Single button device and single channel transmitter, 3-channel (1,2,3) transmitter:

SEQ FUNCTION: Open/Stop/Close/Reverse.
COMMERCIAL FUNCTION: Open/Close/Reverse.

• 3-button O/C/S radio transmitter: Same as open, close, stop buttons.

• Safety Devices: When door is closing, momentary activation reverses the door.

• Timer to close: N/A

19

C2 (Momentary open, constant pressure close)

• Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door (OPEN

OVERRIDE). Momentary contact from mid-stop opens the door to full open position. Constant activation when door is
opening, bypass mid-stop if enabled.

• Close button: Constant pressure on close. Door will stop when button is released

• Stop button: Momentary activation stops the door.

• Single button device:

SEQUENTIAL FUNCTION: Open/Stop/Constant pressure on close/stop.
COMMERCIAL FUNCTION: Open/Constant pressure on close/stop.

• Single channel transmitter, 3-channel (1,2,3) transmitter and 3-button O/C/S radio transmitter:

Momentary activation opens the door. Momentary contact of OPEN button on 3-button (O/C/S)
radio transmitter from mid-stop opens the door to full open position. Cannot close the door.

• Safety Devices: When door is closing, momentary activation reverses the door.

• Timer to close: N/A

D1: (Constant pressure on open and close)

• Open Button: Constant pressure opens the door. Door stops when constant pressure is released.

Constant pressure from mid-stop opens the door to full open position.

• Close button: Constant pressure on close. Door will stop when button is released

• Single button device, single channel transmitter, 3-channel (1,2,3) transmitter and 3-button (O/C/S)

radio transmitter: N/A

• Safety Devices: When door is closing, momentary activation reverses the door.

• Timer to close: N/A

E2: (Momentary on open, constant pressure on close with roll-back feature)

• Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door.

Momentary contact from mid-stop opens the door to full open position. Constant activation when door is opening, bypass
mid-stop if enabled.

• Close button: Constant pressure on close. Door reverses to full open when button is released.

• Single button:

SEQUENTIAL FUNCTION: Open/Stop/Constant pressure on close/Stop.
COMMERCIAL FUNCTION: Open/Constant pressure on close/Reverse.

• Single channel device, 3-channel (1,2,3) transmitter and 3-button (O/C/S) radio transmitter:

Momentary activation opens the door. Momentary contact of OPEN button on
3-button (open/close/stop) radio transmitter from mid-stop opens the door to full open
position. Cannot close the door.

• Safety Devices: When door is closing, momentary activation reverses the door.

• Timer to close: N/A

T: (Momentary on open and close, timer to close, SAFETY ACTIVATION & STOP BUTTON
DISABLE TIMER)

• Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door.

Momentary contact from mid-stop opens the door to full open position. Momentary contact at full-open refreshes the timer
if enabled at full open. Momentary contact at full open position re-activates the timer if timer is disabled previously by stop
button or safety device. Constant activation when door is opening, bypass mid-stop if enabled.

• Close button: Momentary on close.

• Stop button: If door is opening or closing, momentary activation stops the door.

Momentary activation while timer is counting at mid-stop or full open de-activates the timer.

• Single button device, single channel and 3-channel (1,2,3) radio transmitter:

SEQUENTIAL FUNCTION : Open/Stop/Close/Reverse..
COMMERCIAL FUNCTION: Open/Reverse/Refresh timer.

• 3-button (O/C/S) transmitter: Same as open, close, stop buttons.

• Safety Devices: When door is closing, momentary activation reverses the door to full

open AND DISABLES TIMER.

• Timer to close: Closes the door from mid-stop or full open. Momentary activation of stop button will de-activate the timer.

When door is closing, momentary activation of safety devices will reverse the door to mid-stop (if enabled) or full open and

20

de-activates the timer. Timer resumes its normal operation upon momentary activation of open push button or once the
close cycle is completed. If mid-stop is enabled and “Timer from mid-stop only” dip-switch is ON, timer is enabled only from
mid-stop and disabled from full open. If mid-stop is enabled and “Timer from mid-stop only” dip-switch is OFF, timer is
enabled from full open and mid-stop.

