Metal-Fach T703 Operating Manual

METAL-FACH Sp. z o.o.

16-100 Sokółka, ul. Kresowa 62

Tel. no. [phone]

Fax: [phone]

OPERATING MANUAL

FAR MING TR A ILER

TIPPER

Ty pe T703

Edition I – year 2009

Trailer data

Vehicle type: mono-axial farming truck trailer, tipper type

Commercial designation:

Type designation:

T703

Trailer identication number1/:

Trailer manufacturer: METAL-FACH Sp. z o.o.

16-100 Sokółka
ul. Kresowa 62
Tel. no. [phone]
Fax: [phone]

Sold by:

Address:

Tel. /Fax :

Date of delivery:

Owner / User: Name:

Address:

Tel. / Fax :

Hint: Note down the type and serial number of your trailer. Please supply this number every
time you contact your dealer.

1/

The data is found on the trailer nameplate located on the trailer right frame side member

CE DECLARATION OF CONFORMITY

FOR THE MACHINE

„METAL-FACH” Sp. z o.o.
ul. Kresowa 62

16-100 SOKÓŁKA

which acts as the manufacturer

declares under sole responsibility that the following machine:

Farming truck trailer

T703- .........................................

year of manufacture: ........................................

serial number: ...................................................

this declaration concerns, meets the following requirements:

- Directive 2006/42/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL

dated 17 May 2006 on machines and the Resolution of the Minister of Economy

of 21 October 2008 concerning general requirements for machinery (Journal of Laws,

issue 199 item 1228);

The following harmonised standards were used for compliance evaluation:

PN-EN ISO 1853+A1: 2009 PN-EN ISO 4254-1:2009

PN-EN ISO 13857:2010 PN-EN ISO 12100:2011

- and the following standards: PN-ISO 3600:1998, PN-ISO 11684:1998; and the Resolution of
the Ministry of Infrastructure of 31 December 2002 on technical requirements for vehicles

and the scope of their necessary equipment (Journal of Laws 2003, issue 32 item 262

as amended).

Safety Test Report no. ZE/56/09, MF/8/2010

Unit responsible for engineering documentation: METAL-FACH Engineering Department

This Declaration of Conformity becomes void and null if the machine design is changed

or modied in any manner without prior consent from the manufacturer.

Sokółka, 23.12.2010

President of the Management Board

Jacek Marek Kucharewicz

Operating instructions. T703 farming trailer 4

Nameplate

In all correspondence, questions, and warranty issues, please state the type and identication
number of the machine.

Nameplate

The identication data of the trailer is found on the nameplate located on the load body front
crosspiece. The serial number is stamped on the nameplate and underneath.

The manual consist a part of the trailer's equipment.

Operating instructions. T703 farming trailer 5

Table of Contents

1. INTRODUCTION ...................................................................................................................... 7

1.1. Intended use ................................................................................................................................ 7

1.2. Equipment ................................................................................................................................... 8

2. GENERAL SAFETY RULES..................................................................................................... 8

2.1. Symbols and nomenclature ......................................................................................................... 8

2.2. Obligatory notication ................................................................................................................ 8

2.3. General safety regulations of work and use ................................................................................ 8

2.3.1. Safety of operation ...................................................................................................................... 9

2.3.2. Tyres .......................................................................................................................................... 10

2.3.3. Hydraulic and pneumatic systems ............................................................................................. 10

2.3.4. Periodic maintenance .................................................................................................................11

2.3.5. Travelling on public roads .........................................................................................................11

2.4. Warning signs and text on the trailer ......................................................................................... 12

3. TECHNICAL CHARACTERISTICS ....................................................................................... 14

4. GENERAL DESCRIPTION OF DESIGN AND FUNCTION ................................................. 15

4.1. Chassis ...................................................................................................................................... 15

4.2. Load body ................................................................................................................................. 16

4.3. Load body hydraulic tipping mechanism .................................................................................. 16

4.4. Electrical system (signalling and warning) ............................................................................... 16

4.5. Support foot ............................................................................................................................... 17

4.6. Braking system .......................................................................................................................... 17

5. STORAGE, SALE AND SHIPPING TO USER ...................................................................... 18

6. OPERATION INFORMATION ................................................................................................ 19

6.1. Commissioning the trailer ......................................................................................................... 19

6.2. Loading the body ...................................................................................................................... 19

6.3. Travelling on public roads ........................................................................................................ 20

6.4. Unloading .................................................................................................................................. 20

6.5. Decoupling from the tractor ...................................................................................................... 21

7. SERVICING .............................................................................................................................. 22

7.1. Servicing instruction for adjustable trailer components ........................................................... 22

7.2. Brakes ........................................................................................................................................ 23

7.2.1. Brakes – servicing the brake pneumatic system ....................................................................... 23

7.2.2. Brakes – adjustment of the braking system components .......................................................... 23

7.3. Hydraulic system ....................................................................................................................... 24

7.3.1. Hydraulic system – servicing of the load body hydraulic tipping system ................................ 24

7.3.2. Hydraulic system – adjustment of the load body hydraulic tipping mechanism ...................... 24

7.4. Wheels – tyres ........................................................................................................................... 25

8. TROUBLESHOOTING ............................................................................................................ 25

9. PERIODIC MAINTENANCE .................................................................................................. 26

9.1. Lubrication ................................................................................................................................ 26

9.2. Maintenance and servicing ........................................................................................................ 27

10. DISPOSAL OF THE TRAILER ............................................................................................... 27

11. RESIDUAL RISKS ................................................................................................................... 28

11.1. Description of residual risks ..................................................................................................... 28

11.2. Assessment of residual risks ..................................................................................................... 28

Operating instructions. T703 farming trailer 6

1. INTRODUCTION

This manual describes operation and servicing of the T703 trailer.

These instructions contain the essential information only. Since a wide variety of loads
can be carried with this machine, the instructions does not touch all details of information,
especially concerning all possible cases of operation and maintenance.

If you require further information or particular problems arise which were not discussed in
detail in the operating instructions, you should request the information from the manufacturer
or the dealer. The crucial obligations of the manufacturer are stated in the warranty document
which species the complete and current regulations for warranty services.

METAL-FACH Sp. z o.o. reserves the right to introduce changes without prior notice
and without assuming any obligations resulting from those changes.

The T703 trailer has been designed for reliable and safe operation if used in accordance with
the operating instructions. Therefore, before commissioning the machine we request that the
users read the following manual for thorough understanding of specic issues.

All operators of this trailer must understand the contents

of the operating instructions before commencing work.

