Page 1
Q
Q
UII
U
CKK
C
C
O
N
C
O
N
NEE
N
2600
CTT
C
G
G
UII
U
DEE
D
For a complete guide of instructions, see the
manual located on the Manual CD that was
shipped with your system.
www.mfdigital.com
Rev 2-11-09
Page 2
Software Manual is
located on Manuals CD
packaged with your
system.
Page 3
C
ARRTT
C
A
O
N
O
N
Director Series Loader (2602)
Power Cable
LAN Connection Guide
LAN Cable
C
C
O
NTTEE
O
N
NTTSS
N
Quick Connect Guide
User’s Manual CD
System Firmware CD
Windows XP CD
Page 4
PC Cabling with Printer and Hoppersno
1. Attach a Monitor Keyboard and Mouse as shown
above included from MF Digital).
2. Then plug your PC Series into AC Wall Receptacle.
(not
Page 5
Mounting & Connecting Your PicoJet 6000
Printer with the MF Digital PC Series.
K
E
Y
Front
Rear
1. Locate the front of the mounting
plate as indicated by the yellow circle to the right.
2. Slip the groove of the mounting
plate around the white plastic knob.
See picture above (yellow circle).
3. The latch located at the rear
of the mounting plate will
line up with the “U”shaped housing
located on the rear of the MF Digital
PC Series Unit. See picture above
(blue circle).
4. After mounting the Printer, be
sure to push the printer all the way
forward then use the latch
to secure the printer to the MF
Digital PC Series Unit.
5. To wire your printer to MF Digital
PC Series please follow the wiring
diagram to the right.
Page 6
Mounting & Connecting Your Prism Plus Printer
with the MF Digital PC Series.
K
E
Front
Y
Rear
1. Locate the front of the mounting
plate as indicated by the yellow circle
to the right.
2. Slip the groove of the mounting
plate around the white plastic knob.
See picture above (yellow circle).
3. The latch located at the rear of
the mounting plate will line up
with the “U”shaped housing located
on the rear of the MF Digital PC
Series Unit. See picture above (blue
circle).
4. After mounting the Printer, be sure
to push the printer all the way forward then use the latch to
secure the printer to the MF Digital
PC Series Unit.
5. To wire your printer to MF Digital
PC Series please follow the wiring
diagram to the right.
Page 7
Installing P55 Printer
Slide mounting bracket and printer on Scribe (Do not lock down
lever yet)
Install all Cables as shown above (ttl, usb, power)
Electronically align through hyper-terminal – Please contact a
MFD technical support representative for this process.
Lock down printer with locking lever.
Start
Scribe and Go!
Page 8
Genuine MF Digital Consumables
Thermal Printer Supplies
Thermal CD/DVD Printer Ribbons
The Gold Standard
Part# Product Description
CDP-PRN-BK
CDP-PRN-BLK
CDP-PRN-RED
CDP-PRN-BLUE
CDP-PRN-GRN
CDP-PRN-MULTI
750' Black Ribbon for Prism Plus (Fine Line Print)
850' Black Ribbon for Spectrum 2 Printers
656' Red Ribbon for Prism Plus & Spectrum 2 Printers
656' Blue Ribbon for Prism Plus & Spectrum 2 Printers
656' Green Ribbon for Prism Plus & Spectrum 2 Printers
656' Multi Ribbon for Prism Plus
Ink Jet Printer Supplies
Inkjet CD/DVD Printer Cartiridges
Part# Product Description
M56B Black 19ml Ink Cartridge for PicoJet Inkjet Printer
M57C Color 17ml Ink Cartridge for PicoJet Inkjet Printer
www.mfdigital.com
