Version 6.0
06/06/2017
User Manual
JETVARNISH 3DS
EN
Original instructions
JETVARNISH 3DS
User Manual
- 2 -
Created by MGI Digital Technology
4, rue de la Méridienne
94260 Fresnes
FRANCE
© 2017 by MGI. All rights reserved.
The copyright protection includes all forms of material content and information subject to all applicable
legal standards of government regulations and relevant laws of judicial court protection. This includes
without exception the contents generated by software and displayed on the screen such as format,
patterns, symbols, screen display, layout.
MGI®, the MGI logo and all MGI products mentioned in this document are trademarks of MGI Digital
Technology, in France (FR) and/or other countries. All brand names and products mentioned are
trademarks of their respective holders and are hereby acknowledged.
This document is not contractual. Subject to change without notice.
JETVARNISH 3DS
User Manual
- 3 -
Table of contents
1 Revision History .................................................................................................................................................... 6
2 Security and Safety Rules .................................................................................................................................... 7
2.1 Safety and important warning safety and important warning items .............................................................. 7
2.2 Outline ........................................................................................................................................................... 7
2.3 Important notice ............................................................................................................................................. 7
2.4 Description items for danger, warning and caution ....................................................................................... 7
2.5 Safety and warning items location .............................................................................................................. 10
2.6 Emergency stop buttons location ................................................................................................................ 12
2.7 Before doing service work apply security rules when using the JETVARNISH 3DS .................................. 13
2.8 JETVARNISH 3DS Safety Instructions ....................................................................................................... 14
3 Machine specifications and configurations ...................................................................................................... 16
3.1 Machine specifications ................................................................................................................................ 16
3.2 Expected print speeds ................................................................................................................................. 18
3.3 Machine configurations ............................................................................................................................... 19
3.4 Working Conditions ..................................................................................................................................... 21
4 General description ............................................................................................................................................. 25
4.1 Feeder ......................................................................................................................................................... 25
4.2 Margin Table................................................................................................................................................ 25
4.3 Printer .......................................................................................................................................................... 25
4.4 Dryer ............................................................................................................................................................ 26
4.5 Stacker ........................................................................................................................................................ 26
4.6 Pilot presentation ......................................................................................................................................... 26
4.7 JETVARNISH 3DS – Tactile Interface presentation ................................................................................... 32
5 Periodical Maintenance ....................................................................................................................................... 34
5.1 Maintenance chart ....................................................................................................................................... 34
5.2 Cleaning of the cleaning roller ..................................................................................................................... 34
5.3 Cleaning of the print heads ......................................................................................................................... 36
5.4 Cleaning of the printing belt......................................................................................................................... 37
5.5 Cleaning of the top cells reflectors .............................................................................................................. 38
JETVARNISH 3DS
User Manual
- 4 -
6 Installing the Machine Consumables ................................................................................................................ 40
6.1 Installation of the Cleaning Agent. Waste and Varnish Containers ............................................................ 40
6.2 Varnish registration procedure .................................................................................................................... 45
7 Start up & Shutdown procedures ...................................................................................................................... 50
7.1 Procedure details ........................................................................................................................................ 50
7.2 Start up ........................................................................................................................................................ 51
7.3 Shutdown..................................................................................................................................................... 53
8 How to use the machine ..................................................................................................................................... 57
8.1 Feeder ......................................................................................................................................................... 57
8.2 Cleaning unit................................................................................................................................................ 68
8.3 Margin table ................................................................................................................................................. 69
8.4 Stacker ........................................................................................................................................................ 70
9 How to use the 3DSHM ....................................................................................................................................... 72
9.1 Main menu ................................................................................................................................................... 72
9.2 Standard printing ......................................................................................................................................... 75
9.3 Print menu ................................................................................................................................................... 76
9.4 Printing summary ........................................................................................................................................ 87
9.5 History ......................................................................................................................................................... 89
9.6 Supervision menu ........................................................................................................................................ 90
9.7 Settings menu ............................................................................................................................................. 94
9.8 Information and Cost Calculator .................................................................................................................. 95
9.9 How to use the MGI Spot Varnish Editor .................................................................................................... 97
9.10 Login Management .................................................................................................................................... 102
9.11 Remote access .......................................................................................................................................... 103
9.12 Automatic cleaning of the print heads ....................................................................................................... 104
10 MGI ARC system ................................................................................................................................................ 109
10.1 Substrate ................................................................................................................................................... 109
10.2 Camera connection ................................................................................................................................... 109
10.3 Camera setting .......................................................................................................................................... 110
10.4 Image quality ............................................................................................................................................. 112
10.5 Model definition ......................................................................................................................................... 114
10.6 Overall function test ................................................................................................................................... 122
10.7 3DSHM camera configuration ................................................................................................................... 124
JETVARNISH 3DS
User Manual
- 5 -
11 Working method with the JETVARNISH 3DS .................................................................................................. 126
12 Troubleshooting ................................................................................................................................................ 138
12.1 Error codes ................................................................................................................................................ 138
12.2 Jam procedure .......................................................................................................................................... 142
12.3 Emergency stop procedure ....................................................................................................................... 148
12.4 Power failure procedure ............................................................................................................................ 150
12.5 Paper feeding issue ................................................................................................................................... 151
12.6 File troubleshooting ................................................................................................................................... 152
12.7 Varnish image troubleshooting .................................................................................................................. 153
13 Glossary ............................................................................................................................................................. 158
14 Appendix ............................................................................................................................................................ 161
14.1 Pilot tree view ............................................................................................................................................ 161
14.2 3DS Hub Manager tree view ..................................................................................................................... 167
JETVARNISH 3DS
User Manual
- 6 -
1 REVISION HISTORY
Version
Date
Comments
Version 4.0
12/05/2015
Updates
Version 5.0
02/11/2016
Certified version
Version 5.1
26/01/2017
Mark and safety symbol changes
Version 6.0
06/06/2017
Wording changes and better descriptions
Varnish thicknesses & Cost Calculator
changes
New error message table
New printhead height setting
The following changes have been made from the original version.
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 7 -
2 SECURITY AND SAFETY RULES
DANGER
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury*
WARNING
Indicates a hazardous situation that, if not avoided, could
result in death or serious injury*
CAUTION
Indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury*
2.1 Safety and important warning safety and important warning items
Read carefully the Safety and Important Warning Items described below to understand them.
2.2 Outline
Read carefully the Safety and Important Warning Items described below to understand them before doing service
work.
2.3 Important notice
Because of possible hazards to an inexperienced person servicing this product as well as the risk of damage to the
product, MGI Digital Technology (hereafter called MGI) oblige that only an operator trained by MGI or its
distributors can use the machine.
Changes may have been made to this product to improve its performance after this Technical Manual was printed.
Accordingly, MGI does not warrant, either explicitly or implicitly, that the information contained in this Technical
Manual is complete and accurate.
The user of this Technical Manual must assume all risks of personal injury and/or damage to the product while
servicing the product for which this Technical Manual is intended. Therefore, this Technical Manual must be
carefully read before doing service work both in the course of technical training and even after that, for performing
maintenance and control of the product properly. Keep this Technical Manual also for future service.
2.4 Description items for danger, warning and caution
2.4.1 Description in the Technical Manual
In this Technical Manual, each of three expressions «DANGER», «WARNING», and «CAUTION» is defined as
follows together with a symbol mark to be used in a limited meaning. When servicing the product, the relevant
works (disassembling, reassembling, adjustment, repair, maintenance, etc.) need to be conducted with most care.
* using the ANSI Z535.5 definition
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 8 -
2.4.2 Descriptions for safety and important warning items
High Voltage
Caution to be taken against high voltage. Electrification may cause
fatal or serious injury. Handling of the product is allowed only for
the qualified service engineer.
Make sure to open the covers only after disconnecting the
corresponding electric supply line.
Optical Radiation (UV)
Protect your eyes and skin from UV radiation. Exposure to UV
radiation may cause serious eye or skin injury.
High Temperature
Risk of burn when touched. Never remove the safety cover while the
product is in operation.
Maintenance work should be conducted only after confirming the
power supply is cut off and the temperature reaches low and safe
level.
Moving Parts
Risk of injury when hand or finger is caught by the moving parts.
Caution to be taken not to pinch your hand or finger in the moving
parts when working on the product.
Clothing
Caution to be taken so that any part of your clothing is not caught by
the moving parts. It may cause serious injury to the body part
involved.
Eye Protection
Wear eye/face protection such as chemical splash proof UV goggles
or face shield.
Ear Protection
For continuous and all-day use at close proximity of the equipment,
it is recommended to wear ear protection.
When residual risks are present, symbols for safety and important warning items are used as follow:
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 9 -
Skin & Hand Protection
Avoid skin contact. Wear impermeable gloves and suitable
protective clothing. Barrier creams may help to protect the exposed
areas of the skin, they should however not be applied once
exposure has occurred. Use Nitrile rubber gloves. Do not use natural
rubber gloves. Do not wear PVC gloves as PVC absorbs acrylates.
Replace gloves immediately when torn or any change in appearance
(dimension, color, flexibility, etc.) is noticed. When maintaining
varnish or cleaning solution area, replace gloves every 30 minutes.
Use only powder free gloves.
Foreign Materials
Do not introduce foreign materials or leave jigs in the product.
Do not put any weight on this part as it might damage it.
Additional advice
Food, beverages, and tobacco products should not be carried, stored, or consumed where this material
is in use. Before eating, drinking, or smoking, wash face and hand thoroughly with soap and water. End
user must always be present while the machine is running.
