Page 1
Item # ______________________________________________
Item # ______________________________________________
Job ________________________________________________
Job ________________________________________________
WIRE SHELVING ACCESSORIES
Color Shelf Marker
Color code for effective organization. Snaps securely to the front edge of Super Erecta and
Super Adjustable Super Erecta Wire Shelving.
Shelf Marker Size
Model No. (in.) (mm) Color
CSM6-B 6x11/4 152x32 Blue
CSM6-G 6x11/4 152x32 Green
CSM6-R 6x11/4 152x32 Red
CSM6-T 6x11/4 152x32 Tan
CSM6-W 6x11/4 152x32 White
CSM6-Y 6x11/4 152x32 Yellow
CSM6-GR 6x11/4 152x32 Gray
Label Holders
It’s easy to identify shelf contents with these snap-on plastic holders, available in four styles
and a variety of sizes. Labels not included.
11/4" (32mm) Label Holders
Gray. Holds most commercial labels. Available in a variety of lengths.
Label Size Fits Shelf Length
Model No. (in.) (mm) (in.) (mm)
9990P 3x11/4 75x32 All
9990P1 13x11/4 330x32 18 457
9990P2 19x11/4 480x32 24 610
9990P30 25x11/4 635x32 30 760
9990P3 31x11/4 725x32 36 914
9990P4 43x11/4 1090x32 48 1219
9990P5 55x11/4 1395x32 60 1520
Clear Label Holders
Clear plastic allows decorator colors to show through. Holds most commercial 11/4" (32mm)
labels.
Label Size Fits Shelf Length
Model No. (in.) (mm) (in.) (mm)
9990CL 3x11/4 75x32 All
9990CL1 13x11/4 330x32 18 457
9990CL2 19x11/4 480x32 24 610
9990CL30 25x11/4 635x32 30 760
9990CL3 31x11/4 725x32 36 914
9990CL4 43x11/4 1090x32 48 1219
9990CL5 55x11/4 1395x32 60 1520
Slanted Label Holders
Gray solid plastic holder puts 11/4" (32mm) labels on slant for easier viewing.
Label Size Fits Shelf Length
Model No. (in.) (mm) (in.) (mm)
9990SL 3x11/4 75x32 All
9990SL1 13x11/4 330x32 18 457
9990SL2 19x11/4 480x32 24 610
9990SL30 25x11/4 635x32 30 760
9990SL3 31x11/4 725x32 36 914
9990SL4 43x11/4 1090x32 48 1219
9990SL5 55x11/4 1395x32 60 1520
Material specifications
• Color Shelf Markers, 1
a temperature range of -20° to 165°F (-28° to 73°C)
• Clear Label Holders — CAB plastic; suitable for continuous use in a temperature range of 20° to 120°F (-28° to 49°C)
• Label holders are not cart washable or autoclavable.
Notes for Shelf Markers and Label Holders:
• If ledges are desired on the front of the shelf where the label holder is most often attached, the label holder or color shelf marker must be mounted between the vertical support
wires of the ledge.
• Label holders work with standard wire shelving styles — Super Erecta, Super Adjustable, qwikSLOT, Drop Mat wire shelving, cantilever shelves.
• Designed for use with 1" (25mm) high labels.
1
/4" High Gray Label Holders, Slanted Label Holders — Rigid PVC; suitable for continuous use in
Color Shelf Markers
11/4" (32mm) Label Holder
Clear Label Holder
Slanted Label Holder
Wire Shelving Accessories
10.05
InterMetro Industries Corporation
North Washington Street
Wilkes-Barre, PA 18705
www.metro.com
Page 2
WIRE SHELVING ACCESSORIES
Grids and Brackets
Grids
Attach easily to shelf frames or to the wall to provide a structure for mounting baskets,
hooks, hangers, and other storage, workspace management, or display accessories.
Accessories can be found in this spec sheet (10.05) and in spec sheet 10.41.
• Grid openings: 2
• Weight capacity: 250 lb. (112.5kg)
Model No. Approx.
Model No. Metroseal 3 Size Pkd. Wt.
