Metapace S-62 User Manual

Disclaimer

Metapace reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice, and the reader should in all cases consult Metapace to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Metapace.

Metapace shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Metapace.

Microsoft® Windows® is a trademark or registered trademark of Microsoft Corporation. Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies and are the property of their respective owners.

Table of Contents

Wincor Nixdorf Terminal Default Settings....................2-8

Wincor Nixdorf Beetle™ Terminal Default Settings.....2-8

Keyboard Country Layout............................................2-9

Keyboard Style ..........................................................2-15

Keyboard Conversion ................................................2-17

Control Character Output...........................................2-17

Keyboard Modifiers....................................................2-18

RS232 Baud Rate......................................................2-20

RS232 Word Length: Data Bits, Stop Bits,

and Parity ................................................................2-21

RS232 Receiver Time-Out.........................................2-22

RS232 Handshaking..................................................2-22

RS232 Timeout.................................................... 2-23

XON/XOFF ..........................................................2-23

ACK/NAK .............................................................2-23

Scanner to Bioptic Communication............................2-24

Scanner-Bioptic Packet Mode .............................2-24

Scanner-Bioptic ACK/NAK Mode......................... 2-25

Scanner-Bioptic ACK/NAK Timeout.....................2-25

Chapter 3 - Input/Output Settings

Power Up Beeper ........................................................3-1

Wincor Nixdorf Terminal Default Settings....................2-8

Wincor Nixdorf Beetle™ Terminal Default Settings.....2-8

Keyboard Country Layout............................................2-9

Keyboard Style ..........................................................2-15

Keyboard Conversion ................................................2-17

Control Character Output...........................................2-17

Keyboard Modifiers....................................................2-18

RS232 Baud Rate......................................................2-20

RS232 Word Length: Data Bits, Stop Bits,

and Parity ................................................................2-21

RS232 Receiver Time-Out.........................................2-22

RS232 Handshaking..................................................2-22

RS232 Timeout.................................................... 2-23

XON/XOFF ..........................................................2-23

ACK/NAK .............................................................2-23

Scanner to Bioptic Communication............................2-24

Scanner-Bioptic Packet Mode .............................2-24

Scanner-Bioptic ACK/NAK Mode......................... 2-25

Scanner-Bioptic ACK/NAK Timeout.....................2-25

Chapter 3 - Input/Output Settings

Power Up Beeper ........................................................3-1

Beep on BEL Character...............................................3-1

Trigger Click.................................................................3-1

Good Read and Error Indicators..................................3-2

Beeper – Good Read............................................. 3-2

Beeper Volume – Good Read................................ 3-2

Beeper Pitch – Good Read.................................... 3-3

Beeper Pitch – Error ..............................................3-3

Beeper Duration – Good Read ..............................3-3

LED – Good Read .................................................3-4

Number of Beeps – Good Read ............................3-4

Number of Beeps – Error.......................................3-4

Good Read Delay ..................................................3-5

User-Specified Good Read Delay.......................... 3-5

Manual Trigger Mode...................................................3-5

LED Illumination - Manual Trigger............................... 3-6

LED Illumination - Manual Trigger............................... 3-6

In-Stand Sensor Mode ................................................ 3-6

Presentation Mode ...................................................... 3-7

LED Illumination - Presentation Mode......................... 3-7

Presentation Sensitivity......................................... 3-8

Presentation Centering.......................................... 3-8

Chapter 1 - Getting Started

About This Manual .............

......................................... 1-1

Unpacking Your Device......

......................................... 1-1

Connecting the Device ................................................ 1-1

Connecting with USB ............................................ 1-1

Table of Contents

1-1 1-1 1-2 1-2

Chapter 1 - Getting Started

About This Manual ...................................................... 1-1

Unpacking Your Device............................................... 1-1

Connecting the Device ................................................ 1-1

Connecting with USB ............................................ 1-1

Connecting with Keyboard Wedge........................ 1-2

Reading Techniques ..........

......................................... 1-3

Menu Bar Code Security Se

ttings ............................... 1-3

Setting Custom Defaults ......

....................................... 1-4

Resetting the Custom Defaults ................................... 1-4

Resetting the Factory Defaults.................................... 1-5

Chapter 2 - Programming the Interface

Introduction ..................

............................................... 2-1

Programming the Interface - Plug and Play ................ 2-1

Table of Contents

1-6 1-6 1-7 1-7 1-8

2-1 2-1

Chapter 1 - Getting Started

About This Manual ...................................................... 1-1

Unpacking Your Device............................................... 1-1

Connecting the Device ................................................ 1-1

Connecting with USB ............................................ 1-1

Connecting with Keyboard Wedge........................ 1-2

Reading Techniques ................................................... 1-3

Menu Bar Code Security Settings ............................... 1-3

Setting Custom Defaults ............................................. 1-4

Resetting the Custom Defaults ................................... 1-4

Resetting the Factory Defaults.................................... 1-5

Chapter 2 - Programming the Interface

Introduction ................................................................. 2-1

Programming the Interface - Plug and Play ................ 2-1

Keyboard Wedge ........................................................ 2-1

Laptop Direct Connect ................................................ 2-1

USB IBM SurePos....................................................... 2-2

USB PC or Macintosh Keyboard................................. 2-2

USB HID...........................

........................................... 2-3

Keyboard Country Layout ........................................... 2-4

Table of Contents

2-4 2-4 2-5 2-9

LED Illumination - Manual Trigger............................... 3-6

In-Stand Sensor Mode ................................................ 3-6

Presentation Mode ...................................................... 3-7

LED Illumination - Presentation Mode......................... 3-7

Presentation Sensitivity......................................... 3-8

Presentation Centering.......................................... 3-8

CodeGate

®

................................................................ 3-10

Mobile Phone Read Mode......................................... 3-11

Hands Free Time-Out ............................................... 3-11

Reread Delay ............................................................ 3-11

User-Specified Reread Delay.................................... 3-12

Scanner Time-Out..................................................... 3-12

Centering................................................................... 3-13

No Read .................................................................... 3-14

LED Illumination - Manual Trigger............................... 3-6

In-Stand Sensor Mode ................................................ 3-6

Presentation Mode ...................................................... 3-7

LED Illumination - Presentation Mode......................... 3-7

Presentation Sensitivity......................................... 3-8

Presentation Centering.......................................... 3-8

CodeGate

®

................................................................ 3-10

Mobile Phone Read Mode......................................... 3-11

Hands Free Time-Out ............................................... 3-11

Reread Delay ............................................................ 3-11

User-Specified Reread Delay.................................... 3-12

Scanner Time-Out..................................................... 3-12

Centering................................................................... 3-13

No Read .................................................................... 3-14

Video Reverse........................................................... 3-15

Working Orientation .................................................. 3-16

Chapter 4 - Data Editing

Prefix/Suffix Overview ................................................. 4-1

To Add a Prefix or Suffix: ...................................... 4-1

To Clear One or All Prefixes or Suffixes................ 4-2

To Add a Carriage Return Suffix

to All Symbologies ........................................... 4-3

Prefix Selections ......................................................... 4-3

Suffix Selections.......................................................... 4-4

Function Code Transmit.............................................. 4-4

Intercharacter, Interfunction,

and Intermessage Delays ......................................... 4-4

Intercharacter Delay.............................................. 4-5

User Specified Intercharacter Delay...................... 4-5

Interfunction Delay ................................................ 4-6

Intermessage Delay .............................................. 4-6

Chapter 5 - Data Formatting

Data Format Editor Introduction .................................. 5-1

Add a Data Format...................................................... 5-1

Other Programming Selections.............................. 5-3

Terminal ID Table ........................................................5-4

Data Format Editor Commands...................................5-4

Move Commands................................................... 5-5

Search Commands ................................................5-5

Miscellaneous Commands.....................................5-6

Data Formatter.............................................................5-7

Primary/Alternate Data Formats ..................................5-8

Other Programming Selections.............................. 5-3

Terminal ID Table ........................................................5-4

Data Format Editor Commands...................................5-4

Move Commands................................................... 5-5

Search Commands ................................................5-5

Miscellaneous Commands.....................................5-6

Data Formatter.............................................................5-7

Primary/Alternate Data Formats ..................................5-8

All Symbologies ...........................................................6-2

Message Length Description .......................................6-2

Codabar.......................................................................6-3

Codabar Concatenation......................................... 6-4

Code 39 .......................................................................6-6

Full ASCII............................................................... 6-8

Code 39 Code Page ..............................................6-9

Interleaved 2 of 5.......................................................6-10

NEC 2 of 5 .................................................................6-11

Code 93 .....................................................................6-13

Code 93 Code Page ............................................6-14

Straight 2 of 5 Industrial (three-bar start/stop)...........6-15

Straight 2 of 5 IATA (two-bar start/stop) ....................6-16

Matrix 2 of 5...............................................................6-17

Code 128 ...................................................................6-18

ISBT 128 Concatenation...................................... 6-18

Code 128 Code Page ..........................................6-19

GS1-128 ....................................................................6-20

Other Programming Selections.............................. 5-3

Terminal ID Table ........................................................5-4

Data Format Editor Commands...................................5-4

Move Commands................................................... 5-5

Search Commands ................................................5-5

Miscellaneous Commands.....................................5-6

Data Formatter.............................................................5-7

Primary/Alternate Data Formats ..................................5-8

All Symbologies ...........................................................6-2

Message Length Description .......................................6-2

Codabar.......................................................................6-3

Codabar Concatenation......................................... 6-4

Code 39 .......................................................................6-6

Full ASCII............................................................... 6-8

Code 39 Code Page ..............................................6-9

Interleaved 2 of 5.......................................................6-10

NEC 2 of 5 .................................................................6-11

Code 93 .....................................................................6-13