The aim is to follow the right operation method for the trailer, its safety of use and maximum
operating life. This is also the condition which ensures that your warranty rights are maintained.

The manual constitutes a part of the machine's equipment.

1.1. Intended use

The trailer is intended for transport of crops and other bulk or loose materials within a farm
and on public roads.

The trailer is unloaded manually or by tipping the load body to the rear or to the sides. The
trailer is designed for coupling with farming tractors of varying power ratings, equipped with a
external power hydraulic system, a power outlet for the electrical lighting and warning systems
and the braking system of hitched machines, and a transport hitch.

Do not use this trailer to carry fuel, gas cylinders and similar due to the compliance
requirements for transport of hazardous materials.

• Any use than indicated above is unintended use. Do not use the trailer to transport: fuel, gas

cylinders, or toxic materials that may cause environmental pollution. The manufacture shall

not be liable for any resulting damage as it is solely incurred by the owner.

• "Intended use" also includes compliance with the operating, servicing and maintenance

requirements established by the manufacturer.

• The trailer shall only be used by persons who have understood the operating manual and

who have been trained in hazards and rst aid for accident victims.

• Follow all applicable laws for accident prevention and any other recognised rules of

engineering safety, work medicine and road trafc safety.

• The manufacturer shall not be liable for damage from any unauthorised modications of this

trailer's design.

Operating instructions. T703 farming trailer 7

1.2. Equipment

The basic equipment of each trailer includes:

- the operating instructions manual;

- the warranty card with warranty conditions;

- the safety support;

- the two-line brake control system.

On customer's request the manufacturer can supply the trailer with the following optional
accessories (available at extra charge): the slow-moving vehicle sign, a single-line brake control
system, and the load body side board top sections (extensions).

2. GENERAL SAFETY RULES

2.1. Symbols and nomenclature

WA R N I NG!

IMPORTANT!

INFORMATION!

This warning sign in the operating instructions means that special
caution shall be exercised due to hazards to persons and potential
damage to the product.

Failure to comply with these guidelines may result in damage of
equipment or its components.
It is important to carefully follow these notes or guidelines.

Qualied persons are the persons who perform the required tasks by always using their
education, experience and training, as well as their understanding of standards, denitions,
accident prevention regulations and operating conditions; hence they are also capable of
identifying and avoiding potential hazards. Among others, these persons are also required to
understand rst aid measures for the injured (e.g. by wounding).

The term "operation" includes settings, starting (preparation for use) and operation (starting,
commissioning, powering off, etc.).

The term "maintenance of proper condition" includes checks and care (control, adjustments),
servicing and repairs (troubleshooting).

Pay attention to all the other (in particular the highlighted) indications for transport, assembly,
operation, servicing, technical data (in the operating instructions, production records and on the
machine itself). It is equally essential due to the potential (direct and indirect) hazards and their
consequences being severe damage of human health and property.

2.2. Obligatory notication

When the trailer is transferred to another user, the operating instructions shall be transferred
as well, whereas the receiving user must undergo training according to the instructions.

2.3. General safety regulations of work and use

Before each start of work, inspect the trailer for work safety.

1. Aside from the guidelines in these operating instructions, follow the current general

regulations for safety and accident prevention.

2. The afxed information and warning signs and text indicate important guidance for safe

operation. Follow it for your safety.

3. Start the trailer only when all required equipment is connected and secured from unintended

release or opening (e.g. the hitch and tow bar system, couplings, locks etc.).

4. Understand all equipment and controls, as well as their functions, before work.

Operating instructions. T703 farming trailer 8

5. The machine must not be used by persons who are: intoxicated, behave irresponsibly or

children (underage).

2.3.1. Safety of operation

1. All work safety information shall be given to all other users of the trailer.

2. Check the direct environment (for children and bystanders) before start. Pay particular

attention when visibility is poor.

3. Do not remain on the trailer in motion, when coupling the trailer with a tractor and when

loading or unloading the trailer.

4. After unloading the trailer, lower the load body completely. Never leave the trailer unattended

with its load body raised.

5. Enter the trailer only when it has completely stopped and with the tractor engine stopped.

6. Lift and lower the load body only from the driver's seat.

7. Hitch the trailer according to regulations, couple only with recommended equipment and

secure the tow bar hitch-ring to the tractor transport hitch.

8. Exercise extreme caution when coupling/decoupling the trailer with/from the tractor.

9. When installing and removing supports, security/safety equipment and ladders, this types of

equipment must always be positioned to ensure safety to operators.

10. Follow the maximum allowable axle loads, total weight and transport dimensions.

11. Do the following checks: coupling and functional test of brakes and lights, the slow-moving

vehicle sign, and other protective devices.

12. Do a functional test of lights and brakes before driving. Also prepare the trailer as

recommended in Section "Travelling on public roads".

13. Mind the changes in vehicle behaviour, steerability and braking efciency due to the hitched

trailer and its load.

14. When towing the trailer, mind the layout of loads and/or inertia, especially when the load is

unevenly distributed.

15. Bystanders must not enter the work zone of the trailer when it is working.

16. Do not remain within the range of discharged load.

17. Start the hydraulic lift (tipping) of the load body only when:

- the trailer is coupled with the tractor, AND

- the trailer is parked on a hard and level ground, AND

- when no persons remain in the unloading area, AND

- when the tractor's axis is aligned with the trailer, AND

- when the machines are at a safe distance from all power lines, AND

- there are no strong gusts of wind.
If it is necessary to unload from the rear while parked on a slope, the trailer with the tractor
must be in the uphill direction. If unloading to the side on a slope, tilt the load body in the
opposite to the trailer's direction of gradient.

18. During all work with the raised load body, secure it from falling with the support that has
been delivered with the trailer. Turn off the tractor engine and remove the ignition key.

19. Be careful to avoid crushing of ngers and hands during opening and closing of the load
body walls.

20. Mind the warnings of crush and cut hazard areas when starting the trailer to work. There is a
risk of injury when coupling/decoupling the trailer with/from the tractor. Due to that, do not
enter between the trailer and the tractor or stand behind the trailer if the trailer is not secured
with wheel chocks or the parking brake when coupling/decoupling.

Operating instructions. T703 farming trailer 9

21. Nobody is allowed to remain between the trailer and the tractor if the vehicle is not protected
against rolling by the parking brake and/or wheel chocks.

22. When parked, secure the tractor and the trailer from rolling.

23. Couple the trailer only with the upper hitch of a tractor that can transfer at least 11.5 kN of
load.

24. Do not drive with the lifted load body.

25. When raising the load body, maintain a safe distance from power lines. The C.2.30. sign acc.
to PN-ISO 11684:1998 on the front wall of the trailer warns of power lines.

