STEP 1: CHARGING THE LAND VEHICLE'S BATTERY

Before you can experience all the fun and excitement of using your Land-Air R/C™, you must charge your Battery Pack. Follow these simple instructions for your initial charge-up and all recharges afterwards:

1. Connect the Battery Charger Connector into the 9.6V NiCd Rechargeable Battery Pack.

2. Plug the Battery Charger into a standard wall 120V outlet (see Fig.1).

3. Allow the Battery Pack to charge for 4 hours.

4. Disconnect the Battery Pack from the Battery Charger and remove the Battery Charger from the wall outlet. It should feel warm.

Fig.1

Battery Charger

9.6 V

Charger

Battery Pack

IMPORTANT:

- After each use, the Battery Pack may be hot. Allow it to cool for at least 20 minutes before recharging.

- If the Battery Pack shows signs of leakage or erosion, do not recharge; replace it immediately.

- Do not disassemble the Battery Pack.

- If Battery Pack or Charging Unit becomes wet, dry thoroughly before recharging.

- Do not use any other rechargeable battery except for the standard 9.6V NiCd Battery Pack that was intended solely for  use with the product.

- Do not use any other charger on the rechargeable battery of airplane.

- The Battery Charger used with the toy is to be regularly examined for damage to the plug, enclosure and other parts. In  the event of such damage, the battery charger must not be used until the damage has been repaired.

STEP 2: INSTALLATION OF THE LAND VEHICLE'S BATTERY

1. Slide the power switch on the Charging Unit to the "VEHICLE OFF" position (see Fig.2).

2. Slide open the battery door of the Charging Unit and plug in the 9.6V Rechargeable Battery Pack (see Fig.3). Slide to close the battery door to the charging unit.

3. The Charging Unit not only provides power to run the land vehicle but also charges the aircraft for flight.

4. Open the charging hatch on the top left side of the vehicle and turn the vehicle upside down.

5. Slide the Locking Lever (located at the bottom of the vehicle) to the open position. (see Fig. 5)

6. Insert the Charging Connector from the bottom of the vehicle through the charging hatch on top of the vehicle (see Fig.4).

7. Store the Charging Unit inside the vehicle's body.

8. Slide the Charging Unit to lock and secure it in place by turning the Locking Lever towards the battery. (see Fig.5)

9. Turn the vehicle over, fold the loose wire and store it back inside the Charging Hatch (see Fig.6).

TROUBLE SHOOTING

If your Land Air R/C™ responds slowly or fails to operate:

- Make sure the batteries in both the handset controller and Land Air R/C™ are installed properly.

- Make sure your battery pack/aircraft is fully charged.

- Make sure the Vehicle and Aircraft are turned on with the handset controller switched to the corresponding mode.

- Make sure you have installed the antenna on the handset and extended it to full length before use.

If your Land Air R/C™ fails to fly/take off:

- Strong winds may be preventing flight. As a general rule, the aircraft is not powerful enough to fly or take off properly under strong winds.

- The wind direction may be affecting flight; try changing direction for lift off.

- The perfect orientation for launching is a STRAIGHT PATH DIRECTLY AGAINST A STEADY BREEZE.The ribbon attached to the tip of antenna can help to indicate the wind direction.

- For vehicle launching, make sure the vehicle maintains top turbo speed before switching from "LAND" to "AIR"mode.

- Make sure the aircraft is secured to the vehicle properly via the vehicle cradle before vehicle launch.

- For hand launching, hold the aircraft at the bottom clamp area (the middle of the fuselage area), press the "TURBO" button to turn on the propellers, and then throw the aircraft in a horizontal path.

- Be sure to fully discharge the aircraft's battery before recharging.

TIPS & HELPFUL HINTS

-Do not operate during strong wind blowing, raining or thunderstorms.

-When your vehicle starts to lose power, it may experience loss of function or performance ability. If this happens, simply recharge your Battery Pack again and/or replace the Handset battery.

-After aircraft is fully charged, make sure to return the switches on both the Vehicle and Aircraft back to "ON" position.

-Your Land-Air R/C™ is operated by radio waves. It is possible the unit may not perform properly due to interference from nearby electronic devices such as a cordless phone, hair dryer, radio, walkie-talkie or other radio-controlled toys.

-Always launch your aircraft from a clear runway, free of obstruction, people, animals or cars.

-Keep fingers, hair, and loose clothing away from from the tires, propellers, wheel hubs and motors while the vehicle is turned on.

-For best performance, make sure the battery contacts are free of dirt and other interference. To clean, simply brush the contacts with a dry cloth.

-Avoid sand and snow when operating your vehicle.

-Always select a safe place to play. Never drive your vehicle on populated streets or water areas.

-Remember to turn off your handset and vehicle(s) when not using. Failure to do so will result in battery drainage.

Fig.2 Charging Unit

Fig.3 Plug 9.6V BP into Charging Unit

Slide to lock

Fig.5 Slide the charging unit to lock and secure by locking lever

Fig.4 Insert Connector through vehicle

Fig.6 Fold and store the charging wire

charging hatch

IMPORTANT NOTICE

Modifications not authorized by the manufacturer may void user's authority to operate this device.

FCC NOTICE

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.
