Introduction

Product Overview

The SP5600 OptimusR Portable Data Terminals are robust and versatile scanning devices designed to
provide exceptional performance, while enduring the demands of everyday use. The rugged exterior of
the OptimusR make it the ideal PDT for applications that take place in more rigorous environments.
The lithium-ion rechargeable battery provides the Optimus with more than 200 hours of operation. It is
supported by a resourceful set of development tools, including a Windows-based program builder, “C”
compiler, and “BASIC” compiler. The OptimusR has a fully integrated laser for scanning all 1D bar code
symbologies, completely enclosed by the protective ergonomic housing. The built-in functionality of the
Optimus makes it an excellent choice for numerous applications. In addition, when combined with the
optional WiFi module it is the ideal solution for real time applications such as inventory control, shop
floor management, warehousing operations, and distribution operations.

Key Product Features

• Up to 8 MB RAM capable of storing over 400,000 records

• Easy to use Optimizer program builder and download software

• Auto-backlit LCD display

• Audible and visual indications

• Built-in laser bar code scan engine capable of scanning all 1D bar code symbologies.

• Powered by rechargeable Lithium-ion battery

• Upload/download data via RS232, USB, and WiFi interfaces

Scanner and Accessories*

METROLOGIC PART

NUMBERS.

SP5602 OptimusR laser batch unit with 2MB RAM
SP5604 OptimusR laser batch unit with 4MB RAM
SP5608 OptimusR laser batch unit with 8MB RAM
SP5650 OptimusR laser WiFi standard unit
SP5652 OptimusR laser WiFI unit with 2MB RAM
SP5654 OptimusR laser WiFi unit with 4MB RAM
SP5658 OptimusR laser WiFi unit with 8MB RAM

MI5600-614 OptimusR standard cradle

MI5600-6107 OptimusR modem cradle

52-52860A RS232 Cradle Cable
52-52861A USB cradle cable

*

For information on additional accessories and scanner kits contact your local Metrologic Instruments representative.

PART DESCRIPTION

4

General Features and Characteristics

4

6

3

5

2

7

1

9

10

8

Figure 1 Scanner Features

ITEM NO. DESCRIPTION

1 Multi-functional Keypad
2 Scan Button
3 LCD display
4 Red Output Window (Laser Aperture)
5 Speaker for audible indicators
6 Protective rubber bumpers
7 Battery Compartment
8 Communication Ports (RS232 and IrDA), Power Adapter Port, and Battery Contacts
9 Comfort Strap

10 Battery Compartment Release

5

General Features and Characteristics

4

3

2

1

5

Figure 2. Cradle Features

ITEM NO. DESCRIPTION

1 LED Transmission Indicator
2 LED Power indicator
3 Battery Contacts
4 IR communication port
5 Rubber Footpads

6

6 RS232 Communication Port and Power Adapter Port

6

General Features and Characteristics

Multifunctional Keypad

5

4
3

2

6
7

8

1

Figure 3.Keypad Features

ITEM NO. KEY NAME DESCRIPTION

The toggle key for Alphabet/Numeral input.
When the system is in alpha-mode, a small icon will be shown in the lower right
corner of the display. Each numeric key can be used to generate one of the three
capital letters located on that number key. For example, numeral 2 can be used to

1

2
3

4
5

6
7

8

9

ALPHA()

ALPHANUMERIC

ARROW

ESC

SCAN

ENTER

BS

FUNCTION(FN)

POWER

produce A, B, or C. Pressing the same key twice within one second, will produce
the letter B. Pressing the same key without halting longer than one second, will
allow the user to toggle through the three letters. When the key has been
depressed for longer than one second or another key has been pressed, the unit
will send the real key code to the application program.
Alphanumeric These 10 keys can be used for either alpha characters or
numerical input. (See Item 8 for further description of key operation)
Arrow.The two arrow keys located below the Scan key are use d to toggle up and
down between menu selections.