26. During all servicing or repair works which require lifting the load body, the body must be
empty and secured with the mechanical support from accidental falling.

27. Always adapt your driving speed to the conditions. Avoid rapid turns when driving uphill
or downhill.

28. Maintain safe distance from the U-turn range of the tractor and trailer train.

29. Ensure adequate visibility (with the help of a signalling person, if necessary) when driving
in reverse.

30. Mind the inertia of the trailer when cornering.

31. Additional protection for the transported load on the trailer (chains, tarpaulin, plastic sheet,
nets, transport straps, etc.) may be applied only with tractor engine off and the ignition key
removed.

32. Remove functional disturbances of attachments only with the engine turned off and the
ignition key removed.

33. Enter the load body surface only after turning off the drive and stopping the tractor engine.
Remove the ignition key.

34. Always turn off the engine and remove the ignition key before exiting the tractor. Engage
the parking brake and secure the trailer with wheel chocks.

35. When travelling on public roads, the permissible axle load of the trailer must not exceed

37.2 KN.

36. The maximum permissible pressure of the hydraulic system is 16 MPa.

37. The maximum permissible pneumatic pressure of the single-line system is 0.63 MPa or 0.8
MPa for the two-line system.

38. Prepare the trailer for work (connect the pneumatic and hydraulic hoses, etc.) with the tractor
engine off and the ignition key removed.

39. The manufacturer delivers the trailer completely assembled.

2.3.2. Tyre s

1. Make sure to secure the trailer from accidental movement when servicing the tyres.

2. The wheels and tyres shall be repaired by trained personnel using adequate tools.

3. Regularly check the tire pressure. Follow the recommended pressure values.

4. Protect the tyres from sunlight during prolonged parking of the trailer.

5. Replace the wheels with the trailer empty, if possible.

2.3.3. Hydraulic and pneumatic systems

1. The hydraulic and pneumatic systems are under high pressure.

2. When connecting the hydraulic cylinder, follow the manufacturer's guidelines for connection
of hydraulic lines.

3. When connecting the hydraulic and pneumatic lines with the hydraulic and pneumatic
systems of the tractor, ensure that the valves on the tractor and the trailer are depressurised.

Operating instructions. T703 farming trailer 10

4. Periodically inspect the hydraulic and pneumatic connections. Replace all damaged and
aged parts immediately. Replace the lines as recommended in the manufacturer technical
requirements. Replace hoses/lines every ve years unless damage was found earlier.

5. When inspecting for leak sources, overload the hydraulic system for several seconds (leaking
of drops is not permitted).

6. The liquid (hydraulic oil) which escapes under high pressure may puncture the skin and
cause severe injury. Immediately seek medical attention if injured. There is a danger of
infection.

7. Before working on the hydraulic and/or pneumatic systems, depressurize the affected system
and turn off the engine.

8. All repair work on the hydraulic and pneumatic systems may only be performed by specialist
services of METAL-FACH Sokółka or its authorised representatives.

2.3.4. Periodic maintenance

1. All maintenance, repair and cleaning operations, as well as troubleshooting must be
performed after turning the drive and the tractor engine off. Remove the ignition key.

2. Inspect all bolts and nuts periodically and retighten if necessary. Replace regular bolts only
with the bolts of the same quality and strength ratings.

3. When servicing under the lifted and tipped AND unloaded load body, always secure the
body with the support supplied with the trailer.

4. Use proper tools and safety gloves when replacing any parts.

5. After completing your work, thoroughly clean the trailer to leave no remains of the load on
the body.

6. Isolate the continuous power supply before arc welding and/or working on the electrical
system.

7. The safety/protection equipment wears out, which requires periodic adjustments, inspection
and replacement when necessary.

8. Use only the original spare parts recommended by METAL-FACH Sokółka.

9. Store the trailer in sheltered areas (on level and hardened ground at best) and in a manner
which prevents injuries of people and animals.

10. Release all worn out parts to authorised recycling points in accordance with all applicable
environmental protection requirements.

2.3.5. Travelling on public roads

1. Before departing, check that the trailer lighting is working and that the trailer identication
is complete.

2. Follow the trafc code regulations when travelling on public roads.

3. Exceeding the permissible payload and driving speed may damage the trailer and compromise
trafc safety.

4. Do not exceed the permissible driving speed of 30 km/h.

5. The trailer is designed for operation at grades of 8o maximum.

6. When travelling on public roads, place a reective warning triangle on the trailer, and the
slow-moving vehicle sign in the trailer bracket located on the load body wall (included with
the trailer).

7. Do not leave the loaded trailer on slopes and when not protected against rolling. Secure the
trailer by engaging the parking brake and chocking the wheels.

Operating instructions. T703 farming trailer 11

2.4. Warning signs and text on the trailer

The warning signs and text on the trailer must not be removed. They are intended for safe

handling of the trailer. If any information label is damaged or removed, order a spare one. Text
and symbol label stickers are available at service agents or at the trailer manufacturer.

Table 1

Item

1 2 3 4

1 Read the operating instructions

2

3 Keep a safe distance from power lines

Safety symbol

(sign)

Meaning of the symbol (sign) or text

Turn off the engine and remove the ignition key before

servicing or repairs

Location on the

On the load

body frame front

crosspiece

On the load body

front crosspiece

On the load body

front crosspiece

trailer

4 Do not reach into the crushing area if the parts may move

5 Install the support before entering the hazardous area

6 Do not ride on the machine – use the passenger seat only

On side walls/

panels

On the chassis side

frame member, at

the support

On the load body

front wall

Operating instructions. T703 farming trailer 12

Table 1, continued

7 Keep a safe distance from the machine

8

9

10

Warning text on

11

the trailer

Do not stand on ladders and platforms while the tractor is

moving

Feet (toes) crushing hazard.

Force applied from above

Lifting point

"Couple with the tractor upper hitch only that is rated for 11.5

KN of load"

On the load body

front wall

At the ladder

At the support

On the chassis

frame side

members

On the load body

front wall

On the tow bar

12 11.5 kN max

Caution!

Do not perform any checks or servicing under the loaded or

tilted load body without the support

Caution!

