Metra Electronics 99-4503 User Manual
INSTALLATION INSTRUCTIONS FOR PART 99-4503
APPLICATIONS
GENERAL MOTORS 1982-02
VEHICLES EQUIPPED WITH J-2000 PANEL-STYLE
FACTORY HEAD UNIT PROVISIONS
(SEE INSIDE FOR SPECIFIC APPLICA
(USE WITH 02-4544 BRACKET KIT
OR FACTORY BRACKETS)
TIONS)
KIT FEATURES
• Shaft and DIN Unit Provisions
KIT COMPONENTS
• A) Radio Housing • B) Faceplate • C) Equalizer Dummy Plate • D) (4) Keps Nuts
• E) (4) Carriage Bolts
A
C
Phillips Screwdriver • Adjustable Wrench • Cutting Tool
99-4503
B
D
TOOLS REQUIRED:
E
1-800-221-0932
© COPYRIGHT 2001-2008 METRA ELECTRONICS CORPORA
www.metr
aonline.com
TION
99-4503
K
NOWLEDGE IS POWER
Enhance your installation and fabrication skills
by enrolling in the most recognized and
respected mobile electronics school in our
industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take
steps toward a better tomorrow.
TABLE OF CONTENTS
All Vehicles
GENERAL MOTORS 1982-02 VEHICLES EQUIPPED WITH J-2000
PANEL-STYLE FACTORY HEAD UNIT PROVISIONS
Kit Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit
Assembly and Final Assembly
Shaft Head Unit Mount Radio Provision . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
DIN Head Unit Mount Radio Provision
*Note:
Refer also to the instructions included with the aftermarket radio.
.2,3,4
99-4503
APPLICATIONS
NOTE: * THE FACTORY MOUNTING BRACKET(S) MUST BE RETAINED
AND USED WITH THIS VEHICLE.
BUICK
Century 1982-96*
Electra 1984-94*
Estate wagon 1984-94*
LeSabre 1984-94*
Park Ave. 1984-94*
Reatta 1990-91*
Regal 1984-87*
Riviera 1983-85*
Riviera 1990-95*
Roadmaster 1991-94*
Skyhawk 1982-89*
Skylark 1983-85*
Skylark 1987-95*
CADILLAC
Cimarron 1982-88*
DeVille 1985-93*
Eldorado 1984-91*
Escalade 1999-02
Fleetwood 1985-93*
Seville 1984-91*
CHEVROLET
Astro 1985-95*
Astro 1996-02
Beretta 1991-96*
Camaro 1982-92*
Blazer (full) 1989-91*
Blazer 1998-02
Camaro 1982-92*
Camaro 1997-99
Caprice 1991-93*
Caprice 1994-96
Cavalier 1982-94*
Cavalier 1995-99
Celebrity 1982-87*
Citation II 1985*
Corsica 1991-96*
Corvette 1984-89*
CHEVROLET (contionued)
Corvette 1997-02
El Camino 1985-88*
Express 1996-00
Impala SS 1994-96
Lumina 1990-94*
Lumina 1995-99
Lumina APV 1990-95*
Lumina APV 1996*
Malibu 1997-99
Monte Carlo 1985-88*
Monte Carlo 1995-99
Nova 1985-88*
Pickup 1995-02
S10 Blazer 1982-94*
S10 Pickup 1982-93*
S10 Pickup 1998-02
Silverado 1999-02
Suburban 1989-91*
Suburban 1995-02
Tahoe 1995-02
Van (full) 1988-95*
Venture 1997-99
GMC
Jimmy (full) 1989-91*
Jimmy 1998-02
S15 Jimmy 1982-94*
S15 Pickup 1982-93*
Safari 1985-95*
Safari 1996-02
Savana 1996-00
a 1995-02
Sierr
Sonoma 1998-02
Suburban 1989-91*
Suburban 1995-99
Van (full) 1988-95*
Yukon 1995-02
OLDSMOBILE
Achieva 1992-95*
Bravada 1991-94*
Cutlass Calais 1984-91*
Cutlass Ciera 1982-96*
Cutlass Supr. 1984-88*
Delta 88 1986-88*
Firenza 1982-89*
Ninety Eight 1984-90*
Omega 1983-84*
Silhouette 1990-96*
Silhouette 1997-99
Toronado 1982-85*
PONTIAC
6000 1982-91*
Bonneville 1982-93*
Bonneville 1994-99
Fiero 1984-88*
Firebird 1982-92*
Firebird 1993-02
Grand Am 1985-95*
Grand Am 1996-00
Grand Prix 1985-93*
Grand Prix 1994-00
Montana 1999
Sunbird J-2000 1982-88*
Sunfire 1995-99
TransSport 1990-96*
TranSport 1997-98
SATURN
(All models) 1991-94*