TS: (Momentary on open and close, timer to close secure, STOP BUTTON DISABLES TIMER)

• Open Button: Momentary activation opens the door. When door is closing, momentary activation reverses the door.

Momentary contact from mid-stop opens the door to full open position. Momentary contact at full-open refreshes the timer
if enabled at full open. Momentary contact at full open position re-activates the timer if timer has been disabled previously
by stop button. Constant activation when door is opening, bypass mid-stop if enabled.

• Close button: Momentary on close.

• Stop button: If door is opening or closing, momentary activation stops the door.

Momentary activation while timer is counting at mid-stop or full open de-activates the timer.

• Single button device, single channel transmitter and 3-channel (1,2,3) radio transmitter:

SEQUENTIAL FUNCTION: Open/Stop/Close/Reverse.
COMMERCIAL FUNCTION: Open/Reverse/Refresh timer.

• 3-button O/C/S radio transmitter: Same as open, close, stop buttons.

• Safety Devices: When door is closing, momentary activation reverses the door. Momentary activation refreshes the timer to

close.

• Timer to close: Closes the door from mid-stop or full open. Momentary activation of stop button will de-activate the timer.

Timer resumes its normal operation upon momentary activation of open push button or once the close cycle is completed.
If mid-stop is enabled and “Timer from mid-stop only” dip-switch is ON, timer is enabled only from mid-stop and disabled
from full open. If mid-stop is enabled and “Timer from mid-stop only” dip-switch is OFF, timer is enabled from full open and
mid-stop.

Warning: When replacing the logic board in a single-phase operator,
make sure that Jumper 2 is installed properly before operating the door.
Failure to do this will damage the logic board.

PROGRAMMING INSTRUCTIONS:

NOTE: ALL PROGRAM FUNCTIONS CAN BE INITIATED BY TURNING THE SELECTOR

SWTICH TO THE DESIRED SETTING AT ANY POINT DURING OPERATION EXCEPT
FOR THE MID STOP and RUN TIMER MODE,PROGRAMMING MUST START FROM THE
FULL CLOSED POSITION.

RUN-TIMER SETUP

Run-timer is the maximum amount of time the motor will run upon receiving an
open or close command. The factory default value for run-timer is 45 seconds.

Modify the run-timer from factory default:

1. Close the door to full close position.

2. Set the selector dial to “Run-timer” position. The “Delay On Close Timer”

LED should blink.

3. Press open button. Wait until door reaches full open position. The run timer value is set

to the time taken for the door to travel from full close position to full open position plus 5 seconds.

4. Set the selector dial to the desired mode of operation.

Modify the run-timer to factory default:

1. Close the door to full close position.

2. Set the selector dial to “Run-timer” position.

3. Pres stop button. The run-timer is modified to the factory default value. Then set the selector dial to the desired

mode of operation.

21

MID-STOP SETUP:

Mid-stop feature can be used to open the door to a preset point prior to full open position.

To Activate mid-stop:

1. Close the door to full close position.

2. Set the selector dial to “Mid-stop” position. “Mid-stop” LED starts blinking.

3. Press open push button. Door opens. Once the door reaches the desired mid-stop

position, stop the door by activating stop push button.

4. Set the selector dial to the desired mode of operation.

Note: When door opens to the programmed mid-stop position, “Mid-Stop” LED will illuminate.

To De-activate the mid-stop position:

1. Close the door to full close position.

2. Set the selector dial to “Mid-stop” position.

3. Press the stop button, Mid-stop is de-activated.

Modify mid-stop position:

To modify the current mid-stop position, follow the same steps to activate mid-stop. The new mid-stop position will
override the old mid-stop position.

TIMER TO CLOSE SETUP:

Timer to close is enabled only in TS and T modes of operation. To adjust the timer value
turn POT1 clockwise to the desired value. The minimum value for timer to close is
3 seconds and the maximum value is 300 seconds.

