MF Digital Ripstation DataGrabber User Manual
Ripstation DataGrabber
Operating Manual
V 1.029 or higher
Ripstation
A Division of Formats Unlimited, Inc
155 Sherwood Avenue
Farmingdale, NY 11735
T: +1 631 249 9393
F: +1 631 249 9273
Authors: Robert Warnock & Patrick McGrath
support@ripstation.com
www.ripstation.com/support
© Copyright 2009 100-5-01-000
Copyright
All rights within this document and related software belong to Formats Unlimited.
Ripstation is a registered trademark of Formats Unlimited.
BY USING THIS SOFTWARE YOU ARE AGREEING TO THESE TERMS AND
CONDITIONS.
This software (the SOFTWARE) is prepared as a solution to dealers, systems
integrators. This SOFTWARE is provided as is and with warranty only as detailed
in the applicable License agreement.
Ripstation specifically disclaim to the fullest extent permitted by law all
warranties, expressed or implied, including but not limited to implied warranties of
merchantability and fitness for a particular purpose, with respect to this software.
Ripstation shall have no liability including without limitation in negligence with
respect to this software. Ripstation shall have no liability including without
limitation in negligence with respect to any loss or damage directly or indirectly
arising out of the use of this software.
Without limiting the foregoing, Ripstation shall not be liable, including without
limitation in negligence for any loss of profit, interruption of business, loss or
damage to equipment or data, interruption of operations or any other damage,
including but not limited to direct, special, incidental or consequential damages.
This software must not be used for unauthorised duplication of CD's or any other
works protected by copyright unless permitted by law. No license to infringe
copyright is granted by the possession, installation and/ or use of this software.
Any statutory rights you may have are unaffected.
Ripstation DataGrabber User Manual Page 2 of 28
Software EULA 100-5-01-000
Software EULA
End User Software License Agreement
for Ripstation Software
NOTICE TO ALL USERS: PLEASE CAREFULLY READ THE FOLLOWING LEGAL
AGREEMENT ("AGREEMENT") FOR THE LICENSE OF Ripstation ("SOFTWARE") BY
Formats Unlimited, Inc. ("FUI"). BY CLICKING THE ACCEPT BUTTON OR
INSTALLING THE SOFTWARE, YOU (EITHER AN INDIVIDUAL OR A SINGLE ENTITY)
CONSENT TO BE BOUND BY AND BECOME A PARTY TO THIS AGREEMENT. IF YOU DO
NOT AGREE TO ALL OF THE TERMS OF THIS AGREEMENT, CLICK THE BUTTON THAT
INDICATES THAT YOU DO NOT ACCEPT THE TERMS OF THIS AGREEMENT AND DO NOT
INSTALL THE SOFTWARE.
1. License Grant. Subject to the payment of the applicable license
fees, and subject to the terms and conditions of this Agreement and a
pre agreed License term, FUI hereby grants to you a non exclusive, non
transferable right to use one copy of the specified version of the
Software and the accompanying documentation (the "Documentation") on
one computer only unless otherwise agreed.
2. Term. This Agreement is effective for an unlimited duration unless
and until earlier terminated as set forth herein. This Agreement will
terminate automatically if you fail to comply with any of the
limitations or other requirements described herein. Upon any
termination or expiration of this Agreement, you must destroy all
copies of the Software and the Documentation. You may terminate this
Agreement at any point by destroying all copies of the Software and the
Documentation.
3. Ownership Rights. The Software is protected by International
copyright laws and international treaty provisions. FUI and its
suppliers own and retain all right, title and interest in and to the
Software, including all copyrights, patents, trade secret rights,
trademarks and other intellectual property rights therein. Your
possession, installation, or use of the Software does not transfer to
you any title to the intellectual property in the Software, and you
will not acquire any rights to the Software except as expressly set
forth in this Agreement.
4. Restrictions. You may not rent, lease, loan, sublicense or resell
the Software. You may not permit third parties to benefit from the use
or functionality of the Software via a timesharing, service bureau or
other arrangement. You may not transfer any of the rights granted to
you under this Agreement. You may not reverse engineer, decompile, or
disassemble the Software, except to the extent the foregoing
restriction is expressly prohibited by applicable law. You may not
modify, or create derivative works based upon, the Software in whole or
in part. You may not copy the Software or Documentation. Except that
you may either (a) make one copy of the Software solely for backup or
archival purposes, or (b) transfer the Software to a single hard disk
provided that you keep the original solely for backup or archival
purposes. You may not remove any proprietary notices or labels on the
Software. All copies must contain the same proprietary notices that
appear on and in the Software. All rights not expressly set forth
hereunder are reserved by FUI.
5. Warranty and Disclaimer.
a. Limited Warranty. FUI warrants that for sixty (60) days from the
date of original purchase the media (e.g., CD Rom) on which the
Software is contained will be free from defects in materials and
workmanship.