Do not remain within the range of discharged loads

Do not enter the trailer when it is hauled

13 "Load capacity 3.5 t"

14 Maximum hydraulic system pressure: 16 MPa

15

16

17 Tyre pressure

Maximum pneumatic system pressure: 0.6 MPa, single-line

system; 0.8 MPa, two-line system

Approximate weight values of certain goods, see table in

section 5.3 on page 19

- "550 kPa" – 10.0/75-15.3 14PR tyres (MITAS and STARCO)

- "710 kPa" – 10.0/75-15.3 18PR tyres (MITAS)

- "500 kPa" – 10.0/75-15.3 18PR tyres (Trelleborg)

At the support

On the load body

front wall

On the load body

left and right wall

On the oor frame

front crosspiece

On the load body

front wall

On the load body

front wall

Over the wheels

INFORMATION! The trailer user is required to keep the warning symbols and text

on the trailer legible during its entire operating life. If damaged or
destroyed, replace with new ones.

Operating instructions. T703 farming trailer 13

3. TECHNICAL CHARACTERISTICS

T703 trailer Table 2

Item

no.

1. Vehicle type - farming truck trailer

2. Manufacturer - METAL-FACH Sp. z o.o.

3. Type (model) - T703

4. Body type - box type, tipper

5. Nameplate location - load body frame front crosspiece

6. S/N stamping location - on the nameplate and underneath

II Dimensions and weight

7. Length, mm 4802

8. Width, mm 2020

9. Height, mm

10. Number of axles, pcs. 1 (singe axle)

11. Wheel track, mm 1540

12. Front overhang, mm 3705

13. Rear overhang, mm 1097

14. Loading room size

- length, mm 3340

- width, mm 1892

- height, mm 500 or 1000

- load surface, m

- capacity, m

2

3

15. Loading surface height, mm 871

16. Tow bar hitch-ring height, mm 150 - 770

17. Tow bar hitch-ring diameter, mm 450

18. Vehicle ramp clearance, mm 290

19. Vehicle kerb weight, kg 1150

20. Permissible vehicle overall weight, kg: 4650

- per axle, kg 3800

- on the hitch, kg 850

21. Maximum axle load, kN

- per axle, kN 37. 2

- on the tow bar hitch-ring (hitch), kN 11.5

22. Permissible vehicle load capacity, kg 3500

23. Suspension type rigid, dependent, w/o suspension springs

V Wheels and tyres

24. Number of wheels, pcs. 2

25. Wheel disk size 9.0 0 x15.5

26. Tyre size and PR number 10.0/6075-15.5 14PR

- PR number 14 18 14 18

- tyre manufacturer MI TAS MI TAS STARCO Trelleborg

27. Tyre pressure, KPa 550 710 550 500

Contents

I General data

16-100 Sokółka, ul. Kresowa 62

1395 – without body side board top sections

1895 – with body side board top sections

6.3

3.2 or 6.3

IV Suspension

Operating instructions. T703 farming trailer 14

Table 2, continued

VI Braking system

28. Service brake;

- type mechanical, drum-type

- control pneumatic, positive pressure, two-line system (single-line
system available on request)

- no. of wheels operated 2 wheels

29. Parking brake

- type mechanical, drum-type

- control manual, by a screw gear

- operated components 2 wheels on the axle

VII Electrical system

30. Voltage rating, V 12, feed by the driving tractor

VIII Unloading mechanism

31. Mechanism type hydraulic

32. No. of actuators/members, pcs./pcs. 1 / 3

33. Maximum load body tilt angle, sideways /

34. Maximum system pressure, MPa 16

35. Hydraulic connection type ZSR-6-13/200 or acc. to PN-ISO 5675

36. Minimum U-turn diameter, left/right, mm 5160

37. Maximum speed, km/h 40

38. Other information:

o

back,

IX Operating data

X Additional information

- tractor hitch coupling upper or lower transport hitch

- driving tractor 25 kW minimum

- requirements for the driving tractor minimum load transferred by the hitch: 11.5 KN

45 / 50

4. GENERAL DESCRIPTION OF DESIGN AND FUNCTION

The T703 trailer is a steel structure with the load body tipped to the sides and to the rear.
The trailer has a pneumatic service brake (with variable load braking force control) and a
parking brake that is hand-operated via a screw gear, actuating the friction components of the
axle service brake. The trailer features a complete signalling and warning system (an electrical
system and reective lights). The trailer is also suitable for transport on public roads.

The trailer is manufactured in accordance with Directive 98/37/EC and the following
harmonised standards: PN-EN 1853:2002, PN-EN ISO 4254-1:2006, PN-EN ISO 12100-1:2005,
PN-EN ISO 12100-2:2005, PN-EN 294:1994.

4.1. Chassis

The trailer chassis is composed of the following subassemblies: bottom frame, tow bar,
support foot, wheel set and fastening components.

The bottom frame and the tow bar are welded structures made of steel sheet and proles.

The trailer wheel set is composed of: a single axle, land wheels and land wheel brakes.

The axle is made of a square bar terminated with plugs on which land wheel hubs are set by
cone bearings. They are single wheels equipped with drum brakes with the jaws actuated by
mechanical expander cams.

Operating instructions. T703 farming trailer 15

4.2. Load body

The loading space of the trailer is made of the following:

The top frame (box frame) that is set on the bottom frame (chassis frame) in articulated seats
secured by pins which serve as pivots during tilting (tipping) of the top frame (load body/box).

The side walls/boards and their top sections are singular components. Each component
features a separate set of locks for closing and opening of individual wall and top sections
independent of each other and in any order. These design solutions increase functionality and
facilitate operation of the trailer.

The wall and top section locks are secured against accidental release.

4.3. Load body hydraulic tipping mechanism

The hydraulic mechanism is designed for automatic unloading of the trailer by tipping the
load body backwards or sideways. The hydraulic tipping system is fed with oil from the tractor
hydraulic system.

The hydraulic system includes: the coupling valve plug, hydraulic lines, the single-action
hydraulic actuator, the cut-off valve, and connecting and fastening components. Figure 1 shows
the diagram of the load body hydraulic tipping system. The lifting and lowering of the load
body is controlled by the DCV in the tractor's hydraulic system.

INFORMATION! * The cut-off valve limits the load body tilt angle during tipping to

the sides. The valve is pre-adjusted by the trailer manufacturer. Do
not adjust it on your own.

Fig. 1 Diagram of the load body hydraulic tipping system

1 - hydraulic actuator; 2 - hydraulic lines; 3 - cut-off valve;

4 - cut-off valve control cable; 5 - coupling valve plug.

4.4. Electrical system (signalling and warning)

The trailer electrical system is designed for 12 V DC supply from the driving tractor system.

Operating instructions. T703 farming trailer 16

Connect the trailer electrical system with the tractor system by an appropriate coupling
cable. The diagram of the electrical system and the trailer lights layout is shown in g. 2 and 3.