Escape. This key is used to stop and exit current operation
Scan a bar code. Pressing this button will trigger the scanner to read a bar code

Enter. There are two enter keys on the side of the scan key. Normally the enter

keys are used for command execution or input confirmation.
Back Space This key can be used to toggle back one space or if pressed down
longer than one second, a clear code will be sent

The function key.
This key cannot be activated alone; it must be pressed with one of the numeric
keys at the same time. For example, FN + 1 generates function #1, FN + 2
generates function #2, etc (up to 9 functions). Also, this key can be combined with
the UP/DOWN arrow keys to adjust the contrast of the LCD. And when thi s key is
combined with the ENTER key, it will turn ON/OFF the backlight.

Power On/Off. To prevent an accidental power down, it requires about 1.5 sec of
continuous pressing to turn On/Off the power.

7

9

General Features and Characteristics

4

The LCD Screen

The LCD screen of the OptimusR Portable Data Terminal displays program settings, operational
parameters, data collected, and much more. The display is a graphical LCD with the following
characteristics:

y Display area of 64 pixels x 100 pixels
y Resolution:

y Maximum of 8 lines x 16 characters

y Minimum of 4 lines x 12 characters
y Displays alpha-characters, numbers, and symbols
y Automated back light

The Lithium-Ion Battery

The OptimusR Portable Data Terminal includes a
lithium-ion rechargeable battery pack. The battery is
inserted (See Getting Started for battery installation)
into the battery compartment of the Optimus and
recharges with Optimus in the cradle and in charging
mode.

Figure

Lithium-Ion Battery

8

Installation

Getting Started

The OptimusR Portable Data Terminal (PDT) requires minimal effort to begin functional operation for
data collection in any application. In order to get started the unit must have a fresh battery inserted into
the battery compartment.

1. Access the battery compartment by removing the battery cover. To remove the cover , pull the
cover release up on each side of the compartment and slide the cover away form the unit.

2. Insert the Li-ion battery into the battery compartment, battery information side up and battery
contacts to the bottom, at an angle with the battery contacts inserted first.

3. Push the Li-ion battery the remainder of the way into the compartment. The battery will fit
snuggly into place.

4. Close the battery compartment by sliding the battery cover toward the scan head until the
cover locks into place.

5. Turn the unit over, so the keypad is visible and hold down the power button .

6. The LCD graphical display will display a menu and an audible indicator will sound to signify
that the Optimus has been powered up properly.

7. Using the arrow keys select the Run Program option.

8. Scan a bar code.

Note: The OptimusR comes with a default program loaded that allows users to scan items and enter

their quantity. For information on how to create these programs, please refer to the Optimizer
manual.

9

Installation

Basic Operation

In order for the Optimus to operate properly , an application program must be loaded onto the PDT. It is
possible for the Optimus to power up without at active application. On power up if the Optimus has no
application program loaded, then the following Program Manager menu options will appear on the
display:

MENU OPTIONS. DESCRIPTION

This option allows the user to download application programs (*.SHX), BASIC run-time
(bas.ops.shx), BASIC programs (*.SYN) or font files to the terminal. There are 6 resident
locations and one Active Memory. A maximum of 7 programs can be downloaded to the
terminal. The application program downloaded to the Active Memory will be the only activate
program running. In order to activate one of the other programs. Immediately after
downloading, input a name for the program desired or just press the enter key to keep its

Download

Activate

Upload

Selecting and successfully completing one of these three menu options will enable the OptimusR to
begin functional operation.