DELAY ON CLOSE SETUP (only for use with optional apartment board):

Delay on close timer can be used to delay the closing of the door in B2 and TS
modes of operation. This timer is de-activated in C2, D1, E2 and T modes of
operation. Delay on close timer is OFF when the “Delay on close” dial is set
to OFF position. To adjust this timer, rotate the dial clockwise to the desired
value. The minimum value for delay on close timer is 1 second and the
maximum value is 60 seconds. It is recommended to use this feature in
apartment applications where RED and GREEN traffic lights are used.
NOTE: In TS mode, the “Delay on close” timer starts only once the “Timer to close” has finished
counting. Unless a delay on close is required this dial should be rotated to the OFF position

ON-BOARD RECEIVER PROGRAMMING

This logic board has a built-in 372 MHz radio receiver and can only be used with
MICANAN single button, 3-button (OPEN/CLOSE/STOP) and 3-channel radio transmitters.

INSTALLING THE ANTENNA

Direct Connection:
Attach the antenna when supplied with the operator to the F connector
on the control box. For best reception, keep antenna wire straight
and away from metal objects.
Indirect connection (Mounting the antenna at a remote location):

1. Connect coax extension cable (not provided) to the F connector on the control

box.

2. Route cable inside metal enclosure.

3. Route and secure cable away from moving parts.

4. Mount antenna holder (not provided) outside enclosure.

5. Attach antenna to extension wire.

6. Position antenna wire straight. For best reception, keep antenna away from metal.

Note: Do not route coax cable near any moving parts of the operator. If necessary, secure coax wire away from any moving
parts

22

PROGRAMMING THE ON-BOARD RADIO RECEIVER

Warning: During programming, door operator will activate. Keep people and objects away from door.

1. Connect power to door operator.

2. Press and release the learn button once. The receiver’s LED will turn on.

3. To program a single button transmitter, press the button on the

transmitter. The receiver’s LED will blink twice indicating a
successful programming.

4. Press the button on the transmitter once more to confirm operation

of the door operator.

5. To program a 3-channel (1,2,3) transmitter, press any of the 3 buttons on the transmitter. The receiver’s

LED will blink twice indicating a successful programming. Press the same button on the transmitter to confirm
operation of the door operator. This button is now associated with that particular receiver. You can repeat the
programming process for the other two buttons to control two other receivers.

6. To program a 3-button (O/C/S) transmitter, press OPEN button on the transmitter. The receiver’s LED will blink

twice indicating a successful programming. Press the OPEN button on the transmitter to confirm operation of the
door operator. OPEN, CLOSE and STOP buttons on the transmitter can be used to open, close and stop the
operator respectively.

7. Test range of transmitter. Repositioning antenna may provide greater range.

8. Repeat transmitter-programming steps for additional transmitters.

OPERATION:

1. Press and release the button on MICANAN transmitter.

2. Receiver LED will light momentarily and door will cycle.

TO ERASE ALL LEARNED TRANSMITTERS:

1. Press and hold down the LEARN button.

2. After 5 seconds, the LED will blink for 5 seconds.

3. Release the LEARN button during the time LED is blinking.

4. After you released the button, the LED will blink 5 times indicating all transmitters are erased

from the receiver’s memory.

REPLACING REMOTE CONTROL BATTERIES:

The batteries (lithium, 3V) should produce power for up to 5 years. To replace the battery, open the transmitter by removing
the screws on the back of the transmitter. Match the positive and negative terminals of the battery to the positive and
negative terminals of the transmitter.

Note: The receiver and transmitter comply with part 15 of the FCC rules with RSS-210 of industry Canada. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: If an external radio-receiver (MICANAN or other) is used instead of the built-in radio receiver, it is highly recommended
to disconnect the co-axial cable from the logic board.
Note: When using any external receiver, the Micanan on-board receiver should not be used.

23

DIPSWITCH SETUP

Dip-switch

ON

OFF

NOTE

SEQ/COM

Single button and
radio in SEQ mode

Single button and
radio in COM mode

Mid-stop
timer

Timer is enabled
from mid-stop only

Timer is enabled
from both mid-stop
and full open

T or TS mode must be
selected to enable a timer
for mid-stop

Delay on
reverse

Delay on reverse is

1.5 seconds

Delay on reverse is

0.5 seconds

Micanan recommends 1.5
sec delay on reverse for all
applications

Motor
direction

Reverse motor
direction

Standard motor
direction

See Note ** below

NOTE: If motor direction is reversed, the open and close limit switches are automatically reversed. However, the advanced
close limit switch needs to be manually changed. To do this, disconnect the 2 wires from the advanced closed limit switch
and re-connect to the auxiliary limit switch provided.