Fig. 2 Trailer electrical system diagram

1 - 7-pin plug; 2 - 7-pin socket; 3 - right tail cluster lamp; 4 - left tail cluster lamp; 5 - turn indicator light bulbs;

6 - tail parking light bulbs; 7 - STOP light bulbs; 8 - registration plate light bulbs; 9 - front parking light bulb.

Fig. 3 Diagram of trailer lights layout

1 - cable harness with plug; 2 - right wire harness; 3 - front wire harness; 4 - rear wire harness;

5 - front parking lamp; 6 - front reector (white); 7 - tail reector (red); 8 - right tail cluster lamp;

9 - left tail cluster lamp; 10 - registration plate lamps; 11 - side reector (yellow).

4.5. Support foot

The T703 trailer is equipped with a mechanically operated support foot. It is designed to
support the tow bar when the trailer is decoupled from the tractor. The foot is installed at the
tow bar beam fork.

INFORMATION! Do not rest the trailer on the support feet when it is loaded.

4.6. Braking system

The T703 trailer is equipped with the following braking systems:

• Service brake: pneumatically actuated two-line system, operates the axle wheels; controlled

from the driver's seat by pressing the tractor's brake lever;

• Parking brake: hand mechanical control via a crank lever mechanism and a screw gear,

located on the right side of the trailer and operating the axle wheels.

• The service brake design ensures automatic braking of all trailer land wheels if the pneumatic

system is accidentally decoupled between the trailer and the tractor. On customer's request,

the trailer can be alternately equipped with a single-line braking system (i.e. for adaptation

to tractors which support such system conguration).

Operating instructions. T703 farming trailer 17

Figure 4 shows the pneumatic braking system diagram:

a) single-line system; b) two-line system.

Fig. 4 Pneumatic braking system diagram

1 - pneumatic connector plug for coupling with the tractor; 2 - air lter; 3 - control valve; 4 - air tank;

5 - water drain valve; 6 – manual braking force control; 7 - check connector; 8 - pneumatic membrane actuator.

5. STORAGE, SALE AND SHIPPING TO USER

STORAGE

• Protect the trailer against direct exposure to sunlight and rain. Park it with its land wheels

and with the supports extended and locked (if the tyres can be exposed to sunlight, reduce

their pressure).

• If the trailer is stored outdoors, periodically check for rainwater accumulation in the trailer.

Note all damage to the paint coat. Clean and degrease spots of damaged paint. Next, repaint

with the same colour and coat thickness.

• Long-term storage is allowed in sheltered rooms only.

SALE

• The buyer picks the trailer from the manufacturer or the sales representative on their own,

or arranges for the shipping with the manufacturer.

• The trailer is sold as fully assembled and ready for operation, complete with the basic

equipment listed in section 1.2 of this manual. All optional accessories or their parts are

available at extra charge.

• The sales representative personnel is required to introduce the buyer to the design and

operation of the trailer, along with safety requirements and warranty conditions.

• The buyer shall verify the following:

- the trailer is complete, undamaged and with all basic equipment;

- the nameplate located on the load body front frame crosspiece and the surface under it has
the serial number stamped that matches the data in the warranty card;

- the warranty card has been properly lled out with the identication data on the nameplate.

SHIPPING TO USER

The trailer shall be transported from the sales representative on wheels as coupled with a
tractor or a low-bed trailer. Before loading on a low-bed trailer, connect the farming trailer to
the transport hitch and the braking lines of the tractor. Drive the farming trailer to the low-bed
trailer with the extended ramps. Next, secure the farm trailer with wheel chocks. Afterwards,
disconnect the braking system and decouple from the tractor. Secure the farming trailer with
special transport straps. Before unloading the transported trailer, rst extend the low-bed trailer
ramps and release the transport straps used to secure the farming trailer from falling down in

Operating instructions. T703 farming trailer 18

transit. Approach with a tractor and connect the trailer braking system. Next, remove the wheel
chocks from the trailer. When all of the above has been completed, drive the trailer from the
low-bed.

6. OPER ATION INFORM ATION

6.1. Commissioning the trailer

IMPORTANT! • Use only tractors that are t for service (with the transport hitch,

pneumatic and hydraulic systems, and the signalling/warning
system working)

Do the following before commissioning the trailer:

- Understand the names and locations of individual assemblies/components of the trailer;

- Check the tyre pressure;

- Couple the trailer with the tractor:

• set the tow bar hitch-ring of the trailer on the trailer transport hitch height;

• couple the hitch-ring with the trailer hitch;

• secure the hitch pin against falling out;

• turn off the tractor's engine;

• engage the tractor's parking brake;

• release the trailer's parking brake;

• connect the appropriate sockets and plugs of the following systems: pneumatic, hydraulic
and electrical;

- Do the functional checks of the electrical, pneumatic and hydraulic systems of the tractor
and of the trailer, and check leak tightness of the hydraulic and pneumatic systems on both
vehicles;

- Check all equipment, their connections and safety from accidental release or breaking.
Do all these actions each time you start the trailer.

INFORMATION! Couple the trailer with the tractor's transport hitch only that is rated

for 11.5 KN of minimum load. No bystanders shall remain between
the trailer and the tractor when the two are being coupled.

INFORMATION! Two persons and extreme caution are required to install and remove

the top sections.

6.2. Loading the body

Load the body only when the trailer is coupled with the tractor, parked on level ground and

with the tow bar in the forward driving direction.

Use mechanical loading equipment (cranes, loaders, conveyors, etc.) to load the trailer.
Make sure that all wall and top section locks are engaged before loading the trailer.
Spread the load evenly across the entire load body surface. When transporting materials

that exert focused (topical) pressure on the load body (e.g. large rocks), line the oor with thick
planks rst. This will reduce the surface load of the oor and protect it from damage.

When transporting large volume materials, install the top sections of the load body walls. If

the transported materials protrude from the trailer, follow the applicable trafc code regulations
for proper marking of protruding loads.

Operating instructions. T703 farming trailer 19

INFORMATION! • Do not exceed the permissible payload and permissible axle loads,

otherwise the trailer can be damaged and the trafc safety can

be compromised.

• The transported load must be secured from shifting, generating

excessive noise and falling down on the road.

