INSTALLATION INSTRUCTIONS FOR PART 99-2004
APPLICATIONS
Cadillac
1997-2001 Catera
1996-1999 Deville
(Column Shift Only)
99-2004
KIT FEATURES
• DIN Radio Provision with Pocket
• ISO DIN Radio Pro
KIT COMPONENTS
( A) Radio Housing • ( B) Trim Plate • ( C) ISO Brackets • (D) (4) Speed Clips • (E) (4) Phillips head screws
A
vision with Pocket
B
D
C
E
TOOLS REQUIRED:
Phillips Screwdriver • Cutting Tool
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
99-2004
TABLE OF CONTENTS
Dash Disassembly
1997-2001 Cadillac Catera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1996-1999 Cadillac Deville
Assembly
Kit
1997-2001 Cadillac Catera
DIN Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . . . . 2
ISO DIN Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . 2
1996-1999 Cadillac Deville
DIN Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . . . . 3
ISO DIN Radio Provision with Pocket . . . . . . . . . . . . . . . . . . . . . . 3
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
( Column Shift Only)
( Column Shift Only)
. ............
1
99-2004
6:5
9
6:59
1997-2001 CADILLAC CATERA
Disconnect the negative battery
1
terminal to prevent an accidental
short circuit.
2
Remove (1) Phillips head screw from
inside the ashtray and remove ashtray.
(Figure A)
3
Remove screw covers from the radio
trim panel. Remove traction control
and hazard switch covers. Then
remove switches by depressing tabs
and pulling outward.
(Figure B)
DASH DISASSEMBLY
A
B
Remove (4) Phillips head screws
4
from behind covers and ashtray.
Remove radio trim panel and unplug
5
any remaining harnesses from the
panel.
Remove (2) Phillips head screws
6
securing the radio. Unplug and
remove the radio.
(Figure C)
1996-1999 CADILLAC DEVILLE
Disconnect the negative battery
1
terminal to prevent an accidental
short circuit.
C
A
Unsnap and remove radio trim panel.
2
(Open glove box to access.)
Pinch the side clips to disengage
3
radio. Unplug and remove radio.
(Figure A)
1
T
WO ON EACH SIDE
OF RADIO HOUSING
99-2004
KIT ASSEMBLY
1997-2001 CADILLA
Remove (2) tabs from the top edge
1
of the radio housing.
A
(Figure A)
DIN RADIO PROVISION
Slide the DIN cage into the radio
3
housing and secure by bending the
metal locking tabs outward.
A
(Figure A)
C CATERA
Remove both mounting brackets “B”
2
from the radio housing.
B
Slide the radio into the DIN
4
cage/housing assembly until it snaps
into place.
B
(Figure B)
(Figure B)
Continue with final assembly.
5
ISO RADIO PROVISION
Align the holes from the ISO snap in
3
brackets with the holes in the side of
the radio and mount the brackets to
the radio using screws supplied with
the radio.
A
Continue with final assembly.
5
(Figure A)
Slide the radio bracket assembly into
4
the radio housing until the assembly
snaps into place. Snap the ISO
Trimplate over the unit.
B
(Figure B)
2
99-2004
T
WO ON EACH SIDE
OF RADIO HOUSING
KIT ASSEMBLY
1996-1999 CADILLA
Install (4) speed clips into the sub-
1
dash mounting positions.
A
DIN RADIO PROVISION
Slide the DIN cage into the radio
3
housing and secure by bending the
metal locking tabs outward.
A
(Figure A)
(Figure A)
C DEVILLE
Remove mounting brackets “A” from
2
the radio housing.
B
Slide the radio into the DIN
4
cage/housing assembly until it snaps
into place.
B
(Figure B)
(Figure B)
Continue with final assembly.
5
ISO RADIO PROVISION
Align the holes from the ISO snap in
3
brackets with the holes in the side of
the radio and mount the brackets to
the radio using screws supplied with
the radio.
A
Continue with final assembly.
5
(Figure A)
Slide the radio bracket assembly into
4
the radio housing until the assembly
snaps into place. Snap the ISO
Trimplate over the unit.
B
(Figure B)
3
99-2004
FINAL ASSEMBLY
FINAL ASSEMBLY
Locate the factory wiring harness in the dash and make the connection as shown.
1
Metra recomends using the proper mating adapter and making the connections as
shown. (Isolate and individually tape off the ends of any unused wires to prevent
electrical short circuit.)
Re-connect the negative battery terminal and test the unit for proper operation.
2
3
Reassemble radio and dash assemblies in reverse order of disassembly.
FINAL WIRING CONNECTIONS
Make wiring connections using the EIA color code chart shown below and the instructions included with the head
unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and individually
tape off ends of any unused wires to prevent electrical short circuit.
A
B
C
D
A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
METRA / EIA WIRING CODE
12V Ignition / Acc . . . Red
12V Batt / Memory . . Yellow
Ground . . . . . . . . . . . Black*
Power Antenna . . . . . Blue
Amp Turn-On . . . . . . Blue / White
Amp Ground . . . . . . . Black / White
Illumination. . . . . . . . Orange
Right Front (+) . . . . . Gray
Right Front (-) . . . . . . Gray / Black
Left Front (+) . . . . . . White
Left Front (-) . . . . . . . White / Black
Right Rear (+). . . . . . Violet
Right Rear (-) . . . . . . Violet / Black
Left Rear (+). . . . . . . Green
Dimmer . . . . . . . . . . Orange / White
*NOTE: When a Black wire is not present, ground radio to vehicle chassis.
All colors may not be present on all leads due to manufacturer’s specifications.
Left Rear (-) . . . . . . . Green / Black
4
99-2004