Code 93 Code Page ............................................6-14

Straight 2 of 5 Industrial (three-bar start/stop)...........6-15

Straight 2 of 5 IATA (two-bar start/stop) ....................6-16

Matrix 2 of 5...............................................................6-17

Code 128 ...................................................................6-18

ISBT 128 Concatenation...................................... 6-18

Code 128 Code Page ..........................................6-19

GS1-128 ....................................................................6-20

Telepen......................................................................6-21

UPC-A........................................................................6-22

UPC-A/EAN-13

with Extended Coupon Code...................................6-24

Coupon GS1 DataBar Output....................................6-25

UPC-E0......................................................................6-25

UPC-E1......................................................................6-28

EAN/JAN-13 ..............................................................6-28

ISBN Translate.................................................... 6-30

EAN/JAN-8................................................................ 6-31

MSI............................................................................ 6-33

GS1 DataBar Omnidirectional................................... 6-35

GS1 DataBar Limited ................................................ 6-35

GS1 DataBar Expanded............................................ 6-36

Codablock A.............................................................. 6-37

Codablock F .............................................................. 6-38

PDF417 ..................................................................... 6-39

MacroPDF417 ........................................................... 6-40

MicroPDF417 ............................................................ 6-40

UPC-E1......................................................................6-27

EAN/JAN-13 ..............................................................6-27

ISBN Translate ....................................................6-29

EAN/JAN-8 ................................................................6-30

MSI ............................................................................6-32

GS1 DataBar Omnidirectional ...................................6-34

GS1 DataBar Limited.................................................6-34

GS1 DataBar Expanded ............................................6-35

Codablock A ..............................................................6-36

Codablock F...............................................................6-37

PDF417......................................................................6-38

MacroPDF417............................................................6-39

MicroPDF417.............................................................6-39

GS1 Composite Codes..............................................6-40

UPC/EAN Version.............

...................................6-40

GS1 Emulation...........................................................6-41

TCIF Linked Code 39 (TLC39) ..................................6-42

QR Code..................................

..................................6-43

QR Code Page ....................................................6-44

Data Matrix ........................

........................................6-45

Data Matrix Code Page .......................................6-46

Aztec Code ........................

........................................6-47

Aztec Code Page...............

..................................6-48

Chinese Sensible (Han Xin)

Code.............................6-49

Postal Codes - Linear ................................................6-49

China Post (Hong Kong 2 of 5)............................6-49

Korea Post .....................

......................................6-51

Chapter 7 - Interface Keys

Keyboard Function Relationships................................7-1

Supported Interface Keys ............................................7-3

Chapter 8 - Utilities

To Add a Test Code I.D. Prefix to All

Symbologies.....................

.........................................8-1

Show Decoder Revision ..............................................8-1

6-41 6-41 6-42 6-43 6-44 6-45 6-46 6-47 6-48 6-49 6-50 6-50 6-50 6-52

7-1 7-3

Show Scan Driver Revision......................................... 8-1

Show Software Revision ......

....................................... 8-1

Show Data Format .............

......................................... 8-2

Test Menu ................................................................... 8-2

8-1 8-1 8-1 8-1 8-2 8-2

Show Scan Driver Revision......................................... 8-1

Show Software Revision ............................................. 8-1

Show Data Format ...................................................... 8-2

Test Menu ................................................................... 8-2

Chapter 9 - Product Specifications

Metapace S-62

Scanner Product Specifications ......... 9-1

Standard Cable Pinouts .....

......................................... 9-2

Show Scan Driver Revision......................................... 8-1

Show Software Revision ............................................. 8-1

Show Data Format ...................................................... 8-2

Test Menu ................................................................... 8-2

Chapter 9 - Product Specifications

Metapace S-62 Scanner Product Specifications ......... 9-1

Standard Cable Pinouts .............................................. 9-2

Keyboard Wedge................................................... 9-2

USB....................................................................... 9-3

9-1 9-1 9-1

Product Agency Compliance

Europe

The CE marking indicates compliance to 2004/108/EC EMC Directive with Standards EN55022 CLASS B, EN55024, EN61000-3-2, EN61000-3-3. In addition, complies to 2006/95/EC Low Voltage Directive, when shipped with recommended power supply.

Metapace shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.

Waste Electrical and Electronic Equipment Information

Metapace complies with Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE).

Show Scan Driver Revision......................................... 8-1

Show Software Revision ............................................. 8-1

Show Data Format ...................................................... 8-2

Test Menu ................................................................... 8-2

Chapter 9 - Product Specifications

Metapace S-62 Scanner Product Specifications ......... 9-1

Standard Cable Pinouts .............................................. 9-2

Keyboard Wedge................................................... 9-2

USB....................................................................... 9-3

.............................................................................. 9-4

Chapter 10 - Maintenance

Repairs...................................................................... 10-1

Maintenance.............................................................. 10-1

Cleaning the Device ............................................ 10-1

Inspecting Cords and Connectors....................... 10-1

Replacing Cables ...................................................... 10-1

Replacing an Interface Cable.............................. 10-2

Troubleshooting a Metapace S-62 Scanner .............. 10-2

Chapter 11 - Customer Support

Technical Assistance ................................................ 11-1

Appendix A - Reference Charts

Symbology Chart.........................................................A-1

ASCII Conversion Chart (Code Page 1252) ...............A-4

Code Page Mapping of Printed Bar Codes .................A-6

Unicode Key Maps ......................................................A-8

Product Agency Compliance

Europe

The CE marking indicates compliance to 2004/108/EC EMC Direc- tive with Standards EN55022 CLASS B, EN55024, EN61000-3-2, EN61000-3-3. In addition, complies to 2006/95/EC Low Voltage Directive, when shipped with recommended power supply.

Metapace shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.

Waste Electrical and Electronic Equipment Information

Metapace complies with Directive 2002/96/EC OF THE EUROPEAN PARLIA- MENT AND OF THE COUNCIL of 27 January 2003 on waste electrical and electronic equipment (WEEE).

This product has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment, if not properly disposed.

In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal. Those systems will reuse or recycle most of the materials of the product you are disposing in a sound way.

The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal.

If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration.

You may also contact your supplier for more information on the environmental performances of this product.

International

LED Safety Statement

The LED has been tested and classified as “EXEMPT RISK GROUP” to the standard: IEC 62471:2006.

CB Scheme

Required Safety Labels

Compliance Markings information, Part Number, and Serial Number information

1 Getting Started

1-1

1

Getting Started

About This Manual

This User’s Guide provides installation and programming instructions for the Metapace S-62 area-imaging scanner. Product specifications, dimensions, warranty, and customer support information are also included.

Metapace bar code scanners are factory programmed for the most common terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this guide.

An asterisk (*) next to an option indicates the default setting.

Unpacking Your Device

After you open the shipping carton containing the product, take the following steps:

• Check for damage during shipment. Report damage immediately to the carrier who delivered the carton.

• Make sure the items in the carton match your order.

• Save the shipping container for later storage or shipping.

1-2

Connecting the Device

Connecting with USB

A scanner can be connected to the USB port of a computer.

1. Connect the appropriate interface cable to the device first, then to the computer.

2. The scanner beeps.

3. Verify the scanner operation by scanning a bar code from the Sample

Symbols in the back of this manual.

The unit defaults to a USB PC Keyboard. Refer to page 2-4 for other USB terminal settings.

1

Getting Started

About This Manual

This User’s Guide provides installation and programming instructions for the Metapace S-62 area-imaging scanner. Product specifications, dimensions, warranty, and customer support information are also included.

Metapace bar code scanners are factory programmed for the most common termi- nal and communications settings. If you need to change these settings, pro- gramming is accomplished by scanning the bar codes in this guide.

An asterisk (*) next to an option indicates the default setting.

Unpacking Your Device

After you open the shipping carton containing the product, take the following steps:

• Check for damage during shipment. Report damage immediately to the carrier who delivered the carton.

• Make sure the items in the carton match your order.

• Save the shipping container for later storage or shipping.

Connecting the Device

Connecting with USB

A scanner can be connected to the USB port of a computer.

1. Connect the appropriate interface cable to the device first, then to the

computer.

2. The scanner beeps.

1-6

Reading Techniques

The scanner has a view finder that projects a bright red aiming beam that corresponds to the scanner’s horizontal field of view. The aiming beam should be centered over the bar code, but it can be positioned in any direction for a good read.

The aiming beam or pattern is smaller when the scanner is closer to the code and larger when it is farther from the code. Symbologies with smaller bars or elements (mil size) should be read closer to the unit. Symbologies with larger bars or elements (mil size) should be read farther from the unit. To read single or multiple symbols (on a page or on an object), hold the scanner at an appropriate distance from the target, press the button, and center the aiming beam or pattern on the symbol. If the code being scanned is highly reflective (e.g., laminated), it may be necessary to tilt the code up 15° to 18° to prevent unwanted reflection.

Menu Bar Code Security Settings

Metapace scanners are programmed by scanning menu bar codes or by sending serial commands to the scanner. If you want to restrict the ability to scan menu codes, you can use the Menu Bar Code Security settings. Please contact the nearest technical support office (see Customer Support on page 11-1) for further information.

Linear bar code

2D Matrix symbol

1-7

Setting Custom Defaults

You have the ability to create a set of menu commands as your own, custom defaults. To do so, scan the Set Custom Defaults bar code below before scannning the menu commands for your custom defaults. If a menu command requires scanning numeric codes from the back cover, then a Save code, that entire sequence will be saved to your custom defaults. When you have entered all the commands you want to save for your custom defaults, scan the Save Custom Defaults bar code.

You may have a series of custom settings and want to correct a single setting. To do so, just scan the new setting to overwrite the old one. For example, if you had previously saved the setting for Beeper Volume at Low to your custom defaults, and decide you want the beeper volume set to High, just scan the Set Custom Defaults bar code, then scan the Beeper Volume High menu code, and then Save Custom Defaults. The rest of the custom defaults will remain, but the beeper volume setting will be updated.