current name if one is applicable. This will enable the user to download the program. The
application file’s type, name, and size will be shown on the list of programs when enterin g the
Download or Activate menu of the Program Manager. The file type is a small letter that
follows the program number (01~06), it can be either ‘b’, ‘c’ or ‘f’ which represents BASIC
program, C program or font file respectively. The program name is up to 12 characters and
the program size is in units of K bytes.
NOTE: In order to delete a program, select the program designated for deletion. From the
program information screen, press the Alpha/Function key, then zero.
This option will enable the use to activate one of the resident programs. In order to
accomplish this, the user must copy one of the 6 resident programs to the Active Memory.
Upon activation of the new program the original program in the Active Memory will be
replaced. Note: A font file cannot be activated, and a BASIC program cannot be activated if
the BASIC run-time does not exist.
The Upload option gives the user additional method for ret rieving an appli cation prog ram. It
allows a user to transmit the application programs to a host PC or another terminal. This
function also allows a terminal to be cloned without going through a PC.

Communication and Data Collection Setup

The OptimusR Series has various ways of communicating with a host device. Depending on the model
of Optimus, it can communicate via RS232, USB, or via a WiFi connection. The OptimusR can store
data in the unit or send data real time via a WiFi connection. The OptimusR has the ability to utilize a
RS232 or USB connection to communicate to a host device for both application program downloads
and data uploads. The OptimusR includes either a USB or RS232 cable. In order to begin an
application download or data transfer the following steps would need to be followed.

1. Remove the Optimus cradle, the power supply, and either the USB or RS232 cable from the box.

2. Plug the power supply into a power outlet and insert the other end into the cradle. The red LED
on the cradle will illuminate if the power supply is connected correctly.

10

Installation

3. Follow steps a, b, or c

a. For the RS232 cable plug the 9 pin serial connector into a serial port on the host device.

Plug the opposite end into the communication port of the cradle.

b. For the USB cable plug the USB end of the cable into an appropriate communication port

on the host device and the opposite end of the cable into the communication port of the
cradle*.

c. For the WiFi connection to communicate with the host device the settings on OptimusR

and the host device must be configured correctly.

4. Power up the Optimus and select the Utilities option.

5. This will open additional menu options. Select the Transfer Files option.

6. Select Get Program on the next menu. The unit is now ready to download an application
program.

7. Place unit in cradle and download the appropriate application program.

8. Once the Optimus has received the application program the unit is ready for scanning and
collecting data.

Note: There are OptimusR models available that do not include the cradle. Models

that do not include a cradle as an accessory can have the power supply and the
communication cable connected directly to the unit.

*A software driver is required for proper installation. The driver is included with the installation CD provided with each
Optimus. In addition the driver can be downloaded from http://www .metrologic.com

.

11

Installation

Data Upload

1. To transfer the data collected select the Utilities option.

2. Select the Download Method option on the next menu and then select the appropriate method
for downloading files to the host device.

3. The WiFi can send data in real time, however, if cradle options (Cradle-IR or IrDA) are selected
re-insert the Optimus unit into the cradle and upload the data to the host device.

To change the download method select the Utilities option from the main menu and then select the
download method from the list of available options. This allows the user to alter the method by which
data is transferred to the host device.

Note: Plugging the Optimus into a serial port or USB port on the host device does

not guarantee communication with the Optimus. Ensure that the communication
port on the host device is not populated by another device. Confirm that the
communication settings on both the host device and the Optimus correspond prior
to a program download or data upload.

The OptimusRW is similarly connected to the host device and programmed however, there is a key
difference in the data collection process. The OptimusRW support s transmission of data wirelessly and
as such has the capability of communicating that data in real time. The unit needs to be setup to
communicate with the network as follows:

1. With the Optimus powered off press and hold the 7, 9, and power keys. The System Module
menu will appear on screen.

2. Using the arrow keys select the 802.11b Menu option.

3. The list of settings that appears are the settings that require configuration in order for the WiFi to
function effectively.

4. Select Information option to view the current configuration settings on the Optimus.

5. Select the Network Set option to configure the network settings. This is similar to enabling the
network settings on a PC.

6. Select WLAN Setting to select and configure the Optimus for the appropriate network available
to connect to the host device.