Plated with Microban
WG1836BR WG1836K3 18x36 457x914 9 4.1
WG1848BR WG1848K3 18x48 457x1219 12 5.4
WG1860BR WG1860K3 18x60 457x1524 14 6.4
* WG2436K3 24x36 610x914 12 5.4
* WG2448K3 24x48 610x1219 15.5 7
* WG3036K3 30x36 762x914 12.8 5.8
* WG3048K3 30x48 762x1219 16.5 7.5
PBA-GPC — 33x54 840x1370 21 9.5
Note: Consult your Metro representative for availability of stainless steel or decorative epoxy grids.
Grid Clamp (for Shelf)
Allows the grid to attach to a wire or solid shelf frame. Brite zinc finish.
Minimum of four are needed to secure a grid to a shelf. Bag of 8 clamp
assemblies. (Available by the bag only). Model No. 9970Z
3
/4"x23/4" (70x70mm)
®
(in.) (mm) (lbs.) (kg)
Accessories are
ordered separately.
See spec sheet 10.43
Stainless Steel Direct Wall Mount Brackets
Stainless grid brackets allow the grid to attach to the wall and be
removed for easy cleaning. Kit includes 6 brackets. Approximate
packaged weight is 2 lb. (0.9kg). Model No. SWGB2
Grid Clamp WGBRKTSWGB2
Plastic Direct Wall Mount Bracket
Black plastic clamps attach grid to the wall. Kit includes 6 brackets. Approximate
packaged weight is 2 lb. (0.9kg). Model No. WGBRKT
Hanger Rails
Convenient rail fits on posts along the width or length of the unit. Suitable for use with
hanging storage baskets, hooks, and extension display hangers.
Approx.
Model No. Model No. Model No. Model No. Model No. Length† Pkd. Wt.
Chrome Black White Smoked Glass Designer Colors* (in.) (mm) (lbs.) (kg)
H114C H114B H114W H114-DSG H114-D 14 355 1 .45
H118C H118B H118W H118-DSG H118-D 18 457 11/4 .57
H124C H124B H124W H124-DSG H124-D 24 610 11/2 .68
H130C H130B H130W H130-DSG H130-D 30 760 11/2 .68
H136C H136B H136W H136-DSG H136-D 36 914 2 .90
H148C H148B H148W H148-DSG H148-D 48 1219 21/2 1.13
†14", 18" and 24" (355, 457 and 610mm) sizes fit shelf width (depth).
30", 36" and 48" (760, 914 and 1219mm) sizes fit shelf length.
Weight capacity — 25 lb. (11.3kg) evenly distributed.
Hanger Rail
Designer Shelf Colors
*To order a Designer Color, add the appropriate color suffix to the desired catalog numbers above (example: 18"x36" [457x914mm]
Hunter Green Shelf = 1836N-DHG).
BM — Black Matte SH — Silver Hammertone HG — Hunter Green
F — Flame CH — Copper Hammertone
Page 3
WIRE SHELVING ACCESSORIES
Cantilever Shelves
Adds convenient space above a storage unit. Drop mat design creates a retaining ledge
around the entire 12" (305mm) deep shelf. Remember to order rear posts taller than front
posts to accommodate these shelves.
Approx.
Model No. Model No. Model No. Model No. Length Pkd. Wt. Each
Chrome Black White Smoked Glass (in.) (mm) (lbs.) (kg)
1224CSNC 1224CSNBL 1224CSNW 1224CSN-DSG 24 610 41/2 2.0
1230CSNC 1230CSNBL 1230CSNW 1230CSN-DSG 30 750 5 2.3
1236CSNC 1236CSNBL 1236CSNW 1236CSN-DSG 36 914 53/4 2.6
1242CSNC 1242CSNBL 1242CSNW 1242CSN-DSG 42 1066 63/4 3.1
1248CSNC 1248CSNBL 1248CSNW 1248CSN-DSG 48 1219 73/4 3.5
1260CSNC 1260CSNBL 1260CSNW 1260CSN-DSG 60 1524 91/2 4.3
Weight capacity — 150 lb. (67.5kg) evenly distributed.
Storage Baskets
Generous-sized baskets attach in seconds to a hanger rail, wire shelf, enclosure panel,
or grid. Weight capacity — 20 lb. (9kg).
Model No.