STATUS LED

LED

Status

Cause

Fault

ON

-Primary safety devices not connected to P1 & P2
or not functioning properly

- Safety devices are activated

- 10k Ohm resistor (between S1 & S2) removed or
faulty

Fault

Blinking

- Interlock is activated.

- Interlock jumper is not connected.

Run-out timer

ON

- Run-out timer has elapsed

Delay on close timer

Blinking

- Delay on close timer is counting.

- Selector dial is set to Run-timer.

Timer to close

Blinking

Timer to close is counting.

Safety/Photo

ON

-Primary safety devices not connected to P1 & P2
or not functioning properly

- Safety devices are activated

- 10k Ohm resistor (between S1 & S2) removed or
faulty

Mid. Stop

ON

Door is at Mid-stop position.
Close Limit

ON

Close limit switch is activated.

Open Limit

ON

Open limit switch is activated.

Stop PB

ON
OFF

- Stop button connected and functioning

- Stop push button is activated (or stop circuit is
open).

Close Relay

Blinking

- Door is closing.

- Close relay is activated.

Open Relay

Blinking

- Door is opening.

- Open relay is activated.

Power

ON

24 VAC power to logic board is ON.

24

SECTION D: For all operator control types

Adjustment of door travel is done by moving the limit cams on the threaded shaft. The position of the 4 limit
switches are factory adjusted and should not be altered. The limit switches are:

- “Open” limit switch: End of door travel in the fully open position

- “Closed” limit switch: End of door travel in the fully closed position

- “Advanced Open” or “Auxiliary advanced closed” limit switch:

A) For relay logic operators this advanced open limit switch is used for open/close devices or timer
to close features.
B) For logic board this auxiliary closed limit switch is used for open/close devices used when
motor direction is reverse of standard.

- “Advanced Closed” Limit switch: Used to prevent reversing device from reversing

door when door is almost fully closed.

To adjust door travel:

1. Open cycle: Depress cam plate and spin “Open” limit cam away from “Open” limit switch to increase door
travel or spin “Open” limit cam towards the “Open” limit switch to decrease door travel. After each adjustment
ensure that cam plate fully engages in slots of both limit nuts.

2. Adjust “Open” limit cam so that door stops at the desired fully open position.

3. Close cycle: Depress cam plate and spin “Close” limit cam away from “Close” limit switch to increase door
travel or spin “Close” limit cam towards the “Close” limit switch to decrease door travel. After each adjustment
ensure that cam plate fully engages in slots of both limit nuts.

4. Adjust “Close” limit cam so that door stops at the desired fully closed position.

LIMIT SWITCH ADJUSTMENT

WARNING

TO REDUCE THE RISK OF INJURY OR DEATH:

DO NOT ATTEMPT TO MAKE LIMIT SWITCH ADJUSTMENTS UNLESS

POWER HAS BEEN ELECTRICALLY DISCONNECTED

25

SECTION E: For Operators with Interface Modules or Logic boards

Installation Safety Precautions

WARNING: MICANAN MK00649 NEMA-1 infrared photo system is for use only with MICANAN logic board operators
or relay logic operators equipped with the Micanan failsafe interface module. Use of this device on other than
recommended operators can lead to severe or fatal injury. Follow these instructions carefully.

IMPORTANT: For momentary activation on close, the MICANAN photobeams (or a Micanan 2-wire monitored edge),
must be installed as part of the operator system. If a Micanan 2-wire monitored edge or the MICANAN infrared
photobeam system is not installed (or not operating correctly), the operator will only operate in fault mode
(constant pressure to close).

READ and FOLLOW all installation instructions.

1. Before installing the photo beam, read the door or gate operator’s instruction manual fully, so you are aware of all of

the unit’s functions and features.

