Mi Band
Model: XMSH01HM
1. Xiaomi’s Fitness-Bracelet (Mi band) Assembling
Mi Band Core Unit
Strap
Place Core Unit into Strap
a. take the Unit and strap b. insert the unit into a strap
c. put a strap to your wrist
IMPORTANT:
All translations are carried by GearMi. All right
reserved by © GearMi. No further distribution allows.
2. Mi band App Installation
Please install the Mi band App or scan QR code as figure below.
3. Mi band Synchronization
Turn the Mi band on, register with the Mi band App and
login. Then your mobile phone shall detect the Mi band
by bluetooth. The indicators on the Mi band Unit will turn
white. Gently press Mi Band core unit few times to finish
the pairing with your mobile.
IMPORTANT:
All translations are carried by GearMi. All right
reserved by © GearMi. No further distribution allows.
Mi band Start Up
After a successful synchronization the Mi band immediately starts to monitor the activity of your
movements and the trace quality of your sleep. The quantity of included indicators shows the
intensity of your movements. You can look at your bracelet and check the indicators at any time.
1/3 steps to your goal
More than 1/3 steps taken to your goal
More than 2/3 steps taken to
your goal
The goal is achieved
Charging the battery
IMPORTANT:
All translations are carried by GearMi. All right
reserved by © GearMi. No further distribution allows.
Note: The indicator light is white.
Core Unit Weight:
5.0g
Battery Type:
Lithium
-polymer batter
Battery Capacity:
41mAh
Synchronization:
Bluetooth 4.0
Operating Temperature
Range:
-
10ºC - 50 ºC
Water resistance level:
IP67
Length of strap:
225mm
Adjustable Length:
157mm
-205mm
Material of the fastener:
Aluminum Alloy
Strap:
Polyurethane
Requirements:
Synchronized with Apple OIS and Android 4.4 and above, as well as synchronized via
Bluetooth with
Xiaomi 4.0
Items
Toxic and hazardous substances or elements
Pb
PlumbumHgMercur
y
Cd
Cadmium
Cr
Hexavalent
Chromium
PBBs
Polybrominat
ed biphenyls
PBDEs
Polybrominat
ed
diphenylether
s
Core Unit
× ○ ○ ○ ○ ○
Battery
○ ○ ○ ○ ○ ○
Strap
○ ○ ○ ○ ○ ○
Bracelet fastener
○ ○ ○ ○ ○ ○
USB cable
× ○ ○ ○ ○ ○
Main Specifications*
*All technical information is valid, Xiaomi retains final authority in its interpretation
The presence of toxic and hazardous substances
○: toxic and hazardous substances in all parts of the device contain in an amount below the threshold to the
SJ/T11363-2006 “The requirements on restriction toxic and harmful substances in the goods.”
×: means the presence of toxic and hazardous substances at least in one part of this device in the quantity
exceeding the limit value according to the SJ/T11363-2006 “The requirements on toxic and harmful substances
in the goods.”
The copper alloy of the bracelet basics and USB cable contains a small amount of an aluminum alloy.
The device complies with the European requirements RoHS and the standards for environmental protection. It is
reckon that the content of aluminum in copper alloy is still difficult to reduce internationally.
IMPORTANT:
All translations are carried by GearMi. All right
reserved by © GearMi. No further distribution allows.
Item
Faults
Core Unit
The initial configuration function is not working
Indicators fail to light
Vibration does not work
Occurrence of cracks due to the material or construction
apparatus
USB cable
Not charging properly
Warranty
The warranty service of Xiaomi Fitness Band “Mi band” is carried out in accordance with the China law of “consumer rights” and
the “Law on the quality of products”.
The warranty service includes:
During the warranty period you have the right to repair, change or return the item. For repair, replacement or product return you
must provide a receipt or purchase order number.
1. Within 14 days from the date of purchase, if the problem from the <Lists of Faults> occurs, you may return the product for a
replacement or refund.
2. Within 12 months from the date of purchase, if the problem from the <Lists of Faults> occurs, Xiaomi service center
determines the cause of the problem. Free repair may be provided. (*)
Xiaomi Mi Band List of Faults
IMPORTANT:
All translations are carried by GearMi. All right
reserved by © GearMi. No further distribution allows.
(*) For all the customers who buy mi band from GearMi (by providing purchase order number or receipt within 12
months from the date of purchase), we will repair or replace the faulty (from <Lists of Faults>) product on your behalf
with Xiaomi.
