Metabo ASE 18, Ps E 0525 User Manual

ALL-PURPOSE SAW / SABRE SAW

EQUIPMENT FEATURES EQUIPMENT FEATURES



For sawing wood, plastics, gypsum boards, metals...



Lock-on button for remaining switched

on continuously



Aluminum die cast saw blade guide with

plastic trays



Axially adjustable guide for limiting cutting length



Vario Constamatic (VC) full-wave electronics



Thumbwheel for preselection of number of strokes



4-level pendulum blade movement



Auto-stop carbon brushes



Multi-purpose machine by the comprehensive

range of saw blades



To saw wood, plastics, metal pipes and profiles



Ergonomically designed for bent handle for optimum power

transmission



Sheathed die cast aluminium gear housing



Large, easy to use trigger button



Saw blade rotatable by 180°



Metabo "Quick" saw blade change



Axially adjustable guide for limiting cutting length



Multi-purpose machine that will accept a comprehensive range

of saw blades



Li-Ion battery packs for up to 40% more power with up to 40%

less weight. No memory effect!



With "AIR COOLED" quick charger AC 30 Plus for charging NiCd,

NiMH and Li-Ion battery packs; charge time approx. 30 minutes (at 1.4 Ah)

... 40% more output with 40% less weight

SAWS

MACHINES

SPECIAL-PURPOSE

SYSTEMATIC

ORGANISATIONGARDEN

Ps E 0525 ASE 18

500 Watt

Electronic Orbital

All-Purpose Saw

Ps E 0525

Comparative device characteristics

Torque 7 Nm Strokes at no load 500 - 2.500 /min Rated input power 500 W Output power 310 W Saw blade stroke 25 mm Weight (without mains cable) 2,8 kg

Standard equipment Flexible HCS saw

blade, hexagon

spanner

18 Volt

Cordless Sabre Saw

ASE 18

Comparative device characteristics

Type of battery pack Li-Ion Battery pack voltage 18 V

Capacity of battery pack 2,2 Ah Strokes at no load 0 - 2.600 /min Saw blade stroke 27 mm Weight (including battery pack) 3,8 kg

Standard equipment 3 saw blades, hexagon spanner,

2 Li-Ion battery packs (18 V/2.2 Ah),

"AIR COOLED" quick charger

AC 30 Plus, carry case

TECHNOLOGY

WOOD-PROCESSING

TECHNOLOGY

WATER-/PUMP

WELDING

TECHNOLOGY

Type Ps E 0525 Order no. 6.00525

at nominal,

maximal voltage 20 Volts

Type ASE 18 Order no. 6.02169.50

| 207| 207

COMPRESSED

AIR SYSTEMS

SABRE SAWS

EQUIPMENT FEATURES



To saw wood, plastics, metal pipes and profiles



Powerful, sturdy motor



Sheathed die cast aluminium gear housing



Selectable pendulum stroke



Variospeed (V) electronics



Electronic soft start



Saw blade rotatable by 180°



Metabo "Quick" saw blade change



Depth guide adjustable without tools



Multi-purpose machine that will accept

a comprehensive range of saw blades

The features of the Metabo sabre saw blades

Colour

The colour indicates for which material the blade is suited best.

Yellow for wood Yellow with blue lettering for wood with nails Blue for metal Black for special

applications

PSE 1200

1200 Watt Electronic

Orbital Sabre Saw

PSE 1200

Comparative device characteristics

Torque 15 Nm Strokes at no load 0 - 2.600 /min Rated input power 1.200 W Output power 650 W Saw blade stroke 28 mm Weight (without mains cable) 4 kg

Standard equipment 3 saw blades, carry case

Basic blade material

HCS carbon steel, for cutting soft wood,

hardboards, plastics

HSS High yielding high-speed steel,

suitable for metal, aluminium work

BiM Bimetal especially flexible mix

of HCS and HSS. Suitable for quick cuts in pipes, profiles, sheet metals, wood with nails, metalls

HM Hard metal for stainless steel,

glass reinforced plastic, abrasive materials and pourous concrete

Quality class

>classic< series good results and very

good service life

>flexible< series break-proof,

flexible

>professional< series stable, precise

working, for tough applications

>pionier< series quick through all materials

>expert< series for special applications

Type PSE 1200 Order no. 6.01301

208 | 208 |

Type

see jig-saw blades on page 198

Shaft form

The sabre- sawblades from Metabo are supplied with an universal shaft, suitable for the sabre saws from all other brands.



