OWNER'S MANUAL
+
MCD-479
–
PLL SYNTHESIZER STEREO RADIO WITH
COMPACT DISC PLAYER DIGITAL
INSTALLATION
Notes:
• Choose the mounting location where the unit will not interfere with the normal driving
function of the driver.
• Before completly installing the unit, connect the wiring temporarily and make sure it is
functioning properly.
• Use only the parts included with the unit to ensure proper installation. The use of
unauthorized parts can cause malfunctions.
• Consult with your Metrik dealer if installation requires the drilling of holes or other
modifications of the vehicle.
• Install the unit securly and correctly to insure injure saftey of the driver and the
passenger if there is a sudden stop, like an emergency stop.
• If installation angle exceeds 30˚ from horizontal, the unit might not give its optimum
performance and the CD may skip
30˚
• Avoid installing the unit where it would be subject to high temperature, such as
in direct sunlight, in line of vents from the heater, or where it would be subject to
dust, dirt or excessive vibration.
DIN FRONT/REAR-MOUNT
This unit can be properly installed either from "Front" (conventional DIN Front-mount)
or "Rear" (DIN Rear-mount installation, utilizing threaded screw holes at the sides of
the unit chassis). For details, refer to the following illustrated installation methods.
DIN FRONT-MOUNT (Method A)
Installation the unit
1
182
53
(Fig. 1)
2
3
1. Dashboard
2. Holder
3. Rear Support Screw
2
After inserting the sleve into the
dashboard, select the appropriate tab
according to the thickness of the
dashboard material and bend them
inwards to secure the sleve in place.
1
7
4
2
3
6
5
1. Dashboard
2. Nut (5mm)
3. Spring washer
4. Screw (5 x 25mm)
5. Screw
6. Strap
Be sure to use the strap to secure the
back of the unit in place. The strap can
be bent by hand to the desired angle.
7. Plain washer
(Fig. 2)
Removing the unit
1. Frame
1
2. Insert fingers into the groove in the front
of frame and pull out to remove the
frame. (When re-attaching the frame,
point the side with a groove downwards
and attach it.)
3. Lever
3
Insert the levers supplied with the unit
into the grooves at both sides of the unit
as shown in figure until they click.
Pulling the levers makes it possible to
remove the unit from the dashboard.
DIN REAR-MOUNT (Method B)
Installation using the screw holes on the sides of the unit.
1
Fastening the unit to the factory radio
mounting bracket.
1. Select a position where the screw
holes of the bracket and the screw
holes of the main unit become
aligned (are fitted), and tighten the
2
4
5
3
screws at 2 places on each side.
Use either truss screws (5 x 6mm) or
flush surface screws (4 x 6mm),
depending on the shape of the screw
holes in the bracket.
2. Screw
3. Factory radio mounting bracket
2
5
4. Dashboard or Console
5. Hook (Remove this part)
Note: The mounting box, outer trim ring,
and half-sleeve are not used for
this method of installation.
3
HOW TO REMOVE AND INSTALL THE FRONT PANEL
1. Press the release button and pull-off the front panel.
Place the front panel into the supplied case to protect it.
2. To install the front panel, insert the right side of thepanel into the housing first,
then press the left side in until it locks in place. If the panel is not correctly installed
some of the function keys or the display may not function properly.
REMOVING THE FRONT PANEL
Front Panel
Release Button
INSTALLING THE FRONT PANEL
4