7. Select Security to setup any security/authentication settings that match the host device.

8. Select the Echo test to test the settings and verify that the network settings on the Optimus are
configured correctly and that the Optimus is communicating with the host device.

9. Power off the Optimus.

Upon completion of the configuration process, and depending on the active application program, the
user will be able to begin data transmission via WiFi communication.

Note: Contact a Metrologic Instruments representative if assistance is required

when integrating a Metrologic device into a network.

12

Installation

The System Menu

The system menu on the Optimus is another useful tool included with the Optimus. It provides
information about the Optimus and access to the system menu for configuring the Optimus. In order to
access the system module, follow the instructions below:

1. With the Optimus powered off press down and hold the 7, 9, and power button.

2. An audible indicator will sound to indicate that the Optimus is powered on.

3. The Optimus will display the system menu.

The system menu will list a number of options:

• Information

• Settings

• Tests

• Memory

• Power

• Load Program

• 802.11 Menu

System Menu Options

Depending on the application program that is active on the Optimus, there are number of settings and
options that may be selected for both setup and testing. The tables show a number of those settings
and their descriptions.

Information

The Information option provides information about the Optimus including:

• Hardware Version

• Serial Number

• Manufacturing Date

• Application Program Version

13

Installation

Settings

SETTING

Clock Set date and time for the system. N/A

Backlight ON Period Set the duration for the keyboard/LCD backlight

Set CPU running speed. There are five speeds available:

CPU Speed

Auto Off

Power On Options

Key Click

System Password

Font Current font displayed on the Optimus display

Full speed, half speed, quarter speed, eighth speed and
sixteenth speed.
Set time threshold for automatically power off when no
operation is taking place during that specified period. If this
value is set to zero, this function will be disabled.
There are two possible selections: Program Resume, which
starts from the program being used during the last session
before the last power-off; and Program Restart, which starts
with a new program.
Select a tone for the beeper or disable the beeper when the
user presses a key button.
Set a password to protect the user from entering the system
menu.

DESCRIPTION

DEFAULT

the light goes off after 20

seconds

Full speed

10 minutes

Program Resume

Enable

no password is se

System Font

t

Reset to Default Resets the system settings to the default settings

N/A

Tests

The OptimusR has numerous tests available to the user for both operation and diagnostics. Depending
on the application program that is in the active memory will determine which tests can be performed and
are available to the user. The following table provides a description of the available tests.

SETTING

Reader

Buzzer

LCD & LED

Keyboard

Memory

To test the reading performance of the scanner. The following symbologies are enabled for
the Reader test. All other symbologies will need to be enabled via programming.

Default Bar codes: Code 39, Industrial 25, Interleave 25,Codabar, Code 93, Code 128,
UPCE, UPCE with ADDON 2, UPCE with ADDON 5, EAN8, EAN8 with ADDON 2
EAN8 with ADDON 5, EAN13, EAN13 with ADDON 2, EAN13 with ADDON 5

To test the buzzer with different Frequency/Duration. Press ENTER key to start and then
press any key to stop the test.
To test LCD display and LED indicator. Press ENTER key to start and then press any key to
stop the test.
To test the rubber keys. Press a key and the result will be shown on the LCD display. Note
that the FN key should be used in conjunction with numeral keys.
To test the data memory (SRAM). Note after the test, the contents of the memory space will
be wiped out.

Warning: This test erases any data stored in the terminal.

DESCRIPTION

DEFAULTS

Echo Test

Echo Test is used to test the communication between the cradle and the PC. Perform Echo
test from the host device that the cradle is connected.

14

Installation

Memory

The menu option provides the user with ability to gather information on the amount of memory available
on the Optimus, as well as the ability to initialize the memory . This is accomplished by choosing one of
the two available selections.

1. Size Info.

2. Initialize

Size Info.

The Optimus contains two types of memory , SRAM and Flash memory. These two types of memory
allow the Optimus to perform operational tasks at an optimal level.