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 10 -
2.5 Safety and warning items location
① UV Radiation
Protect your eyes from UV radiation. Exposure to UV radiation may cause serious eye injury.
② Eye protection
Wear eye/face protection such as chemical splash proof UV goggles or face shield.
③ Ignitable Liquid/vapor/gas
Risk of explosion or fire. Never bring heat, spark, and fire close to the area. Make sure sufficient
exhaustion or ventilation.
④ High Temperature
Risk of burn when touched. Never remove the safety cover while the product is in operation.
Maintenance work should be conducted only after confirming the power supply is cut off and the
temperature reaches low and safe level.
⑤ Moving Parts
Risk of injury when hand or finger is caught by the moving parts. Caution to be taken not to pinch your
hand or finger in the moving parts when working on the product.
⑥ High Voltage
Caution to be taken against high voltage. Electrification may cause fatal or serious injury. Handling of the
product is allowed only for the qualified service engineer.
Make sure to open the covers only after disconnecting the corresponding electric supply line.
⑦ Skin and Hand Protections
Avoid skin contact. Wear impermeable gloves and suitable protective clothing. Wear eye/face
protection such as chemical splash proof goggles or face shield. Barrier creams may help to protect the
exposed areas of the skin, they should however not be applied once exposure has occurred. Nitrile
rubber gloves. Do not use natural rubber gloves. Do not wear PVC gloves as PVC absorbs acrylates.
Replace gloves immediately when torn or any change in appearance (dimension, color, flexibility, etc.) is
noticed.
⑧ Foreign Materials
Do not introduce foreign materials or leave jigs in the product. It may cause damage to the product or
cause fire due to short-circuit occurred on the electric parts.
⑨ Moving Parts
Caution to be taken so that any part of your clothing is not caught by the moving parts. It may cause
serious injury to the body part involved.
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 11 -
Inside ①②③④
Inside ⑤
Inside ①②⑤
Note: red dotted rectangle indicates an internal part of the machine.
Inside ⑦② ⑥
Note: red dotted rectangle
indicates an internal part of
the machine.
Inside ⑦
①②
⑥ ⑥
Inside ⑥
Inside ⑤
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 12 -
Inside ⑧
Note: red dotted rectangle indicates
an internal part of the machine.
⑨
⑨ ⑧
2.6 Emergency stop buttons location
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 13 -
To acknowledge an emergency stop or a door opening, release the emergency button or close the door
For security purposes, when you see this Logo, take care of moving parts;
disconnect the main power plug before any maintenance or reparation on the
equipment.
and press on the Reset button.
To release an emergency button, turn it counter clockwise to lift it:
To reset a stop, press the Reset button to change the state of the JV3DS from RED to GREEN:
RED
GREEN
2.7 Before doing service work apply security rules when using the JETVARNISH 3DS
2.7.1 General using security rules
For security purposes, always disconnect the main power plug before any maintenance or reparation on the
equipment.
2.7.2 Moving parts
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 14 -
2.8 JETVARNISH 3DS Safety Instructions
General operating rules
For safety reasons, always disconnect power connectors prior to performing
any maintenance or repair operation. Any person authorized to intervene shall
be called for any important setting or repair operations, especially for electrical
repair purposes.
Handling UV varnish and cleaning agent require the following rules to be
complied with in order to prevent any risks to health: Refer to MSDS –
Material Safety Datasheet: Steps 2 - 7 - 8 - 15, delivered together with the
consumables.
Rules related to presence of UV
system
The use of UV systems may entail a few risks. These risks are eliminated
when these systems are used under normal circumstances. The risks to
humans when using UV systems are the following:
Skin and eye exposure to UV radiation.
Contact between skin, eyes and UV varnish.
As regards the environment, two elements have to be taken into account:
UV varnish and UV LED.
UV radiation
Exposure to UV radiation causes skin and eye injury. High doses cause
sunburns. As eyes are the most sensitive to UV radiation, it is recommended
to not directly look at a UV LED. The symptoms are actinic conjunctivitis and
snow blindness. Although such disorders may be very painful, they disappear
without leaving permanent damage. A good UV system features a device
which masks direct radiation of the lamp or reflectors through protective plates
and narrow beam.
UV varnishes and cleaning
agent
UV varnish and the cleaning agent bear a safety sign which warns that eye
and skin irritation may occur upon any contact.
Waste treatment
Residues of UV varnish are chemical residues which shall therefore be
transformed by a specialized company.
Safety - Fire extinguisher
As any machine using elements heating up to more than 70°C, the
JETVARNISH 3DS shall have a fire extinguisher nearby.
Tips and tricks
"Post curing" (that could be termed delayed drying) is a well-known
phenomenon in UV printing processes. It is recognized that, regardless of the
power of the UV LED used for drying, the polymerization reaction is not
complete. It is therefore better to wait for 24 hours prior to performing any
finishing (cutting or scoring) or lamination operation. As regards glossy
varnishes, it is also better to wait for 24 hours before delivery in order to
prevent any fingerprints during handling.
Legislation
Industrial safety legislation concerning control of hazardous materials makes
the user fully responsible for safety during use and application of inks; this
includes by-product treatment and waste disposal. The ink supplier's
responsibility consists in transmitting Safety Datasheets relating to products or
groups of products; the latter contain information in condensed form.
Safety perimeter
For more safety, a 60cm perimeter around the JETVARNISH 3DS is
recommended; as a rule, the freer the direct area around the machine, the
less substantial the risks in terms of both pallet size and chemical products. It
is prohibited to place chemical products inside the machine, except at the
specific locations -replacement of ink container-.
Recommendations
It is highly recommended not to have flammable materials around the
machine; 1 meter clearance all around the machine allows for safe working.
For user convenience, it is recommended to have an air renewal system.
As a matter of fact, the JETVARNISH 3DS operates together with UV LED
which release heat, and the ambient temperature may rise at the end of the
day.
JETVARNISH 3DS
2. Security and Safety Rules
Technical Manual
- 15 -
Do not let the machine operate alone
When operating, the JETVARNISH 3DS uses heating elements - up to more
than 70°C - even though sensors are present to prevent all risks, it is
prohibited to leave the JETVARNISH 3DS in unattended operation.
Wearing protective gloves and
safety goggles
Varnish is an irritating product - see MSDS attached to each product - and
cleaning agent dry skin. It is mandatory to observe the usual precautions:
Wear appropriate protections such as gloves, goggles and gown before
handling.
Avoid skin contact. - Use synthetic material gloves
Change any contaminated clothing.
In case of skin contact, immediately wash with water and soap.
Never use UV cleaning agent to clean hands!
Should there be any risk of varnish or cleaning solution splashes into eyes,
wear protective goggles.
In case of contact with eyes, immediately wash with plenty of water, and
seek medical advice.
Use a hand barrier cream.
In case of varnish splashes, immediately clean.
Dispose of all cleaning materials in containers provided for this purpose.
Machine precautions
Hold the printing unit doors closed. The varnish was specially developed for
the JETVARNISH 3DS; it can harden through the action of UV LED;
nevertheless, varnish left in the open may polymerize under the effect of solar
radiation or neon tubes. Holding the printing system as far away as possible
from direct light guarantees longevity of the components in contact with
varnish.
Caution relating to products
Any product having started a polymerization phase cannot be used as severe
damage to the JETVARNISH 3DS may occur, thus jamming the print heads. It
is mandatory to dispose of any product having suspicious looks.
Dust and environment
The room where the JETVARNISH 3DS is located shall be as clean as
possible as any dust deposited on sheets before varnish drying is
"encapsulated"
Varnish and cleaning agent storage
Preserve inks and varnish in the original containers and cartons closed and
sealed, away from light. - See MSDS Step No. 7
Store in a cool and dry place.
Varnish shelf lives
MGI varnish has a shelf life of 1 year.
The storage place temperature shall be between 15°C and 35°C.
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 16 -
3 MACHINE SPECIFICATIONS AND CONFIGURATIONS
Printing technology
MGI’s exclusive inkjet engine technology
Drop-on-Demand (DoD) technology
Piezoelectric print heads
Single pass printing
Flexible & scalable printing architecture
Coating thicknesses
Depending on your file, the printed material, the CYMK printing technology
and/or finishing technology used, the coating thickness can vary from 21 µm up
to 121 µm for 3D raised effects and a tactile finish (and 42µm to 242µm when
the twin bar option is installed) - new data as of June 2017
30-35 µm required on toner (such as Bizhub C1070/C1060, C1100/C1085 and
Meteor DP8700+) in order to have optimum printing quality
Production speeds
Up to 2,298 A3 per hour at 21** µm
Up to 1,624 A3 per hour at 43** µm
Up to 513 A3 per hour at 116** µm
**new data as of June 2017
NOTA: Printing speeds are given to indicative information and may vary
according to printing substrate, number of drop set on the data file and under
full operator responsibility. See the above table showing the production speeds
per drop.