Approximate weight values of certain goods

1 m3 = kg

Soil 1600–1800
Wheat 710 –820
Rape 700 –750
Potatoes 625–725
Sugar beets 650 –700
Legumes 760 –820
Construction rubble/aggregate 1400 –1850
Lime 900–1500
Hard coal 1200–1600

6.3. Travelling on public roads

Before entering a public road, do the actions listed in section 6.1 and the following:

- install the slow-moving vehicle sign on the trailer (in the bracket on the rear wall);

- ensure that the transported load is secured from shifting and falling down on the road;

- check that the load does not exceed the permissible capacity or multiple axle load.

INFORMATION!

• Follow the trafc code regulations.

• In the rst operating hours of the brakes, the drum brake shoes

align themselves to the drums. The full braking effectiveness is
achieved once the friction parts have run in.

6.4. Unloading

The load body can be unloaded manually, with mechanical equipment or by tipping the box

with the hydraulic mechanism.

Unload by tipping the load body by following these actions in the order presented below:

• align the tractor in the trailer's axis;

• engage the tractor's parking brake;

• remove the safety pin that couples the load body with the chassis frame:
a) unloading to the back – move the pin to the rear;
b) unloading to the left – remove the right safety pin and install it on the left side;
c) unloading to the right – remove the left safety pin and install it on the right side;

• make sure that the pins on the side to which the trailer is to be unloaded have been properly
installed;

• open the body wall locks on the unloaded side;

• tip the load body by operating the hydraulic actuator;

• after the load has been discharged, lower the body and lock the wall(s) with the locks.

Operating instructions. T703 farming trailer 20

INFORMATION! • If it is necessary to unload the trailer on a slope, it is allowed

to tip the trailer body upwards (with the tractor and the trailer
parked in the uphill direction).

• Nobody is allowed to remain near the tipped trailer body and

within the range of discharged load.

• Do not decouple the trailer from the tractor when the load body

is lifted.

• Before unloading by tipping the trailer load body, you must

always verify that the pins have been removed on the correct side
of the trailer. Failure to remove the pins may destroy the trailer!

• Do not transport any persons on the trailer.

Open the top lock of the load body by moving the handle up, and depressing the button

under the handle at the same time. Open the bottom locks of wall segments by operating the
central lock handle:

4

5 3 2 1 4 3 2 1

Fig. 5. Load body wall locks

1 - lever safety stop pin; 2 - central bottom lock handle; 3– lock adjustment mechanism;

4 - central lock shaft; 5 - lock.

Having discharged the load from the trailer, do the following:

- lower the load body and remove all remains of the transported material;

- install and secure the pins that connect the load body with the chassis frame;

- lock and secure the wall(s) from accidental opening.

6.5. Decoupling from the tractor

Do the following actions to decouple the trailer from the tractor:

• stop the tractor with the trailer where the latter will be left, and engage the tractor parking
brake;

• engage the trailer parking brake;

• if the trailer stands on uneven or sloping ground, protect it against rolling down by chocking
the wheels;

• disconnect the electrical, hydraulic and pneumatic lines from the tractor;

• remove the safety from the hitch pin and then remove the pin – this will decouple the tow bar
from the hitch. Drive away with the tractor and reinstall the pin in the hitch.

Operating instructions. T703 farming trailer 21

INFORMATION!

Do not decouple the trailer from the tractor when:

• the load body is lifted;

• the trailer is not protected against rolling away.

7. SERV ICING

7.1. Servicing instruction for adjustable trailer components

In order to maintain proper performance, the T703 trailer requires the following adjustments:
a) Adjustment of the wheel bearing clearance;
b) Adjustment of the braking system components.
c) Adjustment of the load body hydraulic tipping mechanism.

INFORMATION! • Do not perform any checks or servicing under the loaded or tilted

load body without support.

Wheels – bearing slackness adjustment

During the rst operating hours of a newly purchased trailer (i.e. after approximately 100

km of mileage) and further operation (i.e. after the next 1500 or 2000 km), check the wheel
bearing clearance and adjust if necessary.

To do so, it is required to:

• Couple the trailer to the tractor and engage the tractor parking brake.

• Jack up one side of the trailer to lift the wheel from the ground on this side and secure it
against falling.

• If the wheel has excessive clearance, remove the hub cap and remove the crown nut clevis
pin.

• Rotate the wheel and tighten the crown nut at the same time until the wheel stops turning.

• Loosen the crown nut by 1/6 to 1/3 of the full turn, i.e. until the nearest clevis pin groove is
aligned with the hub pivot hole.

• Secure the nut with a new clevis pin, and reinstall and retighten the hub cap.
After a correct adjustment of bearing clearance, the wheel should rotate smoothly, without

cogging or evident resistance (not caused by rubbing of the brake shoes against the drum).
Slight friction of brake shoes against the drum, especially on a brand new trailer or following
replacement of the shoes is normal. Do the nal check of proper bearing adjustment by travelling
several kilometres and inspecting the hub heating by hand. Apart from incorrect slackness
adjustment, signicant rolling resistance of the wheels and excessive heating of the hubs can
also be caused by contaminants in the grease or damage of bearings. If found, these symptoms
require removing the wheel hub to be corrected.

INFORMATION!

Operating instructions. T703 farming trailer 22

• Follow these rules when jacking up the trailer wheel:

• couple the trailer with the tractor, move to level ground and

engage the tractor parking brake;

• chock the wheel that is not being jacked up;

• place the jack under the axis and near the jacked up wheel,

and lift the wheel so that it clears the ground;

• secure the wheel against falling by putting a prop of suitable

height under the axis.

7.2. Brakes

7.2.1. Brakes – servicing the brake pneumatic system

When servicing the trailer, check the tightness and the condition of parts and connections of

the braking system, and periodically drain the water condensate from the air tank.

Check the leak tight ness of the system at the rated pressure of approx. 600 kPa for the single -

line system and 800 kPa for the two-line system. Leaks are detected by a distinct hiss or air
bubbles (after coating with soap water) at the points of air escape from the system. If the leaks
are caused by damaged seals, lines or other parts (valves, actuators, etc.), replace them with new
parts.

Drain the water from the air tank by tilting the drain valve stem to the side when the tank is

pressurised; the drain valve must also be unscrewed from the tank and cleaned of accumulated
dirt once a year, before the winter season.

7.2.2. Brakes – adjustment of the braking system components

When servicing the trailer, check the condition of parts and connections of the braking

system, and periodically inspect the lubrication of control elements.

Adjust the brakes when the following occurs:

• there is excessive clearance between the shoes and the drum from the brake shoe wear,
resulting in decreased braking performance;

• the wheel brakes work unevenly and out of sync.
With the properly adjusted brakes, the braking force (i.e. the total of braking forces at the

circumference of the wheels) shall be at least 27% of the permissible total weight of the trailer
when decelerating with the service brake; the braking force (i.e. the total of braking forces at
the circumference of the wheels) when actuating the parking brake shall be at least 16% of the
permissible total weight of the trailer. Both wheels of the same axle should be braked evenly; the
brake force differential between the left and right trailer side shall not exceed 30%, with 100%
being the higher force.