2. Wear protective gloves and eye protection when using tools.

3. Before installing photo beam, disconnect all power to door operator to prevent unintended operation and have the

door full open or close.

4. Do not reconnect power to the door or gate operator until instructed to do so.

5. Only install photobeams on a properly functioning door or gate operator.

6. Installation and wiring must comply with local building and electrical codes. This device is not intended and must not

be installed in a explosive environment.

WARNING: Keep fingers and other body parts away from all moving parts of the door and gate operator system
while the system is being operated.

WARNING: To prevent unintended operation, disconnect power to the door or gate operator prior to installing the
photobeam system.

MICANAN N-1 PHOTOCELL (MK00649)

Installation
Note: Photo beams should be mounted as close to the door track inside the door to offer maximum entrapment
protection.

Wall installation:

1. Select a location on the wall no more than 6 inches from the floor to install wall mounting brackets on the left and
right side of the door. Both brackets must be mounted at the same height for proper alignment.

2. Drill holes in the wall and attach brackets to the wall using screws and nails provided as shown in Fig. 1.

INSTALLATION OF MICANAN N-1 OR N-4 PHOTOCELLS

26

3- Using the wing nuts, attach the receiver and transmitter of the photo system to the mounting brackets (with arrow

pointing up). Note that the receiver and transmitter can be installed on the left side or right side of the door.

4- Adjust the position of the transmitter and receiver on the slot of the brackets. Secure the receiver and transmitter to

the mounting brackets as shown in figure 2.

5- Pair the two white wires and the two white/grey wires together from transmitter and receiver.
6- Connect these paired wires to the P1 and P2 terminals on the logic board (or interface module if applicable) as

shown in Figure 3. Use minimum 18 gauge wires and secure the wires to wall or ceiling.

MICANAN N-4 PHOTOCELL (MK00650)

Installation

Note: Photo beams should be mounted as close to the door track inside the door to offer maximum entrapment
protection.

Wall installation:

1. Select a location on the wall no more than 6 inches from the floor to install wall mounting brackets on the left and
right side of the door. Both brackets must be mounted at the same height for proper alignment.

2. Drill holes in the wall and attach brackets to the wall using screws and nails provided as shown in Fig. 1.

27

3. Using the 8 phillips head screws, attach the receiver and the transmitter to the two mounting plates (Fig 2A).

4. Using the wing nuts, attach the receiver and the transmitter of the photo system to the mounting L-brackets (with
arrow pointing up) as shown in Fig 2B. Note that the receiver and transmitter can be installed on the left or right
side of the door. For applications requiring the photobeams to be further away from the wall, use the extension
brackets provided as shown in Fig 2C

5. Adjust the position of the transmitter and receiver on the slot of the brackets and tightly secure the wing nuts

6. Loosen the 4 fastening screws and remove the cover from the photobeam transmitter and receiver housings and
insert electrical wire through the strain relief (Fig 3A). Pair the two white/grey wires together from transmitter and
receiver

7. Connect these paired wires to the P1 and P2 terminals on the logic board (or interface module if applicable) as
shown in Fig 3B. Use minimum 18 gauge wires and secure the wires to wall or ceiling.

For Nema-1 and Nema-4 photobeams:

Aligning the photo beams:

1. Turn the power on to the operator. If the transmitter and receiver are installed properly, the lights on both the
transmitter (red L.E.D.) and receiver (green L.E.D.) will be ON.

2. If the photo beams are not aligned properly, the receiver light (green) is OFF. Adjust the position of the transmitter
and/or the receiver on the slot of the mounting bracket until the light on the receiver is ON and then secure to the
bracket.

Photo system operation:

MICANAN photo beams must be connected for the door to close in momentary mode (unless a MICANAN monitored 2­wire edge is connected). When the photo system is properly installed and aligned, the infrared beam will detect any
obstruction in the path of the beam. Upon detecting an obstruction, closing door will stop and reverse to full open. The
MICANAN operator control circuit continuously monitors the correct operation of the photo system. If the photo beams are
not connected or not functioning properly, the operator will go into fail-safe mode and closing door will reverse to full
open. In fail-safe mode door can only be closed by constant pressure on close.