Ripfactory – MediaGrabber User Manual Page
3 of 28
Software EULA 100-5-01-000
b. Remedies. FUI and its suppliers' entire liability and your exclusive
remedy for any breach of the foregoing warranty shall be, at FUI’s
option, either (i) return of the purchase price paid for the license,
if any, or (ii) replacement of the defective media in which the
Software is contained. You must return the defective media to FUI at
your expense with a copy of your receipt. This limited warranty is void
if the defect has resulted from accident, abuse, or misapplication. Any
replacement media will be warranted for the remainder of the original
warranty period.
c. Warranty Disclaimer. Except for the limited warranty set forth
herein, THE SOFTWARE IS PROVIDED "AS IS." TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, FUI DISCLAIMS ALL WARRANTIES, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND
NONINFRINGEMENT WITH RESPECT TO THE SOFTWARE AND THE ACCOMPANYING
DOCUMENTATION. YOU ASSUME RESPONSIBILITY FOR SELECTING THE SOFTWARE TO
ACHIEVE YOUR INTENDED RESULTS, AND FOR THE INSTALLATION OF, USE OF, AND
RESULTS OBTAINED FROM THE SOFTWARE. WITHOUT LIMITING THE FOREGOING
PROVISIONS, FUI MAKES NO WARRANTY THAT THE SOFTWARE WILL BE ERROR FREE
OR FREE FROM INTERRUPTIONS OR OTHER FAILURES OR THAT THE SOFTWARE WILL
MEET YOUR REQUIREMENTS. SOME STATES AND JURISDICTIONS DO NOT ALLOW
LIMITATIONS ON IMPLIED WARRANTIES, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. The foregoing provisions shall be enforceable to the
maximum extent permitted by applicable law.
6. Limitation of Liability. UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL
THEORY, WHETHER IN TORT, CONTRACT, OR OTHERWISE, SHALL FUI OR ITS
SUPPLIERS BE LIABLE TO YOU OR TO ANY OTHER PERSON FOR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY CHARACTER
INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF GOODWILL, COMPUTER
FAILURE OR MALFUNCTION, OR FOR ANY AND ALL OTHER DAMAGES OR LOSSES. IN
NO EVENT WILL TOPIARY BE LIABLE FOR ANY DAMAGES IN EXCESS OF THE LIST
PRICE TOPIARY CHARGES FOR A LICENSE TO THE SOFTWARE, EVEN IF TOPIARY
SHALL HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
FURTHERMORE, SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS
LIMITATION AND EXCLUSION MAY NOT APPLY TO YOU. The foregoing provisions
shall be enforceable to the maximum extent permitted by applicable law.
7. Miscellaneous. This Agreement is governed by the laws of the
Ireland, without reference to conflict of laws principles, and the
parties agree that the sole location and venue for any litigation which
may arise hereunder shall be Ireland. The application of the United
Nations Convention of Contracts for the International Sale of Goods is
expressly excluded. This Agreement sets forth all rights for the user
of the Software and is the entire agreement between the parties. This
Agreement supersedes any other communications with respect to the
Software and Documentation. This Agreement may not be modified except
by a written addendum issued by a duly authorized representative of
FUI. No provision hereof shall be deemed waived unless such waiver
shall be in writing and signed by FUI or a duly authorized
representative of FUI. If any provision of this Agreement is held
invalid, the remainder of this Agreement shall continue in full force
and effect. The parties confirm that it is their wish that this
Agreement has been written in the English language only.
8. The Software and Documentation are provided with Restricted Rights.
9. You agree not to export this software unless previously agreed with
FUI
Copyright © 2002 2006 Formats Unlimited,Inc. All Rights Reserved.
Ripfactory – MediaGrabber User Manual Page
4 of 28
Software EULA 100-5-01-000
Overview
DataGrabber is a dedicated software tool to allow for batch transfer of data files from
Blu-Ray*, DVD or CD utilising MF Digitals’ 7602/7604, 7601, 7601XC, 7601XD or
7601XDP robotic autoloaders.
DataGrabber will take any Data Blu-Ray*, Data DVD or Data CD and create an ISO
image or the resulting file structure from the disc itself, creating a local copy, for use in
archive or backup applications.
The application operates on the Windows Platform.
The product is designed for use by individuals, system integrators and service providers
and offers flexibility, ease of use and high throughput at the core of its operation.
DataGrabber is licensed on a seat or site license basis as purchased by its users and
subject to the conditions laid down in the applicable license agreement.
This document provides a user manual to allow basic and advanced operation as well as
customisation of all parameters, set up and use of robotics for a complete end to end
process.
* Please Note, a Blu-ray drive upgrade is necessary to support Blu-ray data
ripping – this can be added at time of purchase as an optional upgrade to
your system. DataGrabber WILL NOT rip Blu-ray discs without a Blu-ray drive.
