HDMI EXTENDER
AC Power Adapter US standard, UK standard and so on
User Manual
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) Main unit NO. 1 Sender
2) Main unit NO. 2 Receiver
3) 5VDC Power Supply.
4) User’s Manual
4.0 PANEL DESCRIPTIONS
Sender
HDMI EXTENDER
Table of Contents
1.0 Introduction..........................................................................1
2.0 Specifications.......................................................................2
3.0 Package Contents................................................................3
4.0 Panel Descriptions...............................................................3
5.0 Connection and Operation..................................................4
HDMI EXTENDER
HDMI EXTENDER (By CAT-5e/6 cable)
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
The HDMI Extender by CAT-5e/6 uses two pieces of UTP cable to extend the
HDTV display up to 30 meters for 1080p It not only breaks the limitation of the
HDMI cable transmission lengthbut also CAT-5e/6 has more flexibility and
convenience in cable construction.
It is equipped with HDMI (high definition multimedia interface) connectors and is
capable of supporting DVI (digital visual interface) equipment when used with an
HDMI to DVI Adapter, providing greater flexibility and options when integrating
several home theater components.
It offers solutions for residential consumers: HDTV retail and show site, HDTV,
STB, DVD and Projector factories, noise, space and security concerns, data
center control, information distribution, conference room presentation, school and
corporate training environments.
1.1 BENEFITS
1) The length of HDMI cable is fixed and unchangeable after it is produced.
Because the HDMI connector can only be soldered or terminated by the
professional workers in factory, the users can not reduce or increase by
themselves. However CAT-5e/6 cables are available everywhere and be
processed easily by the user or installer.
2) Because the header of the long HDMI cable is big, using it must in hidden
method. What's more, it is not easy to bend the HDMI cable and to pull it
through the in-wall tube or tray. However, CAT-5e/6 cable has no such
problems.
3) Using this Extender together with UTP cable the transmission distance can be
up to 60 meters for 1080p. For the general HDMI cables, they must be
customized when the length is over 10 meters.
1.2 FEATURES
This HDMI Extender has many features that enable it to perform in a superior
manner. Among those features you will find:
HDMI EXTENDER
One pair as a full functional module, no need of setting.
CAT-5e/6 cable can substitute HDMI cable to achieve long distance
transmission.
Follows the standard of IEEE-568B.
Transmission distance can be up to 30 meters for 1080p while using UTP
cable.
Supports HDMI1.2a.
Supports highest video resolution 1080p.
Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.
Supports 8bit per channel (24bit all channel) deep color.
HDCP pass-through.
Supports uncompressed audio such as LPCM
Supports compressed audio such as DTS Digital, Dolby Digitalincluding
DTS-HD and Dolby True HD.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal 5 Volts p-p (TTL)
Maximum Single Link Range 1920x1080p
Output Video HDMI1.2a
HDMI Input/Output Connector Type A 19 pin
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplifier Bandwidth 1.65Gbps/165MHz
Resolutions(HDTV)
Interlaced(50&60Hz) 480i,576i,1080i
Progressive(50&60Hz) 480p,576p,720p,1080p
Mechanical 1.8” W x 1” H x 3.2” D
Size(H-W-D) 45mmW x 25mmH x 81mmD
Weight(Net) 0.246KGs
Warranty
Limited Warranty 1 Year Parts and Labor
Environmental
Operating Temperature
0 to +70
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature
-10 to +80
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
External Power Supply 5V DC@2A(optional)
Power consumption (Max) 5W
Regulatory Approvals
Converter Unit FCC,CE,UL
Power Supply UL,CE,FCC
Accessories Adapter
HDMI EXTENDER
AC Power Adapter US standard, UK standard and so on
User Manual
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1) Main unit NO. 1 Sender
2) Main unit NO. 2 Receiver
3) 5VDC Power Supply.
4) User’s Manual
4.0 PANEL DESCRIPTIONS
Sender
Receiver
HDMI EXTENDER
1) HDMI input.
2) CAT-5e output2.
3) CAT-5e output1.
4) HDMI output
5) CAT-5e input1
6) CAT-5e input2
7) Power Input
5.0 CONNECTION AND OPERATION
1) Connect the HDMI input sources such asHD-DVDPS3STB etc.
2) Connect two CAT-5E cables to both the output of the sender and input of the
receiver.
3) Connect the HDMI output( such as : HD-LCDHD-DLP)into receiver.
4) Insert the DC side of 5v power supply if the 5v of the source is not enough.
Attention: Insert / Extract cable gently.
HDMI EXTENDER
5.1 CONNECTION DIAGRAM
DC 5V
CAT-5e/6 cable
Sender Receiver
CAT-5e/6 cable
HDMI signal source
such as STB
Display Such as
LCD TV