Resetting the Custom Defaults

If you want the custom default settings restored to your scanner, scan the Activate Custom Defaults bar code below. This is the recommended default bar

code for most users. It resets the scanner to the custom default settings. If there are no custom defaults, it will reset the scanner to the factory default settings. Any settings that have not been specified through the custom defaults will be defaulted to the factory default settings.

Save Custom Defaults

Set Custom Defaults

Activate Custom Defaults

1-8

Resetting the Factory Defaults

If you aren’t sure what programming options are in your scanner, or you’ve changed some options and want to restore the scanner to factory default settings, first scan the Remove Custom Defaults bar code, then scan Activate Defaults. This resets the scanner to the factory default settings.

This selection erases all your settings and resets the scanner to the original factory defaults. It also disables all plugins

.

!

Remove Custom Defaults

Activate Defaults

2-1

2 Programming the Interface

2

Programming the Interface

Introduction

This chapter describes how to program your system for the desired interface.

Programming the Interface - Plug and Play

Plug and Play bar codes provide instant scanner set up for commonly used interfaces.

Note: After you scan one of the codes, power cycle the host terminal to have

the interface in effect.

2-4

USB IBM SurePos

Scan one of the following “Plug and Play” codes to program the scanner for an IBM SurePos (USB handheld scanner) or IBM SurePos (USB tabletop scanner) interface.

Note: After scanning one of these codes, you must power cycle the cash

register.

Each bar code above also programs the following suffixes for each symbology:

USB PC or Macintosh Keyboard

Scan one of the following codes to program the scanner for USB PC Keyboard or USB Macintosh Keyboard. Scanning these codes also adds a CR and LF.

Symbology Suffix Symbology Suffix

EAN 8 0C Code 39 00 0A 0B EAN 13 16 Interleaved 2 of 5 00 0D 0B UPC A 0D Code 128 00 18 0B UPC E 0A Code 39 00 0A 0B

USB IBM SurePos

(USB Handheld Scanner)

Interface

USB IBM SurePos

(USB Tabletop Scanner)

Interface

U

S

B

K

e

y

b

o

a

r

d

(

P

C

)

USB Keyboard (Mac)

USB Japanese Keyboard (PC)

2-5

USB HID

Scan the following code to program the scanner for USB HID bar code scanners.

2-9

Keyboard Country Layout

Scan the appropriate country code below to program the keyboard layout for your country or language. As a general rule, the following characters are supported, but need special care for countries other than the United States: @ | $ # { } [ ] = / ‘ \ < > ~

* United States

United States (Dvorak left)

United States (International)

Albania

Azeri (Cyrillic)

Azeri (Latin)

Belarus

Belgium

United States (Dvorak)

United States (Dvorak right)

Bosnia

Brazil

2-10

Keyboard Country (continued)

Bulgaria (Latin)

Canada (French)

Canada (Multilingual)

Croatia

Czech

Czech (Programmers)

Czech (QWERTY)

Czech (QWERTZ)

Bulgaria (Cyrillic)

Canada (French legacy)

Brazil (MS)

Denmark

Dutch (Netherlands)

2-11

Keyboard Country (continued)

Finland

Gaelic

Germany

Greek

Greek (220 Latin)

Greek (220)

Greek (319 Latin)

Greek (319)

Faeroese

France

Estonia

Greek (Latin)

Greek (MS)

2-12

Keyboard Country (continued)

Italian (142)

Hungarian (101 key)

Iceland

Irish

Italy

Japan ASCII

Kazakh

Kyrgyz (Cyrillic)

Hebrew

Hungary

Greek (Polytonic)

Latin America

Latvia

2-13

Keyboard Country (continued)

Lithuania (IBM)

Malta

Mongolian (Cyrillic)

Norway

Poland

Polish (214)

Polish (Programmers)

Portugal

Lithuania

Macedonia

Latvia (QWERTY)

Romania

Russia

2-14

SCS

Serbia (Latin)

Slovakia

Slovakia (QWERTY)

Slovakia (QWERTZ)

Slovenia

Spain

Spanish variation

Russian (Typewriter)

Serbia (Cyrillic)

Russian (MS)

Sweden

Switzerland (French)

2-15

Keyboard Country (continued)

Keyboard Style

This programs keyboard styles, such as Caps Lock and Shift Lock. If you have used Keyboard Conversion settings, they will override any of the following Key- board Style settings.

Default = Regular.

Turkey F

Ukrainian

United Kingdom

United Stated (Dvorak right)

United States (Dvorak left)

United States (Dvorak)

United States (International)

Uzbek (Cyrillic)

Tatar

Turkey Q

Switzerland (German)

2-16

Regular is used when you normally have the Caps Lock key off.

Caps Lock

is used when you normally have the Caps Lock key on.

Shift Lock

is used when you normally have the Shift Lock key on (not common

to U.S. keyboards).

Automatic Caps Lock is used if you change the Caps Lock key on and off. The software tracks and reflects if you have Caps Lock on or off . This selection can only be used with systems that have an LED that notes the Caps Lock status (AT keyboards).

Autocaps via NumLock

bar code should be scanned in countries (e.g., Germany, France) where the Caps Lock key cannot be used to toggle Caps Lock. The NumLock option works similarly to the regular Autocaps, but uses the NumLock key to retrieve the current state of the Caps Lock.

* Regular

Caps Lock

Shift Lock

Automatic Caps Lock

Autocaps via NumLock

2-17

Emulate External Keyboard should be scanned if you do not have an external keyboard (IBM AT or equivalent).

Note: After scanning the Emulate External Keyboard bar code, you must power

cycle your computer.

Keyboard Conversion

Alphabetic keyboard characters can be forced to be all upper case or all lowercase. So if you have the following bar code: “abc569GK,” you can make the output “ABC569GK” by scanning Convert All Characters to Upper Case, or to “abc569gk” by scanning Convert All Characters to Lower Case.

These settings override Keyboard Style selections.

Note: If your interface is a keyboard wedge, first scan the menu code for

Automatic Caps Lock (page 2-16). Otherwise, your output may not be as

expected.

Default = Keyboard Conversion Off

.

Control Character Output

This selection sends a text string instead of a control character. For example, when the control character for a carriage return is expected, the output would display [CR] instead of the ASCII code of 0D. Refer to ASCII Conversion Chart

(Code Page 1252) on page A-4. Only codes 00 through 1F are converted (the

first column of the chart).

Note: Control + ASCII Mode overrides this mode.

Emulate External Keyboard

* Keyboard Conversion Off

Convert All Characters

to Upper Case

Convert All Characters

to Lower Case

2-18

Default = Off.

Keyboard Modifiers

This modifies special keyboard features, such as CTRL+ ASCII codes and Turbo Mode.

Control + ASCII Mode On: The scanner sends key combinations for ASCII control characters for values 00-1F. Windows is the preferred mode. All keyboard country codes are supported. DOS mode is a legacy mode, and it does not support all keyboard country codes. New users should use the Windows mode. Refer to Keyboard Function Relationships, page 7-1 for CTRL+ ASCII Values.

Windows Mode Prefix/Suffix Off: The scanner sends key combinations for ASCII control characters for values 00-1F, but it does not transmit any prefix or suffix information.

Default = Control + ASCII Mode Off.

Control Character Output On

* Control Character Output Off

Windows Mode Control + ASCII

Mode On

* Control + ASCII Mode Off

DOS Mode Control + ASCII Mode

On

Windows Mode Prefix/Suffix Off

2-19

Turbo Mode: The scanner sends characters to a terminal faster. If the terminal

drops characters, do not use Turbo Mode.

Default = Off

Numeric Keypad Mode: Sends numeric characters as if entered from a numeric keypad.

Default = Off

Automatic Direct Connect Mode: This selection can be used if you have an IBM AT style terminal and the system is dropping characters.

Default = Off

Turbo Mode On

* Turbo Mode Off

Numeric Keypad Mode On

* Numeric Keypad Mode Off

Automatic Direct Connect Mode

On

* Automatic Direct Connect

Mode Off

3-1

3 Input/Output Setting

Input/Output Settings

Power Up Beeper

The scanner can be programmed to beep when it’s powered up. Scan the Off bar code(s) if you don’t want a power up beep.

Default = Power Up Beeper On

- Scanner.

Beep on BEL Character

You may wish to force the scanner to beep upon a command sent from the host. If you scan the Beep on BEL On bar code below, the scanner will beep every time a BEL character is received from the host.

Default = Beep on BEL Off.

Trigger Click

To hear an audible click every time the scanner button is pressed, scan the Tri g ger Click On bar code below. Scan the Trigger Click Off code if you don’t

wish to hear the click. (This feature has no effect on serial or automatic triggering.)

Default = Trigger Click Off.

Power Up Beeper Off -

Scanner

* Power Up Beeper On -

Scanner

*Beep on BEL Off

Beep on BEL On

Trigger Click On

*Trigger Click Off

3-2

Good Read and Error Indicators

Beeper – Good Read

The beeper may be programmed On or Off in response to a good read. Turning this option off, only turns off the beeper response to a good read indication. All error and menu beeps are still audible.

Default = Beeper -

Good Read On.

Beeper Volume – Good Read

The beeper volume codes modify the volume of the beep the scanner emits on a good read.

Default = High.

* Beeper - Good Read On

Beeper - Good Read Off

* High

Medium

Off

Low

3-3

Beeper Pitch – Good Read

The beeper pitch codes modify the pitc

h (frequency) of the beep the scan-

ner emits on a good read.

Default = Medium.

Beeper Pitch – Error

The beeper pitch codes modify the pitch (frequency) of

the sound the scan-

ner emits when there is a bad read or error.