Metroseal 3 Model No. Approx.
Model No. with Model No. Model No. Model No. Designer Width/Length/Depth Pkd. Wt.
Chrome Microban
H209C H209K3 H209B H209W H209-DSG H209-D 133/8x5x7 345x127x180 81/2 4
H210C H210K3 H210B H210W H210-DSG H210-D 173/8x71/2x5 440x190x127 7 3
H212C H212K3 H212B H212W H212-DSG H212-D 173/8x71/2x10 440x190x255 11 5
®
Black White Smoked Glass Colors* (in.) (mm) (lbs.) (kg)
Cantilever Shelves
Large Display/Storage Basket
File Basket
The convenient place to keep files and papers.
5
• Measures 2
/8"W. x 123/4" L. x 83/4" H. (67mm W. x 324mm L. x 222mm H.).
• Large enough to hold standard-size file folders.
• Chrome plated.
• Weight capacity — 20 lb. (9kg).
Approx.
Width/Length Height Pkd Wt.
Model No. (in.) (mm) (in.) (mm) (lbs.) (kg)
PH1239C 25/8x123/4 63x330 83/4 228 2.1 1.0
Extension Display Hanger
Snaps on Super Erecta Shelf hanger rails, shelves, enclosure panels, and grids. Accepts
standard carded merchandise.
Approx.
Length Pkd. Wt.
Model No. (in.) (mm) (lbs.) (kg) Finish/Color
HHK6C 6 152 .25 .1 Chrome
HHK6B 6 152 .25 .1 Black
HHK8C 8 203 .25 .1 Chrome
HHK8B 8 203 .25 .1 Black
*White, smoked glass and designer colors also available. Allow 4-6 week lead time.
File Basket
Extension Display Hanger
Page 4
Job ________________________________________________Job ________________________________________________
10.05
WIRE SHELVING ACCESSORIES
Swing Hanger
Attaches to post to provide convenient storage for hanging items. Red
epoxy finish.
Weight
Arm Length Capacity
Model No. (in.) (mm) (lbs.) (kg)
H110R 61/4 160 20 9
Snap-On Hooks
Multi-purpose hooks in three styles attach to hanger rails, mounting
rails, shelves, enclosure panels, or grids for instant access.
Model No. Model No. Height
Chrome Black Description (in.) (mm)
HK23C HK23B Style A — Small 37/16 90
HK25C HK25B Style B — Large 37/16 90
HK26C Style C — Double 37/16 90
Weight capacities: Single Hook — 5 lb. (2.3kg)
Garment Hanger Tube with Brackets
Hanger tubes attach easily under Super Erecta shelves for hanging
garments. Available in 18", 21" and 24" (457, 530 and 610mm) widths
and in same length as shelves.
Tube Approx.
Shelf Width Shelf Width Shelf Width* Length Pkd. Wt.
18" (457mm) 21" (530mm) 24" (610mm) (in.) (mm) (lbs.) (kg)
AT2418NC AT2421NC AT2424NC 24 610 21/2 1.1
AT3018NC AT3021NC AT3024NC 30 760 21/2 1.1
AT3618NC AT3621NC AT3624NC 36 914 3 1.4
AT4218NC AT4221NC AT4224NC 42 1066 31/2 1.6
AT4818NC AT4821NC AT4824NC 48 1219 31/2 1.6
AT6018NC AT6021NC AT6024NC 60 1524 4 1.8
AT7218NC AT7221NC AT7224NC 72 1828 41/2 2.0
Weight capacity — 75 lb. (34kg) evenly distributed.
*Also works with 30" (760mm) and 36" (914) width shelves.
Double Hook — 10 lb. (4.6kg)
Swing Hanger
B
A
Snap-On Hooks
Garment Hanger Tube with Brackets
C
Wire Shelving Accessories
All Metro Catalog Sheets are available on our website: www.metro.com
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
Phone: 570-825-2741
Product Information. U.S. and Canada: 1.800.992.1776
Outside U.S. and Canada: www.metro.com/contactus
Printed in U.S.A Rev. 03/14
Information and specifications are subject to
change without notice. Please confirm at time of order
Copyright © 2014 InterMetro Industries Corp.
L02-008