Base RAM: The Base RAM is the primary memory in the Optimus and is the location where
application is stored and accessed.

Memory Card: The Memory Card is basically SRAM and is memory that retains data as long
as power is being supplied. SRAM does not have to be periodically refreshed and provides
quick access to data. This is the location that the data collected will be stored.

Flash memory: Flash memory is a type of constantly-powered nonvolatile memory that can be
erased and reprogrammed easily. This allows users to program the Optimus effortlessly.

Initialize

This selection enables the user of the Optimus to initialize the memory (SRAM).

Warning: Initializing the memo ry will erase the current data in memory.

Power

Selecting the power option allows the user to view the actual voltages of the main battery and the
backup battery.

Load Program

The selection of Load Program enables the user to download an application program to the Optimus.
Note: For further information on application program downloads see the Optimizer User’s guide.

15

Installation

802.11b Menu

The 802.11b Menu settings will configure the OptimusR with the appropriate network and security
settings for WiFi communication.

1. Information

2. Network Set

3. WLAN Setting

4. Security

5. Echo Test

Information

The information setting list the current network settings of the OptimusR.
Network Set
These are the network settings for the OptimusR.

1. DHCP

2. SubNet Mask

3. Local IP

4. Gateway

5. DNS Server

6. Domain Name

WLAN Setting
These are the Wireless Local Area Network settings.

1. Local Name

2. SS ID

3. System Scale

4. Power Saving

5. Preamble

6. Ad-Hoc

Security
The security settings provide network authentication configuration settings to provide secure data

transfer.

1. Authentications

2. WEP (Wired Equivalent Privacy) Menu

3. EAP (Extensible Authentication Protocol) Menu

Echo Test
Test to verify that the network settings are correct and communication from Optimus to host device

is functioning.

Modifying TCP/IP settings can affect the
performance of certain devices. Contact an IT
professional to ensure that modifying these
settings is done correctly.

16

Installation

Application

The Application module runs on top of the System module. The OptimusR Series Portable Data
Terminals are preloaded with the Optimizer’s run-time program and the following menu will be shown
upon powering the unit up:

Models ():

1. Run Program

2. Utilities

Utilizing the arrow keys select the menu option and execute it by pressing the ENTER key . For cert ain
models of the OptimusR Series the Data Optimizer program may need to be used in order to handle the
in-coming and out-going data to and from a host device. For detailed information, please refer to
“Optimizer User’s Guide” and “DataOptimizer User’s Guide”.

Note: If the Application Generator is used to create the application program, it will be necessary to

download it to the terminal.

Programming the terminal

There are three software tools available for developing application programs for the terminal.

• The Optimizer Program Builder

• The “BASIC” Compiler

• The “C” Compiler

For detailed information, please consult the appropriate manual or contact Metrologic Instruments, Inc..

Programming the communication cradle

The communication cradle of the OptimusR Port able Data Terminal supports serial IR interface only . If a
customized PC application has been developed for communication with the terminal via the cradle, it
will be necessary to first configure the cradle through programming. There is a DLL available for this
purpose.

For more information, please contact Metrologic Instruments, Inc..

17

Troubleshooting

SYMPTOM DESCRIPTION

Make sure the battery is inserted and charged.

Does not power up after

pressing POWER key.

Charge the battery and check the charging status. If no charging information shown o n
the display, reload the battery and check if the battery is properly installed then try again.

Call for service if problem persists.
Check if the cable is plugged tightly into host device and cradle.

Cannot transmit data or

programs to/from the terminal

Keypad does not work

properly

Scanner does not scan

Abnormal responses

Perform Echo test to confirm communication.
Check if host communication parameters (COM port, baud rate, data bits, parity, and

stop bit) match with the Terminal's.
Verify that the communication port on the host device is not in use by another device.

Turn off the power then enter the system menu. From the system menu, select the Test
and then its sub-item KBD. Perform the key-in test.