Registration
Fully motorized and automatic left side lay guide
New feature of automated registration using MGI ARC System with optical
detection of printed crop marks. Overall registration of ± 200 µm
Formats
Min: 21.0x29.7 cm / 8 x 11.8” (in portrait mode i.e. long side first)
Max: 36.4x102.0 cm / 14.33x40.15”
Max. print width
35.3 cm or 353 mm - new data as of September 2016
Substrate thickness
Min: 135 gsm and not less than 150 µm/6 mil before printing & lamination
Motorized height-adjustment print heads
Substrates
Printing on most matte or glossy laminated surfaces, with or without aqueous
coating, layered paper, plastic, PVC and other coated materials
Printing directly on most digital prints (i.e. Bizhub C1070/C1060, C1100/C1085
or Meteor DP8700+) with no lamination or coating required
UV coating container capacity
10 liters/2.6 US gal. tank capacity
High capacity automatic feeder
Feeder able to handle a paper pile up to 30 cm / 11.86” high
Approximately 2,500 sheets at 135 gsm
High pile output stacker
Stacker able to handle a paper pile up to 30 cm / 11.86” high
Approximately 2,500 sheets at 135 gsm
Paper path
100% flat paper path
Vacuum feed system
Air feed system
Automatic double sheet detection
3.1 Machine specifications
Max: 450 gsm and not more than 450 µm/18 mil before printing & lamination
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 17 -
In-line UV dryer
“On-the-fly” drying & curing via integrated LED
Spot Coated sheets can be immediately finished or handled, no additional
drying time required
Front end system
Dedicated PC; CPU + touch-screen + keyboard/mouse
Ethernet connection 10/100/1000 BT (RJ 45)
Built-in application software
Comprehensive job queue management
Predictive printing cost calculator (coating consumption)
Dedicated image editor to do local and fast image editing prior to production
Maintenance & remote
technical support
Daily maintenance completed in less than 10 minutes
Majority of procedures are automated
Automatic cleaning system
From cold start to production in less than 10 minutes
Remote troubleshooting & support via included video/web camera
(high speed internet connection required)
Operator panel
Integrated user-friendly LCD touch-screen
Options
Variable data package: Barcode 1D and 2D camera reader to spot varnish
on-the-fly
Twin bar: Increase the maximum thickness up to 200/232 µm and double the
print speed in most of the situations
iFOIL S: inline hot foiling module
Dimensions (L x W x H)
& weight
4.26 (5.47*) x 1.14 x 1.80 meter
1 meter / 3.3’ clearance required on all 4 sides
± 1,100 kg / ± 2,425 lbs
Electrical requirements
7.5 kW (32 A) at 220-240 Volts - 2 plugs CEE/IP44 32A (1P+N+E)
Operating environment
Temperature: 18 to 30 °C / 64 to 86 °F
Relative humidity: between 35 and 55 % (no condensation)
Optimum 22°C, 40% humidity
*with the longest paper extensions installed
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 18 -
3.2 Expected print speeds
Since the release of the 3D Hub Manager V1.6, the method to compute, both the varnish consumption and the
varnish thicknesses, has evolved. Therefore, the expected JETVARNISH 3DS print speeds are now the following:
JETVARNISH 3DS with 1 printhead bar (standard configuration)
Varnish
thickness
(in µm)
Droplet
number
Speed (in meter per sec.)
Standard varnish
coverage < 50%
High varnish
coverage ≥ 50%
21
3
0.3
0.15
29
4
0.28
0.14
36
5
0.24
0.12
43
6
0.212
0.106
51
7
0.182
0.091
58
8
0.159
0.0795
65
9
0.141
0.0705
73
10
0.127
0.0635
80
11
0.116
0.058
87
12
0.106
0.053
94
13
0.098
0.05
102
14
0.091
0.05
109
15
0.085
0.05
116
16
0.079
0.05
JETVARNISH 3DS with 2 printhead bars (with the optional twin bar)
Varnish
thickness
(in µm)
Droplet
number
Speed (in meter per sec.)
Standard varnish
coverage < 50%
High varnish
coverage ≥ 50%
42
6
0.3
0.15
58
8
0.25
0.125
72
10
0.2
0.1
86
12
0.17
0.085
102
14
0.164
0.082
116
16
0.158
0.079
130
18
0.141
0.0705
146
20
0.127
0.0635
160
22
0.116
0.058
174
24
0.106
0.053
188
26
0.098
0.05
204
28
0.091
0.05
218
30
0.085
0.05
232
32
0.079
0.05
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 19 -
NOTA: Printing speeds are given to indicative information and may vary according to printing substrate,
number of drop set on the data file and under full operator responsibility.
You will notice that JETVARNISH has two technical limits. The upper limit where the JETVARNISH cannot
go faster than 0.3 meter per second. The lower limitation where the JETVARNISH 3DS cannot go slower
than 0.05 meter per second.
It is not possible to print in less than 3 droplets, equivalent to 21µm of thickness.
3.3 Machine configurations
JETVARNISH 3DS:
- Paper Feeder
- Main body with the IJ Print
Engine
- Computer with the 3DS Hub
Manager
- Banner extensions
-AIS SmartScanner (might be
optional and not represented on
this picture)
Variable data option:
1D and 2D barcode reader
(camera 3) with
-JETVARNISH 3DS RIP1 (standard
VDP performances)
or
-JETVARNISH 3DS RIP2 (high VDP
performances)
Hot Foiling Option:
Inline iFOIL S module
Twin bar option:
Increase the maximum thickness
up to 200/232 µm (depending on
the 3DS Hub Manager version)
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 20 -
AIS SmartScanner:
Artificial Intelligence SmartScanner
for an automated registration and
make ready. Replace totally the
ARC System (XY cameras)
Refer to the “AIS Scanner
User” manual
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 21 -
3.4 Working Conditions
IMPORTANT!
It is your responsibility to guarantee the settings of the different terms of this document in order to
have the equipment working according to MGI specifications.
3.4.1 Installation
The machine needs to be installed on the flat stable floor to reduce noise and vibration. The machine is
provided with mounted feet to stabilized and level it. Please refer to the technical manual for
installation instruction.
3.4.2 Electrical Tension
Standard: 2x 220-240V 32A 50/60 Hz.
It is mandatory to be sure that the tension will not drop when all the machines are switched on. The
JETVARNISH 3DS must always be connected to the 230V power due to the ink circuit depression system.
3.4.3 Temperature & Humidity
The UV coating is applied using an UV inkjet system. It is important to ensure its viscosity is adequate. so
the machine needs an operating environment between 18 - 25°C (65 - 77°F)
The humidity needs to stay in the range of RH 35-55% without condensation.
To optimize the quality of the prints. and avoid damage to the heads. it is highly recommended to work
in a dust-free environment. Finishing equipment produces a lot of dust and should not be in the same
environment as the JETVARNISH 3DS.
3.4.4 Sun
The machine cannot be directly exposed to the sunlight.
3.4.5 Workstation
The operators must have a workstation for consumables cleaning and all the recommended tools for
maintenances operations (information given during the training)
3.4.6 Storage
- Varnish
The JETVARNISH coating should be stored at ambient temperature (18-30° Celsius). in particular 4 to 8
hours before being loaded in the machine.
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 22 -
- Paper storage
To ensure good production conditions. MGI recommend you to store your paper prior to production
following the above conditions:
The paper to be spot coated should be stored flat to avoid any deformation and curling. They
should stay also with their original packaging until the last moment prior to printing.
The paper should be stored within a room where the temperature never deviates from 20-25°C
(68°-77°F). The relative humidity (RH) should be kept in the range of 35-55% without
condensation. Do not hesitate to use to use air humidification system when the quality of the air
is to dry. If humidity in the paper storeroom or print shop is too low. the material releases
moisture into the room. This leads to unwanted changes in the dimensions of the paper. The
paper then is no longer perfectly flat and cannot be processed efficiently. Doubling. register
differences. wrinkling and distortion are difficulties frequently encountered as a result of low
humidity. If paper is too dry during processing at low humidity. electrostatic charges are created.
The paper sticks together and stops running smoothly through the printing press. This also
applies even more dramatically to synthetic materials such as PVC or polypropylene.
An air conditioning system is also a good solution to keep the air dry when there is too much
humidity (RH). Do not hesitate to ask your paper supplier about the best storage conditions for
its substrates.
- Acclimation before production
Before production. the paper should reach the production room to be acclimated. The paper should stay
24-36 hours in the production room prior to production, but keep it away from the heater or a cold wall.
Same parameters apply when printing (ambient air 20-25°C and RH 35-55%).
3.4.7 Precautions when handling varnish
The JETVARNISH 3DS varnish is a skin irritant. Any manipulation in its liquid form needs to be done using
gloves (one box of gloves is provided with the machine), protective clothes (such as a lab coat) and
glasses. During fill up and cleaning. it is recommended to have the use of a table, a trash can and paper
towels. MGI also provides a cleaning solution. After drying. the varnish can be handled with no issue.
3.4.8 Precautions with the UV rays
The JETVARNISH 3DS emits UV rays during production. Those rays are contained within the equipment
by the protective covers, and thus do not present a risk to the operators. However. during maintenance
and adjustment operations. it is imperative that UV filtering glasses be worn. You can order them from
MGI. reference PN 4004.
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 23 -
3.4.9 Reception of the equipment
Each crate will be shipped with a “Tilt Watch” indicator. Prior to signing off and opening the crates.
please ensure that each indicator has not been activated (red).
OK
Not good. Do not open the crate
3.4.10 Internet Access
It is mandatory to have access to the internet network on the Command WorkStation (CWS) computer
in order to activate the consumables licenses & the use of the remote access.
3.4.11 Prohibition of the Use of Expired Consumable
We hereby inform you that it is strictly forbidden to use any expired consumable on our MGI
equipment. As you already know. consumables as varnish are made of chemical component which
cannot be used after its lifetime (1 year).
Despite our warnings if you are using varnish which the expiration date has been exceeded in MGI
equipment. this will damage the print heads and all the ink circuit system (pumps. filters. etc.) and
therefore the electronic boards.
Such damages are not covered under the warranty and also by the maintenance agreement.
Likewise. using a new varnish will not eliminate the consequences generated by the use of varnish which
expiration term was exceeded on the JETVARNISH 3DS. A full cleaning and control of machine is
required to verify whether the electronic circuits and other components were not damaged.