SABRE SAW BLADES

Sabre saw blades with 1/2" universal shank

Suitable for Metabo, AEG, Atlas Copco, Black & Decker, Bosch, DeWalt, Flex, Hitachi, Milwaukee, Porter Cable, Skil ...

Material suitability Version Material

finish

FOR METAL, "CLASSIC" SERIES

Overall length mm

ThicknessmmTooth

pitch

Corresponds to Bosch type

Packing unit

Order no.

SAWS

Metal sheets 1-3 mm, Profiles 5-100 mm

Metal sheets 2-8 mm, Profiles 10-100 mm

FOR METAL, "FLEXIBLE" SERIES

Metal sheets 0.7-3 mm, Pipes, Profiles 0.5-100 mm

Metal sheets 3-8 mm, Pipes, Profiles, Ø 10-100 mm

Metal sheets 1.5-4 mm, Profiles, Ø 5-175 mm, Profiles 10 - 175 mm, For flush cuts

Metal sheets 3-8 mm, Pipes, Profiles, Ø 10-175 mm, Flush cuts

Crimped, Milled BiM 150 0,9 1,06mm/

24 TPI

Crimped, Milled BiM 150 0,9 1,8mm/

14 TPI

Crossed, Milled BiM 150 0,9 1,4mm/

18 TPI

Crossed, Milled BiM 150 0,9 1,8mm/

14 TPI

Crossed, Milled BiM 225 0,9 1,4mm/

18 TPI

Crossed, Milled BiM 225 0,9 1,8mm/

14 TPI

S 918 AF 2 6.31129

S 918 BF 2 6.31130

S 922 EF 2 6.31080

5 6.31454 100 6.25490

S 922 BF 2 6.31093

5 6.31491 100 6.25491

S 1122 EF 2 6.31095

5 6.31493

S 1122 BF 2 6.31096

5 6.31494 100 6.25492

MACHINES

SPECIAL-PURPOSE

SYSTEMATIC

ORGANISATIONGARDEN

Metal sheets 1.5-6 mm, Especially for curved cuts

Crossed, Milled BiM 100 0,9 1,8mm/

FOR METAL, "PROFESSIONAL" SERIES

NEW

Metal sheets 4-10 mm, Pipes and profiles, Ø 20-175 mm, For pipe cutting equipment, For demolition and reconstruction work, For straight and clean cuts

Metal sheets 2-8 mm, Pipes, Profiles, Ø 10-150 mm

Metal sheets 2-12 mm, Pipes, Profiles, Ø 10-150 mm

Metal sheets 4-10 mm, Pipes and profiles, Ø 20-100 mm, For pipe cutting equipment, For demolition and reconstruction work

Metal sheets 4-10 mm, Pipes and profiles, Ø 20-175 mm, For pipe cutting equipment, For demolition and reconstruction work

Crossed, Milled BiM 225 1,1 2,54-3,

Crossed, Milled BiM 200 1,25 1,8mm/

Crossed, Milled BiM 200 1,25 1,8-2,6mm/

Crossed, Milled BiM 150 1,6 2,9mm/

Crossed, Milled BiM 225 1,6 2,9mm/

FOR METAL, "PIONEER" SERIES

Metal sheets 1-8 mm, Profiles, Ø 5-100 mm

Crossed, Milled BiM 150 0,9 progressiv S 123 XF 2 6.31911

14 TPI

18 mm/ 8-10 TPI

14 TPI

10-14 TPI

8 - 10 TPI

S 422 BF 5 6.31990

S 1126 CHF 5 6.31989

S 1025 BF 5 6.31909

S 1025 VF 5 6.31991

S 920 CF 5 6.31992

S 1120 CHF 5 6.31993

5 6.31914

WOOD-PROCESSING

WATER-/PUMP

WELDING

COMPRESSED

TECHNOLOGY

AIR SYSTEMS

| 209| 209
