Metcraft-Powersoak PS-200 Installation Manual

PS-200

INSTALLATION GUIDE

ATTENTION INSTALLATION CREW:

Please review and refer to the following instructions prior to installing

the Power Soak warewashing system.

This installation should only be performed by licensed and certified

plumbers and electricians and all work should conform to all local, state

and national regulatory agency requirements.

Power Soak Systems Inc.

903 East 104th Street

Suite 130

Kansas City, Mo 64131

800-444-9624
816-761-3250

816-761-0544 (fax)

www.powersoak.com

Part #: 29222

Rev: 1

1. If not already installed, have a licensed and certified electrician install the proper
electrical service for the new Power Soak® system. The chart below shows the
different configurations for all available systems. Use the provided tables to
determine the appropriate breaker (overcurrent protection) and wire size for the
system's dedicated electrical service.

IMPORTANT: USE COPPER CONDUCTORS ONLY.

Power Soak® Systems with Heaters

Minimum

Minimum

HP Phase Hz

1.5 1 60 208 8 50
2 1 60 208 8 50

1.5 3 60 208 10 30
2 3 60 208 10 30
3 3 60 208 8 40
5 3 60 208 8 40

1.5 1 60 230 8 50
2 1 60 230 8 50

1.5 3 60 230 10 30
2 3 60 230 10 30
3 3 60 230 8 40
5 3 60 230 8 40

1.5 3 60 480 14 15
2 3 60 480 14 15
3 3 60 480 12 20
5 3 60 480 12 20

1.5 1 50 220 8 40
2 1 50 220 8 50

1.5 3 50 380 10 30
2 3 50 380 10 30
3 3 50 380 10 30

System
Voltage

Supply

Conductor

(AWG)

Overcurrent

Protective

Device

(Amps)

5 3 50 380 10 30

Part #: 29222

Rev: 1
