MFuel World Pak 100 User Manual

Trouble Shooting Guide

TM

ENERGY TO RUN WITH™

©2005 Blackstone International, LTD. The MFUEL logo is a trademark of Blackstone
International LTD. The PAK logo is a trademark of Blackstone International, LTD. All

other brand names and logos are trademarks or registered trademarks of their

respective owners. Specifications are subject to change without notice.

In most instances, solving problems with your MFUEL PAK is simple.
If your device is not charging or operating properly, do the following:

1. Disconnect the MFUEL PAK from power source.

2. Verify that the correct Hot Tip has been installed by checking the Hot Tip
compatibility list. Low and high power Hot Tips may fit the power input on

multiple devices. Never force a Hot Tip into an electronic device.
All high power MFUEL products are marked in RED. Be sure that your high power
device such as your notebook is correctly mated to a high power Hot Tip and that it
is being powered through the high power output and cable. All low power MFUEL
products are marked in YELLOW. Be sure that your low power device such as your
cell phone is correctly mated to a low power Hot Tip and that it is being powered
through the low power output and cable.
Using low power devices with the high power output and vice versa constitutes
misuse, can damage your electronics, and voids all warranties.

3. Reconnect the adapter according to the steps in the Product Setup Guide.

Check to ensure all connections are secure.

4. Plug the correct Hot Tip into your electronic device. The device should begin
charging regardless of whether it is powered on or off.

5. If the blue power indicator LED does not light, it may be burned out or the unit
may not be connected to the power supply correctly. Disconnect all connections
and reconnect the adapter according to the steps in the Product Setup Guide.
Check to ensure all connections are secure.

6. If you are still experiencing problems, please contact MFUEL.

HIGH / LOW POWER

WORLD

100

DIGITAL POWER ADAPTER KIT

USER MANUAL

TM

2018 Lord Baltimore Drive, Baltimore, Maryland, 21244 USA

Blackstone International LTD.

Tel: [phone]; Fax: [phone]

ENERGY TO RUN WITH™

International AC Outlets.

WORLD JACK Manual for

See the included

PDA

C1

Low Extender Tip

Use the MFUEL

CAR CHARGER

ADAPTER

to charge

your electronic

device using

your car charger

use instructions.

For use with

TM

PRODUCT SET UP GUIDE

2.

Cell

Laptop

1.

1.

96

POWER ADAPTER KIT

WORLD

10 0

3.

DIGITAL POWER ADAPTER KIT

HIGH / LOW POWER

WORLD

100

36

2.

4.

RED = HIGH POWER

output cord.

2.

PLUG your HOT TIP into correct power

3.

(Powers Notebook Computers)

YELLOW = LOW POWER

(Powers Cell Phones, PDAs, iPods, Digital

Cameras, Camcorders, DVD/MP3 Players,

Plug the desired Power Cable into power

input port.

For Airplane Use: Remove Cigarette

Portable Gaming, and

more)

(WALL / AUTO / AIR)

4.

Plug Power Cable into power source.

Lighter Adapter by depressing clip.

Use your Low

POWER PUCK as a

Data Transfer Cable

1. Attach included Ethernet HOT TIPS

to use POWER PUCK for Internet access.

2. Attach included USB HOT TIPS to use

POWER PUCK to transfer Data, MP3s,

Digital Pictures, and more.

58 58

5964 66

5.

Plug MFUEL HOT TIP into your

Electronic

Device.

TM

Electronic Device using the included

HOT TIP Compatib

ility List.

1.

Select the correct HOT TIP for your

TM

from home, oce, car, boat, RV or airplane

two Portable Electronic Devices

using your MFUEL WORLD PAK 100

Follow the 5 easy steps to Power and Charge