Call for service if problem persists.
Check if the bar codes used are enabled
Check if battery-low indicator is shown on the LCD display. If yes, charge the battery
Call for service if problem persists.
Open the battery cap and re-load the battery.

Enter system menu. Run diagnostic test.

Call for service if problem persists.

18

Specifications

OPTIMUSR SERIES

OPERATIONAL

Light Source: Visible Laser Diode (VLD) @ 650 nm

Normal Depth of Field:

Single-Line

51 mm - 381 mm
(2"- 15")

Width of Scan Field: 305mm (12”) @ 381 mm (15”)

Scan Speed: 42 scan lines per second

No. of Scan Lines: 1

Min Bar Width: 0.127 mm (5.0 mil)

Decode Capability:

Print Contrast: 35% minimum reflectance difference

No. Characters Read:

Beeper Operation: 7 tones or no beep

CPU: 16-bit CMOS, low power consumption

Program Memory: 2 MB Flash ROM

Data Memory: 2 MB SRAM, expandable to 8 MB

All standard 1-D bar codes including RSS-14,
RSS-Expanded, and RSS-14 Limited

Up to 80 data characters
Maximum number will vary based on symbology and density.

0.33 mm (13 mil)
bar code

Display: LCD 128 x 64 pixels, back-lit

Display Resolution: 8 lines x 20 Characters (max), 4 Lines x 15 characters (min)

Communication (Unit): RS232, USB, IrDA, CradleIR or WiFi

Communication (Cradle): RS232 or USB

Application Development: Windows-based Optmizer; optional C & BASIC compilers

19

Specifications

OPTIMUSR SERIES

MECHANICAL

Width (Unit): 81 mm (3.2")

Depth (Unit): 46 mm (1.8")

Height (Unit): 172 mm (6.77")

Weight (Unit): 10.6 oz (300 g) – including battery

Width (Cradle): 96 mm (3.8")

Depth (Cradle): 106 mm (4.17")

Height (Cradle): 80 mm (3.15")

ELECTRICAL

Battery Operation: Li-ion

Battery Backup: 3.7V, 7.0mA hours, rechargeable lithium battery

Operation: Over 200 hours, Over 16 hours (WiFi)

Laser Class:

EMC: FCC Class B

ENVIRONMENTAL

Operating Temperature: 0°C to 50°C (32°F to 122°F)

Storage Temperature: -20°C to 60°C (-4°F to 140°F)

Humidity: 5% to 95% relative humidity, non-condensing

Shock Resistance: 1.2 m (4’) drop onto concrete

CDHR and IEC Class 2 in accordance with
IEC 60825 – 1:1993 + A1:1997 + A2:2001

Figure 5 Scan Areas

20

Contact Information and Office Locations

Corporate Headquarters European, Middle East and Asian Headquarters - Singapore

Metrologic Instruments, Inc.
90 Coles Road

Blackwood, NJ 08012-4683 Metrologic Instruments GmbH 50 Kallang Avenue
Tel: [phone] Dornierstrasse 2 #01-02
Fax: [phone] (Sales) 82178 Puchheim Noel Corporate Building
Fax: [phone] (Marketing) Munich, Germany Singapore 339505
Fax: [phone] (Legal/Finance) Tel: [phone] Tel : [phone]
Email: [e-mail] Fax: [phone] Fax : [phone]
Email: [e-mail] Email: [e-mail]

North America France China

Metrologic The Americas Metrologic Eria France SA MTLG AutoID Instr . (Shanghai) Co.,Ltd
1571 Imperial Way 69 Rue de la Belle Etoile Room 1419, No.1 Ji long Road
Suite B ZI Paris Nord II, BP 50057 Waigaoqiao Bonded Zone
West Deptford, NJ 08066 95947 – ROISSY CDG CEDEX Shanghai 200000
Tel: [phone] Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Fax:[phone]
Email: [e-mail] Email: info@fr. metrologic.com Email: [e-mail]

