Metra Electronics Combo, Keypad, RFID Technical Manual
Display Combo/RFID/Keypad Technical Manual
Page 2
Display Combo/RFID/Keypad Technical Manual
Table of contents
Display Combo/RFID/Keypad Technical Manual ..................................................................................... 3
Product description ............................................................................................................................. 3
Connections ........................................................................................................................................ 4
Display Combo ................................................................................................................................. 4
Display RFID ..................................................................................................................................... 4
Display Keypad ................................................................................................................................ 4
Operating indicator ............................................................................................................................. 5
Display Combo ................................................................................................................................. 5
Display RFID ..................................................................................................................................... 5
Display Keypad ................................................................................................................................ 5
Maintenance ....................................................................................................................................... 6
Technical data ..................................................................................................................................... 6
Appendix ............................................................................................................................................. 7
Page 3
Display Combo/RFID/Keypad Technical Manual
Display Combo/RFID/Keypad Technical Manual
Manufacturer:
Metra inženiring d.o.o.
IOC Trzin
Špruha 19
SI-1236 Trzin, Slovenia
phone:
fax:
web:
+386 1 56 10 740
+386 1 56 10 744
www.metra.si
System:
Metra ELS & ELS SELECT – Electronic Locking Systems
Product Group:
Display
Types:
Display Combo
DDIS (ISO 15693, ISO14443A/B)
DDLF (LF Multitag)
DDMF (Mifare)
DDSD (Skidata)
Display RFID
DSIS (ISO 15693, ISO14443A/B)
DSLF (LF Multitag)
DSMF (Mifare)
DSSD (Skidata)
Display Keypad
DSKP
Year of Construction:
2008-2010
Declaration of Conformity:
The Metra ELS and ELS SELECT products have been developed, designed
and manufactured in accordance with the EU directive for
Electromagnetic Compatibility (2004/108/EC).
Display Combo/RFID/Keypad User Manual [rev.0-250211]
2011 Metra inženiring d.o.o.
All Rights reserved.
No part of this manual may be reproduced in any form or by any means without prior written permission of Metra inženiring d.o.o.
The contents of this manual are subject to change without notice.
All efforts have been made to ensure the accuracy of the contents of this manual, however, should any errors be detected, Metra inženiring would greatly appreciate being informed of
them. Metra inženiring d.o.o. can assume no responsibility for any errors in this manual.
Product description
Display Combo
Display RFID
Display Keypad
Metra Display RFID is a user interface for Metra ELS systems, while
Metra Display Combo and Keypad are a user interfaces for Metra
ELS and Metra ELS SELECT systems.
Display Combo: Read RFID tickets as locker keys. Twelve key
washable keypad is integrated to enable additional user
interaction (PIN, locker number, etc.) and can be used for locking /
unlocking instead of RFID media.
Display RFID: Reads RFID tickets as locker keys.
Display Keypad: Integrated 12 key washable keypad to enable
user interaction (PIN, locker number, etc.).
Each model shows the locker number on a four digit LED display
available in blue or white. They also perform audio signalization
and show an alarm message if an attempt of break-in is detected
on a Metra Electric Lock connected to a Metra Locker Controller.
Locker Controller’s operating parameters are set up through
integrated 4 key system keypad (Display RFID) or through 12 key
keypad (Display Combo and Keypad) and stored in Locker
Controller’s internal battery powered memory. To simplify setup
of Locker Controller and manage master keys and master/setup
codes also Metra software can be used.