Fig. 6. Braking system components

1 - expander shaft lever (arm); 2 - adjusting comb;

3 - lever (arm) adjustment bolt with comb on the expander shaft; 4 - shoe expander shaft;

5 - the link (follower) that couples the pneumatic actuator rod with the expander shaft lever;

6 - pneumatic actuator; 7 - parking brake cable.

Operating instructions. T703 farming trailer 23

Adjust the brakes by changing the expander lever position against the expander shaft. To do

this, jack up the wheel and while turning the wheel, realign the expander lever against the shaft
(on the comb) to feel that the brake shoes slightly rub against the drum.

After a correct adjustment of friction components, the wheel should rotate smoothly, without

cogging or evident resistance (not caused by rubbing of the brake shoes against the drum). Slight
rub of the shoes against the drum, especially on a brand new trailer or following replacement
of the shoes is normal.

Braking force adjustment: the pressure is built in the pneumatic brake system by a three-unit

controller with three control lever positions: empty, half-full and full.

After completing the adjustment, check and adjust the parking brake. The parking brake

is adjusted by setting the cable length that couples the expander shaft lever to the engaging
mechanism. The required sum of braking forces should be produced at the maximum force
applied to the hand crank of 40 daN (at an approximately right angle between the cable and the
expander shaft lever.

INFORMATION!

• Follow these rules when jacking up the trailer wheel:

• couple the trailer with the tractor, move to level ground and

engage the tractor parking brake;

• chock the wheel that is not being jacked up;

• place the jack under the axis and near the jacked up wheel,

and lift the wheel so that it clears the ground;

• secure the wheel against falling by putting a prop of suitable

height under the axis.

• Before driving, periodically inspect all braking components for

proper operation, tightness and clearance. Adjust or repair as
ne cessar y.

IMPORTANT!

• Inspect the brake shoes at least each year. Replace worn shoes.

• In order to achieve the required braking performance after

replacement of friction components, remember to run them in
(by driving with frequent braking), which should be followed by
readjustment.

7.3. Hydraulic system

7.3.1. Hydraulic system – servicing of the load body hydraulic tipping system

The hydraulic oil of the trailer and the external hydraulic system oil (tractor) must always be

of the same grade and type. DO NOT use different oil grades.

The trailer hydraulic system must be absolutely leak-tight. Check the leak tightness of the

hydraulic system by tipping the load body backwards and overloading the hydraulic system for
a few seconds. If there are oil leaks at the hydraulic connections, retighten them. If the problem
persists, replace the hose or the connection ttings. If the hydraulic leak does not occur on any
connector, replace the leaking hydraulic system component. Any and all mechanical damage to
a component requires its replacement with the new one. The condition of the hydraulic system
must be monitored continuously throughout the operating life of the trailer. When coupling the
hydraulic systems of the tractor and of the trailer, keep the couplings as clean as required.

7.3.2. Hydraulic system – adjustment of the load body hydraulic tipping mechanism

The hydraulic system features a safety cable (which is a tipping angle limiter of the load

body) and the cut-off valve that isolates the oil ow to the hydraulic actuator when the body is

Operating instructions. T703 farming trailer 24

tipped. No unauthorised person is allowed to make adjustments or remove the limiters due to
safety concerns. The cut-off valve is intended to isolate the oil feed from the actuator before the
maximum (permissible) tipping angle of the body is reached. Changing the length or breaking
of the safety cable between the load body frame and the cut-off valve installed on the chassis
frame may result in damage of the trailer or a risk of turning over the trailer.

INFORMATION! • Do not remove or disconnect the safety cable / load body tipping

lim iter.

• Unauthorised persons must not adjust the cut-off valve.

7.4. Wheels – tyres

Servicing of the tyres involves checking their condition by visual inspection and checking

the tyre pressure. It is also essential to check that the tyres have no cracks that expose or damage
the carcass, and that the hubs, wheel disks and their fastening in good condition.

INFORMATION! Regularly inspect the wheel nuts (i.e. the condition and tightness

before each use of the trailer); retighten if necessary.

IMPORTANT! • After the rst travels with loads and after each 100 km, inspect

the following:

• the tightness of wheel nuts; retighten if necessary

• tyre pressure. The tyre pressure rating displayed near the

trailer wheels

• applies to transport at the maximum permissible speed (at

the maximum payload).

8. TROUBLESHOOTING

Table 3 lists the examples of common faults, their causes (symptoms) and solutions.

Item

Fault type Possible cause Remedy

no.

1 2 3 4

1. Excessive heating of brake

drums

2. Excessive heating of wheel
hubs

3. The grease ows out on the
brake shoes

4. Uneven braking of wheels Contamination or excessive

5. Insufcient wheel braking
performance.

Brake shoes are out of
adjustment
Insufcient clearing of bearings.
Contamination in bearing
grease.

Damaged, worn out or
improperly installed hub seal

wear of shoe pads, or the brake
shoes are out of adjustment.
Incorrect adjustment of the
shoes and brake controls.

Adjust per section 6.2.2.

Adjust per section 6.1.1.
Remove the hub, replace the grease
and adjust the bearings as indicated
above.
Remove the hub, replace the worn/
damaged seal and reinstall properly.
Remove the grease from the shoes
and the brakes, clean the friction
components with extraction naphtha,
reinstall the hub and adjust the
bearings as indicated above.
Check the brake shoe pads, remove
contaminants, replace worn out pads
and readjust as in section 6.2.2.
Adjust the brake shoes and control
components per section 6.2.2.

Tab le 3

Operating instructions. T703 farming trailer 25

6. Oil leak at the hydraulic
connections.

7. Oil leak from the cut-off
valve or the actuator.

8. The load body locking pin
does not engage the seat.

9. The load body support seat is
misaligned with the chassis
frame plug.

The connectors are made too
loose or damage of connector
seals.
Worn out or damaged seals, or
mechanical damage of devices.
The pin is bent or there is
fouling between the pin and the
casing.

The chassis frame or the load
body frame is bent, or there
is mechanical damage of the
mating components.

Retighten and/or replace the line parts
as necessary.

Replace the seals of the entire devices
(units).
Straighten the pin, clean it and the
casing, apply a thin coat of grease on
the pin, install it in the seat and secure
the pin.
Dismount the load body frame
from the chassis frame. Inspect and
measure the support mating points.
Repair the damaged elements.
Reassemble and secure.