Default = Razz.

Beeper Duration – Good Read

The beeper duration codes modify the

length of the beep the scanner emits

on a good read.

Default = Normal.

Low (1600 Hz)

* Medium (2400 Hz)

High (4200 Hz)

* Razz (250 Hz)

Medium (3250 Hz)

High (4200 Hz)

* Normal Beep

Short BeepShort Beep

3-4

LED – Good Read

The LED indicator can be programmed On or Off in response to a good read.

Default = On.

Number of Beeps – Good Read

The number of beeps of a good read can be programmed from 1 - 9. The same number of beeps will be applied to the beeper and LED in response to a good read. For example, if you program this option to have five beeps, there will be five beeps and five LED flashes in response to a good read. The beeps and LED flashes are in sync with one another. To change the number of beeps, scan the bar code below and then scan a digit (1-9) bar code and the Save bar code on the Programming Chart inside the back cover of this manual.

Default = 1.

Number of Beeps – Error

The number of beeps and LED flashes emitted by the scanner for a bad read or error can be programmed from 1 - 9. For example, if you program this option to have five error beeps, there will be five error beeps and five LED flashes in response to an error. To change the number of error beeps, scan the bar code below and then scan a digit (1-9) bar code and the Save bar code on the Programming Chart inside the back cover of this manual.

Default = 1.

* LED - Good Read On

LED - Good Read Off

Number of Good Read Beeps/LED Flashes

Number of Error Beeps/LED Flashes

3-5

Good Read Delay

This sets the minimum amount of time before the scanner can read another bar code.

Default = 0 ms (No Delay).

User-Specified Good Read Delay

If you want to set your own length for the good read delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save.

Manual Trigger Mode

When in manual trigger mode, the scanner scans until a bar code is read, or until the button is released.

Default = Manual Trigger-Normal.

* No Delay

Short Delay (500 ms)

Medium Delay (1,000 ms)

Long Delay (1,500 ms)

User-Specified Good Read Delay

* Manual Trigger - Normal

3-6

LED Illumination - Manual Trigger

If you wish to set the illumination LED brightness, scan one of the bar codes below. This sets the LED illumination for the scanner when the trigger is pressed.

Default = High.

Note: The LEDs are like a flash on a camera. The lower the ambient light in the

room, the brighter the LEDs need to be so the scanner can “see” the bar codes.

Off

Low

Medium

Medium High

* High

3-7

Presentation Mode

Presentation Mode uses ambient light to detect bar codes. The LED dims until a bar code is presented to the scanner, then the LED brightens to read the code. If the light level in the room is not high enough, Presentation Mode may not work properly.

LED Illumination - Presentation Mode

If you wish to set the illumination LED brightness, scan one of the bar codes below. This sets the LED illumination for the scanner when it is in Presentation Mode. (If the scanner is triggered manually, the LED illumination will switch to the setting for a manual trigger. See LED Illumination - Manual Trigger on page 3-6.)

Default = High.

Note: The LEDs are like a flash on a camera. The lower the ambient light in the

room, the brighter the LEDs need to be so the scanner can “see” the bar codes.

Presentation Mode

Off

Low

Medium

* High

3-8

Presentation Sensitivity

Presentation Sensitivity is a numeric range that increases or decreases the scanner's reaction time to bar code presentation. To set the sensitivity, scan the Sensitivity bar code, then scan the degree of sensitivity (from 0-

20) from the inside back cover, and Save. 0 is the most sensitive setting, and 20 is the least sensitive.

Default = 1.

Presentation Centering

Use Presentation Centering to narrow the scanner’s field of view when it is in the stand to make sure the scanner reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, Presentation Centering will insure that only the desired codes are read.

Note: To adjust centering when the scanner is hand-held, see

Centering (page 3-13).

If a bar code is not touched by a predefined window, it will not be decoded or output by the scanner. If Presentation Centering is turned on by scanning Presentation Centering On, the scanner only reads codes that pass through the centering window you specify using the Top of Presentation Centering Window, Bottom of Presentation Centering Window, Left, and Right of Presentation Centering Window bar codes.

Sensitivity

3-9

In the example below, the white box is the centering window. The centering window has been set to 20% left, 30% right, 8% top, and 25% bottom. Since Bar Code 1 passes through the centering window, it will be read. Bar Code 2 does not pass through the centering window, so it will not be read.

Note: A bar code needs only to be touched by the centering window in

order to be read. It does not need to pass completely through the centering window.

0

Bar Code 1

Bar Code 2

10 20 30 40 50 60 70 80 90 100%

100

90

80

70

60

50

40

30

20

10

0%

3-10

Scan Presentation Centering On, then scan one of the following bar codes to change the top, bottom, left, or right of the centering window. Then scan the percent you want to shift the centering window using digits on the inside back cover of this manual. Scan Save.

Default Presentation

Centering = 40% for Top and Left, 60% for Bottom and Right.

CodeGate

®

When CodeGate is On, the button is used to allow decoded data to be transmit- ted to the host system. The scanner remains on, scanning and decoding bar codes, but the bar code data is not transmitted until the button is pressed. When CodeGate is Off, bar code data is transmitted when it is decoded.

Default = CodeGate Off Out-of-Stand.

Left of

Presentation Centering

Window

Top of Presentation Centering

Window

Right of Presentation Centering

Window

Bottom of Presentation

Centering Window

* Presentation Centering Off

Presentation Centering On

CodeGate On

Out-of-Stand

* CodeGate Off

Out-of-Stand

3-11

Mobile Phone Read Mode

When this mode is selected, your scanner is optimized to read bar codes from mobile phone or other LED displays. However, the speed of scanning printed bar codes may be slightly lower when this mode is enabled.

Note: To turn off Mobil Phone Read Mode, scan the Manual Trigger Mode bar

code (see page 3-5).

Hands Free Time-Out

The Scan Stand and Presentation Modes are referred to as “hands free” modes. If the scanner’s button is pressed when using a hands free mode, the scanner changes to manual trigger mode. You can set the time the scanner should remain in manual trigger mode by setting the Hands Free Time-Out. Once the time-out value is reached, (if there have been no further button presses) the scanner reverts to the original hands free mode.

Scan the Hands Free Time-Out bar code, then scan the time-out duration (from 0-300,000 milliseconds) from the inside back cover, and Save.

Default =

5,000 ms.

Reread Delay

This sets the time period before the scanner can read the

same

bar code a second time. Setting a reread delay protects against accidental rereads of the same bar code. Longer delays are effective in minimizing accidental rereads.

Hand Held Scanning - Mobile

Phone

Presentation Scanning -

Mobile Phone

Hands Free Time-Out

3-12

Use shorter delays in applications where repetitive bar code scanning is required. Reread Delay only works when in Presentation Mode (see page 3-7).

Default = Medium.

User-Specified Reread Delay

If you want to set your own length for the reread delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save.

Scanner Time-Out

Scanner Time-Out powers down the scanner after the unit has been idle for the specified time. To prevent the scanner from powering down, set this time-out to

0. Scan Scanner Time-Out, then set the time-out by scanning digits (from 0 999,999 ms) from the inside back cover, then scanning Save.

Default = 1 ms.

Short (500 ms)

* Medium (750 ms)

Long (1000 ms)

Extra Long (2000 ms)

User-Specified Reread Delay

Scanner Time-Out

3-13

Centering

Use Centering to narrow the scanner’s field of view to make sure that when the scanner is hand-held, it reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, centering will insure that only the desired codes are read.

Note: To adjust centering when the scanner is in the stand, see Presentation

Centering (page 3-8).

If a bar code is not touched by a predefined window, it will not be decoded or output by the scanner. If centering is turned on by scanning Centering On, the scanner only reads codes that pass through the centering window you specify using the Top of Centering Window, Bottom of Centering Window, Left, and Right of Centering Window bar codes.

In the example below, the white box is the centering window. The centering window has been set to 20% left, 30% right, 8% top, and 25% bottom. Since Bar Code 1 passes through the centering window, it will be read. Bar Code 2 does not pass through the centering window, so it will not be read.

Note: A bar code needs only to be touched by the centering window in order to

be read. It does not need to pass completely through the centering window.

0

Bar Code 1

Bar Code 2

10 20 30 40 50 60 70 80 90 100%

100

90

80

70

60

50

40

30

20

10

0%

3-14

Scan Centering On, then scan one of the following bar codes to change the top, bottom, left, or right of the centering window. Then scan the percent you want to shift the centering window using digits on the inside back cover of this manual. Scan Save.

Default Centering = 40% for Top and Left, 60% for Bot-

tom and Right.

No Read

With No Read turned On, the scanner notifies you if a code cannot be read.

Default = Off.

If you want a different notation than “NR,” for example, “Error,” or “Bad Code,” you can edit the output message (see Data Formatting beginning on page 5-1). The hex code for the No Read symbol is 9C.

Left of Centering Window

Top of Centering Window

Right of Centering Window

Bottom of Centering Window

* Centering Off

Centering On

On

* Off

4-1

4 Data Editing





Prefix/Suffix Overview

When a bar code is scanned, additional information is sent to the host computer along with the bar code data. This group of bar code data and additional, user-defined data is called a “message string.” The selections in this section are used to build the user-defined data into the message string.

Prefix and Suffix characters are data characters that can be sent before and after scanned data. You can specify if they should be sent with all symbologies, or only with specific symbologies.



Points to Keep In Mind

• It is not necessary to build a message string. The selections in this chapter are only used if you wish to alter the default settings.

Default

prefix = None. Default suffix = None

.

• A prefix or suffix may be added or cleared from one symbology or all symbologies.

• You can add any prefix or suffix from the ASCII Conversion Chart (Code

Page 1252), beginning on page A-4, plus Code I.D. and AIM I.D.

• You can string together several entries for several symbologies at one time.