3.4.12 Fire protection
We hereby inform you that the JETvarnish. like any machine using heating elements. needs to have
close by the equipment. an adapted Class E (Electrical) fire-extinguisher (CO2 or Powder). We also
strongly recommend avoiding storing flammable products around the equipment.
3.4.13 Running the machine
The JETVARNISH. in running mode. use heating elements (over 100°C) even if sensors are here to
prevent any risk. it is forbidden to run the machine without any human monitoring!
3.4.14 Varnish of the JETVARNISH 3DS
Warning: It is strictly forbidden to use any other varnish than the one provided by MGI Digital
Technology.
Any damage incurred to the equipment due to the use of another varnish will immediately void the
manufacturer’s warranty and the user will be held responsible for all damages.
JETVARNISH 3DS
2. Security and Safety Rules
User Manual
- 24 -
3.4.15 Noise emissions:
Machine running in stand-by: 62 dB (A)
Machine running in printing without foiling: 72 dB (A)
Machine running in printing with foiling: 79 dB (A)
For continuous and all-day use at close proximity of the equipment. it is recommended to wear ear
protection.
3.4.16 Risk of sliding. stumbling of fall:
To avoid that an operator slides, stumbles or falls on the electrical cables on the floor between the
machine and power supply. The installation of over floor trunking is recommended.
JETVARNISH 3DS
4. General description
User Manual
- 25 -
4 GENERAL DESCRIPTION
Printer module
Feeder module
4.5
Stacker
4.4
Dryer
4.3
Printer
4.2
Margin table
4.1
Feeder
4.1 Feeder
The feeder is able to feed paper sheets of different qualities from a pile into the machine. The sheets are
being fed from the top of the pile by a vacuum drum system. For a perfect sheet separation. the feeder
features an air blow system. the approximate loading capacity is 2.500 sheets at 135 gsm.
4.2 Margin Table
The margin table is used to register the sheets to be perfectly aligned with the printing module. It’s
equipped with a side lay. on which you can adjust the skew if necessary. The pressure on paper is
adjustable by the type and quantity of balls applied on the paper. We supply 3 types of ball depending
on the paper type (plastic. glass and metal).
The HMI so called “PILOT” which is the interface between the operator and the machine. is located on
the front of margin table module. and will allow the operator to access the different parts of the
machine.
4.3 Printer
The Inkjet printer is the heart of the machine. this module is equipped with a vacuum belt to transport
the sheets under the print heads. The head plate embedded the electronic boards which are driving the
heads thru the computer and PLC connections.
The print engine also includes an UV LED ramp to freeze the varnish for the 3D effects. and the ARC
system (Automated Registration Camera) to read the printing mark. to ensure accurate spot UV coating.
JETVARNISH 3DS
4. General description
User Manual
- 26 -
4.4 Dryer
This section is also equipped with UV LED to have a perfect varnish curing on the sheet.
4.5 Stacker
The stacker can receive sheets one by one.
4.6 Pilot presentation
The pilot is a mainly technical interface. However. some operator parameters of the machine can be
directly managed from this interface.
The operator can perform the following actions without switching the tactile interface on:
- Manage the side lay position and skew.
- Activate or deactivate the machine dryers for further printing.
- Set the margin and printing belts speed.
- Activate or deactivate the double sheet sensor.
- Activate. deactivate or set the vacuum capacity of the printing belt.
- Move the head plate.
The pilot is also used to display important information such as:
- Appearance of error messages on the printing system.
- Precise location of the reason for any machine problem.
- Number of files sent by the 3DSHM. number of remaining files to be printed. and number of already
printed files.
- Air system status values.
- Varnish system status.
4.6.1 Main screen
[9]
[4]
[10]
[3]
[6]
[5]
[8]
[7]
[11]
[2]
[1]
[12]
JETVARNISH 3DS
4. General description
User Manual
- 27 -
[1] Machine status message (warning + acknowledgment)
[2] Language change button
Change language between English and French
[3] Information screen access button
Access to all machine information in particular sheet counter
[4] Margin table screen access button
Centering/skew adjustment of the side lay
[5] Machine parameter screen access button
Adjustment of the printing belt vacuum. putting into service the double sheet detection
[6] Print head maintenance screen access button
Access to various print head maintenance
[7] Buzzer enable/disable button
[8] Technical menu/MGI mode service access button
Reserved for technicians. a password it is necessary to access it
[9] Printing information
Display information about printing. Quantity asked and Stacker sheet counter. the thickness of the substrate
[10] Varnish level
Display the varnish diagram (container. main tank and intermediate tank levels)
[11] Air circuit and Curing power
Display the state and value of the vacuum. depressurization circuit and the curing modules
[12] Back to previous menu (available for all screen)
JETVARNISH 3DS
4. General description
User Manual
- 28 -
4.6.2 Information screen
The purpose of this screen is to give information about the machine. Refer to Chapter 4.6.1 Main screen
for access.
[13] Machine information
Display the machine serial number. PLC serial number and the IP address of the pilot
[14] Production information
Display the counter of sheet
[15] Software version
Display the version of the panel (pilot). Air/Ink (Air/Varnish) circuit and the 3DSHM
[16] Date
Display the date and hour
[17] Consumable list
On this screen you have the lifetime of the curing modules. the cleaning unit and the 3 maintenance kits
You can reset the counter of a consumable by clicking on it and validate.
[13]
[17]
[15]
[14]
[16]
JETVARNISH 3DS
4. General description
User Manual
- 29 -
4.6.3 Margin table screen access button
The purpose of this screen is to give an access to the side lay position. Refer to Chapter 4.6.1 Main
screen for access.
[18] Paper custom width selection
Select the custom width of your substrate
[19] Paper width selection
Select the width of your paper to move the side lay
[20] Printer side (left side) position adjustment
[21] Feeder side (right side) position adjustment
[22] Side lay position value
4.6.4 Machine parameters
The purpose of this screen is to give an access to settings of the machine. Refer to Chapter 4.6.1 Main
screen for access.
[23] Double sheet sensor
[19]
[20]
[21]
[22]
[18]
[23]
[24]
[25]
[26]
JETVARNISH 3DS
4. General description
User Manual
- 30 -
You can activate or disable the double sheet sensor
[24] Belt cleaning
Make the printing belt turn to clean it (Refer to 5.4 Cleaning of the printing belt)
[25] Drum stop offset
Length of substrate vacuum by the drum
[26] Print heads move to purge position button
4.6.5 Print head maintenance screen access button
This screen shows the cleaning maintenances of the machine. Refer to Chapter 4.6.1 Main screen to
access.
[27]
JETVARNISH 3DS
4. General description
User Manual
- 31 -
[27] Cleaning maintenance selection:
Purge button
Wiping button
[28] Confirmation button to start the selected cleaning
[29] Purge timing
You can select the duration of a purge (of 3 seconds. 5 seconds or 8 seconds).
[30] Printhead selection for the Fill Ink cleaning maintenance
4.6.6 Technical menu/MGI mode service access button
This screen shows how to access to technical mode via a password. Refer to Chapter 4.6.1 Main screen
to access.
[28]
[29]
[30]
JETVARNISH 3DS
4. General description
User Manual
- 32 -
4.7 JETVARNISH 3DS – Tactile Interface presentation
The following icons are present on the desktop:
3DSHM is used to print, monitor production and set up the JETVARNISH 3DS. (Refer
to Chapter 9 How to use the 3DSHM)
MGI Kernel (“Noyau” in French) communicates with all physical components of the
JETVARNISH 3DS.
This application is automatically run upon starting of the 3DSHM and configuration
interface.
MGI ARC System configures the cameras. (Refer to Chapter 10 MGI ARC system)
VeriSens configures the barcode reader (optional)
MGI Access allows for remote access. (Refer to Chapter 9.11 Remote access)
Here is the interface of the 3DSHM such as it will be displayed to the operator during the machine
production phases. This interface is accessible once the whole machine is started.
JETVARNISH 3DS
4. General description
User Manual
- 33 -
The following is a quick presentation. Refer to Chapter 9 How to use the 3DSHM.
[1] Folder selection:
Listing and management of folders
[2] Job management:
When a folder is selected. files inside appear on this area
[3] Printing progress:
Sheet counter. play/pause button and printing stop button
[4] Menu selection:
There are 3 menus available: Printing menu. Management menu and Technician menu
[5] Information message:
Here is displayed all information messages (state of the machine. warning and error messages)
[6] Printing status:
Substrate format. printing speed (in sheet/hour). remaining time of printing and varnishes level (in percentage)
[7] Administration icons:
For Varnish registration. User management and MGI access
[8] Cleaning tab:
This tab display the hot purge procedure. (Refer to Chapter 9.1 for the hot purge procedure)
[8]
[2]
[1]
[3]
[5]
[7]
[6]
[4]
JETVARNISH 3DS
5. Periodical Maintenance
User Manual
- 34 -
5 PERIODICAL MAINTENANCE
Before any periodical maintenance operation:
Refer to Chapter 2. Security and Safety Rules to read carefully the Safety and Important Warning
Items described below to understand them before doing service work.
5.1 Maintenance chart
JETVARNISH 3DS - MAINTENANCE LIST
Operation
Time
Clean the green cleaning roller
Every morning
Clean all the print heads
Every evening
Clean the printing belt
Every week
Clean the top cell reflectors
Every week
The description and the maintenance procedure will be detailed in the following chapters.
5.2 Cleaning of the cleaning roller
[1] Latches
Open the latches [1] on each side of the cleaning unit.
Raise the green cleaning roller to remove it from the machine.