Adaptive Optics A ssociates (AOA)
Ten Wilson Road Metrologic Instruments Italia srl Suzhou Sales Office
Cambridge, MA 02138-1128 Via Emilia 70 BLK A, Room# 03/03-04
Tel: [phone] Ozzano dell’Emilia (BO) No.5 Xinghan Str., Xinsu Industrial Sq
Fax: [phone] Tel: [phone] China-Singapore Suzhou Industrial
Email: [e-mail] Fax: [phone] Park,Suzhou, PRC
Email: [e-mail] Tel: [phone]

Omniplanar

1571 Imperial Way
Suite A Metrologic Instruments Poland Sp.z o.o
West Deptford, NJ Poleczki 21
Tel: [phone] Warsaw, Poland Guangzhou Sales Office
Fax: [phone] Tel: [phone] Room 2307
Email: [e-mail] Fax:[phone] Foreign Economic and Trade Bldg
Email:[e-mail] #351 Tianhe Road
Guangzhou City, Guangdong

Tel: [phone]
Fax: [phone]
Email: [e-mail]

African HQ & Germany Office Singapore
Eastern Europe and Middle East

Italy China

Fax: [phone]

Poland

Metrologic A s ia (Pte) Ltd

Email: [e-mail]

China

Province, PRC

21

Contact Information and Office Locations

South America and Central America European, Middle East and

African Headquarters

Brazil Russia China

Metrologic do Brasil Ltda. Metrologic Russia Beijing Sales Office
Rua da Paz 2059 Bolshaya Novodmitrovskaya 14 Tower A, 5th Floor, Unit 5204
CEP 04713-002 RU-125015 China Intn'l Science and Tech
Chácara Santo Antônio Moscow Russia Convention Ctr
São Paulo, SP, Brasil Tel: [phone] No. 12 Yu Min Road Chao Yang Dist
Tel: [phone] Fax: [phone] Beijing China 100029
Fax: [phone] Email: [e-mail] Tel/Fax: [phone]
Email: [e-mail]. com Email: [e-mail]

Outside Brazil Metrologic Eria Ibérica, SL
Metrologic South America Julián Camarillo 29, D-1 Metrologic India
Rua da Paz 2059 28037 Madrid 403, 4th Floor Carlton Towers
CEP 04713-002 Tel: [phone] No. 1, Airport Road
Chácara Santo Antônio Fax: [phone] Bangalore, India 560 008
São Paulo, SP, Brasil Email: [e-mail] Tel: [phone]
Tel: [phone] Fax: [phone]
Fax: [phone] Metrologic European Re pair Ctr Email: [e-mail]
Email: [e-mail] (MERC)
Metrologic Eria Ibérica, SL

European, Middle East and
African Headquarters

Metrologic Instruments GmbH Tel: [phone] Higashiueno
Dornierstrasse 2 Fax: [phone] Taitou-ku, Tokyo 1 10-0015 Japan
82178 Puchheim Tel: [phone]
Munich, Germany
Tel: [phone] Metrologic Instruments UK Ltd Email: [e-mail]
Fax: [phone] Tempus Business Centre
Email: [e-mail] Kingsclere Road, Basingstoke
Hampshire RG21 6XG

Germany, Austria and Switzerland

Metrologic Instruments GmbH Fax: [phone]
Dornierstrasse 2 Email: [e-mail]
82178 Puchheim Kingsclere Road, Basingstoke
Munich, Germany Hampshire RG21 6XG
Tel: [phone] Tel: [phone]
fax: [phone] Fax: [phone]
Email: [e-mail] Email: [e-mail]

Spain

C/ Alfonso Gomez, 38-40, 1D Metrologic Japan Co., Ltd.
28037 Madrid Matsunoya Building, 6 Floor

United Kingdom

Tel: [phone]

Asian Headquarters - Singapore

India

Japan

Fax: [phone]

22

Safety Notices

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:

• Reposition or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.

23