• Enter prefixes and suffixes in the order in which you want them to appear on the output.

• When setting up for specific symbologies (as opposed to all symbologies), the specific symbology ID value counts as an added prefix

or suffix character.

• The maximum size of a prefix or suffix configuration is 200 characters, which includes header information.

To Add a Prefix or Suffix:

Step 1. Scan the Add Prefix or Add Suffix symbol (page 4-3).

Step 2. Determine the 2 digit Hex value from the Symbology Chart

(included in the Symbology Chart, beginning on page A-1) for the

Prefix

Scanned Data

Suffix

1-11 alpha numeric & control characters

variable length1-11 alpha numeric & control characters

4-2

symbology to which you want to apply the prefix or suffix. For example, for Code 128, Code ID is “j” and Hex ID is “6A”.

Step 3. Scan the 2 hex digits from the Programming Chart inside the back

cover of this manual or scan 9, 9 for all symbologies.

Step 4. Determine the hex value from the ASCII Conversion Chart (Code

Page 1252), beginning on page A-4, for the prefix or suffix you wish

to enter.

Step 5. Scan the 2 digit hex value from the Programming Chart inside the

back cover of this manual.

Step 6. Repeat Steps 4 and 5 for every prefix or suffix character. Step 7. To add the Code I.D., scan 5, C, 8, 0.

To add AIM I.D., scan 5, C, 8, 1. To add a backslash (\), scan 5, C, 5, C.

Note: To add a backslash (\) as in Step 7, you must scan 5C twice – once

to create the leading backslash and then to create the backslash itself.

Step 8. Scan Save to exit and save, or scan Discard to exit without saving. Repeat Steps 1-6 to add a prefix or suffix for another symbology.

Example: Add a Suffix to a specific symbology

To send a CR (carriage return)Suffix for U.P.C. only:

Step 1. Scan Add Suffix. Step 2. Determine the 2 digit hex value from the Symbology Chart

(included in the Symbology Chart, beginning on page A-1) for U.P.C..

Step 3. Scan 6, 3 from the Programming Chart inside the back cover of this

manual.

Step 4. Determine the hex value from the ASCII Conversion Chart (Code

Page 1252), beginning on page A-4, for the CR (carriage return).

Step 5. Scan 0, D from the Programming Chart inside the back cover of this

manual.

Step 6. Scan Save, or scan Discard to exit without saving.

To Clear One or All Prefixes or Suffixes

You can clear a single prefix or suffix, or clear all prefixes/suffixes for a symbology. If you have been entering prefixes and suffixes for single symbologies, you can use Clear One Prefix (Suffix) to delete a specific char- acter from a symbology. When you Clear All Prefixes (Suffixes), all the prefixes or suffixes for a symbology are deleted.

4-3

Step 1. Scan the Clear One Prefix or Clear One Suffix symbol. Step 2. Determine the 2 digit Hex value from the Symbology Chart

(included in the Symbology Chart, beginning on page A-1) for the symbology from which you want to clear the prefix or suffix.

Step 3. Scan the 2 digit hex value from the Programming Chart inside the

back cover of this manual or scan 9, 9 for all symbologies.

Your change is automatically saved.

To Add a Carriage Return Suffix to All Symbologies

Scan the following bar code if you wish to add a carriage return suffix to all symbologies at once. This action first clears all current suffixes, then programs a carriage return suffix for all symbologies.

Prefix Selections

Add CR Suffix

All Symbologies

Add Prefix

Clear One Prefix

Clear All Prefixes

4-4

Suffix Selections

Function Code Transmit

When this selection is enabled and function codes are contained within the scanned data, the scanner transmits the function code to the terminal. Charts of these function codes are provided in Supported Interface Keys starting on

page 7-3. When the scanner is in keyboard wedge mode, the scan code is con-

verted to a key code before it is transmitted.

Default = Enable.

Intercharacter, Interfunction, and Intermessage Delays

Some terminals drop information (characters) if data comes through too quickly. Intercharacter, interfunction, and intermessage delays slow the transmission of data, increasing data integrity.

Add Suffix

Clear One Suffix

Clear All Suffixes

* Enable

Disable

4-5

Intercharacter Delay

An intercharacter delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each character of scanned data. Scan the Intercharacter Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Intercharacter Delay bar code, then set the number of delays to 0. Scan the Save bar code using the Programming

Chart inside the back cover of this manual.

Note: Intercharacter delays are not supported in USB serial emulation.

User Specified Intercharacter Delay

An intercharacter delay of up to 5000 milliseconds (in 5ms increments) may be placed after the transmission of a particular character of scanned data. Scan the Delay Length bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

Next, scan the Character to Trigger Delay bar code, then the 2-digit hex value for the ASCII character that will trigger the delay ASCII Conversion

Chart (Code Page 1252), beginning on page A-4.

To remove this delay, scan the Delay Length bar code, and set the number of delays to 0. Scan the Save bar code using the Programming Chart inside the back cover of this manual.

1 2345

Intercharacter Delay

Prefix Scanned Data Suffix

Intercharacter Delay

Delay Length

Character to Trigger Delay

4-6

Interfunction Delay

An interfunction delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each segment of the message string. Scan the Interfunction Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Interfunction Delay bar code, then set the number of delays to 0. Scan the Save bar code using the Programming

Chart inside the back cover of this manual.

Intermessage Delay

An intermessage delay of up to 5000 milliseconds (in 5ms increments) may be placed between each scan transmission. Scan the Intermessage Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Intermessage Delay bar code, then set the number of delays to 0. Scan the Save bar code using the Programming

Chart inside the back cover of this manual.

Interfunction Delays

Prefix Scanned Data Suffix

1 2345STX HT CR LF

Interfunction Delay

2nd Scan Transmission1st Scan Transmission

Intermessage Delay

Intermessage Delay

5-1

5 Data Formating

5

Data Formatting

Data Format Editor Introduction

You may use the Data Format Editor to change the scanner’s output. For example, you can use the Data Format Editor to insert characters at certain points in bar code data as it is scanned. The selections in the following pages are used only if you wish to alter the output.

Default Data Format setting = None.

Normally, when you scan a bar code, it gets outputted automatically; however when you create a format, you must use a “send” command (see Send

Commands on page 5-4) within the format program to output data.

Multiple formats may be programmed into the scanner. They are stacked in the order in which they are entered. However, the following list presents the order in which formats are applied:

1. Specific Terminal ID, Actual Code ID, Actual Length

2. Specific Terminal ID, Actual Code ID, Universal Length

3. Specific Terminal ID, Universal Code ID, Actual Length

4. Specific Terminal ID, Universal Code ID, Universal Length

5. Universal Terminal ID, Actual Code ID, Actual Length

6. Universal Terminal ID, Actual Code ID, Universal Length

7. Universal Terminal ID, Universal Code ID, Actual Length

8. Universal Terminal ID, Universal Code ID, Universal Length

The maximum size of a data format configuration is 2000 bytes, which includes header information.

If you have changed data format settings, and wish to clear all formats and return to the factory defaults, scan the Default Data Format code below.

Add a Data Format

Step 1. Scan the Enter Data Format symbol (page 5-2). Step 2. Select Primary/Alternate Format

Determine if this will be your primary data format, or one of 3 alternate formats. This allows you to save a total of 4 different data formats. To program your primary format, scan 0 using the Programming Chart inside the back cover of this manual. If you are programming an alternate format, scan 1, 2, or 3, depending on which alternate format

* Default Data Format

5-2

you are programming. (See Primary/Alternate Data Formats on page 5-8 for further information.)

Step 3. Terminal Type

Refer to Terminal ID Table (page 5-4) and locate the Terminal ID number for your PC. Scan three numeric bar codes on the inside back cover to program the scanner for your terminal ID (you must enter 3 digits). For example, scan 0 0 3 for an AT wedge.

Note: The wildcard for all terminal types is 099.

Step 4. Code I.D.

In the Symbology Chart, beginning on page A-1, find the symbology to which you want to apply the data format. Locate the Hex value for that symbology and scan the 2 digit hex value from the Programming Chart inside the back cover of this manual.

Note: If you are creating a data format for Batch Mode Quantity, use 35

for the Code I.D.

Step 5. Length

Specify what length (up to 9999 characters) of data will be acceptable for this symbology. Scan the four digit data length from the

Programming Chart inside the back cover of this manual. (Note: 50

characters is entered as 0050. 9999 is a universal number, indicating all lengths.)

Step 6. Editor Commands

Refer to Data Format Editor Commands (page 5-4). Scan the symbols that represent the command you want to enter. 94 alphanumeric characters may be entered for each symbology data format.

Step 7. Scan Save to save your data format, or Discard to exit without saving

your changes.

Enter Data Format

Save

Discard

5-3

Other Programming Selections

Clear One Data Format

This deletes one data format for one symbology. If you are clearing the primary format, scan 0 from the Programming Chart inside the back cover of this manual. If you are clearing an alternate format, scan 1, 2, or 3, depending on the format you are clearing. Scan the Terminal Type and Code I.D. (see Symbology Chart on page A-1), and the bar code data length for the specific data format that you want to delete. All other formats remain unaffected.

Clear all Data Formats

This clears all data formats.

Save to exit and save your data format changes. Discard to exit without saving any data format changes.

Clear One Data Format

Clear All Data Formats

Save

Discard

5-4

Data Format Editor Commands

Send Commands

Send all characters

F1 Include in the output message all of the characters from the input

message, starting from current cursor position, followed by an insert character.

Syntax = F1xx

where xx stands for the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Send a number of characters

F2 Include in the output message a number of characters followed by an

insert character. Start from the current cursor position and continue for “nn” characters or through the last character in the input message, followed by character “xx.”