[1]
[1]
JETVARNISH 3DS
5. Periodical Maintenance
User Manual
- 35 -
Then rub with a cloth soaked with water onto the entire length of the green roller.
Do not wipe the roller to keep its "adhering" effect.
Put the green cleaning roller in its position on the cleaning unit and close the latches [1].
JETVARNISH 3DS
5. Periodical Maintenance
User Manual
- 36 -
5.3 Cleaning of the print heads
Warning: Print heads are fragile parts that require great care to remain it operational as long
as possible. A scratched nozzle plate can cause missing nozzles which deteriorate print quality.
Caution: Use only cleaning solutions and cleaning foam validated by MGI. Use only one foam
per head. Do not use an used foam.
Caution: Insert the stick properly in foam. Wipe the heads. foam in horizontal position.
without applying excessive pressure. During this operation wear protective equipment (gloves
and glasses).
Caution: Wipe the heads. foam in horizontal position. without applying excessive pressure.
Skin and Hand protections:
Avoid skin contact. Wear impermeable gloves and suitable protective clothing. Wear eye/face
protection such as chemical splash proof goggles or face shield. Barrier creams may help to
protect the exposed areas of the skin. they should however not be applied once exposure has
occurred. Nitrile rubber gloves. Do not use natural rubber gloves. Do not wear PVC gloves as
PVC absorbs acrylates. Replace gloves immediately when torn or any change in appearance
(dimension. color. flexibility. etc.) is noticed.
Eye protection:
Wear eye/face protection such as chemical splash proof UV goggles or face shield.
JETVARNISH 3DS
5. Periodical Maintenance
User Manual
- 37 -
5.4 Cleaning of the printing belt
- Localize the dry varnish on the printing belt.
- Apply a very strong tape on this varnish.
- Remove the tape by sharply pulling. Should varnish do not stick onto. please find a stronger tape.
- Repeat the operation for all surfaces with dry varnish.
JETVARNISH 3DS
5. Periodical Maintenance
User Manual
- 38 -
5.5 Cleaning of the top cells reflectors
[1] Printing belt
[2] Reflector
Caution: Use only cleaning solutions and cleaning foam validated by MGI.
Caution: Insert the stick properly in foam.
Caution: During this operation wear protective equipment (gloves and glasses).
Caution: Do not put cleaning solution on the printing belt.
[1]
[2]
JETVARNISH 3DS
5. Periodical Maintenance
User Manual
- 39 -
Skin and Hand protections:
Eye protection
Make move the printing belt [1] to reveal a reflector [2].
Use cleaning foam with cleaning solution on it and apply on the reflector [2] to remove dust and varnish.
Be careful to not put cleaning solution on the printing belt [1].
Make move the printing belt [1] to access to the other reflector [2] and clean it.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 40 -
6 INSTALLING THE MACHINE CONSUMABLES
6.1 Installation of the Cleaning Agent. Waste and Varnish Containers
The varnish. cleaning agent and waste containers are installed at the back side of the machine.
Open the back door.
[1] Varnish container
[2] Waste container
[3] Cleaning agent container
[1]
[2]
[3]
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 41 -
6.1.1 Cleaning agent container
Open the cleaning agent container by unscrewing its cap.
Insert the pipe with the pierced cap on the container.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 42 -
Place the container to its location and connect the pipe connector.
To remove the cleaning agent container. do the previous steps in reverse order.
6.1.2 Waste container
The waste container is located on the left of the cleaning agent container.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 43 -
Open the waste container by unscrewing its cap.
Place the waste container to have the two pipes inside (one black pipe coming from the cleaning circuit
and a white pipe coming from the purge tray).
6.1.3 Varnish container
The varnish container is located on the back of the machine. A hatch dedicated to its access is located on
the left of the back door.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 44 -
To change a varnish container. remove the pipe inside the empty one and clean it. You can place the
pipe on the holder next to the container with a tissue underneath.
Before opening and placing the new varnish container. you can register it on the 3DSHM (Refer to 6.2
Varnish registration procedure).
Then open the new container and place it at the emplacement inside the machine. Put the metallic pipe
inside the container and push on it to well seal the rubber cap.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 45 -
6.2 Varnish registration procedure
6.2.1 Purpose of the registration
Warning: An Ethernet connection is mandatory to register a varnish container.
Varnish registration enables:
- The varnish to be checked for compatibility with the equipment.
- The validity date of each varnish in the machine to be checked in order to prevent problems at the inkjet
print heads.
This registration shall mandatorily be achieved every time a container is installed in the machine. or in
advance when long production is to be provided for.
Note: Should varnish be not registered. the machine is blocked.
Here is the registration principle for a varnish container. and the sequence to be followed:
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 46 -
Located on the bottom right of the screen. this button is used to access the consumable
register screen.
The above icon opens the window below.
The top of the screen indicates the “JET Code“ and “Control Code“ which are used to identify the
machine. These codes are required to activate the consumables on the site.
The center of the screen displays the list of varnishes which were registered on the JETVARNISH 3DS.
The button below hides the empty pockets:
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 47 -
The "Serial Number" corresponds to the first series of figures written on the consumable. The "type"
corresponds to the varnish type. The third field shows the quantity of varnish used over the quantity of
varnish of the consumable.
The "Activation date" corresponds to the moment when the pocket was registered on the JETVARNISH
3DS.
The "Expiration date" is the varnish expiration date. Should the expiration date be exceeded. the
varnish has to be replaced.
The checkbox of the "In use" field is used to change consumable.
"License" contains a red pictogram should the consumable license be invalid or not entered. and a green
pictogram should the license be entered and valid. Double-clicking the red pictogram enables an
activation key to be entered.
6.2.2 Procedure
1. Click the "Website" icon.
2. The window below opens on the Internet explorer. and enables you to access the varnish registration site in two
languages (French or English).
3. Select the language and then click "Enter".
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 48 -
4. For identification purposes. you must enter the “JET Code” and “Control Code” of the machine. When logging
in with these codes for the first time. a more complete identification procedure is requested in order to localize
the machine in the world and know the person responsible for the machine.
5. The following window asks you to scan or manually enter the two items of information specific to the varnish
container placed in the machine (Serial number and Key).
6. Validating these codes automatically generates a valid license for that varnish pocket only. An email is
automatically sent to the machine production manager in order to confirm the container license. Please copy the
license.
7. In the 3DSHM. please click the following button:
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 49 -
8. The window below should open.
The following fields must then be completed:
- Serial Number.
- Key.
- Activation key.
Identify whether the pocket is being used or not by checking the "Use pocket?" box and then pressing
"Register" to validate pocket registration.
Note: Please note that if the pocket has no license. it can be pre-saved but. upon its use. only 10% of the
pocket is available. Registration will have to be validated through a license to unblock the remaining
90%.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 50 -
7 START UP & SHUTDOWN PROCEDURES
7.1 Procedure details
By touching the Pilot Touch Screen. the starting procedure appears.
It is mandatory to follow up step by step this procedure.
For Starting and Shutdown procedure. check icon are display to inform the state of each step of the
procedure. There are 4 states for this icon:
- Step of procedure not done yet.
- Step in progress.
- Step to validate (to be able to go to the next step).
- Step done.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 51 -
7.2 Start up
[1]
The first step is to disable all emergency buttons (which are activated when the machine is shutdown)
and switch on the power of electronic boards (next to the pilot panel).
This step needs to be acknowledged .
[2]
Then press the blue button next to the switch power of the electronic boards.
1 2 3
4
5
6
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 52 -
[3]
Start the computer at the back of the machine. This step need to be acknowledged .
[4]
During this step the machine make its initialization (the printing plate and purging tray are initialized).
[5]
The next step is to start the 3DSHM on the computer .
The software makes the communication with all cameras and pilot. Then it checks the RCB and ICB
communication. To finish it checks the print heads licence.
The following window appears. Select the “LOGIN” and enter the “PASSWORD”.
As soon as you are logged. the pilot go automatically to the next step.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 53 -
[6]
On the 3DSHM the following message appears when you are starting the machine:
A wiping of print heads is mandatory.
Follow the wiping procedure (Refer to 9.12 for Automatic cleaning of the print heads).
Once the wiping procedure is done. the machine is ready to print.
7.3 Shutdown
7.3.1 Close the 3DSHM
Close the 3DSHM and select to “Shutdown the printer”.
Then. confirm your choice.
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 54 -
The Pilot Touch Screen will show up the shutdown procedure.
It is mandatory to follow up step by step this procedure every time you shutdown the machine.
7.3.2 Cleaning of the print heads
[1] Start the cleaning
Click on the blue icon to start the automatic cleaning of the print heads (Refer to 9.12 for Automatic
cleaning of the print heads).
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 55 -
[2] Switch off the power of the electronic boards and press an emergency button
This step needs to be acknowledged .
[3] Shutdown the computer once you have finish to close everything on it
This step needs to be acknowledged .
JETVARNISH 3DS
6. Erreur ! Résultat incorrect pour u
ne table.
User Manual
- 56 -
[4] Wait for the machine extinction
When all the steps are finished a timer starts to end the shutdown procedure. Once it is finished the
pilot screen turns to the save-screen.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 57 -
8 HOW TO USE THE MACHINE
8.1 Feeder
8.1.1 Feeder guides
[1] Feeder plate
[2] Back stop pile holding weight shaft
[3] Stop pile holding weight
[4] Side guides
8.1.2 Feeder panel (2 versions available)
First generation (up to S/N 122) Second generation (from S/N 123)
[5] Substrate suction test button (blue or white color)
[6] Double-feed reset button (red or yellow color)
[7] UP button
[8] DOWN button
[1]
[3]
[2]
[4]
[7]
[8]
[5]
[6]
[7]
[8
[5]
[6]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 58 -
To move up the feeder plate. press button [7].
