Metermann PM53 User Manual [en, de, fr, it]
PM53
Automatic Pocket Meter
Users Manual
• Mode d’emploi
• Bedienungshandbuch
• Manual d’Uso
• Manual de uso
PN 2153036
August 2004
2004 Meterman Test Tools.
All rights reserved. Printed in Taiwan
SELECT
1
2
Press for 2 seconds
to turn meter on.
3
SELECT
A LCD display
B SELECT-button to select alternate functions and turn the power
off and on.
C Permanently attached red test lead for positive (+) polarity and
black test lead for ground reference (-)
PM53 Pocket Meter
Contents
Introduction 2
Safety Information 2
Symbols Used in this Manual 3
Turning the Meter On and Off 3
Making Measurements 4
TM
AutoTect
Mode 5
Continuity, Audible With Symbolic Display 5
Electric Field EF-Detection, VolTect 5
Voltage 8
Resistance 8
Frequency 8
Capacitance 8
Product Maintenance 8
Maintenance 8
Cleaning 8
Troubleshooting 9
Battery Replacement 9
Limited Warranty and Limitation of Liability 10
Repair 10
Specifications 11
1
Introduction
This unique meter has a full complement of features in a compact package
only 3/8 inch deep and weighing less than 3 oz. The essential shirt-pocket
size meter for portability, Model PM53 is fully autoranging and has an
oversized, easy-to-read digital display. It offers the AutoTect™ feature that
guides the meter to display AC volts, DC volts or resistance based on what
you are measuring. Also offered is VolTect™, a built-in non-contact voltage
detector of AC voltages. Although very small, this meter is fully UL safety
rated to CAT III levels. The Meterman PM53 includes measurement extras
such as capacitance, frequency and continuity plus safety extras such as
transient protection to 4 kV and overload protection to either 450 V.
Safety Information
• The PM53 Digital Multimeter is certified for cULus and
EN61010-1:2001; CAT II 450 V, CAT III 300 V, class 2 and
pollution deg. 2.
• This instrument is EN61010-1 certified for Installation Category II
(450 V). It may only be used to make measurements on energy limited
circuits within equipment and not directly connected to mains.
• This instrument is EN61010-1 certified for Installation Category III
(300 V). It is recommended for use with local level power distribution,
appliances, portable equipment, etc., where only smaller transient
overvoltages may occur, and not for primary supply lines, overhead
lines and cable systems.
• Do not exceed the maximum overload limits per function (see
specifications) nor the limits marked on the instrument itself. Never
apply more than 450 V between the test lead and earth ground.
• Inspect the DMM, test leads and accessories before every use. Do not
use any damaged part.
• Never ground yourself when taking measurements. Do not touch
exposed circuit elements or test probe tips.
• Do not operate the instrument in an explosive atmosphere.
• Exercise extreme caution when: measuring voltage >20 V // current >10
mA // AC power line with inductive loads // AC power line during
electrical storms // current, when the fuse blows in a circuit with open
circuit voltage > 450 V // servicing CRT equipment.
• Remove test leads from circuit before opening the case.
• Always measure current in series with the load – NEVER ACROSS a
voltage source.
2
Symbols Used in this Manual
N Battery W Refer to the manual
T Double insulated X Dangerous Voltage
F Direct Current J Earth Ground
B Alternating Current R Audible tone
Complies with EU
P
directives
I Fuse
Turning the Meter On and Off
• Press the SELECT button for approximately 2 seconds to turn the meter
on.
• To turn the meter off, press the SELECT button until the display goes
blank.
Underwriter Laboratories,
>
Inc.
3
Making Measurements
All measurements described in this manual use the Red test lead for
positive (+) polarity and Black test lead for Ground reference (-) unless
otherwise specified
AutoTect mode is the default function when the meter is first turned on.
Press the SELECT button momentarily to select and step through the
functions:
• AutoTect
• Continuity
• EF
• ACV
• DCV
• Ω
• Hz
• Cx
• AutoTect
4