Syntax = F2nnxx

where nn stands for the numeric value (00-99) for the number of characters, and xx stands for the the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Send all characters up to a particular character

F3 Include in the output message all characters from the input message,

starting with the character at the current cursor position and continuing to, but not including, the search character “ss,” followed by an insert character. The cursor is moved forward to the “ss” character.

Syntax

= F3ssxx

where ss stands for the search character’s hex value for its

Terminal ID Table

Terminal Model(s)

Terminal

ID

IBM PC/AT and compatibles

003

USB SurePOS Handheld Scanner

128

USB SurePOS Tabletop Scanner

129

RS232 True

000

TTL

000

USB Serial

130

PC Keyboard

124

Mac Keyboard

125

Japanese Keyboard (PC)

134

HID POS

131

5-5

ASCII code, and xx stands for the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Send all but the last characters

E9 Include in the output message all but the last “nn” characters, starting

from the current cursor position. The cursor is moved forward to one position past the last input message character included.

Syntax = E9nn

where nn stands for the numeric value (00-99) for the number of characters that will not be sent at the end of the message.

Insert a character multiple times

F4 Send “xx” character “nn” times in the output message, leaving the

cursor in the current position.

Syntax = F4xxnn

where xx stands for the insert character’s hex value for its ASCII code, and nn is the numeric value (00-99) for the number of times it should be sent. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Move Commands

Move the cursor forward a number of characters

F5 Move the cursor ahead “nn” characters from current cursor position.

Syntax = F5nn

where nn is the numeric value (00-99) for the number

of characters the cursor should be moved ahead.

Move the cursor backward a number of characters

F6 Move the cursor back “nn” characters from current cursor position.

Syntax = F6nn

where nn is the numeric value (00-99) for the number

of characters the cursor should be moved back.

Move the cursor to the beginning

F7 Move the cursor to the first character in the input message.

Syntax =

F7.

Move the cursor to the end

EA Move the cursor to the last character in the input message.

Syntax =

EA.

Search Commands

Search forward for a character

F8 Search the input message forward for “xx” character from the current

cursor position, leaving the cursor pointing to the “xx” character.

Syntax

= F8xx

where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

5-6

Search backward for a character

F9 Search the input message backward for “xx” character from the current

cursor position, leaving the cursor pointing to the “xx” character.

Syntax = F9xx

where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Search forward for a non-matching character

E6 Search the input message forward for the first non-“xx” character from

the current cursor position, leaving the cursor pointing to the non-“xx” character.

Syntax = E6xx

where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Search backward for a non-matching character

E7 Search the input message backward for the first non-“xx” character

from the current cursor position, leaving the cursor pointing to the non“xx” character.

Syntax = E7xx

where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Miscellaneous Commands

Suppress characters

FB Suppress all occurrences of up to 15 different characters, starting at the

current cursor position, as the cursor is advanced by other commands. When the FC command is encountered, the suppress function is terminated. The cursor is not moved by the FB command. Syntax = FBnnxxyy . .zz where nn is a count of the number of suppressed characters in the list, and xxyy .. zz is the list of characters to be suppressed.

Stop suppressing characters

FC Disables suppress filter and clear all suppressed characters.

Syntax =

FC.

Replace characters

E4 Replaces up to 15 characters in the output message, without moving

the cursor. Replacement continues until the E5 command is encountered.

Syntax = E4nnxx1xx2yy1yy2...zz1zz

2

where nn is the

total count of of the number of characters in the list (characters to be replaced plus replacement characters); xx

1

defines characters to be

replaced and xx

2

defines replacement characters, continuing through

zz

1

and zz2.

5-7

Stop replacing characters

E5 Terminates character replacement.

Syntax = E5.

Compare characters

FE Compare the character in the current cursor position to the character

“xx.” If characters are equal, move the cursor forward one position.

Syntax = FExx

where xx stands for the comparison character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-4 for decimal, hex and character codes.

Check for a number

EC Check to make sure there is an ASCII number at the current cursor

position. The format is aborted if the character is not numeric.

Check for non-numeric character

ED Check to make sure there is a non-numeric ASCII character at the

current cursor position. The format is aborted if the character is numeric.

Insert a delay

EF Inserts a delay of up to 49,995 milliseconds (in multiples of 5), starting

from the current cursor position. Syntax = EFnnnn where nnnn stands for the delay in 5ms increments, up to 9999. This command can only be used with keyboard emulation.

Data Formatter

When Data Formatter is turned Off, the bar code data is output to the host as read, including prefixes and suffixes.

You may wish to require the data to conform to a data format you have created and saved. The following settings can be applied to your data format:

Data Formatter On, Not Required, Keep Prefix/Suffix

Scanned data is modified according to your data format, and prefixes and suffixes are transmitted.

Data Format Required, Keep Prefix/Suffix

Scanned data is modified according to your data format, and prefixes and suffixes are transmitted. Any data that does not match your data format requirements generates an error tone and the data in that bar code is not transmitted.

Data Formatter Off

5-8

Default = Data Formatter On, Not Required, Keep Prefix/Suffix.

Primary/Alternate Data Formats

You can save up to four data formats, and switch between these formats. Your primary data format is saved under 0. Your other three formats are saved under 1, 2, and 3. To set your device to use one of these formats, scan one of the bar codes below.

* Data Formatter On,

Not Required,

Keep Prefix/Suffix

Data Format Required,

Keep Prefix/Suffix

Primary Data Format

Data Format 1

Data Format 2

Data Format 3

6-1

6 Symbologies

6

Symbologies

This programming section contains the following menu selections. Refer to

Chapter 9 for settings and defaults.

• All Symbologies • Interleaved 2 of 5

• Aztec Code • Korea Post

• China Post (Hong Kong 2 of 5) • Matrix 2 of 5

• Chinese Sensible (Han Xin) Code • MicroPDF417

• Codabar • MSI

• Codablock A • NEC 2 of 5

• Codablock F • Postal Codes - Linear

• Code 128 • PDF417

• Code 39 • GS1 DataBar Omnidirectional

• Code 93 • QR Code

• Data Matrix

• Straight 2 of 5 IATA (two-bar start/ stop)

• EAN/JAN-13

• Straight 2 of 5 Industrial (three-bar start/stop)

• EAN/JAN-8 • TCIF Linked Code 39 (TLC39)

• GS1 Composite Codes • Telepen

• GS1 DataBar Expanded • UPC-A

• GS1 DataBar Limited

• UPC-A/EAN-13 with Extended

Coupon Code

• GS1 DataBar Omnidirectional • UPC-E0

• GS1 Emulation • UPC-E1

• GS1-128

6-2

All Symbologies

If you want to decode all the symbologies allowable for your scanner, scan the

All Symbologies On

code. If on the other hand, you want to decode only a particular symbology, scan All Symbologies Off followed by the On symbol for that particular symbology.

Note: When All Symbologies On is scanned, 2D Postal Codes are not enabled.

2D Postal Codes must be enabled separately.

Message Length Description

You are able to set the valid reading length of some of the bar code symbologies. If the data length of the scanned bar code doesn’t match the valid reading length, the scanner will issue an error tone. You may wish to set the same value for minimum and maximum length to force the scanner to read fixed length bar code data. This helps reduce the chances of a misread.

EXAMPLE: Decode only those bar codes with a count of 9-20 characters.

Min. length = 09Max. length = 20

EXAMPLE: Decode only those bar codes with a count of 15 characters.

Min. length = 15Max. length = 15

For a value other than the minimum and maximum message length defaults, scan the bar codes included in the explanation of the symbology, then scan the digit value of the message length and Save bar codes on the Programming

Chart inside the back cover of this manual. The minimum and maximum

lengths and the defaults are included with the respective symbologies.

All Symbologies On

All Symbologies Off

6-3

Codabar

<Default All Codabar Settings>

Codabar On/Off

Codabar Start/Stop Characters

Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters.

Default = Don’t Transmit

.

Codabar Check Character

Codabar check characters are created using different “modulos.” You can program the scanner to read only Codabar bar codes with Modulo 16 check characters.

Default = No Check Character.

No Check Character

indicates that the scanner reads and transmits bar

code data with or without a check character. When Check Character is set to

Validate and Transmit

, the scanner will only read Codabar bar codes printed with a check character, and will transmit this character at the end of the scanned data.

* On

Off

Transmit

* Don’t Transmit

6-4

When Check Character is set to

Validate, but Don’t Transmit

, the unit will

only read Codabar bar codes printed

with

a check character, but will not

transmit the check character with the scanned data.

Codabar Concatenation

Codabar supports symbol concatenation. When you enable concatenation, the scanner looks for a Codabar symbol having a “D” start character, adjacent to a symbol having a “D” stop character. In this case the two messages are concatenated into one with the “D” characters omitted.

Select Require to prevent the scanner from decoding a single “D” Codabar symbol without its companion. This selection has no effect on Codabar symbols without Stop/Start D characters.

* No Check Character

Validate Modulo 16

and Transmit

Validate Modulo 16, but

Don’t Transmit

A1234D

D5678A

On

* Off

Require

6-5

Codabar Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = 60.

Minimum Message Length

Maximum Message Length

6-6

Code 39

< Default All Code 39 Settings >

Code 39 On/Off

Code 39 Start/Stop Characters

Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters.

Default =

Don’t Transmit.

Code 39 Check Character

No Check Character indicates that the scanner reads and transmits bar

code data with or without a check character. When Check Character is set to Validate, but Don’t Transmit, the unit

only reads Code 39 bar codes printed with a check character, but will not transmit the check character with the scanned data.

* On

Off

Transmit

* Don’t Transmit

6-7

When Check Character is set to Validate and Transmit, the scanner only reads Code 39 bar codes printed with a check character, and will transmit this character at the end of the scanned data.

Default = No Check Charac-

ter.

Code 39 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 0-48. Minimum Default = 0, Maximum Default = 48.