28

To test the photo system:

1. Open the door to full open position.

2. Close the door.

3. When door is closing, obstruct the beam. The door should stop and reverse.

1. Remove cotter pin tapped to pulley.

2. Rotate clutch nut CCW (loosen) until there is insufficient tension to permit clutch to drive door.

3. Gradually tighten clutch nut until the tension on belleville washers is sufficient to permit clutch to drive door smoothly
but will allow clutch to slip if door is obstructed. It should be possible to stop moving door by hand if clutch is properly
adjusted.

4. Lock clutch nut in place by inserting cotter pin.

The brake adjustment is factory set and should only require minor adjustment after extensive use.

Verify brake adjustment by manually holding in solenoid plunger. When brake is properly adjusted, the brake shoe
pads should make complete contact with brake drum with sufficient brake spring tension to stop and maintain
door when solenoid is de-energized. When solenoid is energized, brake shoes should release from drum with
sufficient clearance to avoid contact between shoes and drum.

To adjust brake tension, tighten (to increase) or loosen (to decrease) nylon lock nut on brake spring bolt. Observe
solenoid during electrical testing of brake. Brake spring tension must be adjusted so that solenoid should pull and
release smoothly and quietly. Too much or too little tension on brake spring may cause solenoid to burn out.

To adjust individual brake shoes, loosen nut on brake shoe adjustment bolt and adjust bolt. When properly
adjusted, there should be a small clearance between adjustment bolt and solenoid bracket when solenoid is de­energized. When solenoid is energized, brake shoes should move away from drum with sufficient clearance to
avoid friction between brake shoe pad and drum. After adjustments are made be sure to tighten nuts on brake
shoe adjustment bolts.

CLUTCH ADJUSTMENT

BRAKE ADJUSTMENT (For model PRO-TB)

29

- The operator is equipped with a quick release disconnect system to manually operate door in case of
emergency. This feature should not be used to manually operate a malfunctioning door.

1. Pull the release cord downwards to disconnect trolley arm from carriage and manually operate door.

2. To reconnect door arm to carriage, pull emergency release cord and re-insert trolley arm to trolley carriage
spring pin.

EMERGENCY MANUAL OPERATION

WARNING

TO REDUCE THE RISK OF INJURY OR DEATH:

DO NOT ATTEMPT TO USE EMERGENCY DISCONNECT SYSTEM WHILE

OPERATOR IS RUNNING.

POWER TO THE OPERATOR SHOULD BE TURNED OFF PRIOR TO

OPERATING DOOR MANUALLY.

TO AVOID BEING STRUCK BY DOOR ARM, DO NOT STAND DIRECTLY

UNDER THE RELEASE ARM WHEN PULLING THE RELEASE CORD.

30

- Inspect manual function of the door every 3-months. Make sure that door runs smoothly. If door does not
manually open or close freely, have a qualified service person make repairs. Do not attempt to electrically
operate a malfunctioning door.

- Every 3 months:

1. Verify that door area is kept clean. Remove any obstructions that would prevent proper door operation.

2. Check for any excessive slack in chains. If chain adjustment is required verify and adjust limit switches, if
necessary.

3. Verify and adjust clutch and brake (Do not lubricate).

4. Lubricate chains, bearings and limit shaft.

5. Verify that motor, solenoid and operator runs smoothly and quietly. Verify that carriage runs smoothly
on tracks.

- Every 6 months:

1. Verify tightness of all fasteners and set screws.

2. Verify that operator is properly secured.

3. Inspect manual disconnect.

4. Verify tension and condition of V-belt

- Every 12 months:

1. Perform a complete service check.

2. Verify that inside of control box is clean and that grounding wires, terminations and power terminations
do not show signs of corrosion.