To bring down the feeder plate. press button [8].
To activate the pump and the margin table. press button [5].
To reset a double sheet error. press button [6] after removing the picked up printing substrate (margin
table belt goes ON).
Before printing. it is mandatory to adjust height of paper pile to avoid jam or double sheets trouble. To
do it. setup the upper pile limit sensor. Refer to Chapter 8.1.3 Upper pile limit sensor.
8.1.3 Upper pile limit sensor
[9] Upper pile limit sensor adjusting handle
[10] Upper pile limit sensor
[11] Upper pile limit sensor switch
To setup upper pile sensor:
1. Put top of paper pile in contact with upper pile sensor switch [11] to activate sensor [10] (Refer to Chapter
chapter 8.1.2 to move feeder plate).
[10]
[9]
[9]
[11]
[10]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 59 -
2. Now raise and descent of feeder plate switch to automatic mode (button [7] lights up).
3. Reach this position. To reach this position. check if the positioning of feeder plate is on automatic mode. If it is.
turn the handle [9] to send up or bring down upper pile sensor [10]. As feeder plate positioning is on automatic
mode. it height follow the upper pile sensor height.
8.1.4 Vacuum drum setting
[12] Vacuum drum
[13] Vacuum drum height handle
[14] Vacuum drum angular handle
Adjust the height of vacuum drum [12] according to the substrate thickness. For that. screw or unscrew
the vacuum drum height handle [13].
Depending on the thickness and weight of the paper. the position of the slot inside the vacuum drum
needs to be adjusted.
The position of the vacuum drum slot can be set vertically or diagonally.
For that. push or pull the vacuum drum angular handle [13].
Paper pile
[12]
[13]
[14]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 60 -
8.1.5 Blowing holes
[15] Blowing holes
All blowing holes [15] can be opened and closed with a 3mm Allen screwdriver. Each hole is instead
three holes which can be adjusted.
OPEN CLOSE
All blowing holes [15] outside the substrate pile have to be closed. In order to test the air flow. the
substrate pile has to be in the upper position then use the Pump button [5]. Only the first substrate has
to be separated.
[15]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 61 -
8.1.6 Air flow adjustment
[16] Compressor location
[17] Compressor
[18] Vacuum adjustment handle
[19] Blowing adjustment handle
The power of the air flow can be adjusted in order to separate correctly the different printing substrate
according to their thickness.
The vacuum [18] is always set at 100%.
The blowing [19] can be adjusted depending of the thickness of the substrate. The default value is 30%.
Tips: Between the maximum (to the end) and the minimum (handle release). you can make 3 turns. To
be at 30% turn until the handle is release then make 1 turn in “+” direction.
8.1.7 Side cleats stack adjustment
[20] Handles
To adjust the width of side cleats stack. first release the two handles [20] to be able to slide the side
cleats stack on the ruler. Move aside the side cleats stack at maximum distance. Put the printing
substrate to the middle of the feeder plate and put side cleats stack in contact with printing substrate
on one side and leave a little slack on the other side. Retighten the two handles [20] to fix the position
of side cleats.
[16]
[17]
[18]
[19]
[20]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 62 -
8.1.8 Vacuum drum speed adjustment
The speed of the vacuum drum can be adjusted to change the distance between substrates. You can
modify it on the 3DSHM (Refer to 9.3.5.3 for Feeder tab).
8.1.9 Printing substrate feeder error code
During use of printing substrate feeder. this error code can be displayed:
E566 - Double-sheets.
E572 - Paper jam.
E586 - Paper missing
Refer to Chapter 12.1 Error code to clean this error message.
8.1.10 Sidelay adjustment
Caution: this adjustment needs to be checked during the JETVARNISH 3DS installation.
Remove the ball holder plate.
Select the format 210 mm on the pilot (refer: 4.6.3[19]).
Remove the ball guide.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 63 -
Remove the 2 ball guide holder bars.
To do so. unscrew the 2 Allen screws with Allen key number 3.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 64 -
Remove the sidelay from the margin table. For that remove these 3 following screws.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 65 -
Caution: behind all the screws a counter nut is present. Hold it with wrench key number 7.
When the side lay is out of the margin table you can setup it. Uptight the 4 following screws.
When the lower part of the side lay is free. put 3 plastic cards between the lower and the upper part of
the side lay. It is necessary to place the plastic cards exactly as the same place than 4 the screws.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 66 -
Tight back the 4 screws.
If the setup it is done correctly. you will be able to slide 3 plastics between the lower and the upper part
of the side lay. If you feel some hard point. you have to do again the setting.
Put back the side lay on the margin table.
Caution: it is mandatory to setup the distance between the side lay and the belt of the margin table to
avoid to damage it.
To do so put 3 pieces of 200 gsm paper at these 4 specific points.
Caution: This setting must be done on top the belt.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 67 -
When it is done fix the side lay with the 3 screws and the counter nuts.
Put back the 2 ball guide holder bars. then put back the ball guide.
JETVARNISH 3DS
8. How to use the machine
User Manual
- 68 -
8.2 Cleaning unit
[1] Cleaning unit holder
[2] Green cleaning roller
[3] Grey cleaning roller
This module consists of two rollers:
- One grey roller [3] (in contact with the printed substrate). which is used to transport the substrate from the
feeder to the margin table.
- A green cleaning roller [2] (in contact with the grey roller). which is used. through its adhering surface. to
remove all impurities present on the substrate to be printed (dust. printing substrate residues. powder if
printing substrates are offset-printed. etc.).
These rollers have to be cleaned daily; they will prevent dust to be transported under the print
heads. Refer to Chapter 5.2 Cleaning of the cleaning roller.
[1]
[2]
[3]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 69 -
8.3 Margin table
8.3.1 Margin table presentation
[1] Margin table belt
[2] Left side lay
[3] Balls guide holding bar
[4] Balls guide
8.3.2 Side lays position adjustment
To put the substrate at the center of the printing belt. the substrate pile has to be also centering on the
feeder to be well vacuuming by the vacuum drum. Place the side lay to make the substrate enter at the
middle of this one.
According to the registration side of the substrate. use the corresponding side lay. Turn the margin belt
to make it move toward the used side lay.
Use the pick-up button to put the substrate at the entrance of the margin table belt [1]. Adjust the
position of the side lay to make the substrate enter at the middle of this one. use the position
adjustment handles at each end.
Otherwise if the skew is on the counter-clockwise direction. make the side lay turn the same.
8.3.3 Margin table error code
During use of margin table. these error codes can be displayed:
E562 - Motor board defect.
E572 - Paper jam.
[1]
[2]
[3]
[4]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 70 -
Refer to Chapter 12.1 Error code to clean these error messages.
8.4 Stacker
8.4.1 Stacker presentation
[1] Side cleats stack
[2] Top cleat stack
[3] Cleats shaft
[4] Stacker plate
[5] Top pile sensor
[2]
[1]
[3]
[1]
[4]
[5]
JETVARNISH 3DS
8. How to use the machine
User Manual
- 71 -
8.4.2 Stacker adjustment
[6] Emergency button
[7] Start button
[8] Stop button
[9] Reset / power initialize button
[10] Up button
[11] Down button
[12] Stacker speed up button
[13] Stacker speed down button
The stacker can be controlled by the stacker panel.
The up [10] and down [11] buttons control the stacker. When the stacker plate [4] reaches the top pile
detection sensor [5]. the stacker plate stop. If you press one time the down button [11]. the automatic
mode will start and both up [10] and down [11] buttons will light up.
When the automatic mode is ON. the stacker plate [4] goes down automatically when a printed
substrate stays more than 2 seconds in front of the top pile detection sensor [5].
The stacker speed button [12] and [13] increase or decrease the speed of the driving rollers.
[7]
[10]
[9]
[11]
[8]
[6]
[12]
[13]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 72 -
9 HOW TO USE THE 3DSHM
9.1 Main menu
[1] Folder
selection:
Listing of folder present on the computer
Path of folders
Refresh button
Sorting button (in alphabetical order or reverse)
Searching button
Rename. delete or import a folder
[8]
[2]
[1]
[3]
[5]
[7]
[6]
[4]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 73 -
[2] Job
management:
When a folder is selected. files inside appear on this
area. (Refer to Chapter 9.2 Standard printing to manage
files)
[3] Printing
progress:
Sheet counter
Play/Pause button
Printing stop button
[4] Menu
selection:
User icon access:
Printing icon. management icon and technician icon
Administrator icon access:
Standard printing (Refer to Chapter 9.2 Standard
printing)
Variable printing
(Available only with the Variable Data option)
Merging printing (In Development)
Historic (Refer to Chapter 9.5 History)
Supervision menu (Refer to Chapter 9.6 Supervision
menu)
Technical checking charts
(Available only for technician with Distributor login)
Settings menu (Refer to Chapter 9.7 Settings menu)
Electronic settings
(Available only for technician with Distributor login)
Printhead adjustment
(Available only for technician with Distributor login)
All icons with a padlock are not available with the actual login.
[5] Information
message:
Here is displayed all information messages (state of the
machine. warning and error messages)
Refer to Chapter 12.1 for Error codes.
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 74 -
[6] Printing status
Substrate format
Printing speed (in sheet/hour)
Remaining time of printing
Varnishes level (in percentage)
[7] Administration
icons:
Varnish registration: menu with the listing of varnish and
for varnish registration (Refer to Chapter 6.2 for Varnish
registration procedure)
User management: management of operator and
administrator logins (Refer to Chapter Login
Management)
MGI access: TeamViewer with MGI connection for
remote access (internet assistance and updates) (Refer
to Chapter 9.11 for Remote access)
[8] Cleaning:
This tab displays the cleaning maintenance procedures.