Ripfactory – MediaGrabber User Manual Page
5 of 28
Software EULA 100-5-01-000
Contents
1.0 SOFTWARE INSTALLATION .................................................................................7
1.1 P
REINSTALL CHECKS
1.2 R
UNNING THE EXECUTABLE
1.2.1 R
1.2.2 L
EGISTRATION
IMITS ON REGISTRATION
2.0 HARDWARE INSTALLATION ................................................................................9
2.1 R
OBOTIC HARDWARE
2.2 S
TEP BY STEP GUIDE OF ROBOTIC HARDWARE
2.2.1 STEP ONE R
EMOVE THE PACKING CONSTRAINTS
2.2.2 STEP TWO P
2.2.3 S
TEP THREE PLUGGING IN A
....................................................................................................7
.........................................................................................7
.............................................................................................................7
............................................................................................8
...................................................................................................9
7602/7604 ..........................................9
......................................................9
LUG IN THE PERIPHERALS
USB
ROBOT
(KVM
PC INSIDE UNITS ONLY
) ......................9
...................................................................10
3.0 DATAGRABBER QUICK START GUIDE ...........................................................14
4.0 MAIN USER GUIDE .................................................................................................17
4.1 K
EY FEATURES
4.2 D
ATAGRABBER MAIN SCREEN: ADVANCED OPTIONS
4.2.1 B
UTTON AND SCREEN OPERATIONS
............................................................................................................17
...............................................18
...........................................................................18
4.2.1.1 Group 1: loader type ............................................................................................18
4.2.1.2 Group 2: Select an output format ..........................................................................19
4.2.1.3 Group 3: Enter disc count and type.......................................................................19
4.2.1.4 Group 4: Folder name and destination ..................................................................19
4.2.1.5 Group 5: Buttons ...................................................................................................20
4.2.1.6 Group 6: Batch Status Window ............................................................................25
4.2.1.7 Group 7: Batch Logging Window.........................................................................25
4.2.2 M
AIN SCREEN MENU OPTIONS
...................................................................................26
5.0 HELP AND SUPPORT .............................................................................................27
Ripfactory – MediaGrabber User Manual Page
6 of 28
Software Installation 100-5-01-000
1.0 Software Installation
1.1 Preinstall Checks
For Standalone PC Options:
•
32 bit Windows XP with SP2, Vista or Windows 7
•
Microsoft .NET 2.0, download from
http://www.microsoft.com/downloads/details.aspx?FamilyID=0856eacb-43624b0d-8edd-aab15c5e04f5&displaylang=en
•
PC platforms as specified in pre install documentation
•
Always on internet connection
•
Windows Media Player 10 or above.
1.2 Running the Executable
•
Ensure target PC is connected to the internet.
•
To install the software, double click the icon ‘datagrabbersetup.exe’ to run
and follow the onscreen prompts.
•
If you do not have this software, it can be downloaded from
www.ripstation.com/software/downloads/datagrabbersetup.exe
•
It is recommended that the default paths be selected for installation.
1.2.1 Registration
•
To activate the software installation, double click the program shortcut on the
desktop.
•
When prompted, as shown in figure 1.0, please key in the registration code
supplied at the time of purchase and click ok.
Figure 1.0 Product Registration Code Screen
Software Installation 100-5-01-000
•
Next, enter in the company details when presented with the screen as shown in
figure 1.1 in order to complete the product registration and software installation.
Figure 1.1 Product Registration Details Screen
All details marked as * are required.
•
Click OK to proceed and the application will connect to our server and verify your
code.
1.2.2 Limits on Registration
In the case of a seat License, ONE code for activation is provided. The application may
be uninstalled at any time and reinstalled on an alternate machine by following the
process above. Please note however, only ONE copy of the software will run at any one
time and a second installation of the software with the same code will prevent the first
installation from being run.
Hardware Installation 100-5-01-000
2.0 Hardware Installation
This section details a set of instructions for correct assembly of the robotic hardware (if
purchased). It begins by listing the items contained within the packaging.
2.1 Robotic Hardware
The autoloader box should contain:
1. The robotic hardware system
2. Power cable
3. These Quick Setup Instructions
4. Warranty & support documents
2.2 Step by step guide of Robotic Hardware 7602/7604
2.2.1 STEP ONE Remove the Packing Constraints
•
Carefully remove the autoloader from its carton, lifting from the bottom using the
hand cut outs in the foam base.
•
DO NOT attempt to lift the machine using the spindles, column tower, or pick
arm, as these are delicate pieces and are depended on for proper alignment and
functioning of the unit.
•
Place the system on a level workspace free of debris, dust, humidity, excessive
heat, and electronic or electromagnetic interference.
•
Keep out of direct sunlight.
•
Allow at least six inches of clearance on all sides of unit for ventilation.
•
Remove protective plastic cover from system and save along with the rest of the
packaging.
2.2.2 STEP TWO Plug in the Peripherals (KVM pc inside units only)
••••
Plug in a monitor (VGA DSUB), keyboard and mouse (PS2 or USB) to the robot
••••
Attach the Ethernet cable.
••••
Using the enclosed 3 prong power cord, plug in the autoloader to a properly
grounded AC receptacle. It is highly recommended that a surge protector is
used to ensure safety in operation.
••••
Power on the unit using the main switch at the back
••••
Windows will now load and you will see the Ripstation Desktop
••••
Double click the icon for Ripstation DataGrabber to run the ripper application.
Loading...