3. Verify tightness of all terminal strip screws and electrical connections.

4. Verify power supply, voltage of input terminals during operation.

5. Verify that current consumption of operator corresponds to nameplate information

OPERATOR MAINTENANCE

WARNING

TO REDUCE THE RISK OF INJURY OR DEATH:

DO NOT ATTEMPT TO SERVICE THE OPERATOR UNLESS POWER

SUPPLY HAS BEEN DISCONNECTED

31

32

PRO-T PRO-TB

CODE PART # DESCRIPTION (PRO-T/TB) C/W BRAKE

QTY QTY

** 1 MOTOR 1 1
MM00286 2 FRAME PRO-APT MSI0280 1 1
MM00002 3 CONTROL BOX MSI0001 1 1
MM00001 4 CONTROL BOX COVER MSI0005 1 1
MM00024 5 CAM PLATE MSI0013 1 1

ME00001 6 LIMIT SHAFT 3/8-1/2 x 9.75" 1 1
MG00030 7 LIMIT CAM 1/2-20 UNF 2 2
MH00001 8 BRONZE T-BUSHING 3/8" ID 2 2

MK00004 9 LIMIT SWITCH 4 4

MJ00006 10 LIMIT SWITCH DOUBLE SPACER 3/4" LONG 4 4
MG00003 11 DOUBLE NUT FOR LIM-SW. 4 4

MF00003 12 R.H. PHILLIPS MACHINE SCREW 4-40 UNC x 1-1/2" 8 8

MF00004 13 R.H. PHILLIPS MACHINE SCREW 6-32 UNC x 1" 2 2
MO00001 14 CAM PLATE COMPRESSION SPRING (.178IDx.032GX.55L) 2 2
MG00007 15 HEX NYLON LOCK NUT 6-32UNC 2 2
MH00006 16 COLLAR 3/8 ID 1 1
MM00288 17 VERTICAL MOTOR MOUNT BRACKET PRO-APT (MSI0282) 1 1
MM00046 18 CONTROL BOX HINGE 2 2

MI00001 19 MOTOR PULLEY 5L 5/8 ID X 2" OD 1 1

ME00055 20 KEYWAY 3/16 SQ. x 1-3/4" LONG 1 1

MI00034 21 PULLEY 9" OD c/w bushing 3/4" ID 1 1
MI00006 22 V-BELT 5L-325 1 1

MJ00004 23 CLUTCH PLATE ALUMINIUM 3/4" ID 1 1
MQ00007 24 SPRING PIN 1/4" x 2" LONG 1 1

MJ00005 25 CLUTCH PAD 3/4 ID 1 1
MG00014 26 SLOTTED HEX NUT 3/4-24UNF 1 1
MG00004 27 BELLEVILLE WASHER 13/16 IDx1-3/16X1/8 6 6
MQ00002 28 COTTER PIN 1/8 x 2.5" LONG 1 1

MF00012 29 CARRIAGE BOLT 5/16-18UNC x 5/8" 4 4
MG00012 30 RIBBED HEX NUT 5/16-18UNC 4 4
MH00008 31 COLLAR 3/4" ID 2 2
MH00007 32 COLLAR 1" ID 2 2
MH00013 33 FLANGE BEARING 3/4" IDx1-3/8 OD 2 2
MH00009 34 FLANGE BEARING 1" IDx2"OD 2 2
MD00050 36 SPROCKET 410B23 X 1" 1 1
MD00005 37 SPROCKET 410B12 X 3/8" 1 1
MD00381 38 #410 ROLLER CHAIN 49 PITCH C/W CONNECTING LINK 1 1
MD00059 39 SPROCKET 41B32 x 1" 1 1
MD00006 40 SPROCKET 41B10 x 3/4" 1 1
MD00004 41 A DRIVE SPROCKET 410B12 x1" (1/3, 1/2hp) 1 * 1 *
MD00007 41 B DRIVE SPROCKET 41B12 X 1" (3/4, 1HP) 1 * 1 *
MD00382 42 #41 ROLLER CHAIN 51 PITCH DRIVE 1 1

ME00003 43 TROLLEY INPUT SHAFT 3/4"x 11-3/4" no kw 1" thread 1 1

ME00017 45 KEYWAY 1/4" SQ. x 1-1/4" LG 3 3
MQ00016 47 SPRING PIN 3/16" x 1-1/4" Long 1 1
MQ00005 48 SPRING PIN 3/16" x 1-1/2" Long 2 2