(Refer to Chapter 9.12 for Automatic cleaning of the
print heads)
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 75 -
9.2 Standard printing
[1] File listing:
Click on the file to select it.
A green file means a selected file.
[2] File selection
Sorting button (in alphabetical order or reverse)
Number of file selected and custom selection button.
Custom selection: Select all or custom you selection
[3] File
management:
Rename the selected file
Delete the selected file
Information button with the Cost calculator
Refer to Chapter 9.8 for Information and Cost calculator
Script application on the selected file
Open MGI Spot Editor (Refer to Chapter
How to use the MGI Spot Varnish Editor)
[4] Job ticket
management:
Copy the job ticket of the selected file
Save the job ticket of the selected file
[1]
[2]
[3]
[4]
[5]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 76 -
Listing of saved job ticket
Paste the job ticket on the selected file
[5] Print menu
button:
Open the print menu to set the printing (Refer to
Chapter 9.3 Print menu)
9.3 Print menu
[1] Machine
setting:
Click to open a tab displaying feeder. printer and dryer
setting
(Refer to Chapter 9.3.5 for Machine setting)
[2] File name:
Display the name of the file you are printing
[3] Print menu
tabs:
Click to open the settings for substrate and file position
(Refer to Chapter 9.3.2 Position)
Click to open the settings for printing quality
(Refer to Chapter 9.3.3 Quality)
Click to open the setting for cameras
(Refer to Chapter 9.3.4 Camera)
[4] Print menu
management:
Navigate between Position. Quality and Cameras tabs
Save all actual parameters of the file into the job ticket
Close the print menu to return to the main screen.
All no saved parameters are lost.
[1]
[4]
[5]
[6]
[2]
[3]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 77 -
[5] Quantity:
Click on the quantity to change the number of printing
you want.
[6] Print starting
button:
You have to set all the parameters before to be able to
print.
Once it is done the button become green:
9.3.2 Position
[7] Paper format:
You can select the format of the substrate.
Measure the substrate and select the good format.
Create. delete or modify a paper format
[8] Margin and
position:
This is the preview of the file position on the substrate.
The arrow shows the printing direction.
[7]
[8]
[9]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 78 -
Substrate thickness.
File position on the substrate.
It is recommended to place the file on the center top of
the substrate.
[9] Manual
adjustment:
To adjust the position of the varnish file on the printing
substrate. move the file in X direction (horizontal) and Y
direction (vertical).
Minus “-“ signs are to move to the top or to the left.
Plus “+” signs are to move to the bottom or to the right.
You can select which unit of measure you want to use to
change the position of the file.
The X and Y (horizontal and vertical) positions are
display here.
You can click on these value to directly modify them.
Add value to move to the right or to the bottom.
Remove value to move to the left or to the top.
9.3.3 Quality
[10]
[11]
[12]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 79 -
[10] Thickness:
You can adjust the thickness of varnish you want by
using the slider.
Depending of your 3D Hub Manager version. 2 sets of
thickness values are possible:
3DS Hub Manager < V2.6
From 15 to 100 µm (with one printhead bar)
And the double of these thicknesses if the twin
printhead bar is installed
3DS Hub Manager ≥ V2.6
From 21* to 116 µm (with one printhead bar)
And the double of these thicknesses if the twin
printhead bar is installed
*21µm is the minimum allowed, because 3 droplets are
the lowest possible value.
Display the thickness of varnish you want to apply.
By clicking on this value. you can adjust the thickness.
This is the number of drop of varnish the machine apply
on each pixel to have the wanted thickness.
Display the printing speed depending of the thickness of
the varnish and the length of the printing substrate.
[11] Heads
configuration:
You select two different mode for the overlap
adjustment: mode_2D (for varnish thickness under
30µm and mode_3D for varnish thickness over 30µm)
Depending of the substrate or the printing surface
tension. you maybe have to adjust the print head
overlap.
[12] Pilot settings:
All margin table. printer and dryer parameters are listed
here.
Click on this icon to access to machine setting (Refer to
Chapter 9.3.5 Machine setting)
You have the listing of all machine setting profiles that
you can select. save or delete.
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 80 -
9.3.4 Camera
[13] Cameras
selection:
By clicking on the icon you can select or disable the
camera.
Indicate the identification of the configured crop mark.
(Refer to Chapter 10 for MGI ARC system)
Start the MGI ARC system software to configure the
cameras.
(Refer to Chapter 10 for MGI ARC system)
[14] Crop mark
position:
If you use both cameras. you have to indicate to the
3DSHM the position of the crop mark on the substrate.
1. Measure the distance between the left edge of the
substrate and the left crop mark. then put it on the
first value.
Only if you use both cameras
2. Measure the distance between the two crop marks.
then put it on the second value.
[15] Bar code
camera:
Only available if you are equipped with the Variable
Data option.
[13]
[14]
[15]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 81 -
9.3.5 Machine setting
9.3.5.1 Summary of settings
Machine setting:
Validate the machine settings and go back to the print
menu (Refer to Chapter 9.3 Print menu)
Close the machine setting tab and go back to the print
menu (Refer to Chapter 9.3 Print menu)
Display the activation of the curing unit and the power
adjustment.
Refer to Chapter 9.3.5.5 Curing tab to adjust the curing.
Display the printing belt speed adjusted in the printer tab
(Refer to Chapter 9.3.5.4 Printer tab)
Display the varnish thickness adjusted in the print menu.
in quality tab (Refer to Chapter 9.3.3 Quality)
9.3.5.2 Overview tab
[18]
[17]
[16]
[18]
[17]
[16]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 82 -
[16] Feeder tab:
Click on this tab or on the feeder part on the machine
diagram to go on feeder setting tab.
(Refer to Chapter 9.3.5.3 Feeder tab)
[17] Printer tab:
Click on this tab or on the printer part on the machine
diagram to go on printer setting tab.
(Refer to Chapter 9.3.5.4 Printer tab)
[18] Curing tab:
Click on this tab or on the curing part on the machine
diagram to go on curing setting tab.
(Refer to Chapter 9.3.5.5 Curing tab)
9.3.5.3 Feeder tab
[19] Margin table
speed:
Change the value to adjust the speed of the margin
table. This value is a relative speed.
0% means that the margin table belt goes at the same
speed than the printing belt.
A negative value means that the margin table belt goes
slower than the printing belt.
Be careful to avoid positive value to prevent against
registration and jam issues.
[20] Drum speed:
Change the value to adjust the speed of the vacuum
drum. This value is a relative speed.
0% means that the vacuum drum goes at the same
speed than the margin table.
A negative value means that the vacuum drum goes
slower than the margin table.
[21] Double sheet:
The double sheet sensor (located between the feeder
plate and the cleaning unit) can be deactivated.
It is useful for some substrate due to their
manufacturing. the structure of the substrate itself or the
coating process. The surface is flat but air bubbles can
be inside the substrate.
[21]
[19]
[20]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 83 -
9.3.5.4 Printer tab
[22] Paper
thickness:
Display the thickness of the substrate (Refer to 9.3.2 for
Position to adjust the thickness)
[23] Printing belt
speed
adjustment:
The printing belt maximum and minimum speeds are
automatically adjusted with the varnish thickness.
You can reduce the printing belt speed to allow the
varnish to spread.
[24] Printing belt
vacuum
adjustment:
You can adjust the vacuum power of the zones Z1
(under cameras). Z2 (under print heads) and Z3 (under
curing 1) depending of the substrate flatness
To have a perfect flat surface. increase the power of
vacuum for thick substrates and reduce the power for
light substrates.
[25] Substrate
length:
Display the length of the substrate.
[24]
[25]
[23]
[26]
[22]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 84 -
[26] Varnish circuit
diagram:
Display the varnish circuit diagram.
9.3.5.5 Curing tab
[27] Stacker speed
adjustment:
You can adjust the speed of the stacker.
[28] Curing unit
location:
DRY 1: UV LED 5W located just after the print heads
to freeze the varnish.
DRY 2: UV LED 12W located before the stacker to
deeply cure the varnish.
[29]
[27]
[28]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 85 -
[29] Curing power
management:
You can activate or disable a curing unit by clicking on
the corresponding icon:
You can adjust the power of each unit with the
corresponding slider.
Default values:
DRY 1: UV LED = 100%
DRY 2: UV LED = 100%
9.3.6 Monitoring screen
[30] Machine
settings:
Refer to Chapter 9.3.5 for Feeder. Printer and Curing
settings.
[31] Cameras
information:
Use only if you have the Variable Data option.
Display the code read by the barcode camera and the
corresponding file.
[35]
[36]
[37]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 86 -
Display the cameras configuration. the detection and the
corrections in X. Y directions and the skew.
Display in which mode are the camera.
Refer to Chapter 9.4 for Camera configuration in
3DSHM.
Camera good or bad detection of crop marks.
Refer to Chapter 9.4 for camera detection.
“On the fly” file positioning.
Refer to Chapter 9.3.2 Position to move the file position.
[32] Printing
management:
Display the name of the printing file.
Display the quantity to print.
Click to pause the printing
Click to stop the printing
9.3.7 Machine start button
The “PRINT/PAUSE” button at the front of the machine starts blinking in green when the operator click
on the “Print starting” button (Refer to Chapter 9.3 for Print menu).
By clicking on this button. the machine goes in printing position and the belts start to turn. then the
feeder is activated.