Code 39 Append

This function allows the scanner to append the data from several Code 39 bar codes together before transmitting them to the host computer. When the scanner encounters a Code 39 bar code with the append trigger char-

* No Check Character

Validate and Transmit

Validate, but Don’t Transmit

Minimum Message Length

Maximum Message Length

6-8

acter(s), it buffers Code 39 bar codes until it reads a Code 39 bar code that does not have the append trigger. The data is then transmitted in the order in which the bar codes were read (FIFO).

Default = Off.

Full ASCII

If Full ASCII Code 39 decoding is enabled, certain character pairs within the bar code symbol will be interpreted as a single character. For example: $V will be decoded as the ASCII character SYN, and /C will be decoded as the ASCII character #.

Default = Off

.

NUL %U DLE $P

SP SPAC E

00@ %V PP‘ %W p +P

SOH $A

DC1 $Q ! /A 11 AAQQ a +A q +Q

STX $B

DC2 $R “ /B 22BBRR b +B r +R

ETX $C

DC3 $S # /C 33CC SSc +C s +S

EOT $D

DC4 $T $ /D 44DDTT d +D t +T

ENQ $E

NAK $U % /E 55 EEUU e +E u +U

ACK $F

SYN $V & /F 66 FF VVf +F v +V

BEL $G

ETB $W ‘ /G 77GGWW g +G w +W

BS $H

CAN $X ( /H 88 HH XXh +H x +X

HT $I

EM $Y ) /I 99IIYY i +I y +Y

LF $J

SUB $Z * /J : /Z JJZZ j +J z +Z

VT $K

ESC %A + /K ; %F KK[ %K k +K { %P

FF $L

FS %B , /L < %G LL\ %L l +L | %Q

CR $M

GS %C -- = %H MM ] %M m +M } %R

SO $N

RS %D .. > %I NN^ %N n +N ~ %S

SI $O

US %E / /O ? %J OO_ %O o +O DEL %T

* Off

On

6-9

Character pairs /M and /N decode as a minus sign and period respectively. Character pairs /P through /Y decode as 0 through 9.

Code 39 Code Page

Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting. If this is the case, scan the bar code below, select the code page with which the bar codes were created (see Code Page Mapping of Printed Bar Codes on page A-6), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly.

* Full ASCII Off

Full ASCII On

Code 39 Code Page

6-10

Interleaved 2 of 5

< Default All Interleaved 2 of 5 Settings >

Interleaved 2 of 5 On/Off

Check Digit

No Check Digit indicates that the scanner reads and transmits bar code

data with or without a check digit. When Check Digit is set to Validate, but Don’t Transmit, the unit only

reads Interleaved 2 of 5 bar codes printed with a check digit, but will not transmit the check digit with the scanned data.

When Check Digit is set to Validate and Transmit, the scanner only reads Interleaved 2 of 5 bar codes printed with a check digit, and will transmit this digit at the end of the scanned data.

Default = No Check Digit.

* On

Off

Validate, but Don’t Transmit

* No Check Digit

Validate and Transmit

6-11

Interleaved 2 of 5 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80.

NEC 2 of 5

< Default All NEC 2 of 5 Settings >

NEC 2 of 5 On/Off

Check Digit

No Check Digit indicates that the scanner reads and transmits bar code

data with or without a check digit. When Check Digit is set to Validate, but Don’t Transmit, the unit only

reads NEC 2 of 5 bar codes printed with a check digit, but will not transmit the check digit with the scanned data.

Minimum Message Length

Maximum Message Length

* On

Off

6-12

When Check Digit is set to Validate and Transmit, the scanner only reads NEC 2 of 5 bar codes printed with a check digit, and will transmit this digit at the end of the scanned data.

Default = No Check Digit.

NEC 2 of 5 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80.

* No Check Digit

Validate and Transmit

Validate, but Don’t Transmit

Minimum Message Length

Maximum Message Length

6-13

Code 93

< Default All Code 93 Settings >

Code 93 On/Off

Code 93 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = 80.

Code 93 Append

This function allows the scanner to append the data from several Code 93 bar codes together before transmitting them to the host computer. When this function is enabled, the scanner stores those Code 93 bar codes that start with a space (excluding the start and stop symbols), and does not immediately transmit the data. The scanner stores the data in the order in

* On

Off

Minimum Message Length

Maximum Message Length

6-14

which the bar codes are read, deleting the first space from each. The scanner transmits the appended data when it reads a Code 93 bar code that starts with a character other than a space.

Default = Off.

Code 93 Code Page

Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting. If this is the case, scan the bar code below, select the code page with which the bar codes were created (see Code Page Mapping of Printed Bar Codes on page A-6), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly.

* Off

On

Code 93 Code Page

6-15

Straight 2 of 5 Industrial (three-bar start/stop)

<Default All Straight 2 of 5 Industrial Settings>

Straight 2 of 5 Industrial On/Off

Straight 2 of 5 Industrial Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-48. Minimum Default = 4, Maximum Default = 48.

On

* Off

Minimum Message Length

Maximum Message Length

6-16

Straight 2 of 5 IATA (two-bar start/stop)

<Default All Straight 2 of 5 IATA Settings>

Straight 2 of 5 IATA On/Off

Straight 2 of 5 IATA Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-48. Minimum Default = 4, Maximum Default = 48.

* Off

On

Minimum Message Length

Maximum Message Length

6-17

Matrix 2 of 5

<Default All Matrix 2 of 5 Settings>

Matrix 2 of 5 On/Off

Matrix 2 of 5 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-80. Minimum Default = 4, Maximum Default = 80.

On

* Off

Maximum Message Length

Minimum Message Length

6-18

Code 128

<Default All Code 128 Settings>

Code 128 On/Off

ISBT 128 Concatenation

In 1994 the International Society of Blood Transfusion (ISBT) ratified a standard for communicating critical blood information in a uniform manner. The use of ISBT formats requires a paid license. The ISBT 128 Application Specification describes 1) the critical data elements for labeling blood products, 2) the current recommendation to use Code 128 due to its high degree of security and its space-efficient design, 3) a variation of Code 128 that supports concatenation of neighboring symbols, and 4) the standard layout for bar codes on a blood product label. Use the bar codes below to turn concatenation on or off.

Default =Off.

* On

Off

* Off

On

6-19

Code 128 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = 80.

Code 128 Append

This function allows the scanner to append the data from several Code 128 bar codes together before transmitting them to the host computer. When the scanner encounters a Code 128 bar code with the append trigger character(s), it buffers Code 128 bar codes until it reads a Code 128 bar code that does not have the append trigger. The data is then transmitted in the order in which the bar codes were read (FIFO).

Default = Off.

Code 128 Code Page

Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting. If this is the case, scan the bar code below, select the code page with which the bar codes were created (see Code Page Mapping of Printed Bar Codes on page A-6), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly.

Minimum Message Length

Maximum Message Length

* Off

On

Code 128 Code Page

6-20

GS1-128

<Default All GS1-128 Settings>

GS1-128 On/Off

GS1-128 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-80. Minimum Default = 1, Maximum Default = 80.

* On

Off

Minimum Message Length

Maximum Message Length

6-23

UPC-A Number System

The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it.

Default = On.

UPC-A Addenda

This selection adds 2 or 5 digits to the end of all scanned UPC-A data.

Default = Off for both 2 Digit and 5 Digit Addenda.

UPC-A Addenda Required

When

Required

is scanned, the scanner will only read UPC-A bar codes that have addenda. You must then turn on a 2 or 5 digit addenda listed on

page 6-23.

Default = Not Required.

Off

* On

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* Not Required

Required

6-24

GS1 Composite Code Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-2435. Minimum Default = 1, Maximum Default = 2435.

GS1 Emulation

The scanner can automatically format the output from any GS1 data carrier to emulate what would be encoded in an equivalent GS1-128 or GS1 DataBar symbol. GS1 data carriers include UPC-A and UPC-E, EAN-13 and EAN-8, ITF-14, GS1-128, and GS1-128 DataBar and GS1 Composites. (Any application that accepts GS1 data can be simplified since it only needs to recognize one data carrier type.)

If GS1-128 Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8, EAN13) are expanded out to 16 digits. If the AIM ID is enabled, the value will be the GS1-128 AIM ID, ]C1 (see Symbology Chart on page A-1).

If GS1 DataBar Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8, EAN13) are expanded out to 16 digits. If the AIM ID is enabled, the value will be the GS1-DataBar AIM ID, ]e

m

(see Symbology Chart on page A-1).

If GS1 Code Expansion Off is scanned, retail code expansion is disabled, and UPC-E expansion is controlled by the UPC-E0 Expand (page 6-26) setting. If the AIM ID is enabled, the value will be the GS1-128 AIM ID, ]C1 (see

Symbology Chart on page A-1).

If EAN8 to EAN13 Conversion is scanned, all EAN8 bar codes are converted to EAN13 format.

Maximum Message Length

Minimum Message Length

6-25

Coupon GS1 DataBar Output

If you scan coupons that have both UPC and GS1 DataBar codes, you may wish to scan and output only the data from the GS1 DataBar code. Scan the GS1 Output On code below to scan and output only the GS1 DataBar code data.

Default = GS1 Output Off.

UPC-E0

<Default All UPC-E Settings>

UPC-E0 On/Off

Most U.P.C. bar codes lead with the 0 number system. To read these codes, use the UPC-E0 On selection. If you need to read codes that lead with the 1 number system, use UPC-E1 (page 6-28).

Default = On.

* GS1 Output Off

GS1 Output On

* UPC-E0 On

UPC-E0 Off

6-26

UPC-E0 Expand

UPC-E Expand expands the UPC-E code to the 12 digit, UPC-A format.

Default = Off.

UPC-E0 Addenda Required

When Required is scanned, the scanner will only read UPC-E bar codes that have addenda.

Default = Not Required.