9. PERIODIC MAINTENANCE

9.1. Lubrication

Lubrication is one of the most critical factors for the good performance of individual

assemblies and mechanisms of the trailer.

Timely lubrication and use of correct lubricants signicantly reduces the risk of damage or

premature wearing of individual parts.

Daily lubrication applies only to the days during which the trailer is operated.

• Follow these rules when lubricating:

• clean the grease nipple before feeding the grease;

• feed the lubricant until fresh lubricant comes out of the gaps (through which the used
lubricant is pushed out rst);

• when nishing the lubrication, leave some lubricant on the nipple head;

• use oil to lubricate threaded joints, lever joints and similar parts of the trailer;

• inspect the lubrication of wheel hub bearings each year; add or replace the bearing lubricant;

• when replacing the lubricant, remove the hub, remove the used lubricant, inspect the bearings'
condition (replace with new ones if necessary); after applying the fresh lubricant, adjust the
bearing play.

IMPORTANT!

• Use only quality bearing lubricants.

• Never drive without the hub cap; otherwise penetration by dirt

(sand) will damage the wheel bearings.

Lubrication point Lubricant grade Lubrication frequency

Wheel hub bearings ŁT 43 Every 6 months

Hydraulic actuator head socket Graphite grease Once a year

Load body tipping system parts ŁT 43 Every 6 months

Support foot components ŁT 43 Every 6 months

Eye catch ŁT 43 Every 6 months

Other lubrication points

• Regularly lubricate movable parts of locks, hinges and articulated joints;

• Pressure-feed the lubricant with a lubricating gun through clean nipples;

• Regularly lubricate movable parts of brakes (levers and pins);

• Lubricate the brake shoe axes only when necessary and only with a small amount of lubricant

Operating instructions. T703 farming trailer 26

9.2. Maintenance and servicing

The transport capacity and long operating life of the farming trailer can only be assured if

the machine is properly and reasonably operated within its design and functional capacities.

Even a slight negligence in operation may result in severe consequences. A timely discovered

fault is easy to remove at a minimum cost and effort, while producing the maximum effect.

Faults of the trailer can only be discovered soon if regular, periodic cleaning and thorough

inspection is carried out.

Hence clean the trailer frequently to observe any damage and faults.
Also carry out periodic technical inspection of the trailer. Lubricate the trailer according the

guidelines for lubrication.

Store the trailer in a sheltered area to protect it from weather conditions and deterioration.
In order to preserve its proper performance, the trailer must be maintained, readily repaired

and thoroughly supervised during its operating life.

Daily servicing (before work) of the trailer includes a certain minimum of actions, i.e.:

• check the screwed components and their safeguards from accidental release;

• check the play of mechanisms and articulated joints;

• check the tightness of the hydraulic system and remove all leaks;

• check the tightness of the pneumatic system;

• functional checks of mechanisms;

• check and perform lubrication according to the instructions;

• check the tyre pressure;

• check the wall locks for proper engagement and security;

• wall top sections in use: do functional tests and check that the parts do not pose risk to trafc
safety and operator's safety;

• functional check of the brake system and the warning and signalling system.

Repair instructions

Small repairs required by accidental faults must be carried out with care for cleanliness,

installation of all parts at their locations and adjustments essential to proper performance of the
trailer.

Small repairs during operation (in the eld) shall be done on site by service personnel.
All parts removed during repairs shall be stored in conditions that protect from dust and

other contaminants. Pay particular attention to protection and cleanliness of bearings.

During eld repairs, keep the area clean when reassembling the parts (the parts which

fell to the ground shall be washed or at least cleaned of dirt to an extent that permits proper
functioning).

During running and general repairs, follow the engineering rules for disassembly and (re)

assembly of parts and subassemblies to ensure proper quality and performance of work.

Do functional tests of trailer mechanisms after each repair.

10. DISPOSAL OF THE TRAILER

If the user decides to dispose of the trailer, hand over the entire vehicle to the nearest scrap

collection point approved by local authorities. The proof of disposal issued by the collection
point is essential for de-registration of the trailer. Recycle the parts which remain from repairs
or have become obsolete.

Operating instructions. T703 farming trailer 27

11. RESIDUAL RISKS

11.1. Description of residual risks

METAL-FACH Sokółka is liable for the design and construction in order to eliminate all

hazards; yet some partial risk is unavoidable in operation of the trailer.

The residual risk stems mostly from improper behaviour of the operator caused by lack of

knowledge or attention. The greatest hazards occur during the following forbidden actions:

1. The trailer is operated by minors or persons who are unfamiliar with the operating
instructions.

2. The trailer is operated by persons who are ill or under the inuence of alcohol or other
intoxicants.

3. The trailer is used for purposes other than specied in the operating instructions.

4. A person is present between the tractor and the trailer with the tractor's engine running.

5. Bystanders, especially children are present near the working trailer.

6. The trailer is cleaned while working.

7. Manipulation of the moving elements while the trailer is working.

8. Checking the trailer's technical condition when it is running.
While presenting the residual risk the trailer is treated as designed according to the state of

knowledge in the year of its manufacture and maintaining the basic OH&S rules.

11.2. Assessment of residual risks

Follow these guidelines:

1. Always follow the safety regulations described in the operating instructions.

2. Read and fully understand the operating instructions.

3. Keep your hands out of hazardous spaces.

4. It is forbidden to operate the trailer in the presence of bystanders and in particular children.

5. Maintenance and repairs of the trailer shall only be performed by trained personnel.

6. The trailer shall only be operated by persons who have been trained in its operation and have
familiarised themselves with the operating instructions.

7. The trailer is protected against access by children.

Only then can you eliminate the residual risks to people and the environment when using

this trailer.

ATTENTION!

The residual risks are present when the listed rules and indications are not followed.

Operating instructions. T703 farming trailer 28

16–100 SOKÓŁKA, POLAND UL. KRESOWA 62

WARRANTY CARD

OF THE FARMING TIPPER TRAILER

T–703

The warranty service is provided on behalf of the manufacturer by:

.......................................................................................................................................................

lled out by the seller

Date of manufacture ..................................... Date of sale ...................................................

Serial number ............................................... Signature of the Seller ..................................

Customer's name and surname .........................................................................

Address .............................................................................................................

Operating instructions. T703 farming trailer 29

Item

Service call

date

Date of

completion

Description of completed

service actions and replaced

parts

Service

technician

name

Service

stamp

Operating instructions. T703 farming trailer 30