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 87 -
9.4 Printing summary
9.4.1 Summary window
[1] Printing
summary
Total asked substrate to print
Total printed substrate
Total time to print
Total varnish consumption for the printed substrate
[2] Cameras
summary
Total good detections for all cameras
Total bad detections for all cameras
Camera 1 good (in green) and bad (in red) detections
Camera 2 good (in green) and bad (in red) detections
Only available if you have the Variable Data option.
Camera 3 good (in green) and bad (in red) detections
[3] Close button
Click on this button to close this window
[4] Details icon
Click to access to the detail listing of cameras detection
[1]
[2]
[4]
[3]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 88 -
9.4.2 Detailed window
[5] Number of the
printed page:
Display the number of the printed substrate in the order
of printing
[6] Camera 1:
Display if the camera 1 has a good (in green) or bad (in
red) detection
[7] Camera 2:
Display if the camera 2 has a good (in green) or bad (in
red) detection
[8] X adjustment:
Crossed direction correction depending of the crop mark
position on the substrate (in pixel)
[9] Y adjustment:
Feeding direction correction depending of the crop mark
position on the substrate (in pixel)
[10] Printing skew:
Only if you use both camera
Skew correction depending of the crop marks position
on the substrate
[11] Substrate
skew:
Only if you use both camera
Skew correction of the substrate
[12] Close button
Click on this button to close this window
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 89 -
9.5 History
[1] Job history
listing:
Start date: printing date
Duration: duration of the printing
Speed: the number of sheet per hour
Operator: which operator has printed the file
Mode: the varnish used. 3D
Copies: number of copies was printed and asked
Thickness: the thickness of the varnish
Image: which file was printed
[2] History
settings:
Date selection:
A blue day means that at least, a printing was done this
day.
Select “All” or select a specific operator
Select “All” or select a specific varnish
Refresh button
Total of printed file
Total of printed time
[1]
[2]
[4]
[3]
[5]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 90 -
[3] File preview:
Display a preview of the selected file
[4] File
information:
Display the name and the location of the selected file
Start date: date when the file started to be printed
End date: date when the file stopped
Copies: number of copies was printed and asked
Operator: which operator has printed the file
Thickness: the thickness of the varnish
Paper size: format of paper used (Refer to Chapter
9.3.2 Position)
% camera ok: percentage of good camera detection
iFOIL: if the iFOIL was used for this job
Mode: the varnish used. 3D
Consumption: quantity of varnish used for the
printing
[5] Job access:
Click to this icon to access to the selected file
9.6 Supervision menu
[1] Range
selection:
You can select for the supervision chart a range of
1 Day, 1 Week, 1 Month, 1 Year. All Years or select a
Custom range.
[1]
[3]
[2]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 91 -
[2] Date selection:
You can select the date for the range of the chart.
A blue day means that at least a printing was done this
day.
[3] Chart
selection:
Bar chart (Refer to Chapter 9.6.1 Bar chart)
Pie chart (Refer to Chapter 9.6.2 Pie chart)
Excel export (Refer to Chapter 9.6.3 Excel export)
9.6.1 Bar chart
[4] Supervision
chart:
Display a chart for the consumption of varnish or the
production in number of sheets (depending of the
selected range).
[5] Scrolling
buttons:
Buttons used to change from an hour for a selected day.
a day for a selected week. a week for a selected month
and a month for a selected year.
Buttons used to change to the previous or next day.
week. month or year (depending of the selected range)
[6] Chart settings:
Change the chart of supervision between consumption
of varnish or production in number of sheets
Select the operator to monitoring his consumption and
production
[4]
[5]
[6]
[5]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 92 -
9.6.2 Pie chart
[7] Pie chart:
Operator distribution pie chart for the selected range
[7]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 93 -
9.6.3 Excel export
[8] Date selection:
Select the dates between which you want to export
information
[9] Summary
export
information
selection:
Select which information you want to export:
Total of printed pages
Total of 3D varnish consumed
[10] Job per job
export
information
selection:
Select which information you want to export:
Picture: File name
Copies asked: Number of copies asked
Copies printed: Number of copies printed
Thickness: Thickness of the varnish
Print bars activated: Which print bars were used
Print mode: Which varnish was used (3D)
Paper size: Format name of the substrate
Paper width: Width of the substrate
Paper height: Length of the substrate
Operator: Which operator print the file
Percent camera: Accuracy of the cameras
iFOIL enable: Activation or not of the iFOIL
3D varnish: 3D varnish consumption
[11] Export button:
Click to export the information into an Excel file
[9]
[11]
[11]
[10]
[8]
[8]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 94 -
9.7 Settings menu
[1] 3DSHM
version:
Display the actual version of the 3DSHM software
[2] Image folder:
Display the path of the files on the computer
Click to change the folder where are stored
[3] Printing
counter:
Display the total of substrates printed
[4] Varnish price:
You can change the varnish price and the unit of the
money
[5] Interface
settings:
Change the language between English. French and
Portuguese
Change the keyboard configuration between AZERTY
or QWERTY
Change the unit of measurement between millimeters
(mm) and inches (inch)
You can choose the day for cleaning message of the
top sensors reflectors.
[6] Incoming alert:
Enable or not the message informed a new added job
on the file folder
[7] Save button:
Click on this button to save the settings of the window
[2]
[1]
[3]
[4]
[5]
[6]
[7]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 95 -
9.8 Information and Cost Calculator
[1] File name:
Eiffel Tower 3D effects.tif
Display the name of the file
[2] Close button:
Click on this button to close the Cost Calculator
[3] File preview:
Display a preview of the selected file in grey level
[4] File
information:
Image size: display the dimension of the file (width
and length)
Colors: display if the file is in grayscale or in color
The file must be in GRAYSCALE to be
printed
Bits per pixels: display the colors depth per pixel (1
bit means 1 bit per pixels. monochrome; 8 bit means
8 bit per pixels. grayscale)
Resolution: display the resolution used to define the
file
The file must be in a resolution of 360 x 360
dpi to be correctly printed
File size: File size in Megabyte (Mo in French)
Date: Date of creation of the file
Display a chart showing the percentage of each varnish
shade (corresponding with grayscale shade)
[1]
[3]
[2]
[6]
[7]
[4]
[5]
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 96 -
[5] Thickness
adjustment:
You can adjust the thickness of varnish you want by
using this slider. Please read the remarks on section
“9.3.3 Quality” and item [10]
[6] Cost
information:
Ink coverage: Covered surface given by the file
Thickness: Maximum thickness adjusted by the
operator
Copies: Number of sheet to print (by default 1.000)
Consumption: Quantity of varnish calculated with the
Ink coverage. The Thickness and the number of
Copies
Price per liter: Indicate the price par liter for the
varnish
[7] Total cost:
Total Price : 0.08 €
Display the varnish pricing for the number of copies
wanted (default is 1.000). Here. 1 copy was selected
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 97 -
9.9 How to use the MGI Spot Varnish Editor
The Spot Varnish Editor is a file modification embedded software. It can be accessed by double-clicking
the file to be modified. or clicking the edit button (Refer to Chapter 9.2 for Standard printing).
It is designed to make adjustments of all or part of the file to be printed.
[1] Movement tool:
Used to move the image
[2] Zoom tool:
Used to zoom into a selected area
[3] Selection tools:
Used to make a rectangle selection of the image
Used to make a selection using a magic wand tool
on a shape as a function of its black density.
Adjustment of the density tolerance is possible as
well as activation or deactivation of the contiguous
pixel parameter (all shapes having the same black
density)
Used to draw a random shape with no start and
end point.
This selection is of the lasso type.
Used to draw using line segments a selection area
having a start point and the same end point.
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 98 -
[4] Selected tools:
Used to move a selected area.
Possibility of making up/down and right/left
adjustments.
Adjustments are made in pixels or millimeters
(1 pixel = 0.07mm).
Used to remove or add one or more pixels around
a shape.
This adjustment is particularly used in 3D mode to
bold or unbold a text. a shape.
Used to erase the image within the selection.
Used to fill a selection area according to a color
percentage.
Mainly used upon file misprocessing (90% black
but not 100%).
Used to stretch or compress a selected area along
the vertical and horizontal axes.
The stretch or compression is expressed in mm.
inches or pixels.
It is possible to fix a corner to stretch of compress
proportionally in both directions.
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 99 -
Used to rotate the selection area. with the fixed
point being that at the top left of the area.
This rotation is expressed in mm and the direction
is negative in clockwise.
[5] Image tools:
Used to redefine the printing substrate format.
This function trims or enlarges the working zone
without modifying the image (maybe trimmed).
Used to adjust the stretch of the printing substrate
due to image stretching during printing. This
stretch can be defined in length (printing substrate
feed direction) or width.
JETVARNISH 3DS
9. How to use the 3DSHM
User Manual
- 100 -
Used to adjust a trapeze effect on the global file.
Used to set a general skew to the whole printed
file.
The operator must measure the skew as well as
the position over the length at which the skew was
measured.
You can use left or right registration as you use the
left or right side lay to register the substrate.
Used to rotate the total image clockwise or
counter-clockwise.
This rotation is of 90°.
[6] Script:
This function is used to apply an existed script or
save a new set of settings (stretch. skew. etc.). and
apply them to all selected files. This function is
useful in two cases:
Machine compensation: if a printing machine
regularly stretches on a given printing substrate.
perhaps the setting is identical for all sheets output
from this machine. and a script can be created for
that machine on that type of printing substrate.
Variable data: lockup of page one then production
following application of this script to all pages to be
printed.
To save a script. click on this icon. The software
will automatically request for saving as a name to
be defined.
Loading...