UPC-E0 Addenda Separator

When this feature is On, there is a space between the data from the bar code and the data from the addenda. When turned Off, there is no space.

Default = On.

On

* Off

* Not Required

Required

Off

* On

6-27

UPC-E0 Check Digit

Check Digit specifies whether the check digit should be transmitted at the end of the scanned data or not.

Default = On.

UPC-E0 Number System

The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it. To prevent transmission, scan Off.

Default = On.

UPC-E0 Addenda

This selection adds 2 or 5 digits to the end of all scanned UPC-E data.

Default = Off for both 2 Digit and 5 Digit Addenda.

Off

* On

Off

* On

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

6-28

UPC-E1

Most U.P.C. bar codes lead with the 0 number system. For these codes, use

UPC-E0 (page 6-25). If you need to read codes that lead with the 1 number

system, use the UPC-E1 On selection.

Default = Off.

EAN/JAN-13

<Default All EAN/JAN Settings>

EAN/JAN-13 On/Off

EAN/JAN-13 Check Digit

This selection allows you to specify whether the check digit should be transmitted at the end of the scanned data or not.

Default = On.

UPC-E1 On

* UPC-E1 Off

* On

Off

Off

* On

6-29

EAN/JAN-13 Addenda

This selection adds 2 or 5 digits to the end of all scanned EAN/JAN-13 data.

Default = Off for both 2 Digit and 5 Digit Addenda.

EAN/JAN-13 Addenda Required

When Required is scanned, the scanner will only read EAN/JAN-13 bar codes that have addenda.

Default = Not Required.

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* Not Required

Required

6-30

EAN/JAN-13 Addenda Separator

When this feature is On, there is a space between the data from the bar code and the data from the addenda. When turned Off, there is no space.

Default = On.

Note: If you want to enable or disable EAN13 with Extended Coupon Code,

refer to UPC-A/EAN-13 with Extended Coupon Code (page 6-24).

ISBN Translate

When On is scanned, EAN-13 Bookland symbols are translated into their equivalent ISBN number format.

Default = Off.

Off

* On

* Off

On

6-31

EAN/JAN-8

<Default All EAN/JAN-8 Settings>

EAN/JAN-8 On/Off

EAN/JAN-8 Check Digit

This selection allows you to specify whether the check digit should be transmitted at the end of the scanned data or not.

Default = On.

* On

Off

Off

* On

6-32

EAN/JAN-8 Addenda

This selection adds 2 or 5 digits to the end of all scanned EAN/JAN-8 data.

Default = Off for both 2 Digit and 5 Digit Addenda.

EAN/JAN-8 Addenda Required

When Required is scanned, the scanner will only read EAN/JAN-8 bar codes that have addenda.

Default = Not Required.

EAN/JAN-8 Addenda Separator

When this feature is On, there is a space between the data from the bar code and the data from the addenda. When turned Off, there is no space.

Default = On.

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* Not Required

Required

Off

* On

6-33

MSI

<Default All MSI Settings>

MSI On/Off

MSI Check Character

Different types of check characters are used with MSI bar codes. You can program the scanner to read MSI bar codes with Type 10 check characters.

Default = Validate Type 10, but Don’t Transmit.

When Check Character is set to Validate Type 10/11 and Transmit, the scanner will only read MSI bar codes printed with the specified type check character(s), and will transmit the character(s) at the end of the scanned data.

On

* Off

6-34

When Check Character is set to Validate Type 10/11, but Don’t Transmit, the unit will only read MSI bar codes printed with the specified type check character(s), but will not transmit the check character(s) with the scanned data.

MSI Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 4-48. Minimum Default = 4, Maximum Default = 48.

Validate Type 10 and Transmit

* Validate Type 10, but Don’t

Transmit

Validate 2 Type 10 Characters,

but Don’t Transmit

Validate 2 Type 10 Characters

and Transmit

Validate Type 10 then Type 11

Character, but Don’t Transmit

Validate Type 10 then

Type 11 Character and Transmit

Disable MSI Check Characters

Minimum Message Length

Maximum Message Length

6-35

GS1 DataBar Omnidirectional

< Default All GS1 DataBar Omnidirectional Settings >

GS1 DataBar Omnidirectional On/Off

GS1 DataBar Limited

< Default All GS1 DataBar Limited Settings >

GS1 DataBar Limited On/Off

* On

Off

* On

Off

6-36

GS1 DataBar Expanded

< Default All GS1 DataBar Expanded Settings >

GS1 DataBar Expanded On/Off

GS1 DataBar Expanded Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 4-74. Minimum Default = 4, Maximum Default = 74.

* On

Off

Minimum Message Length

Maximum Message Length

6-37

Codablock A

<Default All Codablock A Settings>

Codablock A On/Off

Codablock A Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-600. Minimum Default = 1, Maximum Default = 600.

On

* Off

Minimum Message Length

Maximum Message Length

6-38

Codablock F

<Default All Codablock F Settings>

Codablock F On/Off

Codablock F Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-2048. Minimum Default = 1, Maximum Default = 2048.

On

* Off

Minimum Message Length

Maximum Message Length

6-39

PDF417

< Default All PDF417 Settings >

PDF417 On/Off

PDF417 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-2750. Minimum Default = 1, Maximum Default = 2750.

* On

Off

Maximum Message Length

Minimum Message Length

6-40

MacroPDF417

MacroPDF417 is an implementation of PDF417 capable of encoding very large amounts of data into multiple PDF417 bar codes. When this selection is enabled, these multiple bar codes are assembled into a single data string.

Default = On.

MicroPDF417

< Default All MicroPDF417 Settings >

MicroPDF417 On/Off

* On

Off

* Off

On

6-41

MicroPDF417 Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-366. Minimum Default = 1, Maximum Default = 366.

GS1 Composite Codes

Linear codes are combined with a unique 2D composite component to form a new class called GS1 Composite symbology. GS1 Composite symbologies allow for the co-existence of symbologies already in use.

Default = Off.

UPC/EAN Version

Scan the

UPC/EAN Version On

bar code to decode GS1 Composite symbols that have a U.P.C. or an EAN linear component. (This does not affect GS1 Composite symbols with a GS1-128 or GS1 linear component.)

Default = UPC/EAN Version Off.

Note: If you scan coupons that have both UPC and GS1 DataBar codes, you

may wish to scan and output only the data from the GS1 DataBar code. See Coupon GS1 DataBar Output (page 6-25) for further information.

Maximum Message Length

Minimum Message Length

On

* Off

UPC/EAN Version On

* UPC/EAN Version Off

6-42

GS1 Composite Code Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-2435. Minimum Default = 1, Maximum Default = 2435.

GS1 Emulation

The scanner can automatically format the output from any GS1 data carrier to emulate what would be encoded in an equivalent GS1-128 or GS1 DataBar symbol. GS1 data carriers include UPC-A and UPC-E, EAN-13 and EAN-8, ITF-14, GS1-128, and GS1-128 DataBar and GS1 Composites. (Any application that accepts GS1 data can be simplified since it only needs to recognize one data carrier type.)

If GS1-128 Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8, EAN13) are expanded out to 16 digits. If the AIM ID is enabled, the value will be the GS1-128 AIM ID, ]C1 (see Symbology Chart on page A-1).

If GS1 DataBar Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8, EAN13) are expanded out to 16 digits. If the AIM ID is enabled, the value will be the GS1-DataBar AIM ID, ]e

m

(see Symbology Chart on page A-1).

If GS1 Code Expansion Off is scanned, retail code expansion is disabled, and UPC-E expansion is controlled by the UPC-E0 Expand (page 6-26) setting. If the AIM ID is enabled, the value will be the GS1-128 AIM ID, ]C1 (see

Symbology Chart on page A-1).

If EAN8 to EAN13 Conversion is scanned, all EAN8 bar codes are converted to EAN13 format.

Maximum Message Length

Minimum Message Length

6-43

Default = GS1 Emulation Off

.

TCIF Linked Code 39 (TLC39)

This code is a composite code since it has a Code 39 linear component and a MicroPDF417 stacked code component. All bar code readers are capable of reading the Code 39 linear component. The MicroPDF417 component can only be decoded if TLC39 On is selected. The linear component may be decoded as Code 39 even if TLC39 is off.

Default = Off.

GS1 DataBar Emulation

GS1-128 Emulation

* GS1 Emulation Off

GS1 Code Expansion Off

EAN8 to EAN13 Conversion

* Off

On

6-44

QR Code

< Default All QR Code Settings >

QR Code On/Off

This selection applies to both QR Code and Micro QR Code.

QR Code Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-7089. Minimum Default = 1, Maximum Default = 7089.

QR Code Append

This function allows the scanner to append the data from several QR Code bar codes together before transmitting them to the host computer. When the scanner encounters an QR Code bar code with the append trigger character(s), it buffers the number of QR Code bar codes determined by

* On

Off

Maximum Message Length

Minimum Message Length

6-45

information encoded in those bar codes. Once the proper number of codes is reached, the data is output in the order specified in the bar codes.

Default = On.

QR Code Page

QR Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting. If this is the case, scan the bar code below, select the code page with which the bar codes were created (see Code Page Mapping of Printed Bar Codes on page A-6), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly.

Off

* On

QR Code Page

6-46

Data Matrix

< Default All Data Matrix Settings >

Data Matrix On/Off

Data Matrix Message Length

Scan the bar codes below to change the message length. Refer to

Message Length Description (page 6-2) for additional information. Mini-

mum and Maximum lengths = 1-3116. Minimum Default = 1, Maximum Default = 3116.

Data Matrix Append

This function allows the scanner to append the data from several Data Matrix bar codes together before transmitting them to the host computer. When the scanner encounters an Data Matrix bar code with the append trigger character(s), it buffers the number of Data Matrix bar codes deter-

Off

* On

Maximum Message Length

Minimum Message Length