MF00011 50 H.H. BOLT 3/8"-16UNC X 3/4" LONG 8 8
MQ00008 51 SET SCREW 5/16" -18 12 14
MQ00009 52 SET SCREW 1/4" -20 5 5

MF00046 53 H.H. SLOTTED SELF ROUNDING WASHER HEAD SCREW 10-32 UNF x 1/2" 5 5
MM00154 54 BRAKE PLATE HR MSI0166 1
MM00289 55 SOLENOID LEVER PRO-APT MSI0283 1

MF00005 56 R.H. PHILLIPS MACHINE SCREW 10-32 UNF x 5/8" 1
MQ00001 57 COTTER PIN 1/8 x 1.5" 1
MG00016 58 FLAT WASHER #10 5
MG00008 59 HEX NYLON NUT 10-32 UNF 1

MK00026 61 A SOLENOID 120V 1 *

MK00027 61 B SOLENOID 220V 1 *

MK00028 61 C SOLENOID 460V 1 *

MK00029 61 D SOLENOID 575V 1 *

MJ00003 62 BRAKE DRUM 1

MJ00001 63 BRAKE SHOE LEFT 1

MJ00002 64 BRAKE SHOE RIGHT 1
MH00002 65 MILD STEEL BUSHING 9/32ID x 13/32OD x1-1/16 1
MO00002 66 BRAKE COMPRESSION SPRING (5/16"ID-.05G-2.50L) 1
MG00006 67 HEX NUT 1/4-20UNC 6
MG00009 68 HEX NYLON LOCK NUT 1/4-20UNC 2

MF00028 69 HEX HEAD BOLT 1/4-20UNC x 1-1/4" (Full thread) 2

MF00029 70 HEX HEAD BOLT 1/4-20UNC x 1-3/4" (partial thread) 1

MF00044 71 HEX HEAD BOLT 1/4-20UNC x 4" (partial thread) 1
MG00017 72 1/4" FLAT WASHER 2
MG00010 74 RIBBED HEX NUT 10-32UNF 2 6
MG00018 75 LOCK WASHER 3/8" 2 2
MG00019 76 FLAT WASHER 13/16" I.D.x1.5OD (3/4" SHAFT SIZE) 2 2
MG00013 98 RIBBED HEX NUT 3/8" - 16UNC 6 6
MR00007 103 BRAKE DISCONNECT CABLE 1/16" x 12" LONG 1
MQ00012 104 ADJUSTABLE CABLE STOPPER 1

ME00006 117 INTERMEDIARY SHAFT (PRO-HHD) 1" X 10-7/16 1 1
MG00063 130 HEX NUT 10-32 4

MF00015 135 ROUND HEAD PHILIPS MACHINE SCREW 6-32 X 3/8" 4
MG00022 136 LOCK WASHER #6 4
MG00023 137 HEX NUT 6-32 4

ME00050 141 FRAME SUPPORT SHAFT 3/4" x 6" LONG 1 1
MG00093 179 FLAT WASHER #8 4

4

MQ00010 180 SET SCREW 10-24 1 1

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

35

36

!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

!
!
!
!
!
!
!
!
!
!
!
!
!

39

40

41

WARRANTY

HEAD OFFICE

1380 St-Regis | Dorval, Quebec | H9P 2T5 | Canada

TEL: [phone]

Toll Free: 1-877-888-1116

Fax: [phone]

PHOENIX

1236 W. Southern Ave. | Suite 104 | Tempe, AZ | USA | 85282

TEL: [phone]

Toll Free: 1-888-816-8584

Fax: [phone]

ATLANTA

2885 N. Berkeley Lake Rd. | Suite 7 | Duluth, GA | USA | 30096

TEL: [phone]

Toll Free: 1-800-798-2543

Fax: [phone]

MICANAN SYSTEMS warrants that materials and workmanship are free from defects for a period of two years from
the date of invoice. Materials returned to Micanan deemed defective after examination will be returned at the
option of Micanan with repaired, new or re-manufactured parts.

MICANAN SYSTEMS will not be responsible for any extra charges incurred in the process of returning defective

material. All returned material must be received pre-paid or it will not be accepted.

This warranty is limited, and in lieu of all other warranty expressed or implied. There is no expressed liability due on

the part of the seller.
